A Division of Snow Joe
®
, LLC Model 24V-X2-JB500 Form No. SJ-24V-X2-JB500-880E-M
R
OPERATOR’S MANUAL
© 2020 by Snow Joe
®
, LLC
All rights reserved. Original instructions.
SAVE THESE INSTRUCTIONS
1
CORDLESS TURBINE JET BLOWER
48V MAX* | 140 MPH MAX | 560-CFM MAX
IMPORTANT!
Safety Instructions
All Operators Must Read These
Instructions Before Use
Read all the instructions contained in this manual. Keep this
manual in a safe place, so that the information is available at
all times. If you give the equipment to another person,
make sure to provide these operating instructions. Basic safety
precautions should always be followed to reduce the risk of
re, electric shock, and personal injury.
mDANGER! This indicates a hazardous situation, which,
if not followed, will result in serious injury or death.
mWARNING! This indicates a hazardous situation, which,
if not followed, could result in serious injury or death.
mCAUTION! This indicates a hazardous situation, which,
if not followed, could result in minor or moderate injury.
Improper use of the machine will invalidate the warranty,
relieve the manufacturer from all liabilities. The user will
consequently be liable for all and any damage or injury to
himself/herself or others.
General Safety
FOR HOUSEHOLD USE ONLY
mCAUTION! Wear appropriate hearing protection during
use. After long periods of extended use, the noise generated
from this appliance may cause hearing loss if your ears are
not properly protected.
mWARNING! When using the power tool, basic safety
precautions should always be followed to reduce the risk of
re, electric shock, and personal injury. These include:
1. Keep work area clean and well-lit – Cluttered,
dark areas invite accidents.
2. Replacement parts – When servicing this unit, use only
identical replacement parts.
3. Keep children, bystanders, and pets away –
All spectators, including pets, should be kept a safe
distance away from the work area.
4. Dress properly – Do not wear loose clothing or jewelry
as such articles can get caught in moving parts. Wear a
protective covering to contain long hair. Wearing rubber
gloves and substantial non-slip footwear is recommended
when working outdoors.
mWARNING! Read all safety warnings and instructions.
Failure to follow the warnings and instructions may result in
electric shock, re and/or serious injury.
5. Prevent unintentional starting – Ensure the switch is
in the o-position before connecting to battery packs,
picking up or carrying the appliance. Carrying the
appliance with your nger on the switch or energizing
appliance that have the switch on invites accidents.
6. Disconnect battery packs from the appliance before
making any adjustments, changing accessories,
or storing appliance – Such preventive safety measures
reduce the risk of starting the appliance accidentally.
7. Rechargeonlywiththechargerspeciedbythe
manufacturer – A charger that is suitable for one type
of battery pack may create a risk of re when used with
another battery pack.
8. Useappliancesonlywithspecicallydesignated
battery packs – Use of any other battery packs may
create a risk of injury and re.
9. When battery pack is not in use, keep it away from
other metal objects, like paper clips, coins, keys, nails,
screws or other small metal objects, that can make a
connection from one terminal to another. Shorting the
battery terminals together may cause burns or a re.
10. Under abusive conditions, liquid may be ejected from
the batteries; avoid contact – If contact accidentally
occurs, ush with water. If liquid contacts eyes,
additionally seek medical help. Liquid ejected from the
batteries may cause irritation or burns.
11. Do not use a battery pack or appliance that is
damagedormodied–Damaged or modiedbatteries
may exhibit unpredictable behavior resulting in re,
explosion or risk of injury.
12.Donotexposeabatterypackorappliancetoreor
excessive temperature – Exposure to re or temperature
above 265ºF (130°C) may cause explosion.
13. Follow all charging instructions and do not charge the
battery pack or appliance outside of the temperature
rangespeciedintheinstructions. Charging improperly
or at temperatures outside of the specied range may
damage the battery and increase the risk of re.
2
14.Haveservicingperformedbyaqualiedrepairperson
using only identical replacement parts. This will ensure
that the safety of the product is maintained.
15. Do not modify or attempt to repair the appliance or the
battery packs (as applicable) except as indicated in the
instructions for use and care.
mWARNING! Do not modify or attempt to repair the
appliance or the battery packs (as applicable) except as
indicated in the instructions for use and care.
16. Moving parts – Keep hands and feet away from moving
parts. Keep guards in place and in proper working order.
17. Do not force the tool – It will perform better with less
likelihood of personal or mechanical injury if it is used at
the rate for which it is designed.
18. Wear personal protective equipment – When using this
tool, wear safety glasses with side shields or goggles to
provide necessary eye protection. Wear ear defenders to
prevent hearing damage. Use a face or dust mask if the
work environment is dusty.
19. Remove the batteries – Remove the batteries when
the tool is not in use, before servicing it, when changing
accessories, and when performing any other maintenance
task.
