TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO
NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.
WARNING:
The lightning flash with arrow-head
symbol, within an equilateral triangle,
is intended to alert the user to the
presence of uninsulated “dangerous
voltage” within the product’s
enclosure that may be of sufficient
magnitude to constitute a risk of
electric shock to persons.
The exclamation point within a
triangle is intended to alert the user
to the presence of important
operating and maintenance
(servicing) instructions in the
literature accompanying the product.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
1
LC-26D40U
LC-32D40U
OPERATION MANUAL
• The illustrations and on-screen displays in this operation
manual are for explanation purposes and may vary
slightly from the actual operations.
• Menu items that are not selectable are grayed out.
• The examples used throughout this manual are based on
the LC-32D40U model.
IMPORTANT:
To aid reporting in case of loss or theft, please record the
TV’s model and serial numbers in the space provided. The
numbers are located at the rear of the TV.
Model No.:
Serial No.:
LIQUID CRYSTAL TELEVISION
ENGLISH
IMPORTANT INFORMATION
ENGLISH
3Y10101A.indb 13Y10101A.indb 1 2006/01/19 20:30:252006/01/19 20:30:25
IMPORTANT INFORMATION
Trademarks
TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO
WIDE SLOT, FULLY INSERT.
CAUTION:
WARNING: FCC Regulations state that any unauthorized changes or modifications to this equipment not expressly
approved by the manufacturer could void the user’s authority to operate this equipment.
“Note to CATV system installer: This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the National
Electrical Code that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to
the grounding system of the building, as close to the point of cable entry as practical.”
This product utilizes tin-lead solder, and fluorescent lamp containing a small amount of mercury. Disposal of these materials may be
regulated due to environmental considerations. For disposal or recycling information, please contact your local authorities or the
Electronic Industries Alliance: www.eia.org
CAUTION:
This product satisfies FCC regulations when shielded cables and connectors are used to connect the unit to other
equipment. To prevent electromagnetic interference with electric appliances such as radios and televisions, use shielded
cables and connectors for connections.
CAUTION:
DO NOT PLACE THIS PRODUCT ON AN UNSTABLE CART, STAND, TRIPOD, BRACKET, OR TABLE.
THE PRODUCT MAY FALL CAUSING SERIOUS PERSONAL INJURY AND SERIOUS DAMAGE TO
THE PRODUCT. USE ONLY WITH A CART, STAND, TRIPOD, BRACKET, OR TABLE RECOMMENDED
BY THE MANUFACTURER OR SOLD WITH THE PRODUCT. FOLLOW THE MANUFACTURER’S
INSTRUCTIONS WHEN INSTALLING THE PRODUCT AND USE MOUNTING ACCESSORIES
RECOMMENDED BY THE MANUFACTURER. A PRODUCT AND CART COMBINATION SHOULD BE
MOVED WITH CARE. QUICK STOPS, EXCESSIVE FORCE, AND UNEVEN SURFACES MAY CAUSE
THE PRODUCT AND CART COMBINATION TO OVERTURN.
2
• Manufactured under license from Dolby Laboratories. “Dolby” and the double-D symbol are trademarks of Dolby
Laboratories.
• “HDMI, the HDMI logo and High-Defi nition Multimedia Interface are trademarks or registered trademarks of HDMI
Licensing LLC.”
• WOW, SRS and
®
symbol are trademarks of SRS Labs, Inc.
WOW technology is incorporated under license from SRS Labs, Inc.
3Y10101A.indb 23Y10101A.indb 2 2006/01/19 20:30:262006/01/19 20:30:26
Electricity is used to perform many useful functions, but it can also cause personal injuries and property damage if
improperly handled. This product has been engineered and manufactured with the highest priority on safety. However,
improper use can result in electric shock and/or fire. In order to prevent potential danger, please observe the following
instructions when installing, operating and cleaning the product. To ensure your safety and prolong the service life of
your Liquid Crystal Television, please read the following precautions carefully before using the product.
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with
one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or
the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an
electrician for replacement of the obsolete outlet.
10) Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the
point where they exit from the apparatus.
11) Only use attachments/accessories specified by the manufacturer.
12) Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the
apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid
injury from tip-over.
13) Unplug this apparatus during lightning storms or when unused for long periods of time.
14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in
any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been
dropped.
Additional Safety Information
15) Power Sources—This product should be operated only from the type of power source indicated on the marking
label. If you are not sure of the type of power supply to your home, consult your product dealer or local power
company. For products intended to operate from battery power, or other sources, refer to the operating
instructions.
16) Overloading—Do not overload wall outlets, extension cords, or integral convenience receptacles as this can
result in a risk of fire or electric shock.
17) Object and Liquid Entry—Never push objects of any kind into this product through openings as they may touch
dangerous voltage points or short-out parts that could result in a fire or electric shock. Never spill liquid of any
kind on the product.
18) Damage Requiring Service—Unplug this product from the wall outlet and refer servicing to qualified service
personnel under the following conditions:
a) When the AC cord or plug is damaged,
b) If liquid has been spilled, or objects have fallen into the product,
c) If the product has been exposed to rain or water,
d) If the product does not operate normally by following the operating instructions.
Adjust only those controls that are covered by the operating instructions as an improper adjustment of other
controls may result in damage and will often require extensive work by a qualified technician to restore the
product to its normal operation,
e) If the product has been dropped or damaged in any way, and
f) When the product exhibits a distinct change in performance - this indicates a need for service.
19) Replacement Parts—When replacement parts are required, be sure the service technician has used replacement
parts specified by the manufacturer or have the same characteristics as the original part. Unauthorized
substitutions may result in fire, electric shock, or other hazards.
20) Safety Check—Upon completion of any service or repairs to this product, ask the service technician to perform
safety checks to determine that the product is in proper operating condition.
21) Wall or ceiling mounting—When mounting the product on a wall or ceiling, be sure to install the product
according to the method recommended by the manufacturer.
3
DEAR SHARP CUSTOMER
Thank you for your purchase of the Sharp Liquid Crystal Television. To ensure safety and many years
of trouble-free operation of your product, please read the Important Safety Instructions carefully before
using this product.
IMPORTANT SAFETY INSTRUCTIONS
3Y10101A.indb 33Y10101A.indb 3 2006/01/19 20:30:262006/01/19 20:30:26
IMPORTANT SAFETY INSTRUCTIONS
4
• Water and Moisture — Do not use this product near water - for example, near a bath tub,
wash bowl, kitchen sink, or laundry tub; in a wet basement; or near a swimming pool; and the
like.
• Stand — Do not place the product on an unstable cart, stand, tripod or table. Placing the
product on an unstable base can cause the product to fall, resulting in serious personal
injuries as well as damage to the product. Use only a cart, stand, tripod, bracket or table
recommended by the manufacturer or sold with the product. When mounting the product on
a wall, be sure to follow the manufacturer’s instructions. Use only the mounting hardware
recommended by the manufacturer.
• Ventilation — The vents and other openings in the cabinet are designed for ventilation. Do not
cover or block these vents and openings since insuffi cient ventilation can cause overheating
and/or shorten the life of the product. Do not place the product on a bed, sofa, rug or other
similar surface, since they can block ventilation openings. This product is not designed for
built-in installation; do not place the product in an enclosed place such as a bookcase or rack,
unless proper ventilation is provided or the manufacturer’s instructions are followed.
• Heat — The product should be situated away from heat sources such as radiators, heat
registers, stoves, or other products (including amplifi ers) that produce heat.
• The Liquid Crystal panel is a very high technology product with 3,147,264 thin fi lm transistors, giving you fi ne picture
details.
Occasionally, a few non-active pixels may appear on the screen as a fi xed point of blue, green or red. Please note that
this does not affect the performance of your product.
Precautions when transporting the TV
• When transporting the TV, never carry it by holding onto the speaker. Be sure to always
carry the TV by two people holding it with two hands — one hand on each side of the
TV.
• The Liquid Crystal panel used in this product is made of glass. Therefore, it can break when
the product is dropped or applied with impact. Be careful not to be injured by broken glass
pieces in case the panel breaks.
• Lightning — For added protection for this television equipment during a lightning storm, or
when it is left unattended and unused for long periods of time, unplug it from the wall outlet
and disconnect the antenna. This will prevent damage to the equipment due to lightning
and power-line surges.
• Power Lines — An outside antenna system should not be located in the vicinity of
overhead power lines or other electric light or power circuits, or where it can fall into such
power lines or circuits. When installing an outside antenna system, extreme care should
be taken to keep from touching such power lines or circuits as contact with them might be
fatal.
• Selecting the location — Select a place with no direct sunlight and good ventilation.
3Y10101A.indb 43Y10101A.indb 4 2006/01/19 20:30:262006/01/19 20:30:26
5
• Outdoor Antenna Grounding — If an outside antenna is connected to the television equipment, be sure the antenna
system is grounded so as to provide some protection against voltage surges and built-up static charges.
Article 810 of the National Electrical Code, ANSI/NFPA 70, provides information with regard to proper grounding
of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding
conductors, location of antenna-discharge unit, connection to grounding electrodes, and requirements for the grounding
electrode.
EXAMPLE OF ANTENNA GROUNDING AS PER
NATIONAL ELECTRICAL CODE, ANSI/NFPA 70
ANTENNA
LEAD IN WIRE
GROUND
CLAMP
NEC — NATIONAL ELECTRICAL CODE
• To prevent fi re, never place any type of candle or fl ames on the top or near the TV set.
• To prevent fi re or shock hazard, do not expose this product to dripping or splashing.
No objects fi lled with liquids, such as vases, should be placed on the product.
• To prevent fi re or shock hazard, do not place the AC cord under the TV set or other heavy
items.
• Turn off the main power and unplug the AC cord from the wall outlet before handling.
• Use a soft cloth and gently wipe the surface of the display panel. Using a hard cloth may
scratch the panel surface.
• Use a soft damp cloth to gently wipe the panel when it is really dirty.
(It may scratch the panel surface when wiped strongly.)
• If the panel is dusty, use an anti-static brush, which is commercially available, to clean it.
• To protect the panel, do not use a dirty cloth, liquid cleaners or chemical cloth to clean it,
such materials may damage the panel surface.
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
ELECTRIC
SERVICE
EQUIPMENT
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
• Do not display a still picture for a long time, as this could cause an afterimage to remain.
IMPORTANT SAFETY INSTRUCTIONS
3Y10101A.indb 53Y10101A.indb 5 2006/01/19 20:30:262006/01/19 20:30:26
6
Supplied accessories
NOTE
• Always use the AC cord supplied with the TV.
Make sure the following accessories are provided with the product.
