Frigidaire GHWQ083WC1 Gallery 8,000 BTU 115V Inverter Quiet Temp Smart Room Air Conditioner

Use& Care - Transcript

• Page 1 - English - : TABLE OF CONTENTS wwwfrigidairecom USA 18009449044 wwwfrigidaireca Canada 18002658352 All about the Useamp Care Care and Cleaning Energy Saving Ideas June 2009 Important Safety Instructions Operating Instructions of your Room Air Conditioner Before You Call Major Appliance Limited Warranty Packaging Normal Sounds Air Conditioner Features Product Registration FCC Statement 24 217 14 16120300A23792
• Page 2 - English - : Important Safety Instructions Grounding type wall receptacle Do not under any circumstances cut remove or bypass the grounding prong Power supply cord with 3prong grounding plug and current detection device WARNING For Your Safety Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance Read product labels for flammability and other warnings WARNING Prevent Accidents To reduce the risk of fire electrical shock or injury to persons when using your air conditioner follow basic precautions including the following Be sure the electrical service is adequate for the model you have chosen This information can be found on the serial plate which is located on the side of the cabinet and behind the grille If the air conditioner is to be installed in a window you will probably want to clean both sides of the glass first If the window is a tripletrack type with a screen panel included remove the screen completely before installation Be sure the air conditioner has been securely and correctly installed according to the separate installation instructions provided with this manual Save this manual and the installation instructions for possible future use in removing or reinstalling this unit When handling the air conditioner be careful to avoid cuts from sharp metal fins on front and rear coils The complete electrical rating of your new room air conditioner is stated on the serial plate Refer to the rating when checking the electrical requirements Be sure the air conditioner is properly grounded To minimize shock and fire hazards proper grounding is important The power cord is equipped with a threeprong grounding plug for protection against shock hazards Your air conditioner must be used in a properly grounded wall receptacle If the wall receptacle you intend to use is not adequately grounded or protected by a time delay fuse or circuit breaker have a qualified electrician install the proper receptacle Do not run air conditioner without outside protective cover in place This could result in mechanical damage within the air conditioner Do not use an extension cord or an adapter plug WARNING Electrical Information WARNING Avoid fire hazard or electric shock Do not use an extension cord or an adaptor plug Do not remove any prong from the power cord NOTE The power supply cord with this air conditioner contains a current detection device designed to reduce the risk of fire Please refer to the section Operation of Current Device for details In the event that the power supply cord is damaged it cannot be repaired It must be replaced with a cord from the product manufacturer devreser sthgir llAcnI stcudorP emoH xulortcelE 9002 NOTE This USE amp CARE MANUAL provides specific operating instructions for your model Use the room air conditioner only as instructed in this USE amp CARE MANUAL These instructions are not meant to cover every possible condition and situation that may occur Common sense and caution must be practiced when installing operating and maintaining any appliance SAFETY PRECAUTIONS This air conditioner contains no userserviceable parts Always call an authorized Electrolux servicer for repairs Do not insert or place fingers or objects into the air discharge area in the front of the unit Do not start or stop the air conditioner by unplugging the power cord or turning off the power at the electrical box Do not cut or damage the power cord If the power cord is damaged it should only be replaced by an authorized Electrolux servicer In the event of a malfunction sparks burning smell etc immediately stop the operation disconnect the power cord and call an authorized Electrolux servicer Do not operate the air conditioner with wet hands Do not pull on the power cord Do not drink any water that is drained from the air conditioner DANGER Avoid Serious Injury or Death
