Ninja QB1004 Master Prep Professional Blender

User Manual

For QB1004. Series: QB1004 Series

PDF File Manual, 16 pages, Read Online | Download pdf file

background
ninjakitchen.com
1 877 646-5288
QB1004 Series
Master Prep
®
Professional
®
OWNER’S GUIDE
Loading page 2...
Loading page 3...
Loading page 4...
Loading page 5...
Loading page 6...
Loading page 7...
Loading page 8...
Loading page 9...
Loading page 10...
Loading page 11...
Loading page 12...
Loading page 13...
Loading page 14...
Loading page 15...
Loading page 16...

Other documents for Ninja QB1004

The following documents are available:
User Manual Other Documents Photos

Specifications

See other models: SP101 BL456 CP307 HB152 CP301

User Manual - Transcript

  • Page 1: ninjakitchencom 1 877 6465288 QB1004 Series Master Prep Professional OWNERS GUIDE
  • Page 2 - English - : 1 18776465288 IMPORTANT SAFETY INSTRUCTIONS For Household Use Only WHEN USING ELECTRICAL APPLIANCES BASIC SAFETY PRECAUTIONS SHOULD ALWAYS BE FOLLOWED INCLUDING THE FOLLOWING READ ALL INSTRUCTIONS BEFORE USING YOUR NINJA MASTER PREP PROFESSIONAL POLARIZED PLUG WARNING To reduce the risk of electric shock this appliance has a polarized plug one blade is wider than the other This plug will fit into a polarized outlet only one way If the plug does not fit fully into the outlet reverse the plug If it still does not fit contact a qualified electrician to install the proper outlet DO NOT modify the plug in any way WARNING Extension cords are not recommended for use with this product WARNING TO REDUCE THE RISK OF FIRE ELECTRIC SHOCK OR INJURY 1 WARNING Remove utensils prior to processing Failure to remove may cause the jar to be damaged or to shatter which may cause personal injury 2 WARNING The Blade Assemblies are sharp not locked in place and removable handle with care When handling the Blade Assemblies always hold them by the shaft Failure to do so will result in a risk of laceration 3 WARNING The Blade Assemblies are sharp and not locked in place When pouring carefully remove the Blade Assembly first holding it by the shaft Failure to do so will result in a risk of laceration 4 WARNING The Blade Assemblies are sharp and not locked in place Make sure to carefully remove the splashguard and Blade Assembly holding it by the shaft Replace the splashguard before emptying contents of the pitcher or Master Prep Professional Bowl Failure to do so will result in a risk of laceration 5 CAUTION DO NOT blend hot liquids doing so may cause excessive pressure buildup resulting in risk of the user being burned 6 To protect against electrical shock DO NOT submerge the appliance or allow the power cord to come into contact with water or any other liquid
  • Page 3 - English - : wwwninjakitchencom 2 7 DO NOT allow the appliance to be used by children Close supervision is necessary when used near children This is not a toy 8 Never leave an appliance unattended when inuse 9 Appliance accessories are not intended to be used in the microwave as it may result in damage to the accessories 10 Remove the Master Pod from the appliance and unplug the power cord from the electrical outlet when not in use before assembling or disassembling parts and before cleaning To unplug grasp the plug and pull from the electrical outlet Never pull from the power cord 11 DO NOT abuse the power cord Never carry the Master Pod by the power cord or yank it to disconnect from electrical outlet instead grasp the plug and pull to disconnect 12 DO NOT operate any appliance with a damaged cord or plug or after the appliance malfunctions has been dropped or damaged in any manner This appliance has no serviceable parts Return the appliance to SharkNinja Operating LLC for examination repair or adjustment 13 DO NOT let the power cord hang over the edge of table or counter or touch hot surfaces such as the stove 14 Always use appliance on a dry level surface 15 Keep hands hair clothing as well as utensils out of container while processing to reduce the risk of severe injury to persons or damage to the appliance A scraper may be used but only when the appliance is not running 16 Avoid contact with moving parts 17 DO NOT attempt to sharpen blades 18 DO NOT use the appliance if blade assemblies are bent or damaged 19 DO NOT expose pitcher or the chopping bowl to extreme temperature changes 20 DO NOT use pitcher or chopping bowl if it is cracked or chipped 21 To reduce the risk of injury NEVER operate the appliance without the splashguard in place 22 DO NOT operate this appliance on or near any hot surfaces such as gas or electric burner or in a heated oven 23 The use of accessory attachments including canning jars not recommended by the manufacturer may cause fire electrical shock or risk of personal injury 24 DO NOT remove the Master Pod before the Blade Assemblies have stopped turning 25 DO NOT overfill 26 DO NOT operate the appliance empty 27 DO NOT try to defeat the interlock mechanism Make sure that the 4Blade Assemblies are properly inserted before operating the appliance 28 Immediately release the OnOff pulse button on the Master Pod in the event that the appliance malfunctions during use 29 DO NOT operate the appliance for more than 15 seconds 30 If the appliance overheats a thermal switch will become activated and shut off the motor To reset unplug the appliance and let it cool down for approximately 10 minutes before using again 31 THIS PRODUCT IS INTENDED FOR HOUSEHOLD USE ONLY Do not use this appliance for anything other than its intended use DO NOT use outdoors SAVE THESE INSTRUCTIONS
