Register your product and get support at
AJ7000
EN User manual
www.philips.com/support
a
b
c
d
e
f
g
h
m
n
i
j
k
l
A
D
E
EN
1 Important
Safety
• Read these instructions.
• Heed all warnings.
• Follow all instructions.
• Do not block any ventilation openings. Install in accordance
with the manufacturer’s instructions.
• Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including ampliers)
that produce heat.
• Protect the power cord from being walked on or pinched,
particularly at plugs, convenience receptacles, and the point
where they exit from the clock radio.
• Only use attachments/accessories specied by the
manufacturer.
• Unplug this clock radio during lightning storms or when
unused for long periods of time.
• Refer all servicing to qualied service personnel. Servicing
is required when the clock radio has been damaged in any
way, such as power-supply cord or plug is damaged, liquid
has been spilled or objects have fallen into the clock radio,
the clock radio has been exposed to rain or moisture, does
not operate normally, or has been dropped.
• This clock radio shall not be exposed to dripping or
splashing.
• Do not place any sources of danger on the clock radio (e.g.
liquid lled objects, lighted candles).
• Where the plug of the Direct Plug-in Adapter is used as
the disconnect device, the disconnect device shall remain
readily operable.
2 Your clock radio
Congratulations on your purchase, and welcome to Philips! To fully
benet from the support that Philips offers, register your product at
www.philips.com/welcome.
Introduction
With this clock radio, you can:
• listen to FM/MW radio;
• set two alarms; and
• wake up to buzzer or radio.
What’s in the box
Check and identify the contents of your package:
• Main unit (with battery)
• Adapter
• User manual
Overview of the main unit A
a SLEEP
• Set sleep timer.
b Main knob
• Adjust volume.
• Conrm selection.
• Adjust settings.
c TIME ZONE
• Set time zone.
d FM/MW
• Select tuner source.
e SET TIME/PROG
• Set time.
• Program radio stations.
f AL1/AL2
• Set alarm.
• View alarm settings.
• Activate/deactivate alarm timer.
g SNOOZE/BRIGHTNESS
• Snooze alarm.
• Adjust display brightness
h TUNING MODE
• Select tuning mode.
i PRESET
• Select a preset radio station.
j DST
• Select daylight saving time (DST) mode.
k AC 6V ~ 450mA
• Connect power.
l FM ANT
• Improve FM reception.
m Battery tray
n Display panel
• Show status.
3 Get started
Always follow the instructions in this chapter in sequence.
Install battery B
Caution
• Risk of explosion! Keep batteries away from heat, sunshine or
re. Never discard batteries in re.
• Danger of explosion if battery is incorrectly replaced. Replace
only with the same or equivalent type.
• The battery contains chemical substances, so it should be
disposed of properly.
• Keep children away from the battery.
Note
• You can only use AC power as power supply. The pre-installed
lithium CR2032 battery can only back up clock and alarm settings.
When the low battery indicator is displayed, replace the battery as
indicated.
Connect power C
Caution
• Risk of product damage! Ensure that the power voltage
corresponds to the voltage printed on the back or underside of
the clock radio.
• Risk of electric shock! When you unplug the AC adapter, always
pull the plug from the socket. Never pull the cord.
Warning
• To reduce the risk of re or electric shock, do not expose this
clock radio to rain or moisture.
Plug and set
Time has been preset at the factory. When power is connected, the
set time is displayed automatically.
The built-in lithium battery can maintain clock setting despite power
interruption.
Select time zone
You can adjust time zone setting according to your location.
1 In standby mode, press TIME ZONE.
» The current time zone number blinks on the display.
2 Rotate the main knob to set time zone (-1 to +12
adjustable).
3 Press the knob to conrm.
For Europe:
Western European Time (WET) +0
Central European Time (CET) +1 (Default)
Eastern European Time (EET) +2
Moscow Standard Time (MST) +3
Set clock D
If the preset time is inaccurate, you can set clock manually.
1 In standby mode, press SET TIME to activate clock setting
mode.
» The hour digits begin to blink.
2 Rotate the main knob to adjust hour.
3 Press the knob to conrm.
» The minute digits begin to blink.
4 Repeat Steps 2-3 to set minute and 12/24 hour format.
4 Listen to FM/MW radio
Tune to radio stations
Tip
• Position the antenna as far as possible from TV, VCR, or other
radiation source.
• For better reception, fully extend and adjust the position of the
antenna.
1 Press FM/MW to select FM or MW tuner source.
2 Press TUNING MODE repeatedly until [FIND] (nd)
blinks.
3 Rotate the main knob slowly.
» The clock radio tunes to a station with strong reception
automatically.
4 Press the knob to conrm.
5 Repeat Steps 3-4 to tune to more radio stations.
To tune to a station manually:
1 In tuner mode, press TUNING MODE repeatedly until
[STEP] (step) blinks.
2 Rotate the knob slowly to select a frequency.
Store radio stations automatically
You can store a maximum of 20 FM radio stations and 10 MW
radio stations.
1 In tuner mode, press TUNING MODE repeatedly until
[AUTO] (auto) blinks.
2 Rotate the main knob slowly.
» The clock radio stores all the available FM/MW radio
stations and broadcasts the rst available station
automatically.
Store radio stations manually
1 Tune to a radio station.
2 Press PROG.
» The preset number begins to blink.
3 Rotate the main knob to select a number.
4 Press the knob to conrm.
» [DONE] (done) is displayed.
5 Repeat steps 1 to 4 to store other stations.
Note
• To remove a pre-stored station, store another station in its place.
Select a preset radio station
In tuner mode, press PRESET, then rotate the main knob to select
a preset number.
Adjust volume E
5 Set alarm timer
Set alarm
You can set two alarms to ring at different time.