20. Store idle tool indoors – When not in use, the blower
should be stored indoors in a dry and high or locked-up
place out of the reach of children.
21. Use the right tool – Do not use the tool for any job except
that for which it is intended.
22. Avoid dangerous environments – Do not use the blower
in rain, damp, or wet locations.
23. Stay alert – Watch what you are doing. Use common
sense. Do not operate the blower when you are tired or
under the inuence of drugs, alcohol, or other medication.
Additional Safety Instructions
• Do not use the blower in the rain or in a damp area.
• Use extra care when cleaning on stairs or steps.
• Keep rm footing and maintain good balance at all times. Do
not overreach. Overreaching can result in loss of balance.
• Do not use the tool if the power button does not turn it ON
or OFF. Any tool that cannot be controlled with the ON/OFF
button is dangerous and must be repaired.
• Carefully inspect your appliance prior to use and follow all
label and marking instructions.
• Keep all parts of your body away from any moving parts
and all hot surfaces of the unit.
• Do not put any object into the tool's openings. Do not use
the tool with any opening blocked; keep openings free of
dust, lint, hair, or any other object that may reduce air ow.
• Check the work area before each use. Remove all objects
such as rocks, broken glass, nails, wire, or string, which can
be thrown or become entangled in the machine.
• Service on the product must be performed by qualied
repair personnel only. Service or maintenance performed
by unqualied personnel could result in injury to the user or
damage to the product.
• This blower is intended for residential use only.
Commercial use of this product is prohibited and will void
the manufacturer's warranty.
• Never run the unit without the proper equipment attached.
Always ensure the blower tube is properly installed.
• Always grasp the handle when operating the unit, only
operate the machine in its intended orientation.
SpecicSafetyRulesFor
Jet Blowers
• The jet blower has been designed to clear light debris and
leaves from hard surfaces – not for clearing grassed areas.
• When operating the unit, never point the jet blower nozzle
in the direction of people or pets or in the direction of
windows. Use extra caution when blowing debris near solid
objects, such as trees, automobiles, and walls.
• Be sure to secure the unit when transporting it.
• Never douse or squirt the unit with water or any other liquid.
Clean the unit after each use as described in the cleaning
and storage section.
Battery & Charger
Safety Instructions
We pay a great deal of attention to the design of every battery
pack to ensure that we supply you with batteries that are safe,
durable and have a high energy density. The battery cells have
a wide range of safety devices. Each individual cell is initially
formatted and its electrical characteristic curves are recorded.
This data is then used exclusively to be able to assemble the
best possible battery packs.
Despite all the safety precautions, caution must always be
exercised when handling batteries. The following points must
be obeyed at all times to ensure safe use. Safe use can only
be guaranteed if undamaged cells are used. Incorrect handling
of the battery packs can cause cell damage.
IMPORTANT! Analyses conrm that incorrect use and poor
care of high-performance batteries are the main factors
responsible for personal and/or product damage.
mWARNING! Use only approved replacement batteries;
other batteries may damage the jet blower and cause it to
malfunction.
mCAUTION! To reduce the risk of injury, charge the
iON+ 24V lithium-ion battery packs only in the designated
iON+ 24V lithium-ion charger. Other types of chargers present
risk of re, personal injury and damage. Do not wire the battery
packs to a power supply plug or car cigarette lighter. Such
misuse will permanently disable or damage the battery packs.
3
• Avoid dangerous environments – Do not charge the
battery packs in rain, snow or in damp or wet locations.
Do not use the battery packs or charger in the presence of
explosive atmospheres (gaseous fumes, dust or ammable
materials) because sparks may be generated when inserting
or removing the battery packs, which could lead to a re.
• Charge in a well-ventilated area – Do not block the
charger vents. Keep them clear to allow for proper
ventilation. Do not allow smoking or open ames near
charging battery packs. Vented gases may explode.
NOTE: The safe temperature range for the batteries is 41°F
– 105ºF (5°C – 40.5°C). Do not charge the batteries outside
in freezing weather; charge it at room temperature.
• Maintain charger cord – When unplugging the charger,
pull the plug, not the cord, from the receptacle to reduce
the risk of damage to the electrical plug and cord.
Never carry the charger by its cord or yank it by the cord
to disconnect it from the receptacle. Keep the cord away
from heat, oil and sharp edges. Make sure the cord will not
be stepped on, tripped over or subjected to damage or
stress when the charger is in use. Do not use the charger
with a damaged cord or plug. Replace a damaged charger
immediately.
• Do not use an extension cord unless it is absolutely
necessary – Using the wrong, damaged or improperly
wired extension cord poses a risk of re and electric shock.
If an extension cord must be used, plug the charger into a
properly wired 16 gauge or larger extension cord with the
female plug matching the male plug on the charger. Make
sure that the extension cord is in good electrical condition.
• Charger 24VCHRG-DPC is rated for 120 volt AC
only – The charger must be plugged into an appropriate
receptacle.
