POWER PER CHANNEL:
• 6 X 150 wRMS @ 4 ohms at less than 1% THD
• 4 x 200 wRMS @ 2ohms + 2 x 250 wRMS
• 4 x 150 wRMS @ 4ohms + 1 x 500 wRMS (Ch 5+6, Bridged @ 4ohms)
• 4 x 150 wRMS @ 4ohms + 1 x 600 wRMS (Ch 5+6, Bridged @ 2ohms)
INPUTS SWITCH
• 2 = Use input 1+2 and route them to channels 3+4 and 5+6
• 4 = Use input 1+2 and 3+4
1+2 and 3+4 are attenuated by -6dB and routed to 5+6.
This allows constant bass loudness when you fade between 1+2 and 3+4.
• 6 = Use all six inputs.
CHANNELS 1 & 2 CROSSOVER CONFIGURATION
• Flat: Full Range Signal. No crossover activated.
• HP: Activates the High Pass Filter for a midbass or tweeter.
• Copy 3 & 4: Copies the signals and filters from channels 3 & 4 to channels 1 & 2. Use this mode when you need
a band pass filter on all four channels. Recommended when bridging channels 1, 2, 3, 4.
CHANNELS 3 & 4 CROSSOVER CONFIGURATION
• Flat: Full Range Signal. No crossover activated.
• HP: Activates the High Pass filter.
• LP/BP: Activates the selection of either a Low Pass filter for woofer or a Band Pass filter for midrange.
CHANNELS 5 & 6 CROSSOVER CONFIGURATION
• Flat: Full Range Signal. No crossover activated.
• HP: Activates the High Pass filter.
• LP/BP: Activates the selection of either a Low Pass filter for woofer or a Band Pass filter for midrange.
• Sub Mode: Inputs 5+6 are mixed to mono for bridge mono operation. Crossover slopes become 24dB.
The subwoofer remote volume control is activated. There is a clip distortion light on the remote volume control.
If you see this light is on, reduce volume until the light goes out so that you do not damage your speaker.
FDP 6.900 : SIX CHANNEL AMPLIFIER
Operation / Configuration
