E-1
Important
Information
IMPORTANT
For your assistance in reporting the loss or theft of your
projector, please record the Serial Number located on
the bottom of the projector and retain this information.
Before recycling the packaging, please be sure that
you have checked the contents of the carton thoroughly
against the list of “Supplied Accessories” on page 10.
Before using the projector, please read this operation manual carefully.
OPERATION MANUAL ENGLISH
Model No.: XG
-
NV7XU
Serial No.:
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER.
NO USER-SERVICEABLE PARTS EXCEPT LAMP UNIT.
REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK.
DO NOT REMOVE SCREWS
EXCEPT SPECIFIED USER
SERVICE SCREW.
There are two important reasons for prompt warranty registration of your new SHARP Projector, using
the REGISTRATION CARD packed with the projector.
1. WARRANTY
This is to assure that you immediately receive the full benefit of the parts, service and labor
warranty applicable to your purchase.
2. CONSUMER PRODUCT SAFETY ACT
To ensure that you will promptly receive any safety notification of inspection, modification, or
recall that SHARP may be required to give under the 1972 Consumer Product Safety Act, PLEASE
READ CAREFULLY THE IMPORTANT “LIMITED WARRANTY” CLAUSE.
U.S.A. ONLY
The lightning flash with arrowhead symbol,
within an equilateral triangle, is intended to
alert the user to the presence of uninsulated
“dangerous voltage” within the product’s
enclosure that may be of sufficient magnitude
to constitute a risk or electric shock to
persons.
The exclamation point within a triangle is
intended to alert the user to the presence of
important operating and maintenance
(servicing) instructions in the literature
accompanying the product.
INFORMATION
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful inter-
ference when the equipment is operated in a commercial environment. This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and used in accordance with the operation manual,
may cause harmful interference to radio communications. Operation of this equipment in a residential area is
likely to cause harmful interference, in which case the user will be required to correct the interference at his own
expense.
U.S.A. ONLY
U.S.A. ONLY
The enclosed computer cable must be used with the device. The cable is provided to ensure that the device
complies with FCC Class A verification.
U.S.A. ONLY
WARNING: High brightness light source. Do not stare into the beam of light, or view directly. Be especially
careful that children do not stare directly into the beam of light.
WARNING: To reduce the risk of fire or electric shock, do not expose this product to rain or moisture.
WARNING: FCC Regulations state that any unauthorized changes or modifications to this equipment not
expressly approved by the manufacturer could void the user’s authority to operate this equip-
ment.
E-2
Important
Information
IMPORTANT SAFEGUARDS
Electrical energy can perform many useful functions. This product has been engineered and manufactured to ensure your
personal safety. But IMPROPER USE CAN RESULT IN POTENTIAL ELECTRICAL SHOCK OR FIRE HAZARD. In order not to
defeat the safeguards incorporated into this Projector, observe the following basic rules for its installation, use and servicing.
For your own protection and reliable usage of your projector, please be sure to read these “IMPORTANT SAFEGUARDS”
carefully before use.
1. Read Instructions
All the safety and operating instructions should be read
before the product is operated.
2. Retain Instructions
The safety and operating instructions should be retained
for future reference.
3. Heed Warnings
All warnings on the product and in the operating
instructions should be adhered to.
4. Follow Instructions
All operating and use instructions should be followed.
5. Cleaning
Unplug this product from the wall outlet before cleaning.
Do not use liquid cleaners or aerosol cleaners. Use a
damp cloth for cleaning.
6. Attachments
Do not use attachments not recommended by the product
manufacturer as they may cause hazards.
7. Water and Moisture
Do not use this product near water–for example, near a
bathtub, wash bowl, kitchen sink, or laundry tub; in a wet
basement; or near a swimming pool; and the like.
8. Accessories
Do not place this product on an unstable cart, stand,
tripod, bracket, or table. The product may fall, causing
serious injury to a child or adult, and serious damage to
the product. Use only with a cart, stand, tripod, bracket,
or table recommended by the manufacturer, or sold with
the product. Any mounting of the product should follow
the manufacturer’s instructions, and should use a
mounting accessory recommended by the manufacturer.
9. Transportation
A product and cart combination
should be moved with care. Quick
stops, excessive force, and
uneven surfaces may cause the
product and cart combination to
overturn.
10. Ventilation
Slots and openings in the cabinet are provided for
ventilation to ensure reliable operation of the product and
to protect it from overheating. The openings should never
be covered or blocked by placing the product on a bed,
sofa, rug, or other similar surface. This product should
not be placed in a built-in installation such as a bookcase
or rack unless proper ventilation is provided or the
manufacturer’s instructions have been adhered to.
11. Power Sources
This product should be operated only from the type of
power source indicated on the marking label. If you are
not sure of the type of power supply to your home, consult
your product dealer or local power company. For products
intended to operate from battery power, or other sources,
refer to the operating instructions.
12. Grounding or Polarization
This product is equipped with a three-wire grounding-type
plug, a plug having a third (grounding) pin. This plug will
only fit into a grounding-type power outlet. This is a safety
feature. If you are unable to insert the plug into the outlet,
contact your electrician to replace your obsolete outlet.
Do not defeat the safety purpose of the grounding-type
plug.
13. Power-Cord Protection
Power-supply cords should be routed so that they are not
likely to be walked on or pinched by items placed upon
or against them, paying particular attention to cords at
plugs, convenience receptacles, and the point where they
exit from the product.
14. Lightning
For added protection for this product during a lightning
storm, or when it is left unattended and unused for long
periods of time, unplug it from the wall outlet and
disconnect the cable system. This will prevent damage
to the product due to lightning and power-line surges.
15. Overloading
Do not overload wall outlets, extension cords, or integral
convenience receptacles as this can result in a risk of fire
or electric shock.
16. Object and Liquid Entry
Never push objects of any kind into this product through
openings as they may touch dangerous voltage points or
short-out parts that could result in a fire or electric shock.
Never spill liquid of any kind on the product.
17. Servicing
Do not attempt to service this product yourself as opening
or removing covers may expose you to dangerous voltage
or other hazards. Refer all servicing to qualified service
personnel.
18. Damage Requiring Service
Unplug this product from the wall outlet and refer servicing
to qualified service personnel under the following
conditions:
a. If the power-supply cord or plug is damaged.
b. If liquid has been spilled, or objects have fallen into
the product.
c. If the product has been exposed to rain or water.
d. If the product does not operate normally by following
the operating instructions. Adjust only those controls
that are covered by the operating instructions, as an
improper adjustment of other controls may result in
damage and will often require extensive work by a
qualified technician to restore the product to normal
operation.
e. If the product has been dropped or damaged in any
way.
f. If the product exhibits a distinct change in
performance, this indicates a need for service.
19. Replacement Parts
When replacement parts are required, be sure the service
technician has used replacement parts specified by the
manufacturer or with the same characteristics as the
original part. Unauthorized substitutions may result in fire,
electric shock, or other hazards.
20. Safety Check
Upon completion of any service or repairs to this product,
ask the service technician to perform safety checks to
determine that the product is in proper operating
condition.
21. Wall or Ceiling Mounting
This product should be mounted to a wall or ceiling only
as recommended by the manufacturer.
22. Heat
This product should be situated away from heat sources
such as radiators, heat registers, stoves, or other products
(including amplifiers) that produce heat.
E-3
Important
Information
Outstanding Features
1. DIRECT DIGITAL COMPUTER INPUT (PanelLink™)
Signals remain digital from the source device to the projector thus resulting in sharper, clearer, noiseless and adjustment-free
computer images.
2. ADVANCED COMPATIBILITY WITH HIGH-END WORKSTATIONS
AND PCS
Compatible with up to 200 Hz vertical refresh rate, Sync on Green and Composite Sync signals
for use with a wide variety of high-end PCs and Workstations. (Page 11)
3. FOR USE WITH DTV*/HDTV
Allows projection of DTV images and 16:9 wide-screen images when connected to a DTV decoder
or similar video systems. (Page 13)
4. COMPONENT VIDEO COMPATIBILITY (VIA RGB)
Equipped with terminals for connection to a DTV decoder, DVD player and similar video systems for higher quality images.
(Page 13)
5. ADVANCED VIDEO CIRCUITRY
Provides high quality video images with minimal noise for more impressive presentations.
6. DIGITAL KEYSTONE CORRECTION
Digitally adjusts an image that is projected at an angle while maintaining image quality and
brightness. (Page 19)
7. EASY-TO-USE GRAPHICAL USER INTERFACE (GUI)
A multi-color, icon based menu system allows for simple image adjustments. (Page 23)
8. USER-FRIENDLY DESIGN
The two-color design along with an intuitive Graphical User Interface (GUI) makes this projector
very easy to set up and adjust.
9. WIRELESS PRESENTATIONS WITH IrCOM
The IrCOM function allows for wireless transmission of digital images via infrared
communication from a PC or digital camera. (Page 25)
10. AUTO SYNC TECHNOLOGY FOR AUTOMATIC IMAGE
PERFECTION
Automatically makes any necessary adjustments for perfectly synced computer images.
(Page 29)
11. INTELLIGENT COMPRESSION AND EXPANSION
By using intelligent resizing technology, this projector can display higher and lower resolution images in detail without
compromising quality. (Page 36)
12. XGA RESOLUTION FOR HIGH RESOLUTION PRESENTATIONS
With XGA (1,024 768) resolution, this projector can display very detailed presentation information.
13. UXGA COMPATIBLE
UXGA (1,600 1,200) resolution images are intelligently resized to 1,024 768 for full-screen or default presentations.
14. CUSTOMIZABLE STARTUP SCREEN
Allows you to load a custom startup image (i.e. your company logo) to be displayed while the projector is warming up.
(Page 42)
15. BUILT-IN PRESENTATION TOOLS
A variety of helpful presentation utilities are incorporated to enhance presentations. These include “Stamp” functions, “Break
Timer”, and “Digital Enlarge”. (Page 44)
16. QUIET OPERATION
The quiet fan operation allows the audience to concentrate on the presentation without the distraction of fan noise.
H
L
X
*DTV is the umbrella term used to describe the new digital television system in the united states.
E-4
Important
Information
Important Information
Contents
IMPORTANT SAFEGUARDS …………………… 2
Outstanding Features …………………………… 3
Contents …………………………………………… 4
Usage Guidelines ………………………………… 5
How to Access the PDF Operation Manuals
(for Windows and Macintosh) ……………… 6
For SHARP Assistance (U.S.A. only) ………… 6
Part Names ………………………………………… 7
Setup & Connections
Operation
Useful Features
Maintenance &
Troubleshooting
Appendix
Useful Features
Freeze Function …………………………………… 33
Digital Image Magnification (ENLARGE) ……… 34
Gamma Correction ……………………………… 35
Selecting the Picture Display Mode …………… 36
Black Screen Function …………………………… 37
On-screen Display Override Function ………… 37
Automatic Power Shutoff Function …………… 38
I/P Conversion …………………………………… 39
Checking the Lamp Usage Time ……………… 39
Selecting the Signal Type ……………………… 40
Checking the Input Signal ……………………… 40
Setting a Background Image …………………… 41
Selecting a Startup Image ……………………… 42
Reverse/Invert Image Function ………………… 43
Using the Presentation Tools …………………… 44
Status Function …………………………………… 45
Lamp/Maintenance Indicators ………………… 47
Replacing the Projection Lamp ………………… 48
Using the Kensington Lock …………………… 49
Troubleshooting …………………………………… 49
Maintenance & Troubleshooting
Appendix
Transporting the Projector ……………………… 51
Connection Pin Assignments…………………… 52
RS-232C Port Specifications …………………… 53
Input Signals (Recommended Timing) ………… 55
Specifications ……………………………………… 57
Dimensions ………………………………………… 58
Guide to Effective Presentations ……………… 59
Glossary …………………………………………… 63
Index ………………………………………………… 64
Setup & Connections
Supplied Accessories …………………………… 10
Connecting the Projector ……………………… 11
Basic Operations ………………………………… 16
Setting up the Screen …………………………… 18
Operating the Wireless Mouse from the
Remote Control ……………………………… 21
Using the GUI (Graphical User Interface)
Menu Screens ………………………………… 23
Using IrCOM for Wireless Presentations ……… 25
Selecting the On-screen Display Language … 26
Selecting the Video Input System Mode
(VIDEO mode only) …………………………… 26
Picture Adjustments ……………………………… 27
Audio Adjustments ……………………………… 28
Computer Image Adjustments ………………… 29
Auto Sync Adjustment ………………………… 30
Auto Sync Display Function …………………… 30
Saving and Selecting Adjustment Settings … 31
Special Mode Adjustment …………………… 32
Operation
E-5
Important
Information
Usage Guidelines
The laser pointer on the remote control emits a laser beam from the laser
pointer window. This is a Class II laser which may impair your sight if directed
into the eyes. The three marks shown on the left are caution labels for the
laser beam.
• Do not look into the laser pointer window or shine the laser beam on yourself or
others. (The laser beam used in this product is harmless when directed onto
the skin. However, be careful not to project the beam directly into the eyes.)
• Always use the laser pointer at temperatures between 41°F and 95°F (5°C
and 35°C).
• Use of controls or adjustments, or performance of procedures other than those
specified herein may result in hazardous radiation exposure.
Cautions Concerning the Laser Pointer
Cautions Concerning the Setup of the Projector
For minimal servicing and to maintain high image quality, SHARP recommends
that this projector be installed in an area free from humidity, dust and cigarette
smoke. When the projector is subjected to these environments, the lens and
filter must be cleaned more often. Periodically the filter should be replaced
and the projector should be cleaned internally. As long as the projector is
properly maintained in this manner, use in these environments will not reduce
the overall operation life. Please note that all internal cleaning must be
performed by an Authorized Sharp Industrial LCD Products Dealer or Service
Center.
Laser pointer
window
AVOID EXPOSURE
-
LASER
RADIATION IS EMITTED
FROM THIS APERTURE.
CAUTION
LASER RADIATION-
DO NOT STARE INTO BEAM
WAVE LENGTH : 650nm
MAX. OUTPUT : 1mW
CLASS II LASER PRODUCT
"COMPLIES WITH 21 CFR SUBCHAPTER J"
SHARP ELECTRONICS CORPORATION
SHARP PLAZA, MAHWAH, NEW JERSEY 07430
TEL : 1-800-BE-SHARP
U.S.A. ONLY
REMOTE CONTROL
MODEL NO. : RRMCG1530CESA
DC3V (1.5VX2PCS.)
MADE IN CHINA
FABRIQUÉ AU CHINE
95˚F
(35˚C)
41˚F
(5˚C)
Temperature Monitor Function
If the projector starts to overheat due to setup problems or a dirty air filter, “TEMP.”
and “
” will flash in the lower-left corner of the picture. If the temperature continues
to rise, the lamp will turn off, the TEMPERATURE WARNING indicator on the
projector will flash, and after a 90-second cooling-off period the power will shut
off. Refer to “Lamp/Maintenance Indicators” on page 47, for details.
• The cooling fan regulates the internal temperature, and its performance is
automatically controlled. The sound of the fan may change during projector
operation due to changes in the fan speed.
Notes on Operation
• The two marks shown on the left are caution labels for parts of the projector
that emit intense heat during operation.
• The exhaust vents, the lamp cage cover and adjacent areas may be extremely
hot during projector operation. To prevent injury, do not touch these areas until
they have sufficiently cooled.
