NS-39E480A13
NS-42E480A13
NS-46E481A13
User Guide
39"/42"/46"
1080p LED TV
ii
www.insigniaproducts.com
Contents
CHILD SAFETY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
WARNING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
CAUTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Insignia Motion 120Hz . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Game mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
INlink . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Installing the stand or wall-mount bracket . . . . . . . . . . . . . . . . . . . . . . . .5
Installing the stand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Installing a wall-mount bracket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
TV components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Package contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Front . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Side . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Back . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Making connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
What connection should I use? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Connecting power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Connecting a cable or satellite box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Connecting an antenna or cable TV (no box) . . . . . . . . . . . . . . . . . . . . . 13
Connecting a DVD or Blu-ray player . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Connecting a VCR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Connecting a camcorder or game console . . . . . . . . . . . . . . . . . . . . . . . 16
Connecting a computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Connecting a USB flash drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Connecting headphones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Connecting a basic home theater system . . . . . . . . . . . . . . . . . . . . . . . . 19
Connecting a home theater system with multiple devices . . . . . . . . 20
Using the remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Installing remote control batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Aiming the remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
iii
Contents
www.insigniaproducts.com
Turning on your TV for the first time . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Understanding the basics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Turning your TV on or off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Selecting the video input source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
On-screen menu overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Navigating the menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Selecting a channel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Adjusting the volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Viewing channel information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Viewing system information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Adjusting the picture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Adjusting the TV picture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Adjusting the computer image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Adjusting component video settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Adjusting the sound . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Adjusting sound settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Playing TV audio only . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Changing channel settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Automatically scanning for channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Hiding channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Setting up a favorite channel list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Viewing a favorite channel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Checking the digital signal strength . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Setting parental controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Setting or changing the password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Locking control buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Blocking unrated TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Setting parental control levels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Downloading rating information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Using closed captioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Turning closed captioning on or off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Selecting the analog closed captioning mode . . . . . . . . . . . . . . . . . . . 37
Customizing digital closed captioning styles . . . . . . . . . . . . . . . . . . . . . 37
Adjusting time settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Setting the clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Setting the sleep timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Adjusting menu settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Selecting the menu language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Labeling an input source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
iv
Contents
www.insigniaproducts.com
Restoring settings to the defaults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Using INlink . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Turning INlink on or off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Turning Device Auto Power Off on or off . . . . . . . . . . . . . . . . . . . . . . . . . 42
Turning TV Auto Power On on or off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Turning Audio Receiver on or off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Opening an INlink-compatible device’s root menu . . . . . . . . . . . . . . . 43
Displaying a list of INlink-compatible (HDMI CEC) devices . . . . . . . . 44
Using a USB flash drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Switching to USB mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Browsing photos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Viewing favorite photos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Viewing photos in a slideshow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Customizing slideshow settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Maintaining . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Cleaning the TV cabinet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Cleaning the TV screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Video and audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Programming universal remote controls . . . . . . . . . . . . . . . . . . . . . . . . 50
Programming a different universal remote control . . . . . . . . . . . . . . . 50
Common universal remote control codes . . . . . . . . . . . . . . . . . . . . . . . . 50
Legal notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
One-year limited warranty - Insignia Televisions . . . . . . . . . . . . . . . . . 52
Definitions: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
How long does the coverage last? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
What does this warranty cover? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
How to obtain warranty service? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Where is the warranty valid? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
What does the warranty not cover? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
1
www.insigniaproducts.com
As you enjoy your new product, keep these
safety tips in mind
The issue
The home theater entertainment experience is a growing trend, and larger TVs are popular
purchases. However, TVs are not always supported on the proper stands or installed
according to the manufacturer’s recommendations. We and the consumer electronics
industry are committed to making home entertainment enjoyable and safe.
TVs that are inappropriately placed on dressers, bookcases, shelves, desks, speakers, chests, or
carts may fall over and cause injury.
Tune into safety
• One size of TV stand does not fit all. Use only a TV stand
rated for the weight of your TV.
• Carefully read and understand all enclosed instructions
for proper use of this product.
• Don’t let children climb on or play with entertainment
system furniture and TVs.
• Don’t place TVs on furniture that can easily be used as
steps, such as a crate or chest of drawers.
• Remember that children can become excited while
watching a program, especially on a “larger-than-life” TV.
Make sure that you place or install the TV where it cannot
be pushed, pulled over, or knocked down.
• Make sure that you route all cords and cables so that they
cannot be pulled or grabbed by curious children.
Wall mounting
If you decide to wall mount your TV, always remember:
• One size of wall mount does not fit all. Use only a wall mount rated for the weight of
your TV and that has been recommended by this TV manufacturer, listed in this
manual, or otherwise listed by an independent laboratory as suitable for your TV.
• Follow all instructions supplied by the TV and wall mount manufacturers.
• If you have any doubts about your ability to safely wall mount your TV, get help from a
professional installer.
• Make sure that the wall where you are mounting the TV is
appropriate. Some wall mounts are not designed to be
mounted to walls backed with steel studs or cinder blocks. If
you are unsure, ask a professional installer.
• TVs can be heavy. At least two people are required for safe wall mount installation.
f
CHILD SAFETY
It makes a difference how and where you use
your flat panel display
2
NS-39E480A13/NS-42E480A13/NS-46E481A13
www.insigniaproducts.com
Important Safety
Instructions
1 Read these instructions.
2 Keep these instructions.
3 Heed all warnings.
4 Follow all instructions.
5 Do not use this apparatus near water.
6 Clean only with dry cloth.
7 Do not block any ventilation openings. Install in
accordance with the manufacturer's
instructions.
8 Do not install near any heat sources such as
radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce
heat.
9 Do not defeat the safety purpose of the
polarized or grounding-type plug. A polarized
plug has two blades with one wider than the
other. A grounding type plug has two blades
and a third grounding prong. The wide blade or
the third prong are provided for your safety. If
the provided plug does not fit into your outlet,
consult an electrician for replacement of the
obsolete outlet.
10 Protect the power cord from being walked on or
pinched particularly at plugs, convenience
receptacles, and the point where they exit from
the apparatus.
11 Only use attachments/accessories specified by
the manufacturer.
12 Use only with the cart, stand,
tripod, bracket, or table specified
by the manufacturer, or sold with
the apparatus. When a cart is used,
use caution when moving the
cart/apparatus combination to avoid injury from
tip-over.
13 Unplug this apparatus during lightning storms
or when unused for long periods of time.
14 Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has
been damaged in any way, such as
power-supply cord or plug is damaged, liquid
has been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to
rain or moisture, does not operate normally, or
has been dropped.
15 The wall plug is the disconnecting device. The
plug must remain readily operable.
16 An apparatus with three-prong, grounding-type
plug is a Class I apparatus which needs to be
grounded to prevent possible electric shock.
Make sure that you connect the Class I
apparatus to a grounding-type, three-prong
outlet.
17 Remote control batteries should not be exposed
to excessive heat such as sunshine, fire, or the
like.
18 The apparatus should not be exposed to
dripping or splashing and no objects filled with
liquids, such as vases, should be placed on the
apparatus.
WARNING
Electric shock hazard
To reduce the risk of fire or electric shock, do not
remove any cover or expose the device to rain or
moisture. No user-serviceable parts are inside. Refer
servicing to qualified service technicians.
Lightning
For added protection for your device receiver
during a lightning storm, or when it is left
unattended and unused for long periods of time,
unplug it from the power outlet and disconnect any
antenna or cable system. This helps prevent
property damage and personal injury from
lightning and power line surges.
Power lines
An outside antenna system should not be located in
the vicinity of overhead power lines or other
electric light or power circuits, or where it can fall
into such power lines or circuits. When installing an
outside antenna system, extreme care should be
taken to keep from touching such power lines or
circuits as contact with them might be fatal.
Handling the LCD panel
• Your TV’s screen is made of glass. Do not drop
your TV or hit, jolt, or press hard against the LCD
panel. If the screen breaks, be careful of broken
glass.
• If the LCD panel is broken, make absolutely sure
that you do not touch the liquid in the panel. This
may cause skin inflammation.
• If the liquid gets in your mouth, immediately
gargle, rinse, and consult with your doctor. Also, if
the liquid gets in your eyes or touches your skin,
consult with your doctor after rinsing for at least
15 minutes or longer in clean water.
Replacement parts
When replacement parts are required, make sure
that the service technician uses replacement parts
specified by the manufacturer that have the same
characteristics as the original part. Unauthorized
substitutions may result in fire, electric shock,
personal injury, or other hazards.
Safety check
After completing any service or repair to this device,
ask the service technician to perform routine safety
checks to determine that your TV is in correct
operating condition.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
This symbol indicates that dangerous
voltage constituting a risk of electric
shock is present within your TV. This
label is located on the back of your TV.
This symbol indicates that there are
important operating and maintenance
instructions in the literature
accompanying your TV.
3
www.insigniaproducts.com
Power source
Operate your TV only from the type of power source
indicated on the marking label. If you are not sure
of the type of power supplied to your home, consult
an electrician or your local power company.
Servicing
These servicing instructions are for use by qualified
service personnel only. To reduce the risk of electric
shock, do not perform any servicing other than that
contained in the operating instructions unless you
are qualified to do so.
CAUTION
Damage requiring service
Unplug this TV from the power outlet and refer
servicing to qualified service personnel under the
following conditions:
• When the power supply cord or plug is damaged
or frayed.
• If liquid has been spilled or objects have fallen
into your TV.
• If your TV has been exposed to rain or water.
• If your TV does not operate normally by following
the operating instructions. Adjust only those
controls that are covered by the operating
instructions because incorrect adjustment of
other controls may result in damage and will
often require extensive work by a qualified
technician to restore your TV to its normal
operation.
• If your TV has been dropped or damaged in any
way.
• When your TV exhibits a distinct change in
performance.
Outdoor antenna grounding
If an outside antenna or cable system is connected
to your TV, make sure that the antenna or cable
system is grounded to provide some protection
against voltage surges and built-up static charges.
Article 810 of the National Electrical Code,
ANSI/NFPA No. 70, provides information with
respect to correct grounding of the mast and
supporting structure, grounding of the lead-in wire
to an antenna discharge unit, size of grounding
conductors, location of the antenna-discharge unit,
connection to grounding electrodes, and
requirements for the grounding electrode.
Note to CATV system installer
Article 820 of the National Electrical Code,
ANSI/NFPA No. 40 provides guidance for correct
grounding. Specifically, it states that the cable
ground must be connected to the grounding
system of the building as close to the point of cable
entry as practical.
Condensation
Moisture will form on the TV if the TV is brought
from cool surroundings into a warm room or if the
temperature of the room rises suddenly. When this
happens, the TV's performance may be impaired. To
prevent this, let the TV stand in its new
surroundings for about an hour before switching it
on, or make sure that the room temperature rises
gradually.
Condensation may also form during the summer if
the TV is exposed to the breeze from an air
conditioner. In such cases, change the location of
the TV.
Mobile telephone warning
To avoid interference with your TV picture and
sound, operating problems, or even damage, keep
your cordless and cellular telephones away from
the TV.
End of life directives
Your TV contains tin-lead solder. Disposal of these
materials may be regulated for environmental
reasons. Your TV also contains material that can be
recycled and reused. For disposal or recycling
information, contact your local authorities to find a
recycler in your area.
Non-active pixels
The LCD panel contains almost 3 million thin film
transistors, which provide exceptionally sharp video
quality. Occasionally, a few non-active pixels may
appear on the screen as a fixed blue, green, or red
point. These non-active pixels do not adversely
affect the performance of your TV, and are not
considered defects.
Antenna lead-in wire
Grounding clamp
Antenna discharge unit
Grounding conductors
Ground clamps
Power service grounding electrode system
Electric service equipment
2
1
3
4
5
6
7
1
2
3
4
5
6
7
4
NS-39E480A13/NS-42E480A13/NS-46E481A13 Insignia 39"/42"/46" 1080p LED TV
www.insigniaproducts.com
Insignia 39"/42"/46" 1080p LED TV
Introduction
Congratulations on your purchase of a high-quality
Insignia product. Your NS-39E480A13,
NS-42E480A13, or NS-46E481A13 represents the
state of the art in LED TV design and is designed for
reliable and trouble-free performance.
Insignia Motion 120Hz
With a 120 Hz screen refresh rate twice the rate of a
60 Hz screen, a screen with 1,080 lines of resolution
(up from 720 lines in the last generation of HDTVs),
and special motion-detection technology, you will
experience a picture with clearer detail and
brightness, smoother transitions, and reduced
motion blurring, particularly when watching
fast-motion sports and action scenes. (See page 26
for instructions on how to adjust the TV picture.)
Game mode
Video games generally require adjustments to the
television picture settings to get the maximum
experience. By simply pressing a button on your
remote control, your television settings will
automatically adjust for video games. It couldn't be
easier. (See page 26
for instruction on how to turn
Game Mode on and off.)
INlink
Enjoy the benefit of having HDMI CEC-compatible
products plug and play! No setup is needed! CEC
technology lets different components discover and
communicate with each other. (See page 41
for
instructions on how to use INlink.)
5
Insignia 39"/42"/46" 1080p LED TV
www.insigniaproducts.com
Installing the stand or
wall-mount bracket
Installing the stand
To install the stand:
1 Carefully place your TV face-down on a
cushioned, clean surface to protect the screen
from damages and scratches.
2 Align the front of the stand column with the
front of the base, then insert the stand column
into the base making sure that the grooves in
the stand column align with the ridges in the
base. Secure the stand column to the base with
three M5 x 12 mm screws (provided).
3 Align the stand cover with the stand column,
then secure the stand cover to the stand column
with one M5 × 12 mm screw (provided). Make
sure that the bottom of the stand cover is flush
against the top of the stand column.
4 Secure the stand cover to the TV using four M5
× 12 mm screws (provided).
Installing a wall-mount bracket
To attach your TV to a wall-mount bracket:
1 Carefully place your TV face-down on a
cushioned, clean surface to protect the screen
from damages and scratches.
2 Remove the four screws that secure the stand
cover to the screen, then remove the cover.
Notes
• If you plan to wall-mount your TV, do not install
the stand.
• Store the stand and stand screws in case you
decide to use the stand in the future.
Screw type Screw length # of screws
M5 12 mm 8
Ridge
Groove
Back view
Stand column
Stand cover
Warning
This TV is intended to be supported by a UL Listed
wall mount bracket with suitable weight/load
capacity. (See “Miscellaneous
” on page 49.)
Note
If the stand and the stand column are installed, you
do not need to remove them before you remove the
stand cover.
6
NS-39E480A13/NS-42E480A13/NS-46E481A13 Insignia 39"/42"/46" 1080p LED TV
www.insigniaproducts.com
3 Attach the wall-mount bracket to your TV using
the mounting holes on the back of your TV. See
the instructions that came with the wall-mount
bracket for information about how to correctly
hang your TV.
TV components
Package contents
• Remote control and batteries (2 AAA)
•Base
•Stand column
•Stand cover
•Screws (8)
• TV mount spacers and screws (4)
• Quick Setup Guide
• Important Information
Front
Note
• The length of the wall-mount screws vary
depending on the wall-mount bracket you
purchased. See the instructions that came with
the wall-mount bracket for screw lengths.
• The mounting holes on the back of your TV take
type M6 screws.
39-in.: 7.87 in. (200 mm)
42-in. and46-in.: 15.75 in. (400 mm)
39-in.: 7.87 in. (200 mm)
42-in. and46-in.: 15.75 in. (400 mm)
Wall-mount brackets
# Item Description
Remote control sensor
Receives signals from the remote control. Do not
block.
Power indicator
Turns off when your TV is on.
Lights red when your TV is off (standby mode).
MENU Press to open the on-screen menu.
INPUT
Press to open the Input source list, then press
INPUT one or more times to select the video input
source. For more information, see “Selecting the
video input source” on page 23.
In menu mode, press to confirm selections.
VOLUME /VOLUME Press to increase or decrease the volume.
CHANNEL /
CHANNEL
Press to go to the next or previous channel in the
channel list. For more information, see “Selecting a
channel” on page 25.
(power)
Press to turn your TV on or off (standby mode).
When your TV is off, power still flows through it. To
completely disconnect power, unplug the power
cord.
2
1
4
5
6
7
3
MENU
INPUT
VOLUME
CHANNEL
Note: The power indicator and remote
control sensor on the NS-39E480A13
model are on the left side of the front of
the TV.
1
2
3
4
5
6
7
7
Insignia 39"/42"/46" 1080p LED TV
www.insigniaproducts.com
Side Back
# Item Description
AV IN L/R (audio)
Connect the audio for a composite video device to
these jacks. For more information, see “Using
composite video (good)” on page 12 or 15.
AV IN VIDEO
Connect the video for a composite video device to this
jack. For more information, see “Using composite
video (good)” on page 12 or 15.
HDMI3/DVI
Connect an HDMI device to this jack. For more
information see “Using HDMI (best)
” on page 10
or 14.
Connect the video for a DVI device to the HDMI 3/DVI
jack. For more information, see “Using DVI (same as
HDMI but requires a sound connection)” on
page 11 or 14.
DIGITAL OUTPUT
(optical)
Connect a digital audio amplifier or home theater
system to this jack to listen to TV audio through the
amplifier speakers. For more information, see “Using
digital audio” on page 19.
PC IN PC/DVI AUDIO IN
Connect the audio for a computer to this jack. For more
information, see “Using VGA
” on page 17.
OR
Connect the audio for a DVI device to this jack. For
more information, see “Using DVI (same as HDMI but
requires a sound connection)” on page 11 or page 14.
PC IN VGA
Connect the video for a computer to this jack. For more
information, see “Connecting a computer” on page 17.
ANT/CABLE
Connect an antenna or cable TV to this jack. For more
information, see “Connecting an antenna or cable TV
(no box)” on page 13.
1
2
3
4
5
6
7
1
2
3
4
5
6
7
# Item Description
/AUDIO OUT
Connect headphones, an analog audio amplifier, a
home theater system, or a sound bar to this jack. For
more information, see “Using analog audio
” on
page 19.
USB
Connect a USB flash drive to this jack to view
compatible JPEG picture files. For more information,
see “Connecting a USB flash drive” on page 18 and
“Using a USB flash drive” on page 44.
