Cleansui Instruction Manual
Model: CB013E,CB073E
Thank you very much for purchasing Cleansui. Read these instructions carefully before
use. A warranty card is included with this product, and this must be stored for future
reference.
Main unit (Complete with 1 cartridge)
Attachment set
Instruction manual
Cartridge replacement reminder sticker
● Attachment Set
Contact your dealer immediately in the event of missing accessories
or damage.
Instruction Manual Contents
1. Checking All Accessories
2. Safety Precautions
3. Precautions During Use
4.
Faucets to which Cleansui cannot be attached
5. Names of Parts
6. Attaching/Replacing Cartridge
7. Selecting the Attachment Accessory
8. Installations
9. 3-way Diverter lever
10. Replacement of Cartridge
11. Maintenance
12. Troubleshooting
13. Specifications
14. After-Sale Service
1. Checking All Accessories
Check to ascertain that all of the following items are included in the package when
it is first opened.
CB013E
CB073E
● Do not use with water that is microbiologically unsafe or unknown
quality without adequate disinfection before or after the system.
● Contact the dealer in the event of the product being damaged. Do
not touch the damaged area under any circumstances.
Forbidden
For your safety, please read the precautions carefully before
installation or usage. Disregard or improper installation/usage
may cause damages or results in dire consequences.
2. Safety Precautions
●The following warning symbols are used in this manual.
● Use tap water that meet the standard requirements for drinking
water.
(Failure to observe this may result in illness.)
Warning
Warning
Never ignore this instruction. Failure to
observe may result in injury or damage to
surrounding assets.
Indicates the actions that are prohibited for
safety precautions.
Indicates that the product must not be
dismantled under any circumstances.
Indicates the instructions that must be
observed.
Forbidden
Instruction
Instruction
No Dismantling
●
Best to use/drink instant filtered water as soon as possible, fresh water is
better than stale water kept for some time. If you like to store filtered
water, we recommend storage in a closed lid container in a refrigerator.
(There is a risk-bacteria, other impurities from the air etc. may settled in stale water, as residual
chlorine is removed)
Instruction
Instruction
Instruction
Forbidden
Forbidden
●
Do not use filtered water for breeding fishes, etc.
●
Run the filtered water for at least 10 seconds before using your Cleansui
for the first time of usage every day.
(How to maintain best hygiene care to avoid spread of bacteria, etc.)
●
Run the filtered water for at least 1 minute to discharge accumulated
water when Cleansui has not been used for 2 or more days.
(How to maintain best hygiene care to avoid spread of bacteria, etc.)
●
Do not touch the filtered water outlet with hands.
(How to maintain best hygiene care to avoid spread of bacteria, etc.)
●
Always ensure that the main unit and cartridge are used in combination as
a set.
(Failure to observe this may result in damage or water leakage.)
●
Turn the tap (ON/OFF) very slowly.
(Failure to observe this may result in damage or water leakage.)
●
Please replace the cartridge when the flow rate of filtered water drops.
(Failure to observe this may result in damage or water leakage.)
●
Please reduce tap water flow speed especially in areas with very high
water pressure.
(The cartridge purifying function may not be at optimum filtration performance if the
waterpressure is too high.)
(Failure to observe this may result in damage or water leakage.)
Using Filtered water
The Risk of the Filtering Abnormalities, Water leakage and Damages
Maintaining Hygiene
Instruction
Forbidden
No
Dismantling
●
Do not allow Cleansui to freeze.
(Failure to observe this may result in damage or water leakage.)
●
Do not run water with a temperature of 35 degrees Celsius or higher
through to the cartridge/filtered water mode.
(Failure to observe this may reduce the effectiveness of the activated carbon and result in
absorbed properties (odors, etc.) which may affect the filtered water.)
●
Do not run water with a temperature of 60 degrees Celsius or higher
through to the straight tap water or spray tap water mode.
(Failure to observe this may result in damage or water leakage.)
●
Do not obstruct the filtered water outlet or attach other equipment to it.
(Failure to observe this may result in damage or water leakage.)
●
Do not use detergent or alcohol, etc., to clean the product.
(Failure to observe this may result in cracking, scratching, discoloring or malformation. See [11.
Maintenance] for further details.)
●
Do not submerge Cleansui in water during maintenance.
(Failure to observe this may result in damage.)
The Risk of the Filtering Abnormalities, Water leakage and Damages
●
Do not connect flash stopcock-type water heaters or
stopcock-type electric water heaters.
(Failure to observe this may result in damage or water leakage.)
●
Do not dismantle the unit or the cartridge.
• See [12. Troubleshooting] if you think something is wrong.
●
Do not install in locations that are close to naked flames or high
temperatures.
