INSTRUCTION MANUAL
CERAMIC UTILITY HEATER
Thank you for choosing BLACK+DECKER!
PLEASE READ BEFORE RETURNING THIS PRODUCT FOR
ANY REASON.
If you have a question or experience a problem with your BLACK+DECKER
purchase, go to www.blackanddecker.com/instantanswers
If you can’t find the answer or do not have access to the Internet, call
844-299-0879 from 10:30 a.m. to 6:30 p.m. EST Mon. - Fri. to speak with an
agent. Please have the catalog number available when you call.
SAVE THIS MANUAL FOR FUTURE REFERENCE.
CATALOG NUMBER
BHUC201B
Page 2
Thank you for purchasing our
BLACK+DECKER product. This
easy-to-use manual will guide you
in getting the best use of your
ceramic utility heater.
Remember to record the model
and serial numbers. They are on a
label on the rear.
Staple your receipt to your manual.
You will need it to obtain warranty service.
Model number
Serial number
Date of purchase
PRODUCT REGISTRATION
CONTENTS
SAFETY INFORMATION
Important Safety Instructions .......................................................................................................................................... 3-5
Electrical Requirements..........................................................................................................................................................4
SET UP & USE
Parts & Features ......................................................................................................................................................................... 6
Operating Instructions ........................................................................................................................................................6-7
Control Panel ............................................................................................................................................................................... 7
TROUBLESHOOTING & WARRANTY
Troubleshooting ...................................................................................................................................................................9-10
Limited Warranty ..................................................................................................................................................................... 10
SPECIFICATIONS
Voltage: 120V, 60Hz
Power Consumption: 1500W
Unit Size (WxDxH): 14.6” x 13.8” x 11.8”
Page 3
SAFETY INFORMATION
IMPORTANT SAFETY INSTRUCTIONS
When using electrical appliances, basic precautions should always be
followed to reduce the risk of re, electric shock, and injury to persons,
including the following:
1. Read all instructions before using this heater.
2. This heater is hot when in use. To avoid burns, do not let bare skin
touch hot surfaces. If provided, use handles when moving this heater.
Keep combustible materials, such as furniture, pillows, bedding,
papers, clothes, and curtains at least 3 feet (0.9m) from the front of
the heater and keep them away from the sides and rear.
3. Extreme caution is necessary when any heater is used by or near
children or invalids and whenever the heater is left operating and
unattended.
4. Always unplug heater when not in use.
5. Do not operate any heater with a damaged cord or plug or after the
heater malfunctions, has been dropped or damaged in any manner.
Discard heater or return heater to authorized service facility for
examination, electrical or mechanical adjustment, or repair.
6. Do not use outdoors.
7. This heater is not intended for use in bathrooms, laundry areas and similar
indoor locations. Never locate heater where it may fall into bathtub or
other water container.
8. Do not run cord under carpeting. Do not cover cord with throw rugs,
runners, or similar coverings. Do not route cord under furniture or
appliances. Arrange cord away from trafc area and where it will not be
tripped over.
9. To disconnect heater, rst turn controls to off, then remove plug from
outlet.
10. Do not insert or allow foreign objects to enter any ventilation or exhaust
opening as this may cause an electric shock or re, or damage the
heater.
11. To prevent a possible re, do not block air intakes or exhaust in any
manner. Do not use on soft surfaces, like a bed, where openings may
become blocked.
WARNING
When using electrical appliances, basic safety precautions
should be followed, including the following
DANGER
DANGER - Immediate hazards
which WILL result in severe
personal injury or death
WARNING
WARNING - Hazards or unsafe
practices which COULD result in
severe personal injury or death
CAUTION
CAUTION - Hazards or unsafe
practices which COULD result in
minor personal injury
Page 4
12. A heater has hot and arcing or sparking parts inside. Do not use it in the
areas where gasoline, paint, or ammable liquids are used or stored.
13. Use this heater only as described in this manual. Any other use not
recommended by the manufacturer may cause re, electric shock, or
injury to persons.
14. CAUTION: Always plug heaters directly into a wall outlet/receptacle.
Never use with an extension cord or relocatable power tap (outlet/
power strip).
15. This heater draws 12.5 amps during operation. To prevent overloading
a circuit, do not plug the heater into a circuit that already has other
appliances working.
16. The output of this heater may vary and its temperature may become
intense enough to burn exposed skin. Use of this heater is not
recommended for persons with reduced sensitivity to heat or an inability
to react to avoid burns.
