CD-G10000 Sharp User Manual

MINI COMPONENT SYSTEM

Accessories

Please confirm that the following accessories are included.

CD-G10000

Note:

Only the above accessories are included.

SPEAKER SYSTEM

CP-G10000S

Thank you for purchasing this SHARP product.

To obtain the best performance from this product, please read

this manual carefully. It will guide you in operating your SHARP

product.

OPERATION MANUAL

CD-G10000

CD-G10000 Mini Component System consisting of CD-G10000 (main

unit) and GBOXSA090AWM1 (rear speaker system).

CP-G10000S

CP-G10000S Speaker System consisting of CP-G10000S (front

speaker system) and CP-SW10000S (active subwoofer).

Remote control 1

(RRMCG0395AWSA)

AM loop antenna 1

(QANTL0005AWZZ)

FM antenna 1

(92LFANT1746A)

Wire for front speaker

(QCNWHA003AWZZ)

Wire for rear speaker

(QCNWHA004AWZZ)

Subwoofer cable

(QCNWGA003AWPZ)

Red

Black

Gray

Black

MODEL

CD-G10000

CP-G10000S

Important Instruction

SPECIAL NOTES

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,

DO NOT REMOVE COVER (OR BACK).

NO USER-SERVICEABLE PARTS INSIDE. REFER SERVIC-

ING TO QUALIFIED SERVICE PERSONNEL.

Explanation of Graphical Symbols:

The lightning flash with arrowhead symbol,

within an equilateral triangle, is intended to

alert the user to the presence of uninsulated

“dangerous voltage” within the product’s en-

closure that may be of sufficient magnitude

to constitute a risk of electric shock to per-

sons.

The exclamation point within an equilateral

triangle is intended to alert the user to the

presence of important operating and main-

tenance (servicing) instructions in the lit-

erature accompanying the appliance.

0012

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC

SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR

MOISTURE.

0012

Caution - use of controls or adjustments or performance

of procedures other than those specified herein may re-

sult in hazardous radiation exposure.

0012

NOTE

This equipment has been tested and found to comply with the limits for a

Class B digital device, pursuant to Part 15 of the FCC Rules. These

limits are designed to provide reasonable protection against harmful in-

terference in a residential installation. This equipment generates, uses,

and can radiate radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful interference to ra-

dio communications. However, there is no guarantee that interference

will not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be deter-

mined by turning the equipment off and on, the user is encouraged to try

to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

WARNING

FCC Regulations state that any unauthorized changes or modifications

to this equipment not expressly approved by the manufacturer could void

the user's authority to operate this equipment.

NOTES

It is the intent of Sharp that this product be used in full compliance

with the copyright laws of the United States and that prior permission

be obtained from copyright owners whenever necessary.

Licensed under one or more of U.S. Pat. 4,972,484, 5,214,678,

5,323,396, 5,530,655, 5,539,829, 5,544,247, 5,606,618, 5,610,985,

5,740,317, 5,777,992, 5,878,080 or 5,960,037.

0303

FOR YOUR RECORDS

For your assistance in reporting this unit in case of loss or theft,

please record below the model number and serial number which

are located on the rear of the unit.

Please retain this information.

Model number .......................................................

Serial number .......................................................

Date of purchase .......................................................

Place of purchase .......................................................

0202

CD-G10000

CP-G10000S

Important Instruction

IMPORTANT SAFETY INSTRUCTIONS

1 Read Instructions - All the safety and operating instructions should

be read before the product is operated.

2 Retain Instructions - The safety and operating instructions should be

retained for future reference.

3 Heed Warnings - All warnings on the product and in the operating

instructions should be adhered to.

4 Follow Instructions - All operating and use instructions should be

followed.

5 Cleaning - Unplug this product from the wall outlet before cleaning.

Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for

cleaning.

6 Attachments - Do not use attachments not recommended by the prod-

uct manufacturer as they may cause hazards.

7 Water and Moisture - Do not use this product near water - for ex-

ample, near a bath tub, wash bowl, kitchen sink, or laundry tub; in a

wet basement; or near a swimming pool; and the like.

8 Accessories - Do not place this product on an unstable cart, stand,

tripod, bracket, or table. The product may fall, causing serious injury to

a child or adult, and serious damage to the product. Use only with a

cart, stand, tripod, bracket, or table recommended by the manufac-

turer, or sold with the product. Any mounting of the product should

follow the manufacturer’s instructions, and should use a mounting ac-

cessory recommended by the manufacturer.

9 A product and cart combination should be moved with

care. Quick stops, excessive force, and uneven surfaces

may cause the product and cart combination to over-

turn.

10 Ventilation - Slots and openings in the cabinet are provided for venti-

lation and to ensure reliable operation of the product and to protect it

from overheating, and these openings must not be blocked or cov-

ered. The openings should never be blocked by placing the product on

a bed, sofa, rug, or other similar surface. This product should not be

placed in a built-in installation such as a bookcase or rack unless proper

ventilation is provided or the manufacturer’s instructions have been

adhered to.

11 Power Sources - This product should be operated only from the type

of power source indicated on the marking label. If you are not sure of

the type of power supply to your home, consult your product dealer or

local power company. For products intended to operate from battery

power, or other sources, refer to the operating instructions.

12 Grounding or Polarization - This product may be equipped with a

polarized alternating-current line plug (a plug having one blade wider

than the other). This plug will fit into the power outlet only one way.

This is a safety feature. If you are unable to insert the plug fully into the

outlet, try reversing the plug. If the plug should still fail to fit, contact

your electrician to replace your obsolete outlet. Do not defeat the safety

purpose of the polarized plug.

Alternate Warnings - This product is equipped with a three-wire

grounding-type plug, a plug having a third (grounding) pin. This plug

will only fit into a grounding-type power outlet. This is a safety feature.

If you are unable to insert the plug into the outlet, contact your electri-

cian to replace your obsolete outlet. Do not defeat the safety purpose

of the grounding-type plug.

13 Power-Cord Protection - Power-supply cords should be routed so

that they are not likely to be walked on or pinched by items placed

upon or against them, paying particular attention to cords at plugs,

convenience receptacles, and the point where they exit from the product.

14 Protective Attachment Plug - The product is equipped with an at-

tachment plug having overload protection. This is a safety feature. See

Instruction Manual for replacement or resetting of protective device. If

replacement of the plug is required, be sure the service technician has

used a replacement plug specified by the manufacturer that has the

same overload protection as the original plug.

0304

CD-G10000

CP-G10000S

Important Instruction

IMPORTANT SAFETY INSTRUCTIONS

(continued)

15 Outdoor Antenna Grounding - If an outside antenna or cable system

is connected to the product, be sure the antenna or cable system is

grounded so as to provide some protection against voltage surges and

built-up static charges. Article 810 of the National Electrical Code, ANSI/

NFPA 70, provides information with regard to proper grounding of the

mast and supporting structure, grounding of the lead-in wire to an an-

tenna discharge unit, size of grounding conductors, location of antenna

discharge unit, connection to grounding electrodes, and requirements

for the grounding electrode.

16 Lightning - For added protection for this product during a lightning

storm, or when it is left unattended and unused for long periods of

time, unplug it from the wall outlet and disconnect the antenna or cable

system. This will prevent damage to the product due to lightning and

power-line surges.

17 Power Lines - An outside antenna system should not be located in the

vicinity of overhead power lines or other electric light or power circuits,

or where it can fall into such power lines or circuits. When installing an

outside antenna system, extreme care should be taken to keep from

touching such power lines or circuits as contact with them might be

fatal.

Overloading - Do not overload wall outlets, extension cords, or integral

convenience receptacles as this can result in a risk of fire or electric shock.

Object and Liquid Entry - Never push objects of any kind into this

product through openings as they may touch dangerous voltage points

or short-out parts that could result in a fire or electric shock. Never spill

liquid of any kind on the product.

20 Servicing - Do not attempt to service this product yourself as opening

or removing covers may expose you to dangerous voltage or other

hazards. Refer all servicing to qualified service personnel.

21 Damage Requiring Service - Unplug this product from the wall outlet

and refer servicing to qualified service personnel under the following

conditions:

a) When the power-supply cord or plug is damaged,

b) If liquid has been spilled, or objects have fallen into the product,

c) If the product has been exposed to rain or water,

d) If the product does not operate normally by following the operating

instructions. Adjust only those controls that are covered by the op-

erating instructions as an improper adjustment of other controls may

result in damage and will often require extensive work by a qualified

technician to restore the product to its normal operation,

e) If the product has been dropped or damaged in any way, and

f) When the product exhibits a distinct change in performance - this

indicates a need for service.

22 Replacement Parts - When replacement parts are required, be sure

the service technician has used replacement parts specified by the

manufacturer or have the same characteristics as the original part.

Unauthorized substitutions may result in fire, electric shock, or other

hazards.

23 Safety Check - Upon completion of any service or repairs to this prod-

uct, ask the service technician to perform safety checks to determine

that the product is in proper operating condition.

24 Wall or Ceiling Mounting - The product should be mounted to a wall

or ceiling only as recommended by the manufacturer.

25 Heat - The product should be situated away from heat sources such

as radiators, heat registers, stoves, or other products (including ampli-

ANTENNA LEAD IN WIRE

POWER SERVICE GROUNDING

ELECTRODE SYSTEM

(NEC ART 250, PART H)

GROUNDING CONDUCTORS

(NEC SECTION 810-21)

GROUND CLAMPS

NEC - NATIONAL ELECTRICAL CODE

S2898A

ELECTRIC

SERV ICE

EQUIPMENT

GROUND

CLAMP

Example of antenna grounding as per

National Electrical Code, ANSI/NFPA 70

ANTENNA DISCHARGE UNIT

(NEC SECTION 810-20)

fiers) that produce heat.