(Failure to observe this may result in damage or water leakage.)
3. Precautions During Use
4. Faucets to which Cleansui cannot be attached
●
There are incompatible faucets to which Cleansui cannot be attached.
• See [4. Faucets to which Cleansui cannot be attached] for further details.
●
Precautions when attaching Cleansui to mixed-water faucets.
• There are rare incidents when the gas frames on the water heater will not ignite properly.
• There are incidents when the safety valve on the water heater operates if it is not equipped with a non-return valve.
• There are incidents when the temperature of the shower water is not stable in locations with low water pressure and
when storage heaters are in use.
●
The lifespan/replacement period of a cartridge will differ in accordance to the volume of filtered water,
tap water quality, water pressure etc.
• See [10. Replacement of Cartridge] for further details.
●
It is not advisable use hot-spring water, well water or any other water that contains large amounts of
impurities.
●
The working pressure for using Cleansui is between 0.07 and 0.35MPa.
●
When the unit has not been used for a long period of time or the tap water has a red tinge (turbidity,)
allow tap water to flow through straight or spray tap water mode for some time before switching to
instant filtered water mode.
●
This model cannot remove saline (seawater) or metallic ions present in water, although it can remove
heavy metal particles/turbidity. It is also not capable of converting hard water to soft water.
●
Use the filtered water for drinking, cooking and washing of vegetables/fruits.
• The lifespan of the cartridge will be greatly reduced if it is used for washing dishes, etc.
Optional special attachment accessories (sold seperately on request) may fit faucet less than 10 mm
when accessories supplied do not fit.
Contact your dealer.
Less than 10mm
Shower head
Sensor head
With a diameter of less than
13mm or 24mm or more
Faucets with rectangular
or oval shaped outlets
● Cross-section of Unit
5. Names of Parts
Cartridge
● Rear View
Streaming tap
water outlet
Shower tap
water outlet
Filtered water
outlet
Rotary ring
Faucet rubber seal
Filtering net
Attaching mark
Diverter lever
Unit
The case of CB073E
* Regardless of the water flow rate, it displays the elapsed me.
Reset
StartReplace
Lifeme:
approx. 3 months
When reset
Lifeme:
approx. 2 months
Lifeme:
approx. 1 month
Lights up everything
The display counts down from me to replace the cartridge by pressing the reset
buon. The bar will disappear one by one about every half a month.
-
At the first me to use the product: Press the
reset buon unl the display lights up
everything. (approx. 1 sec.)
-
Aer the replacing the cartridge: Press the
reset buon unl the display lights up one bar.
(approx. 3 sec.)
Time to replace
the cartridge
At the first me to use the product and aer
replacing the cartridge, please press the reset
buon.
CB013E
CB073E
6. Attaching / Replacing Cartridge
●
Ensure water supply is completely turned off when removing or attaching cartridges.
●
Write the date of cartridge on first day of usage (and at every cartridge replacement) on sticker
provided, stick the sticker on the cartridge to provide a reminder for next replacement.
●
Attach/replace new cartridge in a clean space to avoid any water splash or contamination.
• Avoid water splash from used cartridge.
●
Make sure there is sealing packing of connection fitted.
Attaching cartridge
Align the attaching mark of
cartridge with the front of body
and slide it to back.
Until the sound the attaching is completed
Sealing packing of connection
Attaching mark The correct position Not completed
Top view
Detaching cartridge
Slide the cartridge to front until the sound the detaching is
comleted.
7. Selecting the Attachment Accessory
●
Check your faucet type. Look closely at the edge/tip-that will tell you which attachment will be best
fit. Use/fix the best fit attachment accessory.
• Store unused attachment accessory as they may be useful in future if you change your faucet or move to a new
home.
●
There are faucets to which Cleansui cannot be attached.
• Refer to [4. Faucets to which Cleansui cannot be attached] for further details.
●
Check to ensure that there are no cracks or burrs on the edge of the faucet.
●
Unstable and loose connections with the faucet may result in Cleansui leaking or being damaged.
8. Installations
Outer screw tip faucets
CL
540
CL
521
CL
531
W22
(white)
M22
(gray)
W23
(white)
M24
(gray)
1
Remove the metal loose tip on
faucet in a clockwise direction.
Remove any loose rubber
washer that may still be inside
the current faucet.
2
Insert the new rubber
washer into the neck.
Inner screw tip faucets
Option
1
Remove the metal loose tip on
faucet in a clockwise direction.
Remove any loose rubber
washer that may still be inside
the current faucet.
Faucets to which Cleansui can be affixed
using optional
attachment
2
Insert the new rubber
washer into the neck.
