Washer-Dryer
User Manual
GWDI8542
2820529522_EN/ 28-06-21.(14:57)Document Number :
Please read this user
manual first!
Dear Customer,
Thank you for choosing a Grundig product. We
hope that you get the best results from your
product which has been manufactured with
high quality and state-of-the-art technology.
Therefore, please read this entire user manual
and all other accompanying documents
carefully before using the product and keep it
as a reference for future use. If you handover
the product to someone else, give the user
manual as well. Follow all warnings and
information in the user manual.Throughout this
user manual the following symbols are used:
B
DANGER!
• Warning for electric shock.
DANGER!
• Product weight warning
DANGER!
• Fire risk warning.
A
CAUTION!
• Warning for hazardous situations
with regard to life and property.
A
PRECAUTION!
• Precautions that need to be taken.
C
INFORMATION
• Important information or useful hints about
usage.
• Read user manual.
• Packaging materials of the
product are manufactured
from recyclable materials in
accordance with regulations.
• Do not dispose of the
Packaging materials
together with the domestic
or other wastes. Take them
to the packaging material
collection points designated
by the local authorities.
• Allergy UK, is the brand of
British Allergy Association. Their
main endorsement is the ‚Seal
of Approval‘. When you see
a product with this logo on it,
you have the reassurance the
product has been scientifically
tested to prove it is efficient at
reducing/removing allergens
from the environment
of allergy and asthma
sufferers or the products
have significantly reduced
allergen/chemical content.
3 / EN
Washer-Dryer / User Manual
1 Important instructions for safety and environment
This section contains safety instructions
that will help protect from risk of personal
injury or property damage. Failure to follow
these instructions shall void any warranty.
1.1 General safety
A
CAUTION!
• This product can be used by
children at and above 8 years old
and by persons whose physical,
sensory or mental capabilities are
not fully developed or who lack
experience and knowledge provided
that they are supervised or trained
on the safe use of the product and
the risks involved. Children should
not play with the product. Cleaning
and maintenance works should not
be performed by children unless
they are supervised by someone.
Children under the age of 3 must be
kept away from the product unless
they are continuously supervised.
A
WARNING!
• Never place the product on a carpet-
covered floor. Otherwise, lack of
airflow beneath the product will cause
electrical parts to overheat. This will
cause problems with your product.
C
INFORMATION
• Always have the installation
procedures carried out by
authorised persons. The
manufacturer shall not be held
liable for damages that may arise
from procedures carried out by
unauthorised persons.
A
WARNING!
• If you are going to use the product
in a wardrobe/cabinet/module and
if the opening is not sufficient, it is
recommended to keep the doors
of the wardrobe/cabinet/module
open during the process to ensure
sufficient air circulation.
1.1.1 Electrical safety
B
DANGER!
• If the product has a failure, it should
not be operated unless it is repaired
by the Authorised Service Agent.
There is risk of electric shock!
• Never wash the product by
spreading or pouring water onto it!
There is risk of electric shock!
A
CAUTION!
• If the power cable is damaged, it must
be replaced by the manufacturer, after
sales service or a similarly qualified
person (preferably an electrician) or
someone designated by the importer
in order to avoid possible risks.
4 / EN
Washer-Dryer / User Manual
A
WARNING!
• Unplug the product when it is not
in use.
• Never touch the plug with wet hands!
Never unplug by pulling on the cable,
always pull out by grabbing the plug.
• Unplug the product during installation,
maintenance, cleaning and repair.
• Do not make connections via
extension cables or multi-plugs.
C
INFORMATION
• This product is designed to resume
operating in the event of powering
on after a power interruption. If you
wish to cancel the programme, see
"Cancelling the programme" section.
1.1.2 Product safety
B
DANGER!
• Never open the loading door or remove
the filter while there is still water in the
drum. Otherwise, risk of flooding and
injury from hot water will occur.
A
CAUTION!
• The water supply and draining
hoses must be securely fastened
and remain undamaged. Otherwise,
there is the risk of water leakage.
A
WARNING!
• The product should be used without
removing the upper plate.
C
INFORMATION
• Do not force open the locked loading
door. The door will open immediately
after the washing cycle has ended. If
the machine is not cooled enough at
the end of the programme, the loading
door cannot be opened. Wait for the
product to cool down. If the door still
does not open, apply the solutions
provided for "Loading door cannot
be opened" in the Troubleshooting
section. Do not force the loading door
to open. The loading door and the lock
mechanism may get damaged.
• In the location where this product is
going to be installed, there must be
no doors with a lock, bolt or hinge
that will prevent the loading door
from opening completely.
• Follow the instructions on the textile
tags and on the detergent package.
• Use detergents, softeners and
supplements suitable for washing
machines only.
5 / EN
Washer-Dryer / User Manual
C
INFORMATION
• Do not install or leave the product in
places where it might be exposed to
outdoor conditions.
• Do not play with control elements of
the product.
• If a non-self-resetting thermal cut-out
is required in order to comply with
the standard then the instructions for
appliances incorporating a non-self-
resetting thermal cutout that is reset
by disconnection of the supply mains
shall contain the substance of the
following:
CAUTION:
In order to avoid a hazard
due to inadvertent resetting of the
thermal cut-out, this appliance must
not be supplied through an external
switching device, such as a timer, or
connected to a circuit that is regularly
switched on and off by the utility.
1.1.3 Warnings about drying
DANGER!
• Laundry that has previously been
washed, cleaned, soiled or stained
with petrol/gas, dry cleaning solvents
or other inflammable/combustive
substances must not be dried in the
machine since they emit inflammable/
combustive vapour. Otherwise, there
will be the risk of fire.
• Laundry soiled with vegetable
oil, alcohol, petrol, gas oil, stain
remover, turpentine, wax or wax
remover must be washed with
hot water and a great amount of
detergent before drying. Otherwise,
there will be the risk of fire.
DANGER!
• Rubber (latex) foam, shower caps,
waterproof fabrics, clothes and
rubber-reinforced/rubber-foam
pillows must not be dried with the
drying function. Otherwise, there will
be the risk of fire.
• If you use laundry balls, measuring
scoops or laundry cage in your
machine, these products might melt
during the drying process. If you are
going to select the drying function, do
not use these products. Otherwise,
there will be the risk of fire.
• If you are using industrial chemicals
for cleaning, do not use the drying
function. Otherwise, there will be the
risk of fire.
B
DANGER!
• Do not touch the glass of the
loading door with bare hands after
drying. There is the risk of burning.
• There is a final step, which is
cooling, to keep the laundry at a
certain temperature to ensure that
it is not damaged. You may be
exposed to hot steam if you open
the door before cooling is complete.
There is the risk of scalding.
• If the drying programmes are
interrupted (due to programme
cancellation or power failure), the
laundry in the machine might be
hot. Be careful.
6 / EN
Washer-Dryer / User Manual
A
CAUTION!
• Do not stop the machine before the
drying programme is completed.
If you have to do so, remove all
laundry, place it at an appropriate
place and wait for it to cool down.
• Your product is designed to work at
temperatures between 0°C and +35°C.
• Ambient temperatures between
15°C and +25°C are suitable for
your product.
• Do not let pets enter the product. Check
inside of the product before using it.
• Do not overload the machine to dry
laundry. Observe the maximum load
levels stated for drying.
A
WARNING!
• Do not use the machine to dry
leather clothes or clothes that contain
leather (such as leather labels on
jeans). The colour of the leather parts
might affect other fabrics.
• If there is a problem you cannot solve
by using the information given in the
safety instructions section, switch off
and unplug the machine and call the
Authorised Service Agent.
• You can use your washer-dryer to
only wash, only dry or both wash and
dry laundry. The machine must not
be used to dry wet laundry only for a
long time. When using the machine
only for drying purposes, run a
washing programme with the machine
unloaded after every 15 drying cycles.
A
WARNING!
• Before loading the machine, check
each laundry item and make sure
that there is no lighter, change,
metal objects, needles etc. inside
them or in their pockets.
• Underwear with metal supports
must not be dried in the machine.
Metal supports might come off
during the drying process and
damage the machine. Place them in
a bag or a pillowcase.
• Do not use the machine to dry large
laundry such as tulle, curtains,
sheets/bedding, blanket or rugs.
Your laundry might get damaged.
C
INFORMATION
• Do not dry unwashed laundry in the
machine.
• Do not use softeners or antistatic
agents unless recommended by the
manufacturer.
• Products such as softeners must
be used in accordance with the
manufacturer’s instructions.
• Do not use the machine to dry silk,
wool and similar delicate clothes.
Otherwise, woollen clothes may
shrink, and other delicate clothes
might get damaged.
• Check the symbols on the label of the
clothes before washing and drying.
• The water supply pressure required
to run the product is between 1 to
10 bars (0.1 – 1 MPa).
• Do not use old or used water inlet
hoses on the new product. It may
cause stains on your laundry.
7 / EN
Washer-Dryer / User Manual
1.2 Intended use
C
INFORMATION
• This product has been designed for
domestic use. It is not suitable for
commercial use and it must not be
used out of its intended use.
• The product must be used to wash,
rinse and dry only the textile products
that have the relevant marking.
• The manufacturer waives any
responsibility arisen from incorrect
usage or transportation.
• The service life of your product is
10 years. During this period, original
spare parts will be available for the
product to operate properly.
• This appliance is intended to be
used in household and similar
applications such as:
– staff kitchen areas in shops, offices
and other working environments;
– farm houses;
– by clients in hotels, motels and
other residential type environments;
– bed and breakfast type
environments;
– areas for communal use in blocks
of flats or in launderettes.
1.3 Children's safety
A
CAUTION!
• Children under the age of 3 must be
kept away from the product unless
they are continuously supervised.
• Packaging materials are dangerous
to children. Keep packaging
materials in a safe place away from
reach of the children.
• Electrical products are dangerous for
children. Keep children away from
the product when it is in use. Do not
allow them to play with the product.
Use child lock to prevent children
from intervening with the product.
• Do not forget to close the loading
door when leaving the room where
the product is located.
• Store all detergents and additives in
a safe place away from the reach of
the children by closing the cover of
the detergent container or sealing
the detergent package.
8 / EN
Washer-Dryer / User Manual
1.4 Compliance with the
WEEE Directive and disposing
of the waste product
This product does not contain the harmful
and prohibited materials described in the
“Directive on the Management of Waste
Electrical and Electronic Equipment”. It
complies with the WEEE Directive.
This product has been
manufactured with high quality parts
and materials which can be reused
and are suitable for recycling.
Therefore, do not dispose of the
product with normal domestic
waste at the end of its service life.
Take it to a collection point for the
recycling of electrical and electronic
equipment. Please consult your
local authorities to learn about
the nearest collection point.
Help protect the environment and natural
resources by recycling used products.
For children’s safety, cut the power
cable and break the lock mechanism of
the loading door to make the product
non-functional before disposal.
Compliance with the RoHS Directive
This product complies with the RoHS Directive
No. 2011/65/EU. It does not contain harmful
or prohibited materials stated in the directive.
1.5 Package information
Packaging materials of the product are
manufactured from recyclable materials in
accordance with our National Environment
Regulations. Do not dispose of the packaging
together with normal domestic waste. Take
them to the packaging material collection
points designated by local authorities.
2 Your washer-dryer
2.1 Overview
3
4
5
2
1
6
7
8
1- Power cable
2- Top panel
3- Control panel
4- Filter cover
5- Adjustable feet
6- Loading door
7- Detergent drawer
8- Water discharge hose
9 / EN
Washer-Dryer / User Manual
2.2 Package contents
Power cable
Water discharge hose
Transit bolts
Mains water inlet hose
User manual
Plastic plug group
NOTE
• Figures in this manual are schematic and may not match the product exactly.
10 / EN
Washer-Dryer / User Manual
2.3 Technical specifications
C
INFORMATION
SUPPLIER’S NAME MODEL IDENTIFIER
A
A
(*)
• The model information as stored in the
product database can be reached by entering
following website and searching for your
model identifier (*) found on energy label.
https://eprel.ec.europa.eu/
Supplier name or trademark GRUNDIG
Model name
GWDI8542
7162546500
Maximum spin speed (rpm) 1400
Washing capacity (cotton) (kg) 8
Drying capacity (cotton) (kg) 5
Built-in Yes
Height (cm) 82
Width (cm) 60
Depth (cm) 55
Single Water inlet / Double Water inlet
• / -
• Available
Electrical input (V/Hz) 230 V / 50Hz
Total current (A) 10
Total power (W) 2200
Main model code 1420
Rinse
Spin+Drain
Prewash Fast Fast+ Extra
Rinse
Extra
Water
Anti
Crease
Pet Hair
Removal
Rinse
Hold
No
Water
Drain
Soaking
Spin No
Spin
Tap
Water
(Cold)
Steam
Time
Delay
Night
Modu
Temperature Door
Lock
Child
Lock
On/Off Start /
Pause
Soil Level Add
Garment
AutoDose
Liquid
Detergent
Selection
Softener
Selection
Wash
Downloaded
Program
Steeping
Ok
(End)
Cancel
AntiCrease+ Iron
Dry
Cupboard
Dry
Extra
Dry
Timed
Drying
Clean&
Wear
Symbols Table
Drying
11 / EN
Washer-Dryer / User Manual
3 Installation
To make the product ready for use, review the
information in the user manual and make sure
that the electricity, tap water supply and water
drainage systems are appropriate. If they are
not, call a qualified technician and plumber to
have any necessary arrangements carried out.
B
DANGER!
• Make sure that the installation and
electrical connections of the product
are performed by competent persons.
Manufacturer shall not be held liable for
damages that may arise from procedures
carried out by unauthorised persons.
DANGER!
• Your product is too heavy for
one person to carry.
A
CAUTION!
• Prior to installation, visually check if
the product has any defects on it. If
so, do not have it installed. Damaged
products cause risks for your safety.
A
PRECAUTION!
