Operating Instructions
Blu-ray Disc™ Player
Model No.
DP-UB450
DP-UB159
DP-UB150
Firmware updates
Panasonic is constantly improving the unit’s rmware to ensure
that our customers are enjoying the latest technology.
Panasonic recommends updating your rmware as soon as you
are notied.
For details, refer to “Firmware updates” (
15) or
http://panasonic.jp/support/global/cs/ (This site is in English only.)
Thank you for purchasing this product.
Please read these instructions carefully before using this product, and save this manual for future use.
Model number sufx “EB” denotes UK model.
EB
TQBS0337
- 2 -
Precautions
WARNING
Unit
To reduce the risk of re, electric shock or product damage,
y
Do not expose this unit to rain, moisture, dripping or
splashing.
y
Do not place objects lled with liquids, such as vases, on
this unit.
y
Use the recommended accessories.
y
Do not remove covers.
y
Do not repair this unit by yourself. Refer servicing to
qualied service personnel.
y
Do not let metal objects fall inside this unit.
y
Do not place heavy items on this unit.
AC adaptor
T
o reduce the risk of re, electric shock or product damage,
y
Ensure that the power supply voltage corresponds to the
voltage printed on this unit.
y
Insert the mains plug fully into the socket outlet.
y
Do not pull, bend, or place heavy items on the lead.
y
Do not handle the plug with wet hands.
y
Hold onto the mains plug body when disconnecting the
plug.
y
Do not use a damaged mains plug or socket outlet.
The mains plug is the disconnecting device.
Install this unit so that the mains plug can be unplugged from
the socket outlet immediately
.
Small object
Keep the batteries out of reach of children to prevent
swallowing.
CAUTION
Unit
y
This unit utilizes a laser
. Use of controls or adjustments
or performance of procedures other than those specied
herein may result in hazardous radiation exposure.
y
Do not place sources of naked ames, such as lighted
candles, on this unit.
y
This unit may receive radio interference caused by mobile
telephones during use. If such interference occurs, please
increase separation between this unit and the mobile
telephone.
y
This unit is intended for use in moderate climates.
y
Some portions of this unit may become hot during use.
When moving or cleaning this unit, disconnect the
AC
mains lead and wait for 3 minutes or longer.
Placement
Place this unit on an even surface.
To reduce the risk of re, electric shock or product damage,
y
Do not install or place this unit in a bookcase, built-in
cabinet or in another conned space. Ensure this unit is
well ventilated.
y
Do not obstruct this unit’
s ventilation openings with
newspapers, tablecloths, curtains, and similar items.
y
Do not place the unit on ampliers/receivers or equipment
that may become hot.
The heat can damage the unit.
y
Do not expose this unit to direct sunlight, high
temperatures, high humidity
, and excessive vibration.
Batteries
Mishandling of batteries can cause electrolyte leakage and
may cause a re.
y
Danger of explosion if battery is incorrectly replaced.
Replace only with the type recommended by the
manufacturer
.
y
When disposing of the batteries, please contact your local
authorities or dealer and ask for the correct method of
disposal.
y
Do not mix old and new batteries or dif
ferent types at the
same time.
y
Do not heat or expose to ame.
y
Do not leave the battery(ies) in a car exposed to direct
sunlight for a long period of time with doors and windows
closed.
y
Do not take apart or short circuit.
y
Do not recharge alkaline or manganese batteries.
y
Do not use batteries if the covering has been peeled of
f.
Remove batteries if you do not intend to use the remote
control for a long period of time. Store in a cool, dark place.
AC adaptor
The AC adaptor operates on AC between 110 V and 240 V.
But obtain a suitable plug adaptor if the plug does not t the
AC mains socket.
- 3 -
Restriction on use of
unauthorized copied content
This unit adopts the following technology for copyright
protection.
Cinavia Notice
This product uses Cinavia technology to limit the use of
unauthorized copies of some commercially-produced lm and
videos and their soundtracks. When a prohibited use of an
unauthorized copy is detected, a message will be displayed
and playback or copying will be interrupted.
More information about Cinavia technology is provided at the
Cinavia Online Consumer Information Center at
http://www.cinavia.com. To request additional information
about Cinavia by mail, send a postcard with your mailing
address to:
Cinavia Consumer Information Center, P.O. Box 86851, San
Diego, CA, 92138, USA.
To dispose or transfer this
unit
The unit may keep the user settings information in the unit. If
you discard this unit either by disposal or transfer, then follow
the procedure to return all the settings to the factory presets
to delete the user settings. (
28, “To return all settings to
the factory preset.”)
y
The operation history may be recorded in the memory of
this unit.
Disposal of Old Equipment and Batteries
Only for European Union and countries with
recycling systems
These symbols on the products, packaging, and/
or accompanying documents mean that used
electrical and electronic products and batteries
must not be mixed with general household waste.
For proper treatment, recovery and recycling
of old products and used batteries, please take
them to applicable collection points in accordance
with your national legislation.
By disposing of them correctly, you will help
to save valuable resources and prevent any
potential negative effects on human health and
the environment.
For more information about collection and
recycling, please contact your local municipality.
Penalties may be applicable for incorrect disposal
of this waste, in accordance with national
legislation.
Note for the battery symbol (bottom
symbol):
This symbol might be used in combination with a
chemical symbol. In this case it complies with the
requirement set by the Directive for the chemical
involved.
- 4 -
Table of contents
To enjoy Ultra HD Blu-ray Disc featured with
High Dynamic Range (HDR)
If you see a message about High Dynamic
Range (HDR) compatible issue while an Ultra
HD Blu-ray Disc is played back, please check
your TV settings as follows.
An example of the message:
“This player is not connected to a High Dynamic
Range (HDR) compatible TV.”
1)
When you use a Panasonic
TV that is
compatible with 4K/High Dynamic Range
(HDR) and was released in 2015 or later,
enable the HDR setting of the TV. (This
setting may not be available depending on
the TV. Refer to the operating instructions of
the TV for details.)
2) If you use a TV not from Panasonic,
compatible with 4K and High Dynamic
Range (HDR), please refer to the operating
instructions of the TV.
3)
W
hen you play a High Dynamic Range (HDR)
disc on a TV without High Dynamic Range
(HDR) capability, the disc can be played back
(in non-HDR quality) even if the message
appears.
Precautions.................. 2
Getting Started
Accessories .................
5
Unit and media care ........... 5
Playable media............... 6
Control reference guide
........
8
Connecting to a
TV
........... 10
Connecting to an amplier/
receiver
....................11
Connecting to the network ..... 13
Settings.................... 14
Playback
HOME menu
................ 16
Playback................... 16
Home Network feature . . . . . . . . 19
“HDMI CEC” ................ 20
Option menu................ 21
Reference
Setup menu
................
23
T
roubleshooting guide ........
28
Specications ............... 33
Licenses ................... 36
PRIVACY POLICY (excerpt)
Panasonic Corporation, a company having its registered ofce of 1006, Oaza Kadoma, Kadoma City, Osaka 571-8501, Japan,
automatically collects personal data such as IP address and/or Device ID from your device as soon as you connect it to the
Internet. We do this to protect our customers and the integrity of our Service as well as to protect the rights or property of
Panasonic.
You have a right of access, rectication and objection to in certain circumstances, a right of erasure, restriction of processing,
data portability and a right to object to other forms of processing. If you wish to exercise any of the above rights and/or wish to
know more about the processing of your personal data in this context, please refer to the full text of our privacy policy displayed
at the support page of your device, http://av.jpn.support.panasonic.com/support/global/cs/bd/privacy/ or contact our customer
communications/support number or address described in the Pan European Guarantee included in your device box to send
you the full text of our privacy policy.
- 5 -
Getting Started
Accessories
Check the supplied accessories before using this
unit.
1 Remote control
(N2QAYA000205)
2 Batteries for remote control
1 AC adaptor
(TXH0009DA)
y
Product numbers are provided in these operating
instructions correct as of February 2019.
These may be subject to change.
y
Do not use
AC adaptor with other equipment.
y
Do not use any other
AC adaptors except the supplied one.
Using the remote control
Insert the batteries to the terminal so that it (+ and
‒) matches those in the remote control.
1
2
R03/LR03, AAA
3
(Alkaline or manganese batteries)
Point it at the remote control signal sensor on this
unit. (
9)
Unit and media care
Clean this unit with a soft, dry
cloth
y
Never use alcohol, paint thinner or benzine to
clean this unit.
y
Before using chemically treated cloth, carefully
read the instructions that came with the cloth.
This unit’s lens
Use the lens cleaner (not supplied) to clean the
unit’s lens.
Clean discs
DO
DO NOT
Wipe with a damp cloth and then wipe dry with a
dry cloth.
Disc handling precautions
y
Handle discs by the edges to avoid inadvertent
scratches or ngerprints on the disc.
y
Do not attach labels or stickers to discs.
y
Do not use disc cleaning sprays, benzine,
thinner
, static electricity prevention liquids or
any other solvent.
y
Do not use the following discs:
– Discs with exposed adhesive from removed
stickers or labels (rented discs, etc.).
– Discs that are badly warped or cracked.
– Irregularly shaped discs, such as heart
shapes.
Getting Started
- 6 -
Getting Started
Playable media
Device Media markings Device types Contents format
BD
DVD
CD
USB
Ultra HD Blu-ray
*1*2
Video
BD-Video Video
BD-RE
BD-RE DL
Video,
MKV, MP4, MPEG2,
JPEG, MPO,
AAC, AIFF, ALAC,
DSD (DFF, DSF),
FLAC, MP3, WAV,
WMA
BD-R
BD-R DL
BD
DVD
CD
USB
DVD-Video Video
DVD-R
Video, AVCHD,
MKV, MP4, MPEG2,
JPEG, MPO,
AAC, AIFF, ALAC,
DSD (DFF, DSF),
FLAC, MP3, WAV,
WMA
DVD-R DL
DVD-RW
Video, AVCHD
— +R/+RW/+R DL
BD
DVD
CD
USB
Music CD Music [CD-DA]
—
CD-R
CD-RW
MKV, MP4, MPEG2,
JPEG, MPO,
AAC, AIFF, ALAC,
FLAC, MP3,
Music [CD-DA], WAV,
WMA
BD
DVD
CD
USB
—
USB devices
(up to 4 TB)
AVCHD, AVCHD 3D,
MKV, MP4, MPEG2,
JPEG, MPO,
AAC, AIFF, ALAC,
DSD (DFF, DSF),
FLAC, MP3, WAV,
WMA
y
See pages 7 and 33 for more information on the types of content
that can be played.
