Washer-Dryer
User Manual
GWDI8541
2820528869_EN/ 22-12-20.(15:30)Document Number :
Please read this user
manual first!
Dear Customer,
Thank you for choosing a Grundig product. We
hope that you get the best results from your
product which has been manufactured with
high quality and state-of-the-art technology.
Therefore, please read this entire user manual
and all other accompanying documents
carefully before using the product and keep it
as a reference for future use. If you handover
the product to someone else, give the user
manual as well. Follow all warnings and
information in the user manual.Throughout this
user manual the following symbols are used:
B
DANGER!
• Warning for electric shock.
DANGER!
• Product weight warning
DANGER!
• Fire risk warning.
A
CAUTION!
• Warning for hazardous situations
with regard to life and property.
A
PRECAUTION!
• Precautions that need to be taken.
C
INFORMATION
• Important information or useful hints about
usage.
• Read user manual.
• Packaging materials of the
product are manufactured
from recyclable materials in
accordance with regulations.
• Do not dispose of the
Packaging materials
together with the domestic
or other wastes. Take them
to the packaging material
collection points designated
by the local authorities.
• Allergy UK, is the brand of
British Allergy Association. Their
main endorsement is the ‚Seal
of Approval‘. When you see
a product with this logo on it,
you have the reassurance the
product has been scientifically
tested to prove it is efficient at
reducing/removing allergens
from the environment
of allergy and asthma
sufferers or the products
have significantly reduced
allergen/chemical content.
3 / EN
Washer-Dryer / User Manual
1 Important instructions for safety and environment
This section contains safety instructions
that will help protect from risk of
personal injury or property damage.
Failure to follow these instructions
shall invalidate any warranty.
1.1 General safety
A
CAUTION!
• This product can be used by
children at and above 8 years old
and by persons whose physical,
sensory or mental capabilities
were not fully developed or who
lack experience and knowledge
provided that they are supervised
or trained on the safe usage of the
product and the risks it brings out.
Children should not play with the
device. Cleaning and maintenance
works should not be performed by
children unless they are supervised
by someone. Children under the
age of 3 should be kept away
unless continuously supervised.
A
PRECAUTION!
• Never place the product on a
carpet-covered floor. Otherwise,
lack of airflow beneath the machine
will cause electrical parts to
overheat. This will cause problems
with your product.
C
INFORMATION
• Always have the installation
procedures carried out by the
competent persons. Manufacturer
shall not be held liable for damages
that may arise from procedures
carried out by unauthorised persons.
A
PRECAUTION!
• If the product will be used inside
a wardrobe/cabinet/module, it is
recommended to keep the doors of
the wardrobe/cabinet/module open
during operation in cases where
there are no openings to provide
sufficient air circulation.
1.1.1 Electrical safety
B
DANGER!
• If the product has a failure, it should
not be operated unless it is repaired
by the Authorised Service Agent.
There is the risk of electric shock!
• Never wash the product by
spreading or pouring water onto it!
There is the risk of electric shock!
A
CAUTION!
• If the power cable is damaged,
it must be replaced by the
manufacturer, after sales service
or a similarly qualified person
(preferably an electrician) or
someone designated by the importer
in order to avoid possible risks.
4 / EN
Washer-Dryer / User Manual
A
PRECAUTION!
• Unplug the product when it is not
in use.
• Never touch the plug with wet hands!
Never unplug by pulling on the cable,
always unplug by holding the plug.
• Product should be unplugged
during installation, maintenance,
cleaning and repair procedures.
• Do not make connections via
extension cables or multi-plugs.
C
INFORMATION
• This product is designed to resume
operating in the event of powering
on after a power interruption. If you
wish to cancel the programme, see
“Cancelling the programme” section.
1.1.2 Product safety
B
DANGER!
• Never open the loading door or
remove the filter while there is
still water in the drum. Otherwise,
risk of flooding and injury from hot
water will occur.
A
CAUTION!
• The water supply and draining
hoses must be securely fastened
and remain undamaged. Otherwise,
there is the risk of water leakage.
A
PRECAUTION!
• The product should be used without
removing the upper plate.
C
INFORMATION
• Do not force open the locked
loading door. Door can be opened
a few minutes after the washing
cycle ends. If the machine has not
cooled enough at the end of the
programme, loading door cannot
be opened. Do not force the loading
door to open. It must be left to cool
itself. The loading door and the lock
mechanism may get damaged.
• In the installation location of this
product, there must not be a
lockable, sliding or hinged door that
will restrict the full opening of the
loading door.
• Follow the instructions on the textile
tags and on the detergent package.
• Use only detergents, softeners and
supplements suitable for washing
machines.
• Do not install or leave this product
in places where it might be exposed
to outdoor conditions.
• Controls must not be tampered with.
• If a non-self-resetting thermal cut-out
is required in order to comply with
the standard then the instructions for
appliances incorporating a non-self-
resetting thermal cutout that is reset
by disconnection of the supply mains
shall contain the substance of the
following:
CAUTION: In order to avoid a hazard
due to inadvertent resetting of the
thermal cut-out, this appliance must
not be supplied through an external
switching device, such as a timer, or
connected to a circuit that is regularly
switched on and off by the utility.
5 / EN
Washer-Dryer / User Manual
1.1.3 Warnings for drying
DANGER!
• Laundry that is previously washed,
cleaned, soiled or stained with
petrol / gasoline, dry cleaning
solvents or other flammable or
explosive substances must not be
dried in the machine as they give
out flammable or explosive steam.
It may cause fire risk.
DANGER!
• Laundry stained with Liquid
cooking oil, acetone, alcohol,
petrol, kerosene, spot removers,
turpentine, waxes and wax
removers must be washed in hot
water with plenty of detergent
before drying. It may cause fire risk.
• Foam rubber (latex foam), shower
caps, waterproof textiles, clothes
or pillows with rubber support or
rubber foam pads must not be
dried with drying function. It may
cause fire risk.
• If you use washing ball, detergent
scale, laundry clothing cages and
balls in your machine, they can
melt during drying. Do not use
these products if drying option will
be selected. It may cause fire risk.
• When you use industrial chemicals
for cleaning, do not use drying
function. It may cause fire risk.
B
DANGER!
• Do not touch loading door glass
with bare hands after drying. There
is the risk of getting burnt.
• In order to maintain laundry in a
temperature that will prevent them
from getting damaged, a cooling step
is performed as a final step. You may
be exposed to hot steam if you open
the door before cooling is complete.
There is the risk of scalding.
B
DANGER!
• If the drying programmes are
interrupted (as a result of programme
cancellation or power failure), laundry
in the machine can be hot. Be careful.
A
CAUTION!
• Do not stop the machine before
drying programme is completed.
If you have to stop the machine,
remove all laundry and lay them in a
suitable place to let them cool down.
• Your product is suitable to operate in
ambient temperatures between 0°C
and +35°C.
6 / EN
Washer-Dryer / User Manual
A
CAUTION!
• Ambient temperatures between 15°C
and +25°C are ideal temperatures
for your product.
• Do not let pets enter the product.
Check inside the product before using.
• Do not overload the machine for
drying. Observe the maximum load
levels specified for drying.
A
PRECAUTION!
• Do not dry leather laundry or laundry
that contains leather (such as leather
jeans label). The colour from Leather
parts can run into other textiles.
• In failures that cannot be repaired
using information given in safety
instructions, turn off the machine,
unplug the power cable and call the
Authorised Service Agent.
• You can just wash laundry, just dry
laundry or wash and dry laundry in
your washer-dryer. Machine must
not be used only to dry wet loads
for a long time. When machine is
used only for drying, it must be
operated empty without loading
laundry in a short wash programme
after every 15 operation.
• Check all clothes before loading
them into the machine and ensure
that they do not have objects such
as lighters, coins, metal pieces,
needles in the pockets or inside.
• Underwear with metal supports must
not be dried in the machine. Metal
supports might come off during drying
and cause damage in the machine.
Place in a bag or pillowcase.
A
PRECAUTION!
• Do not dry large laundry such as tulle
curtain, curtain, bedding, blanket, rug
in the machine. Your laundry might get
damaged.
C
INFORMATION
• Do not dry unwashed laundry in the
machine.
• Do not use fabric softeners or static
preventers in the machine unless
recommended by the manufacturer.
• Products such as fabric softeners
must be used in accordance with
manufacturer’s instructions.
• Do not dry sensitive clothes such as silk,
wool, etc. in the machine. Otherwise,
wool clothes may get shrunken and other
sensitive clothes may get damaged.
• Check symbols on the garment tag
before washing and drying.
7 / EN
Washer-Dryer / User Manual
1.2 Intended use
C
INFORMATION
• This product has been designed for
domestic use. It is not suitable for
commercial use and it must not be
used out of its intended use.
• The product must only be used for
washing, rinsing and drying of textile
products that are marked accordingly.
• The manufacturer waives any
responsibility arisen from incorrect
usage or trans
portation.
• The service life of your product is
10 years. During this period, original
spare parts will be available to
operate the product properly.
• This appliance is intended to be used
in household and similar applications
such as:
– staff kitchen areas in shops, offices
and other working environments;
– farm houses;
– by clients in hotels, motels and
other residential type environments;
– bed and breakfast type
environments;
– areas for communal use in blocks
of flats or in launderettes.
1.3 Children's safety
A
CAUTION!
• Children below the age of 3 must be
kept away from the machine unless
they are continuously supervised.
• Packaging materials are dangerous to
children. Keep packaging materials in
a safe place away from reach of the
children.
• Electrical products are dangerous for
the children. Keep children away from
the product when it is in use. Do not
allow them to play with the product.
Use child lock to prevent children
from intervening with the product.
• Do not forget to close the loading
door when leaving the room where
the product is located.
• Store all detergents and additives in
a safe place away from the reach of
the children by closing the cover of
the detergent container or sealing the
detergent package.
8 / EN
Washer-Dryer / User Manual
1.4 Compliance with WEEE
Directive and disposing
of the waste product
This product does not contain harmful and
forbidden materials described in the "Regulation on
the Control of the Waste Electrical and Electronic
Equipment". It complies with the WEEE Directive.
This product has been
manufactured with high quality
parts and materials which can
be reused and are suitable for
recycling. Therefore, do not
dispose the product with normal
domestic waste at the end of its
service life. Take it to a collection
point for the recycling of electrical
and electronic equipment. Please
consult your local authorities to
learn the nearest collection point.
Help protect the environment and natural
resources by recycling used products.
For children’s safety, cut the power cable
and break the locking mechanism of the
loading door so that it will be non-functional
before disposing of the product.
Compliance with RoHS Directive:
The product you have purchased complies
with EU RoHS Directive (2011/65/EU). It
does not contain harmful and prohibited
materials specified in the Directive.
1.5 Package information
Packaging materials of the product are
manufactured from recyclable materials in
accordance with our National Environment
Regulations. Do not dispose of the packaging
with normal domestic waste. Take them
to the packaging material collection points
designated by the local authorities.
2 Your washer-dryer
2.1 Overview
3
4
5
2
1
6
7
8
1- Power cable
2- Top panel
3- Control panel
4- Filter cover
5- Adjustable feet
6- Loading door
7- Detergent drawer
8- Water discharge hose
9 / EN
Washer-Dryer / User Manual
2.2 Package contents
Power cable
Water discharge hose
Transit bolts
Mains water inlet hose
User manual
Plastic plug group
NOTE
• Figures in this manual are schematic and may not match the product exactly.
10 / EN
Washer-Dryer / User Manual
2.3 Technical specifications
C
INFORMATION
SUPPLIER’S NAME MODEL IDENTIFIER
A
A
(*)
• The model information as stored in the
product database can be reached by entering
following website and searching for your
model identifier (*) found on energy label.
https://eprel.ec.europa.eu/
Supplier name or trademark GRUNDIG
Model name
GWDI8541
7165144300
Maximum spin speed (rpm) 1400
Washing capacity (cotton) (kg) 8
Drying capacity (cotton) (kg) 5
Built-in Yes
Height (cm) 82
Width (cm) 60
Depth (cm) 55
Single Water inlet / Double Water inlet
• / -
• Available
Electrical input (V/Hz) 230 V / 50Hz
Total current (A) 10
Total power (W) 2200
Main model code 9620
Rinse
Spin+Drain
Prewash Fast Fast+ Extra
Rinse
Extra
Water
Anti
Crease
Pet Hair
Removal
Rinse
Hold
No
Water
Drain
Soaking
Spin No
Spin
Tap
Water
(Cold)
Steam
Time
Delay
Night
Modu
Temperature Door
Lock
Child
Lock
On/Off Start /
Pause
Soil Level Add
Garment
AutoDose
Liquid
Detergent
Selection
Softener
Selection
Wash
Downloaded
Program
Steeping
Ok
(End)
Cancel
AntiCrease+ Iron
Dry
Cupboard
Dry
Extra
Dry
Timed
Drying
Clean&
Wear
Symbols Table
Drying
11 / EN
Washer-Dryer / User Manual
3 Installation
To make the product ready for use, review the
information in the user manual and make sure
that the electricity, tap water supply and water
drainage systems are appropriate. If they are
not, call a qualified technician and plumber to
have any necessary arrangements carried out.
