Dji MAVIC AIR User Manual

MAVIC AIR

v1.2

2018.05

User Manual

Using This Manual

Legend

Warning Important Hints and Tips Reference

Read Before the First Flight

Read the following documents before using the MAVIC

Air:

1. Mavic Air In the Box

2. Mavic Air User Manual

3. Mavic Air Quick Start Guide

4. Mavic Air Disclaimer and Safety Guidelines

5. Mavic Air Intelligent Flight Battery Safety Guidelines

We recommend that you watch all tutorial videos on the ocial DJI

website and read the Mavic Air

Disclaimer and Safety Guidelines before you y. Prepare for your rst ight by reviewing the Mavic Air

Quick Start Guide and refer to this Mavic Air User Manual for more details.

Video Tutorials

Go to the address below or scan the QR code on the right to watch the Mavic Air tutorial

videos, which demonstrate how to use the Mavic Air safely:

http://www.dji.com/mavic-air/info#video

Download the DJI GO 4 App

Be sure to use the DJI GO

4 app during ight*. Scan the QR code on the right to

download the latest version. The Android version of DJI GO 4 is compatible with Android

v4.4 and later. The iOS version of DJI GO 4 is compatible with iOS v9.0 and later.

Download DJI Assistant 2

Download DJI Assistant 2 at http://www.dji.com/mavic-air/download

* For increased safety, ight is restricted to a height of 98.4 ft (30 m) and range of 164 ft (50 m) when not connected

or logged into the app during ight. This applies to DJI GO 4 and all apps compatible with DJI aircraft.

Searching for Keywords

Search for keywords such as “battery” and “install” to find a topic. If you are using Adobe Acrobat

Reader to read this document, press Ctrl+F on Windows or Command+F on Mac to begin a search.

Navigating to a Topic

View a complete list of topics in the table of contents. Click on a topic to navigate to that section.

Printing this Document

This document supports high resolution printing.

Contents

Using This Manual

Legend 2

Read Before the First Flight 2

Video Tutorials 2

Download the DJI GO 4 App 2

Download DJI Assistant 2 2

Product Prole

Introduction 6

Feature Highlights 6

Preparing the Mavic Air 6

Aircraft Diagram 8

Remote Controller Diagram 8

Activation 9

Aircraft

Flight Modes 11

Aircraft LEDs and Status Indicator 12

Return to Home 13

Vision Systems 16

Intelligent Flight Modes 19

Advanced Pilot Assistance Systems 27

Flight Recorder 27

Attaching and Detaching the Propellers 27

Intelligent Flight Battery 28

Gimbal and Camera 32

Remote Controller

Using the Remote Controller 35

Optimal Transmission Zone 38

Linking the Remote Controller 39

DJI GO 4 App

Equipment 41

Editor 44

SkyPixel 44

Me 44

Controlling the Aircraft with a Mobile Device 44

Flight

Flight Environment Requirements 47

Flight Limits and GEO Zones 47

Preight Checklist 48

Auto Takeoff and Auto Landing 49

Starting/Stopping the Motors 49

Test Flight 50

Appendix

Specications 53

Calibrating the Compass 55

Firmware Updates 57

After-Sales Information 57

Product Prole

This section introduces the Mavic Air

and lists the components of the aircraft

and remote controller.

Product Profile

Introduction

The DJI Mavic Air features a new folding design and a fully stabilized 3-axis gimbal camera capable of

shooting 4K video and 12 megapixel photos. DJI signature technologies such as Obstacle Avoidance

and Intelligent Flight Modes like SmartCapture, Panorama, Advanced Pilot Assistance Systems,

QuickShots, ActiveTrack

, and TapFly

make capturing complex shots easy. The Mavic Air boasts a

maximum ight speed of 42.5 mph (68.4 kph) and a maximum ight time of 21 minutes*.

Feature Highlights

Camera and Gimbal: With the Mavic Air, you are able to shoot 4K video at up to 30 frames per second

and capture 12 megapixel photos that look crisp and clear, all stabilized by the onboard 3-axis gimbal.

Flight Controller: The next-generation ight controller has been updated to provide a safer, more reliable

ight experience. The aircraft is able to automatically return to its Home Point when the remote control

signal is lost or the battery level is low. As well as being able to hover indoors at low altitudes, the aircraft

can sense and avoid obstacles on its route, enhancing safety.

HD Video Downlink: DJI’s enhanced Wi-Fi technology is built into the remote controller, offering a

transmission range of up to 2.49 mi (4 km)** and making it possible stream 720p video to your mobile

device.

Preparing the Mavic Air

Preparing the Aircraft

1. Remove the gimbal protector from the camera.

2. All aircraft arms are folded before the aircraft is packaged at the factory. First, unfold the rear arms,

then unfold the front arms and the front landing gear.

3. For safety reasons the propeller guards should be mounted when

using SmartCapture and it is recommended that the propeller guards

are mounted when ying in Beginner mode or indoors. Refer to the

Mavic Air Propeller Guards User Guide to learn more.

* Maximum ight time was tested in windless conditions ying at a consistent

15.5 mph (25 kph). This value should be taken for reference only.

** The remote controller is able to reach its maximum transmission distance (FCC) in a wide open area with no elec-

tromagnetic interference and at an altitude of about 400 ft (120 m).

Mavic Air

User Manual

It is recommended that the gimbal protector be attached when the aircraft is not in use. Make

sure the gimbal is horizontal when mounting or removing the gimbal protector.

Ensure the landing gear is properly unfolded before use. Otherwise, the built-in antennas may

be aected causing serious problems to the video link.

When putting the aircraft away after use, be sure to fold the landing gear rst before folding

the aircraft arms.

To enable Beginner mode, go to Camera View in the DJI GO 4 app, tap , and then tap the

Beginner mode switch. Flight altitude, distance, and speed are limited in Beginner mode.

Beginner mode is available when the GPS signal is strong.

Preparing the Remote Controller (RC)

1. Unfold the antennas and mobile device clamps.

2. Remove the control sticks from their storage slots on the remote controller and screw them into

place.

3. Choose an appropriate RC cable based on the type of mobile device being used. A cable with

a Lightning connector is connected by default, and Micro USB and USB-C cables are included

in the packaging. Move the cable slider to the end of the slot in the left clamp and connect the

end of the cable to your mobile device. Secure your mobile device by pushing both clamps

inward.

When using a tablet, use the USB port on the remote controller.

Do not use the Micro USB and USB ports simultaneously for video linking. Disconnect all

devices from one port before connecting a device to the other port for video linking.

Power Outlet

100-240 V

4. All Intelligent Flight Batteries are in Hibernation mode before shipment to ensure safety. Use the

provided AC power adapter to charge and activate Intelligent Flight Batteries for the first time.

Charging the Intelligent Flight Battery fully before each ight is recommended. To charge an Intelligent

Flight Battery after ight, remove it from the aircraft and attach it to the AC power adapter.

Mavic Air

User Manual

Aircraft Diagram

Remote Controller Diagram

1. Forward Vision System

2. Propellers

3. Motors

4. Front LEDs

5. Landing Gear (with built-in antennas)

6. Gimbal and Camera

7. GPS Antennas

8. Vents

9. USB-C Port

10. Camera microSD Card Slot

11. Aircraft Status Indicator / Function

Button

12. Backward Vision System

13. Battery Level LEDs

14. Power Button

15. Intelligent Flight Battery

16. Battery Latches

17. Downward Vision System

8 9

1. Antennas

Relay aircraft control and video signals.

2. Status LED

Displays the remote controller's

system status.

3. Return to Home (RTH) Button

Press and hold the button to initiate

RTH. Press again to cancel RTH.

4. Charging / Main Video Link Port

(Micro USB)

Connect to the AC Power Adapter to

charge the remote controller battery;

connect to a mobile device for video

linking via RC cable.

Mavic Air

User Manual

5. Control Sticks

Control the orientation and movement of the

aircraft.

6. Flight Pause Button

Press once for emergency braking (when

GPS or Vision System are available).

7. Mobile Device Clamps

Securely mount your mobile device onto the

remote controller.

8. Flight Mode Switch

Switch between P-mode and S-mode.

9. USB / Assistant Video Link Port

Connect to a mobile device for video

downlink via a standard USB cable.

10. Function Button

Performs various functions based on

settings in the DJI GO 4 app.

11. Power Button

Press once to check the current battery

level. Press once, then again and hold to

turn on/o the remote controller.

12. Battery Level LEDs

Display the remote controller’s battery level.

Activation

The Mavic Air requires activation before rst time use. Follow the steps below to activate the Mavic Air

using the DJI GO 4 app:

1. Connect your mobile device to the remote controller and then launch DJI GO 4.

2. Log in to the app using your DJI account or register a new DJI account.

3. Power on the aircraft and remote controller.

4. Select “Mavic Air”, select “Connect to the Aircraft’s Wi-Fi” and “Wired Connection”, and then follow

the prompts to establish connection.

5. Tap “Activating Device” after connection is complete, and then follow the prompts to activate your

Mavic Air.

13. Gimbal Dial

Controls the camera's tilt.

14. Record Button

Press to start recording video. Press again to

stop recording.

15. Customizable Button

Performs various functions based on settings

in the DJI GO 4 app.

16. Shutter Button

Press to take a photo. If Burst shooting mode

is selected, a pre-set number of photos will

be taken.

Aircraft

This section introduces the ight

controller, Forward, Backward and

Downward Vision Systems, and the

Intelligent Flight Battery.

Aircraft

The Mavic Air contains a ight controller, video downlink system, propulsion system, and an Intelligent

Flight Battery. Refer to the aircraft diagram in the Product Prole section.

Flight Modes

The Mavic Air has two ight modes that users can select, plus a third ight mode that the aircraft falls

back to in certain circumstances:

P-mode (Positioning): P-mode works best when the GPS signal is strong. The aircraft utilizes GPS and

the Vision Systems to locate itself, stabilize, and navigate between obstacles. Intelligent Flight Modes

such as SmartCapture, QuickShots, TapFly, and ActiveTrack are enabled in this mode.

When the Forward and Backward Vision Systems are enabled and lighting conditions are sucient, the

maximum ight attitude angle is 15° and the maximum ight speed is 17.9 mph (28.8 kph).

