User Manual

This is the main product document for model IPS235P-BN.

The file format is pdf, 27 pages, you can download this manual here .

background
www.lg.com
OWNER’S MANUAL
LCD MONITOR
IPS225P
IPS235P
Please read this manual carefully before operating
your set and retain it for future reference.
LCD MONITOR MODEL
ENGLISH
background
2
ENG
ENGLISH
TABLE OF CONTENTS
CONTENTS
3 ASSEMBLINGANDPREPAR-
ING
3 Unpacking
4 Partsandbuttons
6 SettinguptheMonitorset
6 - AttachingtheStandBase
6 - DetachingtheStandBase
7 - Mountingonatable
9 - UsingthePivotfunction
10 - Mountingonawall
11 USINGTHEMONITORSET
11 ConnectingtoaPC
11 - D-SUBconnection
11 - DVI-Dconnection
11 - HDMIconnection
13 CUSTOMIZINGSETTINGS
13 AccessingTheMainMenus
14 CustomizingSettings
14 - MenuSettings
15 -PICTURE
16 -COLOR
17 -DISPLAY
17 -VOLUME
18 -OTHERS
19 MODESetting
20 DUALPACKAGESetting
21 TROUBLESHOOTING
23 SPECIFICATIONS
23 IPS225P
24 IPS235P
25 PresetModes(Resolution)
25 Indicator
background
3
ENG
ENGLISH
ASSEMBLING AND PREPARING
ASSEMBLINGANDPREPARING
Unpacking
Checkyourproductboxforthefollowingitems.Ifthereareanymissingaccessories,contactthelocal
dealerwhereyoupurchasedyourproduct.Theillustrationsinthismanualmaydifferfromtheactualproduct
andaccessories.
Donotuseanyunapprovedaccessoriestoensurethesafetyandproductlifespan.
Anydamagesorinjuriesbyusingunapprovedaccessoriesarenotcoveredbythewarranty.
Theaccessoriessuppliedwithyourproductmayvarydependingonthemodel.
Productspecificationsorcontentsinthismanualmaybechangedwithoutpriornoticeduetoupgrade
ofproductfunctions.
Usermustuseshieldedsignalinterfacecables(D-sub15pincable,DVI-Dcable)withferritecores
(coreintheconnector)tomaintainstandardcompliancefortheproduct.
CAUTION
NOTE
StandBase
PowerCord
CD(Owner'sManual)/
Card
D-SUBCable
(Thissignalcablemaybeattached
tothisproductbeforeshippingout.)
DVI-DCable
(Thiscableisnotincludedinall
countries.)
DisplayQualityAssuranceReport
background
4
ENG
ENGLISH
ASSEMBLING AND PREPARING
Partsandbuttons
PowerIndicator
LightingOn:Turnedon
LightingOff:Turnedoff
Connectionpanel(Seep.11)
Button(Seep.13)
(PowerButton)
background
5
ENG
ENGLISH
ASSEMBLING AND PREPARING
Button Description
MENU Accessesthemainmenus.(Seep.13)
OSDLOCKED/
UNLOCKED
Thisfunctionallowsyoutolockthecurrentcontrolsettings,so
thattheycannotbeinadvertentlychanged.
PressandholdtheMENUbuttonforseveralseconds.
Themessage"OSDLOCKED"shouldappear.
YoucanunlocktheOSDcontrolsatanytimebypushing
theMENUbuttonforseveralseconds.Themessage"OSD
UNLOCKED"shouldappear.
MODE UsethisbuttontoenterUSER,MOVIE,TEXT,PHOTO,sRGBmenus.(Seep.19)
DUAL UsethisbuttontoenterDUALMONITORandDUALWEBmenus.(Seep.20)
AUTO Whenadjustingyourdisplaysettings,alwayspresstheAUTObuttonontheMONITOR
SETUPOSD.(OnlysupportedinAnalogMode)
Thebestdisplaymode 1920x1080
INPUT Youcanchoosetheinputsignal.
• Whentwoinputsignalsareconnected,youcanselecttheinputsignal(D-SUB/DVI/
HDMI)youwant.
• Whenonlyonesignalisconnected,itisautomaticallydetected.Thedefaultsettingis
D-SUB.
EXIT ExittheOSD(OnScreenDisplay).
(PowerButton)
Turnsthepoweronoroff.
PowerIndicator Thepowerindicatorstaysblueifthedisplayisrunning
properly(OnMode).IfthedisplayisinSleepMode,thepower
indicatorblinksblue.
background
6
ENG
ENGLISH
ASSEMBLING AND PREPARING
SettinguptheMonitorset
AttachingtheStandBase
1
PlacetheMonitorsetwiththescreenside
downonaflatandcushionedsurface.
