MODEL:HRBM321S
HRBM321
2
Children aged from 3 to 8 years are allowed to load and
unload refrigerating appliances.
Contents
Safety and warning information…........2
Installing your new appliance………....9
Description of the appliance...............10
Reversing the door............…..........11
Operation.............……….…...............14
Using your appliance.…….…..........18
Helpful hints and tips……….…........19
Cleaning and care.....……………….20
Troubleshooting......…………………21
Disposal of the appliance.......…..…22
For your safety and correct usage, before installing and first
using the appliance, read this user manual carefully, including
its hints and warnings. To avoid unnecessary mistakes and
accidents, it is important to make sure that all people using the
appliance are thoroughly familiar with its
operation and safety features. Save these instructions and be
sure that they remain with the appliance if it is moved or sold,
so that anyone using it throughout its life, will be properly
informed on its usage and safety notices.
For the safety of life and property, keep the precautions of
these user's instructions as the manufacturer is not
responsible for damages caused by omission.
Safety for children and others who are vulnerable people
According to EN standard
This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the
hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by
children without supervision.
According to IEC standard
This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning
3
Children should be supervised to ensure that they do not
play with the appliance.
Keep all packaging away from children as there is a risk of
suffocation.
If you are discarding the appliance, pull the plug out of the
socket, cut the connection cable (as close to the appliance
as you can) and remove the door to prevent children playing
from suffering an electric shock or from closing themselves
inside it.
If this appliance, featuring a magnetic door seals, is to
replace an older appliance having a spring lock (latch) on the
door or lid, be sure to make the spring lock unusable before
you discard the old appliance. This will prevent it from
becoming a death trap for a child.
General safety
WARNING —This appliance is intended to be used in
household and similar applications such as
-staff kitchen areas in shops, offices and other working
environments;
-farm houses and by clients in hotels, motels and other
residential type environments;
-bed and breakfast type environments;
-catering and similar non-retail applications.
WARNING — Do not store explosive substances such as
aerosol cans with a flammable propellant in this appliance.
W
ARNING — If the supply cord is damaged, it must be
replaced by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
WARNING — Keep ventilation openings, in the appliance
enclosure or in the built-in structure, clear of obstruction.
WARNING — Do not use mechanical devices or other
means to accelerate the defrosting process, other than those
recommended by the manufacturer.
WARNING — Do not damage the refrigerant circuit.
WARNING — Do not use electrical appliances inside the
food storage compartments of the appliance, unless they are
use of the appliance by a person responsible for their safety.
of the type recommended by the manufacturer.
4
WARNING ―Food needs to be packed in bags before
putting into the refrigerator, and liquids need to be packed
in bottles or capped containers to avoid the problem that
the product design structure is not easy to clean.
The symbol is a warning and indicates the
refrigerant and insulation blowing gas are flammable.
Warning: Risk of fire / flammable materials
WARNING — The refrigerant and insulation blowing gas are
flammable. When disposing of the appliance, do so only at
an authorized waste disposal centre. Do not expose to
flame.
WARNING —When positioning the appliance, ensure the
supply cord is not trapped or damaged.
WARNING —Do not locate multiple portable socket-outlets
or portable power supplies at the rear of the appliance.
Refrigerant
The refrigerant isobutene (R600a) is contained within the
refrigerant circuit of the appliance, a natural gas with a high
level of environmental compatibility, which is nevertheless
flammable. During transportation and installation of the
appliance, ensure that none of the components of the
refrigerant circuit becomes damaged.
The refrigerant (R600a) is flammable.
Replacing the illuminating lamps
WARNING—The illuminating lamps must not be replaced by
the user! If the illuminating lamps is damaged, contact the
customer helpline for assistance.
This warning is only for refrigerators that contain illuminating
lamps.
Electrical safety
1.The power cord must not be lengthened.
2. Make sure that the power plug is not crushed or damaged.
A crushed or damaged power plug may overheat and cause a
fire.
3. Make sure that you can access the main plug of the
appliance.
4. Do not pull the main cable.
5. If the power plug socket is loose, do not insert the power
plug. There is a risk of electric shock or fire.
6.You must not operate the appliance without the interior
lighting lamp cover.
7.The fridge is only applied with power supply of single phase
alternating current of 220~240V/50Hz. If fluctuation of voltage
in the district of user is so large that the voltage exceeds the
above scope, for safety sake, be sure to apply A.C. automatic
voltage regulator of more than 350W to the fridge. The fridge
must employ a special power socket instead of common one
with other electric appliances. Its plug must match the socket
with ground wire.
