Refrigerator - Freezer
Operation manual
Contents
• Safety information .......................... 3
• Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
• Description ................................ 6
• Useful modes .............................. 7
• Control panel .............................. 8
• Storing food .............................. 10
• Care and cleaning. . . . . . . . . . . . . . . . . . . . . . . . . . 11
• Before you call for service ................... 12
• Specication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
• Warranty ................................. 14
MODEL
SJ-XP624FB
“Plasmacluster” and “Device of a cluster
of grapes” are trademarks of Sharp
Corporation.
(B979).indb 1(B979).indb 1 2020/04/06 17:33:542020/04/06 17:33:54
(B979).indb 2(B979).indb 2 2020/04/06 17:33:542020/04/06 17:33:54
3
Household use only
Thank you very much for buying this SHARP product. Before using your SHARP
refrigerator, please read this operation manual to ensure that you gain the maximum benet
from it.
This refrigerator is for household only, with ambient temperature between +5°C and +43°C.
The refrigerator should not be subjected to temperatures of -10°C or below for a long period
of time.
Safety information
Refrigerant
This refrigerator contains ammable refrigerant (R600a:
isobutane) and insulation blowing gas (cyclopentane).
Observe the following rules to prevent ignition and
explosion.
■ Do not damage the refrigerant circuit.
■ Do not allow any sharp objects to have contact with the
refrigeration system. The refrigeration system behind
and inside the refrigerator contains refrigerant.
Leaking refrigerant can ignite and may damage the
eyes.
■ Do not use mechanical devices or other means to
accelerate the defrosting process. (This refrigerator has
adopted automatic defrosting system.)
■ Do not use electrical appliances inside the refrigerator.
■ Do not block the space around the refrigerator.
■ Do not use ammable sprays, such as spray paint near
the refrigerator.
■ Do not store ammable sprays, such as spray paint in
the refrigerator.
■ In the case of failure of the refrigeration system, do not
touch the wall socket and use open ames.
Open the window and air out the room. Then ask a
service agent approved by SHARP for service.
Power cord, Plug, Socket
Read carefully the following rules to prevent electric
shock or re.
■ Make sure to protect the power cord from being
damaged during installation or moving. If the power
plug or cord is loose, do not insert the power plug.
■ Do not place multiple portable socket-outlets or portable
power supplies at the rear of the refrigerator.
■ Connect the power plug into the wall socket rmly and
directly. Do not use an extension cord or adapter plug.
■ Connect the power plug to the socket with the required
rated voltage.
■ Connect the earth pin to the earth terminal properly.
■ Do not touch the power plug with wet hands.
■ Disconnect from the main electricity supply by removing
the main plug from the socket.
Do not remove by pulling the power cord.
■ Dust deposited on the power plug may cause re.
Wipe it o carefully.
■ Pull out the plug if the refrigerator is not used for a long
time.
■ If the exible supply cord is damaged, it must be
replaced by service agent approved by SHARP in order
to avoid a hazard.
Installation
■ Do not install the refrigerator in a damp or wet location.
It may cause the damage to the insulation or electrical
leak. Dew may also appear on the outer cabinet and it
causes rust.
■ The refrigerator should be installed atly and rmly on
the oor.
In use
■ Do not store volatile and ammable materials such
as ether, petrol, propane gas, aerosol cans, adhesive
agents and pure alcohol etc. These materials are easy
to explode.
■ Do not store temperature-sensitive products such as
pharmaceutical products in the refrigerator.
There are high risks of changes in product quality .
■ Do not attempt to change or modify this refrigerator.
This may result in re, electric shock or injury.
■ Do not place any object on the top of refrigerator.
If the object falls down from the top, it may cause injury.
■ This appliance can be used by children aged from
8 years or above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way or understanding the hazards involved. Children
shall not play with the appliance. Cleaning and user
maintenance shall not be done by children without
supervision.
Warning
This means that there are high risks of death or serious injury.
Caution
This means that there are high risks of material damage or personal injury.
Caution
Fire marks means this refrigerator has risk of re accident.