Layafoammatorsoftprotectivecloth
onthesurfacetoprotectthescreenfrom
damage.
Thisillustrationdepictsthegeneralmodelof
connection.Yourmonitormaydifferfromthe
itemsshowninthepicture.
Donotcarrytheproductupsidedownholding
onlythestandbase.Theproductmayfall
andgetdamagedorinjureyourfoot.
CAUTION
CAUTION
DetachingtheStandBase
1
PlacetheMonitorsetwiththescreenside
downonaflatandcushionedsurface.
2
Turnthescrewtotheleft,andthenpulloutthe
StandBasefromtheStandBody.
2
AttachtheStandBaseandthentightenthe
screwtotherightwithaCoin.
1
S
tandBase
S
tandBase
background
7
ENG
ENGLISH
ASSEMBLING AND PREPARING
Mountingonatable
1
LiftandtilttheMonitorsetintoitsupright
positiononatable.
Leavea10cm(minimum)spacefromthewall
forproperventilation.
2
ConnectthePowerCordtoawalloutlet.
3
Press (Power)buttononthebottomswitch
paneltoturnthepoweron.
10 cm
10 cm
10 cm
10 cm
Unplugthepowercordbeforemovingthe
Monitortoanotherlocation.Otherwiseelectric
shockmayoccur.
Tiltfrom+15to-5degreesupordowntoadjust
theangleoftheMonitorsettosuityourview.
CAUTION
NOTE
Front
Rear
5 - 51
•
SwivelRange:-45°~45°(+/-2°)
-45°~45°(+/-2°)
•
HeightRange:maximum5.12inch(130.0mm)
*Pleasebesureto
removetheLockingpin
toadjusttheheight.
130.0mm
background
8
ENG
ENGLISH
ASSEMBLING AND PREPARING
UsingtheKensingtonsecuritysystem
TheKensingtonsecuritysystemconnectoris
locatedatthebackoftheMonitorset.Formore
informationofinstallationandusing,refertothe
manualsuppliedwiththeKensingtonsecurity
systemorvisit
http://www.kensington.com
.
ConnecttheKensingtonsecuritysystemcable
betweentheMonitorsetandatable.
TheKensingtonsecuritysystemisoptional.
Youcanobtainitfrommostelectronicsstores.
NOTE
WARNING
•Whenadjustingtheangleof
thescreen,donotputyour
finger(s)inbetweenthehead
ofthemonitorandthestand
body.Youcanhurtyour
finger(s).
•Whenadjustingtheheight
ofthescreen,donotput
yourfinger(s)inbetweenthe
headofthemonitorandthe
standbase.Youcanhurtyour
finger(s).
ERGONOMIC
•Itisrecommendedthatinordertomaintainan
ergonomicandcomfortableviewingposition,
theforwardtiltangleofthemonitorshouldnot
exceed5degrees.
WARNING
•YoudonotneedtoreplacetheLockingpinafter
itisremoved,toadjustitsheight.
background
9
ENG
ENGLISH
ASSEMBLING AND PREPARING
UsingthePivotfunction
-Thepivotfunctionallowsyoutorotatethescreen90degreesclockwise.
1.
LiftthemonitortoitshighestheighttoutilizethePivotfunction.
2.
Landscape&Portrait:
Youcanrotatethepanel90°clockwise.
PleasebecautiousandavoidcontactbetweenthemonitorheadandtheStandBasewhenrotating
thescreentoaccessthePivotfunction.IfthemonitorheadtouchestheStandBase,thentheStand
Basecouldcrack.
．．．．．．．
．．．．．
Headsection
Standsection
3.
Becarefulwiththecableswhenrotatingthescreen.
background
10
ENG
ENGLISH
ASSEMBLING AND PREPARING
Disconnectthepowercordfirst,andthen
moveorinstalltheMonitorset.Otherwise
electricshockmayoccur.
IfyouinstalltheMonitorsetonaceilingor
slantedwall,itmayfallandresultinsevere
injury.
UseonlyanauthorizedLGwallmount
andcontactthelocaldealerorqualified
personnel.
Donotovertightenthescrewsasthismay
causedamagetotheMonitorsetandvoid
yourwarranty.
Useonlyscrewsandwallmountsthat
meettheVESAstandard.Anydamages
orinjuriesbymisuseorusinganimproper
accessoryarenotcoveredbythewarranty.
UsethescrewsthatarelistedontheVESA
standardscrewspecifications.
Thewallmountkitwillincludeaninstallation
manualandnecessaryparts.
Thewallmountbracketisoptional.Youcan
obtainadditionalaccessoriesfromyourlocal
dealer.