Remote control unit (
X
1)
Page 8 Page 8 Page 7
Page 7
“AAA” size battery (
X
2) AC cord (
X
1)
Cable Clamp (
X
1)
Operation manual (
X
1)
Stand unit (
X
1)
Page 6
1. Confi rm the 8 screws supplied with the TV.
NOTE
• To detach the stand, perform the steps in reverse order.
4. Insert and tighten the 4 long screws into the 4 holes on
the rear of the TV.
2. Attach the two parts of the stand unit to each other
using the 4 short screws and the hex key (supplied with
the product) as shown.
3. Insert the stand into the opening on the bottom of the TV.
Attaching the stand
• Before attaching (or detaching) stand, unplug the AC cord from the AC input terminal.
• Before performing work spread cushioning over the base area to lay the TV on. This will prevent it from being damaged.
Short screws (
X
4)
(used in step 2)
Long screws (
X
4)
(used in step 4)
QUICK REFERENCE
hex key
hex key
LC-26D40U
LC-32D40U
LIQUID CRYSTAL TELEVISION
TÉLÉVISEUR ACL
TELEVISOR CON PANTALLA
DE CRISTAL LÍQUIDO
ENGLISHFRANÇAISESPAÑOL
OPERATION MANUAL
MODE D’EMPLOI
MANUAL DE OPERACIÓN
Short screw
Long screw
Soft cushion
3Y10101A.indb 63Y10101A.indb 6 2006/01/19 20:30:272006/01/19 20:30:27
7
QUICK REFERENCE
STOP! To safely remove the AQUOS television from the box
It’s best to use 2 people to remove the AQUOS television for stability.
1. Use the cardboard holders on either side of the AQUOS television to remove it from the box.
2. Remove the cardboard; however, keep the wrapping on the AQUOS television to protect it
while moving.
3. Lift onto installation location as the diagram illustrates.
Ventilation & Cleaning Tips
Keep your AQUOS television in a well ventilated area and make sure not to place it by a heat
source or use near water. The AQUOS television is designed for AC use only and should be
used with supplied AC cord.
Clean the screen by spraying a soft lint free cloth with water to lightly moisten. Gently wipe
and avoid pressing on the screen. To clean the outer cabinet, use the same method. Do not
use liquid or aerosol cleaners.
The screen is glass and can be scratched or broken when dropped or impacted.
QUICK INSTALLATION TIPS
1. Attach your antenna to the back of the TV.
(See page 13.)
NOTE
• TO PREVENT RISK OF ELECTRIC SHOCK, DO NOT
TOUCH UN-INSULATED PARTS OF ANY CABLES
WITH THE AC CORD CONNECTED.
3. Bundle the cords properly with a cable clamp and cable
tie.
4. How to turn on the AQUOS television for the fi rst time.
A) Press POWER on AQUOS television.
POWER
POWER indicator
2. Connect the AC plug for the AQUOS television into the
wall outlet.
B) POWER indicator on the front of the AQUOS television
lights GREEN.
NOTE
• Speaker cannot be detached from the TV.
• TV angle cannot be adjusted.
AC outlet
• Place the TV close to the AC outlet, and keep the power
plug within reach.
3Y10101A.indb 73Y10101A.indb 7 2006/01/19 20:30:282006/01/19 20:30:28
30°30°
8
QUICK REFERENCE
If the remote control fails to operate TV functions, replace the batteries in the remote control unit.
1 Open the battery cover.
• Place the batteries with their terminals
corresponding to the (+) and (–)
indications in the battery compartment.
NOTE
Improper use of batteries can result in chemical leakage or explosion. Be sure to follow the instructions below.
• Do not mix batteries of different types. Different types of batteries have different characteristics.
• Do not mix old and new batteries. Mixing old and new batteries can shorten the life of new batteries or cause chemical
leakage in old batteries.
• Remove batteries as soon as they are worn out. Chemicals that leak from batteries that come in contact with skin can
cause a rash. If you fi nd any chemical leakage, wipe thoroughly with a cloth.
• The batteries supplied with this product may have a shorter life expectancy due to storage conditions.
• If you will not be using the remote control unit for an extended period of time, remove batteries from it.
Remote control
sensor
2 Insert two “AAA” size batteries
(supplied with the product).
3 Close the battery cover.
16’4 (5 m)
IMPORTANT:
The POWER indicator on the AQUOS television should light GREEN indicating you have power to the AQUOS
television.
If the POWER indicator on the AQUOS television still does not light up, press TV
POWER on the remote control to turn the power on.
IMPORTANT:
IF THE UNIT DOES NOT POWER ON - UNPLUG THE AQUOS TELEVISION FROM THE OUTLET AND
REPEAT THE INSTALLATION STEPS.
IF YOU STILL ENCOUNTER NO POWER, PLEASE CONTACT US AT 1-800-BE-SHARP.
Please refer to the BASIC ADJUSTMENT SETTINGS SECTION and basic Initial setup functions and USING
EXTERNAL EQUIPMENT SECTION for other device connections (DVD, VCR, AUDIO, etc) in your AQUOS
operation manual.
3Y10101A.indb 83Y10101A.indb 8 2006/01/19 20:30:282006/01/19 20:30:28
9
IMPORTANT INFORMATION ................................... 1
Trademarks ..............................................................2
DEAR SHARP CUSTOMER ..................................... 3
IMPORTANT SAFETY INSTRUCTIONS ..................3
Supplied accessories ..............................................6
QUICK REFERENCE ................................................6
Attaching the stand ..............................................6
Contents ...................................................................9
Part names ............................................................. 10
TV (Front) .......................................................... 10
TV (Rear) ...........................................................11
Remote control unit ...........................................12
Preparation.............................................................13
Using the remote control unit ............................13
Cautions regarding remote control unit .........13
Antennas ........................................................... 13
Watching TV ...........................................................14
Preparation ........................................................14
Turning on the power ........................................14
Turning off the power ........................................14
Initial setup ........................................................14
Simple button operations for
changing channels .........................................16
Simple button operations for
changing volume/sound .................................17
Display the channel information ........................17
Setting MTS/SAP stereo mode .........................18
Setting WOW
TM
surround sound ........................ 18
Basic adjustment settings ....................................19
Menu operation buttons .....................................19
Menu items ........................................................ 19
Favorite channel setting ....................................20
Labeling channels .............................................20
Picture adjustments ........................................... 21
Back lighting ......................................................21
Color temperature .............................................21
Cinema mode ....................................................21
Sound adjustment .............................................22
Digital audio output ............................................22
Using external equipment.....................................23
Displaying an external equipment image ..........23
Connecting a DVD player or a digital TV STB
(Air or Cable) ...................................................24
Connecting a VCR, game console
or camcorder ...................................................24
Using digital audio output ..................................24
Connecting HDMI equipment ............................25
Displaying an image from HDMI equipment ...... 25
Selecting HDMI audio input source ...................25
Useful adjustment settings ................................... 26
Reset .................................................................26
Input label .......................................................... 26
AV mode ............................................................27
Selecting the digital audio language .................. 27
View mode for 4:3 programs .............................28
View mode for HD programs .............................28
Picture scroll ...................................................... 28
Aspect ...............................................................28
Audio output select ............................................ 29
Sleep timer ........................................................29
Closed captions and digital closed captions ...... 30
Caption setup ....................................................31
Password setting for parental control ................32
Parental control (V-CHIP) ..................................33
TV Parental Guide lines (TV Guide lines) .........34
Voluntary movie rating system (MPAA) .............34
How to temporarily release
the V-CHIP block .............................................34
Reactivating the temporarily released
V-CHIP block ...................................................34
Other viewing options ...........................................35
Freezing images ................................................ 35
Signal meter ......................................................35
Presetting remote control function .....................35
Appendix ................................................................39
Removing the stand ..........................................39
Setting the TV on the wall .................................39
Troubleshooting .................................................40
Troubleshooting-Digital broadcasting ................40
Specifi cations ....................................................41
Dimensional drawings ..........................................42
Contents
3Y10101A.indb 93Y10101A.indb 9 2006/01/19 20:30:282006/01/19 20:30:28
10
Part names
POWER button
TV (Front)
Channel buttons
(CH
/ )
Volume buttons (VOL
–
/+)
INPUT button
POWER
indicator*
Remote control sensor
NOTE
*See page 14 for TV status indicator.
3Y10101A.indb 103Y10101A.indb 10 2006/01/19 20:30:292006/01/19 20:30:29
11
Part names
TV (Rear)
INPUT4 terminals
INPUT5 terminals
ANT in
INPUT1 terminals
INPUT2 terminals
INPUT3 terminals
COAXIAL DIGITAL AUDIO
OUTPUT Terminal
AUDIO OUT Terminals
INPUT6 terminal
AC INPUT terminal
3Y10101A.indb 113Y10101A.indb 11 2006/01/19 20:30:292006/01/19 20:30:29
112
3
4
2
6
16
13
15
17
18
5
19
8
7
20
922
23
24
10
11 26
21
25
14
12
Part names
1 TV POWER: Switch the TV power on or enters standby
mode. (See page 14.)
2 External equipment operational buttons: Operate
the external equipment.
3 0 – 9: Set the channel. (See page 16.)
4 • (DOT): (See page 16.)
5 INPUT: Select a TV input source. (TV, INPUT1~6) (See
page 23.)
6 VOL +/
–
: Set the volume. (See page 17.)
7 SURROUND: Display the WOW surround setting
menu. (See page 18.)
8 FREEZE: Set the still image. Press again to return to
normal screen. (See page 35.)
9 EXIT: Turn off the menu screen.
10 SLEEP: Set the sleep timer. (See page 29.)
11 AUDIO: Display the MTS setting menu. (See page 18.)
12 FUNCTION: Switches the remote control for TV, CBL/
SAT, VCR, DVD and AUDIO operation. Indicator lights
up for the current mode. (See pages 35, 37 and 38 for
details.)
* To enter the code registration mode, you need to
press FUNCTION and DISPLAY at the same time.
13 LIGHT
: When pressed all buttons without SLEEP,
AUDIO, FAVORITE, CC and AV MODE on the remote
control unit will light. The lighting will turn off if no
operations are performed within about 5 seconds. This
button is used for performing operations in low-light
situations.
14 DISPLAY: Display the channel information.
15 VIEW MODE: Select the screen size. (See page 28.)
16 ENT: Jumps to a channel after selecting with the 0–9
buttons.
17 FLASHBACK: Return to the previous channel or input
external mode. (See page 16.)
18 CH
/ : Select the channel. (See page 16.)
19 MUTE: Mute the sound. (See page 17.)
20 MENU: Display the menu screen.
21 ////ENTER: Select a desired item on the
screen.
22 RETURN: Return to the previous menu screen.
23 FAVORITE CH
A, B, C, D: Select four preset favorite channels in four
different categories. (See page 20 for details.)