  • Page 4 - English - : 3 18776465288 THIS BOOK COVERS MODEL NUMBERS QB1004 QB1004CO QB1004LD TECHNICAL SPECIFICATIONS Voltage 120V 60Hz Power 450 Watts Pitcher Capacity 48 oz 6 cups 15 L 40 oz 5 cups 125 L Bowl Capacity 16 oz 2 cups 500 ml
  • Page 5 - English - : wwwninjakitchencom 4 Contents Thank you for purchasing the Ninja Master Prep Professional Getting Started 5 Before First Use 7 Assembly and Use of the Pitchers 8 Assembly and Use of the Master Prep Bowl 10 Cleaning and Maintenance 12 Troubleshooting Guide 13 Replacement Parts 13 Warranty amp Registration 14
  • Page 6 - English - : 5 18776465288 Getting Started NOTE Attachments are not interchangeable h Master Prep Professional Bowl with NonSlip Base i Bowl Splashguard j Upper Chopping Blade Assembly bowl k Lower Chopping Blade Assembly bowl l Bowl Storage Lid m Power Cord not shown a Master Pod b Master Prep Professional 40 oz Pitcher with NonSlip Base c Ninja 4Blade Assembly d Master Prep Professional 48 oz Pitcher with NonSlip Base e Pitcher Splashguard f Ninja 6Blade Assembly g Pitcher Storage Lid a h d e f g k j i l b c
  • Page 7 - English - : wwwninjakitchencom 6 The Ninja Master Prep Professional is an indispensable kitchen tool that is perfect for blending chopping mixing or pureeing when preparing your favorite recipes For best results be sure to carefully read all the instructions contained in the manual before using this appliance 450 Watt Master Pod The 450 watt Master Pod operates on 120V 60Hz electrical power NEVER allow the Master Pod to become wet when plugged into an electrical outlet WARNING The Master Pod should never be immersed in water or any other liquid CAUTION Make sure that the Master Pod is unplugged from the electrical outlet and that the Blade Assemblies have stopped turning before removing from the bowl or pitchers CAUTION The Blade Assemblies are sharp and not locked in place Make sure to carefully remove the splashguard and Blade Assembly holding it by the shaft before emptying contents of the pitcher or the Master Prep Professional Bowl Failure to do so will result in a risk of laceration IMPORTANT Never run the appliance empty
  • Page 8 - English - : 7 18776465288 WARNING DO NOT try to place the Blade Assemblies onto the Master Pod and then into the Master Prep Professional pitchers Always assemble the Ninja 6Blade and Ninja 4 Blade Assembly inside the pitchers PLEASE KEEP THESE IMPORTANT SAFEGUARDS IN MIND WHEN USING THE APPLIANCE IMPORTANT Make sure that the Master Pod is plugged in for use IMPORTANT Never add ingredients into the container before placing the Blade Assemblies in first IMPORTANT Attachments are not interchangeable IMPORTANT DO NOT attempt to operate the appliance without the splashguard on IMPORTANT Never run the appliance empty IMPORTANT Appliance accessories are not intended to be used in the microwave as it may result in damage to the accessories Before First Use WARNING Blade Assemblies are sharp and not locked in place Make sure to carefully remove the splashguard and Blade Assembly holding it by the shaft Replace the splashguard before emptying contents of the pitcher Failure to do so will result in a risk of laceration WARNING Blade Assemblies are sharp and not locked in place If using the pour spout ensure that the splashguard is fully on the pitcher Failure to do so will result in a risk of laceration CAUTION DO NOT immerse the Master Pod into water or any other liquid 1 Remove all packaging material and labels from the appliance Separateremove all parts from each other 2 Wash the lids splashguards bowl pitchers and blade assemblies in warm soapy water When washing the blade assemblies use a dishwashing utensil with a handle to avoid direct hand contact with blades WARNING Handle the blade assemblies with care when washing as the blades are sharp 3 Handle the blade assemblies with care to avoid contact with sharp edges Rinse and air dry thoroughly 4 The pitchers bowl lids splashguards and Blade Assemblies are all dishwasher safe It is recommended that the lids spashguards and blade assemblies be placed on the top rack Ensure that the blade assemblies are removed from the pitcher and the bowl before placing in the dishwasher 5 Wipe the motor base clean with a damp cloth