Thelengthofscrewsmaydifferdepending
onthewallmount.Besuretousetheproper
length.
Formoreinformation,refertothe
instructionssuppliedwiththewallmount.
CAUTION
NOTE
Model
IPS225P/IPS235P
VESA(AxB) 100x100
Standardscrew M4
Numberofscrews 4
Mountingonawall
Forproperventilation,allowaclearanceof10cm
oneachsideandfromthewall.Detailed
instructionsareavailablefromyourdealer,seethe
optionalTiltWallMountingBracketInstallationand
SetupGuide.
IfyouintendtomounttheMonitorsettoawall,
attachWallmountinginterface(optionalparts)to
thebackoftheset.
WhenyouinstalltheMonitorsetusingawall
mountinginterface(optionalparts),attachit
carefullysoitwillnotdrop.
1
Please,Usethescrewandwallmountinterface
inaccordancewithVESAStandards.
2
Ifyouusescrewlongerthanstandard,the
monitormightbedamagedinternally.
3
Ifyouuseimproperscrew,theproductmightbe
damagedanddropfrommountedposition.In
thiscase,LGElectronicsisnotresponsiblefor
it.
4
VESAcompatible.
5
PleaseuseVESAstandardasbelow.
784.8mm(30.9inch)andunder
*WallMountPadThickness:2.6mm
*Screw:Φ4.0mmxPitch0.7mmx
Length10mm
787.4mm(31.0inch)andabove
*PleaseuseVESAstandardwallmountpad
andscrews.
10 cm
10 cm
10 cm
10 cm
background
11
ENG
ENGLISH
USING THE MONITOR SET
USINGTHEMONITORSET
ConnectingtoaPC
YourMonitorsetsupportsPlug&Play*.
*Plug&Play:APCrecognizesaconnected
devicethatusersconnecttoaPCandturn
on,withoutdeviceconfigurationoruser
intervention.
D-SUBconnection
TransmitsanalogvideofromyourPCtothe
Monitorset.ConnectthePCandtheMonitorset
withthesuppliedD-sub15pinsignalcableas
showninthefollowingillustrations.
Macadapter
ForAppleMacintoshuse,aseparateplug
adapterisneededtochangethe15pin
highdensity(3row)D-SUBVGAconnector
onthesuppliedcabletoa15pin2row
connector.
WhenusingaD-Subsignalinputcable
connectorforMacintosh
IfyouuseHDMIPC,itcancausecompatibility
problem.
NOTE
NOTE
DVI-Dconnection
TransmitsadigitalvideosignalfromyourPCto
theMonitorset.ConnectthePCandtheMonitor
setwithaDVIcableasshowninthefollowing
illustrations.
HDMIconnection
Transmitsthedigitalvideoandaudiosignalsfrom
yourPCorA/VtotheMonitorset.ConnectthePC
orA/VandtheMonitorsetwiththeHDMIcableas
showninthefollowingillustrations.
background
12
ENG
ENGLISH
USING THE MONITOR SET
WhenyouwanttousetwoPCinourMonitor,
pleaseconnectthesignalcable(D-SUB/
DVI-D/HDMI)respectivelyinMonitorset.
IfyouturntheMonitorsetonwhileitiscold,
thescreenmayflicker.Thisisnormal.
Somered,green,orbluespotsmayappear
onthescreen.Thisisnormal.
"SelfImageSetting"Function.
Thisfunctionprovidestheuserwithoptimal
displaysettings.Whentheuserconnects
themonitorforthefirsttime,thisfunction
automaticallyadjuststhedisplaytooptimal
settingsforindividualinputsignals.(Only
supportedinAnalogMode)
‘AUTO’Function.
Whenyouencounterproblemssuchas
blurryscreen,blurredletters,screenflicker
ortiltedscreenwhileusingthedeviceor
afterchangingscreenresolution,pressthe
AUTOfunctionbuttontoimproveresolution.
(OnlysupportedinAnalogMode)
NOTE NOTE
Connectthesignal
inputcableandtighten
itbyturningthescrews
clockwise.
Donotpressthescreenwithyourfingerfor
alongtimeasthismayresultintemporary
distortiononthescreen.
Avoiddisplayingafixedimageonthe
screenforalongperiodoftimetoprevent
imageburn.Useascreensaverifpossible.
CAUTION
SelfImageSettingFunction
Pressthepowerbuttononthebottompanelto
turnthepoweron.Whenmonitorpoweristurned
on,the"SelfImageSetting"Functionisexecuted
automatically.(OnlysupportedinAnalogMode)
background
13
ENG
ENGLISH
CUSTOMIZING SETTINGS
CUSTOMIZINGSETTINGS
AccessingTheMainMenus
1
PressanybuttononthebottomoftheMonitorsettodisplaytheMONITORSETUPOSDmenu.
