EDH803BEWA
EN Tumble Dryer User Manual
CONTENTS
1. SAFETY INFORMATION
....................................................................................3
2. CONDITIONS OF USE.......................................................................................6
3. SAFETY INSTRUCTIONS..................................................................................6
4. PRODUCT DESCRIPTION................................................................................ 8
5. CONTROL PANEL............................................................................................. 8
6.
WI-FI - CONNECTIVITY SETUP.............................................................. 10
7. PROGRAMME TABLE.....................................................................................
12
8. OPTIONS..........................................................................................................13
9. SETTINGS........................................................................................................15
10. BEFORE FIRST USE..................................................................................... 17
11. DAILY USE..................................................................................................... 17
12. HINTS AND TIPS........................................................................................... 18
13. CARE AND CLEANING..................................................................................19
14. TROUBLESHOOTING....................................................................................22
15. TECHNICAL DATA.........................................................................................23
16. QUICK GUIDE................................................................................................24
17. WARRANTY .................................................................................................. 26
GET IT O N
www.electrolux.com2
IMPORTANT INFORMATION THAT MAY IMPACT
YOUR MANUFACTURER'S WARRANTY
Adherence to the directions for use in this manual is extremely important for
health and safety. Failure to strictly adhere to the requirements in this manual
may result in personal injury, property damage and affect your ability to make a
claim under the Electrolux manufacturer’s warranty provided with your product.
Products must be used, installed and operated in accordance with this manual.
You may not be able to claim on the Electrolux manufacturer’s warranty in the
event that your product fault is due to failure to adhere to this manual.
WE’RE THINKING OF YOU
Thank you for purchasing an Electrolux appliance. You’ve chosen a product that
brings with it decades of professional experience and innovation. Ingenious and
stylish, it has been designed with you in mind. So whenever you use it, you can
be safe in the knowledge that you’ll get great results every time. Welcome to
Electrolux.
Visit our website for:
Get usage advice, brochures, trouble shooter, service information:
www.electrolux.com
Register your product for better service:
www.registerelectrolux.com
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the
following data available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
1. SAFETY INFORMATION
Before the installation and use of the appliance, carefully
read the supplied instructions. The manufacturer is not
responsible if an incorrect installation and use causes
injuries and damage. Always keep the instructions with
the appliance for future reference.
- Read the supplied instructions.
ENGLISH 3
- Warning; Risk of fire / Flammable materials
1.1 Children and vulnerable people safety
WARNING!
Risk of suffocation, injury or permanent
disability.
• This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning the use of the appliance in a
safe way and understand the hazards involved.
• Children between 3 and 8 years of age and persons
with very extensive and complex disabilities shall be
kept away from the appliance unless continuously
supervised.
• Children of less than 3 years of age should be kept
away from the appliance unless continuously
supervised.
• Do not let children play with the appliance.
• Keep all packaging away from children and dispose of
it appropriately.
• Keep detergents away from children.
• Keep children and pets away from the appliance when
the door is open.
• If the appliance has a child safety device, it should be
activated.
• Children shall not carry out cleaning and user
maintenance of the appliance without supervision.
1.2 General Safety
• Do not change the specification of this appliance.
• If the tumble dryer is put on top of a washing machine,
use the stacking kit. The stacking kit, available from
your authorized vendor, can be used only with the
appliance specified in the instructions supplied with
www.electrolux.com4
the accessory. Read it carefully before installation
(refer to the Installation leaflet).
• The appliance can be installed as freestanding or
below a kitchen counter with correct space (refer to
the Installation leaflet).
• Do not install the appliance behind a lockable door, a
sliding door or a door with a hinge on the opposite
side, that would prevent the appliance door from being
fully open.
• The ventilation opening in the base must not be
covered by a carpet, mat, or any floor covering.
• CAUTION: The appliance must not be supplied
through an external switching device, such as a timer,
or connected to a circuit that is regularly switched on
and off by a utility.
• Connect the mains plug to the mains socket only at
the end of the installation process. Make sure that the
mains plug is accessible after installation.
• If the mains power supply cable is damaged, it must
be replaced by the manufacturer, its Authorised
Service Centre or similarly qualified persons to avoid
an electrical hazard.
• Do not exceed the maximum load of 8 kg (refer to the
"Programme chart" chapter).
• Do not use the appliance if items have been soiled
with industrial chemicals.
• Wipe away lint or packaging debris that has
accumulated around the appliance.
• Do not run the appliance without a filter. Clean the lint
filter before or after each use.
• Do not dry unwashed items in the tumble dryer.
• Items that have been soiled with substances such as
cooking oil, acetone, alcohol, petrol, kerosene, spot
removers, turpentine, waxes and wax removers
should be washed in hot water with an extra amount of
detergent before being dried in the tumble dryer.
ENGLISH 5
• Items such as foam rubber (latex foam), shower caps,
waterproof textiles, rubber backed articles and clothes
or pillows fitted with foam rubber pads should not be
dried in the tumble dryer.
• Fabric softeners, or similar products, should only be
used as specified by the product manufacturer’s
instructions.
• Remove all objects from items that could be a source
of fire ignition such as lighters or matches.
• WARNING: Never stop a tumble dryer before the end
of the drying cycle unless all items are quickly
removed and spread out so that the heat is dissipated.