• Use only recommended attachments – Use of an
attachment not recommended or sold by the battery
charger or battery pack manufacturer may result in risk of
re, electric shock or personal injury.
• Unplug charger when not in use – Make sure to remove
battery packs from unplugged chargers.
mWARNING! To reduce the risk of electric shock,
always unplug the charger before performing any cleaning
or maintenance. Do not allow water to ow into the charger.
Use a Ground Fault Circuit Interrupter (GFCI) to reduce shock
hazards.
• Do not burn or incinerate battery packs – Battery packs
may explode, causing personal injury or damage.
Toxic fumes and materials are created when battery packs
are burned.
• Do not crush, drop or damage battery packs – Do not
use the battery packs or charger if they have sustained a
sharp blow, been dropped, run over or have been damaged
in any way (i.e. pierced with a nail, hit with a hammer,
stepped on, etc.).
• Do not disassemble – Incorrect reassembly may pose
a serious risk of electric shock, re or exposure to toxic
battery chemicals. If the batteries or charger are damaged,
please contact an authorized Snow Joe
®
+ Sun Joe
®
dealer
or call the Snow Joe
®
+ Sun Joe
®
customer service center
at 1-866-SNOWJOE (1-866-766-9563).
• Battery chemicals cause serious burns – Never let a
damaged battery pack contact the skin, eyes or mouth. If a
damaged battery pack leaks battery chemicals,
use rubber or neoprene gloves to safely dispose of it. If skin
is exposed to battery uids, wash the aected area with
soap and water and rinse with vinegar. If eyes are exposed
to battery chemicals, immediately ush with water for
20 minutes and seek medical attention. Remove and
dispose of contaminated clothing.
• Do not short circuit – When battery packs are not in use,
keep them away from other metal objects, like paper clips,
coins, keys, nails, screws or other small metal objects,
that can make a connection from one terminal to another.
Shorting the battery terminals together may cause burns or
a re.
• Store your battery packs and charger in a cool, dry
place – Do not store the battery packs or charger where
temperatures may exceed 105ºF (40.5ºC), such as in direct
sunlight or inside a vehicle or metal building during the
summer.
Information about the batteries
1. The battery packs supplied with your cordless jet blower
is only partially charged. The battery packs have to be
charged completely before you use the tool for the rst
time.
2. For optimum battery performance, avoid low discharge
cycles by charging the battery packs frequently.
3. Store the battery packs in a cool place, ideally at 77°F
(25°C) and charged to at least 40%.
4. Lithium-ion batteries are subject to a natural aging
process. The battery packs must be replaced at the latest
when their capacity falls to just 80% of its capacity when
new. Weakened cells in an aged battery packs are no
longer capable of meeting the high power requirements
needed for the proper operation of your jet blower,
and therefore pose a safety risk.
5. Do not throw battery packs into an open re as this poses
a risk of explosion.
6. Do not ignite the battery packs or expose them to re.
7. Do not exhaustively discharge batteries. Exhaustive
discharge will damage the battery cells. The most
common cause of exhaustive discharge is lengthy storage
or non-use of partially discharged batteries. Stop working
as soon as the performance of the batteries fall noticeably
or the electronic protection system triggers. Place the
battery packs in storage only after they have been fully
charged.
8. Protect batteries and the tool from overloads. Overloads
will quickly result in overheating and cell damage inside
the batteries' housing even if this overheating is not
apparent externally.
4
9. Avoid damage and shocks. Immediately replace batteries
that have been dropped from a height of more than one
meter or those that have been exposed to violent shocks,
even if the housing of the battery packs appear to be
undamaged. The battery cells inside the batteries may
have suered serious damage. In such instances,
please read the waste disposal information for proper
battery disposal.
10. If the battery packs suer overloading and overheating,
the integrated protective cuto will switch o the
equipment for safety reasons.
IMPORTANT! Do not press the ON/OFF button any more
if the protective cut-o has been activated. This may
damage the battery packs.
11. Do not use battery packs or an appliance that is damaged
or modied. Damaged or modied batteries may exhibit
unpredictable behavior resulting in re, explosion or risk of
injury.
12. Do not expose battery packs or an appliance to re or
excessive temperature. Exposure to re or temperature
above 266ºF (130°C) may cause explosion.
13. Follow all charging instructions and do not charge the
battery packs or appliance outside of the temperature
range specied in the instructions. Charging improperly
or at temperatures outside of the specied range may
damage the batteries and increase the risk of re.
Information about the charger and the
charging process
1. Please check the data marked on the rating plate of the
battery charger. Be sure to connect the battery charger
to a power supply with the voltage marked on the rating
plate. Never connect it to a dierent mains voltage.
2. Protect the battery charger and its cord from damage.
Keep the charger and its cord away from heat, oil and
sharp edges. Have damaged cords repaired without delay
by a qualied technician at an authorized Snow Joe
®
+
Sun Joe
®
dealer or call the Snow Joe
®
+ Sun Joe
®
customer service center at 1-866-SNOWJOE
(1-866-766-9563).