HDMI1 ARC
Connect an HDMI device to this jack. For more
information see “Using HDMI (best)” on page 10
or 14.
If you are connecting a home theater system using
HDMI, connect it to the HDMI 1 ARC jack.
HDMI2
Connect an HDMI device to this jack. For more
information see “Using HDMI (best)” on page 10
or 14.
COMPONENT IN
Y, PB, PR
Connect the video for a component video device to
these jacks. For more information, see “Using
component video (better)” on page 11 or 15.
COMPONENT IN
L/R (audio)
Connect the audio for a component video device to
these jacks. For more information, see “Using
component video (better)” on page 11 or 15.
1 2 3 4 5
6
1
2
3
4
5
6
8
NS-39E480A13/NS-42E480A13/NS-46E481A13 Insignia 39"/42"/46" 1080p LED TV
www.insigniaproducts.com
Remote control
# Button Description
(power)
Press to turn your TV on or off (standby mode). When
your TV is off, power still flows through it. To
disconnect power, unplug the power cord.
Quick Launch Inputs
TV—Press to select your TV as the input source.
VIDEO—Press to select the device connected to the
COMPONENT video jacks or AV IN/VIDEO jack.
HDMI—Press one or more times to select the device
connected to the HDMI 1 ARC, HDMI 2, or
HDMI 3/DVI jack.
ACC—This button has no function.
Numbers
Press to enter channel numbers and the parental
control password.
Press to enter a digital sub-channel number. For more
information, see “Selecting a channel” on page 25.
ENTER Press to confirm selections or changes.
MENU Press to open the on-screen menu.
EXIT
Press to close the on-screen menu.
INPUT
Press to open the Input source list, press S or T on
the remote control to select the video input source,
then press ENTER. For more information, see
“Selecting the video input source” on page 23.
CH-LIST Press to open the channel list.
*
1
2
3
4
5
6
7
8
9
/MUTE
Press to mute the sound. Press again to restore the
sound.
VOL+/–
Press to increase or decrease the volume.
SLEEP
Press to set the sleep timer. You can select Off, 5, 10,
15, 30, 60, 90, 120, 180, or 240 minutes. For more
information, see “Setting the sleep timer” on page 39.
ZOOM
Press to change how the picture looks on the screen
(aspect ratio). For more information, see “Aspect ratio
options” on page 26.
(return)
In TV mode, press to return to the previous channel.
In USB mode, press to go back to a higher level folder.
S T W X
Press to navigate in on-screen menus and to adjust
settings.
HOME Press to open the on-screen menu.
INFO
Press to display TV status information, such as the
channel number, channel name (if available), or signal
source. For more information, see “Viewing channel
information” on page 25.
CCD
Press to turn closed captioning on or off. You can select
CC Off, CC On, or CC on Mute. For more information,
see “Turning closed captioning on or off” on page 36.
FAVORITE
Press to open the Favorite channel list. For more
information, see “Setting up a favorite channel list
” on
page 31
and “Viewing a favorite channel” on page 31.
CH /CH
Press to change TV channels. For more information,
see “Selecting a channel” on page 25.
Press to select the picture mode. You can select Vivid,
Standard, Energy Savings, Theater, Game, or
Custom. For more information, see “Picture Mode” in
“Adjusting the TV picture
” on page 25.
MTS/SAP
Press to select the audio mode for an analog program.
You can select:
• MONO—Select this option if there is noise
or static on weak stereo broadcasts.
• STEREO—Select this option for programs
broadcast in stereo.
• SAP—Select this option to listen to a
secondary audio program, if available.
AUDIO
Press to select the sound mode. You can select
Standard, News, Music, Movie, or Custom. For
more information, see “Sound Mode” in “Adjusting
sound settings” on page 28.
INlink Controls
Press to control INlink-compatible (HDMI CEC) devices.
For more information, see “Using INlink” on page 41.
# Button Description
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
9
Insignia 39"/42"/46" 1080p LED TV
www.insigniaproducts.com
Making connections
What connection should I use?
Your TV has several connection types for
connecting devices to your TV.
For the best video quality, you should connect a
device to the best available connection.
Use the following tables to identify cables:
You can use the HDMI3/DVI jack on your TV to
connect a DVI device to your TV. You need to attach
an HDMI-to-DVI adapter to the end of the HDMI
cable that connects to the DVI device.
Connection type
and jack
Video quality Cable connector
HDMI
video/audio
Best (use this
if your devices
have HDMI)
Component
video (requires
an audio
connection)
Better than
composite or
coaxial
Composite video
(requires an
audio
connection)
Better than
coaxial
Coaxial
video/audio
Good
Connection type
and jack
Cable connectors
Digital optical
audio
Analog audio
VGA (computer)
video and audio
Cautions
• Check the jacks for position and type before
making any connections.
• Loose connections can result in image or color
problems. Make sure that all connections are
tight and secure.
• The external audio/video equipment shown
may be different from your equipment. If you
have questions, refer to the documentation that
came with your equipment.
• Always unplug the power cord when
connecting external equipment.
10
NS-39E480A13/NS-42E480A13/NS-46E481A13 Insignia 39"/42"/46" 1080p LED TV
www.insigniaproducts.com
Connecting power
To connect the power:
• Plug the AC power cord into a power outlet.
Connecting a cable or satellite box
Many cable or satellite TV boxes have more than
one connection type. To get the best video, you
should use the best connection type available. For
more information, see “What connection should I
use?” on page 9.
Using HDMI (best)
To connect a cable or satellite box using HDMI:
1 Make sure that your TV’s power cord is
unplugged, and all connected equipment is
turned off.
2 Connect the incoming cable from the cable wall
jack to the cable-in jack on the cable or satellite
box.
3 Connect an HDMI cable (not provided) to one of
the HDMI jacks on the back or side of your TV
and to the HDMI OUT jack on the cable or
satellite box.
4 Plug your TV’s power cord into a power outlet,
turn on your TV, then turn on the cable or
satellite box.
5 Go through the Setup Wizard on page 21
.
Note
The back of your TV may vary from the illustration
based on the model of your TV.
Cautions
• Your TV should only be operated from the
power source indicated on the label.
• Always unplug the AC power cord from the
power outlet when you will not be using your
TV for an extended period of time.
Note
The back of your TV may vary from the illustration
based on the model of your TV.
Note
An HDMI cable carries both audio and video. You do
not need to use any audio cables.
HDMI cable
Cable or satellite box
Back of TV
11
Insignia 39"/42"/46" 1080p LED TV
www.insigniaproducts.com
Using DVI (same as HDMI but requires a sound
connection)
To connect a cable or satellite box using DVI:
1 Make sure that your TV’s power cord is
unplugged, and all connected equipment is
turned off.
2 Connect the incoming cable from the cable wall
jack to the cable-in jack on the cable or satellite
box.
3 Connect an HDMI-DVI adapter (not provided) to
one end of an HDMI cable (not provided), then
connect the adapter to the DVI OUT jack on the
cable or satellite box.
4 Connect the other end of the cable to the
HDMI3/DVI jack on the side of your TV.
5 Connect a 3.5mm audio cable (not provided) to
the PC IN PC/DVI AUDIO IN jack on the side of
your TV and to the AUDIO OUT jacks on the
cable or satellite box.
6 Plug your TV’s power cord into a power outlet,
turn on your TV, then turn on the cable or
satellite box.
7 Go through the Setup Wizard on page 21
.
Using component video (better)
To connect a cable or satellite box using
component video:
1 Make sure that your TV’s power cord is
unplugged, and all connected equipment is
turned off.
2 Connect the incoming cable from the cable wall
jack to the cable-in jack on the cable or satellite
box.
3 Connect a component video cable (not
provided) to the COMPONENT IN Y, P
B, and PR
video jacks on the back of your TV and the
component video out jacks on the cable or
satellite box.
4 Connect an audio cable (not provided) to the
COMPONENT IN L/R audio jacks on the back of
your TV and to the audio out jacks on the cable
or satellite TV box.
5 Plug your TV’s power cord into a power outlet,
turn on your TV, then turn on the cable or
satellite box.
6 Go through the Setup Wizard on page 21
.
Notes
•You must use the HDMI3/DVI jack to connect a
cable or satellite box using DVI. If you use
another HDMI jack, you will not hear sound
from the TV speakers.
• The back of your TV may vary from the
illustration based on the model of your TV.
Note
When you connect the audio using the
PC IN PC/DVI AUDIO IN jack, the audio output is
analog.
Cable or satellite box
HDMI cable with
HDMI-DVI adapter
3.5mm audio cable
Side of TV
Note
The back of your TV may vary from the illustration
based on the model of your TV.
Note
When you connect the audio using the
COMPONENT IN L/R audio jacks, the audio output is
analog.
Audio cable
Cable or satellite box
Cables are often color-coded
to match color-coded jacks.
Component video
cable
Back of TV
12
NS-39E480A13/NS-42E480A13/NS-46E481A13 Insignia 39"/42"/46" 1080p LED TV
www.insigniaproducts.com
Using composite video (good)
To connect a cable or satellite box using
composite video:
1 Make sure that your TV’s power cord is
unplugged, and all connected equipment is
turned off.
2 Connect the incoming cable from the cable wall
jack to the cable-in jack on the cable or satellite
box.
3 Connect an AV cable (not provided) to the
AV IN VIDEO jack and AV IN L /R audio jacks on
the side of your TV and to the composite video
and audio out jacks on the cable or satellite box.
4 Plug your TV’s power cord into a power outlet,
turn on your TV, then turn on the cable or
satellite box.
5 Go through the Setup Wizard on page 21
.
Using coaxial (good)
To connect a cable or satellite box using coaxial:
1 Make sure that your TV’s power cord is
unplugged, and all connected equipment is
turned off.
2 Connect the incoming cable from the cable wall
jack to the cable-in jack on the cable or satellite
box.
3 Connect a coaxial cable (not provided) to the
ANT/CABLE jack on the side of your TV and to
the coaxial out jack on the cable or satellite box.
4 Plug your TV’s power cord into a power outlet,
turn on your TV, then turn on the cable or
satellite box.
5 Go through the Setup Wizard on page 21
.
Note
The back of your TV may vary from the illustration
based on the model of your TV.
Note
When you connect the audio using the AV IN L/R
audio jacks, the audio output is analog.
Cable or satellite box
AV cable
Cables are often color-coded
to match color-coded jacks.
Side of TV
Note
The back of your TV may vary from the illustration
based on the model of your TV.
Notes
• Use a coaxial cable to eliminate interference and
noise from radio waves.
• Do not bundle the coaxial cable with the power
cord or other cables.
Cable or satellite box
Coaxial cable
Side of TV
13
Insignia 39"/42"/46" 1080p LED TV
www.insigniaproducts.com
Connecting an antenna or cable TV (no box)
To connect an antenna or cable TV (no box):
1 Make sure that your TV’s power cord is
unplugged, and all connected equipment is
turned off.
2 Connect a coaxial cable (not provided) to the
ANT/CABLE jack on the side of your TV and to
the antenna or cable TV wall jack.
3 Plug your TV’s power cord into a power outlet,
then turn on your TV.
4 Go through the Setup Wizard on page 21
.
Note
The back of your TV may vary from the illustration
based on the model of your TV.
Coaxial cable
Antenna or
cable TV (no box)
Side of TV
Notes
• Use a coaxial cable to eliminate interference and
noise from radio waves.
• Do not bundle the coaxial cable with the power
cord or other cables.
• If the antenna is not installed correctly, contact
qualified service personnel to correct the
problem.
• If the signal level for a channel is weak, the
picture may be distorted. Adjust the antenna or
use a highly directional outdoor or set-top
antenna with a built-in amplifier.
• If the picture quality is good on some channels
and poor on others, the problem may be caused
by a poor or weak signal from the broadcaster
or cable TV provider.
• If you connect to cable or satellite TV without a
set-top box and experience poor picture quality,
you may need to install a set-top box to improve
signal reception and picture quality. Contact
your cable or satellite TV provider about
upgrading to a set-top box.
• Many high-definition (HD) channels upscale
standard-definition (SD) content. The picture
displayed on your TV is still displayed as SD, thus
the picture quality will not be as clear or crisp as
it would be if the content was originally
recorded in HD.
14
NS-39E480A13/NS-42E480A13/NS-46E481A13 Insignia 39"/42"/46" 1080p LED TV
www.insigniaproducts.com
Connecting a DVD or Blu-ray player
Using HDMI (best)
To connect a DVD or Blu-ray player using HDMI:
1 Make sure that your TV’s power cord is
unplugged and the DVD or Blu-ray player is
turned off.
2 Connect an HDMI cable (not provided) to one of
the HDMI jacks on the back or side of your TV
and to the HDMI OUT jack on the DVD or
Blu-ray player.
3 Plug your TV’s power cord into a power outlet,
then turn on your TV.
4 Turn on the DVD or Blu-ray player, then set it to
the correct output mode. For more information,
see the documentation that came with the
player.
5 Press INPUT to open the Input source list.
6 Press
S or T to highlight HDMI 1, HDMI 2, or
HDMI 3, then press ENTER.
Using DVI (same as HDMI but requires a sound
connection)
To connect a DVD or Blu-ray player using DVI:
1 Make sure that your TV’s power cord is
unplugged and the DVD or Blu-ray player is
turned off.
2 Connect an HDMI-DVI adapter (not provided) to
one end of an HDMI cable (not provided), then
connect the adapter to the DVI OUT jack on the
DVD or Blu-ray player.
3 Connect the other end of the cable to the
HDMI3/DVI jack on the side of your TV.
4 Connect a 3.5mm audio cable (not provided) to
the PC IN PC/DVI AUDIO IN jack on the side of
your TV and to the AUDIO OUT jacks on the
DVD or Blu-ray player.
5 Plug your TV’s power cord into a power outlet,
then turn on your TV.
6 Turn on the DVD or Blu-ray player, then set it to
the correct output mode. For more information,
see the documentation that came with the
player.
7 Press INPUT to open the Input source list.
8 Press
S or T to select HDMI 3, then press
ENTER.
Note
The back of your TV may vary from the illustration
based on the model of your TV.
Note
You can also press HDMI repeatedly to select the
DVD or Blu-ray player.
DVD or Blu-ray player
HDMI cable
Back of TV
Notes
•You must use the HDMI3/DVI jack to connect a
DVD or Blu-ray player using DVI. If you use
another HDMI jack, you will not hear sound
from the TV speakers.
• The back of your TV may vary from the
illustration based on the model of your TV.
Note
You can also press HDMI one or more times to select
the DVD or Blu-ray player.
DVD or Blu-ray player
HDMI cable with
HDMI-DVI adapter
3.5mm audio cable
Side of TV
15
Insignia 39"/42"/46" 1080p LED TV
www.insigniaproducts.com
Using component video (better)
To connect a DVD or Blu-ray player using
component video:
1 Make sure that your TV’s power cord is
unplugged and the DVD or Blu-ray player is
turned off.
2 Connect a component video cable (not
provided) to the COMPONENT IN Y, P
B, and PR
jacks on the back of your TV and to the
COMPONENT OUT jacks on the component
video device.
3 Connect an audio cable (not provided) to the
COMPONENT IN L/R audio jacks on the back of
your TV and to the L/R AUDIO OUT jacks on the
DVD or Blu-ray player.
4 Plug your TV’s power cord into a power outlet,
then turn on your TV.
5 Turn on the DVD or Blu-ray player, then set it to
the correct output mode. For more information,
see the documentation that came with the
player.
6 Press INPUT to open the Input source list.
7 Press
S or T to select Component, then press
ENTER.
Using composite video (good)
To connect a DVD or Blu-ray player using
composite video:
1 Make sure that your TV’s power cord is
unplugged and the DVD or Blu-ray player is
turned off.
2 Connect an AV cable (not provided) to the
AV IN VIDEO jack and AV IN L/R audio jacks on
the side of your TV and to the AV OUT jacks on
the DVD or Blu-ray player.
3 Plug your TV’s power cord into a power outlet,
then turn on your TV.
4 Turn on the DVD or Blu-ray player, then set it to
the correct output mode. For more information,
see the documentation that came with the
player.
5 Press INPUT to open the Input source list.
6 Press
S or T to select AV, then press ENTER.
Note
The back of your TV may vary from the illustration
based on the model of your TV.
Notes
• When you connect the audio using the
COMPONENT IN L/R audio jacks, the audio
output is analog.
Note
You can also press VIDEO one or more times to select
the DVD or Blu-ray player.
Component video cable
Audio cable
Cables are often
color-coded to match
color-coded jacks.
DVD or Blu-ray player
Back of TV
Note
The back of your TV may vary from the illustration
based on the model of your TV.
Note
When you connect the audio using the AV IN L /R
audio jacks, the audio output is analog.
Notes
You can also press VIDEO one or more times to select
the DVD or Blu-ray player.
DVD or Blu-ray player
Cables are often color-coded to
match color-coded jacks.
AV cable
Side of TV
16
NS-39E480A13/NS-42E480A13/NS-46E481A13 Insignia 39"/42"/46" 1080p LED TV
www.insigniaproducts.com
Connecting a VCR
To connect a VCR:
1 Make sure that your TV’s power cord is
unplugged and the VCR is turned off.
2 Connect an AV cable (not provided) to the
AV IN VIDEO jack and AV IN L/R audio jacks on
the side of your TV and to the AV OUT jacks on
the VCR.
3 Plug your TV’s power cord into a power outlet,
then turn on your TV and the VCR.
4 Press INPUT to open the Input source list.
5 Press
S or T to select AV, then press ENTER.
6 Insert a videotape in the VCR, then press PLAY
on the VCR.
Connecting a camcorder or game console
To connect a camcorder or game console:
1 Make sure that your TV’s power cord is
unplugged and the camcorder or game console
is turned off.
2 Connect an AV cable (not provided) to the
AV IN VIDEO jack and AV IN L /R audio jacks on
the side of your TV and to the AV OUT jacks on
the camcorder or game console.
3 Plug your TV’s power cord into a power outlet,
then turn on your TV.
4 Turn on the camcorder or game console, then
set it to the correct output mode. For more
information, see the documentation that came
with the camcorder or game console.
5 Press INPUT to open the Input source list.
6 Press
S or T to select AV, then press ENTER.
Note
The back of your TV may vary from the illustration
based on the model of your TV.