It is dangerous to alter the specifications or modify this
product in any way.
Any damage to the cord may cause a short circuit, fire, and/or
electric shock.
-Avoid opening flames and sources of ignition.
-Thoroughly ventilate the room in which the appliance is
situated.
5
If the refrigerant circuit should be damaged:
WARNING — Refrigerators contain refrigerant and gases in
the insulation. Refrigerant and gases must be disposed of
professionally as they may cause eye injuries or ignition.
Ensure that tubing of the refrigerant circuit is not damage
prior to proper disposal.
6
Do not place food products directly against the air outlet on
the rear wall.
Store pre-packed frozen food in accordance with the frozen
food manufacture’s instructions.
The appliances manufactures storage recommendations
should be strictly adhered to relrelevant instructions for
storage.
Do not place carbonated or fizzy drinks in the freeze
compartment as it creates pressure on the container,which
may cause it to explode,resulting in damage to the
appliance.
Frozen food can cause frost burns if consumed straight from
the freezer compartment.
Do not place the appliance in direct sunlight.
Keep buring candles,lamps and other items with naked
flames away from the appliance so that do not set the
appliance on fire.
The appliance is intended for keeping food stuff and/or
beverages in normal household as explained in this
instruction booklet. The appliance is heavy.Care should be
taken when moving it.
Do not remove nor touch items from the freezer
compartment if your hands are damp/wet,as this could cause
skin abrasions or frost/freezer burns.
Never use the base,drawers, doors etc. to stand on or as
supports.
Frozen food must not be refrozen once it has been thawed
out.
Daily use
Do not store flammable gases or liquids in the appliance,
There is a risk of an explosion.
Do not operate any electrical appliances in the appliance
(e.g.electric ice cream makers,mixers etc.).
When unplugging always pull the plug from the mains
socket,do not pull on the cable.
Do not place hot items near the plastic components of this
appliance.
7
Adequate air circulation should be around the appliance,
lacking this leads to overheating. To achieve sufficient
ventilation, follow the instructions relevant to installation.
Wherever possible, the back of the product should not be too
close to a wall to avoid touching or catching warm parts
(compressor, condenser) to prevent the risk of a fire, follow
the instructions relevant to installation.
The appliance must not be located close to radiators or
cookers.
Make sure that the mains plug is accessible after the
installation of the appliance.
Installation Important!
For electrical connection carefully, follow the instructions
given in this manual.
Unpack the appliance and check if there are damages on it.
Do not connect the appliance if it is damaged. Report
possible damages immediately to the place you bought it. In
this case retain packing.
It is advisable to wait at least four hours before connecting
the appliance to allow the oil to flow back in the compressor.
Before maintenance, switch off the appliance and disconnect
the mains plug from the mains socket.
Do not clean the appliance with metal objects, steam
cleaner, ethereal oils, organic solvents or abrasive
cleansers.
Do not use sharp objects to remove frost from the appliance.
Use a plastic scraper
.
Caution!
Care and cleaning
Do not consume ice popsicles or ice cubes straight from
the freezer as this can cause freezer burn to the mouth and
lips.
To avoid items falling and causing injury or damage to
the appliance, do not overload the door racks or put too
much food in the crisper drawers.
8
Service
Any electrical work required to do the servicing of the
appliance should be carried out by qualified electrician or
competent person.
This product must be serviced by an authorized Service
Center, and only genuine spare parts must be used.
1)If the appliance is Frost Free.
2)If the appliance contains freezer compartment.
9
B
In order to improve efficiency
of the cooling system and save
energy, it is necessary to maintain
good ventilation around the appliance
for the dissipation of heat. For this
reason, sufficient clear space should
be available around the refrigerator.
Suggest :It is advisable for there to be
50-70mm of space from the back to
the wall, at least 100mm from its top,at
last 100mm from its side to the wall
and a clear space in front to allow the
doors to
open 115°. As shown in
following diagrams.
