E-1
Important
Information
Before using the LCD projector, please read this operation manual carefully.
IMPORTANT
For your assistance in reporting the loss or theft of your Color LCD Projector,
please record the Serial Number located on the bottom of the projector and
retain this information. Before recycling the packaging, please be sure that you
have checked the contents of the carton thoroughly against the list of “Supplied
Accessories” on page
12
.
There are two important reasons for prompt warranty registration of your new SHARP LCD Projector, using the REGISTRATION CARD
packed with the projector.
1. WARRANTY
This is to assure that you immediately receive the full benefit of the parts, service and labor warranty applicable to your purchase.
2. CONSUMER PRODUCT SAFETY ACT
To ensure that you will promptly receive any safety notification of inspection, modification, or recall that SHARP may be required to give
under the 1972 Consumer Product Safety Act, PLEASE READ CAREFULLY THE IMPORTANT “LIMITED WARRANTY” CLAUSE.
U.S.A. ONLY
WARNING: High brightness light source. Do not stare into the beam of light, or view directly. Be especially
careful that children do not stare directly into the beam of light.
WARNING: To reduce the risk of fire or electric shock, do not expose this product to rain or moisture.
See bottom of actual set.
CAUTION
RISK OF ELECTRIC SHOCK.
DO NOT REMOVE SCREWS
EXCEPT SPECIFIED USER
SERVICE SCREW.
The lightning flash with arrowhead symbol, within
an equilateral triangle, is intended to alert the user
to the presence of uninsulated “dangerous
voltage” within the product’s enclosure that may
be of sufficient magnitude to constitute a risk or
electric shock to persons.
The exclamation point within a triangle is intended
to alert the user to the presence of important
operating and maintenance (servicing) instructions
in the literature accompanying the product.
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER.
NO USER-SERVICEABLE PARTS EXCEPT LAMP UNIT.
REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
U.S.A. ONLY
WARNING: FCC Regulations state that any unauthorized changes or modifications to this equipment not
expressly approved by the manufacturer could void the user’s authority to operate this equip-
ment.
INFORMATION
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with
the operation manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely
to cause harmful interference, in which case the user will be required to correct the interference at his own expense.
U.S.A. ONLY
The enclosed RGB (computer) cable must be used with the device. The cable is provided to ensure that the device complies with FCC
Class A verification.
U.S.A. ONLY
Model No.: XG
-
P20XU
Serial No.:
Introduction ENGLISH
“Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any
interference, including interference that may cause undesired operation of the device”.
CANADA ONLY
For GyroRemote unit (RRMCG1631CESA)
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired operation.
This device operates in the frequency band of 49.82 to 49.90 MHz with RF output power of less than 30 MicroWatts EIRP (Effective Isotropic
Radiated Power).
Caution
Any changes made to this device not expressly approved by the manufacturer could void the users right to operate this device.
E-2
Important
Information
Electrical energy can perform many useful functions. This product has been engineered and manufactured to ensure your
personal safety. But IMPROPER USE CAN RESULT IN POTENTIAL ELECTRICAL SHOCK OR FIRE HAZARD. In order not to
defeat the safeguards incorporated into this LCD Projector, observe the following basic rules for its installation, use and
servicing. For your own protection and reliable usage of your LCD Projector, please be sure to read these “IMPORTANT
SAFEGUARDS” carefully before use.
1. Read Instructions
All the safety and operating instructions should be read
before the product is operated.
2. Retain Instructions
The safety and operating instructions should be retained
for future reference.
3. Heed Warnings
All warnings on the product and in the operating instructions
should be adhered to.
4. Follow Instructions
All operating and use instructions should be followed.
5. Cleaning
Unplug this product from the wall outlet before cleaning.
Do not use liquid cleaners or aerosol cleaners. Use a damp
cloth for cleaning.
6. Attachments
Do not use attachments not recommended by the product
manufacturer as they may cause hazards.
7. Water and Moisture
Do not use this product near water–for example, near a
bathtub, wash bowl, kitchen sink, or laundry tub; in a wet
basement; or near a swimming pool; and the like.
8. Accessories
Do not place this product on an unstable cart, stand, tripod,
bracket, or table. The product may fall, causing serious
injury to a child or adult, and serious damage to the product.
Use only with a cart, stand, tripod, bracket, or table
recommended by the manufacturer, or sold with the
product. Any mounting of the product should follow the
manufacturer’s instructions, and should use a mounting
accessory recommended by the manufacturer.
9. Transportation
A product and cart combination
should be moved with care. Quick
stops, excessive force, and uneven
surfaces may cause the product
and cart combination to overturn.
10. Ventilation
Slots and openings in the cabinet are provided for
ventilation to ensure reliable operation of the product and
to protect it from overheating. The openings should never
be covered or blocked by placing the product on a bed,
sofa, rug, or other similar surface. This product should not
be placed in a built-in installation such as a bookcase or
rack unless proper ventilation is provided or the
manufacturer’s instructions have been adhered to.
11. Power Sources
This product should be operated only from the type of power
source indicated on the marking label. If you are not sure
of the type of power supply to your home, consult your
product dealer or local power company. For products
intended to operate from battery power, or other sources,
refer to the operating instructions.
12. Grounding or Polarization
This product is equipped with a three-wire grounding-type
plug, a plug having a third (grounding) pin. This plug will
only fit into a grounding-type power outlet. This is a safety
feature. If you are unable to insert the plug into the outlet,
contact your electrician to replace your obsolete outlet. Do
not defeat the safety purpose of the grounding-type plug.
13. Power-Cord Protection
Power-supply cords should be routed so that they are not
likely to be walked on or pinched by items placed upon or
against them, paying particular attention to cords at plugs,
convenience receptacles, and the point where they exit
from the product.
14. Lightning
For added protection for this product during a lightning
storm, or when it is left unattended and unused for long
periods of time, unplug it from the wall outlet and disconnect
the cable system. This will prevent damage to the product
due to lightning and power-line surges.
15. Overloading
Do not overload wall outlets, extension cords, or integral
convenience receptacles as this can result in a risk of fire
or electric shock.
16. Object and Liquid Entry
Never push objects of any kind into this product through
openings as they may touch dangerous voltage points or
short-out parts that could result in a fire or electric shock.
Never spill liquid of any kind on the product.
17. Servicing
Do not attempt to service this product yourself as opening
or removing covers may expose you to dangerous voltage
or other hazards. Refer all servicing to qualified service
personnel.
18. Damage Requiring Service
Unplug this product from the wall outlet and refer servicing
to qualified service personnel under the following
conditions:
a. If the power-supply cord or plug is damaged.
b. If liquid has been spilled, or objects have fallen into
the product.
c. If the product has been exposed to rain or water.
d. If the product does not operate normally by following
the operating instructions. Adjust only those controls
that are covered by the operating instructions, as an
improper adjustment of other controls may result in
damage and will often require extensive work by a
qualified technician to restore the product to normal
operation.
e. If the product has been dropped or damaged in any
way.
f. If the product exhibits a distinct change in
performance, this indicates a need for service.
19. Replacement Parts
When replacement parts are required, be sure the service
technician has used replacement parts specified by the
manufacturer or with the same characteristics as the original
part. Unauthorized substitutions may result in fire, electric
shock, or other hazards.
20. Safety Check
Upon completion of any service or repairs to this product,
ask the service technician to perform safety checks to
determine that the product is in proper operating condition.
21. Wall or Ceiling Mounting
This product should be mounted to a wall or ceiling only as
recommended by the manufacturer.
22. Heat
This product should be situated away from heat sources
such as radiators, heat registers, stoves, or other products
(including amplifiers) that produce heat.
IMPORTANT SAFEGUARDS
E-3
Important
Information
IMPORTANT SAFEGUARDS
Caution Concerning the Lamp
Replacement
See “Replacing the Lamp” on pages
68
and
69
.
Cautions Concerning the Setup of
the Projector
For minimal servicing and to maintain high image quality,
SHARP recommends that this projector be installed in
an area free from humidity, dust and cigarette smoke.
When the projector is subjected to these environments,
the lens must be cleaned more often. As long as the
projector is properly maintained in this manner, use in
these environments will not reduce the overall operation
life. Please note that all internal cleaning must be
performed by an Authorized Sharp Industrial LCD
Products Dealer or Service Center.
Notes on Operation
• The exhaust vent, the lamp cage cover and adjacent
areas may be extremely hot during projector
operation. To prevent injury, do not touch these areas
until they have sufficiently cooled.
• Allow at least 4 inches (10 cm) of space between the
exhaust vent and the nearest wall or obstruction.
• If the cooling fan becomes obstructed, a protection
device will automatically turn off the projector lamp.
This does not indicate a malfunction. Remove the
projector power cord from the wall outlet and wait at
least 10 minutes. Then turn on the power by plugging
the power cord back in. This will return the projector
to the normal operating condition.
PRODUCT DISPOSAL
This product utilizes tin-lead solder, and high intensity
discharge lamp (HID lamp) containing a small amount of
mercury. Disposal of these materials may be regulated due
to environmental considerations. For disposal or recycling
information, please contact your local authorities or the
Electronics Industries Alliance: www.eiae.org.
Caution Concerning the Lamp Unit
Potential hazard of glass particles if lamp ruptures. In
case of lamp rupture, contact your nearest Authorized
Sharp Industrial LCD Products Dealer or Service Center
for a replacement.
See “Replacing the Lamp” on pages
68
and
69
.
CAUTION
PRECAUCIÓN
PRÉCAUTION
LAMP REPLACEMENT
CAUTION
BEFORE REMOVING THE SCREW, DISCONNECT
POWER CORD. HOT SURFACE INSIDE
ALLOW 1 HOUR TO COOL BEFORE REPLACING
THE LAMP. REPLACE WITH SAME SHARP LAMP
UNIT TYPE BQC-XGP20X//1 ONLY.
UV RADIATION : CAN CAUSE EYE DAMAGE.
TURN OFF LAMP BEFORE SERVICING.
MEDIUM PRESSURE LAMP : RISK OF EXPLOSION.
POTENTIAL HAZARD OF GLASS PARTICLES IF
LAMP HAS RUPTURED. HANDLE WITH CARE.
SEE OPERATION MANUAL.
E-4
Important
Information
IMPORTANT SAFEGUARDS
Temperature Monitor Function
If the projector starts to overheat due to setup problems
or a dirty air filter, “TEMP.” and “ ” will flash in the lower-
left corner of the picture. If the temperature continues
to rise, the lamp will turn off, the TEMPERATURE
WARNING indicator on the projector will flash, and after
a 90-second cooling-off period the power will shut off.
Refer to “Lamp/Maintenance Indicators” on page
67
,
for details.
• The cooling fan regulates the internal temperature, and its
performance is automatically controled. The sound of the
fan may change during projector operation due to changes
in the fan speed.
Using the Carrying Handle
When transporting the projector, carry it by the carrying
handle on the side.
CAUTION
• Always put on the lens cap to prevent damage to the lens
when transporting the projector.
• Do not lift or carry the projector by the lens or the lens cap
as this may damage the lens.
Using the Kensington Lock
This projector has a Kensington Security Standard
connector for use with a Kensington MicroSaver Security
System. Refer to the information that came with the
system for instructions on how to use it to secure the
projector.
Kensington Security
Standard connector
E-5
Important
Information
1. High-end LCD Projector with Ultra High Brightness
• AC 220 W Lamp
Use AC 220 W lamp for excellent color uniformity and ultra high brightness.
2. Computer Compatibility
• Compatible with resolutions including VGA-SVGA (expanded), XGA (true
resolution) and SXGA-UXGA (compressed) as well as DTV formats (480i, 480P,
720P and 1080i).
3. XGA Image Quality
• OCS LCD panel enhances color uniformity.
• Various other circuits are also used to provide high quality video images.
4. Computer & Video Integrated Composer Technology
• New Progressive Mode
I/P conversion with new algorithm used to achieve beautiful image quality.
• Enhanced Up-scaling and Digital Image Enlargement
Enables sharper image quality without jaggies even for enlarged images.
• Superior 16:9 Image
4:3 images can be converted to 16:9 images using Smart Stretch (sides stretched,
center untouched), previously not achievable with LCD projectors.
• Intelligent Digital Keystone Correction
Smooths out jaggies on keystone images and compresses the image not only
horizontally but vertically keeping the 4 : 3 aspect ratio, and at the same time, calculates
the aspect ratio automatically adjusting to the lens shift width.
• New Intelligent Compression
Efficiently compresses UXGA (1,600 1,200) images to XGA (1,024 768).
• Enhanced three-two pull down
Converts cinema mode DVD images transformed with three-two pull down enhancement
to progressive mode images for easier viewing by Film Mode.
• Dynamic GAMMA Correction
Optimizing GAMMA correction frame by frame in real time.
5. 3D Digital Uniformity and Digital Convergence
• Three-Dimensional Digital Uniformity compensates uneven picture brightness
even for pictures at any brightness level from white to dark. And, with Digital
Convergence, a slight distortion of convergence can be adjusted on the service
menu screen without having to touch the LCD panel.
Outstanding Features
E-6
Important
Information
6. Network Capability
• Self-Diagnosis/Projector Status
Self-diagnosis/Projector status function sends e-mail
messages to a specified computer about lamp usage
time and any malfunctions.
• Multiple & Group Projector Control
Up to 250 projectors can be controled over a network.
Projector RS-232C OUT can be used for daisy chain
connection.
• Simple Stacking and Videowall Display
Comes with software for easy stacking and videowall processing even for input from a
single source.
7. Four Optional Lenses for Maximum Flexibility
• Bayonet mount type: Wide-Zoom Lens, Tele-Zoom Lens
• Screw mount type: Fixed Wide Lens, Tele-Zoom Lens
8. Multiple Input and Output Terminals
• BNC Terminal for RGB/Component/Video Signal
• PC Digital Input (DVI)
• Output terminal with VAO (variable audio output) support
9. Easy Setup
• Lens Shift, Power Zoom & Focus, Digital Keystone Correction
• High Speed Auto Sync Technology
10. Advanced Presentation Features incorporating a unique
gyro device for “in-air” remote control
• An intuitive presentation tool with an easy-to-see screen pointer.
• Raising the bar for roaming interaction with a wireless, RF (nondirectional)
design that erases out-of-sight worries. Loaded with USB mouse control.
11. Useful Features
• Picture-in-Picture, Digital Enlargement, Freeze
• Customizable Startup Screen & Background Screen
12. Application Software
• “Sharp Advanced Presentation Software—Professional Edition” (Network and
Remote Control)
Outstanding Features
LAN
LAN LAN
E-7
Important
Information
Setup & Connections
Operation Buttons
Basic Operation
Appendix
Maintenance &
Troubleshooting
Important Information
Introduction ..........................................
1
IMPORTANT SAFEGUARDS ................
2
Outstanding Features ..........................
5
Contents ................................................
7
How to Access the PDF Operation
Manuals ............................................
9
Part Names............................................
10
Accessories ..........................................
12
Introducing GyroRemote .....................
30
GyroRemote Features ............................
30
Using GyroRemote .................................
32
Setting up GyroRemote ..........................
36
Using the Operation Buttons ..............
39
Selecting the Input Signal Source ..........
39
Adjusting the Volume..............................
39
Muting the Sound ...................................
39
Superimposing a Black Screen..............
40
Displaying a Still Image ..........................
40
Magnifying a Specific Portion
of an Image .......................................
41
Adjusting the Picture Aspect Ratio.........
42
Gamma Correction Function ..................
43
Setup &
Connections
Operation Buttons
Connections..........................................
13
Power Supply .........................................
13
Projecting Computer Images .................
14
Watching Video Images .........................
17
Watching Component Video Images .....
18
For Better Sound ....................................
18
Power ON/OFF .......................................
19
Setting Up the Screen ..........................
20
Using the Adjustment Feet .....................
20
Using the Lens Shift ...............................
20
LENS Button ...........................................
21
Adjusting the Projection Distance ..........
22
Image Projection ..................................
29
Rear Projection .......................................
29
Projection Using a Mirror ........................
29
Ceiling-mount Projection ........................
29
Multiple Function
Contents
E-8
Important
Information
Contents
Basic Operation
Maintenance &
Troubleshooting
Lamp/Maintenance Indicators .............
67
Replacing the Lamp .............................
68
Replacing the Air Filter ........................
70
Troubleshooting ...................................
71
For SHARP Assistance (U.S.A. only) ..
71
Using the GUI (Graphical User
Interface) Menu Screen ...................
44
Basic Operations ....................................
44
Menu Bars ..............................................
45
Adjusting the Picture ..............................
47
Adjusting the Computer Images
(RGB menu only) ..............................
49
Adjusting the Sound ...............................
52
Displaying Dual Pictures
(RGB menu only) ..............................
53
Reducing Image Noise
(VIDEO menu only) ...........................
53
Turning On/Off the On-screen Display ...
54
Setting the Video Signal
(VIDEO menu only) ...........................
54
Selecting a Background Image..............
55
Selecting a Startup Image......................
55
Selecting the Economy Mode ................
56
Confirming the Lamp Usage Time .........
57
Reversing/Inverting Projected Images ...
57
Setting the Stacking Mode .....................
58
Locking the Operation Buttons
on the Projector.................................
58
Deselecting Inputs .................................
59
Selecting the Transmission Speed
(RS-232C) .........................................
59
Controling Multiple Projectors
with ID Numbers ...............................
60
Protecting Important Settings
with a Password ................................
61
Selecting the On-screen Display
Language..........................................
62
Displaying the Adjustment Settings .......
62
Setup & Connections Operation Buttons Basic Operation
Maintenance &
Troubleshooting
Appendix
Multiple Function
Appendix
Connecting Pin Assignments .............
72
(RS-232C) Specifications and
Command Settings..........................
73
Wired Remote Control Terminal
Specifications ..................................
76
Computer Compatibility Chart ............
77
Dimensions ...........................................
78
Specifications .......................................
79
Glossary ................................................
80
Index ......................................................
81
Using Extended Functionality
Features ...........................................
63
Multiple Function
E-9
Important
Information
PDF operation manuals in several languages are included in the CD-ROM. To utilize these manuals, you need to
install Adobe Acrobat Reader on your PC (Windows or Macintosh). If you have not installed Acrobat Reader yet,
you can download it from the Internet (http://www.adobe.com) or install it from the CD-ROM.
To Install Acrobat Reader from the CD-ROM
For other operating systems:
Please download Acrobat Reader from the Internet (http://www.adobe.com).
For other languages:
If you prefer using Acrobat Reader for languages other than those included in the CD-ROM, please download the
appropriate version from the Internet.
Accessing the PDF Manuals
For Windows:
1 Insert the CD-ROM in the CD-ROM drive.
2 Double click on the “My Computer” icon.
3 Double click on the “CD-ROM” drive.
4 Double click on the “acrobat” folder.
5 Double click on the “windows” folder.
6 Double click on the desired installation program
and follow the instructions on the screen.
For Macintosh:
1 Insert the CD-ROM in the CD-ROM drive.
2 Double click on the “CD-ROM” icon.
3 Double click on the “acrobat” folder.
4 Double click on the “mac” folder.
5 Double click on the desired installation program
and follow the instructions on the screen.
For Windows:
1 Insert the CD-ROM in the CD-ROM drive.
2 Double click on the “My Computer” icon.
3 Double click on the “CD-ROM” drive.
4 Double click on the “manuals” folder.
5 Double click on the “xg-p20xu” folder.
6 Double click on the language (name of the folder)
that you want to view.
7 Double click on the “p20x” pdf file to access the
projector manuals.
Double click on the “saps” pdf file to access the
Sharp Advanced Presentation Software manual.
8 Double click on the pdf file.
For Macintosh:
1 Insert the CD-ROM in the CD-ROM drive.
2 Double click on the “CD-ROM” icon.
3 Double click on the “manuals” folder.
4 Double click on the “xg-p20xu” folder.
5 Double click on the language (name of the folder)
that you want to view.
6 Double click on the “p20x” pdf file to access the
projector manuals.
Double click on the “saps” pdf file to access the
Sharp Advanced Presentation Software manual.
7 Double click on the pdf file.
• If the desired pdf file cannot be opened by double clicking the mouse, start Acrobat Reader first, then specify the desired file
using the “File”, “Open” menu.
• See the “readme.txt” file on the CD-ROM for important information on the CD-ROM not included in this operation manual.
