1080P Analog HDCVI Bullet Camera
AMC1080BC36-B
User Manual
Version 2.0.2
2
Contents
Welcome ................................................................................................................................................................ 3
Important Safeguards and Warnings ....................................................................................................................... 3
Product Introduction .............................................................................................................................................. 4
Features ................................................................................................................................................................. 4
Installation ............................................................................................................................................................. 4
Connection ............................................................................................................................................................. 5
Technical Specifications .......................................................................................................................................... 5
FCC Statement ....................................................................................................................................................... 6
IC Warning Statement ............................................................................................................................................ 7
Appendix A: Toxic or Hazardous Materials or Elements ........................................................................................... 7
3
Welcome
Thank you for purchasing an Amcrest camera!
This user manual is designed to be a reference tool for the installation and operation of your
camera. Here you can find information about the camera’s features and functions, as well as
information to aid in troubleshooting.
Many of the setup and installation sections have corresponding videos on YouTube. To access
the setup videos, please go to http://amcrest.com/videos.
For access to other support related materials and information, please visit us at
http://amcrest.com/support.
To contact Amcrest support, please do one of the following:
Visit http://amcrest.com/contacts and use the email form.
Call Amcrest Support using one of the following numbers:
Toll free: (888)212-7538
International Callers (Outside of the US): +1-713-893-9656
USA: 713-893-8956
Canada: 437-888-0177
UK: 203-769-2757
Email Amcrest Customer Support: support@amcrest.com
Important Safeguards and Warnings
1. Electrical Safety
All installation and operation should conform to your local electrical safety codes. The product
must be grounded to reduce the risk of electrical shock. We assume no liability or responsibility
for any fires or electrical shock caused by improper handling or installation.
2. Transportation Security
Heavy stress, violent vibrations, and excess moisture should not occur during transportation,
storage, and installation of the device.
3. Installation
Handle the device with care. Do not apply power to the camera before completing installation.
Do not place objects on top of the camera.
4. Repair Professionals
All the examination and repair work should be performed by a qualified service engineer. We
are not liable for any problems caused by unauthorized modifications or user attempted repair.
5. Environment
The camera should be kept in a cool, dry place away from direct sunlight, flammable materials,
explosive substances, etc. This product should be transported, stored, and used only in the
specified environments as stated above. Do not aim the camera at a strong light source as it
4
may cause overexposure of the picture or affect the longevity of the camera’s sensors. Ensure
the camera is in a well-ventilated area to prevent overheating.
6. Operation and Maintenance
Do not touch the camera sensor or lens directly. To clean dust or dirt off the lens, use an air
blower or a microfiber cloth.
7. Accessories
Be sure to use only the accessories recommended by the manufacturer. Before installation,
please open the package and check to make sure that all the components are present. Contact
the retailer that you purchased from or Amcrest directly if anything is broken or missing in the
package.
Product Introduction
This series of camera is adopted with CMOS image sensors that provide high performance, high
megapixel resolution that supports 1080P video. Transmission distances can range more than
1640ft @ 1080P. This series can also support CVI/TVI/AHD/Analog output as well as recognize
high speed, long distance, and real time video transmissions.
Features
• 1/2.7” 2Megapixel CMOS 1080P@30fps
• 2D/3D DNR, Smart IR Control
• DC12V, 2.0A
Installation
Before physically installing your camera, make sure the mounting surface can support up to 3x
the weight of the camera.
5
1) Locate the position in which you would like to place your camera and using the base of the
camera, mark the 4 installation holes with a marker onto the mounting surface. These holes will
be used to drill the holes needed to mount your camera.
2) Using a drill bit that is the same diameter or slightly smaller diameter than the included
drywall wall anchors, drill the 4 holes and insert the wall anchors into the holes.
Note: The wall anchors should be in the same bag as the screws and a designed to secure the
screws onto the mounting surface.
3) Attach the power cable and BNC cabling to the camera. (If you are running the cables
through a mounting surface, use a 1” paddle bit to bore a hole for the cables.)
4) Place the base of the camera on the wall anchors lining the holes to the mounting surface.
Then, using a Phillips head screwdriver, secure the screws and base of the camera to the
mounting surface.
Note: To adjust the camera, you can loosen the adjustment screws near the base of the
camera. Adjust the position as desired and tighten when complete.
Connection
To connect your camera to your DVR, please follow the steps provided below:
Step 1: Connect a BNC (coaxial) cable to the video out connection of your camera.
Step 2: Connect the male end of the DC power connector of the BNC (coaxial) cable to the
female end of the power connector of the camera.
Step 3: Connect the BNC (coaxial) cable to a video out channel on the back of your DVR.
Step 4: Connect the male end of the DC power connector of the power adapter to the female
end of the power connector of the BNC (coaxial) cable. Plug in the power adapter to apply
power to the camera.
For more information on the installation process described, refer to the image below for more details.