3. Electrical plugs must match the outlet. Never modify
the plug in any way. Do not use any adapter plugs with
grounded appliances. Unmodied plugs and matching
outlets will reduce the risk of electric shock.
4. Keep the battery charger, battery pack(s) and the cordless
tool out of the reach of children.
5. Do not use the supplied battery charger to charge other
cordless tools.
6. During periods of heavy use, the battery packs will become
warm. Allow the battery packs to cool to room temperature
before inserting it into the charger to recharge.
7. Do not overcharge batteries. Do not exceed the maximum
charging times. These charging times only apply to
discharged batteries. Frequent insertion of charged or
partially charged battery packs will result in overcharging
and cell damage. Do not leave batteries in the charger for
days on end.
8. Never use or charge batteries if you suspect that it has
been more than 12 months since the last time they were
charged. There is a high probability that the battery pack
has already suered dangerous damage (exhaustive
discharge).
9. Charging batteries at a temperature below 41°F (5°C) will
cause chemical damage to the cells and may cause a re.
10. Do not use batteries that have been exposed to heat
during the charging process, as the battery cells may have
suered dangerous damage.
11. Do not use batteries that have suered curvature or
deformation during the charging process or those that
exhibit other atypical symptoms (gassing, hissing,
cracking, etc.)
12. Never fully discharge the battery packs (maximum
recommended depth of discharge is 80%). A complete
discharge of the battery packs will lead to premature
aging of the battery cells.
Protectionfromenvironmentalinuences
1. Wear suitable work clothes. Wear safety goggles.
2. Protect your cordless tool and the battery charger from
moisture and rain. Moisture and rain can cause dangerous
cell damage.
3. Do not use the cordless tool or the battery charger near
vapors and ammable liquids.
4. Use the battery charger and cordless tools only in dry
conditions and at an ambient temperature of 41ºF – 105°F
(5°C – 40.5°C).
5. Do not keep the battery charger in places where the
temperature is liable to reach over 105°F (40.5°C).
In particular, do not leave the battery charger in a car that
is parked in the sunshine.
6. Protect batteries from overheating. Overloads,
overcharging and exposure to direct sunlight will result
in overheating and cell damage. Never charge or work
with batteries that have been overheated – replace them
immediately, if possible.
7. Store the charger and your cordless tool only in dry
locations with an ambient temperature of 41ºF – 105°F
(5°C – 40.5°C). Store your lithium-ion battery packs in a
cool, dry place at a temperature of 77°F (25°C). Protect
the battery packs, charger and cordless tool from humidity
and direct sunlight. Only place fully charged batteries in
storage (charged to at least 40%).
8. Prevent the lithium-ion battery packs from freezing.
Battery packs that were stored below 32°F (0°C) for more
than 60 minutes must be discarded.
9. When handling batteries, be wary of electrostatic charge.
Electrostatic discharges can damage the electronic
protection system and the battery cells. Avoid electrostatic
charging and never touch the battery poles.
5
Safety Symbols
The following table depicts and describes safety symbols that may appear on this product. Read, understand and follow all
instructions on the machine before attempting to assemble and operate.
READ THE OPERATOR'S
MANUAL(S) – Read, understand
and follow all instructions in the
user manual(s) before attempting
to assemble and operate.
SAFETY ALERT – Indicates
a precaution, a warning or
a danger.
Immediately remove the plug from
the mains if the power cable is
damaged, frayed or entangled.
Always keep the power cable away
from heat, oil and sharp edges.
WARNING! Do not expose the unit
to rain or wet conditions.
Wear hearing protection.
Wear eye protection.
Wear breathing protection.
Keep bystanders and children
a safe distance away.
Symbols Symbols
Descriptions
Descriptions
DANGER! Rotating impellers
pose a serious risk of injury.
Keep hands and feet away from
openings while the machine is
running.
The rotating part will continuously run
for several seconds after you turn o
the machine.
Beware of ying objects and
debris.
WARNING! Turn the machine OFF
and disconnect it from the power
supply before inspecting, cleaning,
changing accessories or conducting
any other maintenance task.
6
Know Your Cordless Turbine Jet Blower
Read the owner’s manual and safety instructions carefully before operating the cordless turbine jet blower. Compare the
illustration below to the cordless jet blower in order to familiarize yourself with the location of the various controls and
adjustments. Save this manual for future reference.
* Generates 48 V max with two 24 V lithium-ion batteries. Initial no-load voltage, per fully charged battery, peaks at 24 V. Nominal voltage under typical load is 21.6 V.
Technical Data
Battery Voltage Max* ........................................... 2 x 24 V D.C.
