Insignia NS-L46Q120-10A TV User Manual

42"/46" LCD TV

NS-L42Q120-10A/NS-L46Q120-10A

User Guide

www.insigniaproducts.com

Contents

CHILD SAFETY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Important safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Cautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Installing the stand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Installing a wall-mount bracket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

TV components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Cleaning cloth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Side controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Back . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Side . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Using the remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Installing the batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Aiming the remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Using the remote control holder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Programming your remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Programming a different universal remote control . . . . . . . . . . . . . . . 12

Making connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Connecting the power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Connecting an antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Connecting cable TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Connecting a VCR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Connecting a camcorder or game console . . . . . . . . . . . . . . . . . . . . . . . 15

Connecting an HDMI device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Connecting a component video device . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Connecting an S-Video device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Connecting a computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Connecting a digital audio amplifier . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Connecting an analog audio amplifier . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Turning your TV on for the first time . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Understanding the basics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Turning your TV on or off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Selecting the video input source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

On-screen menu overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Navigating the menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Selecting a channel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Adjusting the volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Displaying additional information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Adjusting the picture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Adjusting the TV picture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

iii

Contents

www.insigniaproducts.com

Adjusting the computer image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Changing the aspect ratio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Selecting the picture mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Adjusting advanced video settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Fitting the picture to the screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Freezing the picture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Adjusting the sound . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Selecting the audio mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Selecting the sound mode or audio language . . . . . . . . . . . . . . . . . . . . 25

Adjusting audio settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Playing audio only . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Changing channel settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Automatically scanning for channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Hiding channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Setting up a favorite channel list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Labeling a channel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Viewing the digital TV signal strength . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Setting parental controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Setting the password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Changing the password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Setting parental control levels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Blocking unrated TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Viewing blocked content . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Using downloaded rating information . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Locking control panel buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Using closed captioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Selecting the closed captioning mode . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Customizing the DTV closed captioning style . . . . . . . . . . . . . . . . . . . . 34

Adjusting time settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Manually setting the date and time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Setting the sleep timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Adjusting menu settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Selecting the menu language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Adjusting the menu transparency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Labeling a video input source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Turning the Auto Input Sensor on or off . . . . . . . . . . . . . . . . . . . . . . . . . 37

Restoring factory defaults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Manufacturers’ codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Maintaining . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Cleaning the TV cabinet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Cleaning the LCD screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Legal notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Two-year limited warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Contents

www.insigniaproducts.com

As you enjoy your new product, keep these

safety tips in mind

The issue

The home theater entertainment experience is a growing trend, and larger TVs are popular

purchases. However, TVs are not always supported on the proper stands or installed

according to the manufacturer’s recommendations. We and the consumer electronics

industry are committed to making home entertainment enjoyable and safe.

TVs that are inappropriately placed on dressers, bookcases, shelves, desks, speakers, chests, or

carts may fall over and cause injury.

Tune into safety

• One size of TV stand does not fit all. Use only a TV stand

rated for the weight of your TV.

• Carefully read and understand all enclosed instructions

for proper use of this product.

• Don’t let children climb on or play with entertainment

system furniture and TVs.

• Don’t place TVs on furniture that can easily be used as

steps, such as a chest of drawers.

• Remember that children can become excited while

watching a program, especially on a “larger-than-life” TV.

Make sure that you place or install the TV where it cannot

be pushed, pulled over, or knocked down.

• Make sure that you route all cords and cables so that they

cannot be pulled or grabbed by curious children.

Wall mounting

If you decide to wall mount your TV, always remember:

• One size of wall mount does not fit all. Use only a wall mount rated for the weight of

your TV and that has been recommended by this TV manufacturer, listed in this

manual, or otherwise listed by an independent laboratory as suitable for your TV.

• Follow all instructions supplied by the TV and wall mount manufacturers.

• If you have any doubts about your ability to safely wall mount your TV, get help from a

professional installer.

• Make sure that the wall where you are mounting the TV is

appropriate. Some wall mounts are not designed to be

mounted to walls backed with steel studs or cinder blocks. If

you are unsure, ask a professional installer.

• TVs can be heavy. At least two people are required for safe wall mount installation.

CHILD SAFETY

It makes a difference how and where you use

your flat panel display

NS-L42Q120-10A/NS-L46Q120-10A

www.insigniaproducts.com

Important safety

instructions

1 Read these instructions.

2 Keep these instructions.

3 Heed all warnings.

4 Follow all instructions.

5 Do not use this apparatus near water.

6 Clean only with a dry cloth.

7 Do not block any ventilation openings. Install in

accordance with the manufacturer's

instructions.

8 Do not install near any heat sources such as

radiators, heat registers, stoves, or other

apparatus (including amplifiers) that produce

heat.

9 Do not defeat the safety purpose of the

polarized or grounding-type plug. A polarized

plug has two blades with one wider than the

other. A grounding type plug has two blades

and a third grounding prong. The wide blade or

the third prong are provided for your safety. If

the provided plug does not fit into your outlet,

consult an electrician for replacement of the

obsolete outlet.

10 Protect the power cord from being walked on or

pinched particularly at plugs, convenience

receptacles, and the point where they exit from

the apparatus.

11 Only use attachments/accessories specified by

the manufacturer.

12 Use only with a cart, stand, tripod,

bracket, or table specified by the

manufacturer, or sold with the

apparatus. When a cart is used, use

caution when moving the

cart/apparatus combination to avoid injury from

tip-over.

13 Unplug this apparatus during lightning storms

or when unused for long periods of time.

14 Refer all servicing to qualified service personnel.

Servicing is required when the apparatus has

been damaged in any way, such as

power-supply cord or plug is damaged, liquid

has been spilled or objects have fallen into the

apparatus, the apparatus has been exposed to

rain or moisture, does not operate normally, or

has been dropped.

15 The wall plug is the disconnecting device. The

plug must remain readily operable.

16 An apparatus with three-prong, grounding-type

plug is a Class I apparatus. Class I apparatus

which needs to be grounded to prevent

possible electric shock. Make sure that you

connect the Class I apparatus to a

grounding-type, three-prong outlet.

17 Remote control batteries should not be exposed

to excessive heat such as sunshine, fire, or the

like.

18 The apparatus should not be exposed to

dripping or splashing, and no objects filled with

liquids, such as vases, should be placed on the

apparatus.

Warnings

Electric shock hazard

To reduce the risk of fire or electric shock, do not

remove any cover or expose the device to rain or

moisture. No user-serviceable parts are inside. Refer

servicing to qualified service technicians.

Lightning

For added protection for your device receiver

during a lightning storm, or when it is left

unattended and unused for long periods of time,

unplug it from the power outlet and disconnect any

antenna or cable system. This helps prevent

property damage and personal injury from

lightning and power line surges.

Power lines

An outside antenna system should not be located in

the vicinity of overhead power lines or other

electric light or power circuits, or where it can fall

into such power lines or circuits. When installing an

outside antenna system, extreme care should be

taken to keep from touching such power lines or

circuits as contact with them might be fatal.

Handling the LCD panel

• Your TV’s screen is made of glass. Do not drop

your TV or hit, jolt, or press hard against the LCD

panel. If the screen breaks, be careful of broken

glass.

• If the LCD panel is broken, make absolutely sure

that you do not touch the liquid in the panel. This

may cause skin inflammation.

• If the liquid gets in your mouth, immediately

gargle, rinse, and consult with your doctor. Also, if

the liquid gets in your eyes or touches your skin,

consult with your doctor after rinsing for at least

15 minutes or longer in clean water.

Replacement parts

When replacement parts are required, make sure

that the service technician uses replacement parts

specified by the manufacturer that have the same

characteristics as the original part. Unauthorized

substitutions may result in fire, electric shock,

personal injury, or other hazards.

Safety check

After completing any service or repair to this device,

ask the service technician to perform routine safety

checks to determine that your TV is in correct

operating condition.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

This symbol indicates that dangerous

voltage constituting a risk of electric

shock is present within your TV. This

label is located on the back of your TV.

This symbol indicates that there are

important operating and maintenance

instructions in the literature

accompanying your TV.

S3125A

NS-L42Q120-10A/NS-L46Q120-10A

www.insigniaproducts.com

Power source

Operate your TV only from the type of power source

indicated on the marking label. If you are not sure

of the type of power supplied to your home, consult

an electrician or your local power company.

Cautions

Damage requiring service

Unplug this TV from the power outlet and refer

servicing to qualified service personnel under the

following conditions:

• When the power supply cord or plug is damaged

or frayed.

• If liquid has been spilled or objects have fallen

into your TV.

• If your TV has been exposed to rain or water.

• If your TV does not operate normally by following

the operating instructions. Adjust only those

controls that are covered by the operating

instructions because incorrect adjustment of

other controls may result in damage and will

often require extensive work by a qualified

technician to restore your TV to its normal

operation.

• If your TV has been dropped or damaged in any

way.

• When your TV exhibits a distinct change in

performance.

Outdoor antenna grounding

If an outside antenna or cable system is connected

to your TV, make sure that the antenna or cable

system is grounded to provide some protection

against voltage surges and built-up static charges.

Article 810 of the National Electrical Code,

ANSI/NFPA No. 70, provides information with

respect to correct grounding of the mast and

supporting structure, grounding of the lead-in wire

to an antenna discharge unit, size of grounding

conductors, location of the antenna-discharge unit,

connection to grounding electrodes, and

requirements for the grounding electrode.

Note to CATV system installer

Article 820 of the National Electrical Code,

ANSI/NFPA No. 40 provides guidance for correct

grounding. Specifically, it states that the cable

ground must be connected to the grounding

system of the building as close to the point of cable

entry as practical.

Condensation

Moisture will form on the TV if the TV is brought

from cool surroundings into a warm room or if the

temperature of the room rises suddenly. When this

happens, the TV's performance may be impaired. To

prevent this, let the TV stand in its new

surroundings for about an hour before switching it

on, or make sure that the room temperature rises

gradually.

Condensation may also form during the summer if

the TV is exposed to the breeze from an air

conditioner. In such cases, change the location of

the TV.

Mobile telephone warning

To avoid interference with your TV picture and

sound, operating problems, or even damage, keep

your cordless and cellular telephones away from

the TV.

End of life directives

Your TV contains tin-lead solder and a fluorescent

lamp containing a small amount of mercury.

Disposal of these materials may be regulated for

environmental reasons. Your TV also contains

material that can be recycled and reused. For

disposal or recycling information, contact your local

authorities or the Electronic Industries Alliance at

www.eia.org to find a recycler in your area.

Non-active pixels

The LCD panel contains almost 3 million thin film

transistors, which provide exceptionally sharp video

quality. Occasionally, a few non-active pixels may

appear on the screen as a fixed blue, green, or red

point. These non-active pixels do not adversely

affect the performance of your TV, and are not

considered defects.

Antenna lead-in wire

Grounding clamp

Antenna discharge unit

Grounding conductors

Ground clamps

Power service grounding electrode system

Electric service equipment

NS-L42Q120-10A/NS-L46Q120-10A 42"/46" LCD TV

www.insigniaproducts.com

42"/46" LCD TV

Introduction

Congratulations on your purchase of a high-quality

Insignia product. Your NS-L42Q120-10A or

NS-L46Q120-10A represents the state of the art in

LCD TV design and is designed for reliable and

trouble-free performance.

Installing the stand

To install the stand:

1 Place a cushion or cloth on a flat surface, such as

a table, then place the TV face down on the

cushion or cloth.

2 Insert the stand into the TV base, then secure

the stand to the base with the four provided

M4 × L10 mm screws.

Installing a wall-mount

bracket

To install a wall-mount bracket:

1 Place a cushion or cloth on a flat surface, such as

a table, then place the TV face down on the

cushion or cloth with the stand extended over

the edge of the table.

2 Remove the four screws that secure the stand to

the base, then remove the base.

3 Attach the included TV base cover to the TV

base to prevent debris from entering your TV

after it is mounted on the wall.

4 Attach the wall-mount bracket with the four

screws that come with the wall-mount bracket

kit.

Note

To remove the base, reverse Step 2.

Warning

These servicing instructions are for use by qualified

service personnel only. To reduce the risk of hazards,

do not perform any servicing other than that

contained in the operating instructions unless you

are qualified to do so.

Cover

NS-L42Q120-10A/NS-L46Q120-10A 42"/46" LCD TV

www.insigniaproducts.com

TV components

Accessories

• Remote control

• Remote control holder

• Batteries AA (2)

•AC power cord

•TV stand

•TV base cover

• Screws for TV stand

• Component video cable

•Audio cable

•Cleaning cloth

•User Guide

•Quick Setup Guide

Cleaning cloth

The cleaning cloth is for cleaning the TV screen

only. Do not use the cleaning cloth to clean any

other part of your TV.

Side controls

Back

# Button Description

Press to open the on-screen menu.

INPUT

Press to select the video input source.

VOLUME +/–

Press to increase or decrease the volume.

CHANNEL /

Press to go to the next or previous channel in the

channel list.

POWER

Press to turn your TV on or off (standby mode). When

your TV is in standby mode, electricity still flows into

it. To disconnect all power, unplug the power cord.

# Item Description

AC IN

Connect the power cord to this jack and to a power

outlet.

ANT./CABLE IN

Connect an antenna or cable TV to this jack.

COMPONENT IN 1 and 2

Connect the video for a component video device to

these jacks.

VIDEO IN 2 S-VIDEO

Connect the video for an S-Video device to this jack.

VIDEO IN 2 VIDEO

Connect the video for a composite video device to this

jack.

SERVICE

For service only.

HDMI IN 3 and 4

Connect HDMI devices to these jacks. An HDMI cable

carries both video and audio signals. You do not need

to make an audio connection.

COMPONENT IN L/R

audio

Connect the audio for the device connected to the

COMPONENT IN 1 or COMPONENT IN 2 jacks to

these jacks.

VIDEO IN 2 L/R audio

Connect the audio for the device connected to the

VIDEO 2 VIDEO or S-VIDEO jack to these jacks.

AUDIO OUT L/R

Connect an analog audio amplifier to these jacks.

HDMI/DVI IN L/R audio

Connect the audio for a DVI device to these jacks.

AUDIO OUT SPDIF

Connect a digital audio amplifier to this jack.

8 9

NS-L42Q120-10A/NS-L46Q120-10A 42"/46" LCD TV

www.insigniaproducts.com

Side

# Item Description

VGA AUDIO

Connect the audio for a computer to this jack.

VGA

Connect the video for a computer to this jack.

HDMI 1/HDMI 2

Connect HDMI devices to these jacks. The HDMI cable

carries both video and audio signals, so a separate

audio connection is not required.

VIDEO 1 S-VIDEO

Connect an S-Video device to this jack.

VIDEO 1 AV

Connect a composite video device to this jack.

VIDEO 1 L/R

Connect the audio for the device connected to the

VIDEO 1 AV or S-VIDEO jack to these jacks.

NS-L42Q120-10A/NS-L46Q120-10A 42"/46" LCD TV

www.insigniaproducts.com

Remote control

# Button Description

SET

Press to program the remote control to control

connected devices. For more information, see

“Programming your remote control” on page 9.

DVD

Press to control a connected DVD player. You must

program the remote control before this button works.

For more information, see “Programming your remote

control” on page 9.

Press to control your TV.

Press to open the on-screen menu.

Press to move left, right, up, or down in on-screen

menus.

GUIDE

Press to display the program guide. For more

information, see “Displaying additional information”

on page 21.

(stop)

Press to stop playback on DVD, DVR, PVR, or CD

devices. You need to program the remote control to

control connected devices. For more information, see

“Programming your remote control” on page 9.

(play)

Press to start playback on DVD, DVR, PVR, or CD

devices. You need to program the remote control to

control connected devices. For more information, see

“Programming your remote control” on page 9.

TV VIDEO

COMP

HDMI

(fast reverse)

Press to fast reverse on DVD, DVR, PVR, or CD devices.

You need to program the remote control to control

connected devices. For more information, see

“Programming your remote control” on page 9.

/ (skip back)

In DVD, DVR, PVR, or CD mode, press to skip back to the

previous title or track. You need to program the

remote control to control connected devices. For more

information, see “Programming your remote control”

on page 9.

RECALL

In TV mode, press to return to the previous channel.

VOL+/VOL–

Press to increase or decrease the volume.

Numbers

Press to enter channel numbers and the parental

control password.

When programming the remote control, press to enter

device and programming codes.

INPUT

Press to open the Source List, then press or to

cycle through the available input sources. For more

information, see “Selecting the video input source” on

page 19.

FAV

Press to open the Favorite Channel list. For more

information, see “Setting up a favorite channel list” on

page 26.

SAP

In analog TV mode, press to select Stereo, Mono or

SAP. In digital TV mode, press to select the audio track

(language).

For more information, see “Selecting the sound mode

or audio language” on page 25.

SLEEP

Press to set the sleep timer. You can select Off, 5, 10,

15, 30, 60, 90, 120, 180, or 240 minutes. For more

information, see “Setting the sleep timer” on page 35.

AUDIO

When the Equalizer option is turned on, press to

toggle among different Equalizer modes. When the

Equalizer option is turned off, toggle to adjust the

treble or bass. For more information, see “Adjusting

audio settings” on page 25.

(power)

Press to turn your TV on or off (standby mode). When

your TV is off, power still flows into it. To disconnect

power, unplug the power cord.

