CUSTOMER SERVICE:
1800 663 866 (AUS) 0800 666 783 (NZ)
M2R
FLOOR STEAM CLEANER
WITH ULTRA DRY STEAM
Floor Steam Cleaner with Frontal Steam Jet
INSTRUCTION MANUAL
Before using this product, please read the instructions and keep it for future references
Model #: SC1Z1 AUS, NZ
SAVE THESE INSTRUCTIONS
IMPORTANT SAFE T
2
Safety Instructions
When using an electrical appliance, basic safety precau-
tions should always be observed, including the following:
Read all instructions before using this appliance.
WARNING:
1. This appliance is authorized for household/domestic use only.
steamer in water or other liquids.
when used by or near children. Do not leave Steamer unattended. Always
unplug unit when not in use.
4. Use only as described and for the uses described in this manual. Use only
manufacturer’s approved and supplied parts and accessories. Use of other
accessories is not recommended and will void the warranty.
5. Always make sure the Handle Assembly is in the upright position before plug
-
ging in or unplugging. Keep cord away from heated surfaces (e.g., cooking
surfaces), and sharp edges and corners.
6. Do not use if power cord or plug has been damaged, or if any part of appli
-
ance has been dropped, damaged, left outdoors, or dropped in water. Do
not attempt to disassemble or repair appliance. Return it to manufacturer or
an authorized service center for examination or repair.
7. Do not wrap cord too tightly a
round appliance. Never carry by the cord, or
yank to disconnect from an outlet. To unplug, always grasp plug to remove
from outlet – do not pull on cord.
8. Do not handle cord or appliance with wet hands or without shoes on.
9. Look closely at steamer and follow all labels and marking instructions.
10. Do not put any objects into openings. Do not use with any opening blocked.
openings and moving parts.
Always turn the Boiler Cap slowly to open the water tank – this will allow any
remaining steam to escape gradually.
13. Use caution while emptying the appliance. Contact with hot water or steam
may cause burns.
14. Be sure Boiler Cap is (and remains) closed and do not open during use.
15. Never use cleaning solutions, perfumes, oils or other chemical substances
other than tap or distilled/demineralized water in the Steamer. Use of
chemicals may damage Steamer and will void the warranty.
16. When in use, never turn the appliance on its side. Remove the plug from the
socket-outlet before cleaning or maintaining the appliance. Do not direct
steam at people, animals or other electrical equipment (i.e, inside an oven).
17. Do not operate around flammable or combustible liquids such as gasoline
or in areas where fumes may be present.
SAVE THESE INSTRUCTIONS
FE TY INSTRUCTIONS
3
Safety Instructions
18. The Steamer is not intended for space heating purposes.
19. To reduce the likelihood of circuit overload, do not operate another high
wattage appliance on the same circuit. Plug in to a standard (220-240V,
50/60Hz) electrical outlet.
ATTENTION: This appliance is equipped with a 3-prong grounded power
cord. Insert only into a 3-prong grounded electrical outlet. Do not try to
remove the contacts of the grounded connection.
20. Do not use extension cords or outlets with inadequate voltage. Use only
heavy duty, high-rated extensions cords.
21. Store appliance indoors in a cool, dry place.
22. If appliance or supply cord is damaged, it must be repaired by
manufacturer in order to avoid safety issues to the operator.
23. This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given supervision or instruction
concerning use of appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the
appliance.
24. Read and follow all important notices in this guide.
Euroflex relieves itself of any liability for damages that are the
result of imp
roper use of the appliance or not in conformity with
what’s written in this instruction manual.
*IMPORTANT*
Please read all of the
instructions for use and
Important Safety
Instructions carefully.
Remove and discard all
packaging materials
and keep them out
of the reach of children.
CAUTIONS
•
Do not use your Floor Steamer without a Hard Surface Pad or Carpet Glide
& Pad attached to the system.
