Grundig GSL3671 Fridge User Manual

GSL1671N - GSL1671G - GSL3671G - GSL3671N

Tall Larder Fridge

User Manual

58 0616 0000 / AG

EN /

Contents

1. Safety and environment

instructions 5

1.1. General safety ..................... 5

1.1.1 HC warning ..........................7

1.1.2 For models with water

dispenser ......................................7

1.2. Intended use........................7

1.3. Child safety ..........................8

1.4. Compliance with WEEE

Directive and Disposing of the

Waste Product ..............................8

1.5. Compliance with RoHS

Directive ........................................ 8

1.6. Package information...........8

2. Your Refrigerator 9

3. Installation 10

3.1 Appropriate installation

location .......................................10

3.2 Installing the plastic

wedges ........................................10

3.3 Electrical connection ........11

3.4 Illumination lamp ..............11

4. Preparation 12

4.1 Things to be done for energy

saving .......................................... 12

4.2 Initial use ...........................12

Reversing The Doors .................. 15

5. Using your refrigerator 17

5.1 Temperature Control And

Adjustment .................................17

5.2 Thermostat setting button 17

5.3 Cooling ..............................18

5.4 Placing the food ................18

6. Maintenance and cleaning 19

6.1 Avoiding bad odours..........19

6.2 Protecting the plastic

surfaces .....................................20

7. Troubleshooting 21

Please read these instructions first before using your appliance

Thank you for choosing a Grundig appliance.

Please take some time to read this user manual before using your

appliance, to ensure you know how to safely operate the controls and

functions.

Carefully follow all unpacking and installation instructions to ensure

the appliance is correctly connected and fitted prior to use.

Please write your product model and serial number on the last page of

this user manual, and store in a safe location close to the appliance for

easy future reference.

This user manual may also be applicable for several other models.

Differences between models will be listed.

If you have any questions or concerns, please call our contact centre or

find help and information online at www.grundig.co.uk

Symbols and their descriptions

This instruction manual contains the following symbols:

Important information or useful usage

tips.

Warning against dangerous conditions

for life and property.

Warning against electric voltage.

Packaging materials of the product are

manufactured from recyclable materials

in accordance with our National

Environment Regulations.

SUPPLIER’S NAME

MODEL IDENTIFIER

(*)

INFORMATION

The model information as stored in the product data base

can be reached by entering following website and searching

for your model identiﬁer (*) found on energy label.

https://eprel.ec.europa.eu/

1. Safety and environment instructions

This section provides the safety

instructions necessary to

prevent the risk of injury and

material damage. Failure to

observe these instructions will

invalidate all types of product

warranty.

Intended use

WARNING:

Keep ventilation

openings, in the

appliance enclosure or

in the built-instructure,

clear of obstruction.

WARNING:

Do not use mechanical

devices or other means

to accelerate the

defrosting process,

other than those

recommended by the

manufacturer.

WARNING:

Do not damage the

refrigerant circuit.

WARNING:

Do not use electrical

appliances inside

the food storage

compartments of the

appliance, unless

they are of the type

recommended by the

manufacturer.

This appliance is intended to be

used in household and similar

applications such as

– staff kitchen areas in shops,

offices and other working

environments;

– farm houses and by clients

in hotels, motels and other

residential type environments;

– bed and breakfast type

environments;

– catering and similar non-retail

applications.

1.1. General safety

• This product should not

be used by persons with

physical, sensory and mental

disabilities, without sufficient

knowledge and experience

or by children. The device

can only be used by such

persons under supervision

and instruction of a person

responsible for their safety.

Children should not be

allowed to play with this

device.

• In case of malfunction,

unplug the device.

• After unplugging, wait at

least 5 minutes before

plugging in again.

• Unplug the product when not

in use.

• Do not touch the plug with

wet hands! Do not pull the

cable to plug off, always hold

the plug.

• Do not plug in the refrigerator

if the socket is loose.

• Unplug the product during

installation, maintenance,

cleaning and repair.

• If the product will not be

used for a while, unplug the

product and remove any food

inside.

• Do not use the product when

the compartment with circuit

cards located on the upper

back part of the product

(electrical card box cover) (1)

is open.

• Do not use steam or steamed

cleaning materials for

cleaning the refrigerator and

melting the ice inside. Steam

may contact the electrified

areas and cause short circuit

or electric shock!

• Do not wash the product by

spraying or pouring water on

it! Danger of electric shock!

• In case of malfunction, do not

use the product, as it may

cause electric shock. Contact

the authorised service before

doing anything.

• Plug the product into an

earthed socket. Earthing

must be done by a qualified

electrician.

• If the product has LED

type lighting, contact the

authorised service for

replacing or in case of any

problem.

• Do not touch frozen food with

wet hands! It may adhere to

your hands!

• Do not place liquids in bottles

and cans into the freezer

compartment. They may

explode.

• Place liquids in upright

position after tightly closing

the lid.

• Do not spray flammable

substances near the product,

as it may burn or explode.

• Do not keep flammable

materials and products with

flammable gas (sprays, etc.)

in the refrigerator.

