Dear Customer,
Thank you for choosing a Grundig appliance.
Please take some time to read this user manual before using your appliance, to
ensure you know how to safely operate the controls and functions.
Carefully follow all unpacking and installation instructions to ensure the appliance is
correctly connected and fitted prior to use.
Please write your product model and serial number on the last page of this user
manual, and store in a safe location close to the appliance for easy future reference.
This user manual may also be applicable for several other models. Differences
between models will be listed.
If you have any questions or concerns, please call our contact centre or find help and
information online at www.grundig.co.uk
C
Important information or useful hints about usage.
A
Warning for hazardous situations with regard to life and property.
B
Warning for electric shock.
Product weight warning.
•
Read user manual.
•
Packaging materials of the product are manufactured from recyclable
materials in accordance with regulations.
•
Do not dispose of the Packaging materials together with the domestic
or other wastes. Take them to the packaging material collection points
designated by the local authorities.
•
Allergy UK, is the brand of British Allergy Association. Their main
endorsement is the ‚Seal of Approval‘. When you see a product with this
logo on it, you have the reassurance the product has been scientifically
tested to prove it is efficient at reducing/removing allergens from the
environment of allergy and asthma sufferers or the products have
significantly reduced allergen/chemical content.
“The wool wash cycle of this machine has been approved by The Woolmark
Company for the washing of machine washable wool products provided that the
products are washed according to the instructions on the garment label and
those issued by the manufacturer of this washing machine. M1527.”
“In UK, Eire, Hong Kong and India the Woolmark trade mark is a Certification
trade mark.”
2
T
General safety .............................................................................................................. 5
Electrical safety ............................................................................................................................. 5
Product safety ................................................................................................................................. 6
Warnings for drying ........................................................................................................................ 6
Intended use ................................................................................................................8
Children's safety ..........................................................................................................8
Compliance with WEEE Directive and disposing of the waste product ....................... 9
Package information ....................................................................................................9
Overview .......................................................................................................................10
Package contents .........................................................................................................11
Technical specifications ............................................................................................... 12
Appropriate installation location ................................................................................. 13
Removing packaging reinforcement............................................................................13
Removing the transit bolts ..........................................................................................13
Connecting water supply .............................................................................................14
Connecting to the drain ...............................................................................................15
Adjusting the feet .........................................................................................................16
Electrical connection ...................................................................................................16
Transportation of the product ......................................................................................17
Sorting the laundry ......................................................................................................18
Preparing laundry for washing ....................................................................................19
Tips for energy saving ..................................................................................................19
Initial use .....................................................................................................................20
Correct load capacity ...................................................................................................20
Loading the laundry ..................................................................................................... 20
Using detergent and softener ......................................................................................21
Detergent drawer .......................................................................................................................... 21
Main Wash Compartment .............................................................................................................. 21
Liquid Softener Compartment ....................................................................................................... 22
Pre-Wash Compartment ................................................................................................................ 22
4.7.5 Choosing the detergent ......................................................................................................... 22
Adjusting the amount of detergent ................................................................................................ 22
Using gel and tablet detergent ...................................................................................................... 22
Using laundry starch ...................................................................................................................... 23
Using bleaches ............................................................................................................................... 23
Using limescale remover ............................................................................................................... 23
Tips for efficient washing ............................................................................................23
Tips for correct drying .................................................................................................24
3
EN
T
Control panel ...............................................................................................................26
Display symbols ........................................................................................................... 26
Preparing the machine ................................................................................................27
Selecting the washing programme .............................................................................27
Washing programmes .................................................................................................27
Temperature selection .................................................................................................29
Spin speed selection .................................................................................................... 29
If you want to spin your laundry after the Rinse Hold function: ................................................... 30
Auxiliary function selection for drying ........................................................................................... 30
Drying programmes .....................................................................................................30
Washing and drying programmes ...............................................................................31
Programme and consumption table ........................................................................... 32
Auxiliary function selection .........................................................................................34
Drying steps .................................................................................................................35
Iron Dry ...................................................................................................................................... 35
Cupboard Dry ............................................................................................................................ 35
Extra Dry .................................................................................................................................... 35
Time based drying-minutes ........................................................................................................... 35
Time display ................................................................................................................. 35
End Time ......................................................................................................................35
Starting the programme .............................................................................................. 36
Loading door lock ........................................................................................................36
Changing the selections after programme has started ..............................................36
Adding laundry after the programme has started: ....................................................................... 36
Switching the machine to pause mode: ........................................................................................ 36
Changing the programme selection after programme has started: ........................................... 36
Changing the auxiliary function, spin speed and temperature .................................................... 37
Child Lock ....................................................................................................................37
To activate the child lock: ............................................................................................................... 37
To deactivate the child lock: ........................................................................................................... 37
Cancelling the programme ..........................................................................................37
End of programme ....................................................................................................... 38
Your machine features a "Standby Mode". .................................................................. 38
Cleaning the detergent drawer....................................................................................38
Cleaning the loading door and the drum ..................................................................... 38
Cleaning the body and control panel ...........................................................................39
Cleaning the water intake filters .................................................................................39
Draining remaining water and cleaning the pump filter .............................................40
4
This section contains safety instructions that will help protect from risk of personal
injury or property damage. Failure to follow these instructions shall invalidate any
warranty.
A
• This product can be used by children at and above 8
years old and by persons whose physical, sensory or
mental capabilities were not fully developed or who
lack experience and knowledge provided that they are
supervised or trained on the safe usage of the product
and the risks it brings out. Children should not play with
the device. Cleaning and maintenance works should not
be performed by children unless they are supervised by
someone. Children under the age of 3 should be kept away
unless continuously supervised.
• Never place the product on a carpet-covered floor. Otherwise,
lack of airflow beneath the machine will cause electrical parts
to overheat. This will cause problems with your product.
• If the product will be used inside a wardrobe/cabinet/module,
it is recommended to keep the doors of the wardrobe/cabinet/
module open during operation in cases where there are no
openings to provide sufficient air circulation.
C
•
Always have the installation procedures carried out by the
competent persons. Manufacturer shall not be held liable
for damages that may arise from procedures carried out by
unauthorised persons.
B
A
• If the power cable is damaged, it must be replaced by the
manufacturer, after sales service or a similarly qualified
person (preferably an electrician) or someone designated
by the importer in order to avoid possible risks.
• Unplug the product when it is not in use.
• Never touch the plug with wet hands! Never unplug by pulling
on the cable, always unplug by holding the plug.
• Product should be unplugged during installation, maintenance,
cleaning and repair procedures.
• Do not make connections via extension cables or multi-plugs.
C
•
This product is designed to resume operating in the event of
powering on after a power interruption. If you wish to cancel the
programme, see „Cancelling the programme“ section.
5
EN
A
A
• The water supply and draining hoses must be securely
fastened and remain undamaged. Otherwise, there is the
risk of water leakage.
• The product should be used without removing the upper plate.
C
•
Do not force open the locked loading door. Door can be opened
a few minutes after the washing cycle ends. If the machine has
not cooled enough at the end of the programme, loading door
cannot be opened. Do not force the loading door to open. It must
be left to cool itself. The loading door and the lock mechanism
may get damaged.
•
In the installation location of this product, there must not be a
lockable, sliding or hinged door that will restrict the full opening
of the loading door.
•
Follow the instructions on the textile tags and on the detergent
package.
•
Use only detergents, softeners and supplements suitable for
washing machines.
•
Do not install or leave this product in places where it might be
exposed to outdoor conditions.
•
Controls must not be tampered with.
6
A
• Do not stop the machine before drying programme is
completed. If you have to stop the machine, remove all
laundry and lay them in a suitable place to let them cool
down.
• Your product is suitable to operate in ambient temperatures
between 0°C and +35°C.
• Ambient temperatures between 15°C and +25°C are ideal
temperatures for your product.
• Do not let pets enter the product. Check inside the product
before using.
• Do not overload the machine for drying. Observe the
maximum load levels specified for drying.
• Do not dry leather laundry or laundry that contains leather (such
as leather jeans label). The colour from Leather parts can run
into other textiles.
• In failures that cannot be repaired using information given in
safety instructions, turn off the machine, unplug the power
cable and call the Authorised Service Agent.
• You can just wash laundry, just dry laundry or wash and dry
laundry in your washer-dryer. Machine must not be used only
to dry wet loads for a long time. When machine is used only for
drying, it must be operated empty without loading laundry in a
short wash programme after every 15 operation.
• Check all clothes before loading them into the machine and
ensure that they do not have objects such as lighters, coins,
metal pieces, needles in the pockets or inside.
• Underwear with metal supports must not be dried in the
machine. Metal supports might come off during drying and
cause damage in the machine. Place in a bag or pillowcase.
• Do not dry large laundry such as tulle curtain, curtain, bedding,
blanket, rug in the machine. Your laundry might get damaged.
7
EN
C
•
Do not dry unwashed laundry in the machine.
•
Do not use fabric softeners or static preventers in the machine
unless recommended by the manufacturer.
•
Products such as fabric softeners must be used in accordance
with manufacturer‘s instructions.
•
Do not dry sensitive clothes such as silk, wool, etc. in the
machine. Otherwise, wool clothes may get shrunken and other
sensitive clothes may get damaged.
•
Check symbols on the garment tag before washing and drying.
C
•
This product has been designed for domestic use. It is not
suitable for commercial use and it must not be used out of its
intended use.
•
The product must only be used for washing, rinsing and drying
of textile products that are marked accordingly.
•
The manufacturer waives any responsibility arisen from
incorrect usage or transportation.
•
The service life of your product is 10 years. During this period,
original spare parts will be available to operate the product
properly.
A
• Children below the age of 3 must be kept away from the
machine unless they are continuously supervised.
• Packaging materials are dangerous to children. Keep
packaging materials in a safe place away from reach of
the children.
• Electrical products are dangerous for the children. Keep
children away from the product when it is in use. Do not
allow them to play with the product. Use child lock to
prevent children from intervening with the product.
• Do not forget to close the loading door when leaving the
room where the product is located.
• Store all detergents and additives in a safe place away
from the reach of the children by closing the cover of the
detergent container or sealing the detergent package.
8
This product does not contain harmful and forbidden materials described in the
"Regulation on the Control of the Waste Electrical and Electronic Equipment". It
complies with the WEEE Directive.
• This product has been manufactured with high quality parts and
materials which can be reused and are suitable for recycling.
Therefore, do not dispose the product with normal domestic
waste at the end of its service life. Take it to a collection point
for the recycling of electrical and electronic equipment. Please
consult your local authorities to learn the nearest collection
point. Help protect the environment and natural resources by
recycling used products. For children's safety, cut the power
cable and break the locking mechanism of the loading door so
that it will be non-functional before disposing of the product.
• Compliance with RoHS Directive:
• The product you have purchased complies with EU RoHS
Directive (2011/65/EU). It does not contain harmful and
prohibited materials specified in the Directive.
Packaging materials of the product are manufactured from recyclable materials
in accordance with our National Environment Regulations. Do not dispose of the
packaging with normal domestic waste. Take them to the packaging material
collection points designated by the local authorities.