How to Access the PDF Operation Manuals
E-10
Important
Information
Numbers next to the part names refer to the main pages in this manual where the topic is explained.
38
35
13
17
38
18
4
4
70
56
16
16
14
14
15
65
17
17
16
39
67
44
51
42
43
44
70
3
44
32
19
67
39
21
39
37
40
44
20
52
67
20
32
Front View
Projector
MUTE button
VOLUME buttons (/)
MENU button
ADJUSTMENT buttons
(∂/ƒ/ß/©)
AUTO SYNC button
RESIZE button
GAMMA button
Foot releases
POWER buttons (ON/OFF)
LENS button
ENTER button
INPUT 1, 2, 3, 4, 5 buttons
LEARN button
BLACK SCREEN button
UNDO button
LAMP REPLACEMENT indicator
POWER indicator
Rear View
Air filter/Cooling fan
(Intake vent)
Cooling fan (Exhaust vent)
RS-232C INPUT port/
RS-232C OUTPUT port
INPUT 1 port (15-pin Mini D-sub)
IR/Gyro switch
VIDEO INPUT 4 terminal (RCA)
INPUT 3 port (DVI)
INPUT 2 terminals (BNC)
Computer AUDIO INPUT 2/3 terminal
(ø3.5 mm stereo minijack)
Computer AUDIO INPUT 1 terminal
(ø3.5 mm stereo minijack)
AUDIO OUTPUT terminal
(ø3.5 mm stereo minijack)
WIRED REMOTE control
input terminal
(ø3.5 mm stereo minijack)
OUTPUT port (15-pin Mini
D-sub) for INPUT 1, 2
AUDIO INPUT 4/5
terminals (RCA)
TEMPERATURE WARNING
indicator
GYRO RF indicator
S-VIDEO INPUT 5 terminal
(4-pin Mini DIN)
USB port
AC socket
Antenna
Speakers
Part Names
Kensington Security
Standard connector
Cooling fan (Intake vent)
Carrying handle
Lens shift dial
E-11
Important
Information
Battery
cover
Battery
cover
39
33
32
35
32
33
36
35
4444
39
33
32
21
33
33
36
37
Numbers next to the part names refer to the main pages in this manual where the topic is explained.
GyroRemote
Part Names
Front View
Inserting and removing the batteries
Batteries are not pre-installed at the factory. When inserting batteries for the first time, follow steps 1, 3 and 4
below.
Rear View
Bottom View
Bottom View
Function
button (1)
INPUT button
LEFT-CLICK/
ENTER button
POWER button
Function
button (3)
LENS button
TEACH button
RF CH button
ASSIGN Select
button
VOLUME/
/ button
MENU button
POINTER button
Function
button (2)
32
GYRO ACTIVE
button
Wired remote
control input
38
RIGHT-CLICK/
UNDO button
LED
1
Press in on the arrow
mark and slide in the
direction of the arrow
to remove the battery
cover.
Insert the side tabs
of the battery cover
into the slots and
press the cover in
until it is properly
seated.
Remove the two
upper batteries and
pull the tapes to pick
up two other
batteries at the
bottom of the
compartment.
Insert four AAA size
batteries, making
sure the polarities
match the and
marks inside the
battery compartment
and the batteries are
placed on the tapes.
42
3
Battery
compartment
Gyration U.S. Patents
5698784, 5825350, 5898421
Function
button (4)
E-12
Important
Information
Accessories
ø2.5–ø3.5 mm wired remote
control cable
QCNW-5943CEZZ
Computer audio cable
(ø3.5 mm stereo minijack cable)
QCNW-4870CEZZ
RGB cable
QCNW-5304CEZZ
USB mouse control cable
QCNW-5916CEZZ
Three BNC-RCA adaptors
QPLGJ0107GEZZ
GyroRemote
RRMCG1631CESA
Power cord
QACCU5013DE01
Extra air filter
PFILD0080CEZZ
Lens cap
PCAPH1056CESA
Four AAA size batteries
Supplied Accessories
DVI cable (9 10, 3 m)
AN-C3DV
3RCA to 15pin D-sub cable (9 10, 3 m)
AN-C3CP
5BNC to 15pin D-sub cable (9 10, 3 m)
AN-C3BN
RS-232C serial control cable (32 10, 10 m)
AN-C10RS
CD-ROM
UDSKA0043CEN1
LCD projector operation manual
TINS-7354CEZZ
LCD projector quick guide
TINS-7355CEZZ
Sharp Advanced Presentation
Software operation manual
TINS-7356CEZZ
ID number seal
TLABZ0781CEZZ
Optional cables
E-13
Setup & Connections
Power Supply
Connecting the Power Cord
Plug the supplied power cord into the AC socket on the rear of the projector.
Power cord
Make the necessary connections before proceeding. Connect the power cord to a wall outlet.
The POWER indicator lights up red and the projector enters standby mode.
Connections
POWER indicator
• If the bottom filter cover is not securely installed, the POWER indicator flashes.
E-14
Setup & Connections
Projecting Computer Images
Connecting the Projector to a Computer
You can connect your projector to a computer for projection of full color computer images.
Connecting to a computer using the standard 15-pin Input
1 Connect one end of the supplied RGB cable to the INPUT 1 port on the projector.
2 Connect the other end to the monitor output port on the computer. Secure the connectors by tightening the
thumb screws.
3 To use the built-in audio system, connect one end of the supplied computer audio cable to the AUDIO INPUT 1
terminal on the projector.
4 Connect the other end to the audio output terminal on the computer.
CAUTION
• Before connecting, be sure to turn both the projector and the computer off. After making all connections, turn the projector on first. The
computer should always be turned on last.
• Please read the computer’s operation manual carefully before making connections.
• Refer to page
77
“Computer Compatibility Chart” for a list of computer signals compatible with the projector. Use with computer signals
other than those listed may cause some of the functions not to work.
• A ø3.5 mm stereo minijack to stereo RCA audio cable adaptor may be necessary.
When connecting this projector to a computer, select “RGB” for “Signal Type” on the GUI menu. (See page
47
.)
• A Macintosh adaptor may be required for use with some Macintosh computers. Contact your nearest Authorized Sharp Industrial LCD
Products Dealer or Service Center.
• AUDIO INPUT 1 can be used to input audio corresponding to the INPUT 1.
Computer audio cable
3
4
RGB cable
1
2
E-15
Setup & Connections
Projecting Computer Images
• This projector uses a 5 BNC computer input to prevent deterioration of image quality.
• Connect the R (PR), G/G sync (Y), B (PB), HD/C sync and VD cables (sold separately) to the correct input
terminals on the projector and an RGB switcher (sold separately) connected to the computer, or connect a 5
BNC cable (sold separately) directly from the input terminals on the projector to the computer.
Connecting to an external RGB switcher or other compatible computers using the BNC Input
(Typically used in larger installations )
5 BNC cable
(sold separately)
1 Connect each BNC connector of a 5 BNC cable to the corresponding INPUT 2 terminals on the projector.
2 Connect the other end of the 5 BNC cable to the corresponding BNC terminals on the external RGB switcher.
Connect the RGB switcher to the computer using a RGB cable.
3 To use the built-in audio system, connect one end of the supplied computer audio cable to the AUDIO INPUT 2/
3 terminal on the projector.
4 Connect the other end to the audio output terminal on the computer or external audio system.
• A ø3.5 mm stereo minijack to stereo RCA audio cable adaptor may be necessary.
When connecting the projector to a compatible computer other than a PC (VGA/SVGA/XGA/SXGA/UXGA) or Macintosh (i.e.
Workstation), a separate cable may be needed. Please contact your dealer for more information.
When connecting this projector to a computer, select “RGB” for “Signal Type” on the GUI menu. (See page
47
.)
• Connecting computers other than the recommended types may result in damage to the projector, the computer, or both.
• AUDIO INPUT 2/3 can be used to input audio corresponding to the INPUT 2/3.
Computer audio cable
4 To audio output
terminal
3
1
To R (PR), G/G sync (Y), B (PB),
HD/C sync and VD output terminals
2 To RGB switcher
RGB switcher
(sold separately)
RGB cable
“Plug and Play” function (when connecting to a 15-pin terminal)
• This projector is compatible with VESA-standard DDC 1/DDC 2B. The projector and a VESA DDC compatible
computer will communicate their setting requirements, allowing for quick and easy setup.
• Before using the “Plug and Play” function, be sure to turn on the projector first and the connected computer last.
• The DDC “Plug and Play” function of this projector operates only when used in conjunction with a VESA DDC compatible computer.
E-16
Setup & Connections
Projecting Computer Images
Connecting to a computer using the RS-232C Port
When the RS-232C port on the projector is connected to a computer with an RS-232C cable (null modem, cross
type, sold separately), the computer can be used to control the projector and check the status of the projector.
See pages
73
,
74
and
75
for details.
Connect an RS-232C cable (null modem, cross type, sold separately) to the serial port on the computer.
RGB cable
Computer audio cable
RS-232C cable
(null modem, cross type, sold separately)
CAUTION
• Do not connect or disconnect an RS-232C cable to or from the computer while it is on. This may damage your computer.
• The wireless mouse or RS-232C function may not operate if your computer port is not correctly set up. Please refer to the operation manual
of the computer for details on setting up/installing the correct mouse driver.
• A Macintosh adaptor may be required for use with some Macintosh computers. Contact your nearest Authorized Sharp Industrial LCD
Products Dealer or Service Center.
Connecting to a computer using the direct digital input port
3
1
Computer audio cable
2 To digital output terminal
4 To audio output terminal
1 Connect one end of the DVI cable to the INPUT 3 port on the projector.
2 Connect the other end to the corresponding terminal on a computer.
3 To use the built-in audio system, connect one end of the supplied computer audio cable to the AUDIO INPUT 2/
3 terminal on the projector.
4 Connect the other end to the audio output terminal on the computer.
• This DVI port is DVI version 1.0 compatible. Therefore when the signal is input from copy guard system compatible (DVI version 2.0)
equipment, no signal will be received.
DVI cable (sold separately)
E-17
Setup & Connections
Watching Video Images
Connecting to a VCR, laser disc player and other audiovisual
equipment using the standard video Input
S-video cable (sold separately)
Video cable (sold separately)
1
2
Audio cable (sold separately)
To S-video output terminal
To video output terminal
To audio output terminals
VCR
or
Laser disc player
Example
1 Connect the yellow RCA connectors to the corresponding yellow VIDEO INPUT 4 terminal on the projector and
the Video output terminal on the video source.
2 To use the built-in audio system, connect the red and white RCA connectors to the corresponding red and white
AUDIO INPUT 4/5 terminals on the projector and the Audio output terminals on the video source.
The S-VIDEO INPUT 5 terminal uses a video signal system in which the picture is separated into a color and a luminance signal
to realize a higher-quality image.
• For higher quality video, you may use the S-VIDEO INPUT 5 terminal on the projector. S-video cable is sold separately.
• If your video equipment does not have an S-video output terminal, use a composite video cable.
CAUTION
• Always turn off the projector before connecting to video equipment, in order to protect both the projector and the equipment
being connected.
E-18
Setup & Connections
Watching Component Video Images
Connecting to a DVD video player, DTV decoder and other component
video equipment using the 5 BNC Input
4 To audio output terminals
1
3
Three BNC-RCA adaptors
DTV decoder
or
DVD video player
Example
Audio cable
(ø3.5 mm stereo minijack/RCA cable,
sold separately)
2 To analog component output terminals
Component cable (sold separately)
CAUTION
• Always turn off the projector before connecting to video
equipment, in order to protect both the projector and the
equipment being connected.
1 Connect each BNC connector of a component cable to the corresponding BNC INPUT 2 terminals on the
projector.
2 Connect the other end of the cable to the corresponding terminals on a DVD video player or DTV decoder.
3 To use the built-in audio system, connect one end of an audio cable (sold separately) to the AUDIO INPUT 2/3
terminal on the projector.
4 Connect the other end to the audio output terminal on the DVD video player or DTV decoder.
• BNC-RCA adaptors are included for use with RCA type cables and sources.
• A ø3.5 mm stereo minijack to stereo RCA audio cable adaptor may be necessary.
When connecting this projector to a DVD video player or DTV decoder, select “Component” for “Signal Type” on the GUI
menu. (See page
47
.)
For Better Sound
Connecting to an amplifier and other audio components
Audio cable (sold separately)
To audio input terminals
Amplifier
CAUTION
• Always turn off the projector before connecting to audio
components, in order to protect both the projector and the
components being connected.
• By using external audio components, the volume can be amplified for better sound.
• The AUDIO OUTPUT terminal allow you to output audio to audio components from the selected AUDIO INPUT 1 to 5 terminals connected to
audiovisual equipment.
• For details on Variable Audio Output (VAO) and Fixed Audio Output (FAO), see page
52
.
• A ø3.5 mm stereo minijack to stereo RCA audio cable adaptor may be necessary.
E-19
Setup & Connections
Power ON/OFF
Press POWER ON on the projector or
POWER on the GyroRemote.
Press POWER OFF on the projector or
POWER on the GyroRemote.
LAMP REPLACEMENT
indicator
POWER
• The flashing green LAMP REPLACEMENT indicator
shows that the lamp is warming up. Wait until the
indicator stops flashing before operating the projector.
• If the power is turned off and then immediately turned
on again, it may take a short while before the lamp
turns on.
• When the projector cannot recognize GyroRemote, an on-
screen display appears. Follow the instructions to activate
control.
• After the projector is unpacked and turned on for the first
time, a slight odor may be emitted from the exhaust vent.
This odor will soon disappear with use.
When the power is on, the LAMP REPLACEMENT
indicator lights, indicating the status of the lamp.
Green: Lamp is ready.
Flashing green: Warming up.
Red: Change the lamp.
Press POWER OFF/POWER again while the message
is displayed.
• If you accidentally pressed POWER OFF/POWER and do
not want to turn off the power, wait until the power off screen
disappears.
• When the power is turned off, the POWER indicator will light
up red and the cooling fan will run for about 90 seconds.
The projector will then enter standby mode.
• Wait until the cooling fan stops before disconnecting the
power cord.
• The power can be turned on again by pressing POWER
ON/POWER. When the power is turned on, the POWER
indicator and the LAMP REPLACEMENT indicator light
green.
• The POWER indicator flashes if the bottom filter cover is
not securely installed.
On-screen Display
E-20
Setup & Connections
Setting Up the Screen
1
Using the Adjustment Feet
3
2
Press foot releases. Adjust height of projector
and remove hands from
foot releases.
Rotate feet to make minor changes.
• The projector is adjustable up to approximately 10° from the standard position.
• When the height of the projector is adjusted, the image may become distorted (keystoned), depending on the relative
positions of the projector and the screen.
• Do not press the foot releases when the adjustment feet are extended without firmly holding the projector.
• Do not hold the lens when lifting or lowering the projector.
• When lowering the projector, be careful not to get your fingers caught in the area between the adjustment feet and the
projector.
CAUTION
Using the Lens Shift
The picture can be adjusted within the shift range of the lens by rotating the dial on the top of the projector.
Lens shift dial
UP
DOWN
UP
DOWN
Projector Projected Image
UP DOWN
• The lens shift dial is set to the upper most position at the factory. Remember to adjust lower by turning the dial when operating the projector.
• The lens shift dial has two points to help orient the position. The center of the lens and bottom of the screen are the same height (10:0) and
the center of the lens and center of the screen are the same height (5:5). When either position is reached by turning the dial, you will notice
a slight latching feeling.
• Do not forcefully turn the lens shift dial beyond the 10:0 and 5:5 orientating positions; doing so may result in damaging the equipment.
• When the AN-P9MX of optional lens is attached, lens shift cannot be used.
E-21
Setup & Connections
LENS Button
Projector GyroRemote
Digital Image Adjustments
This function can be used to adjust the focus, zoom,
keystone, v-size and digital shift settings.
1 Press LENS to select mode. Each time LENS is
pressed, the screen changes as shown on the left.
2 Press ENTER to display test
pattern.
3 Press ∂/ƒ/ß/© to make
adjustments. (Press / to
make adjustments on the
GyroRemote.)
4 a. Press LENS until normal screen appears.
b. To reset the “KEYSTONE”, “V-SIZE” and
“DIGITAL SHIFT” setting, press UNDO.
• Do not touch the lens when adjusting the focus or zoom.
ENTER
LENS
∂/ƒ/ß/©
UNDO
On-screen Display
(Example: 4:3
NORMAL image)
On-screen Display
(Example: 16:9
WIDE image)
Keystone setting
Trapezoidal distortion is caused when the projector
image is positioned away from the center axis of the
screen. This function allows you to correct the keystone
effect for excellent picture quality.
• Straight lines and the edges of the displayed image may appear
jagged, when adjusting the KEYSTONE setting.
V-size setting
During keystone correction an error can occur in the
aspect ratio depending on the amount of lens shift. Use
the V-SIZE fine-tuning function to correct this error.
• V-SIZE is only displayed and can only be adjusted when performing
KEYSTONE correction.
Digital shift setting
For easier viewing, this function shifts the image
projected on the screen up or down eliminating either
the upper or lower black band found in 16:9 and other
wide aspect ratios.
• Digital shift function only works with BORDER, STRETCH or SMART
STRETCH of VIDEO and DTV inputs. (See page
42
for details.)
The DIGITAL SHIFT screen is not displayed when projecting images
other than WIDE.
Digital Shift
or
Press ∂.
Press ƒ.
E-22
Setup & Connections
Place the projector at the required distance from the screen according to the
desired picture size. (See pages
24
to
28
.)
Adjusting the Projection Distance
Position the projector perpendicular to the screen with all feet flat and level to achieve an optimal image.
Move the projector forward or backward if the edges of the image are distorted.
• The projector lens should be centered in the middle of the screen. If the lens center is not perpendicular to the screen, the image will be
distorted, making viewing difficult.
• Position the screen so that it is not in direct sunlight or room light. Light falling directly onto the screen washes out colors, making viewing
difficult. Close the curtains and dim the lights when setting up the screen in a sunny or bright room.
• A polarizing screen cannot be used with this projector.
Four optional lenses from Sharp are also available for specialized application. Please see your local Sharp Industrial
LCD Products Dealer to details on all the lenses. (Refer to the lens operation manual when attaching a lens.)
You can install the AN-W6EZ and AN-T6EZ optional lenses yourself. However, be sure to have service personnel
install the AN-P9MX and AN-P48EZ optional lenses.
Screen
5 10152025303540
(
ft
)
AN-P48EZ
3010–404 (9.4–12.3 m)
Throw distance ratio 1:4.6–6.1
AN-T6EZ
165–216 (5.0–6.6 m)
Throw distance ratio 1:2.5–3.3
Standard
12–1511 (3.7–4.9 m)
Throw distance ratio 1:1.8–2.4
AN-W6EZ
86–112 (2.6–3.4 m)
Throw distance ratio 1:1.3–1.7
AN-P9MX
511 (1.8 m)
Throw distance ratio 1:0.9
Standard Setup (Front Projection)
H
L
X
• Four optional lenses from Sharp are available for specialized application. Please see
your local Sharp Industrial LCD Products Dealer for details on all the lenses.
: Screen size and Picture size (16:9)
: Signal mask area
WIDE Mode (16:9)
: Screen size and Picture size (4:3)
4
16
9 3
NORMAL Mode (4:3)
4
3
Throw Distance
The graph below is for 100 inches (254 cm) screen with 4:3 normal mode.
E-23
Setup & Connections
Adjusting the Projection Distance
Upper and Lower Lens Shift Position
• This projector is equipped with a lens shift function that lets you adjust the projection height.
• Adjust to match the setup configuration.
Screen size: 100 inches (254 cm)
WIDE Mode: 16:9
Standard Lens as an example
Upper and Lower Lens Shift Position (Ceiling Mount)
When the projector is in the inverted position, use the upper edge of the screen as the base line, and exchange
the lower and upper lens shift values.
Screen
Upper edge of screen
• Optimal image quality is produced with the projector positioned perpendicular to the screen with all feet flat and level. Tilting or angling
the projector will reduce the effectiveness of the lens shift function.