• Do not place containers

holding liquids on top of the

product. Splashing water on

an electrified part may cause

electric shock and risk of fire.

• Exposing the product to rain,

snow, sunlight and wind

will cause electrical danger.

When relocating the product,

do not pull by holding the

door handle. The handle may

come off.

• Take care to avoid trapping

any part of your hands or

body in any of the moving

parts inside the product.

• Do not step or lean on the

door, drawers and similar

parts of the refrigerator. This

will cause the product to fall

down and cause damage to

the parts.

• Take care not to trap the

power cable.

1.1.1 HC warning

If the product comprises a

cooling system using R600a

gas, take care to avoid

damaging the cooling system

and its pipe while using and

moving the product. This gas

is flammable. If the cooling

system is damaged, keep the

product away from sources

of fire and ventilate the room

immediately.

The label on the inner left

side indicates the type of

gas used in the product.

1.1.2 For models with

water dispenser

• Pressure for cold water inlet

shall be maximum 90 psi (620

kPa). If your water pressure

exceeds 80 psi (550 kPa), use

a pressure limiting valve in

your mains system. If you

do not know how to check

your water pressure, ask for

the help of a professional

plumber.

• If there is risk of water

hammer effect in your

installation, always

use a water hammer

prevention equipment in

your installation. Consult

Professional plumbers if you

are not sure that there is no

water hammer effect in your

installation.

• Do not install on the hot

water inlet. Take precautions

against of the risk of

freezing of the hoses. Water

temperature operating

interval shall be 33°F (0.6°C)

minimum and 100°F (38°C)

maximum.

• Use drinking water only.

1.2. Intended use

• This product is designed for

home use. It is not intended

for commercial use.

• The product should be used

to store food and beverages

only.

• Do not keep sensitive

products requiring controlled

temperatures (vaccines,

heat sensitive medication,

medical supplies, etc.) in the

refrigerator.

• The manufacturer assumes

no responsibility for any

damage due to misuse or

mishandling.

• Original spare parts will

be provided for 10 years,

following the product

purchasing date.

1.3. Child safety

• Keep packaging materials

out of children’s reach.

• Do not allow the children to

play with the product.

• If the product’s door

comprises a lock, keep the

key out of children’s reach.

1.4. Compliance with WEEE

Directive and Disposing

of the Waste Product

This product complies with

EU WEEE Directive (2012/19/EU).

This product bears a classification

symbol for waste electrical and

electronic equipment (WEEE).

This product has been

manufactured with high

quality parts and

materials which can be

reused and are suitable

for recycling. Do not

dispose of the waste

product with normal domestic and

other wastes at the end of its

service life. Take it to the collection

center for the recycling of

electrical and electronic

equipment. Please consult your

local authorities to learn about

these collection centers.

1.5. Compliance with

RoHS Directive

•

This product complies with EU

WEEE Directive (2011/65/EU).

It does not contain harmful and

prohibited materials specified in

the Directive.

1.6. Package information

Packaging materials of the product

are manufactured from recyclable

materials in accordance with our

National Environment Regulations.

Do not dispose of the packaging

materials together with the

domestic or other wastes. Take

them to the packaging material

collection points designated by the

local authorities.

2. Your Refrigerator

Figures in this user manual are schematic and may not match

the product exactly. If the subject parts are not included in the

product you have purchased, then those parts are valid for other

models.

1. Indicator panel

2. Butter & Cheese sections

3. Adjustable door racks

4. Bottle shelves

5. Chrome bottle retainer

6. Adjustable front feet

7. Salad drawer

8. Chiller and glass cover

9. Movable shelves

10. Wine rack

* May not be available in all models

3. Installation

Refer to the nearest Authorised

Service Agent for installation of

the product. To make the product

ready for use, make sure that

the electricity installation is

appropriate before calling the

Authorised Service Agent. If not,

call a qualified electrician to have

any necessary arrangements

carried out.

Preparation of the

location and electrical

installation at the place

of installation is under

customer's responsibility.

Product must not be

plugged in during

installation. Otherwise,

there is the risk of death

or serious injury!

WARNING: Installation

and electrical connections

of the product must

be carried out by the

Authorised Service Agent.

Manufacturer shall not be

held liable for damages

that may arise from

procedures carried out by

unauthorised persons.

WARNING: Prior to

installation, visually

check if the product has

any defects on it. If so,

do not have it installed.

Damaged products cause

risks for your safety.

Make sure that the power

cable is not pinched or

crushed while pushing

the product into its place

after installation or

cleaning procedures.

3.1 Appropriate

installation location

•

Choose a place at where you can

access the product comfortably.

• Install the product at least 30

cm away from heat sources

such as hobs, ovens, heater

cores and stoves and at least 5

cm away from electrical ovens.

Product must not be subjected

to direct sun light and kept in

humid places after installation.

• Appropriate air ventilation must

be provided around your product

in order to achieve an efficient

operation. If the product is to be

placed in a recess in the wall,

pay attention to leave at least 5

cm distance with the ceiling and

side walls.