Note: P-mode requires larger stick movements to achieve high speeds.

S-mode (Sport): In S-mode the aircraft uses GPS only for positioning and the Forward and Backward

Vision Systems are disabled. As such, the aircraft is not able to sense and avoid obstacles and

Intelligent Flight Modes are not available.

Note: In S-mode aircraft responses are optimized for agility and speed making it more responsive to

stick movements.

ATTI mode: The aircraft automatically changes to Attitude mode (ATTI mode) when the Vision Systems

are unavailable or disabled and either the GPS signal is weak or the compass is experiencing

interference. When the Vision Systems are unavailable the aircraft is not able to position itself or auto-

brake, so potential ight hazards exist when ying in ATTI mode. In ATTI mode, the aircraft is easily

aected by its surroundings. Environmental factors such as wind can result in horizontal shifting, which

may present hazards, especially when ying in conned spaces.

It is strongly recommended that you nd a safe place to land as soon as possible if the aircraft

enters ATTI mode. To reduce the likelihood of the aircraft entering ATTI mode and minimize

hazards if it does enter ATTI mode, avoid ying in areas where the GPS signal is weak and

avoid ying in conned spaces.

The Forward and Backward Vision Systems are disabled in S-mode, which means the aircraft

will not be able to automatically sense obstacles on its route.

The aircraft’s maximum speed and braking distance are signicantly increased in S-mode. A

minimum braking distance of 98.4 ft (30 m) is required in windless conditions.

Descent speed is signicantly increased in S-mode.

The aircraft’s responsiveness is signicantly increased in S-mode, which means a small stick

movement on the remote controller will translate into a large travel distance of the aircraft. Be

vigilant and maintain adequate maneuvering space during ight.

Enable “Multiple Flight Modes” in the DJI GO 4 app to allow switching between S-mode and

P-mode.

Use the Flight Mode switch on the remote controller to switch between Flight Modes.

S-mode is only available with a Mavic Air remote controller. S-mode is disabled when ying

with a mobile device.

Mavic Air

User Manual

The Front LEDs show the orientation of the aircraft and the status of some of the functions (refer to

the function sections for more details). The Front LEDs glow solid red when the aircraft is turned on to

indicate the front of the aircraft.

The Aircraft Status Indicator communicates the statuses of the aircraft’s flight control system and

Intelligent Flight Battery. Refer to the table below for more information about the aircraft states indicated

by the Aircraft Status Indicator. The Aircraft Status Indicator also ashes when the Home Point is being

recorded, as described in the Return to Home section.

Aircraft LEDs and Status Indicator

The Mavic Air has Front LEDs and an Aircraft Status Indicator as shown in the gure below:

Aircraft Status Indicator

Front LEDFront LED

Aircraft Status Indicator States

Color Blinking/Solid Description of Aircraft State

Normal States

Alternating red,

green, and yellow

Blinking

Turning on and performing self-diagnostic

tests

Yellow Blinks four times Warming up

Green Blinking slowly P-mode with GPS

Green

Periodically blinks

twice

P-mode with Forward and Downward Vision

Systems

Yellow Blinking slowly

No GPS, Forward Vision System or

Downward Vision System

Green Blinking quickly Braking

Warning States

Yellow Blinking quickly Remote controller signal lost

Red Blinking slowly Low battery

Red Blinking quickly Critically low battery

Red Blinking IMU error

Red Solid Critical error

Alternating red

and yellow

Blinking quickly Compass calibration required

Mavic Air

User Manual

Smart RTH

If the GPS signal is suciently strong, Smart RTH can be used to bring the aircraft back to the Home

Point. Smart RTH is initiated either by tapping in the DJI GO 4 app (and following the on-screen

instructions) or by pressing and holding the RTH button on the remote controller.

Smart RTH can be exited by tapping in the DJI GO 4 app or by pressing the RTH button on the

remote controller.

Low Battery RTH

Low Battery RTH is triggered when the Intelligent Flight Battery is depleted to a point that may aect the

safe return of the aircraft. Return home immediately or land the aircraft promptly when prompted. DJI GO

4 will display a warning when a low battery level warning is triggered. The aircraft will automatically return

to the Home Point if no action is taken after a ten-second countdown. The user can cancel the RTH

procedure by pressing the RTH button or Flight Pause button on the remote controller.

If the RTH procedure is cancelled following a low battery level warning the Intelligent Flight Battery may not

have enough charge for the aircraft to land safely, which may lead to the aircraft crashing or being lost. The

thresholds for the battery level warnings are automatically determined based on the aircraft’s current altitude

and distance from the Home Point. Low Battery RTH will only be triggered one time during each ight.

Return to Home

The Return to Home (RTH) function brings the aircraft back to the last recorded Home Point. There are

three types of RTH: Smart RTH, Low Battery RTH, and Failsafe RTH. This section describes these three

scenarios in detail.

GPS

Description

Home Point

If a strong GPS signal was acquired before takeoff, the Home Point is

the location from which the aircraft launched. The GPS signal strength is

indicated by the GPS icon ( ). The Aircraft Status Indicator will blink

green quickly when the Home Point is recorded.

The colored zones and markers on the DJI GO 4 battery level indicator bar reflect the

estimated remaining flight time. They are automatically adjusted according to the aircraft’s

current location and status.

If the current battery level can only support the aircraft long enough to descend from its

current altitude a critically low battery level warning will be triggered and the aircraft will

descend and land automatically. This procedure cannot be cancelled. If there is danger of

collision occurring, push the throttle up and try to navigate away.

If the battery level is sucient the battery level indicator bar in the DJI GO 4 app displays the

estimated remaining ight time based on current battery level.

Critically low battery level warning

(Red)

Low battery level warning

(Yellow)

Battery level is

sufficient (green)

Remaining flight time

Charge required to

return to Home Point

12:29

DJI GO 4 Battery level Indicator Bar

Mavic Air

User Manual

Warning

Aircraft Status

Indicator

DJI GO 4 App

Remote

Controller

Remarks/Instructions

Low Battery

Level

Blinks red slowly

Tap “Go-home” to have

the aircraft return to the

Home Point automatically

or “Cancel” to resume

normal ight. If no action

is taken, the aircraft will

automatically y home after

10 seconds.

Alarm sounds

continuously

Battery level is low. Fly

the aircraft back and land

promptly, then stop the

motors and replace the

battery.

Critically Low

Battery Level

Blinks red quickly Display ashes red Alarm sounds

continuously

The aircraft will descend

and land automatically.

This procedure cannot be

cancelled. If there is danger

of collision occurring, push

the throttle up and try to

navigate away.

Failsafe RTH

The Forward Vision System allows the aircraft to create a real-time map of its ight route as it ies. If the

Home Point was successfully recorded and the compass is functioning normally, Failsafe RTH will be

automatically activated if the remote control signal is lost for a specied amount of time (three seconds

when using the remote controller and 20 seconds when ying with a mobile device).

When Failsafe RTH is activated the aircraft starts to retrace its original ight route home. If the wireless

control signal is re-established within 60 seconds of Failsafe RTH being activated, the aircraft hovers at

its present location for 10 seconds and waits for pilot commands. The user may tap in the DJI GO 4

app or press the RTH button on the remote controller to cancel Failsafe RTH and retake control. If no pilot

command is given the aircraft ies to the Home Point in a straight line. If the wireless control signal is still

lost 60 seconds after Failsafe RTH was activated the aircraft stops retracing its original ight route and ies

to Home Point in a straight line.

RTH Procedure

Smart RTH, Low Battery RTH, and Failsafe RTH follow this procedure:

1. The aircraft adjusts its orientation.

2. a. If the aircraft is further than 20 m from the Home Point it ascends to the pre-set RTH attitude and

then ies to the Home Point.

b. If the aircraft is between 5 m and 20 m from the Home Point it ies to the Home Point at the

current altitude, unless the current altitude is less than 2.5 m, in which case the aircraft ascends

to 2.5 m and then ies to the Home Point.

c. If the aircraft is less than 5 m from the Home Point it lands immediately.

3. The aircraft lands and stops its motors once it reaches the Home Point.

RTH and Battery Level Warnings

If a battery level warning appears, take action as described in the table below.

Mavic Air

User Manual

1 Record Home Point 2 Conrming Home Point

4 Signal Lost for Extended Time

RTH (adjustable altitude)

Height over HP > Failsafe Altitude

Elevate to Failsafe Altitude

Height over HP<=Failsafe Altitude

Failsafe Altitude

6 Landing

3 Remote Controller Signal Lost

Obstacle Avoidance During RTH

The Mavic Air senses and actively attempts to avoid obstacles during RTH, provided that lighting

conditions are sufficient for the Forward and Backward Vision Systems to operate. The obstacle

avoidance procedure is as follows:

1. The aircraft decelerates when an obstacle is sensed.

2. The aircraft stops and hovers then starts ying backward and ascends vertically until no obstacle is

sensed.

3. The RTH procedure resumes. The aircraft ies to the Home Point at the new altitude.

The aircraft will not be able to return to the Home Point if the GPS signal is weak or if GPS is

unavailable.

In Smart RTH and Low Battery RTH, during the aircraft’s ascent to its RTH altitude, the ascent

is automatic until an altitude of 65 ft (20 m) is reached. Once the altitude is 65 ft (20 m) or

higher, moving the throttle stick commands the aircraft to stop ascending and to y to the

Home Point at its current altitude.

The aircraft will not be able to avoid obstacles during Failsafe RTH if the Forward and

Backward Vision Systems are unavailable. It is important to set a suitable RTH Altitude before

each ight. Launch the DJI GO 4 app, tap and then set the RTH Altitude.

The aircraft cannot avoid obstacles above or beside the aircraft.

During the RTH procedure the aircraft’s speed and altitude can be controlled using the remote

controller or the DJI GO 4 app, but its orientation and direction of ight are controlled by the

ight controller.

Mavic Air

User Manual

Vision Systems

The Mavic Air is equipped with Forward, Backward, and Downward Vision Systems that constantly

scan for obstacles in front of and behind the aircraft, allowing it to avoid collisions by going around or

hovering (if lighting conditions are adequate).