• Preparation of the location and
electrical, tap water and waste water
installations at the place of installation
is under customer’s responsibility.
• Make sure that the water inlet and
discharge hoses as well as the power
cable are not folded, pinched or crushed
while pushing the product into its place
after installation or cleaning procedures.
3.1 Appropriate
installation location
• Place the product on a solid and level
floor. Do not place it onto a carpet with
high pile or other similar surfaces.
• Do not place the product close to the
edge if the floor contains steps. Do not
also place the product on a platform.
• Do not place the product on the power cable.
• Do not install the product in environments
where the temperature falls below
0 ºC.(See. Warnings for Drying)
• Leaving a gap at the sides of the machine
is suggested to reduce vibration and noise
• In the area where this product is
installed, there must not be a lockable,
sliding or hinged door that will restrict
the full opening of loading door.
• Operate the product in a well ventilated
and dust free environment.
• Do not place heat sources such as Hobs,
Irons, Ovens, etc. on the washing machine
and do not use them on the product
3.2 Removing packaging
reinforcement
Tilt the machine backwards to remove
the packaging reinforcement. Remove the
packaging reinforcement attached to the ribbon.
B
DANGER!
• Your product is heavy. Remove packaging
reinforcement as displayed in the figure.
• Be careful not to get your hand caught
under the machine during this procedure.
12 / EN
Washer-Dryer / User Manual
3.3 Removing the transit bolts
A
PRECAUTION!
• Do not remove the transit bolts before
removing the packaging reinforcement.
• Remove the transit bolts before operating
the washing machine! Otherwise,
the product will get damaged.
3
2
1
1 Use a tool to loosen all bolts
until they rotate freely.
2 Remove the transit bolts by
turning them slightly.
3 Attach the plastic covers supplied in the user
manual bag into the holes on the rear panel.
C
INFORMATION
• Keep the transit bolts in a safe place
to reuse when the product needs
to be moved again in the future.
• Never move the product without the
transit bolts properly fixed in place!
3.4 Connecting water supply
C
INFORMATION
• The water supply pressure required to
run the product is between 1 to 10 bars
(0.1 – 1 MPa). It is necessary to have
10 – 80 liters of water flowing from the
fully open tap in one minute to have your
product run smoothly. Attach a pressure
reducing valve if water pressure is higher.
A
CAUTION!
• Models with a single water inlet should
not be connected to the hot water
tap. In such a case the laundry will get
damaged or the product will switch to
protection mode and will not operate.
• Do not use old or used water inlet
hoses on the new product. It may
cause stains on your laundry.
1 2 3
1 Connect the special hose supplied with the
product to the water inlet on the product.
A
CAUTION!
• Ensure that the cold water connection
is made correctly when installing the
product. Otherwise, your laundry
will come out hot at the end of the
washing process and wear out.
2 Tighten the hose nuts securely by hand.
Never use a tool when tightening the nuts.
3 Open the taps completely after making the
hose connection to check for water leaks at
the connection points. If any leak occurs, turn
off the tap and remove the nut. Retighten the
nut carefully after checking the seal. In order
to prevent the water leaks, keep the taps
closed when you do not use the product.
3.5 Connecting to the drain
• Attach the end of the drain hose directly
to waste water drain, sink or bathtub.
A
CAUTION!
• Your house will be flooded if the hose
comes out of its housing during water
discharge. Moreover, there is risk of
scalding due to high washing temperatures!
To prevent such situations and to ensure
smooth water intake and discharge of
the machine, fix the end of the discharge
hose tightly so that it cannot displace.
90 cm
90
40
90
40
90 cm
90 cm
min.40
• Connect the hose to a minimum height of
40 cm and a maximum height of 90 cm.
• If the hose is run along the floor (or at less
than 40 cm above it) and raised later on,
water drain becomes difficult and laundry
may come out extremely wet. Therefore,
observe the heights described in the figure.
13 / EN
Washer-Dryer / User Manual
• To prevent flowing of dirty water back into
the machine and to allow for easy discharge,
do not immerse the hose end into the dirty
water or do not drive it in the drain more
than 15 cm. If it is too long, cut it short.
• The end of the hose should not be
bent, it should not be stepped on
and the hose must not be pinched
between the drain and the machine.
• If the length of the hose is too short, add an
original extension hose. Length of the hose
may not be longer than 3.2 m. To avoid water
leak failures, the connection between the
extension hose and the drain hose of the
product must be fitted well with an appropriate
clamp as not to come off and leak.
3.6 Adjusting the feet
A
CAUTION!
• Adjust feet so that the product will be
balanced in the location it will be used.
• Balance the machine by adjusting the feet.
• Check for any play by pressing the
product from upper diagonal edges.
• Otherwise, the product may move
from its place and cause crushing,
noise and vibration problems.
• Do not use any tools to loosen
the lock nuts. Otherwise, the
lock nuts may get damaged.
a) Loosen the lock nuts on the feet by hand.
b) Adjust the feet until the product
stands level and balanced.
c) Tighten all lock nuts again by hand.
Adjusting Rear Feet
• When you turn the knob (visible in the circle)
in the direction of the arrow, the machine
will be elevated by 0.3 mm. When you turn
it in the opposite direction of the arrow,
the machine will be lowered by 0.3 mm.
• Do not adjust the rear feet by
using chargeable devices. Use
a screwdriver instead.
Adjusting the feet with water level
• You must remove the Detergent
Drawer to set the Water Level.
• For the system to operate properly, the bubble
inside the Water Level must be in the
middle
.
• If the bubble inside the Water Level is
on the
left
, the pre-set
right
foot of the
Washing Machine must be adjusted.
• If the bubble inside the Water Level is
on the
right
, the pre-set
left
foot of the
Washing Machine must be adjusted.
• If the bubble inside the Water Level is at the
back
, the pre-set
front
feet of the Washing
Machine must be turned to the left (clockwise).
• If the bubble inside the Water Level
is at the
front
, the pre-set
front
feet
of the Washing Machine must be
turned to the right (anti-clockwise).
14 / EN
Washer-Dryer / User Manual
3.7 Electrical connection
Connect the product to a grounded outlet
protected by a 13 A fuse. Our company shall
not be liable for any damages that will arise
when the product is used without grounding
in accordance with the local regulations.
• Connection must comply with
national regulations.
• The wiring for the electrical outlet circuit
must be sufficient to meet the appliance
requirements. Use of a Groud Fault Circuit
Interrupter (GFCI) is recommended.
• Power cable plug must be within
easy reach after installation.
• If the current value of the fuse or breaker
in the house is less than 13 Amps, have a
qualified electrician install a 13 Amp fuse.
• The voltage specified in the "Technical
specifications" section must be
equal to your mains voltage.
B
DANGER!
• Damaged power cables must be replaced
by the Authorised Service Agent.
Important
Fitting a different plug
As the colours of the wires in the mains
lead of this appliance may not correspond
with the coloured markings identifying the
terminals on your plug, proceed as follows:
1 Connect the green - yellow or green
(earth) wire to the terminal in the plug
marked ‘E’ or with the symbol f or
coloured green and yellow or green.
2 Connect the blue (neutral) wire to the terminal
in the plug marked ‘N’ or coloured black.
3 Connect the brown (live) wire to the terminal
in the plug marked ‘L’ or coloured red.
With the alternative plugs a 13A fuse
must be fitted either in the plug or
adaptor or in the main fuse box. If in
doubt contact a qualified electrician.
3.8 Transportation of the product
1 Unplug the product before transporting it.
2 Remove water drain and water
supply connections.
3 Drain all water that has remained
in the product. See 6.5
4 Install the transit bolts in reverse order of
the disassembly procedure. See 3.3
B
DANGER!
• Your product is too heavy for
one person to carry.
• Your product is heavy; two persons
must carry it and extra precaution
taken on stairs. If your product falls
on you, it may cause injuries.
A
CAUTION!
• Packaging materials are dangerous to
children. Keep packaging materials in a
safe place away from reach of the children.
C
INFORMATION
• Never move the product without the
transit bolts properly fixed in place!
15 / EN
Washer-Dryer / User Manual
4 Preparation
4.1 Sorting the laundry
* Sort laundry according to type of
fabric, colour, and degree of soiling
and allowable water temperature.
* Always observe the instructions given
on the garment care labels.
4.2 Preparing laundry for washing
• Laundry items with metal attachments
such as, underwired bras, belt buckles or
metal buttons will damage the machine.
Remove the metal pieces or wash such
clothes by putting them in a cotton laundry
bag or cotton pillow case. Also these
type of clothes can heat too much during
drying and damage your other clothes.
Do not dry such laundry in the machine.
• Put small size clothes such as infant's
socks and nylon stockings in cotton a
laundry bag or cotton pillow case.
• Place curtains in without compressing
them. Remove curtain attachment items.
Do not dry tulle curtains in your machine.
• Fasten zips, sew loose buttons
and mend rips and tears.
• Wash “machine washable” or “hand
washable” labelled products only with an
appropriate programme. Dry these type
of clothes by hanging or laying down.
Do not dry them in the machine.
• Do not wash colours and whites together.
New, dark coloured cottons release a
lot of dye. Wash them separately.
• Only use the dyes / colour changers and
descaling agents which are appropriate
to machine wash. Always follow the
instructions on the package.
C
INFORMATION
• Laundry that is subjected to heavy
deposits of materials such as flour, lime
dust, milk powder, etc. Must be shaken
off before placing into the machine.
Such dusts and powders on the laundry
may build up on the inner parts of the
product in time and can cause damage.
• Keep laundry items made of Angora
wool in the freezer for a few hours before
washing. This will reduce pilling.
• Wash trousers and delicate
laundry turned inside out.
• Tough stains must be treated
properly before washing. If unsure,
check with a dry cleaner.
• Take out all substances in the pockets
such as coins, pens and paper clips,
and turn pockets inside out and
brush. Such objects may damage the
product or cause noise problem.
4.3 Tips for energy
and water saving
Following information will help you
use the product in an ecological and
energy/water-efficient manner.
• Operate the product in the highest load
capacity allowed for the programme you
have selected, but do not overload. See,
“Programme and consumption table”.
• Observe the temperature instructions
on the detergent packaging.
• Wash slightly soiled laundry
at low temperatures.
• Use faster programmes for small
quantities of lightly soiled laundry.
• Do not use prewash and high temperatures
for laundry that is not heavily soiled or stained.
• If you plan to dry your laundry in a
dryer, select the highest spin speed
recommended during washing process.
• Do not use more detergent than the
recommended on the detergent packaging.
16 / EN
Washer-Dryer / User Manual
4.4 Initial use
Before starting to use the product make
sure that all preparations are made in
accordance with the “Important safety
and environment instructions” and the
instructions in the “Installation” section.
To prepare the product for washing laundry,
perform first operation in Drum Cleaning
programme. If this programme is not
available in your machine, apply the method
which is described in the section 6.2.
C
INFORMATION
• Use an anti-limescale product suitable
for the washing machines.
• Some water may remain in the product
due to the quality control processes in the
production. It is not harmful for the product.
4.5 Correct load capacity
The maximum load capacity depends on
the type of laundry, the degree of soiling
and the desired washing programme.
The product automatically adjusts the water amount
according to the weight of the laundry put inside it.
A
CAUTION!
• Follow the information in the “Programme
and consumption table”. When overloaded,
machine’s washing performance will drop.
Moreover, noise and vibration problems may
occur. For a successful drying performance,
do not dry more laundry than stated.
Laundry
type
Weight
(g)
Laundry
type
Weight
(g)
Bathrobe 1200 Hand towel 100
Fabric napkin 100
Women‘s
night gown
200
Bed sheet 700 Underclothing 100
Bed sheet 500 Men’s overalls 600
Pillowcase 200 Men’s shirt 200
Tablecloth 250 Men’s pyjamas 500
Towel 200 Blouses 100
4.6 Loading the laundry
1. Open the loading door.
2. Put the laundry items into the
product in a loose manner.
3. Push the loading door to close until
you hear a locking sound. Ensure that
no items are caught in the door.
C
INFORMATION
• The loading door is locked while a
programme is running. The door lock
will open immediately after the washing
programme has ended. If the inner part of
the machine is too hot at the end of the
programme, the loading door will not open
until the temperature drops. If the door
does not open, apply the solutions provided
for “Loading Door Cannot be Opened.”
error in the Troubleshooting section.
A
CAUTION!
• If the laundry is misplaced, noise and
vibration problems may occur in the machine.
4.7 Using detergent and softener
C
INFORMATION
• When using detergent, softener, starch,
fabric dye, bleach and descaling agents;
read the manufacturer’s instructions written
on the package and follow the dosages
specified. Use a measuring cup if available.
17 / EN
Washer-Dryer / User Manual
4.7.1 Detergent drawer
The detergent drawer is composed
of four compartments:
II
II
I
1) Left compartment with number “II” (Main
wash compartment for powder detergent
or powder bleach/stain remover)
2) Left compartment with number “II
” (Main wash compartment for liquid
detergent or liquid stain remover)
3) Middle compartment with number
“I” (pre-wash compartment for powder
detergent, powder stain remover or liquid
bleach - liquid bleach must be added either
during the pre-wash or during the first
rinsing step of the washing Programme).
Liquid bleach must be added manually
while the machine takes in water.
4) Right compartment with “
” symbol (liquid
softener compartment) (
) in addition, there is
a siphon piece in the softener compartment.
C
INFORMATION
• Never leave the detergent drawer open
while the washing programme is running!
• When using a programme without
prewash, do not put any detergent
into the prewash compartment
(compartment nr. “I“).
• Do not select a programme with
prewash if you are using a detergent
bag or dispensing ball. Place the
detergent bag or the dispensing ball
directly among the laundry in the
machine. Remove these if drying
• When machine is in Drying step,
do not add any washing chemicals
(Liquid detergent, Softener, etc.).
4.7.2 Main Wash Compartment
Before starting the washing Programme, put
powder detergent into the left compartment
with number “II”. Powder bleach/stain remover
must also be put into this compartment.