Battery Capacity ................................................... 2.0 Ah each
Battery Runtime Max (on High) ...................................... 18 min
Battery Runtime Max (on Low) ..................................... 50 min
Charger Input ............................................................120 V AC,
............................................................................. 60 Hz, 160 W
Charger Output ......................................... 26 V DC 2.2 A
Charge Time Max ......................................................... 55 min
Motor ............................................................................ 380 W
Air Speed Max (Turbo) ............................................... 140 mph
Air Speed Max (without Turbo) .................................... 90 mph
Air Flow Max ............................................................ 560 CFM
Speed Settings ................................................ Variable speed
.......................................................................... + turbo setting
Weight (without batteries) ................................ 5.7 lbs (2.6 kg)
Weight (with batteries) ........................................ 7.7 lbs (3.5 kg)
5
6
7
1
2 3
4
10
11
1413 15
12
8
9
1. Battery compartment (2)
2. Handle
3. Turbo button
4. ON/OFF button
5. Speed dial
6. Blower
7. Cordless jet blower body
8. Blower tube
9. Blower nozzle
10. Push button for battery indicator
11. Push lock button
12. Battery indicators
13. iON+ 24V lithium-ion battery (2) (24VBAT-LTE)
featuring exclusive EcoSharp
®
technology
14. iON+ 24V lithium-ion charger (24VCHRG-DPC)
15. Charger plug
7
Unpacking
Carton Contents
• Cordless jet blower body
• Blower tube
• Blower nozzle
• iON+ 24V lithium-ion batteries
• iON+ 24V lithium-ion charger
• Manual with registration card
1. Carefully remove the cordless jet blower and check to see
that all of the above items are supplied.
2. Inspect the product carefully to make sure no breakage or
damage occurred during shipping. If you nd damaged or
missing parts, DO NOT return the unit to the store. Please
call the Snow Joe
®
+ Sun Joe
®
customer service center at
1-866-SNOWJOE (1-866-766-9563).
NOTE: Do not discard the shipping carton and packaging
material until you are ready to use the cordless jet blower.
The packaging is made of recyclable materials. Properly
dispose of these materials in accordance with local
regulations.
IMPORTANT! The equipment and packaging material are not
toys. Do not let children play with plastic bags, foils or small
parts. These items can be swallowed and pose a suocation
risk!
Battery Pack Operation
The equipment is powered by two lithium-ion batteries.
The battery packs are completely sealed and maintenance
free.
mWARNING! The cordless turbine jet blower can only be
powered by both of the batteries together. One battery cannot
provide sucient power to the tool. Make sure to use two
batteries of the same voltage and the same capacity. Using the
tool with batteries of dierent capacity will cause damage to
the batteries.
mWARNING! Before rst use, the batteries require 55 min
charge time to be fully charged. When the batteries are at low
capacity, recharge for 55 min again before resuming operation.
Battery Charge Level Indicator
The battery packs are equipped with a push button for
checking the charge level. Simply press the push button to
read o the battery charge level from the LEDs of the battery
indicator:
• All 3 level monitoring LEDs are lit: Battery charge level
is high.
• 2 level monitoring LEDs are lit: Battery charge level is
decreasing. Stop work as soon as possible.
• 1 level monitoring LED is lit: Battery is at. Stop work
IMMEDIATELY and charge the battery. Otherwise the
battery’s service life will be greatly shortened.
NOTE: If the charge level button does not appear to be
working, connect the battery to the charger and charge
as needed.
NOTE: Immediately after using the battery pack, the charge
level button may display a lower charge than it will if checked
a few minutes later. The battery cells “recover” some of their
charge after resting.
Charger Operation
m
WARNING! Charge only iON+ 24V lithium-ion battery
packs with their compatible iON+ 24V lithium-ion charger.
Other types of batteries may cause personal injury
and damage.
To reduce the risk of electric shock, do not allow water to ow
into the charger's AC/DC plug.
When to Charge the iON+ 24VBAT
Lithium-Ion Batteries
NOTE: The iON+ 24VBAT lithium-ion battery packs do
not develop a "memory" when charged after only a partial
discharge. Therefore, it is not necessary to run down the
battery packs before placing them into the charger.
• Use the battery charge indicator lights to determine when to
charge your iON+ 24VBAT lithium-ion battery packs.
• You can "top-o" your battery packs' charge before starting
a big job or after a long day of use.
Charging the Batteries
1. Push the push lock buttons on each battery to pull the
battery packs out of the equipment (Fig. 1).
Charge level button
The battery is at 30% capacity
and requires charging
The battery is at 60% capacity
and requires charging soon
The battery is at full capacity
Light IndicatorsLights
Fig. 1
Battery
packs
Battery
Compartment
Push lock
button
8
2. Check that the mains voltage is the same as that marked
on the rating plate of the battery charger. Then, insert the
charger's plug into the electrical wall outlet. When you
plug in the charger, two green lights will illuminate and
stay green (Fig. 2).
