OPERATOR’S MANUAL
Model SBJ606E-GA Form No. SJ-SBJ606E-GA-MR2
R
ELECTRIC BLOWER/VACUUM/
MULCHER
14-AMP | 4-IN-1 | PLUS: GUTTER CLEANING TUBES
IMPORTANT!
Safety Instructions
All Operators Must Read These
Instructions Before Use
Any electrical appliance can be dangerous if used incorrectly.
Some of the safety precautions given in this manual apply
generally to many appliances. Other warnings are specic to
the use of this electric blower vac.
Always follow these safety guidelines. Failure to do so may
result in serious bodily injury or death.
mDANGER! This indicates a hazardous situation, which,
if not followed, will result in serious injury or death.
mWARNING! This indicates a hazardous situation, which,
if not avoided, could result in serious injury or death.
mCAUTION! This indicates a hazardous situation, which,
if not avoided, could result in minor or moderate injury.
General Safety
FOR HOUSEHOLD USE ONLY
Before using, be sure that everyone using this tool reads
and understands all safety instructions and other information
contained in this manual. Save this manual and review it
frequently prior to using this tool and when instructing
others on the proper operating procedures.
mCAUTION! Wear appropriate hearing protection during
use. After long periods of extended use, the noise generated
from this appliance may cause hearing loss if your ears are
not properly protected.
mWARNING! When using electric yard tools, basic safety
precautions should always be followed to reduce the risk of
re, electric shock, and personal injury, including the following:
1. Keep work area clean and well-lit – Cluttered, dark
areas invite accidents.
2. Replacement parts – When servicing this unit, use only
identical replacement parts. Replace or repair damaged
cords immediately.
3. Keep children, bystanders, and pets away – All
spectators, including pets, should be kept a safe distance
away from the work area.
4. Dress properly – Do not wear loose clothing or jewelry
as such articles can get caught in moving parts. Wear a
protective covering to contain long hair. Wearing rubber
gloves and substantial non-slip footwear is recommended
when working outdoors.
5. Extension cords – To prevent electric shock, use only
with an extension cord suitable for outdoor use.
6. Avoid accidental starting – Do not carry the blower vac
with your nger on the switch. Make sure the switch is o
before plugging in the unit.
mDANGER! Do not manually place objects into the
vacuum tube while operating the unit as this can seriously
damage the unit and/or harm the operator. Keep both hands
on the handles while the power is on.
DO NOT ATTEMPT to remove material or hold material to be
vacuumed when the blower vac is on. Make sure the blower
vac is o when clearing jammed material from the vacuum
tube. Do not pick up the blower vac by the tube or attempt to
carry the unit by the tube.
mCAUTION! Moving parts will continue to run for several
seconds after turning o the machine.
7. Do not abuse the cord – Never carry the blower vac
by the cord or yank the cord to disconnect it from the
receptacle. Keep the cord away from heat, oil, and sharp
edges.
8. Moving parts – Keep hands and feet away from moving
parts. Keep guards in place and in proper working order.
9. Do not force the tool – It will perform better with less
likelihood of personal or mechanical injury if it is used at
the rate for which it is designed.
10. Wear personal protective equipment – When using this
tool, wear safety glasses with side shields or goggles to
provide necessary eye protection. Wear ear defenders to
prevent hearing damage. Use a face or dust mask if the
work environment is dusty.
11. Disconnect the tool – Disconnect the blower vac from
the power supply when it is not in use, before servicing
it, when changing accessories, and when performing any
other maintenance task.
12. Store idle tool indoors – When not in use, the blower vac
should be stored indoors in a dry and high or locked-up
place out of the reach of children.
1
2
13. Maintain the blower vac with care – Keep the blower
tube and the fan area clear and clean for optimal
performance and to reduce the risk of injury. Inspect the
extension cord periodically and immediately replace it
if damaged. Keep the handles dry, clean, and free from
oil and grease. Follow the additional recommendations
described in the maintenance section of this manual.
14. Ground fault circuit interrupter (GFCI) protection should
be provided on the circuit(s) or outlet(s) that are to be used
for the blower vac. Receptacles are available having built-
in GFCI protection and may be used for this measure of
safety.
15. Use the right tool – Do not use the tool for any job except
that for which it is intended.
16.
Double insulation – Double insulation eliminates
the use of the usual three-wire grounded power cords,
thereby providing a measure of safety during the operation
of electric power tools. In a double insulated appliance, all
exposed metal parts are isolated from the internal metal
motor components with protecting insulation. Double
insulation tools do not need to be grounded.
