Register your product and get support at
www.philips.com/welcome
EN User manual 3
DE Benutzerhandbuch 23
ES Manual del usuario 43
FR Mode d’emploi 63
IT Manuale utente 83
NL Gebruiksaanwijzing 103
PT Manual do utilizador 123
SV Användarhandbok 143
DCM2060
DCM2060_12_UM_Book1_V3.0.indb 1 11/15/2013 2:59:13 PM
3
English
EN
8 Troubleshooting 19
9 Notice 20
Contents
1 Important 4
Know these safety symbols 4
Hearing Safety 5
2 Your Micro System 6
Introduction 6
What’s in the box 6
Overview of the main unit 7
Overview of the remote control 8
3 Get started 9
Placement 9
Connect FM antenna 9
Prepare the remote control 10
Connect power 10
Store FM radio stations automatically 10
Set clock 11
Turn on 11
4 Play 12
Play disc 12
Play from USB 12
Play from iPod/iPhone/iPad 12
Play options 13
Adjust sound 14
Display different information 14
5 Listen to FM radio 15
Tune to FM radio stations 15
Program FM radio stations automatically 15
Program FM radio stations manually 15
Select a preset radio station 15
Show RDS information 15
Select stereo/mono broadcast 16
6 Other features 16
Set the alarm timer 16
Set the sleep timer 17
Play from external audio device 17
Listen through the headphone 17
7 Product information 18
Specications 18
USB playability information 18
Supported MP3 disc formats 19
DCM2060_12_UM_Book1_V3.0.indb 3 11/15/2013 2:59:14 PM
4
the disconnect device shall remain readily
operable.
Know these safety symbols
This ‘bolt of lightning’ indicates uninsulated
material within your unit may cause an electrical
shock. For the safety of everyone in your
household, please do not remove product
covering.
The ‘exclamation point’ calls attention to
features for which you should read the enclosed
literature closely to prevent operating and
maintenance problems.
WARNING:Toreducetheriskofreorelectric
shock, this apparatus should not be exposed to
rainormoistureandobjectslledwithliquids,
such as vases, should not be placed on this
apparatus.
CAUTION: To prevent electric shock, match
wide blade of plug to wide slot, fully insert.
Warning
• Never remove the casing of this apparatus.
• Never lubricate any part of this apparatus.
• Never place this apparatus on other electrical
equipment.
• Keep this apparatus away from direct sunlight, naked
amesorheat.
• Never look into the laser beam inside this apparatus.
• Ensure that you always have easy access to the power
cord, plug or adaptor to disconnect this apparatus from
the power.
1 Important
• Read these instructions.
• Follow all instructions.
• Do not block any ventilation openings.
Install in accordance with the
manufacturer’s instructions.
• Do not install near any heat sources such
as radiators, heat registers, stoves, or
otherapparatus(includingampliers)that
produce heat.
• Protect the power cord from being
walked on or pinched, particularly at plugs,
convenience receptacles, and the point
where they exit from the unit.
• Onlyuseattachments/accessoriesspecied
by the manufacturer.
• Unplug this unit during lightning storms or
when unused for long periods of time.
• Referallservicingtoqualiedservice
personnel.Servicingisrequiredwhenthe
unit has been damaged in any way, such
as power-supply cord or plug is damaged,
liquidhasbeenspilledorobjectshave
fallen into the apparatus, the unit has been
exposed to rain or moisture, does not
operate normally, or has been dropped.
• Battery usage CAUTION – To prevent
battery leakage which may result in bodily
injury, property damage, or damage to the
remote control:
• Install all batteries correctly, + and - as
marked on the remote control.
• Do not mix batteries (old and new or
carbonandalkaline,etc.).
• Remove batteries when the remote
control is not used for a long time.
• The unit shall not be exposed to dripping
or splashing.
• Do not place any sources of danger on
theunit(e.g.liquidlledobjects,lighted
candles).
• Where the plug of the Direct Plug-in
Adapter is used as the disconnect device,
EN
DCM2060_12_UM_Book1_V3.0.indb 4 11/15/2013 2:59:17 PM
5
English
Hearing Safety
Danger
• To avoid hearing damage, limit the time you use the
headphones at high volume and set the volume to a
safe level. The louder the volume, the shorter is the safe
listening time.
Be sure to observe the following guidelines
when using your headphones.
