Middle
10. During use, do not place or leave appliance where it may be damaged by an
animal or exposed to weather.
11. To disconnect, turn all controls to “OFF,” then remove plug from outlet.
12.
Turn all controls to “OFF” before attaching or detaching detail trimmer blades.
SAVE THESE INSTRUCTIONS
This Clipper Has Been Designed For Household Use Only
OIL
The blades of your new clipper should be oiled every
few haircuts. Place a few drops of Wahl Clipper Oil
on the teeth of the blades as well as at the back of the
blade. Use only the Wahl Clipper Oil included in the
pack. Do not use hair oil, grease or any oil mixed with
kerosene or any solvent.
POWER SCREW
Your clipper has a power screw and it has been adjusted
for peak efficiency before leaving the factory. However, if voltage
in your home is low, you may need to readjust it. To adjust
power, turn your clipper “On”. Use the end of the cleaning
brush or a screwdriver to turn power screw in a clockwise
direction until you hear a noise. Then, slowly turn power screw
in a counterclockwise direction, just until noise stops. This is
the maximum power setting.
CORD
The cord should not be used to pull the clipper. Since freedom of movement needs to be
maintained, care should be used to keep the cord untwisted and unobstructed.
If your clipper has a polarized plug: To reduce the risk of electric shock, this appliance
has a polarized plug (one blade is wider than the other). This plug fits in a polarized outlet
only one way. In the event the plug does not fit fully in the outlet, reverse the plug. Do not
change the plug in any way.
TAPER LEVER
(NOT INCLUDED ON ALL CLIPPER MODELS)
The taper lever adds versatility to your clipper by allowing you to
gradually change the closeness of your cut. (Up position = closest
cut; Down position = longest cut) Should the blades become jammed
with hair, move the taper lever up and down several times. This will
help free up the blades.
LIMITED WARRANTY
(Valid in U.S.A. only)
If your Wahl product fails to operate satisfactorily within five (5) years from the date of original purchase or
receipt as a gift, Wahl will, at our option, repair or replace it and return it to you FREE OF CHARGE.
DO NOT RETURN THIS PRODUCT TO STORE WHERE PURCHASED. PRODUCTS NEEDING REPAIR
UNDER THIS WARRANTY SHOULD BE RETURNED WITH POSTAGE PREPAID TO:
WAHL CLIPPER CORPORATION
ATTN: REPAIR DEPARTMENT
3001 LOCUST STREET
STERLING, ILLINOIS 61081
Include a note describing the defect and the date of original purchase or receipt as a gift (if in warranty).
Products out of warranty will be repaired at our standard repair charges.
This warranty is void and no repair or replacement will be made under this warranty or otherwise if:
1. The product is modified in any manner or repaired by anyone other than Wahl Clipper
Corporation or Wahl authorized service center.
2. The product has been used commercially or subjected to unreasonable use.
This warranty gives you specific legal rights and you may also have other rights which may
vary from
state to state. No other written express warranty is given. Any implied warranty, including any warranty of
merchantability which may arise from purchase or use, is limited to the five-year period provided in this
express warranty. Some states may not allow such limitation, so it may not apply to you. No responsibility
is assumed for incidental or consequential damages of any type, or for the use of unauthorized attachments.
Some states may not allow the exclusion or limitation of incidental or consequential damages, so the
limitation or exclusion may not apply to you. Warranty valid in U.S.A. only. Outside U.S.A., check with store
for Wahl authorized distributor’s warranty.
IMPORTANT SAFEGUARDS
When using an electrical appliance, basic precautions should always be followed,
including the points listed below. Read all instructions and safeguards before using.
DANGER —
To reduce the risk of injury or death by electric shock:
1. Do not reach for an appliance that has fallen into water. Unplug immediately. Some
electrical parts inside the clipper are electrically live, even with the switch “OFF.”
2. Do not use while bathing or in a shower.
3. Do not place or store appliance where it can fall or be pulled into a tub or sink. Do
not place in or drop into water or other liquid.
4. Always unplug this appliance from the electrical outlet immediately after using.
5. Unplug this appliance before cleaning.
WARNING —
To reduce the risk of burns, fire, electric shock or injury to persons:
1. An appliance should never be left unattended when plugged in.
2. Close supervision is necessary when this appliance is used by, on, or near children
or disabled persons.