9
EN
3
4
5
2
1
6
7
8
1- Power cable
2- Top panel
3- Control panel
4- Filter cover
5- Adjustable feet
6- Loading door
7- Detergent drawer
8- Water discharge hose
10
3
4
5
2
1
6
7
8
1- Power cable
2- Top panel
3- Control panel
4- Filter cover
5- Adjustable feet
6- Loading door
7- Detergent drawer
8- Water discharge hose
Power cable
Water discharge hose
Transit bolts
Mains water inlet hose
User manual
Plastic plug group
C
•
Figures in this manual are schematic and may not match the product exactly.
11
EN
Complying Commission Delegated Regulation (EU) No.96/60/EC/1996
Supplier name or trademark GRUNDIG
Model name GWDI854
Washer Dryer Energy efficiency class
(1)
A
Washing Energy efficiency class
(1)
A
(Washing & Drying) Energy Consumption - full load per cycle (kWh) 5.44
Washing Energy Consumption - full load per cycle (kWh) 0.76
Annual (Washing & Drying) Energy Consumption (kWh)
(2)
1088
Annual Washing Energy Consumption (kWh)
(2)
172
Water Consumption (Washing & Drying) full load per cycle- (l) 78
Water Consumption (Washing) full load per cycle (l) 47
Annual Water Consumption (Washing & Drying)- (l)
(3)
15600
Annual Water Consumption (Washing) (l)
(3)
9400
Spin-drying efficiency class (1) A
Maximum spin speed (rpm) 1400
Airborne acoustical noise emissions washing/spinning/drying (dB) 48/74/59
Built-in Yes
Rated capacity - Washing (kg) 8
Rated capacity - Drying (kg) 5
Height (cm) 82
Width (cm) 60
Depth (cm) 55
Net weight (±4 kg.) 68
Single Water inlet / Double Water inlet
• / -
• Available
Electrical input (V/Hz) 230 V / 50Hz
Total current (A) 10
Total power (W) 2200
VDE Main model code 9620
(1)
Scale from A (Highest Efficiency) to G (Lowest Efficiency)
(2)
Energy Consumption based on 200 standard washing cycles - full loads washing (and drying). Actual energy consumption will
depend on how the appliance is used.
(3)
Water consumption based on 200 standard washing cycles - full loads washing (and drying). Actual energy consumption will
depend on how the appliance is used.
Technical specifications may be changed without prior notice to improve the quality of the product.
12
To make the product ready for use,
review the information in the user
manual and make sure that the
electricity, tap water supply and water
drainage systems are appropriate. If
they are not, call a qualified technician
and plumber to have any necessary
arrangements carried out.
B
Make sure that the installation
and electrical connections of
the product are performed
by competent persons.
Manufacturer shall not be held
liable for damages that may
arise from procedures carried
out by unauthorised persons.
Your product is too heavy for one
person to carry.
A
Prior to installation, visually
check if the product has any
defects on it. If so, do not have
it installed. Damaged products
cause risks for your safety.
Preparation of the location
and electrical, tap water and
waste water installations at the
place of installation is under
customer‘s responsibility.
Make sure that the water inlet
and discharge hoses as well
as the power cable are not
folded, pinched or crushed
while pushing the product into
its place after installation or
cleaning procedures.
• Place the product on a solid and
level floor. Do not place it onto
a carpet with high pile or other
similar surfaces.
• Do not place the product close
to the edge if the floor contains
steps. Do not also place the
product on a platform.
• Do not place the product on the
power cable.
• Do not install the product
in environments where the
temperature falls below 0
ºC.(See. Warnings for Drying)
• Operate the product in a
well ventilated and dust free
environment.
Tilt the machine backwards to remove
the packaging reinforcement. Remove
the packaging reinforcement attached
to the ribbon.
Your product is heavy. Remove
packaging reinforcement as
displayed in the figure.
Be careful not to get your hand
caught under the machine
during this procedure.
A
Do not remove the transit bolts
before removing the packaging
reinforcement.
Remove the transit bolts before
operating the washing machine!
Otherwise, the product will get
damaged.
3
2
1
13
EN
• Use a tool to loosen all bolts until
they rotate freely.
3
2
1
• Remove the transit bolts by
turning them slightly.
3
2
1
• Attach the plastic covers supplied
in the user manual bag into the
holes on the rear panel.
C
Keep the transit bolts in a safe
place to reuse when the product
needs to be moved again in the
future.
Never move the product without
the transit bolts properly fixed
in place!
C
The water supply pressure
required to run the product is
between 1 to 10 bars (0.1 – 1
MPa). It is necessary to have
10 – 80 liters of water flowing
from the fully open tap in one
minute to have your product
run smoothly. Attach a pressure
reducing valve if water pressure
is higher.
A
Models with a single water inlet
should not be connected to the
hot water tap. In such a case the
laundry will get damaged or the
product will switch to protection
mode and will not operate.
Do not use old or used water
inlet hoses on the new product.
It may cause stains on your
laundry.
• Connect the special hose
supplied with the product to the
water inlet on the product.
1 2 3
A
Ensure that the cold water
connection is made correctly
when installing the product.
Otherwise, your laundry will
come out hot at the end of the
washing process and wear out.
• Tighten the hose nuts securely
by hand. Never use a tool when
tightening the nuts.
1 2 3
• Open the taps completely after
making the hose connection
to check for water leaks at the
connection points. If any leak
occurs, turn off the tap and
remove the nut. Retighten the
nut carefully after checking the
seal. In order to prevent the water
leaks, keep the taps closed when
you do not use the product.
14
1 2 3
• Attach the end of the drain hose
directly to waste water drain, sink
or bathtub.
A
Your house will be flooded
if the hose comes out of its
housing during water discharge.
Moreover, there is risk of
scalding due to high washing
temperatures! To prevent such
situations and to ensure smooth
water intake and discharge of
the machine, fix the end of the
discharge hose tightly so that it
cannot displace.
• Connect the hose to a minimum
height of 40 cm and a maximum
height of 90 cm.
90 cm
90
40
90
40
90 cm
90 cm
min.40
• If the hose is run along the floor
(or at less than 40 cm above it)
and raised later on, water drain
becomes difficult and laundry
may come out extremely wet.
Therefore, observe the heights
described in the figure.
90 cm
90
40
90
40
90 cm
90 cm
min.40
• To prevent flowing of dirty water
back into the machine and to
allow for easy discharge, do not
immerse the hose end into the
dirty water or do not drive it in the
drain more than 15 cm. If it is too
long, cut it short.
• The end of the hose should not
be bent, it should not be stepped
on and the hose must not be
pinched between the drain and
the machine.
90 cm
90
40
90
40
90 cm
90 cm
min.40
• If the length of the hose is too
short, add an original extension
hose. Length of the hose may
not be longer than 3.2 m. To
avoid water leak failures, the
connection between the extension
hose and the drain hose of the
product must be fitted well with
an appropriate clamp as not to
come off and leak.
15
EN
A
Adjust feet so that the product
will be balanced in the location
it will be used.Balance the
machine by adjusting the feet.
Check for any play by pressing
the product from upper
diagonal edges.
Otherwise, the product may
move from its place and cause
crushing, noise and vibration
problems.
Do not use any tools to loosen
the lock nuts. Otherwise, the
lock nuts may get damaged.
• Loosen the lock nuts on the feet
by hand.
• Adjust the feet until the product
stands level and balanced.
• Tighten all lock nuts again by
hand.
• When you turn the knob (visible
in the circle) in the direction of
the arrow, the machine will be
elevated by 0.3 mm. When you
turn it in the opposite direction
of the arrow, the machine will be
lowered by 0.3 mm.
• Do not adjust the rear feet by
using chargeable devices. Use a
screwdriver instead.
Connect the product to a grounded
outlet protected by a 13 A fuse. Our
company shall not be liable for any
damages that will arise when the
product is used without grounding in
accordance with the local regulations.
• Connection must comply with
national regulations.
• The wiring for the electrical
outlet circuit must be sufficient
to meet the appliance
requirements. Use of a Groud
Fault Circuit Interrupter (GFCI) is
recommended.
• Power cable plug must be within
easy reach after installation.
• If the current value of the fuse
or breaker in the house is less
than 13 Amps, have a qualified
electrician install a 13 Amp fuse.
• The voltage specified in the
"Technical specifications" section
must be equal to your mains
voltage.
B
Damaged power cables must
be replaced by the Authorised
Service Agent.
16
As the colours of the wires in the
mains lead of this appliance may not
correspond with the coloured markings
identifying the terminals on your plug,
proceed as follows:
• Connect the green - yellow or
green (earth) wire to the terminal
in the plug marked ‘E’ or with the
symbol f or coloured green and
yellow or green.
• Connect the blue (neutral) wire to
the terminal in the plug marked
‘N’ or coloured black.
• Connect the brown (live) wire to
the terminal in the plug marked
‘L’ or coloured red.
With the alternative plugs a 13A fuse
must be fitted either in the plug or
adaptor or in the main fuse box. If in
doubt contact a qualified electrician.
• Unplug the product before
transporting it.
• Remove water drain and water
supply connections.
• Drain all water that has remained
in the product.
• Install the transit bolts in
reverse order of the disassembly
procedure.
Your product is too heavy for
one person to carry.
Your product is heavy; two
persons must carry it and extra
precaution taken on stairs. If
your product falls on you, it may
cause injuries.
A
Packaging materials are
dangerous to children. Keep
packaging materials in a safe
place away from reach of the
children.
C
Never move the product without
the transit bolts properly fixed
in place!
17
EN
• Sort laundry according to type of fabric, colour, and degree of soiling and
allowable water temperature.
• Always observe the instructions given on the garment care labels.
LAUNDRY WASH SYMBOLS
Machine
Wash
Symbols
Normal wash
No Iron
Sensitive-
Delicate
wash
Hand wash
Not washable
No Spin
WASH
Water
Temperatures
Maximum
95
0
C 70
0
C 60
0
C 50
0
C 40
0
C 30
0
C
Symbol(s)
Drying
Symbols
Suitable for
dryer
No Iron
Sensitive /
Delicate dry
Do not dry
with dryer
Do not dry
Do not dry-
clean
DRYING
Drying
Settings
At any temperature
At high temperature
At medium
temperature
At low temperature
Without heating
Hang to dry
Lay to dry
Hang wet to dry
Lay in shadow
to dry
Dry-cleanable
Iron -
IRON
Dry or Steam
Iron at high
temperature
Iron at medium
temperature
Iron at low
temperature
Do not iron
Iron without
steam
Maximum temperature
200
0
C 150
0
C 110
0
C
All bleaches are allowed
Bleach (sodium
hypochlorite)
can be used
Bleach is not
allowed
Only bleaches without
chlorine are allowed
BLEACH
18
• Laundry items with metal
attachments such as, underwired
bras, belt buckles or metal
buttons will damage the machine.
Remove the metal pieces or wash
such clothes by putting them in
a cotton laundry bag or cotton
pillow case. Also these type of
clothes can heat too much during
drying and damage your other
clothes. Do not dry such laundry
in the machine.