• Listen at reasonable volumes for
reasonable periods of time.
• Be careful not to adjust the volume
continuously upwards as your hearing
adapts.
• Do not turn up the volume so high that
you can’t hear what’s around you.
• You should use caution or temporarily
discontinue use in potentially hazardous
situations.
• Excessive sound pressure from earphones
and headphones can cause hearing loss.
Caution
• Use of controls or adjustments or performance of
procedures other than herein may result in hazardous
radiation exposure or other unsafe operation.
Norge
Typeskilt finnes på apparatens
underside.
Observer: Nettbryteren er sekundert
innkoplet. Den innebygde netdelen er
derfor ikke frakoplet nettet så lenge
apparatet er tilsluttet nettkontakten.
For å redusere faren for brann eller
elektrisk støt, skal apparatet ikke
utsettes for regn eller fuktighet.
EN
DCM2060_12_UM_Book1_V3.0.indb 5 11/15/2013 2:59:18 PM
6
• Mountingkit(2dowelsand2screws)
• FM antenna
• Rubber pad for iPad
• User manual
• Quick start guide
• Wall mounting instructions
If you contact Philips, you will be asked for the
model and serial number of this apparatus. The
model number and serial number are on the
bottom of the apparatus. Write the numbers
here:
Model No. __________________________
Serial No. ___________________________
2 Your Micro
System
Congratulations on your purchase, and
welcometoPhilips!Tofullybenetfromthe
support that Philips offers, register your product
at www.philips.com/welcome.
Introduction
With this unit, you can:
• enjoy audio from discs, iPod/iPhone/iPad,
USB devices, and other external devices
• listen to FM radio
You can enrich sound output with these sound
effects:
• DigitalSoundControl(DSC)
• DynamicBassBoost(DBB)
The unit supports these media formats:
What’s in the box
Check and identify the contents of your
package:
• Main unit
• Remote control
• Power adapter
• 1 x MP3 link cable
EN
DCM2060_12_UM_Book1_V3.0.indb 6 11/15/2013 2:59:19 PM
7
English
f OK/
• Conrmselection.
• Start/pause play.
g MP3-LINK
• Connect an external audio device.
h
• Open/close the disk tray.
i VOLUME + / -
• Adjust volume.
j MENU/
• Access iPod/iPhone/iPad menu.
• Stop play or erase a program.
k FM ANT
• Improve FM reception.
l DC IN
• Connect power.
Overview of the main unit
a
• Connect USB device.
b
• Headphone socket.
c
• Turn the unit on/off.
• Switch to standby mode.
d SOURCE
• Select a source: CD, FM, USB, Dock, or
MP3 LINK.
e /
• Skip to the previous/next track.
• Search within a track/disc.
• Tune to radio stations.
• Adjust time.
k
a
g
h
i
j
b
c
d
e
f
MICRO MUSIC SYSTEM DCM2060
l
m
n
FM ANT
DC IN
3A
V
12
o
DOCK for
SOURCE
VOLUME VOLUME
MP
3
-
LINK
MENU
/
OK
/
EN
DCM2060_12_UM_Book1_V3.0.indb 7 11/15/2013 2:59:25 PM
8
a
• Turn the unit on/off.
• Switch to standby mode.
b
• Mute/restore sound.
c CD
• Select CD source.
d /
• Skip to the previous/next track.
• Search within a track/disc.
• Tune to radio stations.
• Adjust time.
e USB/MP3 LINK
• Select USB/MP3 link source.
f RDS/DISPLAY
• For selected FM radio stations: display
RDS information.
• Show time and play information.
g
• Start/pause play.
h VOL +/-
• Adjust volume.
i Numeric Keypad 0 - 9
• Select a track from a disc or USB
device directly.
• Select a preset radio station.
j PROG/CLOCK SET
• Program tracks.
• Program radio stations.