*1 See “Enjoying Ultra HD Blu-ray” (
18)
*2
Unless otherwise indicated, BD-V
ideo content includes Ultra HD Blu-ray content in these operating instructions.
- 7 -
Getting Started
Types of discs that cannot be
played by this unit
Any other disc that is not specically
supported or previously described.
y
DVD-RAM
y
Super
Audio CD
y
Photo CD
y
DVD-Audio
y
V
ideo CD and Super Video CD
y
HD DVD
Region management information
The unit can play back BD-Video/DVD-Video
discs of the following regions codes, including
“ALL”:
Example: BD-Video DVD-Video
2
Finalize
Any DVD-R/RW/R DL, +R/+RW/+R DL and CD-R/
RW that are recorded by a recorder need to be
nalized by the recorder to play on this unit.
Please refer to the recorder’s instructions.
BD-Video
y
This unit supports high bit rate audio (Dolby
®
Digital Plus, Dolby
®
TrueHD, DTS-HD
®
High
Resolution Audio and DTS-HD
®
Master Audio)
adopted in BD-Video.
y
UB150
If “Dolby Audio” is set to “PCM” and “DTS
Neo:6” is set to “Off”, the maximum possible
number of Dolby
®
sound is 2 ch PCM. (
24)
3D
3D videos and 3D still pictures can be played back
when this unit is connected to a 3D compatible TV
using a High Speed HDMI Cable.
Music CD
Operation and sound quality of CDs that do not
comply with CD-DA specications (copy control
CDs, etc.) cannot be guaranteed to work.
USB device
y
Connect a USB device while the Home screen
is displayed.
y
This unit does not guarantee connection with all
USB devices.
y
This
unit does not support USB device charging.
y
F
AT12, FAT16, FAT32, and NTFS le systems
are supported.
y
This unit supports USB 2.0 High Speed.
y
This unit supports an HDD formatted in F
AT32
and NTFS. If the HDD is not recognized, the
power to the HDD may not be supplied. Supply
power from an external source.
BD-RE, BD-R
This unit may not correctly play back the audio
portion of a video recorded to a disc in multiple
languages with a Blu-ray disc recorder.
y
It may not be possible to play the above media in some
cases due to the type of media, the condition of the
recording, the recording method, and how the les were
created.
y
The producers of the disc can control how discs are played,
so you may not always be able to control play as described
in these operating instructions. Read the disc’s instructions
carefully.
- 8 -
Getting Started
Control reference guide
Remote control
1
2
3
7
5
6
9
8
4
13
11
12
10
1 Turn the unit on and off
2 Select title numbers, etc./Enter numbers
3 Cancel
4 Show Top menu/Pop-up menu (
17)
5 [
, , , ] : Move the highlight for
selection
[OK] : Conrm the selection
( ) : Frame-by-frame (
17)
6 Show Option menu (
21)
7 Basic playback control buttons (
16)
8 Show the status messages (
17)
9 Coloured buttons (red, green, yellow, blue)
Used for various purposes depending on the
screen
10 Transmit the remote control signal
11 Open or close the disc tray (
9)
12 Show HOME menu (
16)
13 Return to previous screen
Available keys for HDMI CEC
(
20)
2 Number keys
5 [ , , , ]/[OK] button
6 Option button
7 Basic playback control buttons
9 Coloured buttons (red, green, yellow, blue)
13 Return button
y
When other Panasonic devices respond to this remote
control, change the remote control code of other Panasonic
devices to other than code 1.
- 9 -
Getting Started
Front
1
3 42
5
6
5
6
1 Disc tray
2
USB port (
=
DC 5 V 500 mA)
This port supports USB 2.0 High Speed.
3
Remote control signal sensor
Distance: Within approx. 7 m
Angle: Approx. 20° up and down, 30° left and
right
4
POWER LED
The LED lights up when the unit is turned on,
and ashes when error occurs. (
32)
5 Open or close the disc tray
6 Standby/on switch (
v
/
b
) (
14)
Press to switch the unit from on to standby
mode or vice versa. In standby mode, the unit
is still consuming a small amount of power.
CAUTION
Do not place objects in front of the unit. The disc tray may collide with objects when it is opened, and
this may cause malfunction.
y
When inserting a media item, ensure that it is facing the corre
ct way, which is the right side facing up.
y
If you connect a Panasonic product with a USB connection cable,
the setup screen may be displayed on the connected
equipment. For details, refer to the instructions for the connected equipment.
Rear
3 4 51 2 1 2 6
UB450
UB159 UB150
1 DC IN (12 V) terminal (
10)
2 LAN port (
13)
3
UB450
UB159
HDMI VIDEO OUT terminal (
11)
4
UB450
UB159
HDMI AUDIO OUT terminal (
11)
(Outputs digital audio signal only)
5
UB450
UB159
DIGITAL AUDIO OUT terminal
(COAXIAL terminal) (
11)
6
UB150
HDMI AV OUT terminal (
10)
The symbols on this product (including the accessories)
represent the following.
AC
DC
Class II equipment (The construction of the product
is double-insulated.)
- 10 -
Getting Started
Connecting to a TV
4K images can be played back when this unit is connected to 4K compatible TV.
y
Before making any connections, please disconnect all the units
from AC power.
(Connect the AC adaptor after making all connections.)
y
Use the High Speed HDMI cables. Non-HDMI-compliant cables canno
t be utilized.
y
This unit consumes a small amount of
AC power (
33) even when turned off in standby mode.
For
the purpose of energy conservation, the unit should be disconnected if you will not be using it
for extended period of time.
y
The unit is in the standby condition when the
AC adaptor is connected. The primary circuit is always
“live” as long as the AC adaptor is connected to an electrical outlet.
Enjoying 4K output
y
T
o enjoy images in 4K (50p/60p), you need an HDMI cable that supports 18 Gbps.
When outputting 1080p or 24p (4K) signal, please use HDMI cables 5.0 meters or less.
It is recommended that you use Panasonic’s HDMI cable.
y
If you connect this unit to a 4K-compatible TV and perform “Easy Settings”, 4K (50p/60p) will
be automatically selected. (
14, 27)
y
T
o view Ultra HD Blu-ray content in 4K/HDR format, connect to the HDMI terminal of a device that
supports HDCP2.2, 4K (50p/60p) 4:4:4, and HDR signals that meet Ultra HD Blu-ray standards.
Enjoying video and audio with a 4K-compatible TV
HDMI IN
HDMI Cable
(18 Gbps)
To a household mains socket
AC adaptor
(supplied)
UB150
UB450
UB159
Setting
Set the following item in the setup menu (
23):
y
Set “HDMI(VIDEO) Output Mode” to “Automatic ( V
ideo Only / Video+Audio )”. (
23)
- 11 -
Getting Started
Connecting to an amplier/receiver
UB450
UB159
Enjoying video with a 4K-compatible TV and audio with an amplier
You can enjoy richer sound by using the HDMI AUDIO OUT terminal.
(Audio is output in high resolution.)
HDMI INHDMI IN
HDMI Cable
(18 Gbps)
HDMI Cable
Amplier/receiver
Setting
Set the following items in the setup menu (
23):
y
Set “HDMI(VIDEO) Output Mode” to “Automatic ( V
ideo Only / Video+Audio )”. (
23)
y
T
o enjoy audio with a TV
Set “HDMI(VIDEO) Output Mode” to “Video+Audio”. (
23)
y
The HDMI
AUDIO OUT terminal is not compatible with video signals and the HDMI CEC function (
20).
Enjoying video with a 4K-compatible TV and audio with a 4K-compatible amplier
HDMI IN
(ARC)
HDMI OUT
(ARC)
HDMI IN
HDMI Cable
(18 Gbps)
Amplier/receiver
(4K-compatible)
HDMI Cable
(18 Gbps)
UB150
UB450
UB159
Setting
Set the following item in the setup menu (
23):
y
Set “HDMI(VIDEO) Output Mode” to “Automatic ( V
ideo Only / Video+Audio )”. (
23)
y
About ARC:
When using the
TV or amplier/receiver that does not have the indication of “(ARC)” (non-ARC-compatible) on the HDMI
terminal, the amplier/receiver and TV must also be connected using an optical digital cable or coaxial cable in order to enjoy
the TV’s sound through the amplier/receiver.
UB450
UB159
Enjoying audio with an amplier connected to the COAXIAL terminal
COAXIAL IN
Amplier/receiver
Coaxial Cable
Setting
Set the following items in the setup menu (
23):
y
Set “HDMI(VIDEO) Output Mode” to “Automatic ( V
ideo Only / Video+Audio )”. (
23)
y
Set “HDMI
Audio Output” to “Off” in “Digital Audio Output”. (
24)
- 12 -
Getting Started
Connecting an amplier to a 4K-compatible TV
3D or 4K images can be played back when this unit is connected to a 3D or 4K compatible TV.
y
This connection only supports up to 5.1ch.
y
To connect a TV and amplier with an HDMI cable, connecting terminals on both the TV and amplier
must be ARC-compatible. (
11, “About ARC”)
HDMI OUT
(ARC)
HDMI IN
(ARC)
HDMI IN
HDMI Cable (18 Gbps)
HDMI Cable
Amplier/receiver
UB150
UB450
UB159
Setting
Set the following item in the setup menu (
23):
y
Set “HDMI(VIDEO) Output Mode” to “Automatic ( V
ideo Only / Video+Audio )”. (
23)
UB450
UB159
Enjoying video with a 4K-compatible TV in combination with an amplier connected
to the HDMI AUDIO OUT terminal and another amplier connected to the COAXIAL terminal
HDMI INHDMI IN
COAXIAL IN
HDMI Cable
(18 Gbps)
HDMI Cable
Amplier/receiver
Amplier/receiver
Coaxial Cable
Setting
Set the following items in the setup menu (
23):
y
Set “HDMI(VIDEO) Output Mode” to “Automatic ( V
ideo Only / Video+Audio )”. (
23)
y
To enjoy audio with an amplier connected to the COAXIAL terminal
Set “HDMI Audio Output” to “Off” in “Digital Audio Output”. (
24)
y
T
o enjoy audio with a TV
Set “HDMI(VIDEO) Output Mode” to “Video+Audio”. (
23)
- 13 -
Getting Started
Connecting to the network
The following services can be used when this unit is connected to broadband.
y
Firmware can be updated (
15)
y
Y
ou can enjoy BD-Live (
18)
y
UB450
You can access other devices (Home Network) (
19)
For details about connection method, refer to the instructions supplied with the connected equipment.