• Do not place the product on

materials such as rugs or

carpets.

• Place the product on an even

floor surface to prevent jolts.

• Your product can operate in

ambient temperatures between

-15°C to +43°C.

3.2 Installing the

plastic wedges

Plastic wedges are used to create

the distance for the air circulation

between the product and the rear

wall. Insert the 2 plastic wedges

onto the rear ventilation cover as

illustrated in the figure. To install

the wedges, push and twist a

quarter of a turn.

3.3 Electrical connection

Connect the product to a grounded

outlet protected by a fuse

complying with the values in the

rating plate. Our company shall

not be liable for any damages that

will arise when the product is used

without grounding in accordance

with the local regulations.

• Electrical connection

must comply with national

regulations.

• Power cable plug must be within

easy reach after installation.

• The voltage and allowed fuse or

breaker protection are specified

in the Rating Plate which is

affixed to interior of the product.

If the current value of the fuse

or breaker in the house does

not comply with the value in the

rating plate, have a qualified

electrician install a suitable

fuse.

• The specified voltage must be

equal to your mains voltage.

3.4 Illumination lamp

To change the Bulb/LED used for

illumination of your refrigerator,

call your AuthorisedService.

The lamp(s) used in this appliance

is not suitable for household

room illumination. The intended

purpose of this lamp is to assist

the user to place foodstuffs in the

refrigerator/freezer in a safe and

comfortable way.The lamps used

in this appliance have to withstand

extreme physical conditions such

as temperatures below -20 °C.

(only chest and upright freezer)

• WARNING: Do not locate

extension sockets or charging

transformers/power supplies

or Lithium-Iron battery

operated products adjacent to

the compressor as they could

overheat.

• Do not make connections via

extension cables or multi-plugs.

WARNING: Damaged

power cable must be

replaced by the Authorised

Service Agents.

WARNING: If the product

has a failure, it should not

be operated unless it is

repaired by the Authorised

Service Agent! There is

the risk of electric shock!

4. Preparation

4.1 Things to be done

for energy saving

Connecting the product

to electric energy saving

devices is risky as it may

cause damage on the

product.

• For a freestanding appliance;

‘this refrigerating appliance is

not intended to be used as a

built-in appliance.

• Do not leave the doors of your

refrigerator open for a long

time.

• Do not put hot food or drinks in

your refrigerator.

• Do not overload the refrigerator.

Cooling capacity will fall when

the air circulation inside is

hindered.

• Do not place the refrigerator in

places subject to direct sunlight.

Install the product at least 30

cm away from heat sources

such as hobs, ovens, heater

cores and stoves and at least 5

cm away from electrical ovens.

• Pay attention to store your

food in refrigerator in closed

containers.

• You can load maximum amount

of food to the compartment of

the refrigerator by removing the

compartment drawers. Declared

energy consumption value of

the refrigerator was determined

with the compartment drawers

removed,except if available

bottom drawer and with

maximum amount of food

loaded. There is no risk in

removing a shelf or drawer to

make suitable for the shapes

and sizes of the foods to be

stored.

• Thawing frozen food in fridge

compartment will both provide

energy saving and preserve the

food quality.

• The baskets/drawers that

are provided with the chill

compartment must always be in

use for low energy consumption

and for better storage

conditions.

• Food contact with the

temperature sensor in the

compartment may increase

energy consumption of the

appliance. Thus any contact with

the sensor(s) must be avoided.

Inside of your refrigerator

must be cleaned

thoroughly.

4.2 Initial use

Before starting to use the product,

check that all preparations are

made in accordance with the

instructions in sections "Important

instructions for safety and

environment" and "Installation".

• Clean the interior of the

refrigerator as recommended in

the “Maintenance and cleaning”

section. Check that inside of it is

dry before operating it.

• Plug the refrigerator into the

grounded wall outlet. When

the door is opened the interior

illumination will turn on.

• Run the refrigerator without

putting any food for 6 hours

and do not open its door

unnecessarily.

Front edges of the

refrigerator may feel

warm. This is normal.

These areas are designed

to be warm to avoid

condensation.

You will hear a noise

when the compressor

starts up. The liquids and

gases sealed within the

refrigeration

system may also give rise

to noise, even

if the compressor is not

running and this

is quite normal.

45 °

180°

Reversing the doors

. Proceed in numerical order

Reversing The Doors

We recommend that you reverse

the door before switching on for

the first time.

Tools required: Small and medium

size flat and cross-headed

screwdrivers, a pair of pliers.

Spare Parts supplied in the plastic

bag: The following parts, which are

exclusively for left hand side fitted

hinge operation are supplied in a

plastic bag with the appliance:

- Door top trim hinge covers –

there are 2 different parts, one for

each side of top trim.

We suggest you keep all the parts

supplied in the plastic bag and also

parts, which have been removed

when reversing the door, in a safe

place for possible future, re-use.

Important:

We suggest you ask somebody

to help you when moving the

appliance around and to hold the

door when removing / re-fitting

hinges and the door to avoid any

injury and damage to the product.

Please refer to diagrams supplied.