  • Page 9 - English - : wwwninjakitchencom 8 4 Add the ingredients to be processed into the Ninja Master Prep Professional pitcher 5 Place the pitcher splashguard onto the top of the Ninja Master Prep Professional pitcher fig 3 IMPORTANT Never add ingredients into the Ninja Master Prep Professional pitcher before placing the blade assembly in first Fig 2 Fig 3 Shaft Shaft Assembly and Use of the Pitchers 1 Review warning and caution statements above before proceeding to number 2 2 Place the pitcher on a clean dry level surface 3 Holding the Ninja 4Blade Assembly or Ninja 6Blade Assembly by the shaft place it onto the spindle pin inside the Master Prep Professional pitcher Use the Ninja 6Blade Assembly in the 48 oz Pitcher fig 1 Use the Ninja 4Blade Assembly in the 40 oz Pitcher fig 2 IMPORTANT Place the Ninja Blade Assemblies inside the pitcher carefully as blades are sharp WARNING Handle the Ninja 4Blade and 6Blade Assemblies with care as the blades are sharp WARNING Remove utensils prior to processing Failure to remove may cause the pitcher to be damaged or to shatter which may cause personal injury WARNING DO NOT try to place the Ninja 4Blade or 6Blade Assemblies onto the Master Pod and then into the pitcher WARNING DO NOT attempt to operate the appliance without the safety splashguard in place WARNING Never leave the appliance unattended while in use CAUTION DO NOT blend hot liquids doing so may cause excessive pressure buildup resulting in risk of the user being burned IMPORTANT Make sure that the Master Pod is plugged in for use Fig 1
  • Page 10 - English - : 9 18776465288 6 Review warning and caution statements on page 8 before proceeding to number 7 7 Place the Master Pod on top of the pitcher splashguard making sure that it is securely in place fig 4 DO NOT attempt to operate the appliance without the safety splashguard in place 8 To start the appliance plug the power cord into the electrical outlet securely hold Master Pod while operating and press on the OnOff pulse button located on the top of the power head fig 5 9 Hold the Ninja Master Prep Professional pitcher firmly while depressing the OnOff pulse button to ensure the unit stays in place NOTE DO NOT operate the appliance continuously for more than 15 seconds at a time 10 To stop the appliance remove your fingers from the On Off pulse button 10 In order to obtain a better quality of chopping operate the appliance by using the pulse method 12 Make sure that the Blade Assembly has stopped completely before removing the Master Pod 13 If the ingredients stick to the side of the Master Prep Professional pitcher stop the appliance remove the Master Pod and the splashguard Use a spatula to dislodge the pieces and then replace the splashguard and the Master Pod Continue processing 14 Depending on the consistency of the contents use the pouring spout to empty liquid contents 15 For thicker consistencies first remove the pitcher splashguard Then carefully remove the Blade Assemblies by the top of the shaft Place blade assemblies away from the work area to avoid accidental contact Finally empty contents from the pitcher HINTS amp TIPS FOR USING YOUR NINJA MASTER PREP PROFESSIONAL To crush ice into snow start by using short pulses to break up large chunks Continue until snow is achieved Fig 4 Fig 5 Assembly and Use of the Pitchers cont
  • Page 11 - English - : wwwninjakitchencom 10 WARNING Handle the Upper and Lower Chopping Bowl Blade Assemblies with care as the blades are sharp WARNING Remove utensils prior to processing Failure to remove may cause the bowl to be damaged or to shatter which may cause personal injury WARNING DO NOT try to place the Blade Assemblies onto the Master Pod and then into the bowl WARNING DO NOT attempt to operate the appliance without the safety splashguard in place WARNING DO NOT crush ice in Master Prep Bowl or damage may occur to the unit WARNING Never leave the appliance unattended while in use CAUTION DO NOT blend hot liquids doing so may cause excessive pressure buildup resulting in risk of the user being burned CAUTION Upper and Lower Chopping Bowl Blade Assemblies are loose and not locked in place Make sure to remove the Chopping Blade Assembly before emptying contents of processor bowl IMPORTANT Make sure that the Master Pod is plugged in for use WARNING DO NOT try to place the Upper and Lower Chopping Blade Assembly onto the Master Pod and then into the Master Prep Professional Bowl Assembly and Use of the Master Prep Bowl 1 Review warning and caution statements above before proceeding to number 2 2 Place the Master Prep Professional Bowl on a clean dry level surface 3 Holding the Lower Chopping Blade Assembly by the shaft place it over the spindle pin inside the Master Prep Professional Bowl fig 1 4 Carefully insert the Upper Chopping Blade Assembly over the Lower Chopping Blade Assembly rotating it until it locks onto the Lower Chopping Blade Assembly fig 2 IMPORTANT Always assemble the Chopping Blade Assembly inside the container Shaft Fig 1 Fig 2
