2
YEARS
WARRANTY
*
SOLAR BULKHEAD
This marking indicates that this
product should not be disposed
of with other household wastes.
TECHNICAL DATA
IP65
RATING
INTRODUCTION & WARRANTY
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions
carefully before starting the installation and keep this manual handy for future reference. If you have any another
query, please contact our dealer or local vendor from whom you have purchased the product. They are trained and
ready to serve you at the best. The warranty is valid for 2 years from the date of purchase. The warranty does not apply
to damage caused by incorrect installation or abnormal wear and tear. The company gives no warranty against damage
to any surface due to incorrect removal and installation of the product. The products are suitable for 10-12 Hours Daily
operation. Usage of product for 24 Hours a day would void the warranty. This product is warranted for manufacturing
defects only.
WARNING!
1. Please make sure to turn off the power before starting the installation.
2. Installation must be performed by a qualified person.
3. The light source of this luminaire is not replaceable, when the light source reaches its end of life the whole luminaire
should be replaced.
4. If the external flexible cable or cord of this luminaire is damaged, it shall be exclusively replaced by the manufacturer
or his service agent or a similar qualified person in order to avoid a hazard.
5. Do not use solvents, petrol, etc.
Otherwise the light will be damaged.
INSTALLATION INSTRUCTIONS
INSTALLATION INSTRUCTION
STEP 1
Remove the cover by twisting the diffuser
anti - clockwise and set aside. Carefully
remove the LED tray.
STEP 2
Hold the product in
place, mark & drill
the holes into the
wall then use
expansion screws
to fix the bulkhead
on the wall/ceiling.
Step 3
Install the LED tray on the fitting. Re-install
the cover by twisting the diffuser clockwise.
Ensure the fitting is properly installed.
STEP 5
Plug the twist after the twist cap.
[FIG 1]
[FIG 2]
[FIG 3]
[FIG 4]
[FIG 5]
Step 4
Use 2 expansion
screws to fix the
solar panel on
the wall.
Note: the battery must be fully charged
before using 3-5 rainy days
INSTALLATION GUIDE:
MAINTENANCE &WARNING
1. Before installing please remove all the parts to check if all are in good condition or not.
2. The luminaire is connected to the solar panel against the sun light. Please makes sure
the solar panel is adjusted in correct angle in order to receive sunlight.
3. The remote control is designed with an operation distance of 8-15m.
4. The solar panel Angle must be adjusted in correct direction to receive sunlight.
5. Lamps cannot be installed in low-lying areas, so as not to soak.
6. Plug the male and female plugs and tighten the waterproof cap and install it.
7. After installation test the light using the remote control.
• Clean the light with a dry, lint-free cloth.
• Check the solar panel for dirt regularly. If dirt or is present remove it to guarantee
flawless function of the product.
• Especially during the winter, keep the product free from snow and ice.
• Confirm installation direction is correct (solar panel should be at top).
• Confirm no objects blocking the solar panel to receive sunlight.
• Keep away from fire.
• Don't immerse in the water.
Model
Solar
Panel
Lumens Beam Angle
Solar Panel
Dimension
Ba�ery
Type
Charging
Time
Working
Time
Input
Power
Dimension
Installa�on
Height
4-6 Meters
VT-8415 10W
6400K - 900LM
4000K - 550LM
3000K - 650LM
120°
350x230x17mm
10000mAh
4-6Hours 10-12Hours
DC:3.2V
ø320x100mm
REMOTE CONTROL
PARTS INCLUDED
Solar Panel
Solar Bulkhead
5M Wire Length
Remote Control
IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT: SUPPORT@V-TAC.EU
FOR MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST
DEALERS. V-TAC EUROPE LTD. BULGARIA, PLOVDIV 4000, BUL.L.KARAVELOW 9B
Turn on the light
CCT Color Mode
5H: (The light will work
for 5hrs)
3H: (The light will work
for 3hrs)
8H: (The light will work
for 8hrs)
AUTO: (It will work continuously
no matter it is daytime or night)
Turn off the light
100% Brightness
50% Brightness
ENGLISH