Note
When you connect the audio using the AV IN L/R
audio jacks, the audio output is analog.
Note
You can also press VIDEO one or more times to select
the VCR.
VCR
Cables are often color-coded to
match color-coded jacks.
AV cable
Side of TV
Notes
• If your camcorder or game console has an HDMI
connection, we recommend that you use the
HDMI connection to get the best quality
possible.
• The back of your TV may vary from the
illustration based on the model of your TV.
Note
When you connect the audio using the AV IN L/R
audio jacks, the audio output is analog.
Notes
You can also press VIDEO one or more times to select
the camcorder or game console.
Cables are often color-coded to
match color-coded jacks.
Camcorder or
game console
AV cable
Side of TV
17
Insignia 39"/42"/46" 1080p LED TV
www.insigniaproducts.com
Connecting a computer
Using VGA
To connect a computer using VGA:
1 Make sure that your TV’s power cord is
unplugged and the computer is turned off.
2 Connect a VGA cable (not provided) to the
PC IN VGA jack on the side of your TV and to the
VGA jack on the computer.
3 Connect an audio cable with a stereo mini plug
(not provided) to the PC IN PC/DVI AUDIO IN
jack on the side of your TV and to the AUDIO
OUT jack on the computer.
4 Plug your TV’s power cord into a power outlet,
then turn on your TV and the computer.
5 Press INPUT to open the Input source list.
6 Press
S or T to select VGA, then press ENTER.
7 Adjust the display properties on the computer,
if necessary.
Using HDMI
To connect a computer using HDMI:
1 Make sure that your TV’s power cord is
unplugged and the computer is turned off.
2 Connect an HDMI cable (not provided) to one of
the HDMI jacks on the back or side of your TV
and to the HDMI OUT jack on the computer.
3 Plug your TV’s power cord into a power outlet,
then turn on your TV and the computer.
4 Press INPUT to open the Input source list.
5 Press
S or T to highlight HDMI 1, HDMI 2, or
HDMI 3, then press ENTER.
6 Adjust the display properties on the computer,
if necessary.
Note
The back of your TV may vary from the illustration
based on the model of your TV.
Audio cable with
stereo mini plug
VGA cable
Side of TV
Note
The back of your TV may vary from the illustration
based on the model of your TV.
Note
You can also press HDMI repeatedly to select the
computer.
HDMI cable
Back of TV
18
NS-39E480A13/NS-42E480A13/NS-46E481A13 Insignia 39"/42"/46" 1080p LED TV
www.insigniaproducts.com
Connecting a USB flash drive
To connect a USB flash drive:
1 Plug a USB flash drive into the USB port on the
back of your TV.
2 Turn on your T V.
3 Press INPUT to open the Input source list.
4 Press
S or T to select USB, then press ENTER.
Connecting headphones
The TV speakers are muted when headphones are
attached.
To connect headphones:
• Connect the headphones to the
/AUDIO OUT jack on the back of your TV.
Note
The back of your TV may vary from the illustration
based on the model of your TV.
Caution
Do not remove the USB flash drive or turn off the TV
while using the USB flash drive. You may lose data or
damage the USB flash drive.
Note
The Photos viewer only supports JPEG format
images (with “.jpg” file extensions) and not all JPEG
files are compatible with your TV.
For more information, see “Using a USB flash drive
”
on page 44
.
USB flash
drive
Back of TV
Note
The back of your TV may vary from the illustration
based on the model of your TV.
Warning
Loud noise can damage your hearing. When using
headphones, use the lowest volume setting on your
headphones that still lets you hear the sound.
Note
You can also connect an amplifier, home theater
system, or sound bar to the /AUDIO OUT jack. If
you want to connect an amplifier, home theater
system, or sound bar, you need to disconnect the
headphones.
Back of TV
19
Insignia 39"/42"/46" 1080p LED TV
www.insigniaproducts.com
Connecting a basic home theater system
Using digital audio
To connect a basic home theater system using
digital audio:
1 Make sure that your TV’s power cord is
unplugged and the home theater system is
turned off.
2 Connect a digital optical audio cable (not
provided) to the DIGITAL OUTPUT jack on the
side of your TV and to the digital optical AUDIO
IN jack on the home theater system.
Using analog audio
To connect a home theater system using analog
audio:
1 Make sure that your TV’s power cord is
unplugged and the home theater system is
turned off.
2 Connect a 3.5mm audio cable (not provided) to
the /AUDIO OUT jack on the back of your TV
and to the AUDIO IN jacks on the analog home
theater system.
Note
The back of your TV may vary from the illustration
based on the model of your TV.
Digital optical audio cable
Home theater system
Side of TV
Note
The back of your TV may vary from the illustration
based on the model of your TV.
Note
You can connect headphones, an amplifier, a home
theater system, or a sound bar to the /AUDIO OUT
jack. If you want to use headphones, you need to
disconnect the amplifier, home theater system, or
sound bar.
3.5mm audio cable
Home theater system
Back of TV
20
NS-39E480A13/NS-42E480A13/NS-46E481A13 Insignia 39"/42"/46" 1080p LED TV
www.insigniaproducts.com
Connecting a home theater system with
multiple devices
The connections you make depend on the video
and audio jacks available on your devices. Refer to
the documentation that came with your devices for
connection information.
Just remember to use the best connection types
available for the best picture and sound. For
information about connection types, see “What
connection should I use?” on page 9.
Using the remote control
Installing remote control batteries
To install remote control batteries:
1 Press the release button on the back of the
remote to remove the battery compartment
cover.
2 Insert two AAA batteries into the battery
compartment. Make sure that you match the +
and – symbols on the batteries with the + and –
symbols in the battery compartment.
3 Replace the battery compartment cover.
Aiming the remote control
To aim the remote control:
• Point the remote control towards the remote
sensor on the front of your TV.
Blu-ray player/DVD player/VCR
Cable/satellite box
AV receiver
Camcorder/game console
USB flash drive
Computer
Antenna or cable
TV connected
directly to the
wall jack
Cautions
• Batteries should not be exposed to excessive
heat, such as sunshine, heat registers, or fire.
• Battery chemicals can cause a rash. If the
batteries leak, clean the battery compartment
with a cloth. If chemicals touch your skin, wash
immediately.
• Make sure that batteries are disposed of
correctly. Do not burn or incinerate.
Notes
• Do not mix batteries of different types.
• Do not mix old and new batteries.
• Remove batteries when the charge is depleted.
• If the remote control is not going to be used for
an extended period of time, remove the
batteries.
21
Insignia 39"/42"/46" 1080p LED TV
www.insigniaproducts.com
Turning on your TV for the
first time
The first time you turn on your TV, the Setup Wizard
opens. The Setup Wizard guides you through
setting up basic settings including the menu
language, time setting, picture mode, TV signal
source, and the channel list.
To set up your TV:
1 Make sure that you have:
• Installed the remote control batteries. (See
page 20
for details.)
• Connected an antenna, cable TV, or satellite
TV. (See page 10
through 13 for details.)
• Connected the power cord. (See page 10
for
details.)
2 Press (power) to turn on your TV. The Choose
Your Menu Language screen opens.
3 Press
S or T to highlight the language you
want, then press ENTER. The Choose Your Time
Setting screen opens.
4 Press
S or T to highlight Mode, then press
W or X to select Manual (to set the date and
time manually) or Auto (to set the date and time
automatically from a TV signal source based on
the time zone you select).
5 Press
S or T to highlight Time Zone, then press
W or X to select your time zone. You can select
Eastern, Central, Mountain, Pacific, Alaska,
Hawaii, Atlantic, or Newfoundland.
6 Press
S or T to highlight Daylight Savings,
then press W or X to select On (if your viewing
area observes Daylight Savings Time) or Off (if
your viewing area does not observe Daylight
Savings Time).
7 If you selected Manual for Mode, set the date
by pressing
S or T to highlight Year, Month, or
Day, then pressing
W or X to adjust the setting.
8 If you selected Manual for Mode, set the time
by pressing
S or T to highlight Time, then
pressing W or X to select the hour, minute, or
AM/PM field. Press S or T to adjust the setting.
9 Press ENTER. The Choose Your Picture Mode
screen opens.
10 Press
S or T to highlight Home Mode or Retail
Mode, then press ENTER.
If you selected Retail Mode, the message “If you
select Retail Mode, then Energy savings is not
realized” appears. Select Ye s to continue using
Retail Mode, or select No to change your
selection, then press ENTER.
The Choose Your TV Source screen opens.
5or63or
4
English
ChooseYourMenuLanguage
Move
OK
ENTER
ME NU
EXIT
Exit
Previous
Se lec t
SetmenulanguagetoEnglish, or
Fran aisç
Español
Fran
ais
ç
Espa
ñ
ol
Move
OK
ENTER
ME NU
EXIT
Exit
Previous
Se lec t
Choose YourTimeSetting
Mode Auto
TimeZoneAtlantic
DaylightSavingsOn
Year
MonthOctober
Day
Time
AM
IfAutomaticoptionsareautomaticallysetbyTVsource
Note
If you select Auto, the displayed time will be
incorrect until your TV gets the correct time from a
TV signal source.
Move
OK
ENTER
ME NU
Previous
Se lec t
Choose YourPicture
Mode
Reducestotalpowerconsumption
HomeMode
RetailMode
EXIT
Exit
ChooseYourTVSource
Antenna
Cable
SatelliteBox
Move
OK
ENTER
ME NU
EXIT
Exit
Previous
Se lec t
SelectifusinganantennaforstandardorHDTV
22
NS-39E480A13/NS-42E480A13/NS-46E481A13 Insignia 39"/42"/46" 1080p LED TV
www.insigniaproducts.com
11 Press S or T to highlight Antenna, Cable, or
Satellite Box, then press ENTER.
A If you select Antenna, your TV scans for
available channels. The scan may take
several minutes.
During scanning, your TV searches for
digital channels first. When the digital
channel search is complete, a message
appears asking if you want to search for
analog channels. Select Ye s to continue
searching for analog channels, or select No
to stop searching for channels.
B If you select Cable, a message asks if you
have a cable box:
• Select No, then press ENTER if no cable
box is connected. Your TV scans for
available channels. The scan may take
several minutes.
• Select Ye s , then press ENTER if a cable box
is connected. A message asks how you
connected the cable box to your TV.
• Select AV, Component, or HDMI, then
press ENTER if you connected a cable
box to your TV using one of these
cables. Read the message, then press
ENTER to close the wizard.
• Select Coaxial, then press ENTER if you
connected a cable box to your TV using
a coaxial cable. Read the message, then
press ENTER to start the channel scan
(VHF channels only).
Note
You can press EXIT to stop the auto channel search,
but you will need to run the auto channel search
again to create a channel list.
AnalogChannels
DigitalChannels
Scanning for channels
Move
OK
ENTER
ME NU
EXIT
Exit
Previous
Se lect
Channel scan may take 20+ minutes.
Note
You can press EXIT to stop the auto channel search,
but you will need to run the auto channel search
again to create a channel list.
Channel scan may take 20+ minutes
Do you have a Cable Box?
No
Yes
Move
OK
ENTER
ME NU
EXIT
Exit
Previous
Se lec t
Select if you have a cable service
How did you connect the
AV, Component, or HDMI
Coaxial
Move
OK
ENTER
ME NU
EXIT
Exit
Previous
Se lec t
Cable Box to the
TV?
Select if you have a cable service
23
Insignia 39"/42"/46" 1080p LED TV
www.insigniaproducts.com
C If you select Satellite Box, a message asks
how you connected the satellite box to
your TV:
• Select AV, Component, or HDMI, then
press ENTER if you connected a satellite
box to your TV using one of these cables.
Read the message, then press ENTER to
close the wizard.
• Select Coaxial, then press ENTER if you
connected a satellite box to your TV using
a coaxial cable. Read the message, then
press ENTER to start the channel scan (VHF
channels only).
12 To watch TV, press INPUT, press
S or T to
highlight the video input source for your TV in
the Input source list, then press ENTER.
• If your TV is connected to an antenna, cable TV
(no box), or cable or satellite TV box using a
coaxial cable, select TV.
• If your TV is connected to a cable or satellite
box using an HDMI cable or HDMI cable with a
DVI adapter, select HDMI 1, HDMI 2 or
HDMI 3.
• If your TV is connected to a cable or satellite
box using a component video cable, select
Component.
• If your TV is connected to a cable or satellite
box using a composite video cable, select AV.
Understanding the basics
Turning your TV on or off
To turn your TV on or off:
1 Make sure that the power cord is connected to a
power outlet.
2 Press (power) to turn on your TV. The power
indicator turns off.
3 Press (power) again to turn off your TV. Your
TV enters standby mode, and the power
indicator LED turns red.
Selecting the video input source
To select the video input source:
1 Turn on your TV, then press INPUT. The Input
source list opens.
2 Press
S or T to select a video input source, then
press ENTER.
You can also press a Quick Launch Input button to
select the video input source.
• Press TV to select TV (if your TV is connected to an
antenna, cable TV (no box), or cable or satellite TV
using a coaxial cable).
• Press VIDEO one or more times to select
component or composite input.
•Press HDMI one or more times to cycle between
the HDMI inputs.
Note
You can press EXIT to stop the auto channel search,
but you will need to run the auto channel search
again to create a channel list.
How did you connect the
AV, Component, or HDMI
Coaxial
Move
OK
ENTER
ME NU
EXIT
Exit
Previous
Se lec t
Satellite Box to the TV?
Select if you have a satellite box
Warning
When your TV is in standby mode, it is still receiving
power. To completely disconnect power, unplug the
power cord.
Note
If your TV does not receive an input signal for several
minutes, it automatically goes into standby mode.
TV
AV
HDMI 1
HDMI 2
HDMI 3
USB
Input source
Component
VGA
24
NS-39E480A13/NS-42E480A13/NS-46E481A13 Insignia 39"/42"/46" 1080p LED TV
www.insigniaproducts.com
On-screen menu overview
Picture menu (TV mode)
Audio menu (TV mode)
Channels menu (TV mode)
Settings menu (TV mode)
Photos menu (USB mode)
Navigating the menus
Notes
• Depending on the signal source selected, you
may see different options on your screen. The
following menus are shown in TV mode (except
the Photos menu).
• Menu items that are not selectable are grayed
out.
• Menus in this manual are described in TV mode,
unless otherwise indicated.
• The screens shown in this manual are for
explanation purposes and may vary from the
actual screens on your TV.
OK
ENTER
MENU
EXIT
edoM erutciP Energy Saving
Brightness
48
Contrast
52
Color
68
Tint
0
Sharpness
10
Advanced Video
Reset Picture Settings
Move
Exit
Previous
Select
Adjust settings to affect picture quality.
CHANNELS
SETTINGS
PHOTOS
AUDIO
OK
ENTER
MENU
EXIT
Audio
Music
Move
Exit
Previous
Select
Sound Mode
Balance 0
Advanced Audio
Reset Audio Settings
Adjust settings to affect sound quality.
CHANNELS
SETTINGS
PHOTOS
AUDIO
OK
ENTER
MENU
EXIT
Channels
Auto Channel Search
Add/Skip Channels
Move
Exit
Previous
Select
Favorites
Channel Strength
Audio only Off
Auto Zoom On
Adjust channel options.
CHANNELS
SETTINGS
PHOTOS
AUDIO
OK
ENTER
MENU
EXIT
English
Settings
Menu Language
Input Labels
INLink
Computer Settings
Component Settings
Parental Controls
Closed Caption
Time
Set various TV options.
Move
Exit
Previous
Select
CHANNELS
SETTINGS
PHOTOS
AUDIO
OK
ENTER
MENU
EXIT
Photos
Settings
Browse Photos
Favorite Photos
View Slideshow
View files from a USB flash device that is connected to the TV.
Move
Exit
Previous
Select
CHANNELS
SETTINGS
PHOTOS
AUDIO
*
*
Press MENU to open the on-screen menu.
Press the right or left arrow to move the
cursor on the screen or to adjust a selected
item.
Press the up or down arrow to select menu
options.
Press ENTER to confirm a selection or enter a
sub-menu.
Press MENU to return to the previous menu.
Press EXIT to close the menu.
25
Insignia 39"/42"/46" 1080p LED TV
www.insigniaproducts.com
Selecting a channel
To select a channel:
• Press CH or CH to go to the next or previous
channel on the memorized channel list.
• Press the number buttons to enter the analog or
main digital channel number you want, then wait
for the channel to change or press ENTER to
immediately change the channel.
• To select a digital sub-channel, press the number
buttons to select the main digital channel, press
(dot), then press the number button for the
sub-channel. Wait for the channel to change, or
press ENTER to immediately change the channel.
For example, to tune to channel 5.1, press 5,
(dot), then 1.
• Press (return) to go to the last viewed channel.
• Press CH-LIST to open the channel list, press
S or
T to highlight a channel, then press ENTER.
Hidden channels are grayed and cannot be
selected. See “Hiding channels
” on page 30.
• Press FAVORITE to open the favorite channel list,
press
S or T to highlight a channel, then press
ENTER.
Adjusting the volume
To adjust the volume:
• Press VOL+ or VOL– to increase or decrease the
volume.
• Press MUTE to turn off the sound. Press
MUTE again to turn the sound back on.
Viewing channel information
To view channel information:
• Press INFO to view an information banner. The
information banner shows the current program
information such as channel number, video input
source, and resolution.
• Digital channel information—Displays the
channel number, station name, channel label,
broadcast program name, TV rating, signal
type, audio information, resolution, CC mode,
current time, and current program start and
end times.
• Analog channel information—Displays
channel number, channel label (if present),
signal type, audio information, and resolution.
Viewing system information
To view system information:
1 Press MENU. The on-screen menu opens.
2 Press
W or X to highlight SETTINGS, then press
T or ENTER. The Settings menu opens.
3 Press
S or T to highlight System Info, then
press ENTER. Information about the TV software
version is displayed.
4 Press MENU to return to the previous menu, or
press EXIT to close the menu.
Adjusting the picture
Adjusting the TV picture
To adjust the TV picture:
1 Press MENU. The on-screen menu opens with
the Picture menu displayed.
2 Press
T or ENTER to access the menu.
Note
Button presses must be within three seconds of each
other.
Note
If a list has more than one page, press S or T to
scroll through the pages.