3. Use this appliance only for its intended use, as described in this manual. Do not use
attachments not recommended by the manufacturer.
4. Never operate this appliance if it has a damaged cord or plug, if it is not working
properly, if it has been dropped or damaged, or dropped into water. Return the
appliance to Wahl Clipper Corporation for examination and repair.
5. Keep the cord away from heated surfaces.
6. Never operate the appliance with the air openings blocked or while on a soft
combustible surface, such as a bed or couch, where air openings may be blocked.
Keep the air openings (if any) free from lint, hair or the like.
7. Never drop or insert any object into any opening on this appliance.
8. Do not use outdoors or operate with aerosol (spray) products or where oxygen is
being administered.
9. Do not use this appliance with a damaged or broken comb nor with teeth missing
from the blades, as injury may occur. Before use, make certain blades are aligned
properly. (See Clipper Maintenance Instructions.)
Please register your Wahl Clipper online at: www.home.wahl.com
Purchase Confirmation-
With the information your provide, we confirm the date of purchase of your product. This
confirmation is of benefit to you, especially if your original proof of purchase is lost.
Proof of Ownership-
Your UPC number, item number and other information will be kept in our files for up to ten
years.
CLIPPER MAINTENANCE
Taper Lever
(Not included on
all clipper models)
Top Blade
Bottom
Blade
Switch
Power Screw
ALIGNING CLIPPER BLADES
Your Wahl clipper blades were oiled and aligned before leaving our factory. Blades may
need to be realigned if they have been bumped or removed for cleaning. To determine if
realignment is necessary, compare your clipper blades with this sketch.
1. If your clipper has a taper lever, position the lever in the close cut position.
2. End of top blade teeth should be approximately 1/32-inch (.64 mm) back from bottom blade.
3. Extreme left-hand tooth of top blade must be covering or to the left of the first small tooth
of bottom blade.
4. Extreme right-hand tooth of top blade must be touching the big tooth on the bottom blade.
If blade alignment is incorrect, add a few drops of Wahl Clipper Oil to the blades, turn clipper
“ON” for a few moments, turn “OFF” and unplug. Loosen screws slightly and adjust. Tighten
screws after blades are aligned. Other than blades, this clipper has no user-serviceable parts.
Like us on Facebook and follow us
on Twitter at Wahl Home
For more information or product
registration, visit wahlhaircuts.com
ATTACHING GUIDE COMBS
Align comb onto blade then press
tab until you hear a snap.
GUIDE COMB LISTING
Some kits do not include all Wahl guide combs. Some kits include colored guide combs
for ease in remembering which combs were previously used.
#
1
/2
-
(1.5mm)
1
/16”
Light Green/Black
#
1
-
(3mm)
1
/8”
Red/Black
#
1
1
/2
-
(4.5mm)
3
/16”
Burgundy/Black
#
2
-
(6mm)
1
/4”
Purple/Black
#
3
-
(10mm)
3
/8”
Dark Blue/Black
#
4
-
(13mm)
1
/2”
Orange/Black
#
5
-
(16mm)
5
/8”
Yellow/Black
#
6
-
(19mm)
3
/4”
Lavender/Black
#
7
-
(22mm)
7
/8”
Green/Black
#
8
-
(25mm) 1”
Light Blue/Black
#
12
-
(38mm) 1
1
/2
”
Black Only
#
10
-
(31mm) 1
1
/4
”
White Only
NOTE:
1) Always start with the largest
guide comb, then use shorter
combs if a shorter length is
desired.
2) Cut only a small amount until
you become accustomed to how
long each guide comb leaves
the hair.
3) Cut slowly and smoothly. Do not
force the clipper through the hair.
ActuAl BlAde Size
The first time you cut hair, cut only a small amount of hair
until you become accustomed to the length of hair each
guide comb provides.
• Start by attaching the largest guide comb on the
clipper.
• Then use shorter combs if a shorter length is desired.
• For uniform cutting, cut at a slow even speed.
1
ST
TIME CUTTING HAIR
1
7
8
9
10
11
12
13
2
3
4
5
6
1. Attach the left
ear guide comb
to the clipper.