–H
Screen
Upper lens
shift position
H: 2 1 (62.3 cm)
Lower lens shift position H: 8.2
(20.8 cm)
Lower edge of screen (White portion) = Standard (0) point
Upper lens shift position
(High mount setup)
Lower lens shift position
(Desktop setup)
Lens center
Lens center
–H
E-24
Setup & Connections
Adjusting the Projection Distance
Standard Lens
Throw distance ratio
1:1.8 to 2.4
300
200
150
100
84
72
60
40
240
160
120
80
67
58
48
32
180
120
90
60
50
43
36
24
47 0
32 2
23 6
15 11
13 2
11 1
9 6
6 1
(14.3 m)
(9.8 m)
(7.2 m)
(4.9 m)
(4.0 m)
(3.4 m)
(2.9 m)
(1.9 m)
Diag. Width
Screen size (4:3) (X)
Height
Projection distance (L)
Maximum (l
1
)
36 2
24 3
18 4
12 0
10 1
8 6
7 3
4 7
(11.0 m)
(7.4 m)
(5.6 m)
(3.7 m)
(3.1 m)
(2.6 m)
(2.2 m)
(1.4 m)
Minimum (l
2
)
7 6
5 0
3 9
2 6
2 1
1 10
1 6
1 0
(228.6 cm)
(152.4 cm)
(114.3 cm)
(76.2 cm)
(64.0 cm)
(54.9 cm)
(45.7 cm)
(30.5 cm)
Lens center to the lower edge of the screen (H)
Upper lens shift position (h
1
)
0.0
0.0
0.0
0.0
0.0
0.0
0.0
0.0
(0.0 cm)
(0.0 cm)
(0.0 cm)
(0.0 cm)
(0.0 cm)
(0.0 cm)
(0.0 cm)
(0.0 cm)
Lower lens shift position (h
2
)
NORMAL Mode (4:3)
300
200
150
133
106
100
92
84
72
60
40
261
174
131
116
92
87
80
73
63
52
35
147
98
74
65
52
49
45
41
35
29
20
51 3
34 5
25 11
23 0
18 3
17 0
15 10
14 1
12 0
10 2
6 6
(15.6 m)
(10.5 m)
(7.9 m)
(7.0 m)
(5.6 m)
(5.2 m)
(4.8 m)
(4.3 m)
(3.7 m)
(3.1 m)
(2.0 m)
Diag. Width
Screen size (4:3) (X)
Height
Projection distance (L)
Maximum (l
1
)
39 5
26 5
19 11
17 7
14 0
13 1
12 1
10 10
9 3
7 10
5 0
(12.0 m)
(8.1 m)
(6.1 m)
(5.4 m)
(4.3 m)
(4.0 m)
(3.7 m)
(3.3 m)
(2.8 m)
(2.4 m)
(1.5 m)
Minimum (l
2
)
6 2
4 1
3 1
2 9
2 2
2 1
1 11
1 9
1 6
1 3
9.8
(186.8 cm)
(124.5 cm)
(93.4 cm)
(82.8 cm)
(66.0 cm)
(62.3 cm)
(57.3 cm)
(52.3 cm)
(44.8 cm)
(37.4 cm)
(24.9 cm)
Lens center to the lower edge of the screen (H)
Upper lens shift position (h
1
)
2 1
1 4
1 0
10.9
8.7
8.2
7.5
6.9
5.9
4.9
3.3
(62.3 cm)
(41.5 cm)
(31.1 cm)
(27.6 cm)
(22.0 cm)
(20.8 cm)
(19.1 cm)
(17.4 cm)
(14.9 cm)
(12.5 cm)
(8.3 cm)
Lower lens shift position (h
2
)
WIDE Mode (16:9)
The formula for screen size and projection distance
l
1
(Max.) = (0.0482x 0.0226) 3.28
l
2
(Min.) = (0.037x 0.041) 3.28
h
1
(Upper) = 0.3x
h
2
(Lower) = 0
The formula for screen size and projection distance
l
1
(Max.) = (0.0525x 0.0546) 3.28
l
2
(Min.) = (0.0404x 0.0397) 3.28
h
1
(Upper) = 0.2451x
h
2
(Lower) =0.0817x
x: Screen size (diag.) (X) (inches)
l: Projection distance (L) (feet)
h: Lens center to the lower edge of the screen (H) (inches)
• There is an error of 3% in the formula above.
• Values with a minus () sign indicate the distance of the lens center below the bottom of the screen.
x: Screen size (diag.) (X) (inches)
l: Projection distance (L) (feet)
h: Lens center to the lower edge of the screen (H) (inches)
E-25
Setup & Connections
Adjusting the Projection Distance
AN-W6EZ
Throw distance ratio
1:1.3 to 1.7
NORMAL Mode (4:3)
300
200
150
100
84
72
60
40
240
160
120
80
67
58
48
32
180
120
90
60
50
43
36
24
33 11
22 6
16 10
11 2
9 4
8 0
6 7
4 4
(10.3 m)
(6.9 m)
(5.1 m)
(3.4 m)
(2.8 m)
(2.4 m)
(2.0 m)
(1.3 m)
Diag. Width
Screen size (4:3) (X)
Height
Projection distance (L)
Maximum (l
1
)
26 1
17 3
12 11
8 6
7 1
6 1
5 0
3 3
(7.9 m)
(5.3 m)
(3.9 m)
(2.6 m)
(2.2 m)
(1.9 m)
(1.5 m)
(1.0 m)
Minimum (l
2
)
7 6
5 0
3 9
2 6
2 1
1 10
1 6
1 0
(228.6 cm)
(152.4 cm)
(114.3 cm)
(76.2 cm)
(64.0 cm)
(54.9 cm)
(45.7 cm)
(30.5 cm)
Lens center to the lower edge of the screen (H)
Upper lens shift position (h
1
)
0.0
0.0
0.0
0.0
0.0
0.0
0.0
0.0
(0.0 cm)
(0.0 cm)
(0.0 cm)
(0.0 cm)
(0.0 cm)
(0.0 cm)
(0.0 cm)
(0.0 cm)
Lower lens shift position (h
2
)
300
200
150
133
106
100
92
84
72
60
40
261
174
131
116
92
87
80
73
63
52
35
147
98
74
65
52
49
45
41
35
29
20
37 0
24 7
18 4
16 3
12 11
12 2
11 2
10 2
8 8
7 3
4 9
(11.3 m)
(7.5 m)
(5.6 m)
(5.0 m)
(3.9 m)
(3.7 m)
(3.4 m)
(3.1 m)
(2.7 m)
(2.2 m)
(1.4 m)
Diag. Width
Screen size (4:3) (X)
Height
Projection distance (L)
Maximum (l
1
)
28 5
18 10
14 1
12 6
9 11
9 4
8 6
7 9
6 8
5 6
3 7
(8.7 m)
(5.8 m)
(4.3 m)
(3.8 m)
(3.0 m)
(2.8 m)
(2.6 m)
(2.4 m)
(2.0 m)
(1.7 m)
(1.1 m)
Minimum (l
2
)
6 2
4 1
3 1
2 9
2 2
2 1
1 11
1 9
1 6
1 3
9.8
(186.8 cm)
(124.5 cm)
(93.4 cm)
(82.8 cm)
(66.0 cm)
(62.3 cm)
(57.3 cm)
(52.3 cm)
(44.8 cm)
(37.4 cm)
(24.9 cm)
Lens center to the lower edge of the screen (H)
Upper lens shift position (h
1
)
2 1
1 4
1 0
10.9
8.7
8.2
7.5
6.9
5.9
4.9
3.3
(62.3 cm)
(41.5 cm)
(31.1 cm)
(27.6 cm)
(22.0 cm)
(20.8 cm)
(19.1 cm)
(17.4 cm)
(14.9 cm)
(12.5 cm)
(8.3 cm)
Lower lens shift position (h
2
)
WIDE Mode (16:9)
The formula for screen size and projection distance
l
1
(Max.) = (0.0347x 0.0709) 3.28
l
2
(Min.) = (0.0267x 0.0715) 3.28
h
1
(Upper) = 0.3x
h
2
(Lower) = 0
x: Screen size (diag.) (X) (inches)
l: Projection distance (L) (feet)
h: Lens center to the lower edge of the screen (H) (inches)
The formula for screen size and projection distance
l
1
(Max.)
= (0.0378x 0.0726) 3.28
l
2
(Min.) = (0.0291x 0.0731) 3.28
h
1
(Upper) = 0.2451x
h
2
(Lower) =0.0817x
x: Screen size (diag.) (X) (inches)
l: Projection distance (L) (feet)
h: Lens center to the lower edge of the screen (H) (inches)
• There is an error of 3% in the formula above.
• Values with a minus () sign indicate the distance of the lens center below the bottom of the screen.
E-26
Setup & Connections
Adjusting the Projection Distance
AN-T6EZ
Throw distance ratio
1:2.5 to 3.3
NORMAL Mode (4:3)
300
200
150
100
84
72
60
40
240
160
120
80
67
58
48
32
180
120
90
60
50
43
36
24
65 9
43 8
32 7
21 6
18 0
15 4
12 8
8 3
(20.0 m)
(13.3 m)
(9.9 m)
(6.6 m)
(5.5 m)
(4.7 m)
(3.9 m)
(2.5 m)
Diag. Width
Screen size (4:3) (X)
Height
Projection distance (L)
Maximum (l
1
)
50 5
33 5
24 11
16 5
13 8
11 8
9 7
6 2
(15.4 m)
(10.2 m)
(7.6 m)
(5.0 m)
(4.2 m)
(3.6 m)
(2.9 m)
(1.9 m)
Minimum (l
2
)
7 6
5 0
3 9
2 6
2 1
1 10
1 6
1 0
(228.6 cm)
(152.4 cm)
(114.3 cm)
(76.2 cm)
(64.0 cm)
(54.9 cm)
(45.7 cm)
(30.5 cm)
Lens center to the lower edge of the screen (H)
Upper lens shift position (h
1
)
0.0
0.0
0.0
0.0
0.0
0.0
0.0
0.0
(0.0 cm)
(0.0 cm)
(0.0 cm)
(0.0 cm)
(0.0 cm)
(0.0 cm)
(0.0 cm)
(0.0 cm)
Lower lens shift position (h
2
)
The formula for screen size and projection distance
l
1
(Max.) = (0.0674x 0.178) 3.28
l
2
(Min.) = (0.0519x 0.1829) 3.28
h
1
(Upper) = 0.3x
h
2
(Lower) = 0
x: Screen size (diag.) (X) (inches)
l: Projection distance (L) (feet)
h: Lens center to the lower edge of the screen (H) (inches)
WIDE Mode (16:9)
300
200
150
133
106
100
92
84
72
60
40
261
174
131
116
92
87
80
73
63
52
35
147
98
74
65
52
49
45
41
35
29
20
71 8
47 7
35 6
31 5
24 11
23 6
21 7
19 8
16 9
13 11
9 1
(21.8 m)
(14.5 m)
(10.8 m)
(9.6 m)
(7.6 m)
(7.2 m)
(6.6 m)
(6.0 m)
(5.1 m)
(4.2 m)
(2.8 m)
Diag. Width
Screen size (4:3) (X)
Height
Projection distance (L)
Maximum (l
1
)
55 0
36 5
27 2
24 1
19 1
17 11
16 6
15 0
12 9
10 6
6 10
(16.8 m)
(11.1 m)
(8.3 m)
(7.3 m)
(5.8 m)
(5.5 m)
(5.0 m)
(4.6 m)
(3.9 m)
(3.2 m)
(2.1 m)
Minimum (l
2
)
6 2
4 1
3 1
2 9
2 2
2 1
1 11
1 9
1 6
1 3
9.8
(186.8 cm)
(124.5 cm)
(93.4 cm)
(82.8 cm)
(66.0 cm)
(62.3 cm)
(57.3 cm)
(52.3 cm)
(44.8 cm)
(37.4 cm)
(24.9 cm)
Lens center to the lower edge of the screen (H)
Upper lens shift position (h
1
)
2 1
1 4
1 0
10.9
8.7
8.2
7.5
6.9
5.9
4.9
3.3
(62.3 cm)
(41.5 cm)
(31.1 cm)
(27.6 cm)
(22.0 cm)
(20.8 cm)
(19.1 cm)
(17.4 cm)
(14.9 cm)
(12.5 cm)
(8.3 cm)
Lower lens shift position (h
2
)
The formula for screen size and projection distance
l
1
(Max.)
= (0.0734x 0.1764) 3.28
l
2
(Min.) = (0.0565x 0.1778) 3.28
h
1
(Upper) = 0.2451x
h
2
(Lower) =0.0817x
x: Screen size (diag.) (X) (inches)
l: Projection distance (L) (feet)
h: Lens center to the lower edge of the screen (H) (inches)
• There is an error of 3% in the formula above.
• Values with a minus () sign indicate the distance of the lens center below the bottom of the screen.
E-27
Setup & Connections
Adjusting the Projection Distance
AN-P9MX
Throw distance ratio
1:0.9
NORMAL Mode (4:3)
300
200
150
100
84
72
60
40
240
160
120
80
67
58
48
32
180
120
90
60
50
43
36
24
18 1
12 0
9 0
5 11
4 11
4 2
3 6
2 3
(5.5 m)
(3.7 m)
(2.7 m)
(1.8 m)
(1.5 m)
(1.3 m)
(1.1 m)
(0.7 m)
Diag. Width
Screen size (4:3) (X)
Height
Projection distance (L)
7 6
5 0
3 9
2 6
2 1
1 10
1 6
1 0
(228.6 cm)
(152.4 cm)
(114.3 cm)
(76.2 cm)
(64.0 cm)
(54.9 cm)
(45.7 cm)
(30.5 cm)
Lens center to the lower edge of the screen (H)
The formula for screen size and projection distance
l = (0.0186x 0.0563) 3.28
h = 0.3x
x: Screen size (diag.) (X) (inches)
l: Projection distance (L) (feet)
h: Lens center to the lower edge of the screen (H) (inches)
WIDE Mode (16:9)
300
200
150
133
106
100
92
84
72
60
40
261
174
131
116
92
87
80
73
63
52
35
147
98
74
65
52
49
45
41
35
29
20
Diag. Width
Screen size (4:3) (X)
Height
Projection distance (L)
19 9
13 2
9 10
8 8
6 10
6 6
5 11
5 4
4 8
3 9
2 6
(6.0 m)
(4.0 m)
(3.0 m)
(2.6 m)
(2.1 m)
(2.0 m)
(1.8 m)
(1.6 m)
(1.4 m)
(1.2 m)
(0.8 m)
6 2
4 1
3 1
2 9
2 2
2 1
1 11
1 9
1 6
1 3
10.0
(186.8 cm)
(124.5 cm)
(93.4 cm)
(82.8 cm)
(66.0 cm)
(62.3 cm)
(57.3 cm)
(52.3 cm)
(44.8 cm)
(37.4 cm)
(24.9 cm)
Lens center to the lower edge of the screen (H)
The formula for screen size and projection distance
l = (0.0203x 0.0579) 3.28
h = 0.2451x
x: Screen size (diag.) (X) (inches)
l: Projection distance (L) (feet)
h: Lens center to the lower edge of the screen (H) (inches)
• There is an error of 3% in the formula above.
• Values with a minus () sign indicate the distance of the lens center below the bottom of the screen.
E-28
Setup & Connections
Adjusting the Projection Distance
AN-P48EZ
Throw distance ratio
1:4.6 to 6.1
NORMAL Mode (4:3)
300
200
150
100
84
72
60
240
160
120
80
67
58
48
180
120
90
60
50
43
36
119 9
80 1
60 0
40 4
33 10
29 2
24 3
(36.5 m)
(24.4 m)
(18.3 m)
(12.3 m)
(10.3 m)
(8.9 m)
(7.4 m)
Diag. Width
Screen size (4:3) (X)
Height
Projection distance (L)
Maximum (
l
1)
91 6
61 4
45 11
30 10
25 11
22 4
18 8
(27.9 m)
(18.7 m)
(14.0 m)
(9.4 m)
(7.9 m)
(6.8 m)
(5.7 m)
Minimum (
l
2
)
7 6
5 0
3 9
2 6
2 1
1 10
1 6
(228.6 cm)
(152.4 cm)
(114.3 cm)
(76.2 cm)
(64.0 cm)
(54.9 cm)
(45.7 cm)
Lens center to the lower edge of the screen (H)
Upper lens shift position (
h
1
)
0.0
0.0
0.0
0.0
0.0
0.0
0.0
(0.0 cm)
(0.0 cm)
(0.0 cm)
(0.0 cm)
(0.0 cm)
(0.0 cm)
(0.0 cm)
Lower lens shift position (
h
2
)
The formula for screen size and projection distance
l
1
(Max.) = (0.1214x 0.1272) 3.28
l
2
(Min.) = (0.0927x 0.1233) 3.28
h
1
(Upper) = 0.3x
h
2
(Lower) = 0
x: Screen size (diag.) (X) (inches)
l: Projection distance (L) (feet)
h: Lens center to the lower edge of the screen (H) (inches)
WIDE Mode (16:9)
300
200
150
133
106
100
92
84
72
60
261
174
131
116
92
87
80
73
63
52
147
98
74
65
52
49
45
41
35
29
130 7
87 3
65 7
58 1
46 3
44 0
40 4
36 9
31 10
26 7
(39.8 m)
(26.6 m)
(20.0 m)
(17.7 m)
(14.1 m)
(13.4 m)
(12.3 m)
(11.2 m)
(9.7 m)
(8.1 m)
Diag. Width
Screen size (4:3) (X)
Height
Projection distance (L)
Maximum (l
1
)
99 9
66 7
50 2
44 7
35 5
33 6
30 10
28 3
24 3
20 4
(30.4 m)
(20.3 m)
(15.3 m)
(13.6 m)
(10.8 m)
(10.2 m)
(9.4 m)
(8.6 m)
(7.4 m)
(6.2 m)
Minimum (l
2
)
6 2
4 1
3 1
2 9
2 2
2 1
1 11
1 9
1 6
1 3
(186.8 cm)
(124.5 cm)
(93.4 cm)
(82.8 cm)
(66.0 cm)
(62.3 cm)
(57.3 cm)
(52.3 cm)
(44.8 cm)
(37.4 cm)
Lens center to the lower edge of the screen (H)
Upper lens shift position (h
1
)
2 1
1 4
1 0
10.9
8.7
8.2
7.5
6.9
5.9
4.9
(62.3 cm)
(41.5 cm)
(31.1 cm)
(27.6 cm)
(22.0 cm)
(20.8 cm)
(19.1 cm)
(17.4 cm)
(14.9 cm)
(12.5 cm)
Lower lens shift position (h
2
)
The formula for screen size and projection distance
l
1
(Max.)
= (0.1323x 0.1272) 3.28
l
2
(Min.) = (0.101x 0.1233) 3.28
h
1
(Upper) = 0.2451x
h
2
(Lower) =0.0817x
• There is an error of 3% in the formula above.
• Values with a minus () sign indicate the distance of the lens center below the bottom of the screen.
x: Screen size (diag.) (X) (inches)
l: Projection distance (L) (feet)
h: Lens center to the lower edge of the screen (H) (inches)
E-29
Setup & Connections
Rear Projection
• Place a translucent screen between the projector and
the audience.
• Use the projector’s menu system to reverse the
projected image. (See page
57
for use of this
function.)
• Optimal image quality can be achieved when the projector
is positioned perpendicular to the screen with all feet flat
and level.
Projection Using a Mirror
• When the distance between the projector and screen
is not sufficient for normal rear projection, you can
use a mirror to reflect the image onto the screen.
• Place a mirror (normal flat type) in front of the lens.
• Project the normal image onto the mirror.
• The image reflected from the mirror is projected onto
the translucent screen.
CAUTION
• When using a mirror, be sure to carefully position both the
projector and the mirror so the light does not shine into the
eyes of the audience.
• It is recommended that you use the optional Sharp
ceiling-mount bracket for this installation.
• Before mounting the projector, contact your nearest
Authorized Sharp Industrial LCD Products Dealer or
Service Center to obtain the recommended ceiling-
mount bracket (sold separately). (AN-XGCM61
ceiling-mount bracket, AN-EP101AP extension tube
for AN-XGCM61.)
• When the projector is in the inverted position, use the
upper edge of the screen as the base line.
• Use the projector’s menu system to select the
appropriate projection mode. (See page
57
for use
of this function.)