• Set time.
k SLEEP/TIMER
• Set sleep/alarm timer.
l DSC
• Select a preset sound setting.
m DBB
• Turn dynamic bass enhancement
on/off.
m Display panel
• Show play information.
n Disc tray
o DOCK for iPod/iPhone/iPad
Overview of the remote
control
PRESET/ALBUM
PROG/
CLOCK SET
SLEEP/
TIMER
DSC DBB
FM
VOL
REPEAT/
SHUFFLE
3
456
789
1
0
2
CD
DOCK
DISPLAY
RDS
OK
MENU
USB
MP
3
LINK
a
b
c
e
f
g
p
o
d
h
i
j
m
n
k
l
s
r
q
EN
DCM2060_12_UM_Book1_V3.0.indb 8 11/15/2013 2:59:27 PM
9
English
3 Get started
Caution
• Use of controls or adjustments or performance of
procedures other than herein may result in hazardous
radiation exposure or other unsafe operation.
Always follow the instructions in this chapter in
sequence.
Placement
Youcanplacetheunitonaatsurfaceor
mount the unit on a wall.
Mount on a wall
See the wall mounting instructions included in
the package.
Connect FM antenna
Tip
• For optimal reception, fully extend and adjust the
position of the antenna.
Connect the supplied FM antenna to the FM
ANT socket on the main unit.
n REPEAT/SHUFFLE
• Play a track or all tracks repeatedly.
• Play tracks in current album
repeatedly.
• Play tracks randomly.
o MENU/
• Access iPod/iPhone/iPad menu.
• Stop play or erase a program.
p DOCK
• Select iPod/iPhone/iPad source.
q OK
• Conrmselection.
r /
• Select a preset radio station.
• Skip to previous/next album.
s FM
• Select FM tuner source.
EN
DCM2060_12_UM_Book1_V3.0.indb 9 11/15/2013 2:59:29 PM
10
Connect power
Caution
• Risk of product damage! Ensure that the power supply
voltage corresponds to the voltage printed on the back
or the underside of the unit.
• Risk of electric shock! When you unplug the AC power
cord, always pull the plug from the socket. Never pull
the cord.
• Before connecting the AC adapter, ensure that you have
completed all other connections.
Note
• The type plate is located at the back of the main unit.
Connect the power adapter to:
• the DC IN socket on the main unit.
• the wall socket.
Store FM radio stations
automatically
When the unit turns to FM tuner mode, and
no radio stations are stored, the unit begins to
store FM radio stations automatically.
1 Connect the unit to the power supply.
» [AUTO INSTALL - PRESS PLAY, STOP
CANCEL] (to auto install, press ;
to cancel, press )isdisplayed.
Prepare the remote control
Caution
• Risk of explosion! Keep batteries away from heat,
sunshineorre.Neverdiscardbatteriesinre.
• Risk of decreased battery life! Never mix different
brands or types of batteries.
• Risk of product damage! When the remote control is
not used for long periods, remove the batteries.
To install the remote control battery:
1 Open the battery compartment.
2 Insert 2 AAA batteries with correct
polarity(+/-)asindicated.
3 Close the battery compartment.
a
b
c
EN
DCM2060_12_UM_Book1_V3.0.indb 10 11/15/2013 2:59:31 PM
11
English
Turn on
Press .
» The unit switches to the last selected
source.
Note
• To select a source, press SOURCE repeatedly or the
source selection buttons on the remote control.
Switch to standby mode
Press again to switch the unit to standby
mode.
» Theclock(ifset)appearsonthedisplay
panel.
2 Press and hold for 3 seconds to start
full scan.
» The unit automatically stores FM radio
stationswithsufcientsignalstrength
andthenbroadcaststherstpreset
station.
Tip
• To exit storing mode, press or .
Set clock
1 In standby mode, press and hold CLOCK
SET on the remote control for two
seconds.
» [SET CLOCK] (setclock)scrollson
the display.
2 Press CLOCK SET again.
» The 12/24 hour format blinks.
3 Press / repeatedly to select hour
format.
4 Press CLOCK SETtoconrm.
» The hour digits blink.
5 Repeat steps 3-4 to set the hour.
6 Repeat steps 3-4 to set the minute.
7 Repeat steps 3-4 to select whether to
synchronize time of this unit with RDS
stations.
• [RDS TIME SYNC [N] ]: time
synchronization is deactivated.
• [RDS TIME SYNC [Y] ]: the unit
synchronizes time from the RDS
stations automatically.
Note
• The accuracy of the transmitted time depends on the
RDS station that transmits the time signal.
• If no button is pressed in 90 seconds, the unit exits
clock setting mode automatically.
EN
DCM2060_12_UM_Book1_V3.0.indb 11 11/15/2013 2:59:32 PM
12
Play from iPod/iPhone/iPad
You can enjoy audio from iPod/iPhone/iPad
through this unit.