STB

Press to control a connected set-top box.

AUX

Press to control a connected device. You need to

program the remote control to control connected

devices. For more information, see “Programming your

remote control” on page 9.

INFO

Press to display TV status information, such as the

channel number, channel name (if available), or signal

source. For more information, see “Displaying

additional information” on page 21.

OK/ENTER

Press to confirm selections or changes.

EXIT

Press to close the on-screen menu.

Video input selection

TV—Press to select TV as the video source.

VIDEO— Press one or more times to select the device

connected the AV 1 VIDEO, AV 2 VIDEO, or S-VIDEO

jack.

COMP—Press one or more times to select the device

connected to the COMPONENT 1 or COMPONENT 2

video jacks.

HDMI—Press one or more times to select the device

connected to HDMI 1, HDMI 2, HDMI 3, or HDMI 4.

For more information, see “Selecting the video input

source” on page 19.

(record)

In DVD, DVR, PVR, or CD mode, press to begin

recording. You need to program the remote control to

control connected devices. For more information, see

“Programming your remote control” on page 9.

# Button Description

NS-L42Q120-10A/NS-L46Q120-10A 42"/46" LCD TV

www.insigniaproducts.com

Using the remote control

Installing the batteries

To install the batteries:

1 Open the battery compartment cover by

pressing the cover latch, then remove the cover.

2 Insert two AA batteries into the battery

compartment. Make sure that the + and –

symbols on the batteries match the + and –

symbols in the battery compartment.

3 Replace the cover.

PVR/LIST

Press to list all the recorded programs in a PVR/STB.

You need to program the remote control to control

connected devices. For more information, see

“Programming your remote control” on page 9.

(fast forward)

Press to fast forward on DVD, DVR, PVR, or CD devices.

You need to program the remote control to control

connected devices. For more information, see

“Programming your remote control” on page 9.

/ (skip

forward)

In DVD, DVR, PVR, or CD mode, press to skip forward to

the next title or track. You need to program the remote

control to control connected devices. For more

information, see “Programming your remote control”

on page 9.

/FREEZE

Press to freeze the video image. Press again to

unfreeze the image. For more information, see

“Freezing the picture” on page 24.

Caution: Do not freeze the video image for long

periods of time. You may damage the TV screen.

CH /CH

Press to go change TV channels. For more information,

see “Selecting a channel” on page 20.

MUTE

Press to mute the sound. Press again to restore the

sound.

—

Press to enter a digital sub-channel number. For more

information, see “Selecting a channel” on page 20.

CCD

Press to turn closed captioning on or off. You can select

CC Off, CC On, or CC On when Mute. For more

information, see “Selecting the closed captioning

mode” on page 33.

P-LOCK

If Parental Lock is turned on, when you enter the

correct password to unblock the channels, you can

press P-LOCK to block the channels again.

ZOOM

Press to select the aspect ratio. For more information,

see “Adjusting advanced video settings” on page 23.

PICT

Press to select the video modes. You can select Vivid,

Standard, Energy Savings, Theater, Sports, or

Custom. For more information, see “Adjusting the TV

picture” on page 21.

Caution

• Do not expose the remote control to shock or liquids.

• Do not use the remote control in an area with high

humidity.

• Do not place the remote control in direct sunlight.

• Do not place objects, such as furniture, between the

remote control and the remote sensor.

• The remote control may not work if direct sunlight or

bright light shines on the remote sensor. Either move

your TV or change the angle at which you use the

remote control.

# Button Description

Cautions

• Do not mix different types of batteries.

• Do not mix new and old batteries.

• Remove batteries when they no longer have a charge.

• Chemicals may leak into the battery compartment.

Battery chemicals can cause a rash. If chemicals leak,

clean the battery compartment with a cloth.

• Remove the batteries if you do not intend to use the

remote control for an extended amount of time.

• Do not dispose of batteries in a fire. Dispose of them as

hazardous waste.

NS-L42Q120-10A/NS-L46Q120-10A 42"/46" LCD TV

www.insigniaproducts.com

Aiming the remote control

Point the remote control towards the remote sensor

on the front of your TV. The remote control should

be used within 26 feet (7.9 m) of your TV when you

point the remote control directly at the remote

sensor and not from an angle. If you use the remote

control at an angle to the remote sensor, the

effective distance may be less.

Using the remote control holder

Your TV comes with a remote control holder you

can put the remote control in when you are not

using it. You can put the holder on a table or mount

it on a wall.

Programming your remote control

To program your remote to control home theater

devices, follow these steps.

To program your remote control:

1 Before proceeding, find the codes for the

devices you want to program in “Manufacturers’

codes” on page 38 and write them down or

highlight them.

2 Turn on the device (for example, a DVD player)

and, if needed, load media such as a DVD.

3 Press the device key on the remote for the

device that you want to program (TV, DVD, STB,

or AUX).

4 Press and hold SET until the red LED blinks

twice, then release.

5 Enter the first five-digit code for the device and

brand that you want to program. The LED blinks

once as each digit is entered. If the code is valid,

the LED blinks twice.

6 Aim the remote at the device and press

(power). The device should turn off. If it does

not, repeat Steps 3 through 5, trying each code

for your brand until you find one that works. If

you cannot find a code that works, see

“Searching for your code” below.

7 Repeat Steps 1 to 5 for the other devices you

want to control. For future reference, write down

each working device code.

Searching for your code

If your device does not respond to the remote

control after trying all codes listed for your brand, or

if your brand is not listed, try searching for your

code.

To search for your code:

1 Turn on the device you want to control.

2 Press the desired device key (TV, DVD, STB, or

AUX) once.

3 Press and hold SET until the red LED blinks

twice, then release.

4 Enter 9 9 1. The LED blinks twice.

5 Press the device group number for your device

type (see table below).

• 0—Cable (cable converters, video accessories,

satellite receivers)

• 1—TV ( TVs)

• 2—VCR (VCRs, DVD players)

• 3—Audio (audio amplifiers, audio

amps/tuners, CD players)

6 Aim the remote at the device and press

(power). The remote sends IR codes from its

library to the selected device, starting with the

most popular code first. If the device responds,

go to Step 8.

Tips

• Different types of walls may require different

types of screws. If you want to wall mount the

remote control holder, make sure that you use

the correct screws for the type of wall. (Screws

are not provided.)

• The remote control holder is shipped with

separate adhesive tape for wall mounting. This

tape may not work with all types of walls. Make

sure that you use the correct tape for the type of

wall.

Tape

Screws

Note

If the LED does not blink twice, repeat steps 2 to 4

and try entering the code again.

NS-L42Q120-10A/NS-L46Q120-10A 42"/46" LCD TV

www.insigniaproducts.com

7 If the device does not respond, press CH and

the remote tests the next code for that device

type. Continue to press CH until the device

turns off.

8 Now that you have found the correct code, press

SET to save the code that worked for your

device. The LED blinks twice to indicate that the

code has been saved.

9 To search for other device codes, repeat Steps 1

to 8.

Checking the codes

If you have set up the remote using the procedure

in “Searching for your code” on page 9, you may

need to find out which five-digit code is operating

your equipment.

To find out which code is assigned to your TV

(for example):

1 Press TV once.

2 Press and hold SET until the red LED blinks

twice, then release.

3 Enter 9 9 0. The LED blinks twice.

4 To view the code for the first digit, press 1.

Count the red LED blinks (for example, three

blinks = 3), then write down the number in the

appropriate code listing at the top of this

column.

5 Repeat Step 4 for the four remaining digits,

using 2 for the second digit, 3 for the third digit,

4 for the fourth digit, and 5 for the fifth digit.

6 To check for other device codes, repeat Steps 1

through 5, substituting the device key for the

device you would like to check.

Using learning

This universal remote control includes a learning

feature (some models may not include this) so you

can add functions that are unique to your home

entertainment devices (such as VCR Tracking Up or

Down). However, there are some considerations to

keep in mind.

Precautions

• Your original remote controls must be in working

order for learning to work properly.

• Learned keys are mode-specific, so each one can

store a unique function for each mode.

• Do not use the following keys for learning: Device

Keys, SET, or (record).

• Learning capacity is approximately 42 to 75 keys,

depending on the code being learned.

• Certain device functions are not learnable,

including multi-frequency types, some high

frequency functions, and other unusual formats.

• For optimum learning, avoid high levels of

ambient light such as natural sunlight or

energy-efficient fluorescent lights.

Programming a learned key

To program a learned key:

1 Place your Insignia remote control

head-to-head (about 2" apart) from your

original remote control (the one that came with

the device). Also, locate the key (on your original

remote control) that you want the Insignia

remote control to learn. Press the mode key you

wish to learn functions on.

2 Press and hold SET until the LED blinks twice,

then release.

3 Enter 9 7 5. The LED blinks twice.

4 Press the key on the remote you wish to

program. The feedback LED stays lit for three

seconds, indicating that the remote is ready to

learn.

5 On the original remote, press and hold the key

to be learned. Continue holding the key on the

original remote until the Insignia’s LED blinks

twice.

6 Repeat Steps 4 and 5 to program another key.

Once you have completed programming all the

keys you want, press and hold SET until the LED

blinks twice to save all data learned.

Deleting a single learning key

This process returns the key to its original

programming for the mode you select. You can also

delete learned programming by teaching a

different function to the key (see “Programming a

Learned Key” above).

Note

Press CH to try the previous code.

Note

If the LED does not blink, the code digit is 0.

Note

Please have your original remote controls handy

before programming learning.

Note

If more than 10 seconds pass between key presses,

the remote exits programming.

If the LED displays one long flash instead, either

your batteries are low, or the Insignia remote

control has a memory fault. In either case, the

remote cannot learn a new key.

Note

If the red LED displays one long blink, a learning

error has occurred. Try repeating this step again

until a successful capture occurs. If the function is

still not captured, press and hold SET to exit

programming and review the Precautions” above.

If needed, also see “Remote control

programming” on page 50. After reviewing, start

programming again at Step 1.

Note

If more than 10 seconds pass between key presses,

the remote exits programming.

If the LED displays one long flash instead, either

your batteries are low, or the Insignia remote

control has a memory fault. In either case, the

remote cannot learn a new key.

NS-L42Q120-10A/NS-L46Q120-10A 42"/46" LCD TV

www.insigniaproducts.com

To delete a single learned key:

1 Press the mode key that you wish to remove the

learned key from.

2 Press and hold SET until the LED blinks twice,

then release.

3 Enter 9 7 6. The LED blinks twice.

4 Press the key containing the learned function to

be deleted, twice. The LED blinks twice and

programming ends.

Deleting all learned keys in a specific mode

To delete all learned keys in a specific mode:

1 Press and hold SET until the LED blinks twice,

then release.

2 Press 9 7 6. The LED blinks twice.

3 Press a mode key twice (for example, TV, DVD,

STB, or AUX) to clear all the learned keys for that

mode. The LED blinks twice and programming

ends.

Changing volume lock

The Insignia universal remote control comes preset

to allow independent volume control of each

selected device (global volume unlock). However,

you may change the volume lock setting to global

volume lock so that one device's volume controls

volume in all other modes. After that, you can

perform Individual volume unlock on a selected

device to set its volume control for independent

operation or global volume unlock to remove all

volume locking.

To lock volume control to one mode (global

volume lock):

1 Press and hold SET until the red LED blinks

twice, then release.

2 Enter 9 9 3, the LED blinks twice.

3 Press the mode key for the device you want to

control (for example, TV).

4 The LED blinks twice. Now when you press

VOL+, VOL–, or Mute, the selected device

controls the volume regardless of the current

mode.

To unlock all volume control (restoring global

unlock):

1 Press and hold SET until the red LED blinks

twice, then release.

2 Enter 9 9 3, the LED blinks twice.

3 Press VOL+. The LED blinks four times. Volume is

independently controlled for all programmed

devices.

To unlock a single device’s volume control:

1 Press the desired device mode key (TV, DVD,

STB, or AUX).

2 Press and hold SET

until the red LED blinks

twice, then release.

3 Enter 9 9 3. The LED blinks twice.

4 Press VOL-. The red LED blinks four times.

Volume is independently controlled for the

selected devices.

Programming channel lock

Channel control can be locked so that the Insignia

remote controls a single device’s channel-changing

functions, regardless of operating mode. This is

often enabled by users who watch all broadcast TV

through one device (for example, a cable set-top

box). The affected keys are 1 through 0, CH ,

CH , and RECALL.

To lock all channel controls to one device:

1 Press the mode key that relates to the device

that you use for channel changing control.

2 Press and hold SET until the mode LED blinks

twice, then release.

3 Enter 9 7 3.The mode LED blinks twice.

4 Press CH once. The mode LED blinks twice.

Now, regardless of what mode you select, the

channel keys will only change channels on the

assigned device.

To unlock channel locks:

1 Press and hold SET until the mode LED blinks

twice, then release.

2 Enter 9 7 3. The mode LED blinks twice.

3 Press CH once. The mode LED blinks four

times.

Now the channel functions will correlate to the

active mode (for example, press CH in TV

mode and the TV changes channel accordingly).

Using keymover

Your Insignia universal remote control includes a

keymover feature that lets you map (or copy) keys

from one mode (such as source mode) to another

mode (such as destination mode) or to a different

key in the same mode.

To move keys in the same device mode:

1 Press the desired device key (TV, DVD, STB, or

AUX).

2 Press and hold SET until the LED blinks twice,

then release.

3 Press 9 9 4. The LED blinks twice.

4 Press the key you want to move.

5 Press the new key that should perform the

function. The LED blinks twice.

6 Repeat Steps 1-5 to move additional keys.

To move keys to a different device mode:

1 Press and hold SET until the LED blinks twice,

then release.

2 Press 9 9 4. The LED blinks twice.

3 Press the device key that contains the function

you want to move (for example, DVD).

4 Press the key you want to move (such as Play).

Note

If more than 10 seconds pass between key presses,

the remote exits programming.

If the LED displays one long flash instead, either

your batteries are low, or the Insignia remote

control has a memory fault. In either case, the

remote cannot learn a new key.

Note

Do not use any of the Device Keys, (power),

RECORD, or SET as a source or destination key.

NS-L42Q120-10A/NS-L46Q120-10A 42"/46" LCD TV

www.insigniaproducts.com

5 Press the device key that you want to move the

function to (such as TV).

6 Press the key in the new mode that should

perform the function (for example, Play). The

LED blinks twice.

7 Repeat Steps 1-6 to move additional keys.

To restore all keymoved data in a specific mode:

1 Press and hold SET until the LED blinks twice,

then release.

2 Press 9 9 4. The LED blinks twice.

3 Press the device key you wish to remove all

keymoved data from twice. The LED blinks

twice.

4 Repeat for each device you want to restore.

To restore original key function:

1 Press the device key for which you wish to

remove the keymoved data from a specific key.

2 Press and hold SET until the LED blinks twice,

then release.

3 Enter 9 9 4. The LED blinks twice.

4 Press the key you wish to remove the keymoved

data from twice. The LED blinks twice.

5 Repeat Steps 1-4 for additional keys you wish to

remove.

Programming macros

Your Insignia universal remote control includes the

ability to program any key (other than the SET key)

with a macro function. Each one can be set up to

perform a pre-programmed set of sequential key

presses with the press of a single key. A macro can

be used to control a home theater operation, to set

a favorite channel, or for other functions you would

like to control with one key press. Each macro key

can hold up to 15 key presses, total.

To program a mode-independent macro:

1 Press and hold SET until the red LED blinks

twice, then release.

2 Press 9 9 5. The LED blinks twice.

3 Press the key you want to assign to a macro.

4 Enter the series of commands you want the

macro to execute (up to 15 commands).

5 Press and hold SET until the red LED blinks

twice, then release.

Now, when you press the preset macro key, the

remote sends the series of commands you have

entered, regardless of what mode you are in. For

example, you could program a macro key to

turn on both your TV and cable box and select a

particular channel.

To program a mode-dependent macro:

1 Press the device mode key (TV, DVD, STB, or

AUX).

2 Press and hold SET until the LED blinks twice,

then release.

3 Press

9 7 8. The LED blinks twice.

4 Press the key you wish to assign to a macro.

5 Enter the series of commands you want the

macro to execute (up to 15 commands).

6 Press and hold SET until the red LED blinks

twice, then release.

Now, when you press the macro key, the remote

sends the series of commands you have

entered, but only if you are in the mode you

selected in Step 1. For example, you could

program the macro key to turn on both your TV

and cable box and select a particular channel,

but only if you are in TV mode. If you are in DVD

mode, this key does not execute the macro you

set up in TV mode.

Programming a different universal remote

control

You can operate your Insignia TV with a new or

existing universal remote control.

To program a universal remote control:

1 Find the code for your universal remote control

by identifying its model (or your set-top box’s

remote control manufacturer and model) on the

charts below, then making note of the

numbered code below it. You will use the

numbered code to program your remote control

to work with your Insignia TV.

Note

Programming a new macro over an existing one

erases the original macro.

Note

To clear the macro, repeat Steps 1-5, but do not enter

a series of commands at Step 4.

Note

To clear the macro, repeat Steps 1-6, but do not enter

a series of commands at Step 5.