LAN cable connection
Broadband router, etc.
LAN Cable
Internet
y
Use category 5e or above straight LAN cables (STP) when connecting to peripheral devices.
y
Inserting any cable other than a LAN cable in the LAN port can damage the unit.
- 14 -
Getting Started
Settings
The following settings can be performed anytime
in the Setup menu. (
26, 27)
Easy Settings
After connecting your new player for the rst time
and pressing [
v
], the basic settings screen will
appear.
Preparation
Turn on the TV and select the appropriate
video input.
1
Press [v].
Setup screen appears.
2
Follow the on-screen instructions to
continue with the settings.
(e.g., “Quick Start”)
When connected to a 4K (50p or
60p)-compatible TV
When connected to a 4K (50p or 60p)-compatible
TV, you can set the video output format.
4K(50p/60p) Output
Start
Start connection check with your 4K TV.
Once connection check is started and if the video is not
displayed correctly, please wait for the next display.
The connection check could take up to 30 seconds to display
the new message screen.
OK
RETURN
Follow the on-screen instructions to set the
format.
y
T
o reconnect this unit to a 4K (50p or 60p)-compatible
TV after connecting this unit to a 2K-compatible TV and
completing “Easy Settings”, set “4K(50p/60p) Output” to
“4K(50p/60p) 4:4:4” or “4K(50p/60p) 4:2:0”. (
23)
Easy Network Setting
After completing “Easy Settings”, you can perform
“Easy Network Setting”.
Follow the on-screen instructions to establish
your connection settings.
In your use of internet functions
Your use of internet-enabled functions and
software updates must follow the rules set
forth in the “Terms and Conditions of Use”.
Please review “Terms and Conditions of Use”
and “Privacy Policy” carefully and conrm
your understanding of “Privacy Policy” and
agreement to the “Terms and Conditions of Use”
by checking the box and select “OK”.
(
26, “Legal Notices”)
y
Refer to the operating instructions of the hub or router
.
y
If you have trouble getting online on your PC after
performing network settings on this unit, perform the
network settings on your PC.
- 15 -
Getting Started
Firmware updates
This unit is capable of checking the rmware
automatically when connected to the Internet via
a broadband connection.
When a new rmware version is available, the
following message is displayed.
Firmware Update
Current Version: X.XX
New Version: X.XX
Do you want to start firmware update?
For the update information, please visit the
following website:
http://panasonic.jp/support/global/cs/
Yes No
OK
RETURN
*
Select “Yes” to start downloading the rmware.
You cannot operate the unit until the update is
complete. Don’t remove the AC adaptor during
the update. Removing the AC adaptor while the
update is in progress may damage the unit.
After the rmware is installed, unit will restart and
the following screen will be displayed.
The firmware has been updated.
Current Version
:
x.xx
RETURN
*
y
Y
ou can also download the latest rmware from the
following website and store it to a USB device to
update the rmware.
http://panasonic.jp/support/global/cs/
(This site is in English only.)
When the update is complete, turn off and on the unit.
y
T
o show the rmware version on this unit.
(
27, “Firmware Version Information”)
y
Downloading will require several minutes. It may take
longer or may not work properly depending on the
connection environment.
* “X.XX” represents the rmware version number
.
- 16 -
Playback
HOME menu
Major functions of this unit can be operated from
the HOME menu.
Preparation
Turn on the TV and select the appropriate video
input.
1
Press [v] to turn on the unit.
2
Press [OK] or [ , ] to select the item.
y
Press [OK] or [
, ] to select the item if
necessary.
UB450
Ultra HD Blu-ray Player
Videos Music Photos
Home
Network
Setup
Videos/Music/Photos
Disc
Play back the contents.
(
right)
y
When multiple contents
are recorded, select the
types of contents or the
title.
y
See “Playable media”
(
6)
USB
UB450
Home Network
Network Contents
Playback
(
19)
Media Renderer (
20)
Setup
Player Settings (
23)
Wallpaper
Changes the background
of HOME menu.
USB Management (
18)
To show the HOME menu
Press [HOME].
y
Items to be displayed may vary with the media.
Playback
1
Insert the media.
Playback starts depending on the media.
2
Select the item to play and press [OK].
Repeat this step if necessary.
y
DISCS CONTINUE
TO ROTATE WHILE MENUS ARE
DISPLAYED. Press [ ] when you have nished playback
to protect the unit’s motor, your TV screen and so on.
y
When the following conditions are met, still pictures are
played back in 4K regardless of the image quality
.
– The unit is connected to a 4K compatible TV
– “Video Format” is set to “Automatic” or “4K”
(
23)
y
This unit can not output 4K images when playing back in
3D.
y
It is not possible to play back
AVCHD and MPEG2 videos
which have been dragged and dropped or copied and
pasted to the media.
y
T
o enjoy BD-Video that supports Dolby Atmos
®
or DTS:X
®
(
24)
Operations during playback
Some operations may not work depending on the
media and contents.
Stop
Press [ ].
The stopping point is memorized.
Resume play function
Press [
] to restart from this point.
y
The point is cleared if the media is removed.
y
On BD-V
ideo discs including BD-J, the
resume play function does not work.
Pause
Press [ ].
y
Press [
] again or [ ] to restart play.
Playback
- 17 -
Playback
Search/Slow motion
Search
While playing, press [ ] or [ ].
y
Ultra HD Blu-ray
, MKV, MP4 and MPEG2:
Audio is not heard.
Slow motion
While paused, press [
].
y
MKV
, MP4 and MPEG2: Not effective.
The speed increases up to 5 steps.
y
Music, MP3, etc.:
The speed is xed to a single
step.
y
Press [
] to revert to normal playback speed.
Skip
While playing or paused, press [ ] or [ ].
Skip to the title, chapter or track.
Frame-by-frame
While paused, press [ ] ( ).
y
Each press shows the next frame.
y
Press and hold to change in succession
forward.
y
Press [
] to revert to normal playback speed.
y
MKV
, MP4 and MPEG2: Not effective.
Show top menu/pop-up menu
Press [TOP MENU/POP-UP MENU].
Select the item and press [OK].
Show the status messages
While playing, press [STATUS].
The status messages give you information about
what is currently being played. Each time you
press [STATUS], the display information may
change or disappear from the screen.
y
Depending on media and contents, the display
may change or not appear
.
e.g., Ultra HD Blu-ray
Play
4K
Ultra HD Blu-ray
B
A
T1 C1
D
HDR (High Dynamic Range)
E
F
A
Displayed when an HDR (High Dynamic
Range) video signal is being output.
–
“Dynamic Range Conversion Output” : The
video signal is converted to SDR (Standard
Dynamic Range)
B
T: Title, P: Programme, C: Chapter
C
Elapsed time in the title
D
Method of HDR (High Dynamic Range) video
E
Current position
F
Total time
e.g., JPEG
Date 11.12.2010
Size 500 x 375
Manufacturer
Equipment
e.g., JPEG
- 18 -
Playback
Enjoying Ultra HD Blu-ray
You can enjoy the playback of Ultra HD Blu-ray
discs with this unit.
Preparation
y
For 4K/HDR viewing, connect to a device and
terminals that support HDCP2.2
*
1
, 4K (50p/60p)
4:4:4 and HDR signals that meet Ultra HD Blu-
ray standards. (
10)
Due to copyright restrictions, it may not be
possible to play back certain discs unless this
unit is connected to the Internet.
y
When connected to a device or terminal that does not
support HDCP2.2
*
1
, this unit applies Dynamic Range
Conversion
*
2
to HDR signals to output them in 2K
resolution. In addition, depending on the disc, it may not be
possible to perform playback correctly.
y
When connected to a device or terminal that supports
4K (50p/60p) 4:2:0 (8 bit) and lower
, this unit plays back
50p/60p content by applying Dynamic Range Conversion
*
2
to its HDR signals to output them.
y
When connected to a device or terminal that does not
support 4K resolution, this unit applies Dynamic Range
Conversion
*
2
to HDR signals to output them in 2K
resolution.
y
When connected to a device or terminal that does
not support HDR, this unit applies Dynamic Range
Conversion
*
2
to HDR signals to output them. In addition,
depending on the disc, it may not be possible to output
content in 2K resolution or perform playback correctly.
*1
HDCP
is a technology designed to prevent illegal copying.
“2.2” represents a version.
*2
Dynamic Range Conversion is a function that converts
HDR video signals into video signals suited to
TVs that do
not support HDR input.
Enjoying 3D video and photos
Preparation
Connect this unit to a 3D compatible TV. (
10)
y
Perform the necessary preparations for the
TV.
y
Play back following the instructions displayed
on the screen.
y
3D Settings (
22, 25)
y
Please refrain from viewing 3D images if you do not feel
well or are experiencing visual fatigue.
In the event that you experience dizziness, nausea, or
other discomfort while viewing 3D images, discontinue use
and rest your eyes.
y
3D video might not output the way it is set in “V
ideo
Format” and “24p Output” (
23).
y
When playing back 3D photos from “Photos” screen, select
from the “3D” list. (Still pictures in “2D” are played back in
2D.)
