www.philips.com/support
BTD5210
User manual
Always there to help you
Register your product and get support at
Question?
Contact
Philips
1EN
Contents
1 Important 2
Safety 2
2 Your micro system 3
Introduction 3
What's in the box 3
Overview of the main unit 4
Overview of the remote control 5
3 Connect 7
Place the unit 7
Connect speakers 7
Connect FM antenna 7
Connect video/audio cables 8
Connect an external audio device 8
Connect power 9
4 Get started 10
Prepare the remote control 10
Set clock 10
Activate demonstration mode 10
Turn on 11
Find the correct viewing channel 11
Select the correct TV system 11
Change system menu language 11
5 Play 12
Play from disc 12
Play from USB or recored discs 13
Play a slideshow with background music 13
Resume video play from last stopped
point 13
Control play 14
Play options 14
Change the audio channel 14
6 Enjoy karaoke 15
Adjust Karaoke settings 15
7 Listen to the radio 16
Tune to a radio station 16
Program radio stations automatically 16
Program radio stations manually 16
Select a preset radio station 16
8 Play from Bluetooth-enabled
devices 17
9 Other features 18
Set the alarm timer 18
Set the sleep timer 18
Listen to an external device 18
10 Adjust settings 19
General setup 19
Video setup 19
Audio setup 20
Preferences 20
11 Product information 22
Specications 22
Supported disc formats 23
USB playability information 23
12 Troubleshooting 24
13 Notice 26
Declaration of conformity 26
2 EN
1 Important
Safety
• Make sure that there is enough free space
around the product for ventilation.
• Only use attachments or accessories
speciedbythemanufacturer.
• Battery usage CAUTION – To prevent
battery leakage which may result in bodily
injury, property damage, or damage to the
product:
• Install the battery correctly, + and - as
marked on the product.
• Remove the battery when the product
is not used for a long time.
• The battery shall not be exposed to
excessiveheatsuchassunshine,reor
the like.
• The product shall not be exposed to
dripping or splashing.
• Do not place any sources of danger on the
product(e.g.liquidlledobjects,lighted
candles).
• Where the plug of the Direct Plug-in
Adapter is used as the disconnect device,
the disconnect device shall remain readily
operable.
Warning
• Never remove the casing of this device.
• Never lubricate any part of this device.
• Never place this device on other electrical equipment.
• Keep this device away from direct sunlight, naked
amesorheat.
• Never look into the laser beam inside this device.
• Ensure that you always have easy access to the power
cord, plug, or adaptor to disconnect this device from
the power.
3EN
2 Your micro
system
Congratulations on your purchase, and
welcometoPhilips!Tofullybenetfromthe
support that Philips offers, register your product
at www.philips.com/welcome.
Introduction
With this unit, you can:
• Watch video from DVD/VCD/SVCD, or
USB storage devices;
• enjoy audio from discs, Bluetooth-enabled
devices, USB storage devices, or other
external devices;
• enjoy Karaoke by connecting a microphone.
• view pictures from discs or USB storage
devices;
• listen to FM radio stations.
You can enrich sound output with below
sound effect:
• Digital Sound Control (DSC)
• DSC 1: Balanced
• DSC 2: Clear
• DSC 3: Powerful
• DSC 4: Warm
• DSC 5: Bright
The unit supports these media formats:
DVD region code Countries
Europe
What's in the box
Check and identify the contents of your
package:
• Main unit
• 2 x speakers
• 1 x power cord
• 1 x composite video cable (yellow)
• 1 x FM antenna
• Remote control (with two AAA batteries)
• Short User Manual
• Safety&Notice Sheet
4 EN
Overview of the main unit
a
• Turn the unit on or off.
• Switch to standby mode or Eco
standby mode.
b Display panel
• Show the current status.
c
• Socket for a USB storage device.
d /PAIRING
• Start, pause, or resume play.
• In the Bluetooth source, press and hold
to enter pairing mode.
e MIC IN
• Connect a microphone.
f Disc compartment
g
• Stop play.
• Erase a programed radio station.
• Activate/deactivate demonstration
mode.
MIC IN
a
b
c
d
f
g
h
i
j
k
e
h /
• Skip to the previous/next track, title or
chapter.
• (Press and hold) Fast backward/
forward within a track/disc/USB.
• Tune to a radio station.
• (Press and hold) search for radio
stations automatically.
i
• Open/close the disc compartment.
j SRC
• Select a source: DISC, USB, FM, AUX
IN, BT.
k VOLUME
• Adjust volume.
• Adjust time during alarm/sleep timer
setting.
5EN
Overview of the remote
control
a /STANDBY
• Turn the unit on or off.
• Switch to standby mode or Eco
standby mode.
b
• Access the system menu.
c DISPLAY
• View playback information.
d / ( / )
• Navigate through the menu.
• Search within a track/disc/USB.
• Tune to a radio station.
e SUBTITLE/PRESET + ( ) /
AUDIO/PRESET -( )
• Navigate through the menu.
• Skip to the previous/next album.
• SUBTITLE ( ): Select a preset radio
station.
• AUDIO ( ): Set the subtitle language.
• Set time.
STANDBYEJECT
OK
a
b
c
d
e
f
h
g
p
o
q
l
m
n
i
k
r
s
t
j
u
f
• Return to the previous display menu.
g +/-
• Adjust volume.
h /
• Skip to the previous or next title,
chapter,track,orle.
i Numeric buttons
• Select a title/chapter/track to play.