While watching, you can toggle the selected channels
by pressing A, B, C and D.
24 FAVORITE: Display the Favorite channel menu. (See
page 20.)
25 CC: Display captions during closed-caption source.
(See page 30.)
26 AV MODE: Select an adjusted picture setting.
(SPORTS, STANDARD, MOVIE, MEMORY.)
(See page 27.)
Remote control unit
NOTE
• When using the remote control unit, point it at the TV. (See page 8.)
3Y10101A.indb 123Y10101A.indb 12 2006/01/19 20:30:292006/01/19 20:30:29
300-ohm twin-lead (flat)
300-ohm twin-lead
75-ohm coaxial cable (round)
75-ohm coaxial cable
Cable TV lead-In
or
IN OUT
300-ohm
twin-lead
VHF
ANTENNA
UHF
ANTENNA
Combiner
(commercially
available)
or
Home Antenna
terminal (75-ohm)
300/75-ohm adapter
(commercially available)
Coaxial cable
(commercially
available)
13
Using the remote control unit
Use the remote control unit by pointing it towards the remote control sensor on
the TV. Objects between the remote control unit and the remote control sensor
may prevent proper operation.
Cautions regarding remote control unit
• Do not expose the remote control unit to shock.
In addition, do not expose the remote control unit to liquids, and do not place in an area
with high humidity.
• Do not install or place the remote control unit under direct sunlight. The heat may cause
deformation of the remote control unit.
• The remote control unit may not work properly if the remote control sensor on the TV is
under direct sunlight or strong lighting. In such cases, change the angle of the lighting
or the TV, or operate the remote control unit closer to the remote control sensor.
Antennas
To enjoy a clearer picture, use an outdoor antenna. The following is a brief explanation of the types of
connections that are used for a coaxial cable. If your outdoor antenna uses a 75-ohm coaxial cable with an
F-type connector, plug it into the antenna terminal at the rear of the TV set.
1. A 75-ohm system is generally a round cable with F-type
connector that can easily be attached to a terminal without
tools (Commercially available).
2. A 300-ohm system is a fl at “twin-lead” cable that can be
attached to a 75-ohm terminal through a 300/75-ohm adapter
(Commercially available).
F-type connector
F-type connector should be fi nger-tightened only.
When connecting the RF cable to the TV set, do not tighten
F-type connector with tools.
If tools are used, it may cause damage to your TV set.
(The breaking of internal circuit, etc.)
Connecting Antenna Cable
300-ohm twin-lead cable (fl at)
F-type connector
75-ohm coaxial cable (round)
75-ohm coaxial cable
Preparation
Cable without a CATV
converter
Combination VHF/UHF
antenna
Separate VHF/UHF
antenna
NOTICE
3Y10101A.indb 133Y10101A.indb 13 2006/01/19 20:30:292006/01/19 20:30:29
14
1
Simple operations for watching a TV program
POWER indicator
TV POWER (On/Standby)
Turning on the power
Press POWER on the TV, or TV POWER on the
remote control.
• POWER indicator (Green): The TV is on. (“PLEASE
WAIT” will appear for a few seconds on the screen.)
NOTE
• The LANGUAGE setup menu will appear automatically
when MENU is pressed for the fi rst time. (See below.)
Turning off the power
Press POWER on the TV, or TV POWER on the
remote control.
• The TV enters standby mode and the image on the
screen disappears.
• The POWER indicator on the TV changes to Red.
NOTE
• If you are not going to use this TV for a long period of
time, be sure to remove the AC cord from the power
outlet.
• Weak electric power is still consumed even when
POWER is turned off.
• If a station being viewed stops broadcasting, the TV will
automatically shut itself off after 15 minutes.
Preparation
Perform the following steps before you press TV
POWER on the remote control unit.
1. Insert the batteries into the remote control unit.
(See page 8.)
2. Connect the antenna cable to the TV. (See page
13.)
3. Plug in the AC cord to the AC outlet. (See page 7.)
Watching TV
POWER
TV status indicator (POWER)
ON Lighting (Green)
Lighting (Red)OFF/Standby
Initial setup
Language setting
When you press MENU for the fi rst time, the
LANGUAGE setup menu will appear
automatically.
Select from among 3 languages: English, French and
Spanish.
Press / to select the desired language
from the list.
SETUP
LANGUAGE ENGLISH
ENGLISH/FRANÇAIS/ESPAÑOL
CLOCK SET
TV/CABLE CABLE
AUTO CH MEMORY
ADD/DELETE
:SELECT :ADJUST
3Y10101A.indb 143Y10101A.indb 14 2006/01/19 20:30:302006/01/19 20:30:30
15
CLOCK SET
MONTH 1
DAY 1 (SUN)
YEAR 2006
TIME 12:00AM
:SELECT :ADJUST
ENTER:SET EXIT:END
SETUP
LANGUAGE ENGLISH
CLOCK SET
TV/CABLE TV/CABLE
AUTO CH MEMORY
ADD/DELETE
:SELECT :ADJUST
SETUP
LANGUAGE ENGLISH
CLOCK SET
TV/CABLE CABLE
AUTO CH MEMORY
ADD/DELETE
:SELECT :ADJUST
Clock setting
Please set correct date and time manually.
Press
/
to select “CLOCK SET”, then
press
/
. The CLOCK SET menu screen
displays.
Channel search
AUTO CHANNEL MEMORY makes the TV look for
all channels viewable in the set area.
Press
/
to select “AUTO CH MEMORY”
Antenna setting
Make sure what kind of connection is made with your
TV when selecting “TV” or “CABLE”.
Press
/
to select “TV/CABLE”, then
press
/
to select “TV” or “CABLE”.
Watching TV
2
3
4
Press / to set the MONTH, then press
to move to the next.
Set the DAY, YEAR and TIME (hour and
minuite) as above step.
After setting the date and time correctly,
press ENTER.
Press
/
. The TV will begin memorizing
all the channels available in your area.
• Depending on the reception condition, it may
take approximately 10 minutes to complete
memorizing digital cable channels, please be
patient.
AUTO CH MEMORY
EXIT:CANCEL
PROGRAMMING NOW
PLEASE WAIT
Press / to select the channel which you
want to skip.
Press MENU and the MENU screen
displays.
Press / to select “ADD/DELETE”, and
then press /.
Press / to select (SETUP).
Press / to select “ADD/DELETE”, and
then press /. Now, the channel list
becomes selectable.
Skipping stored channel
You can set channel selection disabled using CH
/
.
1
2
3
4
5
Press / to select “DELETE” for selected
channel.
6
Press EXIT to return to the normal screen.
Now, skipping channel is applied.
7
• To release the skipping channel:
Select “ADD” in step 6.
• To remove all the channels from channel memory:
Select “CLEAR ALL” after step 3, and the press /.
3Y10101A.indb 153Y10101A.indb 15 2006/01/19 20:30:302006/01/19 20:30:30
16
Simple button operations for
changing channels
You can change channels in several ways.
NOTE
• When selecting a 1-digit channel number, it is not
necessary to press 0 before the number.
• When you enter 0-9 only, channel selection will be made
if there is no operation within a few seconds.
To select a 3-digit channel number
(e. g., Channel 115):
Press 1
1
5
ENT
To select a 4-digit channel number
(e. g., Channel 22.1):
Press 2
2
• (DOT)
1
ENT
NOTE
• When you enter 0–9 only, channel selection will be made
if there is no operation within a few seconds.
• If you push “0” by itself, nothing will happen.
• Complete the above steps within a few seconds.
• When you enter 0–9 and • (DOT), channel selection will
be made if there is no operation within a few seconds.
Method 1
Using CH
/ on the remote control unit or on the
TV.
Method 2
1 Press FLASHBACK to switch to the previously
tuned channel.
2 Press FLASHBACK again to switch back to the
currently tuned channel.
NOTE
• FLASHBACK will not work if no channel has been
changed after the TV is turned on.
Method 3
Using remote control buttons 0-9, • (DOT) to select
channels for VHF/UHF/CATV/DIGITAL.
To select a 1 or 2-digit channel number
(e. g., Channel 5):
Press 5
ENT
Watching TV
3Y10101A.indb 163Y10101A.indb 16 2006/01/19 20:30:302006/01/19 20:30:30
17
VOLUME 25
Simple button operations for
changing volume/sound
Changing the volume
You can change the volume on the TV or on the
remote control unit.
NOTE
• VOL+/
–
on the TV operates the same as VOL+/
–
on the
remote control unit.
Using VOL +/
–
• To increase the volume, press VOL+.
• To decrease the volume, press VOL
–
.
Using MUTE on the remote control unit
Mutes the current sound output.
NOTE
• Mute can be canceled if you press VOL+/
–
or MUTE.
Press MUTE.
• “MUTE” will be displayed on the screen, and
the sound is silenced.
Watching TV
1
MUTE
Display the channel information
Press DISPLAY to display the current channel (or
input source) information on the screen.
When the TV receives a digital signal, press once, the
digital information will appear.
• Broadcast program name
• Station name • Remaining time
• Audio language • Program name
• V-CHIP RATING • HD or SD mark
• Closed Caption mark • V-Chip mark
Press DISPLAY again, the analog information will appear.
• Clock
• Channel number or VIDEO mode selected
• Channel label (if preset)
• Stereo or SAP (second audio program) audio status
• Content rating
• View mode
51-3
CITYHD
Moon Star
Remaining Time 0:20 TV-Y7
English
No program information is available.
SUN Jan 01 12:00 PM
HD CC
STEREO
SAP
TV-PG L V
SLEEP TIMER 2h00m
TV
ABCD
S.Stretch CABLE
7
CLOCK 12:00AM SUN
Press DISPLAY again to clear the display.
3Y10101A.indb 173Y10101A.indb 17 2006/01/19 20:30:312006/01/19 20:30:31
18
AUDIO
MTS STR/SAP/MONO
BASS 25
TREBLE 25
BALANCE 0
SPEAKERS ON
:SELECT :ADJUST
Setting MTS/SAP stereo mode
The TV has a feature that allows reception of sound
other than the main audio for the program. This
feature is called Multi-channel Television Sound
(MTS). The TV with MTS can receive mono sound,
stereo sound and Secondary Audio Programs (SAP).
The SAP feature allows a TV station to broadcast
other information, which could be audio in another
language or something completely different like
weather information.
You can enjoy Hi-Fi stereo sound or SAP
broadcasts where available.
• Stereo broadcasts
View programs like live sporting events, shows and
concerts in dynamic stereo sound.
• SAP broadcasts
Receive TV broadcasts in either MAIN or SAP sound.
MAIN sound: The normal program soundtrack (either in
mono or stereo).