• Put small size clothes such as
infant's socks and nylon stockings
in cotton a laundry bag or cotton
pillow case.
• Place curtains in without
compressing them. Remove
curtain attachment items. Do not
dry tulle curtains in your machine.
• Fasten zips, sew loose buttons
and mend rips and tears.
• Wash “machine washable”
or “hand washable” labelled
products only with an appropriate
programme. Dry these type of
clothes by hanging or laying
down. Do not dry them in the
machine.
• Do not wash colours and whites
together. New, dark coloured
cottons release a lot of dye. Wash
them separately.
• Only use the dyes / colour
changers and descaling agents
which are appropriate to
machine wash. Always follow the
instructions on the package.
C
Laundry that is subjected to
heavy deposits of materials
such as flour, lime dust, milk
powder, etc. Must be shaken off
before placing into the machine.
Such dusts and powders on the
laundry may build up on the
inner parts of the product in
time and can cause damage.
Keep laundry items made of
Angora wool in the freezer for a
few hours before washing. This
will reduce pilling.
Wash trousers and delicate
laundry turned inside out.
Tough stains must be treated
properly before washing.
If unsure, check with a dry
cleaner.
Take out all substances in the
pockets such as coins, pens
and paper clips, and turn
pockets inside out and brush.
Such objects may damage the
product or cause noise problem.
Energy efficiency will be improved by
using lower temperature programmes
and appropriate detergents.
• Operate the product in the
highest capacity allowed by the
programme you have selected,
but do not overload; see,
"Programme and consumption
table". See, “Programme and
consumption table"
• Always follow the instructions on
the detergent packaging.
• Wash slightly soiled laundry at
low temperatures.
• Use faster programmes for small
quantities of lightly soiled laundry.
• Do not use prewash and high
temperatures for laundry that is
not heavily soiled or stained.
• If you plan to dry your laundry in
a dryer, select the highest spin
speed recommended during
washing process.
• Do not use more detergent
than the recommended on the
detergent packaging.
19
EN
Before starting to use the product
make sure that all preparations
are made in accordance with the
“Important safety and environment
instructions” and the instructions in
the “Installation” section.
To prepare the product for washing
laundry, perform first operation in
Drum Cleaning programme. If this
programme is not available in your
machine, apply the method which is
described in the section.
C
Use an anti-limescale product
suitable for the washing
machines.
Some water may remain in
the product due to the quality
control processes in the
production. It is not harmful for
the product.
The maximum load capacity depends
on the type of laundry, the degree
of soiling and the desired washing
programme.
The product automatically adjusts the
water amount according to the weight
of the laundry put inside it.
A
Follow the information
in the “Programme and
consumption table”. When
overloaded, machine‘s washing
performance will drop.
Moreover, noise and vibration
problems may occur. For a
successful drying performance,
do not dry more laundry than
stated.
Bathrobe 1200
Fabric napkin 100
Bed sheet 700
Bed sheet 500
Pillowcase 200
Tablecloth 250
Towel 200
Hand towel 100
Women‘s night
gown
200
Underclothing 100
Men’s overalls 600
Men’s shirt 200
Men’s pyjamas 500
Blouses 100
• Open the loading door.
• Put the laundry items into the
product in a loose manner.
• Push the loading door to close
until you hear a locking sound.
Ensure that no items are caught
in the door.
C
The loading door is locked while
a programme is running. The
loading door is unlocked a while
after the programme comes
to an end. If the inside part of
the machine is too hot at the
end of the programme, loading
door will not open until the
temperature decreases.
A
If the laundry is misplaced,
noise and vibration problems
may occur in the machine.
20
C
When using detergent, softener,
starch, fabric dye, bleach and
descaling agents; read the
manufacturer‘s instructions
written on the package and
follow the dosages specified.
Use a measuring cup if
available.
The detergent drawer is composed of
four compartments:
II
II
I
• Left compartment with number
“II” (Main wash compartment
for powder detergent or powder
bleach/stain remover)
• Left compartment with number
“II ” (Main wash compartment
for liquid detergent or liquid stain
remover)
• Middle compartment with number
“I” (pre-wash compartment for
powder detergent, powder stain
remover or liquid bleach - liquid
bleach must be added either
during the pre-wash or during the
first rinsing step of the washing
Programme). Liquid bleach must
be added manually while the
machine takes in water.
Right compartment with “ ”
symbol (liquid softener compartment) (
) in addition, there is a siphon piece
in the softener compartment.
C
Never leave the detergent
drawer open while the washing
programme is running!
When using a programme
without prewash, do not put
any detergent into the prewash
compartment (compartment
nr. “I“).
Do not select a programme
with prewash if you are using
a detergent bag or dispensing
ball. Place the detergent bag
or the dispensing ball directly
among the laundry in the
machine. Remove these if drying
When machine is in Drying
step, do not add any washing
chemicals (Liquid detergent,
Softener, etc.).
Before starting the washing
Programme, put powder detergent into
the left compartment with number “II”.
Powder bleach/stain remover must
also be put into this compartment.
Put the liquid detergent into the main
wash compartment with number
“II ” before starting the washing
Programme. Liquid stain remover must
be put into this compartment.
Put the suggested amount of liquid
detergent into the left compartment
with “II ” symbol and dilute it to the
maximum filling level line (max. II )
with warm water.
Particularly the concentrated
detergents must be diluted with warm
water; otherwise, the siphon may get
clogged in time.
Do not fill the detergent above the
maximum filling level line; otherwise
the excess amount of detergent will
reach the laundry without water and
may cause stains on the garments.
In this case you will need to refill
the compartment. Do not pour the
detergent onto the laundry directly
since this may cause stains on the
garments.
21
EN
Put the suggested amount of liquid
softener into the right compartment with
“ ” symbol and dilute it to the maximum
filling level line (max. ) with warm
water.
Particularly the concentrated softeners
must be diluted with warm water;
otherwise, the siphon may get clogged
in time.
Do not fill the softener above the
maximum filling level line; otherwise
the excess amount of softener will get
mixed with the washing water and you
will need to refill the compartment. Do
not pour the softener onto the laundry
directly since this may cause stains on
the garments.
Liquid softener will be dispensed
automatically at the final rinsing step of
the washing Programme.
Put the powder pre-wash detergent or
powder stain remover into the middle
compartment with number “I”.
You can also put liquid bleach into this
compartment while the machine takes
in water during pre-wash or first rinsing
step. Adding the liquid bleach while
the machine takes in water allows it to
be diluted before it is poured onto the
laundry.
You must select extra rinsing option
if you use liquid bleach in a washing
Programme. Bleach must be removed
from the laundry with rinsing; otherwise
it may cause itching on the skin.
C
Read the dosage instructions and
label of your garments carefully
before using the liquid bleach.
Detergent type to be used depends on
the fabric type and colour.
• Use different detergents for
coloured and white laundry.
• Wash your delicate clothes only
with special detergents (liquid
detergent, wool shampoo, etc.)
intended solely for delicate clothes.
• When washing dark coloured
clothes and quilts, it is
recommended to use liquid
detergent.
• Wash woollens with special
detergent made specifically for
woollens.
A
Use only detergents
manufactured specifically for
washing machines.
Do not use Powdered Soap.
The amount of washing detergent
to be used depends on the amount
of laundry, the degree of soiling and
water hardness.
• Do not use amounts exceeding
the dosage quantities
recommended on the detergent
package to avoid problems of
excessive foam, poor rinsing,
financial savings and finally,
environmental protection.
• Use lesser detergent for small
amounts or lightly soiled clothes.
• If the gel detergent thickness is
fluidal and your machine does not
contain a special liquid detergent
cup, put the gel detergent
into the main wash detergent
compartment during first water
intake. If your machine contains
a liquid detergent container, fill
the detergent into this container
before starting the programme.
• If the gel detergent thickness
is not fluidal or in the shape
of capsule liquid tablet, put it
directly into the drum before
washing.
• Put tablet detergents into
the main wash compartment
(compartment nr. "2") or directly
into the drum before washing.
22
C
Tablet detergents may leave
residues in the detergent
compartment. If you notice
such residues, place the tablet
detergent between the laundry,
close to the lower part of the
drum in future washings.
Use the tablet or gel detergent
without selecting the prewash
function.
Bear in mind that any plastic
detergent cup, bowl etc in the
drum should be removed before
drying..
• Add liquid starch, powder starch
or the dyestuff into the softener
compartment.
• Do not use softener and starch
together in a washing cycle.
• Wipe the inside of the machine
with a damp and clean cloth after
using starch.
• Select a programme with
prewash and add the bleach at
the beginning of the prewash. Do
not put detergent in the prewash
compartment. As an alternative
application, select a programme
with extra rinse, add the bleach
into an empty detergent drawer
compartment and also add 1
glass of water from the same
compartment when you see the
rinsing step on the display for the
first time.
• Do not use bleach and detergent
by mixing them.
• Use just a little amount (approx.
50 ml) of bleaching agent and
rinse the clothes very well as it
causes skin irritation. Do not pour
the bleach onto the laundry and
do not use it with the coloured
items.
• When using oxygen-based
whitener, select a programme
which washes the laundry at a low
temperature.
• Oxygen-based whitener can be
used with the detergent; however,
if it is a different consistency, first
put detergent in the compartment
number “II” in the detergent
dispenser and wait for the
machine to flush the detergent
when taking in water. While
the product continues taking in
water, add whitener in the same
compartment.
• When required, use limescale
removers manufactured
specifically for washing machines
only.
(Recommended temperature
range based on soiling level: 40-
90 °C)
(difficult
stains such
as grass,
coffee, fruits
and blood.)
It may be necessary to pre-treat
the stains or perform prewash.
Powder and liquid detergents
recommended for whites can be
used at dosages recommended
for heavily soiled clothes. It is
recommended to use powder
detergents to clean clay and soil
stains and the stains that are
sensitive to bleaches.
(For
example,
stains
caused by
body on
collars and
cuffs)
Powder and liquid detergents
recommended for whites can be
used at dosages recommended
for normally soiled clothes.
(No visible
stains exist.)
Powder and liquid detergents
recommended for whites can be
used at dosages recommended
for lightly soiled clothes.
23
EN
(Recommended temperature
range based on soiling level: cold
-40 °C)
Powder and liquid detergents
recommended for colours can be
used at dosages recommended
for heavily soiled clothes. It is
recommended to use powder
detergents to clean clay and soil
stains and the stains that are
sensitive to bleaches. Detergents
which do not contain bleach
should be used.
Powder and liquid detergents
recommended for colours can be
used at dosages recommended
for normally soiled clothes.
Detergents which do not contain
bleach should be used.
Powder and liquid detergents
recommended for colours can be
used at dosages recommended
for lightly soiled clothes.
Detergents which do not contain
bleach should be used.
(Recommended temperature
range based on soiling level: cold
-40 °C)
Liquid detergents suitable for
colours and dark colours can be
used at dosages recommended
for heavily soiled clothes.
