www.philips.com/support
User manual
AJ3116
Des
questions ?
Contactez
Philips
Always there to help you
Register your product and get support at
1EN
Contents
1 Important 2
2 Notice 3
3 Your clock radio 4
Introduction 4
What's in the box 4
Overview of the clock radio 5
4 Get started 6
Install battery 6
Connect power 6
Set time 6
5 Listen to FM radio 7
Tune to FM radio stations 7
Store FM radio stations manually 7
Select a preset radio station 7
Adjust volume 7
6 Other features 8
Set alarm timer 8
Set sleep timer 8
7 Product information 10
Specications 10
8 Troubleshooting 11
2 EN
1 Important
Warning
•
Never remove the casing of this clock radio.
• Never lubricate any part of this clock radio.
• Never place this clock radio on other electrical
equipment.
• Keep this clock radio away from direct sunlight, naked
amesorheat.
• Make sure that you always have easy access to the
power cord, plug or adaptor to disconnect the clock
radio from the power.
• Read these instructions.
• Heed all warnings.
• Follow all instructions.
• Do not block any ventilation openings.
Install in accordance with the
manufacturer's instructions.
• Do not install near any heat sources such
as radiators, heat registers, stoves, or
otherapparatus(includingampliers)that
produce heat.
• Protect the power cord from being
walked on or pinched, particularly at plugs,
convenience receptacles, and the point
where they exit from the clock radio.
• Onlyuseattachments/accessoriesspecied
by the manufacturer.
• Unplug this apparatus during lightning
storms or when unused for long periods
of time.
• Referallservicingtoqualiedservice
personnel. Servicing is required when
the apparatus has been damaged in any
way, such as power-supply cord or plug
is damaged, liquid has been spilled or
objects have fallen into the apparatus, the
apparatus has been exposed to rain or
moisture, does not operate normally, or
has been dropped.
• Battery usage CAUTION – To prevent
battery leakage which may result in bodily
injury, property damage, or damage to the
clock radio:
• Install all batteries correctly, + and - as
marked on the unit.
• Remove batteries when the unit is not
used for a long time.
• The battery shall not be exposed to
excessiveheatsuchassunshine,reor
the like.
• This clock radio shall not be exposed to
dripping or splashing.
• Do not place any sources of danger on the
clockradio(e.g.liquidlledobjects,lighted
candles).
• Where the plug of the Direct Plug-in
Adapter is used as the disconnect device,
the disconnect device shall remain readily
operable.
3EN
2 Notice
Anychangesormodicationsmadetothis
device that are not expressly approved by
Gibson Innovations may void the user’s
authority to operate the equipment.
Hereby, Gibson Innovations declares that this
product is in compliance with the essential
requirements and other relevant provisions
ofDirective2014/53/EU.Youcanndthe
Declaration of Conformity on www.philips.com/
support.
Disposal of your old product
Yourproductisdesignedandmanufactured
with high quality materials and components,
which can be recycled and reused.
This symbol on a product means that the
productiscoveredbyEuropeanDirective
2012/19/EU.Informyourselfaboutthelocal
separate collection system for electrical and
electronic products. Follow local rules and never
dispose of the product with normal household
waste. Correct disposal of old products
helps prevent negative consequences for the
environment and human health.
Environmental information
All unnecessary packaging has been omitted.
We have tried to make the packaging easy to
separateintothreematerials:cardboard(box),
polystyrenefoam(buffer)andpolyethylene
(bags,protectivefoamsheet.)
Yoursystemconsistsofmaterialswhichcan
be recycled and reused if disassembled by
a specialized company. Please observe the
local regulations regarding the disposal of
packaging materials, exhausted batteries and old
equipment.
The Bluetooth
®
word mark and logos are
registered trademarks owned by Bluetooth
SIG, Inc. and any use of such marks by Philips is
under license.
4 EN
3 Your clock radio
Congratulations on your purchase, and
welcometoPhilips!Tofullybenetfromthe
support that Philips offers, register your product
at www.philips.com/support.
Introduction
With this clock radio, you can
• listen to FM radio;
• set two alarms to ring at different time.
What's in the box
Check and identify the contents of your
package.
Short user manual
www.philips.com/welcome
Always there to help you
Register your product and get support at
Question?
Contact
Philips
5EN
Overview of the clock radio
a PRESET/SET TIME
• Store radio stations in memory.
• Select a preset radio station.
• Set time.
b RADIO ON/OFF
• Press to turn on or off the radio.
c HR/MIN/
TUNING
• Tune to FM radio stations.
• Set hour and minute.
d SNOOZE/SLEEP
• Snooze alarm.
• Set the sleep timer.
e Display panel
• Display current status.
f AL1/AL2/- VOLUME +
• Set alarm.
• Adjust volume.
a
b
c
d
e
f
6 EN
4 Get started
Always follow the instructions in this chapter in
sequence.
Install battery
The batteries can only back up clock and alarm
settings.
Caution
•
Risk of explosion! Keep the batteries away from heat,
sunshineorre.Neverdiscardbatteriesinre.
• The batteries contains chemical substances, so it should
be disposed of properly.
Insert 2 AAA batteries with correct polarity
(+/-)asillustrated.
Connect power
Caution
•
Risk of product damage! Make sure that the power
voltage corresponds to the voltage printed on the back
or underside of the clock radio.