• Before any maintenance operation, deactivate the
appliance and disconnect the mains plug from the
socket.
2. CONDITIONS OF USE
This appliance is intended to be used in
household and similar applications such
as:
• Farm houses
• By clients in serviced apartments,
holiday apartments and other
residential type environments.
3. SAFETY INSTRUCTIONS
3.1 Installation
• Remove all the packaging.
• Do not install or use a damaged
appliance.
• Follow the installation instructions
supplied with the appliance.
• Always take care when moving the
appliance as it is heavy. Always use
safety gloves and enclosed footwear.
• Do not install or use the appliance
where the temperature can be lower
than 5°C or higher than 35°C.
• The floor area on which the appliance
is to be installed must be flat, stable,
heat resistant and clean.
• Make sure that there is air circulation
between the appliance and the floor.
• Always keep the appliance vertical
when it is being moved.
• The rear surface of the appliance
must be put against a wall.
• When the appliance is in its
permanent position, check if it is
levelled correctly with the aid of a
spirit level. If it is not, adjust the feet
accordingly.
3.2 Electrical connection
WARNING!
Risk of fire and electric
shock.
• Connect the mains plug to the mains
socket only at the end of the
installation. Make sure that there is
access to the mains plug after the
installation.
• The appliance must be earthed.
• Make sure that the parameters on the
rating plate are compatible with the
electrical ratings of the mains power
supply.
www.electrolux.com6
• Always use a correctly installed
shockproof socket.
• Do not use multi-plug adapters and
extension cables.
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
• Do not touch the mains cable or the
mains plug with wet hands.
3.3 Use
WARNING!
Risk of injury, electric shock,
fire, burns or damage to the
appliance.
• Do not dry the damaged items which
contain padding or fillings.
• Only dry fabrics which are applicable
to dry in the tumble dryer. Follow the
instructions on the fabric label.
• If you have washed your laundry with
a stain remover start an extra rinse
cycle before you start the dryer.
• Do not drink or prepare food with the
condensed water/distilled water. It can
cause health problems to people and
pets.
• Do not sit or stand on the open door.
• Do not dry dripping wet clothes in the
tumble dryer.
• Oil-affected items can ignite
spontaneously, especially when
exposed to heat sources such as in a
tumble dryer. The items become
warm, causing an oxidation reaction
in the oil. Oxidation creates heat. If
the heat cannot escape, the items can
become hot enough to catch fire.
Piling, stacking or storing oil-affected
items can prevent heat from escaping
and create a fire hazard.
• If it is unavoidable that fabrics that
contain vegetable or cooking oil or
have been contaminated by hair care
products be placed in a tumble dryer
they should first be washed in hot
water with extra detergent -this will
reduce, but not eliminate, the hazard.
3.4 Internal lighting
WARNING!
Risk of injury.
• Visible LED radiation, do not look
directly into the beam.
• The LED lamp is dedicated to drum
lighting. This lamp cannot be reused
for other lighting purposes.
• To replace the internal lighting,
contact the Authorised Service
Centre.
3.5 Care and cleaning
WARNING!
Risk of injury or damage to
the appliance.
• Do not use water spray and steam to
clean the appliance.
• Clean the appliance with a moist soft
cloth. Use only neutral detergents. Do
not use abrasive products, abrasive
cleaning pads, solvents or metal
objects.
• Be careful when you clean the
appliance to prevent damage to the
cooling system.
3.6 Compressor
WARNING!
Risk of damage to the
appliance.
• The compressor and its system in the
tumble dryer is filled with a special
agent which is free from fluoro-chloro-
hydrocarbons. This system must stay
tight. The damage of the system can
cause a leakage.
3.7 Service
• To repair the appliance contact the
Authorised Service Centre.
• Use original spare parts only.
3.8 Disposal
WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the
mains electrical and water supplies.
• Cut off the mains electrical cable
close to the appliance and dispose of
it.
ENGLISH 7
• Remove the door catch to prevent
children or pets from becoming
trapped in the drum.
• Dispose of the appliance in
accordance with local requirements
for the disposal of Waste Electrical
and Electronic Equipment (WEEE).
4. PRODUCT DESCRIPTION
1 2
6
3
4
5
7
8
9
10
1
Water container
2
Control panel
3
Internal light
4
Appliance door
5
Filter
6
Rating plate
7
Airflow slots
8
Heat Exchanger lid
9
Heat Exchanger cover
10
Adjustable feet
For ease of loading laundry
or ease of installation the
door is reversible. (see
separate leaflet).
5. CONTROL PANEL
1
1112 10 9 8
5
7
6
432
1
Programme knob
2
Extra Anticrease touch button
3
Dryness Level touch button
4
Display
5
Time Dry touch button
6
Start/Pause touch button
7
Delay Start touch button
8
Remote touch button
www.electrolux.com8
9
End Alert touch button
10
Reverse Plus touch button
11
Extra Silent touch button
12
On/Off button
Press the touch buttons with
your finger in the area with
the symbol or name of the
option. Do not wear gloves
when you operate the
control panel. Make sure
that the control panel is
always clean and dry.