WARNING
(B979).indb 3(B979).indb 3 2020/04/06 17:33:542020/04/06 17:33:54
4
Care and Cleaning
■ Unplug the refrigerator rst to prevent electric shock.
■ Do not splash water directly on the outer cabinet or the
interior. This may lead to rusting and deterioration of
the electrical insulation.
Trouble
■ If you smell something burnt, pull out the power plug
immediately. Then ask a service agent approved by
SHARP for service.
■ In case of gas leak, ventilate the area by opening a
window. Do not touch the refrigerator or the power
socket.
Disposal
■ Ensure that the refrigerator presents no danger to
children while being stored for disposal. (e.g. remove
the magnetic door seals to prevent child entrapment.)
■ This refrigerator should be disposed of appropriately.
Take the refrigerator to a professional recycling plant
for ammable refrigerant and insulation blowing gases.
Transportation
■ When you install or move your refrigerator, use a curing
mat to protect the oor from being damaged.
■ Carry the refrigerator by holding the handles located on
the rear and bottom side. If you lift up the refrigerator
improperly, it may cause injury.
Caution
rear
bottom
In use
■ Do not touch the compressor unit or its peripheral parts,
as they become extremely hot during operation and the
metal edges may cause injury.
■ Do not touch foods or metal containers in the freezer
compartment with wet hands. This may cause frostbite.
■ Do not place bottled drinks and cans in the freezer
compartment.
Especially when “Express cool” is in operation, there is
a high risk that glass bottles may burst.
■ Do not use other than potable water to make ice cubes.
■ Do not open or close the door when other people put
a hand near the door. There is a risk that the other
people may get their ngers caught in the door.
■ Do not put oversized object in the pockets of the door.
If the object falls down from the pockets, it may cause
injury.
(B979).indb 4(B979).indb 4 2020/04/06 17:33:542020/04/06 17:33:54
5
1
Keep adequate ventilation space around the
refrigerator.
• The gure shows the
minimum required
space for installing
the refrigerator. The
amount of space around
the refrigerator aects
the amount of power
consumption.
• Insucient spacing
will decrease cooling
eciency and increase energy consumption. This
may reduce the life of the unit and void warranty.
• If using the refrigerator in the smaller space
dimension than gured, it may cause temperature
rise in the unit, loud noise and failure.
• The space between the rear of the refrigerator and
the wall should be 60mm or more, and less than
75mm.
If the space is wider than 75mm, you may get
injured by touching the compressor and its
peripheral parts which are extremely hot during the
operation.
Overall space required in use
Installation
Free standing type
90mm
or more
60mm
or more
60mm
or more
1180 mm
1500 mm
2
Use the two front adjustable feet to place the
refrigerator atly and rmly on the oor.
3
When right and left doors are not properly aligned,
adjust using the adjustable feet.
Adjustable foot
Note
• Position your refrigerator so that the plug is accessible.
• Keep your refrigerator out of direct sunlight and do not
place next to heat generating appliance.
• Do not place your refrigerator directly on the ground.
Insert suitable stand such as wooden board under the
refrigerator.
• When you insert the power plug with the door opened,
door alarm sounds but it is not abnormal. This sound
stops after closing the door.
Before using your refrigerator
Clean the inside parts with a cloth soaked in warm
water.
If soapy water is used, wipe it o thoroughly with water.
When the left door is
raised.
When the right door is
raised.
Lower the foot
at right side.
Lower the foot
at left side.
(Until the adjustable foot on the
other side is slightly o-ground.)
4
Remove the 4 screws of the lower part of the cabinet
and use these screws to set the foot cover. (The foot
cover is packed inside the refrigerator compartment.)
Screw
(4 screws)
Screw
Foot cover
5
Connect the power plug to a 230/240 volt. 10 amp.
power point.
(B979).indb 5(B979).indb 5 2020/04/06 17:33:562020/04/06 17:33:56
6
1. Door pocket
(3 pcs)
2. Refrigerator shelf
(2 pcs)
3. Shelf
4. Bottle pocket (left)
5. Fruit and vegetable crisper
The cover of the fruit and vegetable
crisper opens as the case is pulled.