Put the liquid detergent into the main wash
compartment with number “II
” before
starting the washing Programme. Liquid stain
remover must be put into this compartment.
Put the suggested amount of liquid
detergent into the left compartment with “II
” symbol and dilute it to the maximum filling
level line (max. II
) with warm water.
Particularly the concentrated detergents
must be diluted with warm water; otherwise,
the siphon may get clogged in time.
Do not fill the detergent above the maximum
filling level line; otherwise the excess amount of
detergent will reach the laundry without water
and may cause stains on the garments.In this
case you will need to refill the compartment. Do
not pour the detergent onto the laundry directly
since this may cause stains on the garments.
4.7.3 Liquid Softener Compartment
Put the suggested amount of liquid
softener into the right compartment with “
” symbol and dilute it to the maximum
filling level line (max.
) with warm water.
Particularly the concentrated softeners must
be diluted with warm water; otherwise,
the siphon may get clogged in time.
Do not fill the softener above the maximum
filling level line; otherwise the excess amount of
softener will get mixed with the washing water
and you will need to refill the compartment. Do
not pour the softener onto the laundry directly
since this may cause stains on the garments.
Liquid softener will be dispensed automatically at
the final rinsing step of the washing Programme.
4.7.4 Pre-Wash Compartment
Put the powder pre-wash detergent or
powder stain remover into the middle
compartment with number “I”.
You can also put liquid bleach into this
compartment while the machine takes
in water during pre-wash or first rinsing
step. Adding the liquid bleach while the
machine takes in water allows it to be diluted
before it is poured onto the laundry.
18 / EN
Washer-Dryer / User Manual
You must select extra rinsing option if you use
liquid bleach in a washing Programme. Bleach
must be removed from the laundry with rinsing;
otherwise it may cause itching on the skin.
C
INFORMATION
• Read the dosage instructions and
label of your garments carefully
before using the liquid bleach.
4.7.5 Choosing the detergent type
Detergent type to be used depends on the
washing programme, fabric type and color.
• Use different detergents for
coloured and white laundry.
• Wash your delicate clothes only with
special detergents (liquid detergent, wool
shampoo, etc.) intended solely for delicate
clothes and at suggested programmes.
• When washing dark coloured clothes
and quilts, it is recommended
to use liquid detergent.
• Wash woolens at suggested
programme with special detergent
made specifically for woolens
• Please review the program descriptions part
for suggested program for different textiles.
• All recommendations about detergents
are valid for selectable temperature
range of programmes.
A
CAUTION!
• Use only detergents manufactured
specifically for washing machines.
• Do not use Powdered Soap.
4.7.6 Adjusting the
amount of detergent
The amount of washing detergent to be
used depends on the amount of laundry,
the degree of soiling and water hardness.
• Do not use amounts exceeding the dosage
quantities recommended on the detergent
package to avoid problems of excessive
foam, poor rinsing, financial savings
and finally, environmental protection.
• Use lesser detergent for small
amounts or lightly soiled clothes.
4.7.7 Using gel and tablet detergent
• If the gel detergent thickness is fluidal and
your machine does not contain a special liquid
detergent cup, put the gel detergent into the
main wash detergent compartment during first
water intake. If your machine contains a liquid
detergent container, fill the detergent into this
container before starting the programme.
• If the gel detergent thickness is not fluidal
or in the shape of capsule liquid tablet, put
it directly into the drum before washing.
• Put tablet detergents into the main wash
compartment (compartment nr. "2") or
directly into the drum before washing.
C
INFORMATION
• Tablet detergents may leave residues in
the detergent compartment. If you notice
such residues, place the tablet detergent
between the laundry, close to the lower
part of the drum in future washings.
• Use the tablet or gel detergent without
selecting the prewash function.
• Bear in mind that any plastic detergent
cup, bowl etc in the drum should
be removed before drying..
4.7.8 Using laundry starch
• Add liquid starch, powder starch or the
dyestuff into the softener compartment.
• Do not use softener and starch
together in a washing cycle.
• Wipe the inside of the machine with a
damp and clean cloth after using starch.
4.7.9 Using bleaches
• Select a programme with prewash and
add the bleach at the beginning of the
prewash. Do not put detergent in the
prewash compartment. As an alternative
application, select a programme with
extra rinse, add the bleach into an empty
detergent drawer compartment and
also add 1 glass of water from the same
compartment when you see the rinsing
step on the display for the first time.
• Do not use bleach and detergent
by mixing them.
19 / EN
Washer-Dryer / User Manual
• Use just a little amount (approx. 50 ml)
of bleaching agent and rinse the clothes
very well as it causes skin irritation. Do
not pour the bleach onto the laundry and
do not use it with the coloured items.
• When using oxygen-based whitener,
select a programme which washes
the laundry at a low temperature.
• Oxygen-based whitener can be used with
the detergent; however, if it is a different
consistency, first put detergent in the
compartment number “II” in the detergent
dispenser and wait for the machine to flush
the detergent when taking in water. While
the product continues taking in water, add
whitener in the same compartment.
4.7.10 Using limescale remover
• When required, use limescale
removers manufactured specifically
for washing machines only.
4.8 Tips for efficient washing
Clothes
Light Colours and
Whites
Colours
Black/Dark
Colours
Delicates/
Woollens/Silks
(Recommended temperature range
based on soiling level: 40-90˚C)
(Recommended temperature range
based on soiling level: cold -40˚C)
(Recommended
temperature range based
on soiling level: cold -40˚C)
(Recommended temperature
range based on soiling level:
cold -30˚C)
Soiling Level
Heavily Soiled
(difficult stains such as grass,
coffee, fruits and blood.)
It may be necessary to pre-treat the
stains or perform prewash. Powder
and liquid detergents recommended
for whites can be used at dosages
recommended for heavily soiled
clothes. It is recommended to use
powder detergents to clean clay and
soil stains and the stains that are
sensitive to bleaches.
Powder and liquid detergents
recommended for coloured
laundry can be used at dosages
recommended for heavily soiled
clothes. It is recommended to use
powder detergents to clean clay and
soil stains and the stains that are
sensitive to bleaches. Detergents
which do not contain bleach should
be used.
Liquid detergents suitable
for colours and dark
colours can be used at
dosages recommended for
heavily soiled clothes.
Prefer liquid detergents
produced for delicate
clothes. Woollen and silk
clothes must be washed with
special woollen detergents.
Normally
Soiled
(For example, stains
caused by body on
collars and cuffs)
Powder and liquid detergents
recommended for whites can be
used at dosages recommended for
normally soiled clothes.
Powder and liquid detergents
recommended for colours can be
used at dosages recommended for
normally soiled clothes. Detergents
which do not contain bleach should
be used.
Liquid detergents suitable
for colours and dark
colours can be used at
dosages recommended for
normally soiled clothes.
Prefer liquid detergents
produced for delicate
clothes. Woollen and silk
clothes must be washed with
special woollen detergents.
Lightly
Soiled
(No visible stains
exist.)
Powder and liquid detergents
recommended for whites can be
used at dosages recommended for
lightly soiled clothes.
Powder and liquid detergents
recommended for colours can be
used at dosages recommended for
lightly soiled clothes. Detergents
which do not contain bleach should
be used.
Liquid detergents suitable
for colours and dark
colours can be used at
dosages recommended for
lightly soiled clothes.
Prefer liquid detergents
produced for delicate
clothes. Woollen and silk
clothes must be washed with
special woollen detergents.
20 / EN
Washer-Dryer / User Manual
4.9 Tips for correct drying
Programmes
Cottons Drying Synthetics Drying Babyprotect + Washing and Drying Wash&Wear
Types of Clothes
Durable Clothes with
Cotton-Content
Sheet, bedding, baby
clothes, t-shirts,
sweatshirts, durable knit
clothing, jeans, canvas
trousers, shirts, cotton
socks etc.
Not recommended!
Washes and dries
respectively! Sheet,
bedding, baby clothes,
t-shirts, sweatshirts,
durable knit clothing, jeans,
canvas trousers, shirts,
cotton socks etc.
Washes and dries
respectively! Sheet, bedding,
baby clothes, t-shirts,
sweatshirts, durable knit
clothing, jeans, canvas
trousers, shirts, cotton
socks etc.
Stainless clothes that has
been worn for a short time
such as shirts, t-shirts,
sweatshirts A very small
amount of laundry must be
loaded.
Synthetics Clothes
(Polyester, nylon, etc.)
Not recommended!
It is recommended for
the polyester, nylon,
polyacetate, acrylic-
content clothes. Drying is
not recommended for the
viscose-content clothes.
Drying explanations in the
maintenance label should
be taken into account.
It is recommended
for polyester, nylon,
polyacetate, acrylic
content clothes at low
temperatures, taking into
account the washing and
drying warnings on the
care label.
It is recommended for
polyester, nylon, polyacetate,
acrylic content clothes at
low temperatures, taking
into account the washing
and drying warnings on the
care label.
Lightly soiled and stainless
shirts, t-shirts and synthetic-
content clothes. A very small
amount of laundry should
be loaded.
Delicate (Silk, Woollens,
Cashmere, Angora wool,
etc. content) Clothes
Not recommended! Not recommended! Not recommended! Not recommended! Not recommended!
Bulky laundry such
as blankets, coats,
curtains etc.
Not recommended!
It is not appropriate to
dry bulky laundry in the
washer. Dry them by
hanging them or laying
them flat.
Not recommended!
It is not appropriate to
dry bulky laundry in the
washer. Dry them by
hanging them or laying
them flat.
Not recommended! It is not
appropriate to dry bulky
laundry in the washer. Dry
them by hanging them or
laying them flat.
Not recommended! It is
not appropriate to dry bulky
laundry in the washer. Dry
them by hanging them or
laying them flat.
Not recommended! It is
not appropriate to dry bulky
laundry in the washer. Dry
them by hanging them or
laying them flat.
4.10 Displayed Programme Time
You can see the programme duration
on the display of your machine while
selecting a programme. Depending on the
amount of laundry you have loaded into
your machine, foaming, unbalanced load
conditions, fluctuations in power supply,
water pressure and programme settings,
the programme duration is automatically
adjusted while the programme is running.
SPECIAL CASE:
At programme start of
Cottons and Cotton Eco programmes,
display shows the duration of half load,
which is the most common use case. After
programme starts, in 20-25 minutes actual
load is detected by the machine. And if the
detected load is higher than half load; washing
programme will be adjusted accordingly and
programme duration increased automatically.
You may follow this change on the display.
21 / EN
Washer-Dryer / User Manual
5 Operating the product
5.1 Control panel
1 2 3 4 5 6
789
101112
13
1 - Programme selection knob
2 - Temperature level lights
3 - Spin speed level lights
4 - Display
5 - Start/Pause button
6 - Remote Control button
7 - End Time Adjustment button
8 - Drying Level Adjustment Button
9 - Auxiliary function button 2
10 - Auxiliary function button 1
11 - Spin speed adjustment button
12 - Temperature adjustment button
5.2 Display Symbols
1400
1200
800
600
90
˚
60
˚
40
˚
30
˚
20
˚
a b c d e
f
h
g
ikl jno mpr
a - Temperature indicator
b - Spin speed indicator
c - Duration information
d - Door lock engaged symbol
e - Programme follow-up indicator
f - No water indicator
g - Add laundry indicator
h - Bluetooth connection indicator
i - Remote Control indicator
j - Delayed Start enabled indicator
k - Drying level indicator
l - Child lock enabled symbol
m - Auxiliary function indicators 2
n - Auxiliary function indicators 1
o - No spin indicator
p - Rinse hold indicator
r - Cold water indicator
5.3 Preparing the Machine
1. Check if the hoses are connected tightly.
2. Plug in your machine.
3. Turn the tap on completely.
4. Place the laundry in the machine.
5. Add detergent and fabric softener.
5.4 Selecting a washing
programme
1. In accordance with the “Programme
and consumption table”, select a
suitable programme for the amount
and soiling level of the laundry.
2. Select the desired programme with
the
Programme Selection
knob.
C
INFORMATION
• Programmes are limited to the
highest spin speed appropriate for
that particular type of fabric.
• When selecting a programme, always
consider the type of fabric, colour, soiling
level and permissible water temperature.
5.5 Washing programmes
Depending on the type of fabric, use
the following main programmes.
C
INFORMATION
• After selecting a washing programme suitable
for your laundry, you can press the Drying
button to set the machine to perform drying
after the washing programme. Each time you
press the button, info line shows at which
step the drying process will take place and
the relevant symbol will turn on. If you want,
you can keep pressing the button to perform
drying for the maximum period allowed.
• The symbols shown on the display
are schematic and may not
match the product exactly.
• When you will perform washing and
drying by using the Drying function of your
machine, load maximum 5 kg of laundry
into the machine. If you exceed the capacity
of the machine, your laundry will not dry
and the machine will work longer, which
will result in more energy consumption.
22 / EN
Washer-Dryer / User Manual
• Cottons
You can wash your durable cotton laundry
(sheets, bedlinen, towels, bathrobes, underwear
etc.) in this programme. When you press the
quick wash function key, programme duration
becomes notably shorter but effective washing is
ensured thanks to intense washing movements.
If the quick wash function is not selected,
superior washing and rinsing performance
is ensured for your heavily soiled laundry.
C
INFORMATION
• You can dry your laundry without any
interruption right after the washing programme
(it is possible to perform automatic or
scheduled drying after the washing cycle). For
this, you must also select the Drying function
before starting the washing programme.
• According to the drying selections you
will add to the washing programmes,
you can see when the programme will
end on the display of the machine.
• If you don't want drying to take place
after the programme you have selected,
press and hold the Drying auxiliary function
button until the Drying light turns off.
• Synthetics
You can use this programme to wash
t-shirts, synthetic/cotton mix fabrics etc.
Programme duration is notably shorter and
efficient washing performance is ensured.
