QUICK
START GUIDE
Floodlight Camera 2K
Anker Innovations Limited. All rights reserved. eufy Security and eufy Security Logo
are trademarks of Anker Innovations Limited, registered in the United States and other
countries. All other trademarks are the property of their respective owners.
51005002609 V01
Table of Content
What's in the Box 01
Power On the Floodlight Camera Indoors 02
Get the eufy Security App and Setup the Camera 02
Mount Floodlight Camera Outdoors 04
Safety 10
Customer Service 12
01 02
Power On the Floodlight Camera Indoors
1. Connect Floodlight Camera to a power source, and then wait 1 minute or until
the LED indicator blinks red.
Get the eufy Security App and Set up the Camera
Download the eufy Security app from the App Store (iOS devices) or Google
Play (Android devices).
What's in the Box
Install Floodlight Camera to the junction box outdoors (you need to
have a junction box and wires already installed).
In order to stream video from Floodlight Camera, you need to make
sure the Wi-Fi signal strength is strong at the location you want to
install Floodlight Camera.
To avoid risk of shock, injury or death, always be cautious when
working with electricity. Remember, do hire a professional
electrician if you are uncomfortable working with electrical wiring.
Floodlight Camera 2K
(T8424)
Power Cord
(Connected to the unit)
Central Screw Central Screw Cap Wire Nuts (Connected
to the unit)
Plate Screws
Mounting Plate Installation Hook
03 04
Mount Floodlight Camera Outdoors
Step 1
Unplug Floodlight Camera.
Step 2
Unscrew the power cord; wire nuts will be used later.
The power cord is not required when mounting the Floodlight Camera
outdoors.
Login or sign up for a eufy Security account, then follow the onscreen
instructions to complete setup.
To avoid risk of shock, injury or death, always be cautious when
working with electricity.
Make sure you can livestream video from Floodlight Camera
before mounting.
05 06
Step 5
1. User can hang Floodlight Camera upside down or install it vertically on the
wall. Select the installation method that best suits the position of your
junction box.
Wall Mount
Eave Mount
To avoid risk of shock, injury or death, always be cautious when
working with electricity. Remember, do hire a professional
electrician if you’re uncomfortable working with electrical wiring.
Step 3
Shut down the circuit breaker in your house. Switch on/off the lights to make
sure the electricity in your house is properly shut off.
To avoid risk of shock, injury or death, always be cautious when
working with electricity.
Step 4
Remove the old Floodlight from the junction box and install the mounting
plate to the junction box.
The junction box and existing electrical wires are required to
Floodlight Camera installation.
The concaved side of the mounting plate must face outwards.
07 08
Step 6
1. Hang Floodlight Camera on the junction box with the hook provided.
To avoid risk of shock, injury or death, always be cautious when
working with electricity. Remember, do hire a professional
electrician if you’re uncomfortable working with electrical wiring.
If you plan to install the Floodlight Camera on the wall, please skip to Step 6.
2. For upside down installation, turn the camera down to the end when it’s
placed vertically, then turn the camera 180° in clockwise direction.
1
2
To avoid risk of shock, injury or death, always be cautious when
working with electricity. Remember, do hire a professional
electrician if you’re uncomfortable working with electrical wiring.
09 10
2. Connect both ground wires(yellow or green
) from the junction
box and
Floodlight Camera, join the wires by using a wire nut.
If the existing ground wire has been connected to the junction box or
there's no ground wire, connect the ground wire of the Floodlight Camera
to the junction box or mounting plate directly.
1
2
3
To avoid risk of shock,injury
or death, always be cautious
when working with electricity.
Remember, do hire a
professional electrician if
you’re uncomfortable working
with electrical wiring.
3. Use wire nuts to connect Floodlight Camera wires to the rest of the wires
from junction box. Connect the white wire on the Floodlight Camera to
the white wire(neutral) from junction box. Connect the black wire on the
Floodlight Camera to the black wire(hot) from junction box.
To avoid risk of shock, injury or death, always be cautious when
working with electricity. Remember, do hire a professional
electrician if you’re uncomfortable working with electrical wiring.
11 12
Step 7
Insert the central screw through the center of Floodlight Camera and screw it
tightly.
Use the central screw cap to cover the central screw to prevent the central
screw from rusting.
