1
GB
MHC-RG77 4-238-409-11 (2)
Mini Hi-Fi
Component
System
© 2002 Sony Corporation
Operating Instructions
4-238-409-11 (2)
MHC-GX8000/RG77
MHC-RG66T
GB
Owner’s Record
The model and serial numbers are located on the rear panel. Record the serial number
in the space provided below. Refer to them whenever you call upon your Sony dealer
regarding this product.
Model No. Serial No.
2
GB
MHC-RG77 4-238-409-11 (2)
WARNING
To prevent fire or shock hazard, do not
expose the unit to rain or moisture.
To avoid electrical shock, do not open the cabinet.
Refer servicing to qualified personnel only.
Do not install the appliance in a confined space,
such as a bookcase or built-in cabinet.
This appliance is classified
as a CLASS 1 LASER
product. The CLASS 1
LASER PRODUCT
MARKING is located on
the rear exterior.
To prevent fire, do not cover the ventilation of the
apparatus with news papers, table-cloths, curtains,
etc. And don’t place lighted candles on the apparatus.
To prevent fire or shock hazard, do not place objects
filled with liquids, such as vases, on the apparatus.
Don’t throw away the battery with
general house waste, dispose of it
correctly as chemical waste.
NOTICE FOR THE CUSTOMERS IN THE
U.S.A.
This symbol is intended to alert the
user to the presence of uninsulated
“dangerous voltage” within the
product’s enclosure that may be of
sufficient magnitude to constitute a
risk of electric shock to persons.
This symbol is intended to alert the
user to the presence of important
operating and maintenance (servicing)
instructions in the literature
accompanying the appliance.
WARNING
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there
is no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the
interference by one or more of the following
measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and
receiver.
– Connect the equipment into an outlet on a circuit
different from that to which the receiver is
connected.
– Consult the dealer or an experienced radio/TV
technician for help.
CAUTION
You are cautioned that any changes or modifications
not expressly approved in this manual could void
your authority to operate this equipment.
ENERGY STAR
®
is a U.S.
registered mark.
As an ENERGY STAR
®
partner,
Sony Corporation has determined
that this product meets the
ENERGY STAR
®
guidelines for
energy efficiency.
About this manual
The instructions in this manual are for
model MHC-GX8000, MHC-RG77 and
MHC-RG66T. In this manual, the MHC-RG77
is used for illustration purposes unless stated
otherwise.
3
GB
MHC-RG77 4-238-409-11 (2)
Table of Contents
List of Button Location and
Reference Pages
Main unit ............................................... 4
Remote Control ..................................... 5
Getting Started
Hooking up the system .......................... 6
Inserting two size AA (R6) batteries into
the remote ........................................ 8
Setting the clock .................................... 8
CD
Loading the CD ..................................... 9
Playing the CD
–– Normal Play/Shuffle Play/
Repeat Play ..................................... 9
Programming the CD tracks
–– Program Play ............................ 10
Tuner
Presetting radio stations ....................... 11
Listening to the radio
–– Preset Tuning ........................... 11
Tape
Loading a tape ..................................... 12
Playing a tape ...................................... 12
Recording to a tape
–– CD Synchro Recording/
High Speed Dubbing/Recording
Manually/Program Edit ................. 13
Timer-recording radio programs ......... 14
Sound Adjustment
Adjusting the sound ............................. 16
Selecting the speaker system ............... 16
Selecting the preset effect .................... 16
Adjusting the graphic equalizer and
storing the personal file ................. 17
Selecting the surround effect ............... 17
Other Features
Changing the spectrum analyzer
display ........................................... 18
Adjusting the brightness of the
display ........................................... 18
Enhancing the video game sound
— Game Sync ............................... 18
Mixing the sound
— Game Mixing ........................... 18
Singing along ....................................... 19
Falling asleep to music
— Sleep Timer .............................. 19
Waking up to music
— Daily Timer .............................. 20
Display
Turning off the display
— Power Saving Mode ................. 21
Using the display ................................. 21
Hooking Up the Optional
Components
Connecting an MD deck/VCR ............ 22
Connecting a Video Game Player ....... 22
Connecting external antennas .............. 23
Troubleshooting
Problems and remedies ........................ 24
Additional Information
Precautions .......................................... 26
Specifications ...................................... 27
4
GB
MHC-RG77 4-238-409-11 (2)
CD eg (7, 9, 10, 13, 14)
CD SYNC HI-DUB qf (13, 14)
DECK A A wh (12~14)
DECK B A qh (12~15)
DIMMER 9 (18)
DIRECTION q; (12~14)
DISC 1~3 4 (9, 10)
DISC SKIP EX-CHANGE 5 (9, 10)
Disc tray 3 (9)
DISPLAY 7 (21)
EDIT q; (14)
EFFECT ON/OFF rs (16)
ENTER ra (10, 11, 14, 15, 17, 20,
25)
FM MODE qs (11, 25)
GAME ea (18, 22)
GAME EQ rd (18)
GAME INPUT wd (13, 18)
GAME MIXING wl (13, 18)
GROOVE rf (16)
IR (receptor) 2
MD (VIDEO) es (22, 24)
MIC wa (19)
MIC LEVEL w; (19)
MOVIE EQ ek (16)
MUSIC EQ eh (16)
OPEN/CLOSE Z 6 (9, 10)
P FILE r; (17)
PHONES (jack) ql (24)
PLAY MODE e; (9, 10, 14)
REC PAUSE/START qg (13, 14)
REPEAT qs (10)
SPECTRUM 8 (18)
SURROUND el (17)
SURROUND SPEAKER MODE
(MHC-GX8000/RG77 only)
wj (16)
TAPE A/B ed (12, 13)
TUNER/BAND ef (11)
TUNER MEMORY e; (11)
VOLUME qa (20)
BUTTON DESCRIPTIONS
@/1 1
hH ws
x qd
X wk
> qj
. wg
M/+ qk
m/– wf
v/V/b/B ej
List of Button Location and Reference Pages
ALPHABETICAL ORDER
A - D
M - Q
1
23 4
5
6
7
8
9
0
K
L
M
N
O
qh
qj
qk
qlw;waws
W
X
wg
wh
wj
wk
wl
e;
ea
es
eg
ed
ef
ejeh
ek
el
ra
r;
rdrs
rf
How to use this page
Use this page to find the location of buttons and other
parts of the system that are mentioned in the text.