Insignia TV codes for universal remote controls

(for all Insignia TVs manufactured after Jan. 1, 2007)

Universal remote control manufacturers and models

Philips PHDVD5,

PH5DSS,

PMDVR8, PDVR8

RCA

RCU807

One for All

URC-6690

Sony

RM-VL600

115 135 0464 8043

Set-top box manufacturers and models

Comcast

M1057

Dish Network

VIP508, VIP622

Motorola

DRC800

TIVO

Series 3, HD

DirectTV

RC23

0463 720 0463 0091

10463

NS-L42Q120-10A/NS-L46Q120-10A 42"/46" LCD TV

www.insigniaproducts.com

Codes for other remote controls are available

online at:

www.insigniaproducts.com/universalcontrolco

des.aspx

2 Follow your universal remote control’s

instructions to enter the TV code you found in

Step 1.

3 If all else fails, you must use a different universal

remote control that can operate both your

set-top box and your TV. Four such remotes are

listed on the chart, but many other compatible

models are available in the market.

For more help, call technical support for your

universal remote control or set-top box

manufacturer, or call the Insignia Customer Care

Center at 1-877-467-4289.

Making connections

Connecting the power

To connect the power:

• Plug the power cord into the AC IN jack on the

back of your TV and into a power outlet.

Connecting an antenna

Antenna cables come in two types: Coaxial and

twin-lead.

To connect an antenna:

1 Turn off your TV and all connected equipment.

2 If your antenna cable has a coaxial connector,

connect the cable to the ANT./CABLE IN jack on

the back of your TV.

Or,

If your antenna cable has a twin-lead connector,

connect the cable to a coaxial-to-twin-lead

(300-75 ohm) adapter (not included), connect

the adapter to a coaxial cable, then connect the

other end of the coaxial cable to the

ANT./CABLE IN jack on the back of your TV.

3 Connect the other end of the cable to the

antenna jack.

Tips

• The brand name is often visible on the front of

the universal remote control, and the model

number is often visible on the back.

• If your universal remote control isn’t listed on

the chart, refer to your universal remote

control’s instructions and try codes for the

brands Orion, Emerson, Memorex, Sansui,

Sylvania, or Zenith. You may need to try several

codes before finding a match.

Tips

• If your universal remote control has a code

search feature, run a code search to identify a

code that matches your TV. See your universal

remote control’s instructions for details.

• If your universal remote control has a “Learn”

feature, you can manually program it using the

Insignia TV remote to “teach” the commands

one at a time. See your universal remote

control’s instructions for details.

Cautions

• Check the connectors for position and type before

making any connections.

• Loose connections can result in image or color

problems.

• Make sure that all connections are tight and secure.

• The external audio/video equipment pictures used in

this guide are for illustration purposes only. If you have

questions, refer to the user manual that came with your

equipment.

• Always turn off the power on your TV and the external

audio/video equipment before making a connection.

• Your TV does not support DTS audio format. If you

choose a DTS audio format, you may not hear the

correct audio output from the TV speakers.

Cautions

• Your TV should only be operated from the power source

indicated on the label.

• Always unplug the AC power cord from the power

outlet when you will not be using your TV for an

extended period of time.

Tips

If you plan on receiving over-the-air broadcasts, you

will need to use a separate antenna (not included) to

ensure the best reception.

Consult www.antennaweb.org for a list of local

broadcast channels and recommendations for your

location.

Coaxial cable

Twin-lead cable

NS-L42Q120-10A/NS-L46Q120-10A 42"/46" LCD TV

www.insigniaproducts.com

Connecting cable TV

Your TV has a coaxial jack for connecting cable TV.

Some cable TV providers scramble the signals for

“premium” (pay) channels. To view these channels,

you need a converter/descrambler box.

If you do not require a converter/descrambler box,

you can connect your cable TV directly to your TV.

For more information, see “No

converter/descrambler box” on page 14.

If you require a converter/descrambler box, you can

connect your cable TV using an RF switch (not

included). For more information about connecting

a converter/descrambler box, see “With

converter/descrambler box” on page 14 and

contact your cable TV provider.

You can also connect cable TV using an HDMI,

component video, S-Video, or AV connection,

depending on your cable box.

No converter/descrambler box

To connect cable TV without a

converter/descrambler box:

1 Connect one end of a coaxial cable to the

ANT./CABLE IN jack on the back of your TV.

2 Connect the other end of the cable to the cable

TV wall outlet.

With converter/descrambler box

If your cable box descrambles only some channels

(such as premium channels), you need a two-way

splitter, an RF (A/B) switch, and four lengths of

antenna cable. The two-way splitter and RF switch

are not provided.

To connect cable TV with a

converter/descrambler box:

• Use the following illustration as a guide to

connect a converter/descrambler box.

Set the RF switch to the A position to tune to

unscrambled channels using your TV remote

control. Set the RF switch to the B position to

watch scrambled channels using the

converter/descrambler controls.

Connecting a VCR

To connect a VCR:

1 Make sure the TV’s power cord is unplugged

and the VCR is turned off.

2 Connect an AV cable to the VIDEO IN 2 VIDEO

and VIDEO IN 2 L and R audio jacks on the back

of your TV.

3 Connect the other end of the cable to the

VIDEO OUT and AUDIO OUT jacks on the VCR.

4 Turn on your TV, then turn on the VCR.

5 Press INPUT to open the source list, press or

to highlight A/V 2, then press ENTER.

6 Insert a videotape into the VCR, then press

PLAY.

RF switch

Cable converter/descrambler box

Two-set signal splitter

Out In

Note

The connectors on AV cables are often color-coded.

Yellow is video, white is left audio, and red is right

audio.

Note

You can also press VIDEO twice to select A/V 2.

VCR

Back of TV

NS-L42Q120-10A/NS-L46Q120-10A 42"/46" LCD TV

www.insigniaproducts.com

Connecting a camcorder or game console

To connect a camcorder or game console:

1 Make sure the TV’s power cord is unplugged

and the camcorder or game console is turned

off.

2 Connect an AV cable to the VIDEO IN 1 VIDEO

and VIDEO IN 1 L and R audio jacks on the side

of your TV.

3 Turn on your TV, then turn on the camcorder or

game console.

4 Press INPUT to open the source list, press or

to highlight A/V1, then press ENTER.

Connecting an HDMI device

You can connect an HDMI device to the HDMI 1 or

HDMI 2 jack on the side of your TV or to the

HDMI 3 or HDMI 4 jack on the back of your TV.

An HDMI picture can be displayed only when a

640 × 480, 480P, 720P, or 1080P signal is received.

To connect an HDMI device to the back of

your TV:

1 Make sure the TV’s power cord is unplugged

and the HDMI device is turned off.

2 Connect an HDMI cable to the HDMI 3 or

HDMI 4 jack on the back of your TV and to the

HDMI OUT jack on the HDMI device.

3 Turn on your TV, then turn on the HDMI device.

4 Press INPUT to open the source list, press or

to highlight HDMI 3 or HDMI 4, then press

ENTER.

Note

The connectors on AV cables are often color-coded.

Yellow is video, white is left audio, and red is right

audio.

Note

You can also press VIDEO once to select A/V 1.

Camcorder of game console

Side of TV

Note

You can also press HDMI three times to select

HDMI 3 or four times to select HDMI 4.

You can also attach a DVI device to the HDMI 4 jack. If

you connect a DVI device, you must also make an

audio connection. Connect the audio to the

AUDIO L/R jacks below the HDMI jacks on the back

of your TV. Only the HDMI 4 jack supports DVI.

Back of TV

HDMI device

NS-L42Q120-10A/NS-L46Q120-10A 42"/46" LCD TV

www.insigniaproducts.com

To connect an HDMI device to the side of

your TV:

1 Make sure the TV’s power cord is unplugged

and the HDMI device is turned off.

2 Connect an HDMI cable to the HDMI 1 or

HDMI 2 jack on the side of your TV and to the

HDMI OUT jack on the HDMI device.

3 Turn on your TV, then turn on the HDMI device.

4 Press INPUT to open the source list, press or

to highlight HDMI 1 or HDMI 2, then press

ENTER.

Connecting a component video device

A component (Y, Pb, Pr) picture can be displayed

only when a 480i, 480P, 720P, or 1080i signal is

received.

To connect to a component video device:

1 Make sure the TV’s power cord is unplugged

and the component video device is turned off.

2 Connect a component video cable to the

COMPONENT IN 1 or COMPONENT IN 2 jacks

on the back of your TV and to the COMPONENT

VIDEO OUT jacks on the component video

device.

3 Connect an audio cable to the L and R audio

jacks below the corresponding COMPONENT IN

jacks and to the COMPONENT OUT AUDIO

jacks on the component video device.

4 Turn on your TV, then turn on the component

video device.

5 Press INPUT to open the source list, press or

to highlight COMPONENT 1 or

COMPONENT 2, then press ENTER.

Note

You can also press HDMI once to select HDMI 1 or

twice to select HDMI 2.

Side of TV

HDMI device

Note

The connectors on audio cables are often

color-coded.

White is left audio, and red is right audio.

Note

You can also press COMP once to select

COMPONENT 1 or twice to select COMPONENT 2.

Component video device

Back of TV

NS-L42Q120-10A/NS-L46Q120-10A 42"/46" LCD TV

www.insigniaproducts.com

Connecting an S-Video device

To connect an S-Video device to the back of your

TV:

1 Make sure the TV’s power cord is unplugged

and the S-Video device is turned off.

2 Connect an S-Video cable to the VIDEO IN 2

S-VIDEO jack on the back of your TV and to the

S-VIDEO OUT jack on the S-Video device.

3 Connect an audio cable to the VIDEO IN 2 L

and R audio jacks on the back of your TV and to

the AUDIO OUT jack on the S-Video device.

4 Turn on your TV, then turn on the component

S-Video device.

5 Press INPUT to open the source list, press or

to highlight A/V 2, then press ENTER.

To connect an S-Video device to the side of your

TV:

1 Make sure the TV’s power cord is unplugged

and the S-Video device is turned off.

2 Connect an S-Video cable to the VIDEO IN 1

S-VIDEO jack on the side of your TV and to the

S-VIDEO OUT jack on the S-Video device.

3 Connect an audio cable to the VIDEO IN 1 L

and R audio jacks on the side of your TV and to

the AUDIO OUT jack on the S-Video device.

4 Turn on your TV, then turn on the component

video device.

5 Press INPUT to open the source list, press or

to highlight A/V 1, then press ENTER.

Note

The connectors on audio cables are often

color-coded.

White is left audio, and red is right audio.

Note

You can also press VIDEO twice to select the device

connected to the VIDEO IN 2 S-VIDEO jack.

S-Video device

Back of TV

Note

The connectors on audio cables are often

color-coded.

White is left audio, and red is right audio.

Note

You can also press VIDEO once to select the device

connected to the VIDEO IN 1 S-VIDEO jack.

S-Video device

Side of TV

NS-L42Q120-10A/NS-L46Q120-10A 42"/46" LCD TV

www.insigniaproducts.com

Connecting a computer

To connect a computer:

1 Make sure the TV’s power cord is unplugged

and the computer is turned off.

2 Connect a VGA cable to the VGA jack on the

side of your TV and to the VGA jack on the

computer.

3 Connect an audio cable to the VGA AUDIO jack

on the side of your TV and to the AUDIO OUT

jack on the computer.

4 Turn on your TV, then turn on the computer.

5 Press INPUT to open the source list, press or

to highlight VGA, then press ENTER.

Connecting a digital audio amplifier

To connect a digital audio amplifier:

1 Make sure the TV’s power cord is unplugged

and the amplifier is turned off.

2 Connect a digital optical (Toslink) audio cable to

the AUDIO OUT SPDIF jack on the back of your

TV and to the SPDIF AUDIO IN jack on the

digital audio amplifier.

3 Turn on your TV, then turn on the digital audio

amplifier and set it to the correct output mode.

See the documentation that came with the

amplifier for more information.

Connecting an analog audio amplifier

To connect an analog audio amplifier:

1 Make sure the TV’s power cord is unplugged

and the amplifier is turned off.

2 Connect an audio cable to the AUDIO OUT L

and R on the back of your TV and to the AUDIO

IN L and R jacks on the analog audio amplifier.

3 Turn on your TV, then turn on the analog audio

amplifier and set it to the correct output mode.

See the documentation that came with the

amplifier for more information.

Side of TV

Digital audio amplifier

Back of TV

Note

The connectors on audio cables are often

color-coded.

White is left audio, and red is right audio.

Analog audio amplifier

Back of TV

NS-L42Q120-10A/NS-L46Q120-10A 42"/46" LCD TV

www.insigniaproducts.com

Turning your TV on for the

first time

The first time you turn on your TV, the Setup Wizard

opens. The Setup Wizard guides you through

setting up basic settings including the menu

language, TV signal source, and the channel list.

To set up your TV:

1 Make sure that you have:

• Installed the remote control batteries. (See

page 8 for details).

• Connected an antenna, cable TV, or satellite

TV. (See page 13 through page 14 for details.)

• Connected the power cord. (See page 13 for

details.)

2 Press (power) to turn on your TV. It may take

several seconds for the Choose your menu

language screen to open.

3 Press or to highlight a language, then press

ENTER. The Choose your TV source screen opens.

4 Press or to highlight the TV signal source,

then press ENTER to start scanning for channels

in that signal. You can select:

• Antenna—VHF and UHF channels

• Cable—Cable TV channels (no cable box).

• Cable/Satellite Box—Cable or satellite TV

tuner box. Channel auto scan is not necessary

if you select this option.

The channel scan may take a few minutes

depending on the signal strength and the

number of available channels. When the scan is

complete, the first scanned channel is displayed.

Understanding the basics

Turning your TV on or off

To turn you TV on or off:

1 Make sure that the power cord is connected to

your TV and to a power outlet.

2 Press (power) to turn on your TV. It may take

several seconds for an image to appear on the

screen.

3 Press (power) to turn off your TV. Your TV

enters standby mode.

Selecting the video input source

To select the video input source:

1 With your TV turned on, press INPUT. The Source

List opens.

2 Press or to highlight the video input

source, then press ENTER.

You can also press a direct input button to select

the video input source.

• Press TV to select TV.

• Press VIDEO once to select A/V 1(for VIDEO

IN 1 VIDEO or VIDEO IN 1 S-VIDEO).

• Press VIDEO twice to select VIDEO IN 2

VIDEO or VIDEO IN 2 S-VIDEO.

• Press COMP once to select Component 1.

• Press COMP twice to select Component 2.

Note

Unless otherwise noted, all tasks in this section are

based on using the remote control.

Warning

When your TV is off, power still flows into it. To

disconnect power, unplug the power cord.

Note

If your TV does not detect an input signal for several

minutes, your TV goes into standby mode

automatically.

NS-L42Q120-10A/NS-L46Q120-10A 42"/46" LCD TV

www.insigniaproducts.com

• Press HDMI once to select HDMI 1.

• Press HDMI twice to select HDMI 2.

• Press HDMI three times to select HDMI 3.

• Press HDMI four times to select HDMI 4.

On-screen menu overview

Picture menu

Audio menu

Channel menu

Settings menu

Navigating the menus

To navigate the menus:

1 Press MENU. The on-screen menu opens.

2 Press or to highlight a primary menu, then

press ENTER. You can select:

• PICTURE

• AUDIO

• CHANNEL

• SETTINGS

3 Press or to highlight a setting, then press

ENTER to access the submenu.

4 Press or to highlight a setting selection,

then press ENTER.

Or,

Press or to adjust a setting level, then press

ENTER.

5 Press MENU to return to the previous menu, or

press EXIT to close the menu.

Selecting a channel

To select a channel:

• Press CH or CH to go to the next higher or

lower channel in the channel list.

• Press the number buttons to directly select a

channel. For example, if you want to view

channel 83, press 8, then press 3.

• Press RECALL to go to the last viewed

channel.

• Press the number buttons for a main DTV

channel, press —, then press the number for a

DTV sub-channel to go to a digital

sub-channel. For example, to go to

sub-channel 1 of main channel 83, press 8, 3,

—, then 1.

Note

To automatically switch the input source whenever a

new device is connected, turn on the Auto Input

Sensor feature. See “Turning the Auto Input Sensor

on or off” on page 37.

Notes

• Button presses must be within three seconds of

each other.

• You can press the number buttons to go to a

channel that was skipped in the channel

scanning.

NS-L42Q120-10A/NS-L46Q120-10A 42"/46" LCD TV

www.insigniaproducts.com

Adjusting the volume

To adjust the volume:

• Press VOL – or VOL + to decrease or increase

the volume. A volume level display appears on

the screen.

• Press MUTE to turn off the sound. Press MUTE

again to restore the sound back.

Displaying additional information

To display additional information:

• Press INFO. Your TV displays channel information.

• Digital mode information—Displays the

channel number, station name, channel label

(if assigned), broadcast program name, TV

rating, signal type, audio information,

resolution, CC mode, current time, and current

program start and end times.

• Analog mode information—Displays the

channel number, channel label (if assigned),

signal type, audio information, and resolution.

• Press GUIDE. The electronic program guide (EPG)

opens and displays information about the current

channel, such as a program list, program times,

and program rating. Detailed information about

the program is often included.

Press or to view more information about

programs on the selected channel. Press GUIDE

again to close the EPG.

Adjusting the picture

Adjusting the TV picture

To adjust the TV picture:

1 Press MENU. The on-screen menu opens.

2 Press or to highlight PICTURE, then

press ENTER. The Picture menu opens.

3 Press or to highlight a setting, then press

ENTER to access the submenu. You can select:

• Mode—See “Selecting the picture mode” on

page 23.

