E-1
Important
Information
IMPORTANT
For your assistance in reporting the loss or theft of your
Color LCD Projector, please record the Serial Number
located on the bottom of the projector and retain this
information. Before recycling the packaging, please be
sure that you have checked the contents of the carton
thoroughly against the list of “Supplied Accessories”
on page 13.
Before using the LCD projector, please read this operation manual carefully.
Model No.: XG
-
V10WU
Serial No.:
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER.
NO USER-SERVICEABLE PARTS EXCEPT LAMP UNIT.
REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK.
DO NOT REMOVE SCREWS
EXCEPT SPECIFIED USER
SERVICE SCREW.
There are two important reasons for prompt warranty registration of your new SHARP LCD Projector,
using the REGISTRATION CARD packed with the projector.
1. WARRANTY
This is to assure that you immediately receive the full benefit of the parts, service and labor
warranty applicable to your purchase.
2. CONSUMER PRODUCT SAFETY ACT
To ensure that you will promptly receive any safety notification of inspection, modification, or
recall that SHARP may be required to give under the 1972 Consumer Product Safety Act, PLEASE
READ CAREFULLY THE IMPORTANT “LIMITED WARRANTY” CLAUSE.
U.S.A. ONLY
The lightning flash with arrowhead symbol,
within an equilateral triangle, is intended to
alert the user to the presence of uninsulated
“dangerous voltage” within the product’s
enclosure that may be of sufficient magnitude
to constitute a risk or electric shock to
persons.
The exclamation point within a triangle is
intended to alert the user to the presence of
important operating and maintenance
(servicing) instructions in the literature
accompanying the product.
INFORMATION
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful inter-
ference when the equipment is operated in a commercial environment. This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and used in accordance with the operation manual,
may cause harmful interference to radio communications. Operation of this equipment in a residential area is
likely to cause harmful interference, in which case the user will be required to correct the interference at his own
expense.
U.S.A. ONLY
U.S.A. ONLY
The enclosed computer cable must be used with the device. The cable is provided to ensure that the device
complies with FCC Class A verification.
U.S.A. ONLY
WARNING: High brightness light source. Do not stare into the beam of light, or view directly. Be especially
careful that children do not stare directly into the beam of light.
WARNING: To reduce the risk of fire or electric shock, do not expose this product to rain or moisture.
WARNING: FCC Regulations state that any unauthorized changes or modifications to this equipment not
expressly approved by the manufacturer could void the user’s authority to operate this equip-
ment.
ENGLISHIntroduction
See bottom of actual set.
E-2
Important
Information
Electrical energy can perform many useful functions. This product has been engineered and manufactured to ensure your
personal safety. But IMPROPER USE CAN RESULT IN POTENTIAL ELECTRICAL SHOCK OR FIRE HAZARD. In order not to
defeat the safeguards incorporated into this LCD Projector, observe the following basic rules for its installation, use and
servicing. For your own protection and reliable usage of your LCD Projector, please be sure to read these “IMPORTANT
SAFEGUARDS” carefully before use.
1. Read Instructions
All the safety and operating instructions should be read
before the product is operated.
2. Retain Instructions
The safety and operating instructions should be retained
for future reference.
3. Heed Warnings
All warnings on the product and in the operating instructions
should be adhered to.
4. Follow Instructions
All operating and use instructions should be followed.
5. Cleaning
Unplug this product from the wall outlet before cleaning.
Do not use liquid cleaners or aerosol cleaners. Use a damp
cloth for cleaning.
6. Attachments
Do not use attachments not recommended by the product
manufacturer as they may cause hazards.
7. Water and Moisture
Do not use this product near water–for example, near a
bathtub, wash bowl, kitchen sink, or laundry tub; in a wet
basement; or near a swimming pool; and the like.
8. Accessories
Do not place this product on an unstable cart, stand, tripod,
bracket, or table. The product may fall, causing serious
injury to a child or adult, and serious damage to the product.
Use only with a cart, stand, tripod, bracket, or table
recommended by the manufacturer, or sold with the
product. Any mounting of the product should follow the
manufacturer’s instructions, and should use a mounting
accessory recommended by the manufacturer.
9. Transportation
A product and cart combination
should be moved with care. Quick
stops, excessive force, and uneven
surfaces may cause the product
and cart combination to overturn.
10. Ventilation
Slots and openings in the cabinet are provided for
ventilation to ensure reliable operation of the product and
to protect it from overheating. The openings should never
be covered or blocked by placing the product on a bed,
sofa, rug, or other similar surface. This product should not
be placed in a built-in installation such as a bookcase or
rack unless proper ventilation is provided or the
manufacturer’s instructions have been adhered to.
11. Power Sources
This product should be operated only from the type of power
source indicated on the marking label. If you are not sure
of the type of power supply to your home, consult your
product dealer or local power company. For products
intended to operate from battery power, or other sources,
refer to the operating instructions.
12. Grounding or Polarization
This product is equipped with a three-wire grounding-type
plug, a plug having a third (grounding) pin. This plug will
only fit into a grounding-type power outlet. This is a safety
feature. If you are unable to insert the plug into the outlet,
contact your electrician to replace your obsolete outlet. Do
not defeat the safety purpose of the grounding-type plug.
13. Power-Cord Protection
Power-supply cords should be routed so that they are not
likely to be walked on or pinched by items placed upon or
against them, paying particular attention to cords at plugs,
convenience receptacles, and the point where they exit
from the product.
14. Lightning
For added protection for this product during a lightning
storm, or when it is left unattended and unused for long
periods of time, unplug it from the wall outlet and disconnect
the cable system. This will prevent damage to the product
due to lightning and power-line surges.
15. Overloading
Do not overload wall outlets, extension cords, or integral
convenience receptacles as this can result in a risk of fire
or electric shock.
16. Object and Liquid Entry
Never push objects of any kind into this product through
openings as they may touch dangerous voltage points or
short-out parts that could result in a fire or electric shock.
Never spill liquid of any kind on the product.
17. Servicing
Do not attempt to service this product yourself as opening
or removing covers may expose you to dangerous voltage
or other hazards. Refer all servicing to qualified service
personnel.
18. Damage Requiring Service
Unplug this product from the wall outlet and refer servicing
to qualified service personnel under the following
conditions:
a. If the power-supply cord or plug is damaged.
b. If liquid has been spilled, or objects have fallen into
the product.
c. If the product has been exposed to rain or water.
d. If the product does not operate normally by following
the operating instructions. Adjust only those controls
that are covered by the operating instructions, as an
improper adjustment of other controls may result in
damage and will often require extensive work by a
qualified technician to restore the product to normal
operation.
e. If the product has been dropped or damaged in any
way.
f. If the product exhibits a distinct change in
performance, this indicates a need for service.
19. Replacement Parts
When replacement parts are required, be sure the service
technician has used replacement parts specified by the
manufacturer or with the same characteristics as the original
part. Unauthorized substitutions may result in fire, electric
shock, or other hazards.
20. Safety Check
Upon completion of any service or repairs to this product,
ask the service technician to perform safety checks to
determine that the product is in proper operating condition.
21. Wall or Ceiling Mounting
This product should be mounted to a wall or ceiling only as
recommended by the manufacturer.
22. Heat
This product should be situated away from heat sources
such as radiators, heat registers, stoves, or other products
(including amplifiers) that produce heat.
IMPORTANT SAFEGUARDS
E-3
Important
Information
IMPORTANT SAFEGUARDS
AVOID EXPOSURE
-
LASER
RADIATION IS EMITTED
FROM THIS APERTURE.
CAUTION
LASER RADIATION-
DO NOT STARE INTO BEAM
WAVE LENGTH : 650nm
MAX. OUTPUT : 1mW
CLASS II LASER PRODUCT
"COMPLIES WITH 21 CFR SUBCHAPTER J"
SHARP ELECTRONICS CORPORATION
SHARP PLAZA, MAHWAH, NEW JERSEY 07430
TEL : 1-800-BE-SHARP
U.S.A. ONLY
REMOTE CONTROL
MODEL NO. : RRMCG1564CESA
DC3V (1.5VX2PCS.)
MADE IN CHINA
FABRIQUÉ AU CHINE
The laser pointer on the remote control emits a laser beam from the laser
pointer window. This is a Class II laser which may impair your sight if directed
into the eyes. The three marks shown on the left are caution labels for the
laser beam.
• Do not look into the laser pointer window or shine the laser beam on yourself or
others. (The laser beam used in this product is harmless when directed onto
the skin. However, be careful not to project the beam directly into the eyes.)
• Always use the laser pointer at temperatures between 41°F and 104°F (5°C
and 40°C).
• Use of controls or adjustments, or performance of procedures other than those
specified herein may result in hazardous radiation exposure.
Cautions Concerning the Laser Pointer
Laser pointer
window
Cautions Concerning the Setup of the Projector
For minimal servicing and to maintain high image quality, SHARP recommends
that this projector be installed in an area free from humidity, dust and cigarette
smoke. When the projector is subjected to these environments, the lens must
be cleaned more often. As long as the projector is properly maintained in this
manner, use in these environments will not reduce the overall operation life.
Please note that all internal cleaning must be performed by an Authorized
Sharp Industrial LCD Products Dealer or Service Center.
• The exhaust vent, the lamp cage cover and adjacent areas may be extremely
hot during projector operation. To prevent injury, do not touch these areas until
they have sufficiently cooled.
• Allow at least 4 inches (10 cm) of space between the exhaust vent and the
nearest wall or obstruction.
• If the cooling fan becomes obstructed, a protection device will automatically
turn off the projector lamp. This does not indicate a malfunction. Remove the
projector power cord from the wall outlet and wait at least 10 minutes. Then
turn on the power by plugging the power cord back in. This will return the
projector to the normal operating condition.
Notes on Operation
104˚F
(40˚C)
41˚F
(5˚C)
Caution Concerning the Lamp Replacement
See “Replacing the Lamp” on pages 71 and 72.
LAMP REPLACEMENT CAUTION
BEFORE REMOVING THE SCREW, DISCONNECT
POWER CORD. HOT SURFACE INSIDE ALLOW
1HOUR TO COOL BEFORE REPLACING THE
LAMP. SEE OPERATION MANUAL.
Caution Concerning the Lamp Unit
Potential hazard of glass particles if lamp ruptures. In case of lamp rupture,
contact your nearest Authorized Sharp Industrial LCD Products Dealer or
Service Center for a replacement.
CAUTION
POTENTIAL HAZARD OF GLASS
PARTICLES. SEE OPERATION MANUAL.
LAMP MAY RUPTURE.
ATTENTION
LAMPE. DANGER POTENTIEL DE PARTICULES DE
VERRE. SE REPORTER AU MODE D’EMPLOI.
RUPTURE POSSIBLE DE LA
E-4
Important
Information
Temperature Monitor Function
If the projector starts to overheat due to setup problems or a dirty air filter, “TEMP.”
and “
” will flash in the lower-left corner of the picture. If the temperature continues
to rise, the lamp will turn off, the TEMPERATURE WARNING indicator on the
projector will flash, and after a 90-second cooling-off period the power will shut
off. Refer to “Lamp/Maintenance Indicators” on page 69, for details.
• The cooling fan regulates the internal temperature, and its performance is
automatically controlled. The sound of the fan may change during projector
operation due to changes in the fan speed.
Lamp Monitor Function
When the projector is turned on after the lamp has been used for 900 hours,
“LAMP” and “
” will flash in the lower-left corner of the picture to advise you
to replace the lamp. Check the “Lamp Timer” menu to confirm which lamp
has been used for 900 hours and needs to be replaced. See pages 71 and
72 for lamp replacement. If the lamp has been used for 1,000 hours, the
projector power will automatically turn off and the projector will enter standby
mode. Refer to “Lamp/Maintenance Indicators” on page 69, for details.
IMPORTANT SAFEGUARDS
Using the Carrying Handle
When transporting the projector, carry it by the carrying handle on
the side.
CAUTION
• Always put on the lens cap to prevent damage to the lens when transporting
the projector.
• Do not lift or carry the projector by the lens or the lens cap as this may
damage the lens.
• This equipment is very heavy, so to prevent injury take special care when
carrying on your own.
• Do not put down the equipment when the BNC-RCA adapters are
connected.
Using the Terminal Cover
• When ceiling-mounting the projector, attach the terminal cover
(supplied) to hide the connecting cables.
• Use the terminal cover to hide the connecting cables when the
projector is used on a desktop or high mounted.
1 Attach the terminal cover by aligning with the tabs on the projector.
2 Install the terminal cover using the two supplied user service
screws attached.
s
Carrying handle
Optional lenses
• Lenses are sold separately.
• Be sure to have service personnel install optional lenses.
E-5
Important
Information
Outstanding Features
1. High-end LCD Projector with Ultra High Brightness
• 200 W UHP Lamps
Uses two 200 W UHP lamps for excellent color uniformity and ultra high brightness.
• Newly developed prism enables efficient combination of light from two lamps.
A light axis separation and synthesis prism developed by Sharp enables the efficient
combination of light from the two lamps.
• Single-/Double-lamp Switching Feature
Projection can continue without interruption even if one
lamp burns out. Lamps can be used separately to double
the usage time.
2. Computer Compatibility
• Compatible with resolutions including VGA-XGA (expanded), SXGA (true
resolution) and UXGA (compressed) as well as DTV formats (480i, 480P, 720P
and 1080i).
3. SXGA Image Quality
• OCS LCD panel enhances color uniformity.
• Various other circuits are also used to provide high quality video images.
4. Computer & Video Integrated Composer Technology
• New I/P Conversion
I/P conversion with new algorithm used to achieve beautiful image quality.
• Enhanced Up-scaling
Enables sharper image quality without jaggies even for enlarged images.
• Superior 16:9 Image
4:3 images can be converted to 16:9 images using Smart Stretch (sides stretched,
center untouched), previously not achievable with LCD projectors.
• Smooth Keystone Correction
Smoothes out jaggies on keystone images.
• New Intelligent Compression
Efficiently compresses UXGA (1,600 1,200) images to SXGA (1,280 1,024).
• Film Mode
Converts cinema mode DVD images transformed with three-two pull down
enhancement to progressive mode images for easier viewing.
E-6
Important
Information
Outstanding Features
5. Network Capability
• Self-Diagnosis/Projector Status
Self-diagnosis/Projector status function sends e-mail
messages to a specified computer about lamp usage
time and any malfunctions.
• Multiple & Group Projector Control
Up to 250 projectors can be controlled over a network.
Projector RS-232C OUT can be used for daisy chain
connection.
• Simple Videowall Display
Comes with software for easy videowall processing even for input from a single
source.
6. Six Optional Lenses for Maximum Flexibility
• Standard Zoom Lens, Fixed Wide Lens, Wide-Zoom
Lens, Mid-Range Zoom Lens, Tele-Zoom Lens,
Super Zoom Lens
7. Multiple Input and Output Terminals
• BNC Terminal for RGB/Component/Video Signal
• PC Digital Input (DVI)
• Expansion Terminal for Optional Boards
Board for Network Capability: RS-422 Board, LAN Board
(Soon-to-be-released)
Expansion Video Board: Serial Digital Interface (SDI) Board
8. Easy Setup
• Power Lens Shift, Power Zoom & Focus, Digital Keystone Correction
• High Speed AutoSync Technology (4 to 8 sec.)
9. Advanced Presentation Features
• Built-in Presentation Tools, Picture-in-Picture, Digital Enlargement, Freeze
• Customizable Startup Screen & Background Screen
10. Application Software
• “Sharp Advanced Presentation Software—Professional Edition” (Network and
Remote Control)
LAN
LAN LAN
E-7
Important
Information
Contents
Important Information
Introduction ............................................. 1
IMPORTANT SAFEGUARDS ................... 2
Outstanding Features ............................. 5
Contents................................................... 7
How to Access the PDF Operation
Manuals ............................................... 9
Part Names............................................... 10
Supplied Accessories ............................. 13
Connections............................................. 14
Power Supply ............................................ 14
Projecting Computer Images .................... 14
Watching Video Images and
Laser Disc Images................................. 17
Watching DVD and Digital TV Images ...... 18
For Better Sound ....................................... 18
Power ON/OFF .......................................... 19
Setting Up the Screen ............................. 20
Using the Adjustment Feet ........................ 20
Adjusting the Projection Distance ............. 21
LENS Button .............................................. 29
Image Projection ..................................... 30
Rear Projection .......................................... 30
Projection Using a Mirror ........................... 30
Ceiling-mount Projection ........................... 30
Using the Operation Buttons ................. 31
Selecting the Input Signal Source ............. 31
Adjusting the Volume................................. 31
Muting the Sound ...................................... 31
Superimposing a Black Screen ................. 32
Displaying a Still Image ............................. 32
Magnifying a Specific Portion
of an Image .......................................... 33
Adjusting the Picture Aspect Ratio............ 34
Gamma Correction Function ..................... 35
Selecting the Remote Control Mode ......... 36
Operating the Remote Control .................. 36
Connecting the Mouse Receiver ............... 38
Using as a Laser Pointer ........................... 39
Using as a Wired Remote Control ............. 39
Setup &
Connections
Operation Buttons
Setup & Connections
Operation Buttons
Basic Operation
Useful Features &
Network Function
Appendix
Maintenance &
Troubleshooting
E-8
Important
Information
Contents
Basic Operation
Useful Features &
Network Function
Useful Features ....................................... 59
Locking the Operation Buttons
on the Projector.................................... 59
Deselecting Inputs .................................... 59
Selecting the Transmission Speed
(RS-232C) ............................................ 60
Protecting Important Settings
with a Password ................................... 61
Network Function .................................... 62
Setting Up the Optional Boards ................ 62
Controling Multiple Projectors
with ID Numbers .................................. 63
Setting the Stacking Mode ........................ 63
Using the Presentation Tools ..................... 64
Operating the Network Function ............... 65
Maintenance &
Troubleshooting
Lamp/Maintenance Indicators ................ 69
Lamp Maintenance .................................. 70
Confirming the Lamp Usage Time ............ 70
Setting the Lamp Mode ............................. 71
Replacing the Lamp .................................. 71
Replacing the Air Filter ........................... 73
Troubleshooting ...................................... 74
For SHARP Assistance (U.S.A. only) ..... 74
Appendix
Guide to Effective Presentations ........... 75
Connecting Pin Assignments ................ 79
(RS-232C) Specifications and
Command Settings............................. 80
Wired Remote Control Terminal
Specifications ..................................... 83
Computer Compatibility Chart ............... 84
Dimensions .............................................. 85
Specifications .......................................... 86
Glossary ................................................... 87
Index ......................................................... 88
Using the GUI (Graphical User
Interface) Menu Screen ...................... 40
Basic Operations ....................................... 40
Menu Bars ................................................. 41
Adjusting the Picture ................................. 43
Adjusting the Computer Images
(RGB menu only) ................................. 46
Adjusting the Sound .................................. 50
Displaying Dual Pictures
(RGB menu only) ................................. 51
Reducing Image Noise
(VIDEO menu only) .............................. 52
Turning On/Off the On-screen Display ...... 53
Setting the Video Signal
(VIDEO menu only) .............................. 53
Selecting a Background Image................. 54
Selecting a Startup Image ......................... 54
Selecting the Economy Mode ................... 55
Reversing/Inverting Projected Images ...... 56
Selecting the On-screen Display
Language ............................................ 57
Displaying the Adjustment Settings .......... 58
Setup & Connections Operation Buttons Basic Operation
Maintenance &
Troubleshooting
Appendix
Useful Features &
Network Function
E-9
Important
Information
How to Access the PDF Operation Manuals
PDF operation manuals in several languages are included in the CD-ROM. To utilize these manuals, you need to
install Adobe Acrobat Reader on your PC (Windows or Macintosh). If you have not installed Acrobat Reader yet,
you can download it from the Internet (http://www.adobe.com) or install it from the CD-ROM.
To Install Acrobat Reader from the CD-ROM
For other operating systems:
Please download Acrobat Reader from the Internet (http://www.adobe.com).
For other languages:
If you prefer using Acrobat Reader for languages other than those included in the CD-ROM, please download the
appropriate version from the Internet.
Accessing the PDF Manuals
For Windows:
1 Insert the CD-ROM in the CD-ROM drive.
2 Double click on the “My Computer” icon.
3 Double click on the “CD-ROM” drive.
4 Double click on the “manuals” folder.
5 Double click on the “acrobat” folder.
6 Double click on the “windows” folder.
7 Double click on the desired installation program
and follow the instructions on the screen.
For Macintosh:
1 Insert the CD-ROM in the CD-ROM drive.
2 Double click on the “CD-ROM” icon.
3 Double click on the “manuals” folder.
4 Double click on the “acrobat” folder.
5 Double click on the “mac” folder.
6 Double click on the desired installation program
and follow the instructions on the screen.
For Windows:
1 Insert the CD-ROM in the CD-ROM drive.
2 Double click on the “My Computer” icon.
3 Double click on the “CD-ROM” drive.
4 Double click on the “manuals” folder.
5 Double click on the “xg-v10wu” folder.
6 Double click on the language (name of the folder)
that you want to view.
7 Double click on the “v10” pdf file to access the
projector manuals.
Double click on the “saps” pdf file to access the
Sharp Advanced Presentation Software manual.
8 Double click on the pdf file.
For Macintosh:
1 Insert the CD-ROM in the CD-ROM drive.
2 Double click on the “CD-ROM” icon.
3 Double click on the “manuals” folder.
4 Double click on the “xg-v10wu” folder.
5 Double click on the language (name of the folder)
that you want to view.
6 Double click on the “v10” pdf file to access the
projector manuals.
Double click on the “saps” pdf file to access the
Sharp Advanced Presentation Software manual.
7 Double click on the pdf file.
• If the desired pdf file cannot be opened by double clicking the mouse, start Acrobat Reader first, then specify the desired file
using the “File”, “Open” menu.
• See the “readme.txt” file on the CD-ROM for important information on the CD-ROM not included in this operation manual.
E-10
Important
Information
Part Names
Projector
Numbers next to the part names refer to the main pages in this manual where the topic is explained.
Front and Top View
LENS button
POWER buttons (ON/OFF)
ENTER button
INPUT 1, 2, 3 button
FREEZE button
ENLARGE button
UNDO button
MUTE button
VOLUME buttons (/)
INPUT 4, 5, 6 button
GAMMA button
RESIZE button
AUTO SYNC button
Remote control sensor
Lens (sold separately)
Air filter (Intake vent)
Carrying handle
POWER indicator
TEMPERATURE WARNING indicator
LAMP 1 REPLACEMENT indicator
LAMP 2 REPLACEMENT indicator
MENU button
ADJUSTMENT buttons
(∂/ƒ/ß / ©)
Adjuster
19
29
40
31
32
33
40
31
31
40
40
31
49
34
35
4
20
36
21
73
19
69
69
69
E-11
Important
Information
14
19
62
17
17
17
18
39
16
14
15
14
6268
16
3
36
63
Part Names
Projector
Numbers next to the part names refer to the main pages in this manual where the topic is explained.
Side and Rear View
Speakers
Exhaust vent
Remote control sensor
LED display (ID No.)
RS-232C INPUT port/
RS-232C OUTPUT port
AC socket
MAIN POWER switch
OUTPUT port (15-pin Mini D-sub) for INPUT 1, 2/
AUDIO OUTPUT terminals for INPUT 1, 2
INPUT 1 port (15-pin Mini D-sub)/
AUDIO INPUT 1 terminals
INPUT 3 port (DVI)/
AUDIO INPUT 3 terminals
INPUT 6 EXPANSION board
S-VIDEO INPUT 4 terminal (4-pin Mini DIN)/
INPUT 4 terminals/AUDIO INPUT 4 terminals
S-VIDEO INPUT 5 terminal (4-pin Mini DIN)/
INPUT 5 terminals/AUDIO INPUT 5 terminals
OUTPUT terminals for INPUT 4, 5/
S-VIDEO OUTPUT terminal for INPUT 4, 5 (4-pin Mini DIN)/
AUDIO OUTPUT terminals for INPUT 4, 5
DC 12V OUTPUT
WIRED REMOTE control input terminal
INPUT 2 terminals/AUDIO INPUT 2 terminals
E-12
Important
Information
Part Names
Inserting the batteries
13
Press in on the arrow
mark and slide in the
direction of the arrow to
remove the battery cover.
2
Insert two AA size
batteries, making sure
the polarities match the
and marks inside
the battery compartment.
Insert the side tabs of
the battery cover into the
slots and press the
cover in until it is
properly seated.
Battery
compartment
Battery
cover
Battery
cover
1.2.3 4.5.6
Conference Series
31
19
31
32
33
64
36
31
29
39
37
37
32
40
40
40
31
49
34
35
37
VOLUME buttons
(/)
BACKLIGHT button
MUTE button
Bottom View
39
POWER buttons
(ON/OFF)
LASER POINTER/
MENU button
LENS/BLACK
SCREEN button
RIGHT-CLICK/
ENTER button
INPUT 4, 5, 6 buttonINPUT 1, 2, 3 button
AUTO SYNC button
FREEZE button
RESIZE buttonENLARGE button
GAMMA buttonTOOLS button
MOUSE/
ADJUSTMENT
switch
Wired remote control
input
LEFT-CLICK/
UNDO
button
37
40
MOUSE/
ADJUSTMENT
buttons (∂/ƒ/ß/©)
3
Remote control
signal transmitter
Laser
pointer
window
Front View
Top View
Bottom View
Remote Control
Rear View
E-13
Important
Information
Supplied Accessories
Power cord
QACCU5013CEZZ
RGB cable
QCNW-5304CEZZ
Remote control
RRMCG1564CESA
Two AA size batteries
Remote mouse receiver
RUNTK0673CEZZ
USB mouse control cable
QCNW-5680CEZZ
PS/2 mouse control cable
QCNW-5113CEZZ
Extra air filter
PFILD0110CEZZ
Terminal cover
CCOVA1789CE01
CD-ROM
UDSKA0020CEN1
LCD projector operation manual
TINS-6974CEZZ
LCD projector quick reference
TINS-6980CEZZ
Sharp Advanced Presentation Software operation manual
TINS-6992CEZZ
E-14
Setup & Connections
Power Supply
Connecting the Power Cord
Plug the supplied power cord into the AC socket on the side of the projector.