5.1 Display
Symbol on the display Symbol description
laundry dryness option: iron dry, cupboard dry,
extra dry
time drying option on
delay start option on
indicator:
Wi-Fi connection
remote start option on
indicator:
check Heat Exchanger
indicator:
clean filter
indicator:
drain the water container
child lock on
wrong selection
indicator:
drying phase
indicator:
cooling phase
indicator:
anti-crease phase
programme duration
, , ,
extension of default anti-crease phase:
+30min, +60min, +90min, +2h)
ENGLISH 9
Symbol on the display Symbol description
-
time drying selection (10min-2h)
-
delay start selection (1h-20h)
6. WI-FI - CONNECTIVITY SETUP
This chapter describes how to connect
the smart appliance to the Wi-Fi network
and to link it to a mobile devices.
By this functionality you can receive
notifications, monitor and control your
tumble dryer from your mobile devices.
To connect the appliance to enjoy the full
range of features and services you need:
•
Wireless network at home with
internet connection enabled.
• Mobile device connected to wireless
network.
Frequency 2.4 GHz according to
local country regulation
Protocol IEEE 802.11b/g/n
Max power According to local
country regulation
Minimum requirements:
Operating system
compatibility iOS 9.3/Android
5.1 and above. Install the
My
Electrolux app, create an
account and accept the
Terms and Conditions and
Electrolux's Privacy Policy to
use the connected features.
Stable Internet and good Wi-
Fi connection with 2.4GHz
wireless frequency is
required. Minimum
requirements, apps and
services are subject to
change without notice.
6.1 Installing and configuring
My Electrolux
When connecting the tumble dryer to the
application, stand near it with Your smart
device.
Make sure that your smart device is
connected to the wireless network.
1. Go to the App Store on your smart
device.
2. Download and install App
My
Electrolux .
3. Make sure you started a Wi-fi
connection in the dryer. If not go to
the section below.
4. Start the application. Select the
country and language and login with
Your email and password. If you do
not have an account, create a new
one following the instructions in My
Electrolux.
5. Follow the instructions on the App for
the appliance registration and
configuration.
A message appears on the appliance
display to confirm that the configuration
was successful.
6.2 Configuring the dryer
wireless connection
Have My Electrolux downloaded and
installed on your smart device.
1. Press the on/off button for a few
seconds to activate the appliance.
2. Select a programme by turning the
programme dial.
3. Press and hold
Remote touch
button for 3 seconds.
The text pop up for about 5 seconds
and the icon
starts flashing and
wireless module begins starting up. It
www.electrolux.com10
may takes about 45 seconds before it is
ready. When the wireless module is
ready, the text (Access Point) is on
to inform you, that the access point will
be open for about 3 minute.
4. Configure the
My Electrolux app on
your smart device.
5. If the connectivity is configured,
(Access Point) symbol is off and the
icon
will stop blinking and lit
steadily to confirm that the
configuration was successful.
Every time you switch
the appliance on, the
appliance takes 45
seconds to connect to
the network
automatically. When the
indicator stops
blinking the connection
is ready.
To switch the wireless connection
off,Press and hold Remote touch
button for 3 seconds until the first
acoustic signal: appears on the
display.
If you switch the appliance
off and on again, the
wireless connection is
automatically off.
To remove the wireless
credentials,Press and hold Remote
touch button for 10 seconds until the
second acoustic signal:
appears on the display.
6.3 Remote Start
When the App is installed and the
wireless connection is complete, you can
start and stop a drying programme
remotely by activate remote start.
The Remote Control
activates automatically when
you press the Start/Pause
button to start the
programme, but it is also
possible to start a drying
programme
Activate Remote Start
1. Press the
Remote button and the
indicator appears on the
display.
2. Press the Start/Pause button to
activate the Remote Start.
The indicators appears on the
display. Now it is possible to start the
programme remotely.
Deactivate Remote Start
Press the Remote touch button and
confirm by pressing the Start/Pause
button.
The icon is off and the remote start is
deactivated.
If the door is open, the
Remote Start
is
deactivated.
6.4 Over-the-air update
The App may propose an update for
downloading new features.
The update is accepted via App only.
If a programme is running, the App
notifies that the update will start at the
end of the programme.
During the update, the appliance shows
in the display.
The appliance will usable again at the
end of the update, without any
notification about successful update.
If an error occurs, the appliance shows
in the display: just press any
buttons or turn the knob to return to
normal use.
ENGLISH 11
7. PROGRAMME TABLE
Programme
Load
1)
Properties / Fabric type
2)
Favourite
The load
depends
on a mem‐
orised pro‐
gramme
You can do your configuration of programme
and options and memorise in the appliance
memory (See chapter "
Settings - Favourite
").
Cottons
3)
8 kg Cotton fabrics.
/
Mixed + 6 kg
Mix of garments made of cotton,
cotton-synthetic blend and syn‐
thetic fabric.
/
Bedding + 4,5 kg
Up to three bed linen sets, one
of which can be double size.
/
Energy Saver 8 kg
Cycle to be used to dry cotton
with "cotton cupboard" dryness
level, with maximum energy sav‐
ing.
/
Refresh 1kg Refreshing textiles that were in storage.
App Program
The load
depends
on a selec‐
ted pro‐
gramme in
the app
App Program gives you additional pro‐
grammes that you can select from the App
(see chapter
"WI-FI - CONNECTIVITY SET‐
UP"
to connect the smart appliance to the Wi-
Fi network and to link it to a mobile devices).