• Brightness—Adjusts the black level. This

setting determines the point where grays

become pure black.

• Contrast—Adjusts the white level. This

setting determines how bright the brightest

whites should appear.

• Color—Adjusts the color intensity.

• Tint—Adjusts the balance of the red, green,

and blue colors in the display.

• Sharpness—Adjusts the sharpness or

softness of the display.

• Advanced Video—See “Adjusting advanced

video settings” on page 23.

4 Press or to highlight a setting option, then

press ENTER.

Or,

Press or to adjust a setting level, then press

ENTER.

5 Press MENU to return to the previous menu, or

press EXIT to close the menu.

Note

EPG availability and content depends on the channel

broadcaster.

Note

Unless otherwise noted, all tasks in this section are

based on using the remote control.

NS-L42Q120-10A/NS-L46Q120-10A 42"/46" LCD TV

www.insigniaproducts.com

Adjusting the computer image

To adjust the computer image:

1 Connect a computer to your TV. See

“Connecting a computer” on page 18.

2 Press MENU. The on-screen menu opens.

3 Press or to highlight SETTINGS, then

press ENTER. The Settings menu opens.

4 Press or to highlight Computer Settings,

then press ENTER.

5 Press or to highlight a setting, then press

ENTER to access the submenu. You can select:

• Auto Adjust—Automatically adjusts the

computer image to the best settings.

• H. Position—Moves the computer image left

or right.

• V. Position—Moves the computer image up

or down.

• Clock—Adjusts the sample frequency.

• Phase—Adjusts the focus to stabilize the

image.

6 Press or to highlight a setting option, then

press ENTER.

Or,

Press or to adjust a setting level, then press

ENTER.

7 Press MENU to return to the previous menu, or

press EXIT to close the menu.

Changing the aspect ratio

To change the aspect ratio with the ZOOM

button:

• Press ZOOM one or more times to select an

aspect ratio. The display changes as you go

through the options and your TV displays the

currently selected aspect ratio.

To change the aspect ratio using the on-screen

menu:

1 Press MENU. The on-screen menu opens.

2 Press or to highlight PICTURE, then

press ENTER. The Picture menu opens.

3 Press or to highlight Advanced Video,

then press ENTER. The Advanced Video menu

opens.

4 Press or to highlight Aspect Ratio, then

press ENTER.

5 Press or to highlight an aspect ratio, then

press ENTER. You can select:

• Normal—The picture is displayed in a 4:3

aspect ratio.

• Zoom—The picture is displayed to cover the

entire screen.

• Wide—The picture uses a widescreen aspect

ratio.

• Cinema—The picture is displayed in a 21:9

aspect ratio.

6 Press MENU to return to the previous menu, or

press EXIT to close the menu.

Note

The default aspect ratio for all input sources, except

TV, is Wide. For TV, the default setting is Normal.

NS-L42Q120-10A/NS-L46Q120-10A 42"/46" LCD TV

www.insigniaproducts.com

Selecting the picture mode

To change the aspect ratio with the PICT button:

• Press PICT one or more times to select a picture

mode. Your TV displays the currently selected

picture mode.

To select the picture mode using the on-screen

menu:

1 Press MENU. The on-screen menu opens.

2 Press or to highlight PICTURE, then

press ENTER. This Picture menu opens.

3 Press or to highlight Mode, then press

ENTER.

4 Press or to highlight a picture mode, then

press ENTER. You can select:

• Vivid—Increases color and sharpness for a

vibrant picture display.

• Standard—Displays the picture in its original

display mode.

• Theater—Displays the picture in a quality

suited for viewing under dim lighting

conditions to deliver a “movie house”

experience.

• Sport—Displays the picture in high contrast

display for clear-cut images that are ideal for

viewing sports events.

• Energy Saving—Reduces the picture

brightness and backlight levels for lower

power consumption.

• Custom—When you adjust the Brightness,

Contrast, Color, Tint, and Sharpness settings

in the Picture menu, this mode is automatically

selected.

5 Press MENU to return to the previous menu, or

press EXIT to close the menu.

Adjusting advanced video settings

To adjust advanced video settings:

1 Press MENU. The on-screen menu opens.

2 Press or to highlight PICTURE, then

press ENTER.

3 Press or to highlight PICTURE, then

press ENTER. The Picture menu opens.

4 Press or to highlight Advanced Video,

then press ENTER. The Advanced Video menu

opens.

5 Press or to highlight a setting, then press

ENTER. You can select:

• Backlight—Adjusts the LCD backlight to suit

the current viewing condition.

• Aspect Ratio—See “Changing the aspect

ratio” on page 22.

• Overscan—Extends part of the display past

the visible area of the screen. The resulting

picture will “zoom in” on the image center. You

can select On or Off.

• Color Temperature—Adjusts the white level

of in the display. Options include:

• Cool—Pictures appear with a bluish tint.

• Normal—Pictures appear more white.

• Warm—Pictures appear more reddish.

• Noise Reduction—Improves picture quality

by filtering out unusable data (“noise”) from

video signals. You can select On or Off.

• Blue Stretch—Increases the blue component

of white and near white pixels to achieve a

more natural looking display. You can select

On or Off.

NS-L42Q120-10A/NS-L46Q120-10A 42"/46" LCD TV

www.insigniaproducts.com

• DCM—Delivers clear and fast action images

by reducing motion blur in fast-paced

programming like sports. Image refresh rate

increases to 120 frames per second (120 Hz).

You can select Disable, Low, Normal, or High.

• Advanced Contrast—Sets advanced contrast

settings. You can select:

• Adaptive Contrast—Automatically

adjusts the picture detail and brightness.

• Dynamic Contrast Ratio—Enhances

contrast between the light and dark areas

of the picture. This feature enables

automatic contrast adjustment based on

the picture brightness.

6 Press or to highlight a setting option, then

press ENTER.

Or,

Press or to adjust a setting level, then press

ENTER.

7 Press MENU to return to the previous menu, or

press EXIT to close the menu.

Fitting the picture to the screen

In TV mode only, your TV can automatically adjust

the picture so that everything fits in the visible

space of the screen.

To fit the picture to the screen:

1 Press MENU. The on-screen menu opens.

2 Press or to highlight CHANNEL, then

press ENTER. The Channel menu opens.

3 Press or to highlight Auto Zoom, then

press ENTER.

4 Press or to highlight On or Off, then press

ENTER.

5 Press MENU to return to the previous menu, or

press EXIT to close the menu.

Freezing the picture

There may be instances when you want to jot down

information displayed on the TV but you have no

pen handy. In such cases, you can “lock” the current

display in place.

To freeze the picture:

• Press FREEZE once to “lock” the current display in

place.

• Press the button again to resume the regular

programming.

Adjusting the sound

Selecting the audio mode

When the Equalizer setting in the Audio menu is

set to on, you can press AUDIO to select the audio

mode. If the Equalizer setting is set to Off, you can

select the audio mode from the on-screen menu.

To select the audio mode when the Equalizer

setting is set to On.:

• Press AUDIO one or more times to select the

audio mode. Your TV displays the currently

selected audio mode.

To select the audio mode when the Equalizer

setting is set to Off:

1 Press MENU. The on-screen menu opens.

2 Press or to highlight AUDIO, then press

ENTER. The Audio menu opens.

3 Press or to highlight Equalizer, then press

ENTER.

4 Press or to highlight On, then press ENTER.

5 Press or to highlight Equalizer Mode, then

press ENTER.

6 Press or to highlight an equalizer mode,

then press ENTER. You can select Standard,

Music, Theater, News, or Custom.

7 Press MENU to return to the previous menu, or

press EXIT to close the menu.

Note

Unless otherwise noted, all tasks in this section are

based on using the remote control.

NS-L42Q120-10A/NS-L46Q120-10A 42"/46" LCD TV

www.insigniaproducts.com

Selecting the sound mode or audio language

To select the sound mode in analog TV mode:

• Press SAP one or more times to select a sound

mode. You can select

• Mono —Select this option if there is noise or

static from a weak broadcast signal.

• Stereo—Select this option for programs

broadcast in stereo sound.

• SAP—Select this option to listen to an

alternative audio language (if available).

To select an audio language in digital TV mode:

• Press SAP one or more times to select an audio

language (if available).

Adjusting audio settings

To adjust audio settings:

1 Press MENU. The on-screen menu opens.

2 Press or to highlight AUDIO, then press

ENTER. The Audio menu opens.

3 Press or to highlight an option, then press

ENTER. You can select:

• Equalizer—Sets the audio frequency

response to the optimum level. When turned

on, the Bass and Treble settings are replaced

with:

• Equalizer Mode—Selects one of the

preset EQ modes.

• Equalizer Settings—Adjusts the EQ

settings.

• Treble—Adjusts the high sounds. When the

Equalizer setting is turned off, you can press

AUDIO to access the Treble setting.

• Bass—Adjust the low sounds. When the

Equalizer setting is turned off, you can press

AUDIO to access the Bass setting.

• Balance—Adjusts the balance between the

left and right audio channels.

• Auto Volume—Applies the audio settings to

both digital and analog channels.

• Advanced Audio—Highlight this option, then

press ENTER to access advanced audio

settings.

• Digital Audio/SPDIF—Selects the

preferred audio format for digital audio

signals. This feature is only available on

digital channels or when using an HDMI

device. You can select PCM or RAW.

• Audio Language—Selects the default

language track when watching digital TV

programs. You can select English,

Français, and Español. Languages must

be provide by the broadcaster.

• MTS/SAP—Select the default language

stream when watching analog or digital TV

channels. For more information, see

“Selecting the sound mode or audio

language” on page 25.

• Reset Audio Settings—Resets the audio

settings to the defaults.

4 Press or to highlight a setting option, then

press ENTER.

Or,

Press or to adjust a setting level, then press

ENTER.

5 Press MENU to return to the previous menu, or

press EXIT to close the menu.

Playing audio only

To play audio only:

1 Press MENU. The on-screen menu opens.

2 Press or to highlight CHANNEL, then

press ENTER. The Channel menu opens.

3 Press or to highlight Auto Only, then press

ENTER.

4 Press or to highlight On or Off, then press

ENTER.

5 Press MENU to return to the previous menu, or

press EXIT to close the menu.

Changing channel settings

Automatically scanning for channels

You do not need to scan for channels unless:

• The channels in your area have changed since you

ran the Setup Wizard.

• You change the TV signal source. For example,

you change from an antenna to cable TV.

To automatically scan for channels:

1 Press MENU. The on-screen menu opens.

2 Press or to highlight CHANNEL, then

press ENTER. The Channel menu opens.

Note

Unless otherwise noted, all tasks in this section are

based on using the remote control.

NS-L42Q120-10A/NS-L46Q120-10A 42"/46" LCD TV

www.insigniaproducts.com

3 Press or to highlight Auto Channel

Search, then press ENTER.

4 Press or to highlight the TV signal source,

then press ENTER. Your TV starts scanning for

channels. You can select:

• Antenna— VHF and UHF channels

• Cable—Cable TV channels (no cable box).

• Cable/Satellite Box— Cable or satellite TV

tuner box. You do not need to scan for

channels if your use a tuner box.

The channel scan may take a few minutes

depending on the signal strength and the

number of available channels. When the scan is

complete, your TV displays the first scanned

channels.

Hiding channels

You can hide scanned channels. When your press

CH or CH , your TV skips the hidden channel.

You can still access the channel by pressing the

number buttons.

To hide channels:

1 Press MENU. The on-screen menu opens.

2 Press or to highlight CHANNEL, then

press ENTER. The Channel menu opens.

3 Press or to highlight Add/Skip Channels,

then press ENTER.

4 Press or to select the channel you want

to hide, then press ENTER. If a channel has a

check mark, you can tune to the channel when

you press CH or CH . If the channel does not

have a check mark, it is hidden.

5 Press MENU to return to the previous menu, or

press EXIT to close the menu.

Setting up a favorite channel list

To set up a favorite channel list:

1 Press MENU. The on-screen menu opens.

2 Press or to highlight CHANNEL, then

press ENTER. The Channel menu opens.

3 Press or to highlight Favorites, then press

ENTER.

Note

To add a channel back, select the channel and press

ENTER.

NS-L42Q120-10A/NS-L46Q120-10A 42"/46" LCD TV

www.insigniaproducts.com

4 Press or to select the channel you want

to add to the favorites list, then press ENTER. If a

channel has a check mark, it is in the favorites

list.

5 Press MENU to return to the previous menu, or

press EXIT to close the menu.

To tune to a favorite channel:

1 Press FAV to open the favorite channel list.

2 Press or to highlight a channel. If the list

has more than one page, or to go to the

previous or next page.

3 Press FAV to close the list and tune to the

selected channel.

Labeling a channel

You can assign labels to channels to make them

easier to identify. A channel label can consist of up

to 11 characters. You can use letters, numbers, and

the underscore symbol (_).

To label a channel:

1 Press MENU. The on-screen menu opens.

2 Press or to highlight CHANNEL, then

press ENTER. The Channel menu opens.

3 Press or to highlight Channel Labels, then

press ENTER.

4 Press or to highlight the channel you want

to label, then press ENTER or . The on-screen

keyboard opens.

5 Press or to highlight a character, then

press ENTER. The characters you enter appear

on the display bar above the keyboard.

• To toggle between upper and lower case,

highlight Caps Lock, then press ENTER.

• To delete a character, highlight the backspace

symbol ( ), then press ENTER.

6 When the label is correct, highlight Enter, then

press ENTER.

7 Press MENU to return to the previous menu, or

press EXIT to close the menu.

Viewing the digital TV signal strength

To view the digital TV signal strength:

1 Press MENU. The on-screen menu opens.

2 Press or to highlight CHANNEL, then

press ENTER. The Channel menu opens.

3 Press or to highlight Channel Strength,

then press ENTER. The Channel Strength screen

opens and displays the signal strength. If

necessary, adjust the antenna to improve the

signal strength.

4 Press MENU to return to the previous menu, or

press EXIT to close the menu.

NS-L42Q120-10A/NS-L46Q120-10A 42"/46" LCD TV

www.insigniaproducts.com

Setting parental controls

Your TV supports V-Chip technology. This lets you

set up the content your children can view. When

parental controls are set, your TV reads the program

rating (with some exceptions, such as news and

sports) and denies access to those programs that

exceed the ratings level you selected.

To use set the parental controls, you must first set a

password.

Setting the password

The first time you access the Parental Controls

submenu, you will be prompted to set the

password.

To set the password:

1 Press MENU. The on-screen menu opens.

2 Press or to highlight SETTINGS, then

press ENTER. The Settings menu opens.

3 Press or to highlight Parental Controls,

then press ENTER. The Enter Password screen

opens.

4 Press the number buttons to enter your

password. You do not need to press ENTER.

After you enter your password, the Parental

Controls menu opens.

Changing the password

To change the password:

1 Press MENU. The on-screen menu opens.

2 Press or to highlight SETTINGS, then

press ENTER. The Settings menu opens.

3 Press or to highlight Parental Controls,

then press ENTER. The Enter Password screen

opens.

Note

Unless otherwise noted, all tasks in this section are

based on using the remote control.

NS-L42Q120-10A/NS-L46Q120-10A 42"/46" LCD TV

www.insigniaproducts.com

4 Press the number buttons to enter your

password. You do not need to press ENTER.

After you enter your password, the Parental

Controls menu opens.

5 Press or to highlight Change Password,

then press ENTER. The Change Password screen

opens.

6 Press the number buttons to enter your new

password, then enter the new password again.

7 Press MENU to return to the previous menu, or

press EXIT to close the menu.

Setting parental control levels

To set parental control levels:

1 Press MENU. The on-screen menu opens.

2 Press or to highlight SETTINGS, then

press ENTER. The Settings menu opens.

3 Press or to highlight Parental Controls,

then press ENTER. The Enter Password screen

opens.

4 Press the number buttons to enter your

password. You do not need to press ENTER.

After you enter your password, the Parental

Controls menu opens.

5 Press or to highlight USA Parental Locks

or Canadian Parental Locks, then press ENTER.

One of the following screens opens:

NS-L42Q120-10A/NS-L46Q120-10A 42"/46" LCD TV

www.insigniaproducts.com

6 Press or to highlight a rating, then

press ENTER. A lock icon next to a rating

indicates that the rating is locked. An unlock

icon indicates the rating is not locked.

7 Press MENU to return to the previous menu, or

press EXIT to close the menu.

USA age-based TV program ratings

USA content-based TV program ratings

USA movie ratings

Canadian English ratings

Canadian French ratings

Blocking unrated TV

Not all TV programs have a rating signal. You can

block all unrated programs from displaying on your

TV.

To block unrated TV:

1 Press MENU. The on-screen menu opens.

2 Press or to highlight SETTINGS, then

press ENTER. The Settings menu opens.

3 Press or to highlight Parental Controls,

then press ENTER. The Enter Password screen

opens.

Rating Description

TV-Y Suitable for young children

TV-Y7 May not be suitable for children under 7

TV-G Suitable for all audiences

TV-PG Parental guidance suggested

TV-14 Parental guidance suggested for children under 14

TV-MA

Suitable for mature audiences only; may be

unsuitable for children under 17

Rating Description

Fantasy violence, combative situations

Suggestive dialogue

Coarse language

Sexual situations

Violence

Note

Selecting a lower age-based rating block takes

precedence over content-rating designation.