• Select a preset number.
j MENU
• Access DISC/USB/iPod/iPhone/iPad
menu.
k OPTION
• In DISC/USB play mode, press to
select preferred play options.
l PROG/CLOCK SET
• Program radio stations.
• Set the clock.
• View clock information.
m TIME/SLEEP
• Set the alarm timer.
• Set the sleep timer.
n RDS
• For selected FM radio stations, display
information of Radio Data System
(RDS).
o /PAIRING
• Start, pause, or resume play.
• In the Bluetooth source, press and hold
to enter pairing mode.
p
• Stop play.
q
• Mute or restore volume.
r SOUND
• Enrich sound effect with Digital Sound
Control (DSC).
s OK
• Conrmaselection.
6 EN
t SOURCE
• Select a source: dock, BT (Bluetooth),
DISC, USB, FM, AUX.
u EJECT
• Press to open or close the disc
compartment.
7EN
3 Connect
Place the unit
1 Place the unit near the TV.
2 Place the left and right speakers at equal
distance from the TV and at an angle
of approximately 45 degrees from the
listening position.
Note
• To avoid magnetic interference or unwanted noise,
never place this apparatus and speakers too close to
any radiation devices.
• Place this unit on top of a table.
• Never place this unit in an enclosed cabinet.
• Install this unit near the AC outlet where the AC power
plug can be easily reached.
Connect speakers
Note
• For optimal sound, use the supplied speakers only.
• Connect only speakers with impedance that is the
same or higher than the supplied speakers. Refer to the
Specicationssectionofthismanual.
1 Holddownthesocketap.
2 Insert the stripped part of the wire
completely.
• Insert the right speaker wires to "R",
left speaker wires to "L".
• Insert the red wires to "+", black wires
to "-".
3 Releasethesocketap.
Connect FM antenna
Tip
• For optimal reception, fully extend and adjust the
position of the antenna.
• For better FM stereo reception, connect an outdoor
FM antenna to the FM AERIAL socket.
• The device does not support MW radio reception.
• Connect the supplied FM antenna to the
FM AERIAL socket on the back of the
device.
VIDEO OUT
VIDEO
DIGITAL OUT
AERIAL
SUBWOOFER
OUT
AUX IN
LR
FM
AC IN
~
SPEAKER OUT
8 EN
Connect video/audio cables
Select the best video connection that the TV
can support.
• Option 1: Connect to the HDMI socket
(for an HDMI, DVI or HDCP-compliant
TV).
• Option 2: Connect to the composite
video socket (for a standard TV).
Option 1: Connect to the HDMI
socket
• Connect an HDMI cable (not supplied) to:
• the HDMI (DIGITAL OUT) socket on
this unit.
• the HDMI input socket on the TV.
Tip
• If the TV has a DVI connector only, connect via an
HDMI/DVI adaptor. Connect an audio cable for sound
output.
• If this unit connects to a TV compatible with 1080p
or 1080p/24Hz, Philips recommends HDMI category
2 cable, also known as High Speed HDMI cable, for
optimal video and audio output.
• This type of connection provides the best picture
quality.
Option 2: Connect to the composite
video socket
• Connect a composite video cable to:
• the VIDEO (VIDEO OUT) jack on
this unit.
• the VIDEO input socket on the TV.
Tip
• The video input jack on the TV might be labeled as A/V
IN, VIDEO IN, COMPOSITE or BASEBAND.
Connect an external audio
device
You can route audio from an external audio
device to this unit.
If the external audio device has analog audio
output sockets (such as your TV):
• Connect audio cables (red/white - not
supplied) to:
• the AUDIO-IN(L and R) sockets on
the back of the unit.
• the audio output sockets on the
external audio device.
9EN
If the external audio device has a 3.5mm audio
output socket:
• Connect a red/white-to-3.5mm audio
cable (not supplied) to:
• the AUDIO-IN (L and R) sockets on
the back of the unit.
• the headphone socket on the external
audio player.
Connect power
Caution
• Risk of product damage! Ensure that the power supply
voltage corresponds to the voltage printed on the back
or the underside of the unit.
• Risk of electric shock! When you unplug the AC power
cord, always pull the plug from the socket. Never pull
the cord.
• Before you connect the AC power cord, make sure that
you have completed all other connections.
• Connect the AC power cord to
• the AC IN ~ socket on this unit.
• the wall power socket.
VIDEO OUT
VIDEO
DIGITAL OUT
AERIAL
SUBWOOFER
OUT
AUX IN
LR
FM
AC IN
~
SPEAKER OUT
10 EN
4 Get started
Caution
• Use of controls or adjustments or performance of
procedures other than herein may result in hazardous
laser exposure or other unsafe operation.
Always follow the instructions in this chapter in
sequence.
If you contact Philips, you will be asked for the
model and serial number of this apparatus. The
model number and serial number are on the
back of the apparatus. Write the numbers here:
Model No. __________________________
Serial No. ___________________________
Prepare the remote control
Caution
• Risk of explosion! Keep batteries away from heat,
sunshineorre.Neverdiscardbatteriesinre.
• Risk of decreased battery life! Never mix different
brands or types of batteries.