To follow numbers in brackets

below, refer to the main diagram.

1. Switch off the appliance at

the socket outlet and pull

out the mains plug.

2. Remove all loose items and

fittings and food inside the

appliance.

3. Gently prise off plastic

hinge covers on both

sides of front top panel

using a small flat-headed

screwdriver. (1-2)

4. Unscrew the bolts of the

top hinge and remove top

hinge. (3)

5. Remove door carefully

off the bottom hinge and

stand door upright in a safe

place.(4)

6. Gently prise off plastic

hinge cover on door top

trim. Fit the other door top

trim plastic off hinge cover

supplied in the plastic bag.

(5)

7. Gently tilt the appliance

back against a strong wall

on its rear side sufficiently

to allow the lower hinge to

be removed. Take care to

protect the appliance, your

wall and floor coverings.

You can utilise the original

packaging to do this.Once

you tilt the appliance back,

check to make sure the

appliance is completely

stable and safe before you

carry on. (6)

8. Unscrew and remove the

front feet and 1 bolt. (7)

9. Unscrew and remove the

bottom hinge. (8)

10. Unscrew and remove the

bottom hinge door stopper

and bushing and reposition

them on the other side

while rotating the bushing

180°. (9)

11. Fit the bottom hinge and

tighten the screws as

shown in figure. (10)

12. Fit the other front feet as

shown in figure. (11)

13. Rotate the top hinge 180°.

Unscrew the hinge pin and

re-tighten it to the opposite

side. (12)

14. Fit the top hinge on the left

hand side bushing of the

door. (13)

15. Locate and re-fit door to

bottom hinge pin. (14)

16. Re-fit the upper hinge on

the opposite side by using

a flat headed screwdriver.

(15)

17. Fit front top panel plastic

hinge covers on the

opposite sides. (16)

18. Remove the handle cover

gently taking care not to

damage the appliance.(17)

19. Unscrew and remove the

handle (18). Do not unscrew

the yellow coloured screws!

20. Rotate 180 degrees and fit

handle to the other side

after removing hole plugs

gently.(19,20)

21. Fit the handle cover.(21)

22. Adjust the two front feet if

necessary.

23. Check that door opens and

closes easily, it is aligned

correctly and there are no

gaps allowing air into the

cabinet. If there are gaps

between the door seal

and the cabinet, adjust the

door seal by gently pulling

away from the door using

fingers.

24. Check that all the hinge

screws are tightened. Avoid

over tightening the screws.

25. Put all items, fittings back

in the appliance.

26. Wait for at least 4 hours to

allow the system to settle

before switching on.

27. Once the correct storage

temperatures have been

reached in the appliance,

put back all the food.

Figures in this user manual are schematic and may not match

the product exactly. If the subject parts are not included in the

product you have purchased, then those parts are valid for other

models.

5. Using your refrigerator

5.1 Temperature Control And Adjustment

The operating temperature is

regulated by the temperature control.

Warm Cold

1 2 3 4 5

(Or) Min. Max.

1=Lowest cooling setting

(Warmest setting).

5=Highest cooling setting (Coldest

setting).

The average temperature inside

the fridge should be around +5°C.

Please choose the setting

according to the desired

temperature.

Please note that there will be

different temperatures in the

cooling area.

The coldest region is immediately

above the vegetable compartment.

The interior temperature also

depends on ambient temperature,

the frequency with which the door

is opened and the amount of foods

kept inside.

Frequently opening the door

causes the interior temperature to

rise.

For this reason, it is recommended

to close the door again as soon as

possible after use.

5.2 Thermostat setting button

The interior temperature of your

refrigerator changes for the

following reasons;

• Seasonal temperatures,

• Frequent opening of the door

and leaving the door open for

long periods,

• Food put into the refrigerator

without cooling down to the

room temperature,

• The location of the refrigerator

in the room (e.g. exposing to

sunlight).

• You may adjust the varying

interior temperature due to

such reasons by using the

thermostat. Numbers around

the thermostat button indicates

the cooling degrees.

• If the ambient temperature

is higher than 25°C, turn the

thermostat button to maximum

position.

• If the ambient temperature

is lower than 25°C, turn the

thermostat button to minimum

position.

5.3 Cooling

Food storage

The fridge compartment is for the

short-term storage of fresh food

and drinks.

Store milk products in the intended

compartment in the cooler

Bottles can be stored in the bottle

holder or in the bottle shelf of the

door.

Raw meat is best kept in

a polyethylene bag in the

compartment at the very bottom of

the cooler.

Allow hot foods and beverages to

cool to room temperature prior to

placing them in the cooler.

• Attention

Store alcoholic spirits standing

upright and tightly closed.

• Attention

Do not store explosive substances

or containers with flammable

propellant gases (spray cans etc.)

in the device. There is a danger of

explosion.

5.4 Placing the food

Egg tray Eggs

Fridge

compartment

shelves

Food in pans,

covered plates

and closed

containers

Fridge

compartment

door shelves

Small and

packaged food

or drinks (such

as milk, fruit

juice and beer)

Crisper

Vegetables and

fruits

Chiller

Compartment

Wrapped fresh

fish, meat

and easily

perishable food

Defrosting of the appliance

The appliance defrosts

automatically.