OK
ENTER
MENU
EXIT
edoM erutciP Energy Saving
Brightness
48
Contrast
52
Color
68
Tint
0
Sharpness
10
Advanced Video
Reset Picture Settings
Move
Exit
Previous
Select
Adjust settings to affect picture quality.
CHANNELS
SETTINGS
PHOTOS
AUDIO
OK
ENTER
MENU
EXIT
English
Settings
Menu Language
Input Labels
INLink
Computer Settings
Component Settings
Parental Controls
System info
Time
Set various TV options.
Move
Exit
Previous
Select
CHANNELS
SETTINGS
PHOTOS
AUDIO
OK
ENTER
MENU
EXIT
edoM erutciP Energy Saving
Brightness
48
Contrast
52
Color
68
Tint
0
Sharpness
10
Advanced Video
Reset Picture Settings
Move
Exit
Previous
Select
Adjust settings to affect picture quality.
CHANNELS
SETTINGS
PHOTOS
AUDIO
26
NS-39E480A13/NS-42E480A13/NS-46E481A13 Insignia 39"/42"/46" 1080p LED TV
www.insigniaproducts.com
3 Press S or T to highlight an option, then press
ENTER to access the option. You can select:
• Picture Mode—Selects the picture mode. You
can select:
• Game—Adjusts the picture for the
ultimate gaming experience.
• Vivid—(a bright and vivid picture).
Significantly increases the contrast,
brightness, and sharpness. This selection is
good for video games, animation, and in
bright light environments.
• Standard—(a standard picture).
Moderately increases the contrast,
brightness, and sharpness. This selection is
good for standard TV broadcasts.
• Energy Savings—(the backlight
brightness is decreased). Your TV has a
backlight that provides light for displaying
a picture. By reducing the amount of light,
your TV uses less energy.
• Theater—(a finely detailed picture).
Adjusts the brightness and contrast and
lowers the sharpness for a more realistic
picture. This selection is good for watching
the highest quality video such as Blu-ray
Discs, DVDs, and HDTV.
• Custom—(customized picture). Lets you
manually adjust picture settings such as
brightness, contrast, and sharpness.
• Brightness—Adjusts the brightness of the
dark areas of the picture.
• Contrast—Adjusts the brightness of the light
areas of the picture.
• Color—Adjusts the color intensity of the
picture. A low setting may make the color look
faded. A high setting may make the color look
artificial.
• Tint—Adjusts the color balance of the picture.
Use this control to make skin tones look more
natural.
• Sharpness—Adjusts the color detail of
images. If you set this control too high, dark
images may appear with light or white edges.
• Advanced Video—Opens the
Picture · Advanced Video menu where you can
adjust additional video options.
• Backlight—Sets the overall brilliance of
the screen. When Dynamic Backlight
(DCR) is turned on, you cannot change the
Backlight setting.
• Insignia Motion 120Hz—Eliminates
motion blur with clear detail and smooth
motion. You can select:
• On—Turns on Insignia Motion 120Hz.
• Off—Turns off Insignia Motion 120Hz.
• Aspect Ratio—Selects the aspect ratio of
the picture.
• Color Temperature—Selects the color
temperature. You can select Cool (to
enhance the blues),
Normal, or Warm (to
enhance the reds).
• Overscan—Adjusts the picture’s
reproduction rate. You can select On or
Off.
• Noise Reduction—Selects the noise
reduction mode to reduce picture noise
(snow). You can select Low, Middle, High,
or Off.
• Adaptive Contrast—Automatically
adjusts picture detail and brightness. You
can select On or Off.
• Dynamic Backlight (DCR)—Enhances the
contrast ratio between light and dark areas
of the picture. You can select Off, Low, or
High.
• Reset Picture Settings—Resets all picture
settings to factory mode.
Note
You can also press PICTURE to select the picture
mode.
OK
ENTER
MENU
EXIT
Move
Exit
Previous
Select
Picture Advanced Video
Insignia Motion 120Hz eliminates motion blur with clear detail and smooth motion.
Aspect Ratio
Overscan
Color Temperature
Noise Reduction
Backlight
Adaptive Contrast
Dynamic Backlight (DCR)
75
Wide
Cool
On
Middle
High
On
CHANNELS
SETTINGS
PHOTOS
AUDIO
Insignia Motion 120Hz
On
Aspect ratio options Example
Normal:
Displays the original 4:3 aspect
ratio with vertical black bars on
the left and right of the image.
Zoom:
Expands the image to fill the
screen. The top and bottom of
the image may be cropped.
Wide:
Use this option to view content
recorded in a 16:9
(wide-screen) aspect ratio.
Cinema:
Stretches the image at the
edges, but keeps a clear image
in the center.
Auto:
Automatically adjusts the
image based on the screen size
and the TV program.
Note: Auto is only available
when Auto Zoom in the
Channels menu is set to On.
Note
You can also press ZOOM to select the aspect ratio.
27
Insignia 39"/42"/46" 1080p LED TV
www.insigniaproducts.com
4 Press W or X to adjust the option, or press S or
T to select a setting.
5 Press MENU to return to the previous menu, or
press EXIT to close the menu.
Adjusting the computer image
To adjust the computer image:
1 Make sure that your TV is in VGA mode. For
more information, see “Selecting the video
input source” on page 23.
2 Press MENU. The on-screen menu opens.
3 Press
W or X to highlight SETTINGS, then press
ENTER. The Settings menu opens.
4 Press
S or T to highlight Computer Settings,
then press ENTER. The Settings · Computer
Settings menu opens.
5 Press
S or T to highlight an option, then press
ENTER to access the option. You can select:
• Auto Adjust—Automatically adjusts the
image settings such as position and phase.
• H. Position—Moves the image right or left.
• V. Position—Moves the image up or down.
• Clock—Adjusts the sample frequency.
• Phase—Adjusts the focus of stable images.
• Reset Computer Settings—Resets all
computer settings to factory mode.
6 Press
W or X to adjust the option, or press S or
T to select a setting.
7 Press MENU to return to the previous menu, or
press EXIT to close the menu.
Adjusting component video settings
You can adjust the horizontal distortion that may
occur when watching video from a component
video device.
To adjust component video settings:
1 Make sure you have a device connected to the
Y/P
B/PR (component video) jacks on the side of
your TV.
2 Press VIDEO one or more times to select the
component video device.
3 Press MENU. The on-screen menu opens.
4 Press
W or X to highlight SETTINGS, then press
T or ENTER. The Settings menu opens.
5 Press
S or T to highlight Component Settings,
then press ENTER.
OK
ENTER
MENU
EXIT
edoM erutciP Energy Saving
Brightness
48
Contrast
52
Color
68
Tint
0
Sharpness
10
Advanced Video
Reset Picture Settings
Move
Exit
Previous
Select
Adjust settings to affect picture quality.
CHANNELS
SETTINGS
PHOTOS
AUDIO
OK
ENTER
MENU
EXIT
English
Settings
Menu Language
Input Labels
INLink
Computer Settings
Component Settings
Parental Controls
Closed Caption
Time
Set options for when a computer is connected to the TV.
Move
Exit
Previous
Select
CHANNELS
SETTINGS
PHOTOS
AUDIO
OK
ENTER
MENU
EXIT
Move
Exit
Previous
Select
Settings Computer Settings
Adjust to the PC signal timing automatically when ON.
Auto Adjust
H. Position 63
V. Position 48
Clock 127
Phase 29
Reset Computer Settings
CHANNELS
SETTINGS
PHOTOS
AUDIO
OK
ENTER
MENU
EXIT
edoM erutciP Energy Saving
Brightness
48
Contrast
52
Color
68
Tint
0
Sharpness
10
Advanced Video
Reset Picture Settings
Move
Exit
Previous
Select
Adjust settings to affect picture quality.
CHANNELS
SETTINGS
PHOTOS
AUDIO
OK
ENTER
MENU
EXIT
English
Settings
Menu Language
Input Labels
INLink
Computer Settings
Component Settings
Parental Controls
System info
Time
Set various TV options.
Move
Exit
Previous
Select
CHANNELS
SETTINGS
PHOTOS
AUDIO
28
NS-39E480A13/NS-42E480A13/NS-46E481A13 Insignia 39"/42"/46" 1080p LED TV
www.insigniaproducts.com
6 Press S or T to highlight an option, then press
ENTER to access the option. You can select:
• Phase—Minimizes horizontal distortion.
• Reset Component Settings—Resets all
component video settings to factory mode.
7 Press
W or X to adjust the option, or press S or
T to select a setting.
8 Press MENU to return to the previous menu, or
press EXIT to close the menu.
Adjusting the sound
Adjusting sound settings
To adjust sound settings:
1 Press MENU. The on-screen menu opens.
2 Press
W or X to highlight AUDIO, then press T or
ENTER. The Audio menu opens.
3 Press
S or T to highlight an option, then press
ENTER to access the option. You can select:
• Sound Mode—Selects the sound mode. You
can select:
• Standard—Balances treble and bass. This
setting is good for watching standard TV
broadcasts.
• Theater—Enhances treble and bass for a
rich sound experience. This setting is good
for watching DVDs, Blu-ray discs, and
HDTV.
• News—Enhances vocals for TV audio. This
setting is good for watching news
broadcasts.
• Music—Preserves the original sound. This
setting is good for listening to music.
• Custom—Lets you manually adjust sound
settings.
• Balance—Adjusts the balance between the
left and right audio channels.
• Advanced Audio—Opens the
Audio · Advanced Audio menu where you can
adjust additional audio options.
• Bass—Adjusts the low sounds.
• Treble—Adjusts the high sounds.
• TV Speakers—Selects where to play TV
audio. You can select On (default setting)
to play audio through TV speakers, or
select Off to play audio through the
speakers on an external audio system.
• Digital Audio/SPDIF—Sends digital audio
to an external audio system. You can select
PCM (to output audio in 2-channel stereo),
or RAW (to pass through the original
digital audio sound).
• MTS/SAP—(Analog channels only) Selects
the audio mode. You can select:
• MONO—Select this option if there is
noise or static on weak stereo
broadcasts.
• STEREO—Select this option for
programs broadcast in stereo.
• SAP—Select this option to listen to a
secondary audio program, if available.
• Audio Language—(Digital channels only)
Selects an alternate audio language, if
available.
• Reset Audio Settings—Reset all audio
settings to factory defaults.
4 Press
W or X to adjust the option, or press S or
T to select a setting.
5 Press MENU to return to the previous menu, or
press EXIT to close the menu.
OK
ENTER
MENU
EXIT
edoM erutciP Energy Saving
Brightness
48
Contrast
52
Color
68
Tint
0
Sharpness
10
Advanced Video
Reset Picture Settings
Move
Exit
Previous
Select
Adjust settings to affect picture quality.
CHANNELS
SETTINGS
PHOTOS
AUDIO
OK
ENTER
MENU
EXIT
Audio
Music
Move
Exit
Previous
Select
Sound Mode
Balance 0
Advanced Audio
Reset Audio Settings
Adjust settings to affect sound quality.
CHANNELS
SETTINGS
PHOTOS
AUDIO
Note
You can also press MTS/SAP one or
more times to select the audio mode.
OK
ENTER
MENU
EXIT
Audio
●
Advanced Audio
50
Move
Exit
Previous
Select
Bass
50
PCM
Stereo
English
Treble
Digital Audio/SPDIF
On
TV Speakers
MTS/SAP
Audio Language
Adjust settings to affect sound quality.
CHANNELS
SETTINGS
PHOTOS
AUDIO
29
Insignia 39"/42"/46" 1080p LED TV
www.insigniaproducts.com
Playing TV audio only
You can turn off the picture on your TV and listen to
the program audio only.
To play TV audio only:
1 Press MENU. The on-screen menu opens.
2 Press
W or X to highlight CHANNELS, then press
T or ENTER. The Channels menu opens.
3 Press
S or T to highlight Audio Only, then
press ENTER.
4 Press
S or T to select On.
5 Press MENU to return to the previous menu, or
press EXIT to close the menu.
Changing channel settings
Automatically scanning for channels
When you scan for channels, your TV searches for
channels with signals and stores the channel
information in the channel list. When you press
CH or CH , your TV goes to the next or
previous channel in the channel list.
If the TV signal source changes, for example you
change from an outdoor antenna to cable TV (no
box), you need to scan for channels.
To automatically scan for channels:
1 Press MENU. The on-screen menu opens.
2 Press
W or X to highlight CHANNELS, then press
T or ENTER. The Channels menu opens.
3 Press
S or T to highlight Auto Channel Search,
then press ENTER. The Channels · Auto Channel
Search screen opens.
Notes
• Audio Only works only when the input source is
TV, and your TV is receiving a broadcast signal.
• To exit audio only mode, press any button.
When you exit audio only mode, the Audio
Only option is automatically reset to Off.
OK
ENTER
MENU
EXIT
edoM erutciP Energy Saving
Brightness
48
Contrast
52
Color
68
Tint
0
Sharpness
10
Advanced Video
Reset Picture Settings
Move
Exit
Previous
Select
Adjust settings to affect picture quality.
CHANNELS
SETTINGS
PHOTOS
AUDIO
CHANNELS
SETTINGS
PHOTOS
AUDIO
OK
ENTER
MENU
EXIT
Channels
Move
Exit
Previous
Select
Play the audio with the picture on.
Off
On
Channel Strength
Audio only
Auto Zoom
Auto Channel Search
Add/Skip Channels
Favorites
OK
ENTER
MENU
EXIT
edoM erutciP Energy Saving
Brightness
48
Contrast
52
Color
68
Tint
0
Sharpness
10
Advanced Video
Reset Picture Settings
Move
Exit
Previous
Select
Adjust settings to affect picture quality.
CHANNELS
SETTINGS
PHOTOS
AUDIO
CHANNELS
SETTINGS
PHOTOS
AUDIO
OK
ENTER
MENU
EXIT
Channels
Move
Exit
Previous
Select
Automatically search for channels.
Off
On
Channel Strength
Audio only
Auto Zoom
Auto Channel Search
Add/Skip Channels
Favorites
OK
ENTER
MENU
EXIT
Choose your TV source
Antenna
Cable
Satellite Box
Select if using an antenna for standard or HD TV.
Channels
Auto Channel Search
Move
Exit
Previous
Select
CHANNELS
SETTINGS
PHOTOS
AUDIO
30
NS-39E480A13/NS-42E480A13/NS-46E481A13 Insignia 39"/42"/46" 1080p LED TV
www.insigniaproducts.com
4 Press S or T to highlight Antenna, Cable, or
Satellite Box, then press ENTER.
A If you select Antenna, your TV scans for
available channels. The scan may take
several minutes.
B If you select Cable, a message asks if you
have a cable box:
• Select No, then press ENTER if no cable
box is connected. Your TV scans for
available channels. The scan may take
several minutes.
• Select Ye s , then press ENTER if a cable box
is connected. A message asks how you
connected the cable box to your TV:
• Select AV, Component, or HDMI, then
press ENTER if you connected a cable
box to your TV using one of these
cables. Read the message, then press
ENTER to close the wizard.
• Select Coaxial, then press ENTER if you
connected a cable box to your TV using
a coaxial cable. Read the message, then
press ENTER to start the channel scan
(VHF channels only).
C If you select Satellite Box, a message asks
how you connected the satellite box to your
TV:
• Select AV, Component, or HDMI, then
press ENTER if you connected a satellite
box to your TV using one of these cables.
Read the message, then press ENTER to
close the wizard.
• Select Coaxial, then press ENTER if you
connected a satellite box to your TV using
a coaxial cable. Read the message, then
press ENTER to start the channel scan (VHF
channels only).
Hiding channels
You can hide channels in the channel list. When you
press CH or CH , your TV skips the hidden
channels. You can still tune to a hidden channel by
pressing the number buttons for the channel.
To hide channels:
1 Press MENU. The on-screen menu opens.
2 Press
W or X to highlight CHANNELS, then press
T or ENTER. The Channels menu opens.
3 Press
S or T to highlight Add/Skip Channels,
then press ENTER. The Channels · Add/Skip
Channels screen opens.
4 Press
S T W or X to highlight the channel you
want to hide, then press ENTER. The check mark
disappears.
5 Press MENU to return to the previous menu, or
press EXIT to close the menu.
Note
You can press EXIT to stop the auto channel search,
but you will need to run the auto channel search
again to create a channel list.
OK
ENTER
MENU
EXIT
edoM erutciP Energy Saving
Brightness
48
Contrast
52
Color
68
Tint
0
Sharpness
10
Advanced Video
Reset Picture Settings
Move
Exit
Previous
Select
Adjust settings to affect picture quality.
CHANNELS
SETTINGS
PHOTOS
AUDIO
Notes
• A channel with a check mark is not hidden. A
channel with no check mark is hidden.
• If the list has more than one page, press
S or T
to scroll through the pages.
OK
ENTER
MENU
EXIT
Off
On
Channels
Channel Strength
Audio Only
Auto Zoom
Auto Channel Search
Add/Skip Channels
Favorites
Manually add and skip channels in your program list.
Move
Exit
Previous
Select
CHANNELS
SETTINGS
PHOTOS
AUDIO
OK
ENTER
MENU
EXIT
Manually add and skip channels in your program list.
Channels • Add/Skip Channels
Ch 5 Analog
Digital AT05-1
AT05-2
AT05-3
AT05-4
Digital
Digital
Digital
Analog
Analog
Analog
Ch 5-1
Ch 17
Ch 7
Ch 6
Ch 5-4
Ch 5-3
Ch 5-2
Set
Exit
Previous
Select
CHANNELS
SETTINGS
PHOTOS
AUDIO
31
Insignia 39"/42"/46" 1080p LED TV
www.insigniaproducts.com
Setting up a favorite channel list
You can create a favorite channel list so you can
quickly browse through your favorite channels by
pressing FAVORITE, then selecting a channel from
the list.
To set up a favorite channel list:
1 Press MENU. The on-screen menu opens.
2 Press
W or X to highlight CHANNELS, then press
T or ENTER. The Channels menu opens.
3 Press
S or T to highlight Favorites, then press
ENTER. The Channels · Favorites screen opens.
4 Press
S T W or X to highlight the channel you
want to add to the favorites list, then press
ENTER. A check mark appears next to the
channel.
5 Press MENU to return to the previous menu, or
press EXIT to close the menu.