SAP sound: Listen to a second language, supplementary
commentary or other information. (SAP is mono sound.)
If stereo sound is diffi cult to hear.
• Obtain a clearer sound by manually switching to
fi xed mono-sound mode.
NOTE
• MTS only operates while in TV mode.
• When the TV receives a stereo or SAP broadcast, the
word “STEREO” or “SAP” displays on-screen every
time you turn the TV on, change the channel, or press
DISPLAY.
Watching TV
Press AUDIO and the (AUDIO) menu
screen displays. “MTS” will be highlighted.
Press EXIT to return to the normal screen.
Press AUDIO again or / to select “STR
(STEREO)”, “SAP” or “MONO”.
1
2
3
Setting WOW
TM
surround sound
WOW is a special combination of SRS Labs audio
technologies that creates a thrilling surround sound
experience with deep, rich bass from stereo sound
sources. Your TV’s audio will sound fuller, richer,
and wider. WOW consists of three features; SRS 3D,
FOCUS, and TruBass.
Select STEREO mode (see “Setting MTS/
SAP stereo mode” on this page).
Press SURROUND and the (AUDIO)
menu screen displays. "WOW SRS 3D" will
be highlighted.
1
2
Press / to select the desired WOW
feature you want to adjust.
3
AUDIO
WOW SRS 3D ON/OFF
FOCUS OFF
TruBass OFF
HDMI HDMI
:SELECT :ADJUST
SRS 3D: Press / to turn on or off the
surround sound effect.
FOCUS: Press / to turn on or off the vocal
emphasis effect.
TruBass: Press / to select the bass
expansion effect high, low or off.
After your desired setting, press EXIT to
return to the normal screen.
4
NOTE
• You can enter to the same menu screen from
(AUDIO) menu.
Changing MTS
You can change MTS as shown below to match the
television broadcast signal.
3Y10101A.indb 183Y10101A.indb 18 2006/01/19 20:30:312006/01/19 20:30:31
19
SETUP
AUDIO
OPTION
LOCKS
:SELECT :ADJUST
ENTER:SET EXIT:END
Menu items
List of menu items to help you with operations
Basic adjustment settings
AV MODE ....................................................Page 27
BRIGHTNESS .............................................Page 21
CONTRAST .................................................Page 21
COLOR ........................................................Page 21
TINT .............................................................Page 21
SHARPNESS ..............................................Page 21
COLOR TEMPERATURE ...........................Page 21
RESET (Picture adjustments) ...................Page 26
LANGUAGE .................................................Page 14
CLOCK SET .................................................Page 15
TV/CABLE ...................................................Page 15
AUTO CH MEMORY ...................................Page 15
ADD/DELETE ...............................................Page 15
CLOSED CAPTION .....................................Page 30
CC ADVANCED ...........................................Page 31
VIEW MODE ................................................Page 28
PICTURE SCROLL .....................................Page 28
CINEMA MODE ...........................................Page 21
ASPECT .......................................................Page 28
SIGNAL METER ..........................................Page 35
BACK LIGHTING .........................................Page 21
MTS .............................................................Page 18
BASS ...........................................................Page 22
TREBLE .......................................................Page 22
BALANCE ...................................................Page 22
SPEAKERS .................................................Page 29
WOW
SRS 3D ...............................................Page 18
FOCUS ................................................Page 18
TruBass ..............................................Page 18
HDMI ...........................................................Page 25
AUDIO LANGUAGE ...................................Page 27
DIGITAL OUTPUT ......................................Page 22
RESET (Sound adjustments) ....................Page 26
FAVORITE CH .............................................Page 20
CH LABEL ...................................................Page 20
VIDEO LABEL .............................................Page 26
V-CHIP SET .................................................Page 34
NEW PASSWORD .......................................Page 32
Menu operation buttons
Use the following buttons on the remote control to
operate the menu.
MENU: Press to open the menu screen.
/
/
/
: Press to select a desired item on the
screen or adjust a selected item.
ENTER: Press to go to the next step or complete
the setting.
RETURN: Press to return to the previous step.
EXIT: Press to exit from the menu screen.
All changed settings will be saved.
The lower part of the menu screen is an
operational guide for the remote control.
It will change in accordance with each menu
setting screen.
3Y10101A.indb 193Y10101A.indb 19 2006/01/19 20:30:312006/01/19 20:30:31
20
Basic adjustment settings
Favorite channel setting
This function allows you to program 4 favorite
channels. By setting the favorite channels in advance,
you can select your favorite channels easily.
Programming favorite channel
Select the channel you want to register as a
favorite channel.
1
Press FAVORITE and the FAVORITE CH
menu screen displays.
2
3
Press
/
to select “SET”, and then press
ENTER.
4
Press
/
to select the position, and then
press ENTER to register.
Deleting a favorite channel
Repeat steps 1 to 2 in above procedure.
1
Press
/
to select “CLEAR”, and then
press ENTER.
2
Press
/
to select the registered favorite
channel you want to release, and then press
ENTER.
3
Press EXIT to return to the normal screen.
4
Press EXIT to return to the normal screen.
5
Labeling channels
To create channel labels
Select a channel you want to label.
1
Press MENU, then press / to select
(OPTION).
Press / to select “CH LABEL”, then press
/. The CH LABEL menu will appear.
2
Press / to select “SET/CLEAR”. Press
/ to select “SET” then press ENTER.
P
ress / to enter a character in the fi rst
space. Press the button repeatedly until the
character you want appears on the screen.
4
CH LABEL :CH 12
SET
LABEL A–––
RETURN
:SELECT :ADJUST
ENTER: SET
The characters rotation as follows:
If the character which you desire appears, press
ENTER. Repeat this step to enter the rest of the
characters.
When you fi nish inputting the label name, press
ENTER.
-
0
...
9 A
...
Z
-
0
...
9 A
...
Z
+ SPACE
Press EXIT to return to the normal screen.
Repeat steps 1-5 for other channels. You
can assign a label to each channel.
6
5
To erase channel labels
Select a channel with a label which you
want to remove.
1
Press MENU, then press / to select
(OPTION).
Press
/
to select “CH LABEL”, then
press / to display the CH LABEL menu.
2
Press / to select “SET/CLEAR”. Press
/ to select “CLEAR”, then press ENTER.
Press EXIT to return to the normal screen.
Repeat steps 1-4 to erase other channel
labels.
5
4
3
You can jump to the registered favorite
channels directly using four FAVORITE CH.
6
3
FAVORITE CH :CH 12
SET
A B C D
12 0 0 0
: SELECT ENTER: SET
NOTE
• You can enter to the same menu screen from (OPTION)
menu.
3Y10101A.indb 203Y10101A.indb 20 2006/01/19 20:30:322006/01/19 20:30:32
21
Basic adjustment settings
AV MODE STANDARD
BRIGHTNESS 25
CONTRAST 40
COLOR 25
TINT 0
SHARPNESS 25
:SELECT :ADJUST
Picture adjustments
Adjusts the picture to your preference with the following
picture settings.
NOTE
• For resetting all Picture adjustment items to the factory
preset values, press / to select “RESET”, and then
press / (see page 26 for further information).
Press / to select a specifi c adjustment
item (BRIGHTNESS, CONTRAST, COLOR,
TINT, SHARPNESS).
Press / to adjust the item to the desired
level.
Press MENU and the MENU screen
displays.
Press / to select (PICTURE).
1
2
4
3
Selected item
button button
BRIGHTNESS For less
brightness
For more
brightness
CONTRAST For less contrast For more contrast
COLOR For less color
intensity
For more color
intensity
TINT Skin tones
become purplish
Skin tones
become greenish
SHARPNESS For less
sharpness
For more
sharpness
Press EXIT to return to the normal screen.
5
Color temperature
For a better white balance, use color temperature
correction.
Press MENU and the MENU screen
displays.
Press / to select (PICTURE).
Press / to select “COLOR
TEMPARATURE”.
Press / to select the mode you prefer.
Press EXIT to return to the normal screen.
1
2
3
Cinema mode
A smoother motion may be obtained by setting the
CINEMA MODE to FILM when you view a DVD from
the DVD player connected with the component input.
4
5
Selected item Description
COOL White with Blueish tone
MEDIUM Neutral
WARM White with Reddish tone
Press MENU and the MENU screen
displays.
Press / to select (SETUP).
Press / to select “CINEMA MODE”.
Press / to select “FILM” or “VIDEO”.
1
2
3
4
Selected item Description
FILM Film content viewing mode
VIDEO
Video content viewing mode
Back lighting
BACK LIGHTING adjusts the screen brightness for
improved picture clarity.
Press / to select “BACK LIGHTING”.
Press / to adjust the screen brightness.
Press MENU and the MENU screen
displays.
Press / to select (SETUP).
1
2
4
3
Press EXIT to return to the normal screen.
5
3Y10101A.indb 213Y10101A.indb 21 2006/01/19 20:30:332006/01/19 20:30:33
22
Sound adjustment
You can adjust the sound quality to your preference
with the following settings.
Basic adjustment settings
Press / to adjust the item to the desired
level.
NOTE
• For resetting all Audio adjustment items to the factory
preset values, press / to select “RESET”, and then
press / (see page 26 for further information).
Press MENU and the MENU screen
displays.
Press / to select (AUDIO).
Press / to select a specifi c adjustment
item (BASS, TREBLE, BALANCE).
1
2
3
4
Selected item
button button
BASS For weaker bass For stronger
bass
TREBLE For weaker
treble
For stronger
treble
BLANCE Decrease audio
from the right
speaker
Decrease audio
from the left
speaker
Press EXIT to return to the normal screen.
5
Press / to select “PCM” or “DOLBY
DIGITAL”.
Digital audio output
You can output digital audio to an AV amplifi er
or similar device whose DIGITAL AUDIO INPUT
terminal is connected to the COAXIAL DIGITAL
AUDIO OUTPUT terminal on the TV. Please select
an audio output format compatible with the audio
format of the program you are watching and the
equipment connected.
Press MENU and the MENU screen
displays.
Press / to select (AUDIO).
Press / to select “DIGITAL OUTPUT”.
1
2
4
3
Selected item Description
PCM The coaxial digital audio output
terminal outputs audio signal in
PCM form. If your digital audio
system does not support Dolby
Digital, select “PCM”.
DOLBY DIGITAL The coaxial digital audio output
terminal outputs audio signal in
Dolby Digital form. It reproduces
sound from surround program of
digital.
AUDIO
AUDIO LANGUAGE
DIGITAL OUTPUT PCM
PCM/DOLBY DIGITAL
RESET
:SELECT :ADJUST
AUDIO
MTS STEREO
BASS 25
TREBLE 25
BALANCE 0
SPEAKERS ON
:SELECT :ADJUST
Press EXIT to return to the normal screen.