0304

CD-G10000

CP-G10000S

Important Instruction

Contents

Page

 General Information

Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Controls and indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . .7 - 10

 Preparation for Use

System connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11 - 15

Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Subwoofer control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

 Basic Operation

General control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Setting the clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

 CD or MP3 disc Playback

Listening to a CD or MP3 disc . . . . . . . . . . . . . . . . . . . . . .20 - 22

Advanced CD or MP3 disc playback . . . . . . . . . . . . . . . . .23 - 25

MP3 navigation (only for MP3 files) . . . . . . . . . . . . . . . . . .26 - 29

 Radio

Listening to the radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30, 31

 Tape Playback

Listening to a cassette tape (TAPE 1 or TAPE 2) . . . . . . . 32, 33

 Tape Recording

Recording on a cassette tape . . . . . . . . . . . . . . . . . . . . . . .33 - 35

 Advanced Features

Timer and sleep operation . . . . . . . . . . . . . . . . . . . . . . . . .36 - 39

Enhancing your system . . . . . . . . . . . . . . . . . . . . . . . . . . . 40, 41

 References

Troubleshooting chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41 - 43

Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45, 46

CONSUMER LIMITED WARRANTY . . . . . . . . . . . . . .Back cover

ENERGY STAR

Program Information

0312

Products that have earned

the ENERGY STAR

are

designed to protect the

environment through

superior energy efficiency.

To comply with the ENERGY STAR

standards mentioned above,

please cancel the demonstration mode, as described on page .

ENERGY STAR

is a U.S. registered mark.

CD-G10000

CP-G10000S

General Information

Precautions

 General

Please ensure that the system is positioned in a well-ventilated

area and ensure that there is at least 4" (10 cm) of free space

along the sides, top and back of the unit.

z Do not place anything on top of the unit and subwoofer.

z Do not expose the system to moisture, to temperatures higher

than 140°F (60°C) or to extremely low temperatures.

z If your system does not work properly, disconnect the AC power

cord from the AC outlet. Plug the AC power cord back in, and

then turn on your system.

This system should only be used within the range of 41°F - 95°F

(5°C - 35°C).

Warning:

The voltage used must be the same as that specified on this unit.

Using this product with a higher voltage other than that which is

specified is dangerous and may result in a fire or other type of acci-

dent causing damage. SHARP will not be held responsible for any

damage resulting from use of this unit with a voltage other than that

which is specified.

 Volume control

The sound level at a given volume setting depends on speaker effi-

ciency, location and various other factors. It is advisable to avoid

exposure to high volume levels, which occurs while turning the unit

on with the volume control setting up high, or while continually lis-

tening at high volumes.

Do not place active subwoofer system on

the same surface as main unit to prevent

sound interruption during playback.

z Use the unit on a firm, level surface free from

vibration.

z Keep the unit away from direct sunlight,

strong magnetic fields, excessive dust,

humidity and electronic/electrical equip-

ment (home computers, facsimiles, etc.)

which generate electrical noise.

4" (10 cm)

4" (10 cm) 4" (10 cm)

4" (10 cm)

Floor

In case of an electrical storm, unplug the

system for safety.

Hold the AC power plug by the head when

removing it from the AC outlet, as pulling

the cord can damage internal wires.

Do not remove the outer cover, as this

may result in electric shock. Refer inter-

nal service to your local SHARP service

facility.

CD-G10000

CP-G10000S

General Information

Controls and indicators

 Front panel

Reference page

1. Disc Trays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

2. Timer Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

3. Power On/Stand-by Button . . . . . . . . . . . . . . . . . . . . . . . . . 18

4. Disc Track Up or Fast Forward, Tape 2 Fast Forward,

Tuner Preset Up, Time Up Button . . . . . . . . . . 19, 22, 31, 33

5. Clock/Timer Button . . . . . . . . . . . . . . . . . . . . . . . . . . 19, 36,39

6. Tuning Up Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

7. Tuning Down Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

8. Disc Track Down or Fast Reverse, Tape 2 Rewind,

Tuner Preset Down, Time Down Button . . . . . 19, 22, 31, 33

9. Equalizer Mode Select Button . . . . . . . . . . . . . . . . . . . . . . 18

10. Tape 1 Cassette Compartment . . . . . . . . . . . . . . . . . . . . . . 32

11. Headphone Jack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

12. Game/Video Input Jacks . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

13. Disc Number Select Buttons . . . . . . . . . . . . . . . . . . . . . . . . 21

14. Disc Direct Play Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

15. Disc Tray Open/Close Button . . . . . . . . . . . . . . . . . . . . . . . 21

16. Character Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

17. Enter Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

18. Disc Play or Repeat, Tape Play Button . . . . . . . . . 21, 24, 32

19. Memory/Set Button . . . . . . . . . . . . . . . . 19, 25, 29, 31, 36, 39

20. Tape 2 Record Pause Button . . . . . . . . . . . . . . . . . . . . 34, 35

21. MP3 Disc Navigation Mode Select Button . . . . . . . . . . . . . 27

22. Disc or Tape Stop Button . . . . . . . . . . . . . . . . . . . . . . . 22, 33

23. Cursor Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

24. Extra Bass/Demo Mode Button . . . . . . . . . . . . . . . . . . 15, 18

25. Volume Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

26. Tape 2 Cassette Compartment . . . . . . . . . . . . . . . . . . . . . . 32

27. Tuner (Band) Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

28. CD Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

29. Tape (1 2) Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

30. Game/Video Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

28 29 3027

CD-G10000

CP-G10000S

General Information

Controls and indicators (continued)

 Display

Reference page

1. Disc Number Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

2. MP3 Folder Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

3. MP3 Title Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

4. MP3 Total Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

5. Sleep Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

6. Timer Play Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

7. Timer Recording Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . 37

8. Tape 2 Record Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

9. Daily Timer Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

10. FM Stereo Mode Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . 30

11. FM Stereo Receiving Indicator . . . . . . . . . . . . . . . . . . . . . . 30

12. Memory Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . 25, 29, 31

13. Tape Play Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

14. MP3 Disc Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

15. Extra Bass Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

16. Disc Repeat Play Indicator . . . . . . . . . . . . . . . . . . . . . . . . . 24

17. Disc Pause Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

18. Disc Play Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

 Rear panel

Reference page

1. Cooling Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

2. Subwoofer Pre-output Jack . . . . . . . . . . . . . . . . . . . . . . . . . 14

3. AC Power Cord . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

4. FM 75 Ohms Antenna Terminal . . . . . . . . . . . . . . . . . . . . . . 12

5. FM Antenna Ground Terminal . . . . . . . . . . . . . . . . . . . . . . . 12

6. AM Loop Antenna Jack . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

7. Video Output Jack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

8. Front Speaker Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

9. Rear Speaker Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

4 532167 8

1110 12

14 15 16

CD-G10000

CP-G10000S

General Information

 Front speaker

1. Woofers

2. Tweeter

3. Bass Reflex Duct

4. Speaker Terminals

 Rear speaker

1. Full-range Speakers

2. Speaker Terminals

 Active subwoofer

Reference page

1. Power Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

2. Subwoofer

3. Bass Reflex Duct

4. Power Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

5. Volume Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

6. Crossover Frequency Control . . . . . . . . . . . . . . . . . . . . . . 17

7. Cooling Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

8. Subwoofer Input Jack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

9. AC Power Cord . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

CD-G10000

CP-G10000S

General Information

Controls and indicators (continued)

 Remote control

Reference page

1. Remote Control Transmitter . . . . . . . . . . . . . . . . . . . . . . . . 16

2. Disc Number Select Buttons . . . . . . . . . . . . . . . . . . . . . . . . 21

3. Clock/Timer Button . . . . . . . . . . . . . . . . . . . . . . . . . 19, 36, 39

4. Character Input/Disc Direct Search Buttons . . . . . . . . 23, 28

5. MP3 Disc Navigation Mode Select Button . . . . . . . . . . . . . 27

6. Enter Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

7. Memory/Set Button . . . . . . . . . . . . . . . . 19, 25, 29, 31, 36, 39

8. Tape 2 Record Pause Button . . . . . . . . . . . . . . . . . . . . 34, 35

9. Disc Track Down or Fast Reverse, Tape 2 Rewind,

Tuner Preset Down, Time Down Button . . . . . . 19, 22, 31, 33

10. Disc or Tape Stop Button . . . . . . . . . . . . . . . . . . . . . . . 22, 33

11. CD Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

12. Tuner (Band) Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

13. Equalizer Mode Select Button . . . . . . . . . . . . . . . . . . . . . . . 18

14. Extra Bass Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

15. Power On/Stand-by Button . . . . . . . . . . . . . . . . . . . . . . . . . 18

16. Disc Random Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

17. Character Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

18. Cursor Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

19. Disc Clear/Dimmer Button . . . . . . . . . . . . . . . . . . . . . . . 18, 25

20. Disc Pause Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

21. Disc Track Up or Fast Forward, Tape 2 Fast Forward,

Tuner Preset Up, Time Up Button . . . . . . . . . . . 19, 22, 31, 33

22. Disc Play or Repeat, Tape Play Button . . . . . . . . . 21, 24, 32

23. Tape (1 2) Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

24. Game/Video Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

25. MP3 Disc Display Button . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

26. Volume Up and Down Buttons . . . . . . . . . . . . . . . . . . . . . . 18

CD-G10000

CP-G10000S

Preparation for Use

System connections

Speaker connection (see page 12)

Antenna connection (see page 12)

AC power connection (see page 14)

Make sure to unplug the AC power cord before making any connections.