  • Page 12 - English - : 11 18776465288 12 In order to obtain a better quality of chopping operate the appliance by using the pulse method 13 Make sure that the Chopping Blade Assembly has stopped completely before removing the Master Pod 14 If the ingredients stick to the side of the Master Prep Professional bowl stop the appliance remove the Master Pod and the splashguard Use a spatula to dislodge the pieces and then replace the splashguard and the Master Pod Continue processing 15 Blade assembly is loose and not locked in place Remove the blade assembly by its shaft before you empty the contents of the Master Prep Professional Bowl HINTS amp TIPS FOR USING YOUR NINJA MASTER PREP PROFESSIONAL The Chopping Blade Assembly can be used for chopping meat fish vegetables cheese etc For mincing chopping and pureeing increase the length of pulses For coarse chopping use short quick pulses and monitor food texture Precut larger pieces to make them fit into the Master Prep When chopping hard foods eg meat cheese cut into 1inch cubes 5 Review warning and caution statements on page 10 before proceeding to number 6 6 Place the food that you want to process into the Master Prep Professional Bowl IMPORTANT Never add ingredients into the Master Prep Professional Bowl before placing the blade assembly in first NOTE DO NOT add more than 2 cups dry or 1 cup liquid ingredients as this will strain the motor and may cause overflow 7 Place the splashguard on the bowl fig 3 8 Place the Master Pod on top of the splashguard making sure that it is securely in place fig 4 DO NOT attempt to operate the appliance without the safety splashguard in place 9 To start the appliance plug the power cord into the electrical outlet securely hold Master Pod while operating and press on the onoff pulse button located on the top of the Master Pod fig 5 10 Hold the Master Prep bowl firmly while depressing the OnOff pulse button to ensure the unit stays in place NOTE DO NOT operate the appliance continuously for more than 15 seconds at a time Be careful not to over process For coarsely chopped foods use repeated short pulsing action until the desired consistency is reached 11 To stop the appliance remove your fingers from the On Off pulse button Fig 3 Fig 4 Fig 5 Assembly and Use of the Master Prep Bowl cont
  • Page 13 - English - : wwwninjakitchencom 12 Care amp Maintenance HOW TO STORE 1 Store the Master Prep upright with the blade assembly and splashguard inside the corresponding container Loosely wrap the power cord around the Master Pod RESETTING THE MOTOR THERMOSTAT The Ninja Master Prep Professional features a unique safety system which prevents damage to the units motor and drive system should you inadvertently overload your appliance If the appliance is being overloaded the motor will stop To reset the appliance follow the resetting procedure below 1 Unplug the appliance from the electrical outlet 2 Remove the Master Pod and splashguard and empty the container and ensure that no food is jamming the blade assembly 3 Allow the appliance to cool for approximately 10 minutes 4 Replace the splashguard and Master Pod onto the container and replug the appliance into the electrical outlet 5 Proceed to use the appliance as before making sure not to exceed the recommended maximum capacities HOW TO CLEAN CAUTION Make sure that the Master Pod is unplugged from the power source before inserting or removing any attachment and before cleaning CAUTION DO NOT immerse the Master Pod into water or any other liquid 1 Separateremove all parts from each other 2 Hand Washing Wash the lids splashguards pitchers bowl and Blade Assemblies in warm soapy water When washing the Blade Assemblies use a dishwashing utensil with a handle to avoid direct hand contact with blades Handle the Blade Assemblies with care to avoid contact with sharp edges Rinse and air dry thoroughly Dishwasher The pitchers bowl lids splashguards and Blade Assemblies are all dishwasher safe It is recommended that the lids and blade assemblies be placed on the top rack Ensure the blade assemblies are removed from the pitchers and the bowl before placing in the dishwasher WARNING Handle the Blade Assemblies with care when washing as the blades are sharp Contact with the blades edges can result in laceration 3 Wipe the motor base clean with a damp cloth Please call customer service if any servicing needs to be performed on the appliance at 18776465288