6. Freezer case (small)
(3 pcs)
7. Freezer case (large)
(2 pcs)
8. Caster
(4 pcs)
The casters allow the refrigerator
to move back and forth.
9. Adjustable foot
(2 pcs)
10. Foot cover
11. Hybrid cooling panel
The panel cools the refrigerator compartment
indirectly from the rear. In this way, food is cooled
gently without being exposed to cold air ow.
12. Light
13. Utility pocket
14. Egg holder
15. Bottle pocket (right)
To store large-size bottles, move
the partition all the way back.
16. Fresh case (upper)
17. Fresh case (lower)
18. Ice cube maker
(2 pcs)
1) Do not overll this tray with water.
Otherwise the ice cubes will join
together when frozen.
2) When ice cubes are made, turn the
lever clockwise to put the ice into
the ice cube box.
Description
19. Ice cube box
(2 pcs)
Note
To prevent the ice cube box from being damaged, do
not pour oil into the box or make ice in it.
20. Magnetic door seal
(4 pcs)
21. Control panel
Deodorising unit
Deodorising catalyst is installed on the routes of cold air.
There is no need to operate and clean.
If you wish to store large items within
your freezer
You may remove case or shelves as below gure.
Partition
How to remove
To remove the partition, pull it to
the front with pushing the claw.
Partition
Push
How to set
Insert the four projections into
the upper parts.
Lever
Ice cube box
Claw
16
15
5
2020
20
20
7
7
6
6
88
9
9
10
11 12 12
13
14
18
19
1
17
1
2
1
3
4
21
Cover
Casters
(B979).indb 6(B979).indb 6 2020/04/06 17:33:562020/04/06 17:33:56
7
Useful modes
As for the operations, refer to chapter “Control panel”.
Freezer
compartment
Fresh case
Extra cool
Express freezing
Express cool
Extra cool Express freezing Express cool
Feature This mode is to cool
beverages or foods to
ice-cold.
Note : Food with high-
moisture may freeze.
This mode speeds up
the time to freeze food.
This mode is to cool beverages or foods quickly.
Point of use Fresh case Freezer compartment Freezer compartment
Caution : Do not place glass bottles. There is a
high risk that they may burst.
Operating time 6 hours *
1
2 hours *
1
30 minutes
• This mode ends automatically.
• The alarm does not sound.
• This mode ends automatically.
• The alarm sounds.
To stop the alarm *
2
After the operation
completed
• There is no need for taking beverages or
foods out.
• Be sure to take the beverages and foods out when
the alarm sounds.
• If the beverages and foods are left in the freezer
compartment over approximately 30 minutes, they
may freeze.
At the time of
power failure
during the
operation
• This mode is automatically cancelled. • This mode is automatically restarted from the
previous state at the time of re-power.
Press enter button.
*
1
It may take more time to complete if the operation
overlaps with defrosting. This mode starts after
defrosting is completed.
*
2
If you do not stop the alarm, it sounds 30 minutes
continuously.
Note
• Extra cool, Express freezing and Express cool are not
available at the same time while one of the modes is in
operation.
• Avoid opening the door as much as possible during the
operations of these modes.
Plasmacluster
Use this feature when you want to keep the inside of the
refrigerator clean.
The ionizer inside your refrigerator releases clusters
of ions, which are collective masses of positive and
negative ions, into the refrigerator compartment.
These ion clusters inactivate airborne mold fungus.
Note
• There may be a slight odor in the refrigerator. This
is the smell of ozone generated by the ionizer. The
amount of ozone is minimum and quickly disappears in
the refrigerator.
mold
fungus
(B979).indb 7(B979).indb 7 2020/04/06 17:33:572020/04/06 17:33:57
8
Control panel
Select
button
Switching
button
Enter button
Controlling temperature
Icon Meaning Default setting
Refrigerator
compartment
3°C
Freezer compartment -18°C
Useful modes
Icon Meaning Default setting
Extra cool
OFF
Express freezing
Express cool
Plasmacluster
Additional modes
Indicator Meaning Default setting
Door alarm
ON
Sound of button
operation
Note
• When you press one of the buttons,
all icons ash once and show the
standby display. If the refrigerator
stops because of power failure, the
modes except for Extra cool and
Express freezing function the same
way as before at the time of re-
power.