The main components of the Forward and Backward Vision Systems are four cameras located on the

nose and the rear side of the aircraft.

The Downward Vision System helps the aircraft maintain its current position. With the help of the

Downward Vision System, the Mavic Air can hover in place more precisely and y indoors or in other

environments where a GPS signal is unavailable. The main components of the Downward Vision System

are two cameras and one 3D infrared module located on the underside of the aircraft.

Forward Vision System Backward Vision System

Downward Vision System

Precision Landing performance is subject to the following conditions:

a. The Home Point must be recorded upon takeo and must not be changed during ight,

otherwise the aircraft will have no record of the Home Point’s terrain features.

b. During takeo the aircraft must ascend vertically 7 m before moving horizontally.

c. The Home Point terrain features must remain largely unchanged.

d. The Home Point terrain features must be suciently distinctive.

e. The lighting conditions must not be too light or too dark.

The following actions are available during Precision Landing:

a. Throttle down to accelerate landing.

b. Move the control sticks in any other direction to stop Precision Landing. The Mavic Air will

descend vertically after the control sticks are released.

Landing Protection

Landing Protection will activate during Smart RTH

1. When Landing Protection determines that the ground is suitable for landing, the Mavic Air will land

gently.

2. If Landing Protection determines that the ground is not suitable for landing, the Mavic Air will hover

and wait for pilot conrmation.

3. If Landing Protection is not operational, the DJI GO 4 app will display a landing prompt when the

Mavic Air descends below 0.5 meters. Pull down on the throttle or use the auto landing slider to

land.

Precision Landing

The Mavic Air automatically scans and attempts to match the terrain features underneath during Return

to Home. When the current terrain matches Home Point terrain, the Mavic Air will start landing. The DJI

GO 4 app will show a terrain feature mismatch prompt if matching fails.

Mavic Air

User Manual

Detection Fields

The detection elds of the Forward, Backward and Downward Vision Systems are depicted below. Note

that the aircraft cannot sense or avoid obstacles that are not within the detection elds.

53°

50°

67°

5°

38°

5°

38°

Point the aircraft toward the screen

Align the boxes

Pan and tilt the aircraft

Calibrating Vision System Cameras

The Forward, Backward, and Downward Vision System cameras installed on the aircraft are factory-

calibrated, but may require calibration via DJI Assistant 2 or the DJI GO 4 app if the aircraft is subjected

to an impact.

The most accurate way to calibrate the vision systems is by using DJI Assistant 2. Follow the steps

below to calibrate the Forward Vision System cameras, then repeat the steps to calibrate the Backward

and Downward Vision System cameras.

1. Point the aircraft toward the screen.

2. Move the aircraft to align the boxes shown on the screen.

3. Pan and tilt the aircraft as prompted.

When the DJI GO 4 app noties that a vision system calibration is required but a computer is not nearby

a quick calibration can be performed within the app. Tap through “Aircraft Status” > “Vision Sensors” to

start quick calibration.

Quick calibration is a quick x to vision system issues. When possible, connecting the aircraft

to a computer to carry out a full calibration using DJI Assistant 2 is recommended. Only

calibrate when lighting conditions are adequate and on textured surfaces such as grass.

Do not calibrate the aircraft on highly reective surfaces such as marble or ceramic tiles.

Camera

Centerline

Mavic Air

User Manual

Using the Forward and Backward Vision Systems, the aircraft is able to actively brake when obstacles

are detected in front. The Forward and Backward Vision Systems work best when lighting is adequate

and obstacles are clearly marked or textured. The aircraft must y at no more than 17.9 mph (22.8 kph)

to allow for sucient braking distance.

Using the Vision Systems

The Downward Vision System is activated automatically when the aircraft is turned on. No further action

is required. Using the Downward Vision System, the aircraft can hover precisely even without GPS.

The Downward Vision System is typically used in indoor environments where GPS is unavailable. The

Downward Vision System works best when the aircraft is at altitudes of 1.6 to 26 ft (0.5 to 8 m). If

the aircraft’s altitude is above 8 m the Vision Positioning function may be aected, so extra caution is

required.

Follow the steps below to use the Downward Vision System:

1. Ensure the aircraft is in P-mode and place the aircraft on a at surface. Note that the Downward

Vision System cannot work properly on surfaces without clear pattern variations.

2. Turn on the aircraft. The aircraft will hover in place after takeo. The Aircraft Status Indicator will ash

green twice, which indicates the Downward Vision System is working.

The performance of the Vision Systems is affected by the surface being flown over. The

aircraft automatically changes from to ATTI mode when the Vision Systems are unavailable

or disabled and either the GPS signal is weak or the compass is experiencing interference.

Operate the aircraft with great caution in the following situations:

a. Flying at high speeds below 1.6 ft (0.5 m).

b. Flying over monochrome surfaces (e.g. pure black, pure white, pure red, pure green).

c. Flying over highly reective surfaces.

d. Flying over water or transparent surfaces.

e. Flying over moving surfaces or objects.

f. Flying in an area where the lighting changes frequently or drastically.

g. Flying over extremely dark (< 10 lux) or bright (> 100,000 lux) surfaces or towards bright

sources of light (e.g. towards sunlight).

h. Flying over surfaces without clear patterns or texture.

i. Flying over surfaces with identical repeating patterns or textures (e.g. tiling).

j. Flying over small and ne objects (e.g. tree branches or power lines).

k. Flying at high speeds of over 11.2 mph (18 kph) at 3.3 ft (1 m).

Mavic Air

User Manual

Keep the cameras and sensors clean at all times. Dirt or other debris may adversely aect

their eectiveness.

The Forward, Backward, and Downward Vision Systems may not be able to recognize patterns

on the ground in very dark (< 100 lux) environments.

Intelligent Flight Modes

The Mavic Air supports Intelligent Flight Modes including QuickShots, ActiveTrack, SmartCapture, Tripod

mode, Cinematic mode, TapFly, and Point of Interest. Tap in DJI GO 4 to select an Intelligent Flight

Mode.

QuickShots

QuickShots shooting modes include Dronie, Circle, Helix, Rocket, Boomerang, and Asteroid. The

Mavic Air records a video according to the selected shooting mode and then automatically generates a

10-second video. The video can then be viewed, edited, or shared to social media from the playback

menu.

Dronie: The aircraft ies backward and upward, with the camera locked on your subject.

Circle: The aircraft circles around your subject.

Helix: The aircraft ies upward, spiraling around your subject.

Rocket:

The aircraft ascends with the camera pointing downward.

Boomerang: The aircraft ies around your subject in an oval path ascending as it ies away from

its starting point and descending as it ies back. The aircraft’s starting point forms one end of the

oval’s long axis, while the other end of its long axis is at the opposite side of the subject from the

starting point.

Ensure there is sucient space when using Boomerang: Allow a radius of at least 99 ft (30 m)

horizontally around the aircraft and allow at least 33 ft (10 m) above the aircraft. .

Asteroid: The aircraft ies backward and upward and then takes several photos, then ies back

to its starting point. The video generated starts with a panorama of the highest position and then

shows the descent.

Ensure there is sucient space when using Asteroid: Allow at least 132 ft (40) m behind and 164

ft (50 m) above the aircraft.

Using QuickShots

Ensure that the aircraft is in P-mode and that the Intelligent Flight Battery is suciently charged.

Follow the steps below to use QuickShots:

1. Take o and hover at least 6.6 ft (2 m) above the ground.

2 m

2. In DJI GO 4, tap , then select QuickShots and follow the prompts.

Mavic Air

User Manual

3. Select your target subject in Camera View (tap the circle on the subject or drag a box around the

subject) and choose a shooting mode. Tap “GO” to begin recording. The aircraft will y back to its

original position once shooting is nished.

61%

2.4G

QuickShot

09:29

ISO

SHUTTER

1600 0.31/8000

CAPACITY

1080P/2420GB

In flight (GPS)

AsteroidDronie HelixCircle Rocket Boomerang

4. Tap to access the video.

QuickShots are only available when the GPS signal is strong.

The aircraft cannot avoid obstacles above or beside the aircraft.

In all QuickShots shooting modes videos are recorded at 30 fps and in Asteroid images are

captured at 1080p. These settings are pre-set and cannot be adjusted.

2. In DJI GO 4, tap , then select ActiveTrack.

2 m

ActiveTrack

ActiveTrack allows you to mark and track several moving objects on your mobile device’s screen. No

external tracking device is required. Mavic Air can automatically identify and track people, vehicles and

boats, and use dierent tracking strategies for each.

Using ActiveTrack

Ensure that the aircraft is in P-mode and that the Intelligent Flight Battery is suciently charged. Follow

the steps below to use ActiveTrack:

1. Take o and hover at least 6.6 ft (2 m) above the ground.

Exiting QuickShots

Tap in DJI GO 4 or toggle the Flight Mode switch to S-mode to exit QuickShots anytime during

shooting. Press the Flight Pause button on the remote controller for emergency breaking.

Mavic Air

User Manual

61%

2.4G

ActiveTrack

09:29

ISO

SHUTTER

1600 0.31/8000

CAPACITY

1080P/2420GB

In flight (GPS)

Trace

SpotlightParallel

3. Tap on the subject you want to track then tap to confirm your selection. If the subject is not

automatically recognized, drag a box around it. The box will turn green when the subject has been

recognized and tracking has begun. If the box turns red, the object could not be identied and you

should try again.

4. The aircraft will automatically avoid obstacles in its ight path. If the aircraft loses track of the subject

because it is moving too fast or is obscured, re-select the subject to resume tracking.

Trace

Parallel

Spotlight

The aircraft tracks the subject

at a constant distance. Use

the roll stick on the remote

controller or the slider in DJI

GO 4 to y in a circle around

the subject.

The aircraft tracks the subject

at constant angle and distance

from the side. Use the roll stick

on the remote control to y in a

circle around the subject.

The aircraft will not trace a subject

automatically, but it keeps the

camera pointing at the subject

during ight. The remote controller

can be used to maneuver the

aircraft, but orientation control

is disabled. Using the left stick

and gimbal dial will adjust subject

framing.