• Risk of product damage! When the remote control is
not used for long periods, remove the batteries.
To insert the remote control battery:
1 Open the battery compartment.
2 Insert the supplied AAA batteries with
correct polarity (+/-) as indicated.
3 Close the battery compartment.
a
b
c
Set clock
1 In standby mode, press and hold PROG/
CLOCK SET on the remote control for
more than two seconds.
» [24H] or [12H] hour format is
displayed.
2 Press / (or VOL -/VOL +) to select
[24H] or [12H] hour format, and then
press PROG/CLOCK SET.
» The hour digits are displayed and begin
to blink.
3 Press / (or VOL -/VOL +) to set hour,
and then press PROG/CLOCK SET.
» The minute digits are displayed and
begin to blink.
4 Repeat step 3 to set minute.
Note
• If no button is pressed in 90 seconds, the system exits
clock setting mode automatically.
Tip
• In Eco power mode, you can press PROG/CLOCK
SET to view the clock information.
Activate demonstration mode
In this mode, you can see an overview of all
features.
• In standby mode, press and hold on the
main unit to activate demonstration mode.
» A demonstration of major available
features starts.
To deactivate the demonstration mode:
• Press on the main unit again.
11EN
Turn on
• Press .
» The device switches to the last
selected source.
Switch to standby mode
• Press again to switch the unit to standby
mode.
» The clock (if set) is displayed on the
panel.
To switch to ECO standby mode:
• Press and hold for more than two
seconds.
» The display panel is dimmed.
Note
• The unit switches to Eco Power Standby mode after 15
minutes in standby mode.
To switch between standby mode and ECO
standby mode:
• Press and hold for more than two
seconds.
Find the correct viewing
channel
1 Press DISC to switch to disc mode.
2 Turn on the TV and switch to the correct
video-in channel in one of the following
ways:
• Go to the lowest channel on your TV,
and then press the Channel Down
button until you see the blue screen.
• Press the source button repeatedly on
the remote control of your TV.
Tip
• The video-in channel is between the lowest and highest
channels and may be called FRONT, A/V IN, VIDEO etc.
See the TV user manual on how to select the correct
input on the TV.
Select the correct TV system
Change this setting if the video is not displayed
correctly. By default, this setting matches the
most common setting for TVs in your country.
1 Press .
2 Select [Setup] (Setup) -> [Video] (Video)
-> [TV System](TV System).
3 Select a setting and press OK.
• [PAL] (PAL) - For TV with PAL color
system.
• [Multi] (Multi) - For TV that is
compatible with both PAL and NTSC.
• [NTSC] (NTSC) - For TV with NTSC
color system.
4 To return to the previous menu, press .
5 To exit the menu, press .
Change system menu
language
1 Press .
2 Select [Setup] (Setup) -> [General]
(General) -> [OSD Language] (OSD
Language), and press OK.
3 Select a setting and then press OK.
4 To exit the menu, press .
12 EN
5 Play
Play from disc
Caution
• Risk of product damage! Never play discs with
accessories such as disc stabilizer rings or disc
treatment sheets.
• Never put any objects other than discs into the disc
compartment.
1 Press SOURCE repeatedly to select the
disc source.
2 Press to open the disc compartment.
3 Insert a disc with the printed side facing
upward.
4 Press to close the disc compartment.
» Play starts automatically.
If play does not start automatically:
• Select a title/chapter/track and then press
.
Tip
• To play a locked DVD, enter the 6-digit parental control
password (000000).
STANDBYEJECT
OK
Use the disc menu
When you load a DVD/(S)VCD disc, a menu
may be displayed on the TV screen.
• Press MENU to access or exit disc menu
manually.
For VCD with PlayBack Control (PBC) feature
(version 2.0 only):
With the PBC feature, you can play VCD
interactively according to the menu screen.
• During play, press MENU to enable/disable
PBC.
» When PBC is enabled, the menu
screen is displayed.
» When PBC is disabled, normal play is
resumed.
Select an audio language
• During disc play, press AUDIO ( )
repeatedly to select an audio language for
a DVD or DivX (Home Theater 3.1) video.
» The language options are displayed.
If the selected audio channel is
unavailable, the default disc audio
channel is used.
Note
• For some DVDs, the language can only be changed
from the disc menu. Press MENU to access the menu.
Select a subtitle language
• During play, press SUBTITLE ( )
repeatedly to select a subtitle language for
a DVD or DivX (Home Theater 3.1) video.
Note
• For some DVDs, the language can only be changed
from the disc menu. Press MENU to access the disc
menu.
13EN
Play from USB or recored
discs
You can play DivX (Home Theater 3.1)/MP3/
JPEGpicturelescopiedontoaCD-R/RW,
recordable DVD, or USB storage device.
1 Select a source.
• Press SOURCE repeatedly to select
the USB source or Disc source.
2 Insert the USB storage device.
» Play starts automatically.
To play a specied le:
1 Press to stop play.
2 Press / to select a folder, and then
press OKtoconrm.
• To return to the previous menu, press
.
3 Press / toselectalefromthefolder.
4 Press to start play.
Note
• You can only play DivX (Home Theater 3.1) videos
rented or purchased through the DivX registration
code of this unit.
• Subtitleleswiththefollowinglenameextensions(.srt,
.smi, .sub, .ssa, .ass) are supported but do not appear on
thelenavigationmenu.