Straight edge faucets
1
Insert the rotary ring inside
the screw-stopper ring
2
Temporarily tighten the
four screws
A wrench may be necessary if it is
too tight.
A wrench may be necessary if it is
too tight.
*
When the M24 is to be used.
The W23 (white)
fitting is equipped
with an O-ring
packing, so it is not
necessary to insert
the rubber washer.
more than
10 mm
3
4
5
Set the main unit in place
Tighten the rotary ring gently
but not very tightly
to complete the procedure
Use a coin or something
similar (slot into rear indent
of accessory) and tighten
gently.
Note that it will be impossible to
tighten it correctly in Step #5 as
excessive turning prevent tightening.
*
Same for both
W23 (white) and
M24 (gray)
Slip the rotary ring into the faucet.
In anti-clockwise direction, tighten
the attachment with washer intact.
Turn the rotary ring so that it is face
upward, and then tighten/position
to fit nicely onto main unit ring
3
Slip the rotary ring into the faucet.
In anti-clockwise direction, tighten
the attachment with washer intact.
Turn the rotary ring so that it is face
upward, and then tighten/position
to fit nicely onto main unit ring
3
Insert the rubber washer, turn the
rotary ring once on the main unit’s
ring portion, tighten gently.
4
Firmly press the unit onto the
bottom of the faucet and tighten the
screws. Make sure that the faucet is
located in the center of the screw
stopper ring
5
Tighten the rotary ring
tightly to complete the
procedure
9. 3-way Diverter dial
Run water on and off from the faucet, use the lever on the unit to switch between tap water/straight,
tap water/spray or filtered water. See the following illustrations for further details.
●Tap water (straight)
Set the lever to
" ".
●Tap water (spray)
Set the lever to
" ".
●
Filtered water
Set the lever to
" ".
●
Bubbles may be present in filtered water when used first time, this is not a defect. It denotes that presence of air in
the cartridge.
• It means that air is contained within the main unit.
When you use the product for a first time and run the filtered water immediately after replacing the
cartridge
• Shift the diverter lever to the position of spray mode, and turn the tap ON very slowly and then change the
diverter lever to the position of filtered water mode.
• Check for leaks and other abnormal signs and then change the diverter lever to the position of filtered
water mode.
(Unstable and loose connections with the faucet may result in the product leaking or being damaged.)
10. Replacement of Cartridge
The lifespan of a cartridge may vary subject to the volume of water purified, source water quality,
water pressure etc.
1. When the odor of residual chlorine or other odors are obvious.
➝ The performance of the activated carbon have deteriorated.
2. When the flow rate/volume of purified water is substantially lower than usual speed e.g. it
takes 15 or more seconds to fill a cup.
➝ The hollow fiber membrane filters are clogged. The flow rate will not increase even when the faucet is switch
on maximum.
•
There is a possibility that cracks have appeared (when it is badly clogged), so it is necessary to replace the cartridge.
*
Recommendation: Please replace the cartridge when you notice the following.
Replacement Cartridge : CBC03E
Cleansui unique state-of-art filtration system remove unhealthy substances
but leave healthy minerals intact to give you clean natural delicious water
straight from your tap.
11. Maintenance
1. Rinse Cleansui with water (no detergent, etc.) prior to usage.
2. The rubber seal is expendable, replace when it is old or worn.
3. Rinse the shower head with water and a soft brush (do not use detergent, etc.) to clean it. Set
the position of the 3 way diverter lever to tap water spray for a few moments after cleaning it.
Do not use detergent, cleaner, thinner, benzene, alcohol, oil or any other agent for cleaning
Cleansui.
• Failure to observe this may result in cracks, scratches, discoloring or malformation.
• Wipe immediately if any of these substances come into contact with the unit.
Forbidden
LCD cleaning
➝
Wipe the LCD with a clean cloth.
●
Display has a life of approximately five years.
●
At the end of its life, it needs to be disposed correctly. The battery is sealed within the unit,
dispose the whole unit in accordance with local regulations for battery disposal.
You will be able to order a new unit from the dealer.
CB073E
Cartridge: CBC03E
13. Specifications
Model number
Material
Filter media
Filtration flow rate
Minimum water pressure
Dimensions
Weight (
when filled with water
)
131 (W) X 100 (D) X 59 (H) mm
Filtration Performance
*Based on results of JIS S 3201
Free residual chlorine
Turbidity
Trihalomethanes
Chloroform
Bromodichloromethane
Dibromochloromethane
Bromoform
900 litres
900 litres
900 litres
900 litres
900 litres
900 litres
900 litres
80% removed
50% filtration flow rate
80% removed
80% removed
80% removed
80% removed
80% removed
200g (300g)
1.6litres/minute
0.07MPa
Polyethylene hollow fiber membrane, activated carbon
ABS
Removal performance *Based on JWPAS B.100.
