DCD322
EN User manual 1
FR Mode d’emploi 29
ES Manual del usuario 61
DE Benutzerhandbuch 93
NL Gebruiksaanwijzing 125
IT Manuale utente 157
SV Användarhandbok 189
DA Brugervejledning 217
Register your product and get support at
www.philips.com/welcome
DCD322_12_UM_Book 1.indb Sec3:1 2011-10-8 16:58:43
Norge
Typeskilt nnes på apparatens
underside.
Observer: Nettbryteren er sekundert
innkoplet. Den innebygde netdelen er
derfor ikke frakoplet nettet så lenge
apparatet er tilsluttet nettkontakten.
For å redusere faren for brann eller
elektrisk støt, skal apparatet ikke
utsettes for regn eller fuktighet.
Advarsel: Usynlig laserstråling ved
åbning når sikkerhedsafbrydere er
ude af funktion. Undgå utsættelse for
stråling.
Bemærk: Netafbryderen er sekundært
indkoblet og ofbryder ikke strømmen fra
nettet. Den indbyggede netdel er derfor
tilsluttet til lysnettet så længe netstikket
sidder i stikkontakten.
Luokan 1 laserlaite Varoitus!
Laitteen käyttäminen muulla kuin tässä käyttöohjeessa mainitulla tavalla saattaa altistaa
käyttäjän turvallisuusluokan 1 ylittävälle näkymättömälle lasersäteilylle.
Oikeus muutoksiin varataan. Laite ei saa olla alttiina tippu-ja roiskevedelle. Huom.
Toiminnanvalitsin on kytketty toisiopuolelle, eikä se kytke laitetta irti sähköverkosta.
Sisäänrakennettu verkkoosa on kytkettynä sähköverkkoon aina silloin, kun pistoke on
pistorasiassa.
Huom.Toiminnanvalitsin on kytketty toisiopuolelle, eikä se kytke laitetta irti sähköverkosta.
Sisäänrakennettu verkko-osa on kytkettynä sähköverkkoon aina silloin, kun pistoke on
pistorasiassa.
Italia
DICHIARAZIONE DI CONFORMITA’
Si dichiara che l’apparecchio DCD322 Philips
risponde alle prescrizioni dell’art. 2 comma 1
del D.M. 28 Agosto 1995 n. 548.
Fatto a Eindhoven
Philips Consumer Electronics
Philips, Glaslaan 2
5616 JB Eindhoven, The Netherlands
DCD322_12_UM_Book 1.indb Sec3:2 2011-10-8 16:59:18
1
English
EN
6 Play iPhone/iPod 18
Compatible iPod/iPhone 18
Load the iPhone/iPod 18
Listen to the iPhone/iPod 19
Charge the iPhone/iPod 19
Remove the iPhone/iPod 19
7 Listen to radio 19
Tune to a radio station 19
Program radio stations automatically 19
Program radio stations manually 20
Tune to a preset radio station 20
Show RDS information 20
8 Adjust sound 21
Adjust volume level 21
Select a sound effect 21
Mute sound 21
9 Adjust settings 21
General setup 21
Audio setup 21
Video setup 22
Preferences 22
10 Other features 23
Activate demonstration mode 23
Set alarm timer 23
Set the sleep timer 24
Listen to an audio device 24
Listen through headphone 24
11 Product information 24
Speci cations 24
Supported disc formats 25
USB playability information 26
RDS program types 26
12 Troubleshooting 27
Contents
1 Important 2
Safety 2
Notice 3
2 Your DVD Micro Theater 5
Introduction 5
What’s in the box 5
Overview of the main unit 6
Overview of the remote control 7
3 Connect 8
Place the unit 8
Connect speakers 8
Connect FM antenna 9
Connect audio cables 9
Connect video cables 10
Connect an external audio device
(optional) 11
Connect power 12
4 Get started 12
Prepare the remote control 12
Turn on 13
Store radio stations automatically 13
Set clock 13
Adjust brightness of display panel 13
Find the correct viewing channel 13
Select the correct TV system 14
Change system menu language 14
Turn on Progressive Scan 14
5 Play 15
Play a disc 15
Play from USB or recored discs 15
Play control 16
Play options 17
Picture view options 18
DCD322_12_UM_Book 1.indb Sec1:1 2011-10-8 16:59:18
2
or other apparatus (including ampli ers)
that produce heat.
i Protect the power cord from being
walked on or pinched, particularly at
plugs, convenience receptacles, and
the point where they exit from the
apparatus.
j Only use attachments/accessories
speci ed by the manufacturer.
k Use only with the cart, stand, tripod,
bracket, or table speci ed by the
manufacturer or sold with the apparatus.
When a cart is used, use caution when
moving the cart/apparatus combination
to avoid injury from tip-over.
l Unplug this apparatus during lightning
storms or when unused for long periods
of time.
m Refer all servicing to quali ed service
personnel. Servicing is required when
the apparatus has been damaged in any
way, such as power-supply cord or plug
is damaged, liquid has been spilled or
objects have fallen into the apparatus,
the apparatus has been exposed to rain
or moisture, does not operate normally,
or has been dropped.
n Battery usage CAUTION – To prevent
battery leakage which may result in
bodily injury, property damage, or
damage to the unit:
Install all batteries correctly, + and - •
as marked on the unit.
Do not mix batteries (old and new •
or carbon and alkaline, etc.).
Remove batteries when the unit is •
not used for a long time.
o Apparatus shall not be exposed to
dripping or splashing.
p Do not place any sources of danger on
the apparatus (e.g. liquid lled objects,
lighted candles).
1 Important
Safety
Know these safety symbols
This ‘bolt of lightning’ indicates uninsulated
material within your unit may cause an
electrical shock. For the safety of everyone
in your household, please do not remove
product covering.
The ‘exclamation point’ calls attention to
features for which you should read the
enclosed literature closely to prevent
operating and maintenance problems.
WARNING: To reduce the risk of re or
electric shock, this apparatus should not be
exposed to rain or moisture and objects lled
with liquids, such as vases, should not be
placed on this apparatus.
CAUTION: To prevent electric shock, match
wide blade of plug to wide slot, fully insert.
Important Safety Instructions
a Read these instructions.
b Keep these instructions.
c Heed all warnings.
d Follow all instructions.
e Do not use this apparatus near water.
f Clean only with dry cloth.
g Do not block any ventilation openings.
Install in accordance with the
manufacturer’s instructions.
h Do not install near any heat sources
such as radiators, heat registers, stoves,
EN
DCD322_12_UM_Book 1.indb Sec1:2 2011-10-8 16:59:18
3
To establish a safe volume level:
Set your volume control at a low setting. •
Slowly increase the sound until you can •
hear it comfortably and clearly, without
distortion.
