BN68-25134A-00
1
1
2
3
Unpacking and Installation Guide
Guide de déballage et d’installation
Guía de desembalaje e instalación
Manual de desempacotamento e instalação
Auspacken und Installationsanleitung
Guida al disimballaggio e all’installazione
Руководство по распаковке и установке
Қаптамадан шығару және орнату нұсқаулығы
Посібник з розпаковки та встановлення
Qadoqdan chiqarish va o‘rnatish qo‘llanmasi
85″
55″
85″55″- 75″
55″- 65″
65″- 75″
75″
75″
3
4 5
55M8*H
55MH8*
48.2 inches
(1224.6 mm)
(1224,6 мм)
(122.46 cm)
27.9 inches
(707.8 mm)
(707,8 мм)
(70.78 cm)
3.0 inches
(76.6 mm)
(76,6 мм)
(7.66 cm)
29.9 inches
(760.0 mm)
(760,0 мм)
(76.00 cm)
7.8 inches
(199.0 mm)
(199,0 мм)
(19.90 cm)
54.6 inches
(138 cm)
(138 см)
22.0 lbs
(10.0 kg)
(10,0 кг)
22.7 lbs
(10.3 kg)
(10,3 кг)
65M8*H
65MH8*
56.9 inches
(1444.1 mm)
(1444,1 мм)
(144.41 cm)
32.7 inches
(831.2 mm)
(831,2 мм)
(83.12 cm)
3.0 inches
(76.8 mm)
(76,8 мм)
(7.68 cm)
34.7 inches
(882.2 mm)
(882,2 мм)
(88.22 cm)
8.7 inches
(222.0 mm)
(222,0 мм)
(22.20 cm)
64.5 inches
(163 cm)
(163 см)
30.9 lbs
(14.0 kg)
(14,0 кг)
31.5 lbs
(14.3 kg)
(14,3 кг)
75M8*H
75MH8*
65.7 inches
(1668.1 mm)
(1668,1 мм)
(166.81 cm)
37.7 inches
(957.8 mm)
(957,8 мм)
(95.78 cm)
3.0 inches
(77.0 mm)
(77,0 мм)
(7.70 cm)
39.7 inches
(1007.9 mm)
(1007,9 мм)
(100.79 cm)
11.0 inches
(280.0 mm)
(280,0 мм)
(28.00 cm)
74.5 inches
(189 cm)
(189 см)
48.7 lbs
(22.1 kg)
(22,1 кг)
49.6 lbs
(22.5 kg)
(22,5 кг)
85M8*H
85MH8*
74.4 inches
(1889.9 mm)
(1889,9 мм)
(188.99 cm)
42.7 inches
(1083.5 mm)
(1083,5 мм)
(108.35 cm)
3.0 inches
(77.0 mm)
(77,0 мм)
(7.70 cm)
44.6 inches
(1132.8 mm)
(1132,8 мм)
(113.28 cm)
12.8 inches
(326.0 mm)
(326,0 мм)
(32.60 cm)
84.5 inches
(214 cm)
(214 см)
62.8 lbs
(28.5 kg)
(28,5 кг)
63.9 lbs
(29.0 kg)
(29,0 кг)
* : 0~9, A~Z
VESA
x (mm)
VESA
x (мм)
(mm)
(мм)
x 4
55M8*H
55MH8*
200 x 200
23-25 M8
65M8*H
65MH8*
200 x 200
23-25 M8
75M8*H
75MH8*
400 x 300
10-12 M8
85M8*H
85MH8*
400 x 300
10-12 M8
* : 0~9, A~Z