If the quick wash function is not selected,
superior washing and rinsing performance
is ensured for your heavily soiled laundry.
C
INFORMATION
• You can dry your laundry without any
interruption right after the washing programme
(it is possible to perform automatic or
scheduled drying after the washing cycle). For
this, you must also select the Drying function
before starting the washing programme.
• According to the drying selections you
will add to the washing programmes,
you can see when the programme will
end on the display of the machine.
• If you don't want drying to take place
after the programme you have selected,
press and hold the Drying auxiliary function
button until the Drying light turns off.
• WoolProtect
Use this programme to wash your woollen
clothes. Select the appropriate temperature
complying with the tag of your clothes. Your
laundry will be washed with very delicate
movements to avoid any damage.
C
INFORMATION
• The drying function cannot be
selected for the washing programme
designed for woollen laundry.
• Eco 40-60
The eco 40-60 programme is able to clean
normally soiled cotton laundry declared to be
washable at 40 °C or 60 °C, together in the same
cycle, and that this programme is used to assess
the compliance with the EU ecodesign legislation.
Although it washes longer than all other
programmes, it provides high energy and water
savings. Actual water temperature may be
different from the stated wash temperature.
When you load the machine with less laundry
(e.g. ½ capacity or less), periods in programme
stages may automatically get shorter. In this case,
energy and water consumption will decrease.
Cupboard drying fuction should be
selected with eco 40-60 to perform wash
and dry cycle to assess the compliance
with the EU ecodesign legislation.
The wash and dry cycle is able to clean
normally soiled cotton laundry declared to be
washable at 40 °C or 60 °C, together in the
same cycle, and to dry it in such a way that it
can be immediately stored in a cupboard.
C
INFORMATION
• You can dry your laundry without any
interruption right after the washing programme
(it is possible to perform automatic or
scheduled drying after the washing cycle). For
this, you must also select the Drying function
before starting the washing programme.
• According to the drying selections you
will add to the washing programmes,
you can see when the programme will
end on the display of the machine.
• If you don't want drying to take place
after the programme you have selected,
press and hold the Drying auxiliary function
button until the Drying light turns off.
23 / EN
Washer-Dryer / User Manual
• Mini / Mini 14’
Use this programme to wash your lightly soiled
cotton clothes in a short time. The programme
duration can be reduced down to 14 minutes
when the quick wash function is selected. When
the quick wash function is selected, maximum
2 (two) kg of laundry must be washed.
C
INFORMATION
• You can dry your laundry without any
interruption right after the washing programme
(it is possible to perform automatic or
scheduled drying after the washing cycle). For
this, you must also select the Drying function
before starting the washing programme.
• According to the drying selections you
will add to the washing programmes,
you can see when the programme will
end on the display of the machine.
• If you don't want drying to take place
after the programme you have selected,
press and hold the Drying auxiliary function
button until the Drying light turns off.
• Shirts
Use this programme to wash shirts made of
cotton and synthetic blended fabrics together.
This programme ensures that your clothes
wrinkle less. When the quick wash function is
selected, the Pre-treatment algorithm is used.
• Apply the pre-treatment chemical
directly onto the clothes, or add it together with the
detergent to the powder detergent compartment
when the machine starts to take in water. This
way, it will take you much shorter to get the
performance you would normally get with a regular
washing cycle. Life of your shirts will be longer.
C
INFORMATION
• You can dry your laundry without any
interruption right after the washing programme
(it is possible to perform automatic or
scheduled drying after the washing cycle). For
this, you must also select the Drying function
before starting the washing programme.
• According to the drying selections you
will add to the washing programmes,
you can see when the programme will
end on the display of the machine.
• If you don't want drying to take place
after the programme you have selected,
press and hold the Drying auxiliary function
button until the Drying light turns off.
• Down Wear
Use this programme to wash down coats, vests,
jackets etc. that bear a “machine-washable” tag.
Thanks to special spin profiles, it is ensured that
water reaches the air gaps between feathers.
•
Downloaded Program
This is a special programme that allows you to
download different programmes when you want
to. At the start, there is a programme you will
see with the HomeWhiz application as default.
However, you can use the HomeWhiz application
to select a programme from the predefined
programme settings, and then change it.
C
INFORMATION
• If you wish to use the HomeWhiz and
Remote Control functions, you need to
select Download Programme. Please
see the section HomeWhiz and Remote
Control Function for more details.
• Mix
You can use this programme to wash cottons and
synthetics together without the need to sort them.
C
INFORMATION
• You can dry your laundry without any
interruption right after the washing programme
(it is possible to perform automatic or
scheduled drying after the washing cycle). For
this, you must also select the Drying function
before starting the washing programme.
• According to the drying selections you
will add to the washing programmes,
you can see when the programme will
end on the display of the machine.
• If you don't want drying to take place
after the programme you have selected,
press and hold the Drying auxiliary function
button until the Drying light turns off.
• Outdoor / Sports
Use this programme to wash outdoor/sports
clothes that contain cotton/synthetic mix, as
well as waterproof cloths like gore-tex. This
programme washes your laundry delicately
thanks to its special turning movements.
24 / EN
Washer-Dryer / User Manual
C
INFORMATION
• You can dry your laundry without any
interruption right after the washing programme
(it is possible to perform automatic or
scheduled drying after the washing cycle). For
this, you must also select the Drying function
before starting the washing programme.
• According to the drying selections you
will add to the washing programmes,
you can see when the programme will
end on the display of the machine.
• If you don't want drying to take place
after the programme you have selected,
press and hold the Drying auxiliary function
button until the Drying light turns off.
• Dark Care /Jeans
Use this programme to preserve the colour
of your dark-coloured clothes and jeans. This
programme provides high efficiency in washing,
thanks to a special drum movement, even at low
temperatures. It is recommended to use liquid
detergent or woollen shampoo for dark coloured
laundry. Do not wash your delicate clothes
that contain wool etc. in this programme.
C
INFORMATION
• You can dry your laundry without any
interruption right after the washing programme
(it is possible to perform automatic or
scheduled drying after the washing cycle). For
this, you must also select the Drying function
before starting the washing programme.
• According to the drying selections you
will add to the washing programmes,
you can see when the programme will
end on the display of the machine.
• If you don't want drying to take place
after the programme you have selected,
press and hold the Drying auxiliary function
button until the Drying light turns off.
• Lingerie
You can use this programme to wash delicate
garments that are suitable for hand wash
and delicate women’s underwear. Small
amount of garments must be washed in a
washing net. Hooks, buttons etc. must be
done up and zips must be zipped up.
• Rinsing
Use when you want to rinse or starch separately.
• Spin+Pump
Use this programme to drain
the water in the machine.
5.6 Temperature selection
-
-
-
-
-
-
Whenever a new programme is selected,
the temperature recommended for that
programme appears on the temperature
indicator. It is possible that the recommended
temperature is not the highest value that can
be selected for the relevant programme.
Press the
Temperature Adjustment
key to change the temperature.
C
INFORMATION
• Temperature Adjustment button works only
backwards. For example, if the display
shows 40°C but you want to select 60°C,
you will need to press the button for a few
times until you reach 60°C from 40°C.
C
INFORMATION
• If you scroll to Cold Wash option and press
the Temperature Adjustment button again,
the recommended maximum temperature for
the selected programme will appear on the
display. To decrease the temperature, press
the Temperature Adjustment button again.
Finally, the Cold light will turn
on, indicating cold wash.
You can also change the temperature after
the washing cycle has started. You can select
the desired temperature after the washing
programme has started. However, you need
to do this before the heating step starts.
5.7 Spin speed selection
-
-
-
-
-
-
25 / EN
Washer-Dryer / User Manual
Whenever a new programme is
selected, the spin speed recommended
for the selected programme appears
on the
Spin Speed
indicator.
C
INFORMATION
• It is possible that the recommended spin
speed is not the highest value that can
be selected for the relevant programme.
Press the
Spin Speed Adjustment
button to change the spin speed.
Spin speed decreases gradually.
Then, depending on the model of the
product, "Rinse Hold" and "No Spin"
options appear on the display.
C
INFORMATION
• Spin Speed Adjustment button works
only backwards. For example, if the
display shows 800 rpm but you want
to select 1000 rpm, you will need to
press the button for a few times until
you reach 1000 rpm from 800 rpm.
5.7.1 If you want to spin your laundry
after the Rinse Hold function:
- Adjust the
Spin Speed
.
- Press the
Start/Pause
button.
Programme will resume. The machine will
drain the water and spin the clothes.
If you want to drain the water at the end
of the programme without spinning,
you can use the
No Spin
function.
C
INFORMATION
• If you press the Spin Speed adjustment
button in programmes where the spin
speed is not allowed, the spin speed setting
will not change and you will hear a warning.
You can also change the spin speed after
the washing cycle has started. After the
washing cycle has ended, you can press
the spin speed adjustment button to select
a spin speed. However, you need to do
this before the spinning step begins.
5.7.2 Auxiliary function
selection for drying
-
-
-
-
When you select a new washing
programme, press the Auxiliary Function
Selection button to set the drying
option suitable for this programme.
C
INFORMATION
• If you press the Drying auxiliary function
button in programmes where the drying
step is not allowed, the drying light will
not change and you will hear a warning.
C
INFORMATION
• Only for dying programmes, press the
Auxiliary Function Selection button
to set the suitable drying option.
5.8 Drying programmes
A
CAUTION!
• During the drying programme, the
machine automatically removes the lints
coming from the clothes. The machine
uses water in the drying step. For this
reason, water tap of the machine should
be open also in the drying programmes.
• When you select a new washing
programme, press the Auxiliary Function
Selection button to set the drying
option suitable for this programme.
26 / EN
Washer-Dryer / User Manual
C
INFORMATION
• There is a spinning step in the drying
programmes. Your machine performs
this process in order to shorten the
drying time. While the drying programme
is selected, the spin speed setting is
within the Maximum spin speed range.
• If you press the Drying auxiliary function
button in programmes where the drying
step is not allowed, the drying light will
not change and you will hear a warning.
• Only for dying programmes, press the
Auxiliary Function Selection button
to set the suitable drying option.
• In case of water outage, washing
or drying cannot be performed.
• Synthetic Dry
Use this programme to dry synthetic
clothes with dry weight up to 3 kg. You can
perform only drying in this programme.
C
INFORMATION
• For dry wright of laundry, see
Section 4, Step 4.5.
• Cotton Dry
Use this programme to dry cotton clothes
with dry weight up to 5 kg. You can
perform only drying in this programme.
C
INFORMATION
• If you are going to dry laundry that
comprises only towels and bathrobes,
the maximum amount of laundry
that can be loaded is 4 kg.
• For dry wright of laundry, see
Section 4, Step 4.5.
5.9 Washing and drying
programmes
A
CAUTION!
• During the drying programme, the
machine automatically removes the lints
coming from the clothes. The machine
uses water in the drying step. For this
reason, water tap of the machine should
be open also in the drying programmes.
•
5 Kg Wash & Dry
Use this programme to wash cotton laundry of
up to 5 kg and to dry right after the washing
programme without making any other selection.
C
INFORMATION
• When this programme is selected, the external
Drying auxiliary function cannot be selected.
In the 5 kg Washing and 5 kg Drying programme, it
is recommended to load the machine up to the level
shown above for ideal drying conditions (you can
see the level arrow if you open the loading door).
• Mini Wash&Dry
Use this programme to wash 0.5 kg of
laundry (2 shirts) in 40 minutes or 1 kg
of laundry (5 shirts) in 60 minutes.
C
INFORMATION
• The Wash&Wear programme is designed to
quickly wash and dry daily clothes that have
been worn for a short time and are not heavily
soiled. This programme is suitable for thin-
textured clothes that dry quickly (shirts, t-shirts).
• Other drying options or programmes
should be used for thick texture
laundry that takes long to dry.
• HygieneCare+ Wash&Dry
Applying a steam step at the beginning of the
programme allows to soften the dirt easily.
Use this programme to wash and quickly
dry laundry (up to 2 kg) that requires anti-
allergic and hygienic washing (cottons such
as baby clothes, sheets and underwear).
C
INFORMATION
• The Hygiene programme has been tested and
approved by the “British Allergy Foundation”
(Allergy UK) based in the United Kingdom.
27 / EN
Washer-Dryer / User Manual
5.10 Programme and consumption table (for washing)
•
HygieneRefresh
Hygienic washing with warm air
(program period 58 min.)
With the hygiene air refresh program, hygienic
cleaning with air is ensured by keeping
the temperature of the laundry at relatively
high temperatures for a certain period of
time with a sensitive heating method.
Use this program to quickly clean your
dry clothes made of cotton or synthetic
materials hygienically with warm air.
C
INFORMATION
• Hygiene air refresh program is not a
program where laundry is washed with
water. Use this program for your laundry
that you want to clean by refreshing with air.
• In the hygiene air refresh program, do
not add chemicals such as detergent,
bleach, stain remover, etc. to the detergent
drawer, or do not apply pre-treatment to
the laundry before starting the program.
Refreshing with warm air (48 min. and 38 min.)
When you select the “Hygiene Air Refresh”
program, the default period shall be 58
minutes. With the “Fast+” auxiliary function,
you may select different program periods
such as 48 minutes or 38 minutes.