If “2D” and “3D” indications are not displayed, press the red
button on the remote control to switch the view of playback
contents.
Enjoying BD-Live
With “BD-Live” discs, you can enjoy bonus
contents that use Internet access.
For this BD-Live function, connection of a
USB device is necessary along with Internet
connection.
1
Perform network connection and settings.
( 13, 14)
2
Connect a USB device with 1 GB or more
free space.
y
The USB device is used as the local
storage.
3
Insert the disc.
Deleting data on the USB device
Select “USB Management” in the HOME menu
(
16), then select “BD-Video Data Erase”
and press [OK].
y
The usable functions and the operating method may vary
with each disc, please refer to the instructions on the disc
and/or visit their website.
y
“BD-Live Internet
Access” may need to be changed for
certain discs. (
26)
- 19 -
Playback
Slideshow
Play a slideshow of photos and adjust various
settings during the playback.
1
Insert the media.
2
Select “View Photos”.
3
Select an item and press the green button.
The following items can be set.
Start
Slideshow
Start the slideshow.
You can display still pictures in
the selected folder one by one
at a constant interval.
Interval Change the display interval.
Transition
Effect
Select the effect when sliding
pictures.
Repeat Play
Set whether to repeat the
slideshow.
y
Still pictures displayed as “
” cannot be displayed as
thumbnail with this unit.
Home Network feature
UB450
Before using the following features, be sure to
congure the connected equipment on your Home
Network.
Playing back contents on the
Network Contents server
You can share photos, videos and music stored in
the Network Contents server
*
1
[PC, smartphone,
recorders, etc.] connected to your home network.
y
About support format of Network Contents
(
35)
Server
Player
y
When this unit is connected to a Panasonic
recorder with a server function, register this unit
to the recorder
.
1
Press [HOME].
2
Select “Home Network” and press [OK].
3
Select “Network Contents Playback” and
press [OK].
y
The list can be updated by pressing the red
button on the remote control.
4
Select the equipment and press [OK].
5
Select the item to play and press [OK].
y
Y
ou may be able to use convenient functions
depending on the content by pressing
[OPTION].
To exit from Network Contents Playback
screen
Press [HOME].
- 20 -
Playback
Using the Digital Media
Controller
You can use a smartphone or tablet as the Digital
Media Controller (DMC) to playback contents from
Network Contents server
*
1
on the Renderer (this
unit).
Possible applications:
*2
*2
*2
Renderer
Server
Controller
Server
+
Controller
Renderer
1
Press [HOME].
2
Select “Home Network” and press [OK].
3
Select “Media Renderer” and press [OK].
4
Operate the DMC compatible devices.
To exit from Media Renderer screen
Press [HOME].
y
Depending on the device or connection environment, the
data transfer rate may decrease.
y
Depending on the contents and the connected equipment,
playback may not be possible.
y
Items displayed in grey on the display cannot be played
back by this unit.
*1
DLNA
compatible server, etc.
*2
DMC compatible software should be installed.
“HDMI CEC”
This unit supports “HDMI CEC” (Consumer
Electronics Control) function.
You can use this function by connecting the
equipment that supports “HDMI CEC” with an
HDMI cable*.
See the operating instructions for connected
equipment for operational details.
y
UB450
UB159
Only when connecting via an
HDMI VIDEO OUT terminal on this unit.
Preparation
①
Set “HDMI CEC” to “On” (
27).
(The default setting is “On”.)
②
Set the “HDMI CEC” operations on the
connected equipment (e.g.,
TV).
③
Turn on all “HDMI CEC” compatible equipment
and select this unit’s input channel on the
connected TV so that the “HDMI CEC” function
works properly.
Repeat this procedure when the
connections or settings are changed.
Automatic input switching
Power on link
When the unit starts playback, the TV will
automatically switch the input channel and the
screen of the unit will be displayed.
Additionally when the TV is off, the TV will
automatically turn on.
Power off link
All connected equipment compatible with “HDMI
CEC”, including this unit, automatically turns off
when you switch the TV off.
Easy control only with TV
remote control
By using the TV remote control, you can perform
the same operations as you use the remote
control of this unit. (
8)
y
This unit supports the “HDMI CEC” (Consumer Electronics
Control) function. However
, operation cannot be
guaranteed on all HDMI CEC devices.
- 21 -
Playback
Option menu
A variety of playback operations and settings can
be performed from this menu.
Available options differ depending on the playing
contents and the condition of the unit.
1
Press [OPTION].
e.g., Ultra HD Blu-ray
Operation Menu
Zoom
Top Menu
Pop-up Menu
Secondary Video
Status
Primary Video
Repeat Play
Angle
Subtitle Settings
Soundtrack
Off
1
1HEVC
1 ENG Dolby TrueHD 3/...
2
Select an item and change the settings.
To exit the screen
Press [OPTION].
Regarding Language : (
35)
Operation Menu
Soundtrack
Show or change the soundtrack.
Audio channel
Select the audio channel number
.
Subtitles
Subtitle Settings
Change the subtitle settings.
Angle
Select the number of the angle.
Repeat Play
Select the item that you want to repeat.
y
Y
ou can repeat the playback of a chapter,
playlist, the entire disc, etc., but the items
displayed will differ depending on the type of the
media.
y
Select “Of
f” to cancel.
Shufe
Select whether to play shufe or not.
Start Slideshow
Start the slideshow
.
Status
Show the status messages.
Rotate RIGHT
Rotate LEFT
Rotate the still picture.
W
allpaper
Set the still picture to the wallpaper of HOME
menu. (
16)
V
ideo
The recording method of original video appears.
Primary V
ideo
The recording method of original primary video
appears.
Secondary V
ideo
Video
Select on/off for images. The
recording method of original
video appears.
y
During search/slow motion,
only the primary video is
displayed.
Soundtrack
Select on/of
f for audio and the
language.
Zoom
Videos and pictures are magnied.
y
On BD-V
ideo discs including BD-J, the zoom
function does not work.
T
op Menu
Display Top Menu.
Pop-up Menu
Display Pop-up Menu.
Menu
Display Menu.
- 22 -
Playback
Picture Settings
Dynamic Range Conversion
Adjustment
When this unit is connected to a TV that does not
support HDR (High Dynamic Range) input, HDR
video is output converting to a SDR (Standard
Dynamic Range) video signal. If you set a smaller
value, their contrast will be reproduced more
faithfully, but the entire screen will appear darker.
To increase the brightness, set a larger value.
Picture Mode
Select the picture quality mode during play
.
y
If you select “User”, you can change settings in
“Picture
Adjustment”.
Picture Adjustment
Specic picture quality settings can be changed.
Progressive
Select the method of conversion for progressive
output to suit the type of material being played.
y
If the video is disrupted when “Auto” is selected,
select either “V
ideo” or “Film” depending on the
material to be played back.
Reset to Default Picture Settings
Return picture settings to the factory defaults.
3D Settings
Signal Format
Original Keep original picture format.
Side by side
3D picture format comprising of
left and right screens.
Graphic Display Level
3D position for the Option menu or message
screen, etc. can be adjusted during 3D playback.
- 23 -
Reference
Setup menu
Change the unit’s settings if necessary. The
settings remain intact even if you switch the unit
to standby.
1
Press [HOME].
2
Select “Setup”.
3
Select “Player Settings”.
UB450
OK
RETURN
Player Settings
System
Ratings
Network
Language
3D
Sound
Video Format
Automatic
4K(50p/60p) Output
Off
24p Output
Automatic
HDMI(VIDEO) Output Mode
Automatic
Dolby Vision Setting
Off
HDR10+ Setting
On
Advanced Settings
4
Select an item and change the settings.
To exit the screen
Press [HOME].
V
ideo Format
The items supported by the connected devices
are indicated on the screen as “
∗
”. When any
item without “
∗
” is selected, the images may be
distorted.
y
If “Automatic”
*
1
is selected, the best suited
output resolution to the connected TV is
automatically selected.
4K(50p/60p) Output
This unit automatically chooses to output images
in 4K
*
2
(50p/60p) when connected to a 4K (50p or
60p) compatible TV.
y
This item is available only when “V
ideo Format”
is set to “Automatic” and “4K”.
y
T
o connect to a TV that supports 4K (50p/60p)
4:4:4/8 bit or 4K (50p/60p) 4:2:2/12 bit, select
“4K(50p/60p) 4:4:4”.
Images will not be output correctly with an HDMI
cable that does not support 18 Gbps.
y
T
o connect to a TV that supports 4K (50p/60p)
4:2:0/8 bit, select “4K(50p/60p) 4:2:0”.
24p Output
Content recorded at 24p
*
3
, such as BD-Video
lms, is output at 24p when played back.
y
When this unit is connected to
TV compatible
with 4K/24p and “Video Format” is set to
“Automatic” or “4K”, images will be output in
4K/24p.
y
When this unit is connected to a
TV compatible
with 1080/24p and “Video Format” is set to
“Automatic”, “1080i” or “1080p”, images will be
output in 1080/24p.
y
If images output in 24p are distorted, change
the setting to “Of
f”.
UB450
UB159
HDMI(VIDEO) Output Mode
Set whether or not to output audio from the HDMI
VIDEO OUT
terminal.
y
When an amplier is connected to the HDMI
AUDIO OUT
terminal and this menu item is set
to “Automatic ( Video Only / Video+Audio )”, the
TV may not output audio. In that case, select
“Video+Audio”.
UB450
Dolby V
ision Setting
You can set enable/disable of the Dolby Vision
function.
By changing this setting to “On”, you can use
the Dolby Vision function under the following
conditions:
– A device (TV, etc.) that supports Dolby Vision is
connected (
10).
– A disc that supports Dolby Vision is played back.
y
The “Picture Settings” setting is disabled while
using the Dolby V
ision function. (
22)
y
If all the conditions below are met, both Dolby
V
ision and HDR10+ are enabled. In that case,
playback in HDR10+ format takes precedence.
– The playback media or content is recorded in
both Dolby Vision and HDR10+ formats.