• Operation is invalid while
the freezer door is open.
• Mode icons or indicators
in operation light up on the
standby display.
When Express cool is in
operation, the icon ashes
on the standby display.
• When there is no operation
for approximately
1 minute, the display
returns to the standby
display automatically.
The standby display turns o if
there is no operation for another
1 minute.
Turn-on state
Operations of useful modes
Display
1
Select the mode icon.
(e.g. Extra cool)
2
Select on/o.
(o)
3
Complete the setting.
(Beep)
Mode icon turns
on.
Mode icon turns
o on the standby
display.
“Express cool”only
Complete the setting by pressing
for 3 seconds or more.
(Beep, Beep, Beep)
“Express cool”
only
(Flashing)
Flashing
When press button, the icons
change in the order shown as below.
:
Standby display
Useful modes
Operation of additional modes
Summary Cancel operation Display
Door alarm
• When the refrigerator door is left open for over 1 minute,
door alarm sounds once, and again after 1 minute.
• If the door is left open for approx. 3 minutes, the alarm
sounds continuously.
• The alarm stops after the door is closed.
Press
and simultaneously
for 3 seconds or more.
(Beep, Beep, Beep)
The indicator
turns o.
Sound
of button
operation
• When you want to switch o button operation sound.
Press
and simultaneously
for 3 seconds or more.
(Beep, Beep, Beep)
The indicator
turns o.
Note • When you want to turn on the additional mode, follow the same step again. (The indicator turns on.)
(B979).indb 8(B979).indb 8 2020/04/06 17:33:592020/04/06 17:33:59
9
Advanced Setting of Refrigerator/Freezer compartment
The temperature of the refrigerator compartment and freezer compartment can be adjusted in steps of 0.5 °C by following
the steps a to c below.
a.
After the step 1 of “Basic operations”,
press
for 3 seconds or more.
The current preset temperature returns to the “Default setting”
(The display is indicated as the picture on the right.)
b.
Press or and set the temperature.
c.
Complete the setting. (Same as step 3 of “Basic operations”.)
Follow the steps a to c again if you want to adjust the temperature in steps of
1°C.
Refrigerator
compartment
Freezer
compartment
Beep beep beep
switch
Controlling temperature
The refrigerator controls its temperature automatically. However, you can adjust the temperature as below.
How to check the current
temperature setting
Press button to select or icon.
Setting of Refrigerator / Freezer
compartment
Freezer compartment
: Adjustable between -13°C and -21°C in steps of 1°C
Refrigerator compartment
: Adjustable between 0°C and 6°C in steps of 1°C
Default setting
Refrigerator compartment Freezer compartment
Basic operations
Display
1
Select or
icon.
Refrigerator
compartment
Freezer
compartment
2
Set the
temperature.
3
Complete
the setting.
(Beep)
Flashing
Flashing
(up)
(down)
When press button, the icons
change in the order shown as below.
Standby display
Controlling temperature
:
Flashing
The temperature that indicated on the control panel is
not the exact temperature inside.
(B979).indb 9(B979).indb 9 2020/04/06 17:34:002020/04/06 17:34:00
10
IN
OUT
Fruit / Vegetables
Fruit and vegetables should be loosely enclosed in a
plastic material e.g. wrap, bags (do not seal) and placed in
the fruit and vegetable crisper to minimise moisture loss.
Dairy Products & Eggs
• Most dairy products have their best-before date on
the outer packaging which informs the recommended
temperature and shelf life of the foods.
• Eggs should be stored in the Egg holder.
Meats / Fish / Poultry
• Place on a plate or a dish and cover with paper or
plastic wrap.
