QUICK REFERENCE GUIDE > HP90ICSX3 Date: 14.10.2020 > 1
Integrated Insert Rangehood,
90cm
Series 3 | Integrated
Stainless Steel
This efficient, stylish rangehood is perfectly hidden away in
cabinetry and easy to install.
With three fan speeds, select the perfect extraction rate for
your cooking
Powerful maximum air movement of 740m³/hr
Dishwasher safe filters that are easy to remove and clean
DIMENSIONS
Height
260 mm
Width
792 mm
Depth
277 mm
SPECIFICATIONS
Accessories
Eave ducting kit PD-RHK125E
Light bulb 792603
Recirculation carbon filter 791772
Roof ducting kit PD-RHK125T
Side wall ducting kit PD-RHK125W
Fan ratings
Maximum pressured air
740m³/hr
Maximum sound rating 60dBA
Installation and cleaning
Air outlet size 120mm
Dishwasher safe filters 1
Ducted Top extraction
Recirculation Optional
Performance
Extraction type Surface
Fan speeds 3
Filter type Mesh
Number of filters 1
Power requirements
Supply voltage 220-240V
Product dimensions
Depth 277 mm
Height 260 mm
Width 792 mm
Product information
Control type Slider
Ventilation features
Light type LED 2 x 4W
Warranty
Parts and labour 2 years
SKU 50134
TEST The product dimensions and specifications in this page apply to the specific
product and model. Under our policy of continuous improvement, these dimensions
and specifications may change at any time. You should therefore check with Fisher
& Paykel's Customer Care Centre to ensure this page correctly describes the model
currently available. ? Fisher & Paykel Appliances Ltd 2020