– Both Dolby Vision and HDR10+ are supported
by the connected device (TV, etc.).
– Both this function and “HDR10+ Setting” are
set to “On”.
Reference
- 24 -
Reference
HDR10+ Setting
Y
ou can set enable/disable of the HDR10+
function.
By changing this setting to “On”, you can use the
HDR10+ function under the following conditions:
– A device (TV, etc.) that supports HDR10+ is
connected (
10).
– A disc that supports HDR10+ is played back.
y
The “Picture Settings” setting is disabled while
using the HDR10+ function. (
22)
Advanced Settings
Press [OK] to show the following settings:
Colour Mode
This setting is for selecting colour-space
conversion of the image signal.
Deep Colour Output
Set the output method to be used when this unit
is connected to a
TV that supports Deep Colour.
HDR/Colour Gamut Output
Set the output type for HDR (High Dynamic
Range) material.
Contents Type Flag
Depending on the playback content, the TV will
output adjusting to the optimal method when a
TV that supports this function is connected.
*1 It displays images at the highest resolution available on
your TV.
*2
A
high resolution image/display technology of
approximately 4000 (width) x 2000 (height) pixels.
*3
A
progressive image recorded at a rate of 24 frames
per second (motion-picture lm). Many BD-Video movie
contents are recorded in 24 frames/second in accordance
with the lm materials.
Sound
Dynamic Range Compression
Y
ou can listen at low volumes but still hear
dialogue clearly.
(Dolby Digital, Dolby Digital Plus and Dolby
TrueHD only)
y
“Automatic” is ef
fective only when playing Dolby
TrueHD.
Digital Audio
Output
Press [OK] to show the following settings:
Dolby Audio
DTS/DTS-HD
DSD Output Mode
Select the audio signal to output.
y
Select “PCM”, when the connected equipment
cannot decode the respective audio format.
This unit decodes the audio format and
transmits to the connected equipment.
y
If you do not make proper settings the audio
may be static or noisy
.
y
“DSD Output Mode” is ef
fective only when
connecting the unit with an HDMI cable.
y
When playing DSD 1
1.2 MHz format le
regardless of the settings for “DSD Output
Mode”, PCM signals are output from HDMI
terminal and
UB450
UB159
COAXIAL
terminal.
BD-Video Secondary Audio
Select whether or not to mix the primary and
secondary audio (including the button click
sound).
If “Off” is selected, the unit outputs the primary
audio only.
UB450
UB159
HDMI Audio Output
This setting selects whether or not to output
audio from HDMI.
y
T
o enjoy audio with the HDMI terminal, select
“On”. To enjoy audio with the COAXIAL
terminal, select “Off”. Audio will not be output
from the HDMI terminal regardless of the
settings for “HDMI(VIDEO) Output Mode”.
y
T
o enjoy BD-Video that supports Dolby Atmos
®
or
DTS:X
®
Connect this unit to an AV amplier or similar device that
supports it with an HDMI cable, and select the following
settings:
– Dolby Audio: “Bitstream”
– DTS/DTS-HD: “Bitstream”
– BD-Video Secondary Audio: “Off”
Dolby Atmos is a trademark of Dolby Laboratories.
- 25 -
Reference
UB450
UB159
COAXIAL
Down Sampling
Set the maximum sampling frequency to be used
when outputting down-sampled audio from the
COAXIAL terminal.
y
Set a frequency supported by the connected
device.
y
When playing back BD-V
ideo, signals are
converted to 48 kHz despite the settings in the
following cases:
– when the signals have a sampling frequency
of 192 kHz
– when the disc has copy protection
– when “BD-Video Secondary Audio” is set to
“On”
Downmix
Select the downmix system of multi-channel to
2-channel sound.
y
Select “Surround encoded”, when the connected
equipment supports the virtual surround
function.
y
T
he downmix effect is not available when “Digital
Audio Output” is set to “Bitstream”.
y
The audio will be output in “Stereo” in the
following cases:
–
AVCHD playback
– Playback of secondary audio (including the
button click sound).
DTS Neo:6
2ch (2.1ch) audio is expanded to 7ch (7.1ch).
y
This function works when the following
conditions are met:
– “DTS Neo:6” is e
ffective only when connecting
the unit with an HDMI cable.
– Audio recorded at 96 kHz or lower is output.
– “Digital Audio Output” is set to PCM when
audio other than “PCM” is output.
3D
3D BD-V
ideo Playback
Select the playback method of 3D compatible
video software.
3D A
VCHD Output
Select the output method of 3D AVCHD videos.
3D Playback Message
Set to display or hide the 3D viewing warning
screen when playing back the 3D compatible
video software.
Language
Soundtrack Preference
Choose the language for audio.
y
If “Original” is selected, the original language of
each disc will be selected.
y
When the selected language is not recorded on
the disc, or depending on how the navigation
is created on the disc, it may playback in a
dif
ferent language than the selected language.
y
Enter a code (
35) when you select “Other
****”.
Subtitle Preference
Choose the language for the subtitle.
y
When “Automatic” is selected, a subtitle for
the language selected in the “Soundtrack
Preference” is displayed only when the
language other than the language selected in
the “Soundtrack Preference” is played back.
y
When the selected language is not recorded on
the disc, or depending on how the navigation
is created on the disc, it may playback in a
dif
ferent language than the selected language.
y
Enter a code (
35) when you select “Other
****”.
Menu Preference
Choose the language for the disc menus.
y
Enter a code (
35) when you select “Other
****”.
Subtitle Text
Select a desired item according to the language
used for MKV subtitles text.
y
This item is displayed only after playing back a
le.
On-Screen Language
Choose the language for menus and on-screen
messages.
- 26 -
Reference
Network
Easy Network Setting (
14)
Network Settings
Perform network-related settings individually
.
Press [OK] to show the following settings:
IP Address / DNS Settings
This is for checking the state of the network
connection and setting the IP address and
DNS-related.
Press [OK] to show the respective setting.
Proxy Server Settings
This is for checking the state of connection with
the Proxy server and performing settings.
Press [OK] to show the respective setting.
UB450
Network Drive Connection
This unit can access a hard disk shared folder
on a network and play back videos, still pictures,
and music.
UB450
Remote Device Settings (
20)
Press [OK] to show the following settings:
Device Name Entry
Set the name of this unit to be displayed on
the connected equipment.
Registration Type
Automatic
Allow connections to all the
equipment accessing this
unit.
Manual
Set the permission for
individual equipment
connections accessing this
unit.
Remote Device List
Registering/deregistering of the displayed
equipment can be performed when “Manual” in
“Registration Type” is selected.
y
You can register up to 16 devices.
BD-Live Internet Access (
18)
You can restrict Internet access when BD-Live
functions are used.
y
If “Limit” is selected, Internet access is
permitted only for BD-Live contents which
have content owner certicates.
Legal Notices
Displays the terms of service for the cloud
services.
Displays the “T
erms and Conditions of Use /
Privacy Policy”.
Your use of internet-enabled functions and
software updates must follow the rules set forth
in the “Terms and Conditions of Use”. Please
review “Terms and Conditions of Use” and “Privacy
Policy” carefully and conrm your understanding
of “Privacy Policy” and agreement to the “Terms
and Conditions of Use” by checking the box and
select “OK”.
- 27 -
Reference
Ratings
The following items use the same password.
Don’t forget your password.
DVD-Video Ratings
Set a ratings level to limit DVD-Video play.
BD-V
ideo Ratings
Set an age limit of BD-Video (including Ultra HD
Blu-ray) play.
System
Easy Settings
Y
ou can execute basic settings.
TV Settings
Press [OK] to show the following settings:
TV System
Perform the setup so it matches the
TV System
of the connected TV.
Screen Saver Function
This is to prevent image retention on the screen.
y
When this is set to “On”:
If a list of playback content is displayed and
there is no operation for 5 minutes or more, the
screen switches to HOME menu automatically.
y
While playing and pausing, etc., this function is
not available.
On-Screen Messages
Choose whether to show status messages
automatically
.
HDMI CEC
Set to use “HDMI CEC” function when connected
via HDMI cable to a device that supports “HDMI
CEC”.
Select “Off” when you do not want to use “HDMI
CEC”.
Quick Start
Speed
of start-up from standby mode is increased.
y
When set to “On”, the internal control unit will
be powered.
The idle power consumption will
increase so compared to when set to “Off”.
Firmware Update (
15)
Press [OK] to show the following settings:
Automatic Update Check
When this equipment remains connected to
the Internet, it will check for the latest rmware
version when it is turned on and you can update
it if necessary.
Update Now
You can update the rmware manually if a
rmware update is available.
System Information
Press [OK] to show the following settings:
Software Licence
Information about the software used by this unit
is displayed.
Firmware Version Information
Display rmware version of this unit.
Default Settings
This returns all values in the Setup menu and
the Option menu to the default settings, except
for some settings of network, ratings, on-screen
language, etc.
- 28 -
Reference
Troubleshooting guide
Before requesting service, please perform the
following checks.
If the problem remains unresolved, consult
your dealer for instructions.
Do you have the latest rmware installed?
Panasonic is constantly improving the unit’s
rmware to ensure that our customers are
enjoying the latest technology. (
15)
The following do not indicate a problem with
this unit:
– Regular disc rotating sounds.
– Image disturbance during search.
– Image disturbance when replacing 3D discs.
Unit does not respond to remote
control or unit’s buttons.
Disconnect the AC adaptor, wait 1 minute, then
reconnect the AC adaptor.
Cannot eject disc.
①
While the unit is on
Press and hold [
] on the main unit and the
[0] on the remote control at the same time for
more than 5 seconds.
– POWER LED starts to ash, and “00 RET” is
displayed on the screen.
②
Press [
] (right) repeatedly on the remote
control until “06 FTO” is displayed on the
screen.
③
Press [OK].
General operation
To return to the factory default.
Select “Y
es” in “Default Settings” in the Setup
menu. (
27)
To return all settings to the factory preset.
Reset the unit as follows:
①
While the unit is on
Press and hold [
] on the main unit and the
[0] on the remote control at the same time for
more than 5 seconds.