Put taper
lever in down
position.
2. Hold the clipper
at a slight angle just
back of the ear at the
hairline. Hold top of
ear down.
3. Move the clipper
upward and around
the ear.
Repeat the same for the
right ear with the right
ear guide comb.
To remove more bulk from behind the ears, use the left ear tapered guide
comb. Start behind the ear and arch the clippers around the ear for a clean
line, repeating the steps on the right side using the right ear tapered guide
comb.
When you want to blend from one section to the next, you will need to practice
moving the clipper in an upward rocking motion. This motion will leave the hair
slightly longer where the clipper pulls away from the scalp, enabling you to blend
between the sections and achieve a smooth transition from one length of hair to the
next. This technique will enhance the appearance of your haircuts.
Then clean up your sideburns, neckline and around the ears.
1. Comb hair and remove
tangles. Attach the largest guide
comb to the clipper. Make sure
the taper lever is in the up
position.
2. Start at hairline on side of
head and cut up to middle of
head. Note: If cut hair is
too long repeat with next
smaller guide comb.
3. Continue around head
repeating step 2.
4. You are now ready to cut
the middle portion of the hair.
5. Use the comb with the next
highest number than in step 3.
Example:If you used a #6 comb
in step 3, select comb #7.
6. Continue cutting around
middle portion of head as in
steps 2 and 3.
7. For cutting top of head, use
the comb with the next highest
number than in step 6.
Start at front bang area.
8. Cut across top of head.
Comb hair on entire head
to assess if further cutting
is necessary
.
Tapering
Blending
Outlining
Bald Fade
Bald Cut
Brow Trim
Guide
Ear Trim
Guide
1. Blend out any cut lines.
Lines may form where
you change comb sizes.
Use the same comb used
in step 3 with taper lever
in down position.
3. Using the comb
used in step 8 repeat
blending the top
outline as in step 10.
2. Using a rocking
motion, blend out
the middle cut line.
1. Attach the brow trim
guide to clipper
2. Starting from just
above your nose, slowly
guide the clipper to the
outside of your face.
For shorter brow trim
repeat steps 1 and 2
working from outside
face to your nose.
1. Attach ear trim guide to
clipper.
2. Hold the clipper at a
45-degree angle.
3. Use your finger to tilt
ear forward away from
hairline.
4. Slowly trim along the
hair line from back to front.
Avoid poking eyes.
NOTE: NOT ALL WAHL KITS INCLUDE
BROW OR EAR TRIM GUIDE
For personal attention from one of our
customer service
representitives
please contact us at:
www.home.wahl.com
or
1-800-767-9245
© 2014 WAHL CLIPPER
CORPORATION
P.O. Box 578, Sterling, Illinois 61081
USA
Part #96400-400
Home
H
aircutting
witH
1. No attachments
needed. Push the
taper lever up
to the close cut
position.
2. Start with the
sideburns.
3. Continue
around ear and
neckline as
shown.
4. Trim along
hairline as
shown.
1. This style leaves
the head virtually
bald at the bottom,
fading to slightly
longer hair on top.
Remove the bulk of
hair before starting
the bald fade cut.
2. Start at the temple and
cut all the way around
the head to establish
the ultimate location of
the fade line. Always cut
against the grain for the
shortest cut.
3. Cut around the
head again and up
the nape of the neck
to the fade line,
brushing away the
cut hair as you go.
4. Pull the scalp
taut with the thumb
for the closest cut.
Turn the clipper
upside down when
necessary to keep
cutting against the
grain. Make sure
both sides of the
head are even.
5. For the top of the
head, cut with the grain.
Comb or brush the hair
as you cut for a even
end result.
6. To complete the
fade, blend the hair
at the fade line by
trimming up and
out across the line
and against the
grain all the way
around the head.
2. For a totally smooth,
bald effect, we recommend
you finish by using an
electric shaver or a wet
blade shaver to shave the
entire head.
1. For a totally bald
look, continue to cut
progressively shorter,
against the grain, all over
the head.
Tips and Techniques
When you cut hair, you should visualize the head as if it
were divided into four sections. Image above shows the
different sections. Using proper techniques when moving
from one section to the next will help you blend the
sections together for professional looking results.
Loading ...