Rating Description

Contains nothing most parents will consider

offensive for even their youngest children to see or

hear; suitable for young children.

May contain some material parents might not like

to expose to their young children—material that

will clearly need to be examined or inquired about

before children are allowed to view the film.

PG-13

May contain some scenes of drug use; use of one of

the harsher sexually-derived words may be heard.

May be inappropriate for pre-teens.

May contain some adult material. Parents are urged

to learn more about the film before letting their

children view it.

NC-17

May contain explicit sex scenes, an accumulation of

sexually-oriented language, or scenes of excessive

violence. Suitable for adult audiences only. Rating

does not signify that the film is obscene or

pornographic.

Contains extreme violence or explicit sex; suitable

for adults audiences only.

Rating Description

C Suitable for viewing by children of all ages

C8+ Not suitable for children under 8 years of age

G Suitable for general audiences

PG Parental guidance advised

14+ Suitable for people 14 years of age or older

18+ Suitable for people 18 years of age or older

Rating Description

GFor general audiences

8 ans+ Not suitable for children under 8 years of age

13 ans+ Not suitable for persons under 13 years of age

16 ans+ Not suitable for persons under 16 years of age

18 ans+ Not suitable for persons under 18 years of age

NS-L42Q120-10A/NS-L46Q120-10A 42"/46" LCD TV

www.insigniaproducts.com

4 Press the number buttons to enter your

password. You do not need to press ENTER.

After you enter your password, the Parental

Controls menu opens.

5 Press or to highlight Block Unrated TV,

then press ENTER.

6 Press or to highlight On, then press ENTER.

To remove the block, select Off.

7 Press MENU to return to the previous menu, or

press EXIT to close the menu.

Viewing blocked content

You can temporarily unblock blocked content.

To view blocked content:

1 Tune it to the blocked program you want to

watch.

2 When you see the warning message indicating

the content is blocked, press the number

buttons to enter in your password.

The content restriction will be temporarily

disabled. When the TV is turned off, when the

channel is changed, or when the video input

source is changed, the content restriction is

reactivated.

Using downloaded rating information

Additional RRT5 (regional rating tables) applicable

in your area are automatically downloaded to your

TV’s memory. To use one of the RRT5 ratings, you to

need to turn them on first.

To use downloaded rating information:

1 Press MENU. The on-screen menu opens.

2 Press or to highlight SETTINGS, then

press ENTER. The Settings menu opens.

3 Press or to highlight Parental Controls,

then press ENTER. The Enter Password screen

opens.

4 Press the number buttons to enter your

password. You do not need to press ENTER.

After you enter your password, the Parental

Controls menu opens.

NS-L42Q120-10A/NS-L46Q120-10A 42"/46" LCD TV

www.insigniaproducts.com

5 Press or to highlight RRT5, then press

ENTER. The RRT5 screen opens.

6 Press or to highlight a RRT category, then

press or to turn the category on.

7 Press MENU to return to the previous menu, or

press EXIT to close the menu.

Locking control panel buttons

To lock control panel buttons:

1 Press MENU. The on-screen menu opens.

2 Press or to highlight SETTINGS, then

press ENTER. The Settings menu opens.

3 Press or to highlight Parental Controls,

then press ENTER. The Enter Password screen

opens.

4 Press the number buttons to enter your

password. You do not need to press ENTER.

After you enter your password, the Parental

Controls menu opens.

5 Press or to highlight Button Lock, then

press ENTER.

6 Press or to highlight On, then press ENTER.

7 Press MENU to return to the previous menu, or

press EXIT to close the menu.

NS-L42Q120-10A/NS-L46Q120-10A 42"/46" LCD TV

www.insigniaproducts.com

Using closed captioning

Closed caption availability and content depends on

the channel broadcaster and may vary across

programs in that channel.

To turn closed captioning on or off with the CCD

button:

• Press CCD one or more times. You can select CC

On, CC On Mute, or CC Off.

To turn closed captioning on or off using the

on-screen menu:

1 Press MENU. The on-screen menu opens.

2 Press or to highlight SETTINGS, then

press ENTER. The Settings menu opens.

3 Press or to highlight Closed Caption, then

press ENTER. The Closed Caption menu opens.

4 Press or to highlight Caption Control, then

press ENTER.

5 Press or to highlight CC On, CC On Mute,

or CC Off, then press ENTER.

6 Press MENU to return to the previous menu, or

press EXIT to close the menu.

Selecting the closed captioning mode

Most closed captioning content can be found

within the CC1 setting for analog TV and within the

CS1 setting for digital TV.

To select the closed captioning mode:

1 Press MENU. The on-screen menu opens.

2 Press or to highlight SETTINGS, then

press ENTER. The Settings menu opens.

3 Press or to highlight Closed Caption, then

press ENTER. The Closed Caption menu opens.

Note

Unless otherwise noted, all tasks in this section are

based on using the remote control.

NS-L42Q120-10A/NS-L46Q120-10A 42"/46" LCD TV

www.insigniaproducts.com

4 Press or to highlight Analog Caption or

Digital Caption. One of the following menus

opens.

5 Press or to highlight the mode you want,

then press ENTER.

6 Press MENU to return to the previous menu, or

press EXIT to close the menu.

Customizing the DTV closed captioning style

To customize the DTV closed captioning style:

1 Press MENU. The on-screen menu opens.

2 Press or to highlight SETTINGS, then

press ENTER. The Settings menu opens.

3 Press or to highlight Closed Caption, then

press ENTER. The Closed Caption menu opens.

4 Press or to highlight Digital CC Settings,

then press ENTER.

5 Press or to highlight Style, then press

ENTER.

6 Press or to highlight Custom, then press

ENTER.

7 Press or to highlight the style you want to

customize, then press ENTER. You can select

Style, Size, Font, Text Color, Text Opacity,

Background Color, Background Opacity, Edge

Effect, and Edge Color.

8 Press or to adjust the style, then press

ENTER.

9 Press MENU to return to the previous menu, or

press EXIT to close the menu.

Note

The Text Co lor and Background Color options

cannot be the same.

NS-L42Q120-10A/NS-L46Q120-10A 42"/46" LCD TV

www.insigniaproducts.com

Adjusting time settings

Manually setting the date and time

To manually set the date and time:

1 Press MENU. The on-screen menu opens.

2 Press or to highlight SETTINGS, then

press ENTER. The Settings menu opens.

3 Press or to highlight Date/Time, then press

ENTER. The Time menu opens.

4 Press or to highlight Date/Time, then press

ENTER. The Date/Time menu opens.

5 Press or to highlight Mode, then press

ENTER.

6 Press or to highlight Custom, then press

ENTER.

7 Press or to highlight an option, then press

ENTER. You can select:

•Time Zone

•Daylight Savings

• Year

•Month

•Day

•Time

8 Press or to adjust the setting, then press

ENTER. If you selected the Time option, press

or to move between the hour, minute, and

AM/PM fields.

9 Press MENU to return to the previous menu, or

press EXIT to close the menu.

Setting the sleep timer

To set the sleep timer using the SLEEP button:

• Press SLEEP one or more times to select the

amount of time you want your TV to wait before it

automatically turns off. The turn off the sleep

timer, press SLEEP until Off appears on the

screen.

To set the sleep time using the on-screen menu:

1 Press MENU. The on-screen menu opens.

2 Press or to highlight SETTINGS, then

press ENTER. The Settings menu opens.

Note

Unless otherwise noted, all tasks in this section are

based on using the remote control.

Note

If Mode is set to Auto, the clock setting is

automatically synced to a digital channel that

broadcasts time information. The rest of the clock

settings are not configurable.

NS-L42Q120-10A/NS-L46Q120-10A 42"/46" LCD TV

www.insigniaproducts.com

3 Press or to highlight Time, then press

ENTER. The Time menu opens.

4 Press or to highlight Sleep Timer, then

press ENTER. The Sleep Timer menu opens.

5 Press or to highlight the amount of time

you want your TV to wait before it automatically

turns off, then press ENTER. To turn off the sleep

timer, select Off.

6 Press MENU to return to the previous menu, or

press EXIT to close the menu.

Adjusting menu settings

Selecting the menu language

To select the menu language:

1 Press MENU. The on-screen menu opens.

2 Press or to highlight SETTINGS, then

press ENTER. The Settings menu opens.

3 Press or to highlight Menu Settings, then

press ENTER.

4 Press or to highlight Language, then press

ENTER. The Language menu opens.

5 Press or to highlight the language you

want, then press ENTER.

6 Press MENU to return to the previous menu, or

press EXIT to close the menu.

Adjusting the menu transparency

To adjust the menu transparency:

1 Press MENU. The on-screen menu opens.

2 Press or to highlight SETTINGS, then

press ENTER. The Settings menu opens.

3 Press or to highlight Menu Settings, then

press ENTER.

4 Press or to highlight Transparency, then

press ENTER.

5 Press or to adjust the transparency.

Adjusting left increases the transparency.

Adjusting right decrease the transparency.

Note

Unless otherwise noted, all tasks in this section are

based on using the remote control.

NS-L42Q120-10A/NS-L46Q120-10A 42"/46" LCD TV

www.insigniaproducts.com

6 Press MENU to return to the previous menu, or

press EXIT to close the menu.

Labeling a video input source

You can assign labels to the video jacks on your TV

to make it easier to identify the devices connected

to them. These labels are displayed when you press

INPUT and INFO.

A video input label can consist of up to 11

characters. You can use letters, numbers, and the

underscore symbol (_).

To label a video input source:

1 Press MENU. The on-screen menu opens.

2 Press or to highlight SETTINGS, then

press ENTER. The Settings menu opens.

3 Press or to highlight Input Labels, then

press ENTER.

4 Press or to highlight the input jack you

want to label, then press ENTER. The on-screen

keyboard opens.

5 Press or to highlight a character, then

press ENTER. The characters you enter appear

on the display bar above the keyboard.

• To toggle between upper and lower case,

highlight Caps Lock, then press ENTER.

• To delete a character, highlight the backspace

symbol ( ), then press ENTER.

6 When the label is correct, highlight Enter, then

press ENTER.

7 Press MENU to return to the previous menu, or

press EXIT to close the menu.

Turning the Auto Input Sensor on or off

When the Auto Input Sensor feature is turned on,

your TV automatically detects and switches to a

new input connection. For example, your TV will

automatically switch to HDMI mode when an HDMI

device is connected.

To turn Auto Input Sensor on or off:

1 Press MENU. The on-screen menu opens.

2 Press or to highlight SETTINGS, then

press ENTER. The Settings menu opens.

3 Press or to highlight Auto Input Sensor,

then press ENTER.

4 Press or to highlight On or Off, then press

ENTER.

5 Press MENU to return to the previous menu, or

press EXIT to close the menu.

NS-L42Q120-10A/NS-L46Q120-10A 42"/46" LCD TV

www.insigniaproducts.com

Restoring factory defaults

To restore factory defaults:

1 Press MENU. The on-screen menu opens.

2 Press or to highlight SETTINGS, then

press ENTER. The Settings menu opens.

3 Press or to highlight Reset to Default, then

press ENTER. A confirmation message appears.

4 Press or to highlight Ye s , then press ENTER.

5 Press MENU to return to the previous menu, or

press EXIT to close the menu.