• Thesubtitlelenamehastobethesameasthele
name of the video.
STANDBYEJECT
OK
Play a slideshow with
background music
ThisunitcanplayMP3lesandJPEGphotos
simultaneously.
Note
• TheMP3andJPEGlesmustbestoredonthesame
disc or USB storage device.
1 PlayanMP3le.
2 Navigate to the photo folder/album and
press to start the slideshow.
» Slideshow begins and continues till the
end of the photo folder or album.
» Music play continues till the end of the
lastle.
• To return to the previous menu, press .
• To stop the slideshow, press .
Resume video play from last
stopped point
Note
• This feature is only available for CD/DVD/VCD/DivX
play.
• In stop mode and when the disc has not
been removed, press .
To stop play completely:
• In stop mode, press .
14 EN
Control play
/ Select a folder.
/ ( / ) Fast backward/forward.
/ Skip to previous or next
title/chapter/track/le.
Pause or resume play.
Stop play.
+/- Increase or decrease the
volume.
(mute) Mute or restore sound.
SOUND Enrich sound effect with
DSC: balanced, clear,
powerful, warm, and bright.
DISPLAY View playback information.
Play options
During video play in DISC mode, press
OPTIONS to select different play options.
• [PBC] (PBC): turn PlayBack Control on/off.
• [Aspect Ratio](Aspect ratio): select a
picturedisplayformattottheTVscreen.
• [Angle] (Angle): switch between camera
angles.
Note
• Some DVDs contain alternate scenes, such as scenes
recorded from different camera angles. For such DVDs,
you can select from the available alternate scenes.
• [Microphone] (Microphone): turn on or
off the microphone sound output.
• [Karaoke Setup] (karaoke Setup): set
different volumes of karaoke disc.
• [Vocal] (Vocal): select various Karaoke
audio modes, or turn off original vocal.
• [Zoom] (Zoom): during video play, zoom
in/out to pan through the image.
• [Repeat] (Repeat): choose a repeat play
option or turn off the repeat function.
• [Goto] (Goto): during video play, specify
a position to start play by entering the
desired time or number.
• [Slow forward] (Slow forward) and [Slow
Backward] (Slow Backward): during video
play, select a slow forward/backward speed.
Change the audio channel
Note
• This feature is only available for VCDs and DivX (Home
Theater 3.1) videos.
• During play, press AUDIO ( ) repeatedly
to select an audio channel available on the
disc:
• [Mono Left] (mono left)
• [Mono Right] (mono right)
• [Mix-Mono] (mix-mono)
• [Stereo] (stereo)
15EN
6 Enjoy karaoke
You can connect a microphone (not supplied)
to sing along with a music source.
Note
• Before you connect a microphone, set the microphone
volume to the minimum to prevent howling.
1 Insert a Karaoke disc.
2 Connect a microphone to the MIC IN
socket on this unit.
3 Press , and then select [Karaoke]
(Karaoke).
4 Turn on the microphone sound output.
5 Play a Karaoke disc and sing through the
microphone.
Adjust Karaoke settings
• [Microphone] (Microphone): turn on or
off the microphone sound output.
• [Mic Volume] (Mic Volume): adjust the
microphone volume.
• [Echo Level] (Echo Level): adjust the echo
level.
• [Karaoke Scoring] (Karaoke Scoring): turn
off the function of Karaoke scoring or
selectadifcultyleveltoscoreyoursinging.
If a level is selected, the score is displayed
after each song ends.
• [Karaoke Idol] (Karaoke Idol): Have a
Karaoke contest with your friends. Enable
this feature, and then follow the on-screen
instructions to start the contest.
1) In the [Karaoke Scoring] (Karaoke Scoring)
option, select a level (basic/intermediate/
advance).
2) In the [Karaoke Idol] (Karaoke Idol) option,
turn on the contest.
» The song selection menu is displayed.
3) Input a track (VCD/SVCD) or a title/
chapter(DVD)astherstsong.Upto4songs
can be selected.
4) Then select [Start] (Start), and press OK to
start play selected songs.
» After all the selected songs end, a con-
test result is displayed.
• [Key Shift] (Key Shift): adjust the pitch level
that matches your voice.
• [Vocal] (Vocal): select various Karaoke
audio modes, or turn off the original vocal.
16 EN
7 Listen to the
radio
Tune to a radio station
Tip
• Position the antenna as far as possible from TV, or other
radiation sources.
• For optimal reception, fully extend and adjust the
position of the antenna.
1 Press SOURCE repeatedly to select the
FM source.
2 Press and hold / ( / ) for more
than two seconds.
» The radio tunes to a station with
strong reception automatically.
3 Repeat step 2 to tune to more stations.
To tune to a weak station:
• Press / ( / ) repeatedly until
youndtheoptimalreception.
Program radio stations
automatically
Note
• You can program a maximum of 30 preset radio
stations (FM).
• In tuner mode, press and hold PROG/
CLOCK SET for more than two seconds
to activate automatic programming.
» [AUTO] (auto) is displayed.
» All available stations are programmed
in the order of waveband reception
strength,andtherstprogrammed
radio station is broadcast automatically.
Program radio stations
manually
1 Tune to a radio station.
2 Press PROG, and then press / to
select a number from 1–30.
3 Press PROGtoconrm.
4 Repeat steps 2-3 to program more
stations.