Viewing a favorite channel
To view a favorite channel:
1 Press FAVORITE. The favorite channel list opens.
2 Press
S or T to highlight a channel, then press
ENTER.
Checking the digital signal strength
You can check the digital signal strength to
determine if you need to adjust your antenna or
digital cable input. The higher the signal strength,
the less likely you are to experience picture
degradation.
To check the digital signal strength:
1 Press MENU. The on-screen menu opens.
2 Press
W or X to highlight CHANNELS, then press
T or ENTER. The Channels menu opens.
OK
ENTER
MENU
EXIT
edoM erutciP Energy Saving
Brightness
48
Contrast
52
Color
68
Tint
0
Sharpness
10
Advanced Video
Reset Picture Settings
Move
Exit
Previous
Select
Adjust settings to affect picture quality.
CHANNELS
SETTINGS
PHOTOS
AUDIO
OK
ENTER
MENU
EXIT
Off
On
Channels
Channel Strength
Audio Only
Auto Zoom
Auto Channel Search
Add/Skip Channels
Favorites
Add channels to create a favorites list.
Move
Exit
Previous
Select
CHANNELS
SETTINGS
PHOTOS
AUDIO
CHANNELS
SETTINGS
PHOTOS
AUDIO
OK
ENTER
MENU
EXIT
Add channels to create a favorites list.
Channels • Favorites
Ch 5 Analog
Digital AT05-1
AT05-2
AT05-3
AT05-4
Digital
Digital
Digital
Analog
Analog
Analog
Ch 5-1
Ch 17
Ch 7
Ch 6
Ch 5-4
Ch 5-3
Ch 5-2
Set
Exit
Previous
Select
Notes
• To remove a channel from the favorites list,
highlight the channel, then press ENTER. The
check mark disappears and the channel is
removed from the list.
• If the list has more than one page, press
S or T
to scroll through the pages.
OK
ENTER
MENU
EXIT
edoM erutciP Energy Saving
Brightness
48
Contrast
52
Color
68
Tint
0
Sharpness
10
Advanced Video
Reset Picture Settings
Move
Exit
Previous
Select
Adjust settings to affect picture quality.
CHANNELS
SETTINGS
PHOTOS
AUDIO
OK
ENTER
MENU
EXIT
Off
On
Channels
Channel Strength
Audio Only
Auto Zoom
Auto Channel Search
Add/Skip Channels
Favorites
Display signal strength of selected digital channels.
Move
Exit
Previous
Select
CHANNELS
SETTINGS
PHOTOS
AUDIO
32
NS-39E480A13/NS-42E480A13/NS-46E481A13 Insignia 39"/42"/46" 1080p LED TV
www.insigniaproducts.com
3 Press S or T to highlight Channel Strength,
then press ENTER. The signal strength meter is
displayed.
4 Press MENU to return to the previous menu, or
press EXIT to close the menu.
Setting parental controls
Setting or changing the password
Parental controls let you prevent your children from
watching inappropriate material on TV. When set,
parental controls read the rating of the program
(with some exceptions, such as news and sports)
and deny access to programs that exceed the
ratings level you select. To watch programs that
exceed the selected rating, you must enter a
password.
To set or change the password:
1 Press MENU. The on-screen menu opens.
2 Press
W or X to highlight SETTINGS, then press
T or ENTER. The Settings menu opens with
Parental Controls highlighted.
3 Press ENTER. The Enter Password screen opens.
4 Press the number buttons to enter the four-digit
password. The default password is 0000. You
should change the password to a number you
can remember. The Settings-Parental Controls
menu opens.
5 Press
S or T to highlight Change Password,
then press ENTER. The Settings · Parental
Controls · Change Password screen opens.
6 Press the number buttons to enter a password,
then enter the password again.
7 Press MENU to return to the previous menu, or
press EXIT to close the menu.
Channel Strength
Now 67
%
0
100
5-2AT05-2
Peak 67%
OK
ENTER
MENU
EXIT
edoM erutciP Energy Saving
Brightness
48
Contrast
52
Color
68
Tint
0
Sharpness
10
Advanced Video
Reset Picture Settings
Move
Exit
Previous
Select
Adjust settings to affect picture quality.
CHANNELS
SETTINGS
PHOTOS
AUDIO
OK
ENTER
MENU
EXIT
English
Settings
Menu Language
Input Labels
INLink
Computer Settings
Component Settings
Parental Controls
Closed Caption
Time
Set TV parental controls.
Move
Exit
Previous
Select
CHANNELS
SETTINGS
PHOTOS
AUDIO
Note
If you forget your password, enter 9999.
OK
ENTER
MENU
EXIT
English
Settings
Menu Language
Enter Password
Input Labels
INLink
Computer Settings
Component Settings
Parental Controls
Closed Caption
Time
Enter your 4-digit password. Default is 0000, Please change your password.
Move
Exit
Previous
Select
CHANNELS
SETTINGS
PHOTOS
AUDIO
OK
ENTER
MENU
EXIT
Off
Off
Settings Parental
Canadian Parental Locks
Change Password
RRT5
Reset RRT5
Button Lock
Block Unrated TV
USA Parental Locks
Enter a new 4-digit password then re-enter it for confirmation.
Move
Exit
Previous
Select
CHANNELS
SETTINGS
PHOTOS
AUDIO
OK
ENTER
MENU
EXIT
Off
Off
Settings • Parental
Canadain Parental Locks
Enter new password
Change Password
RRT5
Reset RRT5
Button Lock
Block Unrated TV
USA Parental Locks
Enter a new 4-digit password then re-enter it for confirmation.
Move
Exit
Previous
Select
CHANNELS
SETTINGS
PHOTOS
AUDIO
Confirm new password
33
Insignia 39"/42"/46" 1080p LED TV
www.insigniaproducts.com
Locking control buttons
When the button lock is turned On, the buttons on
the side of your TV are locked, and you can only
operate your TV using the remote control.
To lock control buttons:
1 Press MENU. The on-screen menu opens.
2 Press
W or X to highlight SETTINGS, then press
T or ENTER. The Settings menu opens with
Parental Controls highlighted.
3 Press ENTER. The Enter Password screen opens.
4 Press the number buttons to enter the four-digit
password. The Settings · Parental Controls menu
opens with Button Lock highlighted.
5 Press ENTER.
6 Press
S or T to select On (locks the buttons) or
Off (unlocks the buttons).
7 Press MENU to return to the previous menu, or
press EXIT to close the menu.
Blocking unrated TV
To block unrated TV:
1 Press MENU. The on-screen menu opens.
2 Press
W or X to highlight SETTINGS, then press
T or ENTER. The Settings menu opens with
Parental Controls highlighted.
OK
ENTER
MENU
EXIT
edoM erutciP Energy Saving
Brightness
48
Contrast
52
Color
68
Tint
0
Sharpness
10
Advanced Video
Reset Picture Settings
Move
Exit
Previous
Select
Adjust settings to affect picture quality.
CHANNELS
SETTINGS
PHOTOS
AUDIO
OK
ENTER
MENU
EXIT
English
Settings
Menu Language
Input Labels
INLink
Computer Settings
Component Settings
Parental Controls
Closed Caption
Time
Set TV parental controls.
Move
Exit
Previous
Select
CHANNELS
SETTINGS
PHOTOS
AUDIO
OK
ENTER
MENU
EXIT
English
Settings
Menu Language
Enter Password
Input Labels
INLink
Computer Settings
Component Settings
Parental Controls
Closed Caption
Time
Enter your 4-digit password. Default is 0000, Please change your password.
Move
Exit
Previous
Select
CHANNELS
SETTINGS
PHOTOS
AUDIO
OK
ENTER
MENU
EXIT
Off
Off
Settings Parental
Canadian Parental Locks
Change Password
RRT5
Reset RRT5
Button Lock
Block Unrated TV
USA Parental Locks
Do not lock the buttons on the TV .
Move
Exit
Previous
Select
Off
On
CHANNELS
SETTINGS
PHOTOS
AUDIO
OK
ENTER
MENU
EXIT
edoM erutciP Energy Saving
Brightness
48
Contrast
52
Color
68
Tint
0
Sharpness
10
Advanced Video
Reset Picture Settings
Move
Exit
Previous
Select
Adjust settings to affect picture quality.
CHANNELS
SETTINGS
PHOTOS
AUDIO
OK
ENTER
MENU
EXIT
English
Settings
Menu Language
Input Labels
INLink
Computer Settings
Component Settings
Parental Controls
Closed Caption
Time
Set TV parental controls.
Move
Exit
Previous
Select
CHANNELS
SETTINGS
PHOTOS
AUDIO
34
NS-39E480A13/NS-42E480A13/NS-46E481A13 Insignia 39"/42"/46" 1080p LED TV
www.insigniaproducts.com
3 Press ENTER. The Enter Password screen opens.
4 Press the number buttons to enter the four-digit
password. The Settings · Parental Controls menu
opens.
5 Press
S or T to highlight Block Unrated TV,
then press ENTER.
6 Press
S or T to select On (to block unrated TV)
or Off (to unblock unrated TV).
7 Press MENU to return to the previous menu, or
press EXIT to close the menu.
Setting parental control levels
You can set parental controls for the U.S. and
Canada.
U.S. rating levels
Some of the age-based TV Parental Guidelines
ratings also have content-based ratings.
Canadian rating levels
OK
ENTER
MENU
EXIT
English
Settings
Menu Language
Enter Password
Input Labels
INLink
Computer Settings
Component Settings
Parental Controls
Closed Caption
Time
Enter your 4-digit password. Default is 0000, Please change your password.
Move
Exit
Previous
Select
CHANNELS
SETTINGS
PHOTOS
AUDIO
OK
ENTER
MENU
EXIT
Off
Off
Settings Parental
Canadian Parental Locks
Change Password
RRT5
Reset RRT5
Button Lock
Block Unrated TV
USA Parental Locks
Do not block TV programs that do not have a rating .
Move
Exit
Previous
Select
Off
On
CHANNELS
SETTINGS
PHOTOS
AUDIO
U.S. TV ratings
NONE Not rated
TV-Y All children
TV-Y7 Suitable for children 7 and older
TV-G General audiences
TV-PG Parental guidance suggested
TV-14 Parental guidance strongly suggested
TV-MA Mature audiences only
U.S. TV content ratings
All All ratings are blocked
FV Fantasy violence
LStrong language
S Sexual situations
VViolence
D Suggestive dialog
U.S. movie (MPAA) ratings
None Movie not rated
G General audiences
PG Parental guidance suggested
PG-13 Suitable for children 13 and older
R Parental guidance suggested for
children under 17
NC-17 Not suitable for children under 17
X Adults only
Canadian English ratings
EExempt programming
C Suitable for all children
C8+ Suitable for children 8 and older
G General audiences
PG Parental guidance suggested
14+ Suitable for children 14 and older
18+ Adult only
Canadian French ratings
EExempt programming
G General audiences
8ans+ Suitable for children 8 and older
13ans+ Suitable for children 13 and older
16ans+ Suitable for children 16 and older
18ans+ Adult only
35
Insignia 39"/42"/46" 1080p LED TV
www.insigniaproducts.com
To set parental control levels:
1 Press MENU. The on-screen menu opens.
2 Press
W or X to highlight SETTINGS, then press
T or ENTER. The Settings menu opens with
Parental Controls highlighted.
3 Press ENTER. The Enter Password screen opens.
4 Press the number buttons to enter the four-digit
password. The Settings · Parental Controls menu
opens.
5 Press
S or T to highlight USA Parental Locks,
then press ENTER. (To set Canadian ratings,
select Canadian Parental Locks.)
USA Parental Locks
Canadian Parental Locks
6 Press
W or X to highlight:
• Movie Ratings or TV Ratings for USA ratings.
• Canadian English or Canadian French for
Canadian ratings.
7 Press
S or T to select the rating. If a rating has
sub-ratings, press W or X to highlight a
sub-rating.
8 Press ENTER to confirm. A lock symbol appears
when a rating is blocked.
9 Press MENU to return to the previous menu, or
press EXIT to close the menu.
OK
ENTER
MENU
EXIT
edoM erutciP Energy Saving
Brightness
48
Contrast
52
Color
68
Tint
0
Sharpness
10
Advanced Video
Reset Picture Settings
Move
Exit
Previous
Select
Adjust settings to affect picture quality.
CHANNELS
SETTINGS
PHOTOS
AUDIO
OK
ENTER
MENU
EXIT
English
Settings
Menu Language
Input Labels
INLink
Computer Settings
Component Settings
Parental Controls
Closed Caption
Time
Set TV parental controls.
Move
Exit
Previous
Select
CHANNELS
SETTINGS
PHOTOS
AUDIO
OK
ENTER
MENU
EXIT
English
Settings
Menu Language
Enter Password
Input Labels
INLink
Computer Settings
Component Settings
Parental Controls
Closed Caption
Time
Enter your 4-digit password. Default is 0000, Please change your password.
Move
Exit
Previous
Select
CHANNELS
SETTINGS
PHOTOS
AUDIO
OK
ENTER
MENU
EXIT
Off
Off
Settings Parental
Canadian Parental Locks
Change Password
Button Lock
Block Unrated TV
USA Parental Locks
Restrict movie and TV programs by US Ratings.
Move
Exit
Previous
Select
RRT5
Reset RRT5
CHANNELS
SETTINGS
PHOTOS
AUDIO
Note
When you block a rating, that rating and all higher
ratings are blocked.
OK
ENTER
MENU
EXIT
Settings Parental USA Parental Locks
Restrict movie and TV programs by US Ratings.
Move
Exit
Previous
Select
USA
Parental
Locks
Movie Ratings
TV Ratings
None
G
PG
PG-13
R
NC-17
X
None
TV-Y
TV-Y7
TV-G
TV-PG
TV14
TV-MA
All D L S V FV
CHANNELS
SETTINGS
PHOTOS
AUDIO
OK
ENTER
MENU
EXIT
Settings Parental Canadian Ratings
Restrict movie and TV programs by Canadian Ratings.
Move
Exit
Previous
Select
Canadian
Parental
Locks
Canadian English Canadian French
E
C
C8+
G
PG
14+
18+
E
G
8 ans+
13 ans+
16 ans+
18 ans+
CHANNELS
SETTINGS
PHOTOS
AUDIO
36
NS-39E480A13/NS-42E480A13/NS-46E481A13 Insignia 39"/42"/46" 1080p LED TV
www.insigniaproducts.com
Downloading rating information
You can download rating information to use when
setting parental controls.
To download rating information:
1 Press MENU. The on-screen menu opens.
2 Press
W or X to highlight SETTINGS, then press
T or ENTER. The Settings menu opens with
Parental Controls highlighted.
3 Press ENTER. The Enter Password screen opens.
4 Press the number buttons to enter the four-digit
password. The Settings · Parental Controls menu
opens.
5 Press
S or T to highlight RRT5, then press
ENTER.
If the program is broadcast with RRT5 rating
information, the information is downloaded
automatically and can be used for parental
controls.
6 To reset the RRT5 information to the factory
default, press
S or T to highlight Reset RRT5,
then press ENTER. A box opens. Follow the
on-screen instructions.
7 Press MENU to return to the previous menu, or
press EXIT to close the menu.
Using closed captioning
Turning closed captioning on or off
To turn closed captioning on or off:
1 Press MENU. The on-screen menu opens.
2 Press
W or X to highlight SETTINGS, then press
T or ENTER. The Settings menu opens.
OK
ENTER
MENU
EXIT
edoM erutciP Energy Saving
Brightness
48
Contrast
52
Color
68
Tint
0
Sharpness
10
Advanced Video
Reset Picture Settings
Move
Exit
Previous
Select
Adjust settings to affect picture quality.
CHANNELS
SETTINGS
PHOTOS
AUDIO
OK
ENTER
MENU
EXIT
English
Settings
Menu Language
Input Labels
INLink
Computer Settings
Component Settings
Parental Controls
Closed Caption
Time
Set TV parental controls.
Move
Exit
Previous
Select
CHANNELS
SETTINGS
PHOTOS
AUDIO
OK
ENTER
MENU
EXIT
English
Settings
Menu Language
Enter Password
Input Labels
INLink
Computer Settings
Component Settings
Parental Controls
Closed Caption
Time
Enter your 4-digit password. Default is 0000, Please change your password.
Move
Exit
Previous
Select
CHANNELS
SETTINGS
PHOTOS
AUDIO
OK
ENTER
MENU
EXIT
Off
Off
Settings Parental
Canadian Parental Locks
Change Password
RRT5
Reset RRT5
Button Lock
Block Unrated TV
USA Parental Locks
Display an advanced V-Chip ratings table for digital channels.
Move
Exit
Previous
Select
CHANNELS
SETTINGS
PHOTOS
AUDIO
OK
ENTER
MENU
EXIT
edoM erutciP Energy Saving
Brightness
48
Contrast
52
Color
68
Tint
0
Sharpness
10
Advanced Video
Reset Picture Settings
Move
Exit
Previous
Select
Adjust settings to affect picture quality.
CHANNELS
SETTINGS
PHOTOS
AUDIO
OK
ENTER
MENU
EXIT
English
Settings
Menu Language
Input Labels
INLink
Computer Settings
Component Settings
Parental Controls
Closed Captioning
Time
Set TV parental controls.
Move
Exit
Previous
Select
CHANNELS
SETTINGS
PHOTOS
AUDIO
37
Insignia 39"/42"/46" 1080p LED TV
www.insigniaproducts.com
3 Press S or T to highlight Closed Captioning,
then press ENTER. The Settings · Closed Caption
menu opens.
4 Press
S or T to highlight Caption Control, then
press ENTER. A menu opens.
5 Press
S or T to select CC Off (turns off closed
captioning), CC On (turns on closed captioning),
or CC on Mute (turns on closed captioning
when the sound is muted).
6 Press MENU to return to the previous menu, or
press EXIT to close the menu.
Selecting the analog closed captioning mode
To select the analog closed captioning mode:
1 Press MENU. The on-screen menu opens.
2 Press
W or X to highlight SETTINGS, then press
T or ENTER. The Settings menu opens.
3 Press
S or T to highlight Closed Captioning,
then press ENTER. The Settings · Closed Caption
menu opens.
4 Press
S or T to highlight Analog Caption, then
press ENTER. A menu opens.
5 Press
S or T to select an analog caption setting.