Manufacturers’ codes

Audio amplifiers

Audio accessories

Audio amplifiers

Adcom 30577, 31100

Anthem 32220

Bose 30674

Carver 30892

Durabrand 31561

Elan 30647

GE 30078

Harman/Kardon 30892

JVC 30331

Left Coast 30892

Lenoxx 31561

Marantz 30892

McIntosh 30251

Modulaire 30395

NEC 30264

Optimus 30395, 30823

Philips 30892

Pioneer 30823

Polk Audio 30892

RadioShack 30395

RCA 30823

Realistic 30395

Shure 30264

Sony 30689, 30815

Soundesign 30078

Victor 30331

Wards 30078

Yamaha 30354, 30133

Audio accessories

Accurian 31106

Altec Lansing 30607, 31056

Apple 31115

Creative 30872

DLO 31155

GPX 32113

Griffin 31891

iDeck 31106

iHome 32152

iLive 32113

Imerge 31491

iPort 31917

Klipsch 31339

Marantz 31491

Memorex 32119

Monitor Audio 31106

Motorola 31464

Omnifi 31605

Roku 31828

Sonance 31917

Yamaha 31809, 31810, 32021

NS-L42Q120-10A/NS-L46Q120-10A 42"/46" LCD TV

www.insigniaproducts.com

Audio receivers

Cable converters

Audio receivers

ADC 30531

Adcom 30616

Aiwa 31405, 30189, 30121, 31089, 31388, 31641

Akai 30244, 31512

Alco 31390

AMC 31077

Amphion Media Works 31563

AMW 31563

Anam 31609, 31074

Anthem 31185

Apex Digital 31257, 31430, 31774

Arcam 31189

Audiotronic 31189

Audiovox 31390

B & K 30702, 30820, 30840

BK 30702

Bose 31229, 30639, 31253, 31629, 31841, 31933

Cairn 30189

Cambridge Soundworks 31370

Capetronic 30531

Carver 31189, 30189, 30121, 31089, 31289

Coby 31389

Curtis Mathes 30014

Daewoo 31250

Denon 31360, 30121, 31104, 31142, 31306, 32857

Emerson 30531

Fisher 31801

Garrard 30463

Grundig 30189

Harman/Kardon 30110, 30189, 30891, 31289, 31304, 31306,

32241

Hitachi 31273, 31801

iLive 32013

Inkel 30491

Insignia 31030, 31077, 31893, 32169, 32175

Integra 30135, 30842, 31298, 31320, 31805

iSymphony 32258

JBL 30110, 31306

JVC 31058, 30074, 31374, 31495, 31871, 32239

Kawasaki 31390

Kenwood 31313, 31570, 30077, 30186, 31027

KLH 31390, 31412, 31428

Koss 31366, 31497

Lexicon 31076

LG 31293, 32197

Linn 30189

Liquid Video 31497

Magnavox 31189, 31269, 30189, 30391, 30531, 31089,

31266,31514

Marantz 31189, 31269, 30189, 30891, 31089, 31289

McIntosh 31289

Micromega 31189, 30189

Mitsubishi 31393

Musicmagic 31089

Myryad 31189

Nakamichi 31313, 30097, 31555

Norcent 31389

Nova 31389

Onkyo 30135, 30842, 31298, 31320, 31531, 31805,

31905

Optimus 31023, 30074, 30014, 30121, 30186, 30531,

31074

Oritron 31366, 31497

Outlaw 30391

Panasonic 31308, 31518, 30367, 31275, 31288, 31316,

31548,31633, 31763, 31764

Philips 31189, 31269, 30189, 30391, 30891, 31089,

31266

Pioneer 31023, 30014, 30150, 30244, 30531, 30630,

31123,31384, 31935

Polaroid 31508

Polk Audio 30189, 31289

Proscan 31254

RadioShack 31609

RCA 31023, 31609, 31254, 30531, 31074, 31123,

31390,31511

Realistic 31609, 30121, 30186

Revox 30189

Rio 31869

Samsung 31295, 31304, 31500

Sangean 32165

Sansui 31189, 30189, 31089

Sanyo 31251, 31469, 31801

Sharp 30186, 31286

Sharper Image 31556

Sherwood 30491, 31077, 31653, 31905, 32169

Sherwood Newcastle 32169

Sonic Blue 31869

Sonic Frontiers 31185

Sony 31058, 31441, 31258, 31759, 31622, 30474,

31158,31406, 31558, 31658, 31758, 31822,

31858

Stereophonics 31023

Sunfire 31313

Teac 30463, 31074, 31390, 31528

Technics 31308, 31518, 31633

Thorens 31189

Toshiba 30135, 30842, 31123, 31788

Venturer 31390

Victor 30074

Wards 30189, 30014

XM 31406

Yamaha 31023, 30176, 30186, 30376, 31176, 31276,

31331,31375, 31376, 31476, 31815, 32061

Zenith 30857, 31293

Cable converters

A-Mark 00008,00144

ABC 00237,00003,00008

Accuphase 00003

Acorn 00237

Action 00237

Active 00237

ADB 02586

Americast 00899

Amino 01602,01822

Audio receivers

NS-L42Q120-10A/NS-L46Q120-10A 42"/46" LCD TV

www.insigniaproducts.com

Cable/PVR combos

CD players

Archer 00237

BCC 00276

Bell South 00899

British Telecom 00003

Century 00008

Cisco 01877,00877,01982

Clearmaster 00883

ClearMax 00883

Cool Box 00883

Coolmax 00883

Digeo 01187, 02187

Director 00476

Fosgate 00276

GE 00144

General Instrument 00476,00810,00276,00003

Gibralter 00003

GMI 00883

GoldStar 00144

Hamlin 00009,00273

Hitachi 00003,00008, 00009

i3 Micro 01602

Insight 00476,00810

Jerrold 00476,00810, 00276, 00003

Memorex 00000

Mitsubishi 00003

Motorola 01376,00476, 00810, 00276, 01187, 01106,

01982

Multitech 00883

Myrio 01602,01822

Nova Vision 00008

Novaplex 00008

Pace 01877,00877,00237,00008,01982

Panasonic 00000,00008,00144,00107,01982

Paragon 00000,00008, 00525

Penney 00000

Philips 01305,00317

Pioneer 01877,00877, 00144, 00533

Pulsar 00000

Quasar 00000

RadioShack 00883

RCA 01256

Regal 00276,00279,00273

Runco 00000

Samsung 00003,00144,01982

Scientific Atlanta 01877,00877,00477,00237,00003,00000,00008,0

1982

Sejin 01602

Sony 01006

Sprucer 00144

Starcom 00003

Supercable 00276

Supermax 00883

Thomson 01256

Cable converters

Cable/PVR combos

Americast 00899

Amino 01822

Cisco 01877, 01982

Digeo 01187, 02187

General Instrument 00810

Jerrold 00810

Motorola 01376, 00810, 01187, 01106, 01982

Myrio 01822

Pace 01877, 00237, 01982

Pioneer 01877

RCA 01256

Scientific Atlanta 01877, 01982

Sony 01006

Supercable 00276

Thomson 01256

Zenith 00899

CD players

Acoustic Research 30420

Aiwa 30157

Arcam 30157

Audio Research 30157

Burmester 30420

Cairn 30157

California Audio Labs 30029

Cambridge Soundworks 30157

Carver 30157

Curtis Mathes 30032

Denon 30034

DKK 30000

DMX Electronics 30157

Fisher 30000

Garrard 30393,30420

Genexxa 30032

Grundig 30157

Hafler 30173

Harman/Kardon 30100,30157,30173

Hitachi 30032

Inkel 30157,30180

Integra 30101

JVC 30032,30072

Kenwood 30626,30000,30029,30028,30190

KLH 31318,31711

Krell 30157

Linn 30157

Magnavox 30157,30038,30274

Marantz 30626,30029,30157,30038,30180,30435

Matsui 30157

McIntosh 30256,30290,30660

MCS 30029

Memorex 30000, 30032,30420

Micromega 30157

Miro 30000

Mission 30157

Modulaire 30000,30032,30087,30180,30420

MTC 30420

NS-L42Q120-10A/NS-L46Q120-10A 42"/46" LCD TV

www.insigniaproducts.com

DVD players

Myryad 30157

NSM 30157

Onkyo 31327,30101

Optimus 30000,30032,30087,30393,30420

Panasonic 30029,30388,30752

Parasound 30420

Penney 30029

Philips 30626,30157,30274

Pioneer 31062,30032,31087

Polk Audio 30157

Proceed 30420

Proton 30157

QED 30157

Quad 30157

Quasar 30029

RadioShack 30000,30032,30180,30420

RCA 31062, 30032,30053,30420

Realistic 30000,30032,30087,30180,30420

Revox 30157

Roksan 30435

Rotel 30157,30420

SAE 30157

Sansui 30000,30157

Sanyo 30000,30087

Sharp 30180

Sherwood 30180

Sonic Frontiers 30157

Sony 30490,30000,30100,31364,30185

Sugden 30157

Sylvania 30157

Symphonic 30180

TAG McLaren 30157

Tandy 30032

Tascam 30393,30420

Teac 30490,30180,30393,30420

Technics 30029

Thule Audio 30157

Victor 30072

Wards 30032,30157,30053,30087

Yamaha 30490,30036,31292

Yorx 30000

DVD players

3D LAB 20503, 20539

Accurian 20675, 21072, 21416

Advent 21016

Afreey 20698

Aiwa 20641

Akai 20695, 20705, 20770, 20899, 21089

Alba 20672, 20717

Alco 20790

Allegro 20869

Amphion Media Works 20872

AMW 20872

Apex Digital 20533, 20672, 20717, 20755, 20794, 20796,

20797, 20830, 21004, 21020, 21056, 21061,

21100

CD players

Arrgo 21023

Aspire Digital 21168, 21407

Astar 21489

Audiovox 20717, 20790, 21041, 21071, 21072, 21121,

21122

Axion 21071, 21072

B & K 20655, 20662

BBK 21224

Bel Canto Design 21571

Blaupunkt 20717

Blue Parade 20571

Blue Sky 20695

Bose 21895, 22023

Brandt 20651

Broksonic 20695, 20868

California Audio Labs 20490

Celestial 21020

Centrex 20672, 21004

Cinea 20831

CineVision 20876, 20833, 20869

Citizen 21003, 20695, 21277

Clairtone 20571

Coby 20778, 21077, 21086, 21107, 21177

Craig 20831

Creative 20503, 20539

Curtis Mathes 21087

CyberHome 20816, 20874, 21023, 21024, 21117, 21129,

21502, 21537

Cytron 20705

Daewoo 20784, 20705, 20770, 20833, 20869, 21169,

21172, 21234, 21242

Dansai 20770

Daytek 20872

Decca 20770

Denon 20490, 20634, 22258

Denver 20778

Desay 21407

DigitalMax 21738

Digitrex 20672

Disney 20675, 21270

DiViDo 20705

Dual 20675, 21068, 21085

Durabrand 21127

DVD2000 20521

Electrohome 21003

Emerson 20591, 20675, 20821, 21268

Enterprise 20591

Entivo 20503, 20539

Enzer 20770

ESA 20821, 21268

Firstline 20651

Fisher 20670

Funai 20675, 21268, 21334

Gateway 21073, 21077, 21158

GE 20522, 20815, 20717

Go Video 20573, 20744, 20717, 20715, 20741, 20783,

20833, 20869, 21044, 21075, 21099, 21158,

21304, 21730

Go Vision 21071, 21072

DVD players

NS-L42Q120-10A/NS-L46Q120-10A 42"/46" LCD TV

www.insigniaproducts.com

GoldStar 20741, 20869

Goodmans 20790

Gradiente 20490, 20651

Greenhill 20717

Grundig 20539, 20705

Harman/Kardon 20582, 20702

Hello Kitty 20831

Hitachi 20573, 20664, 21247

Hiteker 20672

Humax 21500, 21588

iLo 21348

Initial 20717

Insignia 21268

Integra 20571, 20627, 21769

IRT 20783

JBL 20702

Jensen 21016

JMB 20695

JVC 20558, 20623, 20867, 21164, 21275, 21550

Kawasaki 20790

Kenwood 20490, 20534

KLH 20717, 20790, 21020, 21149

Kloss 20533

Koss 20651, 21061

Lasonic 20627, 20798

Lecson 21533

Lenoxx 21127

LG 20591, 20741, 20869

LiteOn 21058, 21158, 21416, 21440, 21656, 21738

Loewe 20511, 20741

Logix 20783

Magnasonic 20651, 20675

Magnavox 20503, 20539, 20646, 20675, 20821, 21268,

21354, 21506

Marantz 20503, 20539, 20675

McIntosh 21533, 21273

Medion 20651

Memorex 20695, 20831, 21270

Microsoft 20522, 22083

Minato 20752

Mintek 20839, 20717

Mitsubishi 21521, 20521

NAD 20741

Naiko 20770

NEC 20785, 20869

Nesa 20717

NexxTech 21402

Norcent 21003, 20872, 21107, 21265

Onkyo 20503, 20627, 21769

Oppo 20575, 21224

Optimus 20571

Oritron 20651

Palsonic 20672

Panasonic 20503, 20490, 20571, 20632, 20703, 21362,

21462, 21490, 21641, 21762

Philco 20675

Philips 20503, 20539, 20646, 20675, 20854, 21260,

21267, 21340, 21354, 22056, 22084

PianoDisc 21024

DVD players

Pioneer 20525, 20571, 20142, 20631, 20632, 21460,

21512, 21571

Polaroid 21020, 21061, 21086

Polk Audio 20539

Portland 20770

Presidian 20675, 21072, 21738

Prima 21016

Proceed 20672

Proscan 20522

ProVision 20778

Qwestar 20651

Radionette 20741

RadioShack 20571

RCA 20522, 20571, 20717, 20790, 20822, 21022,

21132, 21769

Realistic 20571

Reoc 20752

Rio 20869

Rotel 20623, 21178

Rowa 20823, 21004

Saba 20651

Sampo 20698, 20752

Samsung 20490, 20573, 20744, 20199, 20820, 20899,

21044, 21075

Sansui 20695

Sanyo 20670, 20675, 20695, 20873, 21334

Schneider 20783

Schwaiger 20752

Sensory Science 21158

Sharp 20630, 20675, 20752, 21256, 22250

Sharper Image 21117

Sherwood 20770, 21043, 21077

Sherwood Newcastle 21077

Shinsonic 20533, 20839

Slim Art 20784

Sonic Blue 20573, 20715, 20783, 20869, 21099

Sony 20533, 21533, 20864, 21033, 21070, 21431,

21516

Sova 21122

Superscan 20821

SVA 20717

Sylvania 20675, 20821, 21268

Symphonic 20675, 20821, 21268, 21334

Tatung 20770

Teac 20571, 20717, 20790

Technics 20490, 20703

Technika 20770

Terapin 21031

Tevion 20651

Theta Digital 20571

Thomson 20522, 20511

Tivo 21503, 21512, 21588

Toshiba 20503, 20573, 20539, 20695, 21045, 21154,

21503, 21510, 21588, 21769

Unimax 20770

Universum 20591

Urban Concepts 20503, 20539

US Logic 20839

V 21064, 21226

DVD players

NS-L42Q120-10A/NS-L46Q120-10A 42"/46" LCD TV

www.insigniaproducts.com

DVD players (Blu Ray and HD-DVD)

DVD/PVR combos controlled by the DVD

Home automation

DVR/PVR Systems for satellite receivers

Venturer 20790

Vizio 21064, 21226

Xbox 20522, 22083

Yamaha 20490, 20539, 20545

Yamakawa 20872

Zenith 20503, 20591, 20741, 20869

Zeus 20784

Zoece 21265

DVD players (Blu Ray and HD-DVD)