NOTE: The double insulated system is intended to protect
the user from shock resulting from a break in the tool's
internal insulation. Observe all normal safety precautions
to avoid electrical shock.
17. Avoid dangerous environments – Do not use the blower
vac in rain, damp, or wet locations. Do not operate the
blower vac in gaseous or explosive atmospheres or use
the blower vac to pick up ammable or combustible
liquids. Motors in these tools normally spark, and the
sparks might ignite fumes.
18. Stay alert – Watch what you are doing. Use common
sense. Do not operate the blower vac when you are
tired or under the inuence of drugs, alcohol, or other
medication.
Additional Safety Instructions
• Use extra care when cleaning on stairs.
• Keep rm footing and maintain good balance at all times.
Do not overreach. Overreaching can result in loss of
balance.
• Turn o all controls before unplugging the tool.
• Do not use the tool if the power switch does not turn it ON
or OFF. Any tool that cannot be controlled with the switch is
dangerous and must be repaired.
• Do not use the tool with a damaged plug. If the tool is not
working as it should or has been dropped, damaged, left
outdoors, or dropped into water, return it to an authorized
Snow Joe
®
+ Sun Joe
®
dealer or contact the Snow Joe
®
+
Sun Joe
®
customer service department at 1-866-SNOWJOE
(1-866-766-9563).
• Do not pick up anything that is burning or smoking, such as
cigarettes, matches, or hot ashes.
• Do not use without the dust bag and/or lters in place.
• Carefully inspect your appliance prior to use and follow all
label and marking instructions.
• Keep the end of the blower tube away from your face and
body.
• Always unplug this appliance before connecting or
disconnecting the vacuum hose.
• Do not use for wet material.
• Keep all parts of your body away from any moving parts
and all hot surfaces of the unit.
• Do not put any object into the tool's openings. Do not use
the tool with any opening blocked; keep openings free of
dust, lint, hair, or any other object that may reduce air ow.
• Check the work area before each use. Remove all objects
such as rocks, broken glass, nails, wire, or string, which can
be thrown or become entangled in the machine.
• Service on the product must be performed by qualied
repair personnel only. Service or maintenance performed
by unqualied personnel could result in injury to the user or
damage to the product.
• This blower vac is intended for residential use only.
Commercial use of this product is prohibited and will void
the manufacturer's warranty.
• Never run the unit without the proper equipment attached.
Always ensure the blower tubes are properly installed.
Specic Safety Rules
for Blower Vacs
• This tool has been designed for blowing/collecting as well
as vacuuming/shredding dry leaves and other dry garden
rubbish, such as grass and twigs.
• When operating the unit as a blower, never point the blower
nozzle in the direction of people or pets or in the direction
of windows. Use extra caution when blowing debris near
solid objects, such as trees, automobiles, and walls.
• Be sure to secure the unit when transporting it.
• Never douse or squirt the unit with water or any other liquid.
Clean the unit after each use as described in the cleaning
and storage section.
Electrical Safety
1. Ground fault circuit interrupter (GFCI) protection should
be provided on the circuit(s) or outlet(s) to be used for
this electric blower vac. Receptacles are available having
built-in GFCI protection and may be used for this
measure of safety.
2. Make sure that the mains voltage matches that listed on
the unit's rating label. Using the improper voltage can
damage the motor and injure the user.
3. To prevent electric shock, use only with an extension cord
suitable for outdoor use, such as SW-A, SOW-A, STW-A,
STOW-A, SJW-A, SJOW-A, SJTW-A, or SJTOW-A.
3
Before use, check that the extension cord is in good
condition. When using an extension cord, make sure to
use one heavy enough to carry the current your product
will draw. An undersized cord will cause a drop in line
voltage resulting in loss of power and overheating.
4. To reduce the risk of electric shock, this appliance has a
polarized plug (i.e. one blade is wider than the other). Use
this appliance only with a polarized UL-, CSA-, or ETL-
listed extension cord recommended for outdoor,
all-weather use, such as the Snow Joe
®
+ Sun Joe
®
SJTW-A 14-gauge 50-foot extension cord with lighted
end (Model PJEXT50-B). Visit sunjoe.com to purchase
this extension cord online or, to order by phone, call
1-866-SNOWJOE (1-866-766-9563).