You can select:
• CC1 through CC4—Closed captioning
appears in a small banner across the bottom
of the screen. CC1 is usually the “printed”
version of the audio. CC2 through CC4 display
content provided by the broadcaster.
• Text1 through Text4—Closed captioning
covers half or all of the screen. Tex t 1 through
Text4 display content provided by the
broadcaster.
6 Press MENU to return to the previous menu, or
press EXIT to close the menu.
Customizing digital closed captioning styles
To customize digital closed captioning styles:
1 Press MENU. The on-screen menu opens.
2 Press
W or X to highlight SETTINGS, then press
T or ENTER. The Settings menu opens.
Note
You can also press CCD to turn closed captioning on
or off.
OK
ENTER
MENU
EXIT
Digital CC Settings
Caption Control CC Off
Analog Caption CC1
Digital Caption CS1
Turn Closed Captioning off.
Move
Exit
Previous
Select
Settings Closed Captioning
CHANNELS
SETTINGS
PHOTOS
AUDIO
OK
ENTER
MENU
EXIT
edoM erutciP Energy Saving
Brightness
48
Contrast
52
Color
68
Tint
0
Sharpness
10
Advanced Video
Reset Picture Settings
Move
Exit
Previous
Select
Adjust settings to affect picture quality.
CHANNELS
SETTINGS
PHOTOS
AUDIO
OK
ENTER
MENU
EXIT
English
Settings
Menu Language
Input Labels
INLink
Computer Settings
Component Settings
Parental Controls
Closed Captioning
Time
Set TV parental controls.
Move
Exit
Previous
Select
CHANNELS
SETTINGS
PHOTOS
AUDIO
OK
ENTER
MENU
EXIT
Digital CC Settings
Caption Control
CC Off
Analog Caption CC1
Digital Caption CS1
Set Closed Caption for standard (analog) programs.
Move
Exit
Previous
Select
Settings Closed Captioning
CHANNELS
SETTINGS
PHOTOS
AUDIO
OK
ENTER
MENU
EXIT
edoM erutciP Energy Saving
Brightness
48
Contrast
52
Color
68
Tint
0
Sharpness
10
Advanced Video
Reset Picture Settings
Move
Exit
Previous
Select
Adjust settings to affect picture quality.
CHANNELS
SETTINGS
PHOTOS
AUDIO
OK
ENTER
MENU
EXIT
English
Settings
Menu Language
Input Labels
INLink
Computer Settings
Component Settings
Parental Controls
Closed Captioning
Time
Set TV parental controls.
Move
Exit
Previous
Select
CHANNELS
SETTINGS
PHOTOS
AUDIO
38
NS-39E480A13/NS-42E480A13/NS-46E481A13 Insignia 39"/42"/46" 1080p LED TV
www.insigniaproducts.com
3 Press S or T to highlight Closed Captioning,
then press ENTER. The Settings · Closed Caption
menu opens.
4 Press
S or T to highlight Digital Caption, then
press ENTER. A menu opens.
5 Press
S or T to highlight a digital caption
setting, then press ENTER. You can select CS1
through CS6 or CC1 through CC4.
6 Press MENU to return to the previous menu.
7 Press
S or T to highlight Digital CC Settings,
then press ENTER. The Settings · Closed
Caption · Digital CC Settings menu opens with
Style highlighted.
8 Press ENTER, then press
W or X to select
Custom.
9 Press
S or T to highlight an option, then press
ENTER. You can select:
• Size—Selects the font size.
• Font—Selects the font style.
• Text Color—Selects the color for the words.
• Text Opacity—Selects the opacity level for
the words.
• Background Color—Selects the color for the
background.
• Background Opacity—Selects the opacity
level for the background.
• Window Color—Selects the color of the
window edge.
• Window Opacity—Selects the transparency
of the window edge.
10 Press MENU to return to the previous menu, or
press EXIT to close the menu.
Adjusting time settings
Setting the clock
To set the clock:
1 Press MENU. The on-screen menu opens.
2 Press
W or X to highlight SETTINGS, then press
T or ENTER. The Settings menu opens.
3 Press
S or T to highlight Time, then press
ENTER. The Settings · Time menu opens.
OK
ENTER
MENU
EXIT
Digital CC Settings
Caption Control
CC Off
Analog Caption CC1
Digital Caption CS1
Set Closed Caption for standard (digital) programs.
Move
Exit
Previous
Select
Settings Closed Caption
CHANNELS
SETTINGS
PHOTOS
AUDIO
OK
ENTER
MENU
EXIT
Style Custom
Size
Window Color Black
Large
Font
Text Color White
Text Opacity Solid
Background Color Black
Background Opacity Solid
Default
Set the look of digital CC. Automatic uses broadcaster’s style.
Move
Exit
Previous
Select
Settings Closed Caption Digital CC Settings
CHANNELS
SETTINGS
PHOTOS
AUDIO
OK
ENTER
MENU
EXIT
edoM erutciP Energy Saving
Brightness
48
Contrast
52
Color
68
Tint
0
Sharpness
10
Advanced Video
Reset Picture Settings
Move
Exit
Previous
Select
Adjust settings to affect picture quality.
CHANNELS
SETTINGS
PHOTOS
AUDIO
OK
ENTER
MENU
EXIT
English
Settings
Menu Language
Input Labels
INLink
Computer Settings
Component Settings
Parental Controls
Closed Caption
Time
Set Date/Time and Sleep Timer.
Move
Exit
Previous
Select
CHANNELS
SETTINGS
PHOTOS
AUDIO
OK
ENTER
MENU
EXIT
Date/Time
Sleep Timer Off
Adjust the date and time to get the correct program times.
Move
Exit
Previous
Select
Settings Time
CHANNELS
SETTINGS
PHOTOS
AUDIO
39
Insignia 39"/42"/46" 1080p LED TV
www.insigniaproducts.com
4 Press S or T to highlight Date/Time, then press
ENTER. The Settings · Time · Date/Time menu
opens.
5 Press
S or T to highlight Mode, then press
ENTER. A menu opens.
6 Press
S or T to highlight Manual (to set the
options manually) or Auto (the options are
automatically set by the TV signal source).
7 Press ENTER to close the menu.
8 Press
S or T to highlight Time Zone, then press
ENTER. The Time · Time Zone menu opens.
9 Press
S or T to select your time zone, then press
ENTER. You can select Eastern, Central,
Mountain, Pacific, Alaska, Hawaii, Atlantic, or
Newfoundland.
10 Press ENTER to close the menu.
11 If your viewing area observes daylight savings
time, press
S or T to highlight Daylight
Savings, then press ENTER.
12 Press
S or T to select On or Off, then press
ENTER to close the menu.
13 If you selected Manual for Mode:
• Press
S or T to highlight Year, Month, or Day,
press W or X to adjust the setting, then press
ENTER.
• Press
S or T to highlight Time, press W or X to
highlight the hour, minute, or AM/PM field,
then press S or T to adjust the setting. When
you are finished, press ENTER.
14 Press MENU to return to the previous menu, or
press EXIT to close the menu.
Setting the sleep timer
You can specify the amount of time before your TV
automatically turns off.
To set the sleep timer:
1 Press MENU. The on-screen menu opens.
2 Press
W or X to highlight SETTINGS, then press
T or ENTER. The Settings menu opens.
3 Press
S or T to highlight Time, then press
ENTER. The Settings · Time menu opens.
4 Press
S or T to highlight Sleep Timer, then
press ENTER. A menu opens.
5 Press
S or T to select the amount of time before
your TV turns off automatically. You can select
Off, 5, 10, 15, 30, 60, 90, 120, 180, or 240
minutes.
To turn off the sleep timer, select Off.
6 Press MENU to return to the previous menu, or
press EXIT to close the menu.
OK
ENTER
MENU
EXIT
Mode Auto
Time Zone
Daylight Savings Off
Year 2004
Month June
Day 30
Time 07 : 11 PM
Pacific
If Automatic, options are automatically set by TV source.
Move
Exit
Previous
Select
Settings Time Date/Time
CHANNELS
SETTINGS
PHOTOS
AUDIO
Note
You can also press SLEEP to set the sleep timer.
OK
ENTER
MENU
EXIT
edoM erutciP Energy Saving
Brightness
48
Contrast
52
Color
68
Tint
0
Sharpness
10
Advanced Video
Reset Picture Settings
Move
Exit
Previous
Select
Adjust settings to affect picture quality.
CHANNELS
SETTINGS
PHOTOS
AUDIO
OK
ENTER
MENU
EXIT
English
Settings
Menu Language
Input Labels
INLink
Computer Settings
Component Settings
Parental Controls
Closed Caption
Time
Set Date/Time and Sleep Timer.
Move
Exit
Previous
Select
CHANNELS
SETTINGS
PHOTOS
AUDIO
OK
ENTER
MENU
EXIT
Date/Time
Sleep Timer Off
Set a time for the TV to turn off automatically.
Move
Exit
Previous
Select
Settings Time
CHANNELS
SETTINGS
PHOTOS
AUDIO
40
NS-39E480A13/NS-42E480A13/NS-46E481A13 Insignia 39"/42"/46" 1080p LED TV
www.insigniaproducts.com
Adjusting menu settings
Selecting the menu language
To select the menu language:
1 Press MENU. The on-screen menu opens.
2 Press
W or X to highlight SETTINGS, then press
T or ENTER. The Settings menu opens.
p
3 Press S or T to highlight Menu Language, then
press ENTER. A menu opens.
4 Press
S or T to highlight a language, then press
ENTER. You can select English, Français, or
Español.
5 Press MENU to return to the previous menu, or
press EXIT to close the menu.
Labeling an input source
You can add a label to an input source to make it
easier to identify.
To label an input source:
1 Press MENU. The on-screen menu opens.
2 Press
W or X to highlight SETTINGS, then press
T or ENTER. The Settings menu opens.
3 Press
S or T to highlight Input Labels, then
press ENTER. The Settings · Input Labels screen
opens with the input source field highlighted.
4 Press
S or T to select the input source you want
to label, then press
X to move to the custom
label field.
5 Press
S or T to select the label you want. You
can select Blu-ray, DVD, VCR, Cable box,
Satellite, DVR/PVR, Set top box, Receiver, PC,
Game, Camcorder, or USB.
6 When you have completed the label, press
MENU. The next time you press INPUT, your
label will appear in the Input source list.
7 Press EXIT to close the menu.
OK
ENTER
MENU
EXIT
edoM erutciP Energy Saving
Brightness
48
Contrast
52
Color
68
Tint
0
Sharpness
10
Advanced Video
Reset Picture Settings
Move
Exit
Previous
Select
Adjust settings to affect picture quality.
CHANNELS
SETTINGS
PHOTOS
AUDIO
OK
ENTER
MENU
EXIT
English
Settings
Menu Language
Input Labels
INLink
Computer Settings
Component Settings
Parental Controls
Closed Caption
Time
Set menu language to English, Francais, or Spanish.
Move
Exit
Previous
Select
CHANNELS
SETTINGS
PHOTOS
AUDIO
OK
ENTER
MENU
EXIT
edoM erutciP Energy Saving
Brightness
48
Contrast
52
Color
68
Tint
0
Sharpness
10
Advanced Video
Reset Picture Settings
Move
Exit
Previous
Select
Adjust settings to affect picture quality.
CHANNELS
SETTINGS
PHOTOS
AUDIO
OK
ENTER
MENU
EXIT
English
Settings
Menu Language
Input Labels
INLink
Computer Settings
Component Settings
Parental Controls
Closed Caption
Time
Create labels for the devices connected to your TV.
Move
Exit
Previous
Select
CHANNELS
SETTINGS
PHOTOS
AUDIO
OK
ENTER
MENU
EXIT
Move
Exit
Previous
Select
Settings
TV
Input Labels
Create labels for the devices connected to your TV.
Custom
CHANNELS
SETTINGS
PHOTOS
AUDIO
OK
ENTER
MENU
EXIT
Move
Exit
Previous
Select
Settings
TV
Input Labels
Create labels for the devices connected to your TV.
Custom
CHANNELS
SETTINGS
PHOTOS
AUDIO
41
Insignia 39"/42"/46" 1080p LED TV
www.insigniaproducts.com
Restoring settings to the defaults
When you restore default settings, all the settings
you have customized (except the password and
parental rating) are reset.
To restore settings to the defaults:
1 Press MENU. The on-screen menu opens.
2 Press
W or X to highlight SETTINGS, then press
T or ENTER. The Settings menu opens.
3 Press
S or T to highlight Reset to Default, then
press ENTER. A confirmation message opens.
4 Press
W or X to select Ye s (to reset) or No (to not
reset), then press ENTER.
5 Press MENU to return to the previous menu, or
press EXIT to close the menu.
Using INlink
INlink lets you control HDMI CEC-compatible
devices connected to the HDMI jacks on your TV
using the remote control that came with your TV. To
use INlink, you must set the INlink Control setting
on the Settings-INlink menu to On.
Turning INlink on or off
To turn INlink on or off:
1 Press MENU. The on-screen menu opens.
2 Press
W or X to highlight SETTINGS, then press
T or ENTER. The Settings menu opens.
3 Press
S or T to highlight INlink, then press
ENTER. The Settings · INlink menu opens.
4 Press
S or T to highlight INlink Control, then
press ENTER.
5 Press
S or T to highlight On or Off, then press
ENTER.
6 Press MENU to return to the previous menu, or
press EXIT to close the menu.
Note
• HDMI cables must be used to connect HDMI
CEC-compatible devices to your TV.
• The connected device’s HDMI CEC feature must
be turned on.
• If you connect an HDMI device that is not HDMI
CEC-compatible, all the INlink Control features
do not work.
• Depending on the connected HDMI device, the
INlink Control feature may not work.
OK
ENTER
MENU
EXIT
edoM erutciP Energy Saving
Brightness
48
Contrast
52
Color
68
Tint
0
Sharpness
10
Advanced Video
Reset Picture Settings
Move
Exit
Previous
Select
Adjust settings to affect picture quality.
CHANNELS
SETTINGS
PHOTOS
AUDIO
OK
ENTER
MENU
EXIT
System Info
Reset to Default
Change power on options or reset TV to factory default.
Move
Exit
Previous
Select
Settings
CHANNELS
SETTINGS
PHOTOS
AUDIO
OK
ENTER
MENU
EXIT
edoM erutciP Energy Saving
Brightness
48
Contrast
52
Color
68
Tint
0
Sharpness
10
Advanced Video
Reset Picture Settings
Move
Exit
Previous
Select
Adjust settings to affect picture quality.
CHANNELS
SETTINGS
PHOTOS
AUDIO
OK
ENTER
MENU
EXIT
English
Settings
Menu Language
Input Labels
INlink
Computer Settings
Component Settings
Parental Controls
Closed Caption
Time
Allow the TV to automatically control CEC devices connected to the TV via HDMI.
Move
Exit
Previous
Select
CHANNELS
SETTINGS
PHOTOS
AUDIO
OK
ENTER
MENU
EXIT
INlink Control
On
Device Auto Power Off
On
TV Auto Power On
Audio Receiver Off
Root Menu
INlink Device Lists
On
Allow the TV to automatically control CEC devices connected to the TV via HDMI.
Move
Exit
Previous
Select
Settings INlink
CHANNELS
SETTINGS
PHOTOS
AUDIO
42
NS-39E480A13/NS-42E480A13/NS-46E481A13 Insignia 39"/42"/46" 1080p LED TV
www.insigniaproducts.com
Turning Device Auto Power Off on or off
When INlink is turned on, Device Auto Power Off
turns off HDMI CEC devices when you turn off
your TV.
To turn Device Auto Power Off on or off:
1 Press MENU. The on-screen menu opens.
2 Press
W or X to highlight SETTINGS, then press
T or ENTER. The Settings menu opens.
3 Press
S or T to highlight INlink, then press
ENTER. The Settings · INlink menu opens.
4 Press
S or T to highlight Device Auto Power
Off, then press ENTER.
5 Press
S or T to highlight On (turns off the
connected devices when you turn off your TV)
or Off (does not turn off the connected devices
when you turn off your TV), then press ENTER.
6 Press MENU to return to the previous menu, or
press EXIT to close the menu.
Turning TV Auto Power On on or off
When INlink is turned on and you turn on an HDMI
CEC device, TV Auto Power On turns on your TV
automatically.
To turn TV Auto Power On on or off:
1 Press MENU. The on-screen menu opens.
2 Press
W or X to highlight SETTINGS, then press
T or ENTER. The Settings menu opens.
3 Press
S or T to highlight INlink, then press
ENTER. The Settings · INlink menu opens.
4 Press
S or T to highlight TV Auto Power On,
then press ENTER.
5 Press
S or T to highlight On (turns on your TV
when you turn on the connected device) or Off
(does not turn on your TV when you turn on the
connected device), then press ENTER.
6 Press MENU to return to the previous menu, or
press EXIT to close the menu.
OK
ENTER
MENU
EXIT
edoM erutciP Energy Saving
Brightness
48
Contrast
52
Color
68
Tint
0
Sharpness
10
Advanced Video
Reset Picture Settings
Move
Exit
Previous
Select
Adjust settings to affect picture quality.
CHANNELS
SETTINGS
PHOTOS
AUDIO
OK
ENTER
MENU
EXIT
English
Settings
Menu Language
Input Labels
INlink
Computer Settings
Component Settings
Parental Controls
Closed Caption
Time
Allow the TV to automatically control CEC devices connected to the TV via HDMI.
Move
Exit
Previous
Select
CHANNELS
SETTINGS
PHOTOS
AUDIO
OK
ENTER
MENU
EXIT
INlink Control
On
Device Auto Power Off
On
TV Auto Power On
Audio Receiver Off
Root Menu
INlink Device Lists
On
Automatically turn off HDMI CEC devices when the TV is turned off and INLink is set to On.
Move
Exit
Previous
Select
Settings INlink
CHANNELS
SETTINGS
PHOTOS
AUDIO
OK
ENTER
MENU
EXIT
edoM erutciP Energy Saving
Brightness
48
Contrast
52
Color
68
Tint
0
Sharpness
10
Advanced Video
Reset Picture Settings
Move
Exit
Previous
Select
Adjust settings to affect picture quality.