  • Page 14 - English - : 13 18776465288 PROBLEMS POSSIBLE REASONS amp SOLUTIONS Motor Doesnt Start or Blade Assembly Doesnt Rotate Check that the bottom of Master Pod is clean and there is no food blocking connection when placing on containers There is too much food in the container The unit has overheated or overloaded Unplug and wait approximately 10 minutes before using again Make sure the splashguard is securely on container Make sure the Master Pod is securely placed on splashguard Check that the plug is securely inserted into the electrical outlet Check fuse or breaker Replace fusereset breaker Food is Unevenly Chopped Either you are chopping too much food at one time or the pieces are not small enough Try cutting the food into smaller pieces of even size and processing smaller amounts per batch Food is Chopped Too Fine or is Too Watery The food has been over processed Use brief pulses or process for shorter time Let blade assembly stop completely between pulses Food Collects On Splashguard or On the Sides of the Master Prep Professional Pitcher or Master Prep Professional Bowl You may be processing too much food Turn the machine off When the blade assembly stops rotating remove the Master Pod and the splashguard Remove some of the food being processed You Cannot Achieve Snow From Solid Ice Do not use ice that has been sitting out or has started to melt Be sure to use short pulses in the beginning to break up large pieces Troubleshooting Guide Replacement Parts ORDERING REPLACEMENT PARTS To order additional parts and attachments please visit our website wwwninjakitchencom or feel free to contact customer service 18776465288
  • Page 15 - English - : wwwninjakitchencom 14 Product Registration Please visit wwwregisteryourninjacom or call 18776465288 to register your new Ninja product within ten 10 days of purchase You will be asked to provide the store name date of purchase and model number along with your name and address The registration will enable us to contact you in the unlikely event of a product safety notification By registering you acknowledge to have read and understood the instructions for use and warnings set forth in the accompanying instructions ONE 1 YEAR LIMITED WARRANTY SharkNinja Operating LLC warrants this product to be free from material defects and workmanship for a period of one 1 year from the date of purchase when utilized for normal household use subject to the following conditions exclusions and exceptions The liability of SharkNinja Operating LLC is limited solely to the cost of the repair or replacement of the unit at our option This Limited Warranty does not cover normal wear of parts and does not apply to any unit that has been tampered with or used for commercial purposes This Limited Warranty does not cover damage caused by misuse abuse negligent handling or damage due to faulty packaging or mishandling in transit This Limited Warranty does not cover damage or defects caused by or resulting from damages from shipping or repairs service or alteration to the product or any of its parts which have been performed by a repair person not authorized by SharkNinja Operating LLC If your appliance fails to operate properly while in use under normal household conditions within the warranty period return the complete appliance and accessories freight prepaid For assistance with warranty service options or customer support please call our customer care and product specialists at call 1 877 6465288 or visit our website wwwninjakitchencom If the appliance is found to be defective in material or workmanship SharkNinja Operating LLC will repair or replace it free of charge Proof of purchase is required and a fee of 1995 will apply to cover the cost of return freight This Limited Warranty is extended to the original purchaser of the unit and excludes all other legal implied andor conventional warranties The responsibility of SharkNinja Operating LLC if any is limited to the specific obligations expressly assumed by it under the terms of this Limited Warranty In no event is SharkNinja Operating LLC liable for incidental or consequential damages to anyone of any nature whatsoever Some states do not permit the exclusion or limitation of incidental or consequential damages so the above may not apply to you This Limited Warranty gives you specific legal rights and you may also have other rights which vary from state to state or from province to province IMPORTANT Carefully pack item to avoid damage in shipping Be sure to include proof of purchase date and to attach tag to item before packing with your name complete address and phone number with a note giving purchase information model number and what you believe is the problem with the item We recommend you insure the package as damage in shipping is not covered by your Limited Warranty Mark the outside of your package ATTENTION CUSTOMER SERVICE
  • Page 16 - English - : SharkNinja Operating LLC US Newton MA 02459 CAN Ville StLaurent QC H4S 1A7 18776465288 wwwninjakitchencom Copyright SharkNinja Operating LLC 2016 Master Prep and Ninja are registered trademarks of SharkNinja Operating LLC Illustrations may differ from actual product We are constantly striving to improve our products therefore the specifications contained herein are subject to change without notice For SharkNinja US Patent information visit wwwsharkninjacomUSPatents Printed in China QB1004Series301610246