AM loop antenna

FM antenna

Front speaker

(right)

Rear speaker

(right)

Rear speaker

(left)

Front speaker

(left)

AC outlet

(AC 120 V, 60 Hz)

Connecting the subwoofer

(see page 14)

CD-G10000

CP-G10000S

Preparation for Use

System connections (continued)

 Antenna connection

Supplied FM antenna:

Connect the FM antenna wire to the FM 75 OHMS terminal and

position the FM antenna wire in the direction where the strongest

signal can be received.

Supplied AM loop antenna:

Connect the AM loop antenna to the AM LOOP jack. Position the

AM loop antenna for optimum reception. Place the AM loop antenna

on a shelf, etc., or attach it to a stand or a wall with screws (not sup-

plied).

Note:

Placing the antenna on the unit or near the AC power cord may

cause noise pickup. Place the antenna away from the unit for better

reception.

Installing the AM loop antenna:

 Speaker connection

Front speakers:

Connect the black wire to the FRONT SPEAKERS (-) terminal, and

the red wire to the FRONT SPEAKERS (+) terminal.

Rear speakers:

Connect the black wire to the REAR SPEAKERS (-) terminal, and

the gray wire to the REAR SPEAKERS (+) terminal.

Caution:

< Assembling > < Attaching to the wall >

Wall Screws (not supplied)

z Connect the speaker wires to the speakers first, then to the unit.

Never mistake the FRONT SPEAKERS and the REAR SPEAK-

ERS terminals. Otherwise the unit or the speakers may be dam-

aged.

z If you use other speakers with impedance lower

than that specified, the unit may be damaged.

Front speakers: 8 ohms Rear speakers: 16 ohms

Do not mistake the right and the left channels. The

right speaker is the one on the right side when you

face the unit.

Do not let the bare speaker wires touch each

other.

z Do not allow any objects to fall into or to be placed

in the bass reflex ducts.

Do not stand or sit on the speakers. You may be injured.

Black

Red

Front speaker (right)

Rear speaker (right) Rear speaker (left)

Front speaker (left)

Gray

Incorrect

CD-G10000

CP-G10000S

Preparation for Use

 Placing the speaker system

To enjoy the surround effect, we recommend that you place each

speaker as shown to the below.

Note:

The speaker grilles are not removable.

 Outdoor FM antenna

Use an outdoor FM antenna if you require better reception.

Consult your dealer.

Note:

When an outdoor FM antenna is used, disconnect the supplied FM

antenna wire.

Notes:

The front speakers, rear speakers and active subwoofer are mag-

netically shielded.

Therefore, they do not affect the display even if you use them near

the TV. However, some color variation may occur, depending on

the type of TV used.

If color variation occurs...

Turn off the TV (from the power switch).

After 15 - 30 minutes, turn the TV on again.

If the color variation is still present...

Move the speakers further away from the TV.

z If any kind of magnet or an electromagnet is placed too close to

the TV and the system, irregular colors may appear on the TV

screen.

Front speaker

(left)

Front speaker

(right)

Rear speaker

(left)

Rear speaker

(right)

TVActive

subwoofer

Main unit

Outdoor

FM antenna

75 ohm

coaxial cable

CD-G10000

CP-G10000S

Preparation for Use

System connections (continued)

 Connecting the subwoofer

Use the subwoofer cable to connect the SUBWOOFER PRE-OUT

jack on the main unit and the SUBWOOFER IN jack on the active

subwoofer.

 AC power connection

After checking all the connections have been made correctly, plug

the AC power cord of this unit into the AC outlet. If you plug in the

unit first, the unit will enter the demonstration mode.

Notes:

z The unit will start the tape initialization when plugged in to the AC

outlet. During this process, an initializing sound will be heard and

the unit cannot be turned on. Wait until the process is finished.

z Unplug the AC power cord from the AC outlet if the unit will not

be in use for a prolonged period of time.

Make sure to unplug the AC power cord of the main unit before

making any connections.

Main unit

Active subwoofer

To subwoofer

output jack

To subwoofer

input jack

Subwoofer cable

Main unit

Active subwoofer

AC outlet

(AC 120 V, 60 Hz)

AC outlet

(AC 120 V, 60 Hz)

CD-G10000

CP-G10000S

Preparation for Use

Cooling fan:

The main unit and the active subwoofer are built with a cooling fan

at the rear of the units for improved cooling. Please do not cover the

opening of the fan with any obstacles, as this will block proper venti-

lation.

 Demonstration mode

When you plug the unit in for the first time, the unit will enter the

demonstration mode. You will see words scroll.

To cancel the demonstration mode:

When the unit is in the power stand-by mode (demonstration mode),

press the X-BASS/DEMO button. The unit will enter the low power

consumption mode.

To return to the demonstration mode:

When the unit is in the power stand-by mode, press the X-BASS/

DEMO button again.

Note:

When the power is on, the X-BASS/DEMO button can be used to

select the extra bass mode.

Main unit

Active subwoofer

CD-G10000

CP-G10000S

Preparation for Use

Remote control

 Battery installation

Precautions for battery use:

Replace all old batteries with new ones at the same time.

Do not mix old and new batteries.

Remove the batteries if the unit will not be used for long periods

of time. This will prevent potential damage due to battery leak-

age.

Caution:

Do not use rechargeable batteries (nickel-cadmium battery, etc.).

Installing the batteries incorrectly may cause the unit to malfunc-

tion.

Battery removal:

Open the battery cover, and pull up the battery to take out.

Notes concerning use:

z Replace the batteries if the operating distance is reduced or if the

operation becomes erratic.

z Periodically clean the transmitter on the remote control and the

sensor on the unit with a soft cloth.

z Exposing the sensor on the unit to strong light may interfere with

operation. Change the lighting or the direction of the unit.

z Keep the remote control away from moisture, heat, shock, and

vibrations.

 Test of the remote control

Check the remote control after checking all the connections (see

pages 11 - 14).

Point the remote control directly at the remote sensor on the unit.

The remote control can be used within the range shown below:

Press the ON/STAND-BY button. Does the power turn on? Now,

you can enjoy music.

Use 2 "AA" size batteries (UM/SUM-3, R6, HP-7 or similar).

Batteries are not included.

1 Open the battery cover.

2 Insert the batteries according to the direction indicated in

the battery compartment.

When inserting or removing the batteries, push them toward the

battery terminals.

3 Close the battery cover.

8" - 20'

(0.2 m - 6 m)

Remote sensor

CD-G10000

CP-G10000S

Preparation for Use

Subwoofer control

 Power switch

The POWER indicator lights up when you press the POWER switch

to ON.

 Volume control

Turn the VOL. control clockwise to increase the volume, and turn it

counterclockwise to decrease the volume.

 Crossover frequency control

Adjust the high frequency cut-off point. Frequencies higher than the

set frequency are removed.

To emphasize the bass, turn this control toward 35 Hz and increase

the volume.

Note:

Observe the following to avoid malfunction and sound distortion.

Do not set the volume too high on the main unit. The subwoofer may

be damaged.

Power indicator

Before you turn the system on/off on the main unit, minimize the

speaker volume on the main unit and turn the VOL. control of the

subwoofer to " ".

CD-G10000

CP-G10000S

Basic Operation

General control

 To turn the power on

Press the ON/STAND-BY button to turn the power on.

 Illumination light control

When the power is turned on, light illuminates around the display.

Hold down the CLEAR/DIMMER button on the remote control for 2

seconds or more to turn on/off the light.

 Volume control

 Bass control (X-BASS)

 Equalizer

When the EQUALIZER (EQUALIZER MODE) button is pressed, the

current mode setting will be displayed. To change to a different

mode, press the EQUALIZER (EQUALIZER MODE) button repeat-

edly until the desired sound mode appears.

Note:

The extra bass mode is canceled when the EQUALIZER (EQUAL-

IZER MODE) button is pressed.

After use:

Press the ON/STAND-BY button to enter the power stand-by

mode.

Main unit operation:

When the VOL. control is turned clock-

wise, the volume will increase. When it is

turned counterclockwise, the volume will

decrease.

Remote control operation:

Press the VOL (+ or -) button to increase

or decrease the volume.

When the power is first turned on, the

unit will enter the extra bass mode which

emphasizes the bass frequencies, and

"X-BASS" will appear. To cancel the ex-

tra bass mode, press the X-BASS/DEMO

(X-BASS) button.

In CD/TUNER/TAPE mode In GAME/VIDEO mode

30 MAXIMUM0

.....

For rock music.

For pop music.

Vocals are enhanced.

No equalization.

For classical music.

For jazz.

FLAT

ROCK

CLASSIC

POPS

VOCAL

JAZZ

ACTION

SPORTS

RACING

FLAT

ROCK

CLASSIC

For rock music.

For action games.

For sports games.

No equalization.

For classical music.

For car racing games.

CD-G10000

CP-G10000S

Basic Operation

Setting the clock

In this example, the clock is set for the 12-hour (AM 12:00) display.

To confirm the time display:

[When the unit is in the stand-by mode]

Press the CLOCK/TIMER button.

The time display will appear for about 10 seconds.

[When the power is on]

Press the CLOCK/TIMER button.

Within 10 seconds, press the or button to display the time.

The time display will appear for about 10 seconds.

Note:

The "CLOCK" will appear or time will flash to confirm the time dis-

play when the AC power supply is restored after a power failure or

unplugging the unit. If incorrect, readjust the clock as follows.

To readjust the clock:

Perform "Setting the clock" from step 1. If the "CLOCK" does not

appear in step 3, step 4 (for selecting the 12-hour or 24-hour dis-

play) will be skipped.