Compatible iPod/iPhone/iPad
The unit supports the following iPod, iPhone
and iPad models:
Made for.
• iPod touch (1st, 2nd, 3rd, and 4th
generation)
• iPod nano (2nd, 3rd, 4th, 5th, and 6th
generation)
• iPhone 4
• iPhone 3GS
• iPhone 3G
• iPhone
• iPad 2
• iPad
Load the iPod/iPhone
1 Push DOCK for iPod/iPhone/iPad to open
the dock compartment.
2 Place the iPod/iPhone into the dock.
Load the iPad
For iPad or iPad 2, you can use the supplied
rubber pad to keep it stable.
4 Play
Play disc
1 Press to open the disc compartment.
2 Insert a disc with the printed side facing up.
3 Press to close the disc compartment.
4 Press CD on the remote control to select
the disc source.
» [Reading](reading)blinksfora
moment, then CD starts playing
automatically. If not, press .
Play from USB
Note
• Make sure that the USB device contains playable audio
content.
1 Insert the USB device into the socket.
2 Press USB on the remote control to select
the USB source.
» Play starts automatically. If not, press
.
EN
DCM2060_12_UM_Book1_V3.0.indb 12 11/15/2013 2:59:33 PM
13
English
When the unit is connected to power, the
docked iPod/iPhone/iPad begins to charge.
Tip
• For certain iPod models, it may take up to a minute
before the charging indication appears.
Play options
Pause/resume play
During play, press to pause/resume play.
Repeat/shufe play
1 During play, press REPEAT/SHUFFLE
repeatedly to select:
• : play the current track repeatedly.
• (forMP3/WMAonly):playall
tracks in this album repeatedly.
• : play all tracks repeatedly.
• : play all tracks randomly.
2 To resume normal play, press REPEAT/
SHUFFLE repeatedly until the above icons
disappear.
Skip to a track
For CD:
Press / to select another track.
For MP3 disc and USB:
1 Press / to select an album or a folder.
2 Press / toselectatrack/le.
Tip
• To select a track directly, you can also press a key on
the numerical keypad.
Search within a track
1 During play, press and hold / .
1 Push DOCK for iPod/iPhone/iPad to open
the dock compartment.
2 Place the rubber pad into the dock
compartment as indicated.
3 Place an iPad or iPad 2 into the dock.
Listen to the iPod/iPhone/iPad
1 Make sure that the iPod/iPhone/iPad is
loaded correctly.
2 Press SOURCE repeatedly or DOCK on
the remote control to select iPod/iPhone/
iPad source.
3 Play tracks in the iPod/iPhone/iPad.
• To pause/resume play, press .
• To skip to a track, press / .
• To search during play, press and hold
/ , then release to resume
normal play.
• To go back to the previous iPod/
iPhone/iPad menu, press MENU.
• To scroll through the menu, press
/ .
• Toconrmaselection,pressOK.
Remove the iPod/iPhone/iPad
Pull the iPod/iPhone/iPad out of the dock.
Charge the iPod/iPhone/iPad
Note
• iPod with color display, iPod classic, and iPod with video
are not compatible with dock charging.
EN
DCM2060_12_UM_Book1_V3.0.indb 13 11/15/2013 2:59:37 PM
14
Display different information
During play, press DISPLAY repeatedly to view
time and different play information.
2 Release to resume normal play.
Program tracks
You can program a maximum of 20 tracks.
1 In CD/USB mode, press to stop
playback, then press PROG to activate the
programming mode.
» [PROG] (program)isdisplayed.
2 For MP3/WMA tracks, press / to
select an album.
3 Press / to select a track, then press
PROGtoconrm.
4 Repeat steps 2 to 3 to program more
tracks.
5 Press to play the programmed tracks.
» During play, [PROG](program)is
displayed.
• To erase the program, when playback
is stopped, press .
Adjust sound
During play, you can adjust volume and select
sound effects.
Function Action
To increase/decrease volume Press VOL
+/-.
To mute/restore sound Press .
To turn dynamic bass
enhancement on/off
Press DBB.
To select a sound effect:
[POP](pop)
[JAZZ](jazz)
[CLASSIC](classic)
[ROCK](rock)
[FLAT](at)
Press DSC
repeatedly.
