CORDLESS SNOW SHOVEL POLE
ASSEMBLY INSTRUCTION
R
STEP 01
LAY THE UNIT ON A LEVEL SURFACE.
Fig. 1
Center pole
section
Upper pole
section
Lower pole
section
STEP 02
INSERT LOWER BOLT THROUGH
LOWER POLE SECTION WHILE
MOVING INNER WIRE ASIDE. SECURE
WITH KNOB.
Fig. 2
Lower bolt
Move inner wire aside
Knob
STEP 03
REPEAT FOR UPPER POLE ASSEMBLY.
Fig. 3
Upper bolt
Move inner wire aside
Knob
UPDATED ASSEMBLY INSTRUCTIONS
FOR 24V-SS11 SERIES MODELS
© 2020 by Snow Joe
®
, LLC
All rights reserved. Original instructions.
SAVE THESE INSTRUCTIONS
IMPORTANT!
INSERT UPPER + LOWER POLE
SECTIONS SIMULTANEOUSLY INTO
CENTER POLE SECTION.
PUSH FIRMLY.