Ceiling-mount Projection
Image Projection
E-30
Operation Buttons
Introducing GyroRemote
GyroRemote Features
1. RF design provides nondirectional control.
2. Individual Recognition (Teach/Learn) function for multi-projector control.
3. Senses your natural hand motion for accurate control of mouse operations and
projector menus.
1. RF Technology
Nondirectional radio design with 98 5 (30 m) range.
• The control range measured is with the antenna fully extended.
• The control range under actual operating conditions may be less than optimum depending on where the projector is placed and the
radio signal environment.
2. Multi-Projector Control
An individual recognition function makes it possible to control multiple projectors.
No radio interference even if other projectors of the same type are within GyroRemote’s
operating range.
Projector: 1 unit
GyroRemote: 1 unit
Can operate one projector using multiple GyroRemotes.
Can operate multiple projections with one GyroRemote.
Projector: multiple units
GyroRemote: 1 unit
RF: Nondirectional
98 5 (30 m)
98 5 (30 m)
98 5 (30 m)
98 5 (30 m)
Projector: 1 unit
GyroRemote: multiple units
E-31
Operation Buttons
Mouse Control
You can operate your computer with the same operating
feeling as a normal mouse.
(See page
35
.)
GyroRemote Features
3. Gesture tracking
Accurately tracks your hand movements in the air for pinpoint control of projector menus and computer cursor.
Mouse Control
• GYRO ACTIVE, LEFT-CLICK/ENTER and RIGHT-CLICK/UNDO controls depend on whether the
GyroRemote is operating the projector or the computer.
Projector Control
On-screen Display
Bright and easy-to-see screen pointer.
(See page
32
.)
Operate the menu with a simple wave of the hand.
(See page
32
.)
Press ASSIGN Select to toggle and display the 5
“Button ASSIGN” lists one-by-one. Each “Button
ASSIGN” list has 4 selection items.
(See page
33
.)
Projector Control
(for OSD)
Inside the
upper cover
USB mouse control cable
E-32
Operation Buttons
Using GyroRemote
Preparation
1 Switch on the projector power source. The projector
image will appear on the screen.
2 Pull out the projector antenna.
• The control range will not be optimized if you do not pull
out the antenna. Always use with the antenna fully
extended.
• The control range under actual operating conditions may
be less than optimum depending on where the projector
is placed and the radio signal environment.
3 Press POWER on the GyroRemote, located on the
front, inside the upper cover.
• The GYRO RF indicator on the projector flashes green
whenever it receives a radio signal from the GyroRemote.
Operating the screen pointer
1 Press POINTER on the GyroRemote.
As the POINTER is being pushed, a pointer on the
screen will display. If you release your finger from
the POINTER it will disappear from the screen.
2 Hold the GyroRemote and move it around freely in
the air. The pointer on the screen moves precisely
in concert with the movement of your GyroRemote
in hand.
Menu Adjustments
1 Open the upper cover on the front of the
GyroRemote.
2 Press MENU.
3 Press GYRO ACTIVE on the back of the
GyroRemote, and select your desired category by
moving the unit left or right.
4 Then select the desired item by moving the unit up
or down.
5 Move the unit left or right, or press / to adjust
item values.
6 Press MENU.
The menu display disappears.
• Double click on GYRO ACTIVE, the LED will light and you can
operate GyroRemote just like pressing the button continuously. To
cancel this mode, press GYRO ACTIVE once.
• If you release GYRO ACTIVE located on the back of the unit, you
will not be able to control operations no matter how you wave your
hand in the air.
Antenna
E-33
Operation Buttons
Using GyroRemote
GyroRemote
On-screen Display
Inside the upper cover
Function (3)
Function (4)
ASSIGN Select
All Button Assign selections
: ASSIGN Select button : LEFT-CLICK/ENTER button
: RIGHT-CLICK/UNDO button
Function ASSIGN
1 Open the upper cover on the front of GyroRemote.
2 Press ASSIGN Select.
“Button Assign” list appears on the lower right of the
display. Each time you press ASSIGN Select,
“Button Assign” list changes as shown below.
1/5 2/5 3/5 4/5 5/5
Function (1)
LEFT-CLICK/ENTER
RIGHT-CLICK/UNDO
Function (2)
• Press ASSIGN Select. After the “Button Assign” list pops up press
LEFT-CLICK/ENTER to view a list of all selections. Refer to the list
of all Button Assign selections below.
3 Press Function (1–4) and select the desired item.
4 Press UNDO. The “Button Assign” list display
disappears.
• The Button Assign function is not recorded on the GyroRemote
itself, it is recorded on the projector side.
Button Assign list
E-34
Operation Buttons
Using GyroRemote
Using the Presentation Tools
This projector is equipped with presentation tools that can be used to emphasize keypoints within your presentation.
You can use these tools by accessing the “Button Assign” list on your GyroRemote. Choose popup list “1/5”. (See
page
33
.)
Button Assign list
Stamp
Each time you press Function (1), stamps can be changed as
shown below.
Line
Each time you press
Function (2)
, lines can be changed as
shown below (straight line, horizontal or vertical line, box, circle,
free line).
Using stamps
1 Press Function (1) repeatedly to select the desired stamp.
• Types of stamps are changed as shown left.
2 Press and hold down GYRO ACTIVE to move the stamp
to the desired position.
3 Release GYRO ACTIVE to set the stamp in the desired
position.
4 Press ENTER to bring up another stamp, then repeat steps
1 to 3 above.
Using lines
1 Press Function (2) repeatedly to select the desired line.
• Types of lines are changed as shown left.
2 Press and hold down GYRO ACTIVE to move the line to
the desired starting position.
3 Release GYRO ACTIVE and press ENTER to set the line
in its starting position.
4 Press and hold down GYRO ACTIVE again and draw the
line by waving the unit around in the air freely.
5 Release GYRO ACTIVE to set the ending point and
complete the line drawing.
6 Press ENTER to bring up another line, then repeat steps
1 to 5 above.
• In steps 2 and 4 above, while holding down GYRO ACTIVE, wave
the unit around in the air with your hand. The stamps and starting
positions of the lines move and the lines are drawn precisely in
concert with your hand movements.
• To change colors, press Function (3) while performing any of the
steps above.
• To erase the item you just placed on the screen, press UNDO.
However, when you are drawing lines with the free line tool, pressing
UNDO will erase all free lines drawn.
Displaying the Break Timer
You can use this tool by accessing the “Button Assign” list on your GyroRemote. Choose popup list “2/5” and press
Function (4). (See page
33
.)
• As soon as Function (4) is pressed, the timer starts to count down from 5 minutes.
• If you press Function (4) again, the Break Timer is canceled.
• You can set the Break Timer from 1 to 60 minutes with ∂/ƒ on the
projector or / on the GyroRemote. The timer starts to count
down as soon as ∂/ƒ or / is pressed.
• The Break Timer is displayed against the background image
selected in “Selecting a Startup Image”. (See page
55
.)
Item Color
Each time you press
Function (3)
, colors can be changed as
shown below.
Red Green Blue Yellow
Black White Purple Light blue
Clear SCRN
When you press
Function (4)
, all items shown on the screen
can be cleared.
• The last item selected before switching off the power is saved as
the default setting.
• A check mark signifies “Stamp”, a straight line is for “Line” and red
is for “Item Color”.
E-35
Operation Buttons
Using GyroRemote
Operating the mouse
Basically operates the same as a standard mouse.
Connecting the projector to the computer
GyroRemote allows you to perform mouse operations on your computer.
1 Connect one end of a USB mouse control cable to your computer.
2 Connect the other end of the cable to the projector USB port.
USB mouse control cable
CAUTION
• Windows 95 does not support USB mouse driver software.
• The minimum system requirements for the USB type mouse system are shown below.
Windows
Hardware: PC/AT compatible machine with USB port
OS: Windows 98/Windows 2000/Windows Me
Macintosh
Hardware: Macintosh series with USB port
OS: Mac OS 8.5 or higher
• If this is the first time connecting the projector to the PC, the PC may need to load standard USB drivers from the operating system. Follow
the on-screen instructions. Some operating systems (Windows 98) may prompt you to insert the original operating system installation CD-
ROM, if the USB driver is not already loaded on the PC.
Using the mouse
You can operate GyroRemote when there is no on-
screen display.
1 Press GYRO ACTIVE on the back of GyroRemote.
While pressing, wave the unit around in the air with
your hand. The mouse cursor responds precisely in
concert with your hand movements.
2 Release your finger from GYRO ACTIVE. The
mouse cursor will stop moving around.
GyroRemote
LEFT-CLICK/
ENTER
RIGHT-CLICK/
UNDO
GYRO ACTIVE
• For left/right mouse clicks, we recommend that you first move
the cursor to the item you want to click on, then release your
finger from GYRO ACTIVE before clicking your target.
• When the projector is connected to a computer by a USB mouse
cable, you can still operate the mouse even if the projector is
unplugged. (However, only when GyroRemote is not connected
to the projector by wired remote control cable.)
E-36
Operation Buttons
Setting up GyroRemote
The projector uses RF channel and TEACH/LEARN settings to recognize individual projectors that may be operating
in the same area, and keep them from interfering with each other. One GyroRemote can operate multiple projectors
or you can even use multiple GyroRemotes to control one projector.
GyroRemote uses radio signals, which can receive interference under certain conditions. To avoid interference,
you can switch RF channels. GyroRemote has 8 channels.
Setting RF channels
Confirming the present RF channel
1 Press RF CHlocated on the front, inside the upper
cover.
2 The current channel in use is displayed on the lower
right of the screen. You can also confirm the RF
channel by the number of times the LED flashes.
(Ex: RF Channel 7 if the LED flashes 7 times.)
Switching RF channels
1 Press RF CH for over 1 sec.
2 Each time you press for over 1 sec. the RF channel
changes as shown below.
3 Each time you change RF channels it is displayed
in the lower right of the screen.
GyroRemote
LED
RF CH
On-screen Display
12345678
• An auto-search is performed on the projector side, so there is no
need for manually adjusting the projector
E-37
Operation Buttons
Setting up GyroRemote
TEACH/LEARN
• Each GyroRemote has its own ID code, which must be recognized by the projector that is going to be used.
• The projector only recognizes the signal of the GyroRemote whose ID code has been input. Signals from other
projectors or GyroRemotes that may be operating in the same area are not allowed to interrupt each other.
Projector GyroRemote
On-screen Display
1 Press LEARN on the projector.
2 While “Do you want to LEARN?” is displaying, press
ENTER. You are now in LEARN mode.
CAUTION
• Entering LEARN mode erases all previously registered
GyroRemotes data. You must re-enter each GyroRemote ID code
in order for the projector to recognize them again.
3 Press TEACH located on the front, inside the upper
cover on the remote within 5 minutes. “Register” will
appear on the display and you can now start using
the GyroRemote with the projector.
4 To exit from the LEARN mode, press LEARN.
TEACH
LEARN
ENTER
Operating multiple projectors with one
GyroRemote
CAUTION
• Be aware that you can operate multiple projectors with one
GyroRemote, even if you are in another room, as long as you stay
within a 98 5 (30 m) range of the projector.
• LEARN mode will exit if the LEARN is pressed or 5 minutes has
elapsed.
1 Set projector to LEARN mode.
2 Press TEACH on the GyroRemote. You can now
operate multiple projectors with one GyroRemote.
3 Perform steps 1 and 2 for each projector you plan to
use.
4 To exit from LEARN mode, press LEARN.
• For setting multiple units in LEARN mode at one time, perform step
1 above for all projectors.
Using multiple GyroRemotes to operate one
projector
One projector can recognize up to 8 GyroRemote ID
codes.
1 Set projector to LEARN mode.
2 Press TEACH on all GyroRemotes being used. Once
the eighth GyroRemote is registered to operate one
projector, the LEARN mode automatically finishes.
You can now operate one projector using multiple
GyroRemotes.
3 To exit from the LEARN mode, press LEARN.
• Contact your nearest Authorized Sharp Industrial LCD Products
Dealer or Service Center if you need to use an additional
GyroRemote unit.
E-38
Operation Buttons
Setting up GyroRemote
Turning off GyroRemote
CAUTION
• Make sure to turn off GyroRemote aboard aircraft or other places where using radio signals is prohibited.
1 Press TEACH and RF CH located inside the upper
cover at the same time, the LED will flash 3 times
and the GyroRemote will turn off.
2 If the LED doesn’t light up after pressing any of the
buttons (except POWER), the GyroRemote power
is turned off.
• Press TEACH and RF CH at the same time or POWER located
inside the upper cover of the GyroRemote to turn the power on.
• When the power is turned off, the GyroRemote is protected from
malfunctioning or battery depletion if control buttons are
inadvertently pressed.
Using as a Wired Remote Control
When the GyroRemote cannot be used due to the range or positioning of the projector (rear projection, etc.),
connect a ø3.5 mm stereo minijack cable (sold separately) from the wired remote control input on the bottom of
the remote control to the WIRED REMOTE control input terminal on the rear of the projector.
ø3.5 mm stereo minijack cable
(sold separately)
ø2.5–ø3.5 mm wired
remote control cable
(supplied)
RF CH+
TEACH
POWER
LED
GyroRemote
Using the GyroRemote with a wired remote control cable
Slide the IR/Gyro switch to the Gyro position.
• To prevent unwanted transmission of radio signals, GyroRemote turns itself off if detached from the ø2.5–ø3.5 mm wired remote control
cable.
• When the cable is inserted into the projector, the projector will not receive radio signals.
Using the IR remote control as a wired remote
You can use the IR remote control by connecting a ø3.5 mm stereo minijack cable (sold separately) from the wired
remote control input on the bottom of the remote control to the WIRED REMOTE control input terminal, a SHARP
product.
Slide the IR/Gyro switch to the IR position.
IR/Gyro switch
• Depending on the IR remote type connected, you may not be able to use certain functions.
E-39
Operation Buttons
Selecting the Input Signal Source
Using the Operation Buttons
Press INPUT again to change the mode.
You can use these tools by accessing the “Button Assign”
list on your GyroRemote. Choose popup list “5/5”. (See
page
33
.)
• When no signal is received, “NO SIGNAL” will be displayed.
When a signal that the projector is not preset to receive is
received, “NOT REG.” will be displayed.
INPUT 1 Mode INPUT 2 Mode INPUT 3 Mode
INPUT 4 Mode INPUT 5 Mode
On-screen Display
Projector GyroRemote
INPUT
Press VOLUME / to adjust the volume.
Adjusting the Volume
On-screen Display
Projector GyroRemote
Muting the Sound
Press MUTE to temporarily turn off the sound.
Press MUTE again to turn the sound back on.
You can use this tool by accessing the “Button Assign”
list on your GyroRemote. Choose popup list “2/5” and
press Function (3). (See page
33
.)
Projector
MUTE
On-screen Display
VOLUME
E-40
Operation Buttons
This function can be used to superimpose a black
screen over the projected image.
Blacking out the Projected Image
Press BLACK SCREEN. The screen turns black and
“BLACK SCREEN” is displayed on the screen. To return
to the original projected image, press BLACK SCREEN
again.
You can use this tool by accessing the “Button Assign”
list on your GyroRemote. Choose popup list “2/5” and
press Function (1). (See page
33
.)
Superimposing a Black Screen
Projector
Projected Image
sg
Displaying a Still Image
This function allows you to instantly freeze a moving
image. This is useful when you want to display a still
image from a computer or video, giving you more time
to explain the image to the audience.
You can also use this function to display a still image
from a computer while you make preparations for the
next computer images to be presented.
You can only use this tool by accessing the “Button
Assign” list on your GyroRemote. Choose popup list “2/
5” and press Function (2). (See page
33
.)
BLACK SCREEN
GyroRemote
Function (2)
1 Press Function (2) to freeze the image.
2 Press Function (2) again to return to the moving
image.
ASSIGN Select
Button Assign list
On-screen Display
E-41
Operation Buttons
Magnifying a Specific Portion of an Image
This function allows you to magnify a specific portion of
an image. This is useful when you want to display a
detailed portion of the image.
You can only use these tools by accessing the “Button
Assign” list on your GyroRemote. Choose popup list “3/
5” and press Function (1) or (2). (See page
33
.)
1 Press Function (2) to zoom in. (Press Function (1)
to zoom out.)
1 4 9 16 36 64
2 To return to 1, press UNDO.
• If you press Function (1) when the zoom is set to 1, no
change will occur. And if you press Function (2) when the
zoom is set to 64, no change will occur.
• If the input signal is changed during digital image
magnification, the image will return to 1. The input signal
is changed
(a) when INPUT is pressed,
(b) when the input signal is interrupted, or
(c) when the input resolution and refresh rate changes.
Pan Around the Screen
Enlarging the screen image and move it around.
You can use this tool by accessing the “Button Assign”
list on your GyroRemote. Choose popup list “3/5” and
press Function (3). (See page
33
.)
1 When the image is magnified, press and hold down
GYRO ACTIVE, and then move the unit in the
direction of the image which you want to see.
2 To exit from the Screen Pan mode, press Function
(3).
• The Screen Pan icon remains on the screen for a few
seconds after the enlargement setting icon disappears. (The
same as when the menu is displayed.)
• Select “Screen Pan” when you want to remove the Screen
Pan icon (exiting this mode).
• You can also pan and scan around the image by using ∂/
ƒ/ß/© on the projector.
Press Function (2)
to zoom in.
Press Function (3).
GyroRemote
Button Assign list
UNDO
Function (2)
Function (1)
Function (3)
ASSIGN Select
GYRO ACTIVE
On-screen Display
4
E-42
Operation Buttons
Adjusting the Picture Aspect Ratio
Projector
RESIZE
UNDO
This function allows you to modify or customize the picture display mode
to enhance the input image. Depending on the input signal, you can
choose NORMAL, FULL, DOT BY DOT, BORDER, STRETCH or SMART
STRETCH image.
1 Press RESIZE. Each time RESIZE is pressed, the picture mode
changes as shown below.
2 To return to the standard image, press UNDO while “RESIZE” is
displayed on the screen.
You can use this tool by accessing the “Button Assign” list on your
GyroRemote. Choose popup list “4/5” and press Function (3). (See page
33
.)
Input Signal
NORMAL FULL
Output screen image
DOT BY DOT
FOR 4:3 aspect ratio
FOR 4:3 aspect ratio
(1024 768)
FOR 5:4 aspect ratio
(1280 1024)
NORMAL
RESIZE
NORMAL
RESIZE
NORMAL
RESIZE
DOT BY DOT
RESIZE
FULL
RESIZE
DOT BY DOT
RESIZE
COMPUTER
EXAMPLE
1024 768
–
800 600
SVGA (800 600)
NORMAL
FULL
DOT BY DOT
For 4:3
aspect ratio
For without
4:3 aspect ratio
1024 768
––
XGA (1024 768)
1024 768
–
1024 768
SXGA (1280 960)
1024 768
–
1024 768
UXGA (1600 1200)
960 768 1024 768 1024 768
SXGA (1280 1024)
VIDEO/DTV
480i
480P
NTSC
PAL
SECAM
720P
1080i
Input Signal
NORMAL BORDER
Output screen image
STRETCH SMART STRETCH
FOR 4:3 aspect ratio
FOR 16:9 aspect ratio
with squeeze
STRETCH
RESIZE
NORMAL
RESIZE
NORMAL
RESIZE
BORDER
RESIZE
BORDER
RESIZE
STRETCH
RESIZE
STRETCH
RESIZE
SMART STRETCH
RESIZE
SMART STRETCH
RESIZE
* The digital image shift function can be used with these picture display modes.
EXAMPLE
1024 768 768 576
NTSC, SECAM, 480i
1024 768 768 576
PAL, 580i
1024 768 768 576
480P
––720P
––
1024 576*
1024 576*
1024 576*
1024 576*
NORMAL BORDER STRETCH
SMART
STRETCH
1024 576*
1024 576*
1024 576*
1024 576*
–
–1080i
For 4:3
aspect ratio
For 16:9
aspect ratio
E-43
Operation Buttons
Gamma Correction Function
On-screen Display
(Example: RGB mode)
sss
STANDARD
PRESENTATION
CINEMA
CUSTOM
Projector
GAMMA
UNDO
• Gamma is an image quality enhancement function
that offers a richer image by brightening the darker
portions of the image without altering the brightness
of the brighter portions.
• Four gamma settings are available to allow for
differences in the images displayed and in the
brightness of the room.