Drying Rack
4)
1kg (or 1
pair of
sport
shoes)
For drying sport shoes only with Drying Rack
(see separate user manual provided with Dry‐
ing Rack).
Sports 2 kg
Sportswear, thin and light fab‐
rics, microfiber, polyester.
/
Silk 1 kg
Gentle drying of hand-washable
silks.
Synthetics 3,5 kg Synthetic and mixed fabrics.
/
www.electrolux.com12
Programme
Load
1)
Properties / Fabric type
2)
Wool
1 kg
The wool drying cycle of this machine has
been approved by The Woolmark Company
for the drying of wool garments labelled as
"hand wash" provided that the garments are
dried according to the instructions issued by
the manufacturer of this machine. Follow the
garment care label for other laundry instruc‐
tions. M1525
Delicates 4 kg
Delicate fabrics such as viscose,
rayon, acrylic, and their blends.
/
1)
The maximum weight refers to dry items.
2)
For fabric mark meaning see chapter
HINTS AND TIPS: Preparing the laundry.
3)
For test institutes only: the Cottons program in combination with the extra dry Dryness
Level is the “Standard cotton program”. It is suitable for drying normal wet cotton laundry
and it is the most efficient program in terms of energy consumption for drying wet cotton
laundry. Standard programme for tests are specified in the AS/NZS2442.2 document.
4)
Only with the Drying Rack (standard accessory or optional, depending on model).
8. OPTIONS
8.1 Extra Anticrease
Extends the anti-crease phase by 30,60,
90 or 2 hours at the end of the drying
cycle. This function reduces creases.
The laundry can be removed during the
anti-crease phase.
8.2 Dryness Level
This function helps to increase dryness
of the laundry. There are 3 options:
• Extra Dry
• Cupboard Dry
• Iron Dry
8.3 Time Dry
You can set the programme duration,
from a minimum of 10 minutes to a
maximum of 2 hours. The required
duration is related to the quantity of
laundry in the appliance.
We recommend that you set
a short duration for small
quantities of laundry or for
only one item.
8.4 Time Dry on Wool
programme
Option suitable for Wool programme to
adjust final dryness level.
ENGLISH 13
8.5 Time Dry on Drying Rack
programme
Option suitable for Drying Rack
programme .
You can set the programme duration,
from a minimum of 10 minutes to a
maximum of 2 hours. The setting of the
duration is related to the quantity of
laundry in the appliance.
We recommend that you set a short
duration for small quantities of laundry or
for only one item.
8.6 End Alert
The buzzer sounds at the:
• cycle end
• start and end of the anti-crease phase
• cycle interruption
The buzzer function is by default always
on. You can use this function to activate
or deactivate the sound.
You can activate the End
Alert option with all
programmes.
8.7 Reverse Plus
Increase drum reversing frequency to
reduce items twisting and entanglement.
To increase uniformity of drying result
and help reduce creases. Recommended
for large or long items (e.g. sheets,
trousers, long dresses)"
8.8 Extra Silent
The appliance operates with low noise
without effect on the drying quality. The
appliance operates slowly with longer
cycle time.
8.9 Options table
Programmes
1)
Dryness Level
Extra
Anti‐
crease
Extra
Silent
Re‐
verse
Plus
Time
Dry
Favourite
Depends on a memorised programme
Cottons ■ ■ ■ ■ ■ ■ ■
Mixed + ■ ■ ■ ■ ■
Bedding + ■ ■ ■ ■ ■
Energy Saver ■ ■
Refresh ■
App Program Depends on a selected programme in the app
Drying Rack
■
2)
Sports ■ ■
Silk ■ ■
Synthetics ■ ■ ■ ■ ■ ■ ■
Wool
■
3)
www.electrolux.com14
Programmes
1)
Dryness Level
Extra
Anti‐
crease
Extra
Silent
Re‐
verse
Plus
Time
Dry
Delicates ■ ■
1)
Together with the programme you can set 1 or more options. To activate or deactivate
them, press the related touch button.
2)
See chapter OPTIONS: Time Dry on Drying Rack programme
3)
See chapter OPTIONS: Time Dry on Wool programme
9. SETTINGS
A B C
E
DFGHI
A. Time Dry touch button
B. Start/Pause touch button
C. Delay Start touch button
D. Remote touch button
E. End Alert touch button
F. Reverse Plus touch button
G. Extra Silent touch button
H. Extra Anticrease touch button
I. Dryness Level touch button
9.1 Child lock function
This option prevents children playing with
the appliance while a programme is
operating. The touch buttons are locked.
Only the on/off button is unlocked.
Activating the child lock option:
1. Press the on/off button to activate the
appliance.
2. Press and hold touch button (E) for a
few seconds.
The child lock indicator comes on.
It is possible to deactivate
the child lock option while a
programme operates. Press
and hold the same touch
buttons until the child lock
indicator goes off. The Child
Lock function isn't available
for 8 s after switching on the
appliance.
9.2 Favourite
App Program cycle cannot
be saved as a Favourite on
the appliance.
You can do your configuration of
programme and options and memorise in
the appliance memory.
To memorise your
configuration:
1. Press the on/off button to activate the
appliance
2. Set the programme and available
options.
3. Press the (F) button for some
seconds.
The sound and the message on the
display confirm that the configuration is
memorised.
To activate your memorised
configuration:
1. Press the on/off button to activate the
appliance.