• Page 3 - English - : Important Safety Instructions devreser sthgir llAcnI stcudorP emoH xulortcelE 9002 READ THIS SECTION BEFORE ATTEMPTING TO OPERATE AIR CONDITIONER Unit must be upright for one hour prior to operating Plug in amp press RESET The power supply cord contains a current device that senses damage to the power cord To test your power supply cord do the following Plug in the Air Conditioner The power supply cord will have TWO buttons on the plug head Press the TEST button You will notice a click as the RESET button pops out Press the RESET button Again you will notice a click as the button engages The power supply cord is now supplying electricity to the unit This is also indicated by a light on the plug head NOTE Do not use this device to turn the unit on or off Always make sure the RESET button is pushed in for correct operation The power supply cord must be replaced if it fails to reset when either the TEST button is pushed or it cannot be reset A new one can be obtained from the product manufacturer If power supply cord is damaged it CANNOT be repaired It MUST be replaced by one obtained from the product manufacturer SAFETY PRECAUTIONS Provide ventilation per installation instructions Do not direct airflow at fireplaces or other heat related sources as this could cause flare ups or make units run excessively Do not climb on or place objects on outdoor part of the unit Do not hang objects off the unit Do not place containers with liquids on the unit Turn off the air conditioner at the power source when it will not be used for an extended period of time Periodically check the condition of the units installation accessories for any damage Do not apply heavy pressure to the radiator fins of the unit Operate the unit with air filter in place Do not block or cover the intake grille discharge area and outlet ports Ensure that any electricalelectronic equipment is one yard away from the unit Do not use or store flammable gases near the unit Do not touch the metal parts of the unit when removing the filter Injuries can occur when handling sharp metal edges Do not use water to clean inside the air conditioner Exposure to water can destroy the insulation leading to possible electric shock When cleaning the unit first make sure that the power and circuit breaker are turned off CAUTION Avoid Injury or damage to the unit or other property Explanation of symbols displayed on the unit This symbol shows that this appliance used a flammable refrigerant If the refrigerant is leaked and exposed to an external ignition source there is a risk of fire This symbol shows that the operation manual should be read carefully This symbol shows that a service personnel should be handling this equipment with reference to the installation manual This symbol shows that information is available such as the operating manual or installation manual WARNING CAUTION CAUTION CAUTION
• Page 4 - English - : Important Safety Instructions CAUTION 7KLVDSSOLDQFHLVQot intended for use by persons including children with reduced physical sensory or mental capabilities or lack of experience and knowledge unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety ampKLOGUHQVKRXOGEHsupervised to ensure that they do not play with the appliance IWKHVXSSOFRUGLs damaged it must be replaced by the manufacturer its service agent or similarly qualified persons in order to avoid a hazard 7KHDSSOLDQFHVKDOO be installed in accordance with national wiring regulations RQRWXVHPHDQVto accelerate the defrosting process or to clean other than those recommended by the manufacturer 7KHDSSOLDQFHVKDOO be stored in a room without continuously operating ignition sources for example open flames an operating gas appliance and ignition sourcesor for examplean operating electric heater close to the appliance The appliance shall be stored in a room without continuously operating ignition sources for example open flames an operating gas appliance or an operating electric heater RQRWSLHUFHRUEXrn HDZDUHWKDWWKHUHIULJHUants may not contain an odour ampRPSOLDQFHZLWKQational gas regulations shall be observed HHSYHQWLODWLRQRSenings clear of obstruction 7KHDSSOLDQFHVKDOO be stored so as to prevent mechanical damage from occurring ZDUQLQJWKDWWKHappliance shall be stored in a wellventilated area where the room size corresponds to the room area as specified for operation QSHUVRQZKRLVinvolved with working on or breaking into a refrigerant circuit should hold a current valid certificate from an industryaccredited assessment authority which authorises their competence to handle refrigerants safely in accordance with an industry recognised assessment specification 6HUYLFLQJVKDOORQO be performed as recommended by the equipment manufacturer Maintenance and repair requiring the assistance of other skilled personnel shall be carried out under the supervision of the person competent in the use of flammable refrigerants 2127PRGLIWKe length of the power cord or use an extension cord to power the unit 2127VKDUHDVLngle outlet with other electrical appliances Improper power supply can cause fire or electrical shock 3OHDVHIROORZWKHLQstruction carefully to handle install clear service the air conditioner to avoid any damage or hazard Flammable Refrigerant R32 is used within air conditioner When maintaining or disposing the air conditioner the refrigerant R32 or R290 shall be recovered properly shall not discharge to air directly 1RDQRSHQILUHRU device like switch which may generate sparkarcing shall be around air conditioner to avoid causing ignition of the flammable refrigerant used Please follow the instruction carefully to store or maintain the air conditioner to prevent mechanical damage from occurring ODPPDEOHUHIULJHUDQW5LVXVHGLQair conditioner Please follow the instruction carefully to avoid any hazard WARNING FOR FLAMMABLE REFRIGERANT devreser sthgir llAcnI stcudorP emoH xulortcelE 9002