2
Pressthedesiredmenuitem.
3
ChangethevalueofthemenuitembypressingthebuttonsonthebottomoftheMonitorset.
Toreturntotheuppermenuorsetothermenuitems,usetheuparrow( )button.
4
SelectEXITtoleavetheOSDmenu.
MonitorsetButtons
MENU(Seep.14)
Setsthescreenoptions.
DUAL(Seep.20)
Setsthescreen.
EXIT
ExitstheOSDmenu.
INPUT
Setstheexternalinput.
MODE(Seep.19)
Setsthemode.
AUTO(Seep.12)
Optimizestheresolution.
Differentmenuitemsareenableddependingonthetypeofinputsignal.
D-SUB/DVIMode:MENU,MODE,DUAL,AUTO,INPUT,EXIT
HDMIMode:MENU,MODE,INPUT,EXIT
NOTE
background
14
ENG
ENGLISH
CUSTOMIZING SETTINGS
CustomizingSettings
MenuSettings
1
PressanybuttononthebottomoftheMonitorsettodisplay
theMONITORSETUPOSDmenu.
2
PresstheMENUbuttontodisplaytheoptionsintheOSD
menu.
3
Settheoptionsbypressingthebuttonsonthebottomofthe
Monitorset.
4
SelectEXITtoleavetheOSDmenu.
Toreturntotheuppermenuorsetothermenuitems,usethe
uparrow( )button.
Theavailableprogramsettingsaredescribedbelow.
Menu Sub-menu Analog Digital HDMI Description
PICTURE BRIGHTNESS
CONTRAST
SHARPNESS
● ● ●
Toadjustthebrightness,contrastandsharpnessofthe
screen
BLACKLEVEL ● Tosetoffsetlevel
COLOR
COLORTEMP
(PRESET/USER)
● ● ● Tocustomizethecolorofthescreen
GAMMA
COLORRESET
DISPLAY HORIZONTAL
VERTICAL
● Toadjustthepositionofthescreen
CLOCKPHASE ●
Toimprovetheclarityandstabilityofthescreen
OVERSCAN ●
VOLUME
● Toadjustthevolume
OTHERS LANGUAGE
POWERINDICATOR
● ● ●
Tocustomizethescreenstatusforauser'soperating
environment
WHITEBALANCE ●
ORIGINALRATIO ● ● ●
SUPERENERGY
SAVING
● ● ●
FACTORYRESET ● ● ●
Analog:D-SUB(Analogsignal)input.
Digital:DVI-D(Digitalsignal)input.
HDMI:HDMI(Digitalsignal)input.
background
15
ENG
ENGLISH
CUSTOMIZING SETTINGS
Theavailableprogramsettingsaredescribedbelow.
1
PressanybuttononthebottomoftheMonitorsettodisplay
theMONITORSETUPOSDmenu.
2
PresstheMENUbuttontodisplaytheoptionsintheOSD
menu.
3
SelectPICTUREbypressingthebuttonsonthebottomof
theMonitorsetandsettheoptions.
4
SelectEXITtoleavetheOSDmenu.
Toreturntotheuppermenuorsetothermenuitems,use
theuparrow( )button.
Theavailablepicturesettingsaredescribedbelow.
Menu Description
BRIGHTNESS Toadjustthebrightnessofthescreen.
CONTRAST Toadjustthecontrastofthescreen.
SHARPNESS Toadjusttheclearnessofthescreen.
BLACKLEVEL Youcansettheoffsetlevel.Ifyouselect'HIGH',thescreenwillbebrightandifyouselect‘LOW’,
thescreenwillbedark.(onlyforHDMIinput)
*Offset?Asthecriteriaforvideosignal,itisthedarkestscreenthemonitorcanshow.
background
16
ENG
ENGLISH
CUSTOMIZING SETTINGS
COLOR
1
PressanybuttononthebottomoftheMonitorsetto
displaytheMONITORSETUPOSDmenu.
2
PresstheMENUbuttontodisplaytheoptionsintheOSD
menu.
3
SelectCOLORbypressingthebuttonsonthebottomof
theMonitorsetandsettheoptions.
4
SelectEXITtoleavetheOSDmenu.
Toreturntotheuppermenuorsetothermenuitems,use
theuparrow( )button.
Theavailablepicturesettingsaredescribedbelow.
Menu Description
COLORTEMP PRESET
Selectthescreencolor.
•WARM:Setthescreentowarmcolortemperature(morered).
•MEDIUM:Setthescreentomediumcolortemperature.
•COOL:Setthescreentocoolcolortemperature(moreblue).