Liquid detergents suitable for
colours and dark colours can be
used at dosages recommended
for normally soiled clothes.
Liquid detergents suitable for
colours and dark colours can be
used at dosages recommended
for lightly soiled clothes.
(Recommended temperature
range based on soiling level: cold
-30 °C)
Prefer liquid detergents
produced for delicate clothes.
Woollen and silk clothes must
be washed with special woollen
detergents.
Prefer liquid detergents
produced for delicate clothes.
Woollen and silk clothes must
be washed with special woollen
detergents.
Prefer liquid detergents
produced for delicate clothes.
Woollen and silk clothes must
be washed with special woollen
detergents.
Durable
Clothes
with Cotton-
Content
Bed sheet, bedding, baby clothes,
t-shirt, sweatshirt, durable
knitted clothes, denim, canvas
trousers, shirts, cotton socks,
etc.
Synthetics
Clothes
(Polyester,
nylon, etc.)
Not recommended!
Delicate
(Silk,
Woollens,
Cashmere,
Angora wool,
etc. content)
Clothes
Not recommended!
Bulky
laundry
such as
quilts, coats,
curtains, etc.
Not recommended! It is not
appropriate to dry bulky laundry
inside the washing machine. Dry
them by hanging or laying down.
24
Durable
Clothes
with Cotton-
Content
Not recommended!
Synthetics
Clothes
(Polyester,
nylon, etc.)
It is recommended for the
polyester, nylon, polyacetate,
acrylic-content clothes. Drying
is not recommended for the
viscose-content clothes. Drying
explanations in the maintenance
label should be taken into
account.
Delicate
(Silk,
Woollens,
Cashmere,
Angora wool,
etc. content)
Clothes
Not recommended!
Bulky
laundry
such as
quilts, coats,
curtains, etc.
Not recommended! It is not
appropriate to dry bulky laundry
inside the washing machine. Dry
them by hanging or laying down.
Durable
Clothes
with Cotton-
Content
It washes and dries
consecutively! Bed sheet,
bedding, baby clothes, t-shirt,
sweatshirt, durable knitted
clothes, denim, canvas trousers,
shirts, cotton socks, etc.
Synthetics
Clothes
(Polyester,
nylon, etc.)
It is recommended for the
polyester, nylon, polyacetate,
acrylic-content clothes at low
temperatures with the washing
and drying warnings given in the
maintenance label taken into
consideration.
Delicate
(Silk,
Woollens,
Cashmere,
Angora wool,
etc. content)
Clothes
Not recommended!
Bulky
laundry
such as
quilts, coats,
curtains, etc.
Not recommended! It is not
appropriate to dry bulky laundry
inside the washing machine. Dry
them by hanging or laying down.
Durable
Clothes
with Cotton-
Content
It washes and dries
consecutively! Bed sheet,
bedding, baby clothes, t-shirt,
sweatshirt, durable knitted
clothes, denim, canvas trousers,
shirts, cotton socks, etc.
Synthetics
Clothes
(Polyester,
nylon, etc.)
It is recommended for the
polyester, nylon, polyacetate,
acrylic-content clothes at low
temperatures with the washing
and drying warnings given in the
maintenance label taken into
consideration.
Delicate
(Silk,
Woollens,
Cashmere,
Angora wool,
etc. content)
Clothes
Not recommended!
Bulky
laundry
such as
quilts, coats,
curtains, etc.
Not recommended! It is not
appropriate to dry bulky laundry
inside the washing machine. Dry
them by hanging or laying down.
Durable
Clothes
with Cotton-
Content
Clothes which are worn for
a short period of time an
unstained, such as shirts,
t-shirts, sweatshirts, etc. A very
small amount of laundry should
be loaded.
Synthetics
Clothes
(Polyester,
nylon, etc.)
Very slightly soiled and unstained
shirts, t-shirts and synthetic
content items. A very small
amount of laundry should be
loaded.
Delicate
(Silk,
Woollens,
Cashmere,
Angora wool,
etc. content)
Clothes
Not recommended!
Bulky
laundry
such as
quilts, coats,
curtains, etc.
Not recommended! It is not
appropriate to dry bulky laundry
inside the washing machine. Dry
them by hanging or laying down.
25
EN
1 - Programme selection knob
2 - Temperature selection lights
3 - Spin speed selection lights
4 - Display
5 - Drying Programme Lights
6 - On / Off button
7 - Start / Pause button
1 2 3 4 5 6
789101112
13
8 - End Time Adjustment button
9 - Drying Level Adjustment button
10 - Auxiliary Function buttons
11 - Spin Speed Adjustment button
12 - Temperature Adjustment button
13 - Programme Selection lights
a b c d e
f
g
h
i
a- Washing indicator
b - Rinsing indicator
c - Spinning indicator
d- Drying indicator
e- End indicator
f- No Water indicator
g - Duration Information display
h- Loading Door Lock indicator
i- Child Lock indicator
26
• Check if the hoses are connected
tightly.
• Plug in your machine.
• Turn the tap on completely.
• Place the laundry in the machine.
• Add detergent and fabric softener.
• Determine the programme
suitable for the type, quantity
and soiling level of the laundry in
accordance with the "Programme
and consumption table".
• Select the desired programme
with the
knob.
C
Programmes are limited
with the highest spin speed
appropriate for that particular
type of fabric.
When selecting a programme,
always consider the type of
fabric, colour, soiling level and
permissible water temperature.
Always select the lowest
appropriate temperature.
Higher temperature means
higher electricity consumption.
Depending on the type of fabric, use
the following main programmes.
C
You can set you machine to
switch to drying step at the end
of washing cycle by pressing
the Drying button after you
have selected the washing
programme for your laundry.
Each time you press the button,
info line shows at which step
the drying process will take
place and the relevant symbol
will turn on. If you want, by
continuing to press the button,
you can perform drying for
the maximum period of time
allowed by the machine for
drying.
Symbols in the display are
schematic and may not match
the product exactly.
When you will perform washing
and drying by using the Drying
function of your machine, load
maximum 5 kg of laundry
into the machine. If you load
excessively, your laundry
will not dry and machine will
operate for a long time and
consume more energy.
Use for your cotton laundry (such
as bed sheets, duvet and pillowcase
sets, towels, bathrobes, underwear,
etc.). Your laundry will be washed with
vigorous washing action for a longer
washing cycle.
C
You can dry your laundry after
the washing cycle without any
interruption (automatic or timed
drying can be performed after
washing). For this, you must
also select the Drying function
before starting the washing
programme.
According to the drying
selections which you will add to
the washing programmes, you
can see when the programme
will end on the display of the
machine.
If you don‘t want drying to take
place after the programme you
have selected, press and hold
the Drying auxiliary function
button until the Drying light is
turned off.
Use to wash your synthetic clothes
(shirts, blouses, synthetic/cotton
blends, etc.). Your laundry will be
washed with a gentle action for a
shorter washing cycle when compared
to the Cottons programme.
For curtains and tulle, use the
Synthetic 40˚C programme with
prewash and anti-creasing functions
selected. As their meshed texture
causes excessive foaming, wash the
veils/tulle by putting little amount
of detergent into the main wash
compartment. Do not put detergent in
the prewash compartment.
27
EN
C
You can dry your laundry after
the washing cycle without any
interruption (automatic or timed
drying can be performed after
washing). For this, you must
also select the Drying function
before starting the washing
programme.
According to the drying
selections which you will add to
the washing programmes, you
can see when the programme
will end on the display of the
machine.
If you don‘t want drying to take
place after the programme you
have selected, press and hold
the Drying auxiliary function
button until the Drying light is
turned off.
Use to wash your woollen laundry.
Select the appropriate temperature
complying with the tag of your clothes.
Use appropriate detergents for
woollens.
C
Drying function cannot be
selected for the woollen wash
programme.
Use to wash your normally soiled,
durable cotton and linen laundry.
Although it washes longer than
all other programmes, it provides
significant energy and water savings.
Actual water temperature may be
different from the stated washing
temperature. When you load the
machine with less laundry (e.g. ½
capacity or less), programme duration
may automatically get shorter. In this
case, energy and water consumption
will decrease more, providing a more
economic wash. This programme
is available in the models with the
remaining time indicator.
C
You can dry your laundry after
the washing cycle without any
interruption (automatic or timed
drying can be performed after
washing). For this, you must
also select the Drying function
before starting the washing
programme.
According to the drying
selections which you will add to
the washing programmes, you
can see when the programme
will end on the display of the
machine.
If you don‘t want drying to take
place after the programme you
have selected, press and hold
the Drying auxiliary function
button until the Drying light is
turned off.
Use to wash your delicate laundry.
Your laundry will be washed with more
gentle washing action compared to the
Synthetics programme.
Use to wash woollen/delicate laundry
that bear “not machine-washable”
care labels and for which hand wash
is recommended. Your laundry will be
washed with a very gentle washing
action in order not to damage the
clothes.
Use to wash your lightly soiled and
unstained cotton laundry in a short
time.
C
You can dry your laundry after
the washing cycle without any
interruption (automatic or timed
drying can be performed after
washing). For this, you must
also select the Drying function
before starting the washing
programme.
According to the drying
selections which you will add to
the washing programmes, you
can see when the programme
will end on the display of the
machine.
28
If you don‘t want drying to take
place after the programme you
have selected, press and hold
the Drying auxiliary function
button until the Drying light is
turned off.
Use it to wash a small amount of lightly
soiled cotton laundry in a short time.
This programme washes your laundry
in 14 minutes.
C
You can dry your laundry after
the washing cycle without any
interruption (automatic or timed
drying can be performed after
washing). For this, you must
also select the Drying function
before starting the washing
programme.
According to the drying
selections which you will add to
the washing programmes, you
can see when the programme
will end on the display of the
machine.
If you don‘t want drying to take
place after the programme you
have selected, press and hold
the Drying auxiliary function
button until the Drying light is
turned off.
Use to wash the shirts made of cotton,
synthetic and synthetic blended fabrics
together.
C
You can dry your laundry after
the washing cycle without any
interruption (automatic or timed
drying can be performed after
washing). For this, you must
also select the Drying function
before starting the washing
programme.
According to the drying
selections which you will add to
the washing programmes, you
can see when the programme
will end on the display of the
machine.
If you don‘t want drying to take
place after the programme you
have selected, press and hold
the Drying auxiliary function
button until the Drying light is
turned off.
Use when you want to rinse or starch
separately.
Use to drain the water in the machine.
Whenever a new programme
is selected, the recommended
temperature for the programme
appears on the temperature indicator.
It is possible that the recommended
temperature value is not the maximum
temperature that can be selected for
the current programme.
Press the
button to change the temperature.
C
Temperature Adjustment button
works only backwards. For
example, when you want to
select 60 0C when the display
shows 40 0C you need to press
the button for several times
until you reach 60 0C by going
backwards from 40 0C.
If you scroll to Cold Wash
option and press Temperature
Adjustment button again, the
recommended maximum
temperature for the selected
programme is displayed. Press
the Temperature Adjustment
button again to decrease the
temperature.