CHANNELS
SETTINGS
PHOTOS
AUDIO
OK
ENTER
MENU
EXIT
English
Settings
Menu Language
Input Labels
INlink
Computer Settings
Component Settings
Parental Controls
Closed Caption
Time
Allow the TV to automatically control CEC devices connected to the TV via HDMI.
Move
Exit
Previous
Select
CHANNELS
SETTINGS
PHOTOS
AUDIO
OK
ENTER
MENU
EXIT
INlink Control
On
Device Auto Power Off
On
TV Auto Power On
Audio Receiver Off
Root Menu
INlink Device Lists
On
Automatically turn on the TV when an HDMI CEC device is used.
Move
Exit
Previous
Select
Settings INlink
CHANNELS
SETTINGS
PHOTOS
AUDIO
43
Insignia 39"/42"/46" 1080p LED TV
www.insigniaproducts.com
Turning Audio Receiver on or off
When INlink is turned on and you have connected
an audio receiver to your TV, turning on Audio
Receiver lets you use your TV’s remote control to
control the volume on the audio receiver.
To turn Audio Receiver on or off:
1 Press MENU. The on-screen menu opens.
2 Press
W or X to highlight SETTINGS, then press
T or ENTER. The Settings menu opens.
3 Press
S or T to highlight INlink, then press
ENTER. The Settings · INlink menu opens.
4 Press
S or T to highlight Audio Receiver, then
press ENTER.
5 Press
S or T to highlight On (your TV’s remote
control controls the connected audio receiver’s
volume) or Off (your TV’s remote control does
not control the connected audio receiver’s
volume), then press ENTER.
6 Press MENU to return to the previous menu, or
press EXIT to close the menu.
Opening an INlink-compatible device’s root
menu
You can open an INlink-compatible device’s root
menu, then use your TV’s remote control to control
the device.
To open an INlink-compatible device’s root
menu:
1 Press MENU. The on-screen menu opens.
2 Press
W or X to highlight SETTINGS, then press
T or ENTER. The Settings menu opens.
3 Press
S or T to highlight INlink, then press
ENTER. The Settings · INlink menu opens.
4 Press
S or T to highlight Root Menu, then press
ENTER. The device’s root menu opens, and you
can use your TV’s remote control to control the
device.
OK
ENTER
MENU
EXIT
edoM erutciP Energy Saving
Brightness
48
Contrast
52
Color
68
Tint
0
Sharpness
10
Advanced Video
Reset Picture Settings
Move
Exit
Previous
Select
Adjust settings to affect picture quality.
CHANNELS
SETTINGS
PHOTOS
AUDIO
OK
ENTER
MENU
EXIT
English
Settings
Menu Language
Input Labels
INlink
Computer Settings
Component Settings
Parental Controls
Closed Caption
Time
Allow the TV to automatically control CEC devices connected to the TV via HDMI.
Move
Exit
Previous
Select
CHANNELS
SETTINGS
PHOTOS
AUDIO
OK
ENTER
MENU
EXIT
INlink Control
On
Device Auto Power Off
On
TV Auto Power On
Audio Receiver Off
Root Menu
INlink Device Lists
On
Receiver’s volume can be controlled by TV’s remote control.
Move
Exit
Previous
Select
Settings INlink
CHANNELS
SETTINGS
PHOTOS
AUDIO
OK
ENTER
MENU
EXIT
edoM erutciP Energy Saving
Brightness
48
Contrast
52
Color
68
Tint
0
Sharpness
10
Advanced Video
Reset Picture Settings
Move
Exit
Previous
Select
Adjust settings to affect picture quality.
CHANNELS
SETTINGS
PHOTOS
AUDIO
OK
ENTER
MENU
EXIT
English
Settings
Menu Language
Input Labels
INlink
Computer Settings
Component Settings
Parental Controls
Closed Caption
Time
Allow the TV to automatically control CEC devices connected to the TV via HDMI.
Move
Exit
Previous
Select
CHANNELS
SETTINGS
PHOTOS
AUDIO
OK
ENTER
MENU
EXIT
INlink Control
On
Device Auto Power Off
On
TV Auto Power On
Audio Receiver Off
Root Menu
INlink Device Lists
On
Control the menu of the HDMI CEC device with the TV remote control.
Move
Exit
Previous
Select
Settings INlink
CHANNELS
SETTINGS
PHOTOS
AUDIO
44
NS-39E480A13/NS-42E480A13/NS-46E481A13 Insignia 39"/42"/46" 1080p LED TV
www.insigniaproducts.com
Displaying a list of INlink-compatible
(HDMI CEC) devices
You can display a list of HDMI CEC devices that are
connected to your TV.
To display a list of INlink-compatible (HDMI CEC)
devices:
1 Press MENU. The on-screen menu opens.
2 Press
W or X to highlight SETTINGS, then press
T or ENTER. The Settings menu opens.
3 Press
S or T to highlight INlink, then press
ENTER. The Settings · INlink menu opens.
4 Press
S or T to highlight INlink Device Lists,
then press ENTER. A list of the HDMI
CEC-compatible devices you have connected
appears.
5 Press MENU to return to the previous menu, or
press EXIT to close the menu.
Using a USB flash drive
You can connect a USB flash drive to your TV to
view compatible JPEG pictures.
Switching to USB mode
To switch to USB mode:
1 Make sure that you have connected the USB
flash drive to the USB port on your TV.
2 Press INPUT. The Input source list opens.
3 Press
S or T to highlight USB, then press
ENTER. The Photos menu opens.
Browsing photos
To browse photos:
1 Switch to USB mode. See “Switching to USB
mode” on page 44. The Photos menu opens.
2 Press
S or T to highlight Browse Photos, then
press ENTER. The screen displays folder names
and photo files stored on the USB flash drive in a
thumbnail index with the first photo or folder
highlighted. A control bar appears at the
bottom of the screen.
OK
ENTER
MENU
EXIT
edoM erutciP Energy Saving
Brightness
48
Contrast
52
Color
68
Tint
0
Sharpness
10
Advanced Video
Reset Picture Settings
Move
Exit
Previous
Select
Adjust settings to affect picture quality.
CHANNELS
SETTINGS
PHOTOS
AUDIO
OK
ENTER
MENU
EXIT
English
Settings
Menu Language
Input Labels
INlink
Computer Settings
Component Settings
Parental Controls
Closed Caption
Time
Allow the TV to automatically control CEC devices connected to the TV via HDMI.
Move
Exit
Previous
Select
CHANNELS
SETTINGS
PHOTOS
AUDIO
OK
ENTER
MENU
EXIT
INlink Control
On
Device Auto Power Off
On
TV Auto Power On
Audio Receiver Off
Root Menu
INlink Device Lists
On
Go to device list to register new devices or remove devices from the list.
Move
Exit
Previous
Select
Settings INlink
CHANNELS
SETTINGS
PHOTOS
AUDIO
Notes
• Never remove the USB flash drive or turn off
your TV while viewing JPEG pictures.
• The JPEG picture viewer only supports JPEG
format images (with “.jpg” file extensions) and
not all JPEG files are compatible with your TV.
Note
To exit USB mode, press INPUT to open the Input
source list, then select another input source, or press
a Quick Launch Input button.
OK
ENTER
MENU
EXIT
Photos
Settings
Browse Photos
Favorite Photos
View Slideshow
Find photos that are on the USB flash device.
Move
Exit
Previous
Select
CHANNELS
SETTINGS
PHOTOS
AUDIO
MOVE
OK
ENTER
MENU
EXIT
EXIT
PREVIOUS
SELECT
45
Insignia 39"/42"/46" 1080p LED TV
www.insigniaproducts.com
3 To navigate the thumbnail index screen, press:
•
S T W or X to browse through the files and
folders.
• ENTER to view a highlighted photo full-screen
or open a highlighted folder.
• MENU to open the Photo menu.
• FAVORITE to add or remove a photo from the
favorite photo list. A heart appears on a photo
that has been added to the favorite photo list.
• Press EXIT to close the control bar.
When a photo is displayed full-screen, a control
bar appears at the bottom of the photo. The file
name, picture resolution, size, and date are
displayed on the bottom of the control bar. If
you do not press a button within 10 seconds,
the control bar closes. Press any button to open
the control bar again.
4 To navigate on the photo screen, press:
•
W or S to go to the previous photo.
•
X or T to go to the next photo.
• ENTER to rotate the photo clockwise.
• ZOOM one or more times to enlarge the
image by 1×, 2×, or 4× or to select Fill (to fill
the screen). You can press
S T W or X to pan
the photo.
• EXIT to return to the thumbnail index.
• MENU to return to the Photo menu.
Viewing favorite photos
After you created your favorite photo list, you can
browse among your favorite photos quickly.
To view favorite photos:
1 Switch to USB mode. See “Switching to USB
mode” on page 44. The Photos menu opens.
2 Press
S or T to highlight Favorite Photos, then
press ENTER. A thumbnail index of your favorite
photos opens with a control bar at the bottom
of the screen. A heart appears on a favorite
photo.
You select photos and navigate on the photo
screen in the same way you do when you are
browsing through photos. For more
information, see “Browsing photos
” on page 44.
Viewing photos in a slideshow
You can view your photos in a slideshow.
To view photos in a slideshow:
1 Switch to USB mode. See “Switching to USB
mode” on page 44. The Photos menu opens.
2 Press
S or T to highlight View Slideshow, then
press ENTER. A slideshow starts with the first
photo in the current folder.
3 To control the slideshow, press:
• ENTER to pause or start the slideshow.
• EXIT to exit the slideshow and return to the
thumbnail index.
• MENU to go to the PHOTO menu.
MENU
EXIT
Move
Exit
Previous
1600X1200 278.0K 6/22/2012 Fill
ENTER
Rotate
ZOOM
Zoom
OK
ENTER
MENU
EXIT
Photos
Settings
Browse Photos
Favorite Photos
View Slideshow
View only the photos you selected as your favorites.
Move
Exit
Previous
Select
CHANNELS
SETTINGS
PHOTOS
AUDIO
MOVE
OK
ENTER
MENU
EXIT
EXIT
PREVIOUS
SELECT
OK
ENTER
MENU
EXIT
Photos
Settings
Browse Photos
Favorite Photos
View Slideshow
View your photos in a slideshow.
Move
Exit
Previous
Select
CHANNELS
SETTINGS
PHOTOS
AUDIO
46
NS-39E480A13/NS-42E480A13/NS-46E481A13 Insignia 39"/42"/46" 1080p LED TV
www.insigniaproducts.com
Customizing slideshow settings
You can customize the slideshow settings,
including Repeat, Shuffle, Speed, and Transition.
To customize slideshow settings:
1 Switch to USB mode. See “Switching to USB
mode” on page 44. The Photos menu opens.
2 Press
S or T to highlight Settings, then press
ENTER. The Photos · Settings menu opens.
3 Press
S or T to highlight an option, then press
ENTER. You can select:
• Repeat—Repeats the slideshow when it
reaches the end. You can select On or Off.
• Shuffle—Displays the slideshow photos in
random order. You can select On or Off.
• Speed—Sets the amount of time a photo is
displayed before the slideshow moves to the
next photo. You can select 4Sec, 6Sec, or
8Sec.
• Transition—Selects the way photos transition
when moving to the next file in the slideshow.
You can select:
• None—No transition effect.
• Fade to Black—Fades the screen to black
between photos.
• Vertical Wipe—Wipes the screen from left
to right between photos.
• Horizontal Wipe—Wipes the screen from
top to bottom between photos.
• Random—Randomly selects a transition
effect.
4 Press EXIT to close the menu.
Maintaining
• Do not use your TV in areas that are too hot or too
cold, because the cabinet may warp or the screen
may malfunction. Your TV works best in
temperatures that are comfortable to you.
• Storage temperatures are 32° to 122°F (0° to 50°C).
• Working temperatures are 41° to 104°F
(5° to 40°C).
• Do not place your TV in direct sunlight or near a
heat source.
Cleaning the TV cabinet
Clean the cabinet with a soft, lint-free cloth. If the
cabinet is especially dirty, moisten a soft, lint-free
cloth in a weak detergent solution, squeeze the
excess moisture from the cloth, then wipe the
cabinet with the cloth. Use a clean cloth to dry the
cabinet.
Cleaning the TV screen
Clean the screen with a soft, lint-free cloth.
Troubleshooting
Video and audio
OK
ENTER
MENU
EXIT
Photos
Settings
Browse Photos
Favorite Photos
View Slideshow
View files from a USB device that is connected to the TV.
Move
Exit
Previous
Select
CHANNELS
SETTINGS
PHOTOS
AUDIO
OK
ENTER
MENU
EXIT
Transition None
Repeat On
Shuffle On
Speed 6sec
Repeat the slideshow when it reaches the end.
Move
Exit
Previous
Select
Photos Settings
CHANNELS
SETTINGS
PHOTOS
AUDIO
Warning
Do not try to repair your TV yourself. Contact
authorized service personnel.
Problem Solution
Picture does not fill the
screen. There are black bars
around the picture.
• Change the aspect ratio. An increasing amount
of digital TV and movies are presented in wide
screen (16:9). See “Aspect ratio options
” on
page 26.
No picture (screen is not lit)
and no sound.
• Press on the TV or the remote control.
• Make sure that the Audio Only option is set to
Off. See “Playing TV audio only” on page 29.
• Make sure that the video cables are connected
securely to your TV.
• Adjust the contrast and brightness. See
“Adjusting the TV picture” on page 25.
• Make sure that the power cord is plugged in.
• Make sure that the correct video input source is
selected. See “Selecting the video input source”
on page 23.
• Try another channel. The station may be
experiencing problems.
• Make sure that the incoming signal is
compatible.
• Make sure that the antenna or cable TV is
connected correctly and securely. See
“Connecting a cable or satellite box” on page 10
or “Connecting an antenna or cable TV (no box)”
on page 13.
• Check the closed caption settings. Some TEXT
modes can block the screen.
47
Insignia 39"/42"/46" 1080p LED TV
www.insigniaproducts.com
Dark, poor, or no picture
(screen is lit), but sound is
good.
• Try another channel. The station may be
experiencing problems.
• Make sure that the antenna or cable TV is
connected correctly and securely. See
“Connecting a cable or satellite box” on page 10
or “Connecting an antenna or cable TV (no box)”
on page 13.
• Adjust the brightness. See “Adjusting the TV
picture” on page 25.
• Make sure that the correct picture mode is
selected. See “Adjusting the TV picture” on
page 25.
• If you are using an antenna, the digital channel
signal may be low. To check the digital channel
signal strength, see “Checking the digital signal
strength” on page 31.
• If you are using an antenna and the signal
strength is low, adjust the antenna or use a
highly directional outdoor antenna or set-top
antenna with a built-in amplifier.
• Make sure that the video cables are connected
securely to your TV.
• The video cable(s) you are using may be bad. Try
a new set.
• Try another channel. The station may be
experiencing problems.
No color, dark picture, or
color is not correct.
• Try another channel. The station may be
experiencing problems.
• Adjust the color settings. See “Adjusting the TV
picture” on page 25.
• Make sure that the video cables are connected
correctly and securely to your TV.
• Make sure that the antenna or cable TV is
connected correctly and securely. See
“Connecting a cable or satellite box” on page 10
or “Connecting an antenna or cable TV (no box)”
on page 13.
• If you are using an antenna, the digital channel
signal may be low. To check the digital channel
signal strength, see “Checking the digital signal
strength” on page 31.
• If you are using an antenna and the signal
strength is low, adjust the antenna or use a
highly directional outdoor antenna or set-top
antenna with a built-in amplifier.
Only snow (noise) appears
on the screen.
• Try another channel. The station may be
experiencing problems.
• Make sure that the antenna or cable TV is
connected correctly and securely. See
“Connecting a cable or satellite box” on page 10
or “Connecting an antenna or cable TV (no box)
”
on page 13.
• If you are using an antenna, the digital channel
signal may be low. To check the digital channel
signal strength, see “Checking the digital signal
strength” on page 31.
• If you are using an antenna and the signal
strength is low, adjust the antenna or use a
highly directional outdoor antenna or set-top
antenna with a built-in amplifier.
Picture quality is good on
some channels and poor on
others. Sound is good.
• The problem may be caused by a poor or weak
signal from the broadcaster or cable TV provider.
• If you connect to cable or satellite TV without a
set-top box and experience poor picture quality,
you may need to install a set-top box to improve
signal reception and picture quality. Contact
your cable or satellite TV provider about
upgrading to a set-top box.
Problem Solution
Dotted lines or stripes
appear on the screen.
• Make sure that the antenna or cable TV is
connected correctly and securely. See
“Connecting a cable or satellite box” on page 10
or “Connecting an antenna or cable TV (no box)”
on page 13.
• If you are using an antenna, the digital channel
signal may be low. To check the digital channel
signal strength, see “Checking the digital signal
strength” on page 31.
• If you are using an antenna and the signal
strength is low, adjust the antenna or use a
highly directional outdoor antenna or set-top
antenna with a built-in amplifier.
• Make sure that the video cables are connected
securely to your TV.
• The video cable(s) you are using may be bad. Try
a new set.
• Other devices (for example, a surround sound
receiver, external speakers, fans, or hair dryers)
may be interfering with your TV. Try turning off
one device at a time to determine which device
is causing interference. After you have
determined which device is causing
interference, move it further from the TV to
eliminate the interference.
Double images.
• Use a highly directional outdoor antenna, cable
TV, or satellite TV.
The picture has a few bright
or dark spots.
• A few bright or dark spots on an LCD screen is
normal. It does not affect the operation of
your TV.
Good picture, but no sound.
• Increase the volume.
• Make sure that the sound is not muted.
• Make sure you do not have headphones
connected. When headphones are connected,
no sound comes from the TV speakers.
• Make sure that the correct audio mode is
selected.
• Make sure that the audio cables are connected
correctly and securely to your TV.
• Make sure that the antenna or cable TV is
connected correctly and securely. See
“Connecting a cable or satellite box” on page 10
or “Connecting an antenna or cable TV (no box)”
on page 13.
• If you are using an antenna, the digital channel
signal may be low. To check the digital channel
signal strength, see “Checking the digital signal
strength” on page 31.
• The audio cable(s) you are using may be bad. Try
a new set.
Poor picture.
• Make sure that the room is not too bright. Light
reflecting off the screen can make the picture
difficult to see.
• If an S-VHS camera or a camcorder is connected
while another connected device is turned on,
the picture may be poor. Turn off one or more
devices.