• Page 5 - English - : FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to part 15 of the FCC Rules These limits are designed to provide reasonable protection against harmful interference in a residential environment This equipment generates uses and can radiate radio frequency energy and if not installed and used in accordance with the instructions may cause harmful interference to radio communications However there is no guarantee that interference will not occur in a particular installation If this equipment does cause harmful interference to radio or television reception which can be determined by tuning the device off and on the user is encouraged to try to correct the interference by one or more of the following measures FCC Interference Statement Reorient or relocate the receiving antenna Increase the separation between the device and receiver Connect the equipment into an outlet other than the one used for the receiver Consult the dealer or an experienced radioTV technician for assistance This device complies with Part 15 of the FCC Rules Operation is subject to the following two conditions 1 This device may not cause harmful interference and 2 This device must accept any interference received including interference that may cause undesired operation This device includes the following module FCC CAUTION Any changes or modifications not expressly approved by the party responsible for compliance could void the users authority to operate the equipment Host device Labeling This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment This equipment should be installed and operated with minimum 20 cm between the radiator and your body This transmitter must not be collocated or operating in conjunction with any other antenna or transmitter unless authorized to do so by the FCC RF exposure statement This Class B digital apparatus complies with Canadian ICES003 This device complies with Industry Canada licenseexempt RSS standards Operation is subject to the following two conditions 1 this device may not cause interference and 2 this device must accept any interference including interference that may cause undesired operation of the device Le présent appareil est conforme aux CNR dIndustrie Canada applicables aux appareils radio exempts de licence Lexploitation est autorisée aux deux conditions suivantes 1 lappareil ne doit pas produire de brouillage et 2 lutilisateur de lappareil doit accepter tout brouillage radioélectrique subi même si le brouillage est susceptible den compromettre le fonctionnement INDUSTRY CANADA IC STATEMENT The antenna or antennas must be installed so as to maintain at all times a distance minimum of at least 20 cm between the radiation source antenna and any individual This device may not be installed or used in conjunction with any other antenna or transmitter RF Exposure Lantenne ou les antennes doit être installé e de façon à maintenir à tout instant une distance minimum de au moins 20 cm entre la source de radiation lantenne et toute personne physique lexposition aux RF This device includes the following module Host device Labeling Ce dispositif inclut le module suivant Host dispositif détiquetage This is the location of the module devreser sthgir llAcnI stcudorP emoH xulortcelE 9002 Contains FCC ID 2AIBXNIU5L Contains IC 21700NIU5L Contient module émetteur IC 21700NIU5L
• Page 6 - English - : Noise when unit starts Record Your Model and Serial Numbers Record in the space provided below the model and serial numbers On all models the serial plate is located on the outside of the cabinet Model No Serial No Register Your Product The selfaddressed PRODUCT REGISTRATION CARD should be filled in completely signed and returned to the Frigidaire Company Normal Sounds Todays high efficiency compressors may have a high pitched chatter during the cooling cycle High pitched Chatter Unit may vibrate and make noise because of poor wall or window construction or incorrect installation Vibration Sound of Rushing Air At the front of the unit you may hear the sound of rushing air being moved by the fan Product Registration Product Registration Packaging amp Normal Sounds GurgleHiss Gurgling or hissing noise ma A dada sound may occur when the unit is turned on in thirty seconds due to the compressor starting For Inverter type It is normal heard due to refrigerant passing through evaporator during normal operation y be Packaging Remove all packaging from inside the carton along with any inserts placed into the side louvers Pinging or Swishing Droplets of water hitting condenser during normal operation may cause pinging or swishing sounds Note Dont try to drill any holes on the base pan to eliminate the normal sounds otherwise it will void the warranty PACKAGING INSERTS devreser sthgir llAcnI stcudorP emoH xulortcelE 9002