B
DANGER!
• Make sure that the installation and
electrical connections of the product
are performed by competent persons.
Manufacturer shall not be held liable for
damages that may arise from procedures
carried out by unauthorised persons.
DANGER!
• Your product is too heavy for
one person to carry.
A
CAUTION!
• Prior to installation, visually check if
the product has any defects on it. If
so, do not have it installed. Damaged
products cause risks for your safety.
A
PRECAUTION!
• Preparation of the location and
electrical, tap water and waste water
installations at the place of installation
is under customer’s responsibility.
• Make sure that the water inlet and
discharge hoses as well as the power
cable are not folded, pinched or crushed
while pushing the product into its place
after installation or cleaning procedures.
3.1 Appropriate
installation location
• Place the product on a solid and level
floor. Do not place it onto a carpet with
high pile or other similar surfaces.
• Do not place the product close to the
edge if the floor contains steps. Do not
also place the product on a platform.
• Do not place the product on the power cable.
• Do not install the product in environments
where the temperature falls below
0 ºC.(See. Warnings for Drying)
• Leaving a gap at the sides of the machine
is suggested to reduce vibration and noise
• In the area where this product is
installed, there must not be a lockable,
sliding or hinged door that will restrict
the full opening of loading door.
• Operate the product in a well ventilated
and dust free environment.
• Do not place heat sources such as Hobs,
Irons, Ovens, etc. on the washing machine
and do not use them on the product
3.2 Removing packaging
reinforcement
Tilt the machine backwards to remove
the packaging reinforcement. Remove the
packaging reinforcement attached to the ribbon.
B
DANGER!
• Your product is heavy. Remove packaging
reinforcement as displayed in the figure.
• Be careful not to get your hand caught
under the machine during this procedure.
12 / EN
Washer-Dryer / User Manual
3.3 Removing the transit bolts
A
PRECAUTION!
• Do not remove the transit bolts before
removing the packaging reinforcement.
• Remove the transit bolts before operating
the washing machine! Otherwise,
the product will get damaged.
3
2
1
1 Use a tool to loosen all bolts
until they rotate freely.
2 Remove the transit bolts by
turning them slightly.
3 Attach the plastic covers supplied in the user
manual bag into the holes on the rear panel.
C
INFORMATION
• Keep the transit bolts in a safe place
to reuse when the product needs
to be moved again in the future.
• Never move the product without the
transit bolts properly fixed in place!
3.4 Connecting water supply
C
INFORMATION
• The water supply pressure required to
run the product is between 1 to 10 bars
(0.1 – 1 MPa). It is necessary to have
10 – 80 liters of water flowing from the
fully open tap in one minute to have your
product run smoothly. Attach a pressure
reducing valve if water pressure is higher.
A
CAUTION!
• Models with a single water inlet should
not be connected to the hot water
tap. In such a case the laundry will get
damaged or the product will switch to
protection mode and will not operate.
• Do not use old or used water inlet
hoses on the new product. It may
cause stains on your laundry.
1 2 3
1 Connect the special hose supplied with the
product to the water inlet on the product.
A
CAUTION!
• Ensure that the cold water connection
is made correctly when installing the
product. Otherwise, your laundry
will come out hot at the end of the
washing process and wear out.
2 Tighten the hose nuts securely by hand.
Never use a tool when tightening the nuts.
3 Open the taps completely after making the
hose connection to check for water leaks at
the connection points. If any leak occurs, turn
off the tap and remove the nut. Retighten the
nut carefully after checking the seal. In order
to prevent the water leaks, keep the taps
closed when you do not use the product.
3.5 Connecting to the drain
• Attach the end of the drain hose directly
to waste water drain, sink or bathtub.
A
CAUTION!
• Your house will be flooded if the hose
comes out of its housing during water
discharge. Moreover, there is risk of
scalding due to high washing temperatures!
To prevent such situations and to ensure
smooth water intake and discharge of
the machine, fix the end of the discharge
hose tightly so that it cannot displace.
90 cm
90
40
90
40
90 cm
90 cm
min.40
• Connect the hose to a minimum height of
40 cm and a maximum height of 90 cm.
13 / EN
Washer-Dryer / User Manual
• If the hose is run along the floor (or at less
than 40 cm above it) and raised later on,
water drain becomes difficult and laundry
may come out extremely wet. Therefore,
observe the heights described in the figure.
• To prevent flowing of dirty water back into
the machine and to allow for easy discharge,
do not immerse the hose end into the dirty
water or do not drive it in the drain more
than 15 cm. If it is too long, cut it short.
• The end of the hose should not be
bent, it should not be stepped on
and the hose must not be pinched
between the drain and the machine.
• If the length of the hose is too short, add an
original extension hose. Length of the hose
may not be longer than 3.2 m. To avoid water
leak failures, the connection between the
extension hose and the drain hose of the
product must be fitted well with an appropriate
clamp as not to come off and leak.
3.6 Adjusting the feet
A
CAUTION!
• Adjust feet so that the product will be
balanced in the location it will be used.
• Balance the machine by adjusting the feet.
• Check for any play by pressing the
product from upper diagonal edges.
• Otherwise, the product may move
from its place and cause crushing,
noise and vibration problems.
• Do not use any tools to loosen
the lock nuts. Otherwise, the
lock nuts may get damaged.
a) Loosen the lock nuts on the feet by hand.
b) Adjust the feet until the product
stands level and balanced.
c) Tighten all lock nuts again by hand.
Adjusting Rear Feet
• When you turn the knob (visible in the circle)
in the direction of the arrow, the machine
will be elevated by 0.3 mm. When you turn
it in the opposite direction of the arrow,
the machine will be lowered by 0.3 mm.
• Do not adjust the rear feet by
using chargeable devices. Use
a screwdriver instead.
3.7 Electrical connection
Connect the product to a grounded outlet
protected by a 13 A fuse. Our company shall
not be liable for any damages that will arise
when the product is used without grounding
in accordance with the local regulations.
• Connection must comply with
national regulations.
• The wiring for the electrical outlet circuit
must be sufficient to meet the appliance
requirements. Use of a Groud Fault Circuit
Interrupter (GFCI) is recommended.
• Power cable plug must be within
easy reach after installation.
• If the current value of the fuse or breaker
in the house is less than 13 Amps, have a
qualified electrician install a 13 Amp fuse.
• The voltage specified in the "Technical
specifications" section must be
equal to your mains voltage.
B
DANGER!
• Damaged power cables must be replaced
by the Authorised Service Agent.
14 / EN
Washer-Dryer / User Manual
Important
Fitting a different plug
As the colours of the wires in the mains
lead of this appliance may not correspond
with the coloured markings identifying the
terminals on your plug, proceed as follows:
1 Connect the green - yellow or green
(earth) wire to the terminal in the plug
marked ‘E’ or with the symbol f or
coloured green and yellow or green.
2 Connect the blue (neutral) wire to the terminal
in the plug marked ‘N’ or coloured black.
3 Connect the brown (live) wire to the terminal
in the plug marked ‘L’ or coloured red.
With the alternative plugs a 13A fuse
must be fitted either in the plug or
adaptor or in the main fuse box. If in
doubt contact a qualified electrician.
3.8 Transportation of the product
1 Unplug the product before transporting it.
2 Remove water drain and water
supply connections.
3 Drain all water that has remained
in the product. See 6.5
4 Install the transit bolts in reverse order of
the disassembly procedure. See 3.3
B
DANGER!
• Your product is too heavy for
one person to carry.
• Your product is heavy; two persons
must carry it and extra precaution
taken on stairs. If your product falls
on you, it may cause injuries.
A
CAUTION!
• Packaging materials are dangerous to
children. Keep packaging materials in a
safe place away from reach of the children.
C
INFORMATION
• Never move the product without the
transit bolts properly fixed in place!
15 / EN
Washer-Dryer / User Manual
4 Preparation
4.1 Sorting the laundry
* Sort laundry according to type of
fabric, colour, and degree of soiling
and allowable water temperature.
* Always observe the instructions given
on the garment care labels.
4.2 Preparing laundry for washing
• Laundry items with metal attachments
such as, underwired bras, belt buckles or
metal buttons will damage the machine.
Remove the metal pieces or wash such
clothes by putting them in a cotton laundry
bag or cotton pillow case. Also these
type of clothes can heat too much during
drying and damage your other clothes.
Do not dry such laundry in the machine.
• Put small size clothes such as infant's
socks and nylon stockings in cotton a
laundry bag or cotton pillow case.
• Place curtains in without compressing
them. Remove curtain attachment items.
Do not dry tulle curtains in your machine.
• Fasten zips, sew loose buttons
and mend rips and tears.
• Wash “machine washable” or “hand
washable” labelled products only with an
appropriate programme. Dry these type
of clothes by hanging or laying down.
Do not dry them in the machine.
• Do not wash colours and whites together.
New, dark coloured cottons release a
lot of dye. Wash them separately.
• Only use the dyes / colour changers and
descaling agents which are appropriate
to machine wash. Always follow the
instructions on the package.
C
INFORMATION
• Laundry that is subjected to heavy
deposits of materials such as flour, lime
dust, milk powder, etc. Must be shaken
off before placing into the machine.
Such dusts and powders on the laundry
may build up on the inner parts of the
product in time and can cause damage.
• Keep laundry items made of Angora
wool in the freezer for a few hours before
washing. This will reduce pilling.
• Wash trousers and delicate
laundry turned inside out.
• Tough stains must be treated
properly before washing. If unsure,
check with a dry cleaner.
• Take out all substances in the pockets
such as coins, pens and paper clips,
and turn pockets inside out and
brush. Such objects may damage the
product or cause noise problem.
4.3 Tips for energy
and water saving
Following information will help you
use the product in an ecological and
energy/water-efficient manner.
• Operate the product in the highest load
capacity allowed for the programme you
have selected, but do not overload. See,
“Programme and consumption table”.
• Observe the temperature instructions
on the detergent packaging.
• Wash slightly soiled laundry
at low temperatures.
• Use faster programmes for small
quantities of lightly soiled laundry.
• Do not use prewash and high temperatures
for laundry that is not heavily soiled or stained.
• If you plan to dry your laundry in a
dryer, select the highest spin speed
recommended during washing process.
• Do not use more detergent than the
recommended on the detergent packaging.
16 / EN
Washer-Dryer / User Manual
4.4 Initial use
Before starting to use the product make
sure that all preparations are made in
accordance with the “Important safety
and environment instructions” and the
instructions in the “Installation” section.
To prepare the product for washing laundry,
perform first operation in Drum Cleaning
programme. If this programme is not
available in your machine, apply the method
which is described in the section 6.2.
C
INFORMATION
• Use an anti-limescale product suitable
for the washing machines.
• Some water may remain in the product
due to the quality control processes in the
production. It is not harmful for the product.
4.5 Correct load capacity
The maximum load capacity depends on
the type of laundry, the degree of soiling
and the desired washing programme.
The product automatically adjusts the water amount
according to the weight of the laundry put inside it.
A
CAUTION!
• Follow the information in the “Programme
and consumption table”. When overloaded,
machine’s washing performance will drop.
Moreover, noise and vibration problems may
occur. For a successful drying performance,
do not dry more laundry than stated.
Laundry
type
Weight
(g)
Laundry
type
Weight
(g)
Bathrobe 1200 Hand towel 100
Fabric napkin 100
Women‘s
night gown
200
Bed sheet 700 Underclothing 100
Bed sheet 500 Men’s overalls 600
Pillowcase 200 Men’s shirt 200
Tablecloth 250 Men’s pyjamas 500
Towel 200 Blouses 100
4.6 Loading the laundry
1. Open the loading door.
2. Put the laundry items into the
product in a loose manner.
3. Push the loading door to close until
you hear a locking sound. Ensure that
no items are caught in the door.
C
INFORMATION
• The loading door is locked while a programme
is running. The loading door is unlocked a
while after the programme comes to an end.
If the inside part of the machine is too hot at
the end of the programme, loading door will
not open until the temperature decreases.
A
CAUTION!
• If the laundry is misplaced, noise and
vibration problems may occur in the machine.
4.7 Using detergent and softener
C
INFORMATION
• When using detergent, softener, starch,
fabric dye, bleach and descaling agents;
read the manufacturer’s instructions written
on the package and follow the dosages
specified. Use a measuring cup if available.