• Allow at least 4 inches (10 cm) of space between the cooling fan (exhaust
vent) and the nearest wall or obstruction.
• If the cooling fan becomes obstructed, a protection device will automatically
turn off the projector lamp. This does not indicate a malfunction. Remove the
projector power cord from the wall outlet and wait at least 10 minutes. Then
turn on the power by plugging the power cord back in. This will return the
projector to the normal operating condition.
E-6
Important
Information
How to Access the PDF Operation Manuals (for Windows and Macintosh)
PDF operation manuals in several languages are included in the CD-ROM. To utilize these manuals, you need to
install Adobe Acrobat Reader on your PC (Windows or Macintosh). If you have not installed Acrobat Reader yet,
you can download it from the Internet (http://www.adobe.com) or install it from the CD-ROM.
To Install Acrobat Reader (English version) from the CD-ROM
For other operating systems:
Please download Acrobat Reader from the Internet (http://www.adobe.com).
For other languages:
If you prefer using Acrobat Reader for other languages, please download the appropriate version from the Internet. (Please
note that you do not have to have Acrobat Reader in your own language. You can read any pdf file using the English version of
Acrobat Reader.)
Accessing the PDF Manuals
For Windows:
1 Insert the CD-ROM in the CD-ROM drive.
2 Double click on the “My Computer” icon.
3 Double click on the “CD-ROM” drive.
4 Double click on the “manuals” folder.
5 Double click on the “acrobat” folder.
6 Double click on the “windows” folder.
7 Double click on the installation program and follow
the instructions on the screen.
For Macintosh:
1 Insert the CD-ROM in the CD-ROM drive.
2 Double click on the “CD-ROM” icon.
3 Double click on the “manuals” folder.
4 Double click on the “acrobat” folder.
5 Double click on the “mac” folder.
6 Double click on the installation program and follow
the instructions on the screen.
For Windows:
1 Insert the CD-ROM in the CD-ROM drive.
2 Double click on the “My Computer” icon.
3 Double click on the “CD-ROM” drive.
4 Double click on the “manuals” folder.
5 Double click on the “xg-nv7xu” folder.
6 Double click on the language (name of the folder)
that you want to view.
7 Double click on the “nv7” pdf file to access the
projector manuals.
Double click on the “saps” pdf file to access the
Sharp Advanced Presentation Software manual.
8 Double click on the pdf file.
For Macintosh:
1 Insert the CD-ROM in the CD-ROM drive.
2 Double click on the “CD-ROM” icon.
3 Double click on the “manuals” folder.
4 Double click on the “xg-nv7xu” folder.
5 Double click on the language (name of the folder)
that you want to view.
6 Double click on the “nv7” pdf file to access the
projector manuals.
Double click on the “saps” pdf file to access the
Sharp Advanced Presentation Software manual.
7 Double click on the pdf file.
• If the desired pdf file cannot be opened by double clicking the mouse, please start Acrobat Reader first, then specify the
desired file using the “File”, “Open” menu.
• See the “readme.txt” file on the CD-ROM for information on the CD-ROM.
For SHARP Assistance (U.S.A. only)
If you encounter any problems during setup or operation of this projector, first refer to the “Troubleshooting”
section on page 49. If this operation manual does not answer your question, please call toll free 1-800-BE-SHARP
(1-800-237-4277) for further assistance. Or, send us an e-mail at lcdsuppor[email protected] .
Our World Wide Web address is http://www.sharp-usa.com/ .
E-7
Important
Information
Part Names
Numbers next to the part names refer to the main pages in this manual where the topic is explained.
Projector
Front and Top View
47
47
17
23
25
29
36
35
23
17
16
17
16
19
17
33
34
19
23
19
21
5
17
17
MUTE button
POWER indicator
POWER buttons (ON/OFF)
KEYSTONE button
INPUT button
FREEZE button
UNDO button
LAMP REPLACEMENT
indicator
TEMPERATURE WARNING
indicator
VOLUME buttons (/)
MENU button
IrCOM button
AUTO SYNC button
RESIZE button
GAMMA button
ENTER button
Speaker
Cooling fan (Exhaust vent)
Remote control sensor
Zoom ring
Focus ring
Foot releases
14 12
11
11
12
12
13
25
11
49
21
AC socket
IrCOM sensor
Side and Rear View
Remote control sensor
Cooling fan (Intake vent)
AUDIO INPUT terminals:
RCA
VIDEO INPUT terminal:
RCA
S-VIDEO INPUT terminal:
4 pin mini DIN
INPUT 1 port (HD 15)
AUDIO INPUT terminal
(3.5 mm stereo minijack)
RS-232C port
(9-pin mini-DIN)
Kensington Security
Standard connector
ENLARGE button
ADJUSTMENT buttons
(∂/ƒ/ß / ©)
INPUT 2 port
E-8
Important
Information
Front View
Remote Control
Part Names
17
37
23
17
33
34
44
21
17
23
19
17
16
22
23
22
22
25
29
36
35
22
Inserting the batteries
13
Press in and downward
on the arrow to remove
the battery cover.
2
I
nsert two AA size batteries
for the remote control,
making sure their polarities
match the and marks
inside the battery
compartment.
Insert the side tabs of
the battery cover into
their slots and press the
cover in until it is
properly seated.
BACKLIGHT button
POWER buttons
(ON/OFF)
LASER POINTER/
MENU button
KEYSTONE/BLACK
SCREEN button
RIGHT-CLICK/
ENTER button
IrCOM buttonINPUT button
AUTO SYNC button
FREEZE button
RESIZE buttonENLARGE button
GAMMA buttonTOOLS button
MOUSE/
ADJUSTMENT
switch
MOUSE/
ADJUSTMENT
buttons (∂/ƒ/ß/©)
Battery
cover
Battery
compartment
Battery
cover
Rear View
LEFT-CLICK/
UNDO
button
22
19
Top View
5
Remote control
signal transmitter
Laser
pointer
window
MUTE button
VOLUME buttons
(/)
E-9
Setup & Connections
Setup & Connections
E-10
Setup & Connections
Power cord
QACCU5013CEZZ
Computer cable
QCNW-5304CEZZ
Mouse control cable
for Mac
QCNW-5114CEZZ
Computer audio cable
QCNW-4870CEZZ
Mouse control
cable for IBM PS/2
QCNW-5113CEZZ
Remote control
RRMCG1530CESA
Two AA size batteries
DIN-D-sub RS-232C cable
QCNW-5288CEZZ
CD-ROM
UDSKA0009CE01
Projector operation manual
TINS-6786CEZZ
Projector quick reference
TINS-6787CEZZ
Sharp Advanced Presentation
Software operation manual
TINS-6888CEZZ
Sharp Advanced Presentation
Software quick reference
TINS-6788CEZZ
IrDA driver installation
instruction sheet
TCAUZ3046CEZZ
Supplied Accessories
Mouse control
serial cable
QCNW-5112CEZZ
Remote mouse receiver
RUNTK0661CEZZ
Carrying bag
GCASN0003CESA
Lens cap
GCOVH1308CESA
Lens cap strap
UBNDT0012CEZZ
E-11
Setup & Connections
Connecting the Power Cord
Plug the supplied power cord into the AC socket on the back of the projector.
Connecting the Projector to a Computer
You can connect your projector to a computer for projection of full color computer images.
Power cord
QACCU5013CEZZ
Computer audio cable
QCNW-4870CEZZ
Computer cable
QCNW-5304CEZZ
Connecting the Projector
To a computer using the standard 15-pin (VGA) input
1 Connect one end of the supplied computer cable to
the INPUT 1 port on the projector.
2 Connect the other end to the Monitor output port on the
computer. Secure the connectors by tightening the
thumb screws.
3 To use the built-in audio system, connect one end of
the supplied computer audio cable to the AUDIO INPUT
terminal on the projector.
4 Connect the other end to the Audio output terminal on
the computer.
CAUTION
• Before connecting, be sure to turn both the projector and the
computer off. After making all connections, turn the projector
on first. The computer should always be turned on last.
• Please read the computer’s operation manual carefully.
• Refer to pages 55 and 56 “Input Signals (Recommended
Timing)” for a list of computer signals compatible with the
projector. Use with computer signals other than those listed may
cause some of the functions not to work.
When connecting this projector to a computer, select
“Computer/RGB” for “Signal Type” on the GUI menu. (See
page 40.)
• A Macintosh adaptor may be required for use with some
Macintosh computers. Contact your nearest Authorized Sharp
Industrial LCD Products Dealer or Service Center.
E-12
Setup & Connections
Connecting other compatible computers
Connecting the Projector
When connecting the projector to a compatible computer other than an IBM-PC (VGA/SVGA/XGA/SXGA/UXGA)
or Macintosh (i.e. Workstation), a separate cable may be needed. Please contact your dealer for more information.
When connecting this projector to a computer, select “Computer/RGB” for “Signal Type” on the GUI menu. (See page 40.)
• Connecting computers other than the recommended types may result in damage to the projector, the computer, or both.
• AUDIO INPUT accepts INPUT 1 or 2 port input.
“Plug and Play” function
• This projector is compatible with VESA-standard DDC 1/DDC 2B when connecting to a 15-pin analog terminal
and VESA-standard DDC 2B when connecting to a 20-pin digital terminal. The projector and a VESA DDC
compatible computer will communicate their setting requirements, allowing for quick and easy setup.
• Before using the “Plug and Play” function, be sure to turn on the projector first and the connected computer last.
• The DDC, Plug and Play function of this projector operates only when used in conjunction with a VESA DDC compatible
computer.
To a computer using the direct digital input (PanelLink™)
Computer audio cable
QCNW-4870CEZZ
1 Connect one end of the digital cable to the INPUT 2
port on the projector.
2 Connect the other end to the corresponding termi-
nal on a computer.
3 To use the built-in audio system, connect one and
of the supplied computer audio cable to AUDIO
INPUT terminal on the projector.
Connect the other end to the Audio output terminal
on the computer.
Digital cable (sold separately)
2 To digital output terminal
Computer audio cable (3.5 mm stereo minijack cable)
Computer
To audio output terminal
E-13
Setup & Connections
1 Connect the yellow RCA connectors to the corresponding
yellow VIDEO INPUT terminal on the projector and the Video
output terminal on the video source.
2 To use the built-in audio system, connect the red and white
RCA connectors to the corresponding red and white AUDIO
INPUT terminals on the projector and the Audio output
terminals on the video source.
The S-VIDEO INPUT terminal uses a video signal system in which
the picture is separated into a color and a luminance signal to
realize a higher-quality image.
• For higher quality video, you may use the S-VIDEO INPUT terminal on
the projector. S-video cable is sold separately.
• If your video equipment does not have an S-video output terminal, use
the Composite video output terminal.
Connecting the Projector
Connecting the Projector to Video Equipment
You can connect your projector to a VCR, laser disc player, DVD player, DTV decoder and other audiovisual
equipment.
CAUTION
• Always turn off the projector while connecting to video equipment, in order to protect both the projector and the equipment
being connected.
To a video source (VCR, laser disc player, DTV decoder or DVD player) using the standard video input
VCR
or
Laser disc player
1 Video cable (sold separately)
S-video cable (sold separately)
2 Audio cable (sold separately)
To S-video output terminal
To video output terminal
To audio output terminals
To a DTV decoder or DVD player
Computer audio cable
QCNW-4870CEZZ
1 Connect one end of the HD-15-RGB cable to the INPUT 1
port on the projector.
2 Connect the other end to the corresponding terminals on the
video source.
3 To use the built-in audio system, connect one end of the
supplied computer audio cable to AUDIO INPUT terminal on
the projector.
Connect the other end to the Audio output terminal on the
video source.
Select “Computer/RGB” or “Component” for “Signal Type” on
the GUI menu, depending on the video source.
HD-15-RGB cable (sold separately)
2 To video input terminals
To audio output terminal
Computer audio cable (3.5 mm stereo minijack cable)
DTV decoder
or
DVD player
E-14
Setup & Connections
Connecting RS-232C Port
When the RS-232C port on the projector is connected to a computer with an RS-232C cable (cross type, sold
separately), the computer can be used to control the projector and check the status of the projector. See pages 53
and 54 for details.
Connecting the Projector
DIN-D-sub RS-232C
cable
QCNW-5288CEZZ
Computer audio cable
QCNW-4870CEZZ
Computer cable
QCNW-5304CEZZ
1 Connect the supplied DIN-D-sub RS-232C cable to the RS-232C port on the projector.
2 Connect a RS-232C cable (sold separately) to the other end of DIN-D-sub RS-232C cable and to the serial
port on the computer.
CAUTION
• Do not connect or remove RS-232C cable to or from the computer while it is on. This may damage your computer.
• The wireless mouse or RS-232C function may not operate if your computer port is not correctly set up. Please refer to the
operation manual of the computer for details on setting up/installing the correct mouse driver.
• The arrows (→, ↔) indicate the direction of the signals.
2 RS-232C cable
(cross type, sold separately)
1 DIN-D-sub
RS-232C cable
E-15
Setup & Connections
Connecting the Remote Mouse Receiver
• You can use the remote control as a remote mouse.
• When the RS-232C port on the projector is connected to a computer with
an RS-232C cable (cross type, sold separately), the computer can be
used to control the projector and check the status of the projector. See
pages 53 and 54 for details.
IBM or IBM compatible PC
Remote mouse
receiver
RUNTK0661CEZZ
Mouse control
serial cable
QCNW-5112CEZZ
Mouse control cable
for IBM PS/2
QCNW-5113CEZZ
or
Mouse control
serial cable
QCNW-5112CEZZ
Mouse control cable
for Mac
QCNW-5114CEZZ
Remote mouse receiver
Use this terminal to con-
nect the supplied
mouse control cable to
the remote mouse
receiver.
IBM PC/AT IBM PS/2
1 Connect one end of the supplied mouse control cable to the corresponding terminal on the PC.
2 Connect the other end to the remote mouse receiver.
Macintosh
1 Connect the mouse control serial cable to the remote mouse receiver.
2 Connect the mouse control cable for Mac to the Mac ADB port on the Mac.
3 Connect the other end of the mouse control cable for Mac to the mouse control serial cable.
Connecting the Projector
CAUTION
• Do not connect or remove the mouse control cables to or from the computer while it is on. This may damage your computer.
• The wireless mouse functions can operate computers compatible with IBM PS/2, serial (RS-232C) or Apple ADB type
mouse systems.
E-16
Operation
Operation
Basic Operations
1 Make the necessary connections before pro-
ceeding. Connect the power cord to a wall outlet.
The POWER indicator lights up red and the
projector enters standby mode.
2 Press Power ON.
• The flashing green LAMP REPLACEMENT indicator shows
that the lamp is warming up. Wait until the indicator stops
flashing before operating the projector.
• If the power is turned off and then immediately turned on
again, it may take a short while before the lamp turns on.
• After the projector is unpacked and turned on for the first
time, a slight odor may be emitted from the exhaust vent.
This odor will soon disappear with use.
2
When the power is on, the LAMP REPLACEMENT
indicator lights indicating the status of the lamp.
Green: Lamp is ready.
Flashing green: Warming up.
Red: Change the lamp.
E-17
Operation
Basic Operations
4
3
3 Rotate the focus ring until the image on the screen
becomes clear.
4 Rotate the zoom ring. The image can be adjusted
to the desired size within the zoom range.
6
7
8
5
5 Press INPUT to select the desired input mode.
Press INPUT again to change the mode.