Main unit
Illustration number
r
PLAY MODE e; (9, 10, 14)
R R
Name of button/part Reference page
E - L
R - Z
MHC-RG77 4-238-409-11 (2)
List of Button Location and Reference Pages
5
GB
Remote Control
D
E
R
S
T
U
V
ABC
Y
X
W
qh
qj
qa
qs
qd
qf
7
q;
qg
8
9
6
CD ql (7, 9, 10, 13, 14)
CLEAR 7 (10, 14)
CLOCK/TIMER SELECT 2
(15, 20)
CLOCK/TIMER SET 3 (8, 14,
20)
D.SKIP 9 (9)
ENTER qd (8, 10, 11, 14, 15, 17,
20)
EFFECT ON/OFF qf (16)
GAME w; (18, 22)
MD (VIDEO) q; (22)
PRESET – wd (11)
PRESET + wf (11)
PRESET EQ qj (16)
P FILE qh (17)
SURROUND SPEAKER MODE
(MHC-GX8000/RG77 only) qs
(16)
SURROUND qs (17)
SLEEP 1 (19)
TAPE A/B qa (12, 13)
TUNER/BAND qk (11)
TUNING – wa (11)
TUNING + ws (11)
VOL +/– 8 (20)
BUTTON DESCRIPTIONS
@/1 4
hH wg
X 5
x 6
. wd
> wf
m wa
M ws
v/V/b/B qg
A - M P - Z
ALPHABETICAL ORDER
6
GB
MHC-RG77 4-238-409-11 (2)
Getting Started
Hooking up the system
Do the following procedure 1 to 5 to hook up your system using the supplied cords and
accessories.
AM loop antenna
Front speaker
(Left)
Front speaker
(Right)
FM antenna
4
5
3
1
2
2
Surround
speaker (Left)
(MHC-GX8000/
RG77 only)
1 Connect the front speakers.
Connect the speaker cords to the SPEAKER
(MHC-RG66T)/FRONT SPEAKER
(MHC-GX8000/RG77) jacks.
2 Connect the surround speaker
(MHC-GX8000/RG77 only).
Connect the speaker cords to SURROUND
SPEAKER jacks.
Note
Keep the speaker cords away from the antennas to
prevent noise.
LR
+
_
3 Connect the FM and AM antennas.
Set up the AM loop antenna, then connect
it.
Insert only the stripped portion.
Black/Stripe (#)Red/Solid (3)
Extend the FM lead
antenna horizontally.
AM loop antenna
Extend the FM lead
antenna horizontally.
AM loop antenna
FM75
AM
FM75
AM
Jack type A
Surround
speaker (Right)
(MHC-GX8000/
RG77 only)
Jack type B
Black/Stripe (#)Blue/Solid (3)
Insert only the stripped portion.
Red
LR
+
_
Blue
7
GB
MHC-RG77 4-238-409-11 (2)
Getting Started
4 For models with a voltage selector, set
VOLTAGE SELECTOR to the position of
your local power line voltage.
5 Connect the power cord to a wall outlet.
The demonstration appears in the display.
When you press ?/1, the system turns on
and the demonstration automatically ends.
If the supplied adaptor on the plug does not
fit your wall outlet, detach it from the plug
(only for models equipped with an adaptor).
To connect optional components
See page 22.
To attach the speaker pads
Attach the supplied speaker pads to the bottom
of the speakers to stabilize the speakers and
prevent them from slipping.
220V
120V
230-
240V
Front
speaker
(L)
Front
speaker
(R)
45º
Positioning the speakers
Place the front speakers at an angle of 45
degrees from your listening position.
Notice for carrying this system
Do the following to protect the CD
mechanism.
1 Make sure that all discs are removed
from the unit.
2 Hold down CD and then press ?/1 until
“LOCK” appears.
3 Release ?/1 first, then release CD.
4 Unplug the AC power cord.
Surround
speaker
(L)
Surround
speaker
(R)
(MHC-GX8000/
RG77 only)
(MHC-GX8000/
RG77 only)
8
GB
MHC-RG77 4-238-409-11 (2)
Inserting two size AA (R6)
batteries into the remote
Tip
With normal use, the batteries should last for about
six months. When the remote no longer operates the
system, replace both batteries with new ones.
Note
If you do not use the remote for a long period of time,
remove the batteries to avoid possible damage from
battery leakage.
Setting the clock
1 Turn on the system.
2 Press CLOCK/TIMER SET on the
remote.
When you set the time for the first time,
proceed to step 5.
3 Press V or v repeatedly to select
CLOCK SET.
4 Press ENTER.
5 Press V or v repeatedly to set the hour.
6 Press ENTER.
7 Press V or v repeatedly to set the
minute.
8 Press ENTER.
The clock starts functioning.
Tip
If you have made a mistake or want to change the
time, start over from step 2.
Note
The clock settings are canceled when you disconnect
the power cord or if a power failure occurs.
E
e
e
E
AA (R6)
batteries
9
GB
MHC-RG77 4-238-409-11 (2)
CD
Loading the CD
1 Press OPEN/CLOSE Z.
The CD compartment slides out.
2 Place a CD with the label side up on the
disc tray.
To insert additional discs, press DISC SKIP
EX-CHANGE to rotate the disc tray.
3 Press OPEN/CLOSE Z to close the CD
compartment.
Playing the CD
––Normal Play/Shuffle Play/Repeat
Play
This unit lets you play the CD in different play
modes.
1 When playback is stopped, press PLAY
MODE repeatedly until the mode you
want appears in the display.
2 Press one of the DISC 1~3 buttons.
If you press hH when CD is selected as
the function (press CD) and the disc tray is
closed, playback starts from the selected
CD.
Tip
You cannot change the play mode during playback.
Other Operations
To
Stop playback
Pause playback
Select a track
Find a point in a track
Select a CD when
playback is stopped
Switch to CD function
from another source
CD
When you play a CD
single, place it on the
inner circle of the
tray.
Select
ALL DISCS
1 DISC
SHUFFLE
ALL DISCS
SHUFFLE
1 DISC
PROGRAM
To play
All CDs in the disc tray
continuously.
The CD you have selected in the
original order.
The tracks on all CDs in random
order.
The tracks on the CD you have
selected in random order.
The tracks on all CDs in the
order you want them to be
played (see “Programming the
CD tracks” on page 10).
Do this
Press x.