Listen for reasonable periods of time:
Prolonged exposure to sound, even •
at normally ‘safe’ levels, can also cause
hearing loss.
Be sure to use your equipment •
reasonably and take appropriate breaks.
Be sure to observe the following guidelines
when using your headphones.
Listen at reasonable volumes for •
reasonable periods of time.
Be careful not to adjust the volume as •
your hearing adapts.
Do not turn up the volume so high that •
you can’t hear what’s around you.
You should use caution or temporarily •
discontinue use in potentially hazardous
situations. Do not use headphones while
operating a motorized vehicle, cycling,
skateboarding, etc.; it may create a traf c
hazard and is illegal in many areas.
Notice
Any changes or modi cations made to this
device that are not expressly approved by
Philips Consumer Lifestyle may void the user’s
authority to operate the equipment.
This product complies with the radio
interference requirements of the European
Community.
Your product is designed and manufactured
with high quality materials and components,
which can be recycled and reused.
q Where the MAINS plug or an appliance
coupler is used as the disconnect device,
the disconnect device shall remain
readily operable.
Risk of overheating! Never install this
apparatus in a con ned space. Always leave
a space of at least four inches around this
apparatus for ventilation. Ensure curtains or
other objects never cover the ventilation slots
on this apparatus.
Caution
Use of controls or adjustments or •
performance of procedures other than herein
may result in hazardous radiation exposure or
other unsafe operation.
Warning
Never remove the casing of this unit. •
Never lubricate any part of this unit. •
Place this unit on a at, hard and stable •
surface.
Never place this unit on other electrical
•
equipment.
Only use this unit indoors. Keep this unit away
•
from water, moisture and liquid- lled objects.
Keep this unit away from direct sunlight, naked
•
ames or heat.
Never look into the laser beam inside the unit.
•
Hearing safety
Listen at a moderate volume.
Using headphones at a high volume can •
impair your hearing. This product can
produce sounds in decibel ranges that
may cause hearing loss for a normal
person, even for exposure less than a
minute. The higher decibel ranges are
offered for those that may have already
experienced some hearing loss.
Sound can be deceiving. Over time your •
hearing ‘comfort level’ adapts to higher
volumes of sound. So after prolonged
listening, what sounds ‘normal’ can
actually be loud and harmful to your
hearing. To guard against this, set your
volume to a safe level before your hearing
adapts and leave it there.
English
EN
DCD322_12_UM_Book 1.indb Sec1:3 2011-10-8 16:59:19
4
Trademark notice
ABOUT DIVX VIDEO: DivX® is a digital
video format created by DivX, Inc. This is
an of cial DivX Certi ed device that plays
DivX video. Visit www.divx.com for more
information and software tools to convert
your les into DivX video.
ABOUT DIVX VIDEO-ON-DEMAND: This
DivX Certi ed® device must be registered in
order to play DivX Video-on-Demand (VOD)
content. To generate the registration code,
locate the DivX VOD section in the device
setup menu. Go to vod.divx.com with this
code to complete the registration process and
learn more about DivX VOD.
DivX®, DivX Certi ed® and associated logos
are registered trademarks of DivX, Inc. and
are used under license.
Manufactured under license from Dolby
Laboratories. Dolby and the double-D symbol
are trademarks of Dolby Laboratories.
‘DVD Video’ is a trademark of DVD Format/
Logo Licensing Corporation.
This apparatus includes this label:
Note
The type plate is located on the bottom of the •
apparatus.
When this crossed-out wheeled bin symbol
is attached to a product it means that the
product is covered by the European Directive
2002/96/EC.
Please inform yourself about the local separate
collection system for electrical and electronic
products.
Please act according to your local rules and
do not dispose of your old products with your
normal household waste. Correct disposal of
your old product helps to prevent potential
negative consequences for the environment
and human health.
Your product contains batteries covered by
the European Directive 2006/66/EC, which
cannot be disposed with normal household
waste. Please inform yourself about the local
rules on separate collection of batteries
because correct disposal helps to prevent
negative consequences for the environmental
and human health.
Environmental information
All unnecessary packaging has been omitted.
We have tried to make the packaging easy to
separate into three materials: cardboard (box),
polystyrene foam (buffer) and polyethylene
(bags, protective foam sheet.)
Your system consists of materials which can
be recycled and reused if disassembled by
a specialized company. Please observe the
local regulations regarding the disposal of
packaging materials, exhausted batteries and
old equipment.
Copyright notice
This item incorporates copy protection
technology that is protected by U.S. patents
and other intellectual property rights of
Rovi Corporation. Reverse engineering and
disassembly are prohibited.
EN
DCD322_12_UM_Book 1.indb Sec1:4 2011-10-8 16:59:19
5
You can play DVD discs marked with the
following region code:
DVD region code Countries
Europe
What’s in the box
Check and identify the contents of your
package:
Main unit•
2 speakers•
Remote control with batteries•
Composite video cable (yellow)•
Power cord•
MP3 link cable (length: 60 cm)•
FM wire antenna•
User manual•
Quick start guide•
2 Your DVD
Micro Theater
Congratulations on your purchase, and
welcome to Philips! To fully bene t from the
support that Philips offers, register your product
at www.philips.com/welcome.
Introduction
With this apparatus, you can:
Watch video from DVD/VCD/SVCD, •
iPhone/iPod, or USB storage devices
Enjoy audio from discs, iPhone/iPod, or •
USB storage devices
View pictures from discs or USB storage •
devices
Listen to FM radio•
You can enrich sound output with these sound
effects:
Dynamic Bass Boost (DBB)•
Digital Sound Control (DSC)•
Automatic loudness control •
(LOUDNESS)
The apparatus supports these media/disc
formats:
English
EN
DCD322_12_UM_Book 1.indb Sec1:5 2011-10-8 16:59:20
6
g
Headphone socket.•
h
USB socket.•
i Disc compartment
j Display panel
Display current status.•
k SOURCE
Select a source.•
l
Turn on the apparatus or switch to •
the standby mode.
m
VOLUME
Adjust volume.•
Adjust time.•
Overview of the main unit
a Dock for iPod/iPhone
b DBB / LOUDNESS
Turn on or off dynamic bass •
enhancement.
Turn on or off automatic loudness •
control.
c
/
Skip to the previous/next track, title, •
or chapter.
Select a preset radio station.•
•
Start or pause play.•
•
Stop play. •
d MODE/DIM
Select repeat/shuf e play modes.•
Select a brightness level for the •
display screen.
e
Open or close the disc •
compartment.
f MP3-LINK
Jack for an external audio device.•
g
h
i
a
c
d
e
f
m
l
k
j
b
EN
DCD322_12_UM_Book 1.indb Sec1:6 2011-10-8 16:59:21
7
For video discs with playback •
control(PBC): turn on/off PBC.