Good sound but poor color.
• Adjust the contrast, color, and brightness
settings. See “Adjusting the TV picture
” on
page 25.
Audio noise.
• Other devices (for example, a surround sound
receiver, external speakers, fans, or hair dryers)
may be interfering with your TV. Try turning off
one device at a time to determine which device
is causing interference. After you have
determined which device is causing
interference, move it further from the TV to
eliminate the interference.
Problem Solution
48
NS-39E480A13/NS-42E480A13/NS-46E481A13 Insignia 39"/42"/46" 1080p LED TV
www.insigniaproducts.com
Remote control
General
No output from one of the
speakers.
• Adjust the audio balance. See “Adjusting sound
settings” on page 28.
• Make sure that the audio cables are connected
correctly and securely to your TV.
After images appear.
• Do not display a still image, such as a logo,
game, or computer image, for an extended
period of time. This can cause a permanent
after-image to be burned into the screen. This
type of damage is not covered by your warranty.
Problem Solution
Remote control does not
work.
• Make sure that the power cord is correctly
connected to a power outlet.
• Make sure that there are no obstructions
between the remote control and the remote
control sensor on the front of the TV.
• Point the remote control directly at the remote
control sensor on your TV. For the location of the
remote control sensor, see “Aiming the remote
control” on page 20.
• The supplied batteries are wrapped tightly in
clear plastic. Make sure that you have removed
this plastic from the batteries.
• Make sure that the batteries are installed
correctly. See “Installing remote control
batteries” on page 20.
• Replace dead batteries with new batteries. See
“Installing remote control batteries” on page 20.
Trouble programming your
existing universal remote
control.
• See instructions and a table of common codes in
“Programming a different universal remote
control” on page 50.
• Codes are subject to change. For up-to-date
codes, go to
www.insigniaproducts.com/remotecodes
• Replace dead batteries with new batteries. See
“Installing remote control batteries” on page 20.
• Refer to the User Guide that accompanied your
universal remote control and contact the
manufacturer if problems persist.
Problem Solution
No power.
• Make sure that the power cord is correctly
connected to a power outlet.
• Unplug the power cord, wait 60 seconds, then
plug the cord back in and turn on your TV.
• Other devices (for example, a surround sound
receiver, external speakers, fans, or hair dryers)
may be interfering with your TV. Try turning off
one device at a time to determine which device
is causing interference. After you have
determined which device is causing
interference, move it further from the TV to
eliminate the interference.
“No signal” error
message is displayed.
•Press INPUT and make sure that you have
selected the correct input for the device or
service you are trying to use.
• If you are using a cable or satellite box, use the
remote that came with that box to change
channels.
• Make sure that you have the correct input
selected to view channels from the cable or
satellite box.
Problem Solution
After Auto Channel
Search, there are no
channels.
• Reception can vary by channel depending on the
broadcast power level of a given station. Contact
your cable or satellite TV provider.
• Make sure that the antenna or cable/satellite TV
is connected securely to your TV.
• Try replacing the cable between the
antenna/cable or cable/satellite box and your
TV.
One or more channels
do not display.
• Make sure that the channels are not blocked. See
“Setting parental control levels
” on page 34.
• Make sure that the channels are not hidden. The
channel may have been deleted from the
channel list. You can tune to the channel by
pressing the number buttons or you can add the
channel back to the channel list. See “Hiding
channels” on page 30.
• If you are using a cable or satellite box, use the
remote that came with that box to change
channels.
• Make sure that you have the correct input
selected to view channels from the cable or
satellite box.
• If you are using an antenna, the digital channel
signal may be low. To check the digital channel
signal strength, see “Checking the digital signal
strength” on page 31.
Password is lost.
•Enter 9999 to access parental controls, then set
a new password. See “Setting or changing the
password” on page 32.
Some settings cannot be
accessed.
• If a setting is grayed, the setting is not available
in the current video input mode.
TV cabinet creaks.
• When the TV is in use, the temperature rises
naturally and may cause the cabinet to expand
or contract which can cause a creaking noise.
This is not a malfunction.
Control buttons do not
work.
• Make sure that the Button Lock option is set to
Off. See “Locking control buttons” on page 33.
• Unplug the power cord, wait a few seconds, then
plug the cord back in and turn on your TV.
TV keeps turning off.
• Make sure that the sleep timer is not turned on.
See “Setting the sleep timer” on page 39.
Note
If the problem is not solved by using these
troubleshooting instructions, turn off your TV, then
turn it on again.
Problem Solution
49
Insignia 39"/42"/46" 1080p LED TV
www.insigniaproducts.com
Specifications
Specifications are subject to change without notice.
Dimensions and weight
Screen
Display resolutions/VGA scan rates (all models)
Tuner (all models)
Inputs (all models)
Outputs (all models)
Audio
Power
Miscellaneous
NS-39E480A13 NS-42E480A13 NS-46E481A13
Without
stand
35 × 2.4 × 21.0 in.
(88.9 × 6 × 53.3 cm)
23.15 lbs. (10.5 kg)
38.8 × 2.28 × 23.3 in.
(98.6 × 5.8 × 59.1 cm)
34.17 lbs. (15.5 kg)
42.3 × 25.24 × 2.28 in.
(107.48 × 64.1 × 5.8 cm)
45.2 lbs. (20.5 kg)
With
stand
35 × 8.9 × 23.2 in.
(88.9 × 22.5 × 59 cm)
26.46 lbs.(12 kg)
38.8 × 9.8 × 25.9 in.
(98.6 × 25.0 × 65.7 cm)
39.68 lbs. (18 kg)
42.3 × 27.6 × 9.8 in.
(107.48 × 70.2 × 25 cm)
49.6 lbs. (22.5 kg)
NS-39E480A13 NS-42E480A13 NS-46E481A13
Screen size
measured
diagonally
38.5 in. 42 in. 46 in.
Display type LED LED LED
Panel 60 Hz
vs.120 Hz
120Hz 120Hz 120Hz
Display
resolution
1080p 1080p 1080p
Panel
resolution
1920 (H) × 1080 (V) 1920 (H) × 1080 (V) 1920 (H) × 1080 (V)
Aspect ratio 16:9 16:9 16:9
Contrast ratio
(typical)–panel
2500:1 2500:1 3000:1
Dynamic
contrast ratio–
list value
6000:1 12,000:1 15,000:1
Brightness
(center typical)
cd/m2
300 nits 300 nits 300 nits
Comb filter 3d y/c digital 3d y/c digital 3d y/c digital
Response time 8 ms 6.5 ms 8 ms
Horizontal
viewing angle
160° 160° 160°
Vertical
viewing angle
160° 160° 160°
HDMI 1080p, 1080i, 720p, 480p, 480i
Component video 1080i, 720p, 480p, 480i
PC/VGA 640 × 480/60Hz,
800 × 600/60Hz,
1024 × 768/60Hz,
1280 × 1024/60Hz,
1680 × 1050/60Hz,
1920 × 1080/60Hz
Analog NTSC
Digital ATSC, 8-VSB, Clear-QAM
HDMI/DVI
2 (back), 1 (side)
E-EDID compliant
HDCP compliant
Component video 1 (back)
Composite video 1 (side)
Shared audio (component
and composite)
No
S-Video No
PC/VGA 1 (side)
3.5mm PC audio input 1 (side)
USB
1 (back)
Supports JPEG and firmware upgrade
Video No
Analog audio/headphone 1 (back)
Digital audio 1 optical (side)
WiFi No
Ethernet No
NS-39E480A13 NS-42E480A13 NS-46E481A13
Speakers
Number: 2
Watts per channel:
6W
Number: 2
Watts per channel:
8W
Number: 2
Watts per channel:
8W
NS-39E480A13 NS-42E480A13 NS-46E481A13
Power
consumption
On: 80 W
Standby: <1W
On: 100W
Standby: <1W
On: 110W
Standby: <1W
Power input 120V/60Hz 120V/60Hz 120V/60Hz
OSD languages English, French,
Spanish
English, French,
Spanish (all
models)
English, French,
Spanish (all
models)
INlink Yes Yes Yes
Game Mode Yes Yes Yes
ENERGY STAR
qualified
No No No
Internet
connectable
No No No
TV base screws M5 type
(12 mm length)
(8pcs.)
M5 type (12 mm
length) (8pcs.)
M5 type (12 mm
length) (8pcs.)
TV mount
spacers and
screws
M6 type
(30 mm length)
(4pcs.)
M6 type (25 mm
length) (4psc.)
M6 type (25 mm
length) (4pcs.)
V-Chip (version
2.0)
Yes Yes Yes
Sleep timer Yes Yes Yes
Channel
labeling
No No No
VESA mount
(Hor.× Ver.)
200 × 200 mm 400 × 400 mm 400 × 400 mm
Note
The length of the wall-mount screws vary depending
on the wall-mount bracket you purchased. See the
instructions that came with the wall-mount bracket
for screw lengths.
50
NS-39E480A13/NS-42E480A13/NS-46E481A13 Insignia 39"/42"/46" 1080p LED TV
www.insigniaproducts.com
Programming universal
remote controls
Programming a different universal remote
control
You can operate your Insignia TV with a new or
existing universal remote control.
To program a different universal remote control:
1 See the table in “Common universal remote
control codes” for common codes. If you have
problems programming your remote or need a
different remote control code, visit
www.insigniaproducts.com/remotecodes
for
the latest remote control code information.
2 Follow your universal remote control’s
instructions to enter the TV code you found in
Step 1.
For additional help and information:
•Visit:
http://www.insigniaproducts.com/remotecodes
• Call technical support for the universal remote
control or cable/satellite company of the
remote/set-top box you are trying to program.
• Call the Insignia Customer Care Center
1-877-467-4289.
Common universal remote control codes
The following is a list of the most common remote
control codes. Codes for other remote controls are
available online at:
http://www.insigniaproducts.com/remotecodes
or check with your cable or satellite TV provider for
the remote control code.
Insignia TV codes for universal remote controls (for all
Insignia TVs manufactured after Jan. 1, 2007)
Tips
• If your universal remote control has a code
search feature, run a code search to identify a
code that matches your TV. See your universal
remote control’s instructions for details.
• If your universal remote control has a “Learn”
feature, you can manually program it using the
Insignia TV remote to “teach” the commands
one at a time. See your universal remote
control’s instructions for details.
Universal remote control makes and models
One for All 0054
Phillips 0198, 0490
RCA 135
Sony
068, 069, 078, 096, 100, 164, 168, 229,
026
Set-top box makes and models
Cablevision
068, 069, 078, 096, 100, 164, 168, 229,
026
Charter
2002, 1204, 1423, 1517, 0171, 1963,
0463, 1463, 0842, 1326, 167, 415, 424,
450, 456, 461, 507, 523, 567, 577, 586
Comcast
10171, 11204, 11326, 11463, 11517,
11641, 11780, 11785, 11892, 11963,
12002
Cox 1326, 1463
DirectTV
10171, 11204, 11326, 11517, 11564,
11641, 11963, 12002
Dish Network 720
Time Warner 400, 450, 461, 456, 10463, 1463, 0463
TiVo 0091
Verizon 0198, 0490
Tips
• The brand name is often visible on the front of
the universal remote control, and the model
number is often visible on the back.
• If your universal remote control isn’t listed on
the chart, refer to your universal remote
control’s instructions and try codes for the
brands Orion, Emerson, Memorex, Sansui,
Sylvania, or Zenith. You may need to try several
codes before finding a match.
51
Insignia 39"/42"/46" 1080p LED TV
www.insigniaproducts.com
Legal notices
FCC Part 15
This device complies with Part 15 of the FCC Rules. Operation of
this product is subject to the following two conditions: (1) this
device may not cause harmful interference, and (2) this device
must accept any interference received, including interference
that may cause undesired operation.
This equipment has been tested and found to comply within the
limits for a class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician
for help.
FCC warning
Changes or modifications not expressly approved by the party
responsible for compliance with the FCC Rules could void the
user’s authority to operate this equipment.
Cables
Connections to this device must be made with shielded cables
with metallic RF/EMI connector hoods to maintain compliance
with FCC Rules and Regulations.
Canada ICES-003 statement
This Class B digital apparatus complies with Canadian ICES-003.
Standard Television Receiving Apparatus — Appareil de
réception télévision ordinaire, Canada BETS-7 / NTMR-7
Dolby License Notice and Trademark Acknowledgement
Manufactured under license from Dolby
Laboratories. Dolby and the double-D symbol
are trademarks of Dolby Laboratories.
HDMI
The terms HDMI and HDMI High-Definition
Multimedia Interface, and the HDMI Logo are
trademarks or registered trademarks of HDMI
Licensing LLC in the United States and other
countries.
52
NS-39E480A13/NS-42E480A13/NS-46E481A13 Insignia 39"/42"/46" 1080p LED TV
www.insigniaproducts.com
One-year limited warranty -
Insignia Televisions
Definitions:
Insignia Products (“Insignia”) warrants to you, the original
purchaser of this new Insignia-branded television (“Product”),
that the Product shall be free of defects in the original
manufacturer of the material or workmanship for a period of one
(1) year from the date of your purchase of the Product (“Warranty
Period”). For this warranty to apply, your Product must be
purchased in the United States or Canada from a Best Buy or
Future Shop authorized dealer of Insignia brand products only
that are packaged with this warranty statement.
How long does the coverage last?
The Warranty Period lasts for 1 year (365 days) from the date you
purchased the Product. Your purchase date is printed on the
receipt you received with the Product.
What does this warranty cover?
During the Warranty Period, if the original manufacture of the
material or workmanship of the Product is determined to be
defective by an authorized Insignia repair center or store
personnel, Insignia will (at its sole option): (1) repair the Product
with new or rebuilt parts; or (2) replace the Product at no charge
with new or rebuilt comparable products or parts. Products and
parts replaced under this warranty become the property of
Insignia and are not returned to you. If service of Products or
parts are required after the Warranty Period expires, you must
pay all labor and parts charges. This warranty lasts as long as you
own your Insignia Product during the Warranty Period. Warranty
coverage terminates if you sell or otherwise transfer the Product.
How to obtain warranty service?
If you purchased the Product at a Best Buy or Future Shop retail
store location and your television Product has a screen size of
less than 42 inches, please take your original receipt and the
Product to any Best Buy or Future Shop store. Make sure that you
place the Product in its original packaging or packaging that
provides the same amount of protection as the original
packaging. If you purchased the Product from a Best Buy or
Future Shop online web site, mail your original receipt and the
Product to the address listed on the web site. Make sure that you
put the Product in its original packaging or packaging that
provides the same amount of protection as the original
packaging.
To obtain in-home warranty service for a television with a screen
42 inches or larger, in the United States call 1-888-BESTBUY,
Canada call 1-866-BESTBUY for Future Shop call 1-800-663-2275.
Call agents will diagnose and correct the issue over the phone or
will have a Insignia-approved repair technician dispatched to
your home.
Where is the warranty valid?
This warranty is valid only in the United States and Canada at
Best Buy or Future Shop branded retail stores or websites to the
original purchaser of the product in the county where the
original purchase was made.
What does the warranty not cover?
This warranty does not cover:
• Customer instruction/education
• Installation
•Set up adjustments
•Cosmetic damage
• Damage due to acts of God, such as power surges
•Accident(s)
•Misuse
•Abuse
• Negligence
• Commercial purposes/use, including but not limited to use
in a place of business or in communal areas of a multiple
dwelling condominium or apartment complex, or
otherwise used in a place of other than a private home.
• Modification of any part of the Product, including the
antenna
• Plasma display panel damaged by static (non-moving)
images applied for lengthy periods (burn-in).
• Damage due to incorrect operation or maintenance
• Connection to an incorrect voltage or power supply
• Attempted repair by any person not authorized by Insignia
to service the Product
• Products sold “as is” or “with all faults”
• Consumables, including but not limited to batteries (i.e. AA,
AAA, C etc.)
• Products where the factory applied serial number has been
altered or removed
• Loss or Theft of this product or any part of the product
• Up to three (3) pixel failures (dots that are dark or
incorrectly illuminated) grouped in an area smaller than
one tenth (1/10) of the display size or up to five (5) pixel
failures throughout the display. (Pixel based displays may
contain a limited number of pixels that may not function
normally.)
• Failures or Damage caused by any contact including but
not limited to liquids, gels or pastes.
REPAIR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS
YOUR EXCLUSIVE REMEDY FOR BREACH OF WARRANTY. INSIGNIA
SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR
CONSEQUENTIAL DAMAGES FOR THE BREACH OF ANY EXPRESS
OR IMPLIED WARRANTY ON THIS PRODUCT, INCLUDING, BUT
NOT LIMITED TO, LOST DATA, LOSS OF USE OF YOUR PRODUCT,
LOST BUSINESS OR LOST PROFITS. INSIGNIA PRODUCTS MAKES
NO OTHER EXPRESS WARRANTIES WITH RESPECT TO THE
PRODUCT, ALL EXPRESS AND IMPLIED WARRANTIES FOR THE
PRODUCT, INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED
WARRANTIES OF AND CONDITIONS OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED IN
DURATION TO THE WARRANTY PERIOD SET FORTH ABOVE AND
NO WARRANTIES, WHETHER EXPRESS OR IMPLIED, WILL APPLY
AFTER THE WARRANTY PERIOD. SOME STATES, PROVINCES AND
JURISDICTIONS DO NOT ALLOW LIMITATIONS ON HOW LONG AN
IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION MAY NOT
APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL
RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS, WHICH VARY
FROM STATE TO STATE OR PROVINCE TO PROVINCE.
INSIGNIA is a registered trademark of BBY Solutions, Inc.
Registered in some countries.
Distributed by Best Buy Purchasing, LLC, 7601 Penn Ave South,
Richfield, MN 55423 U.S.A.
©2012 BBY Solutions, Inc.
All Rights Reserved
Made in China
1-877-467-4289
www.insigniaproducts.com
INSIGNIA is a registered trademark of BBY Solutions, Inc.
Registered in some countries.
Distributed by Best Buy Purchasing, LLC, 7601 Penn Ave South, Richfield, MN 55423 U.S.A.
©2012 BBY Solutions, Inc.
All Rights Reserved
1-877-467-4289
www.insigniaproducts.com
ENGLISH
12-0691