Projecting Computer Images
Connecting the Projector to a Computer
You can connect your projector to a computer for projection of full color computer images.
Connecting to a computer using the standard 15-pin Input
RGB cable
QCNW-5304CEZZ
1 Connect one end of the supplied RGB cable to the INPUT 1 port on the
projector.
2 Connect the other end to the monitor output port on the computer. Secure the
connectors by tightening the thumb screws.
3 To use the built-in audio system, connect one end of the audio cable (sold
separately) to the AUDIO INPUT 1 terminal on the projector.
4 Connect the other end to the audio output terminal on the computer.
CAUTION
• Before connecting, be sure to turn both the projector and the computer off. After making
all connections, turn the projector on first. The computer should always be turned on
last.
• Please read the computer’s operation manual carefully before making connections.
• Refer to page 84 “Computer Compatibility Chart” for a list of computer signals compatible
with the projector. Use with computer signals other than those listed may cause some of
the functions not to work.
• A 3.5 mm stereo minijack to stereo RCA audio cable adaptor may be necessary.
When connecting this projector to a computer, select “RGB” for “Signal Type”
on the GUI menu. (See page 45.)
• A Macintosh adaptor may be required for use with some Macintosh computers. Contact
your nearest Authorized Sharp Industrial LCD Products Dealer or Service Center.
• AUDIO INPUT 1 can be used to input audio corresponding to the INPUT 1.
Connections
Power cord
QACCU5013CEZZ
13
4
2
E-15
Setup & Connections
Projecting Computer Images
• This projector uses a 5 BNC computer input to prevent deterioration of image quality.
• Connect the R (PR), G/G sync (Y), B (PB), HD/C sync and VD cables (sold separately) to the correct input
terminals on the projector and an RGB switcher (sold separately) connected to the computer, or connect a 5
BNC cable (sold separately) directly from the input terminals on the projector to the computer.
Connecting to an external RGB switcher or other compatible computers using the BNC Input
(Typically used in larger installations )
1 Connect each BNC connector of a 5 BNC cable to the corresponding INPUT
2 terminals on the projector.
2 Connect the other end of the 5 BNC cable to the corresponding BNC terminals
on the external RGB switcher.
Connect the RGB switcher to the computer using a RGB cable.
3 To use the built-in audio system, connect one end of the audio cable (sold
separately) to the AUDIO INPUT 2 terminal on the projector.
4 Connect the other end to the audio output terminal on the computer or external
audio system.
• A 3.5 mm stereo minijack to stereo RCA audio cable adaptor may be necessary.
When connecting the projector to a compatible computer other than a PC (VGA/
SVGA/XGA/SXGA/UXGA) or Macintosh (i.e. Workstation), a separate cable may
be needed. Please contact your dealer for more information.
When connecting this projector to a computer, select “RGB” for “Signal Type”
on the GUI menu. (See page 45.)
• Connecting computers other than the recommended types may result in damage to the
projector, the computer, or both.
• AUDIO INPUT 2 can be used to input audio corresponding to the INPUT 2.
“Plug and Play” function (when connecting to a 15-pin terminal)
• This projector is compatible with VESA-standard DDC 1/DDC 2B. The projector and a VESA DDC compatible
computer will communicate their setting requirements, allowing for quick and easy setup.
• Before using the “Plug and Play” function, be sure to turn on the projector first and the connected computer last.
• The DDC “Plug and Play” function of this projector operates only when used in conjunction with a VESA DDC compatible computer.
2 To RGB switcher
5 BNC cable
(sold separately)
RGB cable
QCNW-5304CEZZ
4 To audio output
terminal
To R (PR), G/G sync (Y), B (PB),
HD/C sync and VD output terminals
RGB cable
RGB switcher
(sold separately)
3
1
Audio cable
(3.5 mm stereo minijack/RCA cable,
sold separately)
E-16
Setup & Connections
Projecting Computer Images
Connecting to a computer using the RS-232C Port
When the RS-232C port on the projector is connected to a computer with an RS-232C cable (null modem, cross
type, sold separately), the computer can be used to control the projector and check the status of the projector.
See pages 80, 81 and 82 for details.
Connect an RS-232C cable (null modem, cross type, sold separately) to the serial port on the computer.
RGB cable
QCNW-5304CEZZ
CAUTION
• Do not connect or disconnect an RS-232C cable to or from the computer while it is on. This may damage your computer.
• The wireless mouse or RS-232C function may not operate if your computer port is not correctly set up. Please refer to the operation manual
of the computer for details on setting up/installing the correct mouse driver.
• The arrows (→, ↔) indicate the direction of the signals.
• A Macintosh adaptor may be required for use with some Macintosh computers. Contact your nearest Authorized Sharp Industrial LCD
Products Dealer or Service Center.
Connecting to a computer using the direct digital input port
1 Connect one end of the DVI cable to the INPUT 3 port on the projector.
2 Connect the other end to the corresponding terminal on a computer.
3 To use the built-in audio system, connect one end of an audio cable (sold
separately) to AUDIO INPUT 3 terminal on the projector.
4 Connect the other end to the audio output terminal on the computer.
• This DVI port is DVI version 1.0 compatible. Therefore when the signal is input from copy
guard system compatible (DVI version 2.0) equipment, no signal will be received.
RGB cable
Audio cable
(3.5 mm stereo minijack/RCA cable,
sold separately)
RS-232C cable (null modem,
cross type, sold separately)
Computer
DVI cable (sold separately)
4 To audio output terminal
2 To digital output terminal
Audio cable
(3.5 mm stereo minijack/RCA cable,
sold separately)
3
E-17
Setup & Connections
Watching Video Images and Laser Disc Images
Connecting to a VCR, laser disc player and other audiovisual equipment using
the BNC video Input
1 Connect each BNC connector of a component or video cable to the
corresponding BNC INPUT 4 or 5 terminals on the projector.
• BNC-RCA adaptors are needed for use with RCA type cables and sources.
2 Connect the other end of the cable to the corresponding terminals on a VCR
or laser disc player.
3 To use the built-in audio system, connect one end of an audio cable (sold
separately) to AUDIO INPUT 4 or 5 terminal on the projector.
4 Connect the other end to the audio output terminal on the video component.
The S-VIDEO INPUT terminal uses a video signal system in which the picture is
separated into a color and a luminance signal to realize a higher-quality image.
When cables are connected to both the S-VIDEO INPUT 4 or 5 and VIDEO INPUT
4 or 5 terminals, images input through the S-VIDEO INPUT 4 or 5 terminal have
priority over images input through the VIDEO INPUT 4 or 5 terminal.
• For higher quality video, you may use the S-VIDEO INPUT terminal on the projector. S-
video cable is sold separately.
• If your video equipment does not have an S-video output terminal, use a composite video
cable.
Three BNC-RCA adaptors
(Sold separately)
2 To video
output terminals
Video cable (sold separately)
2 To analog component
output terminals
VCR
or
Laser disc player
CAUTION
• Always turn off the projector before connecting to video equipment, in order to protect both the projector and the equipment
being connected.
S-video cable (sold separately)
To S-video output terminal
3
Audio cable
(sold separately)
11
Component cable (sold separately)
or
4 To audio
output terminals
E-18
Setup & Connections
Watching DVD and Digital TV Images
1 Connect each BNC connector of a component cable to the corresponding
BNC INPUT 2 terminals on the projector.
• BNC-RCA adaptors are needed for use with RCA type cables and sources.
2 Connect the other end of the cable to the corresponding terminals on a DVD
player or DTV decoder.
3 To use the built-in audio system, connect one end of an audio cable (sold
separately) to the AUDIO INPUT 2 terminal on the projector.
4 Connect the other end to the audio output terminal on the DVD player or DTV
decorder.
When connecting this projector to a DVD player or DTV decoder, select
“Component” for “Signal Type” on the GUI menu. (See page 45.)
Connecting to a DVD player, DTV decoder and other component video
equipment using the 5 BNC Input
DTV decoder
or
DVD player
Amplifier
To audio input terminals
Audio cable (sold separately)
For Better Sound
Connecting to an amplifier and other audio components
CAUTION
• Always turn off the projector before connecting to audio components, in order
to protect both the projector and the components being connected.
• By using external audio components, the volume can be amplified for better sound.
• The AUDIO OUTPUT terminals allow you to output audio to audio components from the
selected AUDIO INPUT 1 to 5 terminals connected to audiovisual equipment.
Three BNC-RCA adaptors
(Sold separately)
CAUTION
• Always turn off the projector before connecting to video
equipment, in order to protect both the projector and the
equipment being connected.
3
2 To analog component
output terminals
1
4 To audio output terminals
Component cable (sold separately)
e.g. Outputs for Inputs 4, 5
Audio cable
(sold separately)
E-19
Setup & Connections
Power ON/OFF
Press the MAIN POWER switch on the side of the
projector. The POWER indicator lights up red and the
projector enters standby mode.
• When the main power is not on, the remote control cannot
be used to operate the projector.
Turning on the Main Power
TEMP LAMP2 LAMP1 POWER
2 1
Press POWER ON.
• The flashing green LAMP REPLACEMENT indicator
shows that the lamp is warming up. Wait until the
indicator stops flashing before operating the projector.
• If the power is turned off and then immediately turned
on again, it may take a short while before the lamp
turns on.
• After the projector is unpacked and turned on for the first
time, a slight odor may be emitted from the exhaust vent.
This odor will soon disappear with use.
When the power is on, the LAMP REPLACEMENT
indicator lights, indicating the status of the lamp.
Green: Lamp is ready.
Flashing green: Warming up.
Red: Change the lamp.
• When setting the lamp mode to “Lamp 1 only” or “Lamp
2 only”, only the LAMP REPLACEMENT indicator
corresponding to the lamp set is lit.
TEMP LAMP2 LAMP1 POWER
2 1
POWER
buttons
1.2.3 4.5.6
Conference Series
Press POWER OFF.
Press POWER OFF again while the message is
displayed.
• If you accidentally pressed POWER OFF and do not want
to turn off the power, wait until the power off screen
disappears.
• When POWER OFF is pressed twice, the POWER indicator
will light up red and the cooling fan will run for about 90
seconds. The projector will then enter standby mode.
• Wait until the cooling fan stops before disconnecting the
power cord.
• The power can be turned on again by pressing POWER
ON. When the power is turned on, the POWER indicator
and the LAMP REPLACEMENT indicators light green.
• The POWER indicator flashes if the front filter is not securely
installed.
E-20
Setup & Connections
Using the Adjustment Feet
Setting Up the Screen
Using the Adjustment Feet
Rotate feet to adjust height of the projector.
• The projector is adjustable up to approximately 5° from the standard position.
• When the height of the projector is adjusted, the image may become distorted (keystoned), depending on the relative
positions of the projector and the screen.
CAUTION
• Do not hold the lens when lifting or lowering the projector.
• When lowering the projector, be careful not to get your fingers caught in the area between the adjustment feet and the
projector.
Up Down
E-21
Setup & Connections
Adjusting the Projection Distance
Position the projector perpendicular to the screen with all feet flat and level to achieve an optimal image.
Move the projector forward or backward if the edges of the image are distorted.
• The projector lens should be centered in the middle of the screen. If the lens center is not perpendicular to the screen, the image will be
distorted, making viewing difficult.
• Position the screen so that it is not in direct sunlight or room light. Light falling directly onto the screen washes out colors, making viewing
difficult. Close the curtains and dim the lights when setting up the screen in a sunny or bright room.
• A polarizing screen cannot be used with this projector.
Six optional lenses from Sharp are also available for specialized application. Please see your local Sharp Industrial
LCD Products Dealer to details on all the lenses. (Refer to the lens operation manual when attaching a lens.)
Be sure to have service personnel install optional lenses.
5 10 15 20 25 30 35 (ft)
Screen
AN-LV80EZ
253–355 (7.7–10.8 m)
Throw distance ratio 3.8–5.3:1
AN-LV55EZ
175–247 (5.3–7.5 m)
Throw distance ratio 2.6–3.7:1
AN-LV36EZ
116–181 (3.5–5.5 m)
Throw distance ratio 1.7–2.7:1
AN-LV40EZ
1210–169 (3.9–5.1 m)
Throw distance ratio 1.9–2.5:1
AN-LV26EZ
82–96 (2.5–2.9 m)
Throw distance ratio 1.2–1.4:1
AN-LV18MX
57 (1.7 m)
Throw distance ratio 0.9:1
Throw Distance
Place the projector at the required distance from the screen according
to the desired picture size. (See pages 22–27.)
• Six optional lenses from Sharp are available for specialized application.
Please see your local Sharp Industrial LCD Products Dealer for details
on all the lenses.
Standard Setup (Front Projection)
H
L
X
Computer Input (5:4)
4
5
4 3
Video Input (16:9)
: Screen size and Picture size (4:3)
: Signal mask area
: Screen size and Picture size (16:9)
: Signal mask area
e.g. Screen size: 100 inches (254 cm)
Computer Input: 5:4
5
16
9 4
Video Input (4:3)
5
4
3 4
: Screen size (4:3)
: Picture size (5:4)
E-22
Setup & Connections
Adjusting the Projection Distance
AN-LV40EZ
Throw distance ratio
1.9 to 2.5:1
600
500
400
300
200
150
100
84
72
60
40
480
400
320
240
160
120
80
67
58
48
32
360
300
240
180
120
90
60
50
43
36
24
102 4
85 4
68 3
51 2
33 10
25 3
16 9
14 1
11 10
9 10
6 7
(31.2 m)
(26.0 m)
(20.8 m)
(15.6 m)
(10.3 m)
(7.7 m)
(5.1 m)
(4.3 m)
(3.6 m)
(3.0 m)
(2.0 m)
78 9
65 3
52 2
39 1
25 11
19 4
12 10
10 10
9 2
7 7
4 11
(24.0 m)
(19.9 m)
(15.9 m)
(11.9 m)
(7.9 m)
(5.9 m)
(3.9 m)
(3.3 m)
(2.8 m)
(2.3 m)
(1.5 m)
15 0
12 6
10 0
7 6
5 0
3 9
2 6
2 1
1 10
1 6
1 0
(457.2 cm)
(381.0 cm)
(304.8 cm)
(228.6 cm)
(152.4 cm)
(114.3 cm)
(76.2 cm)
(64.0 cm)
(54.9 cm)
(45.7 cm)
(30.5 cm)
3 0
2 6
2 0
1 6
1 0
9.0
6.0
5.0
4.3
3.6
2.4
(91.4 cm)
(76.2 cm)
(61.0 cm)
(45.7 cm)
(30.5 cm)
(22.9 cm)
(15.2 cm)
(12.8 cm)
(11.0 cm)
(9.1 cm)
(6.1 cm)
Diag. Width
Screen size
Height
Projection distance (L)
Maximum Minimum
Lens center to the lower edge of the screen (H)
Upper Lower
The formula for screen size and projection distance
y
1
(Max.) = (0.0522x 0.1166) 3.28
y
2
(Min.) = (0.0401x 0.1060) 3.28
z
1
(Upper) = 0.300x
z
2
(Lower) =0.060x
x: Screen size (diag.) (inches)
y: Projection distance (L) (feet)
z: Lens center to the lower edge of the screen (H) (inches)
Picture size (diag.) = Screen size (diag.) 0.96047
Computer Input (5:4)
Video Input (4:3)
The formula for screen size and projection distance
y
1
(Max.) = (0.0557x 0.1166) 3.28
y
2
(Min.) = (0.0428x 0.1060) 3.28
z
1
(Upper) = 0.300x
z
2
(Lower) =0.084x
x: Screen size (diag.) (inches)
y: Projection distance (L) (feet)
z: Lens center to the lower edge of the screen (H) (inches)
600
500
400
300
200
150
100
84
72
60
40
480
400
320
240
160
120
80
67
58
48
32
360
300
240
180
120
90
60
50
43
36
24
(33.3 m)
(27.7 m)
(22.2 m)
(16.6 m)
(11.0 m)
(8.2 m)
(5.5 m)
(4.6 m)
(3.9 m)
(3.2 m)
(2.1 m)
109 3
90 11
72 10
54 6
36 1
26 11
18 1
15 1
12 10
10 6
6 11
(25.6 m)
(21.3 m)
(17.0 m)
(12.7 m)
(8.5 m)
(6.3 m)
(4.2 m)
(3.5 m)
(3.0 m)
(2.5 m)
(1.6 m)
84 0
69 11
55 9
41 8
27 11
20 8
13 9
11 6
9 10
8 2
5 3
(457.2 cm)
(381.0 cm)
(304.8 cm)
(228.6 cm)
(152.4 cm)
(114.3 cm)
(76.2 cm)
(64.0 cm)
(54.9 cm)
(45.7 cm)
(30.5 cm)
15 0
12 6
10 0
7 6
5 0
3 9
2 6
2 1
1 10
1 6
1 0
(128.0 cm)
(106.7 cm)
(85.3 cm)
(64.0 cm)
(42.7 cm)
(32.0 cm)
(21.3 cm)
(17.9 cm)
(15.4 cm)
(12.8 cm)
(8.5 cm)
4 2
3 6
2 10
2 1
1 5
1 1
8.4
7.0
6.1
5.0
3.3
Diag. Width
Screen size
Height
Projection distance (L)
Maximum Minimum
Lens center to the lower edge of the screen (H)
Upper Lower
Video Input (16:9)
500
400
300
200
150
133
106
100
92
84
72
60
40
435
348
261
174
131
116
92
87
80
73
63
52
35
245
196
147
98
74
65
52
49
45
41
35
29
20
(30.2 m)
(24.2 m)
(18.1 m)
(12.0 m)
(9.0 m)
(8.0 m)
(6.3 m)
(6.0 m)
(5.5 m)
(5.0 m)
(4.3 m)
(3.5 m)
(2.3 m)
99 1
79 5
59 5
39 4
29 6
26 3
20 8
19 8
18 1
16 5
14 1
11 6
7 7
(23.2 m)
(18.6 m)
(13.9 m)
(9.2 m)
(6.9 m)
(6.1 m)
(4.8 m)
(4.6 m)
(4.2 m)
(3.8 m)
(3.3 m)
(2.7 m)
(1.8 m)
76 1
61 0
45 7
30 2
22 8
20 0
15 9
15 1
13 9
12 6
10 10
8 10
5 11
(311.3 cm)
(249.1 cm)
(186.8 cm)
(124.5 cm)
(93.4 cm)
(82.8 cm)
(66.0 cm)
(62.3 cm)
(57.3 cm)
(52.3 cm)
(44.8 cm)
(37.4 cm)
(24.9 cm)
10 3
8 2
6 2
4 1
3 1
2 9
2 2
2 1
1 11
1 9
1 6
1 3
9.8
(220.0 cm)
(176.0 cm)
(132.0 cm)
(88.0 cm)
(66.0 cm)
(58.5 cm)
(46.6 cm)
(44.0 cm)
(40.5 cm)
(37.0 cm)
(31.7 cm)
(26.4 cm)
(17.6 cm)
7 3
5 9
4 4
2 11
2 2
1 11
1 6
1 5
1 4
1 3
1 0
10.4
6.9
Diag. Width
Screen size
Height
Projection distance (L)
Maximum Minimum
Lens center to the lower edge of the screen (H)
Upper Lower
The formula for screen size and projection distance
y
1
(Max.) = (0.0607x 0.1166) 3.28
y
2
(Min.) = (0.0467x 0.1060) 3.28
z
1
(Upper) = 0.245x
z
2
(Lower) =0.173x
x: Screen size (diag.) (inches)
y: Projection distance (L) (feet)
z: Lens center to the lower edge of the screen (H) (inches)
• There is an error of 3% in the formula above.
• Values with a minus () sign indicate the distance of the lens center below the bottom of the screen.
E-23
Setup & Connections
Adjusting the Projection Distance
AN-LV18MX
Throw distance ratio
0.9 :1
600
500
400
300
200
150
100
84
72
60
40
480
400
320
240
160
120
80
67
58
48
32
360
300
240
180
120
90
60
50
43
36
24
35 1
29 2
23 4
17 5
11 6
8 6
5 7
4 11
3 11
3 3
2 4
(10.7 m)
(8.9 m)
(7.1 m)
(5.3 m)
(3.5 m)
(2.6 m)
(1.7 m)
(1.5 m)
(1.2 m)
(1.0 m)
(0.7 m)
Diag. Width
Screen size
Height
Projection distance (L)
15 0
12 6
10 0
7 6
5 0
3 9
2 6
2 1
1 10
1 6
1 0
(457.2 cm)
(381.0 cm)
(304.8 cm)
(228.6 cm)
(152.4 cm)
(114.3 cm)
(76.2 cm)
(64.0 cm)
(54.9 cm)
(45.7 cm)
(30.5 cm)
Lens center to the lower edge of the screen (H)
Upper
13 6
11 3
9 0
6 9
4 6
3 5
2 3
1 11
1 7
1 4
10.8
(411.5 cm)
(342.9 cm)
(274.3 cm)
(205.7 cm)
(137.2 cm)
(102.9 cm)
(68.6 cm)
(57.6 cm)
(49.4 cm)
(41.1 cm)
(27.4 cm)
Lower
The formula for screen size and projection distance
y = (0.0179x 0.0561) 3.28
z
1
(Upper) = 0.300x
z
2
(Lower) = 0.270x
x: Screen size (diag.) (inches)
y: Projection distance (L) (feet)
z: Lens center to the lower edge of the screen (H) (inches)
Picture size (diag.) = Screen size (diag.) 0.96047
600
500
400
300
200
150
100
84
72
60
40
480
400
320
240
160
120
80
67
58
48
32
360
300
240
180
120
90
60
50
43
36
24
37 5
31 2
24 11
18 8
12 6
9 2
6 3
5 3
4 3
3 7
2 4
(11.4 m)
(9.5 m)
(7.6 m)
(5.7 m)
(3.8 m)
(2.8 m)
(1.9 m)
(1.6 m)
(1.3 m)
(1.1 m)
(0.7 m)
Diag. Width
Screen size
Height
Projection distance (L)
15 0
12 6
10 0
7 6
5 0
3 9
2 6
2 1
1 10
1 6
1 0
(457.2 cm)
(381.0 cm)
(304.8 cm)
(228.6 cm)
(152.4 cm)
(114.3 cm)
(76.2 cm)
(64.0 cm)
(54.9 cm)
(45.7 cm)
(30.5 cm)
Lens center to the lower edge of the screen (H)
Upper
13 5
11 2
8 11
6 8
4 6
3 4
2 3
1 11
1 7
1 4
10.7
(408.4 cm)
(340.4 cm)
(272.3 cm)
(204.2 cm)
(136.1 cm)
(102.1 cm)
(68.1cm)
(57.2 cm)
(49.0 cm)
(40.8 cm)
(27.2 cm)
Lower
The formula for screen size and projection distance
y = (0.0191x 0.0561) 3.28
z
1
(Upper) = 0.300x
z
2
(Lower) = 0.268x
x: Screen size (diag.) (inches)
y: Projection distance (L) (feet)
z: Lens center to the lower edge of the screen (H) (inches)
Computer Input (5:4)
Video Input (4:3)
Video Input (16:9)
500
400
300
200
150
133
106
100
92
84
72
60
40
435
348
261
174
131
116
92
87
80
73
63
52
35
245
196
147
98
74
65
52
49
45
41
35
29
20
Diag. Width
Screen size
Height
Projection distance (L)
33 10
27 3
20 4
13 5
10 2
8 10
6 11
6 7
6 3
5 7
4 7
3 11
2 7
(10.3 m)
(8.3 m)
(6.2 m)
(4.1 m)
(3.1 m)
(2.7 m)
(2.1 m)
(2.0 m)
(1.9 m)
(1.7 m)
(1.4 m)
(1.2 m)
(0.8 m)
10 3
8 2
6 2
4 1
3 1
2 9
2 2
2 1
1 11
1 9
1 6
1 3
9.8
(311.3 cm)
(249.1 cm)
(186.8 cm)
(124.5 cm)
(93.4 cm)
(82.8 cm)
(66.0 cm)
(62.3 cm)
(57.3 cm)
(52.3 cm)
(44.8 cm)
(37.4 cm)
(24.9 cm)
Lens center to the lower edge of the screen (H)
Upper
8 9
7 0
5 3
3 6
2 8
2 4
1 10
1 9
1 7
1 6
1 3
1 1
8.4
(267.0 cm)
(213.6 cm)
(160.2 cm)
(106.8 cm)
(80.1 cm)
(71.0 cm)
(56.6 cm)
(53.4 cm)
(49.1 cm)
(44.9 cm)
(38.5 cm)
(32.0 cm)
(21.4 cm)
Lower
The formula for screen size and projection distance
y = (0.0208x 0.0561) 3.28
z
1
(Upper) = 0.245x
z
2
(Lower) = 0.210x
x: Screen size (diag.) (inches)
y: Projection distance (L) (feet)
z: Lens center to the lower edge of the screen (H) (inches)
• There is an error of 3% in the formula above.