• Page 7 - English - : Operating Instructions NOTE The following instructions represent the touch pad The same instructions can be used for the remote control PRESS ONOFF BUTTON DO THIS Air Conditioner Features amp Operating Instructions Before you begin thoroughly familiarize yourself with the control panel and remote control and all its functions as shown below The unit can be controlled by the touch pad alone with the remote control or with the Frigidaire app Refer to the Quick Start Guide that came with your Smart Air Conditioner for detailed instructions on setting up your air conditioner for connected operation from your smart phone or tablet ELECTRONIC CONTROL Air Conditioner Features YOU WILL SEETO TURN UNIT ON Battery Size CR2025 TO REPLACE BATTERY Turn Remote Control upside down Squeeze tab and pull to remove battery tray Place battery in tray with POSITIVE side facing UP according to diagram Reinsert battery tray TAB REMOTE CONTROL DISPLAYS TEMPERATURE SETS FAN SPEED SET MODE SET SWING TURNS UNIT ON OR OFF SCHEDULE INDICATOR ampamp75 RESET BUTTON WIFI This product contains a lithium buttoncoin cell battery If a new or used lithium buttoncoin cell battery is swallowed or enters the body it can cause severe internal burns and can lead to death in as little as 2 hours Always completely secure the battery compartment If the battery compartment does not close securely stop using the product remove the batteries and keep it away fr om childre n If you think batteries might have been swallowed or placed inside any part of the body seek immediate medical attention The cells shall be disposed of properly including keeping them away from children Even used cells may cause injury WARNING Chemical Burn Hazard Keep batteries away from children NOTE The unit will run in energy saverecon mode when powered on each time if last shutdown is in cool or energy saverecon mode In this mode the fan will The fan then cycles on for 120 seconds at 10 minute intervals until the room temperature is above the set temperature at which time the compressor turns back on devreser sthgir llAcnI stcudorP emoH xulortcelE 9002 ADJUSTS TEMPERATURE
• Page 8 - English - : Operating Instructions Operating Instructions continued devreser sthgir llAcnI stcudorP emoH xulortcelE 9002 S S TO CHANGE TEMPERATURE SETTlNG YOU WILL SEETO ADJUST FAN SPEEDS Note Fan starts at High Speed and adjusts to a slower speeds the room temperature dictates For example if the room doesnt get too warm it will stay at the slowest speed If the room temperature rises quickly such as a door being opened it will automatically go to the highest speed The fan speeds will readjust back to the slowest speed as the room returns to the original set temperature Press either the fan slower or fan faster button to adjust the fan speed manually YOU WILL SEE Note The display will show the set temperature during normal operation press either up or down button to adjust the set temperature to the desired setting The unit will beep twice if the temperature up or down button is pressed continuously when the set temperature reaches the upperlower limits 90F or 60F YOU WILL SEETO USE AUTO FAN FEATURE PRES TO RAISE PRES TO LOWER DO THIS DO THIS PRESS TO SELECT DO THIS PRESS FAN BUTTON CHOOSE AUTO
• Page 9 - English - : Operating Instructions Operating Instructions continued COOL FEATURE YOU WILL SEE EES LLIW UOYNAF NO ETAREPO OT CHOOSE FAN Note Use this function only when cooling is not desired such as for room air circulation or to exhaust stale air on some models You can choose any fan speed you prefer Except Auto Fan During this function display will only show the actual room temperature and the set temperature can not be changed Note In this mode the fan remains on all the time with the compressor cycling on and off when room temperature is reached DO THIS PRESS MODE BUTTON CHOOSE COOL DO THIS PRESS MODE BUTTON The unit is factory set to run in eco energy saver mode We recommend leaving the unit in eco mode to help save energy and money However if you would like to switch out of eco mode touch the button until another mode is selected In eco mode the fan will continue to run for 3 minute after the compressor shuts off The fan then cycles on for 120 seconds at 10 minute intervals until the room temperature is above the set temperature at which time the compressor turns back on ECO ENERGY SAVER MODE NOTE Please note that if the unit is changed to cool or fan mode then shut off the unit will turn back on in eco mode This is mandatory per government regulations If the unit is changed to cool or fan mode and a power failure occurs once the power is restored the unit will return to cool or fan mode devreser sthgir llAcnI stcudorP emoH xulortcelE 9002 CHOOSE COOL DO THIS PRESS MODE BUTTON