Access or exit the menu of iPhone/•
iPod.
Return to the previous menu.•
e AUDIO
For VCD, select stereo, mono-left or •
mono-right channel.
For DVD/DivX video, select an audio •
language.
f
/
Search in a track or disc.•
For menus, navigate left/right.•
Tune to a radio station.•
Rotate a picture.•
g OK
Con rm a selection.•
h
SLOW / ZOOM
For menus: navigate up/down.•
Invert a picture. •
( •
SLOW ) For video discs: select a
slow play mode.
( •
ZOOM ) For video: zoom in/out.
i DBB / LOUDNESS
Turn on or off automatic loudness •
control.
Turn on or off dynamic bass •
enhancement.
j
Start or pause play.•
k VOL +/-
Adjust volume.•
Adjust time.•
l
Stop play. •
m MUTE
Mute or restore volume.•
n CLOCK
Set the clock.•
View the clock.•
o SLEEP/TIMER
Overview of the remote
control
a
Turn on the apparatus or switch to •
the standby mode.
b Source selection keys
Select a source.•
c DISPLAY/RDS
Display play information on a •
connected TV.
For selected FM radio stations: •
display RDS information.
Synchronize clock with RDS. •
d MENU/
For video discs: access or exit the •
disc menu.
w
u
s
r
t
v
b
d
e
f
i
k
m
n
o
p
q
l
j
h
g
c
a
English
EN
DCD322_12_UM_Book 1.indb Sec1:7 2011-10-8 16:59:23
8
3 Connect
Place the unit
1 Place the unit near to the TV.
2 Place the left and right speakers at equal
distance from the TV and at an angle
of approximately 45 degrees from the
listening position.
Note
To avoid magnetic interference or unwanted •
noise, never place this apparatus and speakers
too close to any radiation devices.
Place this unit on top of a table or mount it on
•
the wall.
Never place this unit in an enclosed cabinet.
•
Install this unit near the AC outlet where the •
AC power plug can be easily reached.
Connect speakers
Note
For optimal sound, use the supplied speakers •
only.
Connect only speakers with impedance that is
•
the same or higher than the supplied speakers.
Refer to the Speci cations section of this
manual.
Set the sleep timer.•
Set the alarm timer.•
p SUBTITLE
Select a subtitle language.•
q GOTO
During disc play, specify a position to •
start play.
r ANGLE/PROG
Select a DVD camera angle.•
Program tracks.•
Program titles/chapters for DVD play.•
Program radio stations.•
s Numeric keypad
Select a title/chapter/track directly.•
t
/
Skip to the previous/next track.•
Skip to the previous/next title or •
chapter.
Select a preset radio station.•
u DSC
Select a preset sound setting.•
v MODE/DIM
Select repeat/shuf e play modes. •
Select a brightness level for the •
display screen.
w SYSTEM MENU
Access or exit the system setup •
menu.
EN
DCD322_12_UM_Book 1.indb Sec1:8 2011-10-8 16:59:25
9
Connect audio cables
To hear audio from other audio devices as well
as the accompanied speakers, select a preferred
audio connection:
• Option 1 : Connect through a coaxial
cable
• Option 2 : Connect through analog audio
cables
Option 1: Connect through a coaxial
cable
You can enjoy multi-channel surround sound
from this apparatus when it is connected to a
digital audio device.
1 Connect a coaxial cable (not supplied) to
the • COAXIAL socket on this
product.
the COAXIAL/DIGITAL input socket •
on the device.
1 Insert the speaker plugs to SPEAKER
OUT ( L and R ) sockets.
The red plug to • R .
The white plug to • L .
Connect FM antenna
Tip
For optimal reception, fully extend and adjust •
the position of the antenna.
For better FM stereo reception, connect an
•
outdoor FM antenna to the FM AERIAL jack.
The unit does not support MW radio
•
reception.
1 Connect the supplied FM wire antenna to
the FM AERIAL socket on the unit.
English
EN
DCD322_12_UM_Book 1.indb Sec1:9 2011-10-8 16:59:26
10
Option 1: Connect through an
S-Video cable
1 Connect an S-video cable (not supplied)
to:
the • S-Video socket on this unit.
the • S-Video socket on the TV.
Option 2: Connect through a
composite video cable
1 Connect the composite video cable
(supplied) to:
the • VIDEO socket on this unit.
the video input socket on the TV.•
TV
S-VIDEO IN
S-VIDEO
TV
Option 2: Connect through analog
audio cables
1 Connect an audio cable (red/white ends)
to:
the • AUDIO OUT ( L and R ) sockets
on this unit.
the audio input sockets on the audio •
device.
Connect video cables
You can select the best video connection that
your TV supports.
• Option 1: Connect through an S-Video
cable (for a standard TV).
• Option 2: Connect through a composite
video (CVBS) cable (for a standard TV).
• Option 3: Connect through component
video cables (for a standard TV or
Progressive Scan TV).
• Option 4: Connect through the iPhone/
iPod socket (for a standard TV).
TV
L LINE IN R
EN
DCD322_12_UM_Book 1.indb Sec1:10 2011-10-8 16:59:27
11
1 Connect a composite video cable to:
the • iPhone/iPod socket on this unit.
the video input socket on the TV.•
Note
To play audio only through the speakers of this •
apparatus, mute the TV and other connected
audio devices.
See “Play iPhone/iPod” for how to control the
•
play.
See the user manual of your TV for how to
•
selecte the correct viewing channel.
Connect an external audio
device (optional)
You can also listen to an external audio device
through this unit.
• Option 1: Connect through the AUX IN
sockets
• Option 2: Connect through the MP3-
LINK socket
Option 1: Connect through the AUX
IN sockets
1 Connect audio cables (red/white) to:
the • AUX IN ( L and R ) sockets on
this unit.
the audio output sockets on the •
external audio device.
TV
Option 3: Connect through
component video cables
Note
The progressive scan video quality is only •
available when a progressive scan TV is
connected.
If your TV does not support progressive scan,
•
you cannot view the picture.
For how to activate progressive scan on your
•
TV, refer to the TV user manual.
Connect a progressive scan TV through
component video for higher quality video.
1 Connect component video cables (red/
blue/green - not supplied) to:
the • COMPONENT ( Pr/Cr Pb/Cb Y )
sockets on this unit.
the component input sockets on the •
TV.
Option 4: Connect through the
iPhone/iPod socket
You can view video les that are stored on
your iPhone/iPod on your TV.
TV
English
EN
DCD322_12_UM_Book 1.indb Sec1:11 2011-10-8 16:59:28
12
4 Get started
Caution
Use of controls or adjustments or •
performance of procedures other than herein
may result in hazardous radiation exposure or
other unsafe operation.
