9.31
9.33
9.35
This addendum accompanies your M9.31/M9.33/M9.35 Assembly Guide. Changes have occured to the hardware kit. The length of the socket head
screw (E) has changed from 1½-inch to 1¼-inch, and the quantity of washer (D) has been corrected.
Hardware Kit
The following hardware kit replaces the one found in the Assembly
Guide. If any items are missing, refer to Obtaining Service in your
Owner’s Manual.
1—¼-inch hex key
Fasteners Quantity
(A) Socket head screw (2-inch) 4
(B) Barrel spacer 4
(C) Socket head screw (¾-inch) 10
(D) Washer (⁵⁄₁₆-inch x .562 OD) 16
(E) Socket head screw (1¼-inch) 2
(F) Washer (⁵⁄₁₆-inch x .688 OD) 4
(G) Socket head screw (1-inch) 4
Fasteners Quantity
Assembly Guide Addendum
P/N 48463-101
18 February 2005