6. Maintenance

and cleaning

Cleaning your fridge at regular in-

tervals will extend the service life

of the product.

B WARNING:

Unplug the product before cleaning

it.

• Never use gasoline, benzene or

similar substances for cleaning

purposes.

• Never use any sharp and

abrasive tools, soap, household

cleaners, detergent and wax

polish for cleaning.

• For non-No Frost products,

water drops and frosting up to a

fingerbreadth occur on the rear

wall of the Fridge compartment.

Do not clean it; never apply oil

or similar agents on it.

• Only use slightly damp

microfiber cloths to clean the

outer surface of the product.

Sponges and other types of

cleaning cloths may scratch the

surface

• Dissolve one teaspoon of bi-

carbonate in half litre of water.

Soak a cloth with the solution

and wrung it thoroughly. Wipe

the interior of the refrigerator

with this cloth and the dry

thoroughly.

• Make sure that no water enters

the lamp housing and other

electrical items.

• If you will not use the

refrigerator for a long period of

time, unplug it, remove all food

inside, clean it and leave the

door ajar.

• Check regularly that the door

gaskets are clean. If not, clean

them.

• To remove door and body

shelves, remove all of its

contents.

• Remove the door shelves by

pulling them up. After cleaning,

slide them from top to bottom to

install.

• Never use cleaning agents or

water that contain chlorine to

clean the outer surfaces and

chromium coated parts of

the product. Chlorine causes

corrosion on such metal

surfaces.

6.1 Avoiding bad odours

•

Materials that may cause odour

are not used in the production of

our refrigerators. However, due

to inappropriate food preserving

conditions and not cleaning the

inner surface of the refrigerator

as required can bring forth the

problem of odour. Pay attention

to following to avoid this

problem:

• Keeping the refrigerator clean

is important. Food residuals,

stains, etc. can cause odour.

Therefore, clean the refrigerator

with bi-carbonate dissolved in

water every few months. Never

use detergents or soap.

• Keep the food in closed

containers. Microorganisms

spreading out from uncovered

containers can cause

unpleasant odours.

• Never keep the food that have

passed best before dates and

spoiled in the refrigerator.

6.2 Protecting the plas-

tic surfaces

Do not put liquid oils or oil-cooked

meals in your refrigerator in un-

sealed containers as they dama-

ge the plastic surfaces of the refri-

gerator. If oil is spilled or smeared

onto the plastic surfaces, clean and

rinse the relevant part of the surfa-

ce at once with warm water.

7. Troubleshooting

Check this list before contacting

the service. Doing so will save you

time and money. This list includes

frequent complaints that are not

related to faulty workmanship

or materials. Certain features

mentioned herein may not apply to

your product.

The refrigerator is not working.

• The power plug is not fully

settled. >>> Plug it in to settle

completely into the socket.

• The fuse connected to the

socket powering the product

or the main fuse is blown. >>>

Check the fuses.

Condensation on the side wall of

the cooler compartment (MULTI

ZONE, COOL, CONTROL and FLEXI

ZONE).

• The door is opened too

frequently >>> Take care not

to open the product’s door too

frequently.

• The environment is too humid.

>>> Do not install the product in

humid environments.

• Foods containing liquids are

kept in unsealed holders. >>>

Keep the foods containing

liquids in sealed holders.

• The product’s door is left open.

>>> Do not keep the product’s

door open for long periods.

• The thermostat is set to too

low temperature. >>> Set the

thermostat to appropriate

temperature.

Compressor is not working.

• In case of sudden power failure

or pulling the power plug

off and putting back on, the

gas pressure in the product’s

cooling system is not balanced,

which triggers the compressor

thermic safeguard. The product

will restart after approximately 6

minutes. If the product does not

restart after this period, contact

the service.

• Defrosting is active. >>>

This is normal for a fully-

automatic defrosting product.

The defrosting is carried out

periodically.

• The product is not plugged in.

>>> Make sure the power cord is

plugged in.

• The temperature setting

is incorrect. >>> Select the

appropriate temperature

setting.

• The power is out. >>> The

product will continue to operate

normally once the power is

restored.

The refrigerator’s operating noise

is increasing while in use.

• The product’s operating

performance may vary

depending on the ambient

temperature variations. This is

normal and not a malfunction.

The refrigerator runs too often or

for too long.

• The new product may be larger

than the previous one. Larger

products will run for longer

periods.

• The room temperature may

be high. >>> The product will

normally run for long periods in

higher room temperature.

• The product may have been

recently plugged in or a new

food item is placed inside. >>>

The product will take longer to

reach the set temperature when

recently plugged in or a new

food item is placed inside. This

is normal.

• Large quantities of hot food may

have been recently placed into

the product. >>> Do not place

hot food into the product.

• The doors were opened

frequently or kept open for

long periods. >>> The warm air

moving inside will cause the

product to run longer. Do not

open the doors too frequently.