Always follow the instructions in this chapter in
sequence.
If you contact Philips, you will be asked for the
model and serial number of this apparatus. The
model number and serial number are on the
back of the apparatus. Write the numbers here:
Model No. __________________________
Serial No. ___________________________
Prepare the remote control
Caution
Risk of explosion! Keep batteries away from •
heat, sunshine or re. Never discard batteries
in re.
For rst-time use:
1 Remove the protective tab to activate the
remote control battery.
To replace the remote control batteries:
1 Open the battery compartment.
Option 2: Connect through the MP3-
LINK socket
1 Connect an MP3 link cable to:
the • MP3-LINK socket on this unit.
the headphone socket on the •
external audio device.
Connect power
Caution
Risk of product damage! Ensure that the •
power supply voltage corresponds to the
voltage printed on the back or the underside
of the unit.
Before connecting the AC power cord, ensure
•
you have completed all other connections.
1 Connect the AC power cord to
the • AC ~ socket on this apparatus.
the wall power socket.•
AUDIO OUT
EN
DCD322_12_UM_Book 1.indb Sec1:12 2011-10-8 16:59:29
13
3 Press .
The unit automatically stores radio »
stations with suf cient signal strength.
After all available radio stations are »
stored, the rst stored radio station is
broadcast automatically.
Set clock
1
In standby mode, press and hold CLOCK
for over 2 seconds to activate the clock
setting mode.
» [SET CLOCK] scrolls on the display,
and then [24H MODE] (24-hour time
format) appears.
2 Press VOL +/- to select [24H MODE] or
[12H MODE] (12-hour time format), and
then press CLOCK to con rm.
The hour digits begin to blink. »
3 Press VOL +/- to set the hour.
4 Press CLOCK to con rm.
The minute digits begin to blink. »
5 Press VOL +/- to set the minute.
6 Press CLOCK to con rm.
Adjust brightness of display
panel
1
In standby mode, press MODE/DIM
repeatedly to select different brightness
levels.
Find the correct viewing
channel
1
Press to turn on the unit.
2 Press DISC to switch to disc mode.
3 Turn on the TV and switch to the correct
video-in channel in one of the following
ways:
2 Insert one lithium CR2025 battery with
correct polarity (+/-) as indicated.
3 Close the battery compartment.
Note
Before you press any function button on the •
remote control, rst select the correct source
with the remote control instead of the main
unit.
If you are not going to use the remote control
•
for a long time, remove the battery.
Turn on
1
Press .
The unit switches to the last selected »
source.
Switch to standby mode
1 Press and hold for over 3 seconds to
switch the unit to Eco Power Standby
mode.
The backlight on the display panel »
turns off.
The blue Eco Power indicator turns on. »
To switch the unit to standby mode:
1 In Eco Power Standby mode, press and
hold
for over 3 seconds.
The clock (if set) appears on the »
display panel.
The blue Eco Power indicator turns off. »
Store radio stations
automatically
If no radio stations are stored, the unit can store
radio stations automatically.
1 Turn on the unit.
2 Press SOURCE repeatedly until
[TUNER] is displayed.
» [AUTO INSTALL PRESS----PLAY
KEY] (press
to start the automatic
installation) is displayed.
English
EN
DCD322_12_UM_Book 1.indb Sec1:13 2011-10-8 16:59:30
14
Turn on Progressive Scan
Progressive scan displays twice the number of
frames per seconds than interlaced scanning
(ordinary TV system). With nearly double the
number of lines, progressive scan offers higher
picture resolution and quality.
Before you turn on this feature, ensure that:
The TV supports progressive scan signals.•
You have connected this unit with the TV •
through component video.
1 Turn on the TV.
2 Ensure that the TV progressive scan
mode is deactivated (see the TV user
manual).
3 Switch the TV to the correct viewing
channel for this unit.
4 Press DISC .
5 Press SYSTEM MENU .
6 Press / to select [Video Setup] in the
menu, then press
.
7 Select [Component Video] , then press
.
8 Select [P-Scan] , then press OK .
The progressive setup is complete. »
Go to the lowest channel on your •
TV, then press the Channel Down
button until you see the blue screen.
Press the source button repeatedly •
on the remote control of your TV.
Tip
The video-in channel is between the lowest •
and highest channels and may be called
FRONT, A/V IN, VIDEO etc. See the TV user
manual on how to select the correct input on
the TV.
Select the correct TV system
Change this setting if the video does not appear
correctly. By default, this setting matches the
most common setting for TVs in your country.
1 Press SYSTEM MENU .
2 Select [Video Setup] .
3 Select [TV System] and then press .
4 Select a setting and then press OK .
• [NTSC] - For TV with NTSC color
system.
• [PAL] - For TV with PAL color
system.
• [Multi] - For TV that is compatible
with both PAL and NTSC.
5 To exit the menu, press SYSTEM MENU .
Change system menu
language
1
Press SYSTEM MENU .
2 Select [General Setup] .
3 Select [OSD language] and then press .
4 Select a setting and then press OK .
5 To exit the menu, press SYSTEM MENU .
EN
DCD322_12_UM_Book 1.indb Sec1:14 2011-10-8 16:59:31
15
1 Press MENU/ .
For VCD with PlayBack Control (PBC)
feature (version 2.0 only):
The PBC feature allows you to play VCD
interactively according to the menu screen.
1 During play, press MENU/ to enable/
disable playback control.
When PBC is enabled, the menu »
screen is displayed.
When PBC is disabled, normal play is »
resumed.
Select an audio language
You can select an audio language for a DVD or
DivX (Ultra) video.
1 During disc play, press AUDIO .
The language options appear. If the »
selected audio channels is unavailable,
the default disc audio channel is used.
Note
For some DVDs, the language can only be •
changed from the disc menu. Press MENU/
to access the menu.
Select a subtitle language
You can select a subtitle language for a DVD
or DivX (Ultra) video.
1 During play, press SUBTITLE repeatedly.
Note
For some DVDs, the language can only be •
changed from the disc menu. Press MENU/
to access the menu.
Play from USB or recored
discs
You can play DivX (Ultra)/MP3/WMA/
JPEG picture les copied onto a CD-R/RW,
recordable DVD or USB storage device.
5 Play
Caution
Risk of damage to the unit! During play, never •
move the unit.
Play a disc
Caution
Never look at the laser beam inside the unit. •
Risk of product damage! Never play discs with •
accessories such as disc stabilizer rings or disc
treatment sheets.
Never put any objects other than discs into
•
the disc compartment.