EN
1
Auxiliary functions
Programme (°C)
Max. Load (kg)
Water Consumption (l)
Energy Consumption
(kWh)
Max. Speed
Steam
Express
Prewash
Anti Crease+
Drying
Selectable temperature
range °C
Cottons
90
8 90 2,50 1400 • • • • •
Cold - 90
60
8 90 1,80 1400 • • • • •
Cold - 90
40
8 88 0,97 1400 • • • • •
Cold - 90
Eco 40-60
40 ***
8 54 0,955 1400 •
40 - 60
40 ***
4 35 0,550 1400 •
40 - 60
40 *** 2 28 0,320 1400 •
40 - 60
Eco 40-60 + Cupboard Dry
40 *** 5 61 3,215 1400 •
40 - 60
40 *** 2,5 42 1,780 1400 •
40 - 60
Synthetics
60
3 60 1,35 1200 • • • • •
Cold - 60
40
3 58 0,85 1200 • • • • •
Cold - 60
Mini / Mini 14’
90
8 68 2,20 1400 • • • •
Cold - 90
60
8 68 1,20 1400 • • • •
Cold - 90
30
8 68 0,20 1400 • • • •
Cold - 90
Mini / Mini 14’ + Express 30
2 40 0,15 1400 • • • •
Cold - 90
WoolProtect 40
1,5 55 0,50 1200
Cold - 40
Shirts 60
3 63 1,23 800 • • • • •
Cold - 60
Machine Care 90
- 76 2,6 600 * *
90
Downloaded Programme *****
Mix 40
3,5 70 0,9 800 • • • • •
Cold - 40
Outdoor / Sports 40
3,5 52 0,65 1200 • •
Cold - 40
Dark Care / Jeans 40
3,5 70 0,85 1200 • • • • •
Cold - 40
Down Wear 60
2 75 1,3 800 •
Cold - 60
Lingerie 30
1 65 0,56 600
Cold - 30
28 / EN
Washer-Dryer / User Manual
• : Selectable.
* : Automatically selected, cannot be cancelled.
***: Eco 40-60 with 40 °C temperature selection is the washing performance test program in accordance with
EN 62512 and energy label test program in accordance with Commission Delegated Regulation (EU) 2019/2014
Eco 40-60 with 40 °C temperature and cup board dry selection is the wash and dry cycle test program in accordance
with EN 62512 and energy label test program in accordance with Commission Delegated Regulation (EU) 2019/2014
*****: These programmes can be used with the HomeWhiz application.
Energy consumption may increase with connection.
- : See the programme description for maximum load.
C
INFORMATION
• The auxiliary functions in the table may vary according to the model of your machine.
• Water and power consumption may vary subject to the changes in water pressure, water
hardness and water temperature, ambient temperature, type and amount of laundry, selection of
auxiliary functions and spin speed, and changes in the mains voltage.
• When selecting a programme, you can see the washing duration on the display of your machine.
Depending on the amount of laundry you have loaded into the machine, there might be a
difference of 1 to 1.5 hours between the duration shown on the display and the actual duration
of the washing programme. The duration will be corrected automatically right after the washing
programme has started.
• "Auxiliary function selection modes can be changed by the manufacturing company.
New selection models may be added, or the existing ones may be removed.”
• "Spin speed of your machine may vary depending on the programme; the
spin speed cannot exceed the maximum spin speed of your machine."
• Always select the lowest appropriate temperature. The most efficient programmes in terms of
energy consumption are generally those that perform at lower temperatures and longer duration.
• Noise and remaining moisture content are influenced by the spinning speed: the higher the spinning
speed in the spinning phase, the higher the noise and the lower the remaining moisture content.
EN 1 Auxiliary functions Drying level
Programme (°C)
Max. Load (kg)
Water Consumption (l)
Energy Consumption (kWh)
Max. Speed
Steam
Prewash
Express
Anti Crease+
Drying
Extra Dry
Cupboard Dry
Iron Dry
Time based drying - minutes
Selectable
temperature
range °C
Cotton Dry -
5 45 3,20
1400
• * • • • •
-
Synthetic Dry -
3 30 2,10 - • * • • •
-
HygieneCare+ Wash&Dry 60
2 120 3,80
1400
* • * • • • •
90-30
5 Kg Wash&Dry 60
5 94 5,00
1400
• * • • • •
60-Cold
Mini Wash&Dry 30
0,5 35 0,60 1200 • * •
30-Cold
Mini Wash&Dry 30
1 44 1,00 1200 • * •
30-Cold
HygieneRefresh - 2 1 0,50 - • • *
-
Programme and consumption table (for drying)
29 / EN
Washer-Dryer / User Manual
5.11 Auxiliary function selection
Select the desired auxiliary functions before starting
the programme. When a programme is selected,
lights of the auxiliary functions that can be selected
together with that programme will turn on.
-
-
-
-
C
INFORMATION
• Lights of the auxiliary functions that cannot
be selected together with the selected
programme will not turn on. If you press the
buttons of these auxiliary functions, you will
hear a warning and selection will be disabled.
If the washing programme has reached a
point where an auxiliary function cannot be
selected, you cannot select any function.
C
INFORMATION
• Some functions cannot be selected together.
If a second auxiliary function conflicting
with the first one is selected before starting
the machine, the function selected first
will be cancelled and the second auxiliary
function selection will remain active.
• An auxiliary function which is not compatible
with the programme cannot be selected.
(See "Programme and consumption table")
• Some programmes have auxiliary
functions that must run together with the
selected programme. These functions
cannot be cancelled. The light of the
relevant auxiliary function is already on.
C
INFORMATION
• If the selected wetness level (Iron Dry,
Cupboard Dry, Cupboard Extra Dry)
cannot be reached at the end of the
drying programme, your machine will
automatically extent the programme
duration. The programme will take longer.
• If Timed Drying is selected, the programme
will end at the end of the drying time
even if the laundry is not dry.
• If, during the drying programme, the selected
wetness level (Iron Dry, Cupboard Dry,
Cupboard Extra Dry) is reached or extra
dryness is detected in the timed drying
options, the programme will take shorter. The
time decrease will be shown on the display.
Consumption Values (EN)
Temperature
Selection (°C)
Spin Speed (rpm)
Capacity (kg)
Programme
Duration (hh:mm)
Energy
Consumption
(kWh/cycle)
Water
Consumption
(L/cycle)
Laundry
Temperature (°C)
Remaining
Moisture Content
(%)
Eco 40-60
40 1400 8 03:38
0,955 54,0
40 53
40 1400 4 02:47
0,550 35,0
32 53
40 1400 2 02:47
0,320 28,0
23 53
Cottons
20 1400 8 03:40 0,600 93,0 20 53
Cottons
60 1400 8 03:40 1,800 90,0 60 53
Synthetics
40 1200 3 02:25 0,850 58,0 40 40
Mini / Mini 14’
30 1400 8 00:28 0,200 68,0 23 62
Eco 40-60+Cupboard Dry
40 1400 5 07:55 3,215 61,0 25 53
40 1400 2,5 05:50 1,780 42,0 24 53
The values given for programmes other than the eco 40-60 programme and the wash and dry cycle are indicative only.
30 / EN
Washer-Dryer / User Manual
5.11.1 Auxiliary Functions
• Prewash
A Prewash is required only for heavily
soiled laundry. Not using the Prewash will
save energy, water, detergent and time.
• Express
You can press the Quick Wash button to
shorten the programme time after selecting
the programme. For some programmes, the
time can be shortened by over 50%. Still, for
medium and lightly soiled laundry, you will get
the same washing results in a shorter time.
Although it depends on the programme,
pressing the Quick Wash button once will
shorten the programme time down to a certain
level. Press the same button for the second
time to drop the time to the minimum level.
For better washing results, do not use the
Quick Wash button for heavily soiled laundry.
For medium and lightly soiled laundry, use the
Quick Wash button to shorten the programme time.
• Remote Control
You can use this auxiliary function button
to connect your product to smart devices.
For detailed information, see HomeWhiz
and the Remote Control Function.
• Custom Programme
This auxiliary function can be used for Cottons
and Synthetics programmes only with the
HomeWhiz application. When this auxiliary function
is enabled, you can add up to 4 additional rinse
steps to the programme. You can select and
use some auxiliary functions even though they
are not found on your product. You can increase
and decrease the time of the Cottons and
Synthetics programmes within a safe range.
• Drying
This function dries your laundry after the washing
cycle. Please see the programme table for
programmes that can be used with this function.
5.11.2 Functions/Programmes
Selected by Pressing the
Function Buttons for 3 Seconds
• Machine Care
To select this programme, press and hold the
auxiliary function button 1 for 3 seconds. Use
regularly (once in every 1-2 months) to clean the
drum and provide the required hygiene. Before
the programme, it applies steam to soften
residues in the drum. Operate the programme
while the machine is completely empty. To obtain
better results, put powder lime-scale remover
for washing machines into the detergent
compartment no. “2”. This programme contains
a drying step that runs after the drum cleaning
step to dry the inside of the machine.
C
INFORMATION
• This is not a washing programme.
It is a maintenance programme.
• Do not run this programme when
there are any objects in the machine.
If you try to do so, the machine will
automatically detect that there is load
inside and abort the programme.
• Anti Crease+
If you press and hold the spin selection button
for 3 seconds, this function will be selected and
the programme follow-up light of the relevant
programme will turn on. When this function is
selected, it aerates the laundry for up to 8 hours
at the end of the programme to prevent creasing.
You can cancel the programme and take your
laundry out at any time during the 8-hour
duration. Press the function selection key or the
machine on/off key to cancel the function. The
programme follow-up light will remain on until
the function is cancelled or the step is complete.
If the function cannot be cancelled, it will be
active in the subsequent washing cycles as well.
• Steam
You can press and hold the auxiliary function
key 2 for 3 seconds to select this function.
Use this programme to reduce the
wrinkles and shorten the ironing times
for a small amount of cotton, synthetic
or mixed clothes that are not stained.
31 / EN
Washer-Dryer / User Manual
• Child Lock
You can use the Child Lock to prevent children
from tampering with the machine. Thus you can
avoid any changes in a running programme.
C
INFORMATION
• When the Child Lock is enabled, you
can press the On/Off key to switch the
machine on or off. Programme resumes
when you start the machine again.
• You will hear a warning if the buttons are
pressed while Child Lock is enabled. This
audible warning will be cancelled if the
buttons are pressed five times consecutively.
To enable Child Lock:
Press and hold the Drying Level
Adjustment button
for 3 seconds. When
the countdown
“3-2-1”
on the display
ends, child lock icon will be displayed. Once
you see this warning, you can release the
Drying Level Adjustment button
.
To disable Child Lock:
Press and hold the Drying Level
Adjustment button
for 3 seconds. When
the countdown
“3-2-1”
on the display
ends, child lock icon will disappear.
• Bluetooth
You can use the Bluetooth connection function
to pair your machine with your smart device.
This way, you can use your smart device to get
information about your machine and control it.
To enable Bluetooth:
Press and hold the Remote Control
function button
for 3 seconds. You will
see the countdown
“3-2-1”
, and bluetooth
symbol will be displayed. Release the
Remote
Control function button
. The Bluetooth
icon will flash while the product is being paired
with the smart device. If the connection is
successful, the light of the icon will remain on.
To disable Bluetooth:
Press and hold the Remote Control
function button
for 3 seconds. You
will see the countdown
“3-2-1”
, and
bluetooth symbol will be disappear.
C
INFORMATION
• You must complete the first setup of
the HomeWhiz app for Bluetooth to be
enabled. After the setup, if you press the
Remote Control function button while the
button is in the Programme Download/
Remote Control position, the Bluetooth
connection will be enabled automatically.
5.12 Drying steps
-
-
-
-
5.12.1 Iron Dry
Drying continues until the drying
level reaches the Iron Dry step.
5.12.2 Cupboard Dry
Drying continues until the drying level
reaches the Cupboard Dry step.
5.12.3 Extra Dry
Drying continues until the drying level
reaches the Cupboard Extra Dry step.
C
INFORMATION
• The dryness level might change depending
on the mix of laundry, type of material,
amount and wetness level of the laundry.
• Do not use the machine to dry laundry that
contains lace, tulle, bling, beads, paillette,
wire etc. or laundry with high silk content.
32 / EN
Washer-Dryer / User Manual
5.12.4 Time based
drying - minutes
You can select 30, 90 or 150 minutes
drying to reach the desired dryness
level at a low temperature.
C
INFORMATION
• When drying small amount of laundry
(2 pieces maximum), select the
timed drying steps in the Cottons or
Synthetics drying programmes.
• If the laundry has not reached the
desired dryness level at the end of the
drying programme, you can select
timed drying to end the process.
• When this function is selected, the
machine performs drying for the adjusted
time irrespective of the drying level.
5.13 Time display
While the programme is running, the time
remaining to the end of the programme will be
displayed in hours and minutes, e.g. “01:30”.
C
INFORMATION
• Programme time may differ from the values
in section "Programme and consumption
table" depending on the water pressure,
water hardness and temperature, ambient
temperature, amount and the type of
laundry, auxiliary functions selected and
the changes in the mains voltage.
5.14 End Time
-
With the
End Time
function, start of
the programme can be delayed up to
24 hours. After pressing the
End Time
button, the programme's estimated end
time will be displayed. If an
End Time
is
set, the
End Time
light will turn on.
To ensure that the End Time function is enabled
and the programme ends at the end of the
defined duration, you should press
Start /
Pause
after setting the duration. The
Start/
Pause
button will stop flashing and remain on.
If you want to cancel End Time function,
press the
End Time
button until the End
Time light turns off or press the
On/Off
button to turn off and on the machine.
1. Open the loading door, place the
laundry and add detergent, etc.
2. Select the washing programme,
temperature, spin speed and, if
required, the auxiliary functions.
3. Press the
End Time
button to set the desired
end time. The
End Time
light will turn on.
4. Press the
Start / Pause
button. Countdown
will start. ":" sign in the middle of the end
time on the display will start flashing.
C
INFORMATION
• Do not use liquid detergents when
you enable the End Time function!
Stains might remain on the clothes.
• The door will remain locked during the End
Time countdown. If you want to unlock
the door, press the programme start/
pause button to switch the machine to
pause mode. At the end of the countdown,
End Time indicator turns off, washing
cycle starts and the time of the selected
programme appears on the display.
• When End Time is selected, the time
displayed on the screen consists
of the end time plus the duration
of the selected programme.
5.15 Starting the programme
1. Press the
Start/Pause
button
to start the programme.