• The freezer or cooler door may

be ajar. >>> Check that the

doors are fully closed.

• The product may be set to

temperature too low. >>> Set the

temperature to a higher degree

and wait for the product to reach

the adjusted temperature.

• The cooler or freezer door

washer may be dirty, worn out,

broken or not properly settled.

>>> Clean or replace the washer.

Damaged / torn door washer

will cause the product to run for

longer periods to preserve the

current temperature.

The freezer temperature is very

low, but the cooler temperature is

adequate.

• The freezer compartment

temperature is set to a very

low degree. >>> Set the freezer

compartment temperature to a

higher degree and check again.

The cooler temperature is very

low, but the freezer temperature

is adequate.

• The cooler compartment

temperature is set to a very

low degree. >>> Set the freezer

compartment temperature to a

higher degree and check again.

The food items kept in cooler

compartment drawers are frozen.

• The cooler compartment

temperature is set to a very

low degree. >>> Set the freezer

compartment temperature to a

higher degree and check again.

The temperature in the cooler or

the freeze is too high.

• The cooler compartment

temperature is set to a very high

degree. >>> Temperature setting

of the cooler compartment has

an effect on the temperature

in the compartment. Wait until

the temperature of relevant

parts reach the sufficient level

by changing the temperature of

cooler or freezer compartments.

• The doors were opened

frequently or kept open for long

periods. >>> Do not open the

doors too frequently.

• The door may be ajar. >>> Fully

close the door.

• The product may have been

recently plugged in or a new

food item is placed inside. >>>

This is normal. The product

will take longer to reach the

set temperature when recently

plugged in or a new food item is

placed inside.

• Large quantities of hot food may

have been recently placed into

the product. >>> Do not place

hot food into the product.

Shaking or noise.

• The ground is not level or

durable. >>> If the product is

shaking when moved slowly,

adjust the stands to balance the

product. Also make sure the

ground is sufficiently durable to

bear the product.

• Any items placed on the product

may cause noise. >>> Remove

any items placed on the product.

The product is making noise of

liquid flowing, spraying etc.

• The product’s operating

principles involve liquid and gas

flows. >>> This is normal and

not a malfunction.

There is sound of wind blowing

coming from the product.

• The product uses a fan for the

cooling process. This is normal

and not a malfunction.

There is condensation on the

product’s internal walls.

• Hot or humid weather will

increase icing and condensation.

This is normal and not a

malfunction.

• The doors were opened

frequently or kept open for long

periods. >>> Do not open the

doors too frequently; if open,

close the door.

• The door may be ajar. >>> Fully

close the door.

There is condensation on the

product’s exterior or between the

doors.

• The ambient weather may be

humid, this is quite normal

in humid weather. >>> The

condensation will dissipate

when the humidity is reduced.

The interior smells bad.

• The product is not cleaned

regularly. >>> Clean the interior

regularly using sponge, warm

water and carbonated water.

• Certain holders and packaging

materials may cause odour.

>>> Use holders and packaging

materials without free of odour.

• The foods were placed in

unsealed holders. >>> Keep the

foods in sealed holders. Micro-

organisms may spread out of

unsealed food items and cause

malodour. Remove any expired

or spoilt foods from the product.

The door is not closing.

• Food packages may be blocking

the door. >>> Relocate any items

blocking the doors.

• The product is not standing

in full upright position on the

ground. >>> Adjust the stands to

balance the product.

• The ground is not level or

durable. >>> Make sure the

ground is level and sufficiently

durable to bear the product.

The vegetable bin is jammed.

• The food items may be in

contact with the upper section of

the drawer. >>> Reorganize the

food items in the drawer.

If The Surface Of The Product Is

Hot.

• High temperatures may be

observed between the two

doors, on the side panels and at

the rear grill while the product

is operating. This is normal

and does not require service

maintenance!Be careful when

touching these areas.

A WARNING:

If the problem persists after

following the instructions in this

section, contact your vendor or an

Authorised Service. Do not try to

repair the product.

GRUNDIG UK AND IRELAND STANDARD MANUFACTURER GUARANTEE

TERMS AND CONDITIONS

Your new Grundig product is guaranteed against faulty materials,

defective components or manufacturing defects.

The standard guarantee starts from the date of original purchase of the

product, and lasts for a period of thirty six (36) months unless Beko plc

(the “Manufacturer”) agrees to extend the guarantee for the product in

writing.

If you have registered the product within 90 days of purchase by

completing the online registration form, then the standard 36 month

guarantee will be extended to 60 months, under the same terms and

conditions as detailed below

If you have any questions about the guarantee on your product (including

how long it is valid), please contact your retailer or our contact centre on

0333 207 9920 (UK and Northern Ireland) or 01 691 0203 (Republic of

Ireland)

This guarantee does not in any way diminish or affect your statutory

rights in connection with the product. This guarantee is in addition to

your statutory rights as a consumer. If you have any questions about

these rights, please contact the retailer from which you purchased the

product. In certain circumstances, it is possible that your statutory rights

may offer additional or higher levels of protection than those offered

under the terms of this guarantee.