Note
• To overwrite a programmed station, store another
station in its place.
Select a preset radio station
• In tuner mode, press / (or press a
number directly) to select a preset radio
station.
17EN
8 Play from
Bluetooth-
enabled devices
Note
• The effective operation range between the unit and
your Bluetooth enabled device is approximately 10
meters (30 feet).
• Any obstacle between the system and the device can
reduce the operational range.
• Compatibility with all Bluetooth devices is not guaranteed.
1 Press SOURCE repeatedly to select the
Bluetooth source.
» [BT] (Bluetooth) is displayed.
» The indicatorashesbluequickly.
0000
PIN
BT
2 On your device that supports Advanced
AudioDistributionProle(A2DP),enable
Bluetooth and search for Bluetooth devices
that can be paired (refer to the user
manual of the device).
3 Select 'Philips BTD5210' on your
Bluetooth enabled device and if necessary
input '0000' as the pairing password.
» After successful pairing and connection,
the Bluetooth indicator turns solid
blue, and the unit beeps twice.
4 Play audio on the connected device.
» Audio streams from your Bluetooth
enabled device to this unit.
• If you fail to search for "Philips
BTD5210' or cannot pair with this
product, press and hold /PAIRING
for three seconds until the Bluetooth
indicatorashesbluequicklytoenter
pairing mode.
Tip
• The unit can memorize up to 8 previously connected
Bluetooth devices.
To disconnect the Bluetooth-enabled device:
• Deactivate Bluetooth on your device; or
• Move the device beyond the
communication range.
To clear Bluetooth pairing history:
• Pressand hold on the main set for 8
seconds.
» The current Bluetooth connection is
disconnected.
» After successful clearing, the unit beeps.
18 EN
9 Other features
Set the alarm timer
This unit can be used as an alarm clock. You can
select DISC, FM, or USB as the alarm source.
Note
• Make sure that you have set the clock correctly.
1 In standby mode, press and hold TIME/
SLEEP for more than two seconds.
» "The hour digits are displayed and
begin to blink.
2 Press / (or+/-/) repeatedly to set the
hour, and then press TIME/SLEEP .
» The minute digits are displayed and
begin to blink.
3 Repeat step 2 to select the source, and
adjust volume.
Note
• If no button is pressed in 90 seconds, the unit exits
timer setting mode automatically.
To activate or deactivate the alarm timer:
• In standby mode, press TIME/SLEEP
repeatedly to activate or deactivate the
alarm.
» If the timer is activated, is displayed.
Tip
• If the disc/USB source is selected, but no disc is placed
or no USB connected, the unit switches to the tuner
source automatically.
Set the sleep timer
• To set the sleep timer, when the unit is
switched on, press TIME/SLEEP repeatedly
to select a set period of time (in minutes).
» When the sleep timer is activated,
is displayed.
To deactivate sleep timer:
• When the unit is switched on, press TIME/
SLEEP repeatedly until [SLP OFF] (sleep
off) is displayed.
» When the sleep timer is deactivated,
disappears.
Listen to an external device
You can listen to an external device through this
unit with an 3.5mm audio cable (not supplied).
1 Make sure that the external audio device is
connected to this unit.
2 Press AUX to select the AUX IN source.
3 Start to play the external device (see the
user manual of the external device).
19EN
10 Adjust settings
1 Press .
2 Select the [Setup] (Setup) page.
3 Select a setting and press OK.
• To return to the previous menu, press
.
• To exit the menu, press .
General setup
On the [General] (general) page, you can set
the following options:
[Disc Lock] (disc lock)
Lock or unlock a disc.
[OSD Language] (OSD language)
Select the preferred language for on-screen
display.
[Auto Standby] (Auto Standby)
Enable this feature to automatically switch to
Eco-power standby mode after 15 minutes of
inactivity.
[DivX(R) VOD Code] (DivX(R) VOD Code)
Display the DivX(R) registration code.
Note
• Enter this DivX registration code when you rent or
purchase a video from http://vod.divx.com/. The DivX
videos rented or purchased through the DivX_ VOD
(Video On Demand) service can be played only on the
device to which it is registered.
Video setup
On the [Video] (Video) page, you can set the
following options:
[TV system] (TV System)
Change this setting if the video is not displayed
correctly. By default, this setting matches the
most common setting for TVs in your country.
• [PAL] (PAL) - For TV with PAL color
system.
• [Multi] (Multi) - For TV that is
compatible with both PAL and NTSC.
• [NTSC] (NTSC) - For TV with NTSC
color system.
[TV Display] (TV Display)
The TV format determines the aspect ratio of
display according to the type of TV you have
connected.
• [4:3 Pan Scan](4:3 Pan Scan) – For 4:3
screen TV: full-height display with the
trimmed sides.
• [4:3 Letter Box] (4:3 Letter Box) –
For 4:3 screen TV: wide-screen display
with black bars on the top and bottom
of the screen.
• [16:9] (16:9 Wide Screen) – For wide-
screen TV: display ratio 16:9.
[Picture Setting] (Picture Setting)
Selectapredenedsetofpicturecolorsettings.
• [Standard](Standard) – Original color
setting.
• [Bright] (Bright) – Vibrant color setting.
• [Soft] (Soft) - Soft color setting.