EXAMPLE
INPUT 1 Mode
INPUT 2 Mode
VIDEO Mode
f
f
• When no signal is being received, “NO SIGNAL” will be
displayed. When a signal that the projector is not preset
to receive is being received, “NOT REG.” will be displayed.
6 Press VOLUME / to adjust the volume.
7 Press MUTE to temporarily turn off the sound.
Press MUTE again to turn the sound back on.
8 Press POWER OFF.
Press POWER OFF again while the message is
displayed.
5
6
7
8
• If you accidentally pressed POWER OFF and do not want
to turn off the power, wait until the power off screen
disappears.
• When POWER OFF is pressed twice, the POWER indicator
will light up red and the cooling fan will run for about 90
seconds. The projector will then enter standby mode.
• Wait until the cooling fan stops before disconnecting the
power cord.
• The power can be turned on again by pressing POWER
ON. When the power is turned on, the POWER indicator
and the LAMP REPLACEMENT indicator light green.
E-18
Operation
The formula for picture size and projection distance
y
1
= (0.0533x 0.0552) 3.28
y
2
= (0.0444x 0.0533) 3.28
y
3
= 0.323x
• There is an error of 3% in the formula above.
Width
261
174
131
116
92
87
80
73
63
52
35
Height
147
98
74
65
52
49
45
41
35
29
20
Diag.
300
200
150
133
106
100
92
84
72
60
40
35
1
⁄32 (89.0 cm)
23
11
⁄32 (59.3 cm)
17
33
⁄64 (44.5 cm)
11
11
⁄16 (29.7 cm)
9
49
⁄64 (24.8 cm)
8
25
⁄64 (21.3 cm)
7
1
⁄64 (17.8 cm)
4
11
⁄16 (11.9 cm)
Distance from the lens center to the
bottom of the image (H)
Position the projector perpendicular to the screen with all feet flat and level to achieve an optimal image.
Move the projector forward or backward if the edges of the image are distorted.
• The projector lens should be centered in the middle of the screen. If the lens center is not perpendicular to the screen, the image will be
distorted, making viewing difficult.
• Position the screen so that it is not in direct sunlight or room light. Light falling directly onto the screen washes out colors, making viewing
difficult. Close the curtains and dim the lights when setting up the screen in a sunny or bright room.
• A polarizing screen cannot be used with this projector.
Place the projector at the required distance from the screen according
to the desired picture size (see the table below).
Standard Setup (Front Projection)
H
L
X
Maximum
—
32 (9.8 m)
23 11 (7.3 m)
15 11 (4.9 m)
13 4 (4.1 m)
11 5 (3.5 m)
9 6 (2.9 m)
6 3 (1.9 m)
Minimum
40 (12.2 m)
26 8 (8.1 m)
19 11 (6.1 m)
13 3 (4.0 m)
11 1 (3.4 m)
9 6 (2.9 m)
7 10 (2.4 m)
5 2 (1.6 m)
Projection distance
Picture size
The formula for picture size and projection distance
y
1
= (0.049x 0.0508) 3.28
y
2
= (0.0408x 0.049) 3.28
y
3
= 0.297x
• There is an error of 3% in the formula above.
x: Picture size (diag.) (inches)
y
1
: Maximum projection distance (feet)
y
2
: Minimum projection distance (feet)
y
3
: Distance from the lens center to the
bottom of the image (H) (inches)
NORMAL Mode
(4:3)
WIDE Mode
(16:9)
Diag.
300
200
150
100
84
72
60
40
Width
240
160
120
80
67
58
48
32
Height
180
120
90
60
50
43
36
24
38
9
⁄64 (96.9 cm)
25
7
⁄16 (64.6 cm)
19
5
⁄64 (48.4 cm)
16
29
⁄32 (43.0 cm)
13
31
⁄64 (34.2 cm)
12
23
⁄32 (32.3 cm)
11
45
⁄64 (29.7 cm)
10
11
⁄16 (27.1 cm)
9
5
⁄32 (23.3 cm)
7
5
⁄8 (19.4 cm)
5
3
⁄32 (12.9 cm)
Distance from the lens center to the
bottom of the image (H)
Maximum
—
34 9 (10.6 m)
26 (7.9 m)
23 1 (7.0 m)
18 4 (5.6 m)
17 4 (5.3 m)
15 11 (4.9 m)
14 6 (4.4 m)
12 5 (3.8 m)
10 4 (3.1 m)
6 10 (2.1 m)
Minimum
43 6 (13.3 m)
28 11 (8.8 m)
21 8 (6.6 m)
19 2 (5.9 m)
15 3 (4.7 m)
14 5 (4.4 m)
13 3 (4.0 m)
12 1 (3.7 m)
10 4 (3.1 m)
8 7 (2.6 m)
5 8 (1.7 m)
Projection distance
Picture size
x: Picture size (diag.) (inches)
y
1
: Maximum projection distance (feet)
y
2
: Minimum projection distance (feet)
y
3
: Distance from the lens center to the
bottom of the image (H) (inches)
Setting up the Screen
E-19
Operation
Press foot releases. Adjust height of projector
and remove hands from foot
releases.
Rotate feet to make minor
changes.
Using the Adjustment Feet
There are two front adjustment feet and a rear adjustment foot.
To lower the position of the picture, pull out the folded leg of the rear adjustment foot.
See the diagram shown below for using the front adjustment feet.
• The projector is adjustable up to approximately 5° from the standard position.
• When the height of the projector is adjusted, the image may become distorted (keystoned), depending on the relative positions of the
projector and the screen.
CAUTION
• Do not press the foot releases when the adjustment feet are extended without firmly holding the projector.
• Do not hold the lens when lifting or lowering the projector.
• When lowering the projector, be careful not to get your fingers caught in the area between the adjustment feet and the projector.
Digital Keystone Correction
1
2
3
Setting up the Screen
Projector
1, 5
3, 4
2
6
Remote control
Pressing
ƒƒ
ƒƒ
ƒ
in Step 2
Pressing
∂∂
∂∂
∂
in Step 2
g
44
44
4
33
33
3 Test Pattern
On-screen Display
When the image is distorted due to the projection angle,
the Digital Keystone Correction function allows you to
correct it.
(Slide the MOUSE/ADJUSTMENT switch
on the remote control to the ADJ. position.)
1 Press KEYSTONE.
2 Press ∂ to compress the upper part of the image.
Press ƒ to compress the lower part of the image.
3 Press ENTER to display a test pattern.
4 Press ENTER to clear the test pattern.
5 To exit, press KEYSTONE.
6 To reset, press UNDO.
• Straight lines or the edges of the displayed image may
become jagged.
MOUSE
ADJ.
E-20
Operation
Reversed Image Setup
Rear projection
• Place a translucent screen between the projector and
the audience.
• Use the projector’s menu system to reverse the
projected image. (See page 43 for use of this
function.)
Projection using a mirror
• Place a mirror (normal flat type) in front of the lens.
• Use the projector’s menu system to reverse the
projected image. (See page 43 for use of this
function.)
• The image reflected from the mirror is projected onto
the screen.
• Optimal image quality is produced with the projector positioned perpendicular to the screen with all feet flat and level.
CAUTION
• When using a mirror, be sure to carefully position both the projector and the mirror so the light does not shine into the eyes of
the audience.
Setting up the Screen
• It is recommended that you use the optional Sharp
ceiling-mount bracket for this installation.
• Before mounting the projector, contact your nearest
Authorized Sharp Industrial LCD Products Dealer or
Service Center to obtain the recommended ceiling-
mount bracket (sold separately). (AN-NV7T ceiling-
mount bracket, AN-TK201/202 extension tube for AN-
NV7T.)
• When the projector is in the inverted position, use the
upper edge of the screen as the base line.
• Use the projector’s menu system to select the
appropriate projection mode. (See page 43 for use
of this function.)
Ceiling-mount Setup
E-21
Operation
13(4 m)
30˚
30˚
120˚
MOUSE
ADJ.
MOUSE/ADJUSTMENT switch
(Remote control)
MOUSE
ADJ.
Controlling the Projector
Using the Wireless Mouse
Remote
mouse
receiver
Remote control
Using the Remote Control as a Wireless Mouse
Remote Control/Mouse Receiver Positioning
The remote control has the following three functions:
• Projector control
• Wireless mouse
• Laser pointer
• The remote control can be used to control the projector within the ranges shown below.
• The remote mouse receiver can be used with the remote control to control the mouse functions of a connected
computer within the ranges shown below.
• The signal from the remote control can be reflected off a screen for easy operation. However, the effective distance of the
signal may differ due to the screen material.
Wireless mouse
Laser pointer
Projector control
Operating the Wireless Mouse from the Remote Control
30˚
45˚
23 (7 m)
30˚
30˚
45˚
Remote control
Remote control
E-22
Operation
2
Be sure the supplied remote mouse receiver is connected to your computer.
Slide the MOUSE/ADJUSTMENT switch to MOUSE.
Effective buttons in MOUSE mode
Use as a Wireless Mouse
1
MOUSE
ADJ.
Use as a Laser pointer
Slide the MOUSE/ADJUSTMENT switch to MOUSE.
Press LASER POINTER (
) to activate the laser pointer.
When the button is released, the light automatically goes off.
• For safety, the laser pointer automatically goes off after 1 minute of continuous use. To turn it on,
release LASER POINTER ( ) and press again.
MOUSE
ADJ.
1
• The wireless mouse may not operate correctly if your computer serial port is not correctly set up. Refer
to the computer’s operation manual for details of setting up/installing the mouse driver.
• For one-button mouse systems, use either the LEFT-CLICK or RIGHT-CLICK button.
Using the remote control in a dark room
Press BACKLIGHT, and the buttons will light up. Green lights refer to mouse operations, and red
lights to projector adjustments.
Position of MOUSE/ADJUSTMENT switch
ON (RED)
MOUSE
LASER POINTER (GREEN)
BLACK SCREEN (GREEN)
RIGHT-CLICK (GREEN)
MOUSE (NOT LIT)
LEFT-CLICK (NOT LIT)
ADJ.
MENU (RED)
KEYSTONE (RED)
ENTER (RED)
ADJUSTMENT (NOT LIT)
UNDO (NOT LIT)
Button name
LASER POINTER/MENU
BLACK SCREEN/KEYSTONE
RIGHT-CLICK/ENTER
MOUSE/ADJUSTMENT
LEFT-CLICK/UNDO
POWER ON/OFF
VOLUME /
MUTE
Position of MOUSE/ADJUSTMENT switch
ON (RED)
MOUSE ADJ.
Button name
INPUT
IrCOM
FREEZE
AUTO SYNC
ENLARGE
RESIZE
TOOLS
GAMMA
LEFT-CLICK
RIGHT-CLICK
MOUSE
BLACK SCREEN
LASER
POINTER
Operating the Wireless Mouse from the Remote Control
E-23
Operation
Using the GUI (Graphical User Interface) Menu Screens
This projector has two sets of menu screens (INPUT/VIDEO) that allow you to adjust the image and various projector
settings. These menu screens can be operated from the projector or the remote control with the following buttons.
(GUI) On-screen Display
1
INPUT (COMPUTER/RGB) mode
1
VIDEO mode
4 (Slide the MOUSE/ADJUSTMENT switch
on the remote control to the ADJ. position.)
1 Press MENU to display the INPUT or VIDEO mode
menu bar.
2 Press ß/© to select an adjustment menu on the
menu bar.
3 Press ∂/ƒ to select a specific adjustment item.
4 To display a single adjustment item, press ENTER
after selecting the item. Only the menu bar and
the selected adjustment item will appear.
5 Press ß/© to adjust the item.
6 Press UNDO to return to the previous screen.
7 Press MENU to exit from the GUI.
• For details on items on the menu screen, see the tree charts
on the next page.
ß 2 ©ß 2 ©
ß 2 ©
ß 5 ©
MOUSE
ADJ.
∂
3
ƒ
∂
3
ƒ
ß 5 ©
ß 5 ©
4
6
2, 3, 5
1, 7
Projector Remote control
E-24
Operation
Items on the INPUT1 or INPUT2 Mode Menu Bar
Using the GUI (Graphical User Interface) Menu Screens
Items on the VIDEO Mode Menu Bar
Main menu
Sub menu
Main menu
Sub menu
ContrastPicture
Audio
3030
I/P Conversion
Options
Video System
Language English
PRJ Mode
Status
CeilingFront
CeilingRear
Deutsch
Español
Nederlands
Français
Italiano
Svenska
Português
Front
Rear
Background
Startup Image
Interlaced
Progressive
Auto
PAL (50 /60Hz)
SECAM
NTSC4.43
NTSC3.58
Sharp
Custom
Blue
None
Auto Power Off
Sharp
Custom
None
Lamp Timer
BLK SCRN Disp
OSD Display
[ON/OFF]
[ON/OFF]
[ON/OFF]
Bright 3030
Color 3030
Tint 3030
Sharp 3030
Red 3030
Blue 3030
Treble 3030
Bass 3030
Reset
Reset
1152864
1024864
1152882
1152870
Tint
Auto SyncFine Sync
Audio
3030
Color 3030
Clock 150150
150150
Bass
Options Lamp Timer
Language English
PRJ Mode
Status
CeilingFront
CeilingRear
Deutsch
Español
Nederlands
Français
Italiano
Svenska
Português
Front
Rear
Auto Sync Disp
BLK SCRN Disp
OSD Display
[ON/OFF]
[ON/OFF]
[ON/OFF]
[ON/OFF]
[ON/OFF]
Signal Type
Background
Sharp
Startup Image
Signal Info
Sharp
Custom
Custom
I/P Conversion
Interlaced
Progressive
Blue
None
Computer/RGB
Component
None
3030
Treble 3030
Reset
Phase 6060
H-Pos
V-Pos
Reset
Save Setting
Select Setting
1
2
•
•
7
Resolution
800600
640480
Vert Freq
75 Hz
72 Hz
Special Modes
6060
Sharp 3030
ContrastPicture 3030
Bright 3030
Red 3030
Blue
Reset
3030
1
2
•
•
7
Resolution
800600
640480
Vert Freq
75 Hz
72 Hz
Resolution
Hor Freq
Vert Freq
640480
37.5 kHz
72 Hz
Auto Power Off
• The resolution, vertical frequency and horizontal frequency figures displayed above are for example purposes only.
•“Color”, “Tint”, and “Sharp” appear only when Component input is selected in INPUT 1 mode.
• Only the items highlighted in the tree charts above can be adjusted.
• To adjust the items under the sub menu, press © after selecting the sub menu.
• The signal is set to COMPUTER/RGB, when inputting DIGITAL signal.
• The items displayed in gray cannot be adjusted.
E-25
Operation
The IrCOM function can transfer still images from a
computer or digital camera to the projector via infrared
(wireless) communication.
Sharp Advanced Presentation Software
• This function requires the supplied Sharp Advanced
Presentation Software (SAPS).
• Install the SAPS in the supplied CD-ROM on the
computer.
• See the operation manual of the software for
installation and operating instructions.
• Position the projector and the IrCOM transmitting
device within the range shown on the left.
• To avoid transmission errors or changes in the image, ensure
the following when setting up the projector and transmitting
device.
• The IrCOM sensors on both the projector and transmitting
device are protected from direct sunlight or strong
ambient light.
• The transmitting device has sufficient battery power.
• The projector and transmitting device are positioned
within the designated operating range.
• The IrCOM sensors on the projector and transmitting
device are correctly aligned.
• The distance between the projector and transmitting device
may have to be less than 4 (10 cm) depending on the
transmitting device.