ActiveTrack includes following sub-modes:

Mavic Air

User Manual

Exiting ActiveTrack

Tap on the screen or toggle the Flight Mode switch to S-mode on the remote controller to exit

ActiveTrack. After exiting ActiveTrack, the aircraft will hover in place, at which point you may choose to

y manually, track another subject, or return to home.

SmartCapture

Deep learning gesture recognition allows you to take selfies, record videos, and control the aircraft

using simple hand gestures. The Mavic Air features brand new modes like GestureLaunch, Follow, and

GestureLand. (Note: Aircraft rmware v1.0.1.0 or higher is required to use SmartCapture; Aircraft rmware

v1.0.2.0 or higher is required to y the aircraft without using the remote controller or DJI GO 4. )

DO NOT use ActiveTrack in areas with people, animals, small or fine objects (e.g. tree

branches or power lines), or transparent objects (e.g. glass or water).

Stay clear of obstacles near the ight path, especially obstacles to the left and right of the

aircraft.

Operate the aircraft manually (press the Flight Pause button or toggle the Flight Mode switch

to S-mode on the remote controller) or tap in DJI GO 4 in an emergency.

Be extra vigilant when using ActiveTrack in any of the following situations:

a. The tracked subject is not moving on a level plane.

b. The tracked subject changes shape drastically while moving.

c. The tracked subject could be out of sight for a long time.

d. The tracked subject is moving on a snowy surface.

e. The tracked subject has a similar color or pattern to its surrounding environment.

f. Available light is too low (< 300 lux) or too high (> 10,000 lux).

You must follow local privacy laws and regulations when using ActiveTrack.

1.2m

SmartCapture can be selected either by tapping in the DJI GO 4 app and selecting

SmartCapture or by pressing the Function button twice. The rst time you use SmartCapture

select it in the DJI GO 4 app and read the warning prompt carefully. Only use SmartCapture if

you understand the warning.

Only use SmartCapture in open areas with no obstacles, with sucient light, and away from

crowds.

Only use SmartCapture with the propeller guards mounted.

Activating FaceAware and PalmControl

To use SmartCapture rst activate FaceAware and PalmControl:

1. Tap in the DJI GO 4 app and select SmartCapture or press twice on the Function button. When

FaceAware has activated the aircraft will beep twice and the Front LEDs will become solid yellow.

2. Next, use one of the following two methods to activate PalmControl:

a. GestureLaunch: If the aircraft is on the ground you can use

GestureLaunch to command the aircraft to take off and activate

PalmControl. Stand at a distance of 6.6 to 9.8 ft (2 to 3 m) in front

of the aircraft with your palm in front of the aircraft’s nose. Keep

your palm open and your ngers close together. After about two

seconds the aircraft will take o automatically and hover at a height

of 3.9 ft (1.2 m). The Front LEDs will blink green slowly to indicate

that PalmControl has been activated.

Mavic Air

User Manual

b. If the aircraft is already airborne, raise and extend your arm and position your palm about 6.6 ft

(2 m) in front of the aircraft's nose. Keep your palm open and your ngers close together. After

about two seconds the Front LEDs will blink green slowly to indicate that PalmControl has been

activated.

Control Position

Move your palm up or down slowly to control the

aircraft’s altitude. Move your arm left or right to

control the aircraft’s orientation. Move forward or

backward to y forward or backward.

Front LEDs blink green slowly

Control Distance

Raise and extend your other arm and hold your

two palms close together. Move your hands

apart and the aircraft will y away from you, to a

maximum distance of 19.7 ft (6 m). Move your

hands together and the aircraft will fly towards

you, to a minimum distance of 6.6 ft (2 m).

Front LEDs blink green slowly

Drop your hand towards the floor to activate Follow. Once Follow is

activated, the front LEDs will turn solid green. As you move your body, the

aircraft will follow you automatically. Whilst Follow is active, you can raise

your hand or hands again to use the other SmartCapture features.

Front LEDs solid green

With Follow you can select either Trace to have the aircraft follow you at

a constant distance or Prole to have the aircraft follow you at a constant

angle and distance from the side. (Refer to the ActiveTrack section for more

information about Trace and Prole.) If you are using SmartCapture without

the DJI GO 4 app, Trace or Prole will be selected based on which one you

used last time you used Follow while using SmartCapture with the app. If

you have never used Follow while using SmartCapture with the app, the

default selection (Trace) will be selected.

If conditions are not suitable for using SmartCapture the Front LEDs will be solid red and a

warning will be displayed in DJI GO 4. If you are not using the app, connect the aircraft to

your mobile device and launch the app to view the warning description.

Once FaceAware and PalmControl have been activated you can control the aircraft in the following

ways. (Stay within 23 ft (7 m) of the aircraft for your gestures to be recognized):

Mavic Air

User Manual

Sele

Make a V gesture with one hand. Once your selfie gesture has been

recognized a two-second countdown will begin. With one second remaining

the aircraft’s Front LEDs will start to blink red slowly, then with one second

remaining they will start to blink red quickly.

Group Sele

Make two or more V gestures at the same time. Once your group selfie

gesture has been recognized a two-second countdown will begin, after

which the aircraft will take the rst of three photos. During the countdown

the Front LEDs will blink red slowly for one second and blink red quickly

for one second. The Front LEDs will then turn o and the aircraft will take a

photo at its current position.

Next, the aircraft will y to a point approximately 16 ft (5 m) away from your group

and ascend and take a photo at a 30° angle. The aircraft will then y to a point

approximately 23 ft (7 m) away from your group and ascend and take a photo at

a 15° angle. Finally, the aircraft will y back to its original position. The Front LEDs

will blink red twice when the aircraft is taking the second and third photos.

Only use the group sele feature in areas with a strong GPS signal. The group sele feature is

disabled if there is no GPS signal (e.g. when ying indoors).

Record Videos

Make a frame gesture with your ngers (ensuring at least one hand is above

your nose). Once your frame gesture has been recognized the aircraft’s

Front LEDs will turn off and the camera will start recording. After five

seconds or more have elapsed, making the frame gesture again will stop

the recording.

Front LEDs o

Switching Control

Drop your hand towards the oor. The Front LEDs will turn solid green. The

person who would like to control the aircraft should raise their palm in front

of the aircraft. Once the aircraft is under their control the Front LEDs will

blink green slowly.

Front LEDs blink green slowly

Mavic Air

User Manual

Tripod Mode

Tap in the DJI GO 4 app to select Tripod mode. In Tripod mode, the maximum flight speed is limited

to 2.2 mph (3.6 kph). Responsiveness to stick movements is also reduced for smoother, more controlled

movements.

Only use Tripod mode where the GPS signal is strong or light conditions are ideal for the

Vision Systems. If the GPS signal is lost and if the Vision Systems are disabled or unavailable,

the aircraft will automatically switch to ATTI mode. In this case, ight speed will increase and

the aircraft will not hover in place. Use Tripod mode carefully.

The aircraft does not exit SmartCapture automatically. While the aircraft is airborne and after

it has been landed using GestureLand the aircraft will continue to respond to hand gestures

until you manually exit SmartCapture, so caution is required.

When using SmartCapture without the remote controller or the DJI GO 4 app:

a. If no face or palm is detected in the first 60 seconds after takeoff, the aircraft lands

automatically;

b. If the subject is lost during Follow the aircraft ies back to the position the subject was

most recently detected at and waits. If the aircraft detects the subject within 30 seconds

it continues following it. If the subject is not detected within 30 seconds the aircraft lands

automatically.

Cinematic Mode

Tap

in the DJI GO 4 app to select Cinematic mode. In Cinematic mode, the aircraft’s braking distance

is extended and its rotation speed is reduced. The aircraft will slow down gently until it stops, keeping

footage smooth and stable even if control inputs are choppy.

GestureLand

Move your palm down slowly to make the aircraft descend. Continue until

it has descended to its minimum altitude, then continue commanding it to

descend for a further three seconds and it will land automatically and its

motors will stop.

Front LEDs blink green slowly

Exercise caution once you have landed the aircraft using GestureLand, as the aircraft will

continue to respond to hand gestures until you exit SmartCapture. If the aircraft detects

the GestureLaunch gesture before you have exited SmartCapture, the aircraft will take off.

Exercise caution when approaching the aircraft and ensure you do not accidently make the

GestureLaunch gesture.

Exiting SmartCapture

Tap in DJI GO 4 or toggle the Flight Mode switch to S-mode on the remote controller to exit

SmartCapture. If you are using SmartCapture without the DJI GO 4 app, to exit SmartCapture rst land

the aircraft using GestureLand then either power the aircraft o, connect the aircraft to DJI GO 4 and

tap , or connect the aircraft to the remote controller and toggle the Flight Mode switch to S-mode.

Mavic Air

User Manual

61%

2.4G

09:29

ISO

SHUTTER

1600 0.31/8000

CAPACITY

1080P/2420GB

TapFly

In flight (GPS)

Forward

Reverse CoordinateFree

Exiting TapFly

Press the Flight Pause button on the remote controller or pull a control stick in the direction opposite to

the direction of ight and the aircraft will brake and hover in place. Tap the screen to resume TapFly. Tap

or toggle the Flight Mode switch to S-mode to exit TapFly.

DO NOT use TapFly in areas with people, animals, small or ne objects (e.g. tree branches or

power lines), or transparent objects (e.g. glass or water). TapFly Mode may not work properly

when the aircraft is ying over water or snow covered areas.

There may be deviations between expected and actual ight paths selected in TapFly.

The selectable range for the target direction is limited. You cannot make a selection close to

the upper or lower edges of the screen.

1 m

TapFly

TapFly features four sub-modes, Forward, Backward, Free, and Coordinate. Provided that lighting conditions

are suitable (between 300 and 10,000 lux), the aircraft will automatically avoid obstacles it senses.

Forward: The aircraft will y towards the target with the Forward Vision System sensing obstacles.

Backward: The aircraft will y in the opposite direction of the target with the Backward Vision System

sensing obstacles..

Free: The aircraft will y towards the target. The remote controller can be used to maneuver the

orientation of the aircraft freely.

Coordinate: Tap a specic location on screen. The aircraft will travel to that point at its current altitude,

then hover in place.