To change the 12-hour or 24-hour display:

Note:

The clock can also be set with the remote control.

Press the ON/STAND-BY button to turn the power on.

Press the CLOCK/TIMER button.

Within 10 seconds, press the or button to se-

lect "CLOCK", and press the MEMORY/SET button.

Press the or button to select 12-hour or 24-

hour display and then press the MEMORY/SET button.

"AM 12:00" The 12-hour display will appear.

(AM 12:00 - PM 11:59)

"AM 0:00" The 12-hour display will appear.

(AM 0:00 - PM 11:59)

"0:00" The 24-hour display will appear.

(0:00 - 23:59)

Press the or button to adjust the hour and

then press the MEMORY/SET button.

Press the or button once to advance the time by

1 hour. Hold it down to advance continuously.

Press the or button to adjust the minutes and

then press the MEMORY/SET button.

Press the or button once to advance the time by

1 minute. Hold it down to change the time in 5-minute intervals.

1 Clear all the programmed contents. [Refer to "Clearing all the

memory (reset)" on page 43 for details.]

2 Perform "Setting the clock" from step 1.

CD-G10000

CP-G10000S

CD or MP3 disc Playback

Listening to a CD or MP3 disc

This system can play back a standard CD, CD-R/RW in the CD for-

mat and CD-R/RW with MP3 files, but cannot record on them.

Some audio CD-R and CD-RW discs may not be playable due to the

state of the disc or the equipment used for recording.

MP3 is a form of compression. It is an acronym which stands

for MPEG Audio Layer 3.

MP3 is a type of audio code which is processed by significant

compression from the original audio source with very little loss

in sound quality.

Notes:

z " " indicator will light up after the unit reads information on an

MP3 disc.

z This system supports MPEG 1 Layer 3, MPEG 2 Layer 3, and

VBR files.

z During VBR file playback, time counter in the display may differ

from its actual playback time.

Auto power on function:

When you press any of the following buttons, the unit turns on.

z CD button (main unit and remote control): The unit turns on and

the "CD" function is activated.

z / button (main unit and remote control): The unit turns on

and playback of the last function starts (CD/TAPE/TUNER/

GAME).

CD-G10000

CP-G10000S

CD or MP3 disc Playback

z Playback will begin from track 1 on the disc 1. After that disc fin-

ishes playing, the next disc will automatically play.

z After the last track on the fifth disc is played, the unit will stop

automatically.

z When there is no disc in one of the disc trays (1 - 5), the empty

tray will be skipped to the next tray with a disc.

To exchange other discs while playing a disc:

Press one of the 1 - 5 buttons for the stopped disc and within 5

seconds, press the OPEN/CLOSE button and exchange discs.

To remove the discs:

In the stop mode, press the 1 - 5 button and within 5 seconds,

press the OPEN/CLOSE button.

Caution:

z Do not place two discs in one disc tray.

z Do not play discs of special shapes (heart, octagon, etc.) as it

may cause malfunctions.

z Do not push the disc tray while it is moving.

z If the power fails while the tray is open, wait until the power is

restored.

z If the disc tray is stopped with force, "ER-CD20" will appear on

the display for 3 seconds and the unit will not function. If this

occurs, press the ON/STAND-BY button to enter the power

stand-by mode and then turn the power on again.

z If TV or radio interference occurs during CD operation, move the

unit away from the TV or radio.

z If a disc is damaged, dirty, or loaded upside down, the disc will

skip.

Press the ON/STAND-BY button to turn the power on.

Press the CD button.

Press the 1 button and within 5 seconds, press the

OPEN/CLOSE button to open the disc tray 1.

Place the disc on the disc tray 1, label side up.

Be sure to place 3" (8 cm) disc in the middle of the disc trays.

Press the OPEN/CLOSE button to close the disc tray 1.

z Due to the structure of its disc information, it takes longer to

read an MP3 disc than a normal CD (approximately 20 to 90

seconds).

You can place discs on the trays 2 - 5 by following steps 3

- 5.

Press the / button to start playback.

5" (12 cm) 3" (8 cm)

[CD]

Total number of

tracks on the disc

whose number

is flashing

Total playing

time of the disc

whose number

is flashing

Total number

of folders

Total number

of files

MP3 disc indicator

[MP3]

Disc play indicator

CD-G10000

CP-G10000S

CD or MP3 disc Playback

Listening to a CD or MP3 disc (continued)



Various disc functions

Notes:

z Track up/track down is possible only within individual discs.

z The sound is heard during fast forward/fast reverse with a CD,

but not with an MP3 disc. For fast forward or fast reverse of an

MP3 disc, refer to playback time on the display.

Notes for CD:

Notes for MP3 discs:

z Fast forward/fast reverse is possible only within individual tracks.

z When the end of the track is reached during fast forward, the next

track will be played. Playback of the track will begin when its

beginning is reached during fast reverse.



To change the display (MP3 discs only)

Function Main unit Remote

control

Operation

Play Press in the stop

mode.

Stop Press in the playback

mode.

Pause Press in the playback

mode. Press the /

button to resume play-

back from the paused

point.

Track up/

Track down

Press in the playback

or stop mode.

If you press the button

in the stop mode,

press the / button

to start the desired

track.

Fast for-

ward/Fast

reverse

Press and hold down

in the playback mode.

Release the button to

resume playback.

z Fast forward/fast reverse is possible only within individual discs.

z When the end of the last track is reached during fast forward,

"END" will appear on the display and CD operation will be paused.

When the beginning of the first track is reached during fast re-

verse, the unit will enter the playback mode.

While a disc is playing, press the MP3 DIS-

PLAY button.

Each time the button is pressed, the display

will change as follows.

Folder name

File name

Track number

Elapsed

playback time

CD-G10000

CP-G10000S

CD or MP3 disc Playback

Advanced CD or MP3 disc playback



To specify a disc to play

You can play a disc by specifying the disc number.

z Playback will begin from track 1 on the chosen disc.

z After the last track on the chosen disc is played, the unit stops

automatically.

Note:

If the button of the disc tray with no disc is pressed, playback will not

start and the disc indicator will go out.

To stop playback:

Press the button.



Direct track search

By using the direct search buttons, the desired tracks on the current

disc can be played.

If the direct search buttons are pressed while the disc is stopped,

press the / button to start the desired track on the current disc.

Notes:

z A track number higher than the number of tracks on the disc can-

not be selected.

z During random play, direct search is not possible.

Press one of the 1 - 5 buttons to select the desired disc.

Selected disc number

Within 5 seconds, press the DIRECT PLAY button on the

main unit.

Use the direct search buttons on

the remote control to select the de-

sired track while playing the se-

lected disc.

Selected track number

z The direct search buttons allow you to select up to number 9.

z When selecting number 10 or higher, use the "+10" button.

A. For example, to choose 13

1 Press the "+10" button once.

2 Press the "3" button.

B. For example, to choose 30

1 Press the "+10" button three times.

2 Press the "0" button.

CD-G10000

CP-G10000S

CD or MP3 disc Playback

Advanced CD or MP3 disc playback (continued)



Repeat play

Repeat play can play all 5 discs, all tracks on a chosen disc, or a

programmed sequence continuously.

To cancel repeat play:

Press the / button again.

" " will go out.

To cancel repeat play:

Press the DIRECT PLAY button again.

" " will go out.



Random play

The tracks on the disc(s) can be played in random order automatically.

To cancel random play:

Press the / button.

"R" will go out.

To cancel random play:

Press the DIRECT PLAY button.

"R" will go out.

Notes:

z If you press the button during random play, you can move to

the next track by the random operation. On the other hand, the

button does not allow you to move to the previous track. The

beginning of the track being played will be located.

z In random play, the unit will select and play tracks automatically.

(You cannot select the order of the tracks.)

Caution:

After performing repeat or random play, be sure to press the but-

ton. Otherwise, the disc(s) will play continuously.

To repeat all tracks on up to 5 discs:

Press the / button twice.

To repeat desired tracks:

Perform steps 1 - 6 in "Programmed play" section on page 25 and

then press the / button twice.

To repeat all tracks on the chosen disc:

1 Press one of the 1 - 5 buttons.

2 Within 5 seconds, press the DIRECT PLAY

button twice.

To random play all tracks on up to 5 discs:

Press the RANDOM button on the remote control.

To random play all tracks on the chosen disc:

1 Press one of the 1 - 5 but-

tons.

2 Within 5 seconds, press the DI-

RECT PLAY button.

3 Press the RANDOM button on

the remote control.

CD-G10000

CP-G10000S

CD or MP3 disc Playback



Programmed play

You can choose up to 32 selections for playback in the order you

like.

To cancel the programmed play mode:

While in the stop mode and the "MEMORY" indicator is lit, press the

CLEAR/DIMMER button on the remote control. The "MEMORY"

indicator will disappear and all the programmed contents will be

cleared.

Adding tracks to the program:

If a program has been previously stored, the "MEMORY" indicator

will be displayed. Then follow steps 1 - 6 to add tracks. The new

tracks will be stored after the last track of the original program.

To check which tracks are programmed:

While the unit is stopped in the programmed play mode, press the

or button.

Notes:

z When a disc with programmed tracks is ejected, the program is

automatically canceled.

z Even if you press the ON/STAND-BY button to enter the stand-by

mode or change the function from CD to another, the pro-

grammed selections will not be cleared.

z During the program operation, random play is not possible.

z During programmed play, the DIRECT PLAY button will not work.

While in the stop mode, press the

MEMORY/SET (MEMORY) button

to enter the programming save

mode.