• When using the digital still camera, set it to the image
transmission mode.
• Align the projector and transmitting device at the same
height and angle at a distance of 4 (10 cm) to 3 3 (1 meter)
with an unobstructed line of view.
(Slide the MOUSE/ADJUSTMENT switch
on the remote control to the ADJ. position.)
1 Press IrCOM to enter the IrCOM mode.
2 And then the On-screen Display changes as
shown on the left.
• If the On-screen Display does not change as shown on the
left, the projector may not be within the reception range
from the IrCOM transmitting device.
3 Press INPUT to exit the IrCOM mode.
Using IrCOM for Wireless Presentations
Projector
3
1, 2
Remote control
15˚
15˚
4 (10 cm)–3 3 (1 m)
15˚
15˚
PC
Digital camera
ff
ff
f
ff
ff
f
On-screen Display
MOUSE
ADJ.
E-26
Operation
Selecting the On-screen Display Language
4
2, 3
1, 5
Projector
(GUI) On-screen Display
English is the preset language for the On-screen
Display. It can be changed to English, German, Spanish,
Dutch, French, Italian, Swedish, Portuguese, Chinese,
Korean or Japanese.
(Slide the MOUSE/ADJUSTMENT switch
on the remote control to the ADJ. position.)
1 Press MENU.
2 Press ß/© to select “Language”.
3 Press ∂/ƒ to select the desired language .
4 Press ENTER to save the setting. The On-screen
Display is now programed to display in the
language selected.
5 To exit from the GUI, press MENU.
Selecting the Video Input System Mode (VIDEO mode only)
5
2, 3, 4
1, 6
Projector
The video input system mode is preset to “Auto”;
however, it can be changed to a specific system mode,
if the selected system mode is not compatible with the
connected audiovisual equipment.
(Slide the MOUSE/ADJUSTMENT switch
on the remote control to the ADJ. position.)
1 Press MENU.
2 Press ß/© to select “Options”.
3 Press ∂/ƒ to select “Video System”, and then
press ©.
4 Press ∂/ƒ to select the desired video system
mode.
5 Press ENTER to save the setting.
6 To exit from the GUI, press MENU.
• When the system mode is set to “Auto”, you may not receive
a clear picture due to signal differences. Should this occur,
switch to the video system you are viewing.
(GUI) On-screen Display
MOUSE
ADJ.
MOUSE
ADJ.
Remote control
Remote control
E-27
Operation
2, 3
1, 4
Picture Adjustments
You can adjust the projector’s picture to your prefer-
ences with the following picture settings.
Description of Adjustment Items
Projector
For less contrast
For less brightness
For less color intensity
Skin tones become purplish
For less sharpness
For weaker red
For weaker blue
Selected item
For more contrast
For more brightness
For more color intensity
Skin tones become greenish
For more sharpness
For stronger red
For stronger blue
ß button
© button
All image adjustment items are returned to the factory preset
settings.
Contrast
Bright
Color
Tint
Sharp
Red
Blue
Reset
(GUI) On-screen Display
(COMPUTER/RGB input in INPUT mode)
1
2
•“Color”, “Tint” and “Sharp” do not appear for COMPUTER/
RGB input in INPUT 1 mode.
(Slide the MOUSE/ADJUSTMENT switch
on the remote control to the ADJ. position.)
1 Press MENU. Menu bar and “Picture” menu
screen appear. GUI operation guide is also
displayed.
2 Press ∂/ƒ to select a specific adjustment item.
3 Press ß/© to move the mark of the selected
adjustment item to the desired setting.
4 To exit from the GUI, press MENU.
• To reset all adjustment items, select “Reset” on the “Picture”
menu screen and press ENTER.
• The adjustments can be stored separately in the “INPUT 1”,
“INPUT 2” and “VIDEO” modes.
• For COMPONENT input in INPUT 1 mode, “Sharp” is
adjustable only when a DVD player is connected.
• When adjusting the items under the “Picture” menu in
DIGITAL input, the changes affect both the picture being
viewed and the GUI menu screen.
MOUSE
ADJ.
Remote control
E-28
Operation
This projector’s audio is factory preset to standard
settings. However, you can adjust it to suit your own
preferences by adjusting the following audio settings.
(Slide the MOUSE/ADJUSTMENT switch
on the remote control to the ADJ. position.)
1 Press MENU. Menu bar and “Picture” menu
screen appear. GUI operation guide is also
displayed.
2 Press ß/© to select “Audio”.
3 Press ∂/ƒ to select a specific adjustment item.
4 Press ß/© to move the mark of the selected
adjustment item to the desired setting.
5 To exit from the GUI, press MENU.
• To reset all adjustment items, select “Reset” on the “Audio”
menu screen and press ENTER.
Description of Adjustment Items
2, 3, 4
1, 5
Projector
© buttonß buttonSelected item
2
3
(GUI) On-screen Display
Audio Adjustments
For weaker treble
For weaker bass
Treble
Bass
Reset
For stronger treble
For stronger bass
All audio adjustment items are returned to the factory preset
settings.
MOUSE
ADJ.
Remote control
E-29
Operation
Computer Image Adjustments
When displaying computer patterns which are very
detailed (tiling, vertical stripes, etc.), interference may
occur, causing flickering, vertical stripes, or contrast
irregularities in portions of the screen. Should this occur,
adjust “Clock”, “Phase”, “H-Pos” and “V-Pos” for
optimum computer image.
• Computer image adjustment can be made easily by
pressing AUTO SYNC (
). See the next page for details.
(GUI) On-Screen Display
2, 3, 4
1, 5
Projector
Clock
Phase
H-Pos
V-Pos
Description of Adjustment Items
(Select the desired computer input mode with INPUT.)
(Slide the MOUSE/ADJUSTMENT switch
on the remote control to the ADJ. position.)
1 Press MENU. Menu bar and “Picture” menu
screen appear. GUI operation guide is also
displayed.
2 Press ß/© to select “Fine Sync”.
3 Press ∂/ƒ to select a specific adjustment item.
4 Press ß/© to move the mark of the selected
adjustment item to the desired setting.
5 To exit from the GUI, press MENU.
• To reset all adjustment items, select “Reset” on the “Fine
Sync” menu screen and press ENTER.
• When inputting DIGITAL signal, the projector automatically
selects the settings for the best possible picture. You do
not need to adjust any settings.
2
3
DescriptionSelected item
MOUSE
ADJ.
Remote control
Adjusts vertical noise.
Adjusts horizontal noise (similar to tracking on your VCR).
Centers the on-screen image by moving it to the left or right.
Centers the on-screen image by moving it up or down.
E-30
Operation
Auto Sync Adjustment
• Used to automatically adjust a computer image.
• Auto Sync adjustment can be made manually by
pressing AUTO SYNC, or automatically by setting
“Auto Sync” to “ON” in the projector’s GUI menu.
When “Auto Sync” is set to “ON”:
• The sync adjustment is automatically made each time
the projector is turned on while connected to a com-
puter or the input selection is changed.
• The Auto Sync adjustment setting previously made is
cleared when the projector’s setting is changed.
(Slide the MOUSE/ADJUSTMENT switch
on the remote control to the ADJ. position.)
1 Press MENU.
2 Press ß/© to select “Fine Sync”.
3 Press ∂/ƒ to select “Auto Sync”.
4 Press ß/© to select “ON”.
5 To exit from the GUI, press MENU.
• Automatic adjustments can be made by pressing AUTO
SYNC.
• When the optimum image cannot be achieved with Auto
Sync adjustment, use manual adjustments. (See the
previous page.)
• When inputting DIGITAL signal, the projector automatically
selects the settings for the best possible picture. You do
not need to adjust any settings.
During Auto Sync adjustment, the On-screen Display
changes as shown on the left.
• Auto Sync adjustment may take some time to complete,
depending on the image of the computer connected to the
projector.
(GUI) On-screen Display
Computer Image Adjustments
2, 3, 4
1, 5
Projector
g
s
f
On-screen Display
AUTO SYNC
button
MOUSE
ADJ.
(GUI) On-screen Display
Remote control
Auto Sync Display Function
Normally, an image is not superimposed during Auto
Sync adjustment. You can, however, choose to
superimpose a background image during Auto Sync
adjustment.
(Slide the MOUSE/ADJUSTMENT switch
on the remote control to the ADJ. position.)
1 Press MENU.
2 Press ß /© to select “Options”.
3 Press ∂/ƒ to select “Auto Sync Disp”.
4 Press ß /© to select “ ” to superimpose a
background image or “ ” to remove the
background image during Auto Sync adjustment.
5 To exit from the GUI, press MENU.
MOUSE
ADJ.
E-31
Operation
Saving and Selecting Adjustment Settings
This projector allows you to store up to seven adjustment
settings for use with various computers. Once these
settings are stored, they can be easily selected each
time you connect the computer to the projector.
Saving the adjustment setting
(Slide the MOUSE/ADJUSTMENT switch
on the remote control to the ADJ. position.)
1 Press MENU.
2 Press ß/© to select “Fine Sync”.
3 Press ∂/ƒ to select “Save Setting”, and then press
©.
4 Press ∂/ƒ to select the desired memory location of
the setting.
5 Press ENTER to save the setting.
6 To exit from the GUI, press MENU.
Selecting a saved setting
(Slide the MOUSE/ADJUSTMENT switch
on the remote control to the ADJ. position.)
1 Press MENU.
2 Press ß/© to select “Fine Sync”.
3 Press ∂/ƒ to select “Select Setting”, and then press
©.
4 Press ∂/ƒ to select the desired memory setting.
5 Press ENTER to select the setting.
6 To exit from the GUI, press MENU.
• If the memory position has not been set, the resolution and
frequency will not be displayed.
• When selecting the stored adjustment setting with “Select
Setting”, the computer system should match the stored
setting.
• This function cannot be used when inputting DIGITAL signal.
(GUI) On-screen Display
2
3
4
Computer Image Adjustments
MOUSE
ADJ.
MOUSE
ADJ.
5
2, 3, 4
1, 6
Projector Remote control
E-32
Operation
Computer Image Adjustments
Special Mode Adjustment
Ordinarily, the type of input signal is detected and the
correct resolution mode is automatically selected.
However, for some signals, “Special Modes” on the “Fine
Sync” menu screen may need to be changed to match
the computer display mode.
(Slide the MOUSE/ADJUSTMENT switch on
the remote control to the ADJ. position.)
1 Press MENU.
2 Press ß/© to select “Fine Sync”.
3 Press ∂/ƒ to select “Special Modes”, and then
press ©.
4 Press ∂/ƒ to select the optimal resolution mode.
5 Press ENTER to save the setting.
6 To exit from the GUI, press MENU.
• Avoid displaying computer patterns which repeat every
other line (horizontal stripes). (Flickering may occur, making
the image hard to see.)
• When inputting DTV 480P signals, select “480P” in step
4
above.
5
2, 3, 4
1, 6
Projector
(GUI) On-screen Display
Remote control
MOUSE
ADJ.
E-33
Useful Features
Useful Features
Freeze Function
This function allows you to instantly freeze a moving
image. This is useful when you want to display a still
image from a computer or video, giving you more time
to explain the image to the audience.
You can also use this function to display a still image
from a computer while you make preparations for the
next computer images to be presented.
1 Press FREEZE to freeze the image.
2 Press FREEZE again to return to the moving
image.
Projector
1, 2
On-screen Display
Remote control
E-34
Useful Features
Digital Image Magnification (ENLARGE)
Projector
1
3
2
This function allows you to magnify a specific portion of
an image. This is useful when you want to display a
detailed portion of the image.
(Slide the MOUSE/ADJUSTMENT switch
on the remote control to the ADJ.)
1 Press ENLARGE. Each time ENLARGE is
pressed, the image will be magnified.
2 When the image is magnified, you can pan and
scan around the image by using ∂/ƒ/ß/©.
• Each time ENLARGE is pressed, image magnification
toggles as shown below.
1 2 3 4 6 8
• If the input signal is changed during digital image
magnification, the image will return to 1. The input signal
is changed
(a) when INPUT is pressed,
(b) when the input signal is interrupted, or
(c) when the input resolution and refresh rate changes.
3 To return to 1, press UNDO.
MOUSE
ADJ.
sg
On-screen Display
Remote control
E-35
Useful Features
Gamma Correction
Projector
• Gamma is an image quality enhancement function
that offers a richer image by brightening the darker
portions of the image without altering the brightness
of the brighter portions.
• Four gamma settings are available to allow for
differences in the images displayed and in the
brightness of the room.
• When you are displaying images with frequent, dark
scenes, such as a film or concert, or when you are
displaying images in a bright room, this feature makes
the dark scenes easier to see and gives the impres-
sion of greater depth in the image.
Gamma Modes
Gamma modeSelected Mode
On-screen Display
ss s
STANDARD
GAMMA 1
GAMMA 2
CUSTOM
Remote control
1
2
STANDARD
GAMMA 1
GAMMA 2
CUSTOM
Standard picture without gamma correction.
Brightens darker portions of image for more
enhanced presentations.
Gives greater depth to darker portions of image
for a more exciting theater experience.
Allows you to adjust gamma value using Sharp
Advanced Presentation Software.
MOUSE
ADJ.
(Slide the MOUSE/ADJUSTMENT switch
on the remote control to the ADJ. position.)
1 Press GAMMA. Each time GAMMA is pressed,
the gamma level toggles as shown on the left.
2 To return to the standard image, press UNDO
while “GAMMA” is displayed on the screen.
E-36
Useful Features
Selecting the Picture Display Mode
g
NORMAL WIDE DOT BY DOT DOT BY DOT (WIDE)
For DTV decoder RGB signal in 4:3 aspect ratio.
For COMPUTER/RGB signal without 4:3 aspect ratio.
gg
For DTV decoder RGB signal in 16:9 aspect ratio.
gg
MODE
INPUT SIGNAL
4:3
480 P
16:9
720 P
SXGA
DTV COMPUTER
NORMAL
WIDE
DOT BY DOT
DOT BY DOT
(
WIDE
)
1024 768
1024 576
640 480
853 480
1024 576
—
1280 720
—
960 768
1024 768
1280 1024
—
Projector
EXAMPLE
Remote control
RESIZE
button
This function allows you to modify or customize the picture display mode to enhance the input image. Depending
on the input signal, you can choose NORMAL, WIDE, DOT BY DOT, DOT BY DOT (WIDE), or FIT TO SCREEN
image.
• Each time RESIZE is pressed, the picture mode changes as shown below.
•“FIT TO SCREEN” is displayed only when SXGA signals that are not in 4:3 aspect ratio are input.
• DOT BY DOT mode displays images in their native resolution and not expanded to fit the LCD resolution.
• To return to NORMAL mode, press UNDO while “RESIZE” is displayed on the screen.
E-37
Useful Features
Black Screen Function
This function can be used to superimpose a black
screen over the projected image.
Blacking out the Projected Image
Press BLACK SCREEN. “BLACK SCREEN” is dis-
played on the screen. To return to the original projected
image, press BLACK SCREEN again.
• To use the remote control to operate this
function, slide the MOUSE/ADJUSTMENT switch to the
MOUSE position before pressing BLACK SCREEN.
Turning off the On-screen Display
The On-screen Display (“BLACK SCREEN”) that
appears during black screen can be turned off. When
“BLK SCRN Disp” is set to “ ” in the GUI menu, “BLACK
SCREEN” will not be displayed during function.
(Slide the MOUSE/ADJUSTMENT switch
on the remote control to the ADJ. position.)