• [Personal] (Personal) – Customizes the
color setting. Set the level of brightness,
contrast, tint, and color saturation, and then
press OK.
[HD JPEG] (HD JPEG)
Enjoy untouched and uncompressed JPEG
pictures at its original resolution when you you
connect this product and the TV with an HDMI
cable.
• [On] (On)-Displayhighdenitionpicture.
• [Off] (Off) - Display standard picture.
4:3 Letter Box (LB)
4:3 Pan Scan (PS)
16:9 (Wide Screen)
20 EN
Audio setup
On the [Audio] (Audio) page, you can set the
following options:
[HDMI Audio] (HDMI Audio)
Select the HDMI audio setting when you
connect this product and the TV with an HDMI
cable.
• [On] (On) - Allow audio output through
the TV and the speaker system. If the audio
format on the disc is not supported, it
will be downmixed to two-channel sound
(linear-PCM).
• [Off] (Off) - Disable audio output from
the TV. The sound is only output through
the speaker system.
[Audio Sync] (Audio Sync)
Set the delay time for audio output when you
play a video disc.
1. Press OK.
2. Press to set the volume.
3. Press OKtoconrmandexit.
[Sound Mode] (Sound Mode)
Turn off or select your preferred sound mode.
• [Original] (Original)
• [Movie Mode] (Movie Mode)
• [Music Mode] (Music Mode)
• [Gaming] (Gaming)
• [News] (News)
[Night Mode] (Night Mode)
Make loud sound level softer and soft sound
level louder so that you can watch the DVD
movies at a low volume, without disturbing
others.
• [On] (On) – enjoy quiet viewing at
night (DVDs only).
• [Off] (Off) – enjoy surround sound
with its full dynamic range.
Preferences
On the [Preference] (Preference) page, you can
set the following options:
[Audio] (Audio)
Select the preferred audio language for disc play.
[Subtitle] (Subtitle)
Select the preferred subtitle language for disc
play.
[Disc Menu] (Disc Menu)
Select the preferred disc menu language.
Note
• If the language you have set is not available on the disc,
the disc uses its own default language.
• For some discs, the subtitle/audio language can only be
changed from the disc menu.
[Parental Control] (Parental Control)
Restrict access to discs that are unsuitable for
children. These types of discs must be recorded
with ratings.
1) Press OK.
2) Select a rating level, and then press OK.
3) Press the numeric keys to enter the
password.
Note
• Rated discs above the level you set in [Parental
Control] (Parental Control) require a password to be
played.
• The ratings are country-dependent. To allow all discs to
play, select [8 Adult] (8 Adult).
• Some discs have ratings printed on them but are not
recorded with ratings. This function has no effect on
such discs.
[PBC] (PBC)
Play VCD interactively according to the menu
screen.
• [On] (On): the menu screen is
displayed.
• [Off] (Off): normal play is resumed.
21EN
[Password] (Password)
This setting allows you to change the password
for parental control. The default password is
000000.
1) Press the numeric keys to enter '000000'
or your last set password at [Old Password]
(OldPassword)eld.
2) Enter the new password at [New
Password] (NewPassword)eld.
3) Enter the new password again at [Conrm
PWD] (ConrmPWD)eld.
4) Press OK to exit the menu.
Note
• If you forget the password, enter '000000' before you
set a new password.
[DivX Subtitle] (DivX Subtitle)
Select a character set that supports the DivX
subtitle.
Note
• Ensurethatthesubtitlelehastheexactsamele
nameasthemoviele.Ifforexamplethelenameof
the movie is ‘Movie.avi’, and then you will need to name
thetextle‘Movie.sub’or‘Movie.srt’.
[Version Info] (Version Information)
Display the software version of this device.
[Default] (Default)
Reset all the settings to factory default, except
for the password and parental settings.
22 EN
11 Product
information
Note
• Product information is subject to change without prior
notice.
Specications
Amplier
Maximum Output Power Maximum 70 W
Frequency Response 40 Hz - 20 kHZ;
+/-3 dB
Signal to Noise Ratio ≥75dB
Total Harmonic Distortion <1%
Audio in Input 2V +/- 100mV
RMS 22kohm
Speakers
Speaker Impedance 8 ohm
Speaker Driver 4.5"
woofer,1.25"Tweeter
Sensitivity 83 +/-3 dB/m/W
Tuner (FM)
Tuning Range 87.5-108 MHz
Tuning grid 50 KHz
Preset stations 30
Sensitivity
- Mono, 26dB S/N Ratio
- Stereo, 46dB S/N Ratio
≤22dBf
≤48dBf
Search Selectivity ≤32dBf
Total Harmonic Distortion ≤3%
Signal to Noise Ratio ≥45dB
Bluetooth
Bluetooth version V2.1+EDR
Frequency band 2.4 GHz ~ 2.48 GHz ISM
Band
Range 10 m (free space)
Disc
Laser Type Semiconductor
Disc Diameter 12 cm/8 cm
Video Decoding MPEG-1 / MPEG-2 /
DivX
Video DAC 12 Bits
Signal System PAL / NTSC
Video Format 4:3 / 16:9
Video S/N >57 dB
Audio DAC 24 Bits / 96 kHz
Total Harmonic
Distortion
<1% (1 kHz)
Frequency Response 4 Hz - 20 kHz (44.1 kHz)
4 Hz - 22 kHz (48 kHz)
4 Hz - 24 kHz (96 kHz)
Frequency Response 20 Hz - 20 kHz (44.1 kHz)
S/N Ratio(A-
weighted)
≥80dBA
Mic 3.5 mm input
General information
AC power 100-240 V, 50/60 Hz
Operation Power
Consumption
≤25W
Eco Standby Power
Consumption
≤0.5W
Dimensions
- Main Unit (W x H
x D)
- Speaker Box (W x
H x D)
200 x 240 x 121 mm
160 x 210 x 235 mm
Weight
- Main Unit
- Speaker Box
1.67 kg
2.16 x 2 kg
23EN
Supported disc formats
• Digital Video Discs (DVDs)
• Video CDs (VCDs)
• Super Video CDs (SVCDs)
• Digital Video Discs + Rewritable
(DVD+RW)
• Compact Discs (CDs)
• Picture(Kodak,JPEG)lesonCDR(W)
• DivX(R) disc on CD-R(W):
• DivX 3.11, 4.x and 5.x
Supported MP3-CD formats:
• ISO 9660
• Max. title/album name: 12 characters
• Max. title number plus album: 255.