2. The flashing light of the
Start/Pause
button will remain on, indicating that
the programme has started.
3. Loading door will be locked. When
the door is being locked, “Locking
Door” warning will be displayed.
33 / EN
Washer-Dryer / User Manual
5.16 Loading door lock
There is a locking system on the loading
door of the machine that prevents opening
of the loading door when the water
level is unsuitable to open the door.
"Loading door locked" light on the panel
turns on when the loading door is locked.
C
INFORMATION
• The door will be locked if the Remote
Control function is selected. To open the
door, you need to press the Remote Control
key or change the programme position to
deactivate the Remote Control function.
Opening the loading door in
case of power failure:
C
INFORMATION
• In case of a power failure, you can
use the loading door emergency
handle under the pump filter lid to
manually open the loading door.
A
WARNING!
• Before opening the loading door,
make sure that there is no water in the
machine to avoid flooding. Water may
be hot and could cause scalding.
•
Turn off and unplug the appliance.
• Open the loading door by pulling the loading
door emergency handle downwards.
• Try to pull the handle downwards again
if the loading door is not opened.
5.17 Changing the selections
after programme has started
5.17.1 Adding laundry after the
programme has started
:
When you press the
Start/Pause
button, the
“Loading door locked” light on the panel will go
off if the water level in the machine is suitable.
If the water level in the machine is not suitable
when you press the
Start/Pause
button, the
panel will warn you that the door is closed.
5.17.2 Switching the
machine to pause mode
Press the
Start/Pause
button to
switch the machine to pause mode.
34 / EN
Washer-Dryer / User Manual
5.17.3 Changing the
programme selection after
the programme has started:
If Child Lock is not enabled, you can change
programme while the current one is running.
This will cancel the current programme.
C
INFORMATION
• The newly selected programme will start anew.
5.17.4 Changing the auxiliary
function, spin speed and
temperature settings
Depending on the step the programme has
reached, you can cancel or select auxiliary
functions. See “Auxiliary function selection”.
Also, you can change the spin speed,
temperature and drying settings. See "Spin
speed selection" and "Temperature selection".
C
INFORMATION
• If the temperature of the water inside the
machine is high or if the water level is above
the door line, the loading door will not open.
5.18 Cancelling the programme
The programme will be cancelled if the
programme selection knob is switched to
another programme or if the machine is
switched off and on with this button.
C
INFORMATION
• The programme will not be cancelled
if you turn the programme selection
knob while child lock is enabled. You
should cancel the Child Lock first.
• If you want to open the loading door after
you have cancelled the programme but
you cannot do it since the water level in
the machine is above the loading door
baseline, turn the Programme Selection
knob to Pump+Spin programme and
discharge the water in the machine.
5.19 End of programme
Once the programme is completed,
the End symbol will be displayed.
If you do not press any button for 10 minutes,
the machine will switch to OFF mode.
Display and all indicators are turned off.
If you press any button, the completed
programme steps will be displayed.
5.20 Your machine has the
"Pause Mode" function.
After using the On/Off button to switch on the
machine, if you do not start any programme in
the selection step or do not perform anything
else, or if you do not do anything in 2 minutes
after the selected programme has ended, the
programme will automatically switch to energy
saving mode. Also, if your product has a display
that shows programme time, this display will be
completely turned off. If you turn the programme
knob or touch any button, the lights will switch
back to previous position. The selections you
make when exiting the energy efficiency mode
may change. Check if your selections are correct
before starting the programme. If necessary,
make adjustments again. This is not an error.
35 / EN
Washer-Dryer / User Manual
5.21 HomeWhiz and the
Remote Control Function
HomeWhiz allows you to use your smart device
to control your washing machine and get
information about it. Thanks to the HomeWhiz
application, you can use your smart device
to carry out some procedures you can also
do on the machine. Plus, you can use some
features only with the HomeWhiz function.
To use the Bluetooth function of your machine,
you should download the HomeWhiz app
from the application store of your device.
Make sure that your smart device is
connected to internet to download the app.
If you are using the app for the first time, please
follow the on-screen instructions to complete the
user registration process. Once the registration
is complete, you can use all products with the
HomeWhiz feature in your house on this account.
On the HomeWhiz app, you can tap
“Add/Remove Appliance” to see the
products paired with your account. You
can pair these products on this page.
C
INFORMATION
• To be able to use the HomeWhiz function,
make sure that the app is installed on your
smart device and that your washing machine
is paired with your smart device via Bluetooth.
If the washing machine is not paired with
your smart device, it will function as an
appliance without the HomeWhiz feature.
• Your product will run once it is paired with
your smart device via Bluetooth. Controls
made from the app will be enabled through
this pairing. For this reason, the Bluetooth
signal between the product and the
smart device must be strong enough.
• Please visit www.homewhiz.com to see
the Android and iOS versions supported
by the HomeWhiz application.
A
WARNING!
• All the safety measures described in
"GENERAL SAFETY INSTRUCTIONS"
section of your user manual apply
to remote control through the
HomeWhiz function as well.
5.21.1 HomeWhiz Setup
Your product and the HomeWhiz app
must be connected for the app to run. To
establish this connection, please follow
the steps below for setup both on your
product and on the HomeWhiz App.
• If you are adding an appliance for the first
time, tap “Add/Remove Appliance” on the
HomeWhiz App. Then tap “Tap here to
setup new appliance”. Follow the steps
below as well as the instructions on the
HomeWhiz App to complete the setup.
• To start the setup process, make sure that your
machine is switched off. Press and hold the
Temperature button and the Remote Control
Function button simultaneously for 3 seconds to
switch your machine to HomeWhiz setup mode.
• While the device is in HomeWhiz setup mode,
you will see an animation on the display,
and the Bluetooth icon will flash until the
machine is paired with your smart device.
In this mode, only the programme button
is enabled. Other buttons are disabled.
• On the screen of the app, select the
desired washing machine and tap Next.
• Follow on-screen instructions until the
HomeWhiz app asks you about the product
you wish to connect to your smart device.
• Return to the HomeWhiz app and wait until
the setup is complete. Once the setup is
complete, give your washing machine a name.
You can now tap the screen to see the product
you have added to the HomeWhiz App.
36 / EN
Washer-Dryer / User Manual
C
INFORMATION
• If you cannot complete the setup
successfully in 5 minutes, the washing
machine will switch off automatically. In this
case, you will have to start over the setup
procedure. If the problem persists, please
contact the Authorised Service Agent.
• You can use your washing machine with
more than one smart device. To do this,
download the HomeWhiz app on the other
smart device as well. After launching the
app, you will need to sign in to your account
you have previously created and paired with
your washing machine. Otherwise, please
read “Setting up a washing machine that
is connected to someone else’s account”.
A
WARNING!
• For HomeWhiz setup, your smart device must
be connected to internet. Otherwise, the
HomeWhiz App will not let you complete the
setup process successfully. If you are having
problems with your internet connection,
please contact your internet service provider.
C
INFORMATION
• The HomeWhiz application may ask you
to enter the product number stated on
the label of the product. Product label is
found on the inner side of the product door.
Product number is written on this label.
5.21.2 Setting up a washing
machine that is connected to
someone else’s account
If the washing machine you want to use has
previously been registered in the system
with someone else’s account, you need
to establish a new connection between
the HomeWhiz App and the product.
• Download the HomeWhiz App on the
new smart device you want to use.
• Create a new account and log in to this
account on the HomeWhiz app.
• Follow the steps in the HomeWhiz
Setup (5.21.1 HomeWhiz Setup)
to complete the setup.
A
WARNING!
• Since the HomeWhiz and Remote Control
functions of your product work through
pairing via Bluetooth, the product can be
run by only one HomeWhiz app at a time.
5.21.3 Using the Remote
Control function
After HomeWhiz setup, Bluetooth will turn on
automatically. To enable or disable the Bluetooth
connection, please see 5.11.2 Bluetooth 3”.
If you switch your machine off and on
while Bluetooth is enabled, it will reconnect
automatically. If the paired device goes out
of the range, the Bluetooth connection will
turn off automatically. For this reason, you
will need to turn on Bluetooth again if you
want to use the Remote Control function.
You can check the Bluetooth symbol on
the display to follow the connection status.
If the symbol is on, this means that the
Bluetooth connection is established. If
the symbol is established, the product is
trying to connect. If the symbol is off, this
means that you have no connection.
37 / EN
Washer-Dryer / User Manual
A
WARNING!
• If the Bluetooth connection is enabled on your
product, you can select the Remote Control
function. If the Remote Control function
cannot be selected, check the connection
status. If the connection fails, repeat the
initial set-up settings on the appliance.
• For safety reasons, the product’s door
will remain locked while the Remote
Control function is enabled, independently
of the operating mode. If you want to
open the door of the product, you will
need to turn the programme selection
knob or press the Remote Control key to
disable the Remote Control function.
If you want to control your washing machine
remotely, enable the Remote Control function
by pressing the Remote Control button while
the programme knob is in the Programme
Download/Remote Control position on the
control panel. Once the product is accessed,
you will see a screen similar to the one below.
When Remote Control is enabled, you can
only manage and switch off the machine
and follow status on the washing machine.
All functions except child lock can be
managed through the application.
You can check the function indicator on
the key to follow whether the Remote
Control function is On or Off.
If the Remote Control function is Off,
all the operations are handled on the
washing machine and only status follow-
up is allowed on the application.
If the Remote Control function cannot be
enabled, you will hear a warning after pressing
the button. This might occur if the product
is switched on or if there is no product
paired through Bluetooth. Bluetooth setting
being Off or the washing machine's door
being open are examples for such cases.
When you enable this function on the washing
machine, said function will remain on except
for certain cases, allowing you to control your
washing machine remotely via Bluetooth.
In certain cases, it deactivates
itself for safety reasons:
• When your washing machine
undergoes a power interruption.
• When the programme knob is turned
to select a different programme or
when the product is switched off.
5.21.4 Troubleshooting
Follow the steps below if you are having
problem with controlling or connection.
Observe whether the problem persists or not
after the action you have performed. Do the
following if the problem is not resolved.
• Check whether your smart device is
connected to the relevant home network.
• Restart the product application.
• Turn Bluetooth off and on through
the user control panel.
• If the connection cannot be established
with the above processes, repeat the initial
set-up settings on the washing machine.
If the problem persists, consult an
Authorised Service Agent.
38 / EN
Washer-Dryer / User Manual
6 Maintenance and cleaning
Service life of product extends and frequently
experienced problems will be reduced
if it is cleaned at regular intervals.
6.1 Cleaning the detergent drawer
Remove any powder residue buildup
in the drawer. To do this;
II
II
I
1. You can remove the detergent drawer
by pulling it towards yourself strongly.
C
INFORMATION
• If more than a normal amount of softener
and liquid detergent mixture starts to
remain in the softener compartment,
the siphon must be cleaned.
2. Wash the drawer and the siphon with
plenty of lukewarm water in a washbasin.
Wear protective gloves or use an
appropriate brush to avoid touching the
residues in the drawer when cleaning.
3. Replace the drawer into its housing
after cleaning. Check if the siphon
is in its original location.
6.2 Cleaning the loading
door and the drum
For products with drum cleaning
programme, please see Operating
the product - Programmes.
C
INFORMATION
• Repeat Drum Cleaning process
in every 2 months.
• Use an anti-limescale suitable
for the washing machines.
After every washing and drying make sure
that no foreign substance is left in the drum.
If the holes on the bellow shown in the figure
are blocked, open the holes using a toothpick.
C
INFORMATION
• Foreign metal substances will cause
rust stains in the drum. Clean the
stains on the drum surface by using
cleaning agents for stainless steel.
Never use steel wool or wire wool.
A
CAUTION!
• Never use sponge or scrub materials.
These will damage the painted,
chrome and plastic surfaces.
6.3 Cleaning the body
and control panel
Wipe the body of the machine with soapy
water or non-corrosive mild gel detergents
as necessary, and dry with a soft cloth.
Use only a soft and damp cloth
to clean the control panel.
39 / EN
Washer-Dryer / User Manual
6.4 Cleaning the water
intake filters
There is a filter at the end of each water
intake valve at the rear of the machine and
also at the end of each water intake hose
where they are connected to the tap. These
filters prevent foreign substances and dirt
in the water to enter the washing machine.
Filters should be cleaned if they are dirty.
1. Close the taps.
2. Remove the nuts of the water intake
hoses to access the filters on the water
intake valves. Clean residues on them
with an appropriate brush. If the filters are
too dirty, remove them from their places
with a pliers and clean in this way.
3. Take out the filters on the flat ends of the
water intake hoses together with the gaskets
and clean thoroughly under running water.
4. Replace the gaskets and filters
carefully in their places and tighten
the hose nuts by hand.
6.5 Draining remaining water
and cleaning the pump filter
The filter system in your machine prevents
solid items such as buttons, coins and fabric
fibers clogging the pump impeller during
discharge of washing water. Thus, the water
will be discharged without any problem and
the service life of the pump will extend.
If the machine fails to drain water, the pump filter
is clogged. Filter must be cleaned whenever it
is clogged or in every 3 months. Water must
be drained off first to clean the pump filter.
In addition, prior to transporting the machine
(e.g., when moving to another house)
and in case of freezing of the water, water
may have to be drained completely.
A
CAUTION!
• Foreign substances left in the pump
filter may damage your product
or may cause noise problem.
• If the product is not being used, shut the
tap, remove mains hose and drain the
water inside the machine in places where
there is the risk of the product freezing .
• After each use, turn off the water tap to
which the mains hose is connected.
In order to clean the dirty filter
and discharge the water:
1. Unplug the machine to cut
off the supply power.
A
CAUTION!
• Temperature of the water inside the
machine may rise up to 90 ºC. To avoid
burning risk, filter must be cleaned after
the water in the machine cools down.
2. Some of our products have emergency
draining hose and some does not have.
Follow the steps below to discharge the water.