Finally, Cold light indicating the cold
wash option appears on the display.
You can also change the temperature
after the washing has started. You can
select the desired temperature after
washing starts but you must do this
before heating step starts.
29
EN
Whenever a new programme is
selected, the spin speed recommended
for the selected programme is
displayed on the indicator.
C
It is possible that the
recommended spin speed value
is not the maximum spin speed
that can be selected for the
current programme.
Press the button
to change the spin speed. Spin speed
decreases gradually.
Then, depending on the model of the
product, "Rinse Hold" and "No Spin"
options appear on the display.
C
Spin Speed Adjustment button
works only backwards. For
example, when you want to
select 1000 rpm when the
display shows 800 rpm, you
need to press the button for
several times until you reach
1000 rpm by going backwards
from 800 rpm.
Rinse Hold option is indicated
with “ ” symbol and No Spin
option is indicated with “ ”
symbol.
- Adjust the .
- Press button.
The programme resumes. Machine
drains the water and spins the laundry.
If you want to drain the water at
the end of the programme without
spinning, use function.
C
In programmes that do not
allow spin speed adjustment,
when Spin Speed adjustment
button is pressed, spin speed
light does not change and the
buzzer is heard.
You can also change the Spin Speed
after the washing starts. You can select
spin speed by pressing spin speed
adjustment button after washing has
started but before the spinning step.
When a new programme is selected,
press Auxiliary Function Selection
button to adjust the drying option that
is suitable for the selected washing
programme.
C
In programmes that do not
allow drying adjustment, when
Drying auxiliary function button
is pressed drying light does not
change and the buzzer is heard.
Only for drying programmes,
press Auxiliary Function
Selection button to adjust the
suitable drying option.
A
Machine cleans the lint coming
off the laundry automatically
during the drying cycle. Machine
uses water during drying. For
this reason, water tap of the
machine should be open also in
the drying programmes.
When a new programme
is selected, press Auxiliary
Function Selection button to
adjust the drying option that
is suitable for the selected
washing programme.
C
Drying programmes contain
spinning step. Your machine
performs this process in order
to shorten the drying time.
When drying is selected, spin
speed setting is in Maximum
spin speed range.
In programmes that do not
allow drying adjustment, when
Drying auxiliary function button
is pressed drying light does not
change and the buzzer is heard.
Only for drying programmes,
press Auxiliary Function
Selection button to adjust the
suitable drying option.
While there is a water cut, both
washing and drying could not be
performed.
30
Use to dry damp synthetic laundry
equivalent to 3 kg dry weight. This
programme performs drying only.
C
For the dry weights of the
laundry,
Use to dry damp cotton laundry
equivalent to 5 kg dry weight. This
programme performs drying only.
C
In order to dry the laundry
which contains only towels and
bathrobes, load 4 kg laundry
maximum.
For the dry weights of the
laundry,
A
Machine cleans the lint coming
off the laundry automatically
during the drying cycle. Machine
uses water during drying. For
this reason, water tap of the
machine should be open also in
the drying programmes.
Use to wash cotton laundry up to 5 kg
and dry it right after the washing cycle
without making any other selection.
C
When this programme is
selected, external Drying
auxiliary function cannot be
selected.
In 5 kg Wash & 5 kg Dry programme, it
is recommended to load laundry until
the level indicated in the above figure
for ideal drying conditions (you will
see the level arrow when you open the
loading door).
Use to wash and dry 0.5 kg laundry (2
shirts) in 40 minutes or 1 kg laundry (5
shirts) in 60 minutes.
C
Wash&Wear programme is
intended to quickly wash and
dry the daily clothes which
were worn for a short period
of time and are not soiled. This
programme is suitable for the
laundry which contains thin-
texture and can dry quickly.
(shirts, t-shirts)
Other drying options or
programmes should be used for
the thick texture laundry which
take longer to dry.
Use to wash and then immediately dry
your laundry up to 2 kg which requires
an anti-allergic and hygienic washing
(baby clothes, bed sheets, bedding,
underpants, etc. cotton items).
C
HygieneCare+ programme is
tested and approved by “The
British Allergy Foundation”
(Allergy UK) in United Kingdom.
31
EN
• : Selectable.
* : Automatically selected, no cancelling.
** : Energy Label programme (EN 50229)
***: If maximum spin speed of the machine is lower then this value, you can only select up to the maximum
spin speed.
- : See the programme description for maximum load.
C
***: If maximum spin speed of the machine is lower then this value, you can only select up to
the maximum spin speed.
The auxiliary functions in the table may vary according to the model of your machine.
Water and power consumption may vary subject to the changes in water pressure, water
hardness and temperature, ambient temperature, type and amount of laundry, selection of
auxiliary functions and spin speed, and changes in mains voltage.
You can see the washing time of the programme you have selected on the display of the
machine. It is normal that small differences may occur between the time shown on the
display and the real washing time.
“Selection patterns for auxiliary functions can be changed by the manufacturer. New
selection patterns can be added or removed.”
“The spin speed of your machine may vary according to the programme; this spin speed
cannot exceed the max. spin speed of your machine.”
EN
2
Auxiliary
functions
Programme (°C)
Max. Load (kg)
Water Consumption (l)
Energy Consumption (kWh)
Max. Speed***
Prewash
Express
Extra Rinse
Drying
Selectable temperature
range °C
Cottons
90 8 78 2,40 1400 • • • • 90-Cold
60 8 78 1,50 1400 • • • • 90-Cold
40 8 78 1,00 1400 • • • • 90-Cold
Cottons Eco 60** 8 47 0,76 1400 • 60-Cold
Synthetics
60 3 67 1,05 1200 • • • • 60-Cold
40 3 67 0,75 1200 • • • • 60-Cold
WoolProtect 40 1,5 45 0,45 1200 • 40-Cold
Delicates 40 3,5 48 0,50 1000 • 40-Cold
Hand Wash 30 1 35 0,30 1200 30-Cold
Mini 14’ 30 2 32 0,10 1400 • • 30-Cold
Mini
90 8 54 1,90 1400 • • 90-Cold
60 8 54 1,10 1400 • • 90-Cold
30 8 50 0,18 1400 • • 90-Cold
Shirts 60 3,5 45 0,85 800 • • • • 60-Cold
32
C
„Washing performance tests for EU energy labelling are performed in „Cottons Eco 60°C“
programme as per the EN 50229 standard.
According to the EN 50229 standard for EU energy labelling drying performance, the
maximum washing load must be divided into groups as the maximum drying load and the
remaining drying load, and then each load must be dried using the option „Cottons Drying
Extra Dry“.
EN
2
Auxiliary
functions
Drying level
Programme (°C)
Max. Load (kg)
Water Consumption (l)
Energy Consumption (kWh)
Max. Speed***
Prewash
Express
Extra Rinse
Drying
Extra Dry
Cupboard Dry
Iron Dry
Time based drying - minutes
Selectable
temperature range
°C
Cotton Dry - 5 35 2.75 1400 * • • • • -
Synthetic Dry - 3 22 1.70 - * • • • -
HygieneCare Wash&Dry 60 2 120 3.80 1400 * * • • • • 90-30
5 kg Wash&Dry 60 5 94 5.00 1400 * • • • • 60-Cold
Mini Wash&Dry 30 0.5 35 0.60 1000 • * • 30-Cold
Mini Wash&Dry 30 1 44 1.00 1000 • * • 30-Cold
33
EN
Select the desired auxiliary functions
before starting the programme.
Whenever a programme is selected,
lights of the auxiliary functions that
can be selected together with that
programme illuminate.
C
Light of the auxiliary function
that cannot be selected with
the selected programme does
not illuminate. When you press
the buttons of these auxiliary
functions, buzzer is heard and
selection is prohibited.
If the wash cycle has reached a point
where you cannot select the auxiliary
function, the function cannot be
selected.
C
Some functions cannot be
selected together. If a second
auxiliary function conflicting
with the first one is selected
before starting the machine,
the function selected first will
be cancelled and the second
auxiliary function selection will
remain active. For example,
if you want to select Quick
Wash after you have selected
the Prewash, Prewash will be
cancelled and Quick Wash will
remain active.
An auxiliary function that is not
compatible with the programme
cannot be selected. (See
„Programme and consumption
table“)
Some programmes have
auxiliary functions that must
be operated with the selected
programme. Those functions
cannot be cancelled. Auxiliary
function light is already
selected.
C
If the selected dampness
level (Iron Dry, Wardrobe Dry,
Extra Wardrobe Dry) cannot
be reached at the end of the
drying cycle, your machine will
extend the programme duration
automatically. Programme will
last longer.
If Timed-Drying is selected,
programme is finished at the
end of the drying period even if
the laundry does not get dry.
If the selected dampness level
(Iron Dry, Wardrobe Dry, Extra
Wardrobe Dry) is reached during
drying cycle, or extra dryness
is detected in the timed-drying
options, programme will take
a shorter time. Time decrease
will be shown on the display.
A Prewash is only worthwhile for
heavily soiled laundry. Not using the
Prewash will save energy, water,
detergent and time.
This function can be used in Cottons
and Synthetics programmes. It
decreases the washing times and also
the number of rinsing steps for lightly
soiled laundry.
C
When you select this function,
load your machine with half of
the maximum laundry specified
in the programme table.
This function enables the product
to make another rinse in addition to
the one already made after the main
wash. Thus, the risk for sensitive
skins (babies, allergic skins, etc.) to
be effected by the minimal detergent
remnants on the laundry can be
reduced.
C
Pressing for the first time will
add single rinse, a second press
will add double rinse. The third
press will cancel it.
34
•
This function enables drying of the
laundry after washing. Check with
which programmes this auxiliary
function can be selected, from the
programme table.
Drying is performed until the drying
level reaches Iron Dry step.
Drying is performed until the drying
level reaches Wardrobe Dry step.
Drying is performed until the drying
level reaches Extra Wardrobe Dry step.
C
Dryness level may change
according to the mixture,
material types, amount and
dampness level of the laundry.
Items which contain accessories
such as lace, tulle, stones,
beads, spacer, wire, etc. and
high silk-content items should
not be dried in the machine.
In order to reach the desired drying
level at low temperature, you select
any of 30, 90 and 150 minutes of drying
periods.
C
When drying small amount
of laundry (up to maximum 2
pieces), timed-drying steps
in the Cottons or Synthetics
drying programmes should be
selected.
If the laundry is not at the
desired dryness level at the
end of the drying programme,
timed-drying can be selected to
finish the process.
When this function is selected,
machine performs drying for
the adjusted time irrespective of
the drying level.
Remaining time for the completion
of the programme while it is running
is displayed as “01:30” in hours and
minutes format.
C
Programme time may differ
from the values in section
„Programme and consumption
table“ depending on the water
pressure, water hardness
and temperature, ambient
temperature, amount and
the type of laundry, auxiliary
functions selected and the
changes at the mains voltage.
With the function, the startup
of the programme can be delayed up
to 24 hours. After pressing
button, the programme's estimated
ending time is displayed. If the
is adjusted, light
illuminates.