• Values with a minus () sign indicate the distance of the lens center below the bottom of the screen.
E-24
Setup & Connections
Adjusting the Projection Distance
AN-LV26EZ
Throw distance ratio
1.2 to 1.4 :1
600
500
400
300
200
150
100
84
72
60
40
480
400
320
240
160
120
80
67
58
48
32
360
300
240
180
120
90
60
50
43
36
24
58 5
48 7
38 9
29 2
19 4
14 5
9 6
7 10
6 11
5 7
3 7
(17.8 m)
(14.8 m)
(11.8 m)
(8.9 m)
(5.9 m)
(4.4 m)
(2.9 m)
(2.4 m)
(2.1 m)
(1.7 m)
(1.1 m)
Diag. Width
Screen size
Height
Projection distance (L)
Maximum
50 6
42 0
33 6
25 3
16 9
12 6
8 2
6 11
5 11
4 11
3 3
(15.4 m)
(12.8 m)
(10.2 m)
(7.7 m)
(5.1 m)
(3.8 m)
(2.5 m)
(2.1 m)
(1.8 m)
(1.5 m)
(1.0 m)
Minimum
15 0
12 6
10 0
7 6
5 0
3 9
2 6
2 1
1 10
1 6
1 0
(457.2 cm)
(381.0 cm)
(304.8 cm)
(228.6 cm)
(152.4 cm)
(114.3 cm)
(76.2 cm)
(64.0 cm)
(54.9 cm)
(45.7 cm)
(30.5 cm)
Lens center to the lower edge of the screen (H)
Upper
0 0
0 0
0 0
0 0
0 0
0 0
0 0
0 0
0 0
0 0
0 0
(0.0 cm)
(0.0 cm)
(0.0 cm)
(0.0 cm)
(0.0 cm)
(0.0 cm)
(0.0 cm)
(0.0 cm)
(0.0 cm)
(0.0 cm)
(0.0 cm)
Lower
The formula for screen size and projection distance
y
1
(Max.) = (0.0298x 0.0841) 3.28
y
2
(Min.) = (0.0258x 0.0841) 3.28
z
1
(Upper) = 0.300x
z
2
(Lower) = 0
x: Screen size (diag.) (inches)
y: Projection distance (L) (feet)
z: Lens center to the lower edge of the screen (H) (inches)
Picture size (diag.) = Screen size (diag.) 0.96047
600
500
400
300
200
150
100
84
72
60
40
480
400
320
240
160
120
80
67
58
48
32
360
300
240
180
120
90
60
50
43
36
24
62 4
51 10
41 4
31 2
20 8
15 5
10 2
8 6
7 3
5 11
3 11
(19.0 m)
(15.8 m)
(12.6 m)
(9.5 m)
(6.3 m)
(4.7 m)
(3.1 m)
(2.6 m)
(2.2 m)
(1.8 m)
(1.2 m)
Diag. Width
Screen size
Height
Projection distance (L)
Maximum
54 2
44 11
36 1
26 11
17 9
13 5
8 10
7 3
6 3
5 3
3 3
(16.5 m)
(13.7 m)
(11.0 m)
(8.2 m)
(5.4 m)
(4.1 m)
(2.7 m)
(2.2 m)
(1.9 m)
(1.6 m)
(1.0 m)
Minimum
15 0
12 6
10 0
7 6
5 0
3 9
2 6
2 1
1 10
1 6
1 0
(457.2 cm)
(381.0 cm)
(304.8 cm)
(228.6 cm)
(152.4 cm)
(114.3 cm)
(76.2 cm)
(64.0 cm)
(54.9 cm)
(45.7 cm)
(30.5 cm)
Lens center to the lower edge of the screen (H)
Upper
11.7
9.8
7.8
5.9
3.9
2.9
2.0
1.7
1.4
1.2
0.8
(29.8 cm)
(24.8 cm)
(19.8 cm)
(14.9 cm)
(9.9 cm)
(7.4 cm)
(5.0 cm)
(4.2 cm)
(3.6 cm)
(3.0 cm)
(2.0 cm)
Lower
The formula for screen size and projection distance
y
1
(Max.)
= (0.0318x 0.0841) 3.28
y
2
(Min.) = (0.0276x 0.0841) 3.28
z
1
(Upper) = 0.300x
z
2
(Lower) =0.020x
x: Screen size (diag.) (inches)
y: Projection distance (L) (feet)
z: Lens center to the lower edge of the screen (H) (inches)
Computer Input (5:4)
Video Input (4:3)
Video Input (16:9)
500
400
300
200
150
133
106
100
92
84
72
60
40
435
348
261
174
131
116
92
87
80
73
63
52
35
245
196
147
98
74
65
52
49
45
41
35
29
20
56 5
45 3
33 10
22 4
16 9
14 9
11 10
11 2
10 2
9 2
7 10
6 7
4 3
(17.2 m)
(13.8 m)
(10.3 m)
(6.8 m)
(5.1 m)
(4.5 m)
(3.6 m)
(3.4 m)
(3.1 m)
(2.8 m)
(2.4 m)
(2.0 m)
(1.3 m)
Diag. Width
Screen size
Height
Projection distance (L)
Maximum
48 11
39 1
29 2
19 4
14 5
12 10
10 2
9 6
8 10
7 10
6 11
5 7
3 7
(14.9 m)
(11.9 m)
(8.9 m)
(5.9 m)
(4.4 m)
(3.9 m)
(3.1 m)
(2.9 m)
(2.7 m)
(2.4 m)
(2.1 m)
(1.7 m)
(1.1 m)
Minimum
10 3
8 2
6 2
4 1
3 1
2 9
2 2
2 1
1 11
1 9
1 6
1 3
9.8
(311.3 cm)
(249.1 cm)
(186.8 cm)
(124.5 cm)
(93.4 cm)
(82.8 cm)
(66.0 cm)
(62.3 cm)
(57.3 cm)
(52.3 cm)
(44.8 cm)
(37.4 cm)
(24.9 cm)
Lens center to the lower edge of the screen (H)
Upper
4 4
3 5
2 7
1 9
1 4
1 2
11.0
10.4
9.5
8.7
7.4
6.2
4.1
(131.4 cm)
(105.2 cm)
(78.9 cm)
(52.6 cm)
(39.4 cm)
(35.0 cm)
(27.9 cm)
(26.3 cm)
(24.2 cm)
(22.1 cm)
(18.9 cm)
(15.8 cm)
(10.5 cm)
Lower
The formula for screen size and projection distance
y
1
(Max.) = (0.0346x 0.0841) 3.28
y
2
(Min.) = (0.0300x 0.0841) 3.28
z
1
(Upper) = 0.245x
z
2
(Lower) =0.103x
x: Screen size (diag.) (inches)
y: Projection distance (L) (feet)
z: Lens center to the lower edge of the screen (H) (inches)
• There is an error of 3% in the formula above.
• Values with a minus () sign indicate the distance of the lens center below the bottom of the screen.
E-25
Setup & Connections
Adjusting the Projection Distance
AN-LV36EZ
Throw distance ratio
1.7 to 2.7 :1
600
500
400
300
200
150
100
84
72
60
40
480
400
320
240
160
120
80
67
58
48
32
360
300
240
180
120
90
60
50
43
36
24
111 3
92 10
74 2
55 5
36 9
27 7
18 1
15 1
13 1
10 10
6 11
(33.9 m)
(28.3 m)
(22.6 m)
(16.9 m)
(11.2 m)
(8.4 m)
(5.5 m)
(4.6 m)
(4.0 m)
(3.3 m)
(2.1 m)
Diag. Width
Screen size
Height
Projection distance (L)
Maximum
69 7
58 1
46 3
34 9
23 0
17 1
11 6
9 6
8 2
6 11
4 3
(21.2 m)
(17.7 m)
(14.1 m)
(10.6 m)
(7.0 m)
(5.2 m)
(3.5 m)
(2.9 m)
(2.5 m)
(2.1 m)
(1.3 m)
Minimum
15 0
12 6
10 0
7 6
5 0
3 9
2 6
2 1
1 10
1 6
1 0
(457.2 cm)
(381.0 cm)
(304.8 cm)
(228.6 cm)
(152.4 cm)
(114.3 cm)
(76.2 cm)
(64.0 cm)
(54.9 cm)
(45.7 cm)
(30.5 cm)
Lens center to the lower edge of the screen (H)
Upper
0 0
0 0
0 0
0 0
0 0
0 0
0 0
0 0
0 0
0 0
0 0
(0.0 cm)
(0.0 cm)
(0.0 cm)
(0.0 cm)
(0.0 cm)
(0.0 cm)
(0.0 cm)
(0.0 cm)
(0.0 cm)
(0.0 cm)
(0.0 cm)
Lower
The formula for screen size and projection distance
y
1
(Max.) = (0.0568x 0.1391) 3.28
y
2
(Min.) = (0.0355x 0.0804) 3.28
z
1
(Upper) = 0.300x
z
2
(Lower) = 0
x: Screen size (diag.) (inches)
y: Projection distance (L) (feet)
z: Lens center to the lower edge of the screen (H) (inches)
Picture size (diag.) = Screen size (diag.) 0.96047
600
500
400
300
200
150
100
84
72
60
40
480
400
320
240
160
120
80
67
58
48
32
360
300
240
180
120
90
60
50
43
36
24
118 9
98 9
79 1
59 1
39 4
29 2
19 4
16 1
13 9
11 6
7 7
(36.2 m)
(30.1 m)
(24.1 m)
(18.0 m)
(12.0 m)
(8.9 m)
(5.9 m)
(4.9 m)
(4.2 m)
(3.5 m)
(2.3 m)
Diag. Width
Screen size
Height
Projection distance (L)
Maximum
74 6
62 0
49 6
37 1
24 7
18 4
12 2
10 2
8 10
7 3
4 7
(22.7 m)
(18.9 m)
(15.1 m)
(11.3 m)
(7.5 m)
(5.6 m)
(3.7 m)
(3.1 m)
(2.7 m)
(2.2 m)
(1.4 m)
Minimum
15 0
12 6
10 0
7 6
5 0
3 9
2 6
2 1
1 10
1 6
1 0
(457.2 cm)
(381.0 cm)
(304.8 cm)
(228.6 cm)
(152.4 cm)
(114.3 cm)
(76.2 cm)
(64.0 cm)
(54.9 cm)
(45.7 cm)
(30.5 cm)
Lens center to the lower edge of the screen (H)
Upper
11.7
9.8
7.8
5.9
3.9
2.9
2.0
1.7
1.4
1.2
0.8
(29.8 cm)
(24.8 cm)
(19.8 cm)
(14.9 cm)
(9.9 cm)
(7.4 cm)
(5.0 cm)
(4.2 cm)
(3.6 cm)
(3.0 cm)
(2.0 cm)
Lower
The formula for screen size and projection distance
y
1
(Max.)
= (0.0605x 0.1391) 3.28
y
2
(Min.) = (0.0379x 0.0804) 3.28
z
1
(Upper) = 0.300x
z
2
(Lower) =0.020x
x: Screen size (diag.) (inches)
y: Projection distance (L) (feet)
z: Lens center to the lower edge of the screen (H) (inches)
Computer Input (5:4)
Video Input (4:3)
Video Input (16:9)
500
400
300
200
150
133
106
100
92
84
72
60
40
435
348
261
174
131
116
92
87
80
73
63
52
35
245
196
147
98
74
65
52
49
45
41
35
29
20
107 11
86 3
64 8
43 0
32 2
28 3
22 8
21 4
19 4
17 9
15 1
12 6
8 2
(32.9 m)
(26.3 m)
(19.7 m)
(13.1 m)
(9.8 m)
(8.6 m)
(6.9 m)
(6.5 m)
(5.9 m)
(5.4 m)
(4.6 m)
(3.8 m)
(2.5 m)
Diag. Width
Screen size
Height
Projection distance (L)
Maximum
67 7
53 10
40 4
26 11
20 0
17 9
14 1
13 1
12 2
11 2
9 6
7 10
5 3
(20.6 m)
(16.4 m)
(12.3 m)
(8.2 m)
(6.1 m)
(5.4 m)
(4.3 m)
(4.0 m)
(3.7 m)
(3.4 m)
(2.9 m)
(2.4 m)
(1.6 m)
Minimum
10 3
8 2
6 2
4 1
3 1
2 9
2 2
2 1
1 11
1 9
1 6
1 3
9.8
(311.3 cm)
(249.1 cm)
(186.8 cm)
(124.5 cm)
(93.4 cm)
(82.8 cm)
(66.0 cm)
(62.3 cm)
(57.3 cm)
(52.3 cm)
(44.8 cm)
(37.4 cm)
(24.9 cm)
Lens center to the lower edge of the screen (H)
Upper
4 4
3 5
2 7
1 9
1 4
1 2
11.0
10.4
9.5
8.7
7.4
6.2
4.1
(131.4 cm)
(105.2 cm)
(78.9 cm)
(52.6 cm)
(39.4 cm)
(35.0 cm)
(27.9 cm)
(26.3 cm)
(24.2 cm)
(22.1 cm)
(18.9 cm)
(15.8 cm)
(10.5 cm)
Lower
The formula for screen size and projection distance
y
1
(Max.) = (0.0660x 0.1391) 3.28
y
2
(Min.) = (0.0413x 0.0804) 3.28
z
1
(Upper) = 0.245x
z
2
(Lower) =0.103x
x: Screen size (diag.) (inches)
y: Projection distance (L) (feet)
z: Lens center to the lower edge of the screen (H) (inches)
• There is an error of 3% in the formula above.
• Values with a minus () sign indicate the distance of the lens center below the bottom of the screen.
E-26
Setup & Connections
Adjusting the Projection Distance
AN-LV55EZ
Throw distance ratio
2.6 to 3.7 :1
600
500
400
300
200
150
100
84
480
400
320
240
160
120
80
67
360
300
240
180
120
90
60
50
149 11
125 0
99 9
74 10
49 6
37 1
24 7
20 4
(45.7 m)
(38.1 m)
(30.4 m)
(22.8 m)
(15.1 m)
(11.3 m)
(7.5 m)
(6.2 m)
Diag. Width
Screen size
Height
Projection distance (L)
Maximum
106 11
89 3
71 2
53 2
35 5
26 3
17 5
14 5
(32.6 m)
(27.2 m)
(21.7 m)
(16.2 m)
(10.8 m)
(8.0 m)
(5.3 m)
(4.4 m)
Minimum
15 0
12 6
10 0
7 6
5 0
3 9
2 6
2 1
(457.2 cm)
(381.0 cm)
(304.8 cm)
(228.6 cm)
(152.4 cm)
(114.3 cm)
(76.2 cm)
(64.0 cm)
0 0
0 0
0 0
0 0
0 0
0 0
0 0
0 0
(0.0 cm)
(0.0 cm)
(0.0 cm)
(0.0 cm)
(0.0 cm)
(0.0 cm)
(0.0 cm)
(0.0 cm)
Lens center to the lower edge of the screen (H)
Upper Lower
Computer Input (5:4)
The formula for screen size and projection distance
y
1
(Max.) = (0.0765x 0.1868) 3.28
y
2
(Min.) = (0.0547x 0.1862) 3.28
z
1
(Upper) = 0.300x
z
2
(Lower) = 0
x: Screen size (diag.) (inches)
y: Projection distance (L) (feet)
z: Lens center to the lower edge of the screen (H) (inches)
Picture size (diag.) = Screen size (diag.) 0.96047
600
500
400
300
200
150
100
84
480
400
320
240
160
120
80
67
360
300
240
180
120
90
60
50
160 1
133 6
106 8
79 9
53 2
39 8
26 3
22 0
(48.8 m)
(40.7 m)
(32.5 m)
(24.3 m)
(16.2 m)
(12.1 m)
(8.0 m)
(6.7 m)
Diag. Width
Screen size
Height
Projection distance (L)
Maximum
114 2
95 2
75 9
56 9
37 9
28 3
18 4
15 5
(34.8 m)
(29.0 m)
(23.1 m)
(17.3 m)
(11.5 m)
(8.6 m)
(5.6 m)
(4.7 m)
Minimum
15 0
12 6
10 0
7 6
5 0
3 9
2 6
2 1
(457.2 cm)
(381.0 cm)
(304.8 cm)
(228.6 cm)
(152.4 cm)
(114.3 cm)
(76.2 cm)
(64.0 cm)
11.7
9.8
7.8
5.9
3.9
2.9
2.0
1.7
(29.8 cm)
(24.8 cm)
(19.8 cm)
(14.9 cm)
(9.9 cm)
(7.4 cm)
(5.0 cm)
(4.2 cm)
Lens center to the lower edge of the screen (H)
Upper Lower
Video Input (4:3)
The formula for screen size and projection distance
y
1
(Max.)
= (0.0817x 0.1868) 3.28
y
2
(Min.) = (0.0583x 0.1862) 3.28
z
1
(Upper) = 0.300x
z
2
(Lower) =0.020x
x: Screen size (diag.) (inches)
y: Projection distance (L) (feet)
z: Lens center to the lower edge of the screen (H) (inches)
Video Input (16:9)
500
400
300
200
150
133
106
100
92
84
435
348
261
174
131
116
92
87
80
73
245
196
147
98
74
65
52
49
45
41
145 4
116 2
86 11
57 9
43 4
38 5
30 2
28 7
26 3
23 11
(44.3 m)
(35.4 m)
(26.5 m)
(17.6 m)
(13.2 m)
(11.7 m)
(9.2 m)
(8.7 m)
(8.0 m)
(7.3 m)
Diag. Width
Screen size
Height
Projection distance (L)
Maximum
103 8
82 8
62 0
41 0
30 6
27 3
21 4
20 4
18 8
16 9
(31.6 m)
(25.2 m)
(18.9 m)
(12.5 m)
(9.3 m)
(8.3 m)
(6.5 m)
(6.2 m)
(5.7 m)
(5.1 m)
Minimum
10 3
8 2
6 2
4 1
3 1
2 9
2 2
2 1
1 11
1 9
(311.3 cm)
(249.1 cm)
(186.8 cm)
(124.5 cm)
(93.4 cm)
(82.8 cm)
(66.0 cm)
(62.3 cm)
(57.3 cm)
(52.3 cm)
Lens center to the lower edge of the screen (H)
Upper
4 4
3 5
2 7
1 9
1 4
1 2
11.0
10.4
9.5
8.7
(131.4 cm)
(105.2 cm)
(78.9 cm)
(52.6 cm)
(39.4 cm)
(35.0 cm)
(27.9 cm)
(26.3 cm)
(24.2 cm)
(22.1 cm)
Lower
The formula for screen size and projection distance
y
1
(Max.) = (0.0890x 0.1868) 3.28
y
2
(Min.) = (0.0635x 0.1862) 3.28
z
1
(Upper) = 0.245x
z
2
(Lower) =0.103x
x: Screen size (diag.) (inches)
y: Projection distance (L) (feet)
z: Lens center to the lower edge of the screen (H) (inches)
• There is an error of 3% in the formula above.
• Values with a minus () sign indicate the distance of the lens center below the bottom of the screen.
E-27
Setup & Connections
Adjusting the Projection Distance
AN-LV80EZ
Throw distance ratio
3.8 to 5.3 :1
600
500
400
300
200
150
100
84
480
400
320
240
160
120
80
67
360
300
240
180
120
90
60
50
215 7
179 6
143 4
107 7
71 6
53 6
35 5
29 10
(65.7 m)
(54.7 m)
(43.7 m)
(32.8 m)
(21.8 m)
(16.3 m)
(10.8 m)
(9.1 m)
Diag. Width
Screen size
Height
Projection distance (L)
Maximum
153 10
127 11
102 4
76 9
50 10
38 1
25 3
21 0
(46.9 m)
(39.0 m)
(31.2 m)
(23.4 m)
(15.5 m)
(11.6 m)
(7.7 m)
(6.4 m)
Minimum
15 0
12 6
10 0
7 6
5 0
3 9
2 6
2 1
(457.2 cm)
(381.0 cm)
(304.8 cm)
(228.6 cm)
(152.4 cm)
(114.3 cm)
(76.2 cm)
(64.0 cm)
0 0
0 0
0 0
0 0
0 0
0 0
0 0
0 0
(0.0 cm)
(0.0 cm)
(0.0 cm)
(0.0 cm)
(0.0 cm)
(0.0 cm)
(0.0 cm)
(0.0 cm)
Lens center to the lower edge of the screen (H)
Upper Lower
Computer Input (5:4)
The formula for screen size and projection distance
y
1
(Max.) = (0.1097x 0.1593) 3.28
y
2
(Min.) = (0.0784x 0.1592) 3.28
z
1
(Upper) = 0.300x
z
2
(Lower) = 0
x: Screen size (diag.) (inches)
y: Projection distance (L) (feet)
z: Lens center to the lower edge of the screen (H) (inches)
Picture size (diag.) = Screen size (diag.) 0.96047
600
500
400
300
200
150
100
84
480
400
320
240
160
120
80
67
360
300
240
180
120
90
60
50
229 8
191 3
152 11
114 6
76 1
57 1
37 9
31 10
(70.0 m)
(58.3 m)
(46.6 m)
(34.9 m)
(23.2 m)
(17.4 m)
(11.5 m)
(9.7 m)
Diag. Width
Screen size
Height
Projection distance (L)
Maximum
164 1
136 6
109 3
81 8
54 6
40 8
26 11
22 8
(50.0 m)
(41.6 m)
(33.3 m)
(24.9 m)
(16.6 m)
(12.4 m)
(8.2 m)
(6.9 m)
Minimum
15 0
12 6
10 0
7 6
5 0
3 9
2 6
2 1
(457.2 cm)
(381.0 cm)
(304.8 cm)
(228.6 cm)
(152.4 cm)
(114.3 cm)
(76.2 cm)
(64.0 cm)
11.7
9.8
7.8
5.9
3.9
2.9
2.0
1.7
(29.8 cm)
(24.8 cm)
(19.8 cm)
(14.9 cm)
(9.9 cm)
(7.4 cm)
(5.0 cm)
(4.2 cm)
Lens center to the lower edge of the screen (H)
Upper Lower
Video Input (4:3)
The formula for screen size and projection distance
y
1
(Max.)
= (0.1170x 0.1593) 3.28
y
2
(Min.) = (0.0836x 0.1592) 3.28
z
1
(Upper) = 0.300x
z
2
(Lower) =0.020x
x: Screen size (diag.) (inches)
y: Projection distance (L) (feet)
z: Lens center to the lower edge of the screen (H) (inches)
Video Input (16:9)
500
400
300
200
150
133
106
100
92
84
435
348
261
174
131
116
92
87
80
73
245
196
147
98
74
65
52
49
45
41
208 8
166 8
125 0
83 0
62 4
55 1
44 0
41 4
38 1
34 9
(63.6 m)
(50.8 m)
(38.1 m)
(25.3 m)
(19.0 m)
(16.8 m)
(13.4 m)
(12.6 m)
(11.6 m)
(10.6 m)
Diag. Width
Screen size
Height
Projection distance (L)
Maximum
148 11
119 1
89 3
59 5
44 3
39 4
31 2
29 6
26 11
24 7
(45.4 m)
(36.3 m)
(27.2 m)
(18.1 m)
(13.5 m)
(12.0 m)
(9.5 m)
(9.0 m)
(8.2 m)
(7.5 m)
Minimum
10 3
8 2
6 2
4 1
3 1
2 9
2 2
2 1
1 11
1 9
(311.3 cm)
(249.1 cm)
(186.8 cm)
(124.5 cm)
(93.4 cm)
(82.8 cm)
(66.0 cm)
(62.3 cm)
(57.3 cm)
(52.3 cm)
Lens center to the lower edge of the screen (H)
Upper
4 4
3 5
2 7
1 9
1 4
1 2
11.0
10.4
9.5
8.7
(131.4 cm)
(105.2 cm)
(78.9 cm)
(52.6 cm)
(39.4 cm)
(35.0 cm)
(27.9 cm)
(26.3 cm)
(24.2 cm)
(22.1 cm)
Lower
The formula for screen size and projection distance
y
1
(Max.) = (0.1275x 0.1593) 3.28
y
2
(Min.) = (0.0911x 0.1592) 3.28
z
1
(Upper) = 0.245x
z
2
(Lower) =0.103x
x: Screen size (diag.) (inches)
y: Projection distance (L) (feet)
z: Lens center to the lower edge of the screen (H) (inches)
• There is an error of 3% in the formula above.
• Values with a minus () sign indicate the distance of the lens center below the bottom of the screen.
E-28
Setup & Connections
Adjusting the Projection Distance
Upper and Lower Lens Shift Position
• This projector is equipped with a lens shift function that lets you adjust the projection height.
• Adjust to match the setup configuration.
Screen size: 100 inches (254 cm)
Computer Input: 5:4
AN-LV40EZ as an example
–H
Screen
Upper and Lower Lens Shift Position (Ceiling Mount)
When the projector is in the inverted position, use the upper edge of the screen as the base line, and exchange
the lower and upper lens shift values.