• For larger cuts of meat, sh, or poultry, place to the rear
of the shelves.
• Ensure all cooked food is wrapped securely or placed in
an airtight container.
* Notes for fresh food:
- Fresh food (securely wrapped) should be stored in
limited time to prevent spoilage and badly aecting
other stored foods.
For best freezing
• Quality of foods should be fresh.
• Freeze small quantities of food at a time in order to
freeze them quickly.
• Food should be properly sealed or covered tightly.
• Place foods in the freezer evenly.
• Label bags or containers to keep an inventory of
freezing food.
Advice for preventing dew or frost
inside the refrigerator
• Keep the door securely closed. If the food falls down,
it may cause a gap between the cabinet and the door.
Move it back to the shelf or the pocket.
• Food with high-moisture should be stored in an airtight
container or sealed tightly.
Note
• Evenly place the food on the shelves to allow the cooling
air to circulate efciently.
• Hot foods should be cooled before storing. Storing
hot foods increases the
temperature in the unit and
the risk of food spoilage.
• Opening the door for long
periods can cause a signicant
increase of the temperature
in the compartments of the
appliance.
• Do not block the outlet and
inlet of the cool air circulating
circuit with foods or containers;
otherwise the food will not be
evenly cooled throughout the
refrigerator.
Do not place food directly in front of cold the air outlet.
This may lead to the food freezing.
Refrigeration reduces the rate of food spoilage.
Ensure that the food is of the freshest possible quality to maximize the shelf life of perishable foods.
The following is a general guide to help promote longer food storage.
Storing food
Vegetables are improper ●
in this case. They may
be frozen.
Dairy products
Small foods
Eggs etc.
Meat, Fish, Poultry etc.
Fruits, Vegetables
Small foods
Juice etc.
Bottles etc.
Frozen foods
(Small size)
Frozen foods
(Big size)
Bottles etc.
(Big size)
(B979).indb 10(B979).indb 10 2020/04/06 17:34:012020/04/06 17:34:01
11
■ Keep the ventilation space as much as possible around the refrigerator.
■ Keep your refrigerator out of direct sunlight, and do not place it next to a heat generating appliance.
■ Avoid opening the door as much as possible.
■ Hot foods should be cooled before storing.
■ Place the food evenly on the shelves to allow the cool air to circulate efciently.
Tips for saving energy
Important
To prevent cracks on the inside surfaces and plastic
components, follow these tips.
• Wipe out food oil that has adhered to plastic parts.
• Some household chemicals may cause damage, so use
only diluted washing-up liquid (soapy water).
• Wipe any spills from the refrigerator immediately as acid
or alkaline in the food can cause cracking and staining
of plastic parts.
Cleaning
For hygienic reasons, make sure to do following
things regularly.
■ Remove the accessories (e.g. shelves) from the cabinet
and the door. Wash them with warm soapy dishwashing
water. After that, rinse them in clean water and dry.
(Only fruit and vegetable shelf is not removable.)
How to remove the fruit and vegetable crisper
cover
■ Clean the inside with a cloth soaked in warm soapy
dishwashing water. Then, use cold water to wipe o
soapy water thoroughly.
■ Wipe the exterior with a soft cloth each time it gets
dirty.
■ Clean the Magnetic door seal with a toothbrush and
warm soapy dishwashing water.
■ Wipe the control panel with a dry cloth.
Note
• Do not use hot water, household cleaning powders,
creams or spray-on cleaning products, or any other
cleaning products such as mineral turpentine,
methylated spirits, thinners, petrol etc. These may
damage your refrigerator and may void any warranty.
• If the power supply is disconnected, please wait at least
5 minutes before re-connecting power.
• The glass shelves weigh approximately 3 kg each. Hold
them rmly when removing from the cabinet and carry.
• Do not drop objects inside the refrigerator or strike the
inner wall. This may cause cracks to the inner surface.
Before transporting
Wipe up water in the evaporating pan. Before wiping
up the water, wait more than 1 hour after pulling out the
power plug because the refrigeration cycle equipment
is extremely hot.