– POWER LED starts to ash, and “00 RET” is
displayed on the screen.
②
Press [
] (right) repeatedly on the remote
control until “08 FIN” is displayed on the
screen.
③
Press and hold [OK] for more than 5 seconds.
The remote control doesn’t work properly.
Change the batteries in the remote control.
(
5)
Other Panasonic products respond to this
remote control.
Change the remote control code of other
Panasonic products to other than code 1.
This unit is turned off automatically
.
T
o save on electricity, this unit is turned off
automatically depending on the media if there
is no button operation for about 20 minutes
when not playing back (such as when paused
or displaying the menu, displaying still pictures,
etc.).
- 29 -
Reference
You have forgotten your ratings password.
You want to cancel the ratings level.
The ratings level returns to the factory defaults.
①
While the unit is on
Press and hold [
] on the main unit and the
[0] on the remote control at the same time for
more than 5 seconds.
– POWER LED starts to ash, and “00 RET” is
displayed on the screen.
②
Press [
] (right) repeatedly on the remote
control until “03 VL” is displayed on the screen.
③
Press [OK].
The TV screen turns black.
In the following cases, HDMI authentication
takes place and a black screen is displayed:
– When “24p Output” is set to “Automatic”.
–
When the display is switched between 2D
and 3D images.
–
When you quit the 4K playback by displaying
another screen, including the HOME menu.
This unit does not recognize the USB
connection correctly
.
Disconnect and re-connect the USB cable. If
it still does not recognize the connection, turn
this unit of
f and on again.
USB devices may not be recognized by this
unit when connected using the following :
– a USB hub
– a USB extension cable
If you connect USB HDD to this unit, use the
USB cable that is supplied with the HDD.
If the USB HDD is not recognized, the power
to the USB HDD may not be supplied. Supply
power from an external source.
Images from this unit do not appear on the TV
screen, or they are distorted.
An incorrect resolution is selected in “V
ideo
Format”. Reset the setting as follows:
The connected devices are changed. Reset
the setting as follows:
①
While the unit is on
Press and hold [
] on the main unit and the
[8] on the remote control at the same time for
more than 5 seconds.
②
Set the item again. (
23)
–
When Dolby Digital Plus, Dolby
TrueHD,
and DTS-HD
®
audio are not output properly,
select “Yes” in “Default Settings” (
27)
and make proper settings.
– “4K(50p/60p) Output” will be set to “Off”.
Make the correct setting again. (
23)
PAL discs cannot be correctly viewed on an
NTSC TV.
When “3D BD-Video Playback” in the Setup
menu is set to “Automatic”, images may not be
output depending on the connection method.
After removing the disc from this unit, select
“Set before play” in the Setup menu, and select
“2D Playback” in the setup screen displayed
when playing 3D discs. (
25)
When outputting in 4K, images may be
distorted depending on the HDMI cable. Use
an HDMI cable that supports 18 Gbps.
- 30 -
Reference
Video is not output in 4K or high-denition.
Conrm t
hat “Video Format” in the Setup menu
is set properly. (
23)
Conrm the HDMI cable, related connections
and the compatibility of
TV video input.
T
o output images in 4K, connect the HDMI
cable to a 4K compatible terminal of the
connected device. (
10)
T
o enjoy image in 4K (50p/60p) with the
connected 4K-compatible TV, set “4K(50p/60p)
Output” to “4K(50p/60p) 4:4:4” or “4K(50p/60p)
4:2:0”. (
23)
If “4K(50p/60p) Output” is set to “4K(50p/60p)
4:4:4”, check to see if the connected HDMI
cable supports 18 Gbps. (
10, 23)
When the unit is connected to a
TV that
supports formats up to 4K(50p/60p) 4:2:0 or
“4K(50p/60p) Output” is set to “4K(50p/60p)
4:2:0”, material recorded in 4K(50p/60p)
cannot be output in 4K/HDR.
To play back material recorded in 24p, set “24p
Output” to “Automatic”. (
23)
Cannot output video in HDR quality even when
connected to an HDR-compatible TV.
When connected to a device or terminal
that does not support HDR, this unit applies
Dynamic Range Conversion to HDR signals
to output them. In addition, depending on the
disc, it may not be possible to output content in
2K resolution or perform playback correctly.
(
18)
Video may not be output from your TV in HDR
quality, depending on the content.
Set “HDR/Colour Gamut Output” to “HDR/
BT.2020 (Auto)”. (
24)
3D video is not output.
Connect to a 3D compatible device (e.g.,
TV
and amplier/receiver).
When a non-3D compatible amplier/receiver
is connected between this unit and a
TV, 3D
video is not output. (
12)
Conrm the settings on this unit and the
TV for
3D. (
18)
3D video is not output correctly as 2D.
Select “Set before play” in the Setup menu,
and select “2D Playback” in the setup screen
displayed when playing 3D discs. (
25, “3D
BD-Video Playback”)
Discs that have recorded titles with Side by
side (2 screen structure) and that can be
enjoyed in 3D are played back in accordance
with the settings of the TV.
A black band is displayed around the edge of
the screen.
The aspect ratio of the screen is abnormal.
Adjust the aspect setting on the
TV.
The screen brightness changes automatically.
The screen brightness changes automatically
to suit the scene while using the HDR10+ and
UB450
Dolby Vision function.
- 31 -
Reference
Audio
Cannot switch audio.
The audio cannot switch, if “Digital
Audio
Output” is set to “Bitstream” or “On”*. Set
“Digital Audio Output” to “PCM” or “Off”*.
(
24)
* For “DSD Output Mode”
Cannot hear the desired audio.
Check the connections and the “Digital
Audio
Output” settings. (
11, 24)
UB450
UB159
To output audio from a device
connected with an HDMI cable, set “HDMI
Audio Output” to “On” in the Setup menu.
(
24)
UB450
UB159
When connecting this unit
to a TV via an HDMI VIDEO OUT and to an
amplier/receiver via an HDMI AUDIO OUT,
set “HDMI(VIDEO) Output Mode” to “Automatic
( Video Only / Video+Audio )”. (
11, 23)
There is no sound coming out.
UB450
UB159
To output audio using
COAXIAL terminal, set “COAXIAL Down
Sampling” properly. (
25)
Refer to “Connecting to an amplier/receiver”
(
11 - 12) to check the audio output
settings suited to the connections of your
device.
UB450
UB159
In the following cases, audio is
not output from the terminals listed below:
y
HDMI VIDEO OUT terminal
–
When a device is connected to the HDMI
AUDIO OUT terminal and “HDMI(VIDEO)
Output Mode” is set to “Automatic ( Video
Only / Video+Audio )” (
23)
– When “HDMI Audio Output” in “Digital Audio
Output” is set to “Off” (
24)
y
HDMI
AUDIO OUT terminal
– When “HDMI Audio Output” in “Digital Audio
Output” is set to “Off” (
24)
Playback
Disc cannot be played.
The disc is dirty
. (
5)
The disc is not nalized. (
7)
Depending on the Ultra HD Blu-ray disc, it may
not be p
ossible to perform playback unless this
unit is connected to the Internet.
Still pictures (JPEG) do not play back
normally.
The images that were edited on the PC, such
as Progressive JPEG, etc., may not be played
back.
I can’t play back BD-Live.
Conrm that this unit is connected to the
broadband Internet. (
13)
C
onrm the “BD-Live Internet Access” settings.
(
26)
Conrm a USB device is connected to the USB
port. (
9)
Network
I can’t connect to the network.
Conrm the network connection and settings.
(
13, 14, 26)
Check the operating instructions for each
device and connect accordingly
.
- 32 -
Reference
Messages on the screen
No compatible content on the disc.
Y
ou inserted an incompatible disc.
Cannot play this le.
You tried to play a non-compatible video.
This disc is incompatible.
Y
ou inserted an incompatible disc.
The disc may be upside down.
8
This operation cannot be performed now
.
Some operations (reverse slow motion, etc.)
are unsupported by the unit.
IP
address is not set.
The “IP
Address / DNS Settings”
“Advanced
Settings”
“IP Address” is “---. ---. ---. ---”. Set
the “IP Address”, “Subnet Mask”, and “Gateway
Address”. (Select the automatic address
acquisition if necessary.)
POWER LED
When the POWER LED is ashing other than
during power up or down of this unit, check the
message on the TV screen. If a message is not
displayed on the TV screen, determine the type of
the error by checking the way the POWER LED is
ashing.
Symbols indicate the following states:
Flash
No illumination
Repetition
(Flashes)
The copyright protected disc cannot be played
back.
One of the devices connected to this unit (TV,
amplier, etc.) does not support copyright
protection.
(Flashes 3 times)
The disc in use cannot be played back since
the copyright information is invalid.
- 33 -
Reference
Specications
General
Signal system PAL/NTSC
Operating temperature
range
+5 ºC to +35 ºC
Operating humidity
range
10 % to 80 % RH (no
condensation)
UB450
UB159
DIGITAL AUDIO OUT
(COAXIAL)
1 pc.
Output format : PCM, Dolby
Digital, DTS
®
HDMI OUT
(19 pin type A)
UB450
UB159
2 pcs.
UB150
1 pc.
Output Audio format : PCM,
Dolby Digital, Dolby Digital Plus,
Dolby TrueHD, DTS
®
, DTS-HD
®
High Resolution Audio,
DTS-HD
®
Master Audio
USB port (Type A) 1 pc.
DC 5 V, Max. 500 mA
[High-Speed USB (USB 2.0)]
LAN (Ethernet) Port 1 pc.
10BASE-T/100BASE-TX
LASER Specication Class 1 LASER Product Wave
length:
770-800 nm (CDs)/
650-666 nm (DVDs)/
400-410 nm (BDs)
Laser power: No hazardous
radiation is emitted with the
safety protection
Power supply DC 12 V, 1.5 A (DC IN terminal)
Power consumption
UB450
UB159
Approx. 13 W
UB150
Approx. 12 W
Power consumption in
standby mode
Approx. 0.3 W
(Quick Start: Off)
Dimensions (W x H x D)
Including the projecting
parts
UB450
UB159
320 mm x 46 mm x 198 mm
UB150
320 mm x 46 mm x 193 mm
Mass Approx. 1.2 k
g
y
Specications are subject to change without notice.
