LAVENHAM 1800W LOG EFFECT FIRE STOVE
WL46031
YOUR SAFETY &
INSTRUCTION MANUAL
PLEASE READ CAREFULLY
This product is only suitable for well insulated spaces or occasional use
2 CUSTOMER SUPPORT TEAM: +44 (0) 333 220 6056
WHAT’S IN THE BOX
Instruction Manual
Log Eect Stove Fire
1. Flame eect
2. On/O/heat selection switches
3. Thermostat control dial
4. Flame eect dimmer
5. Air outlet
The images are for illustration purposes only and might not be a true indication of the actual product.
1
2
3
4
TECHNICAL DATA
Description: LAVENHAM 1800W LOG EFFECT FIRE STOVE
Model: WL46031
Rated Voltage: 220-240V
Frequency: 50Hz
Power Consumption: 900-1800W
Lighting: Bulb
DOCUMENTATION
We declare that this product conforms to the following product legislation in accordance with the following directive(s):
2014/30/EU Electromagnetic Compatibility Directive.
2014/35/EU Low Voltage Directive.
2011/65/EU Restriction of Hazardous Substances Directive.
2009/125/EC Eco-Design of Energy Related Products.
RK Wholesale LTD Quality Assurance, United Kingdom
5
3www.warmlite.co
WIRING SAFETY FOR UK USE ONLY
IMPORTANT
As the colours in the mains lead of this appliance
may not correspond with the coloured markings
identifying the terminals in your plug, please
proceed as follows:
The wires in the mains lead are labelled in
accordance with the following code:
Blue neutral [N] Brown live [L] Green/Yellow
[EARTH]
Plug Fitting Details (Where Applicable).
The wire labelled blue is the neutral and must be
connected to the terminal marked [N].
The wire labelled brown is the live wire and must
be connected to the terminal marked [L].
The wire labelled green/yellow must be
connected to the terminal marked with the letter
[E].
On no account must either the brown or the blue
wire be connected to the [EARTH] terminal.
Always ensure that the cord grip is fastened
correctly.
The plug must be tted with a fuse of the same
rating already tted and conforming to BS 1362
and be ASTA approved.
If in doubt consult a qualied electrician who will
be pleased to do this for you.
Non-Rewireable Mains Plug.
If your appliance is supplied with a non-
rewireable plug tted to the mains lead and
should the fuse need replacing, you must use an
ASTA approved one (conforming to BS 1362 of
the same rating).
If in doubt, consult a qualied electrician who will
be pleased to do this for you.
If you need to remove the plug - disconnect it
from the mains - then cut it o of the mains lead
and immediately dispose of it in a safe manner.
Never attempt to reuse the plug or insert it into a
socket outlet as there is a danger of an electric
shock.
FUSE
Earth
(Green/Yellow)
Fuse
Neutral
(Blue)
Live
(Brown)
WARNING:
This appliance MUST be earthed!
DISPOSAL OF THE UNIT
Appliances bearing the symbol shown here may not be disposed of in domestic rubbish.
You are required to dispose of old electrical and electronic appliances like this separately.
Please visit www.recycle-more.co.uk or www.recyclenow.co.uk for access to information about the
recycling of electrical items.
Please visit www.weeeireland.ie for access to information about the recycling of
electrical items purchased in Ireland.
The WEEE directive, introduced in August 2006, states that all electrical items must be
recycled, rather than taken to landll.
Please arrange to take this appliance to your local Civic Amenity site for recycling,
once it has reached the end of its life.
4 CUSTOMER SUPPORT TEAM: +44 (0) 333 220 6056
PRODUCT SAFETY
When using any electrical appliance, basic safety precautions should
always be followed including the following:
• Check that the voltage of the
main circuit corresponds with
the rating of the appliance
before operating.
• The intended use for this unit
is described in this manual.
The use of any accessory
or attachment or the
performance of any operation
with this appliance other
than those recommended in
this instruction manual may
present a risk of personal
injury.
• Retain this manual for future
reference.
• WARNING! When using
mains-powered appliances,
basic safety precautions,
including the following,
should always be followed to
reduce the risk of re, electric
shock and personal injury
and material damage.
• Check that the voltage of the
main circuit corresponds with
the rating of the appliance
before operating.
• Always ensure that the
appliance is placed on a rm
level surface. Ensure that the
appliance is not positioned
close to curtains, furniture or
any combustible materials
as this could create a re hazard.
The appliance must not be
located immediately below a
mains socket outlet.
• DO NOT immerse cords,
plugs or any part of the
appliance in water or any
other liquid.
• DO NOT let the cord hang
over the edge of a table
or counter or let it come
into contact with any hot
surfaces.