Screen
Upper lens
shift position
H: 2 6 (76.2 cm)
Lower lens shift position H: 6.0
(15.2 cm)
Lower edge of screen (White portion) = Standard (0) point
Upper lens shift position
(High mount setup)
Lower lens shift position
(Desktop setup)
Upper edge of screen
Lens center
Lens center
–H
• Optimal image quality is produced with the projector positioned perpendicular to the screen with all feet flat and level. Tilting or angling
the projector will reduce the effectiveness of the lens shift function.
Screen size: 100 inches (254 cm)
Computer Input: 5:4
AN-LV40EZ as an example
E-29
Setup & Connections
LENS Button
Projector
1.2.3 4.5.6
1, 4a
4b
3
2
4b
Remote Control
1 Press LENS to select mode. Each time LENS is
pressed, the screen changes as shown on the
left.
2 Press ENTER to display test
pattern.
3 Press ∂/ƒ/ß/© to make
adjustments.
4 a. Press LENS until normal screen appears.
b. To reset the “KEYSTONE” and “DIGITAL SHIFT”
setting, press UNDO.
Digital Image Adjustments
This function can be used to adjust the focus, zoom,
lens shift, keystone and digital shift settings.
(Slide the MOUSE/ADJUSTMENT switch
on the remote control to the ADJ. position.)
MOUSE
ADJ.
• On 4:3 NORMAL image, the same setting as 16:9 WIDE
image can be used.
• At first when buttons are pushed, “ZOOM” and “LENS
SHIFT” functions move slowly. Keep pushing to move them
faster.
• Straight lines and the edges of the displayed image may
appear jagged, when adjusting the KEYSTONE setting.
• Do not touch the lens when adjusting the focus or zoom.
• Digital shift function only works with WIDE picture display
modes during video or DTV input. (See page 34 for details.)
The DIGITAL SHIFT screen is not displayed when projecting
images other than WIDE.
Digital Shift
or
Press ∂. Press ƒ.
On-screen Display
(Example: 5:4
NORMAL image)
On-screen Display
(Example: 16:9
WIDE image)
E-30
Setup & Connections
Rear Projection
• Place a translucent screen between the projector and
the audience.
• Use the projector’s menu system to reverse the
projected image. (See page 56 for use of this
function.)
• Optimal image quality can be achieved when the projector
is positioned perpendicular to the screen with all feet flat
and level.
Projection Using a Mirror
• When the distance between the projector and screen
is not sufficient for normal rear projection, you can
use a mirror to reflect the image onto the screen.
• Place a mirror (normal flat type) in front of the lens.
• Project the normal image onto the mirror.
• The image reflected from the mirror is projected onto
the translucent screen.
CAUTION
• When using a mirror, be sure to carefully position both the
projector and the mirror so the light does not shine into the
eyes of the audience.
• It is recommended that you use the optional Sharp
ceiling-mount bracket for this installation.
• Before mounting the projector, contact your nearest
Authorized Sharp Industrial LCD Products Dealer or
Service Center to obtain the recommended ceiling-
mount bracket (sold separately). (AN-XGCM70
ceiling-mount bracket, AN-EP101AP extension tube
for AN-XGCM70.)
• When the projector is in the inverted position, use the
upper edge of the screen as the base line.
• Use the projector’s menu system to select the
appropriate projection mode. (See page 56 for use
of this function.)
Ceiling-mount Projection
Image Projection
E-31
Operation Buttons
1.2.3 4.5.6
Conference Series
Selecting the Input Signal Source
Using the Operation Buttons
Muting the Sound
Press VOLUME / to adjust the volume.
Press MUTE to temporarily turn off the sound.
Press MUTE again to turn the sound back on.
1.2.3 4.5.6
Projector Remote Control
Projector Remote Control
VOLUME
buttons
MUTE
button
1.2.3 4.5.6
Projector Remote Control
INPUT
buttons
Adjusting the Volume
Press INPUT 1.2.3 or INPUT 4.5.6 again to change the
mode.
• When no signal is received, “NO SIGNAL” will be displayed.
When a signal that the projector is not preset to receive is
received, “NOT REG.” will be displayed.
INPUT 1 Mode INPUT 2 Mode INPUT 3 Mode
INPUT 4 Mode INPUT 5 Mode
INPUT 6 Mode
On-screen Display
On-screen Display
On-screen Display
E-32
Operation Buttons
1.2.3 4.5.6
1, 2
This function can be used to superimpose a black
screen over the projected image.
Blacking out the Projected Image
Press BLACK SCREEN. The screen turns black and
“BLACK SCREEN” is displayed on the screen. To return
to the original projected image, press BLACK SCREEN
again.
• To use the remote control to operate this
function, slide the MOUSE/ADJUSTMENT
switch to the MOUSE position before pressing
BLACK SCREEN.
1.2.3 4.5.6
Superimposing a Black Screen
Projector Remote Control
BLACK
SCREEN
button
Displaying a Still Image
This function allows you to instantly freeze a moving
image. This is useful when you want to display a still
image from a computer or video, giving you more time
to explain the image to the audience.
You can also use this function to display a still image
from a computer while you make preparations for the
next computer images to be presented.
1 Press FREEZE to freeze the image.
2 Press FREEZE again to return to the moving
image.
Projector Remote Control
On-screen Display
Projected Image
sg
MOUSE
ADJ.
E-33
Operation Buttons
1.2.3 4.5.6
3
2
1
3
Magnifying a Specific Portion of an Image
s
On-screen Display
Projector
This function allows you to magnify a specific portion of
an image. This is useful when you want to display a
detailed portion of the image.
(Slide the MOUSE/ADJUSTMENT switch
on the remote control to the ADJ. position)
1 Press ENLARGE. Each time ENLARGE is
pressed, the image will be magnified.
2 When the image is magnified, you can pan and
scan around the image by using ∂/ƒ/ß/©.
• ENLARGE does not work with UXGA signal image.
• Each time ENLARGE is pressed, image magnification
toggles as shown below.
1 4 9 16 36 64
• If the input signal is changed during digital image
magnification, the image will return to 1. The input signal
is changed
(a) when INPUT 1.2.3 or INPUT 4.5.6 is pressed,
(b) when the input signal is interrupted, or
(c) when the input resolution and refresh rate changes.
3 To return to 1, press UNDO.
Remote Control
MOUSE
ADJ.
4
E-34
Operation Buttons
Adjusting the Picture Aspect Ratio
This function allows you to modify or customize the
picture display mode to enhance the input image.
Depending on the input signal, you can choose
NORMAL, FULL, DOT BY DOT, BORDER, STRETCH or
SMART STRETCH image.
1 Press RESIZE. Each time RESIZE is pressed, the
picture mode changes as shown below.
2 To return to the standard image, press UNDO
while “RESIZE” is displayed on the screen.
COMPUTER
Input Signal
NORMAL FULL
Output screen image
DOT BY DOT
FOR 4:3 aspect ratio
FOR 4:3 aspect ratio
(1280 960)
FOR 5:4 aspect ratio
(1280 1024)
NORMAL
RESIZE
NORMAL
RESIZE
NORMAL
RESIZE
DOT BY DOT
RESIZE
FULL
RESIZE
FULL
RESIZE
Projector Remote Control
1.2.3 4.5.6
2
1
2
VIDEO/DTV
480i
480P
NTSC
PAL
SECAM
720P
1080i
Input Signal
NORMAL FULL BORDER
Output screen image
STRETCH SMART STRETCH
FOR 4:3 aspect ratio
FOR 16:9 aspect ratio
with squeeze
NORMAL
RESIZE
NORMAL
RESIZE
NORMAL
RESIZE
FULL
RESIZE
FULL
RESIZE
FULL
RESIZE
BORDER
RESIZE
BORDER
RESIZE
STRETCH
RESIZE
STRETCH
RESIZE
SMART STRETCH
RESIZE
SMART STRETCH
RESIZE
1280 960 1280 1024 960 720
NTSC, 480i
1280 960 1280 1024 960 720
PAL, 525i
1280 960 1280 1024 960 720
480P
1280 720* 1280 1024
–720P
1280 720* 1280 1024
–
1280 720*
1280 720*
1280 720*
1280 720*
NORMAL FULL BORDER STRETCH
SMART
STRETCH
1280 720*
1280 720*
–
–
–
–1080i
For 4:3
aspect ratio
For 16:9
aspect ratio
EXAMPLE
EXAMPLE
1280 960 1280 1024 800 600
SVGA (800 600)
NORMAL
FULL
DOT BY DOT
For 4:3
aspect ratio
For without
4:3 aspect ratio
1280 960 1280 1024 1024 768
XGA (1024 768)
1280 960 1280 1024
–
SXGA (1280 960)
1280 960 1280 1024
–
UXGA (1600 1200)
1280 1024
––
SXGA (1280 1024)
* The digital image shift function can be used with these picture
display modes.
E-35
Operation Buttons
Gamma Correction Function
1.2.3 4.5.6
2
1
2
• Gamma is an image quality enhancement function
that offers a richer image by brightening the darker
portions of the image without altering the brightness
of the brighter portions.
• Four gamma settings are available to allow for
differences in the images displayed and in the
brightness of the room.
• When you are displaying images with frequent, dark
scenes, such as a film or concert, or when you are
displaying images in a bright room, this feature makes
the dark scenes easier to see and gives the impres-
sion of greater depth in the image.
Gamma Modes
On-screen Display
ss s
STANDARD
GAMMA 1
GAMMA 2
CUSTOM
Gamma modeSelected Mode
STANDARD
GAMMA 1
GAMMA 2
CUSTOM
Standard picture without gamma correction.
Brightens darker portions of image for more
enhanced presentations.
Gives greater depth to darker portions of image
for a more exciting theater experience.
Allows you to adjust gamma value using Sharp
Advanced Presentation Software.
MOUSE
ADJ.
(Slide the MOUSE/ADJUSTMENT switch
on the remote control to the ADJ. position.)
1 Press GAMMA. Each time GAMMA is pressed,
the gamma level toggles as shown on the left.
2 To return to the standard image, press UNDO
while “GAMMA” is displayed on the screen.
Projector Remote Control
E-36
Operation Buttons
Selecting the Remote Control Mode
MOUSE
ADJ.
MOUSE/ADJUSTMENT switch
(Remote control)
MOUSE
ADJ.
Using the Remote Control as a Wireless Mouse
The remote control has the following three functions:
• Projector control
• Wireless mouse
• Laser pointer
Wireless mouse/
Laser pointer
Projector control
Operating the Remote Control
Controling the Projector
Using the Wireless Mouse
Remote Control/Mouse Receiver Positioning
• The remote control can be used to control the projector within the ranges shown below.
• The remote mouse receiver can be used with the remote control to control the mouse functions of a connected
computer within the ranges shown below.
• The signal from the remote control can be reflected off a screen for easy operation. However, the effective distance of the
signal may differ due to the screen material.
45˚
23 (7 m)
30˚
30˚
30˚
45˚
Remote Control
Remote Control
Remote
mouse
receiver
Remote Control
13(4 m)
30˚
120˚
30˚
E-37
Operation Buttons
Be sure the supplied remote mouse receiver is connected to your computer.
Slide the MOUSE/ADJUSTMENT switch to MOUSE.
MOUSE mode buttons
Operating the Remote Control
Use as a Wireless Mouse
• For one-button mouse systems, use either the LEFT-CLICK or RIGHT-CLICK button.
• Press BACKLIGHT, and the buttons will light up. Green lights refer to mouse operations, and red lights to projector
adjustments.
Position of MOUSE/ADJUSTMENT switch
ON (RED)
MOUSE
LASER POINTER (GREEN)
BLACK SCREEN (GREEN)
RIGHT-CLICK (GREEN)
MOUSE (NOT LIT)
LEFT-CLICK (NOT LIT)
ADJ.
MENU (RED)
LENS (RED)
ENTER (RED)
ADJUSTMENT (NOT LIT)
UNDO (NOT LIT)
Button name
LASER POINTER/MENU
BLACK SCREEN/LENS
RIGHT-CLICK/ENTER
MOUSE/ADJUSTMENT
LEFT-CLICK/UNDO
POWER ON/OFF
VOLUME /
MUTE
Position of MOUSE/ADJUSTMENT switch
ON (RED)
ADJ.
Button name
INPUT 1, 2, 3
INPUT 4, 5, 6
FREEZE
AUTO SYNC
ENLARGE
RESIZE
TOOLS
GAMMA
MOUSE
LASER
POINTER
RIGHT-CLICK
MOUSE
BLACK SCREEN
MOUSE
ADJ.
MOUSE/
ADJUSTMENT
switch
LEFT-CLICK
1.2.3 4.5.6
Conference Series
BACKLIGHT
E-38
Operation Buttons
Connecting the Mouse Receiver
Connecting the Remote Mouse Receiver
You can use the remote control as a remote mouse to operate computers
compatible with PS/2 or USB type mouse systems.
1.2.3 4.5.6
Conference Series
1 Connect one end of the supplied USB mouse control cable to the corresponding terminal on the computer.
2 Connect the other end to the USB port on the remote mouse receiver.
USB port
USB mouse control
cable
QCNW-5680CEZZ
Remote mouse
receiver
RUNTK0673CEZZ
Use the USB port
(PC or Macintosh) to
connect the supplied
USB mouse control
cable to the remote
mouse receiver.
1 Turn off the power of the PC.
2 Connect one end of the supplied PS/2 mouse control cable to the corresponding terminal on the PC.
3 Connect the other end to the PS/2 port on the remote mouse receiver.
4 Turn on the power of the PC.
CAUTION
• Do not connect or disconnect the mouse control cables to or from the computer while it is on.
This may damage your computer.
• Do not connect both the PS/2 and USB mouse control cables to the remote mouse receiver.
• Windows 95 does not support USB mouse driver software.
• The minimum system requirements for the USB type mouse system are shown below.
Windows
Hardware: PC/AT compatible machine with USB port that has Windows 98/Windows NT 5.0 or
higher installed.
OS: Windows 98/Windows NT 5.0 or higher
Macintosh
Hardware: Macintosh series with USB port
OS: Mac OS 8.5 or higher
Remote mouse
receiver
RUNTK0673CEZZ
PS/2 mouse control
cable
QCNW-5113CEZZ
PS/2 port
Use the PS/2 port
(PC) to connect the
supplied PS/2 mouse
control cable to the
remote mouse
receiver.
Connecting to the USB port on a PC or Macintosh
Connecting to the PS/2 port on a PC
E-39
Operation Buttons
Using as a Laser Pointer
Use as a Laser Pointer
Slide the MOUSE/ADJUSTMENT switch to MOUSE, and press LASER POINTER ( ) to activate
the laser pointer.
1.2.3 4.5.6
Conference Series
LASER
POINTER
MOUSE
ADJ.
MOUSE/ADJUSTMENT
switch
• When the button is released, the light automatically goes off.
• For safety reasons, the laser pointer automatically goes off after 1 minute of continuous use. To turn it on, release LASER
POINTER (
) and press again.
CAUTION
• Do not look into the laser pointer window or shine the laser beam on yourself or others. (The laser beam used in this
product is harmless when directed onto the skin. However, be careful not to project the beam directly into the eyes.)
Using as a Wired Remote Control
Wired Remote Control
When the remote control cannot be used due to the range
or positioning of the projector (rear projection, etc.), connect
a 3.5 mm stereo minijack cable (sold separately) from the
wired remote control input on the bottom of the remote
control to the WIRED REMOTE control input terminal on the
side of the projector.
• The laser pointer and wireless mouse functions can still be
operated with the wired remote control.
3.5 mm stereo minijack cable
(sold separately)
E-40
Basic Operation
Basic Operations
Projector
Using the GUI (Graphical User Interface) Menu Screen
(GUI) On-screen Display
1
INPUT 1, 2 (RGB) or 3 (DIGITAL) mode
1
INPUT 4, 5 (VIDEO) mode
4
(Slide the MOUSE/ADJUSTMENT switch
on the remote control to the ADJ. position.)
1 Press MENU to display the INPUT 1, 2, 3, 4 or 5
mode menu bar.
2 Press ß/© to select an adjustment menu on the
menu bar.
3 Press ∂/ƒ to select a specific adjustment item.
4 To display a single adjustment item, press ENTER
after selecting the item. Only the menu bar and
the selected adjustment item will appear.
5 Press ß/© to adjust the item.
6 Press UNDO to return to the previous screen.
7 To exit from the GUI, press MENU.
• For details on items on the menu screen, see the tree charts
on pages 41 and 42.
ß 2 ©ß 2 ©
ß 2 ©
MOUSE
ADJ.
1.2.3 4.5.6
1, 7
6
2, 3, 5
4
6
This projector has two sets of menu screens that allow you to adjust the image and various projector settings.
These menu screens can be operated from the projector or the remote control with the following procedure.
∂
3
ƒ
ß 5 ©
∂
3
ƒ
ß 5 ©
Remote Control
ß 5 ©
E-41
Basic Operation
Menu Bars
Items on the INPUT 1, 2 or 3 Mode Menu Bar
Main menu
Sub menu
Main menu
Sub menu
Picture Options
Options
Fine Sync
Audio
Tint Ⳮ30ⳮ30
Color Ⳮ30ⳮ30
Sharp Ⳮ30ⳮ30
Contrast Lamp 1
Lamp 2
Ⳮ30ⳮ30
Bright Ⳮ30ⳮ30
Red Ⳮ30ⳮ30
Blue
Reset
Ⳮ30ⳮ30
CLR Temp
Progressive Mode
Signal Type
Ⳮ3ⳮ3
Component
RGB
2D Progressive
3D Progressive
Film Mode
Auto Sync
Clock Ⳮ150ⳮ150
Ⳮ150ⳮ150
[ON/OFF]
Auto Sync Disp
[ON/OFF]
Phase Ⳮ60ⳮ60
H-Pos
V-Pos
Reset
Save Setting
Select Setting
Special Modes
Ⳮ60ⳮ60
Signal Info
1
2
•
•
7
Resolution
800⳯600
640⳯480
1
2
•
•
7
Resolution
Vert Freq
75 Hz
72 Hz
1
2
•
•
7
Resolution
800⳯600
640⳯480
Vert Freq
75 Hz
72 Hz
Resolution
Hor Freq
Vert Freq
640⳯480
37.5 kHz
72 Hz
Economy Mode
OSD Display
Background
[ON/OFF]
[ON/OFF]
Auto Power Off
ID No. Display
MNTR Out/RS232C
[ON/OFF]
Startup Image
Treble Ⳮ30ⳮ30
Balance Ⳮ30ⳮ30
Bass Ⳮ30ⳮ30
Reset
Pict in Pict
Sharp
Sharp
Custom
Custom
Blue
None
None
Display Off
Standby Off
Display On
Normal
Level A
Level B
Lamp Timer
Lamp Mode
Both Lamps
Lamp 1 Only
Lamp 2 Only
Equal Use
PRJ Mode
Stack Setting
Keylock Level
Set Inputs
RS-232C
Set ID No.
Password
Optional Board
CeilingⳭFront
CeilingⳭRear
Front
Rear
Level B
Input 1
Input 2
Input 3
Input 4
Input 5
9600bps
115200bps
ID No.
Input 6
38400bps
Old Password
Reconfirm
New Password
Slave
Level A
Master
Normal
Normal
Language
English
Deutsch
Español
Nederlands
Français
Italiano
Svenska
Português
Status
[ON/OFF]
[ON/OFF]
[ON/OFF]
[ON/OFF]
[ON/OFF]
[ON/OFF]
• The resolution, vertical frequency and horizontal frequency figures displayed above are for example purposes only.
•“Color”, “Tint”, and “Sharp” appear only when Component input is selected in INPUT 1 or 2 mode. For INPUT 3 (DVI), in
“Picture” menu, only “CLR Temp” is active and the other menus are displayed in gray. In “Fine Sync” menu, only “Signal
Info” is active and the other menus are displayed in gray.
• Only the items highlighted in the tree charts above can be adjusted.
• To adjust the items under the sub menu, press © after selecting the sub menu.
E-42
Basic Operation
Menu Bars
Items on the INPUT 4 or 5 Mode Menu Bar
Main menu
Sub menu
Main menu
Sub menu
Picture Options
Audio
Tint Ⳮ30ⳮ30
Color Ⳮ30ⳮ30
Sharp Ⳮ30ⳮ30
Contrast Lamp 1
Lamp 2
Ⳮ30ⳮ30
Bright Ⳮ30ⳮ30
Red Ⳮ30ⳮ30
Blue
Reset
Ⳮ30ⳮ30
CLR Temp
Progressive Mode
Signal Type
Ⳮ3ⳮ3
Video
Component
2D Progressive
3D Progressive
Film Mode
Economy Mode
Background
[ON/OFF]
Auto Power Off
ID No. Display
MNTR Out/RS232C
[ON/OFF]
Startup Image
Treble Ⳮ30ⳮ30
Balance Ⳮ30ⳮ30
Bass Ⳮ30ⳮ30
Reset
Sharp
Sharp
Custom
Custom
Blue
None
None
Display Off
Standby Off
Display On
Options
3D DNR
OSD Display
[ON/OFF]
Video System
Normal
PAL (50/60Hz)
Level A
SECAM
Level B
Auto
NTSC3.58
PAL–M
PAL–N
NTSC4.43
Lamp Timer
Lamp Mode
Both Lamps
Lamp 1 Only
Lamp 2 Only
Equal Use
PRJ Mode
Stack Setting
Keylock Level
Set Inputs
RS-232C
Set ID No.
Password
Optional Board
CeilingⳭFront
CeilingⳭRear
Front
Rear
Level B
Input 1
Input 2
Input 3
Input 4
Input 5
9600bps
115200bps
ID No.
Input 6
38400bps
Old Password
Reconfirm
New Password
Slave
Level A
Master
Normal
Normal
Language
English
Deutsch
Español
Nederlands
Français
Italiano
Svenska
Português
Status
[ON/OFF]
[ON/OFF]
[ON/OFF]
[ON/OFF]
[ON/OFF]
[ON/OFF]
• Only the items highlighted in the tree charts above can be adjusted.
• To adjust the items under the sub menu, press © after selecting the sub menu.
E-43
Basic Operation
Adjusting the Picture
You can adjust the projector’s picture to your prefer-
ences with the following picture settings.
Description of Adjustment Items
Projector
For less contrast
For less brightness
For less color intensity
Skin tones become purplish
For less sharpness
For weaker red
For weaker blue
Selected item
For more contrast
For more brightness
For more color intensity
Skin tones become greenish
For more sharpness
For stronger red
For stronger blue
ß button
© button
All image adjustment items are returned to the factory preset
settings.
Contrast
Bright
Color
Tint
Sharp
Red
Blue
Reset
•“Color”, “Tint” and “Sharp” do not appear for RGB input in
INPUT 1 or 2 mode.
(Slide the MOUSE/ADJUSTMENT switch
on the remote control to the ADJ. position.)
1 Press MENU. Menu bar and “Picture” menu
screen appear. GUI operation guide is also
displayed.
2 Press ∂/ƒ to select a specific adjustment item.
3 Press ß/© to move the mark of the selected
adjustment item to the desired setting.
4 To exit from the GUI, press MENU.
• To reset all adjustment items, select “Reset” on the “Picture”
menu screen and press ENTER.
• The adjustments can be stored separately in the INPUT 1
to 5 modes.
• Depending on the type of signal received, “Sharp” may not
be adjustable for COMPONENT input in INPUT 1 or 2 mode.
MOUSE
ADJ.
Remote Control
1.2.3 4.5.6
1, 4
2, 3
(GUI) On-screen Display
e. g. (RGB input in INPUT 1 or 2 mode)
1
2
E-44
Basic Operation
Adjusting the Picture
Projector Remote Control
Adjusting the Color Temperature
This function can be used to adjust the color
temperature to suit the type of image input to the
projector (video, computer image, TV broadcast, etc.).
Decrease the color temperature to create warmer,
reddish images for natural flesh tones. Increase the color
temperature to create cooler, bluish images for a brighter
picture.
Description of Color Temperature
(Slide the MOUSE/ADJUSTMENT switch
on the remote control to the ADJ. position.)
1 Press MENU. Menu bar and “Picture” menu
screen appear. GUI operation guide is also
displayed.
2 Press ∂/ƒ to select “CLR Temp”.
3 Press ß/© to move the mark of the selected
adjustment item to the desired setting.
4 To exit from the GUI, press MENU.
1.2.3 4.5.6
1, 4
2, 3
(GUI) On-screen Display
Increases color temperature for
cooler, bluish, florescent-like
images.
(High color temperature)
Decreases color temperature for
warmer, reddish,
incandescent-like images.
(Low color temperature)
ⳮ3 Ⳮ3
(Red) ß button © button (Blue)
MOUSE
ADJ.
E-45
Basic Operation
Projector Remote Control
Selecting the Signal Type
This function allows you to select the input signal type
RGB (VIDEO) or COMPONENT for INPUT 1, 2, 4 or 5
port.
(Slide the MOUSE/ADJUSTMENT switch
on the remote control to the ADJ. position.)
1 Press MENU. Menu bar and “Picture” menu
screen appear. GUI operation guide is also
displayed.
2 Press ∂/ƒ to select “Signal Type”, and then
press ©.
3 Press ∂/ƒ to select “RGB (VIDEO)” or
“Component”.
4 Press ENTER to save the setting.
5 To exit from the GUI, press MENU.
Adjusting the Picture
Projector
Remote Control
1.2.3 4.5.6
1, 5
2, 3
4
(GUI) On-screen Display
1.2.3 4.5.6
1, 5
2, 3
4
(GUI) On-screen Display
Progressive Mode
This function allows you to select the progressive display
of a video signal. The progressive display projects a
smoother video image.