Using TapFly

Ensure that the aircraft is in P-mode and that the Intelligent Flight

Battery is sufficiently charged. Follow the steps below to use

TapFly:

1. Take o and hover at least 3.3 ft (1 m) above the ground.

2. In DJI GO 4, tap , select TapFly, then select a sub-mode and follow the prompts.

3. Tap once on the target and wait for the “GO” button to appear. Tap the “GO” button to conrm the

selection and the aircraft will y to the target automatically. A prompt will appear if the target cannot

be reached. If this is the case, select another target and try again. The target can be changed mid-

ight by tapping the screen.

Mavic Air

User Manual

Point of Interest

Select a subject, and set the circle radius, ight altitude, and ight speed, and the aircraft will y around

the subject according to these settings.

139m

7m/s 1.1m/s 627m

612m

POINT OF INTEREST

Exit

3M/S

12M

34M

Flight Altitude Circle Radius

Stop

Advanced Pilot Assistance Systems

The Advanced Pilot Assistance Systems (APAS) feature is available in P-mode. When APAS is enabled

the aircraft continues to respond to user commands and plans its path according to both control

stick inputs and the ight environment. APAS makes it easier to avoid obstacles and obtain smoother

footage, and gives a better ying experience.

When APAS is enabled, pressing the Flight Pause button on the remote controller or tapping in

the DJI GO 4 app brings the aircraft to a stop. The aircraft will hover for three seconds and await pilot

commands.

To enable APAS, tap

APAS

in the DJI GO 4 app.

Flight Recorder

Flight data including ight telemetry, aircraft status information, and other parameters is automatically

saved to the aircraft’s internal data recorder. This data can be accessed using DJI Assistant 2.

Attaching and Detaching the Propellers

The Mavic Air uses model 5332S propellers. There are two varieties of 5332S propellers, which are

designed to spin in different directions. The presence or absence of white marks on the propellers

indicates which type they are and therefore which motors they should be attached to.

The APAS feature is automatically disabled when using Intelligent Flight Modes and will

resume automatically after exiting from Intelligent Flight Modes.

Mavic Air

User Manual

Intelligent Flight Battery

The Mavic Air Intelligent Flight Battery is an 11.55 V, 2375 mAh battery with smart charging/discharging

functionality. It should only be charged using an appropriate DJI approved AC power adapter.

Battery Features

1. Battery Level Display: The LED indicators display the current battery level.

2. Auto-Discharging Function: To prevent swelling, the battery automatically discharges to below

65% of the maximum charge when it is idle for more than 10 days. It takes approximately one day

to discharge the battery to 65%. It is normal to feel moderate heat being emitted from the battery

during the discharging process.

3. Balanced Charging: The voltages of the battery cells are automatically balanced during charging.

Detaching the Propellers

Press the propellers down into the mounting plate and rotate them in the unlock direction.

Propeller blades are sharp – handle with care.

Only use original DJI propellers and do not mix propeller types.

Ensure that all propellers are in good condition before each ight. Do not use aged, chipped,

or broken propellers.

Ensure that the propellers and motors are installed rmly and correctly before each ight.

To avoid injury, stand clear of and do not touch propellers or motors when they are spinning.

Place the aircraft in the direction shown in the carrying case during transportation or storage

to avoid damaging the propellers. Do not squeeze or bend the propellers. If propellers

become distorted ight performance will be aected.

Marked Unmarked

Attach on motors with white marks Attach on motors without white marks

Turn the propellers in the indicated direction to mount and tighten.

Attaching the Propellers

Attach the propellers with the white marks to the motors with white marks. Press each propeller down

onto the mounting plate and rotate in the lock direction until it is secured. Attach unmarked propellers to

the motors without marks.

White Marks Unmarked

Mavic Air

User Manual

Using the Battery

Press the Power button once, then press again and hold for two seconds to turn the battery on or o.

Low Temperature Notice

1. Battery capacity is signicantly reduced when ying in low temperature (14° to 41° F (-10° to 5° C))

environments.

2. Batteries cannot be used in extremely low temperature (< 14° F (-10° C)) environments.

3. End the ight as soon as the DJI GO 4 app displays the low battery level warning in low temperature

environments.

4. To ensure optimal performance of the battery, keep the battery temperature above 68° F (20° C).

5. The reduced battery capacity in low temperature environments reduces the aircraft's wind speed

resistance performance, so extra caution is required.

In cold environments, insert the battery into the battery compartment and turn on the aircraft

for approximately 1 to 2 minutes to warm up before taking o.

LED2

LED1

Battery Level LEDs

LED3

LED4

Power Button

4. Overcharge Protection: Charging automatically stops when the battery is fully charged.

5. Temperature Detection: The battery will only charge when the temperature is between 41° and 104° F

(5° and 40° C).

6. Overcurrent Protection: The battery stops charging if an excessive current is detected.

7. Overdischarge Protection: Discharging stops automatically to prevent excessive discharge.

8. Short Circuit Protection: The power supply is cut automatically if a short circuit is detected.

9. Battery Cell Damage Protection: The DJI GO 4 app displays a warning message when a damaged

battery cell is detected.

10. Hibernation Mode: The battery will cut the power supply and switch o after 20 minutes of inactivity

to save power. To prevent over discharging the battery will enter Hibernation mode after six hours of

inactivity if the battery level is less than 10%. In Hibernation mode the battery level indicators do not

illuminate. Charging the battery will wake it from hibernation.

11. Communication: Information pertaining to the battery’s voltage, capacity, and current is transmitted

to the aircraft.

Refer to the Mavic Air Intelligent Flight Battery Safety Guidelines before use. Users take full

responsibility for all operations and usage.

Before carrying Intelligent Flight Batteries on an airline ight, they must be discharged to 30%

or lower. This can be done by flying your Mavic Air outdoors until there is less than 30%

charge left or until the Intelligent Flight Battery no longer turns on.

Mavic Air

User Manual

Charging the Battery

The Intelligent Flight Battery must be fully charged before using it for the rst time:

1. Connect the AC power adapter to a power source (100 to 240 V, 50/60 Hz).

2. Attach the Intelligent Flight Battery to the AC power adapter using the battery charging cable with

the battery powered o.

3. The battery level LEDs display the current battery level during charging. The Intelligent Flight Battery

is fully charged when the battery level LEDs all turn o. Detach the AC power adapter when the

battery is full charged.

DO NOT charge an Intelligent Flight Battery immediately after ight, because its temperature

may be too high. DO NOT charge an Intelligent Flight Battery until it cools down to near room

temperature.

The AC power adapter will stop charging the battery if the battery cell temperature is not

within the operating range (41° to 104° F (5° to 40° C)). The ideal charging temperature is

71.6° to 82.4° F (22° to 28° C).

The optional Battery Charging Hub can charge up to four batteries. Please visit the ocial DJI

Online Store to learn more.

Intelligent Flight Battery Charging Time

53 minutes in environments at temperatures between 59° and 104° F (15° and 40° C); 1 hour and 40

minutes in environments at temperatures between 41° and 59° F (5° and 15° C).

AC Power Adapter

Intelligent Flight Battery

Power Outlet

Checking Battery Level

The battery level LEDs on the battery display how much charge remains. If the battery is turned o, press

the Power button once and the battery level LEDs will light up to display the current battery level.

Battery Level LEDs

: LED is on.

: LED is ashing. : LED is o.

LED1 LED2 LED3 LED4

Battery Level

88% - 100%

75% - 88%

63% - 75%

50% - 63%

38% - 50%

25% - 38%

13% - 25%

0% - 13%

Mavic Air

User Manual

Battery Protection

The table below shows battery protection mechanisms and corresponding LED patterns.

In the event of charging temperature protection occurring the battery will resume charging once

the temperature has returned to within the allowable range. If one of the other battery protection

mechanisms activates, to resume charging once the issue has been resolved it is necessary to rst

press the Power button to turn the battery o, unplug the battery from the AC power adapter, and then

plug it back in to resume charging.

DJI does not take any responsibility for damage caused by third-party AC power adapters.

Inserting the Intelligent Flight Battery

Insert the Intelligent Flight Battery into the aircraft’s battery compartment, making sure that it is mounted

rmly and that the battery latches have clicked into place.

Battery Protection Mechanisms

LED1 LED2 LED3 LED4 Blinking Pattern Battery Protection Item

LED2 blinks twice per second Overcurrent detected

LED2 blinks three times per

second

Short circuit detected

LED3 blinks twice per second Overcharge detected

LED3 blinks three times per

second

Over-voltage charger detected

LED4 blinks twice per second Charging temperature is too low

LED4 blinks three times per

second

Charging temperature is too

high

Battery Level LEDs During Charging

: LED is on.

: LED is ashing. : LED is o.

LED1 LED2 LED3 LED4

Battery Level

0% - 50%

50% - 75%

75% - 100%

Fully Charged

click

Mavic Air

User Manual

Gimbal and Camera

Gimbal

The Mavic Air’s 3-axis gimbal provides stabilization for the camera, allowing you to capture clear, stable

images and video. The gimbal has a tilt range of -90˚ to +17˚. The tilt range is set to -90˚ to 0˚ by default

and can be adjusted in DJI GO 4 (tap and select “Advanced Settings” > “Extend Gimbal Tilt Limit”).

Other gimbal settings such as Gimbal Mode and Gimbal Auto Calibration can also be selecting by

tapping .

Use the gimbal dial on the remote controller to control camera tilt. Alternatively, in DJI GO 4, go to

Camera View, press and hold on the screen until a blue circle appears, and drag the circle up and down

to control camera tilt. Dragging the circle left and right will control the aircraft’s orientation.

-90°

0°

17°

Gimbal Operation Modes

Two gimbal operation modes are available. Switch between the different operation modes on the

camera settings page of the DJI GO 4 app.

Follow Mode: The angle between the gimbal’s orientation and aircraft’s nose remains constant at all

times.

FPV Mode: The gimbal will synchronize with the movement of the aircraft to provide a first-person

perspective ying experience.

Do not tap or knock the gimbal when the aircraft is powered on. To protect the gimbal during

takeo, always take o from at, open ground.

A gimbal motor error may occur in these situations:

a. The aircraft is placed on uneven ground or the gimbal’s motion is obstructed.

b. The gimbal has been subjected to excessive external force, such as during a collision.