Step 8
After installation is complete, you can turn the camera knobs on Floodlight
Camera to adjust the camera to your desired angle.
Step 9
Switch on the main circuit breaker in the house.
To check whether Floodlight Camera is operating, check if the LED indicator
has turned solid white.
In case Floodlight Camera is not powered on, switch off the
circuit breaker before checking the wiring of Floodlight Camera.
To avoid risk of shock, injury or death, always be cautious when
working with electricity. Remember, do hire a professional
electrician if you’re uncomfortable working with electrical wiring.
In case Floodlight Camera keeps blinking red, it means the
floodlight is not connected to the Internet. Please make sure the
Wi-Fi signal is strong at the desired location. You may consider
moving the wireless router closer to Floodlight Camera or using
a Wi-Fi range extender.
For troubleshooting, check the Help section in the Eufy
Security app.
Refer to the app page for what the LED indicator status lights
mean.
13 14
distance of d=20 cm between the device and the human body. To maintain compliance with RF exposure
requirement, use product that maintain a 20cm distance between the device and human body.
Wi-Fi Operating Frequency Range:2412~2472MHz Wifi Max Output Power:19dBm(EIRP for 2.4G).
Bluetooth Operating Frequency Range:2402~2480 MHz; Bluetooth Max Output Power:8 dBm(EIRP).
Anker Technology (UK) Ltd I Suite B, Fairgate House, 205 Kings Road, Tyseley, Birmingham, B11 2AA,
United Kingdom
Anker Innovations Deutschland GmbH I Georg-Muche-Strasse 3, 80807 Munich, Germany
This product is designed and manufactured with high quality materials and components, which can
be recycled and reused.
This symbol means the product must not be discarded as household waste, and should be
delivered to an appropriate collection facility for recycling. Proper disposal and recycling helps
protect natural resources, human health and the environment. For more information on disposal and
recycling of this product, contact your local municipality, disposal service, or the shop where you bought
this product.
IC Statement
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the
following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause undesired operation of
the device."
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de
licence. L'exploitation est autorisée aux deux conditions suivantes:
(1) l'appareil nedoit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est
susceptible d'en compromettre le fonctionnement."
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
IC RF Statement:
When using the product, maintain a distance of 20cm from the body to ensure compliance with RF
exposure requirements.
Lors de l'utilisation du produit, maintenez une distance de 20 cm du corps afin de vous conformer aux
exigences en matière d'exposition RF.
Anker Innovations Limited Room 1318-19,Hollywood Plaza,610 Nathan Road,Mongkok,Kowloon,Hong
Kong
Notice
FCC Statement
T
his device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
this device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Warning:
Changes or modifications not expressly approved by the party responsible for compliance could
void the user's authority to operate the equipment.
Note:
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures: (1) Reorient or relocate the receiving antenna. (2) Increase the separation between
the equipment and receiver. (3) Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected. (4) Consult the dealer or an experienced radio/TV technician for help.
FCC Radio Frequency Exposure Statement
The device has been evaluated to meet general RF exposure requirements. The device can be used in
fixed/mobile exposure condition. The min separation distance is 20cm.
Notice:
Shielded cables
All connections to other computing devices must be made using shielded cables to maintain compliance
with FCC regulations.
The following importer is the responsible party
Company Name: POWER MOBILE LIFE, LLC
Address: 400 108th Ave NE Ste 400, Bellevue, WA 98004-5541
Telephone: 1-800-988-7973
This product complies with the radio interference requirements of the European Community.
Declaration of Conformity
Hereby, Anker Innovations Limited declares that this device is in compliance with the essential
requirements and other relevant provisions of Directive 2014/53/EU.For the declaration of conformity,
visit the Web site www.eufylife.com
Do not use the Device in the environment at too high or too low temperature, never expose the Device
under strong sunshine or too wet environment.
The suitable temperature for the product and accessories is -20°C-50°C.
RF exposure information: The Maximum Permissible Exposure (MPE) level has been calculated based on a
15
Customer Service
• Warranty
12-month limited warranty
• Call Us
United States +1 (800) 988 7973 Mon-Fri 9AM-5PM (PT)
United Kingdom +44 (0) 1604 936 200 Mon-Fri 6AM-11AM (GMT)
Germany +49 (0) 69 9579 7960 Mon-Fri 6:00-11:00
• Email Us
Customer Support: [email protected]