USER
•SIXCOLOR: Setsandstoresthehueandsaturationforsixcolors(RED/GREEN/BLUE/
CYAN/MAGENTA/YELLOW)tosatisfythecolorrequirementsofauser.
HUE
Adjuststhescreenhue.
SATURATION
Adjuststhecolorsharpnessonthescreen.Lowervaluesmake
thecolorsharpnessweakerandcolorslighterwhilehigher
valuesmakethecolorsharpnessstrongerandcolorsdark.
•RED:
•GREEN:
•BLUE:
Setyourownredcolorlevels.
Setyourowngreencolorlevels.
Setyourownbluecolorlevels.
GAMMA Setyourowngammavalue.:1.8/2.0/2.2/2.4/2.6Onthemonitor.Imageisadjustedaccordingto
differentgammacurve.
COLORRESET Resetsthecolorsettingstothefactorydefaultsettingsforthecurrentinputdevice.
background
17
ENG
ENGLISH
CUSTOMIZING SETTINGS
DISPLAY
1
PressanybuttononthebottomoftheMonitorsettodisplay
theMONITORSETUPOSDmenu.
2
PresstheMENUbuttontodisplaytheoptionsintheOSD
menu.
3
SelectDISPLAYbypressingthebuttonsonthebottomof
theMonitorsetandsettheoptions.
4
SelectEXITtoleavetheOSDmenu.
Toreturntotheuppermenuorsetothermenuitems,use
theuparrow( )button.
Theavailablepicturesettingsaredescribedbelow.
VOLUME
1
PressanybuttononthebottomoftheMonitorsettodisplay
theMONITORSETUPOSDmenu.
2
PresstheMENUbuttontodisplaytheoptionsintheOSD
menu.
3
SelectVOLUMEbypressingthebuttonsonthebottomof
theMonitorsetandsettheoptions.
4
SelectEXITtoleavetheOSDmenu.
Toreturntotheuppermenuorsetothermenuitems,use
theuparrow( )button.
Theavailablepicturesettingsaredescribedbelow.
Menu Description
HORIZONTAL Tomoveimageleftandright.
VERTICAL Tomoveimageupanddown.
CLOCK Tominimizeanyverticalbarsorstripesvisibleonthescreenbackground.Thehorizontalscreen
sizewillalsochange.
PHASE Toadjustthefocusofthedisplay.Thisitemallowsyoutoremoveanyhorizontalnoiseandclearor
sharpentheimageofcharacters.
OVERSCAN ToselecttherangeofoutputimageforDTVtiminginHDMIinput.(onlyforHDMIinput)Recommend
overscanfunctiontoturnonwhenconnectAVequipment.
Menu Description
VOLUME Toadjustthevolumeofheadphone/Earphone.(OnlyforHDMIinput)
background
18
ENG
ENGLISH
CUSTOMIZING SETTINGS
OTHERS
1
PressanybuttononthebottomoftheMonitorsettodisplaythe
MONITORSETUPOSDmenu.
2
PresstheMENUbuttontodisplaytheoptionsintheOSDmenu.
3
SelectOTHERSbypressingthebuttonsonthebottomofthe
Monitorsetandsettheoptions.
4
SelectEXITtoleavetheOSDmenu.
Toreturntotheuppermenuorsetothermenuitems,usetheup
arrow( )button.
Theavailablepicturesettingsaredescribedbelow.
Menu Description
LANGUAGE Tochoosethelanguageinwhichthecontrolnamesaredisplayed.
POWER
INDICATOR
UsethisfunctiontosetthepowerindicatoronthebottomsideofthemonitortoONorOFF.Ifyou
setOFF,itwillgooff.
IfyousetONatanytime,thepowerindicatorwillautomaticallybeturnedon.
WHITE
BALANCE
Iftheoutputofthevideocardisdifferenttherequiredspecifications,thecolorlevelmaydeteriorate
duetovideosignaldistortion.Usingthisfunction,thesignallevelisadjustedtofitintothestandard
outputlevelofthevideocardinordertoprovidetheoptimalimage.Activatethisfunctionwhen
whiteandblackcolorsarepresentinthescreen.
ORIGINALRATIO WIDE
Switchtofullscreenmodeaccordingtoinputimagesignal.
ORIGINAL
Changetheinputimagesignalratiotooriginal.
*ThisfunctionworksonlyifinputresolutionislowerthanMonitorsetratio(16:9).
SUPERENERGY
SAVING
SetstheSUPERENERGYSAVINGfunction.
ON
EnablesSUPERENERGYSAVINGyoucansaveenergywiththisenergy-efficientfunction
OFF DisablesSUPERENERGYSAVING.
RESET ResetsthevaluesoftotalenergyconsumptionreductionandCO2emissionreduction
estimates.