ENGLISH 15
2. Use the programme knob to set
Favourite position.
Previously memorised configuration of
programme and options will be restore.
9.3 Adjustment of the remaining
moisture
The appliance allows you to chose
between 3 levels corresponding to
different ranges of water hardness.
Dryness
level
ppm
the results
from the inclu‐
ded water
hardness kit.
< 150 C01-C03
150 - 300 C04-C05
> 300 C06-C07
Depending on the country, the water
hardness is expressed in equivalent
scales: e.g. French degrees (°f), German
degrees (°d), English degrees (°e),
mmol/l and ppm
If necessary, please contact your local
water authority to check the water
hardness in your area.
Every time you enter in the
"Adjustment of remaining
laundry moisture" mode,
previously set degree of
remaining moisture will
change into next value ( e.g
previously set will
change into ).
To change the default degree of
remaining moisture:
1. Press the on/off button to activate the
appliance.
2. Use the programme knob to set any
programme.
3. Wait approximately 8 seconds.
4. Press and hold buttons (F) and (E) at
the same time.
One of these indicators comes on:
• maximum dryness
•
more dry laundry
• standard dry laundry
5. Press and hold buttons (F) and (E)
again until the indicator of the correct
level comes on.
If the display returns to
the normal mode (the
time of the selected
programme from step 2.
will be displayed), while
setting the degree of
remaining moisture,
press and hold buttons
(F) and (E) once again to
enter to the "Adjustment
of remaining laundry
moisture" mode
(previously set degree of
remaining moisture will
change into next value).
6. To accept the selected degree of
remaining moisture, wait 5 s and the
display returns to the normal mode.
Dryness level Display symbol
maximum
dryness
more dry
laundry
standard
dry laundry
9.4 Water container indicator
By default, the water container indicator
is on. It comes on when the programme
is completed or when it is necessary to
empty the water container.
If a draining kit is installed
(additional accessory), the
appliance automatically
drains the water from the
water container. In this case
we recommend that you
deactivate the indicator of
the water container.
www.electrolux.com16
Deactivating the water
container indicator:
1. Press the on/off button to activate the
appliance.
2. Wait approximately 8 seconds.
3. Press and hold touch buttons (A) and
(C) at the same time.
The display shows one of these 2
configurations:
• The display shows "Off". After 5 s
the display returns to normal
mode.
• The display shows "On". After 5 s
the display returns to normal
mode.
10. BEFORE FIRST USE
Rear drum locks are
removed automatically when
dryer is activated for the first
time. Possible to hear some
noise.
To unlock the rear drum locks:
1. Switch on the appliance.
2. Set any programme.
3. Press the Start/Pause button.
Drum starts to rotate. Rear drum locks
are deactivated.
Before you use the appliance to dry
items:
• Clean the tumble dryer drum with a
moist cloth.
• Start a 1 hour programme with moist
laundry.
At the beginning of the
drying cycle (first 3-5 min)
there could be a slightly
higher sound level. This is
due to the compressor
starting up. This is normal
for compressor powered
appliances such as
refrigerators and freezers.
11. DAILY USE
11.1 Start a programme without
delay start
1. Prepare the laundry and load the
appliance.
CAUTION!
Make sure that when
you close the door, the
laundry does not get
caught between the
appliance door and the
rubber seal.
2. Press the on/off button to activate the
appliance.
3. Set the correct programme and
options for the type of load.
The display shows the programme
duration.
Real drying time will depend
on type of the load (quantity
and composition), the room
temperature and the
humidity of your laundry
after spin drying phase.
4. Press the Start/Pause touch button.
The programme starts.
11.2 Starting the programme
with delay start
1. Set the correct programme and
options for the type of load.
2. Press the delay start button again
and again until the display shows the
delay time you want to set.
You can delay the start
of a programme from a
minimum of 30 minutes
to a maximum of 20
hours.
3. Press the Start/Pause touch button.
ENGLISH 17
The display shows the countdown of the
delay start.
When the countdown is completed, the
programme starts.
11.3 Change a programme
1. Press the on/off button to deactivate
appliance
2. Press the on/off button to activate the
appliance.
3. Set the programme.
11.4 At the end of the
programme
When the programme is completed:
• An intermittent acoustic signal
operates.
• The display shows
• The indicator is on.
• The indicators Filter and Tank
may come on.
• The Start/Pause indicator is on.
The appliance continues to operate with
the anti-crease phase for approximately
30 minutes or more if Extra Anticrease
option was set (see chapter
Option -
Extra Anticrease
).
The anti-crease phase reduces creasing.
You can remove the laundry before the
anti-crease phase is completed. We
recommend, for better results, that you
remove the laundry when the phase is
almost completed.
When the anti-crease phase is
completed:
• The display still shows
• The indicator is off.
• The indicators
Filter and Tank
remain on.
• Start/Pause indicator goes off.
1. Press the on/off button to deactivate
the appliance.
2. Open the appliance door.
3. Remove the laundry.
4. Close the appliance door.
Always clean the filter and
empty the water container
when a programme is
completed.
11.5 Stand-by function
To reduce energy consumption, this
function automatically deactivates the
appliance:
• After 5 minutes if you do not start the
programme.
• After 5 minutes from the end of the
programme.
12. HINTS AND TIPS
12.1 Preparing the laundry
• Close the zips.