17. Don’t leave the heater on unattended.
18. Connect to properly grounded outlets only.
SAVE THESE INSTRUCTIONS
HOUSEHOLD USE ONLY
SAFETY INFORMATION
Page 5
SAFETY INFORMATION
OVERHEAT SAFETY FEATURE
This heater is equipped with a overheat safety feature. When the heater’s internal
components reach a certain temperature that could cause overheating and
possible re, the heater will automatically shut off. If this should occur, please
contact our Customer Satisfaction Center at 844-299-0879.
WARNING
It is normal for the power cord to feel warm to the touch; however, a
loose t between the outlet and the plug may cause overheating of
the plug. If this occurs, try inserting the plug into a different outlet.
Contact a qualied electrician to inspect the original outlet for
damage.
Grounding
Pin
(A)
Metal Screw
Cover of Grounded
Outlet Box
Adapter
(C)
Grounding
Means
Grounding
Pin
(D)
GROUNDING INSTRUCTIONS
WARNING
This heater has a voltage rating of 120 volts. The cord has a plug as
shown in A. An adapter as shown in C is available for connecting three-
blade grounding-type plugs to two-slot receptacles. The grounding
lug extending from the adapter must be connected to a permanent
ground such as a properly grounded outlet box. The adapter should
not be used if a three-slot grounded receptacle is available. DO NOT
DEFEAT THE SAFETY PURPOSE OF THE GROUNDED PLUG.
Page 6
PARTS & FEATURES
SET UP & USE
Thermostat Control
Power Control Dial
Power ON Indicator
Tension Dial
Airow Grill
OPERATION INSTRUCTIONS
1. Plug the heater into standard 120v household outlet.
2. Rotate the thermostat control clockwise to “MAX” to start and adjust down as
desired.
NOTE: The control is adjusting a mechanical thermostat so the closer it is to “MAX”,
the longer the unit will stay on as it attempts to reach a higher ambient room
temperature. As you rotate closer to “MIN”, there is a better chance of the
heater shutting o as the desired ambient room temperature is also being
lowered. The power on indicator illuminates when the thermostat turns on and
stops illuminating when the thermostat turns o.
Page 7
3. Rotate the power control dial clockwise to desired setting of “FAN” or “LOW”
(800w) or “HIGH” (1500w).
ADJUSTING AIR FLOW ANGLE
1. Turn tension dials FULLY on both sides counter clockwise to loosen.
2. Adjust the angle of the air ow outlet to desired position.
3. Tighten tension dials rmly clockwise.
SET UP & USE
Tension Dial
Angle Adjustment
Thermostat Control
Power Control Dial
Power Indicator Light
Fan Setting
Low Heat Setting
High Heat Setting
Page 8
CARE & CLEANING
MAINTENANCE
1. Turn power control dial to OFF.
2. Unplug the unit from wall outlet and let it cool completely.
3. To keep the heater clean, the outer shell may be cleaned with a soft, damp cloth.
You may use a mild detergent if necessary. After cleaning, dry the unit with a soft
cloth.
CAUTION: DO NOT let liquid enter the heater.
4. DO NOT use alcohol, gasoline, abrasive powders, furniture polish, or rough brushes
to clean the heater. This may cause damage or deterioration to the surface of the
heater.
5. DO NOT immerse the heater in water.
6. Wait until the unit is completely dry before use.
STORAGE
Store the heater in a cool, dry location when not in use. To prevent dust and dirt
build-up, use the original packaging to repack the unit.
Page 9
TROUBLESHOOTING & WARRANTY
BEFORE YOU CALL FOR SERVICE
If your heater fails to operate, please follow these instructions:
• Ensure that your circuit breaker or fuse is working properly.
• Make sure the heater is in the upright position.
• Be sure the heater is plugged in and that the electrical outlet is working properly.
• Check for any obstruction. If you nd any obstruction, turn the heater “OFF”.
Unplug the heater and wait a few minutes for it to cool down. Carefully remove the
obstruction. Plug the heater in and turn it on again by referring to the OPERATING
INSTRUCTIONS.
NOTE: If you experience a problem with your heater, please see the warranty
information for instructions. Please do not attempt to open or repair the
heater yourself. Doing so may void the warranty and could cause damage or
personal injury. If the problem still persists, please contact us by referring to
the service & support information on this and the following page.