17 / EN
Washer-Dryer / User Manual
4.7.1 Detergent drawer
The detergent drawer is composed
of four compartments:
II
II
I
1) Left compartment with number “II” (Main
wash compartment for powder detergent
or powder bleach/stain remover)
2) Left compartment with number “II
” (Main wash compartment for liquid
detergent or liquid stain remover)
3) Middle compartment with number
“I” (pre-wash compartment for powder
detergent, powder stain remover or liquid
bleach - liquid bleach must be added either
during the pre-wash or during the first
rinsing step of the washing Programme).
Liquid bleach must be added manually
while the machine takes in water.
4) Right compartment with “ ” symbol (liquid
softener compartment) ( ) in addition, there is
a siphon piece in the softener compartment.
C
INFORMATION
• Never leave the detergent drawer open
while the washing programme is running!
• When using a programme without
prewash, do not put any detergent
into the prewash compartment
(compartment nr. “I“).
• Do not select a programme with
prewash if you are using a detergent
bag or dispensing ball. Place the
detergent bag or the dispensing ball
directly among the laundry in the
machine. Remove these if drying
• When machine is in Drying step,
do not add any washing chemicals
(Liquid detergent, Softener, etc.).
4.7.2 Main Wash Compartment
Before starting the washing Programme, put
powder detergent into the left compartment
with number “II”. Powder bleach/stain remover
must also be put into this compartment.
Put the liquid detergent into the main wash
compartment with number “II ” before
starting the washing Programme. Liquid stain
remover must be put into this compartment.
Put the suggested amount of liquid
detergent into the left compartment with “II
” symbol and dilute it to the maximum filling
level line (max. II ) with warm water.
Particularly the concentrated detergents
must be diluted with warm water; otherwise,
the siphon may get clogged in time.
Do not fill the detergent above the maximum
filling level line; otherwise the excess amount of
detergent will reach the laundry without water
and may cause stains on the garments.In this
case you will need to refill the compartment. Do
not pour the detergent onto the laundry directly
since this may cause stains on the garments.
4.7.3 Liquid Softener Compartment
Put the suggested amount of liquid
softener into the right compartment with “
” symbol and dilute it to the maximum
filling level line (max. ) with warm water.
Particularly the concentrated softeners must
be diluted with warm water; otherwise,
the siphon may get clogged in time.
Do not fill the softener above the maximum
filling level line; otherwise the excess amount of
softener will get mixed with the washing water
and you will need to refill the compartment. Do
not pour the softener onto the laundry directly
since this may cause stains on the garments.
Liquid softener will be dispensed automatically at
the final rinsing step of the washing Programme.
4.7.4 Pre-Wash Compartment
Put the powder pre-wash detergent or
powder stain remover into the middle
compartment with number “I”.
You can also put liquid bleach into this
compartment while the machine takes
in water during pre-wash or first rinsing
step. Adding the liquid bleach while the
machine takes in water allows it to be diluted
before it is poured onto the laundry.
18 / EN
Washer-Dryer / User Manual
You must select extra rinsing option if you use
liquid bleach in a washing Programme. Bleach
must be removed from the laundry with rinsing;
otherwise it may cause itching on the skin.
C
INFORMATION
• Read the dosage instructions and
label of your garments carefully
before using the liquid bleach.
4.7.5 Choosing the detergent type
Detergent type to be used depends on the
washing programme, fabric type and color.
• Use different detergents for
coloured and white laundry.
• Wash your delicate clothes only with
special detergents (liquid detergent, wool
shampoo, etc.) intended solely for delicate
clothes and at suggested programmes.
• When washing dark coloured clothes
and quilts, it is recommended
to use liquid detergent.
• Wash woolens at suggested
programme with special detergent
made specifically for woolens
• Please review the program descriptions part
for suggested program for different textiles.
• All recommendations about detergents
are valid for selectable temperature
range of programmes.
A
CAUTION!
• Use only detergents manufactured
specifically for washing machines.
• Do not use Powdered Soap.
4.7.6 Adjusting the
amount of detergent
The amount of washing detergent to be
used depends on the amount of laundry,
the degree of soiling and water hardness.
• Do not use amounts exceeding the dosage
quantities recommended on the detergent
package to avoid problems of excessive
foam, poor rinsing, financial savings
and finally, environmental protection.
• Use lesser detergent for small
amounts or lightly soiled clothes.
4.7.7 Using gel and tablet detergent
• If the gel detergent thickness is fluidal and
your machine does not contain a special liquid
detergent cup, put the gel detergent into the
main wash detergent compartment during first
water intake. If your machine contains a liquid
detergent container, fill the detergent into this
container before starting the programme.
• If the gel detergent thickness is not fluidal
or in the shape of capsule liquid tablet, put
it directly into the drum before washing.
• Put tablet detergents into the main wash
compartment (compartment nr. "2") or
directly into the drum before washing.
C
INFORMATION
• Tablet detergents may leave residues in
the detergent compartment. If you notice
such residues, place the tablet detergent
between the laundry, close to the lower
part of the drum in future washings.
• Use the tablet or gel detergent without
selecting the prewash function.
• Bear in mind that any plastic detergent
cup, bowl etc in the drum should
be removed before drying..
4.7.8 Using laundry starch
• Add liquid starch, powder starch or the
dyestuff into the softener compartment.
• Do not use softener and starch
together in a washing cycle.
• Wipe the inside of the machine with a
damp and clean cloth after using starch.
4.7.9 Using bleaches
• Select a programme with prewash and
add the bleach at the beginning of the
prewash. Do not put detergent in the
prewash compartment. As an alternative
application, select a programme with
extra rinse, add the bleach into an empty
detergent drawer compartment and
also add 1 glass of water from the same
compartment when you see the rinsing
step on the display for the first time.
• Do not use bleach and detergent
by mixing them.
19 / EN
Washer-Dryer / User Manual
• Use just a little amount (approx. 50 ml)
of bleaching agent and rinse the clothes
very well as it causes skin irritation. Do
not pour the bleach onto the laundry and
do not use it with the coloured items.
• When using oxygen-based whitener,
select a programme which washes
the laundry at a low temperature.
• Oxygen-based whitener can be used with
the detergent; however, if it is a different
consistency, first put detergent in the
compartment number “II” in the detergent
dispenser and wait for the machine to flush
the detergent when taking in water. While
the product continues taking in water, add
whitener in the same compartment.
4.7.10 Using limescale remover
• When required, use limescale
removers manufactured specifically
for washing machines only.
4.8 Tips for efficient washing
Clothes
Light Colours and
Whites
Colours
Black/Dark
Colours
Delicates/
Woollens/Silks
(Recommended temperature range
based on soiling level: 40-90˚C)
(Recommended temperature range
based on soiling level: cold -40˚C)
(Recommended
temperature range based
on soiling level: cold -40˚C)
(Recommended temperature
range based on soiling level:
cold -30˚C)
Soiling Level
Heavily Soiled
(difficult stains such as grass,
coffee, fruits and blood.)
It may be necessary to pre-treat the
stains or perform prewash. Powder
and liquid detergents recommended
for whites can be used at dosages
recommended for heavily soiled
clothes. It is recommended to use
powder detergents to clean clay and
soil stains and the stains that are
sensitive to bleaches.
Powder and liquid detergents
recommended for coloured
laundry can be used at dosages
recommended for heavily soiled
clothes. It is recommended to use
powder detergents to clean clay and
soil stains and the stains that are
sensitive to bleaches. Detergents
which do not contain bleach should
be used.
Liquid detergents suitable
for colours and dark
colours can be used at
dosages recommended for
heavily soiled clothes.
Prefer liquid detergents
produced for delicate
clothes. Woollen and silk
clothes must be washed with
special woollen detergents.
Normally
Soiled
(For example, stains
caused by body on
collars and cuffs)
Powder and liquid detergents
recommended for whites can be
used at dosages recommended for
normally soiled clothes.
Powder and liquid detergents
recommended for colours can be
used at dosages recommended for
normally soiled clothes. Detergents
which do not contain bleach should
be used.
Liquid detergents suitable
for colours and dark
colours can be used at
dosages recommended for
normally soiled clothes.
Prefer liquid detergents
produced for delicate
clothes. Woollen and silk
clothes must be washed with
special woollen detergents.
Lightly
Soiled
(No visible stains
exist.)
Powder and liquid detergents
recommended for whites can be
used at dosages recommended for
lightly soiled clothes.
Powder and liquid detergents
recommended for colours can be
used at dosages recommended for
lightly soiled clothes. Detergents
which do not contain bleach should
be used.
Liquid detergents suitable
for colours and dark
colours can be used at
dosages recommended for
lightly soiled clothes.
Prefer liquid detergents
produced for delicate
clothes. Woollen and silk
clothes must be washed with
special woollen detergents.
20 / EN
Washer-Dryer / User Manual
4.9 Tips for correct drying
Programmes
Cottons Drying Synthetics Drying Babyprotect + Washing and Drying Wash&Wear
Types of Clothes
Durable Clothes with
Cotton-Content
Sheet, bedding, baby
clothes, t-shirts, sweatshirts,
durable knit clothing, jeans,
canvas trousers, shirts,
cotton socks etc.
Not recommended!
Washes and dries
respectively! Sheet,
bedding, baby clothes,
t-shirts, sweatshirts,
durable knit clothing,
jeans, canvas trousers,
shirts, cotton socks etc.
Washes and dries respectively!
Sheet, bedding, baby clothes,
t-shirts, sweatshirts, durable
knit clothing, jeans, canvas
trousers, shirts, cotton socks
etc.
Stainless clothes that has
been worn for a short time
such as shirts, t-shirts,
sweatshirts A very small
amount of laundry must
be loaded.
Synthetics Clothes
(Polyester, nylon, etc.)
Not recommended!
It is recommended for the
polyester, nylon, polyacetate,
acrylic-content clothes. Drying
is not recommended for the
viscose-content clothes. Drying
explanations in the maintenance
label should be taken into
account.
It is recommended
for polyester, nylon,
polyacetate, acrylic
content clothes at low
temperatures, taking into
account the washing and
drying warnings on the
care label.
It is recommended for
polyester, nylon, polyacetate,
acrylic content clothes at low
temperatures, taking into
account the washing and
drying warnings on the care
label.
Lightly soiled and stainless
shirts, t-shirts and
synthetic-content clothes.
A very small amount of
laundry should be loaded.
Delicate (Silk, Woollens,
Cashmere, Angora wool,
etc. content) Clothes
Not recommended! Not recommended! Not recommended! Not recommended! Not recommended!
Bulky laundry such
as blankets, coats,
curtains etc.
Not recommended! It is
not appropriate to dry bulky
laundry in the washer. Dry
them by hanging them or
laying them flat.
Not recommended! It is not
appropriate to dry bulky laundry
in the washer. Dry them by
hanging them or laying them flat.
Not recommended! It
is not appropriate to
dry bulky laundry in the
washer. Dry them by
hanging them or laying
them flat.
Not recommended! It is
not appropriate to dry bulky
laundry in the washer. Dry
them by hanging them or
laying them flat.
Not recommended! It is
not appropriate to dry bulky
laundry in the washer. Dry
them by hanging them or
laying them flat.
4.10 Displayed Programme Time
You can see the programme duration
on the display of your machine while
selecting a programme. Depending on the
amount of laundry you have loaded into
your machine, foaming, unbalanced load
conditions, fluctuations in power supply,
water pressure and programme settings,
the programme duration is automatically
adjusted while the programme is running.
SPECIAL CASE:
At programme start of
Cottons and Cotton Eco programmes,
display shows the duration of half load,
which is the most common use case. After
programme starts, in 20-25 minutes actual
load is detected by the machine. And if the
detected load is higher than half load; washing
programme will be adjusted accordingly and
programme duration increased automatically.
You may follow this change on the display.
21 / EN
Washer-Dryer / User Manual
5 Operating the product
5.1 Control panel
1 2 3 4 5 6
789
101112
13
1 - Programme selection knob
2 - Temperature selection lights
3 - Spin speed selection lights
4 - Display
5 - Drying Programme Lights
6 - On / Off button
7 - Start / Pause button
8 - End Time Adjustment button
9 - Drying Level Adjustment button
10 - Auxiliary Function buttons
11 - Spin Speed Adjustment button
12 - Temperature Adjustment button
13 - Programme Selection lights
5.2 Display symbols
a b c d e
f
g
h
i
a- Washing indicator
b - Rinsing indicator
c - Spinning indicator
d- Drying indicator
e- End indicator
f- No Water indicator
g - Duration Information display
h- Loading Door Lock indicator
i- Child Lock indicator
5.3 Preparing the machine
1. Check if the hoses are connected tightly.
2. Plug in your machine.
3. Turn the tap on completely.
4.Place the laundry in the machine.