Press X.
Press again to resume
playback.
During playback or pause,
press > (to go forward)
or . (to go back).
Press and hold down M
or m during playback and
release it at the point you
want.
Press one of the DISC 1~3
buttons or DISC SKIP EX-
CHANGE (or D. SKIP on
the remote).
Press CD or one of the
DISC 1~3 buttons
(Automatic Source
Selection).
continued
ALL1 DISCS
Track
number
Playing time
Disc presence
indicator
Disc tray number
10
GB
MHC-RG77 4-238-409-11 (2)
To
Play repeatedly
(Repeat Play)
Cancel Repeat
Play
Exchange other CDs
while playing
Remove the CD
*1
All the tracks repeated up to five times.
You cannot use this function during SHUFFLE
ALL DISCS.
*2
To repeat the current track you are playing.
Tip
Pressing the CD while the power is off automatically
turns the power on and CD is selected as a function.
Programming the CD
tracks
–– Program Play
You can make a program of up to 25 tracks
from all the CDs in the order you want them to
be played.
1 Press CD.
2 Press PLAY MODE repeatedly until
“PROGRAM” appears in the display.
3 Press one of the DISC 1~3 to select a
CD.
To program all the tracks on a CD at once,
proceed to step 5 while “AL” appears on the
display.
Playing the CD (continued)
Do this
Press REPEAT repeatedly to
select “REPEAT”
*1
or
“REPEAT 1”
*2
.
Press REPEAT until
“REPEAT”
or “REPEAT 1”
disappears from the display.
Press DISC SKIP
EX-CHANGE.
Press OPEN/CLOSE Z.
4 Press . or > repeatedly until the
track you want appears in the display.
5 Press ENTER.
The track(s) is (are) programmed. The
program step number appears, followed by
the total playing time.
6 To program additional tracks, repeat
steps 3 to 5.
Skip step 3 to select tracks from the same
disc.
7 Press hH.
To
Cancel Program Play
Clear a track from
the end
Add a track to the
program when
playback is stopped
Tips
• The program you made remains in the system’s
memory even after it has been played back. Press
hH to play the same program again.
• If “--.--” appears instead of the total playing time
during programming, this means:
– you have programmed a track number
which exceeds 20.
– the total playing time has exceeded 100 minutes.
Track
number
Total playing time
(including selected
track)
PROGRAM
Disc tray
number
Do this
Press PLAY MODE
repeatedly until “1 DISC” or
“ALL DISCS” appears in
the display.
Press CLEAR on the remote
when playback is stopped.
1 Press one of the DISC
1~3 buttons to select a
CD.
2 Press . or >
repeatedly to select the
track.
3 Press ENTER.
11
GB
MHC-RG77 4-238-409-11 (2)
Tuner
Tuner
Presetting radio stations
You can preset 20 stations for FM and 10
stations for AM.
1 Press TUNER/BAND repeatedly to
select FM or AM.
2 Press and hold M or m (or TUNING
+/– on the remote) until “AUTO”
appears in the display and the
frequency indication starts to change,
then release.
Scanning stops when the system tunes in a
station. “TUNED” and “STEREO” (for a
stereo program) appear.
3 Press TUNER MEMORY.
A preset number appears in the display.
4 Press . or > to select the preset
number you want to store.
5 Press ENTER.
“COMPLETE” appears in the display.
The station is stored.
6 Repeat steps 1 to 5 to store other
stations.
To tune in a station with a weak
signal (Manual Tuning)
Press M or m (TUNING +/– on the remote)
repeatedly to tune in the station manually.
To change the AM tuning interval
(Except Middle Eastern models)
The AM tuning interval is factory set to 9 kHz
(10 kHz in some areas). To change the AM tuning
interval, select any AM station first, then turn off the
power. While holding down the ENTER button, turn
the power back on. When you change the interval,
AM preset stations will be erased. To reset the
interval, repeat the same procedure.
Preset number
AUTO
MHz
Tips
• The preset stations are retained for half a day even
if you unplug the power cord or if a power failure
occurs.
• Pressing TUNER/BAND while the power is off
automatically turns the power on and TUNER is
selected as a function.
Listening to the radio
–– Preset Tuning
Preset radio stations in the tuner's memory first
(see “Presetting radio stations”).
1 Press TUNER/BAND repeatedly to
select FM or AM.
2 Press . or > (or press PRESET
+/– on the remote) to tune in the preset
station you want.
To listen to non-preset radio stations
Press M or m (or TUNING +/– on the
remote) repeatedly (Manual Tuning) or press
and hold M or m (or TUNING +/– on the
remote) (Automatic Tuning).
Tips
• When an FM program is noisy, press FM MODE so
that “MONO” appears in the display. There will be
no stereo effect, but the reception will improve.
• To improve broadcast reception, reorient the
antennas.
MHz
Preset number Frequency
12
GB
MHC-RG77 4-238-409-11 (2)
Loading a tape
1 Press TAPE A/B repeatedly to select
Deck A or B.
2 Press Z on the selected deck.
3 Insert a tape in deck A or B.
Playing a tape
1 Load a tape.
2 Press DIRECTION repeatedly to select
g to play one side, j to play both
sides or RELAY* (Relay Play) to play
both decks in succession.
3 Press hH. The tape starts playing.
Press hH again to play the reverse side.
* Relay Play always follow this cyclic sequence:
Deck A (front side) t Deck A (reverse side) t
Deck B (front side) t Deck B (reverse side)
Tape
Tape presence indicator
Insert with the
side you want to
play/record facing
forward.
To
Stop playback
Pause playback
Fast-forward
Rewind
Tips
• During j or Relay Play, the deck stops
automatically after repeating the sequence five
times.
• Pressing TAPE A/B while the power is off
automatically turns the power on and TAPE is
selected as a function.
• When a tape (tapes) is (are) inserted, corresponding
presence indicators light up.
Searching for the beginning of a
track (AMS*)
During playback, press . or > repeatedly
for the number of songs you want to skip
forward (or backward).
The search direction, + (forward) or – (back),
and number of songs being skipped (1~9)
appear in the display.
* AMS (Automatic Music Sensor)
Note
The AMS function may not operate correctly under
the following circumstances:
– When the unrecorded space between songs is less
than 4 seconds long.
– When the unit is placed near a television.
Example: searching forward 2 songs
ALL1 DISCS
Do this
Press x.
Press X.