(Slide the MOUSE/ADJUSTMENT switch
on the remote control to the ADJ. position.)
1 Press MENU. Menu bar and “Picture” menu
screen appear. GUI operation guide is also
displayed.
2 Press ∂/ƒ to select “Progressive Mode”, and
then press ©.
3 Press ∂/ƒ to select “2D Progressive”, “3D
Progressive” or “Film Mode”.
4 Press ENTER to save the setting.
5 To exit from the GUI, press MENU.
MOUSE
ADJ.
Progressive Mode
Selects the progressive conversion mode.
2D Progressive
This function is useful to display fast-moving images such as sports
and action films. Mode that optimizes the image in a displayed frame.
3D Progressive
This function is useful to display relatively slow-moving images such
as drama and documentary more clearly.
Mode that optimizes the image by estimating the movement of a
number of preceding and succeeding frames.
Film Mode
Reproduces the image of film software clearly. Displays the optimized
image of film transformed with three-two pull down enhancement to
progressive mode images.
MOUSE
ADJ.
E-46
Basic Operation
When displaying computer patterns which are very
detailed (tiling, vertical stripes, etc.), interference may
occur between the LCD pixels, causing flickering,
vertical stripes, or contrast irregularities in portions of
the screen. Should this occur, adjust “Clock”, “Phase”,
“H-Pos” and “V-Pos” for the optimum computer image.
• Computer image adjustments can be made easily by
pressing AUTO SYNC (
). See page 49 for details.
(GUI) On-screen Display
Projector
Adjusts vertical noise.
Adjusts horizontal noise (similar to tracking on your VCR).
Centers the on-screen image by moving it to the left or right.
Centers the on-screen image by moving it up or down.
Clock
Phase
H-Pos
V-Pos
Description of Adjustment Items
(Select the desired computer input mode with INPUT 1
or 2.)
(Slide the MOUSE/ADJUSTMENT switch
on the remote control to the ADJ. position.)
1 Press MENU.
2 Press ß/© to select “Fine Sync”.
3 Press ∂/ƒ to select a specific adjustment item.
4 Press ß/© to move the mark of the selected
adjustment item to the desired setting.
5 To exit from the GUI, press MENU.
• To reset all adjustment items, select “Reset” on the “Fine
Sync” menu screen and press ENTER.
2
DescriptionSelected item
Remote Control
Adjusting the Computer Images (RGB menu only)
1.2.3 4.5.6
1, 5
2, 3, 4
3
MOUSE
ADJ.
E-47
Basic Operation
Adjusting the Computer Images (RGB menu only)
Saving and Selecting Adjustment Settings
This projector allows you to store up to seven adjustment
settings for use with various computers. Once these
settings are stored, they can be easily selected each
time you connect a computer to the projector.
Saving the adjustment setting
(Slide the MOUSE/ADJUSTMENT switch
on the remote control to the ADJ. position.)
1 Press MENU.
2 Press ß/© to select “Fine Sync”.
3 Press ∂/ƒ to select “Save Setting”, and then
press ©.
4 Press ∂/ƒ to select the desired memory location
of the setting.
5 Press ENTER to save the setting.
6 To exit from the GUI, press MENU.
Selecting a saved setting
(Slide the MOUSE/ADJUSTMENT switch
on the remote control to the ADJ. position.)
1 Press MENU.
2 Press ß/© to select “Fine Sync”.
3 Press ∂/ƒ to select “Select Setting”, and then
press ©.
4 Press ∂/ƒ to select the desired memory setting.
5 Press ENTER to select the setting.
6 To exit from the GUI, press MENU.
• If a memory position has not been set, a resolution and
frequency setting will not be displayed.
• When selecting the stored adjustment setting with “Select
Setting”, the computer system should match the stored
setting.
(GUI) On-screen Display
2
3
MOUSE
ADJ.
Projector Remote Control
1.2.3 4.5.6
1, 6
5
2, 3, 4
3
MOUSE
ADJ.
E-48
Basic Operation
Adjusting the Computer Images (RGB menu only)
Special Mode Adjustment
Ordinarily, the type of input signal is detected and the
correct resolution mode is automatically selected.
However, for some signals, the optimal resolution mode
in “Special Modes” on the “Fine Sync” menu screen
may need to be selected to match the computer display
mode.
(Slide the MOUSE/ADJUSTMENT switch
on the remote control to the ADJ. position.)
1 Press MENU.
2 Press ß/© to select “Fine Sync”.
3 Press ∂/ƒ to select “Special Modes”, and then
press ©.
4 Press ∂/ƒ to select the optimal resolution mode.
5 Press ENTER to save the setting.
6 To exit from the GUI, press MENU.
• Avoid displaying computer patterns which repeat every
other line (horizontal stripes). (Flickering may occur, making
the image hard to see.)
• When inputting DTV 480P signals, select “480P” in step
4
above.
Projector
(GUI) On-screen Display
Remote Control
MOUSE
ADJ.
(Slide the MOUSE/ADJUSTMENT switch
on the remote control to the ADJ. position.)
1 Press MENU.
2 Press ß/© to select “Fine Sync”.
3 Press ∂/ƒ to select “Signal Info” to display the
current input signal.
4 To exit from the GUI, press MENU.
This function allows you to check the current input signal
information.
Projector
MOUSE
ADJ.
Remote Control
1.2.3 4.5.6
1, 6
5
2, 3, 4
1.2.3 4.5.6
1, 4
2, 3
(GUI) On-screen Display
Checking the Input Signal
E-49
Basic Operation
Adjusting the Computer Images (RGB menu only)
Auto Sync Adjustment
• Used to automatically adjust a computer image.
• Auto Sync adjustment can be made manually by
pressing AUTO SYNC, or automatically by setting
“Auto Sync” to “ON” in the projector’s GUI menu.
When “Auto Sync” is set to “ON”:
• The sync adjustment is automatically made each time
the projector is turned on while connected to a com-
puter or the input selection is changed.
• The Auto Sync adjustment setting previously made is
cleared when the projector’s setting is changed.
(Slide the MOUSE/ADJUSTMENT switch
on the remote control to the ADJ. position.)
1 Press MENU.
2 Press ß/© to select “Fine Sync”.
3 Press ∂/ƒ to select “Auto Sync”.
4 Press ß/© to select “ON”.
5 To exit from the GUI, press MENU.
• Automatic adjustments can be made by pressing AUTO
SYNC.
• When the optimum image cannot be achieved with Auto
Sync adjustment, use manual adjustments. (See page 46.)
During Auto Sync adjustment, the On-screen Display
changes as shown on the left.
• Auto Sync adjustment may take some time to complete,
depending on the image of the computer connected to the
projector.
(GUI) On-screen Display
Projector
g
s
f
On-screen Display
Auto Sync Display Function
Normally, an image is not superimposed during Auto
Sync adjustment. You can, however, choose to
superimpose a background image during Auto Sync
adjustment.
(Slide the MOUSE/ADJUSTMENT switch
on the remote control to the ADJ. position.)
1 Press MENU.
2 Press ß/© to select “Fine Sync”.
3 Press ∂/ƒ to select “Auto Sync Disp”.
4 Press ß/© to select “ ” to superimpose a
background image or “ ” to remove the
background image during Auto Sync adjustment.
5 To exit from the GUI, press MENU.
MOUSE
ADJ.
(GUI) On-screen Display
Remote Control
1.2.3 4.5.6
2, 3, 4
1, 5
AUTO SYNC
button
MOUSE
ADJ.
E-50
Basic Operation
Adjusting the Sound
This projector’s audio is factory preset to standard
settings. However, you can adjust it to suit your own
preferences by adjusting the following audio settings.
(Slide the MOUSE/ADJUSTMENT switch
on the remote control to the ADJ. position.)
1 Press MENU.
2 Press ß/© to select “Audio”.
3 Press ∂/ƒ to select a specific adjustment item.
4 Press ß/© to move the mark of the selected
adjustment item to the desired setting.
5 To exit from the GUI, press MENU.
• To reset all adjustment items, select “Reset” on the “Audio”
menu screen and press ENTER.
Description of Adjustment Items
Projector
© buttonß buttonSelected item
Increased audio from the left
speaker
Increased audio from the right
speaker
For weaker treble
For weaker bass
Treble
Bass
Reset
For stronger treble
For stronger bass
All audio adjustment items are returned to the factory preset
settings.
Balance
MOUSE
ADJ.
Remote Control
1.2.3 4.5.6
1, 5
2, 3, 4
2
3
(GUI) On-screen Display
E-51
Basic Operation
Displaying Dual Pictures (RGB menu only)
Projector Remote Control Picture in Picture function allows you to display two
pictures on the same screen. You can display the image
input from INPUT 4 or 5 as an inset picture overlapping
the main picture input from INPUT 1, 2 or 3.
(Slide the MOUSE/ADJUSTMENT switch
on the remote control to the ADJ. position.)
1 Press MENU.
2 Press ß/© to select “Options (1)”.
3 Press ∂/ƒ to select “Pict in Pict”.
4 Press ß/© to select “
” to display an inset picture
(Factory preset to INPUT 4).
• The image from INPUT 1, 2 or 3 is displayed as the main
picture and the image from INPUT 4 or 5 is displayed as
the inset picture.
5 Press ß/©/∂/ƒ to move the inset picture to one
of four preset positions.
6 To exit from the GUI, press MENU.
• Inset picture can only be displayed in composite signal of
NTSC/PAL/SECAM.
• When selecting the image for the inset picture, only the
images being input will be displayed.
• The audio of the insert picture will come out of the projector’s
speakers.
• Picture in Picture does not work with UXGA signal image.
• Picture in Picture does not work when RGB signal is
interlaced.
• You can only use the following functions while in Picture in
Picture mode.
FREEZE: Works for the inset picture only.
TOOLS: Works with Picture in Picture, but the cursor is
used for TOOLS. The inset picture cannot be
moved.
1.2.3 4.5.6
1, 6
2, 3
4, 5
2
(GUI) On-screen Display
4
MOUSE
ADJ.
0
1996 1997 1998 1999
50
100 C
150 B
200 A
250
300
E-52
Basic Operation
Reducing Image Noise (VIDEO menu only)
Projector Remote Control
3D Digital Noise Reduction (3D DNR) provides high
quality images with minimal dot crawl and cross color
noise.
(Slide the MOUSE/ADJUSTMENT switch
on the remote control to the ADJ. position.)
1 Press MENU.
2 Press ß/© to select “Options (1)”.
3 Press ∂/ƒ to select “3D DNR”, and then select
“ ”.
4 To exit from the GUI, press MENU.
• If the image is clear, select “ ” to prevent any blurring.
1.2.3 4.5.6
1, 4
2, 3
(GUI) On-screen Display
MOUSE
ADJ.
E-53
Basic Operation
Turning On/Off the On-screen Display
This function allows you to turn on or off the on-screen
messages that appear during input select.
(Slide the MOUSE/ADJUSTMENT switch
on the remote control to the ADJ. position.)
1 Press MENU.
2 Press ß/© to select “Options (1)”.
3 Press ∂/ƒ to select “OSD Display”, and then
press ©.
4 Press ∂/ƒ to select the desired On-screen
Display.
5 Press ENTER to save the setting.
6 To exit from the GUI, press MENU.
Projector Remote Control
1.2.3 4.5.6
1, 6
5
2, 3, 4
(GUI) On-screen Display
Setting the Video Signal (VIDEO menu only)
1.2.3 4.5.6
1, 6
5
2, 3, 4
Projector
The video input system mode is preset to “Auto”;
however, it can be changed to a specific system mode
if the selected system mode is not compatible with the
connected audiovisual equipment.
(Slide the MOUSE/ADJUSTMENT switch
on the remote control to the ADJ. position.)
1 Press MENU.
2 Press ß/© to select “Options (1)”.
3 Press ∂/ƒ to select “Video System”, and then
press ©.
4 Press ∂/ƒ to select the desired video system
mode.
5 Press ENTER to save the setting.
6 To exit from the GUI, press MENU.
• When the system mode is set to “Auto”, you may not receive
a clear picture due to signal differences. Should this occur,
switch to the video system of the source signal.
• AUTO cannot be set for PAL-M and PAL-N input signals.
Select “PAL-M” or “PAL-N” in “Video System” menu for PAL-
M and PAL-N input signals.
(GUI) On-screen Display
MOUSE
ADJ.
Remote Control
MOUSE
ADJ.
DescriptionSelected item
Normal
Level A
Level B
Description of OSD Display
All On-screen Display are displayed.
INPUT, CUSTOM, FREEZE, ENLARGE, AUTO SYNC,
VOLUME, MUTE, BLACK SCREEN are not displayed.
All On-screen Display are not displayed (except warning
display (MENU, TOOLS, LENS, Power off, Temp., Lamp
etc.)).
E-54
Basic Operation
Selecting a Background Image
Selecting a Startup Image
(GUI) On-screen Display
This function allows you to select the image displayed
when no signal is being sent to the projector.
Description of Background Images
(Slide the MOUSE/ADJUSTMENT switch
on the remote control to the ADJ. position.)
1 Press MENU.
2 Press ß/© to select “Options (1)”.
3 Press ∂/ƒ to select “Background”, and then press
©.
4 Press ∂/ƒ to select the background image you want
to display on the screen.
5 Press ENTER to save the setting.
6 To exit from the GUI, press MENU.
• By selecting “Custom”, the projector can display a custom image
(i.e. your company logo) as the background image. The custom
image must be a 256-color BMP file with a picture size no larger
than 1,280 ⳯ 1,024 pixels. Please see the Sharp Advanced
Presentation Software operation manual for how to save (or change)
a custom image.
Projector
MOUSE
ADJ.
Remote Control
• This function allows you to specify the image to be
displayed upon the projector’s startup.
• A custom image (i.e. your company logo) can be
uploaded to the projector via an RS-232C cable. See
page 16 in this operation manual, and also the
supplied Sharp Advanced Presentation Software
operation manual for detailed instructions.
Description of Startup Images
(Slide the MOUSE/ADJUSTMENT switch
on the remote control to the ADJ. position.)
1 Press MENU.
2 Press ß/© to select “Options (1)”.
3 Press ∂/ƒ to select “Startup Image”, and then press
©.
4 Press ∂/ƒ to select the startup image you want to
display on the screen.
5 Press ENTER to save the setting.
6 To exit from the GUI, press MENU.
• By selecting “Custom”, the projector can display a custom image
(i.e. your company logo) as the startup image. The custom image
must be a 256-color BMP file with a picture size no larger than
1,280 ⳯ 1,024 pixels. Please see the Sharp Advanced Presentation
Software operation manual for how to save (or change) a custom
image.
Projector
(GUI) On-screen Display
MOUSE
ADJ.
Remote Control
1.2.3 4.5.6
1, 6
5
2, 3, 4
1.2.3 4.5.6
1, 6
5
2, 3, 4
Selected item
Sharp
Custom
Blue
None
Description
SHARP default image
User customized image (i.e. company logo)
Blue screen
Black screen
Selected item
Sharp
Custom
None
Description
SHARP default image
User customized image (i.e. company logo)
Black screen
E-55
Basic Operation
Selecting the Economy Mode
(GUI) On-screen Display
Projector
Remote Control
These functions allow you to reduce the power
consumption when the projector is in standby mode.
Monitor Out/RS-232C Off Function
This projector consumes power when using a monitor
connected to the OUTPUT port for INPUT 1, 2 and a
computer connected to the RS-232C port. When not
using these ports, “MNTR Out/RS232C” can be set to
“ ” to reduce standby power consumption.
Description of Monitor Out/RS-232C Off
(Slide the MOUSE/ADJUSTMENT switch
on the remote control to the ADJ. position.)
1 Press MENU.
2 Press ß/© to select “Options (1)”.
3 Press ∂/ƒ to select “MNTR Out/RS232C”.
4 Press ß/© to select “
” or “ ”.
5 To exit from the GUI, press MENU.
CAUTION
• Set “MNTR Out/RS232C” to “ ” when using the Sharp
Advanced Presentation Software (supplied).
1.2.3 4.5.6
1, 5
2, 3, 4
On-screen Display
(GUI) On-screen Display
Automatic Power Shutoff Function
When no input signal is detected for more than 15
minutes, the projector will automatically shut off. The
on-screen message on the left will appear five minutes
before the power is automatically turned off.
Description of Automatic Power Shutoff
(Slide the MOUSE/ADJUSTMENT switch
on the remote control to the ADJ. position.)
1 Press MENU.
2 Press ß/© to select “Options (1)”.
3 Press ∂/ƒ to select “Auto Power Off”.
4 Press ß/© to select “ ” or “ ”.
5 To exit from the GUI, press MENU.
•“MNTR Out/RS232C” is factory preset to “ ”, and “Auto
Power Off” is factory preset to “
”.
Power automatically shuts off after 15 minutes of no
signal input.
Automatic Power Shutoff disabled.
MOUSE
ADJ.
Standby power for Monitor Out/RS-232C connection
turned off.
Monitor Out/RS-232C on
MOUSE
ADJ.
E-56
Basic Operation
Selecting the Economy Mode
ID No. Display Off Function
The LED ID number display on the rear of the projector,
used when controlling multiple projectors, can be turned
on or off.
Description of ID No. Display
(Slide the MOUSE/ADJUSTMENT switch
on the remote control to the ADJ. position.)
1 Press MENU.
2 Press ß/© to select “Options (1)”.
3 Press ∂/ƒ to select “ID No. Display”, and then
press ©.
4 Press ∂/ƒ to select “Display Off”, “Standby
Off” or “Display On”.
5 Press ENTER to save the setting.
6 To exit from the GUI, press MENU.
Projector Remote Control
1.2.3 4.5.6
1, 6
5
2, 3, 4
(GUI) On-screen Display
Reversing/Inverting Projected Images
This projector is equipped with a reverse/invert image
function which allows you to reverse or invert the pro-
jected image for various applications.
Description of Projected Images
Selected item
Front
CeilingⳭFront
Rear
CeilingⳭRear
Description
Normal image
Inverted image
Reversed image
Reversed and inverted image
(Slide the MOUSE/ADJUSTMENT switch
on the remote control to the ADJ. position.)
1 Press MENU.
2 Press ß/© to select “Options (2)”.
3 Press ∂/ƒ to select “PRJ Mode”, and then press
©.
4 Press ∂/ƒ to select the desired projection mode.
5 Press ENTER to save the setting.
6 To exit from the GUI, press MENU.
Projector
MOUSE
ADJ.
Remote Control
1.2.3 4.5.6
1, 6
5
2, 3, 4
(GUI) On-screen Display
Display Off Not displayed
Selected item Description
Displayed except when the projector is
in standby mode.
Always displayed
Standby Off
Display On
MOUSE
ADJ.
• This function is used for the reversed image and ceiling-
mount setups. See page 30 for these setups.
E-57
Basic Operation
Selecting the On-screen Display Language
Projector
(GUI) On-screen Display
English is the preset language for the On-screen
Display; however, this can be changed to German,
Spanish, Dutch, French, Italian, Swedish, Portuguese,
Chinese, Korean or Japanese.
(Slide the MOUSE/ADJUSTMENT switch
on the remote control to the ADJ. position.)
1 Press MENU.
2 Press ß/© to select “Language”.
3 Press ∂/ƒ to select the desired language.
4 Press ENTER to save the setting. The On-screen
Display is now programed to display in the
language selected.
5 To exit from the GUI, press MENU.
MOUSE
ADJ.
Remote Control
1.2.3 4.5.6
1, 5
2, 3
4
E-58
Basic Operation
Displaying the Adjustment Settings
This function can be used to display all the adjusted
settings on the screen simultaneously.
(Slide the MOUSE/ADJUSTMENT switch
on the remote control to the ADJ. position.)
1 Press MENU.
2 Press ß/© to select “Status”.
3 Press ENTER to display all the adjustment
settings.
4 To exit from the GUI, press MENU.
Projector
MOUSE
ADJ.
2
3
Remote Control
1.2.3 4.5.6
1, 4
2
3
INPUT 1, 2 (RGB) or 3 (DIGITAL) mode
2
3
INPUT 4, 5 (VIDEO) mode
(GUI) On-screen Display
E-59
Useful Features &
Network Function
Locking the Operation Buttons on the Projector
Useful Features
This function can be used to lock the use of certain
operation buttons on the projector. The user can still
operate the projector fully with the remote control.
Description of Keylock Levels
1.2.3 4.5.6
1, 6
5
2, 3, 4
Projector
(GUI) On-screen Display
Remote Control
1.2.3 4.5.6
1, 6
5
2, 3, 4
This function allows you to deselect unwanted signal
input.
(Slide the MOUSE/ADJUSTMENT switch
on the remote control to the ADJ. position.)
1 Press MENU.
2 Press ß/© to select “Options (2)”.
3 Press ∂/ƒ to select “Set Inputs”, and then
press ©.
4 Press ∂/ƒ to select the input you want to set to
block.
5 Press ENTER to select “ON” or “OFF”.
6 To exit from the GUI, press MENU.
• Input 6 can be selected only when an SDI board is installed.
Otherwise it is displayed in gray.
• When stack projecting, multi-screen projecting and so on, this
function can be used to cancel the RS-232C control.
• Up to two input signals can be blocked for both Input 1, 2, 3 or
Input 4, 5, 6.
• For details on intended purpose, see pages 67 and 68.
Deselecting Inputs
(Slide the MOUSE/ADJUSTMENT switch
on the remote control to the ADJ. position.)
1 Press MENU.
2 Press ß/© to select “Options (2)”.
3 Press ∂/ƒ to select “Keylock Level”, and then
press ©.
4 Press ∂/ƒ to select the desired level.
5 Press ENTER to save the setting.
6 To exit from the GUI, press MENU.
• To cancel the Keylock Level, perform the above procedure using
the remote control.
• See page 61 for details using the password function.
MOUSE
ADJ.
Projector Remote Control
(GUI) On-screen Display
Selected item
Normal
Level A
Level B
Description
All operation buttons are functional.
Only INPUT, VOLUME, MUTE, BLACK
SCREEN on the projector are available.
All operation buttons on the projector are
unavailable.
MOUSE
ADJ.
E-60
Useful Features &
Network Function
Selecting the Transmission Speed (RS-232C)
1.2.3 4.5.6
1, 6
5
2, 3, 4
Projector Remote Control This menu allows you to adjust the transmission speed
of the RS-232C connection by selecting the baud rate.
(Slide the MOUSE/ADJUSTMENT switch
on the remote control to the ADJ. position.)
1 Press MENU.
2 Press ß/© to select “Options (2)”.
3 Press ∂/ƒ to select “RS-232C”, and then press
©.
4 Press ∂/ƒ to select the desired baud rate.
5 Press ENTER to save the setting.
6 To exit from the GUI, press MENU.
• Make sure that both the projector and computer are set
for the same baud rate. Refer to the computer’s operation
manual for instructions for setting the baud rate.
(GUI) On-screen Display
MOUSE
ADJ.
E-61
Useful Features &
Network Function
A password can be set by the user and used with the
keylock level to prevent adjustments to certain settings
on the GUI.
• When password is set, you need to enter the password to
use “Lamp Mode”, “PRJ Mode”, “Stack Setting”, “Keylock
Level”, “Set Inputs”, “RS-232C” and “Set ID No.” menus.
Setting the Password
(Slide the MOUSE/ADJUSTMENT switch
on the remote control to the ADJ. position.)
1 Press MENU.
2 Press ß/© to select “Options (2)”.
3 Press ∂/ƒ to select “Password”, and then press
©.
4 Enter the new password using ∂/ƒ to select the
desired number, and then press © to select the
next digit. Continue this procedure for the
remaining three digits, and then press ENTER.
5 Enter the password again (“Reconfirm”) using
∂/ƒ/ß/©, and then press ENTER.
6 To exit from the GUI, press MENU.
• After setting the password, be sure to write it down in a
secure location in case you can not remember it.
Changing the Password
(Slide the MOUSE/ADJUSTMENT switch
on the remote control to the ADJ. position.)
1 Follow steps 1 to 3 in “Setting the Password”
above.
2 Enter the old password using ∂/ƒ/ß/©, and then
press ENTER.
3 Enter the new password using ∂/ƒ/ß/©, and
then press ENTER.
4 Enter the password again (“Reconfirm”) using
∂/ƒ/ß/©, and then press ENTER.
Protecting Important Settings with a Password
1.2.3 4.5.6
1, 6
2, 3
4, 5
Projector Remote Control
(GUI) On-screen Display
MOUSE
ADJ.
Setting the Password
Changing the Password
MOUSE
ADJ.
E-62
Useful Features &
Network Function
Setting Up the Optional Boards
Network Function
Three optional Expansion Boards from Sharp are also available for specialized application. Please see your local
Sharp Industrial LCD Products Dealer for details on these boards. Be sure to have service personnel install optional
boards.
Boards for Network Capability
LAN Board
RS-422 Board
Expansion Video Board
SDI (Serial Digital Interface)
RS-422 CONTROL
INPUT
DISABLE
ENABLE
DISABLE
ENABLE
OUTPUT
Soon-to-be-released
The Optional Board function allows you to set and
confirm the optional boards.
(Slide the MOUSE/ADJUSTMENT switch
on the remote control to the ADJ. position.)
1 Press MENU.
2 Press ß/© to select “Options (2)”.
3 Press ∂/ƒ to select “Optional Board”.
4 To exit from the GUI, press MENU.
The type of board and the board status are displayed
as shown below.