5
3Y10101A.indb 223Y10101A.indb 22 2006/01/19 20:30:332006/01/19 20:30:33
23
SOURCE SELECTION
0. TV
1. INPUT1
2. INPUT2
3. INPUT3
4. INPUT4
5. INPUT5
6. INPUT6
[0-6]:SELECT
You can connect many types of external equipment to your TV like a DVD player, VCR, Digital TV tuner, HDMI
equipment, game console or camcorder. To view external source images, select the input source from INPUT
on the remote control unit or on the TV.
Displaying an external equipment
This explanation is for the setting when connecting a
DVD player to the INPUT3 terminal.
CAUTION
• To protect equipment, always turn off the TV before
connecting a DVD player, VCR, Digital TV tuner, HDMI
equipment, game console, camcorder or other external
equipment.
NOTE
• See pages 24 and 25 for external equipment connection.
• Please read the relevant operation manual (DVD player,
etc.) carefully before making connections.
• Refer to your external equipment operation manual for
the signal type.
Using external equipment
To watch a DVD image, select “INPUT3” from
“SOURCE SELECTION” menu using 0-6 on the
remote control.
• Each time INPUT is pressed, SOURCE SELECTION item
toggles.
• You can also select SOURCE SELECTION item by
pressing /.
3Y10101A.indb 233Y10101A.indb 23 2006/01/19 20:30:342006/01/19 20:30:34
24
Connecting a DVD player or a digital TV STB (Air or Cable)
You can use the INPUT1~4 terminals when connecting to a DVD player, a Digital TV STB (Air or Cable) and
other audiovisual equipment.
Using external equipment
DVD player/
Digital TV STB
NOTE
• See page 25 for connecting a DVD player or a Digital TV STB to the HDMI terminal.
Connecting a VCR, game console or
camcorder
A VCR, game console, camcorder and other
audiovisual equipment can be conveniently connected
using the INPUT1 or 2 terminals.
NOTE
• The S-video terminal takes priority over the video
terminals.
VCR/Game console/
Camcorder
Using digital audio output
It is possible to output audio through the COXIAL
DIGITAL AUDIO OUTPUT terminal. (See page 22 for
details.) PCM audio outputs from the terminal.
When using component cable.
(INPUT3 or 4)
When using composite cable. (INPUT1 or 2)
Component video
cable (commercially
available)
AV cable
(commercially available)
Audio cable
(commercially
available)
S-video cable
(commercially
available)
AV cable
(commercially
available)
To coaxial digital input of
external audio devices
Coaxial digital cable
DVD player/
Digital TV STB
3Y10101A.indb 243Y10101A.indb 24 2006/01/19 20:30:352006/01/19 20:30:35
25
SOURCE SELECTION
0. TV
1. INPUT1
2. INPUT2
3. INPUT3
4. INPUT4
5. INPUT5
6. INPUT6
[0-6]:SELECT
Connecting HDMI equipment
You can use the INPUT5 or 6 terminal when connecting HDMI equipment.
HDMI cable (Commercially available)
Using external equipment
When using an HDMI-DVI
conversion cable, use INPUT5
and AUDIO terminal.
HDMI equipment
1
1
2
4
3
AUDIO
WOW SRS 3D OFF
FOCUS OFF
TruBass OFF
HDMI HDMI/DVI
:SELECT :ADJUST
5
Press / to select “HDMI” or “DVI”.
Press MENU and the MENU screen
displays.
Press / to select (AUDIO).
Press / to select “HDMI”.
HDMI: When you connect the HDMI device to
the TV, select this setting.
DVI: When you connect the DVI device to
the TV with analog audio cords, select
this setting.
Press EXIT to return to the normal screen.
NOTE
• Refer to your external equipment operation manual for
the signal type.
To watch an HDMI equipment image, select
“INPUT5” or “INPUT6” from “SOURCE
SELECTION” menu using INPUT on the
remote control unit or on the TV. (See page
23.)
Displaying an image from HDMI
equipment
Selecting HDMI audio input source
3Y10101A.indb 253Y10101A.indb 25 2006/01/19 20:30:352006/01/19 20:30:35
26
Useful adjustment settings
Reset
If complex adjustments are made and the settings
cannot be restored to normal, you can reset the
settings to the factory preset values.
Resetting audio adjustments
Each audio adjustments return to the following factory
settings:
BASS ..................center (25) BALANCE ...... center (0)
TREBLE..............center (25)
Press MENU and the MENU screen
displays.
1
Press / to select (AUDIO).
2
Press / to select “RESET”, and then
press /.
3
The TV screen return to the normal screen,
and “RESET” will be desplayed a few seconds.
AUDIO
AUDIO LANGUAGE
DIGITAL OUTPUT PCM
RESET
Resetting picture adjustments
Each picture adjustments return to the following
factory settings:
AV MODE .....................................................STANDARD
BRIGHTNESS / COLOR / SHARPNESS .....center (25)
CONTRAST ..................................................(40)
TINT ..............................................................center (0)
COLOR TEMPERATURE .............................COOL
Press MENU and the MENU screen
displays.
1
Press / to select (PICTURE).
2
Press / to select “RESET”, and then
press /.
3
The TV screen return to the normal screen,
and “RESET” will be desplayed a few
seconds.
4
COLOR
TEMPERATURE MEDIUM
RESET
Input label
Let you set the input terminal displayed when using
the “SOURCE SELECTION” menu or channel display.
Press / to select the new label for the
selected input source.
NOTE
• You cannot change label for “TV” input.
Press MENU and the MENU screen
displays.
Press / to select (OPTION).
Press / to select “VIDEO LABEL”, and
then press /.
The VIDEO LABEL menu screen displays.
Press / to select the specifi c input
source which you want to change.
1
2
4
3
5
VIDEO LABLE
1. INPUT1 - /VCR/DVD/DTV
2. INPUT2 - SAT/CBL
3. INPUT3 -
4. INPUT4 -
5. INPUT5 -
6. INPUT6 -
:SELECT :ADJUST
Press EXIT to return to the normal screen.
6
NOTE
• The channel setup settings will not be changed.
• The language settings will not be changed.
• The password number setting will not be changed.
– Uses the default label name
VCR Video cassette recorder
DVD DVD video
DTV Digital TV set-top box
SAT Satellite box
CBL Cable box
HD HDMI equipment
4
3Y10101A.indb 263Y10101A.indb 26 2006/01/19 20:30:352006/01/19 20:30:35
27
1
2
3
4
AUDIO
AUDIO LANGUAGE
DIGITAL OUTPUT PCM
RESET
:SELECT :ADJUST
AV MODE STANDARD
SPORTS/STANDARD/MOVIE/MEMORY
BRIGHTNESS 25
CONTRAST 40
COLOR 25
TINT 0
SHARPNESS 25
:SELECT :ADJUST
Useful adjustment settings
AV mode
AV mode gives you four viewing options to choose
from to best match the surrounding environment
of the TV, which can vary due to factors like room
brightness, type of program watched or the type of
image input from external equipment.
Press
/
to select the desired mode.
• The mode can be chosen from the list below.
Press AV MODE and the (PICTURE)
menu screen displays. “AV MODE” will be
highlighted.
NOTE
• Each time AV MODE is pressed, AV MODE item toggles.
• You can select a different AV MODE item for each input
mode. (For example, select STANDARD for TV input and
SPORTS for VIDEO input.)
1
2
Selected item Description
SPORTS For a clear-cut image
emphasizing high contrast,
useful for sports viewing
STANDARD For a highly defi ned image
in a normal lighting
MOVIE For a movie
MEMORY Allows the user to
customize settings as
desired. You can set
the mode for each input
source.
Selecting the digital audio language
When two or more audio languages are included
in a digital signal, you can select one of the audio
languages.
Press / to select your desired language,
then press ENTER.
Press / to select “AUDIO LANGUAGE”,
and then press /.
Press / to select (AUDIO).
Press MENU and the MENU screen
displays.
AUDIO LANGUAGE
0. ENGLISH 1
1. ENGLISH 2
2. FRENCH
3. SPANISH
4. NO INFO
5. NO INFO
6. NO INFO
7. NO INFO
[0-7]:SELECT
SET:ENTER
Press EXIT to return to the normal screen.
5
Press EXIT to return to the normal screen.
3
3Y10101A.indb 273Y10101A.indb 27 2006/01/19 20:30:362006/01/19 20:30:36
28
Useful adjustment settings
Press 0-3 to select each view mode directly
while the view mode menu is still on the
screen.
• Each time VIEW MODE is pressed, VIEW
MODE item toggles.
• You can also select VIEW MODE item by
pressing
/
.
• You can sequentially select a view mode that
has its own aspect ratio.
View mode for 4:3 programs
Stretch:
This mode is useful for 1.78:1 DVDs.
When viewing 1.85:1 DVDs, stretch
mode will still show very thin black
bands at the top and bottom of the
screen.
Press VIEW MODE.
• The View mode menu displays.
• The menu lists the view mode options
selectable for the type of video signal currently
being received.
Side Bar:
Suitable for viewing conventional 4:3
programs in their normal format.
S.Stretch (Smart stretch):
Suitable for stretching 4:3 programs
to fi ll the screen.
Zoom:
Suitable for viewing wide-screen
2.35:1 anamorphic DVDs in full
screen.
1
2
View mode for HD programs
Stretch mode is available for HD programs.
Suitable for viewing wide-screen 1.78:1 aspect-ratio
programs. When viewing 1.85:1 programs, the stretch
mode will still show very thin black bands at the top
and bottom of the screen.
Picture scroll
For adjusting a picture's vertical position in S.Stretch
or Zoom mode.
1
2
4
SCROLL ADJUSTMENT screen displays.
To raise the picture, press . To lower the
picture, press .
Press / to select “PICTURE SCROLL”,
and then press /.
Press / to select (SETUP).
Press MENU and the MENU screen
displays.
3
SCROLL ADJUSTMENT +10
: TO ADJUST
The scroll amounts are as follows:
• 480i/480p signal source:
Zoom: –10 to +20
S.Stretch: –10 to +20
Press EXIT to return to the normal screen.
5
NOTE
• In Side Bar and Stretch mode, PICTURE SCROLL will not
work.
Aspect
When the ASPECT is set to ON and the TV recieves
a 480i signal, the picture size is automatically
selected (as described in the following table).
1
2
Press / to select “ASPECT”, and then
press / to select “ON” or “OFF”.
Press / to select (SETUP).
Press MENU and the MENU screen
displays.
3
Press EXIT to return to the normal screen.