The appliance plug will t into a polarized extension
cord only one way. If the appliance plug does not t
fully into the extension cord, reverse the plug. If the plug
still does not t, obtain a correct polarized extension
cord. A polarized extension cord will require the use of a
polarized wall outlet. The extension cord plug will t into
the polarized wall outlet only one way. If the plug does
not t fully into the wall outlet, reverse the plug. If the plug
still does not t, contact a qualied electrician to install
the proper wall outlet. Do not modify the appliance plug,
extension cord receptacle, or extension cord plug in
any way.
5. To prevent the appliance cord from disconnecting from the
extension cord during operation, make a knot with the two
cords as shown in Table 1.
6. Do not abuse the cord. Never pull the blower vac by the
cord or yank the cord to disconnect it from the receptacle.
Keep the cord away from heat, oil, and sharp edges.
Double-Insulated Appliances
In a double-insulated appliance, two systems of insulation
are provided instead of grounding. No grounding means is
provided on a double-insulated appliance, nor should a means
for grounding be added to the appliance. Servicing a double-
insulated appliance requires extreme care and knowledge
of the system, and should be performed only by qualied
service personnel at an authorized Snow Joe
®
+ Sun Joe
®
dealer. Replacement parts for a double-insulated appliance
must be identical to the parts they replace. A double-insulated
appliance is marked with the words “Double Insulation” or
“Double Insulated.” The symbol
(square within a square)
may also be marked on the appliance.
DOUBLE-INSULATED: GROUNDING NOT
REQUIRED. WHEN SERVICING, USE ONLY
IDENTICAL REPLACEMENT PARTS.
This electric blower vac is double-insulated, eliminating the
need for a separate grounding system. Use only identical
replacement parts. Read the instructions before servicing
double-insulated appliances. Use this blower vac only as
described in this manual.
Extension Cord
Length
Wire Gauge (A.W.G.):
Up to 50 ft
(15 m)
+50 ft - 100 ft
(+15 m - 30 m)
14 12
m WARNING m
Electric shock may cause SEVERE INJURY or DEATH.
Heed these warnings:
• Do not allow any part of the electric blower vac to
make contact with water while it is in operation. If the
appliance becomes wet while turned o, wipe dry
before starting.
• Use only a UL-, CSA-, or ETL-rated extension cord
for outdoor, all-weather use, such as the Snow Joe
®
+
Sun Joe
®
SJTW-A 14-gauge 50-foot extension cord
with lighted end (Model PJEXT50-B). Visit sunjoe.com
to purchase this extension cord online or, to order by
phone, call 1-866-SNOWJOE (1-866-766-9563).
• Do not use an extension cord over 100 ft (30 m).
• Do not touch the appliance or its plug with wet hands
or while standing in water. Wearing rubber boots
oers some protection.
EXTENSION CORD CHART
(B) Connect plug and receptacle
Cord set Appliance cord
(A) Tie cord as shown
Table 1. Method of Securing Extension Cord
Safety Symbols
The following table depicts and describes safety symbols that may appear on this product. Read, understand, and follow all
instructions on the machine before attempting to assemble and operate.
READ THE OPERATOR'S
MANUAL(S) – Read,
understand, and follow
all instructions in the user
manual(s) before attempting to
assemble and operate.
SAFETY ALERT – Indicates
a precaution, a warning, or
a danger.
Immediately remove the plug
from the mains if the power
cable is damaged, frayed, or
entangled. Always keep the
power cable away from heat,
oil, and sharp edges.
DOUBLE INSULATION – When servicing, use only identical replacement parts.
WARNING! Do not expose the
unit to rain or wet conditions.
Wear hearing protection.
Wear eye protection.
Wear breathing protection.
Keep bystanders and children
a safe distance away.
Symbols SymbolsDescriptions Descriptions
DANGER! Rotating blades
pose a serious risk of injury.
Keep hands and feet away
from openings while the
machine is running.
The rotating part will continuously
run for several seconds after you
turn o the machine.
Beware of ying objects
and debris.
WARNING! Turn the machine
OFF and disconnect it from the
power supply before inspecting,
cleaning, changing accessories,
or conducting any other
maintenance task.
4
5
Know Your Electric Blower/Vacuum/Mulcher
Read the owner’s manual and safety instructions carefully before operating the electric blower vac. Compare the illustration
below to the electric blower vac in order to familiarize yourself with the location of the various controls and adjustments.
Save this manual for future reference.