Denon 22258

Integra 21769

LG 20741

Microsoft 22083

Onkyo 21769

Panasonic 21641

Philips 22084

Pioneer 20142

RCA 21769

Samsung 20199

Sharp 22250

Sony 21516

Toshiba 21769

Xbox 22083

DVD/PVR combos controlled by the DVD

Go Video 21730

Humax 21500, 21588

LG 20741

Panasonic 20490

Philips 21340

Pioneer 20631, 21512

RCA 20522

Sharp 21256

Sony 21033, 21070

Sylvania 20675

Tivo 21512

Toshiba 21503, 21510, 21588

Home automation

Accutek 31215

Amana 31716

Bionaire 30846, 31215, 31861

Da-Lite 31794

Draper 32190

Frigidaire 31333

GE 30240

GoldStar 31537

Holmes 31215

Kenmore 31537

Lasko 30846, 31890

LG 31537

Lightolier 30184

Lutron 30597, 30318, 31239, 31597

Marmitek 30167

DVD players

One For All 30167

PCS 30184

RadioShack 30240

Screen Research 32097

Security System 30167

Sharper Image 30846

SmartLinc 30184

Universal 30167

Universal X10 30167

Whirlpool 31332

Windmere 31215

X10 30167

DVR/PVR systems for satellite receivers

AlphaStar 00772

Bell ExpressVu 00775, 01170

Chaparral 00216

Coolsat 01806

Crossdigital 01109

DirecTV 01377, 00392, 00566, 00639, 01639, 01142,

00247, 00749, 01749, 00819, 01856, 01076,

01108, 00099, 01109, 01392, 01414, 01442,

01443, 01444, 01609, 01640

Dish Network System 01505, 00775, 01170, 01775

Dishpro 01505, 00775, 01775

Echostar 01505, 00775, 01170, 01775

Expressvu 00775, 01775

Fortec Star 01821

Funai 01377

GE 00392, 00566

General Instrument 00869

GOI 00775, 01775

Hitachi 00749, 00819

Houston 00775

HTS 00775, 01775

Hughes Network

Systems

01142, 00749, 01749, 01442, 01443, 01444

Humax 01790

Innova 00099

Jerrold 00869

JVC 00775, 01170, 01775

LG 01226, 01414

Magnavox 00722

McIntosh 00869

Mitsubishi 00749

Motorola 00869

Netsat 00099

Next Level 00869

Panasonic 00247, 00701

Pansat 01807

Philips 01142, 00749, 01749, 00775, 00819, 01076,

00722, 00099, 01442

Primestar 00869

Proscan 00392, 00566

RadioShack 00566, 00775, 00869

RCA 00392, 00566, 01142, 00775, 00855, 00143,

01392, 01442

Samsung 01377, 01142, 01276, 01108, 01109, 01442,

01609

Home automation

NS-L42Q120-10A/NS-L46Q120-10A 42"/46" LCD TV

www.insigniaproducts.com

TVs

SKY 00099

Sony 00639, 01639, 01640

Star Choice 00869

Star Trak 00772, 00869

Thomson 00392, 00566

Tivo 01142, 01442, 01443, 01444

Toshiba 00749, 01749, 00790, 01285

UltimateTV 01392, 01640

Ultrasat 01806

Uniden 00722

Voom 00869

Zenith 01856

TVs

A-Mark 10047, 10054

Accurian 11803

Accuscan 10047

Action 10030, 10873

Admiral 10047, 10054, 10017, 10051, 10093, 10463,

10180

Advent 10761, 10783, 10815, 10817, 10842

Adventuri 10000

Agna 10150

Aiko 10092

Akai 10060, 10812, 10702, 10030, 10145, 10056,

10672, 11675, 11676, 11935

Albatron 10700, 10843

Alfide 10672

Alleron 10030

Ambassador 10150, 10177

America Action 10180

American High 10000, 10060

Ampro 10751

Amstrad 10171, 10177

Amtron 10000, 10180

Anam 10180

AOC 10180, 10030, 11365

Aomni 11623

Apex Digital 10156, 10748, 10879, 10765, 10767, 10890,

11217

Astar 11531, 11738

Audinac 10180

Audiovox 10451, 10180, 10092, 10623, 10802, 10846,

10875, 11937, 11951, 11952

Aventura 10171

Axion 11937

Baysonic 10180

Beaumark 10017, 10178, 10030

Belcor 10030

Bell & Howell 10054, 10154, 10093

BenQ 11032, 11212, 11315

Boxlight 10893

Bradford 10180

Brockwood 10178, 10030, 10056

Broksonic 10236, 10463, 10180, 10177, 11935

Byd:sign 11309

Candle 10030, 10056

Capehart 10017, 10178, 10030, 10092

DVR/PVR systems for satellite receivers

Carnivale 10030

Carver 10054

Celebrity 10000

Celera 10765

Changhong 10156, 10765, 10767, 10783

Cineral 10451, 10092

Citek 10047

Citizen 10054, 10000, 10451, 10463, 10180, 10060,

10030, 10171, 10092, 10056, 11935

Clarion 10180

Classic 10030, 10092, 10056

Colortyme 10047, 10054, 10017, 10060, 10178, 10030

Commercial Solutions 11447, 10047

Concerto 10056

Conic 10178

Contec 10180

Craig 10180, 10171

Crosley 10054, 10000, 10180, 10030, 10171

Crown 10093, 10180, 10056, 10672

Crown Mustang 10672

Curtis Mathes 10047, 10054, 10154, 10000, 10051, 10451,

10093, 10180, 10060, 10702, 10178, 10030,

10145, 10166, 10056, 10466, 11147, 11347

CXC 10180

Cytron 11326

Daewoo 10451, 10178, 10092, 11661, 11756, 10623,

10661, 10672, 11755

Dayton 10092

Daytron 10178, 10030, 10092, 10056

Dell 11080, 11178, 11264, 11403, 11863

Denon 10145

Digital Life 10872

Dream Vision 11164

Dumont 10017, 10180, 10178

Durabrand 10463, 10180, 10178, 10171, 11034

Dwin 10093, 10720, 10774

Dynex 11463, 11780, 11785, 11810

Eaton 10060

Electroband 10000

Electrograph 11623, 11755

Electrohome 10154, 10000, 10463, 10150, 10178, 10030,

10056

Emerald 10178, 10177

Emerson 10047, 10154, 10451, 10236, 10463, 10180,

10150, 10178, 10171, 10177, 10623, 11394,

11963

Emprex 11422

Envision 10030, 10813, 11365

Epson 10833, 10840

ESA 10812, 10171, 11963

Fisher 10054, 10154, 10000

Fortress 10093

Fujitsu 10683, 10809, 10853

Funai 10000, 10180, 10171, 11271, 11963

Futuretech 10180

Gateway 11756, 11755

GE 11447, 10047, 10000, 10051, 10451, 10060,

10178, 10030, 11147, 11347

Gemini 10047

Gibralter 10017, 10000, 10030

TVs

NS-L42Q120-10A/NS-L46Q120-10A 42"/46" LCD TV

www.insigniaproducts.com

Go Video 10886

Go Vision 11937

GoldStar 10047, 10054, 10178, 10030, 10056, 11154

Gradiente 10053, 10056

Grundig 10706, 10672, 10683

Grundy 10180

Grunpy 10180

Haier 11034

Hallmark 10236, 10180, 10178

Hannspree 11348, 11351, 11745

Harley Davidson 10000, 10180, 10060, 10178, 10030

Harman/Kardon 10054

Harvard 10180

Havermy 10093

Heathkit 10017

Helios 10865

Hello Kitty 10451

Hewlett Packard 11494, 11502, 11642

Hisense 10748

Hitachi 10047, 10054, 10017, 10000, 10051, 11145,

10145, 10056, 11445, 11643

HP 11494, 11502, 11642

Hyundai 10849, 10865, 11219, 11294

iLo 11286, 11603, 11684, 11990

Ima 10236, 10180, 10178

Infinity 10054

InFocus 11164

Initial 11603, 11990

Insignia 10171, 11204, 11326, 11517, 11564, 11641,

11710, 11780, 11963, 12002

Inteq 10017, 10145

JBL 10054

JCB 10000

Jensen 10761, 10815, 10817

JIL 10030

Jutan 10030

JVC 10054, 10053, 10030, 10650, 10731, 11253,

11774

Kamp 10017, 10180

Kawasho 10030

KEC 10180, 10060

Kenwood 10180, 10030

KLH 10156, 10180, 10765, 10767

Kloss 10030

Konka 10180, 10720

KTV 10463, 10180, 10030

Lark 10154

LG 10054, 11265, 10060, 10178, 10030, 10056,

10700, 10856, 11154, 11178, 11423, 11993

Lloyd's 10236, 10180, 10030, 10056

Logik 10236, 10180, 10056

Luxman 10056

LXI 10047, 10054, 10017, 10154, 10000, 10156,

10051, 10093, 10060, 10053, 10178, 10030,

10171, 10166, 10056

Magnasonic 10054, 10000, 10156, 10093, 10030, 10092,

10056

Magnavox 10047, 11454, 10054, 10154, 10000, 10250,

10051, 10180, 10060, 10030, 10171, 10092,

10706, 10802, 11198, 11254, 11365, 11755,

11866, 11963, 11990

TVs

Majestic 10017

Marantz 11454, 10054, 10030, 10704, 10855, 11154,

11398

Matsui 10056, 10177

Matsushita 10250, 10051, 10650

Maxent 11756, 10762, 11211, 11714, 11755, 11757

Megapower 10700

Megatron 10047, 10178, 10145, 10056

Memorex 10154, 10463, 10180, 10150, 10178, 10030,

10056

MGA 10150, 10178, 10030

MGN Technology 10178

Micro Genius 10150

Midland 10047, 10017, 10051, 10056

Mintek 11603, 11990

Mitsubishi 10154, 10093, 11250, 10150, 10178, 10030,

10836, 10868, 11392

Monivision 10700, 10843

Motorola 10054, 10051, 10093, 10150

MTC 10180, 10060, 10030, 10092, 10056

Multitech 10180

NAD 10156, 10178, 10166, 10056, 10866, 11156

NEC 10047, 10178, 10030, 10056, 10497, 10704,

10882, 11398, 11704

NetTV 10762, 11755

New Tech 10056

Nikko 10178, 10030, 10092

Nikkodo 10178, 10030, 10092

Nishi 10030

Norcent 10748, 10824, 11365

Norwood Micro 11286

NTC 10092

Nyon 10000

Olevia 11144, 11240, 11331, 11610

Onwa 10180

Optimus 10154, 10250, 10093, 10180, 10150, 10178,

10030, 10166, 10056, 10650

Optoma 11348

Optonica 10093

Orion 10017, 10236, 10463, 10180, 10178, 11463,

10177

Pace 10092

Panasonic 10054, 10000, 10156, 10250, 10051, 10236,

10030, 10650, 11291, 11310, 11410, 11480,

11941

Panda 10706

Paxonic 10060, 10030

PCE 10156, 10060

Penney 10047, 10000, 10156, 10250, 10051, 10060,

10178, 10030, 10056, 11347

Petters 11523

Philco 10054, 10463, 10030, 10145

Philips 11454, 10054, 10030, 10171, 10056, 10690,

11154, 11254, 11744, 11867

Pilot 10051, 10060, 10178, 10030, 10056

Pioneer 10166, 10679, 10866, 11260, 11398, 11457

Planar 11496

Polaroid 10765, 10865, 11276, 11314, 11326, 11328,

11341, 11523, 11766, 12002

Portland 10451, 10092

Precision 10236, 10180, 10177

TVs

NS-L42Q120-10A/NS-L46Q120-10A 42"/46" LCD TV

www.insigniaproducts.com

Prima 10761, 10783, 10815, 10817, 11785

Princeton 10700, 10717

Prism 10250, 10051

Proscan 11447, 10047, 10466, 11347

Proton 10178, 10466

Pulsar 10017, 10092

Pulser 10178, 10092

Quartz 10150, 10178

Quasar 10250, 10051, 10650

Rabbit 10047

RadioShack 10047, 10154, 10180, 10150, 10178, 10030,

10056

RCA 11447, 10047, 10054, 10000, 10051, 10093,

10178, 12002, 11958, 11781, 11547, 11347,

11247, 11147, 11047, 10774, 10679, 10090

Realistic 10047, 10154, 10180, 10150, 10178, 10030,

10056

RevolutionHD 11623

Runco 10017, 10060, 10030, 10497, 10603, 11292,

11398, 11629

Sampo 10047, 10030, 11756, 10762, 11755

Samsung 10047, 10054, 10017, 10154, 10060, 10812,

10702, 10178, 10030, 10056, 10587, 10766,

10814, 11060, 11575

Sanky 10060, 10030

Sansui 10463, 10060, 10030, 11409, 11935

Sanyo 10047, 10054, 10154, 10000, 10463, 10171,

10088, 10799, 10893, 11142, 11755

Saville 10060

Sceptre 10878, 11217, 11360, 11599

Scotch 10178

Scott 10236, 10180, 10178, 10030, 10177, 11711

Sears 10047, 10054, 10017, 10154, 10000, 10156,

10051, 10093, 10060, 10053, 10178, 10030,

10171, 10166, 10056

Seleco 11351

Sharp 10054, 10093, 10180, 10491, 10688, 10689,

10818, 10851, 11602

Sheng Chia 10093

Shivaki 10178

Siemens 10145

Signature 10047, 10093, 10030

Simpson 10178, 10030

Singer 10060, 10092

Solar Drape 10000

Sole 10813, 11623

Sony 10017, 10154, 11100, 10000, 10150, 10053,

10834, 11685

Soundesign 10180, 10178, 10056

Sova 11952

Soyo 11520, 11826

Spectravision 10156, 10178

Squareview 10171

SR2000 10154, 10171

SSS 10180

Starlite 10236, 10180

Studio Experience 10843

Superscan 10093, 10864

Supreme 10000

SV2000 10054

SVA 10748, 10587, 10865, 10870, 10871, 10872

TVs

Sylvania 10047, 10054, 10154, 10000, 10051, 10178,

10030, 10171, 10092, 10056, 11271, 11314,

11394, 11864, 11963

Symphonic 10000, 10180, 10178, 10171

Syntax 11144, 11240, 11331, 11610

Tandy 10093

Tatung 10000, 10051, 11756, 11286

Teac 10154, 10706, 10689

Technics 10054, 10250, 10051

Technovox 10030

Techview 10847, 12004

Techwood 10250, 10051, 10060, 10056

Teco 11040

Teknika 10054, 10463, 10180, 10150, 10060, 10178,

10092, 10056

Telecolor 10017

Telefunken 10702, 10056

Thomas 10047, 10178, 10056

Thomson 11447, 10047

TMK 10236, 10180, 10178, 10056, 10177

TNCi 10017

Tocom 10156

Toshiba 10154, 11256, 10156, 10150, 11265, 10060,

11145, 10145, 10166, 12006, 11935, 11704,

11656, 11635, 11524, 11356, 11164, 11156,

10845, 10832, 10822, 10650

Totevision 10051

Toyomenka 10178

Truetone 10250, 10051

TruTech 11723

TVS 10463

Ultra 10092

Universal 10047

Universum 10177

US Logic 11286

V 11756, 10864, 10885, 11755

Vector Research 10030

Victor 10053

Vidikron 10054, 11292, 11398, 11629

Vidtech 10178

Viewsonic 10857, 10864, 10885, 11330, 11578, 11627,

11640, 11755, 12014

Viking 10060

Viore 11684

Vizio 11756, 11758, 10864, 10885, 11755

Wards 10047, 10054, 10017, 10154, 10000, 10051,

10093, 10236, 10178, 10030, 10166, 10056,

10866, 11156

Waycon 10156

Welton 10178

Westinghouse 10000, 10451, 10885, 10889, 10890, 11282,

11577, 11712

White Westinghouse 10451, 10236, 10463, 10623, 10889

World 10451, 10236, 10463, 10180

Wyse 11365

XR-1000 10154, 10180, 10171

Yamaha 10030, 10769, 10833, 10839, 11526

Yorx 10030

Zenith 10047, 10017, 10000, 10093, 10463, 11265,

10812, 10178, 10030, 11145, 10145, 10171,

10092

TVs

NS-L42Q120-10A/NS-L46Q120-10A 42"/46" LCD TV

www.insigniaproducts.com

TV/DVD combination controlled by the DVD

TV/DVD combination controlled by the TV

TV/VCR combination controlled by the TV

TV/VCR combination controlled by the VCR

TV/VCR/DVD combination controlled by the DVD

TV/DVD combination controlled by the DVD

Advent 21016

Akai 20695

Apex Digital 20830

Audiovox 21071, 21121, 21122

Axion 21071

Broksonic 20695

Citizen 20695

Emerson 20675, 21268

ESA 21268

Funai 21268

Go Vision 21071

Hitachi 21247

Insignia 21268

Jensen 21016

Magnavox 21268

Panasonic 21490

Philips 20854, 21260

Prima 21016

RCA 21022

Samsung 20899

Sansui 20695

Sova 21122

Sylvania 20675, 21268

Toshiba 20695

TV/DVD combination controlled by the TV

Accurian 11803

Akai 11675, 11935

Audiovox 11937, 11951, 11952

Axion 11937

Broksonic 11935

Citizen 11935

Dynex 11810

Emerson 11394, 11963

ESA 11963

Funai 11963

iLo 11990

Initial 11990

Insignia 11963, 12002

LG 11993

Magnavox 11866, 11963, 11990

Maxent 11714

Mintek 11990

Panasonic 11941

Polaroid 11523, 11766, 12002

RCA 11958, 12002

Sansui 11935

Sova 11952

Sylvania 11394, 11864, 11963

Techview 12004

Toshiba 11524, 11635, 11935, 12006

TV/VCR combination controlled by the TV

America Action 10180

Audiovox 10180

Emerson 10236

TV/VCR combination controlled by the VCR

Broksonic 20479, 21479

Citizen 21278

Curtis Mathes 21035

Daewoo 21278

Emerson 20479, 20593, 21278, 21479

Funai 20000

GE 20807, 21035, 21060

GoldStar 21237

Harley Davidson 20000

Hitachi 20000

LG 21037

Lloyd's 20000

Magnasonic 20593, 21278

Magnavox 20000, 20593, 21781

Memorex 20162, 21037, 21162, 21237, 21262

Mitsubishi 20807

Optimus 20162, 20593, 21162, 21262

Orion 20479, 21479

Panasonic 20162, 21035, 21162, 21262

Penney 21035, 21237

Quasar 20162, 21035, 21162

RadioShack 20000, 21037

RCA 20807, 21035, 21060

Samsung 21014

Sansui 20000, 20479, 21479

Sears 20000, 21237

Sony 20000, 21232

Sylvania 21781

Symphonic 20000, 20593

Thomas 20000

Toshiba 20845, 21145

Zenith 20000, 20479, 21479

TV/VCR/DVD combination controlled by the DVD

Akai 20899

Broksonic 20868

Emerson 20821

ESA 20821

Funai 21334

Magnavox 20821

Panasonic 21362, 21462

RCA 21132

Sharp 20630

Superscan 20821

Sylvania 20821

Symphonic 20821

Toshiba 21045

NS-L42Q120-10A/NS-L46Q120-10A 42"/46" LCD TV

www.insigniaproducts.com

TV/VCR/DVD combination controlled by the VCR

VCRs

TV/VCR/DVD combination controlled by the VCR

Sharp 20807

VCRs

A-Mark 20037, 20000, 20046

ABS 21972

Accurian 20000

Admiral 20060, 20048, 20039, 20209, 20479

Adventura 20037, 20000

Aiwa 20037, 20000

Alba 20209

Alienware 21972

Allegro 20039

American High 20035, 20081

Amstrad 20000

Astra 20035

Audiovox 20037, 20038

Avis 20000

Bell & Howell 20035, 20048, 20039, 20000, 20046, 20479

Broksonic 20184, 20121, 20209, 20479, 21479

Calix 20037

Candle 20037, 20038

Canon 20035

Carver 20035, 20081

Citizen 20035, 20037, 20000, 20209, 20479, 21278

Classic 20037

Colortyme 20060, 20035, 20045

Colt 20000

Craig 20037

Criterion 20000

Crosley 20035, 20081, 20000, 20149

Curtis Mathes 20060, 20035, 20162, 20000, 21035

CyberPower 21972

Daewoo 20037, 20045, 20046, 21278

Daytron 20037

Dell 21972

Denon 20081, 20042

DirecTV 20739

Dual 20000

Durabrand 20039, 20038

Dynatech 20000

Electrohome 20060, 20037, 20000, 20043, 20209

Electrophonic 20037

Emerald 20184, 20121

Emerex 20032

Emerson 20037, 20184, 20000, 20121, 20043, 20209,

20479, 20593, 21278, 21479, 21593

Fisher 20039, 20000, 20046

Fuji 20035, 20033

Fujitsu 20000

Funai 20037, 20000, 20593, 21593

Garrard 20000

Gateway 21972

GE 20060, 20035, 20048, 20000, 20149, 20807,

21035, 21060

Gemini 20060

Genexxa 20037, 20000

Go Video 20614

GoldStar 20035, 20037, 20039, 20000, 20038, 21237

Goodmans 20037, 20081, 20000

Gradiente 20000

Granada 20081, 20042

Grundig 20081

Harley Davidson 20000

Harman/Kardon 20081, 20038

Headquarter 20046

Hewlett Packard 21972

HI-Q 20035, 20000

Hitachi 20035, 20037, 20045, 20000, 20042, 20089

Howard Computers 21972

HP 21972

Hughes Network

Systems

20042, 20739

Humax 20739

Hush 21972

Hytek 20000

iBUYPOWER 21972

Instant Replay 20035

Jensen 20067

JVC 20067, 21162

KEC 20037

Kenwood 20067, 20038, 20046

Kodak 20035, 20037

KTV 20000

LG 20037, 20038, 21037

Linksys 21972

Lloyd's 20000, 20038

Loewe 20081

Logik 20000

Luxor 20046

LXI 20037, 20000, 20042, 20067

Magnasonic 20037, 20000, 20593, 21278

Magnavox 20035, 20037, 20048, 20039, 20081, 20000,

20149, 20563, 20593, 20618, 21593, 21781

Marantz 20035, 20081, 20038

Marta 20037

Matsui 20037, 20209

Matsushita 20035, 20162, 20081, 21162

Media Center PC 21972

MEI 20035

Memorex 20035, 20162, 20037, 20048, 20039, 20000,

20209, 20046, 20479, 21037, 21162, 21237,

21262

Metz 20037

MGA 20060, 20043

Microsoft 21972

Mind 21972

Minolta 20042

Mitsubishi 20060, 20048, 20000, 20042, 20067, 20043,

20807

Motorola 20035, 20048

MTC 20000

MTX 20000

Multitech 20039, 20000

NEC 20067, 20038

Nikko 20037

VCRs

NS-L42Q120-10A/NS-L46Q120-10A 42"/46" LCD TV

www.insigniaproducts.com

Video Accessories

Nikkodo 20037

Niveus Media 21972

Northgate 21972

Olympus 20035, 20162

Optimus 21062, 20035, 20162, 20037, 20048, 20000,

20593, 21162, 21262

Orion 20184, 20000, 20121, 20209, 20479, 21479

Panama 20035

Panasonic 21062, 20035, 20162, 20000, 20225, 20614,

20616, 21035, 21162, 21262 Penney 20035,

20162, 20037, 20081, 20000, 20042, 20067,

20038, 21035, 21237

Pentax 20042

Philco 20035, 20081, 20000, 20209, 20479

Philips 20035, 20162, 20048, 20081, 20045, 20000,

20209, 20616, 20618, 20739, 21081, 21181

Pilot 20037

Pioneer 20162, 20081, 20042, 20067

Polk Audio 20081

Presidian 21593

Proscan 20060, 21060

Protec 20000

Pulsar 20039

Quarter 20046

Quartz 20035, 20046

Quasar 20035, 20162, 21035, 21162

RadioShack 20035, 20162, 20037, 20048, 20000, 20046,

21037, 21162

Radix 20037

Randex 20037

RCA 20060, 20035, 20048, 20045, 20000, 20042,

20149, 20807, 20880, 21035, 21060

Realistic 20035, 20162, 20037, 20048, 20000, 20121,

20046, 21162

ReplayTV 20614, 20616

Ricavision 21972

Runco 20039

Samsung 20060, 20045, 20000, 20038, 20739, 21014

Sanky 20048, 20039

Sansui 20000, 20067, 20209, 20479, 21479

Sanyo 20000, 20046, 20479

Scott 20184, 20045, 20121, 20043

Sears 20060, 20035, 20162, 20037, 20048, 20039,

20033, 20045, 20000, 20042, 20067, 20043,

20209, 20046, 21237

Sharp 20048, 20032, 20000, 20807, 20848

Shintom 20039, 20000

Siemens 20037

Signature 20060, 20035, 20037, 20048, 20000, 20149,

20046, 20479

Singer 20037

Sonic Blue 20614, 20616

Sonographe 20046

Sony 20035, 20032, 20033, 20000, 20067, 20046,

20636, 21032, 21232, 21972

Soundmaster 20000

Stack 9 21972

STS 20042

SV2000 20000

SVA 20000

VCRs

Sylvania 20035, 20081, 20000, 20043, 20593, 21593,

21781

Symphonic 20000, 20593, 21593

Systemax 21972

Tagar Systems 21972

Tandy 20000

Tashiko 20037

Tatung 20048, 20081, 20000, 20067

Teac 20000, 20067

Technics 20035, 20162, 20037, 20000

Teknika 20035, 20037, 20000

Tevion 20479

Thomas 20000

Thomson 20060

Tivo 20618, 20636, 20739, 21996

TMK 20000

TNIX 20037

Toshiba 20045, 20000, 20043, 20209, 20845, 21008,

21145, 21972, 21996

Totevision 20037

Touch 21972

Trix 20037

Ultra 20045

Vector 20045

Vector Research 20184, 20038

Victor 20067

Video Concepts 20045

Videomagic 20037

Videosonic 20000

Viewsonic 21972

Villain 20000

Voodoo 21972

Wards 20060, 20035, 20037, 20048, 20081, 20033,

20045, 20000, 20042, 20043, 20038, 20149,

20046, 20479

Wharfedale 20593

White Westinghouse 20000, 20209, 20479

World 20209, 20479

XR-1000 20035, 20000

Yamaha 20038

Zenith 20037, 20039, 20033, 20000, 20209, 20479,

21479

ZT Group 21972

Video Accessories

2Wire 02045

ABS 01272

Access HD 02185

Accurian 01653

Alienware 01272

Amino 01481

AT&T 00858, 02045

Buffalo 01739

CASTi 02305

CyberPower 01272

D-Link 01554, 01731, 02186

Digital Stream 02303

Epson 01563

VCRs

NS-L42Q120-10A/NS-L46Q120-10A 42"/46" LCD TV

www.insigniaproducts.com

Maintaining

Cleaning the TV cabinet

Clean the TV cabinet with a soft, dry cloth. If

surfaces are extremely dirty, slightly dampened the

cloth with lukewarm water.