• LAN Board (10BASE-T)
Set the IP Address, Gateway and Subnet mask in
accordance with the sub menu.
• SDI Board
The status of the SDI Board is displayed.
• RS-422 Board
The input and output control signals are displayed.
• For details on intended purpose, see the optional boards
operation manuals.
MOUSE
ADJ.
1.2.3 4.5.6
1, 4
2, 3
Projector Remote Control
(GUI) On-screen Display
INPUT 6 SDI
INPUT OUTPUT AUDIO
INPUT
e.g. when installing SDI board
E-63
Useful Features &
Network Function
Controling Multiple Projectors with ID Numbers
1.2.3 4.5.6
1, 6
5
2, 3, 4
Projector
(GUI) On-screen Display
Remote Control This projector can form a network of up to 250
projectors. To identify separately and control specified
projector, you need to set ID No..
The ID No. you set is displayed on the LED.
(Slide the MOUSE/ADJUSTMENT switch
on the remote control to the ADJ. position.)
Setting the ID No.
1 Press MENU.
2 Press ß/© to select “Options (2)”.
3 Press ∂/ƒ to select “Set ID No.”. (The ID No. is
factory preset to “001”.)
4 Press © to select the first digit and ∂/ƒ to select
the desired number. Continue this procedure for
the remaining two digits.
5 Press ENTER to save the setting.
6 To exit from the GUI, press MENU.
• When ID NO. is not be displayed, refer to the setting of “ID No.
Display”. See page 56 for setting “Display Off” function.
• The ID No. can be set from 001 to 250.
• For details on intended purpose, see pages 65 to 68.
Setting the Stacking Mode
1.2.3 4.5.6
1, 6
5
2, 3, 4
Projector
(GUI) On-screen Display
Remote Control You can double the brightness of an image by stacking
two projectors and projecting same picture
simultaneously. To control two projectors, assign one
as the master and one as the slave. The slave projector
will duplicate any operational settings made to the
master projector.
(Slide the MOUSE/ADJUSTMENT switch
on the remote control to the ADJ. position.)
1 Press MENU.
2 Press ß/© to select “Options (2)”.
3 Press ∂/ƒ to select “Stack Setting”, and then
press ©.
4 Press ∂/ƒ to select “Normal”, “Master” or
“Slave”.
5 Press ENTER to save the setting.
6 To exit from the GUI, press MENU.
• If you set slave, only ∂/ƒ/ß/©, ENTER, UNDO, Power ON, Power
OFF, LENS and MENU can be used. Other buttons cannot be
used and are controlled by the master projector or computer
through the RS-232C connection.
• For details on intended purpose, see pages 67 and 68.
MOUSE
ADJ.
MOUSE
ADJ.
E-64
Useful Features &
Network Function
Using the Presentation Tools
MOUSE
ADJ.
Menu Window
When selecting Sharp default image
Red Green Blue Yellow Orange White Black
This projector is equipped with presentation tools that
can be used to emphasize keypoints within your
presentation.
(Slide the MOUSE/ADJUSTMENT switch
on the remote control to the ADJ. position.)
1 Press TOOLS to display the presentation tools
menu window on the screen.
2 Press ∂/ƒ/ß/© to select the desired tool and
color.
3 Press ENTER to select it.
4 Once the tool is displayed on the screen, press
∂/ƒ/ß/© to move it around the screen.
5 Press ENTER to stamp the tool on the screen.
6 Press UNDO to individually delete tools stamped
on the screen.
• You can stamp each tool as many times as you want on the
screen.
• To clear all the stamped presentation tools from the screen,
press ∂/ƒ/ß/© to select “
” and then press ENTER.
1.2.3 4.5.6
1, 5
2, 4
3
Projector Remote Control
On-screen Display
1.2.3 4.5.6
6
2, 4
3, 5
1
6
Displaying the Break Time
(Slide the MOUSE/ADJUSTMENT switch
on the remote control to the ADJ. position.)
1 Press TOOLS to display the presentation tools
menu window on the screen.
2 Press ∂/ƒ/ß/© to select “ ” in the menu
window.
3 Press ENTER to start counting down the break
time.
4 Press ∂ to increase or ƒ to decrease the break
time.
5 To return to normal screen, press TOOLS.
• The break time is displayed against the background image
selected in “Selecting a Startup Image”. (See page 54.)
Projector Remote Control
MOUSE
ADJ.
E-65
Useful Features &
Network Function
Operating the Network Function
This projector has outstanding network capability.
• Internet access for self-diagnosis
• Multiple and group projector control
• Simultaneous multiple projector control
1. Internet access for self-diagnosis, status information and preventive
maintenance
Internet
LAN
LANLAN
E-mail E-mail
This projector can be used in a network of up to 250 projectors managed from a single PC with the accompanied
Sharp Advanced Presentation Software—Professional Edition. This projector can be connected to a PC using an
RS-232C, RS-422, or LAN (10 BASE-T) connection. (An optional board is required for RS-422 or LAN connection.)
Output terminals are provided (RS-232C on the projector, RS-422 on the optional board) enabling a daisy chain
configuration and eliminating the need for a distributer. The projector can also be managed over a network via an
Ethernet connection.
This projector is also equipped with a function to send status information (lamp usage time, etc.) to a Sharp
Service Center or outside contractor for quick and efficient customer service.
• For more information on these features, see the operation manuals accompanying the Sharp Advanced Presentation Software—
Professional Edition and optional boards.
E-66
Useful Features &
Network Function
Operating the Network Function
2. Multiple and group projector control via computer
Building A
RS-232C
RS-232C
RS-422
RS-232C
RS-232C
RS-232C
RS-422
Optional RS-422 board
RS-422
Control PC
Sharp Advanced
Presentation Software
“Professional Edition”
3rd Floor
2nd Floor
1st Floor
Video
Source 1
Video
Source 2
To Building B
This projector can be used in a network of projectors managed from a single PC with the accompanied Sharp
Advanced Presentation Software—Professional Edition. Projectors in conference rooms on the first and third floors
of a building, for example, can be used for video presentations, while projectors on the second floor can be used
for PC-assisted presentations. Projectors can even be powered down at different times (e.g., projectors on the first
and second floors are powered down in one hour, while those on the third floor are powered down in two hours).
An optional RS-422 board enables control of group projectors on different floors or buildings via cables connecting
up to 4,920 feet (1.5 km), and an optional LAN board can provide management of projectors over an existing
network.
• For more information on these features, see the operation manuals accompanying the Sharp Advanced Presentation Software—
Professional Edition and optional RS-422 board.
E-67
Useful Features &
Network Function
Operating the Network Function
3. Simultaneous multiple projector control for stacking and videowall projection
INPUT1
INPUT2
INPUT4
INPUT5
OUTPUT
Master
OUTPUT
INPUT1
Distributor
INPUT2
INPUT4
INPUT5
OUTPUT
Slave
OUTPUT
DVD
Laser Disc
RS-232C OUTRS-232C IN
RS-232C OUTRS-232C IN
Stack Setting
Master
Set Inputs
INPUT1
INPUT2
INPUT3
INPUT4
INPUT5
INPUT6
Yes
Yes
No
Yes
Yes
No
Stack Setting
Slave
Set Inputs
Yes
No
No
Yes
Yes
No
INPUT1
INPUT2
INPUT3
INPUT4
INPUT5
INPUT6
For brighter images, two projectors can be stacked using the Stack Setting function, with one projector set as the
Master and the other as the Slave. The operations of the Slave projector are controlled by the Master projector
during projection through an RS-232C connection. The RS-232C cable (null modem, cross type, sold separately)
is connected from the RS-232C output on the Master projector to the RS-232C input on the Slave projector.
Projectors can be stacked using an RS-232C cable (null modem, cross type, sold separately).
• See page 59, “Deselecting Inputs”, and page 63, “Setting the Stacking Mode”.
Stack Projection
E-68
Useful Features &
Network Function
Operating the Network Function
INPUT1
INPUT2
INPUT4
INPUT5
OUTPUT
Master
OUTPUT
RS-232C OUT
INPUT1
Control PC
Sharp Advanced
Presentation Software
“Professional Edition”
VIDEO
SOURCE2
VIDEO
SOURCE1
RGB
SOURCE2
RGB
SOURCE1
INPUT2
INPUT4
INPUT5
OUTPUT
Slave
OUTPUT
RS-232C IN
RS-232C OUTRS-232C IN
DVD
DVD
001
002
INPUT1
INPUT2
INPUT4
INPUT5
OUTPUT
Slave
OUTPUT
INPUT1
INPUT2
INPUT4
INPUT5
OUTPUT
Slave
OUTPUT
003
004
RS-232C OUTRS-232C IN
RS-232C OUTRS-232C IN
Master
Set Inputs
Yes
Yes
No
Yes
Yes
No
INPUT1
INPUT2
INPUT3
INPUT4
INPUT5
INPUT6
Slave
Set Inputs
Yes
No
No
Yes
No
No
INPUT1
INPUT2
INPUT3
INPUT4
INPUT5
INPUT6
Videowall
This projector can be used together with other projectors managed using the accompanied Sharp Advanced
Presentation Software—Professional Edition to create a videowall projection. Whereas conventional videowall
technology required the use of an image distributor, this projector videowall feature enables easy image settings
from a PC when inputting a single video source. This function greatly simplifies videowall setup.
RS-232C OUTPUTS also realize the simple daisy chain connection. The master projector directly connected to the
computer can make the daisy chain connection with multiple slave projectors. For details on setting master or
slave, see page 63.
• Use a videowall projector stand, sold separately, when using this function.
• Image quality may deteriorate when picture signals are input through multiple projectors in a daisy chain
connection.
• For more information on this feature, see the operation manuals accompanying the Sharp Advanced Presentation Software—
Professional Edition.
• When UXGA signal is displayed, the videowall can not be set by Sharp Advanced Presentation Software—Professional
Edition.
E-69
Maintenance &
Troubleshooting
TEMP LAMP2 LAMP1 POWER
2 1
Lamp/Maintenance Indicators
Problem
• Blocked air intake.
• Clogged air filter.
• Cooling fan breakdown.
• Internal circuit failure.
• Burnt-out lamp.
• Lamp circuit failure.
• Lamp has been used for
over 900 hours.
• The filter cover is open.
Maintenance Indicator
The internal
temperature is
abnormally high.
TEMPERATURE
WARNING indicator
LAMP REPLACE-
MENT indicator
POWER indicator
The lamp does not
light up.
The lamp requires
replacement.
The POWER
indicator flashes in
red when the
projector is on.
Condition Possible Solution
• Relocate the projector to an area with
proper ventilation.
• Replace the filter.
(See page 73.)
• Take the projector to your nearest
Authorized Sharp Industrial LCD Products
Dealer or Service Center for repair.
• Carefully replace the lamp. (See pages 71
and 72.)
• Take the projector to your nearest
Authorized Sharp Industrial LCD Products
Dealer or Service Center for repair.
• Securely install the filter cover.
Maintenance Indicators
• The warning lights on the projector indicate problems
inside the projector.
• There are three warning lights: a TEMPERATURE
WARNING indicator that warns you when the projector
is too hot, and two LAMP REPLACEMENT indicators
that warn you when to change a lamp.
• If a problem occurs, either the TEMPERATURE
WARNING indicator or the LAMP REPLACEMENT
indicators will light up red. After turning off the power,
follow the procedures given below.
• If the TEMPERATURE WARNING indicator lights up, follow the above possible solutions and then wait until the projector has
cooled down completely before turning the power back on. (At least 5 minutes.)
• If the power is turned off and then turned on again, as during a brief rest, the LAMP REPLACEMENT indicators may be
triggered, preventing the power from going on. Should this occur, take the power cord out of the wall outlet and put it back
in again.
LAMP 2
REPLACEMENT
indicator
TEMPERATURE
WARNING
indicator
LAMP 1
REPLACEMENT
indicator
POWER
indicator
E-70
Maintenance &
Troubleshooting
Confirming the Lamp Usage Time
Lamp Maintenance
Lamp
The lamp in this projector operates for approximately 1,000 cumulative hours, depending on the usage environ-
ment. (As the usage environment can vary significantly, the projector lamp may not operate for 1,000 hours.) It is
recommended that the lamp be replaced after approximately 900 cumulative hours of use or when you notice a
significant deterioration of the picture and color quality. The lamp usage time can be checked with the On-screen
Display.
CAUTION
• Intense light hazard. Do not attempt to look into the aperture and lens while the projector is operating.
This function allows you to check the accumulated lamp
usage time.
(Slide the MOUSE/ADJUSTMENT switch
on the remote control to the ADJ. position.)
1 Press MENU.
2 Press ß/© to select “Options (2)”.
3 Press ∂/ƒ to select “Lamp Timer”. The lamp
usage time will be displayed.
4 To exit from the GUI, press MENU.
• It is recommended that the lamp be replaced after
approximately 900 cumulative hours of use. See pages 71
and 72 for lamp replacement.
1.2.3 4.5.6
1, 4
2, 3
Projector
MOUSE
ADJ.
Remote Control
(GUI) On-screen Display
Problem
• Lamp has been used for over 900
hours.
• Lamp has been used for over 1,000
hours.
Possible Solution
• Purchase a replacement lamp unit
(lamp/cage module) of the current
type BQC-XGV10WU/1 from your
nearest Authorized Sharp Industrial
LCD Products Dealer or Service
Center.
• Replace the lamp. (See pages 71
and 72.) If you wish, you may have
the lamp replaced at your nearest
Authorized Sharp Industrial LCD
Products Dealer or Service Center.
Condition
The LAMP REPLACEMENT
indicator lights up red, and “LAMP”
and “
” will flash in yellow in the
lower-left corner of the picture.
A significant deterioration of the
picture and color quality occurs.
The power will automatically turn
off and the projector will enter
standby mode.
“LAMP” and “
” will flash in red in
the lower-left corner of the picture,
and the power will turn off.
E-71
Maintenance &
Troubleshooting
This function can be used to set the lamp mode.
The mode can be set to double the effective lamp usage
time.
Description of Lamp Mode
(Slide the MOUSE/ADJUSTMENT switch
on the remote control to the ADJ. position.)
1 Press MENU.
2 Press ß/© to select “Options (2)”.
3 Press ∂/ƒ to select “Lamp Mode”, and then
press ©.
4 Press ∂/ƒ to select the desired Lamp Mode.
5 Press ENTER to save the setting.
6 To exit from the GUI, press MENU.
• In “Equal Use” mode, when the projector is used for more than
24 hrs. continuously, it switches in shift of 100 hrs.
Setting the Lamp Mode
1.2.3 4.5.6
1, 6
5
2, 3, 4
Remote ControlProjector
(GUI) On-screen Display
Selected item
Both Lamps
Lamp 1 Only
Lamp 2 Only
Equal Use
Description
Both lamps are used for greater brightness.
Lamp 1 is used.
When lamp 1 burns out, automatically
switches to lamp 2.
Lamp 2 is used.
When lamp 2 burns out, automatically
switches to lamp 1.
Both lamps are used alternatingly.
Switches after every 100 hrs. of use.
Replacing the Lamp
It is recommended that the lamp be replaced after approximately 900 cumulative hours of use or when you notice
a significant deterioration of the picture and color quality. Carefully change the lamp by following the steps on the
next page.
If the new lamp does not light after replacement, take your projector to the nearest Authorized Sharp Industrial
LCD Products Dealer or Service Center for repair. Purchase a replacement lamp unit (lamp/cage module) of the
current type BQC-XGV10WU/1 from your nearest Authorized Sharp Industrial LCD Products Dealer or Service
Center. Then carefully change the lamp by following the instructions on the next page. If you wish, you may have
the lamp replaced at your nearest Authorized Sharp Industrial LCD Products Dealer or Service Center.
IMPORTANT NOTE TO U.S. CUSTOMERS:
The lamp included with this projector is backed by a 90-day parts and labor limited warranty. All service of this
projector under warranty, including lamp replacement, must be obtained through an Authorized Sharp Industrial LCD
Products Dealer or Service Center. For the name of the nearest Authorized Sharp Industrial LCD Products Dealer or
Service Center, please call toll-free: 1-888-GO-SHARP (1-888-467-4277).
U.S.A. ONLY
CAUTION
• Potential hazard of glass particles if lamp ruptures. In case of lamp rupture, contact your nearest
Authorized Sharp Industrial LCD Products Dealer or Service Center for a replacement.
• Do not remove the lamp cage directly after operation of the projector. The lamp may be extremely
hot. Wait at least one hour after the power cord is disconnected to allow the surface of the lamp cage
to fully cool before removing the lamp cage.
MOUSE
ADJ.
E-72
Maintenance &
Troubleshooting
Replacing the Lamp
• Be sure to remove the lamp cage by the handle. Be sure not to touch the glass surface of the lamp cage
or the inside of the projector.
• To avoid injury to yourself and damage to the lamp, be sure to carefully follow the steps below.
• Replace the lamp more safely by unplugging the power cord after turning off the main power.
Removing and installing the lamp unit
CAUTION
46
Remove the lamp
cage.
5
Attach the lamp cage cover
and turn on the main power.
1 3
Turn off the power.
2
Turn off the main
power.
Turn off the MAIN POWER
switch. (Unplug the power cord)
Remove the lamp cage
cover.
Press POWER ON on projector. LAMP
REPLACEMENT indicator flashes red.
Then press ENTER to reset lamp timer.
Press POWER ON, and then
press ENTER on the projector.
Remove the securing screws
from the lamp cage. Hold the
lamp cage by the handle and
pull it horizontally towards you.
Loosen the user service screw
that secures the lamp cage
cover on the back of the
projector. Then slide the cover in
the direction of the arrow (to the
open mark).
Press POWER OFF. Wait until
the cooling fan stops.
Slide the lamp cage cover in the
direction of the arrow (to the
close mark) on the back of the
projector. Then turn on the MAIN
POWER switch.
7
Turn off the main power again and
remove the lamp cage cover.
Insert the new lamp
cage.
Press the lamp cage firmly into
the lamp cage compartment.
Fasten the securing screws.
Turn off the main power switch
and slide the lamp cage cover
in the direction of the arrow (to
the open mark) on the back of
the projector.
Slide the lamp cage cover in the
direction of the arrow (to the
close mark) on the back of the
projector. Then tighten the user
service screw.
8
or
Securing screws
Securing screw
Lamp 1
High angle view
Lamp 2
Attach the lamp cage
cover.
9
• You need to reset lamp timer every time when replacing the lamp and confirm it to be reset on “Lamp Timer” menu.
ENTER
ON
E-73
Maintenance &
Troubleshooting
• This projector is equipped with one air filter to ensure the optimal operating condition of the projector.
• The air filter should be exchanged after every 2,000 hours of use.
• Have your nearest Authorized Sharp Industrial LCD Products Dealer or Service Center exchange the filter
(PFILD0110CEZZ).
Front View
Replacing the Air Filter
46
Remove the air filter.
5
Replace the air filter.
1 3
Turn off the power.
2
Turn off the main power
and unplug the power cord.
Grasp the tab and lift open the
filter cover in the direction of the
arrow.
Remove the front filter
cover.
Reset the filter
cover.
Insert the tab on the end of the
filter cover into the filter cover
opening and press the filter
cover into position.
Press the air filter firmly into the
filter compartment.
Grasp the air filter tabs between
your fingers and pull it out of
the filter compartment.
• When resetting the filter cover, be sure the filter is securely installed. The power will not turn on unless it is correctly
installed.
Replacing the front air filter
or
Air filter
E-74
Maintenance &
Troubleshooting
Troubleshooting
Check
• Keylock level is set to “Level A” or “Level B”, preventing operation of some or all
buttons. (See page 59.)
• When the projector is set to slave, use the buttons on the master projector or change the
setting by RS-232C commands from the computer. (See page 63.)
• When using slave setting in combination with Keylock Level B or C, all the buttons on
the projector and the remote control are disabled. Use the SAPS or RS-232C commands
to release slave and Keylock setting and enable buttons to operate.
Without a computer, you can release slave and Keylock setting by entering the buttons
on the projector as follows.
ON
→
ENTER
→
ON
→
ENTER
→
ON
→
ENTER
→
MENU
However, this operation also releases the password set.
• Projector power cord is not plugged into the wall outlet.
• The front filter cover is not securely installed.
• Selected input is wrong. (See page 31.)
• Cables incorrectly connected to side panel of the projector. (See pages 14–18.)
• Remote control batteries have run down. (See page 12.)
• Remote control’s MOUSE/ADJUSTMENT switch is set to MOUSE.
• Cables incorrectly connected to side panel of the projector. (See pages 14–18.)
•“Contrast” and “Bright” adjustments are set to minimum position. (See page 43.)
• On-screen Display (“BLACK SCREEN”) is turned off and Black Screen function is turned
on, creating a black image. (See page 32.)
•“Color” and “Tint” adjustments are not correct. (See page 43.)
• Adjust the focus. (See page 29.)
• Projection distance is too long or too short to allow for proper focus. (See pages 21–28.)
• Cables incorrectly connected to side panel of the projector. (See pages 14–18.)
• Volume is set to minimum. (See page 31.)
• OSD Display is set to “Level A” or “Level B”, preventing to display some or all On-screen
Displays. (See page 53.)
• If the picture is normal, the sound is due to cabinet shrinkage caused by temperature
changes. This will not affect operation or performance.
• Refer to “Lamp/Maintenance Indicators” on page 69.
• Adjust the “Phase” setting. (See page 46.)
• Noise may appear when used with certain computers. Set the NOISE FILTER to ON
using the RS-232C command. (See pages 80–82.)
• Set the resolution mode to 480P. (See page 48.)
• Change the input signal type. (See page 45.)
• Align the mark on the lens with the corresponding mark on the projector, push the lens
firmly in place, and rotate to the right.
For SHARP Assistance (U.S.A. only)
If you encounter any problems during setup or operation of this projector, first refer to the “Troubleshooting”
section on this page. If this operation manual does not answer your question, please call toll free 1-888-GO-
SHARP (1-888-467-4277) for further assistance. Or, send us an e-mail at lcdsuppor[email protected] .
Our World Wide Web address is http://www.sharplcd.com .
Problem
Power cannot be turned on or
off using the POWER buttons
(ON/OFF) on the projector.
Cannot be operated by
remote control.
Cannot be operated by all
buttons of the projector and
remote control.
No picture and no sound.
Sound is heard but no picture
appears.
Color is faded or poor.
Picture is blurred.
Picture appears but no sound
is heard.
No OSD appears.
An unusual sound is occasion-
ally heard from the cabinet.
Maintenance indicator lights
up.
Picture noise appears.
480P images do not appear.
Image is green on INPUT 1, 2,
4 or 5 COMPONENT.
Image is pink (no green) on
INPUT 1, 2 RGB.
Lens comes off.
E-75
Appendix
Guide to Effective Presentations
Electronic presentations are one of the most effective
tools presenters can use to persuade an audience.
There are several ways to enhance your presentation
and maximize your effectiveness. The following are
guidelines to help you create and deliver a dynamic
presentation.
a. Types of Presentations
Computer Presentations
• To present basic information such as graphs, spreadsheets,
documents and images, use word processing and spreadsheet
applications.
• To convey more complex information and create more dynamic
presentations which allow you to control the pace of your delivery,
utilize software such as Astound
®
, Freelance
®
, Persuasion
®
or
PowerPoint
®
.
• For high-end multimedia and interactive presentations, use software
such as Macromedia Director
®
.
• Astound
®
, Freelance
®
, Persuasion
®
, PowerPoint
®
and Macromedia
Director
®
are trademarks of their respective companies.
Video Presentations
Use of video equipment, such as a VCR, DVD player and laser disc
player, can be effective for delivering instructional or illustrative
information that is difficult to present.
Digital Cameras and Personal Digital Assistants
(PDAs)
For highly compact and portable presentations, digital still cameras,
digital video cameras, document cameras and PDAs are ideal for
transferring data without cumbersome conversions.
Multimedia Presentations
You can integrate all of the above methods for a full multimedia
presentation including video, audio, computer applications and World
Wide Web information.
b. Creative Presentations
Oftentimes presenters do not take advantage of the many
subtle ways they can manipulate their electronic slides to more
effectively persuade the audience.
Color has a great effect on the audience during a presentation.
When used correctly and legibly, studies show that
background and foreground colors establish an emotional
tone for a presentation, help viewers understand and retain
information, and influence an audience to take a desired
course of action.
Color Considerations
• Choose legible colors.
• Text and graphics colors need sufficient contrast.
• Use darker colors for the background since a lighter background
can create uncomfortable glare. (Yellow on black creates an ideal
contrast.)
Yellow
on Black
0
5
10
15
20
25
30
E-76
Appendix
Red
Blue
Green
Black
Presentation from SHARP
O
n
e
o
f
t
h
e
m
o
s
t c
o
m
m
o
n
m
is
ta
k
e
s
in
a
n
y
ty
p
e
o
f
p
r
e
s
e
n
t
a
tio
n
v
is
u
a
l is
th
e
s
e
le
c
t
io
n
o
f ty
p
e
f
o
n
ts
th
a
t a
r
e
t
o
o
s
m
a
ll, to
o
t
h
in
, o
r
h
a
r
d
to
r
e
a
d
.
• Background colors can subconsciously affect the audience:
Red—increases viewers’ pulse and breathing and
encourages risk taking but can also be associated with
financial loss.
Blue—has a calming and conservative affect on the
audience but can also create boredom among corporate
audiences that are often inundated with this background
color.
Green—stimulates interaction.