RTC
(Response
TimeCompensation)
IfyouenableRTCfunction,youcancontrolResponseTimeCompensationlevel.
IfyousetOFF,youdisenabletheResponseTimeCompensationfunction.
FACTORY
RESET
Restoreallfactorydefaultsettingsexcept"LANGUAGE."Pressthe◄,►buttonstoreset
immediately.
TOTALPOWERREDUCTION:Howmuchpowerissavedwhileusingthemonitor.
TOTALCO2REDUCTION:ChangetheTOTALPOWERREDUCTIONtoCO2.
SAVINGDATA(W/h)
545mm(21.5inch) 584mm(23inch)
SUPERSAVING 4W/h 5W/h
LEDSAVING 15W/h 12W/h
SavingDatadependsonthePanel.So,thosevaluesshouldbedifferentfromeachpanelandpanel
vendor.
LGcalculatedthesevaluesbyusing“broadcastvideosignal”.
LEDSavingreferstohowmuchpowercanbesavedusingaWLEDPanelinsteadofCCFLpanel.
SUPERSAVINGreferstohowmuchpowercanbesavedusingtheSUPERENERGYSAVING
function.
NOTE
background
19
ENG
ENGLISH
CUSTOMIZING SETTINGS
MODESetting
1
PressanybuttononthebottomoftheMonitorsettodisplaytheMONITORSETUPOSDmenu.
2
PresstheMODEbuttontodisplaytheoptionsintheOSDmenu.
3
SettheoptionsbypressingthebuttonsonthebottomoftheMonitorset.
4
SelectEXITtoleavetheOSDmenu.
Toreturntotheuppermenuorsetothermenuitems,usetheuparrow( )button.
Theavailablepicturesettingsaredescribedbelow.
Menu Description
USER Itisamodethattheusercanadjusteachelement.ItcanadjustthecolormodeoftheMainMenu.
MOVIE Itisamodethatthescreenisadjustedtothebesttoviewthevideos.
TEXT Itisamodethatthescreenisadjustedtothebestforthetextworks.
PHOTO Itisamodethatthescreenisadjustedtothebesttoviewpictures.
sRGB ItisamodethatthescreenisadjustedtothestandardsRGB.
background
20
ENG
ENGLISH
CUSTOMIZING SETTINGS
Theavailablepicturesettingsaredescribedbelow.
NOTE
WhenmonitorgoestoPowerSavingModewithPCpowersavingoption,onpressinganybuttonand
selectingDualoptionusercanbringbackmonitortonormalmode.
DUALPACKAGESetting
1
PressanybuttononthebottomoftheMonitorsetto
displaytheMONITORSETUPOSDmenu.
2
PresstheDUALbuttontodisplaytheoptionsinthe
OSDmenu.
3
Settheoptionsbypressingthebuttonsonthebottom
oftheMonitorset.
4
SelectEXITtoleavetheOSDmenu.
Toreturntotheuppermenuorsetothermenuitems,
usetheuparrow( )button.
*Beforeusingbelowfunctions,pleaseinstallDUALPACKAGEprogramme.
*OnlyforD-SUB/DVI-Dinput.
Menu Description
DUALMONITOR OFF IfselectOFF,DUALMONITORoff
EXTENDED ByselectingEXTENDED,usercanusesecondarymonitorasextendedmodeof
primarymonitor.
CLONE ByselectingCLONE,usercanusesecondarymonitorasdonemodeofprimary
monitor.
DUALWEB ON Helpusertobrowsewebefficientlybydividinginhalf.Helptoarrangeand
movewindowsonscreen.Helpusertocontroldividedwindowsratio.
OFF IfselectOFF,DUALWEBisoff.

background
21
ENG
ENGLISH
TROUBLESHOOTING
TROUBLESHOOTING
Checkthefollowingbeforecallingforservice.
Noimageappears
Isthepowercordofthedisplay
connected?
Checkandseeifthepowercordisconnectedproperlytothepower
outlet.
Isthepowerindicatorlighton?
PressthePowerbutton.
Isthepoweronandthepower
indicatorblueorgreen?
Adjustthebrightnessandthecontrast.
Isthepowerindicatorflickering?
Ifthedisplayisinpowersavingmode,trymovingthemouseor
pressinganykeyonthekeyboardtobringupthescreen.
TrytoturnonthePC.
Doyouseean"OUTOFRANGE"
messageonthescreen?
ThismessageappearswhenthesignalfromthePC(videocard)is
outofhorizontalorverticalfrequencyrangeofthedisplay.Seethe
'Specifications'sectionofthismanualandconfigureyourdisplay
again.
Doyouseea"CHECKSIGNAL
CABLE"messageonthescreen?