File format
File format Extension Reference
MKV
(Compression
methods
Video: H.264/HEVC
Audio:AAC, PCM,
Vorbis, FLAC,
Dolby Digital,
DTS
®
)
“.MKV”,
“.mkv”
y
Resolution up to
3840x2160 25p/30p,
4096x2160 24p.
y
The video le and
subtitles text le are
inside the same folder
,
and the le names are
the same except for the
le extensions.
y
So
me MKV les may not
be played back correctly,
depending on the video
resolution, frame rate
condition, subtitle format
and so on.
Subtitles
text le
“.SRT”,
“.srt”,
““.SSA”,
“.ssa”,
“.ASS”,
“.ass”
mp4
(Compression
methods
Video: H.264/HEVC
Audio: AAC)
“.MP4”,
“.mp4”,
“.MOV”,
“.mov”
y
Resolution up to
3840×2160 25p/30p,
4096×2160 24p. (except
MPEG2)
y
Some mp4/MPEG les
may not be played back
correctly
, depending on
the video resolution,
frame rate condition and
so on.
y
MOTION JPEG is not
supported.
y
Depending on the audio
compression method,
only images may be
played back and it may
not be possible to output
audio.
MPEG
(TS/PS)
(Compression
methods
V
ideo: MPEG2
/H.264
*
1
/HEVC
*
1
Audio: AAC
*
1
/Dolby Digital
/DTS
®
/LPCM
*
2
)
“.MPG”,
“.mpg”,
“.MPEG”,
“.mpeg”,
“.M2TS”,
“.m2ts”,
“.MTS”,
“.mts”,
“.TS”,
“.ts”
JPEG
“.JPG”,
“.jpg”,
“.JPEG”,
“.jpeg”
y
MOTION JPEG and
Progressive JPEG are
not supported.
y
You may not be able to
play back the le if you
have edited the folder
structure or the le name
on a PC or other device.
MPO
“.MPO”,
“.mpo”
3D still picture
MP3
“.MP3”,
“.mp3”
This unit supports ID3
tags, but only titles, artist
names and album names
can be displayed.
FLAC
“.FLAC”,
“.ac”
Maximum sampling rate:
192 kHz/24 bit
WAV
“.WAV”,
“.wav”
Maximum sampling rate:
384 kHz/24 bit
AAC
“.M4A”,
“.m4a”
This unit supports tags,
but only titles, artist names
and album names can be
displayed.
Maximum sampling rate:
48 kHz/320 kbps
- 34 -
Reference
File format Extension Reference
WMA
“.WMA”,
“.wma”
This unit supports tags,
but only titles, artist names
and album names can
be displayed. Maximum
sampling rate:
48 kHz/385 kbps
DSD
(DFF, DSF)
“.DSF”,
“.dsf”,
“.DFF”,
“.dff”
2.8 MHz (2 ch/5.1 ch),
5.6 MHz (2 ch/5.1 ch),
11.2 MHz (2 ch only)
ALAC
“.M4A”,
“.m4a”
This unit supports tags,
but only titles, artist names
and album names can be
displayed.
Maximum sampling rate:
192 kHz/24 bit
AIFF
“.aif”,
“.aiff”
Maximum sampling rate:
384 kHz/24 bit
*1 TS only
*2 PS only
y
With certain recording states and folder structures, the play
order may differ or playback may not be possible.
y
Up to 10,000 les and up to 300 folders can be displayed
as playable data in each folder regardless of their format.
(Even when the picture playback menu is displayed, for
example, if a folder in the menu contains playable videos
and music les, they are also counted as playable data.)
Audio information
The audio output differs depending on the settings
on the unit
UB450
UB159
and which terminals
are connected to the amplier/receiver. (
24,
“Digital Audio Output”)
y
The number of channels listed is the maximum possible
number of output channels when connected to amplier/
receiver compatible with the respective audio format.
Terminal
“Digital Audio Output”
“Bitstream”/
“On”
*5
“PCM”
*
1
/
“Off”
*5
Output
channel
HDMI OUT
*4
Outputs using
original audio
*
2
BD-Video :
7.1ch PCM
*
2
*
3
DVD-Video :
5.1ch PCM
UB450
UB159
DIGITAL
AUDIO
OUT
(COAXIAL)
Dolby Digital/
DTS
®
Digital
Surround
TM
Down-mixed
2ch PCM
*1
UB150
The maximum possible number of Dolby sound is
2ch PCM.
*2
When “BD-V
ideo Secondary Audio” is set to “On”,
the audio will be output as Dolby Digital, DTS
®
Digital
Surround
TM
or 5.1ch PCM. However, when playing BD-
Video without secondary audio or navigation sounds, the
audio is output as the original format.
*3
The audio output is amplied from 5.1ch or 6.1ch to 7.1ch
depending on the DTS, Inc. specications.
*4
When “DTS Neo:6” is set to “Cinema” or “Music”, 2ch
(2.1ch) audio can be expanded to 7ch (7.1ch) and output.
(
25)
*5
For “DSD Output Mode”
- 35 -
Reference
UB450
Supported format for Network
Contents Playback
When this unit works as a Network Contents
client, following contents are playable.
y
File formats that are not supported by your
Network Contents server* cannot be played.
* DLNA compatible server, etc.
Video
Container Video codec Audio codec
Example of
le extension
MKV
H.264
HEVC
AAC
PCM
Vorbis
FLAC
Dolby Digital
DTS
®
.mkv
AVCHD H.264 Dolby Digital .mts
MP4
H.264
HEVC
AAC .mp4, .mov
PS MPEG2
Dolby Digital
Linear PCM
DTS
®
.mpg, .mpeg
TS
MPEG2
H.264
HEVC
AAC
Dolby Digital
DTS
®
.m2ts, .ts
Format Example of le extension
JPEG .jpg
Audio
Audio codec Example of le extension
MP3 .mp3
FLAC .ac
WAV .wav
AAC .m4a, .adts
WMA .wma
ALAC .m4a
DSD .dsf, .dff
AIFF .aif, .aiff
Linear PCM —
y
Depending on the server
, the contents other than stated
above can be played back.
Language code list
Abkhazian: 6566
Afar: 6565
Afrikaans: 6570
Albanian: 8381
Amharic: 6577
Arabic: 6582
Armenian: 7289
Assamese: 6583
Aymara: 6589
Azerbaijani: 6590
Bashkir: 6665
Basque: 6985
Bengali; Bangla:
6678
Bhutani: 6890
Bihari: 6672
Breton: 6682
Bulgarian: 6671
Burmese: 7789
Byelorussian: 6669
Cambodian: 7577
Catalan: 6765
Chinese: 9072
Corsican: 6779
Croatian: 7282
Czech: 6783
Danish: 6865
Dutch: 7876
English: 6978
Esperanto: 6979
Estonian: 6984
Faroese: 7079
Fiji: 7074
Finnish: 7073
French: 7082
Frisian: 7089
Galician: 7176
Georgian: 7565
German: 6869
Greek: 6976
Greenlandic: 7576
Guarani: 7178
Gujarati: 7185
Hausa: 7265
Hebrew: 7387
Hindi: 7273
Hungarian: 7285
Icelandic: 7383
Indonesian: 7378
Interlingua: 7365
Irish: 7165
Italian: 7384
Japanese: 7465
Javanese: 7487
Kannada: 7578
Kashmiri: 7583
Kazakh: 7575
Kirghiz: 7589
Korean: 7579
Kurdish: 7585
Laotian: 7679
Latin: 7665
Latvian, Lettish:
7686
Lingala: 7678
Lithuanian: 7684
Macedonian: 7775
Malagasy: 7771
Malay: 7783
Malayalam: 7776
Maltese: 7784
Maori: 7773
Marathi: 7782
Moldavian: 7779
Mongolian: 7778
Nauru: 7865
Nepali: 7869
Norwegian: 7879
Oriya: 7982
Pashto, Pushto:
8083
Persian: 7065
Polish: 8076
Portuguese: 8084
Punjabi: 8065
Quechua: 8185
Rhaeto-Romance:
8277
Romanian: 8279
Russian: 8285
Samoan: 8377
Sanskrit: 8365
Scots Gaelic: 7168
Serbian: 8382
Serbo-Croatian:
8372
Shona: 8378
Sindhi: 8368
Singhalese: 8373
Slovak: 8375
Slovenian: 8376
Somali: 8379
Spanish: 6983
Sundanese: 8385
Swahili: 8387
Swedish: 8386
Tagalog: 8476
Tajik: 8471
Tamil: 8465
Tatar: 8484
Telugu: 8469
Thai: 8472
Tibetan: 6679
Tigrinya: 8473
Tonga: 8479
Turkish: 8482
Turkmen: 8475
Twi: 8487
Ukrainian: 8575
Urdu: 8582
Uzbek: 8590
Vietnamese: 8673
Volapük: 8679
Welsh: 6789
Wolof: 8779
Xhosa: 8872
Yiddish: 7473
Yoruba: 8979
Zulu: 9085
Language Code Language Code Language Code
ENG
FRA
DEU
ITA
ESP
NLD
SVE
NOR
DAN
POR
RUS
English
French
German
Italian
Spanish
Dutch
Swedish
Norwegian
Danish
Portuguese
Russian
JPN
CHI
KOR
MAL
VIE
THA
POL
CES
SLK
HUN
FIN
Japanese
Chinese
Korean
Malay
Vietnamese
Thai
Polish
Czech
Slovak
Hungarian
Finnish
ARA
HIN
PER
IND
MRI
BUL
RUM
GRE
TUR
Arabic
Hindi
Persian
Indonesian
Maori
Bulgarian
Romanian
Greek
Turkish
Others
Display Language Display Language Display Language
Display languages list
Abkhazian: 6566
Afar: 6565
Afrikaans: 6570
Albanian: 8381
Amharic: 6577
Arabic: 6582
Armenian: 7289
Assamese: 6583
Aymara: 6589
Azerbaijani: 6590
Bashkir: 6665
Basque: 6985
Bengali; Bangla:
6678
Bhutani: 6890
Bihari: 6672
Breton: 6682
Bulgarian: 6671
Burmese: 7789
Byelorussian: 6669
Cambodian: 7577
Catalan: 6765
Chinese: 9072
Corsican: 6779
Croatian: 7282
Czech: 6783
Danish: 6865
Dutch: 7876
English: 6978
Esperanto: 6979
Estonian: 6984
Faroese: 7079
Fiji: 7074
Finnish: 7073
French: 7082
Frisian: 7089
Galician: 7176
Georgian: 7565
German: 6869
Greek: 6976
Greenlandic: 7576
Guarani: 7178
Gujarati: 7185
Hausa: 7265
Hebrew: 7387
Hindi: 7273
Hungarian: 7285
Icelandic: 7383
Indonesian: 7378
Interlingua: 7365
Irish: 7165
Italian: 7384
Japanese: 7465
Javanese: 7487
Kannada: 7578
Kashmiri: 7583
Kazakh: 7575
Kirghiz: 7589
Korean: 7579
Kurdish: 7585
Laotian: 7679
Latin: 7665
Latvian, Lettish:
7686
Lingala: 7678
Lithuanian: 7684
Macedonian: 7775
Malagasy: 7771
Malay: 7783
Malayalam: 7776
Maltese: 7784