5. Add detergent and fabric softener.
5.4 Selecting the washing
programme
1. Determine the programme suitable
for the type, quantity and soiling level
of the laundry in accordance with the
"Programme and consumption table".
2. Select the desired programme with
the
Programme Selection
knob.
C
INFORMATION
• Programmes are limited with the
highest spin speed appropriate for
that particular type of fabric.
• When selecting a programme, always
consider the type of fabric, colour, soiling
level and permissible water temperature.
5.5 Washing programmes
Depending on the type of fabric, use
the following main programmes.
C
INFORMATION
• You can set you machine to switch to
drying step at the end of washing cycle
by pressing the Drying button after you
have selected the washing programme
for your laundry. Each time you press the
button, info line shows at which step the
drying process will take place and the
relevant symbol will turn on. If you want,
by continuing to press the button, you can
perform drying for the maximum period of
time allowed by the machine for drying.
• Symbols in the display are schematic
and may not match the product exactly.
• When you will perform washing and
drying by using the Drying function of
your machine, load maximum 5 kg of
laundry into the machine. If you load
excessively, your laundry will not dry
and machine will operate for a long
time and consume more energy.
22 / EN
Washer-Dryer / User Manual
• Cottons
Use for your cotton laundry (such as bed
sheets, duvet and pillowcase sets, towels,
bathrobes, underwear, etc.). Your laundry
will be washed with vigorous washing
action for a longer washing cycle.
C
INFORMATION
• You can dry your laundry after the
washing cycle without any interruption
(automatic or timed drying can be
performed after washing). For this, you
must also select the Drying function
before starting the washing programme.
• According to the drying selections which
you will add to the washing programmes,
you can see when the programme will
end on the display of the machine.
• If you don’t want drying to take place after
the programme you have selected, press
and hold the Drying auxiliary function
button until the Drying light is turned off.
• Synthetics
Use to wash your synthetic clothes (shirts,
blouses, synthetic/cotton blends, etc.).
Your laundry will be washed with a gentle
action for a shorter washing cycle when
compared to the Cottons programme.
C
INFORMATION
• You can dry your laundry after the
washing cycle without any interruption
(automatic or timed drying can be
performed after washing). For this, you
must also select the Drying function
before starting the washing programme.
• According to the drying selections which
you will add to the washing programmes,
you can see when the programme will
end on the display of the machine.
• If you don’t want drying to take place after
the programme you have selected, press
and hold the Drying auxiliary function
button until the Drying light is turned off.
• WoolProtect
Use to wash your woollen laundry. Select
the appropriate temperature complying
with the tag of your clothes. Use
appropriate detergents for woollens.
C
INFORMATION
• Drying function cannot be selected
for the woollen wash programme.
• Eco 40-60
The eco 40-60 programme is able to clean
normally soiled cotton laundry declared to
be washable at 40 °C or 60 °C, together in
the same cycle, and that this programme
is used to assess the compliance with
the EU ecodesign legislation.
Although it washes longer than all other
programmes, it provides high energy and
water savings. Actual water temperature
may be different from the stated wash
temperature. When you load the machine
with less laundry (e.g. ½ capacity or
less), periods in programme stages may
automatically get shorter. In this case, energy
and water consumption will decrease.
Cupboard drying fuction should be
selected with eco 40-60 to perform wash
and dry cycle to assess the compliance
with the EU ecodesign legislation.
The wash and dry cycle is able to clean
normally soiled cotton laundry declared to be
washable at 40 °C or 60 °C, together in the
same cycle, and to dry it in such a way that
it can be immediately stored in a cupboard.
C
INFORMATION
• You can dry your laundry after the
washing cycle without any interruption
(automatic or timed drying can be
performed after washing). For this, you
must also select the Drying function
before starting the washing programme.
• According to the drying selections which
you will add to the washing programmes,
you can see when the programme will
end on the display of the machine.
• If you don’t want drying to take place after
the programme you have selected, press
and hold the Drying auxiliary function
button until the Drying light is turned off.
23 / EN
Washer-Dryer / User Manual
• Delicates
Use to wash your delicate laundry. Your laundry
will be washed with more gentle washing action
compared to the Synthetics programme.
• Hand Wash
Use to wash woollen/delicate laundry that bear
“not machine-washable” care labels and for
which hand wash is recommended. Your laundry
will be washed with a very gentle washing
action in order not to damage the clothes.
• Mini
Use to wash your lightly soiled and
unstained cotton laundry in a short time.
C
INFORMATION
• You can dry your laundry after the
washing cycle without any interruption
(automatic or timed drying can be
performed after washing). For this, you
must also select the Drying function
before starting the washing programme.
• According to the drying selections which
you will add to the washing programmes,
you can see when the programme will
end on the display of the machine.
• If you don’t want drying to take place after
the programme you have selected, press
and hold the Drying auxiliary function
button until the Drying light is turned off.
• Mini 14’
Use it to wash a small amount of lightly soiled
cotton laundry in a short time. This programme
washes your laundry in 14 minutes.
C
INFORMATION
• You can dry your laundry after the
washing cycle without any interruption
(automatic or timed drying can be
performed after washing). For this, you
must also select the Drying function
before starting the washing programme.
• According to the drying selections which
you will add to the washing programmes,
you can see when the programme will
end on the display of the machine.
• If you don’t want drying to take place after
the programme you have selected, press
and hold the Drying auxiliary function
button until the Drying light is turned off.
• Shirts
Use to wash the shirts made of cotton, synthetic
and synthetic blended fabrics together.
C
INFORMATION
• You can dry your laundry after the
washing cycle without any interruption
(automatic or timed drying can be
performed after washing). For this, you
must also select the Drying function
before starting the washing programme.
• According to the drying selections which
you will add to the washing programmes,
you can see when the programme will
end on the display of the machine.
• If you don’t want drying to take place after
the programme you have selected, press
and hold the Drying auxiliary function
button until the Drying light is turned off.
• Rinse
Use when you want to rinse or starch separately.
• Spin+Drain
Use to drain the water in the machine.
5.6 Temperature selection
Whenever a new programme is selected, the
recommended temperature for the programme
appears on the temperature indicator. It is
possible that the recommended temperature
value is not the maximum temperature that
can be selected for the current programme.
Press the
Temperature Adjustment
button to change the temperature.
C
INFORMATION
• Temperature Adjustment button works
only backwards. For example, when you
want to select 60
0
C when the display
shows 40
0
C you need to press the
button for several times until you reach
60
0
C by going backwards from 40
0
C.
24 / EN
Washer-Dryer / User Manual
C
INFORMATION
• If you scroll to Cold Wash option and press
Temperature Adjustment button again,
the recommended maximum temperature
for the selected programme is displayed.
Press the Temperature Adjustment button
again to decrease the temperature.
Finally, Cold light indicating the cold
wash option appears on the display.
You can also change the temperature after
the washing has started. You can select the
desired temperature after washing starts but
you must do this before heating step starts.
5.7 Spin speed selection
Whenever a new programme is selected,
the spin speed recommended for
the selected programme is displayed
on the
Spin Speed
indicator.
C
INFORMATION
• It is possible that the recommended
spin speed value is not the maximum
spin speed that can be selected
for the current programme.
Press the
Spin Speed Adjustment
button to change the spin speed.
Spin speed decreases gradually.
Then, depending on the model of the
product, "Rinse Hold" and "No Spin"
options appear on the display.
C
INFORMATION
• Spin Speed Adjustment button works only
backwards. For example, when you want
to select 1000 rpm when the display shows
800 rpm, you need to press the button
for several times until you reach 1000
rpm by going backwards from 800 rpm.
C
INFORMATION
• Rinse Hold option is indicated with “
” symbol and No Spin option is
indicated with “ ” symbol.
5.7.1 If you want to spin
your laundry after the
Rinse Hold function:
- Adjust the
Spin Speed
.
- Press
Start / Pause / Cancel
button.
The programme resumes. Machine drains
the water and spins the laundry.
If you want to drain the water at
the end of the programme without
spinning, use
No Spin
function.
C
INFORMATION
• In programmes that do not allow
spin speed adjustment, when
Spin Speed adjustment button is
pressed, spin speed light does not
change and the buzzer is heard.
You can also change the Spin Speed
after the washing starts. You can select
spin speed by pressing spin speed
adjustment button after washing has
started but before the spinning step.
5.7.2 Auxiliary function
selection for drying
When a new programme is selected,
press Auxiliary Function Selection button
to adjust the drying option that is suitable
for the selected washing programme.
C
INFORMATION
• In programmes that do not allow drying
adjustment, when Drying auxiliary function
button is pressed drying light does not
change and the buzzer is heard.
25 / EN
Washer-Dryer / User Manual
C
INFORMATION
• Only for drying programmes, press
Auxiliary Function Selection button to
adjust the suitable drying option.
5.8 Drying programmes
A
CAUTION!
• Machine cleans the lint coming off
the laundry automatically during the
drying cycle. Machine uses water
during drying. For this reason, water
tap of the machine should be open
also in the drying programmes.
• When a new programme is selected,
press Auxiliary Function Selection button
to adjust the drying option that is suitable
for the selected washing programme.
C
INFORMATION
• Drying programmes contain spinning step.
Your machine performs this process in
order to shorten the drying time. When
drying is selected, spin speed setting
is in Maximum spin speed range.
• In programmes that do not allow drying
adjustment, when Drying auxiliary function
button is pressed drying light does not
change and the buzzer is heard.
• Only for drying programmes, press
Auxiliary Function Selection button to
adjust the suitable drying option.
• While there is a water cut, both washing
and drying could not be performed.
• Synthetic Dry
Use to dry damp synthetic laundry
equivalent to 3 kg dry weight. This
programme performs drying only.
C
INFORMATION
• For the dry weights of the laundry,
see Section 4, Step 4.5
• Cotton Dry
Use to dry damp cotton laundry
equivalent to 5 kg dry weight. This
programme performs drying only.
C
INFORMATION
• In order to dry the laundry which
contains only towels and bathrobes,
load 4 kg laundry maximum.
• For the dry weights of the laundry,
see Section 4, Step 4.5
5.9 Washing and drying
programmes
A
CAUTION!
• Machine cleans the lint coming off
the laundry automatically during the
drying cycle. Machine uses water
during drying. For this reason, water
tap of the machine should be open
also in the drying programmes.
•
5 Kg Wash & Dry
Use to wash cotton laundry up to 5 kg
and dry it right after the washing cycle
without making any other selection.
C
INFORMATION
• When this programme is selected,
external Drying auxiliary function
cannot be selected.
In
5
kg Wash &
5
kg Dry programme, it
is recommended to load laundry until the
level indicated in the above figure for ideal
drying conditions (you will see the level
arrow when you open the loading door).
26 / EN
Washer-Dryer / User Manual
5.10 Programme and consumption table (for washing)
• : Selectable.
* : Automatically selected, no cancelling.
EN 2 Auxiliary functions
Programme (°C)
Max. Load (kg)
Water Consumption (l)
Energy Consumption (kWh)
Max. Speed
Prewash
Express
Extra Rinse
Drying
Selectable temperature
range °C
Cottons
90 8 90 2,50 1400 • • • •
90-Cold
60 8 90 1,80 1400 • • • •
90-Cold
40 8 88 0,97 1400 • • • •
90-Cold
Eco 40-60
40 ***
8 54 0,955 1400 •
40-60
40 ***
4 35 0,550 1400 •
40-60
40 ***
2 28 0,320 1400 •
40-60
60 **
8 47 0,760 1400 •
40-60
Eco 40-60 + Cupboard Dry
40 ***
5 61 3,215 1400 •
40-60
40 ***
2,5 42 1,780 1400 •
40-60
Synthetics
60 3 60 1,35 1200 • • • •
60-Cold
40 3 58 0,85 1200 • • • •
60-Cold
WoolProtect
40 1,5 55 0,50 1200 •
40-Cold
Delicates
40 3,5 55 0,72 1000 •
40-Cold
Hand Wash
30 1 55 0,50 1200
30-Cold
Shirts
60 3,5 45 0,85 800 • • • •
60-Cold
Mini 14’
30 2 40 0,15 1400 • •
30-Cold
Mini
90 8 68 1,90 1400 • •
90-Cold
60 8 68 1,10 1400 • •
90-Cold
30 8 68 0,18 1400 • •
90-Cold
• Mini Wash & Dry
Use to wash and dry 0.5 kg laundry (2 shirts) in 40
minutes or 1 kg laundry (5 shirts) in 60 minutes.