ThismessageappearswhenthesignalcablebetweenyourPCand
yourdisplayisnotconnected.Checkthesignalcableandtryagain.
Doyouseea"OSDLOCKED"messageonthescreen?
Doyousee“OSDLOCKED”when
youpushMENUbutton?
Youcansecurethecurrentcontrolsettings,sothattheycannotbe
inadvertentlychanged.YoucanunlocktheOSDcontrolsatanytime
bypushingtheMENUbuttonforseveralseconds:themessage“OSD
UNLOCKED”willappear.
Displayimageisincorrect
DisplayPositionisincorrect.
PresstheAUTObuttontoautomaticallyadjustyourdisplayimageto
theidealsetting.
Onthescreenbackground,vertical
barsorstripesarevisible.
PresstheAUTObuttontoautomaticallyadjustyourdisplayimageto
theidealsetting.
Anyhorizontalnoiseappearingin
anyimageorcharactersarenot
clearlyportrayed.
PresstheAUTObuttontoautomaticallyadjustyourdisplayimageto
theidealsetting.
CheckControlPanel►Display►Settingsandadjustthedisplay
totherecommendedresolutionoradjustthedisplayimagetothe
idealsetting.Setthecolorsettinghigherthan24bits(truecolor).
background
22
ENG
ENGLISH
TROUBLESHOOTING
Displayimageisincorrect
Thescreencolorismonoor
abnormal.
Checkifthesignalcableisproperlyconnectedanduseascrewdriver
tofastenifnecessary.
Makesurethevideocardisproperlyinsertedintheslot.
Setthecolorsettinghigherthan24bits(truecolor)atControlPanel
►Settings.
Thescreenblinks.
Checkifthescreenissettointerlacemodeandifyes,changeitto
therecommendresolution.
Doyouseean"Unrecognizedmonitor,Plug&Play(VESADDC)monitorfound"message?
Haveyouinstalledthedisplay
driver?
BesuretoinstallthedisplaydriverfromthedisplaydriverCD(or
diskette)thatcomeswithyourdisplay.Or,youcanalsodownloadthe
driverfromourwebsite:http://www.lg.com.
MakesuretocheckifthevideocardsupportsPlug&Playfunction.
CheckControlPanel►Display►Settingsandseeifthefrequencyortheresolutionwere
changed.Ifyes,readjustthevideocardtotherecommendresolution.
Iftherecommendedresolution(optimalresolution)isnotselected,lettersmaybeblurredandthe
screenmaybedimmed,truncatedorbiased.Makesuretoselecttherecommendresolution.
ThesettingmethodcandifferbycomputerandO/S(OperationSystem),andresolutionmentioned
abovemaynotbesupportedbythevideocardperformance.Inthiscase,pleaseasktothecomputer
orthevideocardmanufacturer.
CAUTION
background
23
ENG
ENGLISH
SPECIFICATIONS
SPECIFICATIONS
Display ScreenType 54.5cm(21.5inch)FlatPanelActivematrix-TFT
LCDAnti-Glarecoating
Visiblediagonalsize:54.5cm
PixelPitch 0.247mmx0.247mm(PixelPitch)
SyncInput HorizontalFrequency 30kHzto83kHz(Automatic)
VerticalFrequency 56Hzto75Hz(D-SUB,DVI-D)
56Hzto61Hz(HDMI)
InputForm SeparateSync.Digital
VideoInput SignalInput 15pinD-SUBConnector/DVI-DConnector(Digital)
HDMIConnector
InputForm RGBAnalog(0.7Vp-p/75ohm),Digital
Resolution Max D-SUB(Analog):1920x1080@60Hz
DVI/HDMI(Digital):1920x1080@60Hz
Recommend VESA1920x1080@60Hz
Plug&Play DDC2B(Analog,Digital,HDMI)
PowerConsumption OnMode:31W(Typ.)
SleepMode≤0.3W
OffMode≤0.3W
PowerInput AC100-240V~50/60Hz1.0A
Dimensions
(WidthxHeightxDepth)
WithStand 51.3cmx51.6cmx22.2cm(Max)
51.3cmx38.6cmx22.2cm(Min)
WithoutStand 51.3cmx31.2cmx5.9cm
Weight 5.45kg
Range Tilt -5°to15°
Swivel -45°~45°(+/-2°)
Height 130.0mm(5.12inch)
Environmental
conditions
OperatingTemperature
OperatingHumidity
10°Cto35°C
10%to80%
StorageTemperature
StorageHumidity
-20°Cto60°C
5%to90%non-Condensing
StandBase Attached(),Detached(O)
Powercord Wall-outlettype
Productspecificationsshownabovemaybechangedwithoutpriornoticeduetoupgradeofproduct
functions.