• Never leave your Floor Steamer in one spot on any surface for any period
of time. Make sure that the Floor Steamer Handle Assembly is in the full “UP
POSITION” when not in use - this turns the Steamer Off.
Save your back
No need to
press hard
The steamer
does the
work for you
Safety Informations in Digital Format: www.plastecs.it/warning
Attention: the photographs and/or drawings in this document are for illustrative purposes
only. Actual appliance and the accessories may vary due to product enhancement.
One (1) Floor Steamer
1
5
7
3
8
11
2
1 - Cord Winder
2 - Handle
3 - Metal Extension Tube
4 - Locking Clamp
5 - Measuring Cup (pre-marked)
6 - Filling Funnel
7 - Boiler Cap
8 - Steam Ready Indicator Light
(green)
9 - Power Indicator Light
(orange)
10 - Power Cord
11 - Steam Nozzles
12 - Carpet Pad
13 - Scrubbing Floor Pad (2)
14 - Carpet Glide
15 - Parking Pad
Product Features
4
Product Features
10
9
Technical Data
Adapter Input: 220-240V~, 50/60Hz
Cord Length: 7 meters/23 feet
Power: 120 0 watts
Boiler: Stainless Steel
Boiler Capacity: 0.6 liter/20 ounces
PARKING PAD
15
14
12
13
6
4
Before Use
5
Before Use
Assembly of Parts & Preparation of Steamer
Make sure all parts are in the box (see pg 4).
IMPORTANT: FOLLOW THESE INSTRUCTIONS CAREFULLY!
1
*IMPORTANT*
Frontal steam can only be generated when Extension Tube is in the
“Maximum Extension” position.
BE SURE EXTENSION TUBE IS FULLY
EXTENDED AND LOCKED IN PLACE FOR OPTIMAL STEAM OPERATION.
“Maximum Extension” Position
3. Snap the Locking Clamp closed, to
lock the Extension Tube in position.
Pull apart Extension Tube
A. Assemble Handle
After removing Handle Assembly from carton:
1. Pull Extension Tube apart until you see the lock opening
(hole) on the Tube.
2. Line up the peg on Locking Clamp with the
hole on Extension Tube and...
6
Before Use
Before Use
B. Attach Handle to Steamer
• Before starting, remove the self-tapping screw from the bottom of
Extension Tube.
• Insert the Handle Assembly into the Floor Steamer Base. Align
Arrow on Handle with Arrow on Base (as shown in Fig. A).
• Once inserted, twist Handle Assembly 90° clockwise (as shown
in Fig. B). Be sure Arrow on the Handle is aligned with Line/Lock Icon
on Base.
• Align the Handle Assembly
screw hole with the opening
in the steamer housing.
Secure the handle assembly
with self-tapping screw which
was removed from bottom of
Extension Tube (as shown in
Fig. C).
Fig. A
Fig. B
Fig. C
Front View Side View
90°
7
Before Use
ATTACHING CARPET GLIDE WITH CARPET PAD
place Carpet Pad on top of Carpet Glide. Hold
Floor Steamer over Carpet Glide and gently lower
the Steamer onto the Glide. Make sure the 4 clips
on Glide are around the outside of the Steamer
Base and using hands, attach the 4 clips of the
Carpet Glide to the Steamer Base.
USE ON HARDWOOD FLOORS –
For hardwood
Move Steamer forward and backward while
cleaning, carefully observing the amount of
steam used, as too much water could cause
damage.
Before Use
C. Attach Cleaning Pads to Steamer
WARNING:
Scrubbing Floor Pad or the Carpet Glide Accessory with Carpet Pad
when using your Floor Steamer. NEVER USE WITHOUT EITHER OF THESE
ATTACHMENTS AFFIXED TO THE MACHINE.
ATTACHING SCRUBBING FLOOR PAD
Scrubbing Floor Pad –
Place Scrubbing Floor Pad
center Scrub Strip facing down (and positioned to
match metal heat plate on bottom of Base-see“A”). .