Press one of the 1 - 5 buttons

to select the desired disc.

Selected disc number

Press the direct search buttons

on the remote control to select

the desired track.

Selected track number

You can also select a track by pressing the or button.

Press the MEMORY/SET (MEMO-

RY) button to save the track

number.

Repeat steps 2 - 4 for other tracks. Up to 32 tracks can be

programmed.

If you make a mistake, the programmed tracks can be cleared

by pressing the CLEAR/DIMMER button.

6 Press the button.

The total number of memory will ap-

pear.

7 Press the / button to start playback.

To clear the programmed selections:

Press the CLEAR/DIMMER button on the re-

mote control while the "MEMORY" indicator is

flashing.

Each time the button is pressed, one track will

be cleared, beginning with the last track pro-

grammed.

CD-G10000

CP-G10000S

CD or MP3 disc Playback

MP3 navigation (only for MP3 files)

MP3 navigation:

You can search and play files by folder or title. For example, when

you assign three titles to a file, enter genre (such as jazz) as title 1,

album name as title 2, and music title as title 3 to search the file by

any title.

z You can search and play files by folder or title 1/2/3 within one

MP3 disc (see page 27).

z By entering a name, you can search files by folder or title 1/2/3

within one MP3 disc (see page 28).

z Folders or titles can be programmed within one MP3 disc (see

page 29).

When you enter file names on your PC, connect words with

hyphens. This product recognizes the first word as title 1, second

one as title 2, and third one as title 3. Up to three words can be rec-

ognized.

Notes:

z MP3 files must have the extension ".mp3".

z Up to 100 folders or 300 files can be read on the unit. If either

limit is exceeded, no more folders/files are displayed.

z This unit recognizes and displays up to 48 characters for folder

names, and up to 32 characters for title 1/2/3.

z All file/folder names appear in uppercase.

Example:

(File name)

(POPULAR-HITS 1-A MUSIC.mp3)

AAA

(POPULAR-HITS 2-B MUSIC.mp3)

(JAZZ-HITS 1-A MUSIC.mp3)

BBB

(JAZZ-HITS 2-B MUSIC.mp3)

(ROCK-HITS 1-A MUSIC.mp3)

CCC

(ROCK-HITS 2-B MUSIC.mp3)

(ROCK-HITS 3-C MUSIC.mp3)

(ROCK-HITS 4-D MUSIC.mp3)

Folder

Title 1 Title 2 Title 3

Folder Title 1

Title 2 Title 3

CD-G10000

CP-G10000S

CD or MP3 disc Playback



File search (by folder or title 1/2/3)

You can search and play files by folder or title 1/2/3 within one MP3 disc.

File search by title 1/2/3:

z In step 5, select "T-1", "T-2" or "T-3" and follow the same steps

as file search by folder.

z The unit searches all files on the disc, regardless of the folder.

To stop playback:

Press the button.

To exit the MP3 navigation mode:

In the stop mode, press the button.

Notes:

z In the MP3 navigation mode, direct play and direct search func-

tions are disabled.

z If a folder, title or file name does not appear, or appears incor-

rectly, remove and reinsert the disc and try again.

z If you press the RANDOM button in the stop mode, the MP3 nav-

igation mode will be canceled.

Press one of the 1 - 5 buttons to select a disc tray con-

taining an MP3 disc.

Press the / button, and the unit starts to read the MP3

disc.

Press the button to stop playback.

"NAVI READ" appears and the display shows the total number

of folders and files on the selected disc.

Press the MP3 NAVIGATION button.

Press the , , or button to se-

lect "FOL", "T-1", "T-2" or "T-3".

To search files by folder name, se-

lect "FOL" (will flash).

The following steps describe file search by folder:

Press the ENTER button.

The total number of folders (or titles) appears for 2 seconds,

and names of the first 2 folders (or titles) are displayed.

z The MP3 NAVIGATION button allows you to go one step

back.

z Press the MP3 DISPLAY button to

check the number of files.

Total number

of folders

Total number

of files

MP3 disc

indicator

Folder Title 1

Title 2 Title 3

Folder name

Use the or button to scroll and select a folder (or title),

and then press the ENTER button.

If you press the / button instead of the ENTER button, all

files in the selected folder (or title) are played.

Use the or button to scroll and select a file.

Press the / button to start playback.

The unit plays from the selected file to the last file in the select-

ed folder (or title), and the previous display returns.

Folder name

File name

CD-G10000

CP-G10000S

CD or MP3 disc Playback

MP3 navigation (only for MP3 files) (continued)



Character search (for folder or title 1/2/3)

By entering a name, you can search files by folder or title 1/2/3

within one MP3 disc.

To exit the MP3 navigation mode:

In the stop mode, press the button.

Notes:

z The unit searches regardless of the case, and found names

appear in uppercase.

z Some symbols do not appear properly.

Character entry with direct buttons:

For example, press "2" four times to enter "C".

Perform steps 1 - 3 in "File search (by folder or title 1/2/3)"

on page 27.

Press the MP3 NAVIGATION button.

Press the , , or button to se-

lect "FOL", "T-1", "T-2" or "T-3".

To search files by folder name, se-

lect "FOL" (will flash).

Press the CHARACTER button for 2 seconds.

The display will be ready for editing characters.

1st row: String table

2nd row: Input editor (8 digits)

Press the or button to select the desired alphabet.

Press the or button to go to the next page of character

display.

Press the CHARACTER button and the active character will

be entered in the 2nd row of the display.

To delete an entered character, move the cursor to the charac-

ter with the or button and press the CLEAR/DIMMER but-

ton on the remote control.

Repeat steps 5 and 6 to enter characters.

In the folder (or title) name search, you do not have to enter the

full name. The unit searches for names beginning with the en-

tered characters.

Folder Title 1

Title 2 Title 3

When finished, press the ENTER button. The unit searches

for the same name within folders (or titles).

If the search word is not in the folder (or title) name, "NOT

FOUND" appears and the menu returns.

Use the or button to scroll and select a folder (or title).

Press the / button to start playback.

All files in the selected folder (or title) are played, and the previ-

ous display returns.

The direct buttons on the remote

control can also be used for charac-

ter entry.

In step 5 on the left, use buttons 0 -

9 to enter alphabets.

Alphabet types change as you press

a button.

2 A B C

1 2 ABC 3 DEF 4 GHI 5 JKL 6 MNO

7 PQRS

8 TUV

9 WXYZ

: indicates a space.

Characters:

CD-G10000

CP-G10000S

CD or MP3 disc Playback



Programmed play (for folder, title 1/2/3)

Folders or titles can be programmed within one MP3 disc.

Folder, title 1, title 2 and title 3 cannot be programmed together

simultaneously.

To stop playback:

Press the button.

z The programmed contents are not cleared.

To check, add or delete programmed contents:

In the stop mode, select a folder (or title) with the or button. If

the folder (or title) is programmed, "MEMORY" flashes.

z When you press the MEMORY button with "MEMORY" flashing,

the folder (or title) is removed from the program.

z If you press the MEMORY button with "MEMORY" off, the folder

(or title) is added to the program.

z To clear all programs, press the CLEAR/DIMMER button in the

stop mode.

To exit the MP3 navigation mode:

In the stop mode, press the button.

z The programmed contents are cleared.

Notes:

z The programmed contents are cleared when you eject a disc,

play another disc, switch the function, or enter the stand-by mode

with the ON/STAND-BY button.

z During programmed play, the DIRECT PLAY button on the main

unit will not work.

z If you press the RANDOM button in the stop mode, the MP3 nav-

igation mode will be canceled.

If tracks are programmed using track numbers (see "Pro-

grammed play" on page 25):

In the MP3 navigation mode, only programs by folder (or title) name

are played. When you exit the mode, the programs by folder (or title)

name are cleared.

Even when you exit the MP3 navigation mode, programs by track

number are retained, and you can play tracks according to the num-

bers.

(Programs by track number are cleared when you remove the disc.)

Perform steps 1 - 3 in "File search (by folder or title 1/2/3)"

on page 27.

Press the MP3 NAVIGATION button.

Press the , , or button to select "FOL", "T-1", "T-2"

or "T-3" and then press the ENTER button.

The total number of folders (or titles) appears for 2 seconds,

and names of the first 2 folders (or titles) are displayed.

Press the or button to select the desired folder (or title)

and then press the MEMORY button.

The folder (or title) is memorized with all the files.

Repeat step 4 for other folders (or titles).

Up to 10 folders (or 10 titles) can be programmed.

Press the / button to start playback.

Programmed play will always start from the smallest folder (or

title) number.

Flashes if the folder (or title)

is programmed

CD-G10000

CP-G10000S

Radio

Listening to the radio

Auto power on function:

When you press any of the following buttons, the unit turns on.

z TUNER (BAND) button (main unit and remote control): The unit

turns on and the "TUNER" function is activated.

z / button (main unit and remote control): The unit turns on

and playback of the last function starts (CD/TAPE/TUNER/

GAME).



Tuning

Notes:

z When radio interference occurs, auto scan tuning may stop auto-

matically at that point.

z Auto scan tuning will skip weak signal stations.

z To stop the auto tuning, press the TUNING button again.

To receive an FM stereo transmission:

Press the TUNER (BAND) button to display the "ST" indicator.

z " " will appear when an FM broadcast is in stereo.

z If the FM reception is weak, press the TUNER (BAND) button to

extinguish the "ST" indicator. The reception changes to monau-

ral, and the sound becomes clearer.

Press the ON/STAND-BY button to turn the power on.

Press the TUNER (BAND) button repeatedly to select the

desired frequency band (FM or AM).