• Max. nested directory: 8 levels.
• Max. album number: 32.
• Max. MP3 track number: 999.
• Supported sampling frequencies for MP3
disc: 32 kHz, 44.1 kHz, 48 kHz.
• Supported Bit-rates of MP3 disc are: 32, 64,
96, 128, 192, 256 (kbps).
• The following formats are not supported:
• Files like *.VMA, *.AAC, *.DLF, *.M3U,
• *.PLS, *.WAV
• Non-English Album/Title name
• Discs recorded in Joliet format
• MP3 Pro and MP3 with ID3 tag
USB playability information
Compatible USB devices:
• USBashmemory(USB2.0or
USB1.1)
• USBashplayers(USB2.0orUSB1.1)
• memory cards (requires an additional
card reader to work with this unit)
Supported formats:
• USBormemoryleformat:FAT12,
FAT16, FAT32 (sector size: 512 bytes)
• MP3 bit rate (data rate): 32-320 Kbps
and variable bit rate
• Directory nesting up to a maximum of
8 levels
• Number of albums/ folders: maximum
99
• Number of tracks/titles: maximum 999
• ID3 tag v2.0 or later
• File name in Unicode UTF8 (maximum
length: 32 bytes)
Unsupported formats:
• Empty albums: an empty album is an
album that does not contain MP3/
WMAles,andwillnotbeshownin
the display.
• Unsupportedleformatsareskipped.
For example, word documents (.doc)
orMP3leswithextension.dlfare
ignored and not played.
• WMA,AAC,WAV,PCMaudioles
• DRMprotectedWMAles(.wav,.m4a,
.m4p, .mp4, .aac)
• WMAlesinLosslessformat
24 EN
12 Troubleshooting
Warning
• Never remove the casing of this device.
To keep the warranty valid, never try to repair
the system yourself.
If you encounter problems when using this
device, check the following points before
requesting service. If the problem remains
unsolved, go to the Philips Web page (www.
philips.com/support). When you contact Philips,
make sure that the device is nearby and the
model number and serial number are available.
No power
• Make sure that the AC power cord of the
device is connected properly.
• Make sure that there is power at the AC
outlet.
• As a power-saving feature, the system
switches off automatically 15 minutes after
track play reaches the end and no control
is operated.
No sound or poor sound
• Adjust the volume.
• Check that the speakers are connected
correctly.
• Check if the stripped speaker wires are
clamped.
Remote control does not work
• Beforeyoupressanyfunctionbutton,rst
select the correct source with the remote
control instead of the main unit.
• Reduce the distance between the remote
control and the unit.
• Insert the battery with its polarities (+/–
signs) aligned as indicated.
• Replace the battery.
• Aim the remote control directly at the
sensor on the front of the unit.
No disc detected
• Insert a disc.
• Check if the disc is inserted upside down.
• Wait until the moisture condensation at
the lens has cleared.
• Replace or clean the disc.
• UseanalizedCDorcorrectformatdisc.
Disc does not play
• Insert a readable disc with the label side
facing up.
• Check the disc type, color system and
regional code. Check for any scratches or
smudges on the disc.
• Press to exit the system setup menu.
• Disable the password for parental control
or change the rating level.
• Moisture has condensed inside the system.
Remove the disc and leave the system
turned on for about an hour. Disconnect
and reconnect the AC power plug, and
then turn on the system again.
No picture
• Check the video connection.
• Turn on the TV to the correct Video-In
channel.
• Progressive scan is activated but the TV
does not support progressive scan.
Black and white or distorted picture
• The disc does not match the TV color
system standard (PAL/NTSC).
• Sometimes a slight picture distortion may
appear. This is not a malfunction.
• Clean the disc.
• A distorted picture may appear during
progressive scan setup.
The aspect ratio of the TV screen cannot be
changed even though you have set the TV
display format.
• Theaspectratioisxedontheloaded
DVD disc.
• The aspect ratio may not be changed for
some TV systems.
DivX video les cannot be played.
• EnsurethattheDivXvideoleis
complete.
• Ensurethattheleextensioniscorrect.