≥100
C
≥100
50
-70
mm
A
11
5°
SN
+10℃ to +32℃
+16℃ to +32℃
+16℃ to +38℃
1150
Without handle
With handle
880
B
660
A
708 925
1210
C
1220
A Depth(door clsoed)
B Width
C Depth(door opened)
Technical characteristics
10
Description of the appliance
View of the appliance(display panel)
View of the appliance(control panel)
1.Display panel
2.Door switch
3.Glass shelf
4.Crisper cover
5.Crisper
6.Upper freezer drawer
(Serving tray optional)
7.Middle freezer drawer
8.Lower freezer drawer
9.Adjustable bottom foot
10.Egg rack(inside)
11.Upper rack
12.
Flexible wine rack(optional)
13.Fridge wind channel
14.Fridge gasket
15.Lower rack
16.Fridge door
17.Handle(opitional)
18.Freezer door
19.Freezer gasket
20.Freezer wind channel
1.LED light
2.Door switch
3.Glass shelf
4.Fridge wind channel
5.Control panel
6.Crisper cover
7.Crisper
8.Serving tray(Upper freezer
drawer optional)
9.Middle freezer drawer
10.Lower freezer drqwer
11.Adjustable bottom foot
12.Egg rack(inside)
13.Upper rack
14.Flexible wine rack(optional)
15.Lower rack
16.Fridge gasket
17.Fridge door
18.Handle(opitional)
19.Freezer wind channel
20.Freezer gasket
21.Freezer door
Freezer
Fridge
8
7
9
6
5
4
3
2
1
10
11
12
16
15
14
13
17
19
18
20
Freezer
Fridge
10
11
9
8
7
6
5
4
3
2
1
21
20
19
18
17
16
15
14
13
12
11
Reversing the door
Door stopper-left
press in
wa
rdly
if some parts
are not shown in the picture below, please
ignore the relevant description.
2.Remove part①, then take down
part② from the top right side of
refrigerator. Unscrew screws③ by a
8mm socket driver or a spanner, and
remove hinge④. Please hold upper
door by hand when installing. Use a
putty knife or thin-blade screwdriver
to lever part⑤ which is at the top left
corner of the refrigerator.
③
①
②
④
⑤
①Self-tapping screw
②Upper hinge cover
③Special flange screw
④Upper hinge
⑤Screw hole cover-left
3. Remove the upper door from the
middle hinge by carefully lifting the
door straight up. Then place the
upper door on a smooth surface with
its upper cover upwards.
,
4.Loose screw ③ and take down
part ② and part ①, Install
replacement door stopper-left ④
(provided in the plastic bag) and
part ②(stop block) to the left side
with screw③. Keep part ① with the
appliance for future reference.
8mm socket wrench
Thin-blade
screwdriver
Putty knife
8mm wrench
Monkey wrench
Cross-shaped
screwdriver
12
5. Unscrew the two special flange self-
tapping screws which are used for
fixing the middle hinge part, then
remove the middle hinge part that hold
the lower door in place.
NOTE: When removing the door, watch
for washer(s) between the center hinge
and the upper of the lower door that
may stick to the door. Don't lose it.
7. Change screw and screw hole covers
on midde cover plate from left to right (as
shown in figure below).
screw hole covers
screw hole covers
8. Lay the refrigerator on soft foam
packaging or similar material. Remove
both adjustable bottom feet parts①,
then remove the lower hinge part ②by
unscrewing the special flange self-
tapping screws③.
①
②
③
①Adjustable bottom feet part
②Lower hinge part(right)
③Self-tapping screw
9.Remove part ① from the lower
hinge part(right), loose out the lower
hinge pin, change it to the reverse
hole site, and then tighten into
position, then install part ① on the
lower hinge pin.
6. Place the lower door on a smooth
surface with its panel upwards.
Loose screw ③ and take down part①
and part ②, then Install door stopper-
left ④(provided in the plastic bag) and
left part ② and screw ③ to the left side
and tighten them securely.Keep part ①
①
②
③
①Door stopper
②Stop block
③Self-tapping screw
④
④Door stopper-left
①
①
②
③
①Door stopper
②Stop block
③Self-tapping screw
④
④Door stopper-left
with the appliance for future reference.
screw screw
10. Change screw hole covers on lower
cover plate from left to right (as shown
in figure below).
screw hole cover
screw hole cover
13
11.Replace the lower hinge part to the
left side and fixing it with the special
flange screws. Replace the adjustable
bottom feet parts to another side and
and pre-fixing it.
