S u p p l i e d P a r t s L i s t
2
CAUTION!
WARNING
!
Th i s TV m o u n t m u s t be s ec urely att ached t o the
vertical wal l. If t h e mount i s not p r o per ly
ins t alled it m ay f all, r es ult i n g in p o s s ibl e injur y
an d /o r d am age.
Too l s Required
4m m Dri l l B it
Ph i lli p s S c rewdriver
10mm M asonr y B it
Carp enter 's L evel
(1)VESA Plate-b
(1)Wall Plate &
Articulating Arms-a
(2)Adapter-c (2)Adapter-d
(2)Lag Bolt-r(2)Lag Bolt Washer-q (2)Concrete Anchor-s (3)Cable Tie-t
(8)M4x10 Bolt-e (8)M4 Nut-g(8)M4 Washer-f
(4)M4x12 Bolt-h
(4)M6/M8 Spacer-m (1)Wrench-p(2)Bolt Cover-o(2)M4x6 Bolt-n
(4)M4x30 Bolt-i (4)M6x20 Bolt-j (4)M8x20 Bolt-k (4)M4 Spacer-l
65m m
4mm
Brick Mount
S t e p 1
Install the Wall Plate to the Wall
3
Wood Mount
60m m
65m m
10m m
a
r
s
q
a
r
q
4
S t e p 2 A
For F l at B ac k TV For C u rv ed B ac k T V
Thi s w ay u p!
Thi s w ay u p!
h
i
l
Attach VESA Plate to the Mounting Hole of TV
For VESA 75x75mm and 100x100mm Mounting Holes
250mm
200mm
10
0m
m
h t o k
c
d
e
f
g
S t e p 2 B
Attach VESA Plate to the Mounting Hole of TV
For VESA 200x100mm Mounting Holes
c
d
c
c
d
d
Th is w ay u p !
l,m ( if n ecessar y)
b
b
b
h t o k
Thi s w ay u p!
l,m ( if n ecessar y)
S t e p 3
Attach VESA Plate to the Socket on the Articulating Arm
3.1
3.2
n
3.3
S t e p 2 C
Attach VESA Plate to the Mounting Hole of TV
For VESA 200x200mm Mounting Holes
5
200mm
170mm
160m
m
2
0
0mm
d
c
e
f
g
d
c
d
c
c
d
b
6
S t e p 4
Adjust the Tilting Angle and Attach the Bolt Cover
p
o
Thank y ou f or c h oo si n g o ur p ro du c ts !
S t e p 5
Manage Wires with Included Cable Ties
t