1 Press MENU.
2 Press ß /© to select “Options”.
3 Press ∂/ƒ to select “BLK SCRN Disp”.
4 Press ß/© to select “ ” to turn on or “ ” to
turn off the function.
5 To exit from the GUI, press MENU.
Projector
(GUI) On-screen Display
Projected Image
BLACK
SCREEN
button
This function allows you to turn off the on-screen
messages that appear during “input select” and the
“IrCOM” function. Once “OSD Display” is set to “ ” in
the GUI menu, the on-screen messages will not appear
when INPUT and IrCOM are pressed.
(Slide the MOUSE/ADJUSTMENT switch
on the remote control to the ADJ. position.)
1 Press MENU.
2 Press ß/© to select “Options”.
3 Press ∂/ƒ to select “OSD Display”.
4 Press ß/© to select “ ” to turn on or “ ” to turn
off the On-screen Display.
5 To exit from the GUI, press MENU.
On-screen Display Override Function
2, 3, 4
1, 5
Projector
(GUI) On-screen Display
MOUSE
ADJ.
MOUSE
ADJ.
MOUSE
ADJ.
sg
Remote control
Remote control
2, 3, 4
1, 5
E-38
Useful Features
When no input signal is detected for more than 15
minutes, the projector will automatically shut off.
(Slide the MOUSE/ADJUSTMENT switch
on the remote control to the ADJ. position.)
1 Press MENU.
2 Press ß/© to select “Options”.
3 Press ∂/ƒ to select “Auto Power Off”.
4 Press ß/© to select the “ ” or “ ”.
5 Press ENTER to save the setting.
6 To exit from the GUI, press MENU.
(GUI) On-screen Display
Automatic Power Shutoff Function
5
2, 3, 4
1, 6
Projector Remote control
MOUSE
ADJ.
On-screen Display
• The on-screen message on the left will appear five minutes
before the power is automatically turned off.
E-39
Useful Features
I/P Conversion
This function allows you to select either an interlaced
display or a progressive display of a video signal. The
progressive display projects a smoother video image.
(Slide the MOUSE/ADJUSTMENT switch
on the remote control to the ADJ. position.)
1 Press MENU.
2 Press ß/© to select “Options”.
3 Press ∂/ƒ to select “I/P Conversion”, and then
press ©.
4 Press ∂/ƒ to select “Interlaced” or “Progressive”.
5 Press ENTER to save the setting.
6 To exit from the GUI, press MENU.
Interlaced mode
Interlaced mode creates a single image throught the activation
of scanning lines in two fields. Use this mode when projecting
moving images.
Progressive mode
Progressive mode creates a single image using all available
scanning lines, thereby eliminating the flicker and stripes that
result from interlaced source images projected as still images.
5
2, 3, 4
1, 6
Projector
(GUI) On-screen Display
MOUSE
ADJ.
Remote control
Checking the Lamp Usage Time
This function allows you to check the accumulated lamp
usage time.
(Slide the MOUSE/ADJUSTMENT switch
on the remote control to the ADJ. position.)
1 Press MENU.
2 Press ß/© to select “Options”. The lamp usage
time will be displayed.
• It is recommended that the lamp be replaced after
approximately 1,400 hours of usage. See pages 48 and 49
for lamp replacement.
2
1
Projector
(GUI) On-screen Display
MOUSE
ADJ.
Remote control
E-40
Useful Features
This function allows you to select the input signal type
(COMPUTER/RGB or COMPONENT) for INPUT 1 port.
(Slide the MOUSE/ADJUSTMENT switch
on the remote control to the ADJ. position.)
1 Press MENU.
2 Press ß/© to select “Options”.
3 Press ∂/ƒ to select “Signal Type”, and then
press ©.
4 Press ∂/ƒ to select “Computer/RGB” or
“Component”.
5 Press ENTER to save the setting.
6 To exit from the GUI, press MENU.
Selecting the Signal Type
MOUSE
ADJ.
5
2, 3, 4
1, 6
Projector
(GUI) On-screen Display
(Slide the MOUSE/ADJUSTMENT switch
on the remote control to the ADJ. position.)
1 Press MENU.
2 Press ß/© to select “Options”.
3 Press ∂/ƒ to select “Signal Info” to display the
current input signal.
4 To exit from the GUI, press MENU.
• In VIDEO mode, the resolution and frequency settings will
not be displayed.
This function allows you to check the current input signal
information.
2, 3
1, 4
Projector
Checking the Input Signal
(GUI) On-screen Display
MOUSE
ADJ.
Remote control
Remote control
E-41
Useful Features
(GUI) On-screen Display
Setting a Background Image
This function allows you to select the image displayed
when no signal is being sent to the projector.
Description of Background Images
(Slide the MOUSE/ADJUSTMENT switch
on the remote control to the ADJ. position.)
1 Press MENU.
2 Press ß/© to select “Options”.
3 Press ∂/ƒ to select “Background”, and then press
©.
4 Press ∂/ƒ to select the background image you want
to display on the screen.
5 Press ENTER to save the setting.
6 To exit from the GUI, press MENU.
• By selecting “Custom”, the projector can display a custom
image (i.e. your company logo) as the background image.
Custom image must be 256-color BMP file with a picture
size of 1,024 768 or lower. Please see the Sharp
Advanced Presentation Software operation manual for how
to save (or change) a custom image.
Selected item
Sharp
Custom
Blue
None
Background image
SHARP default image
User customized image (i.e. company logo)
Blue screen
Black screen
5
2, 3, 4
1, 6
Projector
MOUSE
ADJ.
Remote control
E-42
Useful Features
• This function allows you to specify the image to be
displayed upon the projector’s startup.
• A custom image (i.e. your company logo) can be
loaded on the projector via IrCOM or an RS-232C
cable. See pages 14 and 25 in this operation manual,
and also the supplied Sharp Advanced Presentation
Software operation manual for detailed instructions.
Description of Startup Images
(Slide the MOUSE/ADJUSTMENT switch
on the remote control to the ADJ. position.)
1 Press MENU.
2 Press ß/© to select “Options”.
3 Press ∂/ƒ to select “Startup Image”, and then press
©.
4 Press ∂/ƒ to select the startup image you want to
display on the screen.
5 Press ENTER to save the setting.
6 To exit from the GUI, press MENU.
• By selecting “Custom”, the projector can display a custom
image (i.e. your company logo) as the startup image.
Custom image must be 256-color BMP file with a picture
size of 1,024 768 or lower. Please see the Sharp
Advanced Presentation Software operation manual for how
to save (or change) a custom image.
Selected item
Sharp
Custom
None
Startup image
SHARP default image
User customized image (i.e. company logo)
Black screen
5
2, 3, 4
1, 6
Projector
(GUI) On-screen Display
MOUSE
ADJ.
Remote control
Selecting a Startup Image
E-43
Useful Features
Reverse/Invert Image Function
This projector is equipped with a reverse/invert image
function which allows you to reverse or invert the pro-
jected image for various applications.
Description of Projected Images
(GUI) On-screen Display
Selected item
Front
CeilingFront
Rear
CeilingRear
Projected image
Normal image
Inverted image
Reversed image
Reversed and inverted image
(Slide the MOUSE/ADJUSTMENT switch
on the remote control to the ADJ. position.)
1 Press MENU.
2 Press ß/© to select “PRJ Mode”.
3 Press ∂/ƒ to select the desired projection mode.
4 Press ENTER to save the setting.
5 To exit from the GUI, press MENU.
Projector
When Selecting “Front”
When Selecting “CeilingFront”
When Selecting “Rear”
When Selecting “CeilingRear”
MOUSE
ADJ.
• This function is used for the reversed image and ceiling-
mount setups. See page 20 for these setups.
Remote control
4
2, 3
1, 5
E-44
Useful Features
Using the Presentation Tools
Red Green Blue Yellow Orange White Black
When selecting Sharp default image
Menu Window
1
3
2, 4
This projector is equipped with presentation tools. These
will help you emphasize keypoints within your
presentation.
(Slide the MOUSE/ADJUSTMENT switch
on the remote control to the ADJ. position.)
1 Press TOOLS to display the presentation tools
menu window on the screen.
2 Press ∂/ƒ/ß/© to select the desired tool and
color.
3 Press ENTER to select it.
4 Once the tool is displayed on the screen, press
∂/ƒ/ß/© to move it around the screen.
5 Press ENTER to stamp the tool on the screen.
6 Use UNDO to individually delete tools stamped
on the screen.
• You can stamp each tool as many times as you want on the
screen.
• To clear all the stamped presentation tools on the screen,
press ∂/ƒ/ß/© to select “
” and ENTER.
MOUSE
ADJ.
Displaying the break time
(Slide the MOUSE/ADJUSTMENT switch
on the remote control to the ADJ. position.)
1 Press TOOLS to display the presentation tools
menu window on the screen.
2 Press ∂/ƒ/ß/© to select “ ” in the menu
window.
3 Press ENTER to start counting down the break
time.
4 Press ∂ to increase or ƒ to decrease the break
time.
• The break time is displayed against the background image
selected in “Selecting a Startup Image”. (See page 42.)
MOUSE
ADJ.
1
6
3, 5
2, 4
On-screen Display
Projector
Projector
Remote control
Remote control
E-45
Useful Features
Status Function
This function can be used to display all the adjusted
settings on the screen simultaneously.
(Slide the MOUSE/ADJUSTMENT switch
on the remote control to the ADJ. position.)
1 Press MENU.
2 Press ß/© to select “Status”.
3 Press ENTER to display all the adjusted settings.
4 To exit from the GUI, press MENU.
3
2
1, 4
Projector
(GUI) On-screen Display
MOUSE
ADJ.
2
3
Remote control
E-46
Maintenance &
Troubleshooting
Maintenance &
Troubleshooting
E-47
Maintenance &
Troubleshooting
Problem
• Blocked air intake.
• Cooling fan breakdown.
• Internal circuit failure.
• Burnt-out lamp.
• Lamp circuit failure.
Lamp/Maintenance Indicators
Maintenance Indicator
The internal
temperature is
abnormally high.
The lamp does
not light up.
TEMPERATURE
WARNING indicator
LAMP REPLACE-
MENT indicator
Condition Possible Solution
• Relocate the projector to an area with
proper ventilation.
• Take the projector to your nearest
Authorized Sharp Industrial LCD Products
Dealer or Service Center for repair.
• Carefully replace the lamp. (See pages 48
and 49.)
• Take the projector to your nearest
Authorized Sharp Industrial LCD Products
Dealer or Service Center for repair.
Maintenance Indicators
• The warning lights on the projector indicate problems
inside the projector.
• There are two warning lights: a TEMPERATURE
WARNING indicator which warns that the projector is
too hot, and a LAMP REPLACEMENT indicator which
lets you know when to change the lamp.
• If a problem occurs, either the TEMPERATURE
WARNING indicator or the LAMP REPLACEMENT
indicator will light up red. After turning off the power,
follow the procedures given below.
TEMPERATURE
WARNING
indicator
LAMP
REPLACEMENT
indicator
• If the TEMPERATURE WARNING indicator lights up, follow the above possible solutions and then wait until the projector has
cooled down completely before turning the power back on. (At least 5 minutes.)
• If the power is turned off and then turned on again, as during a brief rest, the LAMP REPLACEMENT indicator may be
triggered, preventing the power from going on. Should this occur, take the power cord out of the wall outlet and put it back
in again.
Lamp
The lamp in this projector operates for approximately 1,500 cumulative hours, depending on the usage environ-
ment. It is recommended that the lamp be replaced after 1,400 cumulative hours of use or when you notice a
significant deterioration of the picture and color quality. The lamp usage time can be checked with the On-screen
Display (see page 39).
CAUTION
• Intense light hazard. Do not attempt to look into the aperture and lens while the projector is operating.
• As the usage environment can vary significantly, the projector lamp may not operate for 1,500 hours.
E-48
Maintenance &
Troubleshooting
Replacing the Projection Lamp
46
Remove the lamp
cage.
5
Replace the lamp cage
(after changing the lamp).
1 3
Turn off the power.
2
Disconnect the power
cord.
Unplug the power cord from the
AC socket.
Slide the lamp cage
cover out.
Slide the lamp cage
cover in.
Slide the lamp cage cover in the
direction of the arrow. Then
fasten the user service screw.
Remove the securing screws
from the lamp cage. Hold the
lamp cage by the handle and
pull it towards you.
Turn over the projector and un-
fasten the user service screw
that secures the lamp cage
cover. Then slide the cover in the
direction of the arrow.
Press POWER OFF. Wait until
the cooling fan stops.
Press the lamp cage firmly into
the lamp cage compartment.
Fasten the securing screws.
It is recommended that the lamp be replaced after approximately 1,500 cumulative hours of use or when you
notice a significant deterioration of the picture and color quality. Carefully change the lamp by following the steps
below.
If the new lamp does not light after replacement, take your projector to the nearest Authorized Sharp Industrial
LCD Products Dealer or Service Center for repair. Purchase a replacement lamp unit (lamp/cage module) of the
current type BQC-XGNV7XU/1 from your nearest Authorized Sharp Industrial LCD Products Dealer or Service
Center. Then carefully change the lamp by following the instructions below. If you wish, you may have the lamp
replaced at your nearest Authorized Sharp Industrial LCD Products Dealer or Service Center.
IMPORTANT NOTE TO U.S. CUSTOMERS:
The lamp included with this projector is backed by a 90-day parts and labor limited warranty. All service of this
projector under warranty, including lamp replacement, must be obtained through an Authorized Sharp Industrial LCD
Products Dealer or Service Center. For the name of the nearest Authorized Sharp Industrial LCD Products Dealer or
Service Center, please call toll-free: 1-800-BE-SHARP (1-800-237-4277).
U.S.A. ONLY
Removing and installing the lamp unit
CAUTION
• Do not remove the lamp cage directly after operation of the projector. The lamp may be extremely hot. Wait at least one
hour after the power cord is disconnected to allow the surface of the lamp cage to fully cool before removing the lamp
cage.
• Be sure to remove the lamp cage by the handle. Be sure not to touch the glass surface of the lamp cage or the inside of
the projector.
• To avoid injury to yourself and damage to the lamp, be sure to carefully follow the steps below.
User service screw
or
User service screw
Securing
screw
Securing
screw
E-49
Maintenance &
Troubleshooting
Replacing the Projection Lamp
1
Connect the power
cord.
Reset the lamp timer.
While pressing ƒ, © and
ENTER on the projector, press
POWER ON on the projector.
Plug the power cord into the AC
socket of the projector.
Resetting the lamp timer
Using the Kensington Lock
This projector has a Kensington Security Standard
connector for use with a Kensington MicroSaver Security
System. Refer to the information that came with the
system for instructions on how to use it to secure the
projector.
• Reset the lamp timer only after replacing the lamp.
Problem
No picture and no sound.
Sound is heard but no picture
appears.
Color is faded or poor.
Picture is blurred.
Picture appears but no sound is
heard.
An unusual sound is occasionally
heard from the cabinet.
Maintenance indicator lights up.
Data cannot be received via
IrCOM.
Picture noise appears.
480P images do not appear.
Color is distorted (except for
VIDEO mode).
Lens comes off.
Troubleshooting
“LAMP 0000H” is displayed,
indicating that the lamp timer is
reset.
2
Check
• Projector power cord is not plugged into the wall outlet.
• Selected input is wrong. (See page 17.)