12.Transfer the lower door to the
property position, adjust the lower
hinge part, make the hinge axis into the
lower hole of the lower door, then tight
the bolts.
middle hinge part
14. Transfer the upper door to the
appropriate position. Secure the door’s
level, make the middle hinge axis into
the lower hole of the upper door.
screws
13.Slot the lower door onto the
bottom hinge pin and hold in
position. Turn the middle hinge by
180°, change the washer on the axis
to the lower side, adjust the middle
hinge to the appropriate position
and then install it ensuring the lower
door in secured in place.
washer
Note: washer may stick
to lower door
16. Open the upper door and install the
door racks and then close it.
①Self-tapping screw
②Upper hinge cover
③Special flange screw
④Upper hinge
⑤Screw hole cover
③
①
②
④
⑤
15.Move the upper door to an
appropriate position, and then fix
part④ by screws③.(Please hold the
upper door by hand when
installing).Install the upper hinge
cover② on the left corner by screw①.
Install the screw hole cover ⑤
on the top
right corner of the refrigerator.
Note:
If your appliance has handle, you
have to reverse handle by follow
instructions below.
Remove the upper door and place it
on a smooth surface with its panel
upwards. Lever part① and part④,
then loose screws②. Change
handle③ to the right side, then install
screws②, part① and part④ in turn.
Warning! When changing the side at which
connected to the mains. Remove plug from
the door opens, the appliance must not be
the mains beforehand.
14
Operation
Starting up and temperature regulation
Use your appliance according
to the following control
regulations, your appliance has
the corresponding functions as the
display panels showed in the
pictures below.
We recommend that when you
start your refrigerator for the first
time, the temperature for the
refrigerator is set to 4°C . If you
want to change the temperature,
follow the instructions below.
You can press “ ” display panel
inside door)for 3 sec to get into super
freezer mode.
Controlling the temperature
You can select different modes
according to your requirements by
pressing the button“ ”on the
display panel, and the corresponding
icon will be illuminated.
Super Freeze( )
Super Freeze will quickly lower the
temperature within the freezer so food
will freeze faster. This can lock in the
vitamins and nutrients of fresh food
and keep food fresh longer.
When Super freeze Mode is
selected, the light will be illuminated
and the freezer temperature will be
set at -24°C.
In case of the maximum amount of
food to be frozen, please wait about
24 h.
Super freeze automatically
switches off after about 52 hours and
then the freezer temperature setting
will revert back to the previous
setting.
2. Mode
Display panel
Control panel
Display panel
When you set a temperature, you
set an average temperature for the
whole refrigerator cabinet.
Temperatures inside each
compartment may vary from the
temperature values displayed on
the panel, depending on how
much food you store and where
Caution!
you place them. Ambient
temperature may also affect the
actual temperature inside the
appliance.
Press “ ”to set fridge temperature
between 2℃ and 8℃ as needed, and
display panel will display
corresponding values according to
the following sequence.
Note: When the“ ” is lighted, the
holiday mode is activated. Check the
Holiday mode instruction.
1. Fridge
8℃6℃5℃
4℃ 3℃ 2℃
3.Switch( )
You can switch on or switch off
your appliance by press this
button.
1.Insufficient refrigeration in
chamber. Set the temperature
controller at “Colder”.
2.Using the refrigerator in normal.
Set the temperature controller at
“Mid”
Important! High ambient
temperatures (e.g. on hot summer
days)and a colder setting can
cause the compressor to run
continuously or even non-stop! So
we do not advise the user set the
temperature control knob at
“Cloder” in normal. At the same
time, in order to ensure the fridge
food be in a better storage
condition, we also do not advise
the user set the temperature
control knob at “Cold” in normal.
Press “ ”3 seconds, after a
buzzer sound, the appliance will
be turned off.
Press “ ”1 seconds, after a
buzzer sound, the appliance will
be turned on.
Temperature regulator in
refrigerator chamber
Reason:when the ambient
temperature is high,the
compressor must run continuously
to maintain the low temperature in
the appliance.
Control panel
15
If you are going to be away for a
long period of time, press “ ”you
can activate this function.
When Holiday Mode is activated,
the light will be illuminated. The
freezer temperature will be set at
-18°C and the fridge temperature
will be set at 15°C.
Holiday( )
Important! Do not store any food
in the fridge during this time.
Operation
16
Operation
-20°C
-21°C
-22°C -23°C
-24°C-14°C
-19°C
-17°C
-16°C
-15°C
-18°C
Display panel on door
Display panel on door
Controlling the temperature
We recommend that when you start your
refrigerator for the first time, the
temperature for the refrigerator is set to
4°C. If you want to change the
temperature, follow the instructions
below.