• When you are displaying images with frequent, dark
scenes, such as a film or concert, or when you are
displaying images in a bright room, this feature makes
the dark scenes easier to see and gives the
impression of greater depth in the image.
Gamma Modes
Gamma modeSelected Mode
STANDARD
PRESENTATION
CINEMA
CUSTOM
Standard picture without gamma correction.
Brightens darker portions of image for more
enhanced presentations.
Gives greater depth to darker portions of image
for a more exciting theater experience.
Allows you to adjust gamma value using Sharp
Advanced Presentation Software.
1 Press GAMMA. Each time GAMMA is pressed,
the gamma level toggles as shown on the left.
2 To return to the standard image, press UNDO while
“GAMMA” is displayed on the screen.
You can use this tool by accessing the “Button Assign”
list on your GyroRemote. Choose popup list “4/5” and
press Function (1). (See page
33
).
• The CUSTOM setting of VIDEO mode optimizes the video
source to reproduce the image more beautifully. It darkens
bright portions of the image and gives greater depth to
darker portions of the image.
Select CUSTOM as your default setting if you prefer a
smooth textured image to a sharply contrasted one.
• STANDARD and CINEMA settings of VIDEO mode (except
COMPONENT 480P/720P/1080i) incorporate a DYNAMIC
GAMMA function for optimizing GAMMA correction frame
by frame in real time, thus providing a more beautiful image.
• PRESENTATION settings are the same for both RGB and
VIDEO modes.
E-44
Basic Operation
Using the GUI (Graphical User Interface) Menu Screen
Basic Operations
This projector has two sets of menu screens that allow you to adjust the image and various projector
settings. These menu screens which appear on pages
47
to
62
can be operated from the projector or
the GyroRemote with the following procedure.
1
Press MENU to display the INPUT 1, 2, 3, 4 or 5
mode menu bar.
2 Press ß/© to select an adjustment menu on the
menu bar.
3
Press ∂/ƒ to select a specific adjustment item.
4
To display a single adjustment item, press ENTER
after selecting the item. Only the menu bar and
the selected adjustment item will appear.
5 Press ß/© to adjust the item.
6
Press UNDO to return to the previous screen.
7
To exit from the GUI, press MENU.
• For details on items on the menu screen, see the tree charts on
pages
45
and
46
.
Projector
(GUI) On-screen Display
INPUT 1, 2 (RGB) or 3 (DIGITAL) mode
1
2
3
5
4
2
5
1
2
3
5
INPUT 4, 5 (VIDEO) mode
For operating the GyroRemote, see page
32
.
MENU
∂/ƒ/ß/©
UNDO
ENTER
E-45
Basic Operation
[ON/OFF]
[ON/OFF]
Picture Options (2)
Options (1)
Fine Sync
Audio
Tint 3030
Color 3030
Sharp 3030
Contrast 3030
Bright 3030
Red 3030
Blue
Reset
3030
CLR Temp
Progressive Mode
Signal Type
33
Component
RGB
2D Progressive
3D Progressive
Film Mode
Auto Sync
Clock 150150
150150
Auto Sync Disp
[ON/OFF]
Phase 6060
H-Pos
V-Pos
Reset
Save Setting
Select Setting
Special Modes
6060
Signal Info
1
2
•
•
7
Resolution
800600
640480
1
2
•
•
7
Resolution
Vert Freq
75 Hz
72 Hz
1
2
•
•
7
Resolution
800600
640480
Vert Freq
75 Hz
72 Hz
Resolution
Hor Freq
Vert Freq
Off
Normal
High Speed
640480
37.5 kHz
72 Hz
Economy Mode
OSD Display
Background
[ON/OFF]
Auto Power Off
MNTR Out/RS232C
[ON/OFF]
Startup Image
Treble 3030
Balance 3030
Bass 3030
Reset
Audio Out
Speaker
Pict in Pict
Sharp
Sharp
Custom
Custom
Blue
None
None
Normal
Level A
FAO
VAO
Level B
PRJ Mode
Lamp Timer
Stack Setting
Keylock Level
Set Inputs
RS-232C
Set ID No.
Password
CeilingFront
CeilingRear
Front
Rear
Level B
Input 1
Input 2
Input 3
Input 4
9600bps
115200bps
ID No.
Input 5
38400bps
Old Password
Reconfirm
New Password
Slave
Level A
Master
Normal
Normal
Language
English
Deutsch
Español
Nederlands
Français
Italiano
Svenska
Português
Status
[ON/OFF]
[ON/OFF]
[ON/OFF]
[ON/OFF]
[ON/OFF]
Menu Bars
Items on the INPUT 1, 2 or 3 Mode Menu Bar
Main menu
Sub menu
Main menu
Sub menu
• The resolution, vertical frequency and horizontal
frequency figures displayed above are for example
purposes only.
•“Color”, “Tint”, and “Sharp” appear only when
Component input is selected in INPUT 1 or 2 mode. For
INPUT 3 (DVI), in “Picture” menu, only “CLR Temp” is
active and the other menus are displayed in gray. In “Fine
Sync” menu, only “Signal Info” is active and the other
menus are displayed in gray.
• Only the items highlighted in the tree charts above can
be adjusted.
• To adjust the items under the sub menu, press © after
selecting the sub menu.
E-46
Basic Operation
Menu Bars
Items on the INPUT 4 or 5 Mode Menu Bar
Main menu
Sub menu
Main menu
Sub menu
Picture Options (2)
Audio
Tint 3030
Color 3030
Sharp 3030
Contrast 3030
Bright 3030
Red 3030
Blue
Reset
3030
CLR Temp
Progressive Mode
33
2D Progressive
3D Progressive
FAO
VAO
Audio Out
Speaker
Film Mode
Economy Mode
Background
[ON/OFF]
Auto Power Off
MNTR Out/RS232C
[ON/OFF]
Startup Image
Treble 3030
Balance 3030
Bass 3030
Reset
Sharp
Sharp
Custom
Custom
Blue
None
None
Options (1)
DNR
OSD Display
[ON/OFF]
[ON/OFF]
Video System
Normal
PAL (50/60Hz)
Level A
SECAM
Level B
Auto
NTSC3.58
PAL–M
PAL–N
NTSC4.43
Lamp Timer
PRJ Mode
Stack Setting
Keylock Level
Set Inputs
RS-232C
Set ID No.
Password
CeilingFront
CeilingRear
Front
Rear
Level B
Input 1
Input 2
Input 3
Input 4
Input 5
9600bps
115200bps
ID No.
38400bps
Old Password
Reconfirm
New Password
Slave
Level A
Master
Normal
Normal
Language
English
Deutsch
Español
Nederlands
Français
Italiano
Svenska
Português
Status
[ON/OFF]
[ON/OFF]
[ON/OFF]
[ON/OFF]
[ON/OFF]
• Only the items highlighted in the tree charts above can be adjusted.
• To adjust the items under the sub menu, press © after selecting the sub menu.
E-47
Basic Operation
Adjusting the Picture
You can adjust the projector’s picture to your preferences with the following picture settings. See page
44
for the procedure details.
e. g. RGB input in INPUT 1 or 2 mode
ß button
For less contrast
For less brightness
For less color intensity
Skin tones become purplish
For less sharpness
For weaker red
For weaker blue
For more contrast
For more brightness
For more color intensity
Skin tones become greenish
For more sharpness
For stronger red
For stronger blue
© button
All image adjustment items are returned to the factory preset
settings.
Selected item
Contrast
Bright
Color
Tint
Sharp
Red
Blue
Reset
•“Color”, “Tint” and “Sharp” do not appear for RGB input in INPUT 1 or 2 mode.
• To reset all adjustment items, select “Reset” on the “Picture” menu screen and press ENTER.
• The adjustments can be stored separately in the INPUT 1 to 5 modes.
• Depending on the type of signal received, “Sharp” may not be adjustable for COMPONENT input in INPUT 1 or 2 mode.
Adjusting the Color Temperature
This function can be used to adjust the color temperature to suit the type of image input to the projector
(video, computer image, TV broadcast, etc.). Decrease the color temperature to create warmer, reddish
images for natural flesh tones, or increase to create cooler, bluish images for a brighter picture.
Increases color temperature for
cooler, bluish, florescent-like
images.
(High color temperature)
Decreases color temperature for
warmer, reddish,
incandescent-like images.
(Low color temperature)
3 3
© button (Blue)
Selecting the Signal Type (RGB menu only)
This function allows you to select the input signal type RGB or COMPONENT for INPUT 1 or 2 port.
You can use this tool by accessing the “Button Assign” list on your GyroRemote. Choose popup list “4/5” and press
Function (4). (See page
33
.)
(Red) ß button
E-48
Basic Operation
Adjusting the Picture
Progressive Mode
This function allows you to select the progressive display of a video signal. The progressive display
projects a smoother video image. See page
44
for the procedure details.
Selects the progressive conversion mode.
2D Progressive
This function is useful to display fast-moving images such
as sports and action films. Mode that optimizes the image
in a displayed frame.
3D Progressive
This function is useful to display relatively slow-moving
images such as drama and documentary more clearly.
Mode that optimizes the image by estimating the movement
of a number of preceding and succeeding frames.
Film Mode
Reproduces the image of film software clearly. Displays the
optimized image of film transformed with three-two pull down
enhancement to progressive mode images.
• Film Mode cannot work with PAL 50 Hz.
E-49
Basic Operation
• Computer image adjustments can be made easily by pressing AUTO SYNC ( ). See page
51
for details.
• To reset all adjustment items, select “Reset” on the “Fine Sync” menu screen and press ENTER.
Adjusting the Computer Images (RGB menu only)
When displaying computer patterns which are very detailed (tiling, vertical stripes, etc.), interference
may occur between the LCD pixels, causing flickering, vertical stripes, or contrast irregularities in portions
of the screen. Should this occur, adjust “Clock”, “Phase”, “H-Pos” and “V-Pos” for the optimum computer
image. See page
44
for the procedure details.
Select the desired computer input mode with INPUT 1 or 2.
Clock
Adjusts vertical noise.
Phase
Adjusts horizontal noise (similar to tracking on your VCR).
H-Pos
Centers the on-screen image by moving it to the left or
right.
V-Pos
Centers the on-screen image by moving it up or down.
Saving and Selecting Adjustment Settings
This projector allows you to store up to seven adjustment settings for use with various computers. Once
these settings are stored, they can be easily selected each time you connect a computer to the projector.
Selecting a saved setting
Saving the adjustment setting
• If a memory position has not been set, a resolution and frequency setting will not be displayed.
• When selecting the stored adjustment setting with “Select Setting”, the computer system should match the stored setting.
E-50
Basic Operation
Adjusting the Computer Images (RGB menu only)
Special Mode Adjustment
Ordinarily, the type of input signal is detected and the correct resolution mode is automatically selected.
However, for some signals, the optimal resolution mode in “Special Modes” on the “Fine Sync” menu
screen may need to be selected to match the computer display mode. See page
44
for the procedure
details.
• Avoid displaying computer patterns which repeat every other line (horizontal stripes). (Flickering may occur, making the
image hard to see.)
• When inputting DTV 480P or 1080i signals, select the corresponding type of signal.
Checking the Input Signal
This function allows you to check the current input signal information.
E-51
Basic Operation
Adjusting the Computer Images (RGB menu only)
Auto Sync Adjustment
• Used to automatically adjust a computer image.
• Auto Sync adjustment can be made manually by pressing AUTO SYNC, or automatically by setting
“Auto Sync” to “Normal” or “High Speed” in the projector’s GUI menu. See page
44
for the procedure
details.
You can use this tool by accessing the “Button Assign” list on your GyroRemote. Choose popup list “4/5” and press
Function (2). (See page
33
.)
Off
• Synchronized adjustment is not automatically performed.
• Press AUTO SYNC to perform manual adjustment.
Normal
• Synchronized adjustment is automatically performed the
same as the “High Speed” setting.
• Adjustment using the “Normal” setting takes longer to
perform than using the “High Speed” setting, but it is more
accurate.
High Speed
• The sync adjustment is automatically made each time the
projector is turned on while connected to a computer or
the input selection is changed.
• The Auto Sync adjustment setting previously made is
cleared when the projector’s setting is changed.
• Automatic adjustments can be made by pressing AUTO SYNC.
• When performing AUTO SYNC in Off or High Speed mode, if you press AUTO SYNC once, then press it again within one
minute, AUTO SYNC will be executed in Normal mode.
• Auto Sync adjustment may take some time to complete, depending on the image of the computer connected to the projector.
• When the optimum image cannot be achieved with Auto Sync adjustment, use manual adjustments. (See page
49
.)
Auto Sync Display Function
Normally, an image is not superimposed during Auto Sync adjustment. You can, however, choose to
superimpose a background image during Auto Sync adjustment.
E-52
Basic Operation
Adjusting the Sound
This projector’s audio is factory preset to standard settings. However, you can adjust it to suit your own
preferences by adjusting the following audio settings. See page
44
for the procedure details.
ß buttonSelected item
Increased audio from the right speaker
For stronger treble
For stronger bass
© button
Increased audio from the left speaker
For weaker treble
For weaker bass
Balance
Treble
Bass
Reset
All audio adjustment items are returned to the factory preset settings.
• To reset all adjustment items, select “Reset” on the “Audio” menu screen and press
ENTER.
Audio Out
FAO (Fixed audio output): Audio output that does not vary in strength with
the volume level of the source projector.
VAO (Variable audio output): Audio output that varies in strength with the
volume level of the source projector.
Speaker
Switching the built-in speakers on the projector ON/OFF.
E-53
Basic Operation
Displaying Dual Pictures (RGB menu only)
Picture in Picture function allows you to display two pictures on the same screen. You can display the
image input from INPUT 4 or 5 as an inset picture overlapping the main picture input from INPUT 1, 2 or
3. See page
44
for the procedure details.
You can use this tool by accessing the “Button Assign” list on your GyroRemote. Choose popup list “3/5” and press
Function (4). (See page
33
)
Reducing Image Noise (VIDEO menu only)
Digital Noise Reduction (DNR) provides high quality images with minimal dot crawl and cross color
noise. See page
44
for the procedure details.
• If the image is clear, select “ ” to prevent any blurring.
• The image from INPUT 1, 2 or 3 is displayed as the main picture and the image from INPUT 4 or 5 is displayed as the inset picture.
• The last displayed image from INPUT 4 or 5 is displayed as the inset picture.
For example, when you want to display the image from INPUT 4 as the inset picture, select INPUT 4, then select the main picture, and
then select “Pict in Pict”.
• Inset picture can only be displayed in video signal of NTSC/PAL/SECAM.
• When selecting the image for the inset picture, only the images being input will be displayed.
• The audio of the inset picture will come out of the projector’s speakers.
• Picture in Picture does not work in case of the following RGB signals.
UXGA signal image/Interlaced signal/DTV (480P/720P/1080i)
• You can only use the following functions while in Picture in Picture mode.
FREEZE: Works for the inset picture only.
0
1996 1997 1998 1999
50
100 C
150 B
200 A
250
300
1
Press ß to select “ ” to display an inset picture (Factory preset to INPUT 4).
2
Press ß/©/∂/ƒ to move the inset picture to one of four preset positions.
E-54
Basic Operation
• When the system mode is set to “Auto”, you may not receive a clear picture due to signal differences. Should this occur,
switch to the video system of the source signal.
• AUTO cannot be set for PAL-M and PAL-N input signals. Select “PAL-M” or “PAL-N” in “Video System” menu for PAL-M and
PAL-N input signals.
Setting the Video Signal (VIDEO menu only)
The video input system mode is preset to “Auto”; however, it can be changed to a specific system mode
if the selected system mode is not compatible with the connected audiovisual equipment. See page
44
for the procedure details.
Turning On/Off the On-screen Display
This function allows you to turn on or off the on-screen messages that appear during input select.
See page
44
for the procedure details.
Description
All On-screen Display are displayed.
Input/Custom/Freeze/Enlarge/Auto sync/Volume/Mute/
Black screen functions are not displayed.
All On-screen Display are not displayed (except Menu/
Button assign list/Lens functions and warning display
(Power off/Temp./Lamp function etc.)).
Selected item
Normal
Level A
Level B
E-55
Basic Operation
This function allows you to select the image displayed when no signal is being sent to the projector. See
page
44
for the procedure details.
Selecting a Background Image
Selected item
Sharp
Custom
Blue
None
Description
SHARP default image
User customized image (i.e. company logo)
Blue screen
Black screen
• By selecting “Custom”, the projector can display a custom image (i.e. your company logo) as the background image. The
custom image must be a 256-color BMP file with a picture size no larger than 1,024 768 pixels. Please see the Sharp
Advanced Presentation Software operation manual for how to save (or change) a custom image.
Selecting a Startup Image
This function allows you to specify the image to be displayed upon the projector’s startup.
A custom image (i.e. your company logo) can be uploaded to the projector via an RS-232C cable. See
page
16
in this operation manual, and also the supplied Sharp Advanced Presentation Software
operation manual for detailed instructions. See page
44
for the procedure details.
• By selecting “Custom”, the projector can display a custom image (i.e. your company logo) as the startup image. The custom
image must be a 256-color BMP file with a picture size no larger than 1,024 768 pixels. Please see the Sharp Advanced
Presentation Software operation manual for how to save (or change) a custom image.
Description
SHARP default image
User customized image (i.e. company logo)
Black screen
Selected item
Sharp
Custom
None
E-56
Basic Operation
•“MNTR Out/RS232C” is factory preset to “ ”, and “Auto Power Off” is factory preset to “ ”.
These functions allow you to reduce the power consumption when the projector is in standby mode.
See page
44
for the procedure details.
Monitor Out/RS-232C Off Function
This projector consumes power when using a monitor connected to the OUTPUT port for INPUT 1, 2 and a
computer connected to the RS-232C port. When not using these ports, “MNTR Out/RS232C” can be set to “
”
to reduce standby power consumption.
Selecting the Economy Mode
Standby power for Monitor Out/RS-232C
connection turned off.
Monitor Out/RS-232C on
CAUTION
• Set “MNTR Out/RS232C” to “ ” when using the Sharp Advanced Presentation Software (supplied).
Automatic Power Shutoff Function
When no input signal is detected for more than 15 minutes, the projector will automatically shut off. The on-screen
message, “Power OFF in 5 min.” will appear five minutes before the power is automatically turned off.
Power automatically shuts off after 15 minutes
of no signal input.
Automatic Power Shutoff disabled.
E-57
Basic Operation
Confirming the Lamp Usage Time
This function allows you to check the accumulated lamp usage time. See page
44
for the procedure
details.
Reversing/Inverting Projected Images
This projector is equipped with a reverse/invert image function which allows you to reverse or invert the
projected image for various applications. See page
44
for the procedure details.
Description
Normal image
Inverted image
Reversed image
Reversed and inverted image
Selected item
Front
CeilingFront
Rear
CeilingRear
• This function is used for the reversed image and ceiling-mount setups. See page
29
for these setups.
• It is recommended that the lamp be replaced after approximately 1,000 cumulative hours of use. See pages
68
and
69
for
lamp replacement.
E-58
Basic Operation
Setting the Stacking Mode
You can double the brightness of an image by stacking two projectors and projecting same picture
simultaneously. To control two projectors, assign one as the master and one as the slave. The slave
projector will duplicate any operational settings made to the master projector. See page
44
for the
procedure details.
• When the projector is set to “Master”, button operation signals will be transmitted through RS-232C.
• When the projector is set to “Slave”, operations follow the button operations sent from the “Master”.
• When set to slave, all buttons on the projector along with ENTER, UNDO, POWER, LENS and MENU on the GyroRemote
can be used. The slave cannot operate the other buttons on GyroRemote.
• For details on intended purpose, see pages
65
and
66
.
Locking the Operation Buttons on the Projector
This function can be used to lock the use of certain operation buttons on the projector. The user can still
operate the projector fully with the GyroRemote. See page
44
for the procedure details.
Description
All operation buttons are functional.
Only Input/Volume/Mute functions on the
projector are available.
All operation buttons on the projector are
unavailable.
Selected item
Normal
Level A
Level B
• To cancel the Keylock Level, perform the above procedure using the GyroRemote.
• See page
61
for details using the password function.
E-59
Basic Operation
Deselecting Inputs
This function allows you to deselect unwanted signal input. See page
44
for the procedure details.
• When stack projecting, multi-screen projecting and so on, this function can be used to cancel the RS-232C control.