EN
DCM2060_12_UM_Book1_V3.0.indb 14 11/15/2013 2:59:37 PM
15
English
Program FM radio stations
manually
1 In tuner mode, tune to an FM radio station.
2 Press PROG to activate programming
mode.
» [PROG] (program)blinks.
3 Press / repeatedly to select a channel
number.
4 Press PROGagaintoconrm.
5 Repeat steps 1-4 to store other FM
stations.
Note
• To remove a pre-stored station, store another station
in its place.
Select a preset radio station
In tuner mode, press / or the numeric
buttons to select a preset number.
Show RDS information
RDS(RadioDataSystem)isaservice
that allows FM stations to show additional
information. If you tune to an RDS station, an
RDS icon is displayed.
1 Tune to an RDS station.
2 Press RDS repeatedly to scroll through the
followinginformation(ifavailable):
» Program service
» Program type such as [NEWS](news),
[SPORT](sport),[POP M] (pop
music)...
» Radio text message
» Time
5 Listen to FM
radio
Tune to FM radio stations
Note
• Position the antenna as far as possible from TV, VCR, or
other radiation source.
• Ensure that you have connected and fully extended the
supplied FM antenna.
1 Press FM to select FM tuner mode.
2 Press and hold / for 3 seconds.
» [SEARCH] (search)isdisplayed.
» The unit tunes to an FM station with
strong reception automatically.
3 Repeat step 2 to tune to more stations.
To tune to a weak station:
Press / repeatedlyuntilyoundoptimal
reception.
Program FM radio stations
automatically
Note
• You can program a maximum of 20 preset FM radio
stations.
In FM tuner mode, press and hold PROG for 3
seconds.
» [AUTO] (auto)isdisplayed.
» The unit stores all the FM radio stations
automaticallyandthenbroadcaststherst
preset radio station.
EN
DCM2060_12_UM_Book1_V3.0.indb 15 11/15/2013 2:59:38 PM
16
6 Other features
Set the alarm timer
This unit can be used as an alarm timer. You can
select CD, FM tuner, iPod/iPhone/iPad, or USB
as alarm source.
Note
• Make sure that you have set the clock correctly.
1 In standby mode, press and hold TIMER
until [SET TIMER](settimer)scrollsonthe
display.
» [SELECT SOURCE](selectsource)is
displayed.
2 Press SOURCE repeatedly or the source
selection buttons on the remote control to
select a source: disc, FM tuner, iPod/iPhone/
iPad, or USB.
3 Press TIMERtoconrm.
» The hour digits blink.
4 Press / repeatedly to set the hour.
5 Press TIMERtoconrm.
» The minute digits blink.
6 Repeat steps 4-5 to set the minute.
Note
• If no button is pressed in 90 seconds, the unit exits
alarm setting mode automatically.
• If iPod/iPhone/iPad is selected as alarm source, and you
have created a playlist called “PHILIPS” in iTunes and
import it to your iPod/iPhone/iPad, you will wake to a
random track in the playlist.
• If no “PHILIPS” playlist is created in the iPod/iPhone/
iPad or no track is stored in the playlist, you will wake
to your last listened track in the iPod/iPhone/iPad.
Select stereo/mono broadcast
Note
• Stereo broadcast is the default setting for tuner mode.
• For stations with weak signals: to improve the reception,
change to monaural sound.
In FM tuner mode, press OK to switch between
mono and stereo broadcast.
EN
DCM2060_12_UM_Book1_V3.0.indb 16 11/15/2013 2:59:38 PM
17
English
3 Start to play the external device (see the
device’susermanual).
Listen through the headphone
Plug a headphone into the socket on the unit.
To activate or deactivate the alarm timer,
In standby mode, press TIMER repeatedly to
activate or deactivate the alarm.
» appears when the timer is activated.
Tip
• If CD/USB/iPod source is selected, but no disc is
inserted or no USB/ipod/iPhone/iPad connected, the
unit switches to the tuner source automatically.
Set the sleep timer
Note
• Make sure that you have set the clock correctly.
When the unit is turned on, press SLEEP
repeatedly to select the sleep timer period (in
minutes).
» When sleep timer is activated, is
displayed.
Tip
• To deactivate the sleep timer, press SLEEP repeatedly
until [OFF](off)isdisplayed.