Caution!
When you set a temperature, you set an
average temperature for the whole
refrigerator cabinet. Temperatures inside
each compartment may vary from the
temperature values displayed on the
panel, depending on how much food you
store and where you place them. Ambient
temperature may also affect the actual
temperature inside the appliance.
Fridge
●Press “ZONE CHOICE”, the “ ”light
will turn on. Then press “SET TEMP.”,
you can set fridge temperature between
2°C and 8°C as needed, and display
panel will display corresponding values
according
to the following sequence.
Freezer
Press “ZONE CHOICE”, when the “ ”
light turns on. Then press “SET TEMP.”,
you can set freezer temperature between
-14°C and -24°C as needed, and the
display panel will display corresponding
value according to the following
sequence.
Super Freeze( )
Super Freeze will quickly lower the
temperature within the freezer so food will
freeze faster. This can lock in the vitamins
and nutrients of fresh food and keep food
fresh longer.
●You can press “SUPER” to get into
super freezer mode.
●Whensuper freeze Mode is selected,
the light will be illuminated and the freezer
temperature will be set at -24°C.
●In case of the maximum amount of food
to be frozen, please wait about 24 h.
●Super freeze automatically switches off
after 52 hours and then the freezer
temperature setting will revert back to the
previous setting.
Eco energy
This function makes the freezer work in a
power saving mode which is useful for
reducing energy consumption when you
are away.
●You can press “ECO MODE” to get into
economic energy mode.
●When economic energy Mode is
8
“
When the door of fridge has
been opened for over 2 minutes, the door
Press “
17
activated, the light will be illuminated. The
freezer temperature will be set at -17°C
and the fridge temperature will be set at
6°C.
Switch
You can switch on or switch off your
appliance by press this button.
●Press “ ”for 3 seconds, after a
buzzer sound, meanwhile the digital
light will show “OF”, the appliance will
be turned off.
● ” for 3 seconds, after a
buzzer sound,the appliance will be
turned on.
Alarm
●
alarm will sound. In case of door alarm,
buzzer will sound 3 times every 1 minute
and will stop alarming automatically after
8 minutes.
●To save energy, please avoid keeping
the door open for a long time when using
the appliance. The door alarm can also be
cleared by closing the door.
Various glass, plastic storage shelves
or wire trays are included with your
appliance-different models have
different combinations and different
models have different features.
The walls of the refrigerator are
equipped with a series of runners so
that the shelves can be positioned as
desired.
Accessories
Movable shelves/trays
Install the door shelf
Freezer food compartment
For freezing fresh food and storing
frozen and deep-frozen food for long
periods of time.
Thawing food
In the refrigerator compartment.
At room temperature.
In a microwave oven.
In a conventional or convection oven.
Food once thawed should not be
1) If the appliance contains related
accessories and functions.
2) If the appliance contains a freezer
compartment.
Ice-cube tray
For making ice and storing ice-cubes.
Refrigerator compartment
For storing food that does not need to
Vegetable Drawer
For storing fruit and vegetables.
Freezer Drawer
For storing frozen food.
frozen and different sections suitable
for different kinds of food.
guide
Firstly hold the two side of the door
shelf tightly, fit the door shelf along the
guides on the door, then push it down
to the right place.
Remove and install the door shelf
Remove the door shelf
Warning:The door shelf must not
removed and installed by the user! If
the door shelf is damaged ,contact the
customer helpline for assistance .To
replace the door shelf, the below
steps can be followed:
pre
ss
in
wa
rdl
y
Hold one side of the door shelf,
press the oppsite side inwardly by
the other hand, then lift up the door
rack . When the slot of the door rack
has been detached from the guide on
the door, remove the rack upward
obliquely.
18
Flexible wine rack
It is for storing bottled wine or
drinks, and it can be taken
out to clean.
re-frozen.
It is recommended to label and date each
frozen package in order to keep track of the
storage time.
Hints for the storage of frozen food
Ensure that frozen food has been stored
correctly by the food retailer
Once defrosted， food will deteriorate
rapidly and should not be re-frozen. Do not
exceed the storage period indicated by the
food manufacturer.
Switching off your appliance
If the appliance needs to be switched off for
an extended period, the following steps
should be taken prevent mould on the
appliance.
1. Remove all food.
2. Remove the power plug from the mains
socket.