Technical Data
Rated Voltage ........................................................ 120V ~ 60 Hz
Power ................................................................................... 14A
No Load Speed ......................................... 10,000 – 16,000 rpm
Rotor ..................................................... Aluminum alloy impeller
Air Speed Max ........................................... 250 mph (402 km/hr)
Blower Air Flow Max ................................ 150 cfm (4.2 m³/min)
Vacuum Air Flow Max ............................ 440 cfm (12.5 m³/min)
Variable Speed Settings ........................................................... 6
Mulch Reduction Ratio .........................................................16:1
Mode Conversion ...........................Blower to mulching vacuum
Bag Capacity ............................................................ 18 gal (68 l)
Blower Weight ...................................................... 6.6 lbs (3 kg)
Vacuum/Mulcher Weight .................................... 9.1 lbs (4.1 kg)
Gutter Attachment Weight .................................. 2.7 lbs (1.2 kg)
R
12
11
13
14
15
16
4
6
7
2
3
5
1
8
10
9
1. Variable blower speed control (speed settings 1 to 6)
2. Cord retainer
3. Appliance cord
4. Vacuum/mulcher inlet cover
5. Vacuum/mulcher inlet cover lock button
6. Rear vacuum/mulcher tube
7. Front vacuum/mulcher tube
8. Strap holder
9. Wheel
10. Collection bag
11. Handle
12. ON/OFF switch
13. Auxiliary handle
14. Tube release button
15. Blower tube
16. Blower concentrator nozzle
17. Gutter cleaning attachment kit
17
NOTE: The green adapter is for use with
iONBV Series only.
6
Unpacking
Carton Contents
• Electric blower/vacuum/mulcher
• Blower tube
• Blower concentrator nozzle
• Front vacuum/mulcher tube
• Rear vacuum/mulcher tube
• Collection bag
• Wheel assembly
• Gutter cleaning attachment
• Manuals with registration card
1. Carefully remove the electric blower/vacuum/mulcher and
check to see that all of the above items are supplied.
2. Inspect the product carefully to make sure no breakage or
damage occurred during shipping. If you nd damaged or
missing parts, DO NOT return the unit to the store. Please
call the Snow Joe
®
+ Sun Joe
®
customer service center at
1-866-SNOWJOE (1-866-766-9563).
NOTE: Do not discard the shipping carton and packaging
material until you are ready to use the electric blower/
vacuum/mulcher. The packaging is made of recyclable
materials. Properly dispose of these materials in
accordance with local regulations.
IMPORTANT! The equipment and packaging material are not
toys. Do not let children play with plastic bags, foils, or small
parts. These items can be swallowed and pose a suocation
risk!
Assembly
m
WARNING! To avoid serious personal injury, read and
understand all safety instructions provided.
mWARNING! Do not connect to power supply until
assembly is complete. Failure to comply could result in
accidental starting and possible serious personal injury.
mWARNING! Before performing any maintenance, make
sure the tool is unplugged from the power supply. Failure to
heed this warning could result in serious personal injury.
mWARNING! To prevent serious personal injury,
make sure the switch is in the OFF (O) position, the unit is
unplugged, and the impeller has come to a complete stop
before attaching or removing tubes.
Assemble as a Blower
1. Slide the blower tube forward until the notched area on
the blower housing clicks into the slot on the blower tube
(Fig. 1).
2. Insert the concentrator nozzle onto the end of the blower
tube until it locks into position (Fig. 1).
NOTE: The concentrator nozzle is used to increase
air ow in tight areas (i.e around ower beds, under
decks, etc.).
3. Before using the blower function, securely fasten the inlet
cover over the air inlet until the lock button snaps into the
locked position (Fig. 2).
4. To remove the blower tube, turn the ON/OFF power switch
to the OFF (O) position and disconnect the tool from the
power supply.
5. Press the tube release button and remove the blower tube
(Fig. 3).
Fig. 1
Notched
area
Slot
Blower tube
Air outlet
Concentrator
nozzle
Fig. 2
Inlet cover
lock button
Inlet
cover
Fig. 3
Tube release button
Blower tube
ON/OFF switch
7
Gutter Cleaning Attachment Kit
Rid yourself of gutter-clogging leaves, dirt and debris without
ever having to set foot on an unsteady stepladder or hang
dangerously from your downspout. Simply attach the sturdy,
detachable PVC tubes to extend your reach up to 15' and
unleash a tornado in your gutter tubs. Regularly cleaning your
gutters ensures clear, clog-free performance and eliminates the
potential for costly ice dams.
mCAUTION! All operators must wear close-tting
clothing, safety goggles, and a dust mask when using this
attachment on their electric blower. Keep all bystanders and
pets a safe distance away from the work area. Beware of
foreign objects that could be thrown by the blower.
