SP 7 Dirt Inox
The Kärcher SP7 Dirt Inox is the most powerful pump in our range. Offering an extremely fast
solution to any problem. From clearing ooded water or providing a simple solution to empty-
ing a pond or swimming pool. The additional Inox feature means that the pump has a metal
casing, giving extra durability. The ability to pump 15,000 litres of water an hour offers you a
rapid response to any situation you may nd yourself needing a pump. This is a particularly
important feature when faced with a disaster such as ooding. The SP7 Dirt Inox uses an IQ
level sensor, which uses an electrical current between two electrodes to activate the pump.
This can be height adjusted to the level you wish the pump to pump down to. There is also a
switch at the top of the pump, that you can manually turn on to pump out the last of the wa-
ter. This SP7 has an inbuilt pre-lter to help protect the pump from coarse dirt, helping to pro-
long the life of the pump. It is designed to handle dirt particles up to 30mm in diameter. There
is a 2 year warranty on the SP7 Dirt Inox, however, if you register your pump with Kärcher
UK, we will give you an additional three years warranty totalling ve years.
SP 7 Dirt Inox, 1.645-516.0, 2017-09-25
SP 7 Dirt Inox, 1.645-516.0, 2017-09-25
SP 7 Dirt Inox
Technical data
Order Number 1.645-516.0
EAN code
4054278169897
Max. motor rating W
750
Max. ow rate l/h
< 15500
Delivery head/pressure, max. m / bar
8 / 0,8
Max. depth of immersion m
7
Max. grain size mm
30
Residual water height mm
35
Delivery temperature, max. °C
35
Weight without accessories kg
6,7
Equipment
Comfortable carry handle
Easy hose connection thanks to Quick
Connect
Switching between manual/automatic
operation
Switch on the pump
Level sensor: Continuous switching
level denition
Integrated stainless-steel prelter
Ceramic face seal
Included in delivery.
Accessories for sP 7 Dirt inox
1.645-516.0
1 2
SP 7 Dirt Inox, 1.645-516.0, 2017-09-25
Order Number Price Description
Suction hoses
Suction hose available in bulk
1
6.997-346.0 Vacuum-resistant spiral hose can be cut to length for con-
nection to submersible, garden, submersible pressure pumps
and high-pressure pumps.
Miscellaneous
Flat Hose Set
2
2.997-100.0 The Kärcher at hose set is the perfect addition to your
pump. An ideal hose for pumping out dirty water from your
ooded area.
Available accessories.