Black—conveys finality and certainty. Use it as a transitional
color between slides when moving from one idea to another.
• Foreground colors create a major impact on how well an
audience understands and remembers a message.
• Use one or two bright colors for emphasis.
• Highlight important messages.
• The eye has a difficult time reading certain colored text on
certain colored backgrounds. For example, text and
background colors in red and green, and blue and black
make for difficult viewing.
• Colorblind individuals may find it difficult to distinguish
between red and green, brown and green, and purple and
blue. Avoid using these colors together.
Fonts
• One of the most common mistakes in any type of
presentation visual is the selection of type fonts that are too
small, too thin, or too difficult to read.
• If you are not sure how well a given font will read on a screen
at various sizes, try this: Draw a 6 8 box on a piece of
paper and print out several lines of text inside the box with
your computer printer at 300 or 600 dpi resolution. Vary the
sizes of text to simulate headline, body and text call-outs
for any charts or graphs. Hold the printout at arm’s length.
This is how your text will look on a 4 (1.2 meter)-wide screen
at 10 (3 meters), on a 7.5 (2.3 meter)-wide screen at 20
(6.1 meters) and a 12 (3.7 meter)-wide screen at 30 (9.1
meters). If you cannot read the text easily, you should put
less copy on your visuals or use larger typefaces.
• Design your visuals so that they are visible by the viewer in
the last row.
• Nothing will ruin your presentation faster than misspelled
words. Take the time to proofread and edit your work before
your visuals become a permanent part of your presentation.
• Mixed case text is easier to read than text which is displayed
in capital letters.
• Another important attribute of fonts is whether any particular
face is serif or sans-serif. Serifs are small, usually horizontal
cross strokes that are added to the end of a letter’s main
strokes. Because of their ability to coax the eye along the
line of type, fonts with serifs are generally acknowledged to
be more readable.
Sans-serif
Serif
Guide to Effective Presentations
E-77
Appendix
c. Set-Up
When giving a presentation, you need to set the stage both
figuratively and literally for success. The way you set up a
presentation room will have a great impact on the audience’s
perception of you and your message. By manipulating the
placement and use of the following tools, you will improve the
impact of your presentation.
Lighting—Good lighting is an important component of a
successful presentation. You should strive to create an
unequal distribution of light. An audience should always see
as much of the presenter’s face as possible, so most of the
light should be focused on you. Because it is important for
you to be able to read the audience’s faces and body
language, some light should be shed upon them. However,
no light should shine on the screen.
Stage— When presenting on the same level surface that your
audience is on, most people can only see the top one-third of
your body. Therefore, it is recommended that when giving a
presentation to an audience of 25 or more, you stand on a
stage or platform. As more of your body is visible, the easier
it is to communicate with an audience.
Podiums—The best presenters avoid podiums because they
hide 75% of the body and restrict movement. However, many
people feel more comfortable with a podium to hold their notes
and hide their discomfort. If you must use a podium, angle it
at 45 degrees to the audience so that you are not completely
hidden.
Visuals—It is imperative that you make sure your visuals are
large enough and projected far enough for the audience to
see. Eight times the height of an image is the optimal viewing
distance to read 24 point type. The bottom of a screen should
be at least 6 (1.8 meters) above the floor.
Screen—The screen should always be in the center of the
room so that all audience members can see it. Because people
read from left to right, you should always stand to the
audience’s left when discussing visuals.
Seating—Arrange seating according to the dynamics of your
presentation. If the presentation is more than half-a-day, use
classroom style seating—a chair and a desk. If you would
like to encourage audience interaction, use chevron seating,
angling the chairs into a “V” shape. When you have a very
small audience, a “U” shaped arrangement will increase
interchange.
Good Bad Good
Presentation from SHARP
0
5
10
15
20
25
30
Guide to Effective Presentations
E-78
Appendix
d. Rehearsing & Delivery
• The best time to rehearse is the day or evening before,
not a couple of hours before, and the best place to
rehearse is in the actual room. Rehearsing a speech
in a small office is not the same as standing up in
front of 100 people in a hotel ballroom or classroom.
• Due to varying processor speeds of computers,
practice your slide transitions for proper timing.
• Whenever possible, set up your equipment well in
advance to allow adequate time to resolve any
unexpected issues such as lighting, power, seating
and audio.
• Thoroughly check every piece of equipment you bring
along. Make sure you have fresh batteries in your
remote controls and laptop computer. Fully charge
your computer’s battery before the presentation and
connect your AC adaptor for added safety.
• Make sure you are completely familiar with the control
panel on your projector and remote controls.
• If you are using a microphone, check it out before
hand and walk around to see where you might have
problems with feedback. Avoid standing in these
problem areas during your presentation.
e. Presentation Tips
• Before beginning, visualize yourself delivering an
outstanding presentation.
• Know your speech, memorizing at least the first three
minutes of your presentation will allow you to focus
on your rhythm and pacing.
• Speak to early arrivals to help you build a rapport
with the audience and make you feel more
comfortable.
• Do not be overly dependent on your visuals by reciting
what your audience is already reading. Know your
material well enough to be able to deliver the
presentation with ease. Use your visuals to emphasize
keypoints.
• Be sure to project your voice clearly and use eye
contact to maintain audience attention.
• Do not wait until halfway through your presentation to
get your point across. If you wait and try to create a
“build-up”, you may lose some of your audience along
the way.
• Keep your audience’s attention. As most people only
focus for 15 to 20 minutes during a one-hour
presentation, it is important to recapture their attention
periodically. Use phrases like, “This is critical to my
point” or “This is absolutely fundamental” to remind
them you are saying something they need to hear.
Guide to Effective Presentations
E-79
Appendix
Connecting Pin Assignments
INPUT 1 RGB and OUTPUT (INPUT 1, 2) Signal Input Ports: 15-pin Mini D-sub female connector
RGB Input
Analog
1. Video input (red)
2. Video input
(green/sync on green)
3. Video input (blue)
4. Reserve input 1
5. Composite sync
6. Earth (red)
7. Earth (green/sync on green)
8. Earth (blue)
9. Not connected
10. GND
11. GND
12. Bi-directional data
13. Horizontal sync signal
14. Vertical sync signal
15. Data clock
RS-232C Port: 9-pin D-sub male connector of the DIN-D-sub RS-232C cable
5
10
15
1
6
11
Pin No. Signal Name I/O Reference
1 CD Not connected
2 RD Receive Data Input Connected to internal circuit
3 SD Send Data Output Connected to internal circuit
4 ER Not connected
5 SG Signal Ground Connected to internal circuit
6 DR Data Set Ready Output Not connected
7 RS Request to Send Output Connected to internal circuit
8 CS Clear to Send Input Connected to internal circuit
9 CI Not connected
15
69
DVI Port: 29-pin
91 816
C1C2
C32417 C4
C5
Pin No. Name
1 T.M.D.S. Data 2
2 T.M.D.S. Data 2
3 T.M.D.S. Data 2/4 Shield
4 T.M.D.S. Data 4*
3
5 T.M.D.S. Data 4*
3
6 DDC Clock
7 DDC Data
8 Analog Vertical Sync
9 T.M.D.S. Data 1
10 T.M.D.S. Data 1
11 T.M.D.S. Data 1/3 Shield
12 T.M.D.S. Data 3*
3
13 T.M.D.S. Data 3*
3
14 5 V Power
15 Ground*
1
16 Hot Plug Detect
17 T.M.D.S. Data 0
18 T.M.D.S. Data 0
19 T.M.D.S. Data 0/5 Shield
20 T.M.D.S. Data 5*
3
21 T.M.D.S. Data 5*
3
22 T.M.D.S. Clock Shield
23 T.M.D.S. Clock
24 T.M.D.S. Clock
C1 Analog Red
C2 Analog Green
C3 Analog Blue
C4 Analog Horizontal sync
C5 Analog Ground*
2
• *
1
Return for 5 V, Hsync. and Vsync.
• *
2
Analog R, G and B return
• *
3
These pins are not used on this equipment.
Component Input
Analog
1. P
R (CR)
2. Y
3. P
B (CB)
4. Not connected
5. Not connected
6. Earth (P
R)
7. Earth (Y)
8. Earth (P
B)
9. Not connected
10. Not connected
11. Not connected
12. Not connected
13. Not connected
14. Not connected
15. Not connected
E-80
Appendix
(RS-232C) Specifications and Command Settings
PC control
A computer can be used to control the projector by connecting an RS-232C cable (null modem, cross type, sold
separately) to the projector. (See page 16 for connection.)
Communication conditions
Set the serial port settings of the computer to match that of the table.
Signal format: Conforms to RS-232C standard.
Baud rate: 9,600 bps
Data length: 8 bits
Parity bit: NON
Stop bit: 1 bit
Flow control: None
Basic format
Commands from the computer are sent in the following order: command, parameter, and return code. After the
projector processes the command from the computer, it sends a response code to the computer.
Return code (0DH)
C1 C2 C3 C4 P1 P2 P3 P4
Response code format
Normal response
O K
Return code (0DH)
Problem response (communication error or incorrect command)
E R R
Return code (0DH)
Command 4-digits Parameter 4-digits
Command format
When more than one code is being sent, send each command only after the OK response code for the previous
command from the projector is verified.
• When using the computer control function of the projector, the projector operating status cannot be read to the computer.
Therefore, confirm the status by transmitting the display commands for each adjustment menu and checking the status with
the On-screen Display. If the projector receives a command other than a menu display command, it will execute the com-
mand without displaying the On-screen Display.
Commands
EXAMPLE
• When “BRIGHT” of INPUT 1 IMAGE ADJUSTMENT is set to ⳮ10.
→
←
RABR 1 0_ ⳮ
OK
ProjectorComputer
CONTROL CONTENTS
POWER ON
POWER OFF
VOLUME (0–60)
MUTE ON
MUTE OFF
LENS FOCUS (ⳮ30 – Ⳮ30)
LENS ZOOM (ⳮ30 – Ⳮ30)
LENS SHIFT (ⳮ30 – Ⳮ30)
KEYSTONE (ⳮ200 – Ⳮ200)
DIGITAL SHIFT (ⳮ152 – Ⳮ152)
BLACK SCREEN ON
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
P
P
V
M
M
L
L
L
K
L
I
O
O
O
U
U
N
N
N
E
N
M
W
W
L
T
T
F
Z
S
Y
D
B
R
R
A
E
E
O
O
H
S
S
K
_
_
_
_
_
_
_
_
*
_
_
_
_
_
_
_
*
*
*
*
*
_
_
_
*
_
_
*
*
*
*
*
_
1
0
*
1
0
*
*
*
*
*
1
BUTTONS & REMOTE CONTROL KEY
COMMAND
PARAMETER
RETURN
CONTROL CONTENTS
BLACK SCREEN OFF
INPUT 1 (RGB 1)
INPUT 2 (RGB 2)
INPUT 3 (RGB 3)
INPUT 4 (VIDEO 1)
INPUT 5 (VIDEO 2)
INPUT 6 (VIDEO 3)
INPUT CHECK
FREEZE ON
FREEZE OFF
AUTO SYNC START
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
I
I
I
I
I
I
I
I
F
F
A
M
R
R
R
V
V
V
C
R
R
D
B
G
G
G
E
E
E
H
E
E
J
K
B
B
B
D
D
D
K
Z
Z
S
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
0
1
2
3
1
2
3
0
1
0
1
BUTTONS & REMOTE CONTROL KEY
COMMAND
PARAMETER
RETURN
E-81
Appendix
(RS-232C) Specifications and Command Settings
CONTROL CONTENTS
INPUT 2 (RGB 2) SIGNAL TYPE : RGB
INPUT 2 (RGB 2) SIGNAL TYPE : COMPONENT
INPUT 1 (RGB 1) 2D PROGRESSIVE
INPUT 1 (RGB 1) 3D PROGRESSIVE
INPUT 1 (RGB 1) Film MODE
INPUT 2 (RGB 2) 2D PROGRESSIVE
INPUT 2 (RGB 2) 3D PROGRESSIVE
INPUT 2 (RGB 2) Film MODE
INPUT 3 (RGB 3) 2D PROGRESSIVE
INPUT 3 (RGB 3) 3D PROGRESSIVE
INPUT 3 (RGB 3) Film MODE
INPUT 4 (VIDEO 1) CONTRAST (30 – 30)
INPUT 4 (VIDEO 1) BRIGHT (30 – 30)
INPUT 4 (VIDEO 1) RED (30 – 30)
INPUT 4 (VIDEO 1) BLUE (30 – 30)
INPUT 4 (VIDEO 1) COLOR (30 – 30)
INPUT 4 (VIDEO 1) TINT (30 – 30)
INPUT 4 (VIDEO 1) SHARP (30 – 30)
INPUT 4 (VIDEO 1) CLR TEMP (3 – 3)
INPUT 4 (VIDEO 1) DISPLAY
INPUT 4 (VIDEO 1) ADJUSTMENT RESET
INPUT 5 (VIDEO 2) CONTRAST (30 – 30)
INPUT 5 (VIDEO 2) BRIGHT (30 – 30)
INPUT 5 (VIDEO 2) RED (30 – 30)
INPUT 5 (VIDEO 2) BLUE (30 – 30)
INPUT 5 (VIDEO 2) COLOR (30 – 30)
INPUT 5 (VIDEO 2) TINT (30 – 30)
INPUT 5 (VIDEO 2) SHARP (30 – 30)
INPUT 5 (VIDEO 2) CLR TEMP (3 – 3)
INPUT 5 (VIDEO 2) DISPLAY
INPUT 5 (VIDEO 2) ADJUSTMENT RESET
INPUT 6 (VIDEO 3) CONTRAST (30 – 30)
INPUT 6 (VIDEO 3) BRIGHT (30 – 30)
INPUT 6 (VIDEO 3) RED (30 – 30)
INPUT 6 (VIDEO 3) BLUE (30 – 30)
INPUT 6 (VIDEO 3) COLOR (30 – 30)
INPUT 6 (VIDEO 3) TINT (30 – 30)
INPUT 6 (VIDEO 3) SHARP (30 – 30)
INPUT 6 (VIDEO 3) CLR TEMP (3 – 3)
INPUT 6 (VIDEO 3) DISPLAY
INPUT 6 (VIDEO 3) ADJUSTMENT RESET
INPUT 4 (VIDEO 1) SIGNAL TYPE : VIDEO
INPUT 4 (VIDEO 1) SIGNAL TYPE : COMPONENT
INPUT 5 (VIDEO 2) SIGNAL TYPE : VIDEO
INPUT 5 (VIDEO 2) SIGNAL TYPE : COMPONENT
INPUT 4 (VIDEO 1) 2D PROGRESSIVE
INPUT 4 (VIDEO 1) 3D PROGRESSIVE
INPUT 4 (VIDEO 1) Film MODE
INPUT 5 (VIDEO 2) 2D PROGRESSIVE
INPUT 5 (VIDEO 2) 3D PROGRESSIVE
INPUT 5 (VIDEO 2) Film MODE
INPUT 6 (VIDEO 3) 2D PROGRESSIVE
INPUT 6 (VIDEO 3) 3D PROGRESSIVE
INPUT 6 (VIDEO 3) Film MODE
(INPUT 1–6) 2D PROGRESSIVE
(INPUT 1–6) 3D PROGRESSIVE
(INPUT 1–6) Film MODE
CLOCK (150 – 150)
PHASE (60 – 60)
H-POSITION (150 – 150)
V-POSITION (60 – 60)
RGB INPUT DISPLAY
RGB ADJUSTMENT RESET
SAVE SETTING (1 – 7)
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
I
I
R
R
R
R
R
R
R
R
R
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
I
I
I
I
V
V
V
V
V
V
V
V
V
I
I
I
I
I
I
I
I
I
M
B
B
A
A
A
B
B
B
C
C
C
A
A
A
A
A
A
A
A
A
A
B
B
B
B
B
B
B
B
B
B
C
C
C
C
C
C
C
C
C
C
A
A
B
B
A
A
A
B
B
B
C
C
C
M
M
M
N
N
A
A
A
A
E
S
S
I
I
I
I
I
I
I
I
I
P
B
R
B
C
T
S
C
R
R
P
B
R
B
C
T
S
C
R
R
P
B
R
B
C
T
S
C
R
R
S
S
S
S
I
I
I
I
I
I
I
I
I
I
I
I
C
P
H
V
R
R
M
I
I
P
P
P
P
P
P
P
P
P
I
R
D
E
O
I
H
T
E
E
I
R
D
E
O
I
H
T
E
E
I
R
D
E
O
I
H
T
E
E
V
V
V
V
P
P
P
P
P
P
P
P
P
P
P
P
L
H
P
P
E
E
S
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
*
*
*
*
*
*
_
_
_
_
*
*
*
*
*
*
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
*
_
*
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
*
*
*
*
*
*
*
_
_
_
*
*
*
*
*
*
*
_
_
_
*
*
*
*
*
*
*
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
*
*
*
*
_
_
_
_
_
_
_
_
_
_
_
_
_
_
*
*
*
*
*
*
*
*
_
_
*
*
*
*
*
*
*
*
_
_
*
*
*
*
*
*
*
*
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
*
*
*
*
_
_
_
0
1
0
1
2
0
1
2
0
1
2
*
*
*
*
*
*
*
*
0
1
*
*
*
*
*
*
*
*
0
1
*
*
*
*
*
*
*
*
0
1
0
1
0
1
0
1
2
0
1
2
0
1
2
0
1
2
*
*
*
*
0
1
*
PICTUREFINE SYNC
*1
COMMAND
PARAMETER
RETURN
CONTROL CONTENTS
INPUT 1 (RGB 1) RESIZE : NORMAL
INPUT 1 (RGB 1) RESIZE : FULL
INPUT 1 (RGB 1) RESIZE : DOT BY DOT
INPUT 2 (RGB 2) RESIZE : NORMAL
INPUT 2 (RGB 2) RESIZE : FULL
INPUT 2 (RGB 2) RESIZE : DOT BY DOT
INPUT 3 (RGB 3) RESIZE : NORMAL
INPUT 3 (RGB 3) RESIZE : FULL
INPUT 3 (RGB 3) RESIZE : DOT BY DOT
INPUT 4 (VIDEO 1) RESIZE : NORMAL
INPUT 4 (VIDEO 1) RESIZE : FULL
INPUT 4 (VIDEO 1) RESIZE : BORDER
INPUT 4 (VIDEO 1) RESIZE : STRETCH
INPUT 4 (VIDEO 1) RESIZE : SMART STRETCH
INPUT 5 (VIDEO 2) RESIZE : NORMAL
INPUT 5 (VIDEO 2) RESIZE : FULL
INPUT 5 (VIDEO 2) RESIZE : BORDER
INPUT 5 (VIDEO 2) RESIZE : STRETCH
INPUT 5 (VIDEO 2) RESIZE : SMART STRETCH
INPUT 6 (VIDEO 3) RESIZE : NORMAL
INPUT 6 (VIDEO 3) RESIZE : FULL
INPUT 6 (VIDEO 3) RESIZE : BORDER
INPUT 6 (VIDEO 3) RESIZE : STRETCH
INPUT 6 (VIDEO 3) RESIZE : SMART STRETCH
RGB GAMMA : STANDARD
RGB GAMMA : GAMMA1
RGB GAMMA : GAMMA2
RGB GAMMA : CUSTOM
VIDEO GAMMA : STANDARD
VIDEO GAMMA : GAMMA1
VIDEO GAMMA : GAMMA2
VIDEO GAMMA : CUSTOM
INPUT 1 (RGB 1) CONTRAST (30 – 30)
INPUT 1 (RGB 1) BRIGHT (30 – 30)
INPUT 1 (RGB 1) RED (30 – 30)
INPUT 1 (RGB 1) BLUE (30 – 30)
INPUT 1 (RGB 1) COLOR (30 – 30)
INPUT 1 (RGB 1) TINT (30 – 30)
INPUT 1 (RGB 1) SHARP (30 – 30)
INPUT 1 (RGB 1) CLR TEMP (3 – 3)
INPUT 1 (RGB 1) DISPLAY
INPUT 1 (RGB 1) ADJUSTMENT RESET
INPUT 2 (RGB 2) CONTRAST (30 – 30)
INPUT 2 (RGB 2) BRIGHT (30 – 30)
INPUT 2 (RGB 2) RED (30 – 30)
INPUT 2 (RGB 2) BLUE (30 – 30)
INPUT 2 (RGB 2) COLOR (30 – 30)
INPUT 2 (RGB 2) TINT (30 – 30)
INPUT 2 (RGB 2) SHARP (30 – 30)
INPUT 2 (RGB 2) CLR TEMP (3 – 3)
INPUT 2 (RGB 2) DISPLAY
INPUT 2 (RGB 2) ADJUSTMENT RESET
INPUT 3 (RGB 3) CONTRAST (30 – 30)
INPUT 3 (RGB 3) BRIGHT (30 – 30)
INPUT 3 (RGB 3) RED (30 – 30)
INPUT 3 (RGB 3) BLUE (30 – 30)
INPUT 3 (RGB 3) COLOR (30 – 30)
INPUT 3 (RGB 3) TINT (30 – 30)
INPUT 3 (RGB 3) SHARP (30 – 30)
INPUT 3 (RGB 3) CLR TEMP (3 – 3)
INPUT 3 (RGB 3) DISPLAY
INPUT 3 (RGB 3) ADJUSTMENT RESET
INPUT 1 (RGB 1) SIGNAL TYPE : RGB
INPUT 1 (RGB 1) SIGNAL TYPE : COMPONENT
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
G
G
G
G
G
G
G
G
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
I
I
A
A
A
B
B
B
C
C
C
A
A
A
A
A
B
B
B
B
B
C
C
C
C
C
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
B
B
B
B
B
B
B
B
B
B
C
C
C
C
C
C
C
C
C
C
A
A
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
M
M
M
M
M
M
M
M
P
B
R
B
C
T
S
C
R
R
P
B
R
B
C
T
S
C
R
R
P
B
R
B
C
T
S
C
R
R
S
S
R
R
R
R
R
R
R
R
R
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
R
R
R
R
V
V
V
V
I
R
D
E
O
I
H
T
E
E
I
R
D
E
O
I
H
T
E
E
I
R
D
E
O
I
H
T
E
E
I
I
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
*
*
*
*
*
*
*
_
_
_
*
*
*
*
*
*
*
_
_
_
*
*
*
*
*
*
*
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
*
*
*
*
*
*
*
*
_
_
*
*
*
*
*
*
*
*
_
_
*
*
*
*
*
*
*
*
_
_
_
_
1
5
3
1
5
3
1
5
3
1
5
3
2
4
1
5
3
2
4
1
5
3
2
4
1
2
3
4
1
2
3
4
*
*
*
*
*
*
*
*
0
1
*
*
*
*
*
*
*
*
0
1
*
*
*
*
*
*
*
*
0
1
0
1
BUTTONS & REMOTE CONTROL KEYPICTURE
COMMAND
PARAMETER
RETURN
E-82
Appendix
(RS-232C) Specifications and Command Settings
CONTROL CONTENTS
SELECT SETTING (1 – 7)
RGB HORIZONTAL FREQUENCY CHECK
RGB VERTICAL FREQUENCY CHECK
AUTO SYNC ON
AUTO SYNC OFF
AUTO SYNC DISPLAY ON
AUTO SYNC DISPLAY OFF
BALANCE (30 – 30)
TREBLE (30 – 30)
BASS (30 – 30)
AUDIO DISPLAY
AUDIO ADJUSTMENT RESET
PICT IN PICT (SMALL) : BOTTOM RIGHT
PICT IN PICT (SMALL) : BOTTOM LEFT
PICT IN PICT (SMALL) : UPPER RIGHT
PICT IN PICT (SMALL) : UPPER LEFT
PICT IN PICT (BIG) : BOTTOM RIGHT
PICT IN PICT (BIG) : BOTTOM LEFT
PICT IN PICT (BIG) : UPPER RIGHT
PICT IN PICT (BIG) : UPPER LEFT
PICT IN PICT RESET
VIDEO 3D DNR OFF
VIDEO 3D DNR ON
OSD DISPLAY ON
OSD DISPLAY OFF (LEVEL A)
OSD DISPLAY OFF (LEVEL B)
BLACK SCREEN DISPLAY ON
BLACK SCREEN DISPLAY OFF
VIDEO SYSTEM SELECTION : AUTO
VIDEO SYSTEM SELECTION : PAL
VIDEO SYSTEM SELECTION : SECAM
VIDEO SYSTEM SELECTION : NTSC4.43
VIDEO SYSTEM SELECTION : NTSC3.58
VIDEO SYSTEM SELECTION : PAL_M
VIDEO SYSTEM SELECTION : PAL_N
BACKGROUND SELECTION : SHARP
BACKGROUND SELECTION : CUSTOM
BACKGROUND SELECTION : BLUE
BACKGROUND SELECTION : NONE
STARTUP IMAGE SELECTION : SHARP
STARTUP IMAGE SELECTION : CUSTOM
STARTUP IMAGE SELECTION : NONE
MONITOR OUT OFF
MONITOR OUT ON
AUTO POWER OFF : NO USE
AUTO POWER OFF : USE
ID NO. LED DISPLAY : DISPLAY OFF
ID NO. LED DISPLAY : STANDBY OFF
ID NO. LED DISPLAY : DISPLAY ON
OK OR ERR
kHz (***. *OR_)
Hz (***. *OR_)
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
M
T
T
A
A
I
I
A
A
A
A
A
P
P
P
P
P
P
P
P
P
3
3
I
I
I
I
I
M
M
M
M
M
M
M
I
I
I
I
I
I
I
M
M
A
A
I
I
I
E
F
F
A
A
M
M
A
A
A
A
A
I
I
I
I
I
I
I
I
I
D
D
M
M
M
M
M
E
E
E
E
E
E
E
M
M
M
M
M
M
M
O
O
P
P
L
L
L
M
R
R
D
D
A
A
B
T
B
R
R
N
N
N
N
N
N
N
N
N
N
N
D
D
D
B
B
S
S
S
S
S
S
S
B
B
B
B
S
S
S
U
U
O
O
E
E
E
L
Q
Q
J
J
S
S
L
E
A
E
E
P
P
P
P
P
P
P
P
P
R
R
I
I
I
O
O
Y
Y
Y
Y
Y
Y
Y
G
G
G
G
I
I
I
T
T
W
W
D
D
D
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
*
*
*
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
*
*
*
_
_
1
1
1
1
2
2
2
2
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
*
1
2
1
0
1
0
*
*
*
0
1
1
2
3
4
1
2
3
4
0
0
1
1
2
0
1
0
1
2
3
4
5
6
7
1
2
3
4
1
2
3
0
1
0
1
0
1
2
FINE SYNC
*1
AUDIOOPTIONS (1)
COMMAND
PARAMETER
RETURN
CONTROL CONTENTS
LAMP 1 USAGE TIME
LAMP 2 USAGE TIME
LAMP MODE : BOTH LAMPS
LAMP MODE : LAMP 1 ONLY
LAMP MODE : LAMP 2 ONLY
LAMP MODE : EQUAL USE
LAMP QUANTITY
LAMP 1 STATUS
LAMP 2 STATUS
PRJ MODE : REVERSE OFF
PRJ MODE : REVERSE ON
PRJ MODE : INVERT OFF
PRJ MODE : INVERT ON
STACK SETTING : NORMAL
STACK SETTING : MASTER
STACK SETTING : SLAVE
KEYLOCK LEVEL : NORMAL
KEYLOCK LEVEL : LEVEL A
KEYLOCK LEVEL : LEVEL B
SET INPUTS : INPUT 1 NO USE
SET INPUTS : INPUT 1 USE
SET INPUTS : INPUT 2 NO USE
SET INPUTS : INPUT 2 USE
SET INPUTS : INPUT 3 NO USE
SET INPUTS : INPUT 3 USE
SET INPUTS : INPUT 4 NO USE
SET INPUTS : INPUT 4 USE
SET INPUTS : INPUT 5 NO USE
SET INPUTS : INPUT 5 USE
SET INPUTS : INPUT 6 NO USE
SET INPUTS : INPUT 6 USE
ID NO. CHECK
LANGUAGE SELECTION : ENGLISH
LANGUAGE SELECTION : DEUTSCH
LANGUAGE SELECTION : ESPAÑOL
LANGUAGE SELECTION : NEDERLANDS
LANGUAGE SELECTION : FRANÇAIS
LANGUAGE SELECTION : ITALIANO
LANGUAGE SELECTION : SVENSKA
LANGUAGE SELECTION :
LANGUAGE SELECTION : PORTUGUÊS
LANGUAGE SELECTION :
LANGUAGE SELECTION :
MODEL NAME CHECK
NOISE FILTER OFF
NOISE FILTER ON
*2
SERIAL NO. CHECK
*3
PROJECTOR NAME
*4
0–9999 (INTEGER)
0–9999 (INTEGER)
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
1 OR 2
0: OFF, 1: ON, 2: RETRY,
3: WAITING, 4: LAMP ERROR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
001–250
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
MODEL NAME
OK OR ERR
OK OR ERR
SERIAL NO.