• Page 10 - English - : Operating Instructions Operating Instructions continued Note In this feature the louver will swing up and down to distribute the air evenly TO OPERATE SWING FEATURE devreser sthgir llAcnI stcudorP emoH xulortcelE 9002 Note This feature is a reminder to clean the Air Filter See Care and Cleaning for more efficient operation The LED light will illuminate after 250 hours of operation To reset after cleaning the filter hold the quot reset filterquot button 3 seconds and the light will go off CHECK FILTER FEATURE YOU WILL SEE DO THIS HOLD RESET FILTER BUTTON 3 SECONDS DO THIS PRESS SWING BUTTON YOU WILL SEE TO ACTIVATE THE CHILD LOCK FEATURE Note Press and hold the Fan Speed and Filter Reset EXWWRQIRUVHFFDQDFWLYDWHRUGHDFWYDWHWKH2ampIXQFWLRQ The display will show LC for 5 secs The control panel will be lock and the setting can not be changed YOU WILL SEE DO THIS PRESS AND HOLD THE Fan Speed amp Filter Reset BUTTONS SIMULTANEOUSLY FOR 3 SECONDS
• Page 11 - English - : Operating Instructions Operating Instructions continued devreser sthgir llAcnI stcudorP emoH xulortcelE 9002 Note The error code will be seperated to 2 part and shown in the display alternately in 1 second intervals for example when the fault code EH03 occur the panel will first display EH for 1 sec then display 03 for another sec and keep repeatedly showing EH and 03 until the issue are solved When below error code show on the display please contact your Authorized Frigidaire Service Center Error Code Description EH03 EC51 EC52 EC53 EC54 EH60 EH61 EC07 EH0b EL0C PC00 PC01 PC02 PC04 PC0L Internal motorfan motor loss speed Outdoor unit EEPROM malfunction Outdoor condenser temperature sensor is openshort circuited Outdoor ambient temperature sensor is openshort circuited Outdoor discharge temperature sensor is openshort circuited Indoor ambient temperature sensor is openshort circuited Indoor evaporator temperature sensor is openshort circuited Internal motorfan motor loss speedoutdoor motor loss speedCompressor starting anomalyoutdoor unit was stolen Communication malfunction Refrigerant detection failure Outdoor IPM unit protection Outdoor voltage protection Compressor top temperature Protection IPM module temperature protection Outdoor compressor feedback protection Outdoor cryogenic protection FAULT CODES SHOW EH FOR ONE SECONDS THEN SHOW 03 FOR ANOTHER SECONDS TO CHANGE TEMPERATURE DISPLAY Note The control is capable of displaying temperature in degrees Fahrenheit or degrees Celsius YOU WILL SEE DO THIS PRESS AND HOLD THE UPDOWN BUTTONS SIMULTANEOUSLY FOR 3 SECONDS
• Page 12 - English - : Operating Instructions Operating Instructions continued ADDITIONAL THINGS YOU SHOULD KNOW Now that you have mastered the operating procedure here are more features in your control that you should become familiar with The quotCoolquot circuit has an automatic 3 minute time delayed start if the unit is turned off and on quickly This prevents overheating of the compressor and possible circuit breaker tripping The fan will continue to run during this time There is a 2Second delay for the compressor shutting down when selecting FAN ONLY This is to cover the possibility of having to roll through to select another mode After a power outage the unit will memorize the last setting and return the unit to the same setting once power is restored The control will maintain the set temperature within 2 degrees Fahrenheit between 60F and 90F degrees TO TURN UNIT OFF Note After the unit is turned off the light on the display will gradually fade away in 3 seconds The unit will always return to eco mode and auto fan speed setting when it is turned on again YOU WILL SEE DO THIS PRESS ONOFF BUTTON After 60 seconds of control inactivity the display and indicator lights will turn off Press any button on the control panel or remote control and the display will resume Please note that if the unit is in eco mode and the set temperature has been reached the unit may appear off However the unit is on and will continue to sample the air every 10 minutes To confirm press any button on the control panel or remote control to illuminate the display to show unit in eco mode DIMMING DISPLAY devreser sthgir llAcnI stcudorP emoH xulortcelE 9002