4
Aspect ratio of signal
source
Automatic aspect size
(when ASPECT is ON)
4:3 Normal Side Bar
16:9 Full Stretch
4:3 Letter box Stretch
Not defi ned User-set mode
VIEW MODE
0. Side Bar
1. S.Stretch
2. Zoom
3. Stretch
[0-3]:SELECT
NOTE
• You can enter to the same menu screen from
(SETUP) menu.
• When this function is not available, “NOT AVAILABLE”
will display.
3Y10101A.indb 283Y10101A.indb 28 2006/01/19 20:30:362006/01/19 20:30:36
29
SLEEP
0h07m
SLEEP
0h00m
SLEEP
0h10m
(Sleep timer off)
step up by 10 minutes
SLEEP
1h50m
SLEEP
2h00m
Sleep timer
Allows you to set a time when the TV automatically
switches to standby.
2
1
Audio output select
Allows you to select what controls the audio output.
Press
/
to select “ON” or “OFF”.
Press MENU and the MENU screen
displays.
Press / to select (AUDIO).
Press / to select “SPEAKERS”.
1
2
4
3
Selected item
ON
OFF
Description
• Sound via speaker is adjusted with
VOL +/
–
on the remote control unit or
VOL
–
/+ on the TV.
• Sound via the AUDIO OUTPUT
terminal is not adjustable and outputs
at a consistent level.
• Sound via the AUDIO OUTPUT
terminal is adjusted with VOL +/
–
on
the remote control unit or VOL
–
/+ on
the TV.
• Sound via speaker is muted.
AUDIO
MTS STEREO
BASS 25
TREBLE 25
BALANCE 0
SPEAKERS ON/OFF
:SELECT :ADJUST
Useful adjustment settings
Each time you press SLEEP, the remaining
time setting switches as shown below.
Press SLEEP.
• The remaining time displays when the sleep
timer has been set.
This display will disappear after a few
seconds, the sleep timer automatically
starts counting down.
• If you want to adjust the sleep timer again, you
can press SLEEP repeatedlly then change the
time setting.
NOTE
• Select “0h00m” by pressing SLEEP repeatedly to cancel
the sleep timer.
• The TV will enter the standby mode when the remaining
time reaches zero.
Press EXIT to return to the normal screen.
5
3Y10101A.indb 293Y10101A.indb 29 2006/01/19 20:30:372006/01/19 20:30:37
30
SETUP
CLOSED CAPTION OFF
C1/C2/T1/T2/OFF
CC ADVANCED
VIEW MODE
PICTURE SCROLL
:SELECT :ADJUST
4
Closed captions and digital closed
captions
Your TV is equipped with an internal Closed Caption
decoder. It allows you to view conversations,
narration and sound effects as subtitles on your TV.
Closed Captions are available on some TV programs
and on some VHS home video tapes at the discretion
of the program provider.
Digital Closed Caption service is a new caption
service available only on digital TV programs (also
at the discretion of the service provider). It is a more
fl exible system than the original Closed Caption
system, because it allows a variety of caption
sizes and font styles. When the Digital Closed
Caption service is in use, it will be indicated by
the appearance of a 3-letter abbreviation that also
indicates the language of the Digital Closed Captions:
ENG (English), SPA (Spanish), FRA (French) or other
language codes.
Not all programs and VHS videotapes offer closed
captions. Please look for the “
” symbol to ensure
that captions will be shown.
In the Closed Caption system, there can be more
than one caption service provided. Each is identifi ed
by its own number. The “C1” and “C2” services
display subtitles of TV programs superimposed over
the program’s picture. Generally, Closed Captions in
English are transmitted on C1 and Closed Captions in
other languages are transmitted on C2.
In the Closed Caption system, the “Text1” or “Text2”
services display text that is unrelated to the program
being viewed (e.g., weather or news). These services
are also superimposed over the program currently
being viewed.
Tune the TV to the desired program.
NOTE
• If the program or video you selected is not closed-captioned, no captions will display on-screen.
• If text is not available in your viewing area, a black rectangle may appear on-screen. If this happens, set the Closed
Caption feature to “OFF“.
• When selecting Closed Captions, the captioning will be delayed approx. 10 seconds.
• If no caption signal is received, no captions will appear, but the television will remain in the Caption Mode.
• Misspellings or unusual characters may occasionally appear during Closed Captioning. This is normal with Closed
Captioning, especially with live programs. This is because during live programs, captions are also entered live. These
transmissions do not allow time for editing.
• When Captions are being displayed, on-screen displays, such as volume and mute may be seen but may interfere with
Closed Captions.
• Some Cable TV systems and copy protection systems may interfere with the Closed Captioned signal.
• If using an indoor antenna or if TV reception is very poor, the Closed Caption Decoder may not appear or may appear with
strange characters or misspelled words. In this case, adjust the antenna for better reception or use an outdoor antenna.
Useful adjustment settings
1
Press CC to display “CLOSED CAPTION”
menu.
2
Press CC repeatedly to select your desired
Closed Caption mode.
• When an Analog signal is received, you can
choose C1, C2, T1, T2 and OFF.
3
SETUP
CLOSED CAPTION OFF
CS1/CS2/CS3/CS4/CS5/CS6
C1/C2/C3/C4/T1/T2/T3/T4/OFF
CC ADVANCED
VIEW MODE
PICTURE SCROLL
:SELECT :ADJUST
• Depending on the broadcast signal, some
Analog Captions will function with a Digital
broadcast signal.
Press EXIT to return to the normal screen.
NOTE
• You can enter to CLOSED CAPTION menu from
(SETUP) menu.
• To turn the Closed Caption feature off, select “OFF”.
• When a Digital signal is received, you can
choose from CS1, CS2, CS3, CS4, CS5, CS6,
C1, C2, C3, C4, T1, T2, T3, T4 and OFF.
3Y10101A.indb 303Y10101A.indb 30 2006/01/19 20:30:372006/01/19 20:30:37
31
CC ADVANCED
TEXT SIZE
TEXT TYPE
TEXT COLOR
TEXT EDGE
BACKGROUND COLOR
:SELECT :ADJUST
6
Caption setup
This function allows you to adjust the closed caption
screen appearance to suit your preference.
Press
/
to select a specifi c adjustment
item, then press
/
. The selectable
parameter of each items will appear.
Press
/
to select the desired parameter.
NOTE
• This feature is designed to customize Digital Captions
only.
• The “AUTO” value depends on the broadcasting station.
Selectable parameters available in each adjustment
item.
Press MENU and the MENU screen
displays.
Press
/
to select (SETUP).
Press
/
to select “CC ADVANCED”, and
then press
/
. The CC ADVANCED menu
displayed.
• You can adjust 5 items here.
Useful adjustment settings
1
2
4
5
3
TEXT SIZE
AUTO
SMALL
STANDARD
LARGE
:SELECT :ADJUST
Item Selectable parameter
TEXT SIZE: AUTO, SMALL,
STANDARD, LARGE
TEXT TYPE: AUTO, DEFAULT, MONO
W. SERIF, PROP. W.
SERIF, MONO W/O SERIF,
PROP. W/O SERIF,
CASUAL, CURSIVE,
SMALL CAPITALS
TEXT COLOR: AUTO, BLACK, WHITE,
RED, GREEN, BLUE,
YELLOW, MAGENTA,
CYAN
TEXT EDGE: AUTO, NONE, RAISED,
DEPRESSED, UNIFORM,
LEFT DROP SHADOW,
RIGHT DROP SHADOW
BACKGROUND COLOR: AUTO, BLACK, WHITE,
RED, GREEN, BLUE,
YELLOW, MAGENTA,
CYAN
Press EXIT to return to the normal screen.
3Y10101A.indb 313Y10101A.indb 31 2006/01/19 20:30:382006/01/19 20:30:38
32
LOCKS
CONFIRM PASSWORD
[0-9]:SELECT ENTER:SET
EXIT:END
LOCKS
V-CHIP SET
V-CHIP OFF
TV RATING OFF
MOVIE RATING OFF
NEW PASSWORD
:SELECT :ADJUST
LOCKS
NEW PASSWORD
----
[0-9]:SELECT ENTER:SET
EXIT:END
Password setting for parental
control
Allows you to use a password to protect certain
settings from being accidentally changed.
IMPORTANT:
Two conditions must be met to enable the V-Chip
1
Password is registered.
2
V-CHIP settings have been made.
3
“V-CHIP” is set to “ON”.
Setting a password
Press
/
to select (LOCKS).
Press
/
. The password entering menu
displays.
Press MENU and the MENU screen
displays.
Select and enter a password (4 digits) using
the number buttons (0–9), then press
ENTER.
Enter the same password again to confi rm,
then press ENTER, the password is now
registered and the V-CHIP SET menu will
appear on the screen.
Useful adjustment settings
1
2
5
3
Press / to select “NEW PASSWORD”,
then press /.
Repeat steps 1 to 3 in setting a password.
• The password entering menu displays.
Changing the password
Allows you to change your current password.
Input the 4-digit password by using 0–9.
1
2
3
Enter a new password using 0–9, then
press ENTER.
Enter the same password again to confi rm,
then press ENTER.
LOCKS
NEW PASSWORD
----
[0-9]:SELECT ENTER:SET
EXIT:END
“ ” appears instead of the number.
4
4
5
LOCKS
CONFIRM PASSWORD
[0-9]:SELECT ENTER:SET
EXIT:END
The screen returns to V-CHIP SET menu.
Your new password has been set.
6
NOTE
• As a precautionary measure, make a note of your
password and keep it in a familiar place.
3Y10101A.indb 323Y10101A.indb 32 2006/01/19 20:30:382006/01/19 20:30:38
33
Parental control (V-CHIP)
V-CHIP is an electronic fi ltering device built into your TV. This tool gives parents a great degree of control over
broadcasts accessed by their children. It allows parents to select programs judged suitable for child viewing
while blocking ones judged not suitable. It does so automatically once you activate the V-CHIP feature in your
TV.
V-CHIP SET menu will not be selectable from the menu if you do not fi rst confi gure your password.
(See page 32 for password setting for parental control.)
• The U.S. has two rating systems for viewing content: movie ratings and TV Parental Guidelines.
• The TV Parental Guidelines work in conjunction with the V-CHIP to help parents screen out inappropriate
television shows from their children.
• Movie ratings are used for original movies rated by the Motion Picture Association of America (MPAA) as
watched on cable TV and not edited for television. The V-CHIP can also be set to block MPAA-rated movies.
TV Parental Guidelines
EXAMPLE
• If you select “PG-13”, this will automatically block the higher ratings “R”, “NC-17” and “X”.
NOTE
• Voluntary movie rating system only uses an age-based rating.
X: Content rating can be set.