3. Place the battery packs into the charger by sliding the
packs to lock them into position. When you insert the
batteries into the charger, the two green lights will go
o, and the red lights will illuminate to indicate that the
batteries are charging (Fig. 3).
4. When the charger lights turn green, the batteries are fully
charged (Fig. 3).
NOTE: A fully discharged pack with an internal
temperature in the normal range will fully charge in
55 min (between 32ºF/0ºC and 113ºF/45ºC).
5. If the light indicators do not come on at all, check that
the battery packs are fully seated into the bay. Remove
the battery packs and reinsert. If the problem persists,
contact an authorized Snow Joe
®
+ Sun Joe
®
dealer or
call the Snow Joe
®
+ Sun Joe
®
customer service center at
1-866-SNOWJOE (1-866-766-9563) for assistance.
6. When charging is complete, remove the batteries from the
charger by pressing the push lock buttons and sliding the
batteries backward to unlock them from the charger
(Fig. 4).
mCAUTION! FIRE HAZARD. When removing the batteries
from the charger, be sure to unplug the charger from the outlet
rst, then remove the batteries from the charger.
mWARNING! This charger does not automatically turn
o when the batteries are fully charged. Please take care not
to leave the batteries in the charger. Switch o or unplug the
charger at the mains when charging is complete.
7. Timely recharging of the batteries will help prolong the
batteries' life. You must recharge the battery packs when
you notice a drop in the equipment's power.
IMPORTANT! Never allow the battery packs to become
fully discharged as this will cause irreversible damage to
the batteries.
Charging a Hot or Cold Battery Pack
The green indicator lights on the charger base indicates that
the battery packs' temperatures are outside the charging
range. Once the packs are within the acceptable range,
normal charging will take place and the red light will be
continuous. Hot or cold battery packs may take longer to
charge.
Assembly
m
WARNING! To avoid serious personal injury, read and
understand all safety instructions provided.
mWARNING! Do not insert batteries until assembly is
complete. Failure to comply could result in accidental starting
and possible serious personal injury.
mWARNING! Before performing any maintenance,
make sure batteries are removed. Failure to heed this warning
could result in serious personal injury.
mWARNING! To prevent serious personal injury,
make sure the ON/OFF button is in the OFF (0) position,
the batteries are removed and the impeller has come to a
complete stop before attaching the tube.
Fig. 2
Charger
green
Power on
Fig. 3
Battery packs
red
Charging
green
Fully
Charged
Fig. 4
Push lock
button
9
Attaching the Jet Blower Tube
1. Align the slot on the blower tube with the notch on the
cordless jet blower body. Slide the two together
(Fig. 5).
2. Twist the blower tube clockwise until the notch clicks into
the end of the slot (Fig. 6).
3. Then, align the notch on the blower tube with the slot on
the blower nozzle. Slide the pieces together until they click
in place (Fig. 7).
mWARNING! To avoid the risk of injury, it is not
recommended to disassemble the blower tube.
Operation
Starting + Stopping
mCAUTION! Starting, stopping, and restarting a DC
motor repeatedly within a few seconds can generate a great
deal of heat and damage the motor. To protect the life of your
cordless jet blower, always wait at least ve seconds after
stopping before restarting the jet blower.
1. Insert the batteries in the battery compartments (Fig. 8).
2. To start the cordless jet blower, press the ON/OFF button
(Fig. 9).
3. To control the speed, use the dial to adjust between low to
high speed, and reach up to 90 mph (Fig. 10).
Fig. 5
Blower tube
Cordless jet
blower body
Slot
Notch
Fig. 6
Slot
Notch
Locked
position
Fig. 7
Blower nozzle
Blower tube
Slot
Notch
Fig. 8
Battery
packs
Battery
Compartment
Push lock
button
Fig. 9
ON/OFF button
Fig. 10
Speed dial
High
Low
10
4. This unit is equipped with a Turbo button that will allow the
blower to reach 140 mph. Press and hold the Turbo button
to activate. Release the Turbo button to turn Turbo mode
o (Fig. 11).
mWARNING! The Turbo button is for short term use only.
Do not use the Turbo function for extended periods of time.
Using this function for an extended time can cause damage.
5. To turn the tool o, press the ON/OFF button (Fig. 9).
Operating Tips
mWARNING! Use the cordless jet blower only in daylight
or good articial light.
• When using the cordless jet blower, plant your feet rmly
on the ground and place your dominant hand on the unit
handle to control the unit. Use your other hand to steady
the unit as needed.
• Wear personal protective equipment during your work
session. This includes boots, safety glasses/goggles,
ear defenders, long pants and a long-sleeve shirt.
• Make sure the jet blower tube nozzle is not directed at
anybody or any loose debris before starting the unit.
• Verify that the unit is in good working condition. Make sure
the tubes and guards are in place and secure.
• Keep a rm grip on the unit handle while in use.
• To reduce the risk of hearing loss associated with
increased sound levels, hearing protection is required.