• Up to two input signals can be blocked for both Input 1, 2, 3 or Input 4, 5.
• For details on intended purpose, see pages
65
and
66
.
Selecting the Transmission Speed (RS-232C)
This menu allows you to adjust the transmission speed of the RS-232C connection by selecting the
baud rate. See page
44
for the procedure details.
• Make sure that both the projector and computer are set for the same baud rate. Refer to the computer’s operation manual
for instructions for setting the baud rate.
E-60
Basic Operation
Controling Multiple Projectors with ID Numbers
This projector can form a network of up to 250 projectors. To identify separately and control specified
projector, you need to set ID No.. The ID No. is factory preset to “001”. See page
44
for the procedure
details.
Setting the ID No.
Press © to select the first digit and ∂/ƒ to select the desired number. Continue this procedure for the remaining
two digits.
• Be sure to set the ID No. in the Option menu and attach a corresponding number seal to the projector.
• The ID No. can be set from 001 to 250.
• For details on intended purpose, see pages
63
to
66
.
E-61
Basic Operation
Protecting Important Settings with a Password
A password can be set by the user and used with the keylock level to prevent adjustments to certain
settings on the GUI. See page
44
for the procedure details.
• When password is set, you need to enter the password to use “PRJ Mode”, “Stack Setting”, “Keylock Level”, “Set Inputs”,
“RS-232C” and “Set ID No.” menus.
Setting the Password
1 Enter the new password using ∂/ƒ to select the desired number, and then press © to select the next digit.
Continue this procedure for the remaining three digits, and then press ENTER.
2 Enter the password again (“Reconfirm”) using ∂/ƒ/ß/©, and then press ENTER.
• After setting the password, be sure to write it down in a secure location in case you can not remember it.
Changing the Password
1 Enter the old password using ∂/ƒ/ß/©, and then press ENTER.
2 Enter the new password using ∂/ƒ/ß/©, and then press ENTER.
3 Enter the password again (“Reconfirm”) using ∂/ƒ/ß/©, and then press ENTER.
E-62
Basic Operation
Selecting the On-screen Display Language
English is the preset language for the On-screen Display; however, this can be changed to German,
Spanish, Dutch, French, Italian, Swedish, Portuguese, Chinese, Korean or Japanese. See page
44
for
the procedure details.
Displaying the Adjustment Settings
This function can be used to display all the adjusted settings on the screen simultaneously. See page
44
for the procedure details.
INPUT 1, 2 (RGB) or 3 (DIGITAL) mode INPUT 4, 5 (VIDEO) mode
E-63
Multiple Function
Using Extended Functionality Features
This projector has outstanding network capability.
• Internet access for self-diagnosis
• Multiple and group projector control
• Simultaneous multiple projector control
Internet access for self-diagnosis, status information and preventive
maintenance
This projector can be used in a network of up to 250 projectors managed from a single PC with the accompanied
Sharp Advanced Presentation Software—Professional Edition. This projector can be connected to a PC using an
RS-232C connection. Output terminals are provided (RS-232C on the projector) enabling a daisy chain configuration
and eliminating the need for a distributor.
This projector is also equipped with a function to send status information (lamp usage time, etc.) to a Sharp
Service Center or outside contractor for quick and efficient customer service.
• For more information on these features, see the operation manuals accompanying the Sharp Advanced Presentation Software—
Professional Edition and optional boards.
Internet
LAN
LANLAN
E-mail E-mail
E-64
Multiple Function
This projector can be used in a network of projectors managed from a single PC with the accompanied Sharp
Advanced Presentation Software—Professional Edition. Projectors in conference rooms on the first and third floors
of a building, for example, can be used for video presentations, while projectors on the second floor can be used
for PC-assisted presentations. Projectors can even be powered down at different times (e.g., projectors on the first
and second floors are powered down in one hour, while those on the third floor are powered down in two hours).
• For more information on these features, see the operation manuals accompanying the Sharp Advanced Presentation Software—
Professional Edition.
• Transmission performance of the RS-232C cable can vary depending on the surrounding conditions. Use the transmission
repeater if performance is not up to par.
• We recommend you use an RS-232C cable not longer than 49 3 (15 m).
Multiple and group projector control via computer
Building
RS-232C
RS-232C
RS-232C
RS-232C
RS-232C
Control PC
Sharp Advanced
Presentation Software
“Professional Edition”
3rd Floor
2nd Floor
1st Floor
Video
Source 1
Video
Source 2
(RS-232C) Specifications and Command SettingsUsing Extended Functionality Features
E-65
Multiple Function
Simultaneous multiple projector control for stacking and videowall
projection
INPUT1
INPUT2
INPUT4
INPUT5
OUTPUT
Master
INPUT1
Distributor
INPUT2
INPUT4
INPUT5
OUTPUT
Slave
DVD
Laser Disc
RS-232C OUTRS-232C IN
RS-232C OUTRS-232C IN
Stack Setting
Master
Stack Setting
Slave
Set Inputs
INPUT1
INPUT2
INPUT3
INPUT4
INPUT5
Yes
Yes
No
Yes
Yes
Set Inputs
Yes
No
No
Yes
Yes
INPUT1
INPUT2
INPUT3
INPUT4
INPUT5
For brighter images, two projectors can be stacked using the Stack Setting function, with one projector set as the
Master and the other as the Slave. The operations of the Slave projector are controlled by the Master projector
during projection through an RS-232C connection. The RS-232C cable (null modem, cross type, sold separately)
is connected from the RS-232C output on the Master projector to the RS-232C input on the Slave projector.
Projectors can be stacked using an RS-232C cable (null modem, cross type, sold separately).
• See page
58
, “Setting the Stacking Mode”, and page
59
, “Deselecting Inputs”.
Stack Projection
Using Extended Functionality Features
E-66
Multiple Function
Videowall
INPUT1
INPUT2
INPUT4
INPUT5
OUTPUT
Master
RS-232C OUT
INPUT1
Control PC
Sharp Advanced
Presentation Software
“Professional Edition”
VIDEO
SOURCE
RGB
SOURCE2
RGB
SOURCE1
INPUT2
INPUT4
INPUT5
OUTPUT
Slave
RS-232C IN
RS-232C OUTRS-232C IN
DVD
001
002
INPUT1
INPUT2
INPUT4
INPUT5
OUTPUT
Slave
INPUT1
INPUT2
INPUT4
INPUT5
OUTPUT
Slave
003
004
RS-232C OUTRS-232C IN
RS-232C OUTRS-232C IN
Distributor
Master
Set Inputs
Yes
Yes
No
Yes
Yes
INPUT1
INPUT2
INPUT3
INPUT4
INPUT5
Slave
Set Inputs
Yes
No
No
Yes
No
INPUT1
INPUT2
INPUT3
INPUT4
INPUT5
This projector can be used together with other projectors managed using the accompanied Sharp Advanced
Presentation Software—Professional Edition to create a videowall projection. Whereas conventional videowall
technology required the use of an image distributor, this projector videowall feature enables easy image settings
from a PC when inputting a single video source. This function greatly simplifies videowall setup.
RS-232C OUTPUTS also realize the simple daisy chain connection. The master projector directly connected to the
computer can make the daisy chain connection with multiple slave projectors. For details on setting master or
slave, see page
58
.
• Use a videowall projector stand, sold separately, when using this function.
• Image quality may deteriorate when picture signals are input through multiple projectors in a daisy chain
connection.
• For more information on this feature, see the operation manuals accompanying the Sharp Advanced Presentation Software—
Professional Edition.
• When UXGA signal is displayed, the videowall can not be set by Sharp Advanced Presentation Software—Professional
Edition.
Using Extended Functionality Features
E-67
Maintenance &
Troubleshooting
Lamp/Maintenance Indicators
Maintenance Indicators
TEMPERATURE
WARNING
indicator
LAMP
REPLACEMENT
indicator
POWER
indicator
Problem
• Blocked air intake.
• Clogged air filter.
• Cooling fan breakdown.
• Internal circuit failure.
• Burnt-out lamp.
• Lamp circuit failure.
• The filter cover is open.
Maintenance Indicator
The internal
temperature is
abnormally high.
TEMPERATURE
WARNING indicator
LAMP REPLACE-
MENT indicator
POWER indicator
The lamp does not
light up.
The POWER
indicator flashes in
red when the
projector is on.
Condition Possible Solution
• Relocate the projector to an area with
proper ventilation.
• Replace the filter.
(See page
70
.)
• Take the projector to your nearest
Authorized Sharp Industrial LCD Products
Dealer or Service Center for repair.
• Carefully replace the lamp. (See pages
68
and
69
.)
• Take the projector to your nearest
Authorized Sharp Industrial LCD Products
Dealer or Service Center for repair.
• Securely install the filter cover.
• The warning lights on the projector indicate problems
inside the projector.
• There are two warning lights: a TEMPERATURE
WARNING indicator which warns that the projector is
too hot, and a LAMP REPLACEMENT indicator which
lets you know when to change the lamp.
• If a problem occurs, either the TEMPERATURE
WARNING indicator or the LAMP REPLACEMENT
indicator will light up red. After turning off the power,
follow the procedures given below.
• If the TEMPERATURE WARNING indicator lights up, follow the above possible solutions and then wait until the projector has
cooled down completely before turning the power back on. (At least 5 minutes.)
• If the power is turned off and then turned on again, as during a brief rest, the LAMP REPLACEMENT indicator may be
triggered, preventing the power from going on. Should this occur, take the power cord out of the wall outlet and put it back
in again.
Lamp
It is recommended that the lamp be replaced after approximately 1,000 cumulative hours of use or when you
notice a significant deterioration of the picture and color quality. The lamp usage time can be checked with the
On-screen Display. (As the usage environment can vary significantly, the projector lamp may not operate for 1,000
hours.)
CAUTION
• Intense light hazard. Do not attempt to look into the aperture and lens while the projector is operating.
E-68
Maintenance &
Troubleshooting
46
Remove the air filter.
5
Replace the air filter.
1 3
Turn off the power.
2
Disconnect the power
cord.
Unplug the power cord from the
AC socket.
Remove the bottom
filter cover.
Replace the filter
cover.
Insert the tab on the end of the
filter cover into the filter cover
opening and press the filter
cover into position.
Grasp the air filter between your
fingers and lift it out of the filter
cover.
Turn over the projector. Press the
tab and lift open the filter cover
in the direction of the arrow.
Press POWER OFF. Wait until
the cooling fan stops.
Push the antenna completely
down to its resting position.
Place the air filter underneath the
tabs on the filter frame.
Replacing the Lamp
• Be sure to remove the lamp cage by the handle. Be sure not to touch the glass surface of the lamp cage or the inside of
the projector.
• To avoid injury to yourself and damage to the lamp, be sure to carefully follow the steps below.
• Be sure to change the air filter during lamp replacement. The air filter comes packaged with the lamp unit.
Removing and installing the lamp unit
CAUTION
It is recommended that the lamp be replaced after approximately 1,000 cumulative hours of use or when you
notice a significant deterioration of the picture and color quality. Carefully change the lamp by following the steps
below.
If the new lamp does not light after replacement, take your projector to the nearest Authorized Sharp Industrial
LCD Products Dealer or Service Center for repair. Purchase a replacement lamp unit (lamp/cage module) of the
current type BQC-XGP20X//1 from your nearest Authorized Sharp Industrial LCD Products Dealer or Service Center.
Then carefully change the lamp by following the instructions below. If you wish, you may have the lamp replaced
at your nearest Authorized Sharp Industrial LCD Products Dealer or Service Center.
IMPORTANT NOTE TO U.S. CUSTOMERS:
The lamp included with this projector is backed by a 90-day parts and labor limited warranty. All service of this
projector under warranty, including lamp replacement, must be obtained through an Authorized Sharp Industrial LCD
Products Dealer or Service Center. For the name of the nearest Authorized Sharp Industrial LCD Products Dealer or
Service Center, please call toll-free: 1-888-GO-SHARP (1-888-467-4277).
U.S.A. ONLY
CAUTION
• Potential hazard of glass particles if lamp ruptures. In case of lamp rupture, contact your nearest
Authorized Sharp Industrial LCD Products Dealer or Service Center for a replacement.
• Do not remove the lamp cage directly after operation of the projector. The lamp may be extremely
hot. Wait at least one hour after the power cord is disconnected to allow the surface of the lamp cage
to fully cool before removing the lamp cage.
Tab
Tab
E-69
Maintenance &
Troubleshooting
Replacing the Lamp
10
Attach the lamp cage
cover.
79
Remove the lamp cage
cover.
8
Remove the lamp
cage.
Remove the securing screws
from the lamp cage. Hold the
lamp cage by the handle and
pull it towards you.
Insert the new lamp cage.
Slide the lamp cage cover in
the direction of the arrow. Then
tighten the user service screw.
Press the lamp cage firmly into
the lamp cage compartment.
Fasten the securing screws.
Turn over the projector and
loosen the user service screw
that secures the lamp cage
cover. Then slide the cover in
the direction of the arrow.
User service screw
Securing
screw
Securing
screws
1
Connect the power
cord.
Reset the lamp timer.
While pressing ƒ, © and
ENTER on the projector, press
POWER ON on the projector.
Plug the power cord into the AC
socket of the projector.
Resetting the lamp timer
“LAMP 0000H” is displayed,
indicating that the lamp timer is
reset.
2
• Reset the lamp timer only after replacing the lamp.
User service screw
E-70
Maintenance &
Troubleshooting
• This projector is equipped with two air filters to ensure the optimal operating condition of the projector.
• The air filters should be cleaned every 100 hours of use. Clean the filters more often when the projector is used
in a dusty or smoky location.
• Have your nearest Authorized Sharp Industrial LCD Products Dealer or Service Center exchange the filter
(PFILD0080CEZZ) when it is no longer possible to clean it.
Replacing the Air Filter
46
Clean the air filter.
5
Replace the air filter.
1 3
Turn off the power and
disconnect the power
cord.
2
Remove the bottom
filter cover.
Grasp the air filter between your
fingers and lift it out of the filter
cover.
Turn over the projector. Press the
tab and lift open the filter cover
in the direction of the arrow.
Remove the air filter.
Insert the tab on the end of the
filter cover into the filter cover
opening and press the filter
cover into position.
Place the air filter underneath
the tabs on the filter frame.
Clean the dust off the air filter
and cover with a vacuum
cleaner extension hose.
Cleaning and replacing the bottom air filter
• Be sure the filter cover is securely installed. The power will not turn on unless it is correctly installed.
Cleaning the side air filter (not removable)
If dust or dirt has collected inside the air filter, clean the filter with a vacuum cleaner extension hose.
Replace the filter
cover.
• The side air filter cannot be removed.
Bottom View
Side and Rear View
Air filter
Air filter (not removable)
Tab
Tab
Press POWER OFF. Wait until
the cooling fan stops.
Push the antenna completely
down to its resting position.
E-71
Maintenance &
Troubleshooting
Troubleshooting
Check
• Keylock level is set to “Level A” or “Level B”, preventing operation of some or all
buttons. (See page
58
.)
• Register GyroRemote once again the projector. (See page
37
.)
• When the GyroRemote is connected to the projector with wired remote control cable,
confirm the position of the IR/Gyro switch. (See page
38
.)
• When the projector is set to slave, use the buttons on the master projector or change the
setting by RS-232C commands from the computer. (See page
58
.)
• When using slave setting in combination with Keylock Level B, all the buttons on the
projector and the GyroRemote are disabled. Use the SAPS or RS-232C commands to
release slave and Keylock setting and enable buttons to operate.
Without a computer, you can release slave and Keylock setting by entering the buttons
on the projector as follows.
ON
→
ENTER
→
ON
→
ENTER
→
ON
→
ENTER
→
MENU
However, this operation also releases the password set.
• Projector power cord is not plugged into the wall outlet.
• The bottom filter cover is not securely installed.
• Selected input is wrong. (See page
39
.)
• Cables incorrectly connected to rear panel of the projector. (See pages
13
–
18
.)
• GyroRemote batteries have run down. (See page
11
.)
• Cables incorrectly connected to rear panel of the projector. (See pages
13
–
18
.)
•“Contrast” and “Bright” adjustments are set to minimum position. (See page
47
.)
• On-screen Display (“BLACK SCREEN”) is turned off and Black Screen function is turned
on, creating a black image. (See page
40
.)
•“Color” and “Tint” adjustments are not correct. (See page
47
.)
• Adjust the focus. (See page
21
.)
• Projection distance is too long or too short to allow for proper focus. (See pages
22
–
28
.)
• Cables incorrectly connected to rear panel of the projector. (See pages
13
–
18
.)
• Volume is set to minimum. (See page
39
.)
• OSD Display is set to “Level A” or “Level B”, preventing to display some or all On-screen
Displays. (See page
54
.)
• If the picture is normal, the sound is due to cabinet shrinkage caused by temperature
changes. This will not affect operation or performance.
• Refer to “Lamp/Maintenance Indicators” on page
67
.
• Adjust the “Phase” setting. (See page
49
.)
• Noise may appear when used with certain computers. Set the NOISE FILTER to ON
using the RS-232C command. (See pages
73
–
75
.)
• Set the resolution mode to 480P. (See page
50
.)
• Change the input signal type. (See page
47
.)
• Align the mark on the lens with the corresponding mark on the projector, push the lens
firmly in place, and rotate to the right.
For SHARP Assistance (U.S.A. only)
If you encounter any problems during setup or operation of this projector, first refer to the “Troubleshooting”
section on this page. If this operation manual does not answer your question, please call toll free 1-888-GO-
SHARP (1-888-467-4277) for further assistance. Or, send us an e-mail at [email protected] .
Our World Wide Web address is http://www.sharplcd.com .
Problem
Power cannot be turned on or
off using the POWER buttons
(ON/OFF) on the projector.
Cannot be operated by
GyroRemote.
Cannot be operated by all
buttons of the projector and
GyroRemote.
No picture and no sound.
Sound is heard but no picture
appears.
Color is faded or poor.
Picture is blurred.
Picture appears but no sound
is heard.
No OSD appears.
An unusual sound is occasion-
ally heard from the cabinet.
Maintenance indicator lights
up.
Picture noise appears.
480P images do not appear.
Image is green on INPUT 1 or
2 COMPONENT.
Image is pink (no green) on
INPUT 1, 2 RGB.
Lens comes off.
E-72
Appendix
Connecting Pin Assignments
RGB Input
Analog
1. Video input (red)
2. Video input
(green/sync on green)
3. Video input (blue)
4. Reserve input 1
5. Composite sync
6. Earth (red)
7. Earth (green/sync on green)
8. Earth (blue)
9. Not connected
10. GND
11. GND
12. Bi-directional data
13. Horizontal sync signal
14. Vertical sync signal
15. Data clock
RS-232C Port: 9-pin D-sub male connector of the DIN-D-sub RS-232C cable
5
10
15
1
6
11
Pin No. Signal Name I/O Reference
1 CD Not connected
2 RD Receive Data Input Connected to internal circuit
3 SD Send Data Output Connected to internal circuit
4 ER Not connected
5 SG Signal Ground Connected to internal circuit
6 DR Data Set Ready Output Not connected
7 RS Request to Send Output Connected to internal circuit
8 CS Clear to Send Input Connected to internal circuit
9 CI Not connected
15
69
INPUT 3 DVI Port: 29-pin
91 816
C1C2
C32417 C4
C5
Pin No. Name
1 T.M.D.S. Data 2
2 T.M.D.S. Data 2
3 T.M.D.S. Data 2/4 Shield
4 T.M.D.S. Data 4*
3
5 T.M.D.S. Data 4*
3
6 DDC Clock
7 DDC Data
8 Analog Vertical Sync
9 T.M.D.S. Data 1
10 T.M.D.S. Data 1
11 T.M.D.S. Data 1/3 Shield
12 T.M.D.S. Data 3*
3
13 T.M.D.S. Data 3*
3
14 5 V Power
15 Ground*
1
16 Hot Plug Detect
17 T.M.D.S. Data 0
18 T.M.D.S. Data 0
19 T.M.D.S. Data 0/5 Shield
20 T.M.D.S. Data 5*
3
21 T.M.D.S. Data 5*
3
22 T.M.D.S. Clock Shield
23 T.M.D.S. Clock
24 T.M.D.S. Clock
C1 Analog Red
C2 Analog Green
C3 Analog Blue
C4 Analog Horizontal sync
C5 Analog Ground*
2
• *
1
Return for 5 V, Hsync. and Vsync.