Hold Floor Steamer about 2” above Pad and gently
place Floor Steamer on the Pad. Firmly press down
to assure Pad is adhered to the Floor Steamer.
A -
Heat Plate on
bottom of Base
provides additional
cleaning boost.
NOTE: See “Maintenance & Cleaning” for care and cleaning instructions for
IMPORTANT NOTE ABOUT LINOLEUM FLOORING
Steam can cause wax to be stripped from, and consequently damage, some
For some varieties of linoleum or vinyl floors the floor steamer is harder to push
forward and back.
Before Use
8
Before Use
*IMPORTANT*
• Do not overll the Boiler as excess water will be ushed out of the Boiler
before dry steam will emit.
• If re-lling the Boiler while Steamer has been in use, be sure to allow Steamer
to cool for at least 5 minutes and loosen Boiler Cap slowly to allow any
excess steam to escape before completely removing Cap. (See page 10,
“Relling Boiler During Use” for detailed instructions.)
D. Filling Boiler with Water
WARNINGS:
•
Carefully read all instructions before removing Boiler Cap.
•
Always unplug appliance before lling the Boiler.
•
The appliance must be unplugged after use and before performing
user maintenance on the appliance.
Follow these instructions to avoid overlling the Boiler:
• Be sure appliance is unplugged from the electri-
cal power outlet, and has
cooled for at least
5 minutes before lling with water.
• Make sure Handle Assembly is in the upright “off”
position.
Remove Boiler Cap by turning it counter-
clockwise.
• Pour in 600 mls of water using the
Measuring Cup and Filler Funnel provi-
ded – ll cup to the “200 ml” marking
three times.
Be careful not to overll the
Boiler.
Please note that excess water will be
ushed out during use if the Boiler is overl-
led, resulting in wet oors.
• Replace Boiler Cap by turning it clockwise. Do not tighten Boiler Cap
too much – nger tightening is sufcient to lock the steam in the Boiler.
If using cold water, heating time is about 3-5 minutes. If using warm
water, heating time is reduced.
*IMPORTANT*
Use ordinary tap water. Distilled or demineralized water is recommended if tap
water is too hard. DO NOT add detergents, perfumes, oils, or other chemical
substances to the Boiler. The product warranty will be null and void if anything
other than water is added to the Boiler.
100 ml
200 ml
A
N
T
(
M
a
x
100 ml
200 ml
A
N
T
I
B
A
K
(
M
a
x
)
9
Using Your Floor Steamer
Using Your Floor Steamer
Using Your Floor Steamer
2
B. Starting the Appliance
Cap is securely in place.
• Insert the plug into a-3 prong grounded
electrical outlet (orange Power Indicator
Light will illuminate).
•
Keeping the handle in the upright “Off”
position
, wait until the (green) Steam Ready
Indicator Light illuminates.
Once Boiler is lled and the green Steam
Ready Indicator Light glows, Steamer is ready to clean.
A. Using the Parking Pad
You can use the Parking Pad if the Steamer is warm or hot.
CAUTION
The Parking Pad is provided to prevent
a hot steamer resting on the same spot
for too long. ALWAYS place Floor Steamer
on the Parking Pad when not in use, or
while it is cooling before storage.
PARKING PAD
C. Using Steam
• To emit steam from the
underside of the Steamer,
simply pull the Handle
downwards.
• Return Handle to upright
position to stop steam.
Steamer can easily clean
most hard surfaces and
the underside alone.
NOTE: Some water may be emitted
PLEASE NOTE:
The green Steam Ready Indicator Light will turn
on and off during use. This is normal and not a fault.
Continued on next page
10
Using Your Floor Steamer
Using Your Floor Steamer
• To emit steam from the Steam
Nozzles, pull the trigger on
the Handle upward.
*IMPORTANT*
The Steam Nozzles are meant
to be used in steam “bursts”
and should never be used on
a sustained basis. The Steam
Nozzles will loosen especially
difcult debris and will assist in
cleaning hard to reach areas
such as oor edges.