Maori: 7773
Marathi: 7782
Moldavian: 7779
Mongolian: 7778
Nauru: 7865
Nepali: 7869
Norwegian: 7879
Oriya: 7982
Pashto, Pushto:
8083
Persian: 7065
Polish: 8076
Portuguese: 8084
Punjabi: 8065
Quechua: 8185
Rhaeto-Romance:
8277
Romanian: 8279
Russian: 8285
Samoan: 8377
Sanskrit: 8365
Scots Gaelic: 7168
Serbian: 8382
Serbo-Croatian:
8372
Shona: 8378
Sindhi: 8368
Singhalese: 8373
Slovak: 8375
Slovenian: 8376
Somali: 8379
Spanish: 6983
Sundanese: 8385
Swahili: 8387
Swedish: 8386
Tagalog: 8476
Tajik: 8471
Tamil: 8465
Tatar: 8484
Telugu: 8469
Thai: 8472
Tibetan: 6679
Tigrinya: 8473
Tonga: 8479
Turkish: 8482
Turkmen: 8475
Twi: 8487
Ukrainian: 8575
Urdu: 8582
Uzbek: 8590
Vietnamese: 8673
Volapük: 8679
Welsh: 6789
Wolof: 8779
Xhosa: 8872
Yiddish: 7473
Yoruba: 8979
Zulu: 9085
Language Code Language Code Language Code
ENG
FRA
DEU
ITA
ESP
NLD
SVE
NOR
DAN
POR
RUS
English
French
German
Italian
Spanish
Dutch
Swedish
Norwegian
Danish
Portuguese
Russian
JPN
CHI
KOR
MAL
VIE
THA
POL
CES
SLK
HUN
FIN
Japanese
Chinese
Korean
Malay
Vietnamese
Thai
Polish
Czech
Slovak
Hungarian
Finnish
ARA
HIN
PER
IND
MRI
BUL
RUM
GRE
TUR
Arabic
Hindi
Persian
Indonesian
Maori
Bulgarian
Romanian
Greek
Turkish
Others
Display Language Display Language Display Language
- 36 -
Reference
Licenses
“AVCHD”, “AVCHD 3D”, “AVCHD Progressive” and “AVCHD 3D/
Progressive” are trademarks of Panasonic Corporation and Sony
Corporation.
Java is a registered trademark of Oracle and/or its afliates.
Dolby, Dolby Audio, Dolby Vision, and the double-D symbol are
trademarks of Dolby Laboratories.
For DTS patents, see http://patents.dts.com.
Manufactured under license from DTS, Inc.
DTS, the Symbol, DTS and the Symbol together, DTS-HD, and
the DTS-HD logo are registered trademarks and/or trademarks of
DTS, Inc. in the United States and/or other countries.
© DTS, Inc. All Rights Reserved.
The product with Hi-Res AUDIO logo is conformed to
High-Resolution Audio standard dened by Japan Audio Society.
This logo is used under license from Japan Audio Society.
The terms HDMI and HDMI High-Denition Multimedia Interface,
and the HDMI Logo are trademarks or registered trademarks of
HDMI Licensing Administrator, Inc. in the United States and other
countries.
<AVC>
This product is licensed under the AVC Patent Portfolio License
for the personal use of a consumer or other uses in which it does
not receive remuneration to (i) encode video in compliance with
the AVC Standard (“AVC Video”) and/or (ii) decode AVC Video that
was encoded by a consumer engaged in a personal activity and/
or was obtained from a video provider licensed to provide AVC
Video. No license is granted or shall be implied for any other use.
Additional information may be obtained from MPEG LA, L.L.C.
See http://www.mpegla.com
<VC-1>
This product is licensed under the VC-1 Patent Portfolio License
for the personal and non-commercial use of a consumer to (i)
encode video in compliance with the VC-1 Standard (“VC-1
Video”) and/or (ii) decode VC-1 Video that was encoded by a
consumer engaged in a personal and non-commercial activity
and/or was obtained from a video provider licensed to provide
VC-1 Video. No license is granted or shall be implied for any other
use. Additional information may be obtained from MPEG LA, L.L.C.
See http://www.mpegla.com
“DVD Logo” is a trademark of DVD Format/Logo Licensing
Corporation.
Windows is a trademark or a registered trademark of Microsoft
Corporation in the United States and other countries.
Adobe is a trademark or registered trademark of Adobe Systems
Incorporated in the United States and/or other countries.
HDR10+
TM
logo is a trademark of HDR10+ Technologies, LLC.
Copyright 2004-2014 Verance Corporation. Cinavia
TM
is a Verance
Corporation trademark. Protected by U.S. Patent 7,369,677 and
worldwide patents issued and pending under license from Verance
Corporation. All rights reserved.
This product incorporates the following software:
(1) the software developed independently by or for Panasonic
Corporation,
(2) the software owned by third party and licensed to Panasonic
Corporation,
(3) the software licensed under the GNU General Public License,
Version 2.0 (GPL V2.0),
(4) the software licensed under the GNU LESSER General Public
License, Version 2.1 (LGPL V2.1), and/or
(5) open source software other than the software licensed under
the GPL V2.0 and/or LGPL V2.1.
The software categorized as (3) - (5) are distributed in the hope
that it will be useful, but WITHOUT ANY WARRANTY, without
even the implied warranty of MERCHANTABILITY or FITNESS
FOR A PARTICULAR PURPOSE.
Please refer to the detailed terms and conditions thereof shown in
the Player Settings menu.
At least three (3) years from delivery of this product, Panasonic will
give to any third party who contacts us at the contact information
provided below, for a charge no more than our cost of physically
performing source code distribution, a complete machine-readable
copy of the corresponding source code covered under GPL V2.0,
LGPL V2.1 or the other licenses with the obligation to do so, as
well as the respective copyright notice thereof.
Contact Information: [email protected]
The source code and the copyright notice are also available for
free in our website below.
https://panasonic.net/cns/oss/
(1) MS/WMA
This product is protected by certain intellectual property rights
of Microsoft Corporation and third parties. Use or distribution
of such technology outside of this product is prohibited without
a license from Microsoft or an authorized Microsoft subsidiary
and third parties.
(2) MS/PlayReady/Final Product Labeling
This product contains technology subject to certain intellectual
property rights of Microsoft. Use or distribution of this
technology outside of this product is prohibited without the
appropriate license(s) from Microsoft.
(3) MS/PlayReady/End User Notices
Content owners use Microsoft PlayReady™ content access
technology to protect their intellectual property, including
copyrighted content. This device uses PlayReady technology
to access PlayReady-protected content and/or
WMDRM-protected content. If the device fails to properly
enforce restrictions on content usage, content owners may
require Microsoft to revoke the device’s ability to consume
PlayReady-protected content. Revocation should not affect
unprotected content or content protected by other content
access technologies. Content owners may require you to
upgrade PlayReady to access their content. If you decline an
upgrade, you will not be able to access content that requires
the upgrade.
(4) Vorbis, FLAC
The software licenses are displayed when “Software Licence”
in the Setup menu is selected. (
27)
- 37 -
Reference
Sales and Support Information
Customer Communications Centre
≥ For customers within the UK: 0344 844 3899
≥ For customers within Ireland: 01 289 8333
≥ Monday–Friday 9:00 am – 5:00 pm (Excluding public holidays).
≥ For further support on your product, please visit our website:
www.
panasonic.co.uk
Direct Sales at Panasonic UK
≥ Order accessory and consumable items for your product with ease and confidence by phoning our
Customer Communications Centre Monday–Friday 9:00 am – 5:00 pm (Excluding public holidays).
≥ Or go on line through our Internet Accessory ordering application at www.pas-europe.com
.
≥ Most major credit and debit cards accepted.
≥ All enquiries transactions and distribution facilities are provided directly by Panasonic UK.
≥ It couldn’t be simpler!
≥ Also available through our Internet is direct shopping for a wide range of finished products. Take a
browse on our website for further details.
DP-UB420-320-EB-TQBS0188_eng.book 45 ページ ２０１８年２月２３日 金曜日 午後７時２２分
Manufactured by: Panasonic Corporation
Kadoma, Osaka, Japan
Importer for Europe: Panasonic Marketing Europe GmbH
Panasonic Testing Centre
Winsbergring 15, 22525 Hamburg, Germany
Panasonic Corporation
Web Site: http://www.panasonic.com
En
Ge
Fr
It
Sp
Du
Sw
Da
Cz
Hu
Po
Fi
Cf
Cn
Co
© Panasonic Corporation 2019
TQBS0337
CH0119TH0
(Inside of product) (Back of product)