Press again to resume
playback.
Press M while playing the
front side, or press m while
playing the reverse side.
Press m while playing the
front side, or press M while
playing the reverse side.
13
GB
MHC-RG77 4-238-409-11 (2)
Tape
Recording to a tape
–– CD Synchro Recording/High Speed Dubbing/Recording Manually/
Program Edit
You can record from a CD, tape, radio or other connected component. The recording level is adjusted
automatically.
Recording from a tape
(High-Speed Dubbing)
Recording from a CD
(CD Synchro Recording)
Recording Manually
Insert a recordable tape into deck B.
Press TAPE A/B repeatedly
to select TAPE A.
Press CD.
Press a function button
for the recording source.
Load the tape you want to
record into deck A.
Load the CD you want to
record.
Load the CD or tape
(or other audio
sources), or tune to the
station you want to
record.
Press CD SYNC HI-DUB.
Press REC PAUSE/
START.
DECK B stands by for recording.
REC PAUSE/START indicator flashes.
Press DIRECTION repeatedly to select g to record on one side.
Select j (or RELAY) to record on both sides.
Press REC PAUSE/START. If you are recording manually, press hH to start
playing the source (for CD or Tape).
Recording starts.
Tips
• When you record on both sides, be sure to start
from the front side. If you start from the reverse
side, recording stops at the end of the reverse side.
• For recording from the reverse side:
After step 1, press TAPE A/B to select deck B and
press hH twice to start playback of the reverse
side. Press x at the point where you want to start
recording. The TAPE B reverse side indicator lights
up.
• (High-Speed Dubbing only)
If you set direction to j when the tapes you use
have different lengths, the tapes in each deck
reverses independently. If you select RELAY, the
tapes in both decks reverse together.
• For recording from the radio:
If noise is heard while recording from the radio,
move the respective antenna to reduce the noise.
Press x to stop recording.
Steps
1
2
3
4
5
6
7
• For recording from a CD to a tape manually:
You can press . or > to select tracks during
recording pause mode (after step 4 and before step
6).
• You can mix the sound from the component
connected to the GAME INPUT jacks with another
function such as CD, tape, radio or an MD
connected to this system. To record the mixed
sound, press GAME MIXING after step 4 of
“Recording Manually” and then press REC
PAUSE/START to start recording. Game Mixing
does not function during High-Speed Dubbing and
CD Synchro Recording.
Note
You cannot listen to other sources while recording.
continued
14
GB
MHC-RG77 4-238-409-11 (2)
Recording a CD by specifying
track order
— Program Edit
You can record tracks from all the CDs in the
order you want. When programing, make sure
the playing times for each side do not exceed
the length of one side of the tape.
1 Insert a recordable tape into deck B,
then press CD.
2 Press PLAY MODE repeatedly until
“PROGRAM” appears in the display.
3 Press one of the DISC 1–3 button to
select a CD.
To program all the tracks on a CD at once,
proceed to step 6 while “AL” appears in the
display.
4 Press . or > repeatedly until the
tracks you want appears in the display.
5 Press ENTER.
The track(s) is (are) programmed. The
program step number appears, followed by
the total playing time.
6 To program additional tracks, repeat
steps 3 to 5.
Skip step 3 to select tracks from the same
disc.
7 Press CD SYNC HI-DUB.
Deck B standby for recording. The REC
PAUSE/START indicator flashes.
8 Press DIRECTION repeatedly to select
g to record on one side. Select j
(or RELAY) to record on both sides.
9 Press REC PAUSE/START.
Recording starts.
Recording to a tape (continued)
To
Cancel Program Edit
Clear a track from
the end
Tip
To check the required tape length for recording a CD,
press EDIT after you have loaded a CD and pressed
CD. The required tape length for the currently
selected CD appears, followed by the total playing
time for side A and side B respectively (Tape Select
Edit).
Note
You cannot use Tape Select Edit for discs containing
over 20 tracks.
Timer-recording radio
programs
To timer-record, you must preset the radio
station (see “Presetting radio stations” on
page 11) and set the clock (see “Setting the
clock” on page 8) beforehand.
1 Tune in the preset radio station (see
“Listening to the radio” on page 11).
2 Press CLOCK/TIMER SET on the
remote.
“DAILY1 SET” appears.
3 Press V or v repeatedly to select “REC
SET”, then press ENTER.
“ON” appears and the hour indication flash
in the display.
4 Set the time to start recording.
Press V or v repeatedly to set the hour, then
press ENTER.
The minute indication starts flashing.
Press V or v repeatedly to set the minute,
then press ENTER.
The hour indication flashes again.
Do This
Press PLAY MODE
repeatedly until “1 DISC” or
“ALL DISCS” appears in
the display.
Press CLEAR on the remote
when playback is stopped.
15
GB
MHC-RG77 4-238-409-11 (2)
Tape
5 Set the time to stop recording following
the above procedure.
The start time appears, followed by the stop
time, the preset radio station to be recorded
(e.g., “TUNER FM 5”), then the original
display appears.
6 Insert a recordable tape into deck B.
Make sure the tape is in forward direction.
7 Turn off the power.
When the recording starts, the volume level
is set to the minimum.
To
Check the setting
Change the setting
Cancel timer
operation
Notes
• If the power is on at the preset time, the Timer
recording does not work.
• The power turns on 15 seconds before the preset
time.
Do this
Press CLOCK/TIMER
SELECT on the remote and
press V or v repeatedly to
select “REC SEL”. Then, press
ENTER.
Start from step 1.
Press CLOCK/TIMER
SELECT on the remote and
press V or v repeatedly to
select “TIMER OFF”. Then,
press ENTER.
16
GB
MHC-RG77 4-238-409-11 (2)
Sound Adjustment
Adjusting the sound
You can reinforce the bass and create a more
powerful sound.
Press GROOVE.
Each time you press this button, the display
changes cyclically as follows:
GROOVE t V-GROOVE t GROOVE OFF
GROOVE
The volume switches to power mode and the
equalizer curve changes.
V-GROOVE
The volume switches to power mode, the low
base frequencies are powerfully reinforced, and
the equalizer curve changes.
Selecting the speaker
system
(MHC-GX8000/RG77 only)
You can enjoy different sounds when you
select the surround speaker mode.
Press SURROUND SPEAKER MODE to
select the surround speaker mode you
want.
LINK : Reproduces the same sound with the
different output level.