NOTE:
Your Steamer will not need
relling for about 20-25 minutes
of usage.
The Floor Steamer will stop producing steam when the Boiler is
empty. When this happens unplug and store unit or rell with water
per instructions (below).
NOTE: If the Floor or Carpet Pad becomes too wet or too dirty, replace with a
clean, dry Pad and continue cleaning.
C. Using Steam (continued)
D. Relling Boiler During Use
When the Floor Steamer has run out of water, there will be no more
steam coming out of the unit. At this stage it is time to rell the Boiler.
Follow the relling instructions below.
*IMPORTANT*
The Floor Steamer has a Boiler that should not be overlled. To avoid the
potential for overlling, only rell the Boiler when it is completely run out of
water and only add 600ml. Always follow the practice of using the Floor Steamer
until it has run out of water and then rell 600ml only.
If oor cleaning is completed and water remains in the Boiler, the Floor Steamer
can be stored with the remaining water in the Boiler, there will be no harm done
to the unit. At the next cleaning session simply heat up the unit and use the
water already in the Boiler, then rell when empty.
Or alternatively at the next cleaning session, open the Boiler Cap when the unit
is still cold and pour out the water and then rell (if this alternative method is
used, it is recommended that only 500ml of water is added, because the unit
will not completely drain when the water is poured out from the Boiler).
WARNING:
Let Steamer cool 5 minutes before opening Boiler Cap.
Use care when opening Boiler Cap as it may still be hot and steam
may escape, causing burns. If Boiler is still hot, water may spurt out
during relling which can also cause burns.
11
remaetS roolF ruoY gnisU
Using Your Floor Steamer
•
Unplug the appliance from the electrical power outlet. This will stop
the Steamer from continuing to heat up.
• Once unplugged from the power outlet, place Handle in the “On”
position to release any residual steam and pressure from the Boiler.
• After all steam and pressure has been expressed from the Steamer,
return the Handle to the upright “Off” position.
• Slowly turn Boiler Cap counterclockwise. This will allow remaining
steam to escape.
•
Be sure Steamer has cooled 5 minutes before re lling with water.
The product warranty will be null and void if
anything other than water is added to the Boiler.
• Pour in 600 mls of water using the Measuring Cup
Cup to the 200 ml marking 3 times. Be careful
• Replace Boiler Cap by turning it clockwise. Do
-
the Boiler.
• Insert plug into 3-prong electrical outlet. Wait for
green Steam Ready Indicator Light to turn on. Steamer is ready to use
once again.
1
00 ml
200 ml
A
N
T
(
M
a
x
*IMPORTANT*
Boiler before dry steam will emit.
REMINDERS
• Always use ordinary tap water.
• If tap water is too hard, use distilled or demineralized water to
avoid the risk of mineral deposits and sediment from forming.
• Do not add detergents, perfumes, oils or other chemical
substances to the Boiler. This will damage the Steamer and void the
warranty.
• The green Steam Ready Indicator Light will turn on and off during
use. This is normal and not a fault.
12
Maintenance & Cleaning
Maintenance & Cleaning
If distilled or demineralized water is regularly used in the
Steamer, cleaning of the Boiler can be done less frequently. In
some areas tap water is very hard, it is recommended that the
Boiler is cleaned more frequently if hard water is used.
The cleaning of the Boiler and Steamer is the sole responsibility of the
appliance owner. Calcium, mineral deposits and other sediment left
to build up in the Floor Steamer causing the Steamer to fail and/or the
steam pathways in the Steamer to block, is not covered by the product
warranty. Users must follow the cleaning instructions above.
If the Steamer and Boiler are not cleaned according to the
instructions above and the product fails and/or the steam
pathways are blocked, the appliance owner should send the
product for servicing by contacting the Customer Support Line.
The Steamer is intended for domestic household use only. It is
not intended for commercial use. Any use other than for do
-
mestic household purposes will void the product warranty.