C
INFORMATION
• Wash&Wear programme is intended to
quickly wash and dry the daily clothes
which were worn for a short period of time
and are not soiled. This programme is
suitable for the laundry which contains thin-
texture and can dry quickly. (shirts, t-shirts)
• Other drying options or programmes
should be used for the thick texture
laundry which take longer to dry.
• Anti Allergy Wash&Dry
Use to wash and then immediately dry your
laundry up to 2 kg which requires an anti-allergic
and hygienic washing (baby clothes, bed sheets,
bedding, underpants, etc. cotton items).
C
INFORMATION
• BabyProtect+ programme is tested and
approved by “The British Allergy Foundation”
(Allergy UK) in United Kingdom.
27 / EN
Washer-Dryer / User Manual
** : Eco 40-60 with 60 °C temperature selection is the washing performance test program in accordance with EN
50229:2015 and energy label test program in accordance with Commission Delegated Regulation (EU) 96/60/EC.
Cottons Drying with Extra Dry selection is the drying performance test program in accordance with EN
50229:2015 and energy label test program in accordance with Commission Delegated Regulation (EU) 96/60/
EC. The maximum washing load must be divided into groups as the maximum drying load and the remaining
drying load, and then each load must be dried using the option Cottons Drying with Extra Dry selection.
***: Eco 40-60 with 40 °C temperature selection is the washing performance test program in accordance with
EN 62512 and energy label test program in accordance with Commission Delegated Regulation (EU) 2019/2014
Eco 40-60 with 40 °C temperature and cup board dry selection is the wash and dry cycle test program in accordance
with EN 62512 and energy label test program in accordance with Commission Delegated Regulation (EU) 2019/2014.
- : See the programme description for maximum load.
C
INFORMATION
• The auxiliary functions in the table may vary according to the model of your machine.
• Water and power consumption may vary subject to the changes in water pressure, water
hardness and water temperature, ambient temperature, type and amount of laundry, selection of
auxiliary functions and spin speed, and changes in the mains voltage.
• When selecting a programme, you can see the washing duration on the display of your machine.
Depending on the amount of laundry you have loaded into the machine, there might be a
difference of 1 to 1.5 hours between the duration shown on the display and the actual duration
of the washing programme. The duration will be corrected automatically right after the washing
programme has started.
• “Auxiliary function selection modes can be changed by the manufacturing company.
New selection models may be added, or the existing ones may be removed.”
• “Spin speed of your machine may vary depending on the programme; the
spin speed cannot exceed the maximum spin speed of your machine.”
• Always select the lowest appropriate temperature. The most efficient programmes in terms of
energy consumption are generally those that perform at lower temperatures and longer duration.
• Noise and remaining moisture content are influenced by the spinning speed: the higher the
spinning speed in the spinning phase, the higher the noise and the lower the remaining moisture
content.
Programme and consumption table (for drying)
EN
2
Auxiliary
functions
Drying level
Programme (°C)
Max. Load (kg)
Water Consumption (l)
Energy Consumption (kWh)
Max. Speed
Prewash
Express
Extra Rinse
Drying
Extra Dry
Cupboard Dry
Iron Dry
Time based drying - minutes
Selectable
temperature range
°C
Cotton Dry
- 5 45 3,20 1400 * • • • •
-
Synthetic Dry
- 3 30 2,10 - * • • •
-
Anti Allergy Wash&Dry
60 2 120 3,80 1400 * * • • • •
90-30
5 Kg Wash&Dry
60 5 94 5,00 1400 * • • • •
60-Cold
Wash&Wear
30 0,5 35 0,60 1000 • * •
30-Cold
Wash&Wear
30 1 44 1,00 1000 • * •
30-Cold
28 / EN
Washer-Dryer / User Manual
5.11 Auxiliary function selection
Select the desired auxiliary functions
before starting the programme. Whenever
a programme is selected, lights of the
auxiliary functions that can be selected
together with that programme illuminate.
C
INFORMATION
• Light of the auxiliary function that cannot
be selected with the selected programme
does not illuminate. When you press the
buttons of these auxiliary functions, buzzer
is heard and selection is prohibited.
If the wash cycle has reached a point where
you cannot select the auxiliary function,
the function cannot be selected.
C
INFORMATION
• Some functions cannot be selected
together. If a second auxiliary function
conflicting with the first one is selected
before starting the machine, the function
selected first will be cancelled and the
second auxiliary function selection will
remain active. For example, if you want to
select Quick Wash after you have selected
the Prewash, Prewash will be cancelled
and Quick Wash will remain active.
• An auxiliary function that is not compatible
with the programme cannot be selected.
(See “Programme and consumption table”)
• Some programmes have auxiliary
functions that must be operated
with the selected programme. Those
functions cannot be cancelled. Auxiliary
function light is already selected.
Consumption Values (EN)
Temperature
Selection (°C)
Spin Speed (rpm)
Capacity (kg)
Programme
Duration (hh:mm)
Energy Consumption
(kWh/cycle)
Water Consumption
(L/cycle)
Laundry
Temperature (°C)
Remaining Moisture
Content (%)
Eco 40-60
40 1400 8 03:38
0,955 54,0
40 53
40 1400 4 02:47
0,550 35,0
32 53
40 1400 2 02:47
0,320 28,0
23 53
Cottons
20 1400 8 03:40 0,600 88,0 20 53
Cottons
60 1400 8 03:40 1,800 90,0 60 53
Synthetics
40 1200 3 02:25 0,850 58,0 40 40
Mini
30 1400 8 00:28 0,180 68,0 23 62
Eco 40-60+Cupboard Dry
40 1400 5 07:55 3,215 61,0 25 53
40 1400 2,5 05:50 1,780 42,0 24 53
29 / EN
Washer-Dryer / User Manual
C
INFORMATION
• If the selected dampness level (Iron Dry,
Wardrobe Dry, Extra Wardrobe Dry)
cannot be reached at the end of the
drying cycle, your machine will extend
the programme duration automatically.
Programme will last longer.
• If Timed-Drying is selected, programme
is finished at the end of the drying period
even if the laundry does not get dry.
• If the selected dampness level (Iron
Dry, Wardrobe Dry, Extra Wardrobe
Dry) is reached during drying cycle,
or extra dryness is detected in the
timed-drying options, programme will
take a shorter time. Time decrease
will be shown on the display.
• Prewash
A Prewash is only worthwhile for heavily
soiled laundry. Not using the Prewash will
save energy, water, detergent and time.
• Express
This function can be used in Cottons and
Synthetics programmes. It decreases the
washing times and also the number of
rinsing steps for lightly soiled laundry.
C
INFORMATION
• When you select this function, load your
machine with half of the maximum laundry
specified in the programme table.
• Extra Rinse
This function enables the product to make
another rinse in addition to the one already
made after the main wash. Thus, the risk
for sensitive skins (babies, allergic skins,
etc.) to be effected by the minimal detergent
remnants on the laundry can be reduced.
C
INFORMATION
• Pressing for the first time will add single
rinse, a second press will add double
rinse. The third press will cancel it.
• Drying
This function enables drying of the
laundry after washing. Check with which
programmes this auxiliary function can be
selected, from the programme table.
5.12 Drying steps
5.12.1 Iron Dry
Drying is performed until the drying
level reaches Iron Dry step.
5.12.2 Cupboard Dry
Drying is performed until the drying
level reaches Wardrobe Dry step.
5.12.3 Extra Dry
Drying is performed until the drying level
reaches Extra Wardrobe Dry step.
C
INFORMATION
• Dryness level may change according
to the mixture, material types, amount
and dampness level of the laundry.
• Items which contain accessories such
as lace, tulle, stones, beads, spacer,
wire, etc. and high silk-content items
should not be dried in the machine.
5.12.4 Time based drying-minutes
In order to reach the desired drying level
at low temperature, you select any of 30,
90 and 150 minutes of drying periods.
C
INFORMATION
• When drying small amount of laundry
(up to maximum 2 pieces), timed-drying
steps in the Cottons or Synthetics drying
programmes should be selected.
• If the laundry is not at the desired
dryness level at the end of the drying
programme, timed-drying can be
selected to finish the process.
• When this function is selected, machine
performs drying for the adjusted time
irrespective of the drying level.
30 / EN
Washer-Dryer / User Manual
5.13 Time display
Remaining time for the completion of the
programme while it is running is displayed
as “01:30” in hours and minutes format.
C
INFORMATION
• Programme time may differ from the values
in section “Programme and consumption
table” depending on the water pressure,
water hardness and temperature, ambient
temperature, amount and the type of
laundry, auxiliary functions selected and
the changes at the mains voltage.
5.14 End Time
With the
End Time
function, the startup of the
programme can be delayed up to 24 hours. After
pressing
End Time
button, the programme's
estimated ending time is displayed. If the
End
Time
is adjusted,
End Time
light illuminates.
In order for the End Time function is activated
and the programme is completed at the
end of the specified time, you must press
Start / Pause
button after adjusting the
time.
Start / Pause
button stops flashing
and remains illuminated continuously.
If you want to cancel End Time function,
press
End Time
button until the End
Time light turns off or press
On / Off
button to turn off and on the machine.
1. Open the loading door, place the
laundry and put detergent, etc.
2. Select the washing programme,
temperature, spin speed and, if
required, the auxiliary functions.
3. Set the end time of your choice
by pressing the
End Time
button.
End Time
light is illuminated.
4. Press
Start / Pause
button. Time countdown
starts. “:” symbol in the middle of the
end time on the display starts flashing.
C
INFORMATION
• Do not use liquid detergents when you
activate End Time function! There is
the risk of staining of the clothes.
• Door keeps locked during the End
Time countdown period. In order
to unlock the door, machine should
be switched to the pause mode by
pressing the programme start/pause
button. At the end of the countdown,
End Time indicator turns off, washing
cycle starts and the time of the selected
programme appears on the display.
• When the End Time selection is
completed, the time appearing on the
display consists of end time plus the
duration of the selected programme.
5.15 Starting the programme
1400
800
1000
600
150’
Ütü Kuruluğu
Dolap Kuruluğu
Extra Kurutma
90’
20°
30’
8.5
10.5
Malzeme rengi ARC 716
Colour of material is ARC 716
%DVN×UHQJL3DQWRQH&
3ULQWLQJFRORULV3DQWRQH&
INLAY STOCK NO:
2846559001
1400
800
1000
600
150’
Ütü Kuruluğu
Dolap Kuruluğu
Extra Kurutma
90’
20°
30’
1. Press
Start / Pause
button
to start the programme.
2. The light of
Start / Pause
button which
was flashing starts to illuminate steadily now,
indicating that the programme has started.
3. Loading door is locked. "Locking
the Door" appears on the display
when the door is being locked.
5.16 Loading door lock
1400
800
1000
600
150’
Ütü Kuruluğu
Dolap Kuruluğu
Extra Kurutma
90’
20°
30’
8.5
10.5
Malzeme rengi ARC 716
Colour of material is ARC 716
%DVN×UHQJL3DQWRQH&
3ULQWLQJFRORULV3DQWRQH&
INLAY STOCK NO:
2846559001
1400
800
1000
600
150’
Ütü Kuruluğu
Dolap Kuruluğu
Extra Kurutma
90’
20°
30’
There is a locking system on the loading
door of the machine that prevents opening
of the loading door in cases when the water
level is unsuitable for door opening.
"Loading door locked" light in the panel
turns on when the loading door is locked.
31 / EN
Washer-Dryer / User Manual
5.17 Changing the selections
after programme has started
5.17.1 Adding laundry after
the programme has started:
1400
800
1000
600
150’
Ütü Kuruluğu
Dolap Kuruluğu
Extra Kurutma
90’
20°
30’
8.5
10.5
Malzeme rengi ARC 716
Colour of material is ARC 716
%DVN×UHQJL3DQWRQH&
3ULQWLQJFRORULV3DQWRQH&
INLAY STOCK NO:
2846559001
1400
800
1000
600
150’
Ütü Kuruluğu
Dolap Kuruluğu
Extra Kurutma
90’
20°
30’
If the water level in the machine is suitable when
you press
Start / Pause
button, “Loading
door locked” light on the panel is turned off.
If the water level in the machine is not suitable
when you press
Start / Pause
button, the panel
will indicate that the loading door is locked.
5.17.2 Switching the
machine to pause mode:
1400
800
1000
600
150’
Ütü Kuruluğu
Dolap Kuruluğu
Extra Kurutma
90’
20°
30’
8.5
10.5
Malzeme rengi ARC 716
Colour of material is ARC 716
%DVN×UHQJL3DQWRQH&
3ULQWLQJFRORULV3DQWRQH&
INLAY STOCK NO:
2846559001
1400
800
1000
600
150’
Ütü Kuruluğu
Dolap Kuruluğu
Extra Kurutma
90’
20°
30’
Press the
Start / Pause
button to
switch the machine to pause mode.