• *
2
Analog R, G and B return
• *
3
These pins are not used on this equipment.
Component Input
Analog
1. P
R (CR)
2. Y
3. P
B (CB)
4. Not connected
5. Not connected
6. Earth (P
R)
7. Earth (Y)
8. Earth (P
B)
9. Not connected
10. Not connected
11. Not connected
12. Not connected
13. Not connected
14. Not connected
15. Not connected
INPUT 1 RGB and OUTPUT (INPUT 1, 2) Signal Ports: 15-pin Mini D-sub female connector
E-73
Appendix
CONTROL CONTENTS
POWER ON
POWER OFF
VOLUME (0 – 60)
MUTE ON
MUTE OFF
LENS FOCUS (30 – 30)
LENS ZOOM (30 – 30)
KEYSTONE (127 – 127)
V-SIZE (30 – 30)
DIGITAL SHIFT (96 – 96)
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
P
P
V
M
M
L
L
K
V
L
O
O
O
U
U
N
N
E
S
N
W
W
L
T
T
F
Z
Y
I
D
R
R
A
E
E
O
O
S
Z
S
_
_
_
_
_
_
_
*
_
_
_
_
_
_
_
*
*
*
_
*
_
_
*
_
_
*
*
*
*
*
1
0
*
1
0
*
*
*
*
*
BUTTONS & REMOTE CONTROL KEY
COMMAND
PARAMETER
RETURN
(RS-232C) Specifications and Command Settings
Return code (0DH)
C1 C2 C3 C4 P1 P2 P3 P4
Response code format
Normal response
O K
Return code (0DH)
Problem response (communication error or incorrect command)
E R R
Return code (0DH)
Command 4-digit Parameter 4-digit
Command format
When more than one code is being sent, send each command only after the OK response code for the previous
command from the projector is verified.
• When using the computer control function of the projector, the projector operating status cannot be read to the computer.
Therefore, confirm the status by transmitting the display commands for each adjustment menu and checking the status with
the On-screen Display. If the projector receives a command other than a menu display command, it will execute the com-
mand without displaying the On-screen Display.
Commands
EXAMPLE
• When “BRIGHT” of INPUT 1 (RGB 1) image adjustment is set to 10.
→
←
RABR 1 0_ OK
ProjectorComputer
CONTROL CONTENTS
BLACK SCREEN ON
BLACK SCREEN OFF
INPUT 1 (RGB 1)
INPUT 2 (RGB 2)
INPUT 3 (RGB 3)
INPUT 4 (VIDEO 1)
INPUT 5 (VIDEO 2)
INPUT CHECK
FREEZE ON
FREEZE OFF
AUTO SYNC START
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
I
I
I
I
I
I
I
I
F
F
A
M
M
R
R
R
V
V
C
R
R
D
B
B
G
G
G
E
E
H
E
E
J
K
K
B
B
B
D
D
K
Z
Z
S
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
1
0
1
2
3
1
2
0
1
0
1
BUTTONS & REMOTE CONTROL KEY
COMMAND
PARAMETER
RETURN
PC control
A computer can be used to control the projector by connecting an RS-232C cable (null modem, cross type, sold
separately) to the projector. (See page
16
for connection.)
Communication conditions
Set the serial port settings of the computer to match that of the table.
Signal format: Conforms to RS-232C standard.
Baud rate: 9,600 bps
Data length: 8 bits
Parity bit: None
Stop bit: 1 bit
Flow control: None
Basic format
Commands from the computer are sent in the following order: command, parameter, and return code. After the
projector processes the command from the computer, it sends a response code to the computer.
E-74
Appendix
(RS-232C) Specifications and Command Settings
CONTROL CONTENTS
INPUT 1 (RGB 1) SIGNAL TYPE : RGB
INPUT 1 (RGB 1) SIGNAL TYPE : COMPONENT
INPUT 2 (RGB 2) SIGNAL TYPE : RGB
INPUT 2 (RGB 2) SIGNAL TYPE : COMPONENT
INPUT 1 (RGB 1) 2D PROGRESSIVE
INPUT 1 (RGB 1) 3D PROGRESSIVE
INPUT 1 (RGB 1) Film MODE
INPUT 2 (RGB 2) 2D PROGRESSIVE
INPUT 2 (RGB 2) 3D PROGRESSIVE
INPUT 2 (RGB 2) Film MODE
INPUT 3 (RGB 3) 2D PROGRESSIVE
INPUT 3 (RGB 3) 3D PROGRESSIVE
INPUT 3 (RGB 3) Film MODE
INPUT 4 (VIDEO 1) CONTRAST (30 – 30)
INPUT 4 (VIDEO 1) BRIGHT (30 – 30)
INPUT 4 (VIDEO 1) RED (30 – 30)
INPUT 4 (VIDEO 1) BLUE (30 – 30)
INPUT 4 (VIDEO 1) COLOR (30 – 30)
INPUT 4 (VIDEO 1) TINT (30 – 30)
INPUT 4 (VIDEO 1) SHARP (30 – 30)
INPUT 4 (VIDEO 1) CLR TEMP (3 – 3)
INPUT 4 (VIDEO 1) DISPLAY
INPUT 4 (VIDEO 1) ADJUSTMENT RESET
INPUT 5 (VIDEO 2) CONTRAST (30 – 30)
INPUT 5 (VIDEO 2) BRIGHT (30 – 30)
INPUT 5 (VIDEO 2) RED (30 – 30)
INPUT 5 (VIDEO 2) BLUE (30 – 30)
INPUT 5 (VIDEO 2) COLOR (30 – 30)
INPUT 5 (VIDEO 2) TINT (30 – 30)
INPUT 5 (VIDEO 2) SHARP (30 – 30)
INPUT 5 (VIDEO 2) CLR TEMP (3 – 3)
INPUT 5 (VIDEO 2) DISPLAY
INPUT 5 (VIDEO 2) ADJUSTMENT RESET
INPUT 4 (VIDEO 1) 2D PROGRESSIVE
INPUT 4 (VIDEO 1) 3D PROGRESSIVE
INPUT 4 (VIDEO 1) Film MODE
INPUT 5 (VIDEO 2) 2D PROGRESSIVE
INPUT 5 (VIDEO 2) 3D PROGRESSIVE
INPUT 5 (VIDEO 2) Film MODE
(INPUT 1–5) 2D PROGRESSIVE
(INPUT 1–5) 3D PROGRESSIVE
(INPUT 1–5) Film MODE
CLOCK (150 – 150)
PHASE (60 – 60)
H-POSITION (150 – 150)
V-POSITION (60 – 60)
RGB INPUT DISPLAY
RGB ADJUSTMENT RESET
SAVE SETTING (1 – 7)
SELECT SETTING (1 – 7)
RGB HORIZONTAL FREQUENCY CHECK
RGB VERTICAL FREQUENCY CHECK
AUTO SYNC OFF
NORMAL AUTO SYNC
HIGH SPEED AUTO SYNC
AUTO SYNC DISPLAY ON
AUTO SYNC DISPLAY OFF
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
kHz (***. * OR _)
Hz (***. * OR _)
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
I
I
I
I
R
R
R
R
R
R
R
R
R
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
I
I
I
I
I
I
I
I
I
M
M
T
T
A
A
A
I
I
A
A
B
B
A
A
A
B
B
B
C
C
C
A
A
A
A
A
A
A
A
A
A
B
B
B
B
B
B
B
B
B
B
A
A
A
B
B
B
M
M
M
N
N
A
A
A
A
E
E
F
F
A
A
A
M
M
S
S
S
S
I
I
I
I
I
I
I
I
I
P
B
R
B
C
T
S
C
R
R
P
B
R
B
C
T
S
C
R
R
I
I
I
I
I
I
I
I
I
C
P
H
V
R
R
M
M
R
R
D
D
D
A
A
I
I
I
I
P
P
P
P
P
P
P
P
P
I
R
D
E
O
I
H
T
E
E
I
R
D
E
O
I
H
T
E
E
P
P
P
P
P
P
P
P
P
L
H
P
P
E
E
S
L
Q
Q
J
J
J
S
S
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
*
_
*
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
*
*
*
*
*
*
*
_
_
_
*
*
*
*
*
*
*
_
_
_
_
_
_
_
_
_
_
_
_
*
*
*
*
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
*
*
*
*
*
*
*
*
_
_
*
*
*
*
*
*
*
*
_
_
_
_
_
_
_
_
_
_
_
*
*
*
*
_
_
_
_
_
_
_
_
_
_
_
0
1
0
1
0
1
2
0
1
2
0
1
2
*
*
*
*
*
*
*
*
0
1
*
*
*
*
*
*
*
*
0
1
0
1
2
0
1
2
0
1
2
*
*
*
*
0
1
*
*
1
2
0
1
2
1
0
PICTUREFINE SYNC
*1
COMMAND
PARAMETER
RETURN
CONTROL CONTENTS
INPUT 1 (RGB 1) RESIZE : NORMAL
INPUT 1 (RGB 1) RESIZE : FULL
INPUT 1 (RGB 1) RESIZE : DOT BY DOT
INPUT 2 (RGB 2) RESIZE : NORMAL
INPUT 2 (RGB 2) RESIZE : FULL
INPUT 2 (RGB 2) RESIZE : DOT BY DOT
INPUT 3 (RGB 3) RESIZE : NORMAL
INPUT 3 (RGB 3) RESIZE : FULL
INPUT 3 (RGB 3) RESIZE : DOT BY DOT
INPUT 4 (VIDEO 1) RESIZE : NORMAL
INPUT 4 (VIDEO 1) RESIZE : FULL
INPUT 4 (VIDEO 1) RESIZE : BORDER
INPUT 4 (VIDEO 1) RESIZE : STRETCH
INPUT 4 (VIDEO 1) RESIZE : SMART STRETCH
INPUT 5 (VIDEO 2) RESIZE : NORMAL
INPUT 5 (VIDEO 2) RESIZE : FULL
INPUT 5 (VIDEO 2) RESIZE : BORDER
INPUT 5 (VIDEO 2) RESIZE : STRETCH
INPUT 5 (VIDEO 2) RESIZE : SMART STRETCH
RGB GAMMA : STANDARD
RGB GAMMA : PRESENTATION
RGB GAMMA : CINEMA
RGB GAMMA : CUSTOM
VIDEO GAMMA : STANDARD
VIDEO GAMMA : PRESENTATION
VIDEO GAMMA : CINEMA
VIDEO GAMMA : CUSTOM
INPUT 1 (RGB 1) CONTRAST (30 – 30)
INPUT 1 (RGB 1) BRIGHT (30 – 30)
INPUT 1 (RGB 1) RED (30 – 30)
INPUT 1 (RGB 1) BLUE (30 – 30)
INPUT 1 (RGB 1) COLOR (30 – 30)
INPUT 1 (RGB 1) TINT (30 – 30)
INPUT 1 (RGB 1) SHARP (30 – 30)
INPUT 1 (RGB 1) CLR TEMP (3 – 3)
INPUT 1 (RGB 1) DISPLAY
INPUT 1 (RGB 1) ADJUSTMENT RESET
INPUT 2 (RGB 2) CONTRAST (30 – 30)
INPUT 2 (RGB 2) BRIGHT (30 – 30)
INPUT 2 (RGB 2) RED (30 – 30)
INPUT 2 (RGB 2) BLUE (30 – 30)
INPUT 2 (RGB 2) COLOR (30 – 30)
INPUT 2 (RGB 2) TINT (30 – 30)
INPUT 2 (RGB 2) SHARP (30 – 30)
INPUT 2 (RGB 2) CLR TEMP (3 – 3)
INPUT 2 (RGB 2) DISPLAY
INPUT 2 (RGB 2) ADJUSTMENT RESET
INPUT 3 (RGB 3) CONTRAST (30 – 30)
INPUT 3 (RGB 3) BRIGHT (30 – 30)
INPUT 3 (RGB 3) RED (30 – 30)
INPUT 3 (RGB 3) BLUE (30 – 30)
INPUT 3 (RGB 3) COLOR (30 – 30)
INPUT 3 (RGB 3) TINT (30 – 30)
INPUT 3 (RGB 3) SHARP (30 – 30)
INPUT 3 (RGB 3) CLR TEMP (3 – 3)
INPUT 3 (RGB 3) DISPLAY
INPUT 3 (RGB 3) ADJUSTMENT RESET
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
G
G
G
G
G
G
G
G
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
A
A
A
B
B
B
C
C
C
A
A
A
A
A
B
B
B
B
B
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
B
B
B
B
B
B
B
B
B
B
C
C
C
C
C
C
C
C
C
C
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
M
M
M
M
M
M
M
M
P
B
R
B
C
T
S
C
R
R
P
B
R
B
C
T
S
C
R
R
P
B
R
B
C
T
C
C
R
R
R
R
R
R
R
R
R
R
R
V
V
V
V
V
V
V
V
V
V
R
R
R
R
V
V
V
V
I
R
D
E
O
I
H
T
E
E
I
R
D
E
O
I
H
T
E
E
I
R
D
E
O
I
H
T
E
E
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
*
*
*
*
*
*
*
_
_
_
*
*
*
*
*
*
*
_
_
_
*
*
*
*
*
*
*
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
*
*
*
*
*
*
*
*
_
_
*
*
*
*
*
*
*
*
_
_
*
*
*
*
*
*
*
*
_
_
1
5
3
1
5
3
1
5
3
1
5
3
2
4
1
5
3
2
4
1
2
3
4
1
2
3
4
*
*
*
*
*
*
*
*
0
1
*
*
*
*
*
*
*
*
0
1
*
*
*
*
*
*
*
*
0
1
BUTTONS & REMOTE CONTROL KEYPICTURE
COMMAND
PARAMETER
RETURN
E-75
Appendix
(RS-232C) Specifications and Command Settings
CONTROL CONTENTS
BALANCE (30 – 30)
TREBLE (30 – 30)
BASS (30 – 30)
AUDIO DISPLAY
AUDIO ADJUSTMENT RESET
FAO
VAO
SPEAKER ON
SPEAKER OFF
PICT IN PICT : BOTTOM RIGHT
PICT IN PICT : BOTTOM LEFT
PICT IN PICT : UPPER RIGHT
PICT IN PICT : UPPER LEFT
PICT IN PICT RESET
VIDEO DNR OFF
VIDEO DNR ON
OSD DISPLAY ON
OSD DISPLAY OFF (LEVEL A)
OSD DISPLAY OFF (LEVEL B)
BLACK SCREEN DISPLAY ON
BLACK SCREEN DISPLAY OFF
VIDEO SYSTEM SELECTION : AUTO
VIDEO SYSTEM SELECTION : PAL
VIDEO SYSTEM SELECTION : SECAM
VIDEO SYSTEM SELECTION : NTSC4.43
VIDEO SYSTEM SELECTION : NTSC3.58
VIDEO SYSTEM SELECTION : PAL_M
VIDEO SYSTEM SELECTION : PAL_N
BACKGROUND SELECTION : SHARP
BACKGROUND SELECTION : CUSTOM
BACKGROUND SELECTION : BLUE
BACKGROUND SELECTION : NONE
STARTUP IMAGE SELECTION : SHARP
STARTUP IMAGE SELECTION : CUSTOM
STARTUP IMAGE SELECTION : NONE
MONITOR OUT OFF
MONITOR OUT ON
AUTO POWER OFF : NO USE
AUTO POWER OFF : USE
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
A
A
A
A
A
A
A
A
A
P
P
P
P
P
3
3
I
I
I
I
I
M
M
M
M
M
M
M
I
I
I
I
I
I
I
M
M
A
A
A
A
A
A
A
O
O
S
S
I
I
I
I
I
D
D
M
M
M
M
M
E
E
E
E
E
E
E
M
M
M
M
M
M
M
O
O
P
P
B
T
B
R
R
U
U
P
P
N
N
N
N
N
N
N
D
D
D
B
B
S
S
S
S
S
S
S
B
B
B
B
S
S
S
U
U
O
O
L
E
A
E
E
T
T
K
K
P
P
P
P
P
R
R
I
I
I
O
O
Y
Y
Y
Y
Y
Y
Y
G
G
G
G
I
I
I
T
T
W
W
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
*
*
*
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
*
*
*
_
_
_
_
_
_
1
1
1
1
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
*
*
*
0
1
1
2
1
0
1
2
3
4
0
0
1
1
2
0
1
0
1
2
3
4
5
6
7
1
2
3
4
1
2
3
0
1
0
1
AUDIOOPTIONS (1)
COMMAND
PARAMETER
RETURN
CONTROL CONTENTS
LAMP USAGE TIME
LAMP STATUS
PRJ MODE : REVERSE OFF
PRJ MODE : REVERSE ON
PRJ MODE : INVERT OFF
PRJ MODE : INVERT ON
STACK SETTING : NORMAL
STACK SETTING : MASTER
STACK SETTING : SLAVE
KEYLOCK LEVEL : NORMAL
KEYLOCK LEVEL : LEVEL A
KEYLOCK LEVEL : LEVEL B
SET INPUTS : INPUT 1 NO USE
SET INPUTS : INPUT 1 USE
SET INPUTS : INPUT 2 NO USE
SET INPUTS : INPUT 2 USE
SET INPUTS : INPUT 3 NO USE
SET INPUTS : INPUT 3 USE
SET INPUTS : INPUT 4 NO USE
SET INPUTS : INPUT 4 USE
SET INPUTS : INPUT 5 NO USE
SET INPUTS : INPUT 5 USE
ID NO. CHECK
LANGUAGE SELECTION : ENGLISH
LANGUAGE SELECTION : DEUTSCH
LANGUAGE SELECTION : ESPAÑOL
LANGUAGE SELECTION : NEDERLANDS
LANGUAGE SELECTION : FRANÇAIS
LANGUAGE SELECTION : ITALIANO
LANGUAGE SELECTION : SVENSKA
LANGUAGE SELECTION :
LANGUAGE SELECTION : PORTUGUÊS
LANGUAGE SELECTION :
LANGUAGE SELECTION :
MODEL NAME CHECK
NOISE FILTER OFF
NOISE FILTER ON
*2
SERIAL NO. CHECK
*3
PROJECTOR NAME SETTING
*4
PROJECTOR NAME CHECK
0–9999 (INTEGER)
0:OFF, 1:ON, 2:RETRY,
3:WAITING, 4:LAMP ERROR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
001–250
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
OK OR ERR
MODEL NAME
OK OR ERR
OK OR ERR
SERIAL NO.
OK OR ERR
PROJECTOR NAME
T
T
I
I
I
I
S
S
S
K
K
K
R
R
R
R
R
R
V
V
V
V
R
M
M
M
M
M
M
M
M
M
M
M
M
N
N
S
P
P
L
L
M
M
M
M
T
T
T
E
E
E
A
A
B
B
C
C
A
A
B
B
D
E
E
E
E
E
E
E
E
E
E
E
N
F
F
N
J
J
T
P
R
R
I
I
A
A
A
Y
Y
Y
S
S
S
S
S
S
S
S
S
S
I
L
L
L
L
L
L
L
L
L
L
L
R
I
I
R
N
N
T
S
E
E
N
N
K
K
K
L
L
L
I
I
I
I
I
I
I
I
I
I
D
A
A
A
A
A
A
A
A
A
A
A
D
L
L
D
A
A
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
1
_
_
_
_
_
_
1
1
0
1
0
1
0
1
2
0
1
2
0
1
0
1
0
1
0
1
0
1
1
0
1
2
3
4
5
6
7
8
9
0
1
0
1
1
1
2
OPTIONS (2)LANGUAGE
COMMAND
PARAMETER
RETURN
• If an underbar (_) appears in the parameter column, enter a space. If an asterisk (*) appears, enter a value in the range
indicated in brackets under CONTROL CONTENTS.
•
*1
FINE SYNC can only be set in the displayed RGB mode.
•
*2
Noise may appear when used with certain computers. Set the NOISE FILTER to ON using the RS-232C command.
•
*3
SERIAL NO. CHECK command is used to read out the 12 digits of serial No..
•
*4
After OK is returned, enter PROJECTOR NAME, up to 12-character memory. The PROJECTOR NAME in memory can then
be output (confirmed).