Cleaning the Floor Steamer
We recommend you periodically clean the Floor Steamer to prevent
the accumulation of calcium, mineral deposits and other sediment
caused by the use of tap water. After every 10-15 rells, ll the Boiler
three-quarters full of hot tap water, shake several times and empty
out the water into sink. Repeat several times to ensure that the Boiler
is ushed of any calcium or mineral deposits. Wipe the Steamer
base with a damp cloth and dry.
NEVER HOLD THE STEAMER UNDER THE TAP TO FILL. Use the
Measuring Cup and Funnel provided to ll the Boiler.
3
13
Maintenance & Cleaning & Troubleshooting
Maintenance & Cleaning Troubleshooting
regularly, either by hand (using mild soap and warm water) or in your
clothes washer on a delicate cycle, cool water. Never use fabric
softener or bleach. We recommend letting Pads air dry to maintain
maximum long term effectiveness.
Replacement pads are available at most retail outlets.
SCRUBBING FLOOR PAD
90% Polyester / 10% Polyamide
Machine wash at 40°
Tumble dry low or air dry
No bleach / No fabric softener
CARPET PAD
90% Polyester / 10% Polyamide
Machine wash at 40°
Tumble dry low or air dry
No bleach / No fabric softener
IMPORTANT QUESTION:
Steamer?
A. YES!
Floor Steamer should NEVER be used without either a Hard Surface
Floor Pad or Carpet Glide with Carpet Pad.
Iss u e s Po s s ib le C a u s e s S o lu tio n s
Steam is not coming out of the Improper Handle assembly. Call Customer Service to receive instructions
Steam Nozzles. to correct the problem .
The Scrubbing Floor Pad Not enoug h pressure was Position Steamer about 2” above Pad and
is not adhering to Steamer. applied when attaching Pad. FIRMLY press it down onto the Pad.
Floor Pad requires replacing Replacement Floor Pads can be pu rchased at
due to age of the Floor Pad. most electrical appli ance retail outlets.
The Cleaning Pads a re getting Boiler is
overfilled
. Let Steamer run until excess water ceases.
soaked (too wet). Why? -OR- Remove some water from Boiler onc
e
the Boiler has cooled down completely.
Green “Steam Read y Indicator Wait for green “Steam Ready Indicator Light”
Lig ht” is not illumina ted. to illuminate.
The steam seems to be Front Steam J ets are being Only use Front Steam J ets in short bursts for
making my floor too wet. used too frequently. clea
ning toug her dirt or to clean hard to
reach areas.
The Cleaning Pad is too wet Replace the wet Pad with a dry, clean Pad
(saturated with moisture) and continue cleaning .
Microfiber washing instructions – ULTRA MICROFIBER
14
Notes
Notes
15
Notes Notes
Notes
Customer Support
Customers needing assistance with their Floor Steamer can call the Customer Support Line on the phone
numbers listed below. Customers should also call the Customer Support Line if they require product
warranty repair or post-warranty product servicing.Our friendly Customer Service Team can assist you with
getting the best cleaning results from your Floor Steamer, they are full of helpful steam cleaning tips, too.
Customer Support Line
AUSTRALIA 1800 663 866
NEW ZEALAND 0800 666 783
Euroflex Australia Pty Ltd
79 Furniss Road
DARCH WA 6065
AUSTRALIA
TEL: 08 9302 2526
Email: [email protected]
Website: www.euroflex.com.au
Euroflex New Zealand Ltd
c/- Dubins
137 Glenfield Road
Birkenhead Auckland 0626
NEW ZEALAND
TEL: 0800 666 783
Email: [email protected]
Website: www.euroflex.com.au
SC1Z1 (Australia/NZ) 12/2019
Plastecs SRL
Via dei Colli, 59
31058 Susegana (TV)
ITALY
Tel: +39 0438 453334
Email: [email protected]
Website: www.euroflex-appliances.com