Play from external audio
device
With this unit, you can play audio from an
external audio device like MP3 player.
1 Connect the supplied MP3 Link cable to
• the MP3-LINK socket.
• the audio output socket of an external
device.
2 Press USB/MP3 LINK repeatedly to select
MP3 link mode.
EN
DCM2060_12_UM_Book1_V3.0.indb 17 11/15/2013 2:59:40 PM
18
Tuner (FM)
Tuning range 87.5 - 108 MHz
Tuning grid 50 KHz
Sensitivity
- Mono, 26dB S/N Ratio
- Stereo, 46dB S/N Ratio
<22 dBf
>43 dBf
Search selectivity >28 dBf
Total harmonic distortion <3%
Signal to noise ratio >50 dB
Number of presets 20
General information
AC power Model: AS360-120-
AE300;
Input: 100 - 240 V ~,
50/60 Hz, 1.2 A;
Output: 12 V 3.0 A
Operation Power
Consumption
25 W
Standby Power
Consumption
≤1W
Dimensions
- Main Unit (W x H
xD)
400 x 235 x 97.5 mm
Weight
- With Packing
- Main Unit
3.8 kg
2.2 kg
USB playability information
Compatible USB devices:
• USBashmemory(USB1.1)
• USBashplayers(USB1.1)
• memorycards(requiresanadditionalcard
readertoworkwiththisunit)
Supported formats:
• USBormemoryleformat:FAT12,FAT16,
FAT32(sectorsize:512bytes)
• MP3bitrate(datarate):32-320Kbpsand
variable bit rate
• WMA v9 or earlier
7 Product
information
Note
• Product information is subject to change without prior
notice.
Specications
Amplier
Rated Output
Power
2 X 10 W RMS
Frequency
Response
80 Hz - 16 kHz, ± 3 dB
Signal to Noise
Ratio
≥60dB
MP3 Link Input 0.5 V RMS 20 kohm
Disc
Laser Type Semiconductor
Disc Diameter 12 cm/8 cm
Support Disc CD-DA, CD-R, CD-RW,
MP3-CD, WMA-CD
Audio DAC 24 Bits/44.1 kHz
Total Harmonic
Distortion
<1.5%(1kHz)
FrequencyResponse 60 Hz - 16 kHz
S/N Ratio >55 dBA
EN
DCM2060_12_UM_Book1_V3.0.indb 18 11/15/2013 2:59:40 PM
19
English
8 Troubleshooting
Warning
• Never remove the casing of this apparatus.
To keep the warranty valid, never try to repair
the system yourself.
If you encounter problems when using this
apparatus, check the following points before
requestingservice.Iftheproblemremains
unsolved, go to the Philips web site (www.
philips.com/welcome).Whenyoucontact
Philips, ensure that the apparatus is nearby
and the model number and serial number are
available.
No power
• Ensure that the power adaptor of the unit
is connected properly.
• Ensure that there is power at the AC
outlet.
• As a power-saving feature, the system
switches off automatically 15 minutes after
track play reaches the end and no control
is operated.
No sound or poor sound
• Adjust the volume.
• Disconnect the headphones.
No response from the unit
• Disconnect and reconnect the AC power
plug, then turn on the unit again.
• As a power-saving feature, the system
switches off automatically 15 minutes after
track play reaches the end and no control
is operated.
Remote control does not work
• Beforeyoupressanyfunctionbutton,rst
select the correct source with the remote
control instead of the main unit.
• Reduce the distance between the remote
control and the unit.
• Insert the battery with its polarities (+/–
signs)alignedasindicated.
• Directory nesting up to a maximum of 8
levels
• Number of albums/ folders: maximum 99
• Number of tracks/titles: maximum 999
• ID3 tag v2.0 or later
• File name in Unicode UTF8 (maximum
length:16bytes)
Unsupported formats:
• Empty albums: an empty album is an album
thatdoesnotcontainMP3/WMAles,and
is not be shown in the display.
• Unsupportedleformatsareskipped.For
example,Worddocuments(.doc)orMP3
leswithextension.dlfareignoredand
not played.
