Installation
Product : Slim Portable Blu-ray/DVD Writer
Fold 1 :
4-panel
accordion
Fold 2 :
2-panel
accordion
Document : Combined
No : MFL67900080
Color Side 1: Black Flat size : 50 x 25 cm
Color Side 2: Black Finished size : 12.5 x 12.5 cm
• Please pay attention to handling Electrostatic Sensitive Devices, you may use
anti-static products such as wrist straps, heel straps, mats to protect your body
from electrostatic.
• Make sure you have a personal computer with any open USB ports before
connecting the drive to your computer.
USB Power
cable
This following is the general figure of the design of the drive.
The drive’s appearance and specifications may change without prior notice.
Slim Portable
Blu-ray/DVD Writer
Location and Functions
Disc tray
1
Drive activity indicator
This connector is used to
connect to the USB 2.0 cable.
The emergency eject procedure
should only be used to retrieve
your disc if the drive fails to eject.
Shut down the power supply when
this eject will be used.
Caution:
Notes:
Connecting to computer or A/V Device.
• Please do not connect the USB cables by any means other than specified above.
Using the wrong type of cable with this drive can cause it to malfunction.
• The appliance is not intended for use by young children or infirm persons without
supervision. Young Children should be supervised to ensure that they do not play with
appliance.
• If the appliance is supplied from a cord extension set or an electrical portable outlet
device, the cord extension set on electrical portable outlet device must be positioned
so that it is not subject to splashing or ingress of moisture.
®
The drive supports both Windows and Mac . To use it properly, please follow
directions below.
Notes:
• Normal operation is not guaranteed if you use a USB hub or unspecified USB extension
cables. TV connectivity functions support with files under 4GB.
• Due to compatibility issue of some AV devices and disc, may not work.
• DVD/Blu-ray movie titles and album titles cannot be played when using TV connectivity.
• TV connectivity function may not be available in BD-R/RE DL or XL disc.
Notes:
• When using with Mac
- Click the eject button located on Mac OS menu or toolbar.
• When using with Windows
- Press the eject button in the front of the product.
* Software CD (for Windows only)
- The Software CD includes DVD software for usage for Windows.
How to Eject Disc from the drive
* This product is defaulted to ODD mode when it is powered on.
1. With the tray open, press and hold the ‘Eject’button for 2 seconds.
(The LED indicator will turn on, switching to TV mode. Press and hold the button
again for 2 seconds with the tray open to return to ODD mode).
2. Insert your supported media into the drive.
The disc file system will be converted to FAT32 and will be recognized as USB
flash memory.
3. Select and play the files from your A/V device to enjoy videos, pictures and music.
Refer to your A/V device owner’s manual for more information.
How to Use TV Connectivity
• An application included in the Mac OS must be used to play data records or DVD
video discs through Mac OS.
- When recording data: Finder Burn, iTunes must be used.
- When playing a DVD movie disc: A DVD Player must be used.
• The Mac OS & Windows OS do not include an application that can play Blu-ray
movie titles. Separate playback software for Mac OS must be used to play Blu-ray
movie titles through Mac OS.
• DVD/Blu-ray movie titles cannot be recorded because of the copyright protection.
Notes:
TV Connectivity is a function that allows you to enjoy videos, pictures and music by
connecting this product to a compatible A/V device (e.g.DIGITALTV, DIGITALPHOTO
FRAME, PC) that supports USB connectivity.
What is TV Connectivity?
2
USB Connector (mini)
1
Eject Button
3
Manual Emergency
Eject Hole
4
Connect the USB 2.0 (Ytype) cable to the drive.
- Connect the drive to the computer as shown in figure.
When the computer is ready, confirm that the drive is detected. And then, insert
the supplied software CD into the driveand install the software.
1
Connect the other end of the USB 2.0 cable to your computer.
2
The drive may get its power from the PC USB power. All systems may not
meet USB power requirements and full performance may not be achieved.
In this case, connect to the USB power cable.
3
3
4
1
2
3
1
2
1
Front View
Rear View
Quick Set-up Guide
Slim Portable Blu-ray / DVD Writer
WP50
To install of your product, please read this guide manual carefully and completely.