1 Press DISC to select the DISC source.
2 Press on the front panel.
The disc tray opens. »
3 Place a disc onto the tray and press .
Ensure that the label faces up. »
4 Play starts automatically.
To stop play, press •
.
To pause or resume play, press •
.
To skip to the previous/next title/•
chapter/track, press
/ .
If play does not start automatically:
1 Select a title/chapter/track and then press
.
Tip
To play a locked DVD, enter the 6-digit •
parental control password.
Use the disc menu
When you load a DVD/(S)VCD disc, a menu
may be displayed on the TV screen.
To access or exit the menu manually:
English
EN
DCD322_12_UM_Book 1.indb Sec1:15 2011-10-8 16:59:32
16
Play control
Select repeat/shuf e play options
1 During play, press MODE/DIM repeatedly
to select a play option.
To resume normal play, press •
MODE/DIM repeatedly until no
option is displayed.
Search forward/backward
1 During video/audio play, press /
repeatedly to select a search speed.
To resume play at normal speed, •
press
.
Search by time or title/chapter/track
number
1 During video/audio play, press GOTO .
2 Press to select a eld.
3 Enter the desired time or number.
For the time eld, enter the play •
position in sequence of hour, minute
and second.
For the title/chapter/track eld, enter •
the title/chapter/track number.
4 Press OK to start play at the selected
point.
Resume video play from last stopped
point
Note
This feature is only available for DVD/VCD •
play.
1 In stop mode and when the disc has not
been removed, press
.
To cancel resume mode and stop play
completely:
1 In stop mode, press .
1 Select a source.
For a USB storage device, press • USB .
For a disc, press • DISC .
2 Insert the USB storage device or disc.
The play starts automatically. »
To select a speci ed le for play,
1 Press to stop play.
2 Press / to select a folder, and then
press OK to con rm.
To return to the upper-level •
directory, press
/ to select ,
and then press OK .
3 Press / to select a le from the folder.
4 Press to start play.
To pause or resume play, press •
.
To skip to the previous/next le, •
press
/ .
To change the subtitle language •
during the play of a DivX (Ultra)
video, press SUBTITLE .
Note
You can only play DivX (Ultra) videos rented •
or purchased through the DivX registration
code of this unit.
Subtitle les with the following lename
•
extensions (.srt, .smi, .sub, .ssa, .ass) are
supported but do not appear on the le
navigation menu.
The subtitle lename has to be the same as
•
the le name of the video.
EN
DCD322_12_UM_Book 1.indb Sec1:16 2011-10-8 16:59:34
17
3 Repeat steps 1-2 to program more tracks.
You can program tracks in different •
formats in different folders.
4 Press MENU/ to access the list of
programmed tracks.
5 Press to start play.
To switch between the USB/disc •
directory and the list of programmed
tracks, press MENU/
repeatedly.
To remove a programmed track •
from the list, access the list of
programmed tracks, press
/
to select a track, and then press
ANGLE/PROG .
To erase the program, remove all •
programmed tracks from the list.
Display play information
1 During play, press DISPLAY/RDS to
display play information on the TV.
Zoom in/out image
1 During video play, press and hold
( ZOOM ) to zoom in/out the image.
When the image is zoomed in, you •
can press
/ / / to pan through
the image.
Slow-motion play
1 During video play, press (SLOW) to
select a play speed.
The sound is muted. »
To resume play at normal speed, •
press
.
Change camera angle
Some DVDs contain alternate scenes, such as
scenes recorded from different camera angles.
For such DVDs, you can select from the
available alternate scenes.
1 During play, press PROG/ANGLE
repeatedly to switch between camera
angles.
Play options
Program tracks
This function is only available for audio CDs
and WMA/MP3/DivX (Ultra) les.
For an audio CD,
1 During play, press twice.
The list of all tracks is displayed.
2 Press / to select a track.
3 Press ANGLE/PROG .
» [Add to Program List] (added to the
program list) is displayed.
4 Repeat steps 2-3 to program more tracks.
5 Press MENU/ to access the list of
programmed tracks.
6 Press to start play.
To switch between the list of all •
tracks and the list of programmed
tracks during play, press
twice,
and then press MENU/
repeatedly.
To remove a programmed track •
from the list, access the list of
programmed tracks, press
/
to select a track, and then press
ANGLE/PROG .
To erase the program, remove all •
programmed tracks from the list.
For MP3/WMA/DivX (Ultra) les stored on a
CD-R/RW, recordable DVD, or USB storage
device,
1 During play, press / to select a track.
If a DivX (Ultra) le is played, press •
to access the USB/disc directory
rst.
To return to the upper-level •
directory, press
/ to select ,
and then press OK .
2 Press ANGLE/PROG .
» [Add to Program List] (added to the
program list) is displayed.
English
EN
DCD322_12_UM_Book 1.indb Sec1:17 2011-10-8 16:59:36
18
6 Play iPhone/iPod
You can enjoy audio from iPhone/iPod through
this unit.
Note
The audio is only output through the supplied •
speakers.
Compatible iPod/iPhone
The unit supports the following iPod and
iPhone models.
“ Made for iPod ” and “ Made for iPhone ”
mean that an electronic accessory has been
designed to connect speci cally to iPod or
iPhone respectively, and has been certi ed by
the developer to meet Apple performance
standards. Apple is not responsible for the
operation of this device or its compliance with
safety and regulatory standards. Please note
that the use of this accessory with iPod or
iPhone may affect wireless performance.
Made for
iPod mini•
iPod touch (1st, 2nd, 3rd, and 4th •
generation)
iPod nano (1st, 2nd, 3rd, 4th, 5th, and 6th •
generation)
iPod 4G•
iPod 5G•
iPod classic•
iPhone•
iPhone 3G•
iPhone 3GS •
Change the audio channel
Note
This feature is only available for VCDs and •
DivX (Ultra) videos.
1 During play, press AUDIO repeatedly to
select an audio channel available on the
disc:
Mono Left•
Mono Right•
Stereo•
Picture view options
Select a slide show play mode
You can view pictures as slide show in
different play modes.
1 Press MODE/DIM repeatedly.
Rotate picture
1 During play, press / / / to rotate
the picture anti-clockwise/clockwise.
EN
DCD322_12_UM_Book 1.indb Sec1:18 2011-10-8 16:59:39
19
Charge the iPhone/iPod
When the unit is connected to power, the
docked iPhone/iPod begins to charge.
Remove the iPhone/iPod
1
Pull the iPhone/iPod out of the dock.
2 Press down to hide the dock.
Load the iPhone/iPod
1
Lift up the iPhone/iPod dock on top panel
until you hear a click.
2 Place the iPhone/iPod in the dock.
Listen to the iPhone/iPod
1
Press iPhone/iPod to select iPhone/iPod
source.