• Page 13 - English - : Care and Cleaning amp Energy Saving Ideas Energy Saving Ideas Do not block air flow inside with blinds curtains or furniture or outside with shrubs enclosures or other buildings The capacity of the room air conditioner must fit the room size for efficient and satisfactory operation Install the room air conditioner on the shady side of your home A window that faces north is best because it is shaded most of the day Close the fireplace damper floor and wall registers so cool air does not escape up the chimney and into the duct work eep blinds and drapes in other windows closed during the sunniest part of the day Clean the air filter as recommended in the section Care and Cleaning Proper insulation and weather stripping in your home will help keep warm air out and cool air in External house shading with trees plants or awnings will help reduce the air conditioners work load Operate heat producing appliances such as ranges washers dryers and dishwashers during the coolest part of the day Care and Cleaning Clean your air conditioner occasionally to keep it looking new Be sure to unplug the unit before cleaning to prevent shock or fire hazards Air Filter Cleaning The air filter should be checked at least once a month to see if cleaning is necessary Trapped particles in the filter can build up and cause an accumulation of frost on the cooling coils Grasp the filter by the center and pull up and out Wash the filter using liquid dishwashing detergent and warm water Rinse filter thoroughly Gently shake excess water from the filter Be sure filter is thoroughly dry before replacing Or instead of washing you may vacuum the filter clean Push the vent handle to the Vent Closed positionwhere applicable Open the front panel Cabinet Cleaning Be sure to unplug the air conditioner to prevent shock or fire hazard The cabinet and front may be dusted with an oilfree cloth or washed with a cloth dampened in a solution of warm water and mild liquid dishwashing detergent Rinse thoroughly and wipe dry Never use harsh cleaners wax or polish on the cabinet front Be sure to wring excess water from the cloth before wiping around the controls Excess water in or around the controls may cause damage to the air conditioner Plug in air conditioner Winter Storage If you plan to store the air conditioner during the winter remove it carefully from the window according to the installation instructions Cover it with plastic or return it to the original carton NOTE When replacing the air filter after cleaning make sure the tabs on the air filter are on the upper part of filter and placed outward as shown in the drawing on the left side Tab Air Filter devreser sthgir llAcnI stcudorP emoH xulortcelE 9002
• Page 14 - English - : OCCURRENCE SOLUTION Wall plug disconnected Push plug firmly into wall outlet Plug Current Device Tripped Press the RESET button House fuse blown or circuit breaker tripped Replace fuse with time delay type or reset circuit breaker Control is OFF Turn Control ON and set to desired setting Air conditioner will not operate Air conditioner cooling but room is too warm NO ice forming on cooling coil behind decorative front Dirty air filter air restricted Clean air filter Refer to Care and Cleaning section Temperature is set too high Set temperature to a lower setting Air directional louvers positioned improperly Position louvers for better air distribution Front of unit is blocked by drapes blinds furniture etc restricts air distribution Clear blockage in front of unit Doors windows registers etc open cool air escapes Close doors windows registers etc Unit recently turned on in hot room Allow additional time to remove stored heat from walls ceiling floor and furniture Air conditioner turns on and off rapidly Dirty air filter air restricted Clean air filter Outside temperature extremely hot Set FAN speed to a faster setting to bring air through cooling coils more frequently Air conditioner cooling but room is too warm ice forming on cooling coil behind decorative front Outdoor temperature below 60 F 16 C To defrost the coil set FAN ONLY mode OO Air filter may be dirty Clean filter Refer to Care and Cleaning section To defrost set to FAN ONLY mode Temperature is set too low for nighttime cooling To defrost the coil set to FAN ONLY mode Then set temperature to a higher setting Room temperature below 60F 16C Cooling may not occur until room temperature rises above 60F 16C Temperature sensing element touching cold coil located behind air filter Straighten away from coil Air from unit does not feel cold enough Compressor shutoff by changing modes Wait approximately 3 minutes and listen for compressor to restart when set in the COOL mode Reset to a lower temperature Noise when unit is cooling Air movement sound This is normal If too loud set to lower FAN setting Water dripping INSIDE when unit is cooling Improper installation Tilt air conditioner slightly to the outside to allow water drainage Refer to installation instructions or check with installer Water dripping OUTSIDE when unit is cooling Unit removing large quantity of moisture from humid room This is normal during excessively humid days Window vibration poor installation Refer to installation instructions or check with installer Before calling for service review this list It may save you time and expense This list includes common occurrences that are not the result of defective workmanship or materials in this appliance Remote Sensing Deactivating Prematurely some models Remote control not located within range Place remote control within 20 feet amp 120 radius of the front of the unit Room too cold Set temperature too low lncrease set temperature Remote control signal obstructed Remove obstruction Remote Sensing activated on some models and remote control located in Hot Spot Relocate remote control or deactivate remote sensing Trouble connecting the smart appliance to your wifi network or experiencing an issue with the app Please visit Frigidairecom and select the Owner Support section to view Frequently Asked Questions Before You Call If These Solutions Fail Call 18009449044US18002658352Canada For Frigidaire Service devreser sthgir llAcnI stcudorP emoH xulortcelE 9002