In order for the End Time function
is activated and the programme is
completed at the end of the specified
time, you must press
button after adjusting the time.
button stops flashing and
remains illuminated continuously.
If you want to cancel End Time
function, press button until
the End Time light turns off or press
button to turn off and on the
machine.
• Open the loading door, place the
laundry and put detergent, etc.
• Select the washing programme,
temperature, spin speed and, if
required, the auxiliary functions.
• Set the end time of your choice by
pressing the button.
light is illuminated.
• Press button. Time
countdown starts. “:” symbol in
the middle of the end time on the
display starts flashing.
35
EN
C
Do not use liquid detergents
when you activate End Time
function! There is the risk of
staining of the clothes.
Door keeps locked during the
End Time countdown period.
In order to unlock the door,
machine should be switched to
the pause mode by pressing the
programme start/pause button.
At the end of the countdown,
End Time indicator turns off,
washing cycle starts and the
time of the selected programme
appears on the display.
When the End Time selection is
completed, the time appearing
on the display consists of end
time plus the duration of the
selected programme.
1400
800
1000
600
150’
Ütü Kuruluğu
Dolap Kuruluğu
Extra Kurutma
90’
20°
30’
8.5
10.5
Malzeme rengi ARC 716
Colour of material is ARC 716
%DVN×UHQJL3DQWRQH&
3ULQWLQJFRORULV3DQWRQH&
INLAY STOCK NO:
2846559001
1400
800
1000
600
150’
Ütü Kuruluğu
Dolap Kuruluğu
Extra Kurutma
90’
20°
30’
• Press button to start
the programme.
• The light of button
which was flashing starts to
illuminate steadily now, indicating
that the programme has started.
• Loading door is locked. "Locking
the Door" appears on the display
when the door is being locked.
1400
800
1000
600
150’
Ütü Kuruluğu
Dolap Kuruluğu
Extra Kurutma
90’
20°
30’
8.5
10.5
Malzeme rengi ARC 716
Colour of material is ARC 716
%DVN×UHQJL3DQWRQH&
3ULQWLQJFRORULV3DQWRQH&
INLAY STOCK NO:
2846559001
1400
800
1000
600
150’
Ütü Kuruluğu
Dolap Kuruluğu
Extra Kurutma
90’
20°
30’
There is a locking system on the
loading door of the machine that
prevents opening of the loading door
in cases when the water level is
unsuitable for door opening.
"Loading door locked" light in the
panel turns on when the loading door
is locked.
1400
800
1000
600
150’
Ütü Kuruluğu
Dolap Kuruluğu
Extra Kurutma
90’
20°
30’
8.5
10.5
Malzeme rengi ARC 716
Colour of material is ARC 716
%DVN×UHQJL3DQWRQH&
3ULQWLQJFRORULV3DQWRQH&
INLAY STOCK NO:
2846559001
1400
800
1000
600
150’
Ütü Kuruluğu
Dolap Kuruluğu
Extra Kurutma
90’
20°
30’
If the water level in the machine is
suitable when you press
button, “Loading door locked” light on
the panel is turned off.
If the water level in the machine is not
suitable when you press
button, the panel will indicate that the
loading door is locked.
1400
800
1000
600
150’
Ütü Kuruluğu
Dolap Kuruluğu
Extra Kurutma
90’
20°
30’
8.5
10.5
Malzeme rengi ARC 716
Colour of material is ARC 716
%DVN×UHQJL3DQWRQH&
3ULQWLQJFRORULV3DQWRQH&
INLAY STOCK NO:
2846559001
1400
800
1000
600
150’
Ütü Kuruluğu
Dolap Kuruluğu
Extra Kurutma
90’
20°
30’
Press the button to switch
the machine to pause mode.
Changing the programme is not
allowed when a programme is already
running.
If you turn the
knob while the programme is running,
buzzer is heard and change is
prohibited.
You can select the new programme
after switching the current programme
to pause mode.
C
The newly selected programme
starts from beginning.
36
Depending on the step the programme
has reached, you can cancel or select
auxiliary functions. See, "Auxiliary
function selection".
Also, you can change the spin speed,
temperature and drying settings.
See, "Spin speed selection" and
"Temperature selection".
C
The loading door will not open
if the water temperature in the
machine is high or the water
level is above the loading door
baseline.
Use Child Lock function to prevent
children from tampering with the
machine. Thus you can avoid any
changes in a running programme.
C
You can switch the machine
on and off with On / Off button
when the Child Lock is active.
When you switch on the
machine again, programme
will resume from where it has
stopped.
Machine will give an audio
alarm when the buttons are
pressed if the child lock is
active.
After
the countdown as "Child Lock 3-2-
1" on the display is over, "Child Lock
Enabled" appears on the display.
You can release
buttons when this warning is
displayed.
After
the countdown as "Child Lock 3-2-
1" on the display is over, "Child Lock
Enabled" is turned off on the display.
1400
800
1000
600
150’
Ütü Kuruluğu
Dolap Kuruluğu
Extra Kurutma
90’
20°
30’
8.5
10.5
Malzeme rengi ARC 716
Colour of material is ARC 716
%DVN×UHQJL3DQWRQH&
3ULQWLQJFRORULV3DQWRQH&
INLAY STOCK NO:
2846559001
1400
800
1000
600
150’
Ütü Kuruluğu
Dolap Kuruluğu
Extra Kurutma
90’
20°
30’
The programme is cancelled when the
machine is turned off and on again.
Press and hold button for 3
seconds. After the countdown as "3-2-
1" on the display is over, the machine
turns off.
C
If you press On / Off button
when the Child Lock is active,
the programme will not be
cancelled. You should cancel the
child lock first. Countdown as
„3-2-1“ appears on the display.
If you want to open the loading
door after you have cancelled
the programme but it is not
possible to open the loading
door since the water level in the
machine is above the loading
door baseline, then turn the
Programme Selection knob to
Pump+Spin programme and
drain the water in the machine.
37
EN
When the programme is over the End
of Programme indicator illuminates
and a buzzer is heard.
If you do not press any button for 2
minutes, the machine will switch
to standby mode. Display and all
indicators are turned off.
If you press any button or turn the
knob when
the machine is in standby mode,
programme steps that are completed
will appear on the display.
After you switch on your machine
with On-Off button, if no programme
is started or no other procedure is
performed at the selection step or
no action is taken within approx. 2
minutes after the selected programme
ends, your machine will switch to
energy saving mode automatically.
Also, if your product has a display that
shows programme time, this display
will be completely turned off. If you
turn the Programme Selection knob
or touch any button, lights and display
will switch back to previous condition.
The selections which you make when
exiting from the energy efficiency may
change. Please check the correctness
of your selections before starting the
programme. If necessary, please make
your settings again. This is not an
error.
Service life of product extends and
frequently experienced problems will
be reduced if it is cleaned at regular
intervals.
Remove any powder residue buildup in
the drawer. To do this;
II
II
I
• You can remove the detergent
drawer by pulling it towards
yourself strongly.
C
If more than a normal amount
of softener and liquid detergent
mixture starts to remain in the
softener compartment, the
siphon must be cleaned.
• Wash the drawer and the siphon
with plenty of lukewarm water
in a washbasin. Wear protective
gloves or use an appropriate
brush to avoid touching the
residues in the drawer when
cleaning.
• Replace the drawer into its
housing after cleaning. Check
if the siphon is in its original
location.
For products with drum cleaning
programme, please see Operating the
product - Programmes.
For products without drum cleaning
programme, follow the below steps to
:
38
Select or
auxiliary functions. Use Cottons
without pre-wash. Set
which can
be found in the detergent aisle in
supermarkets Apply this procedure
.
Before starting the programme, put
1 pouch of special drum cleaning
agent (if the special agent could not be
supplied, put max. 1 tea-cup of (max.
100 g) of antilimescale powder) into the
main wash detergent compartment.
If the antilimescale is in tablet form,
put only one tablet into the main wash
compartment no. "2". Dry the inside of
the bellow with a clean piece of cloth
after the programme has come to an
end.
C
Repeat Drum Cleaning process
in every 2 months.
Use an anti-limescale suitable
for the washing machines.
After every washing and drying make
sure that no foreign substance is left in
the drum.
If the holes on the bellow shown in
the figure are blocked, open the holes
using a toothpick.
C
Foreign metal substances will
cause rust stains in the drum.
Clean the stains on the drum
surface by using cleaning
agents for stainless steel. Never
use steel wool or wire wool.
A
Never use sponge or scrub
materials. These will damage
the painted, chrome and plastic
surfaces.
Wipe the body of the machine with
soapy water or non-corrosive mild gel
detergents as necessary, and dry with
a soft cloth.
Use only a soft and damp cloth to clean
the control panel.
There is a filter at the end of each
water intake valve at the rear of the
machine and also at the end of each
water intake hose where they are
connected to the tap. These filters
prevent foreign substances and dirt
in the water to enter the washing
machine. Filters should be cleaned if
they are dirty.
• Close the taps.
• Remove the nuts of the water
intake hoses to access the filters
on the water intake valves.
Clean residues on them with an
appropriate brush. If the filters
are too dirty, remove them from
their places with a pliers and
clean in this way.
• Take out the filters on the flat
ends of the water intake hoses
together with the gaskets and
clean thoroughly under running
water.
• Replace the gaskets and filters
carefully in their places and
tighten the hose nuts by hand.
39
EN
The filter system in your machine
prevents solid items such as buttons,
coins and fabric fibers clogging the
pump impeller during discharge of
washing water. Thus, the water will be
discharged without any problem and
the service life of the pump will extend.
If the machine fails to drain water, the
pump filter is clogged. Filter must be
cleaned whenever it is clogged or in
every 3 months. Water must be drained
off first to clean the pump filter.
In addition, prior to transporting the
machine (e.g., when moving to another
house) and in case of freezing of the
water, water may have to be drained
completely.
A
Foreign substances left in the
pump filter may damage your
product or may cause noise
problem.
If the product is not being used,
shut the tap, remove mains
hose and drain the water inside
the machine in places where
there is the risk of the product
freezing .
After each use, turn off the
water tap to which the mains
hose is connected.
• In order to clean the dirty filter
and discharge the water:
• Unplug the machine to cut off the
supply power.
A
Temperature of the water inside
the machine may rise up to
90 ºC. To avoid burning risk,
filter must be cleaned after
the water in the machine cools
down.
• Some of our products have
emergency draining hose and
some does not have. Follow the
steps below to discharge the
water.
• Discharging the water when
the product does not have an
emergency draining hose:
• Place a large container in front of
the filter to catch water from the
filter.
• Loosen pump filter
(anticlockwise) until water starts
to flow. Fill the flowing water into
the container you have placed in
front of the filter. Always keep a
piece of cloth handy to absorb any
spilled water.
• When the water inside the
machine is finished, take out the
filter completely by turning it.
• Clean any residues inside the
filter as well as fibers, if any,
around the pump impeller region.
• Install the filter, turn clockwise to
ensure it is closed and watertight.
40
• Start / Pause / Cancel button is not pressed.>>>
*Press Start/Pause/Cancel
button.