• Operate power equipment only at reasonable hours—
not early in the morning or late at night when people might
be disturbed. Comply with times listed in local ordinances.
Usual recommendations are 9:00 am to 5:00 pm,
Monday through Saturday.
• To reduce noise levels, limit the number of pieces of
power equipment used at any one time and operate power
blowers at the lowest possible speed setting necessary to
do the job.
• Use rakes and brooms to loosen debris before blowing.
• In dusty conditions, slightly dampen surfaces.
• Conserve water by using power blowers instead of hoses
for many lawn and garden applications, including areas
such as gutters, screens, patios, grills, porches and
gardens.
• Blow debris into a safe, open area away from children,
pets, open windows or freshly washed cars.
• Clean up after using leaf blowers and other lawn
equipment. Dispose of debris appropriately.
mWARNING! To avoid serious personal injury,
wear ear defenders, goggles or safety glasses at all times
when operating this unit. Wear a face mask or dust mask in
dusty locations.
mWARNING! To prevent serious personal injury or
damage to the unit, make sure the blower tube is in place
before operating the unit.
Air Vents
Never cover air vents. Keep them free from obstructions
and debris. They must always remain clear for proper motor
cooling.
mWARNING! To avoid serious personal injury, do not
wear loose tting clothing or articles such as scarves, strings,
chains, ties, etc., that could get drawn into the air vents.
To make sure long hair does not get drawn into the air vents,
tie back long hair.
Blowing Operation
• Hold the jet blower rmly with your dominant hand on
the unit handle. Sweep from side to side with the nozzle
several inches above the ground or oor (Fig. 12).
• Slowly advance the unit, keeping the accumulated pile of
debris in front of you.
Fig. 11
Turbo button
Fig. 12
11
Maintenance
mWARNING! Always wear protective gloves during
maintenance operations. Do not carry out maintenance when
the engine is running or hot.
mWARNING! Use only original manufacturer’s
replacement parts, accessories and attachments. Failure to do
so can cause possible injury and poor performance.
To order genuine replacement parts or accessories for the
Sun Joe
®
24V-X2-JB500 cordless jet blower, please visit
sunjoe.com or contact the Snow Joe
®
+ Sun Joe
®
customer
service center at 1-866-SNOWJOE (1-866-766-9563).
mWARNING! Remove the batteries before performing
any maintenance task.
If the battery is connected with the unit, someone could
accidentally turn on the unit while you are inspecting it, which
could result in serious personal injury.
1. Store the tool, instruction manual and accessories in a
secure, dry place. In this way, you will always have the
information ready at hand.
2. Keep the tool’s air vents unclogged and clean at all times.
3. Remove dust and dirt regularly. Cleaning is best done with
a rag or brush.
4. Never use caustic agents to clean plastic parts.
mWARNING! Do not use cleaning agents to clean the
plastic parts of the tool. A mild detergent on a damp cloth is
recommended. Water must never come into contact with the
tool.
Storage
1. Examine the cordless jet blower thoroughly for worn,
loose, or damaged parts. Should you need to repair or
replace a part, contact an authorized Snow Joe
®
+
Sun Joe
®
dealer or call the Snow Joe
®
+ Sun Joe
®
customer service center at 1-866-SNOWJOE
(1-866-766-9563) for assistance.
2. Remove the batteries from the cordless jet blower before
storing.
3. Store the jet blower in a dry, well-ventilated place that is
inaccessible to children. Keep away from corrosive agents.
Battery Caution + Disposal
Always dispose of your battery packs according to federal,
state, and local regulations. Contact a recycling agency in your
area for recycling locations.
mCAUTION! Even discharged battery packs contain
some energy. Before disposing, use electrical tape to cover
the terminals to prevent the battery packs from shorting, which
could cause a re or explosion.
mWARNING! To reduce the risk of injury or explosion,
never burn or incinerate a battery pack even if it is damaged,
dead, or completely discharged. When burned, toxic fumes
and materials are emitted into the surrounding atmosphere.
1. Batteries vary according to device. Consult your manual
for specic information.
2. Install only new batteries of the same type in your product
(where applicable).
3. Failure to insert batteries in the correct polarity,
as indicated in the battery compartment or manual,
may shorten the life of the batteries or cause batteries to
leak.
4. Do not mix old and new batteries.
5. Do not mix Alkaline, Standard (Carbon-Zinc), or
Rechargeable (Nickel Cadmium, Nickel Metal Hydride, or
Lithium-Ion) batteries.
6. Do not dispose of batteries in re.
7. Batteries should be recycled or disposed of as per state
and local guidelines.
Service and Support
If your Sun Joe
®
iON+ 24V-X2-JB500 cordless jet blower
requires service or maintenance, please call 1-866-SNOWJOE
(1-866-766-9563) for assistance.
