User Manual Bose F1 812 Flexible Array Loudspeaker

The Bose F1 Model 812 12” 1000-watt powered loudspeaker is the first powered loudspeaker that delivers the benefits of an adjustable array in a portable system package. Its unique flexible baffle allows you to tailor the loudspeaker’s vertical coverage to a wide variety of listening environments. Simply push or pull the array into position to create “Straight,” “C,” “J” or “Reverse J” coverage patterns. Once set, the system automatically updates the EQ to maintain optimum tonal balance for each coverage pattern. So whether you’re playing at floor level, on a stage, or facing raked seats or bleachers, you can adapt your PA to the room.

Engineered with an array of 8 high-output drivers, a high-powered 12" woofer and a lower crossover point, the loudspeaker delivers full-range, high-SPL performance while maintaining vocal and midrange clarity that’s dramatically better than conventional loudspeakers.

The Bose F1 subwoofer packs all the power of a larger bass box into a more compact design that’s easier to carry and fits in a car. A mounting stand for the loudspeaker is stored right in the body of the subwoofer, making setup fast and easy. The stand even includes cable channels to neatly hide wires.

The loudspeaker and subwoofer combined deliver 2,000 watts of power, so you can fill nearly any room with sound.

And now getting there is easier, too. The loudspeaker and subwoofer feature strategically-placed handles for easy transportation

Yes. The F1 Model 812 loudspeaker and F1 sub are ideal for DJs that want high power and sonic clarity in a portable system. The F1 subwoofer’s compact design and high capability remove the need for transporting subwoofers twice their size. Plus, the integrated stand eliminates ugly tripod bases that expose hanging wires and create tripping hazards.

Yes. The F1 Model 812 loudspeaker and F1 subwoofer combination can be used inside or outside. However, it must never be exposed to precipitation or extended periods of direct sunlight. In cases of light rain, take precautions to cover the back panel of the loudspeaker. Water must not get into the air inlet slits inside the back I/O panel, handle recess or front grille.

The system has been tested to operate in temperatures from 0° to 50° C (32° to 122° F), and be stored in temperatures from -30° to 70° C (-22° to 158° F).

Yes, there is a pole cup on the bottom of the enclosure that is compatible with standard 1 3/8 inch diameter (35mm) speaker stands.

The 8 drivers on the F1 Model 812 flexible array are mounted on a specially designed flexible baffle that is hinged in two locations. When the array position is changed, the loudspeaker’s internal EQ automatically changes according to the array’s positon: “Straight,” “C,” “J” or “Reverse J.” This allows the loudspeaker to maintain tonal balance no matter which position is used.