IPS225P
background
24
ENG
ENGLISH
SPECIFICATIONS
SPECIFICATIONS
Display ScreenType 58.4cm(23inch)FlatPanelActivematrix-TFTLCD
Anti-Glarecoating
Visiblediagonalsize:58.4cm
PixelPitch 0.265mmx0.265mm(PixelPitch)
SyncInput HorizontalFrequency 30kHzto83kHz(Automatic)
VerticalFrequency 56Hzto75Hz(D-SUB,DVI-D)
56Hzto61Hz(HDMI)
InputForm SeparateSync.Digital
VideoInput SignalInput 15pinD-SUBConnector/DVI-DConnector(Digital)
HDMIConnector
InputForm RGBAnalog(0.7Vp-p/75ohm),Digital
Resolution Max D-SUB(Analog):1920x1080@60Hz
DVI/HDMI(Digital):1920x1080@60Hz
Recommend VESA1920x1080@60Hz
Plug&Play DDC2B(Analog,Digital,HDMI)
PowerConsumption OnMode:35W(Typ.)
SleepMode≤0.3W
OffMode≤0.3W
PowerInput AC100-240V~50/60Hz1.0A
Dimensions
(WidthxHeightxDepth)
WithStand 54.7cmx51.6cmx22.2cm(Max)
54.7cmx38.6cmx22.2cm(Min)
WithoutStand 54.7cmx33.1cmx5.9cm
Weight 5.75kg
Range Tilt -5°to15°
Swivel -45°~45°(+/-2°)
Height 130.0mm(5.12inch)
Environmental
conditions

OperatingTemperature
OperatingHumidity
10°Cto35°C
10%to80%
StorageTemperature
StorageHumidity
-20°Cto60°C
5%to90%non-Condensing
StandBase Attached(),Detached(O)
Powercord Wall-outlettype
Productspecificationsshownabovemaybechangedwithoutpriornoticeduetoupgradeofproduct
functions.
IPS235P
background
25
ENG
ENGLISH
SPECIFICATIONS
PresetModes(Resolution)
DisplayModes(Resolution)
Horizontal
Frequency(kHz)
Vertical
Frequency(Hz)
Polarity(H/V)
720x400 31.468 70 -/+
640x480 31.469 60 -/-
640x480 37.500 75 -/-
800x600 37.879 60 +/+
800x600 46.875 75 +/+
1024x768 48.363 60 -/-
1024x768 60.123 75 -/-
1152x864 67.500 75 +/+
1280x1024 63.981 60 +/+
1280x1024 79.976 75 +/+
1680x1050 65.290 60 -/+
1920x1080 67.500 60 +/+ RecommendMode
HDMITIMING
DisplayModes(Resolution) HorizontalFrequency(kHz) VerticalFrequency(Hz)
480P 31.50 60
576P 31.25 50
720P 37.50 50
720P 45.00 60
1080i 28.12 50
1080i 33.75 60
1080P 56.25 50
1080P 67.50 60 RecommendMode
Indicator
Mode LEDColor
OnMode Blue
SleepMode BlinkingBlue
OffMode Off
background
background
Make sure to read the Safety Precautions before
using the product.
Keep the Owner’s Manual (CD) in an accessible
place for future reference.
The model and serial number of the SET is
located on the back and one side of the SET.
Record it below should you ever need service.
As an ENERGY STAR Partner LGE
U. S. A.,Inc. has determined that this
product meets the ENERGY STAR
guidelines for energy efficiency.
ENERGY STAR is a set of power-saving
guidelines issued by the U.S.Environmental
Protection Agency(EPA).
MODEL
SERIAL

Specifications

Indexed Terms: Monitor, LED Backlight

LG Electronics IPS235P-BN Questions and Answers

Find answers or ask new question.
Questions and Answers

Related Products

Product LG Electronics 23EA53V image
LG Electronics 23EA53V Lg - 23'' Lg Ips Led Lcd Monitor
2020-12-13 1 docs
Product LG Electronics 22MP57VQ image
LG Electronics 22MP57VQ Lg Ips Monitor
2021-04-27 1 docs
Product LG Electronics 22MP58VQ image
LG Electronics 22MP58VQ Lg Ips Monitor
2021-04-19 1 docs
Product LG Electronics 24MB35D image
LG Electronics 24MB35D Lg Ips Monitor
2021-02-01 2 docs
Product LG Electronics 24MP56HQ image
LG Electronics 24MP56HQ - Ips Monitor Mp56
2020-12-13 1 docs
Product LG Electronics 22MP56HQ image
LG Electronics 22MP56HQ - Lg Ips Monitor Mp56
2020-12-12 1 docs