Press the TUNING ( or ) button to tune in to the desired

station.

Manual tuning:

Press the TUNING button as many times as required to tune in

to the desired station.

Auto tuning:

When the TUNING button is pressed for more than 0.5 sec-

onds, scanning will start automatically and the tuner will stop at

the first receivable broadcast station.

FM stereo mode indicator

FM stereo receiving indicator

CD-G10000

CP-G10000S

Radio

 Memorizing a station

You can store 40 AM and FM stations in memory and recall them at

the push of a button. (Preset tuning)

Note:

The backup function protects the memorized stations for a few

hours should there be a power failure or the AC power cord become

disconnected.

 To recall a memorized station

 To scan the preset stations

The stations saved in memory can be scanned automatically. (Pre-

set memory scan)

 To erase entire preset memory

Perform steps 1 - 3 in "Tuning" on page 30.

Press the MEMORY/SET (MEMORY) button to enter the

preset tuning saving mode.

Within 30 seconds, press the PRESET ( or ) button to

select the preset channel number.

Store the stations in memory, in order, starting with preset

channel 1.

Within 30 seconds, press the MEMORY/SET (MEMORY)

button to store that station in memory.

If the "MEMORY" and preset number indicators go out before

the station is memorized, repeat the operation from step 2.

Repeat steps 1 - 4 to set other stations, or to change a pre-

set station.

When a new station is stored in memory, the station previously

memorized for that preset channel number will be erased.

Press the PRESET ( or ) button for less than 0.5 seconds to se-

lect the desired station.

1 Press the PRESET ( or ) button for more than 0.5 seconds.

The preset number will flash and the programmed stations will be

tuned in sequentially, for 5 seconds each.

2 Press the PRESET ( or ) button again when the desired sta-

tion is located.

1 Press the ON/STAND-BY button to enter the stand-by mode.

2 While pressing down the button and the X-BASS/DEMO but-

ton, press the CLOCK/TIMER button until "TUNER CL" appears.

CD-G10000

CP-G10000S

Tape Playback

Listening to a cassette tape (TAPE 1 or TAPE 2)

 Tape playback

Auto power on function:

When you press any of the following buttons, the unit turns on.

z TAPE (1 2) button (main unit and remote control): The unit

turns on and the "TAPE" function is activated.

z / button (main unit and remote control): The unit turns on

and playback of the last function starts (CD/TAPE/TUNER/

GAME).

Before playback:

z For playback, use normal or low-noise tapes for

the best sound. (Metal or CrO tapes are not rec-

ommended.)

Do not use C-120 tapes or poor-quality tapes, as

they may cause malfunctions.

z Before loading a tape into the cassette compartment,

tighten the slack with a pen or a pencil.

Press the ON/STAND-BY button to turn the power on.

Open the cassette com-

partment by pushing the

area marked " ".

Load a cassette into the

TAPE 1 compartment or

TAPE 2 compartment with

the side to be played fac-

ing toward you.

Press the TAPE (1 2) button to select the cassette you

want to listen to.

Press the / button to

start playback.

Tape play indicator

TAPE 1 TAPE 2

CD-G10000

CP-G10000S

Tape Recording

 Various tape functions

Caution:

z To remove the cassette, press the button, and then open the

compartment.

z Before changing from one tape operation to another, press the

button.

z If a power failure occurs during tape operation, the tape head will

remain engaged with the tape and the cassette door will not

open. In this case, wait until the power is restored.

Recording on a cassette tape

Function Main unit Remote

control

Operation

Play Press in the stop

mode.

Stop Press in the playback,

fast forward or fast re-

wind mode.

Fast for-

ward/Fast

rewind

Press in the playback

or stop mode.

(TAPE 2

only)

Before recording:

z When recording important selections, make a preliminary test to

ensure that the desired material is properly recorded.

SHARP is not liable for damage or loss of your recording arising

from malfunction of this unit.

z The volume and sound controls can be adjusted with no effect

on the recorded signal (Variable Sound Monitor).

z For recording, use only normal tapes. Do not use metal or

CrO tapes.

z Recording can be operated in the TAPE 2 compartment only.

The TAPE 1 is for playback only.

Erase-prevention tab of cassette tapes:

z When recording on a cassette tape, make sure that the erase-

prevention tabs are not removed. Cassettes have removable

tabs that prevent accidental recording or erasing.

To protect the recorded sound, remove the tab after recording.

Cover the tab hole with adhesive tape to record on the tape with-

out the tab.

Side A

Tab for side B

Tab for side A

CD-G10000

CP-G10000S

Tape Recording

Recording on a cassette tape (continued)

 Recording from a CD or MP3 disc

You can record the desired disc using the DIRECT PLAY button.

To stop recording:

Press the button.

The disc and tape will stop.

Press the ON/STAND-BY button to turn the power on.

Press the CD button.

Load a cassette into the TAPE 2 cassette compartment

with the side to be recorded on facing you.

Wind past the leader of the tape, on which recording cannot be

performed.

Press the button.

Recording will be paused.

Press one of the 1 - 5 buttons to select the desired disc.

Within 5 seconds, press the DIRECT PLAY button to start

recording.

Recording is started from the selected disc. When the play-

back of the last track is finished or the end of the tape is

reached, the disc and the cassette will stop automatically.

z Playback of the disc will start approximately 7 seconds after

the tape starts.

CD-G10000

CP-G10000S

Tape Recording

Sequential recording from several discs:

To perform programmed recording:

To stop recording:

Press the button.

The disc and tape will stop.

 Recording from the radio

To interrupt recording:

Press the button.

To resume recording, press the / button.

To stop recording:

Press the button.

Note:

If you hear a whistling noise while recording an AM station, move

the AM loop antenna.

 Dubbing from tape to tape

You can record from TAPE 1 to TAPE 2.

To stop dubbing:

Press the button.

TAPE 1 and TAPE 2 will simultaneously stop.

 Erasing recorded tapes

Note:

Make sure that the TAPE 1 is not in use.

1 Perform steps 1 - 5 in "Recording from a CD or MP3 disc" on page

34.

2 Within 5 seconds, press the / button.

1 Program discs and tracks (see pages 25, 29).

2 Press the button.

3 Press the / button.

Tune in to the desired station (see page 30).

Load a cassette into the TAPE 2 cassette compartment

with the side to be recorded on facing you.

Wind past the leader of the tape, on which recording cannot be

performed.

Press the button.

Recording will be paused.

Press the / button to start recording.

Press the ON/STAND-BY button to turn the power on.

Load a prerecorded cassette

into the TAPE 1 cassette com-

partment. Insert a blank tape

into the TAPE 2 cassette com-

partment.

It is recommended that the recording tape is the same length as

the master tape.

Press the TAPE (1 2) button until "TAPE 1" appears on

the display.

Press the button.

Recording will be paused.

Press the / button to start dubbing.

1 Load the tape to be erased into the TAPE 2 cassette compart-

ment with the side to be erased facing toward you.

2 Press the TAPE (1 2) button until "TAPE 2" appears on the dis-

play.

3 Press the button.

4 Press the / button to start erasing.

TAPE 1 TAPE 2

CD-G10000

CP-G10000S

Advanced Features

Timer and sleep operation

Timer playback:

The unit turns on and plays the desired source (CD, MP3 disc,

tuner, tape) at a preset time.

Timer recording:

The unit turns on and starts recording from the tuner at the preset

time.

Using the once timer and daily timer in combination:

For example, use the once timer to record a radio program, and use

the daily timer to wake up.

Note:

When set times for the daily timer and once timer overlap, the once

timer takes priority. Allow an interval of at least 1 minute between

operations.

 Timer playback or timer recording

Before setting timer:

This unit has 2 types of timer: ONCE TIMER and DAILY TIMER.

Once timer: Once timer play or once timer recording works for

one time only at a preset time.

For example, if you are away but want to record a program on a ra-

dio station.

Daily timer: Daily timer play or daily timer recording works at

the same preset time every day.

For example, set the timer as a wake-up call every morning.

1 Set the daily timer (pages 36 - 38).

2 Set the once timer (pages 36 - 38).

Start

Daily timer

Once timer

1 minute or more

Stop Start Stop

1 Check that the clock is set to the correct time (refer to page 19).

If it is not set, you cannot use the timer function.

2 For timer playback: Load a cassette or discs to be played.

For timer recording: Load a cassette for recording in the

TAPE 2 cassette compartment.

Press the ON/STAND-BY button to turn the power on.

Press the CLOCK/TIMER button.

Within 10 seconds, press the or button to se-

lect "ONCE" or "DAILY", and press the MEMORY/SET but-

ton.

Set the clock to the correct time if "ONCE" or "DAILY" does not

appear.

CD-G10000

CP-G10000S

Advanced Features

Continued to the next page

Within 10 seconds, press the or button to se-

lect "ONCE SET" or "DAILY SET", and press the MEMORY/

SET button.

Press the or button to select "PLAY" or

"REC", and press the MEMORY/SET button.

The illustrations show the daily timer setting.

Press the or button to adjust the hour and

then press the MEMORY/SET button.

The illustrations show the timer playback setting in the daily tim-

er mode.

Press the or button to adjust the minutes and

then press the MEMORY/SET button.

8 Set the time to finish as in steps 6 and 7 above.

White Red

Folder name

Switch input with the or button, and then

press the MEMORY/SET button.

To select the timer playback source: CD, TUNER, TAPE 1 or

TAPE 2.

To select the timer recording source: TUNER.

When you select the tuner, select a station by pressing the

or button, and then press the MEMORY/SET

button.

If a station has not been programmed, "NO PRESET" will be

displayed and timer setting will be canceled.