Note
• Make sure that the clock is set correctly.
1 In standby mode, press and hold AL1/AL2 for two seconds
to activate alarm setting mode.
» The hour digits and [AL1]/[AL2] begin to blink.
2 Rotate the main knob to adjust hour.
3 Press the main knob to conrm.
» The minute digits and [AL1]/[AL2] begin to blink.
4 Repeat Step 2-3 to set minute and alarm source: buzzer or
your last listened channel.
Activate/deactivate alarm timer
1 Press AL1/AL2 to view alarm settings.
2 Press AL1/AL2 again to activate or deactivate the alarm
timer.
» [AL1]/[AL2] appears if alarm timer is on and disappears
if it is off.
• To stop the ringing alarm, press the corresponding
AL1/AL2.
• The alarm repeats ringing for the next day.
Snooze alarm
When alarm sounds, press SNOOZE.
» The alarm snoozes and repeats ringing nine minutes later.
6 Other features
Set sleep timer
This clock radio can switch to standby mode automatically after a
preset period.
1 Press SLEEP.
2 Rotate the main knob to select the sleep timer period (in
minutes).
3 Press the knob to conrm.
» When the sleep timer is activated, appears.
To deactivate the sleep timer:
In sleep timer setting mode, rotate the knob until [OFF] (off)
appears, then press the knob.
15 30 60 90 120
off
Select DST (daylight saving time) mode
For countries with daylight saving time (DST), the clock radio offers
you DST option to adjust summer time.
In standby mode, press and hold DST for 3 seconds.
» The clock advances by one hour and [DST] is displayed.
Adjust display brightness
Press BRIGHTNESS repeatedly to select different brightness levels:
[HI] (high), [MID] (mid), and [LOW] (low).
7 Product information
Note
• Product information is subject to change without prior notice.
Specications
Amplier
Rated Output Power 0.6 W RMS
Tuner
Tuning Range FM: 87.5 - 108 MHz
MW: 531-1602 KHz
Sensitivity
- Mono, 26dB S/N Ratio
FM: <22 dBu
MW: <92 dBuV/M
Search Selectivity FM: <28 dBf
MW:<98 dBuV/M
Total Harmonic Distortion FM: <3%
MW:<5%
Signal to Noise Ratio FM: >45 dB
MW:>40 dB
General information
AC Power Model : AGC060V0450T or
EML352540VD;
Input : 220-240V ~, 50/60Hz;
Output : AC6V 450MA
Operation Power
Consumption
<5 W
Standby Power Consumption <1 W
Dimensions
- Main Unit (W x H x D) 134 x 112 x 42 mm
Weight
- With Packing
- Main Unit
0.82 kg
0.38 kg
8 Troubleshooting
Warning
• Never remove the casing of this apparatus.
To keep the warranty valid, never try to repair the system yourself.
If you encounter problems when using this apparatus, check the
following points before requesting service. If the problem remains
unsolved, go to the Philips web site (www.philips.com/support).
When you contact Philips, ensure that the apparatus is nearby and
the model number and serial number are available.
No power
• Ensure that the AC power plug of the clock radio is
connected properly.
• Ensure that there is power at the AC outlet.
No response from the clock radio
• Disconnect and reconnect the AC power plug, then turn on
the clock radio again.
Poor radio reception
• Keep the clock radio away from other electronic devices to
avoid radio interference.
• Fully extend and adjust the position of the FM antenna.
Alarm does not work
• Set the clock/alarm correctly.
9 Notice
This product complies with the radio interference requirements of
the European Community.
Any changes or modications made to this device that are not
expressly approved by Gibson Innovations may void the user’s
authority to operate the equipment.
Your product is designed and manufactured with high quality
materials and components, which can be recycled and reused.
When this crossed-out wheeled bin symbol is attached to a
product it means that the product is covered by the European
Directive 2002/96/EC.
Please inform yourself about the local separate collection system
for electrical and electronic products.
Please act according to your local rules and do not dispose of
your old products with your normal household waste. Correct
disposal of your old product helps to prevent potential negative
consequences for the environment and human health.
Your product contains batteries covered by the European Directive
2006/66/EC, which cannot be disposed with normal household
waste.Please inform yourself about the local rules on separate
collection of batteries because correct disposal helps to prevent
negative consequences for the environmental and human health.
Environmental information
All unnecessary packaging has been omitted. We have tried to
make the packaging easy to separate into three materials: cardboard
(box), polystyrene foam (buffer) and polyethylene (bags, protective
foam sheet.)
Your system consists of materials which can be recycled and reused
if disassembled by a specialized company. Please observe the local
regulations regarding the disposal of packaging materials, exhausted
batteries and old equipment.
Note
• The type plate is located on the bottom of the apparatus.
2015 © Gibson Innovations Limited. All rights reserved.
Specications are subject to change without notice. Gibson
reserves the right to change products at any time without being
obliged to adjust earlier supplies accordingly.
Norge
Typeskilt nnes på apparatens underside.
Observer: Nettbryteren er sekundert innkoplet. Den innebygde
netdelen er derfor ikke frakoplet nettet så lenge apparatet er
tilsluttet nettkontakten.
For å redusere faren for brann eller elektrisk støt, skal apparatet ikke
utsettes for regn eller fuktighet.
2015 © Gibson Innovations Limited. All rights reserved.
This product has been manufactured by, and is sold under
the responsibility of Gibson Innovations Ltd., and Gibson
Innovations Ltd. is the warrantor in relation to this product.
Philips and the Philips Shield Emblem are registered
trademarks of Koninklijke Philips N.V. and are used under
license from Koninklijke Philips N.V.
AJ7000_12_UM_V5.0