Iron (fine particle) 80% removed
Aluminum (neutral) 80% removed
*These removal substances detemined by Japan Water Purifier Association.
220g (320g)
CB013E CB073E
12. Troubleshooting
Water leakage at
attachment accessory
Had the accessories been attached to
the faucet correctly?
Is the tip of the faucet damaged?
Is the rubber seal damaged?
Is the filtering net stained?
Is the shower head stained?
Could the hollow fiber membrane be
clogged. Refer to [10. Replacement of
Cartridge] for further details.
The water pressure is low
The water temperature is low
Is the cartridge lifespan up, is it due for
replacement. Refer to [10. Replacement of
Cartridge] for further details.
This is not a defect.
Re-attach the unit from the beginning.
The faucet need to be repaired, or the heat-insulation
packing needs to be replaced.
Replace the rubber seal.
Rinse the shower head with water and a sanitary toothbrush (do
not use detergent, etc.) to clean it. Set the position of the 3 way
diverter lever to tap water spray for a few moments after
cleaning it.
Replace the cartridge.
This is not a defect
This is not a defect
Replace the cartridge.
This is not a defect.
Air is present in the unit.
Shower head output is
not even
Low filtered water
volume
Strange taste or odor in
filtered water
Bubbles in filtered water
when used for the first
time
Low water volume/slow
flow from both the tap
water and shower head
Problem Potential Causes Recovery
13. Specifications and Performance
NSF/ANSI Standard 42 – Aesthetic Effects
Substance
Influent Challenge
Concentration
Overall Percent
Reduction
Reduction
Requirement
Chlorine 2.0 mg/L + /-10 % 95.8 %
≥
50 %
NSF/ANSI Standard 53 – Health Effects
Substance
Influent Challenge
Concentration
Overall Percent
Reduction
Reduction Requirement
Cysts minimum 50,000/L > 99.99 % 99.95 %
Substance
Influent Challenge
Concentration
Overall Percent
Reduction
Maximum permissible product
water concentration
Turbidity 11 ± 1 NTU 99.1 % 0.5 NTU
Maintenance according to the manufacturer’s instructions is critical for proper filter performance.
Filter life should not exceed 900 liters. If filtering time is notably increased, replace
the filter earlier.
This system has been tested according to NSF/ANSI 42 and 53 standards by NSF International
for reduction of the substances listed above. The concentration of the indicated substances in water
entering the system was reduces to a concentration less than or equal to the permissible limit for water
leaving the system, as specified in NSF/ANSI 42 and 53.
The system conforms to NSF/ANSI 42 and 53 for specific performance claims as verified and
substantiated by test data. While testing was performed under standard laboratory conditions,
actual performance may vary.
The use of this system shall comply with applicable state and local laws.
Water pressure (min/max): 70 kPa / 350 kPa. Capacity: 900 liters.
Service flow rate: 1.6 l/min.
Filtered water temperature (min/max): 1 °C /35 °C Electrical requirements: none.
Replacement Cartridge: CBC03E
Model # CB013E, CB073E
Model # CB013E, CB073E
14. After - Sale Service
●
Warranty
Cleansui water purifier comes with a warranty. Full details including dealer's name,
the date of purchase etc. must be completed accurately and duly return. The validity
of the warranty is one years from the date of purchase, subject to terms & conditions
listed on warranty.
●
Requested Repairs
1. When repairs are required during the validity period of the warranty, take the
product and the warranty card to your dealer.
2. Seek your dealer's advice if repairs are required after warranty lapse. There will
be a chargeable repair service fee.
3. Parts for Cleansui water purifier (including the cartridge) will be kept in stock
and made available for a minimum of five years after the product has been
discontinued.
Verbatim USA
1200 West W.T. Harris Boulevard
Charlotte, North Carolina 28262
USA
Tel. (704) 547-6500
Fax. (704) 547-6619
Verbatim Argentina SA
Irala 1950 1er piso
Capital federal (1644)
Buenos Aires Argentina
TEL/FAX. (+54911) 52742000
www.cleansui.com
• AMERICAS: USA Verbatim Americas LLC.
1200 West W.T. Harris Boulevard Charlotte, North Carolina 28262 USA
• EUROPE/ MIDDLE EAST/ AFRICA: Verbatim Ltd, Prestige House,
23- 26 High Street, Egham, Surrey, TW20 9DU, UK
• AUSTRALIA/ NEW ZEALAND: Verbatim Australia Pty Ltd,
Unit 6, 450 Princes Highway, Noble Park, Victoria, 3174 Australia