2 Load your iPhone/iPod onto this apparatus.
3 Play the desired le on your iPhone/iPod.
To pause/resume play, press •
.
To skip to a track, press •
/ .
To navigate the menu: press •
MENU/
to access the menu, press
/ to select an item, and then
press OK to con rm.
English
EN
DCD322_12_UM_Book 1.indb Sec1:19 2011-10-8 16:59:39
20
Program radio stations
manually
Note
You can program a maximum of 20 preset •
radio stations.
1 Tune to a radio station.
2 Press ANGLE/PROG to activate
programming.
3 Press / to allocate a number from
1 to 20 to this radio station, then press
ANGLE/PROG to con rm.
The preset number and the frequency »
of the preset station are displayed.
4 Repeat the previous steps to program
other stations.
Note
To overwrite a programmed station, store •
another station in its place.
Tune to a preset radio station
1
Press / to select a preset number
that you want.
Show RDS information
RDS (Radio Data System) is a service
that allows FM stations to show additional
information. If you tune to an RDS station, an
RDS icon and the station name are displayed.
1 Tune to an RDS station.
2 Press DISPLAY/RDS repeatedly to scroll
through the following information (if
available):
Station name »
Program type such as » [NEWS] (news),
[SPORT] (sport), [POP M] (pop
music)...
Frequency »
7 Listen to radio
The unit can automatically search and store
radio stations (see “Get started” > “Store radio
stations automatically”). You can also search and
store radio stations manually.
Tune to a radio station
1
Press FM .
2 Press and hold / for more than 2
seconds.
The radio tunes to a station with »
strong reception automatically.
3 Repeat step 2 to tune to more stations.
To tune to a weak station, press •
/ repeatedly until you nd optimal
reception.
Program radio stations
automatically
Note
You can program a maximum of 20 preset •
radio stations.
1 Press and hold ANGLE/PROG for
2 seconds to activate automatic
programming.
» [AUTO] (auto) is displayed brie y.
All available stations are programmed »
in the order of waveband reception
strength.
The rst programed radio station is »
broadcast automatically.
EN
DCD322_12_UM_Book 1.indb Sec1:20 2011-10-8 16:59:41
21
8 Adjust sound
Adjust volume level
1
During play, press VOL +/- to increase/
decrease the volume level.
Select a sound effect
Note
You cannot use different sound effects at the •
same time.
Select a preset sound effect
1 During play, press DSC repeatedly to select:
• [FLAT] ( at)
• [POP] (pop)
• [JAZZ] (jazz)
• [ROCK] (rock)
• [CLASSIC] (classic)
Enhance bass
The best DBB (Dynamic Bass Enhancement)
setting is generated automatically for each
DSC option. You can manually select the
DBB setting that best suits your listening
environment.
The feature of automatic loudness control
(LOUDNESS) enables the system to increase
the treble and bass sound effect at low volume
levels automatically (the higher the volume,
the lower the treble and bass increase).
1 During play, press DBB / LOUDNESS
repeatedly to turn on/off the DBB or
LOUDNESS feature.
• [DBB] : The DBB feature is enabled.
• [LOUDNESS] : The LOUDNESS
feature is enabled.
• [FLAT] : Both the DBB feature and
the LOUDNESS feature are disabled.
Mute sound
1
During play, press MUTE to mute or
restore sound.
Note
There are de nitions of RDS program types •
(see “Product information” > “RDS program
types”).
Synchronize clock with RDS station
You can synchronize the clock time on the
unit with an RDS station.
1 Tune to an RDS radio station that
transmits time signals.
2 Press DISPLAY / RDS for over 2 seconds.
» [CT SYNC] is displayed and the unit
reads RDS time automatically.
If no time signal is received, » [NO CT]
is displayed.
Note
The accuracy of the transmitted time depends •
on the RDS station that transmits the time
signal.
English
EN
DCD322_12_UM_Book 1.indb Sec1:21 2011-10-8 16:59:42
22
• [PCM] – If the connected device
cannot decode multichannel audio,
select this option.
• [All] – If the connected device
supports multi-channel audio
formats, select this option.
[Night Mode]
Make loud sound level softer and soft sound
level louder so that you can watch the DVD
movies at a low volume, without disturbing
others.
• [On] – enjoy quiet viewing at night
(DVDs only).
• [Off] – enjoy surround sound with
its full dynamic range.
Video setup
On the [Video Setup] page, you can set the
following options:
[TV System]
Change this setting if the video does not
appear correctly. By default, this setting
matches the most common setting for TVs in
your country.
• [NTSC] - For TV with NTSC color
system.
• [PAL] - For TV with PAL color
system.
• [Multi] - For TV that is compatible
with both PAL and NTSC.
[TV Display]
The TV format determines the aspect ratio of
display according to the type of TV you have
connected.
• [4:3 Pan Scan] – For 4:3 screen TV:
full-height display with the trimmed
sides.
4:3 Letter Box (LB)
4:3 Pan Scan (PS)
16:9 (Wide Screen)
9 Adjust settings
1 Press SYSTEM MENU .
2 Select a setup page.
3 Select an option and then press .
4 Select a setting and then press OK .
To return to the previous menu, •
press
.
To exit the menu, press • SYSTEM
MENU .
General setup
On the [General Setup] page, you can set the
following options:
[OSD language]
Select the preferred language for on-screen
display.
[DivX® VOD Code]
Display the DivX® registration code.
[DivX Deactivation]
Deactivate the authorization to current user.
Note
Enter this DivX registration code when you •
rent or purchase a video from http://vod.divx.
com/. The DivX videos rented or purchased
through the DivX® VOD (Video On
Demand) service can be played only on the
device to which it is registered.
Audio setup
On the [Audio Setup] page, you can set the
following options:
[Digital Output]
Select audio formats supported by the
connected device.
• [Off] – Turn off the digital output.
EN
DCD322_12_UM_Book 1.indb Sec1:22 2011-10-8 16:59:42
23
[Parental Control]
Restrict access to discs that are unsuitable
for children. These types of discs must be
recorded with ratings.
1) Press OK .
2) Select a rating level, and then press OK .
3) Press the numeric keys to enter the
password.
Note
Rated discs above the level you set in • [Parental
Control] require a password to be played.
The ratings are country-dependent. To allow
•
all discs to play, select [8. Adult] .
Some discs have ratings printed on them but
•
are not recorded with ratings. This function
has no effect on such discs.
[Password]
This setting allows you to change the
password for parental control. The default
password is ‘123456’.
1) Press the numeric keys to enter ‘123456’
or your last set password at [Old
Password] eld.
2) Enter the new password at [New
Password] eld.
3) Enter the new password again at [Con rm
new password] eld.
4) Press OK to exit the menu.