(The evaporating pan is located on the rear of the
product.)
Switching off your refrigerator
If the refrigerator needs to be switched o for an
extended period, the following steps should be taken to
reduce the growth of mould:
1. Remove all food.
2. Remove the power plug from the power point.
3. Clean and dry the interior thoroughly.
4. Ensure that all the doors are wedged open slightly
for air circulation.
Defrosting
Defrosting is automatically operated by a unique energy
saving system.
When the compartment light is blown
Contact the service agent approved by SHARP to
replace the light. The light is not to be replaced other
than by a qualied service personnel.
Care and cleaning
Evaporating pan
Projection
portion
Hole
Note
Remove the cover
carefully not to break
the projection.
(B979).indb 11(B979).indb 11 2020/04/06 17:34:012020/04/06 17:34:01
12
Before calling for service, check the following points.
Problem Solution
The outside of the cabinet is
hot when touched.
It is normal. The hot pipe is in the cabinet in order to prevent
dew generation.
The area around the door
handle of the refrigerator is
hot when touched.
It is normal.
The heater to prevent dew generation is inside the door.
When there is refrigerator
noise.
It is normal for the refrigerator to make the following sounds.
• Loud noise is made by the compressor when its operation starts
-- Sound becomes quieter after a while.
• The compressor makes loud noise once a day.
-- Operating sound is made immediately after automatic defrost operation.
• Sound of owing uid (gurgling sound, zzing sound)
-- Sound of refrigerant owing in pipes (sound may become louder from time to time).
• Cracking or crunching sound, squeaking sound
-- Sound produced by expansion and contraction of inner walls and internal parts during
cooling.
Frost or dew appears inside
or outside the refrigerator.
This may occur in one of the following cases. Use a wet cloth for wiping frost and a dry
cloth for wiping dew.
• When the ambient humidity is high.
• When the door is frequently opened and closed.
• When foods containing plenty of moisture are stored. (Wrapping is required.)
The foods in the refrigerator
compartment freeze.
• Is the refrigerator operated for a long time with refrigerator temperature control set at
0°C?
-- Change the temperature control back to around 3°C.
• Is the refrigerator operated for a long time with freezer temperature control set at -21°C?
-- Change the temperature control back to around -18°C.
• If ambient temperature is low, foods may freeze even if the refrigerator compartment is
set at 6°C.
Odours in the compartment. • Wrapping is required for the foods with strong odours.
• Deodorising unit cannot remove all odours.
If door alarm does not stop. • The alarm stops after the door is closed.
For Australia
If you encounter problems with this product, or if it fails to perform to your expectations, make sure to contact our
After Sales Support Centre on (AU) 1300 886 649
Customer Helpline: (AU) 1300 886 649
Email: [email protected]
For an electronic copy of this manual, please contact our after sales support centre.
For New Zealand
If you still require service contact your SHARP Approved Service Centre.
SHARP Approved Service Centre locations or an electronic copy of this manual can be found
in the Support area of our website:
New Zealand : https://www.sharp.net.nz
Before you call for service
(B979).indb 12(B979).indb 12 2020/04/06 17:34:012020/04/06 17:34:01
13
Specication
SJ-XP624FB
Rated voltage (V~) 220 - 240
Rated frequency (Hz) 50
Rated current (A) 1.7 - 1.8
Rated input of heating systems (W) 173 - 206
Defrosting input (W) 173 - 206
Climate class T
Refrigerant R600a
Charge (g) 70
Insulation blowing gas Cyclo pentane
Rated storage volume (L) 556
Group 5B
Net weight (kg) 100
Overall dimensions
(mm)
Height 1720
Width 892
Depth 771
Dimensions with
handles, protrutions
(mm)
Height 1720
Width 892
Depth 771
* AS/NZS 4474:2018
(B979).indb 13(B979).indb 13 2020/04/06 17:34:012020/04/06 17:34:01
14
Congratulations on Your Purchase!
This Sharp product is warranted against faults in material and manufacture for the
period as stated in the table below.