E-76
Appendix
Wired Remote Control Terminal Specifications
Specifications of wired remote control input
• ø3.5 mm minijack
• External: 5 V (1 A)
• Internal: GND
Function and transmission codes
• To operate the mouse, left-click and right-click functions
through the wired remote control input, connect the cable
from the WIRED REMOTE control input terminal on the
projector to the remote control. The codes for these functions
are complex and are, therefore, not listed here.
Wired remote control function code
10110********10
C1 System Code C5 C6 Data Code C13 C14 C15
• System codes C1 to C5 are fixed at “10110”.
• Codes C14 and C15 are reverse confirmation bits, with “10”
indicating “Front” and “01” indicating “Rear”.
LSB MSB
Sharp remote control signal format
Transmission format: 15-bit format
Wave form of output signal: Output using Pulse Position Modulation
DDDDDD
DDDDDDD
67.5 ms 67.5 ms
“0”“1”“0”
D
“0”“0”“0”“1”
T
0T1
t
t
26.4 µs
• t 264 µs
• T0 1.05 ms
• T1 2.10 ms
Transmission control code
15 bit
• Pulse carrier frequency 455/12 kHz
• Duty ratio 1:1
C1 C2 C3 C4 C5 C6 C7 C8 C9 C10 C11 C12 C13 C14
System Address
D to D Common Data Bit Reverse in D
Function Key Data Bit
Data
Expansion
Data
Deter-
mination
Mask
C15
C1
1
DC2
0
C3
1
C4
1
C5
0
C6
1
C7
0
C8
0
C9
0
C10
0
C11
0
C12
0
C13
0
C14
1
C15
0
C1
1
DC2
0
C3
1
C4
1
C5
0
C6
0
C7
1
C8
1
C9
1
C10
1
C11
1
C12
1
C13
1
C14
0
C15
1
CONTROL
ITEM
SYSTEM CODE
C1
1
1
1
1
1
1
1
1
1
1
1
ON
OFF
VOLUME
VOLUME
MUTE
MENU
LENS
BLACK SCREEN
ENTER
RESIZE
UNDO
0
0
0
0
0
0
0
0
0
0
0
C2
1
1
1
1
1
1
1
1
1
1
1
C3
1
1
1
1
1
1
1
1
1
1
1
C4
0
0
0
0
0
0
0
0
0
0
0
C5 C6
0
0
0
1
1
0
1
1
1
0
1
1
1
0
0
1
0
1
0
1
1
0
C7
1
1
1
1
1
1
0
0
1
1
0
C8
0
0
0
0
0
0
1
1
0
1
1
C9
1
1
1
1
1
0
0
0
1
1
1
C10 C11
0
0
0
0
0
0
0
1
0
0
0
1
0
0
0
0
1
0
1
1
1
1
C12
0
1
0
0
0
1
1
0
0
0
0
C13
1
1
1
1
1
1
1
1
1
1
1
C14
0
0
0
0
0
0
0
0
0
0
0
C15
DATA CODE
EXTERNAL
CODE
CONTROL
ITEM
SYSTEM CODE
C1
1
1
1
1
1
1
1
1
1
1
Freeze
Enlarge
AUTO SYNC
∂
ƒ
ß
©
GAMMA
INPUT 1. 2. 3
INPUT 4. 5
0
0
0
0
0
0
0
0
0
0
C2
1
1
1
1
1
1
1
1
1
1
C3
1
1
1
1
1
1
1
1
1
1
C4
0
0
0
0
0
0
0
0
0
0
C5 C6
1
1
0
0
1
0
1
0
0
0
0
0
1
0
0
0
1
0
0
1
C7
1
1
0
1
1
0
1
0
1
1
C8
1
1
1
1
1
0
1
0
1
0
C9
0
0
1
1
1
1
0
0
0
1
C10 C11
0
1
1
0
0
0
0
0
1
1
0
1
1
0
0
1
1
1
1
0
C12
1
0
1
1
1
0
0
0
1
1
C13
1
1
1
1
1
1
1
1
1
1
C14
0
0
0
0
0
0
0
0
0
1
C15
DATA CODE
EXTERNAL
CODE
Example of Reverse D to
E-77
Appendix
Computer Compatibility Chart
Horizontal Frequency: 15–126 kHz
Vertical Frequency: 43–200 Hz
Pixel Clock: 12–230 MHz
Compatible with sync on green and composite sync signals
UXGA and SXGA compatible in advanced intelligent compression or intelligent compression
AICS (Advanced Intelligent Compression and Expansion System) resizing technology
PC/
MAC/
WS
Horizontal
Frequency
(kHz)
Vertical
Frequency
(Hz)
VGA
PC
PC
SVGA
XGA
VESA
Standard
Resolution
640 350
1,152 864
1,152 882
1,280 1,024
720 350
640 400
720 400
640 480
800 600
1,024 768
Display
Upscale
True
27.0 60
27.0 60
27.0 60
60
31.5 70
31.5 70
31.5
70
31.5
60
34.7
70
37.9
72
37.5
75
43.3
85
47.9
90
53.0
100
61.8
120
78.5
150
80.9
160
100.4 200
31.4 50
35.1 56
37.9 60
44.5 70
48.1 72
46.9 75
53.7 85
56.8 90
64.0 100
77.2 120
98.3 150
102.1 160
125.6 200
98.8 120
31.5 70
37.9 85
37.9
27.0
85
37.9
85
26.2
50
PC/
MAC/
WS
Horizontal
Frequency
(kHz)
Vertical
Frequency
(Hz)
Resolution Display
Advanced
Intelligent
Compression
Advanced
Intelligent
Compression
Advanced
Intelligent
Compression
54.3 60
67.5 75
75.7 80
77.3 85
111.1 120
65.9 72
54.8 60
67.4 74
64.0 60
1,600 1,200
VESA
Standard
SXGA
UXGA
91.1 85
74.7 52
75.7 75
78.1 74
74.6 70
81.3 65
90.1 72
93.8 75
106.3 85
75.0 60
108.4 100
87.5 70
MAC 16"
MAC 21"
HP (WS)
WS
PC/
MAC 13"
PC/
MAC 19"
PC/
MAC 21"
PC (WS)
SGI (WS)
SUN (WS)
Intelligent
Compression
640 480
832 624
Upscale
Upscale
34.9
1,152 870
68.5
67
1,280 1,024
60.0
75
1,280 1,024
78.1 72
60.0 60
1,024 768
1,280 960
VGA
SVGA
SXGA
SXGA
SXGA
XGA
True
48.4 60
80.0
75
46.8 75
1,280 1,024
53.5 50
76.8 72
85.9 85
1,152 900
60.9 66
71.9 76
49.6 75
75
90.2 100
64.0 70
64.1 72
113.2 140
125.6 150
35.5 43
40.3 50
58.1 72
68.7 85
73.5 90
77.2 96
80.6 100
56.5 70
• This projector may not be able to display images from notebook computers in simultaneous (CRT/LCD) mode. Should this
occur, turn off the LCD display on the notebook computer and output the display data in “CRT only” mode. Details on how
to change display modes can be found in your notebook computer’s operation manual.
• This projector can receive 640 350 VESA format VGA signals, however, “640 400” will appear on the screen.
• When receiving 1,600 1,200 VESA format UXGA signals, sampling occurs and the image is displayed with 1,024 lines,
causing part of the image to be blocked.
E-78
Appendix
Dimensions
Units: inches (mm)
Side View
Front View
Bottom View
11
3
/
25
(282.5)
2
9
/
16
(65)
9
/
32
(7)4
37
/
64
(116.5)
3
1
/
6
(79)
16
21
/
32
(423)
17
15
/
64
(438)
1
/
8
(3)
12
9
/
16
(319)
9
/
64
(3.5)
29
/
32
(23)
9
3
/
4
(248)
1
11
/
32
(34)
1
3
/
64
(26.5)
6
3
/
32
(155)
Top View
Side View
Rear View
E-79
Appendix
Specifications
Product type
Model
Video system
Display method
LCD panel
Standard Lens
Projection lamp
Contrast ratio
Video input signal
S-video input signal
Component input signal
Horizontal resolution
RGB input signal
Pixel clock
Vertical frequency
Horizontal frequency
Computer control signal
Speaker system
Rated voltage
Input current
Rated frequency
Power consumption
Power dissipation
Operating temperature
Storage temperature
Cabinet
GyroRemote
Dimensions (approx.)
Weight (approx.)
Supplied accessories
Replacement parts
LCD Projector
XG-P20XU
PAL/PAL 60/PAL-M/PAL-N/SECAM/NTSC 3.58/NTSC 4.43
DTV 480P/720P/1080i
LCD panel 3, RGB optical shutter method
Panel size: 1.3 (20.0 [H] 26.6 [W] mm)
Display method: Translucent TN liquid crystal panel
Drive method: TFT (Thin Film Transistor) Active Matrix panel
No. of dots: 786,432 dots (1,024 [H] 768 [V])
1–1.3 zoom lens, F1.7–2.3, f = 49.1–63.8 mm
AC 220 W lamp
600:1
RCA Connector: VIDEO, composite video, 1.0 Vp-p, sync negative, 75 Ω terminated
RCA Connector: AUDIO, 0.5 Vrms more than 22 kΩ (stereo)
4-pin Mini DIN connector
Y (luminance signal): 1.0 Vp-p, sync negative, 75 Ω terminated
C (chrominance signal): Burst 0.286 Vp-p, 75 Ω terminated
BNC Connector (INPUT 2)
Y: 1.0 Vp-p, sync negative, 75 Ω terminated
P
B: 0.7 Vp-p, 75 Ω terminated
P
R: 0.7 Vp-p, 75 Ω terminated
520 TV lines (S-video input), 750 TV lines (DTV 720P input, STRETCH mode)
15-
PIN MINI D-SUB CONNECTOR (INPUT 1), 5 BNC CONNECTOR (INPUT 2):
RGB separate/composite sync/sync on green type analog input: 0–0.7 Vp-p, positive,
75 Ω terminated
DVI CONNECTOR (29-PIN) (INPUT 3), RGB (DIGITAL), 250–1,000 mV, 50 Ω
H
ORIZONTAL SYNC. SIGNAL: TTL level (positive/negative) or composite sync (Apple only)
V
ERTICAL SYNC. SIGNAL: Same as above
S
TEREO MINIJACK: AUDIO, 0.5 Vrms, more than 22 kΩ (stereo)
12–230 MHz
43–200 Hz
15–126 kHz
9-pin D-sub connector (RS-232C Input Port/Output Port)
1
49
⁄64 (4.5 cm) round 2
2 W 2 W (stereo)
AC 100–240 V
3.95 A
50/60 Hz
330 W
< 1,250 BTU/hour
41°F to 104°F (5°C to 40°C)
4°F to 140°F (20°C to 60°C)
Plastic
Radio Frequency Range: 49.825–49.895 MHz
12
9
⁄16 (W) 6
3
⁄32 (H) 16
21
⁄32 (D) (319.0 155.0 423.0 mm) (main body only)
12
11
⁄32 (W) 7
27
⁄64 (H) 17
15
⁄64 (D) (322.5 188.5 438.0 mm) (including standard
lens, adjustment feet and projecting parts)
21.0 lbs. (9.5 kg)
GyroRemote, Four AAA size batteries, Power cord (11 10, 3.6 m), RGB cable (9 10,
3 m), USB mouse control cable (3 3, 1 m), Computer audio cable (9 10, 3 m), ø2.5–ø3.5
mm wired remote control cable (6
45
⁄64, 15 cm), Three BNC-RCA adaptors, Extra air filter,
Lens cap, CD-ROM, LCD projector operation manual, LCD projector quick guide, Sharp
Advanced Presentation Software operation manual, ID number seal
Standard lens unit (CLNS-0236CE01), Lamp unit (Lamp/cage module) (BQC-XGP20X//1),
GyroRemote (RRMCG1631CESA), AAA size batteries, Power cord (QACCU5013DE01),
RGB cable (QCNW-5304CEZZ), USB mouse control cable (QCNW-5916CEZZ), Computer
audio cable (QCNW-4870CEZZ), ø2.5–ø3.5 mm wired remote control cable (QCNW-
5943CEZZ), BNC-RCA adaptors (QPLGJ0107GEZZ), Air filter (PFILD0080CEZZ), Lens cap
(PCAPH1056CESA), CD-ROM (UDSKA0043CEN1), LCD projector operation manual (TINS-
7354CEZZ), LCD projector quick guide (TINS-7355CEZZ), Sharp Advanced Presentation
Software operation manual (TINS-7356CEZZ), ID number seal (TLABZ0781CEZZ)
This SHARP projector uses LCD (Liquid Crystal Display) panels. These
very sophisticated panels contain 786,432 pixels ( RGB) TFTs (Thin
Film Transistors). As with any high technology electronic equipment
such as large screen TVs, video systems and video cameras, there
are certain acceptable tolerances that the equipment must conform
to.
This unit has some inactive TFTs within acceptable tolerances which
may result in illuminated or inactive dots on the picture screen. This
will not affect the picture quality or the life expectancy of the unit.
If you have any questions about this matter, please call toll free 1-888-
GO-SHARP (1-888-467-4277). U.S.A. ONLY
Specifications are subject to change without notice.
E-80
Appendix
Glossary
Aspect ratio
Width and height ratio of an image. The normal aspect ratio of a computer and video image is 4:3. There are also wide images with an aspect ratio of 16:9 and
21:9.
Auto Sync
Optimizes projected computer images by automatically adjusting certain characteristics.
Background
Initial setting image projected when no signal is being input.
Border
Displays the 4:3 image as the biggest size (768576) that can be displayed on the WIDE mode screen (1024576).
Clock
Clock adjustment is used to adjust vertical noise when clock level is incorrect.
CLR Temp (Color temperature)
Function that can be used to adjust the color temperature to suit the type of image input to the projector. Decrease the color temperature to create warmer,
reddish images for natural flesh tones, or increase to create cooler, bluish images for a brighter picture.
Composite sync
Signal combining horizontal and vertical sync pulses.
Digital shift
Shifts image up or down easily by ∂/ƒ buttons when RESIZE mode of input image is BORDER, STRETCH or SMART STRETCH of COMPUTER (except for
SXGA and UXGA), VIDEO and DTV inputs.
DNR (Digital Noise Reduction)
Provides high quality images with minimal dot crawl and cross color noise.
Dot by dot
Mode that projects images in their native resolution.
DVI
Digital Visual Interface that supports both digital and analog displays.
GAMMA
Image quality enhancement function that offers a richer image by brightening the darker portions of the image without altering the brightness of the brighter
portions. You can select four different modes : STANDARD, PRESENTATION, CINEMA and CUSTOM.
GyroRemote
Remote control device with a built-in sensor that can operate projectors and computers. GyroRemote communicates with a projector via radio signals and
therefore does not encounter the line-of-sight problems found in infrared devices.
Intelligent compression and expansion
High quality resizing of lower and higher resolution images to fit the projector’s native resolution.
Intelligent digital keystone correction
Function to digitally correct a distorted image when the projector is set up at an angle, smooths out jaggies on keystone images and compresses the image not
only horizontally but vertically keeping the 4:3 aspect ratio, and at the same time, calculates the aspect ratio automatically adjusting to the lens shift width.
Keylock level
Mode that can lock the operation of projector buttons to prevent mischief.
Lens shift
The lens can be easily raised and lowered to minimize or eliminate “Keystone” type effect.
Magnification (Enlarge)
Digitally zooms in on a portion of an image.
Phase
Phase shift is a timing shift between isomorphic signals with the same resolution. When phase level is incorrect, the projected image typically displays horizontal
flicker.
Picture in Picture
Allows you to add video images onto a data screen image, providing you with even more effective presentations.
Presentation tools
Helpful tools used to emphasize keypoints throughout a presentation.
Progressive Mode
The progressive display projects a smoother video image. You can select three different modes : 2D Progressive, 3D Progressive and Film Mode.
RESIZE
Allows you to modify or customize the picture display mode to enhance the input image. You can select six different modes: NORMAL, FULL, DOT BY DOT,
BORDER, STRETCH and SMART STRETCH.
RS-232C
Function to control the projector from the computer by using the RS-232C ports on the projector and computer.
Set Inputs
Function to limit inputs. For example, when setting Input 2 to “OFF”, the input is switchable only between Input 1 and Input 3, skipping Input 2.
Smart Stretch
Mode that stretches the right and left sides of the 4:3 image horizontally while maintaining the aspect ratio around the center of the image to display it on the WIDE
screen.
Stack Setting
Prevents trouble with adjustment and operation when stack projecting. When setting two projectors, one to master and the other to slave, the slave follows the
master’s operation.
Status function
Displays the settings of each adjustment item.
Stretch
Mode that stretches the 4:3 image horizontally to display it on the WIDE screen.
Sync on green
Video signal mode of a computer which overlaps horizontal and vertical sync signal to green color signal pin.
E-81
Appendix
Index
A
AC socket........................................................................
13
Adjusting the Picture .......................................................
47
Adjustment Feet ..............................................................
20
Air filter ............................................................................
70
Aspect ratio .....................................................................
42
ASSIGN Select button .....................................................
33
Audio ...............................................................................
52
Audio cable .....................................................................
18
AUDIO INPUT terminal ...................................................
14
AUDIO OUTPUT terminal ................................................
18
Auto sync adjustment .....................................................
51
AUTO SYNC button.........................................................
51
B
Background ....................................................................
55
BLACK SCREEN button ..................................................
40
BNC-RCA adaptors.........................................................
18
BORDER .........................................................................
42
C
Carrying handle ..............................................................
4
Ceiling-mount ..................................................................
29
Ceiling+Rear ...................................................................
57
Clock ...............................................................................
49
CLR Temp (Color Temperature) ......................................
47
D
Digital shift ......................................................................
21
DNR (Digital Noise Reduction) .......................................
53
DOT BY DOT ...................................................................
42
DVI INPUT port (INPUT 3) ...............................................
16
E
Economy Mode ...............................................................
56
ENTER button..................................................................
44
Exhaust vent....................................................................
3
Extra air filter ...................................................................
12
F
FAO .................................................................................
52
Function button ...............................................................
33
G
GAMMA button ...............................................................
43
GUI (Graphical User Interface) .......................................
44
GyroRemote ....................................................................
30
I
INPUT button...................................................................
39
INPUT port ......................................................................
14
Intelligent digital keystone correction .............................
21
K
Keylock Levels ................................................................
58
L
LAMP REPLACEMENT indicator .....................................
67
LEARN button .................................................................
37
LEFT-CLICK button .........................................................
35
LENS button ....................................................................
21
Lens shift .........................................................................
20
M
MENU button...................................................................
44
Monitor Out/RS-232C Off Function .................................
56
MUTE button ...................................................................
39
N
Network Function ............................................................
63
O
On-screen display...........................................................
54
On-screen display Language .........................................
62
OUTPUT port ..................................................................
56
P
Password ........................................................................
61
PDF .................................................................................
9
Phase ..............................................................................
49
Picture in Picture .............................................................
53
POINTER button ..............................................................
32
POWER buttons ..............................................................
19
Power cord ......................................................................
13
POWER indicator ............................................................
13
Presentation tools............................................................
34
Progressive Mode ...........................................................
48
R
Rear projection................................................................
29
RESIZE button .................................................................
42
RF CH button ...............................................................
36
RGB cable.......................................................................
14
RIGHT-CLICK button .......................................................
35
RS-232C port ..................................................................
16
S
Save Setting ....................................................................
49
Select Setting ..................................................................
49
Set ID No. ........................................................................
60
Set Inputs ........................................................................
59
Speaker ...........................................................................
52
Stack Setting ...................................................................
58
Startup image .................................................................
55
Status function ................................................................
62
S-VIDEO INPUT terminal .................................................
17
Sync ................................................................................
51
Sync on green .................................................................
72
T
TEACH button .................................................................
37
TEMPERATURE WARNING indicator ..............................
67
Transmission Speed (RS-232C) ......................................
59
U
UNDO button ..................................................................
44
USB mouse control cable ...............................................
35
V
VAO .................................................................................
52
VIDEO INPUT terminal ....................................................
17
Video System ..................................................................
54
Videowall .........................................................................
66
VOLUME buttons ............................................................
39
W
Wired remote control input ..............................................
38
WIRED REMOTE control input terminal ..........................
38
No.
1.2.3 button .....................................................................
39
4.5 button ........................................................................
39
SHARP CORPORATION