Flying in heavy fog or clouds may make the gimbal wet, leading to temporary failure. The

gimbal will recover full functionality once it dries.

Removing the Intelligent Flight Battery

Slide the battery latches on the sides of the Intelligent Flight Battery and it will pop out of the battery

compartment.

Never insert or remove the battery when it is turned on.

Ensure the battery is mounted rmly. The aircraft will not take o if the battery is mounted

incorrectly.

Mavic Air

User Manual

Do not remove the microSD card from the aircraft when it is turned on.

To ensure the stability of the camera system, single video recordings are capped at 30

minutes.

Camera

The onboard camera uses its 1/2.3” CMOS sensor to capture video at up to 4K at 30 fps and 12

megapixel stills. You can record video in either MOV or MP4 formats. Available picture shooting modes

include Single Shot, Burst, Interval, HDR, and various Panorama modes. A live preview of what the

camera is seeing can be monitored on a connected mobile device via the DJI GO 4 app.

Camera microSD Card Slot

The Mavic Air comes with 8 GB of internal storage, and it also supports using a microSD card to store

your photos and videos. A UHS-1 microSD card is required due to the fast read and write speeds

required for high-resolution video data.

microSD Card Slot

Remote Controller

This section describes the features

of the remote controller and includes

instructions for controlling the aircraft

and the camera.

Remote Controller

Built into the remote controller is DJI’s enhanced Wi-Fi technology, enabling a maximum transmission

distance of 2.49 miles (4 km)* and downlinking of 720p video from the aircraft to the DJI GO 4 app on

your mobile device. The detachable control sticks make the remote controller easier to store. Maximum

remote controller battery life is approximately 3 hours**. Refer to the remote controller diagram in the

Product Prole section.

Using the Remote Controller

The remote controller is powered by a rechargeable battery that has a capacity of 2970 mAh. Press

the Power button once to check the current battery level. Press once, then again and hold to turn the

remote controller on or o.

Controlling the Camera

Shoot videos/photos and adjust the camera’s tilt via the Shutter Button, Record Button, and Gimbal Dial

on the remote controller.

Charging the Battery

Use a USB-C cable to connect the USB adapter to the AC power adapter, then plug the USB adapter

into the Charging / Main Video Link port on the remote controller. It takes approximately two and a half

hours to fully charge the remote controller battery.

* The remote controller is able to reach its maximum transmission distance (FCC) in a wide open area with no electro-

magnetic interference and at an altitude of about 400 ft (120 m).

** Maximum battery life was tested under laboratory conditions using an iOS device. This value should be taken for ref-

erence only.

AC Power Adapter

Power Outlet

USB

Adapter

Mavic Air

User Manual

Right StickLeft Stick

Turn RightTurn Left

Down

RightLeft

Down

Turn RightTurn Left

RightLeft

Forward

Backward

Left Stick Right Stick

Forward

Backward

Right Stick

Down

Forward

Backward

Left Stick

Turn RightTurn Left

RightLeft

Controlling the Aircraft

The remote controller’s control sticks are used to control the aircraft’s orientation (yaw), forward/

backward movement (pitch), altitude (throttle), and left/right movement (roll). The function that each

control stick movement performs is determined by the choice of control stick mode. Three pre-

programmed modes (Mode 1, Mode 2, and Mode 3) are available and custom modes can be dened in

the DJI GO 4 app. The default mode is Mode 2.

In each of the three pre-programmed modes the Mavic Air hovers in place at a constant orientation

when both sticks are centered. Pushing a control stick away from the center position performs the

functions show in the gure below.

Mode 1

Mode 2

Mode 3

Mavic Air

User Manual

Remote

Controller

(Mode 2)

Aircraft

( Indicates Nose Direction)

Remarks

Moving the left stick up or down changes the

aircraft’s altitude. Push the stick up to ascend

and down to descend. The more the stick is

pushed away from the center position, the faster

the aircraft will change altitude. Always push the

stick gently to prevent sudden and unexpected

changes in altitude.

Moving the left stick to the left or right controls

the orientation of the aircraft. Push the stick left to

rotate the aircraft counter-clockwise and right to

rotate the aircraft clockwise. The more the stick is

pushed away from the center position, the faster

the aircraft will rotate.

Moving the right stick up and down changes the

aircraft’s pitch. Push the stick up to fly forward

and down to y backward. The more the stick is

pushed away from the center position, the faster

the aircraft will move.

Moving the right stick to the left or right changes

the aircraft’s roll. Push the stick left to y left and

right to fly right. The more the stick is pushed

away from the center position, the faster the

aircraft will move.

Keep the remote controller away from magnetic materials to avoid it being affected by

magnetic interference.

It is recommended that the control sticks are removed and stored in their storage slots on the

remote controller during transportation or storage to avoid them getting damaged.

The gure below explains how to use each control stick, using Mode 2 as an example.

Mavic Air

User Manual

Flight Mode Switch

Toggle the switch to select the desired flight mode.

Choose between P-mode and S-mode.

RTH Button

Press and hold the RTH button to start the Return-to-Home (RTH) procedure. The aircraft will then

return to the last recorded Home Point. Press this button again to cancel the RTH procedure and regain

control of the aircraft. Refer to the Return to Home section for more information about RTH.

SPORT

Function Button and Customizable Button

The functions of the Function button and Customizable button are set in the DJI GO 4 app.

Optimal Transmission Zone

The signal between the aircraft and the remote controller is most reliable when the antennas are

positioned in relation to the aircraft as depicted below.

strong

weak

Position Flight Mode

SPORT

P-mode

SPORT

S-mode

Ensure that the aircraft is flying within the optimal transmission zone. To maintain optimal transmission

performance, adjust the remote controller and antennas according to the gure above.

Mavic Air

User Manual

Linking the Remote Controller

Remote controllers that are bought together with a Mavic Air are linked before shipment. To link a

remote controller to a Mavic Air, follow the instructions below:

1. Power on the aircraft and the remote controller.

2. Launch DJI GO 4.

3. Select “Connect to the Aircraft’s Wi-Fi” and “Wired Connection”. And then select “Linking the remote

controller”.

4. Press and hold the aircraft’s Function button for two seconds. Release the button upon hearing a

single beep and the Front LEDs blink red.

5. When the status LED on the remote controller turns solid green and the Front LEDs turn solid red,

linking is complete.

Ensure the remote controller is within 1.6 ft (0.5 m) of the aircraft during linking.

DJI GO 4 App

This section introduces the main

functions of the DJI GO 4 app.

DJI GO 4 App

Use this app to control the gimbal, camera, and other aircraft functions. The app features Equipment,

Editor, SkyPixel, and Me sections, which are used for conguring your aircraft, and editing and sharing

your photos and videos with others.

Equipment

Device Menu

If it is not already selected, select Mavic Air from the device menu in the top left corner of the screen.

Function Menu

Tap in the top right corner of the screen to open the Function menu. This menu has ve options:

Scan QR Code: Scan a QR code to connect to an aircraft.

Academy: Use the ight simulator, watch tutorials, and read the product manuals.

Flight Records: Access all your ight records.

GEO zones: Read information about GEO zones.

Find My Drone: Get the map coordinates of your aircraft’s last-recorded location and command the

aircraft to blink its LEDs and make a beeping sound.

Camera View

Enter Camera View by tapping the “GO FLY” button on the Equipment screen with your mobile device

connected to the aircraft.

1. System Status Bar

READY TO GO (GPS)

: This icon indicates aircraft ight status and displays various warning messages.

2. Obstacle Detection Status

: Red bars are displayed when obstacles are close to the aircraft. Orange bars are displayed

when obstacles are in detection range.

61%

2.4G

GPS

09:29

ISO

SHUTTER

1600 0.31/8000

CAPACITY

1080P/2420GB

APAS

139m

7m/s 1.1m/s 627m

612m

In flight (GPS)

9 1087654321

Mavic Air

User Manual

3. Battery Level Indicator Bar

: The battery level indicator provides a dynamic display of the battery level. The colored zones on

the battery level indicator represent the power levels needed to carry out dierent functions.

4. Flight Mode

: The text next to this icon indicates the current ight mode.

Tap to congure the Flight Controller settings. These settings allow you to modify ight limits and set gain

values.

5. Camera Parameters

Displays camera parameters and the capacity of the internal storage and the microSD card.

TER

1600 0.31/8000

CAPACITY

1080P/2420GB

6. GPS Signal Strength

: Shows the current GPS signal strength. White bars indicate adequate GPS strength.

7. Forward and Backward Vision Systems Status

: Tap into this button to enable or disable features provided by the Forward and Backward Vision

Systems.

8. Wi-Fi Settings

2.4G

: Tap to enter the Wi-Fi Settings menu.

9. Battery Level

61%

: Shows the current battery level. Tap to view the battery information menu, set the various battery

warning thresholds, and view the battery warning history.

10. General Settings

: Tap to enter the General Settings menu to set units of measurement, enable/disable

livestream, and adjust ight route display settings.

11. Photo/Video Toggle

: Tap to switch between photo and video recording modes.

12. Gimbal Slider

: Displays the gimbal tilt angle.

13. Shoot / Record Button

/ : Tap to start shooting photos or recording video.

Mavic Air

User Manual

14. Camera Settings

: Tap to enter the Camera Settings menu.

Tap to set the camera’s ISO, shutter, and auto exposure settings.

Tap to select picture shooting modes. The Mavic Air supports Single Shot, Burst Shot,

Interval Shot, and various Panorama modes. Panorama supports four shooting sub-modes

and can capture and generate 32 megapixel sphere panorama photos.

Tap to enter the General Camera Settings menu.

15. Playback

: Tap to enter the playback page and preview photos and videos as soon as they are captured.

16. Flight Telemetry

D 30M

: Distance between the aircraft and the Home Point.

H 10.0M

: Height from the Home Point.

HS 10.0M/S

Aircraft horizontal speed.

VS 2.0M/S

Aircraft vertical speed.

17. Map

Tap to view the map.

18. Advanced Pilot Assistance Systems

APAS

: Tap to enable/disable the APAS feature. The APAS feature is disabled if the Forward and

Backward Vision Systems are disabled/unavailable.