Useful adjustment settings
MOVIE RATING Description
G
PG
PG-13
R
NC-17
X
Age
General audiences. All ages admitted.
Parental guidance suggested. Some material may not be suitable for children.
Parents strongly cautioned. Some material may be inappropriate for children under 13.
Restricted. Under 17 requires accompanying parent or adult guardian (age varies in some
jurisdictions).
No one 17 and under admitted.
X is an older rating that is unifi ed with NC-17 but may be encoded in the data of older movies.
TV RATING
TV-Y (All children)
TV-Y7 (Directed to older children)
TV-G (General audience)
TV-PG (Parental Guidance suggested)
TV-14 (Parents strongly cautioned)
TV-MA (Mature audience only)
Suggested
age
Content
SEXUAL
DIALOG
ADULT
LANGUAGE
SEXUAL
SITUATIONS
VIOLENCE
FANTASY
VIOLENCE
X
X
X
X
X
X
X
X
X
X
X
X
Voluntary movie rating system (MPAA)
3Y10101A.indb 333Y10101A.indb 33 2006/01/19 20:30:392006/01/19 20:30:39
34
LOCKS
V-CHIP SET
V-CHIP OFF
TV RATING OFF
MOVIE RATING OFF
OFF/G/PG/PG-13/R/NC17/X
NEW PASSWORD
:SELECT :ADJUST
1
2
Press EXIT to return to the normal screen.
3
• See page 33 for setting details.
Input the 4-digit password by using 0–9.
The V-CHIP SET menu displays.
Press / to select (LOCKS).
Press
/
. The password entering menu
displays.
Press
/
to select “TV RATING”. Then
press
/
to select the desired rating.
• When you select TV-Y7, TV-PG, TV-14 or
TV-MA, “DISPLAY TO SET CONTENTS”
will appear on the screen. Press DISPLAY
to explain the rating. Press
/
to select
the desired rating you want. Press
/
to
select the setting
“
ON
”
or
“
OFF
”
. Then press
RETURN.
• See page 33 for setting details.
Voluntary movie rating system
(MPAA)
Repeat steps 1 to 4 in TV Parental
Guidelines (TV Guidelines).
Press
/
to select “MOVIE RATING”.
Then press
/
to display the desired
rating.
TV Parental Guidelines
(TV Guidelines)
Press MENU and the MENU screen
displays.
Useful adjustment settings
1
2
4
5
1
2
3
LOCKS
V-CHIP SET
V-CHIP OFF
TV RATING OFF
OFF/TV-Y/TV-Y7/TV-G
TV-PG/TV-14/TV-MA
MOVIE RATING OFF
NEW PASSWORD
:SELECT :ADJUST
Press / to select “ON”.
• If “V-CHIP” is not set to “ON” the V-CHIP
settings will not work.
Press
/
to select “V-CHIP”.
7
6
How to temporarily release the
V-CHIP block
The V-CHIP block is working and censors
a broadcast, “THIS PROGRAM HAS BEEN
BLOCKED!” displays.
Reactivating the temporarily
released V-CHIP block
You can reactivate the temporarily released V-CHIP
block as shown below.
Method 1:
Change to the other channel.
Method 2:
Switch off the TV power.
NOTE
• Performing any of the two above will activate the V-CHIP
block.
Press MUTE while the V-CHIP is working
and then the password entering menu
displays.
Enter your 4-digit password with 0–9.
At this time V-CHIP block temporarily
releases.
Press EXIT to return to the normal screen.
Your setting are now set into memory.
8
3Y10101A.indb 343Y10101A.indb 34 2006/01/19 20:30:392006/01/19 20:30:39
35
NOTE
• When this function is not available, “NOT AVAILABLE”
will display.
• The still image automatically goes out after 30 minutes.
• If you are using the freeze function and a broadcast
activates the V-CHIP block, the freeze function will be
cancelled and a V-CHIP block message will appear.
Presetting remote control function
You can operate the connected AV products (AV
Receiver, Cable Box, SAT tuner, DTV, VCR, DVD,
LD) using the presetting manufacturer function of your
remote control unit.
Press FREEZE again to cancel the
function.
Other viewing options
Freezing images
Allows you to capture and freeze an image from a
moving image that you are watching.
Press FREEZE.
• A moving image is captured.
Presetting manufacturer codes
After the LED for your device lights up,
press FUNCTION and DISPLAY at the
same time to enter the code registration
mode. The LED will blink.
Press FUNCTION until the LED for your
device lights up.
After registering the code, the LED will stop
blinking then turn off after one second. (If
you perform an incorrect operation, the LED
will blink quickly then turn off.)
Press 0–9 to enter the manufacturer code.
(See page 36.)
• Preset mode is fi nished once the LED no
longer lights up.
1
2
1
2
4
3
SIGNAL METER
CHANNEL (DIGITAL) 23.002
40
Signal meter
In order to receive digital air broadcasts, you need a
digital broadcast antenna. You can confi rm the antenna
confi guration through the “SIGNAL METER” menu.
If necessary, adjust the direction of the antenna to
obtain the maximum signal strength.
Signal strength
Press MENU and the MENU screen
displays.
Press / to select (SETUP).
Press / to select “SIGNAL METER”.
Press /.
• The strength of the digital signal is displayed.
The signal information is based on the current
channel.
1
2
3
4
Press EXIT to return to the normal screen.
5
3Y10101A.indb 353Y10101A.indb 35 2006/01/19 20:30:402006/01/19 20:30:40
36
Manufacturer codes
REMOTE CONTROL CODE
NUMBER
Other viewing options
VCR BRAND
REMOTE CONTROL CODE
NUMBER
DVD/LD BRAND
REMOTE CONTROL CODE
NUMBER
CATV/SAT BRAND
NOTE
• Numbers marked with * are SAT codes, all others are
CATV codes.
AUDIO BRAND
REMOTE CONTROL CODE
NUMBER
3Y10101A.indb 363Y10101A.indb 36 2006/01/19 20:30:402006/01/19 20:30:40
37
1
2
3
4
1
2
3
Cable control buttons
When the FUNCTION is set to CBL/SAT, the cable
converter connected to the TV can be operated using
1 to 4.
1 SOURCE POWER
Turns the cable converter power on and off.
2 0–9
Press a button (or buttons) that corresponds to
the channel that you wish to watch.
3 FLASHBACK *
Press to switch between the current channel
and the channel you were watching immediately
before.
4 CH
/
Press CH or CH to tune in a higher or lower
channel.
* Some manufacturers do not preset FLASHBACK.
NOTE
• CABLE and SAT cannot be selected at the same time.
SAT control buttons
1 SOURCE POWER
Turns the cable converter power on and off.
2 0–9, • (DOT)
Press a button (or buttons) that corresponds to
the channel that you wish to watch.
3 ENTER,
/
/
/
ENTER: Press to activate the selected function.
/
/
/
: Press the button to select items on the
SAT GUIDE screen or SAT MENU
screen.
NOTE
• CABLE and SAT cannot be selected at the same time.
Other viewing options
3Y10101A.indb 373Y10101A.indb 37 2006/01/19 20:30:412006/01/19 20:30:41
38
2
8
4
1
7
6 5
3
8
2
1
103
5
6
9
4
7
Other viewing options
VCR control buttons
The remote control unit button will function as follows
when the FUNCTION of the remote control unit is set
to VCR.
• Press INPUT until the input connected to the VCR is
selected. The following 1 to 8 can be used to control the
VCR.
1 CH /
Press to select the channel of the TV tuner on the
VCR.
2 SOURCE POWER
Turns the power of the VCR on and off.
3
Sets pauses and still pictures.
4
Rewinds the tape and allows picture search.
5
Stops the tape transport.
6 REC
Starts recording.
7
Rapidly advances the tape and allows picture search.
8
Starts playback.
DVD control buttons
The remote control unit button will function as follows
when the FUNCTION of the remote control unit is set
to DVD.
• Press INPUT until the input connected to the DVD player
is selected. The following 1 to 10 can be used to control
the DVD player.
1
Pressing quickly once takes you to the start of the
next chapter. Each time you press it, you move
ahead to the start of the next chapter.
2
Pressing quickly once takes you to the start of the
chapter currently playing. Each time you press
it, you move back to the start of the previous
chapter.
3 SOURCE POWER
Turns the power of the DVD player on and off.
4
Set pauses and still pictures.
5
Hold down to go in reverse.
6
Playback stops when pressed.
With some DVD players, pressing the button
twice may open the disc tray.
7 MENU
When this button is pressed, the DVD menu will
display.
8 ENTER,
/
/
/
ENTER: Press to activate the selected function.
/
/
/
: Press the button to select items on
the DVD MENU screen.
9
Hold down to fast forward.
10
Starts playback.
3Y10101A.indb 383Y10101A.indb 38 2006/01/19 20:30:412006/01/19 20:30:41
39
Removing the stand
Before detaching (or attaching) stand, unplug the AC cord from the AC INPUT terminal.
CAUTION
• Do not remove the stand from the TV unless using an optional wall mount bracket to mount it.
Before attaching/detaching stand
• Before performing work make sure to turn off the TV.
• Before performing work spread cushioning over the base area to lay the TV on. This will prevent it from being
damaged.
Setting the TV on the wall
CAUTION
• Installing the TV requires special skill that should only be performed by qualifi ed service personnel. Customers
should not attempt to do the work themselves. SHARP bears no responsibility for improper mounting or mounting
that results in accident or injury.
Using an optional bracket to mount the TV
• You can ask a qualifi ed service professional about using an optional AN-26AG1 bracket for LC-26D40U or AN-
37AG2 bracket for LC-32D40U to mount the TV to the wall.
• Carefully read the instructions that come with the bracket before beginning work.
Hanging on the wall
Wall mount bracket. (See the bracket instructions for details.)
Vertical mounting
About setting the TV angle
Unfasten the four screws used to secure the stand in
place.
Detach the stand from the TV.
(Hold the stand so it will not drop from the edge of the
base area.)
Appendix
NOTE
• To attach the stand, perform the above steps in reverse order.
Angular mounting
12
Selected
item
Up to 20°
Up to 10°
LC-26D40U
LC-32D40U
Angle of TV
hex key
NOTE
• Detach the cable clamp on the rear of the TV when using the optional mount bracket.
Soft cushion
3Y10101A.indb 393Y10101A.indb 39 2006/01/19 20:30:412006/01/19 20:30:41
40
Troubleshooting
Possible Solution
• Is the volume too low? (See page 17.)
• Is “OFF” selected in “SPEAKERS”? (See page 29.)
Troubleshooting-Digital broadcasting
This messages about reception of broadcasting
Cautions regarding use in high and low temperature environments
Appendix
Problem
• No power
• Unit cannot be operated.
• Remote control unit does not
operate.