• DO NOT operate the blower with this attached gutter
cleaner when fatigued.
• DO NOT overreach or stand on an unstable support. Keep
proper footing and balance at all times.
• Never direct airow towards bystanders. Always be aware of
the direction in which the debris will be thrown.
• Use a face lter mask to avoid breathing dust and debris.
1. Attach the gutter kit as shown in Figs. 4 and 5: Connect
the A, B, and C components by screwing them together.
Then snap the A, B and C assembly into D, and then snap
the completed gutter atttachment into the electric blower.
NOTE: Use only enough gutter tube extensions to
comfortably reach the inside of the rain gutter you wish to
clear.
NOTE: The green adapter is for use with iONBV Series only.
2. The gutter tube nozzle (A) can be adjusted to any desired
direction by rotating the gutter tube connecter (D) as
shown in Fig. 6. Gutter cleaning applications will vary.
We recommend you try various nozzle positions until you
nd the one that works most eectively with your home’s
gutter design.
NOTE: If you have any questions, please call the Snow Joe
®
+
Sun Joe
®
customer service department at 1-866-SNOWJOE
(1-866-766-9563) for assistance.
Fig. 4
Gutter tube nozzle
Gutter tube adapter
Gutter tube connectors
(Green + Black)
Gutter tube extension
A
B
C
D
Fig. 5
A B
B
C
B
B
D
Fig. 6
Gutter tube nozzle
Gutter tube
connector
8
Assemble as a Vacuum/Mulcher
1. Slide the front and rear vacuum/mulcher tubes together
until the lock button engages (Fig. 7).
2. Slide the inlet cover lock button forward to disengage the
inlet cover. Hold the cover open (Fig. 8).
3. With the blower tube removed from the blower housing,
insert the "hooked" side end of the vacuum/mulcher tube
into the rear clip on the unit. Securely fasten the vacuum/
mulcher tube by pushing the "wedged" side end of the
vacuum/mulcher tube up until the lock button snaps into
the locked position (Fig. 9).
4. Insert the collection bag adaptor into the blower air outlet
until the collection bag is securely fastened (Fig. 10), then
clip the bag to the strap holder.
5. Press the button on the wheel assembly, then slide it onto
the lead rail. Adjust the wheel position by pressing the
button and sliding the wheel assembly up and down the
lead rail until the desired setting is reached (Fig. 11).
6. To remove the bag, press the tube release button and slide
the bag o of the unit. Unclip the bag from the strap holder
(Fig. 12).
Fig. 7
Rear tube Front tube
Fig. 8
Inlet cover
lock button
Inlet cover
Fig. 9
Rear clip +
Hook side
Wedged side
R
Fig. 10
Collection bag
Air outlet
Collection
bag adaptor
Fig. 11
Press button to adjust position
Lead rail
Wheel
Assembly
Button
R
Fig. 12
Tube
release
button
9
7. To remove the vacuum/mulcher tube assembly, slide the
inlet cover lock button to unlock, then remove the tube
assembly from its housing (Fig. 13).
NOTE: It may be necessary to remove the blower tube or
vacuum/mulcher tubes to clear a blocked tube or impeller.
Make sure to disconnect the unit from the power supply
before attempting to clear any obstructions.
Operation
Connecting to a Power Source
1. Secure the extension cord to the motor housing using the
cord retainer located at the rear of the blower. Securing
the extension cord in this manner prevents accidental
removal of the electrical cord during operation (Fig. 14).
2. Connect the extension cord to the appliance cord
(Fig. 14).
Starting + Stopping
1. To start the electric blower/vacuum/mulcher, slide the
ON/OFF switch to the ON position (I) (Fig. 15).
2. To stop the unit, slide the ON/OFF switch to the OFF
position (O) (Fig. 15).
Speed Control
This unit is equipped with six variable speed settings (1 to 6)
(Fig. 16).
• Turn the speed dial to position “1” or “2” for LOW speeds.
• Turn the speed dial to position “3” or “4” for
MEDIUM speeds.
• Turn the speed dial to position “5” or “6” for
HIGH speeds.
Operating Tips
mWARNING! Use the blower/vacuum/mulcher only in
daylight or good articial light.
• When using the blower vac, plant your feet rmly on the
ground and place one hand on the unit handle and the
other hand on the auxiliary handle.
