MCM2150
2014 © WOOX Innovations Limited. All rights reserved.
Philips and the Philips’ Shield Emblem are registered
trademarks of Koninklijke Philips N.V. and are used
by WOOX Innovations Limited under license from
Koninklijke Philips N.V.
MCM2150_05_UM_V2.0
EN User manual
1 Important
Safety
This ‘bolt of lightning’ indicates uninsulated material within the device may
cause an electrical shock. For the safety of everyone in your household,
please do not remove the covering.
The ‘exclamation mark’ calls attention to features for which you should
read the enclosed literature closely to prevent operating and maintenance
problems.
WARNING: To reduce the risk of re or electric shock, the device should
not be exposed to rain or moisture and objects lled with liquids, such as
vases, should not be placed on the device.
CAUTION: To prevent electric shock, fully insert the plug. (For regions
with polarized plugs: To prevent electric shock, match wide blade to wide
slot.)
Important Safety Instructions
• Follow all instructions.
• Heed all warnings.
• Do not use this device near water.
• Clean only with dry cloth.
• Do not block any ventilation openings. Install in accordance with
the manufacturer’s instructions.
• Do not install near any heat sources such as radiators, heat
registers, stoves, or other devices (including ampliers) that
produce heat.
• Protect the power cord from being walked on or pinched,
particularly at plugs, convenience receptacles, and the point where
they exit from the device.
• Only use attachments/accessories specied by the manufacturer.
• Use only with the cart, stand, tripod, bracket,
or table specied by the manufacturer or sold
with the device. When a cart is used, use caution
when moving the cart/device combination to
avoid injury from tip-over.
• Unplug this device during lightning storms or
when unused for long periods of time.
• Refer all servicing to qualied service personnel. Servicing is
required when the device has been damaged in any way, such as
power-supply cord or plug is damaged, liquid has been spilled or
objects have fallen into the device, the device has been exposed to
rain or moisture, does not operate normally, or has been dropped.
• Battery usage CAUTION – To prevent battery leakage which may
result in bodily injury, property damage, or damage to the unit:
• Install all batteries correctly, + and - as marked on the unit.
• Batteries (packed or installed) shall not be exposed to
excessive heat such as sunshine, re or the like.
• Remove batteries when the unit is not used for a long time.
• The device shall not be exposed to dripping or splashing.
• Do not place any sources of danger on the device (e.g. liquid lled
objects, lighted candles).
• Where the MAINS plug or an appliance coupler is used as the
disconnect device, the disconnect device shall remain readily
operable.
Warning
• Never remove the casing of this device.
• Never lubricate any part of this device.
• Never place this device on other electrical equipment.
• Keep this device away from direct sunlight, naked ames or heat.
• Never look into the laser beam inside this device.
• Ensure that you always have easy access to the power cord, plug, or adaptor to
disconnect this device from the power.
Mains fuse
This information applies only to products with a UK mains plug.
This product is tted with an approved molded plug. If you replace the
fuse, use one with:
• the ratings shown on the plug,
• a BS 1362 approval, and
• the ASTA approval mark.
Contact your dealer if you are not sure about what type of fuse to use.
Caution: To conform with the EMC directive (2004/108/EC), do not
detach the plug from the power cord.
2 Your micro system
Congratulations on your purchase, and welcome to Philips! To fully benet
from the support that Philips offers, register your product at www.philips.
com/welcome.
Introduction
With this unit, you can:
• enjoy audio from discs, USB devices, and other external devices;
• listen to radio stations.
You can enrich sound output with below sound effect:
• Digital Sound Control (DSC)
The unit supports these media formats:
What’s in the box
Check and identify the contents of your package:
SOURCE
AUDIO IN
VOLUME
CD
AUDIO IN
PRESET/ALBUM
MUTE
SHUFFLE
CLOCKSLEEP
TIMER
PROG
SOUND
FM
VOL
DISPLAY
REPEAT
SOURCE
AUDIO IN
VOLUME
3 Get started
Caution
• Use of controls or adjustments or performance of procedures other than herein may
result in hazardous radiation exposure or other unsafe operation.
Always follow the instructions in this chapter in sequence.
If you contact Philips, you will be asked for the model and serial number
of this apparatus. The model number and serial number are on the back
of the apparatus. Write the numbers here:
Model No. __________________________
Serial No. ___________________________
Connect speakers
Note
• For optimal sound, use the supplied speakers only.
• Connect only speakers with impedance that is the same or higher than the supplied
speakers. Refer to the Specications section of this manual.
Connect power
Caution
• Risk of product damage! Ensure that the power supply voltage corresponds to the
voltage printed on the back or the underside of the unit.
• Risk of electric shock! When you unplug the AC power cord, always pull the plug from
the socket. Never pull the cord.
• Before you connect the AC power cord, ensure that you have completed all other
connections.
Demonstrate the features
In the standby mode, you can demonstrate features by pressing .
» The features are displayed one by one across the display
panel.
• To turn off the demonstration, press again.
Prepare the remote control
Caution
• Risk of explosion! Keep batteries away from heat, sunshine or re. Never discard
batteries in re.
• Risk of product damage! When the remote control is not used for long periods,
remove the batteries.
To insert the remote control battery:
1 Open the battery compartment.
2 Insert the supplied AAA battery with correct polarity (+/-) as
indicated.
3 Close the battery compartment.
Set clock
1 In standby mode, press and hold CLOCK on the remote control
for more than two seconds.
» [24H] or [12H] hour format is displayed.
SPEAKER OUT (8Ω)
FM
ANTENNA
100-240 V~50/60 Hz
AC MAINS~
SPEAKER OUT (8Ω)
SPEAKER OUT (8Ω)
FM
ANTENNA
100-240 V~50/60 Hz
AC MAINS~
2 Press / to select [24H] or [12H] hour format, and then
press CLOCK.
» The hour digits are displayed and begin to blink.
3 Press / to set hour, and then press CLOCK.
» The minute digits are displayed and begin to blink.
4 Repeat step 3 to set minute.
Note
• If no button is pressed in 90 seconds, the system exits clock setting mode automatically.
Tip
• You can view clock information in power on mode by pressing CLOCK.
Turn on
Press .
» The unit switches to the last selected source.
Switch to standby mode
Press again to switch the unit to standby mode.
» The clock (if set) is displayed on the panel.
Switch to ECO standby mode:
Press and hold
for three seconds.
» The display panel is dimmed.
Note
• The unit switches to Eco Power Standby mode after 15 minutes in standby mode.
Switch between standby mode and ECO standby mode:
Press and hold
for more than two seconds.
4 Play
Play from disc
Play from USB
Note
• Make sure that the USB device contains playable audio content.
Control play
/
Select a folder.
/
Select an audio le.
Pause or resume play.
SOURCE
AUDIO IN
VOLUME
AUDIO IN
PRESET/ALBUM
MUTE
CLOCK SLEEP
TIMER
PROG
SOUND
FM
VOL
SHUFFLE
CD
REPEAT
DISPLAY
CD
SOURCE
AUDIO IN
VOLUME
AUDIO IN
PRESET/ALBUM
MUTE
CLOCK SLEEP
TIMER
PROG
SOUND
FM
VOL
SHUFFLE
CD
REPEAT
DISPLAY
USB