5.17.3 Changing the
programme selection after
programme has started:
Changing the programme is not allowed
when a programme is already running.
If you turn the
Programme Selection
knob while the programme is running,
buzzer is heard and change is prohibited.
You can select the new programme
after switching the current
programme to pause mode.
C
INFORMATION
• The newly selected programme
starts from beginning.
5.17.4 Changing the
auxiliary function, spin
speed and temperature
Depending on the step the programme has
reached, you can cancel or select auxiliary
functions. See, "Auxiliary function selection".
Also, you can change the spin speed,
temperature and drying settings. See, "Spin
speed selection" and "Temperature selection".
C
INFORMATION
• The loading door will not open if the
water temperature in the machine
is high or the water level is above
the loading door baseline.
5.18 Child Lock
Use Child Lock function to prevent children
from tampering with the machine. Thus you can
avoid any changes in a running programme.
C
INFORMATION
• You can switch the machine on and
off with On / Off button when the Child
Lock is active. When you switch on
the machine again, programme will
resume from where it has stopped.
• Machine will give an audio alarm
when the buttons are pressed
if the child lock is active.
5.18.1 To activate the child lock:
Press and hold 2nd and 3rd auxiliary
function buttons for 3 seconds.
After
the countdown as "Child Lock 3-2-1" on
the display is over, "Child Lock Enabled"
appears on the display. You can release
2nd and 3rd Auxiliary Function
buttons
when this warning is displayed.
32 / EN
Washer-Dryer / User Manual
5.18.2 To deactivate the child lock:
Press and hold 2nd and 3rd auxiliary
function buttons for 3 seconds.
After
the countdown as "Child Lock 3-2-
1" on the display is over, "Child Lock
Enabled" is turned off on the display.
5.19 Cancelling the programme
1400
800
1000
600
150’
Ütü Kuruluğu
Dolap Kuruluğu
Extra Kurutma
90’
20°
30’
8.5
10.5
Malzeme rengi ARC 716
Colour of material is ARC 716
%DVN×UHQJL3DQWRQH&
3ULQWLQJFRORULV3DQWRQH&
INLAY STOCK NO:
2846559001
1400
800
1000
600
150’
Ütü Kuruluğu
Dolap Kuruluğu
Extra Kurutma
90’
20°
30’
The programme is cancelled when the
machine is turned off and on again. Press
and hold
On / Off
button for 3 seconds.
After the countdown as "3-2-1" on the
display is over, the machine turns off.
C
INFORMATION
• If you press On / Off button when the
Child Lock is active, the programme
will not be cancelled. You should
cancel the child lock first. Countdown
as “3-2-1” appears on the display.
• If you want to open the loading door
after you have cancelled the programme
but it is not possible to open the loading
door since the water level in the machine
is above the loading door baseline,
then turn the Programme Selection
knob to Pump+Spin programme and
drain the water in the machine.
5.20 End of programme
When the programme is over the End
of Programme indicator illuminates
and a buzzer is heard.
If you do not press any button for 2 minutes,
the machine will switch to standby mode.
Display and all indicators are turned off.
If you press any button or turn the
Programme
Selection
knob when the machine is in
standby mode, programme steps that are
completed will appear on the display.
5.21 Your machine features
a "Standby Mode".
After you switch on your machine with On-Off
button, if no programme is started or no other
procedure is performed at the selection step or
no action is taken within approx. 2 minutes after
the selected programme ends, your machine
will switch to energy saving mode automatically.
Also, if your product has a display that shows
programme time, this display will be completely
turned off. If you turn the Programme Selection
knob or touch any button, lights and display
will switch back to previous condition. The
selections which you make when exiting from
the energy efficiency may change. Please
check the correctness of your selections before
starting the programme. If necessary, please
make your settings again. This is not an error.
33 / EN
Washer-Dryer / User Manual
6 Maintenance and cleaning
Service life of product extends and frequently
experienced problems will be reduced
if it is cleaned at regular intervals.
6.1 Cleaning the detergent drawer
Remove any powder residue buildup
in the drawer. To do this;
II
II
I
1. You can remove the detergent drawer
by pulling it towards yourself strongly.
C
INFORMATION
• If more than a normal amount of softener
and liquid detergent mixture starts to
remain in the softener compartment,
the siphon must be cleaned.
2. Wash the drawer and the siphon with
plenty of lukewarm water in a washbasin.
Wear protective gloves or use an
appropriate brush to avoid touching the
residues in the drawer when cleaning.
3. Replace the drawer into its housing
after cleaning. Check if the siphon
is in its original location.
6.2 Cleaning the loading
door and the drum
For products with drum cleaning
programme, please see Operating
the product - Programmes.
For products without drum cleaning programme,
follow the below steps to
clean the drum
:
Select
Additional Water
or
Extra Rinse
auxiliary functions. Use Cottons
programme
without pre-wash. Set
the temperature to the
level recommended on the drum cleaning
agent
which can be found in the detergent aisle
in supermarkets
.
Apply this procedure
without
any laundry in the product
. Before starting
the programme, put 1 pouch of special drum
cleaning agent (if the special agent could not
be supplied, put max. 1 tea-cup of (max. 100
g) of antilimescale powder) into the main wash
detergent compartment. If the antilimescale
is in tablet form, put only one tablet into the
main wash compartment no. "2". Dry the
inside of the bellow with a clean piece of cloth
after the programme has come to an end.
C
INFORMATION
• Repeat Drum Cleaning process
in every 2 months.
• Use an anti-limescale suitable
for the washing machines.
After every washing and drying make sure
that no foreign substance is left in the drum.
If the holes on the bellow shown in the figure
are blocked, open the holes using a toothpick.
C
INFORMATION
• Foreign metal substances will cause
rust stains in the drum. Clean the
stains on the drum surface by using
cleaning agents for stainless steel.
Never use steel wool or wire wool.
A
CAUTION!
• Never use sponge or scrub materials.
These will damage the painted,
chrome and plastic surfaces.
34 / EN
Washer-Dryer / User Manual
6.3 Cleaning the body
and control panel
Wipe the body of the machine with soapy
water or non-corrosive mild gel detergents
as necessary, and dry with a soft cloth.
Use only a soft and damp cloth
to clean the control panel.
6.4 Cleaning the water
intake filters
There is a filter at the end of each water
intake valve at the rear of the machine and
also at the end of each water intake hose
where they are connected to the tap. These
filters prevent foreign substances and dirt
in the water to enter the washing machine.
Filters should be cleaned if they are dirty.
1. Close the taps.
2. Remove the nuts of the water intake
hoses to access the filters on the water
intake valves. Clean residues on them
with an appropriate brush. If the filters are
too dirty, remove them from their places
with a pliers and clean in this way.
3. Take out the filters on the flat ends of the
water intake hoses together with the gaskets
and clean thoroughly under running water.
4. Replace the gaskets and filters
carefully in their places and tighten
the hose nuts by hand.
6.5 Draining remaining water
and cleaning the pump filter
The filter system in your machine prevents
solid items such as buttons, coins and fabric
fibers clogging the pump impeller during
discharge of washing water. Thus, the water
will be discharged without any problem and
the service life of the pump will extend.
If the machine fails to drain water, the pump filter
is clogged. Filter must be cleaned whenever it
is clogged or in every 3 months. Water must
be drained off first to clean the pump filter.
In addition, prior to transporting the machine
(e.g., when moving to another house)
and in case of freezing of the water, water
may have to be drained completely.
A
CAUTION!
• Foreign substances left in the pump
filter may damage your product
or may cause noise problem.
• If the product is not being used, shut the
tap, remove mains hose and drain the
water inside the machine in places where
there is the risk of the product freezing .
• After each use, turn off the water tap to
which the mains hose is connected.
In order to clean the dirty filter
and discharge the water:
1. Unplug the machine to cut
off the supply power.
A
CAUTION!
• Temperature of the water inside the
machine may rise up to 90 ºC. To avoid
burning risk, filter must be cleaned after
the water in the machine cools down.
35 / EN
Washer-Dryer / User Manual
2. Some of our products have emergency
draining hose and some does not have.
Follow the steps below to discharge the water.
Discharging the water when the product does
not have an emergency draining hose:
a. Place a large container in front of the
filter to catch water from the filter.
b. Loosen pump filter (anticlockwise) until
water starts to flow. Fill the flowing water
into the container you have placed in
front of the filter. Always keep a piece of
cloth handy to absorb any spilled water.
c. When the water inside the
machine is finished, take out the
filter completely by turning it.
3. Clean any residues inside the filter
as well as fibers, if any, around
the pump impeller region.
4. Install the filter, turn clockwise to
ensure it is closed and watertight.
7 Troubleshooting
Programmes do not start after the loading door is
closed.
• Start / Pause / Cancel button is not pressed.>>>
*Press Start/
Pause/Cancel button.
• It may be difficult to close the loading door in case of excessive
loading.>>>
*Reduce the amount of laundry and make sure
that the loading door is closed properly.
Programme cannot be started or selected.
• Washing machine has switched to self protection mode due to
a supply problem (line voltage, water pressure, etc. >>>
Press
and hold On/Off button for 3 seconds to reset the machine to
factory settings. (See. “Cancelling the programme”)
Water in the machine.
• Some water may remain in the product due to the quality
control processes in the production. >>>
This is not a failure;
water is not harmful to the machine.
There is water leaking from the bottom of the
machine.
• There is a problem with hoses or the pump filter. >>>
Be sure
the seals of the water inlet hoses are securely fitted. Attach the
hose to the tap tightly.
• Pump filter is not closed securely. >>>
Make sure that the
pump filter is closed securely.
Machine does not fill with water.
• Tap is turned off. >>>
Turn on the taps.
• Water inlet hose is bent. >>>
Flatten the hose.
• Water inlet filter is clogged. >>>
Clean the filter.
• Loading door is not closed. >>>
Close the loading door.
Machine does not drain water.
• Water drain hose is clogged or twisted. >>>
Clean or flatten
the hose.
• Pump filter is clogged. >>>
Clean the pump filter.
Machine vibrates or makes noise.
• Machine is standing unbalanced. >>>
Adjust the feet to level
the machine.
• A hard substance has entered into the pump filter. >>>
Clean
the pump filter.
• Transit bolts are not removed. >>>
Remove the transit bolts.
• Laundry quantity in the machine is too little. >>>
Add more
laundry to the machine.
• Machine is overloaded with laundry. >>>
Take out some of
the laundry from the machine or distribute the load by hand to
balance it.
• Machine is in contact with a rigid surface. >>>
Make sure that
the machine is not contacting anything.
Machine stopped shortly after the programme
started.
• Machine has stopped temporarily due to low voltage. >>>
It
will resume running when the voltage restores to the normal
level.
36 / EN
Washer-Dryer / User Manual
Machine directly discharges the water it takes in.
• Draining hose is not at adequate height. >>>
Connect the
water draining hose as described in the user manual.
No water can be seen in the machine during
washing.
• The water level is not visible from outside of the washing
machine. This is not a failure.
Loading door cannot be opened.
• Loading door lock is activated because of the water level in the
machine. >>>
Drain the water by running the Pump or Spin
programme.
• Machine is heating up the water or it is at the spinning cycle.
>>>
Wait until the programme completes.
• Loading door lock is engaged. Loading door lock will be
deactivated a couple of minutes after the programme comes
to an end. >>>
Wait for a couple of minutes for deactivation of
the loading door lock.
• Loading door may be stuck because of the pressure it is
subjected to. >>>
Grab the handle and push and pull the
loading door to release and open it.
Washing takes longer than specified in the user
manual.(*)
• Water pressure is low. >>>
Machine waits until taking in
adequate amount of water to prevent poor washing quality due
to the decreased amount of water. Therefore, the washing time
extends.
• Voltage is low. >>>
Washing time is prolonged to avoid poor
washing results when the supply voltage is low.
• Input temperature of water is low. >>>
Required time to heat
up the water extends in cold seasons. Also, washing time can
be lengthened to avoid poor washing results.
• Number of rinses and/or amount of rinse water have increased.
>>>
Machine increases the amount of rinse water when good
rinsing is needed and adds an extra rinsing step if necessary.
• Excessive foam has occurred and automatic foam absorption
system has been activated due to too much detergent usage.
>>>
Use recommended amount of detergent.
Programme time does not countdown. (On models
with display) (*)
• Timer may stop during water intake. >>>
Timer indicator will
not countdown until the machine takes in adequate amount of
water. The machine will wait until there is sufficient amount of
water to avoid poor washing results due to lack of water. Timer
indicator will resume countdown after this.
• Timer may stop during heating step. >>>
Timer indicator
will not countdown until the machine reaches the selected
temperature.