• Wear personal protective equipment during your work
session. This includes boots, safety glasses/goggles, ear
defenders, long pants, and a long-sleeve shirt.
Fig. 13
Inlet cover
lock button
Fig. 14
Cord retainer
Extension
cord
Fig. 15
ON (I)
OFF (O)
Fig. 16
6 5 4 3 2 1
Variable blower
speed control
10
• When using the unit as a vacuum/mulcher, make sure the
bag is properly installed and zipped closed.
• Make sure the blower tube nozzle is not directed at
anybody or any loose debris before starting the unit.
• Verify that the unit is in good working condition. Make
sure the tubes and guards are in place and secure.
• Ensure that the vacuum/mulch inlet cover is completely
closed and locked.
• Keep a rm grip on both the front and rear handle or grips.
• To reduce the risk of hearing loss associated with sound
level(s), hearing protection is required.
• Operate this blower vac and other power equipment only
at reasonable hours. Avoid use early in the morning or late
at night when people might be disturbed. Comply with
times listed in local ordinances. Usual recommendations
are 9:00 am to 5:00 pm, Monday through Saturday.
• To reduce noise levels, limit the number of pieces of
power equipment used at any one time and operate
power blowers at the lowest possible speed setting
necessary to do the job.
• Use rakes and brooms to loosen debris before blowing.
• In dusty conditions, slightly dampen surfaces.
• Conserve water by using power blowers instead of hoses
for many lawn and garden applications, such as cleaning
gutters, screens, patios, grills, porches, and gardens.
• Blow debris into a safe, open area away from children,
pets, open windows, or freshly washed cars.
• Clean up after using leaf blowers and other lawn
equipment. Dispose of debris appropriately.
mWARNING! To avoid serious personal injury, wear
ear defenders, goggles, or safety glasses at all times when
operating this unit. Wear a face mask or dust mask in dusty
locations.
mWARNING! To prevent serious personal injury or
damage to the unit, make sure the blower tube or the vacuum/
mulcher tubes and the collection bag are in place before
operating the unit.
Air Vents
Never cover air vents. Keep them free from obstructions
and debris. They must always remain clear for proper motor
cooling.
mWARNING! To avoid serious personal injury, tie back
long hair and do not wear loose tting clothing or dangling
articles such as scarves, strings, chains, ties, etc. Such items
could get drawn into the air vents.
Blower Mode
• Hold the blower rmly with one hand on the main handle
and the other hand on the auxiliary handle. Sweep from
side to side with the nozzle several inches above the
ground or oor (Fig. 17).
• Slowly advance the unit, keeping the accumulated pile
of debris in front of you. Most dry blowing operations are
better suited to low speeds rather than high speeds. High
speed blowing is best for moving heavier items like large
debris or gravel.
Vacuum + Mulcher Mode
• Once you have blown the debris/leaves into a pile, you
can convert to vacuum/mulcher mode to collect the
debris.
• With a rm hold on the unit, tilt the vacuum/mulcher tubes
2 in. (5 cm) from the ground and use a sweeping action
to collect light debris. The debris will ow into the bag.
Items such as small leaves and twigs will be mulched as
they pass through the fan housing. For longer bag life and
optimal performance, empty the bag frequently
(Fig. 18).
• Move easily from one pile of debris to the next by gliding
the vacuum/mulcher along the ground using the wheel
assist assembly.
Fig. 17
R
Fig. 18
11
• As the bag lls, suction power will decrease. When this
happens, turn the power switch to the OFF (O) position
and unplug the unit from the power supply. Remove the
bag and empty the debris.
• To remove the bag, press the tube release button
(Fig. 12). To empty, hold the plastic handle and grab the
nylon handle on the underside of the bag. Turn the bag
upside down and shake out any debris and leaves.
mWARNING! Never remove the collection bag without
rst turning the power switch to the OFF (O) position and
unplugging the unit from the main power source.
mWARNING! Do not use in vacuum/mulcher mode
without the vacuum/mulcher tubes and collection bag in place.
Clearing a Blocked Tube/Impeller
mWARNING! To avoid serious personal injury, be sure the
unit is OFF and unplugged before clearing the impeller.
mWARNING! To avoid serious personal injury, always
wear gloves to protect yourself from the impeller blades or
other sharp objects.
During the vacuuming/mulching process, certain objects such
as cloth, rope, or large diameter sticks may obstruct the fan
and block the motor. A thermal protection device, which is built
into the blower vac, will cut o the electricity to the motor to
prevent damage from overheating.