MATRIX SUR : Reproduces a wide range of
sound that actually can sense the size of the
room.
Selecting the preset
effect
Press MUSIC EQ, MOVIE EQ or GAME EQ
(or PRESET EQ on the remote) repeatedly to
select the preset effect you want.
The preset effect name appears in the display.
See the chart “Preset effect options”.
To cancel the effect
Press EFFECT ON/OFF repeatedly until
“EFFECT OFF” appears.
Preset effect options
“
SUR
” appears if you select an effect with
surround effects.
MENU Effect
button
MUSIC ROCK
EQ POP
JAZZ
DANCE
SOUL
ORIENTAL*
MOVIE ACTION
EQ DRAMA
MUSICAL
GAME ARCADE
EQ RACING
ADVENTURE
* CLASSIC for Latin and North American models
only.
For
standard music
sources.
soundtracks and
special listening
situations.
Play station 1, 2 and
other video game
music sources.
17
GB
MHC-RG77 4-238-409-11 (2)
Sound Adjustment
Adjusting the graphic
equalizer and storing a
personal file
You can adjust the sound by raising or
lowering the level of specific frequency band,
then store up to three personal files (P FILE) in
the memory.
Before operation, select the preset effect you
want for your basic sound.
1 Press b or B repeatedly to select a
frequency band or surround, then
press v or V to adjust the level or
select the surround effect.
2 Press and hold P FILE until the
personal file number appears in the
display.
3 Press v or V or B or b to select the
personal file number (P FILE) where
you want to store the equalizer setting.
4 Press ENTER.
The setting is automatically stored as the
personal file you selected in step 3. The
previous setting stored at this memory
location is erased and replaced by the new
setting.
To call up the personal file
Press P FILE repeatedly until the personal file
number you want appears in the display.
Tip
If you do not want to store a personal file, press
ENTER after step 1.
Frequency band Frequency level
Selecting the surround
effect
Press SURROUND.
Each time you press the button, the display
changes as follows:
SURROUND ON (
SUR
)
Y
SURROUND OFF
Note
When you choose other sound effects, the surround
effect may be cancelled.
18
GB
MHC-RG77 4-238-409-11 (2)
Other Features
Changing the spectrum
analyzer display
Press SPECTRUM.
Each time you press the button, the display
changes cyclically as follows:
SPECTRUM 1 t SPECTRUM 2 t
SPECTRUM 3 t PATTERN 1 t
PATTERN 2 t PATTERN 3 t
PATTERN OFF
Adjusting the brightness
of the display
Press DIMMER.
Each time you press the button, the display
changes cyclically as follows:
DIMMER 1 t DIMMER 2 t DIMMER 3
Enhancing the video game
sound
— Game Sync
You need to connect a video game player
(see “Connecting a Video Game Player” on
page 22).
Press GAME.
Tips
• In standby mode, the system automatically turns on.
• The previously selected GAME EQ is automatically
selected.
• This operation cannot be performed in the Power
Saving Mode.
Mixing the sound
— Game Mixing
You can mix the sound from the component
connected to the GAME INPUT jacks with
another function such as CD, tape, radio or
an MD connected to this system.
1 Select source sound you want.
2 Press GAME MIXING.
Each time you press the button, the level of
the game sound changes cyclically as
follows:
MIXING LOW t MIXING MID t
MIXING HIGH t MIXING OFF
Tips
• To record the mixed sound, press GAME MIXING
after step 4 of “Recording Manually” on page 13
and then press REC PAUSE/START to start
recording.
• The GAME MIXING indicator lights up while
Game Mixing is activated and it will remain active
while the power is on even if the function is
changed.
Notes
• Game Mixing is cancelled when you press REC
PAUSE/START.
• Game Mixing does not function during High Speed
Dubbing and CD Synchro Recording.
19
GB
MHC-RG77 4-238-409-11 (2)
Other Features
Singing along
You can sing along with any stereo CD or
Tape. You need to connect an optional
microphone.
1 Turn MIC LEVEL to MIN to turn down
the microphone volume.
2 Connect an optional microphone to MIC
jack.
3 Start playing the music and adjust the
volume.
4 Adjust the microphone volume by
turning MIC LEVEL.
After you have finished.
Turn MIC LEVEL to MIN and disconnect the
microphone from MIC jack.
Tips
• You can mix and record sound from microphone
after step 2. To record the sound see “Recording
Manually” on page 13. To stop recording, press x.
• If acoustic feedback (howling) occurs, move the
microphone away from the speakers or change the
direction of the microphone.
• If you want to record your voice through the
microphone only, you can do so by selecting the
CD function and not playing a CD.
• When high level sound signals are input, the unit
automatically adjust the recording level to prevent
distortion of the recorded sound signals (Auto
Level/ Control Function).
Note
The microphone does not function during High Speed
Dubbing.
Falling asleep to music
— Sleep Timer
You can set the system to turn off at a preset
time, so you can fall asleep to the music.
Press SLEEP on the remote.
Each time you press the button, the minute
display (the turn-off time) changes as follows:
AUTO* t 90 t 80 t 70 t … t 10 t
OFF
* The power turns off when the current CD or tape
finishes playback (for up to 100 minutes).
To
Check the remaining
time
Change the time to turn
off
Cancel the Sleep Timer
Do this
Press SLEEP once.
Press SLEEP
repeatedly to select the
time you want.
Press SLEEP
repeatedly until
“SLEEP OFF” appears.
20
GB
MHC-RG77 4-238-409-11 (2)
Waking up to music
— Daily Timer
You can wake up to music at a preset time
every day. Make sure you have set the clock
(see “Setting the clock” on page 8).
1 Prepare the music source you want to
play.
• CD: Load a CD. To start from a specific
track, make a program (see “Programming
the CD tracks” on page 10).
• Tape: Load a tape with the side you want
to play facing forward.
• Radio: Tune in the preset station you
want (see “Listening to the radio” on page
11).
2 Adjust the volume.
3 Press CLOCK/TIMER SET on the
remote.
“DAILY1 SET” appears.
4 Press V or v repeatedly to select
“DAILY1 SET (or DAILY2 SET)”, then
press ENTER.
“ON” appears and the hour digits flash in
the display.
5 Set the time to start playback.
Press V or v repeatedly to set the hour,
then press ENTER.
The minute indication flashes.
Press V or v repeatedly on the remote to
set the minute, then press ENTER.