19. Intelligent Flight Mode

: Tap to select Intelligent Flight Modes.

20. Smart RTH

: Tap to initiate the Smart RTH procedure and have the aircraft return to the last recorded Home

Point.

21. Auto Takeo/Landing

/ : Tap to initiate auto takeo or landing.

22. Back

: Tap to return to the main menu.

Mavic Air

User Manual

Controlling the Aircraft with a Mobile Device

You can connect a mobile device via Wi-Fi to control the aircraft with DJI GO 4:

1. Power on the aircraft.

2. Press and hold the Function button on the aircraft for four seconds until you hear a double beep,

which indicates that the aircraft has switched to mobile device control.

3. Launch the DJI GO 4 app and tap the icon in the top right corner of the screen. Next, scan the Wi-Fi

QR Code on the aircraft to start the connection procedure.

4. Tap to take o automatically. Put both your thumbs on screen and use the virtual joysticks to

maneuver the aircraft.

When ying with just a mobile device in a wide open area with no electromagnetic interference,

the maximum transmission distance is approximately 328 ft (100 m) at an altitude of 164 ft (50 m).

The Wi-Fi frequency can be set to 2.4 GHz (default) or 5 GHz. On supported mobile devices,

set Wi-Fi to 5 GHz for less interference.

Turn on your mobile device's Wi-Fi and enter the Wi-Fi password shown on the aircraft to

connect to the Mavic Air network if for any reason you cannot scan the QR code.

Linking is required when switching back to Remote Control mode.

To reset the Wi-Fi SSID and password, and to reset the Wi-Fi frequency to 2.4 GHz, press

and hold the aircraft’s Function button for about 6 seconds, until you hear three beeps.

Alternatively, tap “Help” in the DJI GO 4 app, then follow the instructions.

Only y with a mobile device in wide open areas with relatively little electromagnetic

interference. If your connection is adversely aected by interference, y with the remote

controller instead, or move to an area with less interference.

Editor

An intelligent video editor is built into the DJI GO 4 app. After recording several video clips and

downloading them to your mobile device, go to Editor on the home screen. You can then select a

template and a specied number of clips which are automatically combined to create a short lm that

can be shared immediately.

SkyPixel

View and share the photos and videos in the SkyPixel page.

If you already have a DJI account, you will be able to participate in forum discussions, and share your

creation with the community.

Mavic Air

User Manual

The area beyond the white circles is also responsive to control commands.

Left Right

Using Virtual Joysticks

Ensure the mobile device has been connected to the aircraft before using the virtual joysticks. The

illustrations below are based on Mode 2 (left stick controls throttle and yaw, right stick controls pitch

and roll). Tap to enable or disable the virtual joysticks.

09:29

61%

P-GPS

In flight (GPS)

Virtual Joysticks

Flight

This section describes safe ight

practices and ight restrictions.

Flight

Once pre-ight preparation is complete, it is recommended that you use the ight simulator in the DJI

GO 4 app to hone your ight skills and practice ying safely. Ensure that all ights are carried out in an

open area. Refer to the Remote Controller and DJI GO 4 App sections for information about using the

remote controller and the app to control the aircraft.

Flight Environment Requirements

1. Do not use the aircraft in severe weather conditions. These include wind speeds exceeding 10 m/s,

snow, rain, and fog.

2. Fly in open areas. Tall structures and large metal structures may aect the accuracy of the on-board

compass and GPS system.

3. Avoid obstacles, crowds, high voltage power lines, trees, and bodies of water.

4. Minimize interference by avoiding areas with high levels of electromagnetism such as locations near

power lines, base stations, electrical substations, and broadcasting towers.

5. Aircraft and battery performance is subject to environmental factors such as air density and

temperature. Be very careful when ying 16404 ft (5000 m) or more above sea level, since battery

and aircraft performance may be reduced.

6. The Mavic Air cannot use GPS within the polar areas. Use the Downward Vision System when ying

in such locations.

Flight Limits and GEO Zones

Abide by all laws and regulations when ying your Mavic Air. Flight limitations are applied by default

in order to help users operate this product safely and legally. Flight limitations include altitude limits,

distance limits, and GEO Zones.

When operating in P-mode, altitude limits, distance limits, and GEO Zones function concurrently to

manage ight safety.

Flight Altitude and Distance Limits

The ight altitude and distance limits may be changed in the DJI GO 4 app. The maximum ight altitude

setting cannot exceed 1640 ft (500 m). Based on these settings, your Mavic Air will y in a restricted

cylinder, as shown below:

Max Flight Altitude

Max Radius

Home Point

Height of aircraft

when turned on

Mavic Air

User Manual

GPS Signal Weak Blinking Yellow

Flight Limits DJI GO 4 App Aircraft Status Indicator

Max Altitude

Height is restricted to 16 feet (5 meters)

when the GPS signal is weak and

Downward Vision System is activated.

Height is restricted to 98 feet (30 meters)

when the GPS signal is weak and

Downward Vision System is inactivated.

Warning:

Height limit

reached.

N/A

Max Distance No limit

If the aircraft reaches one of the limits, you can still control the aircraft, but you cannot y it any farther.

If the aircraft ies out of the max radius, it will y back within range automatically when the

GPS signal is strong.

For safety reasons, please do not y close to airports, highways, railway stations, railway lines,

city centers, or other sensitive areas. Fly the aircraft only within your line of sight.

GEO Zones

All GEO Zones are listed on the DJI official website at http://www.dji.com/flysafe. GEO Zones are

divided into different categories and include locations such as airports, flying fields where manned

aircraft operate at low altitudes, borders between countries, and sensitive locations such as power

plants.

GPS Signal Strong Blinking Green

Flight Limits DJI GO 4 App Aircraft Status Indicator

Max Altitude

Aircraft's altitude cannot

exceed the specied value.

Warning: Height

limit reached.

N/A

Max Distance

Flight distance must be within

the max radius.

Warning: Distance

limit reached.

N/A

Preflight Checklist

1. Ensure the remote control device, smart device, and Intelligent Flight Battery are fully charged.

2. Ensure the Intelligent Flight Battery is mounted rmly.

3. Ensure the aircraft arms and landing gears are unfolded.

4. Ensure the propellers and propeller guards are in good condition and securely mounted and

tightened.

5. Ensure that there is nothing obstructing the motors and that the motors are functioning normally.

Ensure that the camera lens and Vision System sensors are clean.

6. Ensure the gimbal and camera are functioning normally.

7. Ensure that the DJI GO 4 app is successfully connected to the aircraft.

Mavic Air

User Manual

Auto Takeoff and Auto Landing

Auto Takeo

Use auto takeo only if the Aircraft Status Indicator is blinking green. Follow the steps below to use the

auto takeo feature:

1. Launch the DJI GO 4 app, and tap “GO FLY” to enter Camera View.

2. Complete all steps in the pre-ight checklist.

3. Tap .

4. If conditions are safe for takeo slide the slider to conrm and the aircraft will take o and hover 3.9 ft (1.2 m)

above the ground.

Auto Landing

Use auto landing only if the Aircraft Status Indicator is blinking green. Follow the steps below to use the

auto landing feature:

1. Tap .

2. If conditions are safe for landing condition slide the slider to conrm and the aircraft will commence

the auto landing procedure. Warnings will appear in the DJI GO 4 app if the aircraft detects that

conditions are not suitable for landing. Be sure to respond promptly.

During the auto landing procedure, auto landing can be aborted immediately by tapping in

the DJI GO 4 app.

The Aircraft Status Indicator indicates whether the aircraft is using GPS and/or the Downward

Vision System for ight control. Refer to the Aircraft LEDs and Status Indicator section for

more information.

It is recommended to wait until the GPS signal is strong before using the auto takeo.

Starting/Stopping the Motors

Starting the Motors

A Combination Stick Command (CSC) is used to start the motors. Push both sticks to the bottom

inner or outer corners to start the motors. Once the motors have started spinning, release both sticks

simultaneously.

Mavic Air

User Manual

Stopping Motors Mid-ight

Stopping motors mid-ight will cause the aircraft to crash. The motors should only be stopped mid-

ight in an emergency situation such as if a collision has occurred or if the aircraft is out of control and

is ascending/descending very quickly, rolling in the air, or if a motor has stalled. To stop the motors mid-

ight use the same CSC that was used to start the motors.

Test Flight

Takeo/Landing Procedures

1. Place the aircraft in an open, at area with the Aircraft Status Indicator facing towards you.

2. Turn on the aircraft and the remote controller.

3. Launch the DJI GO 4 app and enter Camera View.

4. Wait until the Aircraft Status Indicator blinks green quickly indicating that the Home Point has been

recorded and it is now safe to y.

5. Gently push the throttle stick to take o, or use auto takeo.

6. Pull the throttle stick or use auto landing to land the aircraft.

7. Turn o the aircraft and remote controller.

If the Aircraft Status Indicator blinks yellow quickly during ight, the remote control signal has

been lost and the aircraft will activate Failsafe RTH. Refer to the Return to Home section for

more information.

If the Aircraft Status Indicator blinking red slowly or quickly during ight a low battery level

warning or critically low battery level warning has occurred.

Watch the Mavic Air video tutorials to learn more about takeo/landing procedures.

Video Suggestions and Tips

1. The pre-ight checklist is designed to help you y safely and to ensure that you are able to shoot

video during ight. Go through the full pre-ight checklist before each ight.

2. Select the desired gimbal operation mode in the DJI GO 4 app.

3. Only shoot video when ying in P-mode.

Stopping the Motors

There are two methods to stop the motors.

1. Method 1: When the aircraft has landed, push and hold the left stick down. The motors will stop after

three seconds.

2. Method 2: When aircraft has landed, push the left stick down, then conduct the same CSC that was

used to start the motors, as described above. The motors will stop immediately. Release

both sticks once the motors have stopped.

Method 1 Method 2

Mavic Air

User Manual

4. Always y in good weather and avoid ying in rain or wind.

5. Choose the camera settings that suit your needs. Settings include photo format and exposure

compensation.