• Picture is cut off screen.
• Strange color, light color, or color
misalignment
• Power is suddenly turned off.
• No picture
• No sound
• Check if you pressed TV POWER on the remote control unit. (See page 14.) If
the indicator on the TV does not light up, press TV POWER on the TV.
• Is the AC cord disconnected? (See page 7.)
• Has the power been turned on? (See page 14.)
• External infl uences such as lightning, static electricity, may cause improper
operation. In this case, operate the unit after fi rst turning on the power of the TV
or unplugging the AC cord and replugging it in after 1 or 2 minutes.
• Is the FUNCTION set correctly? Set it to the TV setting position.
• Are batteries inserted with polarity (+,
–
) aligned? (See page 8.)
• Are batteries worn out? (Replace with new batteries.)
• Are you using it under strong or fl uorescent lighting?
• Is a fl uorescent light illuminated near the remote control sensor?
• Are screen mode adjustments such as view mode choose made correctly? (See
page 28.)
• Adjust the picture tone. (See pages 21–22.)
• Is the room too bright? The picture may look dark in a room that is too bright.
• Is the sleep timer set? (See page 29.)
• Check the power control settings. (See page 14.)
• The unit’s internal temperature has increased.
Remove any objects blocking vent or clean.
• Is connection to other components correct? (See pages 24 to 25.)
• Is correct input signal source selected after connection? (See page 23.)
• Is the correct input selected? (See page 23.)
• Is picture adjustment correct? (See page 21.)
• When the unit is used in a low temperature space (e.g. room, offi ce), the picture may leave trails or appear slightly
delayed. This is not a malfunction, and the unit will recover when the temperature returns to normal.
• Do not leave the unit in a hot or cold location. Also, do not leave the unit in a location exposed to direct sunlight or near
a heater, as this may cause the cabinet to deform and the Liquid Crystal panel to malfunction.
Storage temperature: –4°F to +140°F (– 20°C to +60°C)
The example of an error message
displayed on a screen
Possible Solution
• DIGITAL CHANNEL SIGNAL
STRENGTH IS LOW
• Check the antenna cable. Check that the antenna is correctly setup.
• DIGITAL CHANNEL IS
ENCRYPTED
• It is subscription channel. Contact the service provider.
• AUDIO ONLY • The channel has audio contents only.
3Y10101A.indb 403Y10101A.indb 40 2006/01/19 20:30:422006/01/19 20:30:42
41
Specifi cations
• *Emergency alert messages via Cable are unreceivable.
• As part of policy of continuous improvement, SHARP reserves the right to make design and specifi cation changes for
product improvement without prior notice. The performance specifi cation fi gures indicated are nominal values of production
units. There may be some deviations from these values in individual units.
Appendix
LCD panel
Number of dots
TV
Function
TV-standard (CCIR)
Receiving
Channel
VHF/UHF
CATV
Digital Terrestrial
Broadcast (8VSB)
Audio multiplex
Brightness
Backlight
Viewing angles
Audio out
Terminals
Rear
INPUT 1
INPUT 2
INPUT 3
INPUT 4
INPUT 5
ANT/CABLE
DIGITAL AUDIO OUTPUT
OUTPUT
OSD language
Power Requirement
Power Consumption
Weight
Dimension
(W H D)
Accessories
Operating temperature
3,147,264 dots (1366 x 768 x 3 dots)
American TV Standard ATSC/NTSC System
VHF 2-13ch, UHF 14-69ch
1-125ch* (non-scrambled channel only.)
2-69ch
BTSC System
450cd/m
2
60,000 hours (at Backlight Standard position)
H : 176° V : 176°
10W x 2
AV in, S-VIDEO in
AV in, S-VIDEO in
COMPONENT in, Audio in
COMPONENT in, Audio in
HDMI in with HDCP, Audio in
75 Ω Unbalance, F Type x 1 for Analog (VHF/UHF/CATV) and Digital (AIR/CABLE)
Coaxial Digital audio output x 1 (PCM/Dolby Digital)
Audio out
English/French/Spanish
AC 120 V, 60 Hz
Remote control unit (x1), AC cord (x1), “AAA” size battery (x2), Cable clamp (x1),
Stand unit (x1), Operation manual (x1)
+32°F to +104°F (0°C to +40°C)
Item
Model: LC-26D40U Model: LC-32D40U
26” Advanced Super View & BLACK
TFT LCD
32” Advanced Super View & BLACK
TFT LCD
with stand
w/o stand
w/o stand
with stand
145 W (Standby 1W) 170 W (Standby 1W)
29.8 lbs./13.5 kg
35.3 lbs./16.0 kg
26-
7
/
8
x 10
13
/
16
x 21
6
/
8
inch
37.5 lbs./17.0 kg
43.0 lbs./19.5 kg
32
5
/
16
x 4
9
/
16
x 23
5
/
16
inch
32
5
/
16
x 10
13
/
16
x 25
9
/
16
inch
26-
7
/
8
x 4-
1
/
2
x 19-
5
/
8
inch
INPUT 6 HDMI in with HDCP
Optional accessories
The listed optional accessories are available for
the LCD colour TV. Please purchase them at your
nearest shop.
• Additional optional accessories may be available in
near future. When purchasing, please read the newest
catalogue for compatibility and check the availability.
No. Part name Part number
1
Wall mount bracket
(for LC-26D40U)
AN-26AG1
2
Wall mount bracket
(for LC-32D40U)
AN-37AG2
3Y10101A.indb 413Y10101A.indb 41 2006/01/19 20:30:422006/01/19 20:30:42
42
21
7
/
32
(538.7)
32
5
/
16
(820.8)
4
33
/
64
(114.8)
27
9
/
16
(700)
25
17
/
32
(648.35)
23
9
/
32
(591.25) 2
1
/
4
(57)
15
9
/
16
(395.2)
15
9
/
16
(394.6)
10
49
/
64
(273.2)
4
23
/
32
(120.1)
7
7
/
8
(200)
4
33
/
64
(115)
7
7
/
8
(200)
21
7
/
32
(538.7)
10
49
/
64
(273.2)
2
53
/
64
(71.65)
26
7
/
8
(682)
22
23
/
64
(567.9)
21
11
/
16
(550.95)
19
41
/
64
(498.85)
13
17
/
64
(337.1)
2
3
/
64
(52.1)
4
1
/
2
(114)
3
15
/
16
(100)
2
23
/
64
(60)
3
15
/
16
(100)
12
5
/
8
(320.6)
Dimensional drawings
Unit: inch/(mm)
LC-26D40U
LC-32D40U
3Y10101A.indb 423Y10101A.indb 42 2006/01/19 20:30:432006/01/19 20:30:43
43
The password is
NOTE
• As a precautionary measure, make a note of your password above, cut it from this manual, and keep it in a safe place.
.
CLEARING THE PASSWORD
If you forget the password, clear the password using the following procedure.
Now the old password was cleared. You can set the new password. (See page 32.)
Press and hold both VOL – on the TV and 0 on the remote control simultaneously for a few
seconds until (LOCKS) menu appears on the screen.
1
2
3Y10101A.indb 433Y10101A.indb 43 2006/01/19 20:30:432006/01/19 20:30:43
44
For location of the nearest Sharp Authorized Service, or to obtain product literature, accessories, supplies, or
customer assistance, please call 1-800-BE-SHARP.
Calling for Service
LIMITED WARRANTY
Model Specific Section
Where to Obtain Service:
From a Sharp Authorized Servicer located in the United
States. To find the location of the nearest Sharp Authorized
Servicer, call Sharp toll free at 1-800-BE-SHARP.
What to do to Obtain Service:
Contact your Sharp Authorized Servicer to obtain in-home
service for this Product. The Servicer will come to your home
and if it is necessary to remove the Product, the Servicer will
reinstall it. Be sure to have Proof of Purchase available.
Additional Item(s) Excluded from
Warranty Coverage (if any): Non-rechargeable batteries.
Warranty Period for this Product: One (1) year parts and labor from the date of purchase.
TO OBTAIN PRODUCT INFORMATION, CALL 1-800-BE-SHARP OR VISIT www.sharpusa.com
SHARP ELECTRONICS CORPORATION
SHARP CORPORATION
Sharp Plaza, Mahwah, New Jersey 07430-2135
Your Product Model Number & Description:
(Be sure to have this information available when you need
service for your Product.)
LC-26D40U •LC-32D40U LCD Color Television
CONSUMER LIMITED WARRANTY
SHARP ELECTRONICS CORPORATION warrants to the first consumer purchaser that this Sharp brand product (the
“Product”), when shipped in its original container, will be free from defective workmanship and materials, and agrees that
it will, at its option, either repair the defect or replace the defective Product or part thereof with a new or remanufactured
equivalent at no charge to the purchaser for parts or labor for the period(s) set forth below.
This warranty does not apply to any appearance items of the Product nor to the additional excluded item(s) set forth
below nor to any Product the exterior of which has been damaged or defaced, which has been subjected to improper
voltage or other misuse, abnormal service or handling, or which has been altered or modified in design or construction.
In order to enforce the rights under this limited warranty, the purchaser should follow the steps set forth below and
provide proof of purchase to the servicer.
The limited warranty described herein is in addition to whatever implied warranties may be granted to purchasers by
law. ALL IMPLIED WARRANTIES INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS FOR USE
ARE LIMITED TO THE PERIOD(S) FROM THE DATE OF PURCHASE SET FORTH BELOW. Some states do not allow
limitations on how long an implied warranty lasts, so the above limitation may not apply to you.
Neither the sales personnel of the seller nor any other person is authorized to make any warranties other than those
described herein, or to extend the duration of any warranties beyond the time period described herein on behalf of
Sharp.
The warranties described herein shall be the sole and exclusive warranties granted by Sharp and shall be the sole and
exclusive remedy available to the purchaser. Correction of defects, in the manner and for the period of time described
herein, shall constitute complete fulfillment of all liabilities and responsibilities of Sharp to the purchaser with respect to
the Product, and shall constitute full satisfaction of all claims, whether based on contract, negligence, strict liability or
otherwise. In no event shall Sharp be liable, or in any way responsible, for any damages or defects in the Product which
were caused by repairs or attempted repairs performed by anyone other than an authorized servicer. Nor shall Sharp be
liable or in any way responsible for any incidental or consequential economic or property damage. Some states do not
allow the exclusion of incidental or consequential damages, so the above exclusion may not apply to you.
THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY ALSO HAVE OTHER RIGHTS WHICH VARY FROM
STATE TO STATE.
D40U_en_j.indd 53 2005/12/01 14:29:03
3Y10101A.indb 443Y10101A.indb 44 2006/01/19 20:30:432006/01/19 20:30:43