The hour indication flashes again.
6 Set the time to stop playback following
step 5 above.
7 Press V or v repeatedly until the music
source you want appears.
The indications change as follows:
t TUNER y CD PLAY T
t TAPE PLAY T
8 Press ENTER.
The type of timer (“DAILY1” or
“DAILY2”), followed by the start time, stop
time and the music source appears, then the
original display appears.
9 Turn off the power.
To
Check the setting
Change the setting
Cancel the timer
operation
Tip
The power turns on 15 seconds before the preset time.
Note
If the power is on at the preset time, the Daily Timer
does not work.
Do this
Press CLOCK/TIMER
SELECT on the remote and
press V or v repeatedly to
select the respective mode
(“DAILY1” or “DAILY2”),
then press ENTER.
Start from step 1.
Press CLOCK/TIMER
SELECT on the remote and
press V or v repeatedly to
select “TIMER OFF”, then
press ENTER.
MHC-RG77 4-238-409-11 (2)
Display
21
GB
Display
Turning off the display
— Power Saving Mode
The demonstration display (the display changes
and the indicators flash even when the system
is turned off) and the clock display can be
turned off to minimize the amount of power
consumed during standby mode (Power Saving
Mode).
Press DISPLAY repeatedly while the
system is turned off until the
demonstration display or the clock display
disappears.
To cancel Power Saving Mode
Press DISPLAY once to show the
demonstration, twice to show the clock
display.
Each time you press the button, the system
changes cyclically as follows:
Demonstration t Clock* t Power Saving
Mode
* “--.-- ” appears in the display if you have not set the
clock.
Tips
• The @/1 indicator lights up even in Power Saving
Mode.
• The timer continues to operate in Power Saving
Mode.
• During Power Saving Mode, the following
functions do not work:
— Setting the time.
— Changing the AM tuning interval.
— Pressing a function button to turn the power on.
— Switching the function of MD (VIDEO).
Using the display
You can check the remaining time of the
current track or that of the CD.
When a CD TEXT disc is loaded, you can
check the information stored on the disc, such
as the titles. When the unit detects CD TEXT
discs, the “CD-TEXT” indication appears in
the display.
Press DISPLAY.
Each time you press the button, the display
changes cyclically as follows:
During normal playback
Playing time of the current track t Remaining
time of the current track t Remaining time of
the current CD (“1 DISC” mode) or “--.-- ”
display (“ALL DISCS” mode) t Title name
of the current track
1)
t Clock display (for
eight seconds) t Effect status
When playback is stopped
When the CD player is in program mode and
there is a program:
The last track number of the program and the
total playing time
2)
t Total number of
programmed tracks (for eight seconds)
3)
t
Title name of the CD
1)
t Clock display (for
eight seconds) t Effect status
In other conditions:
Total number of tracks and the total playing
time t Title name of the CD
1)
t Clock
display (for eight seconds) t Effect status
1)
With CD TEXT discs only (certain characters
cannot be displayed). Depending on the disc,
some CD TEXT information may not appear.
2)
“--.-- ” appears in the following cases:
– when the CD contains 21 tracks or more,
and the track number which exceeds 20 is
selected.
– when the program time exceeds 100 minutes.
3)
“CD NO STEP” appears in the display if there is
no program track.
22
GB
MHC-RG77 4-238-409-11 (2)
Hooking Up the Optional Components
Connecting a Video Game
Player
You can enjoy the video games with audio
emphasis by connecting a video game player.
To
Listen to the sound
of a connected
video game player
Select the preset effect
Note
Pressing GAME while the power is off automatically
turns the power on and GAME is selected as a
function. The equalizer also switches to GAME EQ
and the previously selected effect is restored.
To the audio and video output of your
video game player.
To the video input of your TV
Do this
Press GAME (or GAME on
the remote).
(See “Selecting the preset
effect” on page 16)
Optical cover holder
To the
DIGITAL IN
jack of your
MD deck
To the audio
output of your
MD deck/VCR
Connecting an MD deck
or VCR
You can connect your MD deck or VCR to this
system. Be sure to match the color of the plugs
and the connectors.
To
Make a digital
recording from
CD to MD
Listen to the analog
sound of a connected
MD deck
Listen to the
connected VCR
Tip
When you remove the optical cover, keep it at the
optical cover holder provided.
Notes
• Pressing the MD (VIDEO) while the power is off
automatically turns the power on and MD is
selected as a function.
• If the sound is distorted or too loud when VIDEO
function is selected, or you want to switch back to
MD function, repeat the operation described above
to switch to MD function.
Do This
Connect an optional optical
cable.
Press MD (VIDEO).
Hold down MD (VIDEO) and
press @/1 while the power is
on. Release @/1 first, then
release MD (VIDEO). This
switches the function from
MD to VIDEO. Once you
switched to the VIDEO
function, just press MD
(VIDEO).
MHC-RG77 4-238-409-11 (2)
Hooking Up the Optional Components
23
GB
Connecting external
antennas
Connect an external antenna to improve the
reception.
FM antenna
Connect an optional FM external antenna. You
can also use the TV antenna instead.
FM75
AM
AM antenna
Connect a 6 to 15 meter (20 to 50 feet)
insulated wire to the AM antenna terminal.
Leave the supplied AM loop antenna
connected.
FM75
AM
Insulated wire (not supplied)
24
GB
MHC-RG77 4-238-409-11 (2)
Problems and remedies
If you run into any problem using this unit, use
the following check list.
First, check that the power cord is connected
firmly and the speakers are connected correctly
and firmly.
Should any problem persist, consult your
nearest Sony dealer.
General
The display starts flashing as soon as you plug
in the power cord even though you haven’t
turned on the power.
The demonstration mode started. Press @/1. (see
step 5 on page 7)
The clock/timer setting is canceled.
• The power cord is disconnected or a power
failure occurs. Redo “Setting the clock”
(on page 8). If you have set the timer, redo
“Waking up to music” (on page 20) and
“Timer-recording radio programs” (on page 14).
The radio presetting is canceled.
• The power cord is disconnected or a power
failure occurs for longer than half a day. Redo
“Presetting radio stations” (on page 11).
There is no sound.
• Turn VOLUME clockwise.
• The headphones are connected to the PHONES
jack.
• Insert only the stripped portion of the speaker
cord into the SPEAKER jack. Inserting the vinyl
portion of the speaker cord will obstruct the
speaker connections.