OK OR ERR
PROJECTOR NAME
T
T
L
L
L
L
T
T
T
I
I
I
I
S
S
S
K
K
K
R
R
R
R
R
R
V
V
V
V
V
V
R
M
M
M
M
M
M
M
M
M
M
M
M
N
N
S
P
P
L
L
P
P
P
P
L
L
L
M
M
M
M
T
T
T
E
E
E
A
A
B
B
C
C
A
A
B
B
C
C
D
E
E
E
E
E
E
E
E
E
E
E
N
F
F
N
J
J
T
T
M
M
M
M
P
P
P
R
R
I
I
A
A
A
Y
Y
Y
S
S
S
S
S
S
S
S
S
S
S
S
I
L
L
L
L
L
L
L
L
L
L
L
R
I
I
R
N
N
T
T
D
D
D
D
N
S
S
E
E
N
N
K
K
K
L
L
L
I
I
I
I
I
I
I
I
I
I
I
I
D
A
A
A
A
A
A
A
A
A
A
A
D
L
L
D
A
A
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
1
_
_
_
_
_
_
1
2
0
1
2
3
1
1
2
0
1
0
1
0
1
2
0
1
2
0
1
0
1
0
1
0
1
0
1
0
1
1
0
1
2
3
4
5
6
7
8
9
0
1
0
1
1
1
2
OPTIONS (2)LANGUAGE
COMMAND
PARAMETER
RETURN
• If an underbar (_) appears in the parameter column, enter a space. If an asterisk (*) appears, enter a value in the range
indicated in brackets under CONTROL CONTENTS.
•
*1
FINE SYNC can only be set in the displayed RGB mode.
•
*2
Noise may appear when used with certain computers. Set the NOISE FILTER to ON using the RS-232C command.
•
*3
SERIAL NO. CHECK command is used to read out the 12 digits of serial No..
•
*4
After OK is returned, enter PROJECTOR NAME, up to 16-character memory. The PROJECTOR NAME in memory can then
be output (confirmed).
E-83
Appendix
Wired Remote Control Terminal Specifications
Specifications of wired remote control input
• ø3.5 mm minijack
• External: 5 V (1 A)
• Internal: GND
Function and transmission codes
• To operate the mouse, left-click and right-click functions
through the wired remote control input, connect the cable
from the WIRED REMOTE control input terminal on the
projector to the remote control. The codes for these functions
are complex and are, therefore, not listed here.
Wired remote control function code
10110********10
C1 System Code C5 C6 Data Code C13 C14 C15
• System codes C1 to C5 are fixed at “10110”.
• Codes C14 and C15 are reverse confirmation bits, with “10”
indicating “Front” and “01” indicating “Rear”.
LSB MSB
Sharp remote control signal format
Transmission format: 15-bit format
Wave form of output signal: Output using Pulse Position Modulation
DDDDDD
DDDDDDD
67.5 ms 67.5 ms
“0”“1”“0”
D
“0”“0”“0”“1”
T
0T1
t
t
26.4 µs
• t 264 µs
• T0 1.05 ms
• T1 2.10 ms
Transmission control code
15 bit
• Pulse carrier frequency 455/12 kHz
• Duty ratio 1:1
C1 C2 C3 C4 C5 C6 C7 C8 C9 C10 C11 C12 C13 C14
System Address
D to D Common Data Bit Reverse in D
Function Key Data Bit
Data
Expansion
Data
Deter-
mination
Mask
C15
C1
1
DC2
0
C3
1
C4
1
C5
0
C6
1
C7
0
C8
0
C9
0
C10
0
C11
0
C12
0
C13
0
C14
1
C15
0
C1
1
DC2
0
C3
1
C4
1
C5
0
C6
0
C7
1
C8
1
C9
1
C10
1
C11
1
C12
1
C13
1
C14
0
C15
1
CONTROL
ITEM
SYSTEM CODE
C1
1
1
1
1
1
1
1
1
1
1
1
ON
OFF
VOL
VOL
MUTE
MENU
LENS
TOOLS
BLACK SCREEN
ENTER
RESIZE
0
0
0
0
0
0
0
0
0
0
0
C2
1
1
1
1
1
1
1
1
1
1
1
C3
1
1
1
1
1
1
1
1
1
1
1
C4
0
0
0
0
0
0
0
0
0
0
0
C5 C6
0
0
0
1
1
0
1
0
1
1
0
1
1
0
0
1
0
1
1
0
1
1
C7
1
1
1
1
1
1
0
0
0
1
1
C8
0
0
0
0
0
0
1
1
1
0
1
C9
1
1
1
1
1
0
0
0
0
1
1
C10 C11
0
0
0
0
0
0
0
1
1
0
0
1
0
0
0
0
1
0
1
1
1
1
C12
0
1
0
0
0
1
1
1
0
0
0
C13
1
1
1
1
1
1
1
1
1
1
1
C14
0
0
0
0
0
0
0
0
0
0
0
C15
DATA CODE
EXTERNAL
CODE
CONTROL
ITEM
SYSTEM CODE
C1
1
1
1
1
1
1
1
1
1
1
1
UNDO
FREEZE
ENLARGE
AUTO SYNC
∂
ƒ
ß
©
GAMMA
INPUT 1. 2. 3
INPUT 4. 5. 6
0
0
0
0
0
0
0
0
0
0
0
C2
1
1
1
1
1
1
1
1
1
1
1
C3
1
1
1
1
1
1
1
1
1
1
1
C4
0
0
0
0
0
0
0
0
0
0
0
C5 C6
1
1
1
0
0
1
0
1
0
0
0
0
0
0
1
0
0
0
1
0
0
1
C7
0
1
1
0
1
1
0
1
0
1
1
C8
1
1
1
1
1
1
0
1
0
1
0
C9
1
0
0
1
1
1
1
0
0
0
1
C10 C11
0
0
1
1
0
0
0
0
0
1
1
1
0
1
1
0
0
1
1
1
1
0
C12
0
1
0
1
1
1
0
0
0
1
1
C13
1
1
1
1
1
1
1
1
1
1
1
C14
0
0
0
0
0
0
0
0
0
0
1
C15
DATA CODE
EXTERNAL
CODE
Example of Reverse D to
E-84
Appendix
Computer Compatibility Chart
Horizontal Frequency: 15–126 kHz
Vertical Frequency: 43–200 Hz
Pixel Clock: 12–230 MHz
Compatible with sync on green and composite sync signals
UXGA (1,600 1,200) compatible in advanced intelligent compression
AICS (Advanced Intelligent Compression and Expansion System) resizing technology
PC/
MAC/
WS
Horizontal
Frequency
(kHz)
Vertical
Frequency
(Hz)
VGA
PC
PC
SVGA
XGA
VESA
Standard
Resolution
640 350
1,152 864
1,152 882
1,280 1,024
720 350
640 400
720 400
640 480
800 600
1,024 768
Display
Upscale
27.0 60
27.0 60
27.0 60
60
31.5 70
31.5 70
31.5
70
31.5
60
34.7
70
37.9
72
37.5
75
43.3
85
47.9
90
53.0
100
61.8
120
78.5
150
80.9
160
100.4 200
31.4 50
35.1 56
37.9 60
44.5 70
48.1 72
46.9 75
53.7 85
56.8 90
64.0 100
77.2 120
98.3 150
102.1 160
125.6 200
98.8 120
31.5 70
37.9 85
37.9
27.0
85
37.9
85
26.2
50
PC/
MAC/
WS
Horizontal
Frequency
(kHz)
Vertical
Frequency
(Hz)
Resolution Display
Upscale
Advanced
Intelligent
Compression
54.3 60
67.5 75
75.7 80
77.3 85
111.1 120
65.9 72
54.8 60
67.4 74
64.0 60
1,600 1,200
VESA
Standard
SXGA
UXGA
91.1 85
74.7 52
75.7 75
78.1 74
74.6 70
81.3 65
90.1 72
93.8 75
106.3 85
75.0 60
108.4 100
87.5 70
MAC 16"
MAC 21"
HP (WS)
WS
PC/
MAC 13"
PC/
MAC 19"
PC/
MAC 21"
PC (WS)
SGI (WS)
SUN (WS)
Intelligent
Compression
True
640 480
832 624
Upscale
Upscale
Upscale
34.9
1,152 870
68.5
67
1,280 1,024
60.0
75
1,280 1,024
78.1 72
60.0 60
1,024 768
1,280 960
VGA
SVGA
SXGA
SXGA
SXGA
XGA
True
True
48.4 60
80.0
75
46.8 75
1,280 1,024
53.5 50
76.8 72
85.9 85
1,152 900
60.9 66
71.9 76
49.6 75
75
90.2 100
64.0 70
64.1 72
113.2 140
125.6 150
35.5 43
40.3 50
58.1 72
68.7 85
73.5 90
77.2 96
80.6 100
56.5 70
• This projector may not be able to display images from notebook computers in simultaneous (CRT/LCD) mode. Should this
occur, turn off the LCD display on the notebook computer and output the display data in “CRT only” mode. Details on how
to change display modes can be found in your notebook computer’s operation manual.
• This projector can receive 640 350 VESA format VGA signals, however, “640 400” will appear on the screen.
• When receiving 1,600 1,200 VESA format UXGA signals, sampling occurs and the image is displayed with 1,024 lines,
causing part of the image to be blocked.
E-85
Appendix
16
5
/16 (414.5)
8
47
/64 (221.85)
2
15
/16 (74.5)
1
1
/64 (25.65) 3
7
/32 (81.85) 24
29
/64 (621.3)
17
31
/64 (444.2)
5
/32 (3.9)
1
21
/32 (42)
14
51
/64 (376)
Dimensions
Rear View
Top View
Side View
Side View
Front View
Bottom View
Units: inches (mm)
E-86
Appendix
Specifications
Product type
Model
Video system
Display method
LCD panel
Projection lamp
Contrast ratio
Video input signal
S-video input signal
Component input signal
Horizontal resolution
RGB input signal
Pixel clock
Vertical frequency
Horizontal frequency
Computer control signal
Speaker system
Rated voltage
Input current
Rated frequency
Power consumption
Power dissipation
Operating temperature
Storage temperature
Cabinet
I/R carrier frequency
Laser pointer of remote control
Dimensions (approx.)
Weight (approx.)
Supplied accessories
Replacement parts
LCD Projector
XG-V10WU
PAL/PAL 60/PAL-M/PAL-N/SECAM/NTSC 3.58/NTSC 4.43
DTV 480i/480P/720P/1080i
LCD panel 3, RGB optical shutter method
Panel size: 1.8 (28.7 [H] 35.8 [W] mm)
Display method: Translucent TN liquid crystal panel
Drive method: TFT (Thin Film Transistor) Active Matrix panel
No. of dots: 1,310,720 dots (1,280 [H] 1,024 [V])
200 W UHP lamp 2
400:1
BNC Connector: VIDEO (INPUT 4, 5), composite video, 1.0 Vp-p, sync negative, 75 Ω
terminated
RCA Connector: AUDIO (INPUT 4, 5), 0.5 Vrms more than 22 kΩ (stereo)
4-pin Mini DIN connector (INPUT 4, 5)
Y (luminance signal): 1.0 Vp-p, sync negative, 75 Ω terminated
C (chrominance signal): Burst 0.286 Vp-p, 75 Ω terminated
BNC Connector (INPUT 2, 4, 5)
Y: 1.0 Vp-p, sync negative, 75 Ω terminated
P
B: 0.7 Vp-p, 75 Ω terminated
P
R: 0.7 Vp-p, 75 Ω terminated
620 TV lines (video input), 720 TV lines (DTV 720P input, Dot by Dot)
15-
PIN MINI D-SUB CONNECTOR (INPUT 1), 5 BNC CONNECTOR (INPUT 2):
RGB separate/composite sync/sync on green type analog input: 0–0.7 Vp-p, positive,
75 Ω terminated
DVI
CONNECTOR (29-PIN) (INPUT 3), RGB (DIGITAL), 250–1,000 mV, 50 Ω
H
ORIZONTAL SYNC. SIGNAL: TTL level (positive/negative) or composite sync (Apple only)
V
ERTICAL SYNC. SIGNAL: Same as above
12–230 MHz
43–200 Hz
15–126 kHz
9-pin D-sub connector (RS-232C Input Port/Output Port)
1
31
⁄32 3
5
⁄32 (5 8 cm) oval 2, 3 W 3 W (stereo)
AC 110–120/220–240 V
6.2 A/3.1 A
50/60 Hz
575 W
< 2,100 BTU/hour
41°F to 104°F (5°C to 40°C)
4°F to 140°F (20°C to 60°C)
Plastic
38 kHz
Wave length: 650 nm / Max. output: 1 mW / Class II Laser Product
17
31
⁄64 (W) 7
23
⁄32 (H) 24
29
⁄64 (D) (444.2 196.2 621.3 mm) (main body only)
20
55
⁄64 (W) 8
23
⁄32 (H) 25
5
⁄16 (D) (530.1 221.9 643.2 mm) (including standard
lens, terminal cover, adjustment feet and projecting parts)
41.7 lbs. (18.9 kg) (main body only)
Remote control, Two AA size batteries, Power cord (11 10, 3.6 m), RGB cable (9 10,
3 m), PS/2 mouse control cable (3 3, 1 m), USB mouse control cable (3 3, 1 m), Remote
mouse receiver, Extra air filter, Terminal cover, CD-ROM, LCD projector operation manual,
LCD projector quick reference, Sharp Advanced Presentation Software operation manual
Lamp unit (Lamp/cage module) (BQC-XGV10WU/1), Remote control (RRMCG1564CESA),
AA size batteries, Power cord (QACCU5013CEZZ), RGB cable (QCNW-5304CEZZ), PS/2
mouse control cable (QCNW-5113CEZZ), USB mouse control cable (QCNW-5680CEZZ),
Remote mouse receiver (RUNTK0673CEZZ), Air filter (PFILD0110CEZZ), Terminal cover
(CCOVA1789CE01), CD-ROM (UDSKA0020CEN1), LCD projector operation manual (TINS-
6974CEZZ), LCD projector quick reference (TINS-6980CEZZ), Sharp Advanced
Presentation Software operation manual (TINS-6992CEZZ)
This SHARP projector uses LCD (Liquid Crystal Display) panels. These
very sophisticated panels contain 1,310,720 pixels ( RGB) TFTs
(Thin Film Transistors). As with any high technology electronic
equipment such as large screen TVs, video systems and video
cameras, there are certain acceptable tolerances that the equipment
must conform to.
This unit has some inactive TFTs within acceptable tolerances which
may result in illuminated or inactive dots on the picture screen. This
will not affect the picture quality or the life expectancy of the unit.
If you have any questions about this matter, please call toll free 1-888-
GO-SHARP (1-888-467-4277). U.S.A. ONLY
Specifications are subject to change without notice.
E-87
Appendix
Glossary
Anti-aliasing digital keystone correction
Function to digitally correct a distorted image when the projector is set up at an angle.
Aspect ratio
Width and height ratio of an image. The normal aspect ratio of a computer and video image is 4 : 3. There are also wide images with an aspect ratio of 16 : 9
and 21 : 9.
Auto sync
Optimizes projected computer images by automatically adjusting certain characteristics.
Background
Initial setting image projected when no signal is being input.
Border
Displays the 4:3 image as the biggest size (960720) that can be displayed on the WIDE mode screen (1280720).
Clock
Clock adjustment is used to adjust vertical noise when clock level is incorrect.
Compatibility
Ability to use with various image signal modes.
Composite sync
Signal combining horizontal and vertical sync pulses.
Dot by dot
Mode that projects images in their native resolution.
DVI
Digital Visual Interface that supports both digital and analog displays.
Freeze
Function to freeze a moving image.
GUI
Graphical User Interface. User interface with graphics that allow easier operation.
Intelligent compression and expansion
High quality resizing of lower and higher resolution images to fit the projector’s native resolution.
Keylock
Mode that can lock the operation of projector buttons to prevent mischief.
Lamp Mode
Mode that enables you to use two lamps in different combinations. You can select four different modes : Both Lamps (use two lamps simultaneously), Lamp 1 only
(use only lamp 1), Lamp 2 only (use only lamp 2 ) and Equal Use (use lamp 1 and lamp 2 alternatingly).
Magnification
Digitally zooms in on a portion of an image.
Optional Board
The expansion board (sold separately) enables you to respond to the image signal for business-use and RS-422 control.
PDF
Portable Document Format. Documentation format used to transfer text and images from the CD-ROM.
Phase
Phase shift is a timing shift between isomorphic signals with the same resolution. When phase level is incorrect, the projected image typically displays horizontal
flicker.
Presentation tools
Helpful tools used to emphasize keypoints throughout a presentation.
Progressive Mode
Selects three different modes : 2D Progressive, 3D Progressive and Film Mode.
RS-232C
Function to control the projector from the computer by using the RS-232C ports on the projector and computer.
Set Inputs
Function to limit inputs. For example, when setting Input 2 to “OFF”, the input is switchable only between Input 1 and Input 3, skipping Input 2.
Smart Stretch
Mode that stretches the right and left sides of the 4:3 image horizontally while maintaining the aspect ratio around the center of the image to display it on the WIDE
screen.
Stack Setting
Prevents trouble with adjustment and operation when stack projecting. When setting two projectors, one to master and the other to slave, the slave follows the
master’s operation.
Startup image
The image displayed when the projector is turned on.
Status function
Displays the settings of each adjustment item.
Stretch
Mode that stretches the 4:3 image horizontally to display it on the WIDE screen.
Sync
Synchronizes the resolution and phase shift of two signals. When receiving an image with a resolution different from that of the computer, the projected image
may be distorted.
Sync on green
Video signal mode of a computer which overlaps horizontal and vertical sync signal to green color signal pin.
Wireless mouse
Function to operate the mouse control of a computer with the supplied remote control.
E-88
Appendix
Index
A
AC socket......................................................................... 14
Adjusting the Picture ........................................................ 43
Adjustment Feet ............................................................... 20
ADJUSTMENT switch....................................................... 12
Air filter ............................................................................. 73
Anti-aliasing digital keystone correction .......................... 29
Aspect ratio ...................................................................... 34
Audio ................................................................................ 50
Audio cable ...................................................................... 18
AUDIO INPUT terminals ................................................... 11
AUDIO OUTPUT terminals ............................................... 11
Automatic power shutoff function .................................... 55
Auto sync adjustment ...................................................... 49
AUTO SYNC button.......................................................... 49
B
Background ..................................................................... 54
BACKLIGHT button .......................................................... 37
BLACK SCREEN button ................................................... 32
BNC-RCA adaptors.......................................................... 17
BORDER .......................................................................... 34
C
Carrying handle ............................................................... 4
Ceiling-mount ................................................................... 30
Ceiling+Rear .................................................................... 56
Clock ................................................................................ 46
Color Temperature ........................................................... 44
D
DOT BY DOT .................................................................... 34
DVI INPUT port (INPUT 3) ................................................ 16
E
Economy Mode ................................................................ 55
ENLARGE button ............................................................. 33
ENTER button................................................................... 10
Exhaust vent..................................................................... 3
Extra air filter .................................................................... 13
F
FREEZE button ................................................................. 32
G
GAMMA button ................................................................ 35
GUI (Graphical User Interface) ........................................ 40
I
INPUT buttons .................................................................. 31
INPUT port ....................................................................... 11
Input Setting ..................................................................... 59
K
Keylock Levels ................................................................. 59
L
LAMP REPLACEMENT indicators .................................... 69
LASER POINTER button................................................... 39
LEFT-CLICK button .......................................................... 37
LENS button ..................................................................... 29
M
MENU button.................................................................... 40
Monitor Out/RS-232C Off Function .................................. 55
MOUSE/ADJUSTMENT buttons ....................................... 12
MOUSE/ADJUSTMENT switch ......................................... 36
MUTE button .................................................................... 31
N
Network Function ............................................................. 65
O
On-screen display............................................................ 53
On-screen display Language .......................................... 57
Optional Board ................................................................. 62
OUTPUT port ................................................................... 11
P
Password ......................................................................... 61
PDF .................................................................................. 9
Phase ............................................................................... 46
Picture in Picture .............................................................. 51
POWER buttons ............................................................... 19
Power cord ....................................................................... 14
POWER indicator ............................................................. 19
Presentation tools............................................................. 64
Progressive Mode ............................................................ 45
PS/2 mouse control cable ................................................ 38
R
Rear projection................................................................. 30
Remote control ................................................................. 12
Remote control sensor ..................................................... 36
Remote control signal transmitter .................................... 12
Remote mouse receiver ................................................... 38
RESIZE button .................................................................. 34
RGB cable........................................................................ 14
RIGHT-CLICK button ........................................................ 37
RS-232C port ................................................................... 11
S
Save Setting ..................................................................... 47
Select Setting ................................................................... 47
Set ID No. ......................................................................... 63
Set Inputs ......................................................................... 59
Speakers .......................................................................... 11
Stack Setting .................................................................... 63
Startup image .................................................................. 54
Status function ................................................................. 58
S-VIDEO INPUT terminal .................................................. 11
Sync ................................................................................. 49
Sync on green .................................................................. 79
SXGA................................................................................ 5
T
TEMPERATURE WARNING indicator ............................... 69
TOOLS button .................................................................. 64
Transmission Speed (RS-232C) ....................................... 60
U
UNDO button ................................................................... 40
USB mouse control cable ................................................ 38
V
VIDEO INPUT terminal ..................................................... 11
Video System ................................................................... 53
Videowall .......................................................................... 68
VOLUME buttons ............................................................. 31
W
Wired remote control input ............................................... 39
WIRED REMOTE control input terminal ........................... 39
Wireless mouse ................................................................ 37
No.
1.2.3 button ...................................................................... 31
3D DNR ............................................................................ 52
4.5.6 button ...................................................................... 31
E-89
Appendix
SHARP CORPORATION