If service is required during the warranty period, please contact your nearest Sharp
Approved Service Centre. These repairs would be carried out at no charge to the
owner, subject to the conditions specified herein.
This warranty does not extend to defects or injuries caused by or resulting from causes
not attributable to faulty parts or the manufacture of the product, including but not
limited to, defect or injury caused by or resulting from misuse, abuse, neglect, lack of
maintenance, accidental damage, improper voltage, liquid spillage, vermin infestation,
software, or any alterations made to the product which are not authorised by Sharp.
Please retain your sales documentation, as this should be produced to validate a
warranty claim. This warranty is in addition to and in no way limits, varies or excludes
any implied rights and remedies under any relevant legislation in the country of sale.
WARRANTY PERIODS
Refrigerator 24 months
IMPORTANT NOTICE: This warranty applies only to products sold in Australia & New Zealand
WARRANTY
Consumer Electronic Products
Australian customers: Our goods come with guarantees that cannot be excluded
under the Australian Consumer Law. You are entitled to a replacement or refund
for a major failure and for compensation for any other reasonably foreseeable
loss or damage. You are also entitled to have the goods repaired or replaced
if the goods fail to be of acceptable quality and the failure does not amount
to a major failure. The criteria of a major failure is defined in the Australian
Consumer Law. Should you require any assistance with a major failure please
contact Sharp Customer Care.
This warranty does not cover transportation to and from the Sharp Approved Service
Centre. Goods presented for repair may be replaced by refurbished goods of the same
type rather than being repaired. Refurbished parts may be used to repair the goods.
The repair of your goods may result in the loss of user generated data, please ensure
that you have saved this data elsewhere prior to repair.
FOR LOCATION ENQUIRIES WITHIN
NEW ZEALAND
REGARDING YOUR LOCAL
SHARP CORPORATION OF NEW ZEALAND LIMITED
VISIT OUR WEBSITE AT
SHARP CUSTOMER SERVICES
TELEPHONE: 09 573 0111
FACSIMILE: 09 573 0113
SHARP APPROVED SERVICE CENTRE
www.sharp.net.nz
CONTACT YOUR SELLING DEALER/RETAILER
OR CALL
FOR LOCATION ENQUIRIES WITHIN
AUSTRALIA
REGARDING YOUR LOCAL
SHARP APPROVED SERVICE CENTRE
Customer service helplines
(calling within Australia)
Monday - Saturday, 9am - 6pm
Open Monday to Saturday except on public holidays.
Distributed by
Tempo (Aust) Pty Ltd
PO Box 6056 Frenchs Forest DC 2086 Australia
1300 886 649
FOR LOCATION ENQUIRIES WITHIN
NEW ZEALAND
REGARDING YOUR LOCAL
SHARP CORPORATION OF NEW ZEALAND LIMITED
VISIT OUR WEBSITE AT
SHARP CUSTOMER SERVICES
TELEPHONE: 09 573 0111
FACSIMILE: 09 573 0113
SHARP APPROVED SERVICE CENTRE
www.sharp.net.nz
CONTACT YOUR SELLING DEALER/RETAILER
OR CALL
FOR LOCATION ENQUIRIES WITHIN
AUSTRALIA
REGARDING YOUR LOCAL
SHARP APPROVED SERVICE CENTRE
Customer service helplines
(calling within Australia)
Monday - Saturday, 9am - 6pm
Open Monday to Saturday except on public holidays.
Distributed by
Tempo (Aust) Pty Ltd
PO Box 6056 Frenchs Forest DC 2086 Australia
1300 886 649
(B979).indb 14(B979).indb 14 2020/04/06 17:34:012020/04/06 17:34:01
(B979).indb 15(B979).indb 15 2020/04/06 17:34:012020/04/06 17:34:01
TINS-B979CBRZ 20EK TH
1
Printed in Thailand
SHARP CORPORATION
OSAKA, JAPAN
(B979).indb 16(B979).indb 16 2020/04/06 17:34:012020/04/06 17:34:01
