2 Place two batteries in the battery
compartment (Fig. 3).
Note: Make sure the + and - indications on
the batteries match the indications in the
battery compartment.
Note: The shaver does not work if the
batteries have been placed incorrectly.
3 Put the lid of the battery
compartment back onto the appliance.
First insert the top part of the lid
(1) and then press down the bottom
part (2) until you hear a click (Fig. 4).
How to avoid damage due to
battery leakage
- Do not expose the appliance to
temperatures higher than 35°C.
- Remove the batteries if you are not
going to use the appliance for a month
or more.
- Do not leave empty batteries in the
appliance.
Shaving time
Two new batteries offer a shaving time of
60 minutes.
Using the appliance
Shaving
Your skin may need 2 or 3 weeks to get
accustomed to the Philips shaving system.
Shaving on a dry face gives the best results.
1 Push the on/off slide upwards to
switch on the shaver (Fig. 5).
2 Move the shaving heads over your
skin. Make both straight and circular
movements (Fig. 6).
3 Push the on/off slide downwards to
switch off the shaver.
4 Push the protection cap onto the
shaver after use to prevent damage to
the shaving heads (‘click’) (Fig. 7).
Cleaning and maintenance
Never use scouring pads, abrasive cleaning
agents or aggressive liquids such as petrol
or acetone to clean the appliance.
Regular cleaning guarantees better shaving
performance.
For easy and optimal cleaning, Philips
Shaving Head Cleaning Spray (type no.
HQ110) is available. Ask your Philips dealer
for information.
Note: Philips Shaving Head Cleaning
Spray may not be available in all countries.
Contact the Consumer Care Centre in your
country about the availability in your country.
You can also clean the shaver in the
following way:
Every week: shaving unit and hair
chamber
1 Switch off the shaver.
2 Clean the top of the appliance with
the cleaning brush (Fig. 8).
3 Press the release button (1) and
remove the shaving unit (2) (Fig. 9).
4 Clean the inside of the hair
chamber with the cleaning
brush (Fig. 10).
5 Clean the inside of the shaving unit
with the cleaning brush (Fig. 11).
6
Put the shaving unit back onto the shaver.
Every two months: shaving heads
1 Switch off the shaver.
2 Press the release button (1) and
remove the shaving unit (2) (Fig. 9).
3 To remove the retaining frame, push the
sides of the central spring towards each
other (1). Then lift the retaining frame
out of the shaving unit (2) (Fig. 12).
4 Slide the shaving heads out of the
retaining frame (Fig. 13).
Do not mix up the cutters and the guards.
Cutters and guards are matching sets.
Each cutter has been ground with
its corresponding guard for optimal
performance. If you accidentally mix up the
sets, it may take several weeks before
optimal shaving performance is restored.
5 Clean the cutter with the short-
bristled side of the cleaning
brush (Fig. 14).
Brush carefully in the direction of the arrow.
6 Clean the guard with the cleaning
brush (Fig. 15).
HQ139, HQ136, HQ132, HQ130
Register your product and get support at
www.philips.com/welcome
4222.002.5009.6
1 2 3
4
5 6
7
8 9
10
11 12
13
14 15
16
2
yrs
17 18
19
ENGLISH
Introduction
Congratulations on your purchase and
welcome to Philips! To fully benet from
the support that Philips offers, register your
product at www.philips.com/welcome.
Important
Read this user manual carefully before you
use the appliance and save it for future
reference.
Danger
- Keep the appliance dry.
Warning
- This symbol means: Forbidden to clean
under a running tap (Fig. 1).
- This appliance is not intended for use
by persons (including children) with
reduced physical, sensory or mental
capabilities, or lack of experience and
knowledge, unless they have been given
supervision or instruction concerning
use of the appliance by a person
responsible for their safety.
- Children should be supervised to ensure
that they do not play with the appliance.
Caution
- Use and store the appliance at a
temperature between 15°C and 35°C.
- Remove the batteries from the
appliance if you are not going to use it
for a month or more.
Electromagnetic elds (EMF)
This shaver complies with all standards
regarding electromagnetic elds (EMF).
If handled properly and according to the
instructions in this user manual, the shaver
is safe to use based on scientic evidence
available today.
Preparing for use
Inserting batteries
This shaver runs on two R6 AA 1.5-volt
batteries. Preferably use Philips alkaline
batteries.
Make sure that your hands are dry when
you insert the batteries.
1 Remove the lid of the battery
compartment (Fig. 2)