What is covered by this guarantee?

• Repairs to the product required as a result of faulty materials,

defective components or manufacturing defects.

• Functional replacement parts to repair a product.

• The costs of a Grundig Approved Engineer to carry out the repair.

What is not covered?

• Transit and delivery damage.

• Cabinet or appearance parts, including but not limited to control

knobs, flaps and handles.

• Accessories and/or consumable items including but not limited to ice

trays, scrapers, cutlery baskets, filters and light bulbs.

• Repairs necessary as a direct or indirect result of:

-Accidental damage, misuse or abuse of a product.

-An attempted repair of a product by anyone other than a Grundig

Approved Engineer (the “Engineer”).

-Installation or use of a product where such installation or use

fails to meet the requirements contained in this guarantee or the User

Instructions Booklet.

• Repairs to a product operated at any time on commercial or non-

residential household premises (unless we have previously agreed to the

installation environment).

This guarantee is limited to the cost of repairing the product. To the

extent permitted by law, the Manufacturer does not accept and will not be

held liable for any financial loss incurred in connection with the failure of

any product to operate in accordance with the expected standards. Such

financial loss includes but is not limited to loss arising from:

• Time taken off work.

• Damaged food, clothing or other items.

• Meals taken at restaurants or from takeaways.

• General compensation for inconvenience.

Important Notes

1. Your product is designed and built for domestic household use

only.

2. The guarantee will automatically be void if the product is installed

or is used in commercial or non-residential domestic household

premises, unless we have previously agreed to the installation

environment.

3. The product must be correctly installed, located and opera-

ted in accordance with the instructions contained in the User

Instructions Booklet provided with your product.

4. Professional installation by a qualified Electrical Domestic

Appliance Installer is recommended for all Washing Machines,

Dishwashers and Electric Cookers (as incorrect installation may

result in you having to pay for the cost of repairing the product).

5. Gas Cookers must be professionally installed by a Gas Safe (or

Gas Networks Ireland for Republic of Ireland) registered gas

installer.

6. This guarantee is given in respect of products purchased and used

within the United Kingdom and the Republic of Ireland.

7. This guarantee is effective from the initial date of purchase of a

new product from an authorised retailer and will be void if the

product is resold.

8. This guarantee does not apply to graded sales (where the product

is purchased as a “second”).

9. Possession of a copy of these terms and conditions does not ne-

cessarily mean that a product has the benefit of this guarantee. If

you have any questions, please call our Call Centre on the number

set out above.

10. The Manufacturer reserves the right to terminate the guarantee

if its staff or representatives are subjected to physical or verbal

abuse in the course of carrying out their duties.

11. Optional extras, where available (i.e. extendable feet) are supplied

on a chargeable basis only.

Does Grundig offer replacements?

This is a repair-only guarantee. On occasion, the Manufacturer may at

its sole discretion, replace your product with a new product instead of

carrying out a repair. Where a replacement is offered, this would normally

be an identical model but when this is not possible, a model of similar

specification will be provided. The Manufacturer will cover the costs

and arrange for the delivery of the new product and for the return of the

old product. Any costs related to disconnecting the faulty product and

installing the replacement product will not be borne by the Manufacturer

unless previously agreed to in writing. The original guarantee will

continue to apply to the replacement product; the new product will not

come with a new guarantee.

When will the repair take place?

Our Engineers work Monday to Friday 9.00am to 5.00pm. Appointments

outside these hours may be possible at the sole discretion of the

Manufacturer but cannot be guaranteed. Whilst our Engineers will

endeavour to minimize inconvenience and to meet requests for specific

timed appointments, this cannot be guaranteed. We will not be liable

for delays or if it is unable to carry out a repair because a convenient

appointment cannot be arranged.

Will there be any charge for the repairs?

It is your responsibility to provide evidence to the Engineer that your

product is covered by this guarantee with a proof of purchase. The

Manufacturer reserves the right to charge for the reasonable cost of any

service call if:

• You cannot provide evidence that your product is covered by this

guarantee.

• Where a service call has been made and the engineer finds that there

is no fault with your product.

• That your product has not been installed or operated in accordance

with the User Instructions Booklet.

• That the fault was caused by something other than faulty materials,

defective components or manufacturing defects.

• For missed appointments.

Payment of these costs are due immediately upon the Engineer providing

you with an invoice. The Manufacturer reserves the right to terminate

the guarantee if you fail to pay the costs for the service call in a timely

manner.

If you are a resident of the United Kingdom, this guarantee will be

governed by English law and subject to the English Courts, save where

you live in another part of the United Kingdom, in which case the law and

courts of that location will apply.

If you are resident in the Republic of Ireland, this guarantee will be

governed by Irish law and the Irish courts will have jurisdiction.

This guarantee is provided by Beko plc. Beko House, 1 Greenhill

Crescent, Watford, Hertfordshire. WD18 8QU.

Beko plc is registered in England and Wales with company registration

number 02415578.

GRUNDIG UK AND IRELAND ECO INVERTER MOTOR GUARANTEE

TERMS AND CONDITIONS

This 10 year guarantee relates to Grundig products that feature the Eco

Inverter Motor.