Note
If you forget the password, enter ‘123456’ •
before you set a new password.
[Version Info]
Display the software version of this apparatus.
[Default]
Reset all the settings to factory default, except
for the password and parental settings.
• [4:3 Letter Box] – For 4:3 screen TV:
wide-screen display with black bars
on the top and bottom of the screen.
• [Wide Screen] – For wide-screen
TV: display ratio 16:9.
[Picture Setting]
Customize picture color settings.
[Component Video]
Set the video output according to the video
connection. If the composite connection is
used, this setting is not required.
• [S-VIDEO] – If the S-Video
connection is used, select this option.
• [Interlaced] – For ordinary TV: turn
on the interlace mode.
• [P-Scan] – For progressive scan TV:
turn on the progressive scan mode.
Preferences
On the [Preferences] page, you can set the
following options:
[Audio]
Select the preferred audio language for disc play.
[Subtitle]
Select the preferred subtitle language for disc play.
[Disc Menu]
Select the preferred disc menu language.
Note
If the language you have set is not available on •
the disc, the disc uses its own default language.
For some discs, the subtitle/audio language can
•
only be changed from the disc menu.
[DivX Subtitle]
Select a character set that supports the DivX
subtitle.
Note
Ensure that the subtitle le has the exact same •
le name as the movie le. If for example the
le name of the movie is ‘Movie.avi’, then you
will need to name the text le ‘Movie.sub’ or
‘Movie.srt’.
English
EN
DCD322_12_UM_Book 1.indb Sec1:23 2011-10-8 16:59:44
24
Activate/deactivate alarm timer
1 In the standby mode, press SLEEP/TIMER
repeatedly.
If timer is activated, »
is displayed.
If timer is deactivated, »
disappears on
the display.
Tip
Alarm timer is not available when the source is •
set as “ MP3 LINK ” or “ AUX ”.
If CD/USB/iPod/iPhone source is selected but no
•
disc is placed or no USB/iPod/iPhone connected,
the system switches to FM automatically.
Set the sleep timer
This apparatus can switch to standby
automatically after a set period.
1 When the apparatus is turned on, press
SLEEP/TIMER repeatedly to select a
preset period (in minutes).
When sleep timer is activated, »
is
displayed.
To deactivate sleep timer
1 Press SLEEP/TIMER repeatedly until [SLE
OFF] is displayed.
Listen to an audio device
You can listen to an audio device through this
apparatus.
1 Ensure the external audio device
is connected to this apparatus (see
“Connect” > “Connect an external audio
device”).
2 Press MP3 LINK/AUX repeatedly to select
the audio input through the MP3-LINK
socket or AUX IN ( L and R ) sockets.
3 Start to play the device (see the device
user manual).
Listen through headphone
1
Plug a headphone into the socket.
10 Other features
Activate demonstration mode
You can see an overview of all features.
1 In the standby mode with clock display
(if set), press
on the main unit to
activate the demonstration mode.
A demonstration of major available »
features starts.
To deactivate the demonstration mode:
1 Press on the main unit again.
Set alarm timer
This unit can be used as an alarm clock. You can
select CD, iPod/iPhone, FM or USB as alarm source.
Note
Ensure that you have set the clock correctly. •
1 In standby mode, press and hold SLEEP/
TIMER until [SET TIMER] (set timer)
scrolls on the display.
2 Press SOURCE repeatedly to select a
source: CD, FM, USB, iPod/iPhone or
iPod/iPhone playlist.
If iPod/iPhone playlist is selected as •
alarm source, you need create a playlist
called “PHILIPS” in your iPod/iPhone.
If no playlist called “PHILIPS” is •
created in the iPod/iPhone or no
track is stored in the playlist, the unit
switches to iPod/iPhone alarm source.
3 Press SLEEP/TIMER to con rm.
The hour digits are displayed and begin »
to blink.
4 Press VOL +/- repeatedly to set hour, and
then press SLEEP/TIMER again.
The minute digits are displayed and »
begin to blink.
5 Press VOL +/- to set minute, and then
press SLEEP/TIMER to con rm.
6 Press VOL +/- to adjust volume, and then
press SLEEP/TIMER to con rm.
A clock icon appears on the display. »
EN
DCD322_12_UM_Book 1.indb Sec1:24 2011-10-8 16:59:45
25
Tuner (FM)
Tuning Range 87.5 - 108MHz
Tuning grid 50KHz
Sensitivity - Mono, 26dB
S/N Ratio
<22 dBf
Sensitivity - Stereo, 46dB
S/N Ratio
<43 dBf
Search Selectivity >28dBf
Total Harmonic
Distortion
<2%
Signal to Noise Ratio >55dB
Speakers
Speaker
Impedance
6 ohm
Speaker Driver 3.5” woofer + 1” tweeter
Sensitivity > 80 dB/m/W±4dB/m/W
General information
AC power 220 - 230 V, 50 Hz
Operation Power
Consumption
45 W
Eco Standby Power
Consumption
< 1 W
Composite Video
Output
1.0 Vp-p, 75 ohm
Coaxial Ouput 0.5 Vpp ± 0.1 Vpp,
75 ohm
Headphone output 2 x 15 mW, 32 ohm
USB Direct Version 2.0
Dimensions
- Main Unit
(W x H x D)
- Speaker Box
(W x H x D)
223 x 88 x 242 mm
140 x 220 x 206 mm
Weight
- With Packing
- Main Unit
- Speaker Box
7.7 kg
1.8 kg
2 x 1.95 kg
11 Product
information
Note
Product information is subject to change •
without prior notice.
Speci cations
Ampli er
Rated Output
Power
2 X 30 W RMS
Frequency
Response
40 Hz - 20000 Hz, ±3
dB
Signal to Noise
Ratio
> 65 dB
Aux Input 1 V RMS 20k ohm
Disc
Laser Type Semiconductor
Disc Diameter 12 cm/8 cm
Video Decoding MPEG-1 / MPEG-2 / DivX
Video DAC 12 Bits
Signal System PAL / NTSC
Video Format 4:3 / 16:9
Video S/N > 48 dB
Audio DAC 24 Bits / 96 kHz
Total Harmonic
Distortion
< 0.8% (1 kHz)
Frequency
Response
4 Hz - 20 kHz (44.1 kHz)
4 Hz - 22 kHz (48 kHz)
4 Hz - 24 kHz (96 kHz)
S/N Ratio > 65 dBA
English
EN
DCD322_12_UM_Book 1.indb Sec1:25 2011-10-8 16:59:45
26
Directory nesting up to a maximum of 8 •
levels
Number of albums/ folders: maximum 99•
Number of tracks/titles: maximum 999•
ID3 tag v2.0 or later•
File name in Unicode UTF8 (maximum •
length: 128 bytes)
Unsupported formats:
Empty albums: an empty album is an •
album that does not contain MP3/WMA
les, and is not be shown in the display.