40 / EN
Washer-Dryer / User Manual
Discharging the water when the product does
not have an emergency draining hose:
a. Place a large container in front of the
filter to catch water from the filter.
b. Loosen pump filter (anticlockwise) until
water starts to flow. Fill the flowing water
into the container you have placed in
front of the filter. Always keep a piece of
cloth handy to absorb any spilled water.
c. When the water inside the
machine is finished, take out the
filter completely by turning it.
3. Clean any residues inside the filter
as well as fibers, if any, around
the pump impeller region.
4. Install the filter, turn clockwise to
ensure it is closed and watertight.
7 Troubleshooting
Programmes won’t start after the loading door has
been closed.
• You did not press the Start/Pause/Cancel button.>>>
*Press the
Start/Pause/Cancel button.
• If the load is too much, it might be hard for the loading door to be
closed.>>>
*Load less laundry and make sure that the loading
door is closed properly.
Programme cannot be started or selected.
• The machine may have switched itself to self-protection mode
due to a supply problem (mains voltage, water pressure etc.).
>>>
Press and hold the On/Off button for 3 seconds to reset the
machine to factory settings (See "Cancelling the programme").
To cancel the programme, turn the Programme Selection knob
to select another programme. Previous programme will be
cancelled. (see. “Cancellation of programme”)
Water inside the machine.
• There might be some water remaining in the product due to the
quality control processes carried out during production. >>>
This is not a failure, water does not harm the machine.
Water is leaking from the bottom of the machine.
• There might be a problem with the hoses or the pump filter.
>>>
Make sure that the seals of the water inlet hoses are
securely fitted. Attach the hose to the tap tightly.
• Pump filter might not be closed securely. >>>
Make sure that
the pump filter is closed securely.
Machine does not take in water.
• Tap might be turned off. >>>
Turn on the taps.
• Water inlet hose might be bent. >>>
Flatten the hose.
• Water inlet filter might be clogged. >>>
Clean the filter.
• Loading door might not be closed. >>>
Close the loading door.
Machine does not drain water.
• Water drain hose might be clogged or twisted. >>>
Clean or
flatten the hose.
• Pump filter might be clogged. >>>
Clean the pump filter.
Machine vibrates or makes noise.
• Machine might be unbalanced. >>>
Adjust the feet to level the
machine.
• A hard substance might have entered the pump filter. >>>
Clean the pump filter.
• Transportation safety bolts might not be removed. >>>
Remove the transportation safety bolts.
• The amount of laundry might be too little. >>>
Add more
laundry to the machine.
• The machine might be overloaded with laundry. >>>
Take out
some of the laundry from the machine or distribute the load by
hand to balance it evenly in the machine.
• The machine might be in contact with a hard surface. >>>
Make sure that the machine is not in contact with anything.
Machine stopped shortly after the programme started.
• The machine might have stopped temporarily due to low
voltage. >>>
It will resume running once the voltage returns to
a normal level.
41 / EN
Washer-Dryer / User Manual
Machine directly discharges the water it takes in.
• The drain hose might be at an inappropriate height. >>>
Connect the water drain hose as described in the user manual.
No water can be seen in the machine during
washing.
• Water level cannot be seen outside the machine. This is not a
failure.
Loading door cannot be opened.
• Door lock might be enabled because of the water level in the
machine. >>>
Drain the water by running the Pump or Spin
programme.
• Machine might be heating the water or at the spinning
step.>>>
Wait until the programme is complete.
• The loading door might be jammed due to the pressure it is
exposed to. >>>
Hold the grip, push and pull the loading door
to free it from the pressure and open it.
• The loading door will not open if there is no power. >>>
To
open the loading door, open the pump filter cap and pull down
the emergency handle positioned at the rear side of the said
cap. See “Loading door lock”
Washing takes longer than specified in the user
manual.(*)
• Water pressure might be low. >>>
Since the amount of the
water has decreased, the machine will wait until it takes
adequate water to avoid poor washing quality. Therefore, the
washing time extends.
• Voltage might be low. >>>
If the supply voltage is low, the
washing time is extended to prevent poor washing quality.
• Inlet temperature of water might be too low. >>>
The time
required to heat up the water extends in cold seasons. Also,
washing time can be extended to avoid poor washing results.
• The number of rinsing cycles and/or the amount of rinsing
water might have increased. >>>
When a better rinsing
performance is needed, the machine increases the amount of
rinsing water, and adds another rinsing cycle, if necessary.
• Excessive foam might have formed due to use of too much
detergent, and the automatic foam absorption system might
have been activated. >>>
Use the recommended amount of
detergent.
Programme time does not countdown. (On models
with display) (*)
• The timer may stop during water intake. >>>
The timer
indicator will not count down until the machine takes in an
adequate amount of water. When the amount of the water
taken in decreases, the machine will wait until it takes in
enough water to avoid poor washing results. Timer indicator
will resume countdown after this.
• The timer indicator might stop during heating. >>>
The timer
indicator will not count down until the machine reaches the
selected temperature.
• The timer indicator might stop during spinning. >>>
The
automatic unbalanced load detection system might have been
activated due to uneven distribution of the laundry in the drum.
Programme time does not countdown. (*)
• The laundry in the machine might be unbalanced. >>>
The
automatic unbalanced load detection system might have been
activated due to uneven distribution of the laundry in the drum.
Machine does not switch to spinning step. (*)
• The laundry in the machine might be unbalanced. >>>
The
automatic unbalanced load detection system might have been
activated due to uneven distribution of the laundry in the drum.
• The machine cannot spin if the water in it is not drained
completely. >>>
Check the filter and the drain hose.
• Excessive foam might have formed due to use of too much
detergent, and the automatic foam absorption system might
have been activated. >>>
Use the recommended amount of
detergent.
Washing performance is poor: Clothes are going grey.(**)
• Insufficient amount of detergent might have been used over
a long period of time. >>>
Use the recommended amount of
detergent according to water hardness and the laundry.
• Washing might have been performed at low temperatures for a
long time. >>>
Select the proper temperature for the laundry
to be washed.
• Hard water and insufficient amount of detergent. >>>
Using
hard water together with insufficient amount of detergent
might cause dirt accumulation and greying on laundry in
time. It is difficult to eliminate greying once it happens. Use
the recommended amount of detergent appropriate for water
hardness and the laundry.
• Excessive amount of detergent might have been used. >>>
Use the recommended amount of detergent appropriate for
water hardness and the laundry.
Washing performance is poor: Stains persist or the
laundry is not whitened. (**)
• Insufficient amount of detergent might have been used. >>> Use
recommended amount of detergent appropriate for the laundry.
• Machine might have been overloaded. >>>
Do not overload the
machine. Load the machine with the amounts recommended in
the "Programme and consumption table".
• Wrong programme and temperature might have been selected.
>>>
Select the right programme and temperature for the
laundry to be washed.
• Wrong type of detergent might have been used. >>>
Use
original detergent appropriate for the machine.
• Detergent might have been put in the wrong compartment.
>>> Put the detergent in the correct compartment. Do not mix
the bleaching agent and the detergent with each other.
Washing performance is poor: Oily stains appeared
on the laundry. (**)
• The drum might not have been cleaned regularly. >>>
Clean
the drum regularly. To do this, please see. 6.2.
Washing performance is poor: Clothes smell bad. (**)
• Washing at low temperatures and/or with short programmes
for a long time will cause smell and bacteria in the drum. >>>
Leave the detergent drawer and loading door of the machine
ajar after every washing cycle. Thus, a humid environment
favorable for bacteria cannot occur in the machine.
42 / EN
Washer-Dryer / User Manual
Colour of the clothes faded. (**)
• Machine might have been overloaded. >>>
Do not overload
the machine.
• Detergent used might be damp. >>> Keep detergents closed
in an environment free of humidity and do not expose them to
excessive temperatures.
• A high temperature might have been selected. >>> Select
a programme and temperature suitable for the type and soiling
degree of the laundry.
Rinsing performance is poor
• The amount, brand or storage conditions of the detergent might
not be suitable. >>> Use a detergent appropriate for the washing
machine and your laundry. Keep detergents closed in an environment
free of humidity and do not expose them to excessive temperatures.
• The detergent might have been added to the wrong compartment.
>>> If you add detergent to the prewash compartment even if
you have not selected a prewash programme, the machine might
take this detergent during the rinsing or softener step. Put the
detergent in the correct compartment.
• Pump filter might have been clogged. >>>
Check the filter.
• Drain hose might be folded. >>>
Check the drain hose.
Laundry became stiff after washing. (**)
• Insufficient amount of detergent might have been used. >>>
Using insufficient amount of detergent for the water hardness
can cause the laundry to become stiff in time. Use appropriate
amount of detergent according to the water hardness.
• The detergent might have been added to the wrong compartment.
>>> If you add detergent to the prewash compartment even if
you have not selected a prewash programme, the machine might
take this detergent during the rinsing or softener step. Put the
detergent in the correct compartment.
• Detergent might have been mixed with softener. >>> Do not mix the
detergent with softener. Wash and clean the drawer with hot water.
Laundry does not smell like softener. (**)
• The detergent might have been added to the wrong compartment.
>>> If you add detergent to the prewash compartment even if you
have not selected a prewash programme, the machine might take
this detergent during the rinsing or softener step. Wash and clean the
drawer with hot water. Put the detergent in the correct compartment.
• Detergent might have been mixed with softener. >>> Do not mix the
detergent with softener. Wash and clean the drawer with hot water.
Detergent residue in the detergent drawer. (**)
• Detergent might have been added to wet drawer. >>>
Dry the
detergent drawer before adding detergent.
• Detergent might have gotten damp. >>>
Keep detergents
closed in an environment free of humidity and do not expose
them to excessive temperatures.
• Water pressure might be low. >>>
Check the water pressure.
• The detergent in the main wash compartment got wet while
the machine was taking in the prewash water. Holes of the
detergent compartment might have been blocked. >>>
Check
the holes and clean if they are clogged.
• There might be a problem with the detergent drawer valves.
>>>
Call the Authorised Service Agent.
• Detergent might have been mixed with softener. >>> Do not mix the
detergent with softener. Wash and clean the drawer with hot water.
There is detergent left on the laundry.
• Machine might have been overloaded. >>>
Do not overload
the machine.
• Wrong programme and temperature might have been selected.
>>>
Select the right programme and temperature for the
laundry to be washed.
• Wrong detergent might have been used. >>>
Select a proper
detergent for the laundry to be washed.
Too much foam forms in the machine. (**)
• Improper detergents for the washing machine might have been
used. >>>
Use detergents suitable for washing machine.
• Excessive amount of detergent might have been used. >>>
Use only sufficient amount of detergent.
• Detergent might have been stored under inappropriate
conditions. >>>
Keep the detergent in a closed and dry area.
Do not store it in excessively hot places.
• Meshed laundry such as tulles might foam too much due to
their texture. >>>
Use less detergent for these types of fabrics.
• Detergent might have been put in the wrong compartment.
>>> Put the detergent in the correct compartment.
• Softener is taken early. >>> There might be a problem with the
valves or the detergent drawer. Call the Authorised Service Agent.
Foam is overflowing from the detergent drawer.
• Excessive amount of detergent might have been used.
>>>>
Mix 1 tablespoonful softener and ½ l water and pour
into the main wash compartment of the detergent drawer.
• Put detergent into the machine suitable for the programmes
and maximum loads indicated in the “Programme and
consumption table”. If you use additional chemicals (stain
removers, bleaches and etc), reduce the amount of detergent.
Laundry remains wet at the end of the programme. (*)
• Excessive foam might have formed due to use of too much
detergent, and the automatic foam absorption system might have
been activated. >>> Use the recommended amount of detergent.
43 / EN
Washer-Dryer / User Manual
(*) Machine does not switch to spinning step
when the laundry is not evenly distributed in the
drum to prevent any damage to the machine
and to its surrounding environment. Readjust
the laundry and perform spinning again.
(**) The drum might not have been cleaned
regularly.
>>>
Clean the drum regularly. See 6.2
A
CAUTION!
• If you cannot eliminate the problem
although you follow the instructions in
this section, consult your dealer or the
Authorised Service Agent. Never try to
repair a nonfunctional product yourself.
Drying lasts too long.
• Machine might have been overloaded. >>>
Do not
overload the machine.
• Spinning might not be sufficient for laundry. >>> Select
a higher spin speed in the washing step of the Washer-Dryer.
• Tap might be turned off. >>> Turn on the taps.
Laundry comes off wet after the drying step.
• The programme selected might not be suitable for the type
of laundry. >>>
Check the care labels on garments and select a
programme accordingly, or select timed programmes additionally.
• Machine might have been overloaded. >>> Do not
overload the machine.
• Spinning might not be sufficient for laundry. >>> Select
a higher spin speed in the washing step of the Washer-Dryer.
Machine does not start or programme cannot be started.
• Power cable might be unplugged. >>> Make sure that
the power cable is plugged in.
• Programme might not be set, or the Start/Pause/
Cancel button might not be pressed.
>>> Make sure the
programme is set and the machine is not in Stand-by mode.
• Child lock might be enabled. >>> Disable Child Lock.
Laundry shrinks, fades, tarnishes or gets damaged.
• The programme selected might not be suitable for the type
of laundry. >>>
Check the care labels on garments and select a
programme accordingly, or select timed programmes additionally.
You should not dry laundry that is not suitable for drying.
Machine does not dry.
• Laundry might not be dried or the drying step might not
be enabled. >>>
Check if the drying function is selected
after the selected washing programme.
Loading door cannot be opened.
• The door of your machine might not be opening due to
safety reasons. >>>
If the door locked indicator is active
on the display after the drying step, the machine will keep the
door locked for your safety until it cools down.
• The loading door will not open if there is no power.