Adjust the volume using the VOL. control, and then press

the MEMORY/SET button.

Do not turn the volume up too high.

Press the ON/STAND-BY button to enter the power stand-

by mode.

The "TIMER" indicator lights up and the unit is ready for timer

playback or timer recording.

CD-G10000

CP-G10000S

Advanced Features

Timer and sleep operation (continued)

Note:

Checking the timer setting in the timer stand-by mode:

Canceling the timer setting in the timer stand-by mode:

Reusing the memorized timer setting:

The timer setting will be memorized once it is entered. To reuse the

same setting, perform the following operations.

Note:

The timer can also be set with the remote control.

When the preset time is reached, playback or recording will

start.

The volume will increase gradually until it reaches the preset

volume.

When the timer end time is reached, the system will enter

the power stand-by mode automatically.

Once timer:

The timer will be canceled.

Daily timer:

The timer will operate at the same time every day. It will contin-

ue until the daily timer setting is canceled. Cancel the daily timer

when it is not in use.

When performing timer playback or recording using another unit con-

nected to the GAME INPUT jacks, select "GAME" in step 9.

This unit will turn on or enter the power stand-by mode automatically,

however, the connected unit will not turn on or off.

1 Press the CLOCK/TIMER button.

2 Within 10 seconds, press the or button to select

"ONCE" or "DAILY", and press the MEMORY/SET button.

3 Within 10 seconds, press the or button to select

"ONCE CALL" or "DAILY CALL", and press the MEMORY/SET

button.

The unit returns to the timer stand-by mode after displaying the

settings in order.

1 Press the CLOCK/TIMER button.

2 Within 10 seconds, press the or button to select

"ONCE" or "DAILY", and press the MEMORY/SET button.

3 Within 10 seconds, press the or button to select

"ONCE OFF" or "DAILY OFF", and press the MEMORY/SET but-

ton.

Timer will be canceled (the setting will not be canceled).

1 Turn the power on and press the CLOCK/TIMER button.

2 Within 10 seconds, press the or button to select

"ONCE" or "DAILY", and press the MEMORY/SET button.

3 Within 10 seconds, press the or button to select

"ONCE ON" or "DAILY ON", and press the MEMORY/SET button.

4 Press the ON/STAND-BY button to enter the power stand-by

mode.

CD-G10000

CP-G10000S

Advanced Features

 Sleep operation

The radio, CD, MP3 disc and cassette tape can all be turned off

automatically.

To confirm the remaining sleep time:

To cancel the sleep operation:

Press the ON/STAND-BY button while "SLEEP" is indicated.

To cancel the sleep operation without setting the system to the

stand-by mode, proceed as follows.

 To use timer and sleep operation together

Sleep and timer playback:

For example, you can fall asleep listening to the radio and wake up

to CD in the next morning.

Sleep and timer recording:

For example, you can fall asleep listening to the CD and record

radio programs while sleeping.

Caution:

When using the cassette deck, be sure the tape length is long

enough to perform both functions. If you want to sleep and wake up

listening to a tape, and the length of the tape is shorter than the

sleep timer setting, timer playback or recording will not be possible.

Play back the desired sound source.

Press the CLOCK/TIMER button.

Within 10 seconds, press the

or button to select

"SLEEP", and press the MEMO-

RY/SET button.

Press the or button to select the time.

(Maximum: 3 hours - Minimum: 1 minute)

z 3 hours - 5 minutes 5-minute intervals

z 5 minutes - 1 minute 1-minute intervals

Press the MEMORY/SET but-

ton.

"SLEEP" will appear.

The unit will enter the power stand-by mode automatically

after the preset time has elapsed.

The volume will be turned down 1 minute before the sleep op-

eration finishes.

1 While "SLEEP" is indicated, press the CLOCK/TIMER button.

2 Within 10 seconds, press the or button to select

"SLEEP X : XX".

"X : XX" is remaining sleep time.

The remaining sleep time is displayed for about 10 seconds.

z You can change the remaining sleep time while it is displayed by

pressing the MEMORY/SET button (steps 4 - 5).

1 While "SLEEP" is indicated, press the CLOCK/TIMER button.

2 Within 10 seconds, press the or button to select

"SLEEP OFF", and press the MEMORY/SET button.

1 Set the sleep time (see left, steps 1 - 5).

2 While the sleep timer is set, set the timer playback or recording

(steps 2 - 10, pages 36 - 37).

Sleep timer setting

Timer playback or

recording setting

Sleep operation will

automatically stop.

Timer playback or recording

start time

End time

1 minute - 3 hours Desired time

CD-G10000

CP-G10000S

Advanced Features

Enhancing your system

The connection cord is not included. Purchase a commercially avail-

able cord as shown below.

 Listening to sounds of game, VCR, DVD, etc.

Note:

To prevent noise interference, place the unit away from the televi-

sion.

Auto power on function:

When you press any of the following buttons, the unit turns on.

z GAME/VIDEO button (main unit and remote control): The unit

turns on and the "GAME" function is activated.

/ button (main unit and remote control): The unit turns on

and playback of the last function starts (CD/TAPE/TUNER/

GAME).

 To record sounds of game, VCR, etc.

Yellow

To the line output jacks

To video

input jack

RCA cord

(not supplied)

Video cable

(not supplied)

Video cable

(not supplied)

Yellow

Red

White

RedWhiteYellow

Game system, VCR,

DVD player, etc.

Connect a video game system, VCR, DVD, etc. to the front

GAME INPUT (VIDEO, AUDIO L and R) jacks.

Connect a TV to the rear VIDEO OUT jack.

Switch the TV input to auxiliary.

Press the ON/STAND-BY button to turn the power on.

Press the GAME/VIDEO button.

Play the connected equipment.

You can enjoy sounds from the supplied speakers and images

on the TV.

Insert a cassette in the TAPE 2 cassette compartment.

Press the GAME/VIDEO button.

Press the button.

4 Press the / button.

Start the game system, VCR, etc.

CD-G10000

CP-G10000S

References

 Headphones

z Before plugging in or unplugging the headphones, reduce the

volume.

z Be sure your headphones have a 1/8" (3.5 mm) diameter plug

and impedance between 16 and 50 ohms. The recommended

impedance is 32 ohms.

z Plugging in the headphones disconnects the speakers automati-

cally. Adjust the volume using the VOL. control.

Troubleshooting chart

Many potential problems can be resolved by the owner without call-

ing a service technician.

If something is wrong with this product, check the following before

calling your authorized SHARP dealer or service center.

 General

 CD player

Symptom Possible cause

The clock is not set to the

correct time.

Did a power failure occur? Reset

the clock. (Refer to page 19.)

z When a button is pressed,

the unit does not respond.

z Set the unit to the power stand-

by mode and then turn it back on.

If the unit still malfunctions, reset

it. (Refer to page 43.)

z No sound is heard. z Is the volume level set to "0"?

z Are the headphones connected?

z Are the speaker wires discon-

nected?

Symptom Possible cause

z Playback does not start. z Is the disc loaded upside down?

z Playback stops in the mid-

dle or is not performed

properly.

z Does the disc satisfy the stan-

dards?

z Is the disc distorted or

scratched?

z Playback sounds are

skipped, or stopped in the

middle of a track.

z Is the unit located near excessive

vibrations?

Is the disc very dirty?

Has condensation formed inside

the unit?

CD-G10000

CP-G10000S

References

Troubleshooting chart (continued)

 Cassette deck

 Remote control

 Tuner

 Condensation

Sudden temperature changes, storage or operation in an extremely

humid environment may cause condensation inside the cabinet (CD

pickup, tape heads, etc.) or on the transmitter on the remote control.

Condensation can cause the unit to malfunction. If this happens,

leave the power on with no disc (or cassette) in the unit until normal

playback is possible (about 1 hour). Wipe off any condensation on

the transmitter with a soft cloth before operating the unit.

Symptom Possible cause

z Cannot record. z Is the erase-prevention tab re-

moved?

Cannot record tracks with

proper sound quality.

Is it a normal tape? (You cannot

record on a metal or CrO tape.)

z Cannot erase completely.

z Sound skipping. z Is there slack in the tape?

Is the tape stretched?

z Cannot hear treble. z Are the capstans, pinch rollers,

or heads dirty?

z Sound fluctuation.

z Cannot remove the tape. z If a power failure occurs during

playback, the heads remain en-

gaged with the tape. Do not open

the compartment with great

force.

Symptom Possible cause

The remote control does

not operate.

Is the AC power cord of the unit

plugged in?

Is the battery polarity correct?

z Are the batteries dead?

z Is the distance or angle incor-

rect?

z Does the remote control sensor

receive strong light?

Symptom Possible cause

z The radio makes unusual

noises continuously.

z Is the unit placed near the TV or

computer?

Is the FM antenna or AM loop an-

tenna placed properly? Move the

antenna away from the AC power

cord if it's located nearby.

CD-G10000

CP-G10000S

References

 If trouble occurs

When this product is subjected to strong external interference

(mechanical shock, excessive static electricity, abnormal supply

voltage due to lightning, etc.) or if it is operated incorrectly, it may

malfunction.

If such a problem occurs, do the following:

1 Set the unit to the stand-by mode and turn the power on again.

2 If the unit is not restored in the previous operation, unplug and

plug in the unit, and then turn the power on.

Note:

If neither operation above restores the unit, clear all the memory by

resetting it.

 Clearing all the memory (reset)

1 Press the ON/STAND-BY button to enter the power stand-by

mode.

2 While pressing down the button and the X-BASS/DEMO but-

ton, press the PRESET button until "CLEAR ALL"

appears.