The Eco Inverter Motor guarantee terms and conditions are in addition

to our Standard guarantee terms and conditions detailed in the previous

section.

In order to activate the 10 year guarantee you MUST register the

appliance within 90 days of the original purchase date. You can register

by first visiting grundig.co.uk/register and by following the online

instructions.

Grundig Free standing and Built-in appliances come with a 36 month

parts and labour guarantee as standard, which can be extended to a 60

months parts and labour guarantee by registering within 90 days of the

original purchase date

To make a claim against your Grundig Eco Inverter Motor Guarantee (the

“Guarantee”), all customer and product details must be registered with

Beko plc using the procedure outlined below.

1. This extra 7 years (or 5 years for appliances registered within 90

days of the original purchase date) Guarantee is only effective

after the expiration of the standard manufacturer’s guarantee.

2. It is only valid for the Eco Inverter motors of selected washing

machines, washer-dryers, tumble dryers and dishwashers. It

does not cover any labour charge or any other components of the

product. In addition, it is only valid for one replacement of the Eco

Inverter motor during the extra 7 years (or 5 years for appliances

registered within 90 days of the original purchase date) guaran-

tee period.

3. To activate your guarantee, you MUST register your appliance

within 90 days of the original purchase date, by visiting Grundig.

co.uk/register.

4. Customers will receive a unique reference code as proof of gua-

rantee validation by email or post, which must be quoted at the

time of a claim being made.

5. Any repair/replacement of the Eco Inverter motor must only be

carried out by an authorised Grundig Service Agent (the “Service

Agent”).

6. Labour for the repair/replacement of the Eco Inverter motor is

not included in this guarantee and is chargeable directly by the

Service Agent.

7. Any additional components fitted to the product at any time will

not be covered by this guarantee and will be chargeable directly

by the Service Agent.

8. The guarantee is not transferable and cannot be exchanged for

cash.

9. There are no alternative or additional offers to this Guarantee.

10. The guarantee is exclusive of the manufacturer’s standard gua-

rantee.

11. The Terms and Conditions shown above are in addition to the

standard terms and conditions of your product guarantee. Please

read and refer to such Terms and Conditions when making any

claim.

12. We may use the information you provide for marketing purposes

and to analyse your purchasing preferences. We may keep your

information for a reasonable period for these purposes in ac-

cordance with the applicable Data Protection Laws and General

Data Protection Regulations (GDPR). You can opt into this service

during the registration process. Further details are available at

http://www.Grundig.co.uk/cookie-and-privacy.

13. These Terms and Conditions are governed by the laws of England

and Wales; manufacturer: Beko plc, Beko House, 1 Greenhill

Crescent, Watford WD18 8QU. Company Registration Number:

02415578.

HOW TO OBTAIN SERVICE FOR YOUR APPLIANCE

Please keep your purchase receipt or other proof of purchase details in a

safe place; you will need to have this documentation available should the

product require attention under guarantee.

Please take a few moments to complete the details below, as you will

need this information when you call us, or to use our online services.

When you call us you may be required to input your serial number into

your telephone keypad. For help please visit grundig.co.uk/support/

model-finder

• The product model number is printed on the Operating Instruction

Booklet / User guide

• The product model and serial number is printed on the Rating Label

affixed to the appliance.

• The Retailer (Purchased from) and Date of purchase will be printed on

your purchase receipt or other proof of purchase paperwork

Recording of these details alone will not count as proof of purchase.

A valid proof of purchase is required for requesting service under

guarantee.

Model number Serial number Purchased from Date of purchase

For service under guarantee or for product advice please call our

Contact centre

Before requesting service please check the troubleshooting guide in the

Operating Instructions booklet, as a charge may be levied where no fault

is found, and even though your product may still be under guarantee.

After arranging service the area around the product must be easily

accessible to the Engineer, without the need for cabinets or furniture to

be removed or moved.

It is your responsibility to ensure our Engineers have a clean and safe

environment to carry out any repairs.

Please have your Model number and Serial number available when you

call us, as you may be required to input your serial number into your

telephone keypad during your call.

UK Mainland & Northern Ireland:

0333 207 9920

Landline or mobile calls to 0333 numbers cost no more than calls to

geographic numbers 01 or 02, and are charged at the basic rate. Calls

from landlines and mobiles are included in free call packages but please

check with your telephone service provider for exact call charges.

Republic of Ireland:

01 691 0203

Service once the manufacturers guarantee has expired

If you have purchased an extended guarantee please refer to the

instructions contained within the extended guarantee agreement

document, otherwise please call us using the appropriate number above,

where service can be obtained at a charge.

Should you experience any difficulty in obtaining service please call us on

0333 207 9920 or 01 691 0203

Send us a secure message through our online contact us form. Please

visit our website, click Contact Us and choose a product support topic

from the list of options. Complete the required details and click send

message.

Product registrations

For UK and Republic of Ireland product registrations please visit grundig.

co.uk/register.

Notes

...............................................................................................................................

..................................................................................
