PW172SFZ
172 Litre Upright Freezer
1
1. SAFETY WARNINGS
1) WARNING― Keep venlaon openings, in the appliance enclosure or in the built-in
structure, clear of obstrucon.
2) WARNING― Do not use mechanical devices or other means to accelerate the defrosng
process, other than those recommended by the manufacturer.
3) WARNING― Do not damage the refrigerant circuit.
4)WARNING― Do not use electrical appliances inside the food storage compartments of the
appliance, unless they are of the type
recommended by the manufacturer.
5)The appliance has to be unplugged aer use and before carrying out user maintenance on the
appliance.
6)This appliance can be used by children aged from 8 years and above and persons with reduce
physical sensory or mental capabilies or lack of experience and knowledge if they have been
given supervision or instrucon concerning use of the appliance in a safe way and understand the
hazards involved. Children shall not play with the applian
ce. Cleaning and user maintenance shall
not be made by children without supervision.
7)If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or
similarly qualified persons in order to avoid a hazard.
8)Please abandon the refrigerator according to local regulators for it use flammable blowing gas
and refrigerant.
9)Please according to local regulaons regarding disposal of the appliance for its flammable
refrigerant
and blowing gas. Before you scrap the appliance, please take off the doors to prevent
children trapped.
10)This appliance is intended to be used in household and similar applicaons such as
– staff kitchen areas in shops, offices and other working environments;
– farm houses and by clients in hotels, motels and other residenal type environments;
– bed and breakfast type environments;
– catering and similar non-retail applicaons.
11)Do not store explosive substances such as aeroso
l cans with a flammable propellant inthis
appliance.
IT IS HAZARDOUS FOR ANYONE OTHER THAN AUTHORISEDSERVICE PERSONNEL TO
CARRY OUT SERVICING OF REPAIRS WHICHINVOLVE THE REMOVAL OF COVERS.
TO AVOID THE RISK OF AN ELECTRICAL SHOCK DO NOT ATTEMPTREPAIRS YOURSELF.
2
2. INSTALLTION
When selec ng a posi on for your unit you should make sure the floor is flat and firm, and the
room is well ven
lated. Avoid loca ng your unit near a heat source, e.g. cooker, boiler or radiator.
Also avoid direct sunlight as it may increase the electrical consump
on.Extreme cold ambient
temperatures may also cause the unit not to perform properly. This unit is not designedfor use in
a garage or outdoor installa
on. Do not drape the unit with any covering.
When installing the unit, ensure that 10 cm of free space is le at both sides, 10 cm at the rear
and 30 cm at the top of the unit. This will allow cold air to circulate around the unit and improve
the efficiency of the cooling process.
2.2 Reversing the Door Swing
Phillips style screwdriver / Flat-blade screwdriver/ Hexagonal spanner/
Hexagonal socket wrench
1) Remove the right top hinge cover.
Right top hinge cover
3
2) Remove the screws fixed the top-hinge with cross-slot screwdriver.
3) Replace the top-hinge and the top-door limit block and the door bearing bush to the other
side.
A. Remove the nut with sleeve.Take off the washer then remove the axes to the other side
and fixed.
B. Remove the door limit block
C. Please taking out another door limit block, with screw mounng to the door
4
4) Disassemble the screws fixed the boom-hinge with Hexagonal socket wrench.
Note：the refrigerator-freezer incline angle less 45°.
5) Replace the bo
om hinge to the other side then fix it with screws.
6) Set the door right posi
on,fix the mid-hinge.
5
7) Replace the top-hinge.
8) Set the top door right posion,fix the top-hinge and the cover.
9) Replace the leveler to the other side and adjust it to make sure the cabinet level.
*All images in this instruc
on manual are for indica on only; please refer to your individual unit for details.
Palsonic Customer Service
Telephone (Australia) 1300 657 888
Palsonic Corporation Pty Ltd ABN 34 000 474 108
1 Joynton Avenue, Waterloo NSW 2017 Australia
Telephone (02) 9313 7111 Facsimile (02) 9697 0655
www.palsonic.com.au