Caution:

This operation will erase all data stored in memory including clock,

timer settings, tuner preset, and CD program.

 Before transporting the unit

Remove all CDs from the unit. Make sure there is no CD in the disc

tray. Then, set the unit to the power stand-by mode. Carrying the

unit with discs left inside can damage the unit.

 Care of compact discs

Compact discs are fairly resistant to damage, however mistracking

can occur due to an accumulation of dirt on the disc surface. Follow

the guidelines below for maximum enjoyment from your CD collec-

tion and player.

z Do not write on either side of the disc, particularly the non-label

side from which signals are read. Do not mark this surface.

z Keep your discs away from direct sunlight, heat, and excessive

moisture.

Always hold the CDs by the edges. Fingerprints, dirt, or water on

the CDs can cause noise or mistracking. If a CD is dirty or does

not play properly, clean it with a soft, dry cloth, wiping straight out

from the center, along the radius.

NO YES

Correct

CD-G10000

CP-G10000S

References

Maintenance

 Cleaning the tape-handling parts

Dirty heads, capstans or pinch rollers can cause poor sound and

tape jams. Clean these parts with a cotton swab moistened with

commercial head/pinch roller cleaner or isopropyl alcohol.

When cleaning the heads, pinch rollers, etc., unplug the unit

which contains high voltages.

z After long use, the deck's heads and capstans may become mag-

netized, causing poor sound. Demagnetize these parts once

every 30 hours of playing/recording time by using a commercial

tape head demagnetizer. Read the demagnetizer's instructions

carefully before use.

 Cleaning the CD pickup lens

In order to ensure proper operation of the CD player, preventative

maintenance (cleaning of the laser pickup lens) should be per-

formed periodically. Lens cleaners are commercially available. Con-

tact your local CD software dealer for options.

 Cleaning the cabinet

Periodically wipe the cabinet with a soft cloth and a diluted soap

solution, then with a dry cloth.

Caution:

Do not use chemicals for cleaning (gasoline, paint thinner, etc.).

It may damage the cabinet finish.

Do not apply oil to the inside of the unit. It may cause malfunc-

tions.

Playback head Erase head

Capstan Recording/Playback head

Pinch roller

TAPE 1

TAPE 2

CD-G10000

CP-G10000S

References

Specifications

As part of our policy of continuous improvement, SHARP reserves

the right to make design and specification changes for product

improvement without prior notice. The performance specification fig-

ures indicated are nominal values of production units. There may be

some deviations from these values in individual units.

 General

 CD player

 Amplifier

Power source AC 120 V, 60 Hz

Power

consumption

175 W

Dimensions Width: 10-1/4" (260 mm)

Height: 13" (330 mm)

Depth: 12-7/8" (326 mm)

Weight 23.0 lbs. (10.4 kg)

Type 5-disc multi-play compact disc player

Signal readout Non-contact, 3-beam semiconductor laser

pickup

D/A converter 1-bit D/A converter

Frequency

response

20 - 20,000 Hz

Dynamic range 90 dB (1 kHz)

Output power

Front speakers 135 watts minimum RMS per channel into

8 ohms from 100 Hz to 20 kHz, 10% total

harmonic distortion

Rear speakers 65 watts minimum RMS per channel into

16 ohms from 5 kHz to 20 kHz, 10% total

harmonic distortion

Output terminals Front speakers: 8 ohms

Rear speakers: 16 ohms

Headphones: 16 - 50 ohms

(recommended: 32 ohms)

Subwoofer pre-out (audio signal):

200 mV/10 k ohms at 70 Hz

Video out: 1 Vp-p (75 ohms)

Input terminals Game/ Auxiliary (audio signal):

500 mV/ 47 k ohms

Game/Video: 1 Vp-p (75 ohms)

CD-G10000

CP-G10000S

References

Specifications (continued)

 Tuner

 Cassette deck

 Front speaker

 Rear speaker

 Active subwoofer

Frequency range FM: 87.5 - 108.0 MHz

AM: 530 - 1,720 kHz

Frequency

response

50 - 14,000 Hz (normal tape)

Signal/noise ratio 55 dB (TAPE 1, playback)

50 dB (TAPE 2, recording/playback)

Wow and flutter 0.3 % (WRMS)

Type 2-way type speaker system

2" (5 cm) tweeter 1

5-1/8" (13 cm) woofer 2

Maximum input

power

270 W

Rated input power 135 W

Impedance 8 ohms

Dimensions Width: 8-11/16" (220 mm)

Height: 16-9/16" (420 mm)

Depth: 16-15/16" (430 mm)

Weight 12.1 lbs. (5.5 kg)/each

Type Full-range speaker system

4" (10 cm) speaker 2

Maximum input

power

130 W

Rated input power 65 W

Impedance 16 ohms

Dimensions Width: 7-7/8" (200 mm)

Height: 16-9/16" (420 mm)

Depth: 16-15/16" (430 mm)

Weight 8.8 lbs. (4.0 kg)/each

Power source AC 120 V, 60 Hz

Power

consumption

120 W

Output power 400 watts minimum RMS into 6 ohms from

50 Hz to 120 Hz, 10% total harmonic distor-

tion

Input terminals Subwoofer input (audio signal):

200mV / 10 k ohms at 70 Hz

Speaker type 10" (25 cm) woofer

Impedance 6 ohms

Dimensions Width: 15-3/4" (400 mm)

Height: 16-9/16" (420 mm)

Depth: 20-1/16" (510 mm)

Weight 47.6 lbs. (21.6 kg)

SHARP ELECTRONICS CORPORATION

Sharp Plaza, Mahwah, New Jersey 07430-2135

SHARP CORPORATION

9906

Printed in Malaysia

TINSEA075AWZZ

04K R YT 1

SHARP ELECTRONICS CORPORATION

Sharp Plaza, Mahwah, New Jersey 07430-2135

SHARP CORPORATION

9906

CONSUMER LIMITED WARRANTY

SHARP ELECTRONICS CORPORATION warrants to the first consumer purchaser that this Sharp brand product (the “Product”), when shipped in its original con-

tainer, will be free from defective workmanship and materials, and agrees that it will, at its option, either repair the defect or replace the defective Product or part thereof

with a new or remanufactured equivalent at no charge to the purchaser for parts or labor for the period(s) set forth below.

This warranty does not apply to any appearance items of the Product nor to the additional excluded item(s) set forth below nor to any Product the exterior of which has

been damaged or defaced, which has been subjected to improper voltage or other misuse, abnormal service or handling, or which has been altered or modified in

design or construction.

In order to enforce the rights under this limited warranty, the purchaser should follow the steps set forth below and provide proof of purchase to the servicer.

The limited warranty described herein is in addition to whatever implied warranties may be granted to purchasers by law. ALL IMPLIED WARRANTIES INCLUDING

THE WARRANTIES OF MERCHANTABILITY AND FITNESS FOR USE ARE LIMITED TO THE PERIOD(S) FROM THE DATE OF PURCHASE SET FORTH BELOW.

Some states do not allow limitations on how long an implied warranty lasts, so the above limitation may not apply to you.

Neither the sales personnel of the seller nor any other person is authorized to make any warranties other than those described herein, or to extend the duration of any

warranties beyond the time period described herein on behalf of Sharp.

The warranties described herein shall be the sole and exclusive warranties granted by Sharp and shall be the sole and exclusive remedy available to the purchaser.

Correction of defects, in the manner and for the period of time described herein, shall constitute complete fulfillment of all liabilities and responsibilities of Sharp to the

purchaser with respect to the Product, and shall constitute full satisfaction of all claims, whether based on contract, negligence, strict liability or otherwise. In no event

shall Sharp be liable, or in any way responsible, for any damages or defects in the Product which were caused by repairs or attempted repairs performed by anyone

other than an authorized servicer. Nor shall Sharp be liable or in any way responsible for any incidental or consequential economic or property damage. Some states

do not allow the exclusion of incidental or consequential damages, so the above exclusion may not apply to you.

THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY ALSO HAVE OTHER RIGHTS WHICH VARY FROM STATE TO STATE.

Model Specific Section

Your Product Model Number & Description:

(Be sure to have this information available when you need service for your Product.)

Warranty Period for this Product: One (1) year parts and labor from the date of purchase.

Additional Item(s) Excluded from Warranty Coverage (if any): Non-functional accessories, supplies, and consumable items.

Where to Obtain Service: At a Sharp Authorized Servicer located in the United States.

To find a location of the nearest Sharp Authorized Servicer, call Sharp toll free at 1-800-BE-SHARP.

What to do to Obtain Service: Ship prepaid or carry in your Product to a Sharp Authorized Servicer.

Be sure to have Proof of Purchase available. If you ship the Product, be sure it is insured and

packaged securely.

TO OBTAIN SUPPLY, ACCESSORY OR PRODUCT INFORMATION, CALL 1-800-BE-SHARP.

0311

CD-G10000 Mini Component System / CP-G10000S Speaker System

CD-G10000 Sharp

Product's Documents

User Manual

Specifications

Sharp CD-G10000 Questions and Answers

Related Products

Sharp SMD2420MS 24 Inch Built-In Microwave Drawer with 11 Power Levels, Sensor Cook, ADA Compliant

Sharp SMD2430MS 24 Inch Built-In Microwave Drawer with 11 Power Levels and Sensor Cook for Convenient Cooking

Sharp SWA3099MS Celerity High-Speed Oven

Rowenta TN6000F4 FOREVER SHARP TN6000

Rowenta TN6010F4 FOREVER SHARP TN6010

Rowenta TN6030F4 FOREVER SHARP SP TN6030
