Operating Instruction Manual Opti-myst Electric Stove Dimplex WLL20

General Information

  • The fire incorporates a flame effect, which can be used with or without heating, so that the comforting effect may be enjoyed at any time of the year.
  • A fan heater can provide heating in cold weather. A distance of 1 metre (3 feet) must be maintained between the front of the heater and any surrounding furniture, overhanging curtains or other obstructions.
  • Always ensure that the appliance is sitting on a level surface.
  • Before connecting the appliance, check that the supply voltage is the same as that stated on the appliance.
  • Only use filtered water in this appliance.
  • Once installed, never move this appliance or lay it on its back, without draining the water from sump and water tank. The water tank, sump, sump lid, tank cap and air filters must be cleaned once every 2 weeks, particularly in hard water areas. If you intend not using the appliance for longer than 2 weeks, drain the water from sump and water tank and dry the sump.

Maintenance

General Tips

  • Only use filtered tap water in this appliance.
  • Always ensure that the appliance is sitting on a level surface.
  • If you intend not using the appliance for longer than 2 weeks, remove and empty the sump and water tank.
  • Once installed, never move this appliance or lay on its back, without draining the water from sump and water tank.

Cleaning

  • Warning – Always press to turn off the product and disconnect the product from the power supply before cleaning the fire. Leave the appliance for 10 minutes to allow the product to cool down.

Water Tank

  1. Remove water tank, as described earlier, put into sink and empty water.
  2. Using the supplied brush gently rub the inside surfaces of the cap paying particular attention to the rubber ring in the the outer groove and the center rubber seal.
  3. Put a small quantity of washing up liquid into the tank, refit the cap and shake well, rinse out until all traces of washing up liquid are gone.
  4. Refill with filtered tap water only, replace the cap, do not over tighten.

Sump

  • Gently lift out the fuelbed and place carefully on the ground.
  • Remove the water tank by lifting upwards.
  • Remove the sump lid, this allows the sump to be lifted completely from its location. (Fig 5)
  • Gently lift up the sump, taking care to keep level so as not to spill any water. Sit the assembly in the sink.
  • Carefully tilt so that the liquid drains out of the sump.
  • Put a small amount of washing up liquid into the sump, and using the supplied brush, gently clean all surfaces including the metal disc (Fig 9)
  • When cleaned, thoroughly rinse the sump with clean water.
  • Clean the outlet surface of the sump lid with the brush and flush out thoroughly with water.
  • Reverse the above steps to reassemble.

Air Filter

  1. Press power button on the remote control or on the product to turn it off
  2. Gently lift off the fuelbed and set aside
  3. Remove the tank and place in a sink with the cap facing upwards.
  4. Gently slide up the air filter (Fig. 10)
  5. Gently rinse with water in the sink and dry with fabric towel before returning.
  6. Replace the filter making sure that the course black filter is in contact with the plastic holder.
  7. Replace the tank.
  8. Replace the fuelbed.
  9. Press power button to turn on the product