• Cables improperly connected to side panel of the projector. (See pages 11–15.)
• Remote control batteries have run down. (See page 8.)
• Remote control’s MOUSE/ADJUSTMENT switch is set to MOUSE.
• Cables improperly connected to side panel of the projector. (See pages 11–15.)
•“Contrast” and “Bright” adjustments are set to minimum position. (See page 27.)
• On-screen Display (“BLACK SCREEN”) is turned off and Black Screen function is turned on,
creating a black image. (See page 37.)
•“Color” and “Tint” adjustments are not correct. (See page 27.)
• Adjust the focus. (See page 17.)
• Projection distance is too long or too short to allow for proper focus. (See page 18.)
• Cables improperly connected to side panel of the projector. (See pages 11–15.)
• Volume is set to minimum. (See page 17.)
• If the picture is normal, the sound is due to cabinet shrinkage caused by temperature changes.
This will not affect operation or performance.
• Refer to “Lamp/Maintenance Indicators” on page 47.
• Distance and angle between the projector and transmitting device are out of the designated range.
(See page 25.)
• Refer to the operation manual of the transmitting device.
• Refer to the section “Troubleshooting” in the operation manual of the supplied software.
• Adjust the phase setting. (See page 29.)
• Noise may appear when used with certain computers. Set the NOISE FILTER to ON using the RS-
232C command. (See pages 53 and 54.)
• Set the resolution mode to 480P. (See page 32.)
• Change the input signal type. (See page 40.)
• Align the mark on the lens with the corresponding mark on the projector, push the lens firmly in
place, and rotate to the right.
Kensington Security
Standard connector
E-50
Appendix
Appendix
E-51
Appendix
Transporting the Projector
Using the Carrying Bag
A soft-side carrying bag is provided to transport the
projector. Before placing the projector into the carrying
bag, set up the inner pad inside the bag as shown.
CAUTION
• Rotate the focus and zoom rigns to store the lens before
placing the projector into the carrying bag.
• The supplied carrying bag is made exclusively for the
projector and its supplied accessories. Do not place other
items into the carrying bag with the projector or use the
bag to transport items other than the projector and its
accessories.
• This bag is provided merely to transport the projector and
its accessories, not to protect these products from damage
as a result of rough handling. Do not expose these products
to shocks or impact when transported in the carrying bag.
• Wait until the projector has sufficiently cooled before placing
it into the carrying bag. If the projector is placed into the
bag while it is still hot, the heat may damage the bag lining.
Carrying bag
Inner pad
Projector
Attaching the shoulder strap to the carrying bag
1
Take the shoulder strap
out.
The shoulder strap is stored in the
pocket located in front of the
carrying bag.
Using the Lens Cap Strap
A lens cap strap is provided to prevent the loss of the lens cap.
1
Attach the lens cap strap to the lens
cap.
2
Attach the lens cap strap to the
projector.
• You can also use the end of a mechanical pencil or other pointed object to feed the lens cap strap through the openings.
2
Fasten the shoulder strap
to the carrying bag.
Follow the same procedure for the
other end of the strap.
E-52
Appendix
Connection Pin Assignments
Analog Computer 1 Signal Input Port: 15-pin mini D-sub female connector
Computer Input
Analog
1. Video input (red)
2. Video input
(green/sync on green)
3. Video input (blue)
4. Reserve input 1
5. Composite sync
6. Earth (red)
7. Earth (green/sync on green)
8. Earth (blue)
9. Not connected
10. GND
11. GND
12. Bi-directional data
13. Horizontal sync signal
14. Vertical sync signal
15. Data clock
1
15
5
6
11
10
Pin No. Signal Name I/O Reference
1 CD Not connected
2 RD Receive Data Input Connected to internal circuit
3 SD Send Data Output Connected to internal circuit
4 ER Not connected
5 SG Signal Ground Connected to internal circuit
6 DR Data Set Ready Output Not connected
7 RS Request to Send Output Connected to internal circuit
8 CS Clear to Send Input Connected to internal circuit
9 CI Not connected
Pin No. Signal Name I/O Reference
1 VCC 3.3V (Reserved) Output Not connected
2 RD Receive Data Input Connected to internal circuit
3 SD Send Data Output Connected to internal circuit
4 EXIR Detector of Option Unit Input Not connected
(Reserved)
5 SG Signal Ground Connected to internal circuit
6 ERX IR Receive Signal from Input Not connected
IR Amplifire (Reserved)
7 RS Request to Send Output Connected to internal circuit
8 CS Clear to Send Input Connected to internal circuit
9 ETX IR Transmit Signal Output Not connected
(Reserved)
RS-232C Terminal: 9-pin mini DIN connector
6
8
4
9
7
3
5
21
RS-232C Port: 9-pin D-sub male connector of the DIN-D-sub RS-232C cable
1
5
6
9
Pin No. Signal Name Reference
1 RX0 Blue Input () Connected to internal circuit
2 RX0 Blue Input () Connected to internal circuit
3 RX0 SHIELD Panel Link Shield Connected to internal circuit
4 RX2 SHIELD Panel Link Shield Connected to internal circuit
5 RX2 Red Input () Connected to internal circuit
6 RX2 Red Input () Connected to internal circuit
7 DDC/SCL SCL Connected to internal circuit
8 DDC/SDA SDA Connected to internal circuit
9 NC N.C. Not connected
10 NC N.C. Not connected
11 RXC Clock Input () Connected to internal circuit
12 RXC Clock Input () Connected to internal circuit
13 RXC SHIELD Panel Link Shield Connected to internal circuit
14 RX1 SHIELD Panel Link Shield Connected to internal circuit
15 RX1 Green Input () Connected to internal circuit
16 RX1 Green Input () Connected to internal circuit
17 NC N.C. Not connected
18 SENS SENS Connected to internal circuit
19 DDC 5V DC 5V Connected to internal circuit
20 DDC GND GND Connected to internal circuit
PanelLink™ Port: MDR-type 20-pin connector
10
20 11
1
E-53
Appendix
PC control
A computer can be used to control the projector by connecting an RS-232C cable (cross type, sold separately) to
the projector. (See page 14 for connection.)
Communication conditions
Set the serial port settings of the computer to match that of the table.
Signal format: Conforms to RS-232C standard.
Baud rate: 9,600 bps
Data length: 8 bits
Parity bit: NON
Stop bit: 1 bit
Flow control: None
Basic format
Commands from the computer are sent in the following order: command, parameter, and return code. After the
projector processes the command from the computer, it sends a response code to the computer.
RS-232C Port Specifications
Return code (0DH)
C1 C2 C3 C4 P1 P2 P3 P4
Response code format
Normal response
O K
Return code (0DH)
Problem response (communication error or incorrect command)
E R R
Return code (0DH)
Command 4-digits Parameter 4-digits
Command format
When more than one code is being sent, send each command only after the OK response code for the previous
command from the projector is verified.
• When using the computer control function of the projector, the projector operating status cannot be read to the computer.
Therefore, confirm the status by transmitting the display commands for each adjustment menu and checking the status with
the On-screen Display. If the projector receives a command other than a menu display command, it will execute the com-
mand without displaying the On-screen Display.
Commands
EXAMPLE
• When “BRIGHT” of INPUT 1 IMAGE ADJUSTMENT is set to 10.
→
←
RABR 1 0_
OK
ProjectorComputer
CONTROL ITEM
COMMAND
C1
A
A
P
P
I
I
I
I
I
P
P
O
O
V
R
R
C
C
O
O
W
W
E
G
G
O
H
W
W
R
R
D
B
B
M
K
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
0
1
0
1
1
1
2
1
0
AUTO POWER OFF
AUTO POWER ON
POWER OFF (STANDBY)
POWER ON
VIDEO
INPUT1
INPUT2
IrCOM
INPUT CHECK
KEYSTONE
(127 – 127)
C2 C3 C4 P1 P2 P3 P4
PARAMETER
CONTROL
CONTENTS
POWER SETTING
AUTO POWER OFF
KEYSTONE
ADJUSTMENT
KEYS * * *
*
INPUT SWITCHING
LANGUAGE
SELECTION
INPUT CHECK
CONTROL ITEM
COMMAND
C1
M
M
M
M
M
M
M
M
M
M
M
E
E
E
E
E
E
E
E
E
E
E
L
L
L
L
L
L
L
L
L
L
L
A
A
A
A
A
A
A
A
A
A
A
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
1
1
1
2
3
4
5
6
7
8
9
0
1
ENGLISH
DEUTSCH
ESPAÑOL
NEDERLANDS
FRANÇAIS
ITALIANO
SVENSKA
PORTUGUÊS
C2 C3 C4 P1 P2 P3 P4
PARAMETER
CONTROL
CONTENTS
E-54
Appendix
RS-232C Port Specifications
CONTROL ITEM
COMMAND
C1
M
M
M
M
M
V
V
V
V
V
V
V
V
V
V
I
I
I
I
I
I
I
V
M
M
A
A
A
A
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
A
A
A
E
E
E
E
E
A
A
A
A
A
A
A
A
A
A
M
M
M
M
M
M
M
O
U
U
A
A
A
A
A
A
A
A
A
A
A
A
A
B
B
B
B
B
B
A
A
D
S
S
S
S
S
P
B
C
T
S
R
R
B
R
R
B
B
B
B
S
S
S
L
T
T
T
B
R
R
P
B
R
B
R
C
T
S
R
P
B
R
B
R
R
D
D
J
Y
Y
Y
Y
Y
I
R
O
I
H
E
D
E
E
E
G
G
G
G
I
I
I
A
E
E
E
A
E
E
I
R
D
E
E
O
I
H
E
I
R
D
E
E
E
J
J
S
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
*
*
*
*
*
_
*
*
_
_
_
_
_
_
_
_
_
_
_
_
*
*
_
_
*
*
*
*
_
*
*
*
_
*
*
*
*
_
_
_
_
_
_
_
_
_
_
*
*
*
*
*
_
*
*
_
_
_
_
_
_
_
_
_
*
_
_
*
*
_
_
*
*
*
*
_
*
*
*
_
*
*
*
*
_
_
_
_
_
1
2
3
4
5
*
*
*
*
*
1
*
*
0
1
1
2
3
4
1
2
3
*
0
1
*
*
0
1
*
*
*
*
0
*
*
*
1
*
*
*
*
0
1
0
1
1
AUTO
PAL (50/60 Hz)
SECAM
NTSC 4.43
NTSC 3.58
CONTRAST (30 – 30)
BRIGHT (30 – 30)
COLOR (30 – 30)
TINT (30 – 30)
SHARPNESS (30 – 30)
RESET
RED (30 – 30)
BLUE (30 – 30)
VIDEO DISPLAY
RESET
SHARP
CUSTOM
BLUE
NONE
SHARP
CUSTOM
NONE
VOLUME (00 – 60)
MUTE OFF
MUTE ON
TREBLE (30 – 30)
BASS (30 – 30)
AUDIO DISPLAY
RESET
CONTRAST (30 – 30)
BRIGHT (30 – 30)
RED (30 – 30)
BLUE (30 – 30)
INPUT 1 DISPLAY
COLOR (30 – 30)
TINT (30 – 30)
SHARPNESS (30 – 30)
RESET
CONTRAST (30 – 30)
BRIGHT (30 – 30)
RED (30 – 30)
BLUE (30 – 30)
INPUT 2 DISPLAY
RESET
AUTO SYNC OFF
AUTO SYNC ON
AUTO SYNC START
C2 C3 C4 P1 P2 P3 P4
PARAMETER
CONTROL
CONTENTS
CONTROL ITEM
COMMAND
C1 C2 C3 C4 P1 P2 P3 P4
PARAMETER
CONTROL
CONTENTS
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
G
G
G
G
G
G
G
G
I
I
I
I
M
M
R
R
R
R
R
R
R
R
R
R
R
N
N
N
N
A
A
A
A
M
M
M
M
M
M
M
M
M
M
A
A
A
A
A
A
A
A
A
A
M
M
M
M
E
E
A
A
A
A
B
B
B
B
A
A
A
F
F
C
P
H
V
R
R
D
D
R
R
I
I
A
A
I
I
S
S
M
M
M
M
M
M
M
M
B
B
B
B
M
M
S
S
S
S
S
S
S
S
S
S
S
I
I
L
H
P
P
E
E
I
I
E
E
N
N
S
S
P
P
I
I
R
R
R
R
V
V
V
V
K
K
O
O
S
L
R
R
R
R
R
R
R
R
V
V
V
L
L
*
_
*
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
*
*
*
*
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
*
*
*
*
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
*
*
*
*
0
1
0
1
0
1
0
1
0
1
0
1
1
2
1
2
3
4
1
2
3
4
0
1
0
1
*
*
1
2
3
4
1
2
3
4
1
2
3
0
1
CLOCK (150 – 150)
PHASE (60 – 60)
H-POS (150 – 150)
V-POS (60 – 60)
COMPUTER INPUT DISPLAY
RESET
OSD DISPLAY OFF
OSD DISPLAY ON
REVERSE OFF
REVERSE ON
INVERT OFF
INVERT ON
AUTO SYNC DISPLAY OFF
AUTO SYNC DISPLAY ON
I/P CONVERSION INTERLACED
I/P CONVERSION PROGRESSIVE
RGB
COMPONENT
STANDARD
GAMMA1
GAMMA2
CUSTOM
STANDARD
GAMMA1
GAMMA2
CUSTOM
BLACK SCREEN OFF
BLACK SCREEN ON
BLACK SCREEN DISPLAY OFF
BLACK SCREEN DISPLAY ON
SAVE SETTING (1–7)
SELECT SETTING (1–7)
NORMAL
WIDE/FIT TO SCREEN
DOT BY DOT
DOT BY DOT (WIDE)
NORMAL
WIDE/FIT TO SCREEN
DOT BY DOT
DOT BY DOT (WIDE)
NORMAL
WIDE
DOT BY DOT
FILTER OFF
FILTER ON
INPUT
ADJUSTMENT
SCREEN SETTING
VIDEO
SYSTEM
SELECTION
VIDEO
ADJUSTMENT
STARTUP
SELECTION
BACKGROUND
SELECTION
VIDEO
CONFIRMATION
VIDEO GAMMA
SELECTION
INPUT GAMMA
SELECTION
INPUT1 SIGNAL TYPE
SELECTION
SYSE___
0
DISPLAY
BLACK SCREEN
SCREEN MODE
MEMORY
INPUT1 RESIZE
INPUT2 RESIZE
VIDEO RESIZE
NOISE FILTER
INPUT 1
ADJUSTMENT
INPUT 2
ADJUSTMENT
AUDIO
ADJUSTMENT
INPUT AUTO
SYNCHRONIZATION
VOLUME
ADJUSTMENT
• If a dash (_) appears in the parameter column, enter a space. If an asterisk (*) appears, enter a value in the range indicated
in brackets under CONTROL CONTENTS.
• INPUT ADJUSTMENT can only be set in the displayed computer mode.
• Noise may appear when used with certain computers. Set the NOISE FILTER to ON using the RS-232C command.
E-55
Appendix
The computer output signal timing of different types of computer signals are shown below for reference.
For IBM and compatibles
For Macintosh Series
abc d
w
x
y
z
VIDEO SIGNAL
HORIZONTAL
SYNC SIGNAL
VIDEO SIGNAL
VERTICAL
SYNC SIGNAL
e
a
b
c
d
w
x
y
z
VIDEO SIGNAL
C-SYNC(H)
C-SYNC(V)
VIDEO SIGNAL
V-SYNC
e = 2 dot
The following is a list of compatible VESA standards. Please note that this projector also accepts signals outside
of the VESA standards.