• The protective device on the amplifier has been
activated because of short circuit. (“PROTECT”
and “PUSH POWER” flash alternately.) Turn off
the unit, eliminate the short-circuit problem and
turn on the power again.
• There is no audio output during Timer-
Recording.
There is severe hum or noise.
• A TV or VCR is placed too close to the unit.
Move the unit away from the TV or VCR.
The sound from the component connected to the
MD (VIDEO) jacks is distorted.
• If “VIDEO” appears in the display when you
press MD (VIDEO), switch to “MD” function
(see “Note: Connecting an MD deck/VCR” on
page 22).
“-- --:-- --” appears in the display.
• A power interruption occurred. Set the clock and
timer settings again.
The timer does not function.
• Set the clock correctly.
• You cannot activate the Daily timer and Timer-
recording simultaneously.
“DAILY1 SET”, “DAILY2 SET”, and “REC SET”
do not appear when you press the CLOCK/
TIMER SET button.
• Set the timer correctly.
• Set the clock.
The remote does not function.
• There is an obstacle between the remote and the
system.
• The remote is not pointing in the direction of the
unit’s sensor.
• The batteries have run down. Replace the
batteries.
There is acoustic feedback.
• Decrease the volume level.
• Move the microphone away from the speakers or
change the direction of the microphone.
The color irregularity on a TV screen persists.
• Turn off the TV set once, then turn it on after 15
to 30 minutes. If the color irregularity still
persists, place the speakers farther away from the
TV set.
“PROTECT”and “PUSH POWER” appear
alternately.
• A strong signal is input. Turn off the power,
leave the system turned off for a while, then turn
on the power again. If “PROTECT” and “PUSH
POWER” still appear alternately check the
speaker cords.
Speakers
Sound comes from only one channel or
unbalanced left and right volume.
• Check the speaker connection and speaker
placement.
Sound lacks bass.
• Check that the speaker’s + and – terminals are
connected correctly.
Troubleshooting
MHC-RG77 4-238-409-11 (2)
Troubleshooting
25
GB
CD Player
The disc tray does not open and “LOCKED”
appears on the front panel display.
• Contact your Sony dealer or local authorized
Sony service facility.
The disc tray does not close.
• The CD is not placed properly.
The CD does not play.
• The CD is not lying flat in the disc tray.
• The CD is dirty.
• The CD is inserted label side down.
• Moisture condensation has built up. Remove the
CD and leave the system turned on for about an
hour until the moisture evaporates.
Playback does not start from the first track.
• The player is in Program Play or Shuffle Play
mode. Press PLAY MODE repeatedly until
“1 DISC” or “ALL DISCS” appears.
“OVER” is displayed.
• You have reached the end of the CD. Press m .
Tape Deck
The tape does not record.
• The tab has been removed from the cassette,
cover the broken tab with adhesive tape.
• The tape has reeled to the end.
The tape does not record nor play or there is a
decrease in sound level.
• The heads are dirty. (See “Cleaning the tape
heads” on page 26).
• The record/playback heads are magnetized. (See
“Demagnetizing the tape heads” on page 26).
The tape does not erase completely.
• The record/playback heads are magnetized. (See
“Demagnetizing the tape heads” on page 26).
There is excessive wow or flutter, or the sound
drops out.
• The capstans or pinch rollers are dirty. (See
“Cleaning the tape heads” on page 26).
Noise increases or the high frequencies are erased.
• The record/playback heads are magnetized. (See
“Demagnetizing the tape heads” on page 26).
Tuner
There is severe hum or noise (“TUNED” or
“STEREO” flashes in the display).
• Adjust the antenna.
• The signal is too weak. Connect an external
antenna.
A stereo FM program cannot be received in
stereo.
• Press FM MODE so that “MONO” disappears.
If other troubles not described above
occur, reset the system as follows:
1 Press x, ENTER and ?/1 at the same
time.
2 Unplug the power cord.
3 Plug the power cord back in.
4 Press ?/1 to turn on the power.
The unit is reset to factory settings. All the
settings are cleared.
26
GB
MHC-RG77 4-238-409-11 (2)
Additional Information
Precautions
On operating voltage
Before operating the unit, check that the operating
voltage of your unit is identical with the voltage of
your local power supply.
On safety
• The unit is not disconnected from the AC power
source (mains) as long as it is connected to the wall
outlet, even if the unit itself has been turned off.
• Unplug the unit from the wall outlet (mains) if it is
not to be used for an extended period of time. To
disconnect the cord (mains lead), pull it out by the
plug. Never pull the cord itself.
• Should any solid object or liquid fall into the
component, unplug the unit and have the
component checked by qualified personnel before
operating it any further.
• The AC power cord must be changed only at the
qualified service shop.
On placement
• Place the unit in a location with adequate
ventilation to prevent heat build-up in the unit.
• Do not place the unit in an inclined position.
• Do not place the unit in locations where it is:
— extremely hot or cold
— dusty or dirty
— very humid
— vibrating
— subject to direct sunlight
On heat buildup
• Although the unit heats up during operation, this is
not a malfunction.
• Place the unit in a location with adequate
ventilation to prevent heat build-up in the unit.
If you use this unit at a large volume, the cabinet
temperature of the top, side and bottom rises
considerably. To avoid burning yourself, do not touch
the cabinet.
To prevent a malfunction, do not cover the ventilation
hole for the cooling fan.
On operation
• If the unit is brought directly from a cold to a warm
location, or is placed in a very damp room, moisture
may condense on the lens inside the CD player.
Should this occur, the unit will not operate properly.
Remove the CD and leave the unit turned on for
about an hour until the moisture evaporates.
• When you move the unit, take out any discs.
If you have any questions or problems concerning
your unit, please consult your nearest Sony dealer.
Notes on CDs
• Before playing, clean the CD with a cleaning cloth.
Wipe the CD from the center out.
• Do not use solvents.
• Do not expose the CD to direct sunlight or heat
sources.
• Discs with non-standard shapes (e.g., heart, square,
star) cannot be played on this unit. Attempting to do
so may damage the unit. Do not use such discs.
Note on CD-R/CD-RW playback
Discs recorded on CD-R/CD-RW drives may not be
played back because of scratches, dirt, recording
conditions or the drive's characteristics. Besides, the
discs which are not yet finalized at the end of
recording, cannot be played back.
