Installation, Care and Use of
Your Lynx Beverage Tower
Kits
Introduction:
Your Lynx Beverage Kits comes with all of the components necessary to install a
keg tap and tray to an outdoor island or to the Lynx model L24BF outdoor
refrigerator. An optional Tower Base (L24TWB) and caster kit (L24CST) is
available to set this kit up as a mobile beverage station as shown, when used
with the L24BF.
The Lynx model L24BF outdoor refrigerator has been designed specifically to
work with the Beverage Kits. The volume is designed to accommodate two 1/6
kegs, or all single standard keg sizes except a ½ keg or larger (not provided), the
CO2 tank and required connections.
WARNINGS:
CO2 cylinders contain high pressure gas which can be hazardous if not handled
properly. Make sure you READ and UNDERSTAND the procedures included with
the CO2 cylinders BEFORE installation.
Beverage Tower Kit Components
A
B
C
D
E
A) Single or Double Keg Tower
B) Low Profile Keg Coupler (D System for North American Beers)
C) Regulator, Dual Gauge CO2 (Kit contains all hoses and fittings, Sleeve
D) CO2 Gas Cylinder connectors, bushing and insulator sleeves)
E) Spill Tray L24TWD L24TWS
Lynx Beverage Kits
Model L24TWS Single Tower and L24TWD Double Tower
Lynx Professional Grills, Inc.
7300 Flores St., Downey, CA 90242
Phone: (562)299‐6900 Fax: (562)299‐6978 | www.lynxgrills.com P/N 33913 Rev. C 1/14