Computer compatibility table for INPUT 1 (HD-15)
• Depending on the mode selected, the projector may clearly display images under 200 Hz.
Input Signals (Recommended Timing)
640
640
720
640
640
640
640
800
800
800
800
800
1,024
1,024
1,024
1,024
1,024
1,152
1,280
1,280
1,280
1,280
1,280
1,600
1,600
1,600
1,600
1,600
dot
32
32
36
8
16
16
56
24
40
56
16
32
8
24
24
16
48
64
96
64
48
16
64
64
64
64
64
64
dot
64
64
72
96
40
64
56
72
128
120
80
64
176
136
136
96
96
128
112
160
112
144
160
192
192
192
192
192
dot
96
96
108
40
120
120
80
128
88
64
160
152
56
160
144
176
208
256
312
224
248
248
224
304
304
304
304
304
dot
640
640
720
640
640
640
640
800
800
800
800
800
1,024
1,024
1,024
1,024
1,024
1,152
1,280
1,280
1,280
1,280
1,280
1,600
1,600
1,600
1,600
1,600
dot
832
832
936
800
832
840
832
1,024
1,056
1,040
1,056
1,048
1,264
1,344
1,328
1,312
1,376
1,600
1,800
1,728
1,688
1,688
1,728
2,160
2,160
2,160
2,160
2,160
dot
26.4
26.4
26.4
31.8
26.4
26.7
23.1
28.4
26.4
20.8
21.3
18.6
28.2
20.7
17.7
16.7
14.6
14.8
16.7
11.6
15.6
12.5
11.0
13.3
12.3
11.4
10.7
9.4
37.861
37.861
37.927
31.469
37.861
37.500
43.269
35.156
37.879
48.077
46.875
53.674
35.522
48.363
56.476
60.023
68.677
67.500
60.000
85.938
63.981
79.976
91.146
75.000
81.250
87.500
93.750
106.250
31.500
31.500
35.500
25.175
31.500
31.500
36.000
36.000
40.000
50.000
49.500
56.250
44.900
65.000
75.000
78.750
94.500
108.000
108.000
148.500
108.000
135.000
157.500
162.000
175.500
189.000
202.500
229.500
ms
32
1
1
2
1
1
1
1
1
37
1
1
0
3
3
1
1
1
1
1
1
1
1
1
1
1
1
1
H
3
3
3
2
3
3
3
2
4
6
3
3
4
6
6
3
3
3
3
3
3
3
3
3
3
3
3
3
H
60
41
42
25
20
16
25
22
23
23
21
27
20
29
29
28
36
32
36
47
38
38
44
46
46
46
46
46
H
350
400
400
480
480
480
480
600
600
600
600
600
768
768
768
768
768
864
960
960
1,024
1,024
1,024
1,200
1,200
1,200
1,200
1,200
H
445
445
446
525
520
500
509
625
628
666
625
631
817
806
806
800
808
900
1,000
1,011
1,066
1,066
1,072
1,250
1,250
1,250
1,250
1,250
H
11.8
11.8
11.8
16.7
13.7
13.3
11.8
17.8
16.6
13.9
13.3
11.8
23.0
16.7
14.3
13.3
11.8
13.3
16.7
11.8
16.7
13.3
11.8
16.7
15.4
14.3
13.3
11.8
Hz
85.080
85.080
85.039
59.940
72.809
75.000
85.008
56.250
60.317
72.188
75.000
85.061
43.479
60.004
70.069
75.029
84.997
75.000
60.000
85.002
60.020
75.025
85.024
60.000
65.000
70.000
75.000
85.000
kHz MHz
31.7
31.7
28.2
39.7
31.7
31.7
27.8
27.8
25.0
20.0
20.2
17.8
22.3
15.4
13.3
12.7
10.6
9.3
9.3
6.7
9.3
7.4
6.3
6.2
5.7
5.3
4.9
4.4
350
400
400
480
480
480
480
600
600
600
600
600
768
768
768
768
768
864
960
960
1,024
1,024
1,024
1,200
1,200
1,200
1,200
1,200
line
MODE
VGA
SVGA
XGA
SXGA
UXGA
VESA
Standard
VESA
Standard
VESA
Guidelines
VESA
Standard
VESA
Standard
Industry
Standard
VESA
Guidelines
Industry
Standard
HSYNC VSYNC
VIDEO
PERIOD
z
BACK
PORCH
y
FRONT
PORCH
w
1V
(wxyz)
LEVEL1/V
SYNC
x
VIDEO
PERIOD
d
BACK
PORCH
c
FRONT
PORCH
a
1H
(abcd)
LEVEL1dot 1/H 1/dot
SYNC
b
0.7 Vp-p
75 Ω load
LEVEL
R • G • B
ns
µs
TTL TTL
TYPE
VIDEO
E-56
Appendix
Input Signals (Recommended Timing)
640
832
1,024
1,152
1,152
1,152
1,152
640
640
1,280
1,920
dot
64
31
35
36
29
16
24
–
–
–
–
dot
64
65
96
128
128
96
96
–
–
–
–
dot
96
224
173
140
195
208
168
–
–
–
–
dot
640
832
1,024
1,152
1,152
1,152
1,024
–
–
–
–
dot
864
1,152
1,328
1,456
1,504
1,472
1,312
–
–
–
–
dot
28.6
20.1
16.7
14.5
14.8
13.9
14.1
–
–
–
–
35.000
49.693
60.000
68.887
61.795
71.713
70.838
15.734
31.469
44.955
33.716
30.2400
57.246
79.760
100.300
92.940
105.561
92.940
–
–
–
–
ms
3
1
3
3
2
2
2
–
–
–
–
H
3
3
3
3
4
8
8
–
–
–
–
H
39
39
30
39
31
33
33
–
–
–
–
H
480
624
768
870
900
900
800
–
–
–
–
H
525
667
804
915
937
943
843
–
–
–
–
H
15.0
13.4
13.4
13.3
14.3
13.1
11.9
–
–
–
–
Hz
66.670
74.502
74.700
75.287
69.950
76.048
84.031
59.940
59.940
59.740
59.940
kHz MHz
33.1
17.5
12.5
10.0
10.8
9.5
10.8
–
–
–
–
480
624
768
870
900
900
900
480
480
720
1,080
line
MODE
HSYNC VSYNC
VIDEO
PERIOD
z
BACK
PORCH
y
FRONT
PORCH
w
1V
(wxyz)
LEVEL1/V
SYNC
x
VIDEO
PERIOD
d
BACK
PORCH
c
FRONT
PORCH
a
1H
(abcd)
LEVEL1dot 1/H 1/dot
SYNC
b
LEVEL
R • G • B/
COMPONENT
R • G • B
TTL TTL
0.7 Vp-p
75 Ω load
ns
µs
TYPE
VIDEO
13 Monitor
16 Monitor
19 Monitor
21 Monitor
66Hz
76Hz
84Hz
480I
480P
720P
1080I
Macintosh™
SUN
DTV
• This projector may not be able to display images from notebook computers in simultaneous (CRT/LCD) mode. Should this
occur, turn off the LCD display on the notebook computer and output the display data in “CRT only” mode. Details on how
to change display modes can be found in your notebook computer’s operation manual.
• This projector can receive 640 350 VESA format VGA signals, however, “640 400” will appear on the screen.
• When receiving 1,600 1,200 VESA format UXGA signals, sampling occurs and the image is displayed with 1,024 lines,
causing part of the image to be blocked.
Computer compatibility table for INPUT 2 (DIGITAL INPUT)
• This projector does not accept Panel Link input from INPUT 2 with a pixel clock greater than 108 MHz.
640
640
720
640
640
640
640
800
800
800
800
800
1,024
1,024
1,024
1,024
1,024
1,152
1,280
1,280
dot
32
32
36
8
16
16
56
24
40
56
16
32
8
24
24
16
48
64
96
48
dot
64
64
72
96
40
64
56
72
128
120
80
64
176
136
136
96
96
128
112
112
dot
96
96
108
40
120
120
80
128
88
64
160
152
56
160
144
176
208
256
312
248
dot
640
640
720
640
640
640
640
800
800
800
800
800
1,024
1,024
1,024
1,024
1,024
1,152
1,280
1,280
dot
832
832
936
800
832
840
832
1,024
1,056
1,040
1,056
1,048
1,264
1,344
1,328
1,312
1,376
1,600
1,800
1,688
dot
26.4
26.4
26.4
31.8
26.4
26.7
23.1
28.4
26.4
20.8
21.3
18.6
28.2
20.7
17.7
16.7
14.6
14.8
16.7
15.6
37.861
37.861
37.927
31.469
37.861
37.500
43.269
35.156
37.879
48.077
46.875
53.674
35.522
48.363
56.476
60.023
68.677
67.500
60.000
63.981
31.500
31.500
35.500
25.175
31.500
31.500
36.000
36.000
40.000
50.000
49.500
56.250
44.900
65.000
75.000
78.750
94.500
108.000
108.000
108.000
ms
32
1
1
2
1
1
1
1
1
37
1
1
0
3
3
1
1
1
1
1
H
3
3
3
2
3
3
3
2
4
6
3
3
4
6
6
3
3
3
3
3
H
60
41
42
25
20
16
25
22
23
23
21
27
20
29
29
28
36
32
36
38
H
350
400
400
480
480
480
480
600
600
600
600
600
768
768
768
768
768
864
960
1,024
H
445
445
446
525
520
500
509
625
628
666
625
631
817
806
806
800
808
900
1,000
1,066
H
11.8
11.8
11.8
16.7
13.7
13.3
11.8
17.8
16.6
13.9
13.3
11.8
23.0
16.7
14.3
13.3
11.8
13.3
16.7
16.7
Hz
85.080
85.080
85.039
59.940
72.809
75.000
85.008
56.250
60.317
72.188
75.000
85.061
43.479
60.004
70.069
75.029
84.997
75.000
60.000
60.020
kHz MHz
31.7
31.7
28.2
39.7
31.7
31.7
27.8
27.8
25.0
20.0
20.2
17.8
22.3
15.4
13.3
12.7
10.6
9.3
9.3
9.3
350
400
400
480
480
480
480
600
600
600
600
600
768
768
768
768
768
864
960
1,024
line
MODE
VGA
SVGA
XGA
SXGA
VESA
Standard
VESA
Standard
VESA
Guidelines
VESA
Standard
VESA
Standard
Industry
Standard
VESA
Guidelines
Industry
Standard
HSYNC VSYNC
VIDEO
PERIOD
z
BACK
PORCH
y
FRONT
PORCH
w
1V
(wxyz)
LEVEL1/V
SYNC
x
VIDEO
PERIOD
d
BACK
PORCH
c
FRONT
PORCH
a
1H
(abcd)
LEVEL1dot 1/H 1/dot
SYNC
b
0.7 Vp-p
75 Ω load
LEVEL
R • G • B
ns
µs
TTL TTL
TYPE
VIDEO
E-57
Appendix
Specifications
Product type
Model
Video system
Display method
DMD panel
Lens
Projection lamp
Contrast ratio
Video input signal
S-video input signal
Digital input signal
Horizontal resolution
Audio output
Computer RGB input signal
Pixel clock
Vertical frequency
Horizontal frequency
Computer control signal
Speaker system
Rated voltage
Input current
Rated frequency
Power consumption
Operating temperature
Storage temperature
Cabinet
I/R carrier frequency
Laser pointer of remote control
Dimensions (approx.)
Weight (approx.)
Supplied accessories
Replacement parts
Digital Multimedia Projector
XG-NV7XU
PAL/SECAM/NTSC 3.58/NTSC 4.43/DTV 480P/DTV 720P/DTV 1080I
Single panel Digital Micromirror Device™ (DMD™) by Texas Instruments
Panel size:
55
⁄64 (21.8 mm), 1 chip XGA DMD
No. of dots: 786,432 dots (1,024 [H] 768 [V])
1–1.2 zoom lens, F2.7–3.0, f 35–42 mm
P-VIP lamp, AC 120 W
500:1
RCA Connector: VIDEO, composite video, 1.0 Vp-p, sync negative, 75 Ω terminated
RCA Connector: AUDIO, 0.5 Vrms more than 22 kΩ (stereo)
4-pin mini DIN connector
Y (luminance signal): 1.0 Vp-p, sync negative, 75 Ω terminated
C (chrominance signal): Burst 0.286 Vp-p, 75 Ω terminated
20-
PIN DIGITAL CONNECTOR (INPUT 2):
TMDS/PanelLink
520 TV lines (video input), 750 TV lines (DTV 720P input, Dot by Dot)
2 W (monaural)
15-
PIN MINI D-SUB CONNECTOR (INPUT 1):
RGB separate/composite sync/sync on green type analog input: 0–0.7 Vp-p, positive,
75 Ω terminated
STEREO MINIJACK: AUDIO, 0.5 Vrms, more than 22 kΩ (stereo)
H
ORIZONTAL SYNC. SIGNAL: TTL level (positive/negative) or composite sync (Apple only)
V
ERTICAL SYNC. SIGNAL: Same as above
12–230 MHz
43–200 Hz
15–126 kHz
9-pin mini-DIN male connector (RS-232C Input Port)
1
37
⁄64 1
3
⁄16 (4 3 cm) oval
AC 110–120/220–240 V
1.0 A/1.9 A
50/60 Hz
197 W
41°F to 95°F (5°C to 35°C)
14°F to 140°F (10°C to 60°C)
Magnesium alloy (Front panel and rear terminal panel constructed of plastic)
38 kHz
Wave length: 650 nm / Max. output: 1 mW / Class II Laser Product
9
1
⁄4 (W) 2
9
⁄32 (H) 12
19
⁄64 (D) (235 58 312.5 mm) (main body only)
9
1
⁄4 (W) 3
15
⁄64 (H) 12
43
⁄64 (D) (235 82 321.8 mm) (including
adjustment feet and projecting parts)
6.28 lbs. (2.85 kg)
Remote control, Two AA size batteries, Power cord (11 10, 3.6 m), Computer cable (9
10, 3 m), Computer audio cable (9 10, 3 m), Mouse control serial cable (3 3, 1 m),
Mouse control cable for IBM PS/2 (3 3, 1 m), Mouse control cable for Mac (6
45
⁄64,
17 cm), DIN-D-sub RS-232C cable (6
45
⁄64, 15 cm), Remote mouse receiver, Carrying bag,
Lens cap (attached), Lens cap strap, CD-ROM, Projector operation manual, Projector
quick reference, Sharp Advanced Presentation Software operation manual, Sharp
Advanced Presentation Software quick reference, IrDA driver installation instruction sheet
Remote control (RRMCG1530CESA), AA size batteries, Power cord (QACCU5013CEZZ),
Computer cable (QCNW-5304CEZZ), Computer audio cable (QCNW-4870CEZZ), Mouse
control serial cable (QCNW-5112CEZZ), Mouse control cable for IBM PS/2 (QCNW-
5113CEZZ), Mouse control cable for Mac (QCNW-5114CEZZ), DIN-D-sub RS-232C cable
(QCNW-5288CEZZ), Remote mouse receiver (RUNTK0661CEZZ), Carrying bag
(GCASN0003CESA), Lens cap (GCOVH1308CESA), Lens cap strap (UBNDT0012CEZZ),
CD-ROM (UDSKA0009CE01), Projector operation manual (TINS-6786CEZZ), Projector
quick reference (TINS-6787CEZZ), Sharp Advanced Presentation Software operation
manual (TINS-6888CEZZ), Sharp Advanced Presentation Software quick reference (TINS-
6788CEZZ), IrDA driver installation instruction sheet (TCAUZ3046CEZZ)
This unit has some inactive pixels within acceptable tolerances which
may result in inactive dots on the picture screen. This will not affect
the picture quality or the life expectancy of the unit.