Cleaning the cabinet
Use a soft cloth slightly moistened with mild
detergent solution.
To save a tape permanently
To prevent a tape from being accidentally recorded
over, break off the cassette tab. Refer to the
instructions of the tape.
Before placing a cassette in the tape
deck
Take up any slack in the tape. Otherwise the tape may
get entangled in the parts of the tape deck and become
damaged.
When using a tape longer than 90
minutes
The tape is very elastic. Do not change the tape
operations such as play, stop, and fast-winding etc.
frequently. The tape may get entangled in the tape
deck.
Cleaning the tape heads
Clean the tape heads after every 10 hours of use.
Make sure to clean the tape heads before you start an
important recording or after playing an old tape. Use
separately sold dry-type or wet-type cleaning cassette.
For details, refer to the instructions of the cleaning
cassette.
Demagnetizing the tape heads
Demagnetize the tape heads and the metal parts that
have contact with the tape every 20 to 30 hours of use
with a separately sold demagnetizing cassette. For
details, refer to the instructions of the demagnetizing
cassette.
MHC-RG77 4-238-409-11 (2)
Additional Information
27
GB
Specifications
Amplifier section
MHC-GX8000
Total harmonic distortion
Less than 0.1 % (6 ohms
at 1 kHz, 100 W)
MHC-RG77
The following are measured at AC 120, 220, 240V
50/60 Hz
DIN power output (rated) 160 + 160 watts
(6 ohms at 1 kHz, DIN)
Continuous RMS power output (reference)
200 + 200 watts
(6 ohms at 1 kHz,
10% THD)
MHC-RG66T
The following are measured at AC 120, 220, 240V
50/60 Hz
DIN power output (rated) 100 + 100 watts
(6 ohms at 1 kHz, DIN)
Continuous RMS power output (reference)
145 + 145 watts
(6 ohms at 1 kHz,
10% THD)
Inputs
GAME (VIDEO): 1 Vp-p, 75 ohms
(phono jack)
GAME (AUDIO): Voltage 250 mV,
(phono jacks) impedance 47 kilohms
MD/VIDEO (AUDIO) IN: voltage 450 mV/250 mV,
(phono jacks) impedance 47 kilohms
MIC: sensitivity 1 mV,
(phone jack) impedance 10 kilohms
Outputs
VIDEO OUT: max. output level 1 Vp-p,
(phono jacks) unbalanced, Sync.
negative load impedance
75 ohms
PHONES: accepts headphones of
(stereo mini jack) 8 ohms or more
FRONT SPEAKER: accepts impedance of 6 to
16 ohms
SURROUND SPEAKER: accepts impedance of
(MHC-GX8000/RG77 24 ohms or more
only)
CD player section
System Compact disc and digital
audio system
Laser Semiconductor laser
(λ=795nm)
Laser Output Max. 44.6 µW*
*This output is the value
measured at a distance of
200 mm from the
objective lens surface on
the Optical Pick-up Block
with 7 mm aperture.
Frequency response 2 Hz – 20 kHz (±0.5 dB)
Wave length 795 nm
CD OPTICAL DIGITAL OUT
(Square optical connector jack, rear panel)
Wave length 660 nm
Output Level –18 dBm
Tape player section
Recording system 4-track 2-channel stereo
Frequency response 50 – 13,000 Hz (±3 dB),
using Sony TYPE I
cassette
Wow and flutter ±0.15% W.Peak (IEC)
0.1% W.RMS (NAB)
±0.2% W.Peak (DIN)
Tuner section
FM stereo, FM/AM superheterodyne tuner
FM tuner section
Tuning range 87.5 – 108.0 MHz
Antenna FM lead antenna
Antenna terminals 75 ohm unbalanced
Intermediate frequency 10.7 MHz
AM tuner section
Tuning range
Latin and North American models:
530 – 1,710 kHz
(with the interval set at 10
kHz)
531 – 1,710 kHz
(with the interval set at 9
kHz)
Middle Eastern models: 531 – 1,602 kHz
(with the interval set at 9
kHz)
Other models: 531 – 1,602 kHz
(with the interval set at 9
kHz)
530 – 1,710 kHz
(with the interval set at 10
kHz)
Antenna AM loop antenna
Antenna terminals External antenna terminal
Intermediate frequency 450 kHz
continued
AUDIO POWER SPECIFICATIONS
(MHC-GX8000 USA model only)
POWER OUTPUT AND TOTAL
HARMONIC DISTORTION:
With 6-ohm loads, both channels driven, from
120 Hz - 10 kHz; rates 200 watts per channel
minimum RMS power, with no more than 10%
total harmonic distortion from 250 miliwatts to
rated output.
28
GB
MHC-RG77 4-238-409-11 (2)
Sony Corporation Printed in Malaysia
Speaker
Front speaker SS-RG88
Speaker system 3-way, 3-unit,
bass-reflex type
Speaker units
Super Woofer: 15 cm, cone type
Woofer: 15 cm, cone type
Tweeter: 5 cm, cone type
Nominal impedance 6 ohms
Dimensions (w/h/d) Approx. 250 x 395 x
310 mm
Mass Approx. 6.2 kg net per
speaker
Surround speaker SS-RS88 for MHC-GX8000/
RG77
Speaker system 2 way, 2 unit,
bass-reflex type
Speaker units
Woofer 13 cm, cone type
Tweeter 5 cm, cone type
Nominal impedance 24 ohms
Dimensions (w/h/d)
Approx. 175 x 360 x 260
mm
Mass Approx. 3.4 kg net per
speaker
General
Power requirements
North America and Mexican models:
120 V AC, 60 Hz
Argentina/Thailand models:
220 V AC, 50/60 Hz
Other models: 120 V, 220 V or 230 - 240
V AC, 50/60 Hz
Adjustable with voltage
selector
Power consumption
MHC-GX8000/RG77 240 watts
MHC-RG66T 230 watts
Dimensions (w/h/d)
HCD-GX8000/RG77/RG66T
Approx. 280 x 360 x 445
mm
Mass :
HCD-GX8000/RG77/RG66T
Approx. 11.0 kg
Supplied accessories: AM loop antenna (1)
Remote commander (1)
Batteries (2)
FM lead antenna (1)
Front speaker pads (8)
Surround speaker pads (8)
(MHC-GX8000/RG77
only)
Design and specifications are subject to change
without notice.
Specifications (continued)