>>>
To open the loading door, open the pump filter cap and
pull down the emergency handle positioned at the rear side of
the said cap. See “Loading door lock”
8 Built-in installation guide
T20
Ø 4 x 16mm
M 5 x 10mm
x8 x2x6
a b c d e
x2 x2
580 mm
560 mm
595 mm
600 mm
818 mm
820 mm
1
165 mm
15 mm
54 mm
2
3
172
338
36
190
338
52
536
21
26
590 / 595
4
Ø
35
12
[mm]
L
26
4
190
338
36
172
338
52
536
21
26
590 / 595
Ø
35
12
R
26
[mm]
5
Ø35
12
16-22
Ø2
[mm]
12
Ø2
36
[mm]
6
7
±2mm
±2mm
GRUNDIG UK AND IRELAND STANDARD MANUFACTURER GUARANTEE TERMS AND CONDITIONS
Your new Grundig product is guaranteed against faulty materials, defective components or manufacturing defects.
The standard guarantee starts from the date of original purchase of the product and lasts for a period of twenty four
(24) months unless Beko plc (the “Manufacturer”) agrees to extend the guarantee for the product in writing.
If you have purchased a Built-In/integrated product, the standard guarantee starts from the date of original purchase
of the product, and lasts for a period of thirty six (36) months unless Beko plc (the “Manufacturer”) agrees to extend
the guarantee for the product in writing.
If you have registered Built-In/integrated product within 90 days of purchase by completing the online registration
form, then the standard 36-month guarantee will be extended to 60 months, under the same terms and conditions as
detailed below.
If you have any questions about the guarantee on your product (including how long it is valid), please contact your retailer or
our contact centre on 0333 207 9920 (UK and Northern Ireland) or 01 691 0203 (Republic of Ireland)
This guarantee does not in any way diminish or affect your statutory rights in connection with the product. This guarantee is in
addition to your statutory rights as a consumer. If you have any questions about these rights, please contact the retailer from
which you purchased the product. In certain circumstances, it is possible that your statutory rights may offer additional or
higher levels of protection than those offered under the terms of this guarantee.
What is covered by this guarantee?
• Repairs to the product required as a result of faulty materials, defective components or manufacturing defects.
• Functional replacement parts to repair a product.
• The costs of a Grundig Approved Engineer to carry out the repair.
What is not covered?
• Transit and delivery damage.
• Cabinet or appearance parts, including but not limited to control knobs, flaps and handles.
• Accessories and/or consumable items including but not limited to ice trays, scrapers, cutlery baskets, filters and light
bulbs.
• Repairs necessary as a direct or indirect result of:
- Accidental damage, misuse or abuse of a product.
- An attempted repair of a product by anyone other than a Grundig Approved Engineer (the “Engineer”).
- Installation or use of a product where such installation or use fails to meet the requirements contained in this
guarantee or the User Instructions Booklet.
• Repairs to a product operated at any time on commercial or non-residential household premises (unless we have
previously agreed to the installation environment).
This guarantee is limited to the cost of repairing the product. To the extent permitted by law, the Manufacturer does not accept
and will not be held liable for any financial loss incurred in connection with the failure of any product to operate in accordance
with the expected standards. Such financial loss includes but is not limited to loss arising from:
• Time taken off work.
• Damaged food, clothing or other items.
• Meals taken at restaurants or from takeaways.
• General compensation for inconvenience.
Important Notes
1. Your product is designed and built for domestic household use only.
2. The guarantee will automatically be void if the product is installed or is used in commercial or non-residential
domestic household premises, unless we have previously agreed to the installation environment.
3. The product must be correctly installed, located and operated in accordance with the instructions contained in the
User Instructions Booklet provided with your product.
4. Professional installation by a qualified Electrical Domestic Appliance Installer is recommended for all Washing
Machines, Dishwashers and Electric Cookers (as incorrect installation may result in you having to pay for the cost of
repairing the product).
5. Gas Cookers must be professionally installed by a Gas Safe (or Gas Networks Ireland for Republic of Ireland)
registered gas installer.
6. This guarantee is given in respect of products purchased and used within the United Kingdom and the Republic of
Ireland.
7. This guarantee is effective from the initial date of purchase of a new product from an authorised retailer and will be
void if the product is resold.
8. This guarantee does not apply to graded sales (where the product is purchased as a “second”).
9. Possession of a copy of these terms and conditions does not necessarily mean that a product has the benefit of this
guarantee. If you have any questions, please call our Call Centre on the number set out above.
10. The Manufacturer reserves the right to terminate the guarantee if its staff or representatives are subjected to physical
or verbal abuse in the course of carrying out their duties.
11. Optional extras, where available (i.e. extendable feet) are supplied on a chargeable basis only.
Does Grundig offer replacements?
This is a repair-only guarantee. On occasion, the Manufacturer may at its sole discretion, replace your product with a new
product instead of carrying out a repair. Where a replacement is offered, this would normally be an identical model but when
this is not possible, a model of similar specification will be provided. The Manufacturer will cover the costs and arrange for the
delivery of the new product and for the return of the old product. Any costs related to disconnecting the faulty product and
installing the replacement product will not be borne by the Manufacturer unless previously agreed to in writing. The original
guarantee will continue to apply to the replacement product; the new product will not come with a new guarantee.
When will the repair take place?
Our Engineers work Monday to Friday 9.00am to 5.00pm. Appointments outside these hours may be possible at the sole
discretion of the Manufacturer but cannot be guaranteed. Whilst our Engineers will endeavour to minimize inconvenience and
to meet requests for specific timed appointments, this cannot be guaranteed. We will not be liable for delays or if it is unable to
carry out a repair because a convenient appointment cannot be arranged.
Will there be any charge for the repairs?
It is your responsibility to provide evidence to the Engineer that your product is covered by this guarantee with a proof of
purchase. The Manufacturer reserves the right to charge for the reasonable cost of any service call if:
• You cannot provide evidence that your product is covered by this guarantee.
• Where a service call has been made and the engineer finds that there is no fault with your product.
• That your product has not been installed or operated in accordance with the User Instructions Booklet.
• That the fault was caused by something other than faulty materials, defective components or manufacturing defects.
• For missed appointments.
Payment of these costs are due immediately upon the Engineer providing you with an invoice. The Manufacturer reserves the
right to terminate the guarantee if you fail to pay the costs for the service call in a timely manner.
If you are a resident of the United Kingdom, this guarantee will be governed by English law and subject to the English Courts,
save where you live in another part of the United Kingdom, in which case the law and courts of that location will apply.
If you are resident in the Republic of Ireland, this guarantee will be governed by Irish law and the Irish courts will have
jurisdiction.
This guarantee is provided by Beko plc. Beko House, 1 Greenhill Crescent, Watford, Hertfordshire. WD18 8QU.
Beko plc is registered in England and Wales with company registration number 02415578.
GRUNDIG UK AND IRELAND ECO INVERTER MOTOR GUARANTEE TERMS AND CONDITIONS
This 10-year guarantee relates to Grundig products that feature the Eco Inverter Motor.
The Eco Inverter Motor guarantee terms and conditions are in addition to our Standard guarantee terms and conditions
detailed in the previous section.
In order to activate the 10 year guarantee you MUST register the appliance within 90 days of the original purchase
date. You can register by first visiting registermygrundig.co.uk and by following the online instructions.
Grundig Free standing appliances come with a 24-month parts and labour guarantee as standard.
Grundig Built-in/integrated appliances come with a 36-month parts and labour guarantee as standard, which can be extended
to a 60 months parts and labour guarantee by registering within 90 days of the original purchase date.
To make a claim against your Grundig Eco Inverter Motor Guarantee (the “Guarantee”), all customer and product details must
be registered with Beko plc using the procedure outlined below.
1. This extra 7 or 8 years (or 5 years for Built-in appliances registered within 90 days of the original purchase date)
Guarantee is only effective after the expiration of the standard manufacturer’s guarantee.
2. It is only valid for the Eco Inverter motors of selected washing machines, washer-dryers, tumble dryers and
dishwashers. It does not cover any labour charge or any other components of the product. In addition, it is only valid
for one replacement of the Eco Inverter motor during the extra 7 or 8 years (or 5 years for Built-in appliances
registered within 90 days of the original purchase date) guarantee period.
3. To activate your guarantee, you MUST register your appliance within 90 days of the original purchase date, by visiting
registermygrundig.co.uk.
4. Customers will receive a unique reference code as proof of guarantee validation, which must be quoted at the time of
a claim being made.
5. Any repair/replacement of the Eco Inverter motor must only be carried out by an authorised Grundig Service Agent
(the “Service Agent”).
6. Labour for the repair/replacement of the Eco Inverter motor is not included in this guarantee and is chargeable
directly by the Service Agent.
7. Any additional components fitted to the product at any time will not be covered by this guarantee and will be
chargeable directly by the Service Agent.
8. The guarantee is not transferable and cannot be exchanged for cash.
9. There are no alternative or additional offers to this Guarantee.
10. The guarantee is exclusive of the manufacturer’s standard guarantee
11. The Terms and Conditions shown above are in addition to the standard terms and conditions of your product
guarantee. Please read and refer to such Terms and Conditions when making any claim.
12. We may use the information you provide for marketing purposes and to analyse your purchasing preferences. We
may keep your information for a reasonable period for these purposes in accordance with the applicable Data
Protection Laws and General Data Protection Regulations (GDPR). You can opt into this service during the
registration process. Further details are available at http://www.Grundig.co.uk/cookie-and-privacy.
13. These Terms and Conditions are governed by the laws of England and Wales; manufacturer: Beko plc, Beko House,
1 Greenhill Crescent, Watford WD18 8QU. Company Registration Number: 02415578.
HOW TO OBTAIN SERVICE FOR YOUR APPLIANCE
Please keep your purchase receipt or other proof of purchase details in a safe place; you will need to have this documentation
available should the product require attention under guarantee.
Please take a few moments to complete the details below, as you will need this information when you call us, or to use our
online services. When you call us you may be required to input your serial number into your telephone keypad. For help please
visit grundig.co.uk/support/model-finder
• The product model number is printed on the Operating Instruction Booklet / User guide
• The product model and serial number is printed on the Rating Label affixed to the appliance.
• The Retailer (Purchased from) and Date of purchase will be printed on your purchase receipt or other proof of
purchase paperwork
Recording of these details alone will not count as proof of purchase. A valid proof of purchase is required for requesting
service under guarantee.
Model number
Serial number
Purchased from
Date of purchase
For service under guarantee or for product advice please call our Contact centre
Before requesting service please check the troubleshooting guide in the Operating Instructions booklet, as a charge may be
levied where no fault is found, and even though your product may still be under guarantee.
After arranging service the area around the product must be easily accessible to the Engineer, without the need for cabinets or
furniture to be removed or moved.
It is your responsibility to ensure our Engineers have a clean and safe environment to carry out any repairs.
Please have your Model number and Serial number available when you call us, as you may be required to input your serial
number into your telephone keypad during your call.
UK Mainland & Northern Ireland:
0333 207 9920
Landline or mobile calls to 0333 numbers cost no more than calls to geographic numbers 01 or 02, and are charged at the
basic rate. Calls from landlines and mobiles are included in free call packages but please check with your telephone service
provider for exact call charges.
Republic of Ireland:
01 691 0203
Service once the manufacturers guarantee has expired
If you have purchased an extended guarantee please refer to the instructions contained within the extended guarantee
agreement document, otherwise please call us using the appropriate number above, where service can be obtained at a
charge.
Should you experience any difficulty in obtaining service please call us on 0333 207 9920 or 01 691 0203
Contact us though our website
Send us a secure message through our online contact us form. Please visit our website, click Contact Us and choose a
product support topic from the list of options. Complete the required details and click send message.
Product registrations
For UK registrations please visit registermygrundig.co.uk and for the Republic of Ireland please call 01 514 3552†.
† Calls cost up to 9 cents a minute (plus call set up fee of 29 cents).
DISCLAIMER / WARNING (EN)
Some (simple) failures can be adequately handled by the end-user without any safety issue or
unsafe use arising, provided that they are carried out within the limits and in accordance with the
following instructions (see the “Self-Repair” section).
Therefore, unless otherwise authorized in the “Self-Repair” section below, repairs shall be
addressed to registered professional repairers in order to avoid safety issues. A registered
professional repairer is a professional repairer that has been granted access to the instructions
and spare parts list of this product by the manufacturer according to the methods described in
legislative acts pursuant to Directive 2009/125/EC.
However, only the service agent (i.e. authorized professional repairers) that you can
reach through the phone number given in the user manual/warranty card or through
your authorized dealer may provide service under the guarantee terms. Therefore,
please be advised that repairs by professional repairers (who are not authorized by
Grundig) shall void the guarantee.
Self-Repair
Self-repair can be done by the end-user with regard to the following spare parts: door, door
hinge and seals, other seals, door locking assembly and plastic peripherals such as detergent
dispensers (an updated list is also available in
support.grundig.com as of 1st of March 2021).
Moreover, to ensure product safety and to prevent risk of serious injury, the mentioned self-repair
shall be done following the instructions in the user manual for self-repair or which are available in
support.grundig.com. For your safety, unplug the product before attempting any self-repair.
Repair and repair attempts by end-users for parts not included in such list and/or not following the
instructions in the user manuals for self-repair or which are available in
support.grundig.com, might
give raise to safety issues not attributable to
Grundig, and will void the warranty of the product.
Therefore, it is highly recommended that end-users refrain from the attempt to carry out repairs
falling outside the mentioned list of spare parts, contacting in such cases authorized professional
repairers or registered professional repairers. On the contrary, such attempts by end-users may
cause safety issues and damage the product and subsequently cause fire, flood, electrocution and
serious personal injury to occur.
By way of example, but not limited to, the following repairs must be addressed to authorized
professional repairers or registered professional repairers: motor, pump assembly, main board,
motor board, display board, heaters etc.
The manufacturer/seller cannot be held liable in any case where end-users do not comply with the
above.
The spare part availability of the washing machine or washer-dryer that you purchased is 10 years.
During this period, original spare parts will be available to operate the washing machine or washer-
dryer properly.