• DO NOT carry the appliance
by the power cord.
• DO NOT use any extension
cord with this appliance.
• The use of accessory
attachments is not
recommended by the
appliance manufacturer,
apart from those supplied
with this product. DO NOT
use extension cords with the
appliance.
• DO NOT pull the plug out by
the cord as this may damage
the plug and/or the cable.
• Switch o at the wall socket
then remove the plug from
the socket when not in use
or before cleaning.
5www.warmlite.co
• Switch o and unplug before
tting or removing tools/
attachments, after use and
before cleaning.
• DO NOT use this product
for anything other than its
intended use.
• DO NOT leave the appliance
unattended while it is
operating.
• This appliance is for
household use only.
• DO NOT use the appliance
outdoors.
• DO NOT use the appliance
near water.
• Always place wires in a
regular and orderly manner
to prevent the appliance from
becoming a trip hazard or
the plug from accidentally
being pulled out.
• The appliance must not be
located immediately below a
socket outlet.
• Do not use this appliance in
the immediate surroundings
of a bath, a shower or a
swimming pool.
• In order to avoid overheating,
do not cover the appliance.
• Children of less than 3 years
should be kept away unless
continuously supervised.
• Children between the ages of
3 and 8 years old should only
switch the appliance on or
o when it has been placed
and installed in its intended,
normal operating position
and when they have been
given adequate supervision
or instruction concerning
safe use of the appliance
and understand the hazards
involved. Children between
the ages of 3 and 8 years
old should not plug in,
regulate, clean or perform
user maintenance on the
appliance.
• The appliance is not to be
used by persons (including
children) with reduced
physical, sensory or mental
capabilities, or lack of
experience and knowledge,
unless they have been given
supervision or instruction.
• Close supervision is
necessary when any
appliance is used by or near
children.
• Children should not play with
the appliance.
6 CUSTOMER SUPPORT TEAM: +44 (0) 333 220 6056
• This appliance can be
used by children aged
from 8 years and above
and persons with reduced
physical, sensory or mental
capabilities or lack of
experience and knowledge
if they have been given
supervision or instruction
concerning use of the
appliance in a safe way and
understand the hazards
involved.
• CAUTION! Some parts of
this product can become
very hot and cause burns.
Particular attention has to
be given where children
and vulnerable people are
present.
• Cleaning and user
maintenance should not
be undertaken by children
without supervision.
• Take care when any
appliance is used near pets.
• When not in use, please
unplug the portable
appliance from the mains
socket.
• Always unplug the appliance
and allow it to cool before
moving it from one location
to another.
• Please ensure that the
appliance is used on a
stable, level, and heat
resistant surface.
• If the supply cord or
appliance is damaged,
stop using the appliance
immediately and seek advice
from the manufacturer, its
service agent or a similarly
qualied person.
• DO NOT attempt to
dismantle or repair any part
of the appliance. This should
only be done by a qualied
service agent.
• DO NOT install the appliance
in washhouses or other
places with water and moist.
• DO NOT turn the appliance
on or o by inserting or
pulling out the plug.
• DO NOT place things on the
appliance.
• DO NOT put anything into
the air inlet and outlet.
• DO NOT use insecticide
spray or other ammable
matters in the vicinity of the
appliance.
• DO NOT splash oil or water
into the appliance.
7www.warmlite.co
• DO NOT clean the appliance
with water. Wipe it with a
semi-wet soft cloth.
• DO NOT wipe the appliance
with chemical solvents
such as benzene, gasoline
or alcohol. Use neutral
detergents only.
• Only install the appliance in
at and dry places. Keep the
appliance 50cm away from
surrounding objects.
• The appliance should be
placed away from gasoline,
cooking stoves or other
combustibles and heat
sources.
• Use the appliance in a well-
ventilated area.
• CAUTION! DO NOT operate
the appliance with wet
hands.
• DO NOT tip the appliance
over as this may cause
damage to the appliance and
create a re hazard.
• CAUTION! No wall xings are
provided with this replace
suite. Take care to ensure
the suite is set on a at and
stable surface and placed
against a wall to prevent it
from falling over or being
dislodged.
• In the unlikely event the
appliance develops a fault,
stop using it immediately
and seek advice from the
Customer Support Team.
HIGH VOLTAGE HOT SURFACE DO NOT COVER
8 CUSTOMER SUPPORT TEAM: +44 (0) 333 220 6056
HANDLING
Before continuing any further with the installation of this
re please read the following:
• Two people should be sucient to lift the re.
• When lifting always keep your back straight. Bend
your legs and not your back.
• Avoid twisting at the waist. It is better to reposition
your feet.