• Close the fasteners of duvet covers.
• Do not dry ties or ribbons loose (e.g.
apron ribbons). Tie them before you
start a programme.
• Remove all items from pockets.
• Turn items with the internal layer
made of cotton inside out. Cotton
layer must be faced outwards.
• Always set the programme suitable
for the type of laundry.
• Do not put light and dark colours
together.
• Use suitable programme for cottons,
jersey and knitwear to reduce
shrinkage.
• Do not exceed the maximum load
stated in the programmes chapter or
shown on the display.
• Dry only the laundry that is suitable
for tumble drying. Refer to the fabric
label on the items.
• Do not dry large and small items
together. Small items can be trapped
inside the large items and remain wet.
www.electrolux.com18
Fabric label Description
Laundry is suitable for tumble drying.
Laundry is suitable for tumble drying at higher temperatures.
Laundry is suitable for tumble drying at low temperatures only.
Laundry is not suitable for tumble drying.
13. CARE AND CLEANING
13.1 Cleaning the filter
CAUTION!
Avoid the use of water to
clean the filter. Instead throw
away lint in the dustbin
( avoid dispersion of plastic
fiber in water ambient).
To achieve the best drying
performances clean the filter
regularly , clogged filter lead
to longer cycles and energy
consumption increase.
Use your hand to clean the
filter , and if necessary , a
vacuum cleaner .
1. 2.
1
2
3.
1
2
4.
5.
1)
6.
2
1
1)
If necessary remove fluff from the filter socket and gasket. You can use a vacuum
cleaner.
ENGLISH 19
13.2 Emptying the water container
1. 2.
3. 4.
You can use the water from
the water container as an
alternative to distilled water
(e.g. for steam ironing).
Before you use the water,
remove dirt residues with a
filter.
13.3 Cleaning the Heat Exchanger
1. 2.
1
2
3. 4.
11
22
www.electrolux.com20
5. 6.
7. 8.
9.
2
1
CAUTION!
Do not touch the metal
surface with bare hands.
Risk of injury. Wear
protective gloves. Clean
carefully to avoid damaging
the metal surface.
13.4 Cleaning the drum
WARNING!
Disconnect the appliance
before you clean it.
Use a standard neutral soap detergent to
clean the inner surface of the drum and
drum lifters. Dry the cleaned surfaces
with a soft cloth.
CAUTION!
Do not use abrasive
materials or steel wool to
clean the drum.
13.5 Cleaning the control panel
and housing
Use a standard neutral soap detergent to
clean the control panel and housing.
Use a moist cloth to clean. Dry the
cleaned surfaces with a soft cloth.
CAUTION!
Do not use furniture cleaning
agents or cleaning agents
which can cause corrosion.
13.6 Cleaning the airflow slots
Use a vacuum cleaner to remove fluff
from the airflow slots.
ENGLISH 21
14. TROUBLESHOOTING
Problem Possible solution
You cannot activate the appliance. Make sure that the mains plug is connec‐
ted to the mains socket.
Check fuse in fuse box (domestic installa‐
tion).
The programme does not start. Press Start/Pause.
Make sure that the appliance door is
closed.
The appliance door does not close. Make sure that the installation of the filter
is correct.
Make sure that the laundry is not caught
between the appliance door and the rub‐
ber seal.
The appliance stops during operation. Make sure that the water container is
empty. Press Start/Pause to start the pro‐
gramme again.
Load is too small, increase the load or
use the Time Drying programme.
The cycle time is too long or unsatisfacto‐
ry drying result.
1)
Make sure that the weight of the laundry
is suitable for the duration of the pro‐
gramme.
Make sure that the filter is clean.
The laundry is too wet. Spin the laundry
in the washing machine again.
Ensure that the room temperature is
higher than +5°C and lower than +35°C.
Optimal room temperature is 19°C to
24°C.
Set the Time Drying or the Extra Dry pro‐
gramme.
2)
The App cannot connect to the dryer. Check if your smart device is connected
to the wireless network.
Check your home network and router.
Restart the router.
Contact your wireless service provider if
there are problems with the wireless net‐
work.
The dryer, the smart device, or both,
need to be configured again.
www.electrolux.com22
Problem Possible solution
The App frequently cannot connect to the
dryer.
Try to move the home router as near the
dryer as possible or consider purchasing
a wireless range extender.
Turn the microwave off. Avoid using the
microwave and the Remote Control of the
oven at the same time. The microwaves
disrupt the Wi-Fi signal.
The display shows .
If you want to set a new programme, de‐
activate and activate the appliance.
Make sure that the options are suitable
for the programme.
The display shows Error code (e.g. E51). Deactivate and activate the appliance.
Start a new programme. If the problem
occurs again, contact the Service centre.
1)
After maximum 5 hours, the programme ends automatically.
2)
It can happen that some area remains humid when drying big items (e.g. bed sheets ).
14.1 If the drying results are not
satisfactory
• The set programme was incorrect.
• The filter is clogged.
• The Heat Exchanger is clogged.
• There was too much laundry in the
appliance.
• The drum is dirty.
• Incorrect setting of the conductivity
sensor ( See chapter "
Settings -
Adjustment of the remaining laundry
moisture degree
" for better setting).
• The airflow slots are clogged.