• Washing machine has switched to self protection mode due to a supply
problem (line voltage, water pressure, etc. >>>
Press and hold On/Off button
for 3 seconds to reset the machine to factory settings. (See. “Cancelling the
programme”)
• Some water may remain in the product due to the quality control processes in
the production. >>>
This is not a failure; water is not harmful to the machine.
• There is a problem with hoses or the pump filter. >>>
Be sure the seals of the
water inlet hoses are securely fitted. Attach the hose to the tap tightly.
• Pump filter is not closed securely. >>>
Make sure that the pump filter is closed
securely.
• Tap is turned off. >>>
Turn on the taps.
• Water inlet hose is bent. >>>
Flatten the hose.
• Water inlet filter is clogged. >>>
Clean the filter.
• Loading door is not closed. >>>
Close the loading door.
• Water drain hose is clogged or twisted. >>>
Clean or flatten the hose.
• Pump filter is clogged. >>>
Clean the pump filter.
• Machine is standing unbalanced. >>>
Adjust the feet to level the machine.
• A hard substance has entered into the pump filter. >>>
Clean the pump filter.
• Transit bolts are not removed. >>>
Remove the transit bolts.
• Laundry quantity in the machine is too little. >>>
Add more laundry to the
machine.
• Machine is overloaded with laundry. >>>
Take out some of the laundry from the
machine or distribute the load by hand to balance it.
• Machine is in contact with a rigid surface. >>>
Make sure that the machine is
not contacting anything.
• Machine has stopped temporarily due to low voltage. >>>
It will resume
running when the voltage restores to the normal level.
• Draining hose is not at adequate height. >>>
Connect the water draining hose
as described in the user manual.
• The water level is not visible from outside of the washing machine. This is not
a failure.
41
EN
• Loading door lock is activated because of the water level in the machine. >>>
Drain the water by running the Pump or Spin programme.
• Machine is heating up the water or it is at the spinning cycle. >>>
Wait until the
programme completes.
• Loading door lock is engaged. Loading door lock will be deactivated a couple
of minutes after the programme comes to an end. >>>
Wait for a couple of
minutes for deactivation of the loading door lock.
• Water pressure is low. >>>
Machine waits until taking in adequate amount of
water to prevent poor washing quality due to the decreased amount of water.
Therefore, the washing time extends.
• Voltage is low. >>>
Washing time is prolonged to avoid poor washing results
when the supply voltage is low.
• Input temperature of water is low. >>>
Required time to heat up the water
extends in cold seasons. Also, washing time can be lengthened to avoid poor
washing results.
• Number of rinses and/or amount of rinse water have increased. >>>
Machine
increases the amount of rinse water when good rinsing is needed and adds an
extra rinsing step if necessary.
• Excessive foam has occurred and automatic foam absorption system has been
activated due to too much detergent usage. >>>
Use recommended amount of
detergent.
• Timer may stop during water intake. >>>
Timer indicator will not countdown
until the machine takes in adequate amount of water. The machine will wait
until there is sufficient amount of water to avoid poor washing results due to
lack of water. Timer indicator will resume countdown after this.
• Timer may stop during heating step. >>>
Timer indicator will not countdown
until the machine reaches the selected temperature.
• Timer may stop during spinning step. >>>
Automatic unbalanced load detection
system might be activated due to the unbalanced distribution of the laundry in
the drum.
• Laundry is unbalanced in the machine. >>>
Automatic unbalanced load
detection system might be activated due to the unbalanced distribution of the
laundry in the drum.
• Laundry is unbalanced in the machine. >>>
Automatic unbalanced load
detection system might be activated due to the unbalanced distribution of the
laundry in the drum.
• The machine will not spin if water is not drained completely. >>>
Check the
filter and the draining hose.
• Excessive foam has occurred and automatic foam absorption system has been
activated due to too much detergent usage. >>>
Use recommended amount of
detergent.
42
• Insufficient amount of detergent has been used over a long period of time. >>>
Use the recommended amount of detergent appropriate for water hardness
and the laundry.
• Washing has been performed at low temperatures for a long time. >>>
Select
the proper temperature for the laundry to be washed.
• Insufficient amount of detergent is used with hard water. >>>
Using insufficient
amount of detergent with hard water causes the soil to accumulate on the
clothes over time and turns them grey. It is difficult to eliminate greying once
it happens. Use the recommended amount of detergent appropriate for water
hardness and the laundry.
• Excessive amount of detergent has been used. >>>
Use the recommended
amount of detergent appropriate for water hardness and the laundry.
• Insufficient amount of detergent is used. >>>
Use recommended amount of
detergent appropriate for the laundry.
• Excessive laundry is loaded in. >>>
Do not load the machine in excess. Load
with amounts recommended in the "Programme and consumption table".
• Wrong programme and temperature were selected. >>>
Select the proper
programme and temperature for the laundry to be washed.
• Wrong type of detergent is used. >>>
Use original detergent appropriate for the
machine.
• Detergent is put in the wrong compartment. >>>
Put the detergent in the
correct compartment. Do not mix the bleaching agent and the detergent with
each other.
• Regular drum cleaning is not applied. >>>
Clean the drum regularly.
• Odours and bacteria layers are formed on the drum as a result of continuous
washing at lower temperatures and/or in short programmes. >>>
Leave the
detergent drawer as well as the loading door of the machine ajar after each
washing. Thus, a humid environment favorable for bacteria cannot occur in the
machine.
• Excessive laundry was loaded in. >>>
Do not load the machine in excess.
• Detergent in use is damp. >>>
Keep detergents closed in an environment free
of humidity and do not expose them to excessive temperatures.
• A higher temperature is selected. >>>
Select the proper programme and
temperature according to the type and soiling level of the laundry.
43
EN
• The amount, brand and storage conditions of the detergent used are
inappropriate. >>>
Use a detergent appropriate for the washing machine and
your laundry. Keep detergents closed in an environment free of humidity and do
not expose them to excessive temperatures.
• Detergent is put in the wrong compartment. >>>
If detergent is put in the
prewash compartment although prewash cycle is not selected, machine can
take this detergent during rinsing or softener steps. Put the detergent in the
correct compartment.
• Pump filter is clogged. >>>
Check the filter.
• Drain hose is folded. >>>
Check the drain hose.
• Insufficient amount of detergent is used. >>>
Using insufficient amount of
detergent for the water hardness can cause the laundry to become stiff in time.
Use appropriate amount of detergent according to the water hardness.
• Detergent is put in the wrong compartment. >>>
If detergent is put in the
prewash compartment although prewash cycle is not selected, machine can
take this detergent during rinsing or softener steps. Put the detergent in the
correct compartment.
• Detergent was mixed with the softener. >>>
Do not mix the softener with
detergent. Wash and clean the drawer with hot water.
• Detergent is put in the wrong compartment. >>>
If detergent is put in the
prewash compartment although prewash cycle is not selected, machine can
take this detergent during rinsing or softener steps. Wash and clean the drawer
with hot water. Put the detergent in the correct compartment.
• Detergent was mixed with the softener. >>>
Do not mix the softener with
detergent. Wash and clean the drawer with hot water.
• Detergent was put in wet drawer. >>>
Dry the detergent drawer before putting
in detergent.
• Detergent has gotten damp. >>>
Keep detergents closed in an environment
free of humidity and do not expose them to excessive temperatures.
• Water pressure is low. >>>
Check the water pressure.
• The detergent in the main wash compartment got wet while taking in the
prewash water. Holes of the detergent compartment are blocked. >>>
Check
the holes and clean if they are clogged.
• There is a problem with the detergent drawer valves. >>>
Call the Authorised
Service Agent.
• Detergent was mixed with the softener. >>>
Do not mix the softener with
detergent. Wash and clean the drawer with hot water.
• Excessive laundry was loaded in. >>>
Do not load the machine in excess.
• Wrong programme and temperature were selected. >>>
Select the proper
programme and temperature for the laundry to be washed.
• Wrong detergent was used. >>>
Select the proper detergent for the laundry to
be washed.
44
• Improper detergents for the washing machine is used. >>>
Use detergents
appropriate for the washing machine.
• Excessive amount of detergent is used. >>>
Use only sufficient amount of
detergent.
• Detergent was stored under improper conditions. >>>
Store detergent in a
closed and dry location. Do not store in excessively hot places.
• Some meshed laundry such as tulle may foam too much because of their
texture. >>>
Use smaller amounts of detergent for this type of item.
• Detergent was put in the wrong compartment. >>>
Put the detergent in the
correct compartment.
• Softener is being taken early. >>>
There may be problem in the valves or in the
detergent drawer. Call the Authorised Service Agent.
• Excessive amount of detergent is used. >>>>
Mix 1 tablespoonful softener and ½
L water and pour into the main wash compartment of the detergent drawer.
• Put detergent into the machine suitable for the programmes and maximum
loads indicated in the “Programme and consumption table". When you use
additional chemicals (stain removers, bleaches and etc), reduce the amount of
detergent.
• Excessive foam has occurred and automatic foam absorption system has been
activated due to too much detergent usage. >>>
Use recommended amount of
detergent.
45
EN
• Excessive laundry loaded. >>>
Do not load the machine in excess.
• Laundry is not spun enough.>>>
Spin at a higher spin speed in washing step in the
Dryer-Washing Machine.
• Tap is turned off. >>>
Turn on the taps.
• An appropriate programme according to laundry type might is not selected.>>>
Check
care labels on clothes and select an appropriate programme or use timed
programmes in addition.
• Excessive laundry loaded. >>>
Do not load the machine in excess.
• Laundry is not spun enough.>>>
Spin at a higher spin speed in washing step in the
Dryer-Washing Machine.
• Power cable is not connected. >>>
Make sure the power cable is connected.
• Programme is not set or Start / Pause / Cancel button is not pressed. >>>
Make sure the
programme is set and it is not in Stand-by mode.
• Child lock enabled. >>>
Disable Child lock.
• An appropriate programme according to laundry type is not selected.>>>
Check
care labels on clothes and select an appropriate programme or use timed
programmes in addition. You must not dry clothes that are not suitable for drying.
• Laundry is not dried or drying step is not enabled. >>>
Check if drying function is
selected after the selected washing programme.
• Your machine’s door is not opened for safety reasons.>>>
If door locked indicator is still
active on display after drying, machine keeps the loading door locked until it cools
for your safety.
(*) Machine does not switch to spinning step when the laundry is not evenly
distributed in the drum to prevent any damage to the machine and to its
surrounding environment. Laundry should be rearranged and re-spun.
(**) Regular drum cleaning is not applied.
>>> Clean the drum regularly.
A
If you cannot eliminate the problem although you follow the instructions in this
section, consult your dealer or the Authorised Service Agent. Never try to repair a
nonfunctional product yourself.
46
GRUNDIG UK AND IRELAND STANDARD MANUFACTURER GUARANTEE TERMS AND CONDITIONS
Your new Grundig product is guaranteed against faulty materials, defective components or manufacturing defects.