• Avoid upper body / top heavy bending. Always
bend from the knees rather than the waist. Do not
lean forward or sideways whilst handling the re.
• Always grip with the palm of your hand. Do not
use the tips of ngers for support.
• Always keep the product as close to the body as
possible to prevent unnecessary and undue strain
on the body.
• Use gloves to provide additional grip.
• Always use assistance if required.
BEFORE YOUR FIRST USE:
1. Remove your appliance from the packaging.
2. Keep the front of the appliance through which
the heat is radiated at least one meter away from
furniture, curtains and other ammable objects at
all times.
3. Ensure there is a grounded socket nearby (back of
the appliance).
4. Never use an extension lead. The main cable must
remain at the back of the appliance and must not
be in contact with any hot elements.
5. Your appliance is now ready for normal use.
6. Dispose of the packaging in a responsible manner
CONTROL PANEL:
Power/Flame switch – Switches both Flame eect and
Power ON/OFF
900W Heat Selection – Press “-” for 900W
1800W Heat Selection – Press “-” and “=” at the same
time for 1800W heating. The higher heating selection
cannot be activated without rst activating the 900W
setting.
Thermostat control dial – Adjust to maintain room
temperature
Flame Eect Dimmer – Rotate this dial to dim or brighten
the ame eect as required.
NOTE: The ame eect can be operated with or without
heat.
USING YOUR APPLIANCE:
1. Plug the heater into the mains socket and switch
the socket on.
2. The heater switches are located at the front of
the unit, inside the door and directly above the
exhaust vents.
3. Switch the re on by pushing the Power/Flame
switch to the ON position, represented by the
symbol ‘I’. The ame eect will automatically come
on to indicate the heater is in operation.
4. Once the unit is on, ick the heat selection
switches to the ON position to choose between
two settings: 900W or 1800W.
5. Push switch ‘I’ to the ON position to select the
Low heat setting (900W).
6. Push switch ‘II’ to the ON position to select the
High heat setting (1800W).
NOTE: The higher heating selection cannot be activated
without rst activating the lower setting.
7. Once the desired heat setting has been selected,
rotate the thermostat dial clockwise or counter-
clockwise to increase or decrease the desired
room temperature setting.
8. The ame eect can also be turned on
independently from the heat settings. To turn the
ame eect on without activating the heat settings,
ick the Power/Flame switch to the ON position,
but leave both heat switches and the thermostat
dial turned to the OFF position, represented by
the symbol ‘O’. The realistic ame eect will now
operate normally, but the unit will not give o any
heat.
9. The ame eect can also be made brighter or
dimmer, using the rotary ame dimmer dial on
the unit’s control panel. Turn this dial clockwise
to make the ame eect brighter, or counter-
clockwise to dim it.
10. To turn the unit o altogether, push all the switches
to the OFF position. Heat will stop emitting from
the vents and the ame eect will go out to
indicate the unit has been turned o.
Safety Cut-Out:
• This appliance is tted with a safety cut-o which
will operate if the heater overheats (e.g. Due to
blocked air vents). For safety reasons, the heater
will NOT automatically reset when this cut-out
activates.
• To reset the appliance, disconnect the appliance
from the mains supply for at least 15 minutes.
Once this time has elapsed, reconnect the supply
to the mains and switch on the appliance.
9www.warmlite.co
CHECK THAT YOU HAVE NOTED ALL THE
FOLLOWING INSTRUCTIONS:
Do:
• Always install the re in accordance with this
guide. If in doubt obtain expert advice.
• Always make sure the electrical socket is
accessible and located adjacent to, but not above
or behind the re.
• Always disconnect the re from the electrical
supply before carrying out cleaning or
maintenance.
• Always ensure the product is placed in an area
that is free from dust, grease or liquids.
Don’t:
• Never leave children unsupervised in a room where
the re is ON and unguarded.
• Never obstruct or cover the fan outlet or force
items into the re openings.
• Never install or use the re anywhere where water
is in use, i.e. bathrooms, kitchens, shower rooms,
swimming pools etc.
• Never use aerosols or steam cleaners on or
around the re.
• Never route the mains supply cable under carpet
etc.
• Never install the re close to curtains or
combustible materials.
• Never use the re to dry clothes etc.
• Never sit or stand on the re.
• Never cut the o the plug and hard wire into a
xed fused spur.
NOTE: Any new wiring required, must be in accordance
with local and national codes and other applicable
regulations in order to reduce the risk of re, electric
shock, or other injuries.
NOTE: When the re is turned on for the rst time
or when it has not been used for some time, it may
release a slight, harmless odour. This odour is a normal
occurrence caused by the initial heating of the internal
heating elements or dust, and will disappear with use.