• Room temperature is too low or too
high ( optimal room temperature 19°C
to 24°C )
15. TECHNICAL DATA
Height x Width x Depth 850 x 600 x 600 mm (maximum 665 mm)
Max. depth with the appliance door open 1100 mm
Max. width with the appliance door open 950 mm
Adjustable height 850 mm (+ 15 mm - feet regulation)
Drum volume 118 l
Maximum load volume 8 kg
Voltage 230-240 V
Frequency 50 Hz
Total power 900 W
Type of use Household
Permitted ambient temperature + 5°C to + 35°C
ENGLISH 23
Level of protection against ingress of sol‐
id particles and moisture ensured by the
protective cover, except where the low
voltage equipment has no protection
against moisture
IPX4
This product contains fluorinated greenhouse gases, hermetically sealed
Gas designation R134a
Weight
0,30 kg
Global-warming potential (GWP) 1430
16. QUICK GUIDE
16.1 Daily use
1 2
3
5
4
1. Push the On/Off button to turn on the
appliance.
2. Use the programme dial to set the
programme.
3. Together with the programme you
can set 1 or more special options. To
activate or deactivate an option touch
the relevant button.
4. To start the programme , Touch the
Start/Pause button.
5. The appliance starts.
www.electrolux.com24
16.2 Cleaning the filter
1 32
At the end of each cycle the filter symbol
appears on the display and you must
clean the filter.
16.3 Programme table
Programme
Load
1)
Properties / Fabric type
2)
Favourite
The load
depends
on a mem‐
orised pro‐
gramme
You can do your configuration of programme
and options and memorise in the appliance
memory (See chapter "
Settings - Favourite
").
Cottons
3)
8 kg Cotton fabrics.
/
Mixed + 6 kg
Mix of garments made of cotton,
cotton-synthetic blend and syn‐
thetic fabric.
/
Bedding + 4,5 kg
Up to three bed linen sets, one
of which can be double size.
/
Energy Saver 8 kg
Cycle to be used to dry cotton
with "cotton cupboard" dryness
level, with maximum energy sav‐
ing.
/
Refresh 1kg Refreshing textiles that were in storage.
App Program
The load
depends
on a selec‐
ted pro‐
gramme in
the app
App Program gives you additional pro‐
grammes that you can select from the App
(see chapter
"WI-FI - CONNECTIVITY SET‐
UP"
to connect the smart appliance to the Wi-
Fi network and to link it to a mobile devices).
Drying Rack
4)
1kg (or 1
pair of
sport
shoes)
For drying sport shoes only with Drying Rack
(see separate user manual provided with Dry‐
ing Rack).
ENGLISH 25
Programme
Load
1)
Properties / Fabric type
2)
Sports 2 kg
Sportswear, thin and light fab‐
rics, microfiber, polyester.
/
Silk 1 kg
Gentle drying of hand-washable
silks.
Synthetics 3,5 kg Synthetic and mixed fabrics.
/
Wool
1 kg
The wool drying cycle of this machine has
been approved by The Woolmark Company
for the drying of wool garments labelled as
"hand wash" provided that the garments are
dried according to the instructions issued by
the manufacturer of this machine. Follow the
garment care label for other laundry instruc‐
tions. M1525
Delicates 4 kg
Delicate fabrics such as viscose,
rayon, acrylic, and their blends.
/
1)
The maximum weight refers to dry items.
2)
For fabric mark meaning see chapter
HINTS AND TIPS: Preparing the laundry.
3)
For test institutes only: the Cottons program in combination with the extra dry Dryness
Level is the “Standard cotton program”. It is suitable for drying normal wet cotton laundry
and it is the most efficient program in terms of energy consumption for drying wet cotton
laundry. Standard programme for tests are specified in the AS/NZS2442.2 document.
4)
Only with the Drying Rack (standard accessory or optional, depending on model).
17. WARRANTY
FOR SALES IN AUSTRALIA AND NEW
ZEALAND
APPLIANCE: ELECTROLUX DRYER
This document sets out the terms and
conditions of the product warranties
for Electrolux Appliances. It is an
important document. Please keep it
with your proof of purchase
documents in a safe place for future
reference should there be a
manufacturing defect in your
Appliance. This warranty is in addition
to other rights you may have under
the Australian Consumer Law.
1. In this warranty:
a) ‘ACL’ or ‘Australian Consumer
Law’ means Schedule 2 to the
Competition and Consumer Act
2010;
b) ‘Appliance’ means any Electrolux
product purchased by you and
accompanied by this document;
www.electrolux.com26
c) ‘ASC’ means Electrolux
authorised service centres;
d) ‘Electrolux’ is the brand
controlled Electrolux Home
Products Pty Ltd of 163
O’Riordan Street, Mascot NSW
2020, ABN 51 004 762 341 in
respect of Appliances purchased
in Australia and Electrolux (NZ)
Limited (collectively “Electrolux”)
of 3-5 Niall Burgess Road, Mount
Wellington, in respect of
Appliances purchased in New
Zealand;
e) ‘Warranty Period’ means the
period specified in clause 3 of
this warranty;
f) ‘you’ means the purchaser of the
Appliance not having purchased
the Appliance for re-sale, and
‘your’ has a corresponding
meaning.