In the event an obstruction occurs and power is curtailed:
1. Slide the ON/OFF switch to the OFF (O) position until the
unit comes to a complete stop.
2. Unplug the unit.
3. Remove the blower tube or vacuum/mulcher tubes and
the collection bag.
4. Using protective gloves, carefully remove the material
blocking the tube or impeller. Inspect the blades to ensure
no damage has occurred. Rotate the impeller blades by
hand to ensure the blockage is completely cleared.
5. Reinstall the blower tube or vacuum/mulcher tubes and
the collection bag.
6. Wait 3 minutes for the motor to cool.
7. Plug the unit back into the power supply and turn the ON/
OFF switch to the ON (I) position. The blower vac will
resume normal function.
Maintenance
To order genuine replacement parts or accessories for the
Sun Joe
®
SBJ606E-GA electric blower/vacuum/mulcher,
please visit sunjoe.com or contact the Snow Joe
®
+
Sun Joe
®
customer service center at 1-866-SNOWJOE
(1-866-766-9563).
mWARNING! Disconnect the extension cord before
performing any maintenance task.
If the extension cord is plugged into the appliance, someone
could accidentally turn on the unit while you are inspecting it,
which could result in serious personal injury.
Cleaning the Unit
mWARNING! To avoid serious personal injury, always turn
the unit o and unplug it before cleaning or servicing.
Use a small brush to clean the outside of the unit. Do not use
strong detergents, household cleaners that contain aromatic
oils (e.g. pine and lemon), or harsh solvents such as kerosene
as these substances can damage the plastic housing or the
handles. Wipe o any moisture with a soft, dry cloth.
1. Empty the bag after each use to avoid deterioration and
air ow obstruction, which will reduce the performance of
the vacuum/mulcher.
2. Wear eye protection and a dust mask. Clean the bag as
needed. Turn the bag inside out after initial emptying and
vigorously shake out any dust and debris.
3. Wash the bag once a year, or more often if needed. Follow
the steps below:
i. Remove the bag.
ii. Turn the bag inside out.
iii. Hang it up.
iv. Hose it down thoroughly.
v. Leave it hanging to dry.
vi. Turn the bag right-side up and reinstall.
12
Storage
1. Examine the electric blower/vacuum/mulcher thoroughly
for worn, loose, or damaged parts. Should you need to
repair or replace a part, contact an authorized Snow Joe
®
+
Sun Joe
®
dealer or call the Snow Joe
®
+ Sun Joe
®
customer service center at 1-866-SNOWJOE
(1-866-766-9563) for assistance.
2. Examine the extension cord thoroughly for signs of
excess wear or damage. If it is worn or damaged, replace
it immediately.
3. Disconnect the extension cord from the electric blower/
vacuum/mulcher before storing.
4. Store the cord with the electric blower/vacuum/mulcher
indoors in a clean, dry, and locked location out of the
reach of children and animals.
NOTE: Devices for retaining extension cords are
commercially available should you wish to purchase one.
Service + Support
If your Sun Joe
®
SBJ606E-GA electric blower/vacuum/mulcher
requires service or maintenance, please call the Snow Joe
®
+
Sun Joe
®
customer service center at 1-866-SNOWJOE
(1-866-766-9563).
Model + Serial Numbers
When contacting the company, reordering parts, or arranging
service from an authorized dealer, you will need to provide the
model and serial numbers, which can be found on the decal
located on the housing of the unit. Copy these numbers into
the space provided below.
Record the following numbers from the housing or handle of your
new product:
Model #:
Serial #:
SBJ606E-GA
13
Troubleshooting
m
WARNING! Always unplug the power cord before performing any adjustments, maintenance, or repairs to your
electric blower vac.
Unit will not blow
or mulch
Unit will not start
1. Bag full
2. Blocked tube
3. Blocked impeller
4. Dirty bag
5. Torn bag
6. Bag unzipped
7. Unit unplugged
1. Unit is unplugged.
2. Power/speed switch is in the OFF (O)
position.
3. Defective power switch.
4. Vac tubes are not correctly installed.
5. Intake gate/cover is not closed.
6. House circuit may have tripped.
1. Empty the bag.
2. Clear the blockage.
3. Clear the blockage.
4. Clean the bag.
5. Replace the bag.
6. Zip up the bag.
7. Plug into an outlet or an extension cord.
1. Check cord to make sure it is plugged into an
electrical outlet.