Technical Specifications
Model
AMC1080BC36-B
Camera
Image Sensor
1/2.7” 2Megapixel CMOS
Effective Pixels
1920 (H) x 1080 (V)
Electronic Shutter
1/30s ~ 1/100,000s
Video Frame Rate
30fps@1080P
Synchronization
Internal
Min. Illumination
0.02Lux/F2.0, 0Lux IR on
Video Output
1CH BNC HD Video Output / CVBS SD Video Output
Camera Features
Night Vision
98 Feet, Smart IR
Backlight Compensation
DWDR
Day/Night
Auto (ICR) / B&W / Color
Noise Reduction
2D
Lens
6
Focal Length
3.6mm
Viewing Angle
90°
Mount Type
M12
General
Power Supply
DC12C±25%
Power Consumption
Max 4W
Working Environment
-40°F ~ 140°F / Less than 95% RH (no condensation)
Transmission Distance
Over 1640ft via 75-3 coaxial cable
Ingress Protection
IP67
Dimensions (W x D x H)
Φ2.75” x 6.5”
Weight
0.77 lbs.
Material
Metal (body) + Plastic (sunshield)
FCC Statement
1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
2. The user’s manual or instruction manual for an intentional or unintentional radiator shall
caution the user that changes, or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate the equipment. In cases where the
manual is provided only in a form other than paper, such as on a computer disk or over the
Internet, the information required by this section may be included in the manual in that
alternative form, provided the user can reasonably be expected to have the capability to access
information in that form.
3. (b) For a Class B digital device or peripheral, the instructions furnished the user shall
include the following or similar statement, placed in a prominent location in the text of the
manual: NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-- Consult the dealer or an experienced radio/TV technician for help.
4. RF exposure warning: This equipment must be installed and operated in accordance with
provided instructions and the antenna(s) used for this transmitter must be installed to provide
a separation distance of at least 20 cm from all persons and must not be co-located or
operating in conjunction with any other antenna or transmitter. End-users and installers must
7
be provided with antenna installation instructions and transmitter operating conditions for
satisfying RF exposure compliance.
IC Warning Statement
This device complies with Industry Canada’s license-exempt RSSs. Operation is subject to the
following two conditions:
(1) This device may not cause interference; and (2) This device must accept any interference,
including interference that may cause undesired operation of the device. Le présent appareil
est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence.
L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire
de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi,
même si le brouillage est susceptible d'en compromettre le fonctionnement. This equipment
complies with IC RSS-102 radiation exposure limits set forth for an uncontrolled environment.
This equipment should be installed and operated with a minimum distance of 20cm between
the radiator and any part of your body. Pour se conformer aux exigences de conformité CNR
102 RF exposition, une distance de séparation d'au moins 20 cm doit être maintenue entre
l'antenne de cet appareil ettoutes les personnes.
Appendix A: Toxic or Hazardous Materials or Elements
Component Name
Toxic or Hazardous Materials or
Elements
Pb
Hg
Cd
Cr VI
PBB
PBDE
Sheet Metal (Case)
○
○
○
○
○
○
Plastic Parts (Panel）
○
○
○
○
○
○
Circuit Board
○
○
○
○
○
○
Fastener
○
○
○
○
○
○
Wire and Cable/Ac
Adapter
○
○
○
○
○
○
Packing Material
○
○
○
○
○
○
Accessories
○
○
○
○
○
○
O: Indicates that the concentration of the hazardous substance in all homogeneous materials in
the parts is below the relevant threshold of the SJ/T11363-2006 standard.
X: Indicates that the concentration of the hazardous substance of at least one of all
homogeneous materials in the parts is above the relevant threshold of the SJ/T11363-2006
standard. During the environmental-friendly use period (EFUP) period, the toxic or hazardous
8
substance or elements contained in products will not leak or mutate so that the use of these
(substances or elements) will not result in any severe environmental pollution, any bodily injury
or damage to any assets. The consumer is not authorized to process such kind of substances or
elements, please return to the corresponding local authorities to process according to your
local government statutes.
O: Indicates that the concentration of the hazardous substance in all homogeneous materials in
the parts is below the relevant threshold of the SJ/T11363-2006 standard.
X: Indicates that the concentration of the hazardous substance of at least one of all
homogeneous materials in the parts is above the relevant threshold of the SJ/T11363-2006
standard. During the environmental-friendly use period (EFUP) period, the toxic or hazardous
substance or elements contained in products will not leak or mutate so that the use of these
(substances or elements) will not result in any severe environmental pollution, any bodily injury
or damage to any assets. The consumer is not authorized to process such kind of substances or
elements, please return to the corresponding local authorities to process according to your
local government statutes.
Note:
• To view setup videos for many of the steps outlined in this guide, go to http://amcrest.com/videos
• This user manual is for reference only. Slight differences may be found in the user interface.
• All the designs and software here are subject to change without prior written notice.
• All trademarks and registered trademarks mentioned are the properties of their respective owners.