3. Clean and dry the interior thoroughly.
4. Ensure that all the doors are wedged
open slightly to allow air to circulate.
●
●
●
Helpful hints and tips
below to save energy.
Try to avoid keeping the door open for long
periods in order to conserve energy.
Ensure the appliance is away from any
sources of heat (Direct sunlight, electric
oven or cooker etc)
Don't set the temperature colder than
necessary.
Don't store warm food or evaporating
liquid in the appliance.
Place the appliance in a well ventilated,
humidity free, room. Please refer to Installing
your new appliance chapter.
If the diagram shows the correct
combination for the drawers, crisper and
shelves, do not adjust the combination as
this is designed to be the most energy
efficient configuration.
●
●
●
●
●
●
●
Hints for fresh food refrigeration
Do not place hot food directly into the
refrigerator or freezer, the internal
●
●
●
●
temperature will increase resulting in the
compressor having to work harder and will
consume more energy.
Do cover or wrap the food，particularly if it
has a strong flavor.
Place food properly so that air can
circulate freely around it.
Hints for refrigeration
Meat (All Types) wrap in polythene food:
wrap and place on the glass shelf above the
vegetable drawer. Always follow food
storage times and use by dates suggested
by manufacturers.
Cooked food, cold dishes, etc.:
They should be covered and may be placed
on any shelf.
Butter and cheese:
Should be wrapped in airtight foil or plastic
film wrap.
●
Fruit and vegetables:
They should be stored in the specia ldrawer
●
provided.
19
Energy saving tips
We recommend that you follow the tips
Milk bottles:
Should have a lid and be stored in the door
racks.
Hints for freezing
When first starting-up or after a period out
of use, let the appliance run at least 2 hours
on the higher settings before putting food in
the compartment.
Prepare food in small portions to enable it
to be rapidly and completely frozen and to
make it possible to subsequently thaw only
the quantity required.
Wrap up the food in aluminum foil or
polyethylene food wraps which are airtight,
Do not allow fresh，unfrozen food to
touch the food which is already frozen to
avoid temperature rise of the latter.
Iced products，if consumed immediately
after removal from the freezer compartment,
will probably cause frost burns to the skin.
●
●
●
●
●
●
20
Cleaning and care
-Wipe the control panel with a clean, soft cloth.
interior
appliance
(including exterior and interior accessories)
be
cleaning.
Danger of electrical shock! Before cleaning
switch the appliance off and remove the plug
your
-Spray water onto the cleaning cloth instead
even
cabinet
-Don't use sharp objects as they are likely to
solvent such as Benzene for cleaning. They
regularly. It will be easier to clean when food
stocks are low. Wipe the inside of the fridge
freezer with a weak solution of bicarbonate
completely dry before replacing the shelves
Thoroughly dry all surfaces and removable
should be cleaned regularly at least every
ethereal oil, abrasive cleansers or organic
may damage the surface of the appliance
using a wrung-out sponge or cloth. Wipe
defrosts, a layer of frost may occur on the
freezer compartment's interior walls if the
freezer door is opened frequently or kept
choose a time when the supply of food
stocks are low and proceed as follows:
not
of
appliance, you should clean it regularly.
of spraying directly on the surface of the
surfaces with a mild detergent and then
-Don't use thinner, car detergent, clorox,
of soda, and then rinse with warm water
open too long. If the frost is too thick,
an
distribution of moisture to the surface.
appliance
Although this appliance automatically
must
and
during
appearance
ensure
the
handles
appliance
mains
wiped dry with a soft cloth.
reasons
helps
the
from the mains socket.
2. When defrosting is completed, clean your
freezer as described above.
Caution! Don't use sharp objects to remove
frost from the freezer compartment. Only
after the interior is completely dry should the
appliance be switched back on and plugged
back into the mains socket.
Gasket cleaning
Take care to keep gaskets clean. Sticky
food and drinks can cause gaskets to stick to
the cabinet and tear when you open the
door. Wash gaskets with a mild detergent and
warm water. Rinse and dry it thoroughly after
cleaning.
Caution! Only after the gaskets are
completely dry should the appliance be
powered on.
Replacing the LED light:
Warning:
The LED light should be replaced by a
competent person. If the LED light is
damaged, contact the customer
helpline for assistance. To replace the
LED light, the below steps can be
followed:
1. Unplug your appliance.
2. Remove light cover by pushing up
and out.