• Timer may stop during spinning step. >>>
Automatic
unbalanced load detection system might be activated due to
the unbalanced distribution of the laundry in the drum.
Programme time does not countdown. (*)
• Laundry is unbalanced in the machine. >>>
Automatic
unbalanced load detection system might be activated due to
the unbalanced distribution of the laundry in the drum.
Machine does not switch to spinning step. (*)
• Laundry is unbalanced in the machine. >>>
Automatic
unbalanced load detection system might be activated due to
the unbalanced distribution of the laundry in the drum.
• The machine will not spin if water is not drained completely.
>>>
Check the filter and the draining hose.
• Excessive foam has occurred and automatic foam absorption
system has been activated due to too much detergent usage.
>>>
Use recommended amount of detergent.
Washing performance is poor: Laundry turns grey.
(**)
• Insufficient amount of detergent has been used over a long
period of time. >>>
Use the recommended amount of
detergent appropriate for water hardness and the laundry.
• Washing has been performed at low temperatures for a long
time. >>>
Select the proper temperature for the laundry to be
washed.
• Insufficient amount of detergent is used with hard water. >>>
Using insufficient amount of detergent with hard water causes
the soil to accumulate on the clothes over time and turns them
grey. It is difficult to eliminate greying once it happens. Use
the recommended amount of detergent appropriate for water
hardness and the laundry.
• Excessive amount of detergent has been used. >>>
Use the
recommended amount of detergent appropriate for water
hardness and the laundry.
Washing performance is poor: Stains persist or the
laundry is not whitened. (**)
• Insufficient amount of detergent is used. >>>
Use
recommended amount of detergent appropriate for the laundry.
• Excessive laundry is loaded in. >>>
Do not load the machine in
excess. Load with amounts recommended in the "Programme
and consumption table".
• Wrong programme and temperature were selected. >>>
Select the proper programme and temperature for the laundry
to be washed.
• Wrong type of detergent is used. >>>
Use original detergent
appropriate for the machine.
• Detergent is put in the wrong compartment. >>>
Put the
detergent in the correct compartment. Do not mix the bleaching
agent and the detergent with each other.
Washing performance is poor: Oily stains appeared
on the laundry. (**)
• Regular drum cleaning is not applied. >>>
Clean the drum
regularly. For this, please see 6.2.
Washing performance is poor: Clothes smell
unpleasantly. (**)
• Odours and bacteria layers are formed on the drum as a result
of continuous washing at lower temperatures and/or in short
programmes. >>>
Leave the detergent drawer as well as the
loading door of the machine ajar after each washing. Thus, a
humid environment favorable for bacteria cannot occur in the
machine.
37 / EN
Washer-Dryer / User Manual
Colour of the clothes faded. (**)
• Excessive laundry was loaded in. >>>
Do not load the machine
in excess.
• Detergent in use is damp. >>>
Keep detergents closed in
an environment free of humidity and do not expose them to
excessive temperatures.
• A higher temperature is selected. >>>
Select the proper
programme and temperature according to the type and soiling
level of the laundry.
Washing machine does not rinse well.
• The amount, brand and storage conditions of the detergent
used are inappropriate. >>>
Use a detergent appropriate for
the washing machine and your laundry. Keep detergents closed
in an environment free of humidity and do not expose them to
excessive temperatures.
• Detergent is put in the wrong compartment. >>>
If detergent
is put in the prewash compartment although prewash cycle is
not selected, machine can take this detergent during rinsing or
softener steps. Put the detergent in the correct compartment.
• Pump filter is clogged. >>>
Check the filter.
• Drain hose is folded. >>>
Check the drain hose.
Laundry became stiff after washing. (**)
• Insufficient amount of detergent is used. >>>
Using insufficient
amount of detergent for the water hardness can cause the
laundry to become stiff in time. Use appropriate amount of
detergent according to the water hardness.
• Detergent is put in the wrong compartment. >>>
If detergent
is put in the prewash compartment although prewash cycle is
not selected, machine can take this detergent during rinsing or
softener steps. Put the detergent in the correct compartment.
•
Detergent was mixed with the softener. >>> Do not mix the
softener with detergent. Wash and clean the drawer with hot water.
Laundry does not smell like the softener. (**)
• Detergent is put in the wrong compartment. >>>
If detergent
is put in the prewash compartment although prewash cycle is
not selected, machine can take this detergent during rinsing or
softener steps. Wash and clean the drawer with hot water. Put
the detergent in the correct compartment.
•
Detergent was mixed with the softener. >>> Do not mix the
softener with detergent. Wash and clean the drawer with hot water.
Detergent residue in the detergent drawer. (**)
• Detergent was put in wet drawer. >>>
Dry the detergent
drawer before putting in detergent.
• Detergent has gotten damp. >>>
Keep detergents closed in
an environment free of humidity and do not expose them to
excessive temperatures.
• Water pressure is low. >>>
Check the water pressure.
• The detergent in the main wash compartment got wet
while taking in the prewash water. Holes of the detergent
compartment are blocked. >>>
Check the holes and clean if
they are clogged.
• There is a problem with the detergent drawer valves. >>>
Call
the Authorised Service Agent.
•
Detergent was mixed with the softener. >>> Do not mix the
softener with detergent. Wash and clean the drawer with hot water.
There is detergent left on the laundry. (**)
• Excessive laundry was loaded in. >>>
Do not load the machine
in excess.
• Wrong programme and temperature were selected. >>>
Select the proper programme and temperature for the laundry
to be washed.
• Wrong detergent was used. >>>
Select the proper detergent
for the laundry to be washed.
Too much foam forms in the machine. (**)
• Improper detergents for the washing machine is used. >>>
Use detergents appropriate for the washing machine.
• Excessive amount of detergent is used. >>>
Use only sufficient
amount of detergent.
• Detergent was stored under improper conditions. >>>
Store detergent in a closed and dry location. Do not store in
excessively hot places.
• Some meshed laundry such as tulle may foam too much
because of their texture. >>>
Use smaller amounts of
detergent for this type of item.
• Detergent was put in the wrong compartment. >>>
Put the
detergent in the correct compartment.
• Softener is being taken early. >>>
There may be problem
in the valves or in the detergent drawer. Call the Authorised
Service Agent.
Foam is overflowing from the detergent drawer.
• Excessive amount of detergent is used. >>>>
Mix 1
tablespoonful softener and ½ L water and pour into the main
wash compartment of the detergent drawer.
• Put detergent into the machine suitable for the programmes
and maximum loads indicated in the “Programme and
consumption table". When you use additional chemicals (stain
removers, bleaches and etc), reduce the amount of detergent.
Laundry remains wet at the end of the programme.
(*)
• Excessive foam has occurred and automatic foam absorption
system has been activated due to too much detergent usage.
>>>
Use recommended amount of detergent.
38 / EN
Washer-Dryer / User Manual
(*) Machine does not switch to spinning step
when the laundry is not evenly distributed
in the drum to prevent any damage to the
machine and to its surrounding environment.
Laundry should be rearranged and re-spun.
(**) Regular drum cleaning is not applied.
>>> Clean the drum regularly. See 6.2
A
CAUTION!
• If you cannot eliminate the problem
although you follow the instructions in
this section, consult your dealer or the
Authorised Service Agent. Never try to
repair a nonfunctional product yourself.
Drying lasts too long.
• Excessive laundry loaded. >>> Do not load the machine
in excess.
• Laundry is not spun enough.>>> Spin at a higher spin
speed in washing step in the Dryer-Washing Machine.
• Tap is turned off. >>> Turn on the taps.
Laundry is still damp after drying.
• An appropriate programme according to laundry
type might is not selected.>>>Check care labels on
clothes and select an appropriate programme or use timed
programmes in addition.
• Excessive laundry loaded. >>> Do not load the machine
in excess.
• Laundry is not spun enough.>>> Spin at a higher spin
speed in washing step in the Dryer-Washing Machine.
Machine does not start or programme cannot be started.
• Power cable is not connected. >>> Make sure the power
cable is connected.
• Programme is not set or Start / Pause / Cancel button
is not pressed. >>> Make sure the programme is set and
it is not in Stand-by mode.
• Child lock enabled. >>> Disable Child lock.
Laundry is shrunken, pale, matted or damaged.
•
An appropriate programme according to laundry type is
not selected.>>>Check care labels on clothes and select an
appropriate programme or use timed programmes in addition.
You must not dry clothes that are not suitable for drying.
Machine does not dry.
• Laundry is not dried or drying step is not enabled. >>>
Check if drying function is selected after the selected washing
programme.
Loading door cannot be opened.
Your machine’s door is not opened for safety
reasons.>>>If door locked indicator is still active on display
after drying, machine keeps the loading door locked until it
cools for your safety.
8 Built-in installation guide
T20
Ø 4 x 16mm
M 5 x 10mm
x8 x2x6
a b c d e
x2 x2
580 mm
554 mm
597 mm
600 mm
817 mm
820 mm
1
153 mm
15 mm
60 mm
2
3
172
338
36
190
338
52
536
21
26
590 / 595
4
Ø
35
12
[mm]
L
26
4
190
338
36
172
338
52
536
21
26
590 / 595
Ø
35
12
R
26
[mm]
5
Ø35
12
16-22
Ø2
[mm]
12
Ø2
36
[mm]
6
7
±2mm
±2mm
BEKO UK AND IRELAND STANDARD MANUFACTURER GUARANTEE TERMS AND CONDITIONS
Your new Beko product is guaranteed against faulty materials, defective components or manufacturing defects.
The standard guarantee starts from the date of original purchase of the product, and lasts for a period of twelve (12)
months unless Beko plc (the “Manufacturer”) agrees to extend the guarantee for the product in writing.
If you have purchased an American style Fridge freezer, the standard guarantee starts from the date of original
purchase of the product, and lasts for a period of twenty four (24) months unless Beko plc (the “Manufacturer”)
agrees to extend the guarantee for the product in writing.
If you have any questions about the guarantee on your product (including how long it is valid), please contact your retailer or
our contact centre on 0333 207 9710 (UK and Northern Ireland) or 01 862 3411 (Republic of Ireland)
This guarantee does not in any way diminish or affect your statutory rights in connection with the product. This guarantee is in
addition to your statutory rights as a consumer. If you have any questions about these rights, please contact the retailer from
which you purchased the product. In certain circumstances, it is possible that your statutory rights may offer additional or
higher levels of protection than those offered under the terms of this guarantee.
What is covered by this guarantee?
• Repairs to the product required as a result of faulty materials, defective components or manufacturing defects.
• Functional replacement parts to repair a product.
• The costs of a Beko Approved Engineer to carry out the repair.
What is not covered?
• Transit and delivery damage.
• Cabinet or appearance parts, including but not limited to control knobs, flaps and handles.
• Accessories and/or consumable items including but not limited to ice trays, scrapers, cutlery baskets, filters and light
bulbs.
• Repairs necessary as a direct or indirect result of:
- Accidental damage, misuse or abuse of a product.
- An attempted repair of a product by anyone other than a Beko Approved Engineer (the “Engineer”).
- Installation or use of a product where such installation or use fails to meet the requirements contained in this
guarantee or the User Instructions Booklet.
• Repairs to a product operated at any time on commercial or non-residential household premises (unless we have
previously agreed to the installation environment).
This guarantee is limited to the cost of repairing the product. To the extent permitted by law, the Manufacturer does not accept
and will not be held liable for any financial loss incurred in connection with the failure of any product to operate in accordance
with the expected standards. Such financial loss includes but is not limited to loss arising from:
• Time taken off work.
• Damaged food, clothing or other items.
• Meals taken at restaurants or from takeaways.
• General compensation for inconvenience.
Important Notes
1. Your product is designed and built for domestic household use only.
2. The guarantee will automatically be void if the product is installed or is used in commercial or non-residential
domestic household premises, unless we have previously agreed to the installation environment.
3. The product must be correctly installed, located and operated in accordance with the instructions contained in the
User Instructions Booklet provided with your product.
4. Professional installation by a qualified Electrical Domestic Appliance Installer is recommended for all Washing
Machines, Dishwashers and Electric Cookers (as incorrect installation may result in you having to pay for the cost of
repairing the product).
5. Gas Cookers must be professionally installed by a Gas Safe (or Gas Networks Ireland for Republic of Ireland)
registered gas installer.
6. This guarantee is given in respect of products purchased and used within the United Kingdom and the Republic of
Ireland.
7. This guarantee is effective from the initial date of purchase of a new product from an authorised retailer and will be
void if the product is resold.
8. This guarantee does not apply to graded sales (where the product is purchased as a “second”).
9. Possession of a copy of these terms and conditions does not necessarily mean that a product has the benefit of this
guarantee. If you have any questions, please call our Call Centre on the number set out above.