The standard guarantee starts from the date of original purchase of the product, and lasts for a period of thirty six
(36) months unless Beko plc (the “Manufacturer”) agrees to extend the guarantee for the product in writing.
If you have registered the product within 90 days of purchase by completing the online registration form, then the
standard 36 month guarantee will be extended to 60 months, under the same terms and conditions as detailed below
If you have any questions about the guarantee on your product (including how long it is valid), please contact your retailer or
our contact centre on 0333 207 9920 (UK and Northern Ireland) or 01 691 0203 (Republic of Ireland)
This guarantee does not in any way diminish or affect your statutory rights in connection with the product. This guarantee is in
addition to your statutory rights as a consumer. If you have any questions about these rights, please contact the retailer from
which you purchased the product. In certain circumstances, it is possible that your statutory rights may offer additional or
higher levels of protection than those offered under the terms of this guarantee.
What is covered by this guarantee?
• Repairs to the product required as a result of faulty materials, defective components or manufacturing defects.
• Functional replacement parts to repair a product.
• The costs of a Grundig Approved Engineer to carry out the repair.
What is not covered?
• Transit and delivery damage.
• Cabinet or appearance parts, including but not limited to control knobs, flaps and handles.
• Accessories and/or consumable items including but not limited to ice trays, scrapers, cutlery baskets, filters and light
bulbs.
• Repairs necessary as a direct or indirect result of:
- Accidental damage, misuse or abuse of a product.
- An attempted repair of a product by anyone other than a Grundig Approved Engineer (the “Engineer”).
- Installation or use of a product where such installation or use fails to meet the requirements contained in this
guarantee or the User Instructions Booklet.
• Repairs to a product operated at any time on commercial or non-residential household premises (unless we have
previously agreed to the installation environment).
This guarantee is limited to the cost of repairing the product. To the extent permitted by law, the Manufacturer does not accept
and will not be held liable for any financial loss incurred in connection with the failure of any product to operate in accordance
with the expected standards. Such financial loss includes but is not limited to loss arising from:
• Time taken off work.
• Damaged food, clothing or other items.
• Meals taken at restaurants or from takeaways.
• General compensation for inconvenience.
Important Notes
1. Your product is designed and built for domestic household use only.
2. The guarantee will automatically be void if the product is installed or is used in commercial or non-residential
domestic household premises, unless we have previously agreed to the installation environment.
3. The product must be correctly installed, located and operated in accordance with the instructions contained in the
User Instructions Booklet provided with your product.
4. Professional installation by a qualified Electrical Domestic Appliance Installer is recommended for all Washing
Machines, Dishwashers and Electric Cookers (as incorrect installation may result in you having to pay for the cost of
repairing the product).
5. Gas Cookers must be professionally installed by a Gas Safe (or Gas Networks Ireland for Republic of Ireland)
registered gas installer.
6. This guarantee is given in respect of products purchased and used within the United Kingdom and the Republic of
Ireland.
7. This guarantee is effective from the initial date of purchase of a new product from an authorised retailer and will be
void if the product is resold.
8. This guarantee does not apply to graded sales (where the product is purchased as a “second”).
9. Possession of a copy of these terms and conditions does not necessarily mean that a product has the benefit of this
guarantee. If you have any questions, please call our Call Centre on the number set out above.
47
EN
10. The Manufacturer reserves the right to terminate the guarantee if its staff or representatives are subjected to physical
or verbal abuse in the course of carrying out their duties.
11. Optional extras, where available (i.e. extendable feet) are supplied on a chargeable basis only.
Does Grundig offer replacements?
This is a repair-only guarantee. On occasion, the Manufacturer may at its sole discretion, replace your product with a new
product instead of carrying out a repair. Where a replacement is offered, this would normally be an identical model but when
this is not possible, a model of similar specification will be provided. The Manufacturer will cover the costs and arrange for the
delivery of the new product and for the return of the old product. Any costs related to disconnecting the faulty product and
installing the replacement product will not be borne by the Manufacturer unless previously agreed to in writing. The original
guarantee will continue to apply to the replacement product; the new product will not come with a new guarantee.
When will the repair take place?
Our Engineers work Monday to Friday 9.00am to 5.00pm. Appointments outside these hours may be possible at the sole
discretion of the Manufacturer but cannot be guaranteed. Whilst our Engineers will endeavour to minimize inconvenience and
to meet requests for specific timed appointments, this cannot be guaranteed. We will not be liable for delays or if it is unable to
carry out a repair because a convenient appointment cannot be arranged.
Will there be any charge for the repairs?
It is your responsibility to provide evidence to the Engineer that your product is covered by this guarantee with a proof of
purchase. The Manufacturer reserves the right to charge for the reasonable cost of any service call if:
• You cannot provide evidence that your product is covered by this guarantee.
• Where a service call has been made and the engineer finds that there is no fault with your product.
• That your product has not been installed or operated in accordance with the User Instructions Booklet.
• That the fault was caused by something other than faulty materials, defective components or manufacturing defects.
• For missed appointments.
Payment of these costs are due immediately upon the Engineer providing you with an invoice. The Manufacturer reserves the
right to terminate the guarantee if you fail to pay the costs for the service call in a timely manner.
If you are a resident of the United Kingdom, this guarantee will be governed by English law and subject to the English Courts,
save where you live in another part of the United Kingdom, in which case the law and courts of that location will apply.
If you are resident in the Republic of Ireland, this guarantee will be governed by Irish law and the Irish courts will have
jurisdiction.
This guarantee is provided by Beko plc. Beko House, 1 Greenhill Crescent, Watford, Hertfordshire. WD18 8QU.
Beko plc is registered in England and Wales with company registration number 02415578.
48
GRUNDIG UK AND IRELAND ECO INVERTER MOTOR GUARANTEE TERMS AND CONDITIONS
This 10 year guarantee relates to Grundig products that feature the Eco Inverter Motor.
The Eco Inverter Motor guarantee terms and conditions are in addition to our Standard guarantee terms and conditions
detailed in the previous section.
In order to activate the 10 year guarantee you MUST register the appliance within 90 days of the original purchase
date. You can register by first visiting grundig.co.uk/register and by following the online instructions.
Grundig Free standing and Built-in appliances come with a 36 month parts and labour guarantee as standard, which can be
extended to a 60 months parts and labour guarantee by registering within 90 days of the original purchase date
To make a claim against your Grundig Eco Inverter Motor Guarantee (the “Guarantee”), all customer and product details must
be registered with Beko plc using the procedure outlined below.
1. This extra 7 years (or 5 years for appliances registered within 90 days of the original purchase date) Guarantee is
only effective after the expiration of the standard manufacturer’s guarantee.
2. It is only valid for the Eco Inverter motors of selected washing machines, washer-dryers, tumble dryers and
dishwashers. It does not cover any labour charge or any other components of the product. In addition, it is only valid
for one replacement of the Eco Inverter motor during the extra 7 years (or 5 years for appliances registered within 90
days of the original purchase date) guarantee period.
3. To activate your guarantee, you MUST register your appliance within 90 days of the original purchase date, by visiting
Grundig.co.uk/register.
4. Customers will receive a unique reference code as proof of guarantee validation by email or post, which must be
quoted at the time of a claim being made.
5. Any repair/replacement of the Eco Inverter motor must only be carried out by an authorised Grundig Service Agent
(the “Service Agent”).
6. Labour for the repair/replacement of the Eco Inverter motor is not included in this guarantee and is chargeable
directly by the Service Agent.
7. Any additional components fitted to the product at any time will not be covered by this guarantee and will be
chargeable directly by the Service Agent.
8. The guarantee is not transferable and cannot be exchanged for cash.
9. There are no alternative or additional offers to this Guarantee.
10. The guarantee is exclusive of the manufacturer’s standard guarantee
11. The Terms and Conditions shown above are in addition to the standard terms and conditions of your product
guarantee. Please read and refer to such Terms and Conditions when making any claim.
12. We may use the information you provide for marketing purposes and to analyse your purchasing preferences. We
may keep your information for a reasonable period for these purposes in accordance with the applicable Data
Protection Laws and General Data Protection Regulations (GDPR). You can opt into this service during the
registration process. Further details are available at http://www.Grundig.co.uk/cookie-and-privacy.
13. These Terms and Conditions are governed by the laws of England and Wales; manufacturer: Beko plc, Beko House,
1 Greenhill Crescent, Watford WD18 8QU. Company Registration Number: 02415578.
49
EN
HOW TO OBTAIN SERVICE FOR YOUR APPLIANCE
Please keep your purchase receipt or other proof of purchase details in a safe place; you will need to have this documentation
available should the product require attention under guarantee.
Please take a few moments to complete the details below, as you will need this information when you call us, or to use our
online services. When you call us you may be required to input your serial number into your telephone keypad. For help please
visit grundig.co.uk/support/model-finder
• The product model number is printed on the Operating Instruction Booklet / User guide
• The product model and serial number is printed on the Rating Label affixed to the appliance.
• The Retailer (Purchased from) and Date of purchase will be printed on your purchase receipt or other proof of
purchase paperwork
Recording of these details alone will not count as proof of purchase. A valid proof of purchase is required for requesting
service under guarantee.
Model number
Serial number
Purchased from
Date of purchase
For service under guarantee or for product advice please call our Contact centre
Before requesting service please check the troubleshooting guide in the Operating Instructions booklet, as a charge may be
levied where no fault is found, and even though your product may still be under guarantee.
After arranging service the area around the product must be easily accessible to the Engineer, without the need for cabinets or
furniture to be removed or moved.
It is your responsibility to ensure our Engineers have a clean and safe environment to carry out any repairs.
Please have your Model number and Serial number available when you call us, as you may be required to input your serial
number into your telephone keypad during your call.
UK Mainland & Northern Ireland:
0333 207 9920
Landline or mobile calls to 0333 numbers cost no more than calls to geographic numbers 01 or 02, and are charged at the
basic rate. Calls from landlines and mobiles are included in free call packages but please check with your telephone service
provider for exact call charges.
Republic of Ireland:
01 691 0203
Service once the manufacturers guarantee has expired
If you have purchased an extended guarantee please refer to the instructions contained within the extended guarantee
agreement document, otherwise please call us using the appropriate number above, where service can be obtained at a
charge.
Should you experience any difficulty in obtaining service please call us on 0333 207 9920 or 01 691 0203
Contact us though our website
Send us a secure message through our online contact us form. Please visit our website, click Contact Us and choose a
product support topic from the list of options. Complete the required details and click send message.
Product registrations
For UK and Republic of Ireland product registrations please visit grundig.co.uk/register.
50
BUILT-IN INSTALLATION GUIDE
60 mm
597 mm
820 mm
153 mm
600 mm
820 mm
554 mm
580 mm
14 mm
51
EN
52
53
EN
54
IF THE CABINET DOOR OPENS TO LEFT
IF THE CABINET DOOR OPENS TO RIGHT
55
EN
56
1
2
3
4
57
EN
58
820 mm
820 mm
Service Ref. No.
1493
Service Ref. No.
1493
59
EN
60
www.grundig.com
www.grundig.com
AUS GUTEM GRUND