• Page 15 - English - : Major Appliance Limited Warranty Exclusions 1 Products with original serial numbers that have been removed altered or cannot be readily determined This warranty does not cover the following 2 Product that has been transferred from its original owner to another party or removed outside the USA or Canada 3 Rust on the interior or exterior of the unit 4 Products purchased quotasisquot are not covered by this warranty 5 Food loss due to any refrigerator or freezer failures 6 Products used in a commercial setting 7 Service calls which do not involve malfunction or defects in materials or workmanship or for appliances not in ordinary household use or used other than in accordance with the provided instructions 8 Service calls to correct the installation of your appliance or to instruct you how to use your appliance 9 Expenses for making the appliance accessible for servicing such as removal of trim cupboards shelves etc which are not a part of the appliance when it is shipped from the factory 10 Service calls to repair or replace appliance light bulbs air filters water filters other consumables or knobs handles or other cosmetic parts 11 Surcharges including but not limited to any after hour weekend or holiday service calls tolls ferry trip charges or mileage expense for service calls to remote areas including the state of Alaska 12 Damages to the finish of appliance or home incurred during installation including but not limited to floors cabinets walls etc 13 Damages caused by services performed by unauthorized service companies use of parts other than genuine Electrolux parts or parts obtained from persons other than authorized service companies or external causes such as abuse misuse inadequate power supply accidents fires or acts of God DISCLAIMER OF IMPLIED WARRANTIES LIMITATION OF REMEDIES CUSTOMERS SOLE AND EXCLUSIVE REMEDY UNDER THIS LIMITED WARRANTY SHALL BE PRODUCT REPAIR OR REPLACEMENT AS PROVIDED HEREIN CLAIMS BASED ON IMPLIED WARRANTIES INCLUDING WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ARE LIMITED TO ONE YEAR OR THE SHORTEST PERIOD ALLOWED BY LAW BUT NOT LESS THAN ONE YEAR ELECTROLUX SHALL NOT BE LIABLE FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES SUCH AS PROPERTY DAMAGE AND INCIDENTAL EXPENSES RESULTING FROM ANY BREACH OF THIS WRITTEN LIMITED WARRANTY OR ANY IMPLIED WARRANTY SOME STATES AND PROVINCES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSE QUENTIAL DAMAGES OR LIMITATIONS ON THE DURATION OF IMPLIED WARRANTIES SO THESE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO YOU THIS WRITTEN WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS YOU MAY ALSO HAVE OTHER RIGHTS THAT VARY FROM STATE TO STATE If You Need Service HHSRXUUHFHLSWGHOLYHUVOLSRUVRPHRWKHUDSSURSULDWHSDPHQWUHFRUGWRHVWDEOLVKWKHZDUUDQWSHULRG should service be required If service is performed it is in your best interest to obtain and keep all receipts Service under this warranty must be obtained by contacting Electrolux at the addresses or phone numbers below This limited warranty only applies in the USA and Canada In the USA your appliance is warranted by Electrolux Major Appliances North America a division of Electrolux Home Products Inc In Canada your appliance is warranted by Electrolux Canada Corp Electrolux authorizes no person to change or add to any obligations under this warranty Obligations for service and parts under this warranty must be performed by Electrolux or an authorized service company Product features or specifications as described or illustrated are subject to change without notice Canada 18002658352 Electrolux Canada Corp 5855 Terry Fox Way Mississauga Ontario Canada L5V 3E4 USA 18009449044 Electrolux Major Appliances 10200 David Taylor Drive Charlotte NC 28262 Your appliance is covered by a limited oneyear warranty for functional repairs only For one year from your original date of purchase Electrolux will pay all costs for repairing or replacing any parts of this appliance that prove to be defective in materials or workmanship when such appliance is installed used and maintained in accordance with the provided instructions After one year from your original date of purchase the consumer will be responsible for diagnostic labor and parts costs as well as any removal transportation and reinstallation expenses which are incurred during service on components devreser sthgir llAcnI stcudorP emoH xulortcelE 9002