10. The Manufacturer reserves the right to terminate the guarantee if its staff or representatives are subjected to physical
or verbal abuse in the course of carrying out their duties.
11. Optional extras, where available (i.e. extendable feet) are supplied on a chargeable basis only.
Does Beko offer replacements?
This is a repair-only guarantee. On occasion, the Manufacturer may at its sole discretion, replace your product with a new
product instead of carrying out a repair. Where a replacement is offered, this would normally be an identical model but when
this is not possible, a model of similar specification will be provided. The Manufacturer will cover the costs and arrange for the
delivery of the new product and for the return of the old product. Any costs related to disconnecting the faulty product and
installing the replacement product will not be borne by the Manufacturer unless previously agreed to in writing. The original
guarantee will continue to apply to the replacement product; the new product will not come with a new guarantee.
When will the repair take place?
Our Engineers work Monday to Friday 9.00am to 5.00pm. Appointments outside these hours may be possible at the sole
discretion of the Manufacturer but cannot be guaranteed. Whilst our Engineers will endeavour to minimize inconvenience and
to meet requests for specific timed appointments, this cannot be guaranteed. We will not be liable for delays or if it is unable to
carry out a repair because a convenient appointment cannot be arranged.
Will there be any charge for the repairs?
It is your responsibility to provide evidence to the Engineer that your product is covered by this guarantee with a proof of
purchase. The Manufacturer reserves the right to charge for the reasonable cost of any service call if:
• You cannot provide evidence that your product is covered by this guarantee.
• Where a service call has been made and the engineer finds that there is no fault with your product.
• That your product has not been installed or operated in accordance with the User Instructions Booklet.
• That the fault was caused by something other than faulty materials, defective components or manufacturing defects.
• For missed appointments.
Payment of these costs are due immediately upon the Engineer providing you with an invoice. The Manufacturer reserves the
right to terminate the guarantee if you fail to pay the costs for the service call in a timely manner.
If you are a resident of the United Kingdom, this guarantee will be governed by English law and subject to the English Courts,
save where you live in another part of the United Kingdom, in which case the law and courts of that location will apply.
If you are resident in the Republic of Ireland, this guarantee will be governed by Irish law and the Irish courts will have
jurisdiction.
This guarantee is provided by Beko plc. Beko House, 1 Greenhill Crescent, Watford, Hertfordshire. WD18 8QU.
Beko plc is registered in England and Wales with company registration number 02415578.
9. Possession of a copy of these terms and conditions does not necessarily mean that a product has the benefit of this
guarantee. If you have any questions, please call our Call Centre on the number set out above.
10. The Manufacturer reserves the right to terminate the guarantee if its staff or representatives are subjected to physical
or verbal abuse in the course of carrying out their duties.
11. Optional extras, where available (i.e. extendable feet) are supplied on a chargeable basis only.
Does Beko offer replacements?
This is a repair-only guarantee. On occasion, the Manufacturer may at its sole discretion, replace your product with a new
product instead of carrying out a repair. Where a replacement is offered, this would normally be an identical model but when
this is not possible, a model of similar specification will be provided. The Manufacturer will cover the costs and arrange for the
delivery of the new product and for the return of the old product. Any costs related to disconnecting the faulty product and
installing the replacement product will not be borne by the Manufacturer unless previously agreed to in writing. The original
guarantee will continue to apply to the replacement product; the new product will not come with a new guarantee.
When will the repair take place?
Our Engineers work Monday to Friday 9.00am to 5.00pm. Appointments outside these hours may be possible at the sole
discretion of the Manufacturer but cannot be guaranteed. Whilst our Engineers will endeavour to minimize inconvenience and
to meet requests for specific timed appointments, this cannot be guaranteed. We will not be liable for delays or if it is unable to
carry out a repair because a convenient appointment cannot be arranged.
Will there be any charge for the repairs?
It is your responsibility to provide evidence to the Engineer that your product is covered by this guarantee with a proof of
purchase. The Manufacturer reserves the right to charge for the reasonable cost of any service call if:
• You cannot provide evidence that your product is covered by this guarantee.
• Where a service call has been made and the engineer finds that there is no fault with your product.
• That your product has not been installed or operated in accordance with the User Instructions Booklet.
• That the fault was caused by something other than faulty materials, defective components or manufacturing defects.
• For missed appointments.
Payment of these costs are due immediately upon the Engineer providing you with an invoice. The Manufacturer reserves the
right to terminate the guarantee if you fail to pay the costs for the service call in a timely manner.
If you are a resident of the United Kingdom, this guarantee will be governed by English law and subject to the English Courts,
save where you live in another part of the United Kingdom, in which case the law and courts of that location will apply.
If you are resident in the Republic of Ireland, this guarantee will be governed by Irish law and the Irish courts will have
jurisdiction.
This guarantee is provided by Beko plc. Beko House, 1 Greenhill Crescent, Watford, Hertfordshire. WD18 8QU.
Beko plc is registered in England and Wales with company registration number 02415578.
BEKO UK AND IRELAND BUILT-IN APPLIANCES GUARANTEE TERMS AND CONDITIONS
If you have purchased a built-in or integrated appliance, and registered it within 90 days of purchase by completing
the online registration form, then the standard 12 month guarantee will be extended to 24 months, under the same
terms and conditions as detailed in our Standard Guarantee Terms and Conditions.
BEKO UK AND IRELAND PROSMART INVERTER MOTOR GUARANTEE TERMS AND CONDITIONS
This 10 year guarantee relates to Beko products that feature the ProSmart Inverter Motor.
The ProSmart Motor guarantee terms and conditions are in addition to our Standard guarantee terms and conditions detailed
in the previous section.
In order to activate the 10 year guarantee you MUST register the appliance within 90 days of the original purchase
date. You can register by first visiting Beko.co.uk/register and by following the online instructions.
Beko Free standing appliances come with a 12 month parts and labour guarantee as standard,
Beko Built-in appliances come with a 12 month parts and labour guarantee as standard. This is extended to 24 months, free of
charge, upon registration of the appliance. When you register your appliance for additional guarantee, you will automatically
activate the ProSmart Motor 10 year guarantee. You do not need to register twice. (beko.co.uk/guarantee-terms).
To make a claim against your Beko ProSmart Inverter Motor Guarantee (the “Guarantee”), all customer and product details
must be registered with Beko plc using the procedure outlined below.
1. This extra 9 years (for free standing appliances) or 8 years (for built-in or integrated appliances) guarantee is only
effective after the expiration of the standard manufacturer’s guarantee.
2. It is only valid for the ProSmart Inverter motors of selected washing machines, washer-dryers, tumble dryers and
dishwashers. It does not cover any labour charge or any other components of the product. In addition, it is only valid
for one replacement of the ProSmart motor during the extra 9-year (for free standing appliances) or 8 year (for built-in
appliances) guarantee period.
3. To activate your guarantee, you MUST register your appliance within 90 days of the original purchase date, by visiting
beko.co.uk/register.
4. Customers will receive a unique reference code as proof of guarantee validation by email or post, which must be
quoted at the time of a claim being made.
5. Any repair/replacement of the ProSmart Inverter motor must only be carried out by an authorised Beko Service Agent
(the “Service Agent”).
6. Labour for the repair/replacement of the ProSmart Inverter motor is not included in this guarantee and is chargeable
directly by the Service Agent.
7. Any additional components fitted to the product at any time will not be covered by this guarantee and will be
chargeable directly by the Service Agent.
8. The guarantee is not transferable and cannot be exchanged for cash.
9. There are no alternative or additional offers to this Guarantee.
10. The guarantee is exclusive of the manufacturer’s standard guarantee
11. The Terms and Conditions shown above are in addition to the standard terms and conditions of your product
guarantee. Please read and refer to such Terms and Conditions when making any claim.
12. We may use the information you provide for marketing purposes and to analyse your purchasing preferences. We
may keep your information for a reasonable period for these purposes in accordance with the applicable Data
Protection Laws and General Data Protection Regulations (GDPR). You can opt into this service during the
registration process. Further details are available at http://www.beko.co.uk/cookie-and-privacy.
13. These Terms and Conditions are governed by the laws of England and Wales; manufacturer: Beko plc, Beko House,
1 Greenhill Crescent, Watford WD18 8QU. Company Registration Number: 02415578.
HOW TO OBTAIN SERVICE FOR YOUR APPLIANCE
Please keep your purchase receipt or other proof of purchase details in a safe place; you will need to have this documentation
available should the product require attention under guarantee.
Please take a few moments to complete the details below, as you will need this information when you call us, or to use our
online services. When you call us you may be required to input your serial number into your telephone keypad. For help please
visit beko.co.uk/support/model-finder
• The product model number is printed on the Operating Instruction Booklet / User guide
• The product model and serial number is printed on the Rating Label affixed to the appliance.
• The Retailer (Purchased from) and Date of purchase will be printed on your purchase receipt or other proof of
purchase paperwork
Recording of these details alone will not count as proof of purchase. A valid proof of purchase is required for requesting
service under guarantee.
Model number
Serial number
Purchased from
Date of purchase
For service under guarantee or for product advice please call our Contact centre
Before requesting service please check the troubleshooting guide in the Operating Instructions booklet, as a charge may be
levied where no fault is found, and even though your product may still be under guarantee.
After arranging service the area around the product must be easily accessible to the Engineer, without the need for cabinets or
furniture to be removed or moved.
It is your responsibility to ensure our Engineers have a clean and safe environment to carry out any repairs.
Please have your Model number and Serial number available when you call us, as you may be required to input your serial
number into your telephone keypad during your call.
UK Mainland & Northern Ireland:
0333 207 9710
Landline or mobile calls to 0333 numbers cost no more than calls to geographic numbers 01 or 02, and are charged at the
basic rate. Calls from landlines and mobiles are included in free call packages but please check with your telephone service
provider for exact call charges.
Republic of Ireland:
01 862 3411
Service once the manufacturers guarantee has expired
If you have purchased an extended guarantee please refer to the instructions contained within the extended guarantee
agreement document, otherwise please call us using the appropriate number above, where service can be obtained at a
charge.
Should you experience any difficulty in obtaining service please call us on 0333 207 9710 or 01 862 3411
Contact us though our website
Send us a secure message through our online contact us form. Please visit our website, click Contact Us and choose a
product support topic from the list of options. Complete the required details and click send message.
Product registrations
For UK registrations please visit beko.co.uk/register and for the Republic of Ireland visit beko.ie/register.
DISCLAIMER / WARNING (EN)
Some (simple) failures can be adequately handled by the end-user without any safety issue or
unsafe use arising, provided that they are carried out within the limits and in accordance with the
following instructions (see the “Self-Repair” section).
Therefore, unless otherwise authorized in the “Self-Repair” section below, repairs shall be
addressed to registered professional repairers in order to avoid safety issues. A registered
professional repairer is a professional repairer that has been granted access to the instructions
and spare parts list of this product by the manufacturer according to the methods described in
legislative acts pursuant to Directive 2009/125/EC.
However, only the servce agent (.e. authorzed professonal reparers) that you can
reach through the phone number gven n the user manual/warranty card or through
your authorzed dealer may provde servce under the guarantee terms. Therefore,
please be advsed that repars by professonal reparers (who are not authorzed by
Grundg) shall vod the guarantee.
Self-Repair
Self-repair can be done by the end-user with regard to the following spare parts: door, door
hinge and seals, other seals, door locking assembly and plastic peripherals such as detergent
dispensers (an updated list is also available in support.grundig.com as of 1st of March 2021).
Moreover, to ensure product safety and to prevent risk of serious injury, the mentioned self-repair
shall be done following the instructions in the user manual for self-repair or which are available in
support.grundig.com. For your safety, unplug the product before attempting any self-repair.
Repair and repair attempts by end-users for parts not included in such list and/or not following the
instructions in the user manuals for self-repair or which are available in support.grundig.com, might
give raise to safety issues not attributable to Grundig, and will void the warranty of the product.
Therefore, it is highly recommended that end-users refrain from the attempt to carry out repairs
falling outside the mentioned list of spare parts, contacting in such cases authorized professional
repairers or registered professional repairers. On the contrary, such attempts by end-users may
cause safety issues and damage the product and subsequently cause fire, flood, electrocution and
serious personal injury to occur.
By way of example, but not limited to, the following repairs must be addressed to authorized
professional repairers or registered professional repairers: motor, pump assembly, main board,
motor board, display board, heaters etc.
The manufacturer/seller cannot be held liable in any case where end-users do not comply with the
above.
The spare part availability of the washing machine or washer-dryer that you purchased is 10 years.
During this period, original spare parts will be available to operate the washing machine or washer-
dryer properly.