Cleaning the LCD screen

Clean the screen with a clean, soft, lint-free cloth. If

additional cleaning is necessary, apply a small

amount of non-ammonia, non-alcohol-based glass

cleaner onto the cloth, then wipe the screen.

Troubleshooting

Gateway 01272

Hewlett Packard 01272, 01267

Howard Computers 01272

HP 01272, 01267

Hush 01272

iBUYPOWER 01272

Insignia 01415

KoolConnect 01481

LG 01415

Linksys 01272, 01365

Media Center PC 01272

Microsoft 01272, 02049

Mind 01272

Motorola 00858, 01363, 01998

Netgear 02036

Niveus Media 01272

Northgate 01272

Panasonic 01120

Pioneer 01010

Ricavision 01272

Roku 01486

Samsung 01190, 01490

Scientific Atlanta 00858

Sensory Science 01126

Sharp 01010

SMC 01456

Sony 01272, 01324, 01364

Stack 9 01272

SureWest 01481

Sylvania 01563

Systemax 01272

Tagar Systems 01272

Toshiba 01272

Touch 01272

Viewsonic 01272, 01329

Vizio 01126

Voodoo 01272

VUDU 02298

Xbox 02049

Zenith 01415

ZT Group 01272

Cautions

• Make sure that your TV is turned off and the

power cord is disconnected from the power

outlet before cleaning your TV.

• Never spray or pour any liquid directly onto the

LCD screen or the TV cabinet.

• Never use a solvent or alcohol to clean your TV

and do not spray insecticide near your TV. Such

chemicals may cause damage and discoloration

to the exposed surfaces.

Video Accessories

Problem Solution

Power

No power

• Make sure the power indicator is

illuminated blue.

• Make sure the power cord is securely

connected to the power jack and is

plugged into a working power outlet.

You may want to plug in another

electrical device to the power outlet to

make sure that it is supplying the

correct voltage.

Power suddenly turns off

• Press SLEEP repeatedly to make sure

that the sleep option is turned off.

Remote control

Remote control does not work

• Press only one button at a time.

• Make sure the batteries are correctly

inserted.

• Replace batteries with two new AA

batteries.

Remote control code is not detected

by a universal remote control

• Purchase a separate learning remote

control.

•Go to

http://insigniaproducts.com/support

for a list of remote control codes.

Remote control programming

LED does not light when a button is

pressed

• Try pressing different keys.

• Replace batteries with two new AA

batteries.

LED blinks when a button is pressed

but device does not respond

• Make sure the remote is aimed at your

device and is not more than 40 feet

(12 meters) away.

LED blinks one long blink while in SET

mode

• An entry error has occurred (for

example, wrong button). Try entering

the sequence again.

Remote does not control devices or

commands are not working correctly

• Try all listed codes for the device.

• Make sure the device operates with an

infrared remote control.

No volume on a device

• Refer to “Changing volume lock” on

page 11 and make sure that the volume

is not locked to a different mode

already.

Channels do not change correctly

when directly entering digits to

change channels

• If the original remote control required

you to press ENTER to change

channels, press ENTER on this remote

after entering the channel number.


NS-L42Q120-10A/NS-L46Q120-10A 42"/46" LCD TV

www.insigniaproducts.com

Specifications

Specifications subject to change without notice.

No picture

• Make sure the video input cable is

securely connected to the correct

terminal, and that the correct input

mode is enabled. For example, when a

VGA cable is connected to display a

computer screen, the PC input mode

must be enabled.

• In TV mode, verify that the antenna is

correctly connected and that the

preferred channel is enabled in the

channel list.

• Press MENU, then select Picture to

adjust the display settings.

• If you are using a Macintosh computer

that is older than a G3 model, you need

a Macintosh adapter.

No picture or the “Unsupported

signal” or “No signal” message

appears when a VGA cable is

connected

• Make sure the VGA cable is correctly

connected to the TV’s VGA port.

• Decrease the video resolution setting

on the computer and try again.

• Press MENU, select Settings, then

select Computer Settings to adjust

the computer settings.

Picture is cut off or appears in a

sidebar screen

• Press ZOOM and make sure that the

Normal option is selected.

Poor image quality in TV mode (cutoff

picture, snowy images)

• Check your antenna connection. If

necessary, rotate the antenna and wait

up to ten seconds for a signal.

• Reduce signal splitters and excessively

long cables.

• Replace poor antenna cables or

connectors to improve signal quality.

• Press ZOOM and make sure the

Normal option is selected.

• Press MENU, select Picture, then

select Advanced Video and adjust the

Noise Reduction setting.

• In HDMI mode, make sure that the

external device is compatible with

your TV.

Wrong, abnormal, or missing colors

•If any colors (red, green or blue) are

missing, check the video cable to make

sure it is securely connected. Loose or

broken pins in the cable connector

could cause a poor connection.

• Press MENU, select Picture, then

select Settings to adjust the Color and

Tint settings. You can also select

Picture, then select Advanced Video

to adjust the Color Temperature

settings.

• Connect the TV to another computer to

see if the problem is with the

computer.

Audio

No sound

• Make sure the audio input cable is

correctly connected to the correct

terminal and that the correct input

mode is enabled.

• The volume may be muted. Press MUTE

or Vol+ button to turn on the volume.

• Press MENU, then select Audio to

adjust the Bass, Treble, and Balance

settings.

• If you are using an external audio

device, make sure volume on the

external audio device is turned on.

Password

Password has been compromised

• Change the password. See “Changing

the password” on page 28.

Problem Solution

Models

NS-L42Q120-10A/NS-L46Q120-10A

LCD panel

Panel 42- or 46-inch active matrix full

High-Definition TFT

Motion control 120 Hz MEMC (motion control, motion

enhancement) chip

Resolution 1920 x 1080 (RGB vertical stripe)

Color 42-inch: 8 bit / 16.77 million

46-inch: 10 bit /1.07 billion

Viewing angle 178° horizontal; 178° vertical

Contrast ratio 4000:1

Brightness 400 nits

Response time 6.5 ms

Physical

specifications

NS-L42Q120-10A Dimensions (W × D × H)

With stand:

41.1 × 12.22 × 29.32 in.

(1043.94 × 310.47× 744.77 mm)

Without stand:

41.1 × 4.26 × 26.72 in.

(1043.94 × 108.3 × 678.6 mm)

Weight

With stand: 46.3lb (21.0kg)

Without stand: 39.6lb (17.97kg)

NS-L46Q120-10A Dimensions (W × D × H)

With stand:

44.29 × 12.22 × 30.87in.

(1125 × 310.47× 784 mm)

Without stand:

44.29 × 4.13 × 28.48 in.

(1125 × 105 × 723.41 mm)

Weight

With stand: 54.3lb (24.6kg)

Without stand: 47.6lb (21.6kg)

Standard NTSC and ATSC

Tuning system Electronic tuning system

Frequency range VHF and UHF

CATV 135 channel, QAM channels

Compatibility 480i, 480p, 720p, 1080i, 1080p

Power

Input voltage 120 VAC, 60 Hz, 3A

Consumption 42": 207w 115V

46": 244w 115V

Off: <1 W

Speaker output

10 W (two channels)

Terminals

AV 1 and 2 inputs Video, audio L/R

S-Video1 and 2 inputs S-Video, audio L/R

Component 1 and 2

inputs

Y, PB, Pr, audio L/R

HDMI 1, 2, 3, and 4 HDMI IN

VGA VGA input, audio (mini jack)

Audio Audio output, L/R (analog) SPDIF

output (digital)

Antenna F type

Image processor

Broadcom Xilleon™ X243

NS-L42Q120-10A/NS-L46Q120-10A 42"/46" LCD TV

www.insigniaproducts.com

Legal notices

FCC Part 15

This device complies with Part 15 of the FCC Rules. Operation of

this product is subject to the following two conditions: (1) this

device may not cause harmful interference, and (2) this device

must accept any interference received, including interference

that may cause undesired operation.

This equipment has been tested and found to comply within the

limits for a class B digital device, pursuant to Part 15 of the FCC

Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential

installation. This equipment generates, uses, and can radiate

radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful

interference to radio communications. However, there is no

guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to

radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try

to correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and

receiver.

• Connect the equipment into an outlet on a circuit different

from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician

for help.

FCC warning

Changes or modifications not expressly approved by the party

responsible for compliance with the FCC Rules could void the

user’s authority to operate this equipment.

DHHS and FDA safety certification

This product is made and tested to meet safety standards of the

FCC, requirements and compliance with safety performance of

the U.S. Department of Health and Human Services, and also

with FDA Radiation Performance Standards 21 CFR Subchapter J.

Canada ICES-003 statement

This Class B digital apparatus complies with Canadian ICES-003.

Standard Television Receiving Apparatus — Appareil de

réception télévision ordinaire, Canada BETS-7 / NTMR-7

RSS 310 statement

To reduce potential radio interference to other users, the

antenna type and its gain should be so chosen that the

equivalent isotropically radiated power (e.i.r.p.) is not more than

that permitted for successful communication.

Operating

conditions

Tem per at ur e 15 to 35°C (humidity < 75%)

Humidity 20 to 90% non-condensing

(Ta < 35%)

Atmospheric pressure 0 to 2,000 m

Package contents

• Remote control

• Remote control holder

• Batteries AA (2)

•AC power cord

•TV stand

•TV base cover

•Screws for TV stand

• Component video cable

•Audio cable

•Cleaning cloth

NS-L42Q120-10A/NS-L46Q120-10A 42"/46" LCD TV

www.insigniaproducts.com

NS-L42Q120-10A/NS-L46Q120-10A 42"/46" LCD TV

www.insigniaproducts.com

NS-L42Q120-10A/NS-L46Q120-10A 42"/46" LCD TV

www.insigniaproducts.com

Two-year limited warranty

Insignia Products (“Insignia”) warrants to you, the original

purchaser of this new product (“Product”), that the Product shall

be free of defects in the original manufacture of the material or

workmanship for a period of two (2) years from the date of your

purchase of the Product (“Warranty Period”). This Product must

be purchased from an authorized dealer of Insignia brand

products and packaged with this warranty statement. This

warranty does not cover refurbished Product. If you notify

Insignia during the Warranty Period of a defect covered by this

warranty that requires service, terms of this warranty apply.

How long does the coverage last?

The Warranty Period lasts for 2 years (730 days) from the date

you purchased the Product. The purchase date is printed on the

receipt you received with the Product.

What does this warranty cover?

During the Warranty Period, if the original manufacture of the

material or workmanship of the Product is determined to be

defective by an authorized Insignia repair center or store

personnel, Insignia will (at its sole option): (1) repair the Product

with new or rebuilt parts; or (2) replace the Product at no charge

with new or rebuilt comparable products or parts. Products and

parts replaced under this warranty become the property of

Insignia and are not returned to you. If service of Products or

parts are required after the Warranty Period expires, you must

pay all labor and parts charges. This warranty lasts as long as you

own your Insignia Product during the Warranty Period. Warranty

coverage terminates if you sell or otherwise transfer the Product.

How to obtain warranty service?

If you purchased the Product at a retail store location, take your

original receipt and the Product to the store you purchased it

from. Make sure that you place the Product in its original

packaging or packaging that provides the same amount of

protection as the original packaging. If you purchased the

Product from an online web site, mail your original receipt and

the Product to the address listed on the web site. Make sure that

you put the Product in its original packaging or packaging that

provides the same amount of protection as the original

packaging.

To obtain in-home warranty service for a television with a screen

30 inches or larger, call 1-888-BESTBUY. Call agents will diagnose

and correct the issue over the phone or will have an

Insignia-approved repair person dispatched to your home.

Should the Insignia-approved repair person not correct the issue

on the first call, an Insignia television (size and features to be

determined by Insignia) will be loaned to you until your TV is

repaired and returned, at no charge to you. This feature is only

available to Insignia television consumers residing in the United

States.

Where is the warranty valid?

This warranty is valid only to the original purchaser of the

product in the United States, Canada, and Mexico.

What does the warranty not cover?

This warranty does not cover:

• Customer instruction

•Installation

•Set up adjustments

•Cosmetic damage

• Damage due to acts of God, such as lightning strikes

•Accident

•Misuse

•Abuse

•Negligence

•Commercial use

• Modification of any part of the Product, including the

antenna

• Plasma display panel damaged by static (non-moving)

images applied for lengthy periods (burn-in).

This warranty also does not cover:

• Damage due to incorrect operation or maintenance

• Connection to an incorrect voltage supply

• Attempted repair by anyone other than a facility

authorized by Insignia to service the Product

• Products sold as is or with all faults

• Consumables, such as fuses or batteries

• Products where the factory applied serial number has been

altered or removed

REPAIR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS

YOUR EXCLUSIVE REMEDY. INSIGNIA SHALL NOT BE LIABLE FOR

ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES FOR THE

BREACH OF ANY EXPRESS OR IMPLIED WARRANTY ON THIS

PRODUCT, INCLUDING, BUT NOT LIMITED TO, LOST DATA, LOSS

OF USE OF YOUR PRODUCT, LOST BUSINESS OR LOST PROFITS.

INSIGNIA PRODUCTS MAKES NO OTHER EXPRESS WARRANTIES

WITH RESPECT TO THE PRODUCT, ALL EXPRESS AND IMPLIED

WARRANTIES FOR THE PRODUCT, INCLUDING, BUT NOT LIMITED

TO, ANY IMPLIED WARRANTIES OF AND CONDITIONS OF

MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE,

ARE LIMITED IN DURATION TO THE WARRANTY PERIOD SET

FORTH ABOVE AND NO WARRANTIES, WHETHER EXPRESS OR

IMPLIED, WILL APPLY AFTER THE WARRANTY PERIOD. SOME

STATES, PROVINCES AND JURISDICTIONS DO NOT ALLOW

LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS, SO

THE ABOVE LIMITATION MAY NOT APPLY TO YOU. THIS

WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY

ALSO HAVE OTHER RIGHTS, WHICH VARY FROM STATE TO STATE

OR PROVINCE TO PROVINCE.

Contact Insignia:

For customer service please call 1-877-467-4289

www.insignia-products.com

Distributed by Best Buy Purchasing, LLC

7601 Penn Avenue South, Richfield, Minnesota, U.S.A.

55423-3645

Enterprise Services, Inc. Registered in some countries. All other

products and brand names are trademarks of their respective

owners.

www.insigniaproducts.com (877) 467-4289

Distributed by Best Buy Purchasing, LLC

7601 Penn Avenue South, Richfield, MN USA 55423-3645

All other products and brand names are trademarks of their respective owners.

ENGLISH

09-0619

Insignia NS-L46Q120-10A TV

Product's Documents

User Manual

Specifications

Insignia NS-L46Q120-10A Questions and Answers

Related Products

Insignia NS-27HTV Remote Control for Insignia TV NS-20FTV, NS-24FTV, NS-27FTV, NS-27HTV, NS-30HTV, NS-27RTV

Insignia TV Stand for Most Flat-Panel TVs up to 40" - Carbon Ash NS-HWD1636

Insignia TV Stand for Most Flat-Panel TVs Up to 60" - NS-HWMG1754M-C NS-HWMG1754M | NS-HWMG1754M-C

Insignia TV Stand for Most TVs Up to 65" - Black NS-HMG1856

Insignia TV Stand for Most TVs up to 60" - Espresso NS-HWG1655E | NS-HWG1655E-C

Insignia TV NS-RTV32 Remote control