If you have any questions about this matter, please call toll free 1-800-
BE-SHARP (1-800-237-4277). U.S.A. ONLY
This SHARP projector uses a DMD panel. This very sophisticated
panel contains 786,432 pixels. As with any high technology electronic
equipment such as large screen TVs, video systems and video
cameras, there are certain acceptable tolerances that the equipment
must conform to.
Specifications are subject to change without notice.
E-58
Appendix
Dimensions
Units: inches (mm)
Rear View
8
5
/
8
(219)
1
15
/
32
(37.5)
3
15
/
64
(82 )
12
19
/
64
(312.5)
5
/
16
(8.1)
3
/
64
(1.2)
2
13
/
16
(71.5 )
2
9
/
32
(58)
9
1
/
4
(235)
8
11
/
32
(212)
Front View
Top View
Side View
Bottom View
E-59
Appendix
Guide to Effective Presentations
Electronic presentations are one of the most effective
tools presenters can use to persuade an audience.
There are several ways to enhance your presentation
and maximize your effectiveness. The following are
guidelines to help you create and deliver a dynamic
presentation.
a. Types of Presentations
Computer Presentations
• To present basic information such as graphs, spreadsheets,
documents and images, use word processing and spreadsheet
applications.
• To convey more complex information and create more dynamic
presentations which allow you to control the pace of your delivery,
utilize software such as Astound
®
, Freelance
®
, Persuasion
®
or
PowerPoint
®
.
• For high-end multimedia and interactive presentations, use software
such as Macromedia Director
®
.
• Astound
®
, Freelance
®
, Persuasion
®
, PowerPoint
®
and Macromedia
Director
®
are trademarks of their respective companies.
Video Presentations
Use of video equipment, such as a VCR, DVD player and laser disc
player, can be effective for delivering instructional or illustrative
information that is difficult to present.
Digital Cameras and Personal Digital Assistants
(PDAs)
For highly compact and portable presentations, still cameras, digital
video cameras, document cameras and PDAs are ideal for transferring
data without cumbersome conversions.
Multimedia Presentations
You can integrate all of the above methods for a full multimedia
presentation including video, audio, computer applications and World
Wide Web information.
Wireless Presentations
Use any IrDA/IrTranP compatible source such as a laptop, digital
camera or PDA to project still images quickly and effortlessly without
the use of cables.
b. Creative Presentations
Oftentimes presenters do not take advantage of the many
subtle ways they can manipulate their electronic slides to more
effectively persuade the audience.
Color has a great effect on the audience during a presentation.
When used correctly and legibly, studies show that
background & foreground colors establish an emotional tone
for a presentation, help viewers understand and retain
information, and influence an audience to take a desired
course of action.
Color Considerations
• Choose legible colors.
• Text and graphics colors need sufficient contrast.
• Use darker colors for the background since a lighter background
can create uncomfortable glare. (Yellow on black creates an ideal
contrast.)
Yellow
on Black
0
5
10
15
20
25
30
E-60
Appendix
Guide to Effective Presentations
Red
Blue
Green
Black
Presentation from SHARP
O
n
e
o
f th
e
m
o
s
t c
o
m
m
o
n
m
is
ta
k
e
s
in
a
n
y
ty
p
e
o
f
p
r
e
s
e
n
ta
tio
n
v
is
u
a
l is
th
e
s
e
le
c
tio
n
o
f
ty
p
e
fo
n
t
s
th
a
t a
re
to
o
s
m
a
ll, to
o
th
in
, o
r h
a
rd
to
re
a
d
.
• Background colors can subconsciously affect the audience:
Red—increases viewers’ pulse and breathing and
encourages risk taking but can also be associated with
financial loss.
Blue—has a calming and conservative affect on the
audience but can also create boredom among corporate
audiences that are often inundated with this background
color.
Green—stimulates interaction.
Black—conveys finality and certainty. Use it as a transitional
color between slides when moving from one idea to another.
• Foreground colors create a major impact on how well an
audience understands and remembers a message.
• Use one or two bright colors for emphasis.
• Highlight important messages.
• The eye has a difficult time reading certain colored text on
certain colored backgrounds. For example, text and
background colors in red and green, and blue and black
make for difficult viewing.
• Colorblind individuals may find it difficult to distinguish
between red and green, brown and green, and purple and
blue. Avoid using these colors together.
Fonts
• One of the most common mistakes in any type of
presentation visual is the selection of type fonts that are too
small, too thin, or too difficult to read.
• If you are not sure how well a given font will read on a screen
at various sizes, try this: Draw a 6 8 box on a piece of
paper and print out several lines of text inside the box with
your computer printer at 300 or 600 dpi resolution. Vary the
sizes of text to simulate headline, body and text call-outs
for any charts or graphs. Hold the printout at arm’s length.
This is how your text will look on a 4 (1.2 meters)-wide
screen at 10 (3 meters), on a 7.5 (2.3 meters)-wide screen
at 20 (6.1 meters) and a 12 (3.7 meters)-wide screen at
30 (9.1 meters). If you cannot read the text easily, you
should put less copy on your visuals or use larger typefaces.
• Design your visuals so that they are visible by the viewer in
the last row.
• Nothing will ruin your presentation faster than misspelled
words. Take the time to proofread and edit your work before
your visuals become a permanent part of your presentation.
• Mixed case text is easier to read than text which is displayed
in capital letters.
• Another important attribute of fonts is whether any particular
face is serif or sans-serif. Serifs are small, usually horizontal
cross strokes that are added to the end of a letter’s main
strokes. Because of their ability to coax the eye along the
line of type, fonts with serifs are generally acknowledged to
be more readable.
Sans-serif
Serif
E-61
Appendix
c. Set-Up
When giving a presentation, you need to set the stage both
figuratively and literally for success. The way you set up a
presentation room will have a great impact on the audience’s
perception of you and your message. By manipulating the
placement and use of the following tools, you will improve the
impact of your presentation.
Lighting—Good lighting is an important component of a
successful presentation. You should strive to create an unequal
distribution of light. An audience should always see as much
of the presenter’s face as possible, so most of the light should
be focused on you. Because it is important for you to be able
to read the audience’s faces and body language, some light
should be shed upon them. However, no light should shine
on the screen.
Stage— When presenting on the same level surface that your
audience is on, most people can only see the top one-third of
your body. Therefore, it is recommended that when giving a
presentation to an audience of 25 or more, you stand on a
stage or platform. As more of your body is visible, the easier
it is to communicate with an audience.
Podiums—The best presenters avoid podiums because they
hide 75% of the body and restrict movement. However, many
people feel more comfortable with a podium to hold their notes
and hide their discomfort. If you must use a podium, angle it
at 45 degrees to the audience so that you are not completely
hidden.
Visuals—It is imperative that you make sure your visuals are
large enough and projected far enough for the audience to
see. Eight times the height of an image is the optimal viewing
distance to read 24 point type. The bottom of a screen should
be at least 6 (1.8 meters) above the floor.
Screen—The screen should always be in the center of the
room so that all audience members can see it. Because people
read from left to right, you should always stand to the
audience’s left when discussing visuals.
Seating—Arrange seating according to the dynamics of your
presentation. If the presentation is more than half-a-day, use
classroom style seating—a chair and a desk. If you would
like to encourage audience interaction, use chevron seating,
angling the chairs into a “V” shape. When you have a very
small audience, a “U” shaped arrangement will increase
interchange.
Good Bad Good
Presentation from SHARP
0
5
10
15
20
25
30
Guide to Effective Presentations
E-62
Appendix
d. Rehearsing & Delivery
• The best time to rehearse is the day or evening before,
not a couple of hours before, and the best place to
rehearse is in the actual room. Rehearsing a speech
in a small office is not the same as standing up in
front of 100 people in a hotel ballroom or classroom.
• Due to varying processor speeds of computers,
practice your slide transitions for proper timing.
• Whenever possible, set up your equipment well in
advance to allow adequate time to resolve any
unexpected issues such as lighting, power, seating
and audio.
• Thoroughly check every piece of equipment you bring
along. Make sure you have fresh batteries in your
remote controls and laptop computer. Fully charge
your computer’s battery before the presentation and
connect your AC adaptor for added safety.
• Make sure you are completely familiar with the control
panel on your projector and remote controls.
• If you are using a microphone, check it out before
hand and walk around to see where you might have
problems with feedback. Avoid standing in these
problem areas during your presentation.
e. Presentation Tips
• Before beginning, visualize yourself delivering an
outstanding presentation.
• Know your speech, memorizing at least the first three
minutes of your presentation will allow you to focus
on your rhythm and pacing.
• Speak to early arrivals to help you build a rapport
with the audience and make you feel more
comfortable.
• Do not be overly dependent on your visuals by reciting
what your audience is already reading. Know your
material well enough to be able to deliver the
presentation with ease. Use your visuals to emphasize
keypoints.
• Be sure to project your voice clearly and use eye
contact to maintain audience attention.
• Do not wait until halfway through your presentation to
get your point across. If you wait and try to create a
“build-up”, you may lose some of your audience along
the way.
• Keep your audience’s attention. As most people only
focus for 15 to 20 minutes during a one-hour
presentation, it is important to recapture their attention
periodically. Use phrases like, “This is critical to my
point” or “This is absolutely fundamental” to remind
them you are saying something they need to hear.
Guide to Effective Presentations
E-63
Appendix
Aspect ratio
Width and height ratio of an image. The normal aspect ratio of a computer and video image is 4 : 3. There are also wide
images with an aspect ratio of 16 : 9 and 21 : 9.
Auto sync
Optimizes projected computer images by automatically adjusting certain characteristics.
Background
Initial setting image projected when no signal is being input.
Clock
Clock adjustment is used to adjust vertical noise when clock level is incorrect.
Compatibility
Ability to use with various image signal modes.
Composite sync
Signal combining horizontal and vertical sync pulses.
Digital keystone correction
Function to digitally correct a distorted image when the projector is set up at an angle.
Direct digital computer input
Digital input terminal developed by Silicon Image that can receive a digital signal from the PC platform.
DMD
Digital Micromirror Device™ (DMD™) by Texas Instruments.
Dot by dot
Mode that projects images in their native resolution.
Fit to screen
Function to adjust an image without keeping a native aspect ratio other than 4 : 3, and project it in a 4 : 3 ratio.
GUI
Graphical User Interface. User interface with graphics that allow easier operation.
I/P conversion
Function to convert an image between “Interlaced” and “Progressive” scan displays.
Intelligent compression and expansion
High quality resizing of lower and higher resolution images to fit the projector’s native resolution.
IrCOM
Function to transmit still images from a computer, hand-held PC or digital still camera via infrared communication for
“Wireless Presentations”.
IrDA
Standard protocol for wireless communication.
IrTranP
Standard format (protocol) for transmission of images.
PDF
Portable Document Format. Documentation format used to transfer text and images from the CD-ROM.
Phase
Phase shift is a timing shift between isomorphic signals with the same resolution. When phase level is incorrect, the
projected image typically displays horizontal flicker.
Presentation tools
Helpful tools used to emphasize keypoints throughout a presentation.
RS-232C
Function to control the projector from the computer by using the RS-232C ports on the projector and computer.
Startup image
The image displayed when the projector is turned on.
Status function
Displays the settings of each adjustment item.
Sync
Synchronizes the resolution and phase shift of two signals. When receiving an image with a resolution different from that of
the computer, the projected image may be distorted.
Sync on green
Video signal mode of a computer which overlaps horizontal and vertical sync signal to green color signal pin.
Glossary
E-64
Appendix
Index
A
AC socket......................................................................... 11
ADJUSTMENT buttons ..................................................... 23
Aspect ratio ...................................................................... 36
Audio adjustments ........................................................... 28
AUDIO INPUT terminal .................................................... 11
AUDIO INPUT terminals ................................................... 13
Automatic power shutoff function .................................... 38
Auto sync adjustment ...................................................... 30
AUTO SYNC button.......................................................... 29
B
Background ..................................................................... 41
BACKLIGHT button .......................................................... 22
BLACK SCREEN button ................................................... 37
C
Carrying bag .................................................................... 51
Ceiling-mount ................................................................... 20
CeilingⳭRear ................................................................... 43
Clock ................................................................................ 29
Computer audio cable ..................................................... 11
Computer cable ............................................................... 11
Cooling fan (Exhaust vent) ............................................... 5
D
Digital keystone correction .............................................. 19
DIN-D-sub RS-232C cable............................................... 14
Dot by dot ........................................................................ 36
E
ENLARGE button ............................................................. 34
ENTER button................................................................... 23
F
Fit to screen ..................................................................... 36
Foot releases.................................................................... 19
FREEZE button ................................................................. 33
G
GAMMA button ................................................................ 35
GUI (Graphical User Interface) ........................................ 23
I
INPUT 1 port .................................................................... 11
INPUT 2 port .................................................................... 12
INPUT button.................................................................... 17
Intelligent compression and expansion ........................... 3
I/P conversion .................................................................. 39
IrCOM............................................................................... 25
IrCOM button ................................................................... 25
IrCOM sensor ................................................................... 25
IrDA .................................................................................. 59
IrTranP .............................................................................. 59
K
Kensington Security Standard connector ........................ 49
KEYSTONE button ........................................................... 19
L
LAMP REPLACEMENT indicator ...................................... 47
LASER POINTER button................................................... 22
LEFT-CLICK button .......................................................... 22
Lens cap .......................................................................... 51
Lens cap strap ................................................................. 51
M
MENU button.................................................................... 23
MOUSE/ADJUSTMENT switch ......................................... 21
MOUSE buttons ............................................................... 22
Mouse control cable for IBM PS/2 ................................... 15
Mouse control cable for Mac ........................................... 15
Mouse control serial cable ............................................... 15
MUTE button .................................................................... 17
O
On-screen display language ........................................... 26
P
PDF .................................................................................. 6
Phase ............................................................................... 29
Picture adjustments ......................................................... 27
POWER buttons ............................................................... 16
Power cord ....................................................................... 11
POWER indicator ............................................................. 16
Presentation tools............................................................. 44
R
Rear projection................................................................. 20
Remote control ................................................................. 21
Remote control sensor ..................................................... 21
Remote mouse receiver ................................................... 21
RESIZE button .................................................................. 36
RIGHT-CLICK button ........................................................ 22
RS-232C port ................................................................... 14
S
Sharp Advanced Presentation Software (SAPS) .............. 25
Special mode adjustment ................................................ 32
Startup image .................................................................. 42
Status function ................................................................. 45
S-VIDEO INPUT terminal .................................................. 13
Sync ................................................................................. 30
Sync on green .................................................................. 52
T
TEMPERATURE WARNING indicator ............................... 47
TOOLS button .................................................................. 44
U
UNDO button ................................................................... 19
V
VIDEO INPUT terminal ..................................................... 13
VOLUME buttons ............................................................. 17
W
Wireless mouse ................................................................ 21
E-65
Appendix
SHARP CORPORATION
OSAKA, JAPAN
Printed in Japan
TINS
-
6786CEZZ
T2278-A
9P08
-
JWG