6. Perform ight tests to establish ight routes and preview scenes.

7. Push the control sticks gently to keep the aircraft’s movement smooth and stable.

Appendix

Specifications

Aircraft

Weight

430 g

Dimensions (L×W×H) Folded

168×83×49 mm

Unfolded

168×184×64 mm

Diagonal Length

213 mm (excluding propellers)

Max Ascent Speed 2 m/s (P-mode with RC); 4 m/s (S - mode); 2 m/s (P-mode without RC)

Max Descent Speed 1.5 m/s (P-mode with RC); 3 m/s (S -mode); 1 m/s (P-mode without RC)

Max Speed (Near Sea

Level, No Wind)

17.9 mph (28.8 km/h); P-mode with RC

42.5 mph (68.4 km/h); S-mode

6.7 mph (10 km/h); P-mode without RC

Max Service Ceiling Above

Sea Level

5000 m

Max Flight Time

21 minutes (0 wind at a consistent 15.5 mph (25 kph))

Max Hovering Time

20 minutes (0 wind)

Max Flight Distance

10 km (0 wind)

Max Wind Speed

Resistance

22 mph (10 m/s)

Max Tilt Angle

35° (S-mode); 25° (P-mode)

Max Angular Velocity

250°/s

Operating Temperature 32° to 104° F (0° to 40° C)

GNSS GPS/GLONASS

Operating Frequency 2.4-2.4835 GHz; 5.725-5.850 GHz

Transmitter Power (EIRP)

2.4 GHz:

FCC:

＜

28 dBm; CE:

＜

19 dBm; SRRC:

＜

19 dBm; MIC:

＜

19 dBm

5.8 GHz:

FCC:

＜

31 dBm; CE:

＜

14 dBm; SRRC:

＜

27 dBm

GPS Hover Accuracy

Range

Vertical: ±0.1 m (With Vision Positioning); ±0.5 m (With GPS Positioning)

Horizontal: ±0.1 m (With Vision Positioning); ±1.5 m (With GPS Positioning)

Internal Storage 8 GB

Gimbal

Stabilization 3-axis (tilt, roll, pan)

Max Control Speed (Tilt) 120°/s

Angular Vibration Range ±0.005°

Controllable Range Tilt

-90° to +0° (default setting); -90° to +17° (extended)

Vision System

Eective Sensing Speed

≤ 8 m/s

Altitude Range 0.3 to 26 ft (0.1 to 8 m)

Operating Range 1.6 to 98 ft (0.5 to 30 m)

Operating Environment Surfaces with diuse reection material, size > 20×20 mm and reectivity

> 20% (such as wall, trees, humans), adequate lighting (> 15 lux)

Mavic Air

User Manual

Directions Forward/Backward/Downward

FOV Forward: Horizontal: 50°, Vertical: 19°

Backward: Horizontal: 50°, Vertical: 19°

Downward: Front and Back: 67°, Left and Right: 53°

Sensing Range Forward:

Precision Measurement Range: 0.5-12 m

Detectable Range: 12-24 m

Backward:

Precision Measurement Range: 0.5-10 m

Detectable Range: 10-20 m

Camera

Sensor

1/2.3” CMOS; Eective pixels: 12 megapixels

Lens 85° FOV, 24 mm (35 mm format equivalent) f/2.8

Shooting Range: 0.5 m to innity

ISO Range Video: 100 to 3200 (Auto), 100 to 3200 (Manual)

Photo: 100 to 1600 (Auto), 100 to 3200 (Manual)

Electronic Shutter Speed 8 to 1/8000 s

Max Image Size 4056×3040

Still Photography Modes Single shot

HDR

Burst shooting: 3 frames

Auto Exposure Bracketing (AEB): 3/5 bracketed frames at 0.7 EV Bias

Interval (2/3/5/7/10/15/20/30/60 s)

Pano: 3×1: 42°×78°, W: 2048×H:3712

3×3: 119°×78°, W: 4096×H:2688

180°: 251°×88°, W: 6144×H:2048

Sphere (3×8+1): 8192×4096

Video Recording Modes 4K Ultra HD: 3840×2160 24/25/30 p

2.7K: 2720×1530 24/25/30/48/50/60 p

FHD: 1920×1080 24/25/30/48/50/60/120 p

HD: 1280×720 24/25/30/48/50/60/120 p

Video Storage Bitrate 100 Mbps

Supported File System FAT32

Photo JPEG / DNG (RAW)

Video MP4, MOV (MPEG-4 AVC/H.264)

Supported SD Cards microSD (Class 10 or UHS-1 rating required)

Remote Controller

Operating Frequencies 2.4-2.4835 GHz; 5.725-5.850 GHz

Max Transmission Distance

(Unobstructed, free of

interference)

2.4 GHz: FCC: 2.5 mi (4 km); CE/SRRC/MIC: 1.2 mi (2 km)

5.8 GHz: FCC: 2.5 mi (4 km); CE: 0.3 mi (0.5 km); SRRC: 1.6 mi (2.5 km)

Operating Temperature

Range

32° to 104° F (0° to 40° C)

Mavic Air

User Manual

Transmitter Power (EIRP)

2.4 GHz:

＜

26 dBm (FCC),

＜

18 dBm (CE),

＜

18 dBm (SRRC),

＜

18 dBm (MIC)

5.8 GHz:

＜

30 dBm (FCC),

＜

14 dBm (CE),

＜

26 dBm (SRRC)

Built-in Battery 2970 mAh

Operating Current/Voltage 1400 mA 3.7 V (Android)

750 mA 3.7 V (iOS)

Supported Mobile Device

Size

Thickness: 6.5 to 8.5 mm

Max length: 160 mm

Supported USB port types Lightning, Micro USB (Type-B), USB-C

Power Adapter

Input 100 to 240 V, 50/60 Hz, 1.4 A

Output Main: 13.2 V 3.79 A

USB: 5 V 2 A

Voltage 13.2 V

Rated Power 50 W

Intelligent Flight Battery

Capacity 2375 mAh

Voltage 11.55 V

Max Charging Voltage 13.2 V

Battery Type LiPo 3S

Energy 27.43 Wh

Net Weight Approx. 140 g

Charging Temperature

Range

5℃ to 40℃

Max Charging Power 60 W

Calibrating the Compass

It is recommended that the compass is calibrated in any of the following situations when ying outdoors:

1. Flying at a location farther than 31 miles (50 km) away from the last ight location.

2. The aircraft has not been own for more than 30 days.

3. A compass interference warning appears in the DJI GO 4 app and/or the Aircraft Status Indicator

blinks alternating red and yellow quickly.

DO NOT calibrate your compass where magnetic interference may occur, such as locations

close to magnetite deposits or large metallic structures such as parking structures, steel-

reinforced basements, bridges, cars, or scaolding.

DO NOT carry objects (such as cell phones) that contain ferromagnetic materials near the

aircraft during calibration.

It is not necessary to calibrate compass when ying indoors.

Mavic Air

User Manual

3. Hold the aircraft vertically, with its nose pointing downward, and rotate it 360 degrees around a

vertical axis.

4. If the Aircraft Status Indicator blinks red the calibration has failed. Change your location and try the

calibration procedure again.

The aircraft is able to take o immediately once the calibration has completed successfully.

If you do not take off within three minutes of completing the calibration it is possible that

another compass interference warning will appear while the aircraft is on the ground. If this

happens it indicates that the current location is not suitable for ying the aircraft, due to the

level of magnetic interference.

Calibration Procedure

Choose an open area to carry out the following procedure.

1. Tap the System Status Bar in the DJI GO 4 app and select “Calibrate”, then follow the on-screen

instructions.

2. Hold the aircraft horizontally and rotate it 360 degrees. The Aircraft Status Indicator will turn solid

green.

Mavic Air

User Manual

After-Sales Information

Visit https://www.dji.com/support to learn more about after-sales service policies, repair services and

support.

Ensure the aircraft is connected to the computer before powering on.

The firmware update will take around 15 minutes. It is normal that the gimbal goes limp,

aircraft status indicators blink, and the aircraft reboots. Please wait patiently until the update

is complete.

Ensure the computer has access to the Internet.

Before performing an update ensure the Intelligent Flight Battery has at least 50% power and

the remote controller has at least 30% power.

Do not disconnect the aircraft from the computer during an update.

Follow the instructions below to update the rmware through DJI Assistant 2:

1. With the aircraft powered o, connect the aircraft to a computer via the Micro USB port using a

Micro USB cable.

2. Power on the aircraft.

3. Launch DJI Assistant 2 and login with your DJI account.

4. Select “Mavic Air” and click on Firmware Updates on the left panel.

5. Select the rmware version that you wish to update to.

6. Wait for the rmware to be downloaded. The rmware update will start automatically.

7. Reboot the aircraft after the rmware update is complete.

Firmware Updates

Use DJI GO 4 or DJI Assistant 2 to update aircraft rmware.

Using DJI GO 4

When you connect the aircraft or remote controller to the DJI GO 4 app you will be notied if a new

rmware update is available. To start updating, connect your mobile device to the Internet and follow the

on-screen instructions. Note that you cannot update the rmware if the remote controller is not linked to

the aircraft.

Using DJI Assistant 2

The USB-C port is used when connecting the Mavic Air to a computer to update rmware.

This content is subject to change.

Download the latest version from

http://www.dji.com/mavic-air

If you have any questions about this document, please

contact DJI by sending a message to

[email protected]

MAVIC

is a trademark of DJI.

DJI Support

http://www.dji.com/support

Dji MAVIC AIR

Product's Documents

User Manual

Specifications

Dji MAVIC AIR Questions and Answers

Related Products

Dji E800 Multirotor Propulsion System

Dji AR36517 Mount 360-Degree Rotation for Insta360 X3 Mobile Phones - Versatile Clip for Live Broadcast and Accessories

Dji 10771328 Purple Panda Lavalier Microphone Kit

Dji Avata 2 Fly More Combo FPV Drone 4K Camera, Immersive Experience, One-Push Acrobatics, Built-in Propeller Guard 6941565980120

Dji Mavic 4 Pro Tri-Camera Drone 100MP Hasselblad, Ideal for Professionals 30km Video Range and 51-Min Flight Time 6937224109933

Dji Mavic 4 Pro Creator Combo Flagship Tri-Camera Drone 100MP Hasselblad Camera Long Flight Time Three Batteries 6937224110014