25EN
• Due to Digital Rights issue, the DRM-
protectedvideolescannotbeplayed
through an analog video connection (e.g.
composite, component and scart). Transfer
the video content onto the Disc Media
andplaytheseles.
Audio or subtitle languages cannot be set
• The disc is not recorded with sound or
subtitles in multiple languages.
• The audio or subtitle language setting is
prohibited on the disc.
Cannot display some les in USB device
• ThenumberoffoldersorlesintheUSB
device has exceeded a certain limit. This
phenomenon is not a malfunction.
• Theformatsoftheselesarenot
supported.
USB device not supported
• The USB device is incompatible with the
unit. Try another one.
Poor radio reception
• Increase the distance between the unit and
your TV or other radiation sources.
• Connect and fully extend the supplied
antenna.
Music playback is unavailable on this unit even
after successful Bluetooth connection.
• The device cannot be used to play music
through this unit wirelessly.
The audio quality is poor after connection
with a Bluetooth-enabled device.
• The Bluetooth reception is poor. Move the
device closer to this unit or remove any
obstacle between them.
Cannot connect with this unit.
• Thedevicedoesnotsupporttheproles
required for this unit.
• The Bluetooth function of the device is
not enabled. Refer to the user manual of
thedevicetondouthowtoenablethe
function.
• This unit is not in pairing mode.
• This unit is already connected with another
Bluetooth-enabled device. Disconnect that
device and then try again.
The paired mobile device connects and
disconnects constantly.
• The Bluetooth reception is poor. Move the
device closer to this unit or remove any
obstacle between them.
• Some mobile phones may connect and
disconnect constantly when you make
or end calls. This does not indicate any
malfunction of this unit.
• For some devices, the Bluetooth
connection may be deactivated
automatically as a power-saving feature.
This does not indicate any malfunction of
this unit.
Timer does not work
• Set the clock correctly.
• Switch on the timer.
Clock/timer setting erased
• Power has been interrupted or the power
cord has been disconnected.
• Reset the clock/timer.
26 EN
13 Notice
Anychangesormodicationsmadetothis
device that are not expressly approved by
Gibson Innovations may void the user’s
authority to operate the equipment.
Declaration of conformity
Hereby, Gibson Innovations declares that this
product is in compliance with the essential
requirements and other relevant provisions
ofDirective1999/5/EC.Youcanndthe
Declaration of Conformity on www.philips.com/
support.
Disposal of your old product and battery
Your product is designed and manufactured
with high quality materials and components,
which can be recycled and reused.
This symbol on a product means that the
product is covered by European Directive
2012/19/EU.
This symbol means that the product contains
batteries covered by European Directive
2013/56/EU which cannot be disposed of with
normal household waste.
Inform yourself about the local separate
collection system for electrical and electronic
products and batteries. Follow local rules and
never dispose of the product and batteries
with normal household waste. Correct disposal
of old products and batteries helps prevent
negative consequences for the environment and
human health.
Removing the disposable batteries
To remove the disposable batteries, see battery
installation section.
Environmental information
All unnecessary packaging has been omitted.
We have tried to make the packaging easy to
separate into three materials: cardboard (box),
polystyrene foam (buffer) and polyethylene
(bags, protective foam sheet.)
Your system consists of materials which can
be recycled and reused if disassembled by
a specialized company. Please observe the
local regulations regarding the disposal of
packaging materials, exhausted batteries and old
equipment.
This item incorporates copy protection
technology that is protected by U.S. patents
and other intellectual property rights of
Rovi Corporation. Reverse engineering and
disassembly are prohibited.
The Bluetooth® word mark and logos are
registered trademarks owned by Bluetooth
SIG, Inc. and any use of such marks by Gibson
Innovations Limited is under license. Other
trademarks and trade names are those of their
respective owners.
Manufactured under license from Dolby
Laboratories.
"Dolby" and the double-D symbol are
trademarks of Dolby Laboratories.
27EN
'DVD Video' is a trademark of DVD Format/
Logo Licensing Corporation.
ABOUT DIVX VIDEO: DivX® is a digital video
format created by DivX, LLC, a subsidiary
ofRoviCorporation.ThisisanofcialDivX
Certied®devicethatplaysDivXvideo.Visit
divx.com for more information and software
toolstoconvertyourlesintoDivXvideos.
ABOUT DIVX VIDEO-ON-DEMAND: This
DivXCertied®devicemustberegistered
in order to play purchased DivX Video-on-
Demand (VOD) movies. To obtain your
registration code, locate the DivX VOD section
in your device setup menu. Go to vod.divx.com
for more information on how to complete your
registration.
DivX®,DivXCertied®andassociatedlogos
are trademarks of Rovi Corporation or its
subsidiaries and are used under license.
HDMI,andHDMIlogoandHigh-Denition
Multimedia Interface are trademarks or
registered trademarks of HDMI licensing LLC in
the United States and other countries.
This apparatus includes this label:
Note
• The type plate is located on the back of the device.
Specications are subject to change without notice.
2015 © Gibson Innovations Limited. All rights reserved.
This product has been manufactured by, and is sold under the responsibility of Gibson
Innovations Ltd., and Gibson Innovations Ltd. is the warrantor in relation to this product.
Philips and the Philips Shield Emblem are registered trademarks of Koninklijke Philips N.V.
and are used under license from Koninklijke Philips N.V.
BTD5210_12_UM_V1.0