Model and Serial Numbers
When contacting the company, reordering parts, or arranging
service from an authorized dealer, you will need to provide the
model and serial numbers, which can be found on the decal
located on the housing of the unit. Copy these numbers into
the space provided below.
Record the following numbers from the housing or handle of your
new product:
Model #:
Serial #:
24V-X2-JB500
12
Optional Accessories
mWARNING! ALWAYS use only authorized Snow Joe
®
+ Sun Joe
®
replacement parts and accessories. NEVER use
replacement parts or accessories that are not intended for use with this cordless jet blower. Contact Snow Joe
®
+
Sun Joe
®
if you are unsure whether it is safe to use a particular replacement part or accessory with your cordless jet blower.
The use of any other attachment or accessory can be dangerous and could cause injury or mechanical damage.
NOTE: Accessories are subject to change without any obligation on the part of Snow Joe
®
+ Sun Joe
®
to provide notice of such
changes. Accessories can be ordered online at sunjoe.com or via phone by contacting the Snow Joe
®
+ Sun Joe
®
customer
service center at 1-866-SNOWJOE (1-866-766-9563).
iON+ 24V Lithium-Ion Battery Quick Charger 24VCHRG-QC
ModelAccessories Item
1
2
3
4
5
iON+ 24V 2.0 Ah Lithium-Ion Battery
Battery Charge Time Max:
24VCHRG-QC: 55 min | 24VCHRG-DPC: 55 min
Battery Runtime Max: high speed 18 min; low speed 50 min
24VBAT-LTE
iON+ 24V 2.5 Ah Lithium-Ion Battery
Battery Charge Time Max:
24VCHRG-QC: 1 hr 10 min | 24VCHRG-DPC: 1 hr 10 min
Battery Runtime Max: high speed 22 min; low speed 1 hr 2 min
24VBAT-LT
iON+ 24V 4.0 Ah Lithium-Ion Battery
Battery Charge Time Max:
24VCHRG-QC: 1 hr 50 min | 24VCHRG-DPC: 1 hr 50 min
Battery Runtime Max: high speed 36 min; low speed 1 hr 40 min
24VBAT
iON+ 24V 5.0 Ah Lithium-Ion Battery
Battery Charge Time Max:
24VCHRG-QC: 2 hr 20 min | 24VCHRG-DPC: 2 hr 20 min
Battery Runtime Max: high speed 45 min; low speed 2 hrs 5 min
24VBAT-XR
6
iON+ 24V Lithium-Ion Dual-Port Battery Charger
24VCHRG-DPC
13
NOTES
14
NOTES
15
R4_01282020
SNOW JOE
®
+ SUN JOE
®
CUSTOMER PROMISE
OUR WARRANTY:
Snow Joe
warrants new, genuine, powered and non-powered Products to be free from defects in material or workmanship when used
for ordinary household use for a period of two years from the date of purchase by the original, end-user purchaser when purchased
from Snow Joe or from one of Snow Joe’s authorized sellers with proof of purchase. Because Snow Joe is unable to control the quality
of its Products sold by unauthorized sellers, unless otherwise prohibited by law, this Warranty does not cover Products purchased from
unauthorized sellers. If your Product does not work or there’s an issue with a specic part that is covered by the terms of this Warranty,
Snow Joe will elect to either (1) send you a free replacement part, (2) replace the Product with a new or comparable product at no
charge, or (3) repair the Product. How cool is that!
This Warranty gives you specific legal rights, and you may also have other rights which vary from State to State.
PRODUCT REGISTRATION:
Snow Joe strongly encourages you to register your Product. You can register online at snowjoe.com/register, or by printing and
mailing in a registration card available online from our website, or calling our Customer Service Department at 1-866-SNOWJOE
(1-866-766-9563), or by e-mailing us at [email protected]. Failure to register your Product will not diminish your warranty
rights. However, registering your Product will allow Snow Joe to better serve you with any of your customer service needs.
WHO CAN SEEK LIMITED WARRANTY COVERAGE:
This Warranty is extended by Snow Joe to the original purchaser and original owner of the Product.
WHAT IS NOT COVERED?
This Warranty does not apply if the Product has been used commercially or for non-household or rental applications. This Warranty also
does not apply if the Product was purchased from an unauthorized seller. This Warranty also does not cover cosmetic changes that do
not aect performance. Wearing parts like belts, augers, chains and tines are not covered under this Warranty, and can be purchased
at snowjoe.com or by calling 1-866-SNOWJOE (1-866-766-9563).
ABOVE ALL ELSE, Snow Joe, LLC (“Snow Joe”) is dedicated to you, our customer. We strive to make your experience as pleasant as
possible. Unfortunately, there are times when a Snow Joe
®
, Sun Joe
®
, or Aqua Joe
®
product (“Product”) does not work or breaks under
normal operating conditions. We think it’s important that you know what you can expect from us. That’s why we have a Limited Warranty
(“Warranty”) for our Products.
sunjoe.com