3. Hold the LED cover with one hand
and pull it with the other hand while
pressing
the connector latch.
4. Replace LED light and snap it
correctly in place.
Ventilate the room thoroughly to accelerate
1.Remove existing food and accessories
baskets, unplug the appliance from the
mains power and leave the doors open.
the thawing process.
good
doors,
scratch the surface.
and may cause fire.
clean
the
Exterior cleaning
The
This
Interior cleaning
hygienic
to
maintain
and baskets.
two months.
the
should
Caution!
connected
appliance.
-
Clean
Caution!
parts.
For
T
o
You
Troubleshooting
If you experience a problem with your appliance or are concerned that the appliance is not
functioning correctly, You can carry out some easy checks according to this section before
calling for service.
Warning! Don't try to repair the appliance yourself. If the problem persists after you have
made the checks mentioned below, contact a qualified electrician, authorized service engineer
or the shop where you purchased the product.
Problem
Check whether the power cord is plugged into the power outlet
properly.
Check the fuse or circuit of your power supply,replace if necessary.
The ambient temperature is too low. Try setting the chamber
temperature to a colder level to solve this problem.
The interior may need to be cleaned.
Some food, containers or wrapping cause odours.
Appliance is not working
correctly
Odours from the
compartments
The sounds below are quite normal:
Compressor running noises.
compartment or other compartments.
Gurgling sound similar to water boiling.
Popping noise during automatic defrosting.
Clicking noise before the compressor starts.
Noise from the
appliance
Other unusual noises are due
to the reasons below and may
need you to check and take action:
The cabinet is not level.
The back of appliance touches the wall.
Bottles or containers fallen or rolling.
The motor runs
continuously
It is normal to frequently hear the sound of the motor, it will
need to run more when in following circumstances:
Temperature setting is colder than necessary
Large quantity of warm food has recently been stored within
the appliance.
The temperature outside the appliance is too high.
Doors are kept open too long or too often.
After your installing the appliance or it has been switched off
for a long time.
A layer of frost occurs
in the compartment
Ensure food is placed within the appliance to allow sufficient
●
●
●
●
●
●
●
●
●
It is normal that the freezer is not operating during the
defrost cycle, or for a short time after the appliance is
switched on to protect the compressor.
21
ventilation.Ensure that door is fully closed.To remove the frost,
please refer to cleaning care chaper.
Possible cause
Solution
&
Temperature inside is
too warm
Temperature inside is
too cold
Doors can’t be closed
easily
inside is preventing the doors from closing.
Water drips on the floor
The light is not working
The light may be damaged. Refer to replace lights in
cleaning and care chapter.
●
Disposal of the appliance
It is prohibited to dispose of this appliance as household waste.
Packaging materials
Packaging materials with the recycle symbol ar
e recyclable. Dispose of the packaging into
a suitable waste collection container to recycle it.
Before disposal of the appliance
1.Pull out the mains plug from the mains socket.
2.Cut off the power cord and discard with the mains plug.
Warning! Refrigerators contain refrigerant and gases in the insulation. Refrigerant and
Correct Disposal of this product
22
This symbol on the product or in its packing indicates that this
product may not be treated as household waste. Instead, it should
be taken to the appropriate waste collection point for the recycling
of electrical and electronic equipment. By ensuring this product is
disposed of correctly, you will help prevent potential negative
consequences for the environment and human health, which could
otherwise be caused by the inappropriate waste handling of this
product, please contact your local council your household waste
disposal service, or the shop where you purchased the product.
spout is blocked. You may need to pull the refrigerator away
properly positioned to direct water into this pan, or the water
underneath the top of the compressor depot) may not be
not be properly leveled, or the draining spout (located
The water pan (located at the rear bottom of the cabinet) may
from the wall to check the pan and spout.
Check whether the top of the refrigerator is tilted back by
10-
15 mm to allow the doors to self close, or if something
Increase the temperature by following the “Display Operation”
chapter.
Y
ou may have left the doors open too long or too frequently; or
the doors are kept open by some obstacle; or the appliance is
located with insufficient clearance at the sides, back and top.
gases must be disposed of professionally as they may cause eye injuries or ignition.
Ensure that tubing of the refrigerant circuit is not damage prior to proper disposal.
~
~
~
- If the refrigerating appliance is left empty for long periods, switch off, defrost,
clean, dry, and leave the door open to prevent mould developing within the
appliance.
23
~
~
24
