e great-sounding NexD™ switching technology
that debuted in the original XD ampli ers carries
over unchanged to the XDv2’s, as does the
compact chassis design and exible feature set.
Under the hood, we have done some upgrading
to give the XDv2’s even more exibility and
integration capabilities than their predecessors.
All XDv2 models o er the convenience of automatic
turn-on (signal or DC-o set sensing), making them easier
to integrate with OEM systems. We have also upgraded
the input sections to have equal capabilities as our agship
HD ampli ers, accepting a wide range of input signals,
from line-level all the way to high-power speaker level
Even better.
signals (with a dual-range switch). e nal tweak is an
improved remote level circuit, with more linear behavior.
In all of our full-range XDv2 ampli ers, each
channel pair o ers a powerful 75W x 2 into 4 ohms,
bridgeable to 200W x 2 into 4 ohms, for high-power
applications. All you have to decide is how many
channels you need, and then choose the appropriate
model: 2-channel, 4-channel, 6-channel or 8-channel.
Whether you are building a simple two-
channel system or a really sophisticated, multi-
way setup with active ltering, there is an XDv2
full-range ampli er to ll almost any need.
XDv2: Full-Range Ampli ers
www.jlaudio.com
10369 North Commerce Parkway • Miramar, Florida • 33025 • USA
©2014 JLAudio, Inc. • “JLAudio”, “Ahead of the Curve” and the JLAudio logo are registered trademarks of JLAudio, Inc.
Due to our policy of continuous product development, all specifications are subject to change without notice.
SKU#97213 12-2013
Printed in U.S.A.
XD200/2v2
200W, 2-channel
full-range amplifier
XD800/8v2
800W, 8-channel
full-range amplifier
XD400/4v2
400W, 4-channel
full-range amplifier
XD600/6v2
600W, 6-channel
full-range amplifier
XDv2 Full-Range Amplifiers
Model Description Continuous Power (RMS Method)
THD+N
at Rated
Power
Frequency
Response
Damping Factor
Dimensions
H x W x D
XDv2 Ampli ers
XD200/2v2
Class D, Full-Range
2-Channel Ampli er
75W RMS x 2 @ 4 ohms
100W RMS x 2 @ 2 ohms
Bridged: 200W RMS x 1 @ 4 ohms
(Ratings at 14.4V supply voltage)
<1%
12 Hz - 22 kHz
(+0, -1dB)
>150 @ 4 ohms
per ch./ 50 Hz
>75 @ 2 ohms
per ch. / 50 Hz
2.05 in. x 6.85 in. x 7.09 in.
52 mm x 174 mm x 180 mm
XD400/4v2
Class D, Full-Range
4-Channel Ampli er
75W RMS x 4 @ 4 ohms
100W RMS x 4 @ 2 ohms
Bridged: 150W RMS x 2 @ 8 ohms
Bridged: 200W RMS x 2 @ 4 ohms
(Ratings at 14.4V supply voltage)
<1%
12 Hz - 22 kHz
(+0, -1dB)
>150 @ 4 ohms
per ch./ 50 Hz
>75 @ 2 ohms
per ch. / 50 Hz
2.05 in. x 8.52 in. x 7.09 in.
52 mm x 217 mm x 180 mm
XD600/6v2
Class D, Full-Range
6-Channel Ampli er
75W RMS x 6 @ 4 ohms
100W RMS x 6 @ 2 ohms
Bridged: 150W RMS x 3 @ 8 ohms
Bridged: 200W RMS x 3 @ 4 ohms
(Ratings at 14.4V supply voltage)
<1%
12 Hz - 22 kHz
(+0, -1dB)
>150 @ 4 ohms
per ch./ 50 Hz
>75 @ 2 ohm
per ch. / 50 Hz
2.05 in. x 10.23 in. x 7.09 in.
52 mm x 260 mm x 180 mm
XD800/8v2
Class D, Full-Range
8-Channel Ampli er
75W RMS x 8 @ 4 ohms
100W RMS x 8 @ 2 ohms
Bridged: 150W RMS x 4 @ 8 ohms
Bridged: 200W RMS x 4 @ 4 ohms
(Ratings at 14.4V supply voltage)
<1%
12 Hz - 22 kHz
(+0, -1dB)
>150 @ 4 ohms
per ch./ 50 Hz
>75 @ 2 ohms
per ch. / 50 Hz
2.05 in. x 14.73 in. x 7.09 in.
52 mm x 374 mm x 180 mm
Remote Level Control (HD-RLC)
With the addition of an HD-RLC you can
control the overall level of the subwoofer
from the front of your vehicle.