IMPORTANT
DO NOT RETURN THIS PRODUCT TO THE STORE
If you have a problem with this product, please contact the
W Appliance Co. Customer Satisfaction Center at
844-299-0879.
DATED PROOF OF PURCHASE, MODEL # AND SERIAL #
REQUIRED FOR WARRANTY SERVICE
Page 10
TROUBLESHOOTING & WARRANTY
LIMITED WARRANTY
Any repair, replacement, or warranty service,
and all questions about this product should be
directed to W Appliance Co. at 844-299-0879
from the USA or Puerto Rico.
W Appliance Co. warrants to the original purchaser
that the product will be free from defects in material,
parts and workmanship for the period designated for
this product. The warranty commences the day the
product is purchased and covers up to a period of 1
year (12 months) for labor/1 year (12 months) for parts
(manufacturing defects only).
W Appliance Co. agrees that it will, at its option,
replace the defective product with either a new
or remanufactured unit equivalent to your original
purchase during the warranty period.
Exclusions: This warranty does not apply to the
below:
1. If the appearance or exterior of
the product has been damaged or
defaced, altered or modified in design or
construction.
2. If the product original serial number
has been altered or removed or cannot
be readily determined.
3. If there is damaged due to power line
surge, user damage to the AC power
cord or connection to improper voltage
source.
4. If damage is due to general misuse,
accidents or acts of God.
5. If repair attempts are done by
unauthorized service agents, use of
parts other than genuine parts or parts
obtained from persons other than
authorized service companies.
6. On units that have been transferred
from the original owner.
7. On products that have been purchased
as refurbished, like new, second-hand, in
a “As-Is” or “Final Sale” terms.
8. To products used in a commercial or
rental setting.
9. To products used in settings other than
ordinary household use or used other
than in accordance with the provided
instructions.
10. To damages for service calls for
improper installations.
11. Transportation and shipping costs
associated with the replacement of the
unit.
12. Service calls to instruct you how to use
your product.
13. Service calls to repair or replace the
house fuse, reset the circuit breaker or
correct the wiring in the house.
REPAIR OR REPLACEMENT AS PROVIDED UNDER
THIS WARRANTY IS THE EXCLUSIVE REMEDY OF
THE CUSTOMER; W Appliance Co. SHALL NOT BE
LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL
DAMAGES FOR BREACH OF ANY EXPRESS OR
IMPLIED WARRANTY ON THIS PRODUCT, EXCEPT
TO THE EXTENT PROHIBITED BY APPLICABLE LAW.
ANY IMPLIED WARRANTY OF MERCHANTABILITY
OF FITNESS FOR A PARTICULAR PURPOSE ON THIS
PRODUCT IS LIMITED TO THE DURATION OF THE
WARRANTY.
Some states do not allow the exclusion or limitations
of incidental or consequential damages, or limitations
on how long the warranty lasts. In these cases the
above exclusions or limitations may not apply to you.
This warranty gives you specific legal rights and you
may also have other rights which vary from state to
state.
Obtaining Service: To obtain service, product
literature, supplies or accessories please call
844-299-0879 to create a ticket for exchange/repair.
Please make sure to provide the date of purchase,
model number and a brief description of the problem.
Our customer service representative
will contact you or send detailed return instructions.
W Appliance Co. does not warrant that the appliance will work
properly in all environmental conditions, and makes no warranty
and representation, either implied or expressed, with respect
to the quality, performance, merchantability, or fitness for a
particular purpose other than the purpose identified within this
user’s manual. W Appliance Co. has made every eort to ensure
that this user’s manual is accurate and disclaims liability for any
inaccuracies or omissions that may have occurred. Information in
this user’s manual is subject to change without notice and does
not represent a commitment on the part of W Appliance Co.. W
Appliance Co. reserves the right to make improvements to this
user’s manual and/or to the products described in this user’s
manual at any time without notice. If you find information in this
manual that is incorrect, misleading, or incomplete, please contact
us at 844-299-0879.
W Appliance Co.
1356 Broadway
New York, NY 10018
Page 11
Page 12
BLACK & DECKER, BLACK+DECKER, the BLACK & DECKER and BLACK+DECKER
logos and product names and the orange and black color scheme are trademarks of The
Black & Decker Corporation, used under license. All rights reserved.
Product in this box may differ slightly from that pictured. Does not affect function.
Not all accessories shown in photography are included in this package.
Imported by W Appliance, Inc., 1356 Broadway, New York, NY 10018
October 2016 Printed in China