• AAC,WAV,PCMaudioles
• DRMprotectedWMAles(.wav,.m4a,
.m4p,.mp4,.aac)
• WMAlesinLosslessformat
Supported MP3 disc formats
• ISO9660, Joliet
• Maximum title number: 999 (depending on
lenamelength)
• Maximum album number: 99
• Supportedsamplingfrequencies:32kHz,
44.1 kHz, 48 kHz
• SupportedBit-rates:32~320(kbps),
variable bit rates
EN
DCM2060_12_UM_Book1_V3.0.indb 19 11/15/2013 2:59:40 PM
20
9 Notice
Anychangesormodicationsmadetothis
device that are not expressly approved by
WOOX Innovations may void the user’s
authoritytooperatetheequipment.
This product complies with the radio
interferencerequirementsoftheEuropean
Community.
Thisproductcomplieswiththerequirements
of the following directives and guidelines:
2004/108/EC + 2006/95/EC
Your product is designed and manufactured
withhighqualitymaterialsandcomponents,
which can be recycled and reused.
When this crossed-out wheeled bin symbol is
attached to a product it means that the product
is covered by the European Directive 2002/96/
EC.
Please inform yourself about the local separate
collection system for electrical and electronic
products.
Please act according to your local rules and
do not dispose of your old products with your
normal household waste. Correct disposal of
your old product helps to prevent potential
negativeconsequencesfortheenvironmentand
human health.
Your product contains batteries covered by
the European Directive 2006/66/EC, which
• Replace the battery.
• Aim the remote control directly at the
sensor on the front of the unit.
No disc detected
• Insert a disc.
• Check if the disc is inserted upside down.
• Wait until the moisture condensation at
the lens has cleared.
• Replace or clean the disc.
• UseanalizedCDorcorrectformatdisc.
Cannot display some les in USB device
• ThenumberoffoldersorlesintheUSB
device has exceeded a certain limit. This
phenomenon is not a malfunction.
• Theformatsoftheselesarenot
supported.
USB device not supported
• The USB device is incompatible with the
unit. Try another one.
Poor radio reception
• Increase the distance between the unit and
your TV or VCR.
• Fully extend the FM antenna.
Timer does not work
• Set the clock correctly.
• Switch on the timer.
Clock/timer setting erased
• Power has been interrupted or the power
cord has been disconnected.
• Reset the clock/timer.
EN
DCM2060_12_UM_Book1_V3.0.indb 20 11/15/2013 2:59:43 PM
21
English
Thisequipmentshouldnotbeusedforsuch
purposes.
This apparatus includes this label:
cannot be disposed with normal household
waste.Please inform yourself about the local
rules on separate collection of batteries
because correct disposal helps to prevent
negativeconsequencesfortheenvironmental
and human health.
Environmental information
All unnecessary packaging has been omitted.
We have tried to make the packaging easy to
separateintothreematerials:cardboard(box),
polystyrenefoam(buffer)andpolyethylene
(bags,protectivefoamsheet.)
Your system consists of materials which can
be recycled and reused if disassembled by
a specialized company. Please observe the
local regulations regarding the disposal of
packaging materials, exhausted batteries and old
equipment.
“Made for iPod,” “Made for iPhone,” and “Made
for iPad” mean that an electronic accessory
has been designed to connect specifcally to
iPod, iPhone, or iPad, respectively, and has
been certifed by the developer to meet
Apple performance standards. Apple is not
responsible for the operation of this device
or its compliance with safety and regulatory
standards. Please note that the use of this
accessory with iPod, iPhone, or iPad may affect
wireless performance.iPod and iPhone are
trademarks of Apple Inc., registered in the U.S.
and other countries. iPad is a trademark of
Apple Inc.
The making of unauthorized copies of copy-
protected material, including computer
programs,les,broadcastsandsound
recordings, may be an infringement of
copyrights and constitute a criminal offence.
EN
DCM2060_12_UM_Book1_V3.0.indb 21 11/15/2013 2:59:44 PM
Specifications are subject to change without notice.
2013 © WOOX Innovations Limited. All rights reserved.
This product was brought to the market by WOOX Innovations
Limited or one of its affiliates, further referred to in this document as
WOOX Innovations, and is the manufacturer of the product. WOOX
Innovations is the warrantor in relation to the product with which
this booklet was packaged. Philips and the Philips Shield Emblem are
registered trademarks of Koninklijke Philips N.V.
DCM2060_12_UM_V3.0
DCM2060_12_UM_Book1_V3.0.indb 164 11/15/2013 3:02:40 PM