• Risk of electric shock! When you unplug the power
adapter, always pull the plug from the socket. Never
pull the cord.
Note
•
The type plate is located at the bottom of the clock
radio.
Set time
Note
•
Youcanonlysettimeinstandbymode.
1
2 sec
PRESET/
SET TIME
HR
MIN
PRESET/
SET TIME
2
3 4
7EN
5 Listen to FM
radio
Note
•
Keep the clock radio away from other electronic
devices to avoid radio interference.
• For better reception, fully extend and adjust the
position of the FM antenna.
Tune to FM radio stations
1
Press RADIO ON/OFF to turn on the FM
radio.
2 Press and hold TUNING for two
seconds.
» The clock radio tunes to a station with
strong reception automatically.
3 Repeat step 2 to tune to more radio
stations.
To tune to a station manually:
In tuner mode, press
TUNING repeatedly
to select a frequency.
2 sec
HR
TUNING
RADIO
ON/OFF
2 sec
1 2
3 4
MIN
TUNING
VOLUME
VOLUME
Note
•
Thetunninggridoftheclockradiois50KHz,theradio
frequencyonthedisplaypanelwillincrease0.1MHzby
pressing
TUNING twice.
Store FM radio stations
manually
Youcanstoreupto10FMradiostations.
1 Tune to an FM radio station.
2 Press and hold PRESET for two seconds.
» The preset number begins to blink.
3 Press TUNING repeatedly to select a
number.
4 Press PRESETagaintoconrm.
5 Repeat steps 1 to 4 to store other stations.
Tip
•
To remove a pre-stored station, store another station
in its place.
Select a preset radio station
In tuner mode, press PRESET repeatedly to
select a preset number.
Adjust volume
While listening, press - VOLUME + to adjust
volume.
8 EN
6 Other features
Set alarm timer
Set alarm
Note
•
Youcanonlysetthealarminstandbymode.
• Make sure that you have set the clock correctly.
Followtheillustrationtosettherstalarm.
• AL1:settherstalarm.
• AL2: set the second alarm.
Tip
•
The clock radio exits alarm setting mode when being
idlefor10seconds.
2 sec
1
HR
MIN
3 4
2
Select alarm source
YoucanselectFMradioorbuzzerasthealarm
source.
» The corresponding alarm icon lights up.
Note
•
The gentle wake-up function is designed for radio
source only.
Activate/deactivate alarm timer
Press AL1 or AL2 repeatedly to activate or
deactivate the alarm timer.
» If the alarm timer is deactivated, the
alarm indicator turns off.
» The alarm repeats ringing for the next
day.
Snooze alarm
When alarm sounds, press SNOOZE.
» The alarm snoozes and repeats ringing
nine minutes later.
AL1FM
AL
1
9EN
Set sleep timer
This clock radio can switch to standby mode
automatically after a preset period.
• Press SLEEPrepeatedly to select a period
(inminutes).
» The clock radio switches to standby
mode automatically after the preset
period.
To deactivate the sleep timer:
• Press SLEEP repeatedly until [OFF]
(off)appears.
15 30 60 90 120
OFF
SLEEP
10 EN
7 Product
information
Note
•
Product information is subject to change without prior
notice.
Specications
Amplier
Rated Output Power 200mWRMS
Tuner (FM)
Tuning Range 87.5-108MHz
Tuning Grid 100KHz
Sensitivity
- Mono, 26 dB S/N Ratio
- Stereo, 46 dB S/N Ratio
<22 dBf
<51.5 dBf
Total Harmonic Distortion <3%
Signal to Noise Ratio >50dBA
General information
AC Power (power
adapter)
Brand name: Philips;
Model:AS030-060-
EE050,orEML0600500;
Input:100-240V~,
50/60Hz;0.15A;
Output:6V
0.5A
Operation Power
Consumption
<5 W
Standby Power
Consumption
<1 W
Dimensions:
Main Unit
(WxHxD)
130x46x130mm
Weight
- Main Unit
0.3kg
11EN
8 Troubleshooting
Warning
•
Never remove the casing of this device.
To keep the warranty valid, never try to repair
the system yourself.
If you encounter problems when using this
device, check the following points before
requesting service. If the problem remains
unsolved, go to the Philips Web page (www.
philips.com/support).WhenyoucontactPhilips,
make sure that the device is nearby and the
model number and serial number are available.
No power
• EnsurethattheACpowerplugoftheunit
is connected properly.
• EnsurethatthereispowerattheAC
outlet.
No sound
• Adjust the volume.
No response from the unit
• Disconnect and reconnect the AC power
plug, then turn on the unit again.
Poor radio reception
• Increase the distance between the unit and
yourTVorVCR.
• Fully extend the FM antenna.
Alarm does not work
• Set the clock/alarm correctly.
Clock/alarm setting erased
• Power has been interrupted or the power
plug has been disconnected.
• Reset the clock/alarm.
Copyright © 2014 Gibson Innovations Limited. Revised Edition © 2017
This product has been manufactured by, and is sold under the responsibility of Gibson Innovations Ltd.,
and Gibson Innovations Ltd. is the warrantor in relation to this product.
Philips and the Philips Shield Emblem are registered trademarks of Koninklijke Philips N.V. and are used
under license.
AJ3116_12_UM_V3.0