Unsupported le formats are skipped. For •
example, Word documents (.doc) or MP3
les with extension .dlf are ignored and
not played.
AAC, WAV, PCM audio les•
DRM protected WMA les (.wav, .m4a, •
.m4p, .mp4, .aac)
WMA les in Lossless format•
Supported disc formats
Digital Video Discs (DVDs)•
Video CDs (VCDs)•
Super Video CDs (SVCDs)•
Digital Video Discs + Rewritable •
(DVD+RW)
Compact Discs (CDs)•
Picture (Kodak, JPEG) les on CDR(W)•
DivX(R) disc on CD-R(W):•
DivX 3.11, 4.x and 5.x•
WMA•
Supported MP3-CD formats:
ISO 9660•
Max. title/album name: 12 characters•
Max. title number plus album: 255.•
Max. nested directory: 8 levels.•
Max. album number: 32.•
Max. MP3 track number: 999.•
Supported sampling frequencies for MP3 •
disc: 32 kHz, 44.1 kHz, 48 kHz.
Supported Bit-rates of MP3 disc are: 32, •
64, 96, 128, 192, 256 (kbps).
The following formats are not supported:•
Files like *.VMA, *.AAC, *.DLF, •
*.M3U,
*.PLS, *.WAV•
Discs recorded in Joliet format •
USB playability information
Compatible USB devices:
USB ash memory (USB 2.0 or USB1.1)•
USB ash players (USB 2.0 or USB1.1)•
memory cards (requires an additional •
card reader to work with this apparatus)
Supported formats:
USB or memory le format FAT12, •
FAT16, FAT32 (sector size: 512 bytes)
MP3 bit rate (data rate): 32-320 Kbps and •
variable bit rate
WMA v9 or earlier•
EN
DCD322_12_UM_Book 1.indb Sec1:26 2011-10-8 16:59:45
27
12 Troubleshooting
Caution
Never remove the casing of this apparatus. •
To keep the warranty valid, never try to repair
the system yourself.
If you encounter problems when using this
apparatus, check the following points before
requesting service. If the problem remains
unsolved, go to the Philips web site (www.
Philips.com/support). When you contact Philips,
ensure that your apparatus is nearby and the
model number and serial number are available.
No power
Ensure that the AC cord of the apparatus •
is connected properly.
Ensure that there is power at the AC •
outlet.
As a power-saving feature, the system •
switches off automatically 15 minutes
after track play reaches the end and no
control is operated.
No disc detected
Insert a disc. •
Check if the disc is inserted upside down. •
Wait until the moisture condensation at •
the lens has cleared.
Replace or clean the disc. •
Use a nalized CD or correct format disc. •
No picture
Check the video connection. •
Turn on the TV to the correct Video-In •
channel.
Progressive scan is activated but the TV •
does not support progressive scan.
Black and white or distorted picture
The disc does not match the TV color •
system standard (PAL/NTSC).
Sometimes a slight picture distortion may •
appear. This is not a malfunction.
Clean the disc. •
RDS program types
NO TYPE No RDS programme type
NEWS News services
AFFAIRS Politics and current affairs
INFO Special information
programs
SPORT Sports
EDUCATE Education and advanced
training
DRAMA Radio plays and literature
CULTURE Culture, religion and
society
SCIENCE Science
VARIED Entertainment programs
POP M Pop music
ROCK M Rock music
MOR M Light music
LIGHT M Light classical music
CLASSICS Classical music
OTHER M Special music programs
WEATHER Weather
FINANCE Finance
CHILDREN Children’s programs
SOCIAL Social Affairs
RELIGION Religion
PHONE IN Phone In
TRAVEL Travel
LEISURE Leisure
JAZZ Jazz Music
COUNTRY Country Music
NATION M National Music
OLDIES Oldies Music
FOLK M Folk Music
DOCUMENT Documentary
TES Alarm Test
ALARM Alarm
English
EN
DCD322_12_UM_Book 1.indb Sec1:27 2011-10-8 16:59:46
28
DivX video les cannot be played.
Ensure that the DivX video le is •
complete.
Ensure that the le extension is correct. •
Due to Digital Rights issue, the DRM- •
protected video les cannot be played
through an analog video connection
(e.g. composite, component and scart).
Transfer the video content onto the Disc
Media and play these les.
Poor radio reception
Increase the distance between the •
apparatus and your TV or VCR.
Fully extend the FM antenna. •
Connect an outdoor FM antenna instead. •
Audio or subtitle languages cannot be set
The disc is not recorded with sound or •
subtitles in multiple languages.
The audio or subtitle language setting is •
prohibited on the disc.
Cannot display some les in USB device
The number of folders or les in the USB •
device has exceeded a certain limit. This
phenomenon is not a malfunction.
The formats of these les are not •
supported.
USB device not supported
The USB device is incompatible with the •
unit. Try another one.
Timer does not work
Set the clock correctly. •
Switch on the timer. •
Clock/timer setting erased
Power has been interrupted or the power •
cord has been disconnected.
Reset the clock/timer. •
A distorted picture may appear during •
progressive scan setup.
The aspect ratio of the TV screen cannot be
changed even though you have set the TV
display format.
The aspect ratio is xed on the loaded •
DVD disc.
The aspect ratio may not be changed for •
some TV systems.
No sound or poor sound
Adjust the volume. •
Disconnect the headphones. •
Check that the speakers are connected
•
correctly.
Check if the stripped speaker wires are •
clamped.
Remote control does not work
Before you press any function button, •
rst select the correct source with the
remote control instead of the main unit.
Reduce the distance between the remote •
control and the unit.
Insert the battery with its polarities •
(+/– signs) aligned as indicated.
Replace the battery. •
Aim the remote control directly at the •
sensor on the front of the unit.
Disc does not play
Insert a readable disc with the label side •
facing you.
Check the disc type, color system and •
regional code. Check for any scratches or
smudges on the disc.
Press •SYSTEM MENU to exit the system
setup menu.
Disable the password for parental control •
or change the rating level.
Moisture has condensed inside the •
system. Remove the disc and leave the
system turned on for about an hour.
Disconnect and reconnect the AC power
plug, and then turn on the system again.
As a power-saving feature, the system •
turns off automatically 15 minutes after
disc play reaches the end and no control
is operated.
EN
DCD322_12_UM_Book 1.indb Sec1:28 2011-10-8 16:59:46
© 2011 Koninklijke Philips Electronics N.V.
All rights reserved.
DCD322_12_UM_Book 1_V4.0
DCD322_12_UM_Book 1.indb 246 2011-10-8 17:02:39