2. Slide the power switch to the ON (I) position and
select your desired speed setting with the speed
control switch.
3. Call the Snow Joe
®
+ Sun Joe
®
customer
service center at 1-866-SNOWJOE
(1-866-766-9563).
4. Check vac tubes and ensure that they are
correctly installed to allow the switch to
be engaged.
5. Ensure that gate/cover is fully closed
and locked.
6. Check wall circuit breaker panel and reset
if necessary.
Problem Possible Cause Solution
Optional Accessories
mWARNING! ALWAYS use only authorized Snow Joe
®
+ Sun Joe
®
replacement parts and accessories. NEVER use
replacement parts or accessories that are not intended for use with this electric blower vac. Contact Snow Joe
®
+ Sun Joe
®
if you
are unsure whether it is safe to use a particular replacement part or accessory with your electric blower vac. The use of any other
attachment or accessory can be dangerous and could cause injury or mechanical damage.
NOTE: Accessories are subject to change without any obligation on the part of Snow Joe
®
+ Sun Joe
®
to provide notice of such
changes. Accessories can be ordered online at sunjoe.com or via phone by contacting the Snow Joe
®
+ Sun Joe
®
customer
service center at 1-866-SNOWJOE (1-866-766-9563).
18-Gallon (68 l) collection bag
Gutter cleaning attachment kit
Universal wall bracket with
mounting hardware
Snow Joe
®
+ Sun Joe
®
SJTW-A 14-gauge
50-foot extension cord with lighted end
SBJ605E-BAG18
(For use with blower vac
models SBJ603E + SBJ605E
+ SBJ606E-GA)
SBJ6-GA
(For use with blower vac
models SBJ601E + SBJ603E
+ SBJ605E + SBJ606E-GA +
iONBV)
SJWB
(Fits most Snow Joe
®
+
Sun Joe
®
tools)
PJEXT50-B
ModelAccessories Item
1
2
3
4
5
12-Gallon (45 l) collection bag
SBJ603E-BAG
(For use with blower vac
models SBJ603E + SBJ605E +
SBJ606E-GA)
R
14
R
15
R4_01282020
SNOW JOE
®
+ SUN JOE
®
CUSTOMER PROMISE
OUR WARRANTY:
Snow Joe
warrants new, genuine, powered and non-powered Products to be free from defects in material or workmanship when used
for ordinary household use for a period of two years from the date of purchase by the original, end-user purchaser when purchased
from Snow Joe or from one of Snow Joe’s authorized sellers with proof of purchase. Because Snow Joe is unable to control the quality
of its Products sold by unauthorized sellers, unless otherwise prohibited by law, this Warranty does not cover Products purchased from
unauthorized sellers. If your Product does not work or there’s an issue with a specic part that is covered by the terms of this Warranty,
Snow Joe will elect to either (1) send you a free replacement part, (2) replace the Product with a new or comparable product at no
charge, or (3) repair the Product. How cool is that!
This Warranty gives you specific legal rights, and you may also have other rights which vary from State to State.
PRODUCT REGISTRATION:
Snow Joe strongly encourages you to register your Product. You can register online at snowjoe.com/register, or by printing and
mailing in a registration card available online from our website, or calling our Customer Service Department at 1-866-SNOWJOE
(1-866-766-9563), or by e-mailing us at [email protected]. Failure to register your Product will not diminish your warranty
rights. However, registering your Product will allow Snow Joe to better serve you with any of your customer service needs.
WHO CAN SEEK LIMITED WARRANTY COVERAGE:
This Warranty is extended by Snow Joe to the original purchaser and original owner of the Product.
WHAT IS NOT COVERED?
This Warranty does not apply if the Product has been used commercially or for non-household or rental applications. This Warranty also
does not apply if the Product was purchased from an unauthorized seller. This Warranty also does not cover cosmetic changes that do
not aect performance. Wearing parts like belts, augers, chains and tines are not covered under this Warranty, and can be purchased
at snowjoe.com or by calling 1-866-SNOWJOE (1-866-766-9563).
ABOVE ALL ELSE, Snow Joe, LLC (“Snow Joe”) is dedicated to you, our customer. We strive to make your experience as pleasant as
possible. Unfortunately, there are times when a Snow Joe
®
, Sun Joe
®
, or Aqua Joe
®
product (“Product”) does not work or breaks under
normal operating conditions. We think it’s important that you know what you can expect from us. That’s why we have a Limited Warranty
(“Warranty”) for our Products.
sunjoe.com