TROUBLE SHOOTING
Symptom Corrective action
The heater will not
turn on.
Make sure the appliance
is plugged into the
mains and that it is
switched on. If plugged
in, make sure the
Power/Flame switch
is turned to the On
position. Check that the
safety cut-o feature
has not been activated.
No re eect light Check with the
manufacturer or a
qualied service person
for repair.
CLEANING AND CARE
WARNING! Always disconnect from the mains supply
before cleaning the wall re.
CAUTION! Allow the product to completely cool before
handling or cleaning it.
• Before cleaning always switch o the re and
remove the plug from the electrical socket.
• Ensure that the unit is cool enough to work on.
• To remove the dust, wipe the appliance with a dry
cloth.
• To keep the heater clean, the outer shell may be
cleaned with a soft, damp cloth. After cleaning, dry
the unit with a soft cloth.
CAUTION! DO NOT let liquid enter the heater. This may
cause damage or deterioration to the heater’s surface.
WARNING! DO NOT immerse the heater in water or any
other liquid.
• Never use abrasives or detergents.
• If the heater shows any signs of wear or damage
disconnect immediately from the mains supply,
and do NOT use it – have it checked by a suitably
qualied person.
• This product uses a standard bulb for its ame
eect. The appliance uses an electronically
controlled system to create the eect, therefore no
parts need to be replaced. There are no user-
serviceable parts on this appliance. Under no
circumstances should the appliance be serviced
be anyone other than a qualied electrician.
WARNING:
DO NOT IMMERSE ANY ELECTRICAL PART
OF THE APPLIANCE IN WATER SUCH AS
MOTOR UNITS OR PLUGS.
PLEASE SEE CLEANING SECTION FOR
FURTHER INSTRUCTIONS.
10 CUSTOMER SUPPORT TEAM: +44 (0) 333 220 6056
Model Identifier(s): WL46031
Item Symbol Valve Unit Item Unit
Heat Output
Type of heat input for electric storage, local
space heaters only (select one)
Nominal heat
output
Pnom 1,8 kW
Manual heat charge with integrated
thermostat
No
Minimum heat
output (indicative)
Pmin 0.9 kW
Manual heat charge control with room
and/or outdoor temperature feedback
No
Maximum
continuous heat
output
Pmax, c 1.8 kW
Electronic heat charge control with
room
and/or outdoor temperature feedback
No
Auxiliary electricity
consumption
Fan assisted heat output No
At nominal heat
output
elmax 1,767 kW
Type of heat output/room temperature control
(select one)
At minimum heat
output
elmin 0,899 kW
Single stage heat output and no room
temperature control
No
In standby mode eISB N/A kW
Two or more manual stages, no room
temperature control
No
With mechanic thermostat room
temperature control
Yes
With electronic room temperature
control
No
Electronic room temperature control
plus day timer
No
Electronic room temperature control
plus week timer
No
Other control options (multiple selections
possible)
Room temperature control with pres-
ence detection
No
Room temperature control with open
window detection
No
With distance control option No
With adaptive start control No
With working time limitation No
With black bulb sensor No
Contact Details: Imported by RK Wholesale LTD., Berryhill Road, Stoke-on-Trent ST4 2NL
11www.warmlite.co
0720.V1
Thank You!
We hope you enjoy your appliance for many years.
This product is guaranteed for 12 months from the date of original purchase.
If any defect arises due to faulty materials of workmanship, the faulty products must be returned to the
place of purchase.
Refund or replacement is at the discretion of the retailer.
The Following Conditions Apply:
The product must be returned to the retailer with proof of purchase or a receipt.
The product must be installed and used in accordance with the instructions contained in this instruction guide.
It must be used only for domestic purposes.
It does not cover wear and tear, damage, misuse or consumable parts.
RKW has limited liability for incidental or consequential loss or damage.
This guarantee is valid in the UK and Eire only.
The standard one year guarantee is only extended to the maximum available for each particular product upon
registration of the product within 28 days of purchase. If you do not register the product with us within the 28 day
period, your product is guaranteed for 1 year only.
To validate your extended warranty, please visit
www.warmlite.co and register with us online.
Please note that length of extended warranty oered is dependent on product type and that each qualifying
product needs to be registered individually in order to extend its warranty past the standard 1 year.
Extended warranty is only valid with proof of purchase or receipt.
Your warranty becomes void should you decide to use non Warmlite spare parts.
Spare parts can be purchased from www.warmlite.co
Should you have a problem with your appliance, or need any spare parts,
please call our Customer Support Team on:
+44 (0) 333 220 6056