2. Application: This warranty only
applies to new Appliances,
purchased and used in Australia or
New Zealand and is in addition to
(and does not exclude, restrict, or
modify in any way) other rights and
remedies under a law to which the
Appliances or services relate,
including any nonexcludable
statutory guarantees in Australia and
New Zealand.
3. Warranty Period: Subject to these
terms and conditions, this warranty
continues for in Australia for a period
of 24 months and in New Zealand for
a period of 24 months, following the
date of original purchase of the
Appliance.
4. Repair or replace warranty: During
the Warranty Period, Electrolux or its
ASC will, at no extra charge if your
Appliance is readily accessible for
service, without special equipment
and subject to these terms and
conditions, repair or replace any
parts which it considers to be
defective. Electrolux may, in its
absolute discretion, choose whether
the remedy offered for a valid
warranty claim is repair or
replacement. Electrolux or its ASC
may use refurbished parts to repair
your Appliance. You agree that any
replaced Appliances or parts become
the property of Electrolux.
5. Travel and transportation costs:
Subject to clause 7, Electrolux will
bear the reasonable cost of
transportation, travel and delivery of
the Appliance to and from Electrolux
or its ASC. Travel and transportation
will be arranged by Electrolux as part
of any valid warranty claim.
6. Proof of purchase is required before
you can make a claim under this
warranty.
7. Exclusions: You may not make a
claim under this warranty unless the
defect claimed is due to faulty or
defective parts or workmanship. This
warranty does not cover:
a) light globes, batteries, filters or
similar perishable parts;
b) parts and Appliances not
supplied by Electrolux;
c) cosmetic damage which does not
affect the operation of the
Appliance;
d) damage to the Appliance caused
by:
1. negligence or accident;
2. misuse or abuse, including
failure to properly maintain or
service;
3. improper, negligent or faulty
servicing or repair works
done by anyone other than
an Electrolux authorised
repairer or ASC;
4. normal wear and tear;
5. power surges, electrical
storm damage or incorrect
power supply;
6. incomplete or improper
installation;
7. incorrect, improper or
inappropriate operation;
8. insect or vermin infestation;
9. failure to comply with any
additional instructions
supplied with the Appliance;
In addition, Electrolux is not liable
under this warranty if:
a. the Appliance has been, or
Electrolux reasonably believes
that the Appliance has been,
used for purposes other than
those for which the Appliance
ENGLISH 27
was intended, including where
the Appliance has been used for
any non-domestic purpose;
b. the Appliance is modified without
authority from Electrolux in
writing;
c. the Appliance’s serial number or
warranty seal has been removed
or defaced
8. How to claim under this warranty:
To enquire about claiming under this
warranty, please follow these steps:
a. carefully check the operating
instructions, user manual and the
terms of this warranty;
b. have the model and serial
number of the Appliance
available;
c. have the proof of purchase (e.g.
an invoice) available;
d. telephone the numbers shown
below.
9. Australia: For Appliances and
services provided by Electrolux in
Australia: Electrolux goods come with
guarantees that cannot be excluded
under the Australian Consumer Law.
You are entitled to a replacement or
refund for a major failure and for
compensation for any other
reasonably foreseeable loss or
damage. You are also entitled to
have the Appliance repaired or
replaced if the Appliance fails to be of
acceptable quality and the failure
does not amount to a major failure.
‘Acceptable quality’ and ‘major
failure’ have the same meaning as
referred to in the ACL.
10. New Zealand: For Appliances and
services provided by Electrolux in
New Zealand, the Appliances come
with a guarantee by Electrolux
pursuant to the provisions of the
Consumer Guarantees Act, the Sale
of Goods Act and the Fair Trading
Act. Where the Appliance was
purchased in New Zealand for
commercial purposes the Consumer
Guarantee Act does not apply.
11. Confidentiality: You accept that if
you make a warranty claim,
Electrolux and its agents including
ASC may exchange information in
relation to you to enable Electrolux to
meet its obligations under this
warranty.
Important Notice
Before calling for service, please ensure that the steps listed in clause 8 above have
been followed.
FOR SERVICE
or to find the address of
your nearest authorised
service centre in Australia
PLEASE CALL 13 13 49
For the cost of a local call (Australia
only)
AUSTRALIA
ELECTROLUX HOME
PRODUCTS
163 O’Riordan Street,
Mascot NSW 2020
electrolux.com.au
FOR SPARE PARTS
or to find the address of
your nearest
spare parts centre in Aus‐
tralia
PLEASE CALL13 13 50
For the cost of a local call (Australia
only)
FOR SERVICE
or to find the address of
your nearest authorised
service centre in New Zea‐
land
PLEASE CALL 0800 10
66 10
(New Zealand only)
NEW ZEALAND
ELECTROLUX (NZ) Limi‐
ted
3-5 Niall Burgess Road,
Mount Wellington
electrolux.co.nz
FOR SPARE PARTS
or to find the address of
your nearest state spare
parts centre in New Zea‐
land
PLEASE CALL 0800 10
66 20
(New Zealand only)
www.electrolux.com28
EDryer_Warr_May_17
18. ENVIRONMENTAL CONCERNS
Recycle materials with the symbol .
Put the packaging in relevant containers
to recycle it. Help protect the
environment and human health by
recycling waste of electrical and
electronic appliances. Do not dispose of
appliances marked with the symbol
with the household waste. Return the
product to your local recycling facility or
contact your municipal office.
*
ENGLISH 29
